Samsung NF108 User guide

User Guide

SAMSUNG NF108/NF208/NF308

Contents

Chapter 1. Getting Started

Cautions Regarding OS Support 6
Before You Start 7
Safety Precautions 9
Proper Posture During Computer Use 23
Important Safety Information 26
Replacement Parts and Accessories 28
Regulatory Compliance Statements 30
WEEE SYMBOL INFORMATION 44
Basic Items 45
Overview 46

Front View 46
Status Indicators 47
Right View 48
Left View 49
Bottom View 50

Chapter 3. Settings and

Upgrade

LCD Brightness Control 66
BIOS Setup 67

Entering the BIOS Setup 67
The BIOS Setup Screen 68

Setting a Boot Password 70
Changing the Boot Priority 72
Upgrading Memory 73
Battery 75

Installing/Removing the Battery 75
Charging the Battery 76
Measuring

the Remaining Battery Charge 77
Extending the Battery Usage Time 77

Using the Security Lock Port 79

Turn on the computer 51

Attaching the Battery 51
Connect the AC adapter 51
Turn on the computer 52

Using Sleep Mode 53

Chapter 2. Using the computer

Keyboard 56
Touchpad 59
CD Drive (ODD, Optional) 60

Connecting the CD Drive 60
Inserting and Ejecting a CD 61

Multi Card Slot (Optional) 62
Adjusting the Volume 64

Chapter 4. Appendix

Product Specications 82

Chapter 1.

Getting Started

Contents 3

Cautions Regarding OS Support 6

Before You Start 7

Safety Precautions 9

Proper Posture During Computer Use 23

Important Safety Information 26

Replacement Parts and Accessories 28

Regulatory Compliance Statements 30

WEEE SYMBOL INFORMATION 44

Basic Items 45

Overview 46

Front View 46
Status Indicators 47
Right View 48
Left View 49
Bottom View 50

Turn on the computer 51

Attaching the Battery 51
Connect the AC adapter 51
Turn on the computer 52

Using Sleep Mode 53

Cautions Regarding OS Support

z Windows is neither installed nor supplied with this computer.
x Therefore, customers should purchase a Windows XP or Windows 7/Vista software license

and install the software. Do not install an illegal copy or a copy that has already been
installed on another PC.

c For the installation procedures and any issues with the operating systems or applications

not supplied by Samsung Computer, contact the corresponding software company.

v The company will not provide a replacement or refund due to the reason x, c and if our

service engineer visits you due to this problem, a service charge will be applied.

Charge the battery fully when using the computer for the rst time.

Before You Start

Before reading the User Guide, rst check the following information.

Safety Precaution Notations

Icon Notation Description

Warning

Caution

Failing to follow instructions marked with this symbol, may

cause personal injury and or fatality.

Failing to follow instructions marked with this symbol, may

cause slight injury to yourself or damage your property.

Text Notations

Icon Notation Description

Before You Start

Caution

Note

Content included in this section includes information
required before using a function.

Content included in this section includes information
required about the function.

Content included in this section includes helpful information
to use the function.

Copyright

©

Samsung Electronics Co., Ltd. 2010

Samsung Electronics Co., Ltd. owns the copyright of this manual.
No part of this manual may be reproduced or transmitted in any form or by any means,

electronic or mechanical, without the consent of Samsung Electronics Co., Ltd.
The information in this document is subject to change without notice due to improving the

performance of the product.

Samsung Electronics shall not be liable for any data loss. Please take care to avoid losing any
important data and backup your data to prevent any such data loss.

About the Product Capacity Representation Standard

About HDD Capacity Representation

The capacity of the storage device (HDD, SSD) of the manufacturer is calculated assuming that
1KB=1,000 Bytes.

However, the operating system (Windows) calculates the storage device capacity assuming
that 1KB=1,024 Bytes, and therefore the capacity representation of the HDD in Windows is
smaller than the actual capacity due to the difference in capacity calculation.

(E.g. For a 80GB HDD, Windows represents the capacity as 74.5GB, 80x1,000x1,000x1,000
byte/(1,024x1,024x1,024)byte = 74.505GB)

In addition, the capacity representation in Windows may be even smaller because some
programs such as Recovery Solution may reside in a hidden area of the HDD.

About Memory Capacity Representation

The memory capacity reported in Windows is less than the actual capacity of memory.
This is because BIOS or a video adapter uses a portion of memory or claims it for further use.
(E.g. For 1GB(=1,024MB) memory installed, Windows may report the capacity as 1,022MB or

less)

Safety Precautions

For your security and to prevent damage, please read the following safety instructions
carefully.
Since this is commonly applied to Samsung Computers, some pictures may differ from
actual products.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

Installation Related

Do not install the product in
places exposed to humidity
such as a bathrooms.

There is a danger of electric

shock. Use the product within

the operating conditions

specied in the Manufacturers

User Guide.

Keep the plastic bags out of
the reach of children.

There is a danger of
suffocation.

Keep a distance of 15cm or
more between the computer
and the wall and do not place
any objects between them.

This may increase the internal
temperature of the computer
and may cause an injury.

Do not install the computer
on a slant or a place prone to
vibrations, or avoid using the
computer in that location for
a long time.

This increases the risk that a

malfunction or damage to the
product will occur.

Avoid exposing any part of
your body to the heat from
the computer vent or AC
adapter for a long time when
the computer is on.

Exposing a part of your body
close to the heat from the vent
or AC adapter for long periods
of time may cause a burn.

Avoid blocking the vent at
the bottom or side of the
computer when using it on a
bed or cushion.

If the vent is blocked, there

is a danger of damaging the
computer or overheating the
inside of the computer.

NP Ver 2.4

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

Power Related

The power plug and wall outlet gures may differ depending on the country specications

and the product model.

Do not touch the main plug
or power cord with wet
hands.

There is a danger of electric

shock.

Do not exceed the standard
capacity (voltage/current)
of a multiplug or power
outlet extension when
using it for the product.

There is a danger of electric

shock or re hazard.

If the power cord or power
outlet makes a noise,
disconnect the power cord
from the wall outlet and
contact a service center.

There is a danger of electric

shock or re hazard.

Do not use a damaged or
loose main plug or power
cord or power outlet.

There is a danger of electric

shock or re hazard.

Plug the power cord rmly

into the power outlet and
AC adapter.

Failing to do so may cause

re hazard.

Do not unplug the power
cord out by pulling the
cable only.

If the cord is damaged, it

may cause electric shock.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

Power Related

Do not bend the power cord
excessively or do not place
a heavy object over the
power cord. It is especially
important to keep the
power cord out of reach of
infants and pets.

If the cord is damaged, it

may cause electric shock
or re.

If water or another
substance enters the
power input jack, AC
adapter or the computer,
disconnect the power cord
and contact the service
center.

Damage to the device within
the computer may cause

electric shock or re hazard.

Connect the power cord to
an outlet or multiple power
plug (extended cable) with
a ground terminal.

Failing to do so may result

in electric shock.

Keep the power cord or
outlet clean so that they are
not covered with dust.

Failing to do so may result

in re.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

AC Adapter Usage Precautions

Connect the power cord to

the AC adapter rmly.

Otherwise, there is a

danger of re due to an

incomplete contact.

Use only the AC adapter
supplied with the product.

Using another adapter may

cause the screen to icker.

Do not place heavy objects
or step onto the power
cord or AC adapter to avoid
damaging the power cord
or AC adapter.

If the cord is damaged,
there is a danger of electric

shock or re.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

Battery Usage Related

Keep the battery out of
the reach of infants and
pets, as they could put the
battery into their mouths.

There is a danger of electric

shock or choking.

Authorized

Parts

Use an authorized battery
and AC adapter only.

Please use an authorized

battery and adapter
approved by Samsung
Electronics.

Unauthorized batteries and

adapters may not meet the
proper safety requirements
and may cause problems or
malfunctions and result in an

explosion or re.

Do not use the computer in
a badly ventilated location
such as on bedding, on a
pillow or cushion, etc, and
do not use it in a location

such as room with oor

heating as it may cause the
computer to overheat.

Take care that the computer

vents (on the side or the

bottom) are not blocked

especially in these
environments. If the vents

are blocked, the computer

may overheat and it may
cause a computer problem,
or even explosion.

Do not use the computer in
a humid location such as a
bathroom or sauna.

Please use the computer
within the recommended
temperature and humidity
range (10~32ºC, 20~80%
RH).

Power Off

Do not close the LCD panel
and put the computer into
your bag to move it when it
is still turned on.

If you put the computer into
your bag without turning
it off, the computer may
overheat and there is a

danger of re. Shut the

computer down properly
before moving it.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

Never heat the battery
or put the battery into a

re. Do not put or use the

battery in a hot location
such as a sauna, inside
a vehicle exposed to the
heat, and so on.

There is a danger of an

explosion or re.

If liquid leaks out of the
battery or there is a funny
smell coming from the
battery, remove the battery
from the computer and
contact a service center.

There is a danger of an

explosion or re.

Usage Related

Disconnect all cables
connected to the
computer before cleaning
it. If you are cleaning
a notebook computer,
remove the battery.

There is a danger of

electric shock or damage to

the product.

Take care not to allow
metal objects such as a key
or clip to touch the battery
terminal (metal parts).

If a metal object touches
the battery terminals, it may
cause excessive current

ow and it may damage the
battery, or result in a re.

To use the computer safely,
replace a dead battery with
a new, authorized battery.

Please charge the
battery fully before
using the computer

for the rst time.

Do not connect a phone
line connected to a digital
phone to the modem.

There is a danger of a

electric shock, re or

damage to the product.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

Do not place any container

lled with water or

chemicals over or near the
computer.

If water or chemicals enter
the computer, this may

cause re or electric shock.

Avoid direct sunlight when
the computer is in an
air-tight location such as
inside a vehicle.

There is a danger of a re
hazard. The computer may

overheat and also present
opportunity to thieves.

Upgrade Related

Never disassemble the
power supply or AC
adapter.

There is a danger of

electric shock.

If the computer is broken
or dropped, disconnect the
power cord and contact a
service center for a safety
check.

Using a broken computer
may cause electric shock or
re hazard.

Do not use your notebook
PC for long periods of time
while a part of your body
is making direct contact
with it. The temperature of
the product may increase
during normal operation.

This may result in harming

or burning your skin.

When removing the RTC
(Real Time Clock) battery,
keep it out of the reach
of children as they could
touch and/or swallow it.

There is a danger of

choking. If a child has

swallowed it, contact a
doctor immediately.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

Use only authorized
parts (multiplug, battery
and memory) and never
disassemble parts.

There is a danger of
damaging the product,

electric shock or re
hazard.

Custody and Movement Related

Follow the instructions
for the relevant location
(e.g. airplane, hospital,
etc.) when using a wireless
communication device
(wireless LAN, Bluetooth,
etc.).

When carrying the
notebook computer with
other items, such as the
adapter, mouse, books
etc, take care not to press
anything against the
notebook computer.

If a heavy object is pressed

against the notebook

computer, a white spot or
stain may appear on the

LCD. Therefore, take care

not to apply any pressure to

the notebook.

Shut down the computer
and disconnect all cables
before disassembling
the computer. If there is
a modem, disconnect
the phone line. If you are
disassembling a notebook
computer, make sure to
remove the battery.

Failing to do so, may cause

electric shock.

Avoid exposing a drive to

magnetic elds. Security

devices with magnetic

elds include airport

walk-through devices and
security wands.

The airport security
devices that check carry­on luggage, such as
conveyor belts, use x-rays
instead of magnetism and
will not damage a drive.

In this case, place the

notebook computer in a

separate compartment away
from the other objects.

Caution

Failing to follow instructions marked with this symbol may cause slight injury or damage to the product.

Installation Related

Do not block the ports
(holes), vents, etc. of the
product and do not insert
objects.

Damage to a component
within the computer may

cause electric shock or re.

When using the computer
with it lying on its side,
place it so that the vents
face upwards.

Failing to do so, may cause
the internal temperature of
the computer to rise and
the computer to malfunction
or halt.

Battery Usage Related

Dispose of worn-out
batteries properly.

There is a danger of re



or explosion.

The battery disposal



method may differ
depending on your
country and region.
Dispose of the used
battery in an appropriate
way.

Do not throw or
disassemble the battery
and do not put it into water.

This may cause an injury,

re or explosion.

Avoid contact with metal
objects such as car keys
or clips when keeping or
carrying a battery.

Contact with a metal may
cause excessive current
and a high temperature and
may damage the battery or

cause a re.

Charge the battery
according to the
instructions in the manual.

Failing to do so, may cause

an explosion or re from

damage to the product.

Do not place a heavy
object over the product.

This may cause a problem
with the computer. In
addition, the object may
fall and cause injury, or
damage the computer.

Use only a battery
authorized by Samsung
Electronics.

Failing to do so may cause
an explosion.

Do not heat the battery
or expose it to heat (e.g.
inside a vehicle during the
summer).

There is a danger of

explosion or re.

Caution

Failing to follow instructions marked with this symbol may cause slight injury or damage to the product.

Usage Related

Do not place a candle, light
cigar, etc. over or on the
product.

There is a danger of re.

Use a wall outlet or multi­plug with a grounding part.

Failing to do so may cause

electric shock hazard.

Make sure to have the
product tested by a safety
service engineer after
repairing the product.

Authorized Samsung Repair

Centers will carry out safety

checks after a repair. Using

a repaired product without
testing it for safety may

cause an electric shock or
re.

Do not use your computer
and AC Adapter on your lap
or soft surfaces.

If the computer temperature
increases, there is a danger
of burning yourself.

Connect only permitted
devices to the connectors
or ports of the computer.

Failing to do so, may cause

electric shock and re.

Close the LCD panel
only after checking if the
notebook computer is
turned off.

The temperature may
rise and it may cause
overheating and deformation
of the product.

Do not touch the antenna
with electricity facility such
as the power outlet.

There is a danger of electric

shock.

When handling computer
parts, follow the
instructions on the manual
supplied with the parts.

Failing to do so, may cause
damage to the product.

If the computer emits
smoke, or there is a burning
smell, disconnect the
power plug from the wall
outlet and contact a service
center. If your computer is
a notebook computer, make
sure to remove the battery.

There is a danger of re.

In case of lightning,
immediately turn the
system off, disconnect
the power cord from the
wall outlet and phone line
from modem. Do not use a
modem or phone.

There is a danger of electric

shock or re.

Do not press the Eject
Button while the Floppy
Disk/CD-ROM drive is in
operation.

You might lose data and

the disk might be suddenly

ejected and could cause an
injury.

Take care not to drop the
product while using it.

This may cause personal
injury or loss of data.

Do not use a damaged or

modied CD/Floppy Disk.

There is a danger of
damaging the product or
personal injury.

Do not insert your ngers

into the PC Card Slot.

There is a danger of injury or

electric shock.

Caution

Failing to follow instructions marked with this symbol may cause slight injury or damage to the product.

Use recommended
computer cleansing
solution when cleaning
the product and only use
the computer when it is
completely dried.

Failing to do so may cause

electric shock or re.

Emergency disk eject
method using paperclip
should not be used while
the disk is in motion. Make
sure to use the emergency
disk eject method only
when the Optical Disk
Drive is stopped.

There is a danger of injury.

Do not place your face
close to the Optical Disk
Drive tray when it is
operating.

There is a danger of injury
due to an abrupt ejection.

Upgrade Related

Take care when touching
the product or parts.

The device may be
damaged or you may be
injured.

Take care not to throw or
drop a computer part or
device.

This may cause injury or
damage to the product.

Make sure to close the
computer cover before
connecting the power after
a reassembly.

There is a danger of electric

shock if your body touches

an internal part.

Use parts authorized by
Samsung Electronics only.

Failing to do so, may cause

re or damage the product.

To connect a device that
is not manufactured or
authorized by Samsung
Electronics, enquire at
your service center before
connecting the device.

There is a danger of
damaging the product.

Check CDs for cracks and
damage prior to use.

It may damage the disc and
cause disorder of device
and injury of user.

Never disassemble or
repair the product by
yourself.

There is a danger of electric

shock or re.

Caution

Failing to follow instructions marked with this symbol may cause slight injury or damage to the product.

Custody and
Movement Related

When moving the product,
turn the power off and
separate all connected

cables rst.

The product might be
damaged or users may trip
over the cables.

For long periods of not
using the notebook
computer, discharge the
battery and preserve as it
is detached.

The battery will be
preserved at its best
condition.

Do not operate or watch
the computer while driving
a vehicle.

There is a danger of a

trafc accident. Please

concentrate on driving.

Cautions on Preventing Data Loss
(Hard Disk Management)

Take care not to damage the data on a hard disk drive.

 A hard disk drive is so sensitive to external impact

that an external impact may cause loss of data on the

surface of the disk.

 Take extra care, because moving the computer or

an impact on the computer when it is turned on may

damage the data of the hard disk drive.

 The company is not liable for any loss of any data

caused by a customer’s careless usage or bad
environmental conditions.

Causes that may damage the data of a hard disk drive and
the hard disk drive itself.

 The data may be lost when an external impact is applied

to the disk while disassembling or assembling the

computer.

 The data may be lost when the computer is turned off

or reset by a power failure while the hard disk drive is

operating.

 The data may be lost and irrecoverable due to a

computer virus infection.

 The data may be lost if the power is turned off while

running a program.

 Moving or causing an impact to the computer while

the hard disk drive is operating, may cause les to be
corrupted or bad sectors on the hard disk.

To prevent data loss due to damage to the hard disk drive,
please backup your data frequently.

Caution

Failing to follow instructions marked with this symbol may cause slight injury or damage to the product.

Using the power supply in an airplane

Since the power outlet type differs depending on the type of airplane, connect the power
appropriately.

When using the AC power plug

Connect the power plug pins perpendicular into the center of the power outlet.

 If the plug pins are not inserted into the center of the holes, the plug pins are only inserted up

to half their length. In this case, reconnect the power plug.

 You have to insert the power plug into the outlet when the power indicator (LED) of the power

outlet is lit green. If the power is connected properly, the power indicator (LED) remains green.

Otherwise, the power indicator (LED) is turned off. In this case, unplug the power, check if the

power indicator (LED) is green, and then reconnect the power plug.

Power Indicator (LED)

Center
Holes

220V Power Plug 110V Power Plug

Good Example

Wrong Example

Caution

Failing to follow instructions marked with this symbol may cause slight injury or damage to the product.

When using the auto adapter

When the cigar socket is provided, you have to use the auto adapter (optional). Insert the cigar
plug of the auto adapter into the cigar socket and connect the DC plug of the auto adapter to the

power input port of the computer.

Auto Adapter

In- ight Cigar SocketCigar PlugDC Plug

When using the Airplane Charging Converter

Depending on the airplane, you have to use the auto adapter and charging converter. Connect the
airplane charging converter (optional) to the auto adapter (optional) and then insert the airplane

power input jack into the power outlet.

Charging
Converter

Connect the airplane power

input jack to the power

outlet of the airplane.

2

Connect this end to

1

the auto adapter.

Proper Posture During Computer Use

Maintaining a proper posture during computer use is very important to prevent physical
harm.

The following instructions are about maintaining a proper posture during computer use
developed through human engineering. Please read and follow them carefully when using
the computer.

Otherwise, the probability of (RSI: Repetitive Strain Injury) from repeated operations may
increase and serious physical harm may be caused.

The instructions in this manual have been prepared so that they can be applied
within the coverage of general users. If the user is not included in the coverage, the
recommendation is to be applied according to the user’s needs.

Proper Posture

Adjust the heights of desks and chairs
appropriate to your height.

The heights are to be adjusted so that your
arm forms a right angle when you place your

hand over the keyboard while sitting down on

a chair.
Adjust the height of chair so that your heel is

comfortably placed on the oor.

 Do not use the computer while you are

lying down, but only while you are sitting
down..

 Do not use the computer on your lap.

If the computer temperature increases,
there is a danger of burning yourself.

 Work while keeping your wrist straight.

 To use the computer while talking over

the telephone, use a headset. Using
the computer with the phone on your
shoulder is bad for posture.

 Keep frequently used items within a

comfortable work range (where you can

reach them with your hands).

 Use a chair with a comfortable back.

 Keep the center of your leg weight not on

the chair but on your feet when you are
sitting on a chair.

Eye Position

Hand Position

Keep the monitor or LCD away from your
eyes by at least 50cm.

50cm

 Adjust the height of the monitor and the

LCD screen so that its top height is equal
to or lower than your eyes.

 Avoid setting the monitor and LCD

excessively bright.

 Keep the monitor and LCD screen clean.

Keep your arm at a right angle as shown by

the gure.

 Keep the line from your elbow to your

hand straight.

 Do not place your palm over the keyboard

while typing.

 Do not hold the mouse with excessive

force

 If you wear glasses, clean them before

using the computer.

 When entering contents printed on a

paper into the computer, use a static
paper holder so that the height of the
paper is almost equal to that of the
monitor.

 Do not press the keyboard, touchpad or

mouse with excessive force.

 It is recommended connecting an

external keyboard and mouse when using

the computer for long periods of time.

Volume Control (Headphones and
Speakers)

Check your volume rst to listen to music.

Check your

volume!!

 Check if the volume is too loud before

using headphones.

Use Time (Break Time)

 Take a break for 10 minutes or more after

a 50-minute period when working for

more than one hour.

Illumination

 Do not use the computer in dark

locations. The illumination level for
computer use must be as bright so for

reading a book.

 Indirect illumination is recommended.

Use a curtain to prevent reection on the

LCD screen.

 It is not recommended using headphones

for long periods of time.

 Any deviation from the equalizer default

setting could cause hearing impairment.

 The default setting can be changed

through software and driver updates

without your intervention. Please check
the equalizer default setting before rst

usage.

Operation Condition

 Do not use the computer in hot and

humid locations.

 Use the computer within the allowed

temperature and humidity range specied

in the User Guide.

Important Safety Information

Safety Instructions

Openings in the computer case are

Your system is designed and tested to meet
the latest standards for safety of information
technology equipment. However, to ensure
safe use of this product, it is important that

the safety instructions marked on the product

and in the documentation are followed.

Always follow these instructions to
help guard against personal injury
and damage to your system.

Setting Up your System

Read and follow all instructions marked



on the product and in the documentation
before you operate your system. Retain
all safety and operating instructions for
future use.

Do not use this product near water or a



heat source such as a radiator.



provided for ventilation. Do not block
or cover these openings. Make sure

you provide adequate space, at least 6
inches (15 cm), around the system for

ventilation when you set up your work
area. Never insert objects of any kind into

the computer ventilation openings.

Ensure that the fan vents on the bottom



of the casing are clear at all times. Do
not place the computer on a soft surface,

doing so will block the bottom vents.

If you use an extension cord with this



system, make sure that the total power

rating on the products plugged into the
extension cord does not exceed the
extension cord power rating.

 For Notebooks with glossy display bezels

the user should consider the placement

of the Notebook as the bezel may cause
disturbing reections from surrounding

light and bright surfaces.

Set up the system on a stable work



surface.

The product should be operated only with



the type of power source indicated on the
rating label.

Ensure that the electrical outlet you are



using to power your equipment is easily

accessible in case of re or short circuit.

If your computer has a voltage selector



switch, make sure that the switch is in the

proper position for your area.

Care During Use

Do not walk on the power cord or allow



anything to rest on it.

Do not spill anything on the system. The



best way to avoid spills is to not eat or

drink near your system.

Some products have a replaceable



CMOS battery on the system board.
There is a danger of explosion if the
CMOS battery is replaced incorrectly.
Replace the battery with the same or
equivalent type recommended by the
manufacturer.
Dispose of batteries according to the
manufacturers instructions. If the CMOS
battery requires replacement insure that

a qualied technician performs the task.

When the computer is turned off, a small



amount of electrical current still ows

through the computer.

To avoid electrical shock, always unplug

all power cables, remove the battery
and modem cables from the wall outlets
before cleaning the system.

Unplug the system from the wall outlet



and refer servicing to qualied personnel

if:

The Instruction On Safety Operation
of NotePC

When installing and operating devices

z

please refer to safety requirements in the
user guide.

Devices can be used only with the

x

equipment specied in the technical
specications of the devices.

If any smell of burning or smoke from the

c

computer the unit should be switched off
and battery removed. The unit should be

checked by a qualied technician before

reuse.

Service and repair of devices should be

v

carried out by authorized service centers.

Do not allow your portable computer to

b

operate with the base resting directly

on exposed skin for extended periods

of time. The surface temperature of the
base will rise during normal operation
(particularly when AC Power is present).
Allowing sustained contact with exposed

skin can cause discomfort or eventually

a burn.

– The power cord or plug is damaged.
– Liquid has been spilled into the system.
– The system does not operate properly

when the operating instructions are
followed.

– The system was dropped or the casing

is damaged.

– The system performance changes.

Replacement Parts and Accessories

Use only replacement parts and accessories recommended by manufacturer.

To reduce the risk of re, use only No. 26 AWG or larger telecommunications line cord.

Do not use this product in areas classied as hazardous. Such areas include patient

care areas of medical and dental facilities, oxygen rich environments, or industrial
areas.

Battery Disposal

Do not put rechargeable batteries
or products powered by non­removable rechargeable batteries
in the garbage.

Contact the Samsung Helpline for information
on how to dispose of batteries that you
cannot use or recharge any longer.

Follow all local regulations when disposing of
old batteries.

THERE IS A RISK OF
EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT
TYPE.

DISPOSE OF USED BATTERIES
ACCORDING TO THE
INSTRUCTIONS.

Laser Safety

All systems equipped with CD or DVD drives
comply with the appropriate safety standards,
including IEC 60825-1. The laser devices in

these components are classied as “Class

1 Laser Products” under a US Department
of Health and Human Services (DHHS)
Radiation Performance Standard. Should
the unit ever need servicing, contact an

authorized service location.



Laser Safety Note:

Use of controls or adjustments

or performance of procedures

other than those specied

in this manual may result in

hazardous radiation exposure.

To prevent exposure to laser
beams, do not try to open the
enclosure of a CD or DVD drive.

 Class 1M laser radiation when

operating part is open.

Do not view directly with optical

instruments.

 Class 3B invisible laser

radiation when open.

Avoid exposure to the beam.

Connect and Disconnect
the AC adapter

The socket-outlet shall be installed near the

equipment and shall be easily accessible.

Do not unplug the power cord out by pulling
the cable only.

Power Cord Requirements

The power cord set (wall plug, cable and
AC adapter plug) you received with your
computer meets the requirements for use
in the country where you purchased your
equipment.

Power cord sets for use in other countries
must meet the requirements of the country
where you use the computer. For more
information on power cord set requirements,

contact your authorized dealer, reseller, or

service provider.

General Requirements

The requirements listed below are
applicable to all countries:

All power cord sets must be approved



by an acceptable accredited agency
responsible for evaluation in the country
where the power cord set will be used.

The power cord set must have a minimum



current capacity of 7 A and a nominal
voltage rating of 125 or 250 volts AC, as
required by each country’s power system.
(USA ONLY)

The appliance coupler must meet the



mechanical conguration of an EN 60

320/IEC 320 Standard Sheet C7(or C5)
connector, for mating with appliance inlet
on the computer.

Regulatory Compliance Statements

Wireless Guidance

(If tted with 2.4G band or 5G band)
Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices),

operating in the 2.4GHz/ 5GHz Band, may be present (embedded) in your notebook system.

The following section is a general overview of considerations while operating a wireless device.

Additional limitations, cautions, and concerns for specic countries are listed in the specic

country sections (or country group sections). The wireless devices in your system are only

qualied for use in the countries identied by the Radio Approval Marks on the system rating

label. If the country you will be using the wireless device in, is not listed, please contact your
local Radio Approval agency for requirements. Wireless devices are closely regulated and use
may not be allowed.

The RF eld strength of the wireless device or devices that may be embedded in your notebook
are well below all international RF exposure limits as known at this time. Because the wireless
devices (which may be embedded into your notebook) emit less energy than is allowed in radio

frequency safety standards and recommendations, manufacturer believes these devices are

safe for use. Regardless of the power levels, care should be taken to minimize human contact

during normal operation.
Some circumstances require restrictions on wireless devices. Examples of common

restrictions are listed on the next page:

Radio frequency wireless communication can interfere with equipment on commercial



aircraft. Current aviation regulations require wireless devices to be turned off while
traveling in an airplane.

802.11ABGN (also known as wireless Ethernet or Wi-Fi) and Bluetooth communication

devices are examples of devices that provide wireless communication.

In environments where the risk of interference to other devices or services is harmful



or perceived as harmful, the option to use a wireless device may be restricted or

eliminated. Airports, Hospitals, and Oxygen or ammable gas laden atmospheres are

limited examples where use of wireless devices may be restricted or eliminated. When

in environments where you are uncertain of the sanction to use wireless devices, ask
the applicable authority for authorization prior to use or turning on the wireless device.

Every country has different restrictions on the use of wireless devices. Since your



system is equipped with a wireless device, when traveling between countries with your

system, check with the local Radio Approval authorities prior to any move or trip for

any restrictions on the use of a wireless device in the destination country.

If your system came equipped with an internal embedded wireless device, do not



operate the wireless device unless all covers and shields are in place and the system
is fully assembled.

Wireless devices are not user serviceable. Do not modify them in any way. Modication



to a wireless device will void the authorization to use it. Please contact manufacturer

for service.

Only use drivers approved for the country in which the device will be used. See the



manufacturer System Restoration Kit, or contact manufacturer Technical Support for
additional information.

United States of America

USA and Canada Safety
Requirements and Notices

Do not touch or move antenna while the unit
is transmitting or receiving.

Do not hold any component containing
the radio such that the antenna is very
close or touching any exposed parts of the
body, especially the face or eyes, while
transmitting.

Do not operate the radio or attempt
to transmit data unless the antenna is
connected; if not, the radio may be damaged.

Use in specic environments:

The use of wireless devices in hazardous

locations is limited by the constraints posed
by the safety directors of such environments.

The use of wireless devices on airplanes
is governed by the Federal Aviation
Administration (FAA).

The use of wireless devices in hospitals
is restricted to the limits set forth by each
hospital.

Use On Aircraft Caution

Regulations of the FCC and FAA
prohibit airborne operation of
radio-frequency wireless devices
because their signals could
interfere with critical aircraft
instruments.

Other Wireless Devices

Safety Notices for Other Devices in
the Wireless Network:

documentation supplied with wireless
Ethernet adapters or other devices in the

wireless network.

The Part 15 radio device operates
on a non-interference basis
with other devices operating at
this frequency. Any changes or

modication to said product not

expressly approved by Intel could
void the user’s authority to operate
this device.

Refer to the

Explosive Device Proximity
Warning

Do not operate a portable
transmitter (such as a wireless

network device) near unshielded

blasting caps or in an explosive
environment unless the device has

been modied to be qualied for

such use.

Unintentional Emitter per FCC Part 15

(If tted with 2.4G band or 5G band)
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:(1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.

This equipment has been tested
and found to comply with the
limits for a Class B digital device
pursuant to Part 15 of the FCC
Rules. These limits are designed
to provide reasonable protection
against harmful interference in
a residential installation. This
equipment generate uses and can
radiate radio frequency energy
and if not installed and used in
accordance with the instructions
may cause harmful interference
will not occur in a particular
installation. If this equipment does
cause harmful interference to
radio or television reception, which
can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:

Reorient or relocate the



receiving antenna.

If necessary, the user should consult the
dealer or an experienced radio/television
technician for additional suggestions. The

user may nd the following booklet helpful: “

Something About Interference.”
This is available at FCC local regional

ofces. Our company is not responsible

for any radio or television interference

caused by unauthorized modications of this

equipment or the substitution or attachment
of connecting cables and equipment other

than those specied by our company. The

correction will be the responsibility of the
user. Use only shielded data cables with this
system.

Increase the separation between



the equipment and receiver.

Connect the equipment into an



outlet on a circuit different from
that to which the receiver is
connected.

Consult the dealer or an



experienced radio/TV technician
for help.

Intentional emitter per FCC Part 15

Low power, Radio LAN type devices (radio
frequency (RF) wireless communication

devices), operating in the 2.4GHz/5GHz

Band, may be present (embedded) in your

notebook system. This section is only

applicable if these devices are present. Refer
to the system label to verify the presence of
wireless devices.

Wireless devices are not user
serviceable. Do not modify them in
any way.

Modication to a wireless device
will void the authorization to use it.

Contact manufacturer for service.

FCC Statement for Wireless LAN
use:

Wireless devices that may be in your system

are only qualied for use in the United States

of America if an FCC ID number is on the
system label.

This device is restricted to indoor use due

to its operation in the 5.15 to 5.25 GHz

frequency range. FCC requires this product
to be used indoors for the frequency range

5.15 to 5.25 GHz to reduce the potential for

harmful interference to co-channel Mobile
Satellite systems. High power radars are
allocated as primary users of the 5.25 to 5.35

GHz and 5.65 to 5.85 GHz bands. These

radar stations can cause interference with
and /or damage this device.

Operation of this device is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation of the device.

“While installing and operating

this transmitter and antenna
combination the radio frequency
exposure limit of 1mW/cm2 may
be exceeded at distances close to
the antenna installed. Therefore,
the user must maintain a minimum
distance of 20cm from the antenna
at all times. This device can not be
colocated with another transmitter
and transmitting antenna.”

FCC Part 68

(If tted with a modem device.)

This equipment compiles with part of the

FCC rules. On the back of this equipment

is a label that contains, among other
information, the FCC registration number
and ringer equivalence number (REN) for
this equipment. If requested, this information
must be provided to the telephone company.

This equipment uses the following USOC

jacks : RJ11C

An FCC compliant telephone cord and
modular plug is provided with this equipment.
This equipment is designed to be connected

to the telephone network or promises wiring
using a compatible modular jack which is Part

68 compliant. See Installation Instructions for
details.

The REN is used to determine the quantity
of devices which may be connected to
telephone line. Excessive RENs on the
telephone line may result in the devices not
ringing in response to an incoming call. In
most, but not all areas, the sum of RENs

should not exceed ve (5.0). To be certain of

the number of devices that may be connected
to a line, as determined by total RENs,
contact the local telephone company to
determine the maximum REN for the calling
area.

If the terminal equipment causes harm to the

telephone network, the Telephone Company

will notify you in advance that temporary
discontinuance of service may be required.
But if advance notice is not practical, the
telephone company will notify the customer
as soon as possible. Also, you will be advised

of your right to le a complaint with the FCC if

you believe it is necessary.

The telephone company may make changes

in its facilities, equipment, operations, or
procedures that could affect the operation
of the equipment. If this happens, the
telephone company will provide advanced

notice in order for you to make necessary
modications to maintain uninterrupted

service.
If trouble is experienced with this equipment

(Modem) for repair or warranty information,
please contact your local distributor. If the
equipment is causing harm to the telephone

network, the telephone company may request

that you disconnect the equipment until the
problem is resolved.

The user must use the accessories and
cables supplied by the manufacturer to get
optimum performance from the product.

No repairs may be done by the customer.
This equipment cannot be used on public

coin phone service provided by the telephone
company. Connection to party line service is
subject to state tariffs.

The Telephone Consumer Protection Act

of 1991 makes it unlawful for any person

to use a computer or other electronic
device, including fax machines, to send
any message unless such message clearly
contains in a margin at the top or bottom of

each transmitted page or on the rst page

of the transmission, the date and time it is

sent and an identication of the business

or other entity, or other individual sending
the message and the telephone number
of the sending machine or such business,
other entity, or individual. (The telephone
number provided may not be any number for
which charges exceed local or long-distance
transmission charges.)

In order to program this information into your
fax machine, refer to your communications
software user manual.

Canada

Unintentional Emitter per ICES-003

This digital apparatus does not exceed the
Class B limits for radio noise emissions
from digital apparatus as set out in the radio
interference regulations of Industry Canada.

Le présent appareil numérique n’émet pas
de bruits radioélectriques dépassant les
limitesapplicables aux appareils numériques
de Classe B prescrites dans le règlement
sur le brouillage radioélectrique édicté par
Industrie Canada.

Intentional Emitter per RSS 210

(If tted with 2.4G band or 5G band)
Low power, Radio LAN type devices (radio
frequency (RF) wireless communication

devices), operating in the 2.4GHz/5GHz

Band, may be present (embedded) in your

notebook system. This section is only

applicable if these devices are present. Refer
to the system label to verify the presence of
wireless devices.

Wireless devices that may be in your system

are only qualied for use in Canada if an

Industry Canada ID number is on the system
label.

When using IEEE 802.11a wireless LAN, this
product is restricted to indoor use due to its

operation in the 5.15- to 5.25-GHz frequency

range. Industry Canada requires this product
to be used indoors for the frequency range of

5.15 GHz to 5.25 GHz to reduce the potential

for harmful interference to co-channel
mobile satellite systems. High power radar
is allocated as the primary user of the 5.25-

to 5.35-GHz and 5.65 to 5.85-GHz bands.

These radar stations can cause interference
with and/or damage to this device.

The maximum allowed antenna gain for use
with this device is 6dBi in order to comply
with the E.I.R.P limit for the 5.25- to 5.35 and

5.725 to 5.85 GHz frequency range in point-

to-point operation.
The power output of the wireless device (or

devices), which may be embedded in your

notebook, is well below the RF exposure

limits as set by Industry Canada.
Operation of this device is subject to the

following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation of the device.

To prevent radio interference to
licensed service, this device is
intended to be operated indoors
and away from windows to provide
maximum shielding. Equipment (or
its transmit antenna) that is installed
outdoors is subject to licensing.

Wireless devices are not user
serviceable. Do not modify them in

any way. Modication to a wireless
device will void the authorization

to use it. Contact manufacturer for
service.

Telecommunications per DOC notice

(for products tted with an IC-

compliant modem)

The Industry Canada label identies certied
equipment. This certication means that the

equipment meets certain telecommunications

network protective, operation, and safety

requirements. The Department does not
guarantee the equipment will operate to the
users’ satisfaction.

Before installing this equipment, users

should make sure that it is permissible

to be connected to the facilities of the
local telecommunications company. The
equipment must also be installed using
an acceptable method of connection. In
some cases, the inside wiring associated
with a single-line individual service may be

extended by means of a certied connector

assembly. The customer should be aware
that compliance with the above conditions
may not prevent degradation of service in
some situations.

Repairs to certied equipment should
be made by an authorized Canadian

maintenance facility designated by
the supplier. Any repairs or alterations
made by the user to this equipment, or
equipment malfunctions, may give the
telecommunications company cause to
request the user to disconnect the equipment.

To avoid electrical shock or

equipment malfunction do not

attempt to make electrical ground

connections by yourself. Contact
the appropriate inspection authority
or an electrician, as appropriate.

Ringer Equivalence Number

The
assigned to each terminal device provides
an indication of the maximum number of
terminals allowed to be connected to a
telephone interface. The termination on an
interface may consist of any combination of
devices subject only to the requirement that
the sum of the Ringer Equivalence Numbers
of all the devices does not exceed 5.

(REN)

Brazil

Este equipamento opera em caráter
secundário, isto é, não tem direito a proteção
contra interferência prejudicial, mesmo
de estações do mesmo tipo, e não pode
causar interferência a sistemas operando em
caráter primário.

Users should make sure, for their own

protection, that the electrical ground
connections of the power utility, telephone
lines, and internal metallic water pipe system,
if present, are connected together. This
precaution may be particularly important in
rural areas.

European Union

European Union CE Marking and
Compliance Notices

Products intended for sale within the

European Union are marked with the
Conformité Européene (CE) Marking, which

indicates compliance with the applicable
Directives and European standards and

amendments identied below. This equipment
also carries the Class 2 identier.

The following information is only applicable

to systems labeled with the CE mark

.

European Directives

This Information Technology Equipment has
been tested and found to comply with the
following European directives:

EMC Directive 2004/108/EC



Low Voltage Directive 2006/95/EC



R&TTE Directive 1999/5/EC



Manufacturer Information

Samsung Electronics Co., Ltd.
416, Maetan-3Dong, Yeongtong-Gu, Suwon­City, Gyeonggi-Do, 443-742, Korea

Samsung Electronics Suzhou Computer CO.,

LTD

No. 198, Fangzhou Road, Suzhou Industrial
Park, Jiangsu Province, 215021, China

Tel:[phone]

For the web or the phone number of
Samsung Service Centre, see the Warranty
or contact the retailer where you purchased
your product.

European Radio Approval

Information (for products tted with

EU-approved radio devices)

This Product is a Notebook computer;

low power, Radio LAN type devices (radio
frequency (RF) wireless communication

devices), operating in the 2.4GHz/5GHz

band, may be present (embedded) in your

notebook system which is intended for home
or ofce use. This section is only applicable

if these devices are present. Refer to the
system label to verify the presence of
wireless devices.

Wireless devices that may be in your system

are only qualied for use in the European
Union or associated areas if a CE mark

with a Notied Body Registration Number

and the Alert Symbol is on the system label.
The power output of the wireless device

or devices that may be embedded in you

notebook is well below the RF exposure limits

as set by the European Commission through
the R&TTE directive.

The low band 5.15 - 5.35 GHz is for indoor

use only.

See 802.11b and 802.11g

restrictions for specic countries or

regions within countries under the

heading “European Economic Area

Restrictions” below.

EU R&TTE Compliance Statements

Česky

[Czech]

Dansk
[Danish]

Deutsch
[German]

Eesti
[Estonian]

English

Español
[Spanish]

Samsung tímto prohlašuje, že tento Notebook PC je ve shodě se
základními požadavky a dalšími příslušnými ustanoveními směrnice

1999/5/ES.

Undertegnede Samsung erklærer herved, at følgende udstyr Notebook PC
overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/

EF.

Hiermit erklärt Samsung, dass sich das Gerät Notebook PC in

Übereinstimmung mit den grundlegenden Anforderungen und den übrigen

einschlägigen Bestimmungen der Richtlinie 1999/5/EG be ndet.

Käesolevaga kinnitab Samsung seadme Notebook PC vastavust direktiivi
1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele
asjakohastele sätetele.

Hereby, Samsung, declares that this Notebook PC is in compliance with

the essential requirements and other relevant provisions of Directive
1999/5/EC.

Por medio de la presente Samsung declara que el Notebook PC cumple

con los requisitos esenciales y cualesquiera otras disposiciones aplicables
o exigibles de la Directiva 1999/5/CE.

Ελληνική

[Greek]

Français
[French]

Italiano
[Italian]

Latviski
[Latvian]

Lietuvių

[Lithuanian]

Nederlands
[Dutch]

ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Samsung ΔΗΛΩΝΕΙ ΟΤΙ Notebook PC
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ
ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.

Par la présente Samsung déclare que l’appareil Notebook PC est

conforme aux exigences essentielles et aux autres dispositions pertinentes
de la directive 1999/5/CE.

Con la presente Samsung dichiara che questo Notebook PC è conforme
ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla

direttiva 1999/5/CE.

Ar šo Samsung deklarē, ka Notebook PC atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.

Šiuo Samsung deklaruoja, kad šis Notebook PC atitinka esminius
reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.

Hierbij verklaart Samsung dat het toestel Notebook PC in

overeenstemming is met de essentiële eisen en de andere relevante
bepalingen van richtlijn 1999/5/EG.

Malti
[Maltese]

Hawnhekk, Samsung, jiddikjara li dan Notebook PC jikkonforma mal­ħtiāijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm  d-

Dirrettiva 1999/5/EC.

Magyar
[Hungarian]

Polski
[Polish]

Português
[Portuguese]

Slovensko
[Slovenian]

Slovensky
[Slovak]

Suomi
[Finnish]

Svenska
[Swedish]

Alulírott, Samsung nyilatkozom, hogy a Notebook PC megfelel a
vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb
elõírásainak.

Niniejszym Samsung oświadcza, Ŝe Notebook PC jest zgodny z
zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami
Dyrektywy 1999/5/EC.

Samsung declara que este Notebook PC está conforme com os requisitos

essenciais e outras disposições da Directiva 1999/5/CE.

Samsung izjavlja, da je ta Notebook PC v skladu z bistvenimi zahtevami in
ostalimi relevantnimi določili direktive 1999/5/ES.

Samsung týmto vyhlasuje, že Notebook PC spĺňa základné požiadavky a
všetky príslušné ustanovenia Smernice 1999/5/ES.

Samsung vakuuttaa täten että Notebook PC tyyppinen laite on direktiivin
1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden
ehtojen mukainen.

Härmed intygar Samsung att denna Notebook PC står I överensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som
framgår av direktiv 1999/5/EG.

Íslenska
[Icelandic]

Norsk
[Norwegian]

Türkiye
[Türkçe]

Hér með lýsir Samsung y r því að Notebook PC er í samræmi við
grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC.

Samsung erklærer herved at utstyret Notebook PC er i samsvar med de
grunnleggende krav og øvrige relevante krav i direktiv 1999/5/EF.

Bu belge ile, Samsung bu Notebook PC’nin 1999/5/EC Yönetmeliğinin
temel gerekliliklerine ve ilgili hükümlerine uygun olduğunu beyan eder.

To view the EU Declaration of Conformity for this product (in English only), go to: http://www.

samsung.com/uk/support/download/supportDownMain.do then search the model number of

the product.
If the Declaration of Conformity for the model you are interested in is not available on our web-

site, please contact your distributor.

European Economic Area
Restrictions

Local Restriction of 802.11b/802.11g Radio
Usage

[Note to integrator: The following statements
on local restrictions must be published in all
end-user documentation provided with the
system or product incorporating the wireless
product.]

Due to the fact that the frequencies
used by 802.11b/802.11g wireless
LAN devices may not yet be

harmonized in all countries,

802.11b/802.11g products are

designed for use only in specic

countries or regions, and are not
allowed to be operated in countries
or regions other than those of
designated use.

As a user of these products, you
are responsible for ensuring that
the products are used only in the
countries or regions for which they
were intended and for verifying

that they are congured with the

correct selection of frequency and
channel for the country or region of
use. Any deviation from permissible
settings and restrictions in the
country or region of use could be an
infringement of local law and may
be punished as such.

The European variant is intended for use
throughout the European Economic Area.

However, authorization for use is further

restricted in particular countries or regions
within countries, as follows:

General

European standards dictate maximum
radiated transmit power of 100 mW effective
isotropic radiated power (EIRP) and the

frequency range 2400 – 2483.5 MHz.
The low band 5.15 - 5.35 GHz is for indoor

use only.

Belgium

The product may be used outdoors, but for
outdoor transmissions over a distance of
300m or more, a license from the BIPT is
required.

This restriction should be indicated in the
manual as follows:

Dans le cas d’une utilisation privée, à l’
extérieur d’un bâtiment, au-dessus d’un
espace public, aucun enregistrement n’
est nécessaire pour une distance de moins
de 300m. Pour une distance supérieure à
300m un enregistrement auprès de l’IBPT
est requise. Pour une utilisation publique à l’
extérieur de bâtiments, une licence de l’IBPT
est requise. Pour les enregistrements et

licences, veuillez contacter l’IBPT.

France

For Metropolitan departments:

2.400 - 2.4835 GHz for indoor use.

2.400 - 2.454 GHz (channels 1 to 7) for

outdoor use.

For Guadeloupe, Martinique, St Pierre et
Miquelon, Mayotte:

2.400 - 2.4835 GHz for indoor and outdoor

use.

For Reunion, Guyane:

2.400 - 2.4835 GHz for indoor use.

2.420 - 2.4835 GHz for outdoor use (channels

5 to 13)

The low band 5.15 - 5.35 GHz is for indoor

use only.

European Telecommunication

Information (for products tted with

EU-approved modems)

Marking by the symbol indicates
compliance of this equipment to the Radio

and Telecom Terminal Equipment Directive

1999/5/EC. Such marking is indicative

that this equipment meets or exceeds the
following technical standards:

CTR 21 - Attachment requirements for
pan-European approval for connection to
the analogue Public Switched Telephone

Networks (PSTNs) of TE (excluding TE

supporting voice telephony services) in

which network addressing, if provided, is by

means of Dual Tone Multi-Frequency (DTMF)
signaling.

This equipment has been approved to Council

Decision 98/482/EEC - “CTR 21” for Pan-

European single terminal connection to the

Public Switched Telephone Network (PSTN).

However, due to differences between the
individual PSTNs provided in different
countries, the approval does not, of itself, give
an unconditional assurance of successful
operation on every PSTN termination point.
In the event of problems, you should contact
manufacturer Technical Support.

Although this equipment can use
either loop disconnect (pulse) or
DTMF (tone) signaling, only the
performance of the DTMF signaling
is subject to regulatory requirements
for correct operation.

It is therefore strongly
recommended that the equipment
is set to use DTMF signaling
for access to public or private
emergency services. DTMF
signaling also provides faster call
setup.

WEEE SYMBOL INFORMATION

Correct disposal of this product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate
collection systems.)

This marking on the product, accessories or literature indicates that the product and its

electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other

household waste at the end of their working life. To prevent possible harm to the environment

or human health from uncontrolled waste disposal, please separate these items from other
types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.

Household users should contact either the retailer where they purchased this product, or

their local government ofce, for details of where and how they can take these items for

environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the

purchase contract. This product and its electronic accessories should not be mixed with other
commercial wastes for disposal.

Correct disposal of batteries in this product

Pb

This marking on the battery, manual or packaging indicates that the batteries in this product
should not be disposed of with other household waste at the end of their working life. Where
marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury,

cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are not
properly disposed of, these substances can cause harm to human health or the environment.

To protect natural resources and to promote material reuse, please separate batteries from
other types of waste and recycle them through your local, free battery return system.

USA ONLY

This Perchlorate warning applies only to primary CR (Maganese Dioxide) Lithium coin cells in
the product sold or distributed ONLY in California USA.

“Perchlorate Material- special handling may apply, See www.dtsc.ca.gov/hazardouswaste/

perchlorate.”

(Applicable in the European Union and other European countries with separate
battery return systems.)

Basic Items

The items included in the package may vary depending on your selection of the optional

items. Some items may be replaced with similar products and the color of some items
may differ from that in this document.

Computer AC AdapterStandard Battery

Power Cable

Charge the battery fully when using the computer for the rst time.

Overview

Before You Start!

 Optional items may be changed or may not be provided depending on the computer

model.

 The actual color and appearance of the computer may differ from the pictures used

in this guide.

Front View

1

2

Camera (Optional)

1

LCD

2

3

Speaker

4

Power Button

Keyboard

5

Touchpad/

6

Touchpad Buttons

3
4

5
6

7

8

Using this camera, you can take still pictures and record video.

The screen images are displayed here.

A device used to generate sound.

Turns the computer on or off.

A device to enter data by pressing the keys.

The touchpad and touchpad buttons provide functions similar to
the mouse ball and buttons.

7

Microphone (Optional)

Status Indicators

8

You can use the built-in microphone.

Shows the operating status of the computer.
The corresponding operating LED is lit when the corresponding

function operates.

Status Indicators

Caps Lock

1

2

HDD/ODD

3

Wireless LAN

Charge Status

4

2

This turns on when the Caps Lock key is pressed allowing capital

letters to be typed without holding the Shift button down.

On

: Upper-case alphabetic input

Off

: Lower-case alphabetic input

This turns on when the hard disk is or ODD being accessed.

This turns on when the wireless LAN is operating.

This shows the power source and the battery charge status.

Green:

installed.

Orange:

When the battery is fully charged or the battery is not

3

When the battery is being charged.

4 51

5

Power

Off:

When the computer is running on battery power without being

connected to AC adapter.

This shows the computer operating status.

On:

When the computer is operating.

Blinks:

When the computer is in Sleep mode.

Right View

1 2 3 4

USB Port

1

Multi Card Slot

2

(Optional)

3

Wired LAN Port

Security Lock Port

4

You can connect USB devices to the USB port such as a

keyboard/mouse, digital camera, etc.

A card slot that supports SD card, SDHC card, MMC card and
SDXC card.

Connect the Ethernet cable to this port.

You can connect a Kensington lock to the Security Lock Port to

prevent the computer from being stolen.

Left View

21 3 4 5 6

DC Jack

1

Monitor Port

2

Fan Vents

3

USB Port

4

5

Microphone Jack

6

Headphone Jack

A jack to connect the AC adapter that supplies power to the

computer.

A port used to connect a monitor, TV or projector supporting a
15pin D-SUB interface.

The internal heat of the computer is emitted through these holes.

If the vents are blocked the computer may overheat.
Avoid blocking the vents as this may be dangerous.

You can connect USB devices to the USB port such as a keyboard/

mouse, digital camera, etc.

A jack used to connect the microphone.

A jack used to connect the headphones.

Bottom View

1

2

3

4

Battery

1

Battery Latches

2

Memory Compartment Cover

3

Fan Vents

4

This is a Lithium-Ion rechargeable battery that supplies power to
the computer.

The latch used to remove or install the battery.

The main memory is installed inside the cover.

The internal heat of the computer is emitted through these
holes.

If the vents are blocked the computer may
overheat. Avoid blocking the vents as this may be

dangerous.

Turn on the computer

Attaching the Battery

Battery preparation.

1

Attaching the Battery.

2

Connect the AC adapter

Connect the AC adapter.

1

Connect the power cable.

2

x

z

x

Power

Cable

 Charge the battery fully when using the computer for the  rst time.
 When using the power cable, insert the power cable completely into the AC adapter.
 Some items may be replaced with similar products and the color of some items may

differ from that in this document.

 The images used for the illustration are of a representative model, therefore the

images may differ from the the actual product.

AC Adapter

z

DC-in Jack

Turn on the computer

Charge the battery fully when using the computer for the rst time.

Lift up the LCD panel.

1

Press the

2

Power button

Press the

You can only use this function after installing Windows XP or Windows 7/Vista and
installing the Easy Display Manager program with the system software media disk.

Fn

+ key to increase the LCD brightness.

to turn the computer on.

z

x

Using Sleep Mode

Windows XP, Windows Vista or Windows 7.

Sleep mode enables switching the computer to Standby mode in order to minimize power
consumption and enables users to use the computer instantly by pressing any key on the
mouse or keyboard.

Using Sleep Mode in Windows 7/Vista

Click

Start

> >

Sleep

.

Using Stand by Mode in Windows XP

Click

Start

>

Turn Off Computer

>

Stand By

.

Chapter 2.

Using the
computer

Keyboard 56

Touchpad 59

CD Drive (ODD, Optional) 60

Connecting the CD Drive 60

Inserting and Ejecting a CD 61

Multi Card Slot (Optional) 62

Adjusting the Volume 64

Keyboard

Shortcut key functions and procedures are discussed in the following sections.

 The keyboard is supplied according to the corresponding country.

 The keyboard image may differ from the actual keyboard.

 You can only use the hot keys and the pre-determined shortcut keys (Windows key,

application key, volume key, etc.) after installing Windows XP or Windows 7/Vista.

 Some model is not supplied System Software Media depending on your computer

model.

Shortcut Keys

You can use the following functions by pressing the keys below with the Fn key.

Fn+ Name Function

Pressing the key switches the computer to power-saving (Standby)

REST

(Sleep Mode)

Gauge

Euro

CRT/LCD

mode. To use the computer in this state, press the Power button.

You can use this button after installing Windows XP or Windows
7/Vista.

Shows the remaining battery charge.

You can only use this function after installing Windows XP or Windows
7/Vista and installing the

system software media disk

Enters the Euro monetary unit symbol.

Switches the screen output to the LCD or external monitor when an
external monitor (or TV) is connected to the computer.

You can only use this function after installing Windows XP or Windows
7/Vista and installing the

system software media disk

Easy Display Manager

.

Easy Display Manager

.

program with the

program with the

Backlit

Mute

You can turn the LCD on or off after installing Windows XP or Windows
7/Vista.

You can turn the sound on or off after installing Windows XP or
Windows 7/Vista.

Fn+ Name Function

System diagnosis, recovery and Internet consultation program,

Samsung

Support

Center

Easy

SpeedUp

Manager

Samsung Support Center, will be launched. (Optional)

You can only use this function after installing Windows XP or Windows
7/Vista and installing the

system software media disk

You can select operation mode when you need maximum system
performance or low-noise/low power consumption with one-click.

You can only use this function after installing Windows XP or Windows
7/Vista and installing the

software media disk



Silent



Normal



Speed

maximum performance, and system resources are allocated to the
currently active program with priority for maximum performance.



Speed Boot

when the booting process has slowed down because multiple
programs have been installed. You can boot up the computer more
quickly by setting the time to execute the S/W in the
menu.

: Low-noise and low power consumption mode

: Normal Mode

: Maximum performance mode. The system operates in its

: Quick booting mode. This mode enables quick booting

Samsung Support Center

. (Optional)

Magic Keyboard

. (Only for XP)

program with the

program with the

Advanced

system

Wireless LAN

Touchpad

Num Lock

Scroll Lock

If you don’t want fan noise turning ON and OFF in the Silent
mode, select the
in the BIOS Setup. The fan keeps turning ON and works in
Low noise mode.

Turns the wireless LAN function on or off in models with wireless LAN
capability.

You can only use this function after installing Windows XP or Windows
7/Vista and installing the
LAN driver with the

You can turn the Touchpad function on or off by pressing this button
after installing Windows XP or Windows 7/Vista.

When using an external mouse only, you can turn the Touchpad off.

You can use some of the character keys as numeric keys by turning
the Num Lock on, after installing Windows XP or Windows 7/Vista.

You can scroll up or down the screen while maintaining the cursor
position by turning on Scroll Lock, after installing Windows XP or
Windows 7/Vista.

system software media disk

Advanced

Magic Keyboard

menu

> Fan Silent Mode > Low

program and the wireless

.

Screen Brightness Control

To adjust the LCD brightness press the Fn + key combination or the Fn + key
combination.

The changed screen brightness is displayed at the center of the screen for a moment.

You can use the screen brightness control keys after installing Windows and Easy
Display Manager.

Volume Control

To control the volume, press the Fn + key combination or the Fn + key combination.

You can mute the sound or cancel the mute function by clicking the
combination.

You can use the volume and numeric keys after installing Windows XP or Windows
7/Vista.

Numeric Key

The numbers are printed in blue on the numeric keys.

If Num Lock is turned on by pressing the
keys to enter digits.

You can only use the numeric keys after installing Windows XP or Windows 7/Vista.

Fn

+ key combination, you can use the numeric

Fn

+ key

Touchpad

The touchpad provides the same function as a mouse and the left and right buttons of the
touchpad plays the role of the left and right buttons of a mouse.

Before You Start!



Use the Touchpad with your  ngers. Using a sharp object may damage the

Touchpad.

If you touch the Touchpad or press the Touchpad buttons while booting up, the



Windows boot time may be extended.

Scroll Area

Touch Area

Use to move the cursor.

Touchpad Left Button

You can select or run

a program using this

button.

This corresponds to the wheel
of the mouse and can be
moved up, down, left or right.

Touchpad Right Button

Plays the role of the right
mouse button.

CD Drive (ODD, Optional)

An optical disk drive is optional and may differ depending on your computer model. For

detailed speci cations, refer to the catalogue.

 Do not insert a cracked or scratched CD.

Otherwise, the CD may break and damage the optical disk drive when the CD rotates
at a high speed.

 When you clean a CD or DVD title, wipe with a soft cloth from inside to outside.

 Do not eject a CD when the CD operating LED is on.

 The images used for the illustration are of a representative model, therefore the

images may differ from the the actual product.

 Using a CD that is not in the shape of a circle is not recommended.

Connecting the CD Drive

Connect the CD drive to the

USB port

.

USB port

Inserting and Ejecting a CD

Press the

1

When the CD tray opens, insert a CD or DVD and push the tray in until it clicks.

2

Eject

button of the CD drive.

Status Indicator

Emergency Hole

Eject Button

Push the CD tray inward until it clicks.

3

The CD drive status indicator is turned on.

 A CD drive’s reading and writing speed may differ depending on the condition and

type of the media.

 To eject a CD when the CD drive does not work or the computer is off, place the end

of a paper clip (

) into the Emergency Hole until the CD tray is ejected.

Multi Card Slot (Optional)

Using the multi card slot, you can read and write data to a SDHC, MMC, SDXC and SD
card.

You can use a card as a removable disk and conveniently exchange data with digital
devices such as a digital camera, digital camcorder, MP3, etc.

You can only use it after installing Windows XP or Windows 7/Vista.

Before You Start!

 You have to additionally purchase a multi card with the necessary capacity

depending on your requirements.

 You can use a multi card just like any data storage device. A copyright protection

function is not supported.

 Since you can lose a card when moving the computer, keep the card separately.

 Before using the slot, remove the dummy card from the slot.

(Only models supplied with a dummy card).

 Supported Cards : SD Card, SDHC card, MMC card, SDXC card

 The images used for the illustration are of a representative model, therefore the

images may differ from the the actual product.

To Insert and Use a Memory Card

Insert a card into the slot according to the directions printed on the slot.

Example) SD Card

Using a Mini SD and RS-MMC

Since the above cards are too
small, you cannot insert the cards
into the slot directly.

Insert the card into the dedicated
adapter (available from most
electronic retailers) and then insert
the adapter into the multi card slot.

However, depending on the
adapter’s body material, some RS­MMC cards may not be recognized
properly. Samsung recommends
checking the card is recognized
correctly prior to purchasing.

To remove a memory card

To format a memory card

When using a memory card for the rst time,

you must format the card before using it.

Formatting a card deletes all data
saved on the card. If the card
includes data, backup the data
before formatting it.

Click

1

Right-click over a card drive with the

2

Start

>

My computer

touchpad and select

.

Format

.

Take hold of the end of the card and remove
the card.

Click

3

Start

to the formatting.

 To use a card to exchange data

with a digital device such as a
digital camera, formatting the
data using the digital device is
recommended.

 When you try to use a card,

which is formatted in the
computer, in another digital
device, you may have to format
the card again in the device.

 You cannot format, write or

delete data from a SD, or SDHC
card with a write protection tab
when it is in the Lock position.

 Inserting and removing a

memory card repeatedly may
damage the memory card.

Adjusting the Volume

You can adjust the volume using the keyboard and the volume control program.

Adjusting the Volume using the
Keyboard

Press the

key combination to adjust the volume.

Press the
the volume on or off.

Fn

+ key combination or Fn +

Fn

+ key combination to turn

You can only use it after installing
Windows XP or Windows 7/Vista.

Adjusting the Volume using the
Volume Adjustment Program

You can only use it after installing
Windows XP or Windows 7/Vista.

The following are the procedures
to control the volume in Windows
7/Vista. For the Windows XP
procedures, refer to the following
as the procedures are similar.

Click the
slide the volume control bar to adjust the
volume.

Volume

icon on the taskbar and

Mute

Alternatively, right-click over the

and select

the volume.

Open Volume Mixer

Volume

to adjust

icon

Chapter 3.

Settings and
Upgrade

LCD Brightness Control 66

BIOS Setup 67

Entering the BIOS Setup 67

The BIOS Setup Screen 68

Setting a Boot Password 70

Changing the Boot Priority 72

Upgrading Memory 73

Battery 75

Installing/Removing the Battery 75

Charging the Battery 76

Measuring the Remaining Battery Charge 77

Extending the Battery Usage Time 77

Using the Security Lock Port 79

LCD Brightness Control

You can adjust the LCD brightness in 8 levels.

Before You Start!

The LCD brightness is the brightest (Level 8) when the computer is running on AC
power, and it becomes dimmer when running on battery power.

Controlling the Brightness Using the Keyboard

You can use the screen brightness control keys after installing Windows and Easy Display
Manager.

Adjust the LCD brightness by pressing the

Fn

+ key or the Fn + key.

The LCD brightness can change up to 8 levels and the brightness increases by 1 level when

pressing the

Fn

+ key once.



Maintaining the changed LCD brightness even after turning the computer on again

To maintain the LCD brightness set by using the brightness control keys or through

the Power Options, follow the procedures below.

1.

Turn the computer on and press the F2 key when the SAMSUNG logo appears on
the screen to enter the BIOS Setup.

2.

Select the

3.

Press the

LCD bad pixels principle of laptop computer



Samsung observes the specications regarding strict quality and reliability of LCD

But in spite of that, it is inevitable that there might be a small number of bad pixels. A
large number of bad pixels can cause problems in appearance, but a small number
of pixels doesn't affect the computer performance.

Boot

menu and set the

F10

key to save the settings and exit Setup.

Brightness Mode Control

item to

User Control

.

Therefore Samsung observes and manages the following dot principles:

- Bright dot : 2 or less

- Black dot : 4 or less

- Combination of Bright and Dark : 4 or less

Instructions for Cleaning the LCD

Clean the LCD panel with a soft cloth lightly moistened with computer cleansing
detergent moving in one direction.

Cleaning the LCD panel with excessive force can damage the LCD.

BIOS Setup

The BIOS Setup enables you to congure your computer hardware according to your

needs.

Before You Start!

 Use the BIOS setup to dene a boot password, change the booting priority, or add a

new device.
Since incorrect settings may cause your system to malfunction or crash, take care

when conguring the BIOS.

 The functions of the BIOS setup are subject to change for product function

enhancement purposes.

The BIOS Setup menus and items may differ depending on your computer model.

Entering the BIOS Setup

Turn the computer on.

1

When the booting screen (SAMSUNG logo) appears, press the F2 key to enter the BIOS

2

Setup.

Press the
try to boot from the network.

After a moment, the BIOS setup screen appears.

3

The items in the BIOS setup may differ depending on the product.

F12

key while the booting screen(SAMSUNG logo) appears, the system will

The BIOS Setup Screen

The functions of the BIOS setup are subject to change for product function
enhancement purposes.

Setup Menu

Help

Help for the selected item
appears automatically.

Setup Menu Description

Sysinfo

Advanced

Security

Boot

Exit

This is a description about the basic specications of the computer.

Using this menu, you can congure the major chipsets and additional functions.

Used to congure security functions, including passwords.

This menu enables you to congure peripherals and booting related settings

such as the boot priority.

Used to exit the Setup either saving the changes or not.

Setup Items

System Setup Keys

In the Setup, you have to use the keyboard.

F1

Up & Down Keys

F5/F6

F9

ESC

Left & Right Keys

Press to view the Setup Help.

Press to move up and down.

Press to change the item value.

Press to load the default Setup settings.

Press to return to a higher level menu or to move to the
Exit menu.

Press to move to another menu.

Enter

F10

The keyboard image may differ from the actual keyboard.

Press to select an item or to enter a sub menu.

Press to save the changes and exit Setup.

Setting a Boot Password

When setting a password, you have to enter a password to use the computer or enter the
BIOS Setup.

By conguring a password, you can restrict system access to authorized users only and
protect data and les saved on the computer.

Before You Start!

 Do not lose or forget your password.

 If you have forgotten your password, contact a Samsung service center. In this case,

a service fee will be charged.

Setting a Supervisor Password

A Supervisor Password is required to turn
the computer on or to start the System
Setup.

When setting a Supervisor Password, users
other than a supervisor cannot use the
computer.

Select the

1

Setup.

In the

2

press <

Security

Set Supervisor Password

Enter

>.

menu in the BIOS

item,

Enter a password, press <

3

enter the password for conrmation,

and press <
password can be up to 8 alphanumeric
characters. Special characters are not
allowed.

When a message conrming the

4

password conguration appears in the

[

Setup Notice

The supervisor password has been set.
The supervisor password is required to
turn the computer on or to enter the
BIOS Setup.

Enter

> again. The

] window, press <

Enter

>, re-

Enter

>.

Setting a User Password

Users can start the system with a user
password, but cannot enter the System
Setup. By doing this, you can prevent other
users from entering Setup.

Before conguring a user password, a

supervisor password

congured. Deactivating the supervisor

password also deactivates the user
password.

In the
<
Step 3 of Setting a Supervisor Password.

Set User Password

Enter

> and complete the procedures from

must have been

item, press

Setting Up a Boot Password

To setup a boot password, the administrator
password (
be set in advance.

Set Supervisor Password

) should

Changing the hard disk drive
password

For security purposes, you can
only change a hard disk drive
password after restarting the
computer by pressing the computer

Power

If you cannot change the hard
disk drive password or the

Password Frozen

appears when entering the BIOS
Setup and then selecting

> HDD Password

button to turn the computer on
again.

button.

HDD

message

Security

, press the Power

Set the
Once a boot password is set, you have to
enter a password to boot up the computer.

Password on boot

item to

Enabled

.

Setting up a Hard Disk Drive
Password (Optional)

A supervisor password must be set using the
Set Supervisor Password menu.

If you set a password for a hard disk drive, it
cannot be accessed from another computer.

Press Enter in the

and dene a password as described in Step

3 of the Setting up the Supervisor Password.

The hard disk drive password
setting function is not provided for
some models.

Set HDD Password

item

Deactivating the Password

Press <

1

deactivated. For example, to deactivate
a supervisor password in the

Supervisor Password

<

Enter

In the

2

enter the currently congured password

and press <

Leave the

3

eld empty, and press <

Enter

> on the password to be

item, press

>.

Enter Current Password

Enter

Enter New Password

>.

Enter

Set

item,

item

>.

Leave the

4

empty, and press <

In the [

5

<

Enter

The password is deactivated.

Conrm New Password

Setup Notice

>.

Enter

>.

] window, press

eld

Changing the Boot Priority

Boot Device Priority

[Boot priority order]

1. AHCI CD : N/A

2. AHCI HDD : XXXXXXXXXXXXXXXX

3. USB KEY : N/A

4. USB CD : XXXXXXXXXXXXXX

5. USB FDD : N/A

6. USB HDD : N/A

7. PCI BEV : N/A

8.

- PCI SCSI : N/A

- USB ZIP : N/A

- USB LS120 : N/A

- Legacy Network Card

- Legacy

[Excluded from boot order]

This computer is congured to boot from an external-type ODD rst.

This chapter describes how to change the boot priority so that the computer boots from

the hard disk drive rst.

Select the

1

Setup.

Press <

2

Priority

Boot

Enter

item.

menu in the BIOS

> on the

Boot Device

Press the down key (↓) to move to the

3

IDE HDD

item and press the F6 key to

move the item to the top.

Press the

4

F10

key to save the settings
and exit Setup. The highest boot
priority device is now set to the Hard
Drive.

Upgrading Memory

A memory is installed in the memory slot at the bottom of this computer. The procedures
to replace the memory are described below.

Before You Start!

 Replace new memory only after shutting the computer down completely. Do not

replace memory when the computer is in Sleep mode.

 Disconnect main power plug and remove the battery before continuing.
 Only use the same type of memory as specied in the Product Specication.
 The memory compartment cover may differ from the gure below.
 You must use only memory modules with the specications (DDR2 or DDR3) printed

on the memory slot that appears when you open the memory compartment cover at
the bottom.

e.g) in the case of using DDR2

Replacing the Memory

Remove the screw on the memory

1

compartment cover at the bottom of
the computer using a screw driver.

Fixing Screw

Pull the memory module latches

2

outward. The memory module will pop
up.

Remove the memory module out at an
angle of 30 degrees.

Insert a new memory module into

3

the memory slot at an angle of
approximately 30 degrees aligning it to
the angle of the memory slot.

Push the memory module down so that

4

it is completely xed. If the memory
does not t easily, push the memory

module down while pulling the memory
module latches outward.

Memory Slot

Close the memory compartment cover

5

and fasten the screw.

Battery

Please refer to the following instructions when running the computer on battery power
without connecting the AC power.

A Lithium-Ion smart battery is supplied with this computer.

Before You Start!

Carefully read and follow the precautions printed on the battery before using the battery.

Precautions

 Use only chargers specied in the User Manual.
 Never heat the battery pack, put it near or in a re or use at a temperature higher

than 60°C, as this may cause re.

 Never cause a short circuit between the battery pack terminals or disassemble the

battery pack.

 Carefully read and follow the precautions printed on the battery and the safety

instructions in the User Manual before using the battery.

 Please refer to the system operation environment of this manual and operate and

store the battery at room temperature.

Installing/Removing the Battery

Shutdown the system, close the LCD

1

panel and place the computer upside

down on a at surface.

Slide the battery latches

2

and separate the battery.

outwards

Charging the Battery

To install the battery again, slide the

3

battery into the system.
The battery latches move inwards and

 x the battery automatically.

Check if the battery latch has been
moved inwards.

Attach the battery and connect the

1

AC adapter to the DC-in jack of the
computer.

The battery will then start charging.

x

z

When charging is complete, the Charge

2

LED turns green.

Status Charge LED

Red

Charging

Charging complete Green

AC adapter not

connected

or

Orange

or

Blue

Off

Measuring the Remaining
Battery Charge

You can view the battery charge status by
completing the following procedures.

To use the shortcut key to view

You can only use this function after installing
Windows XP or Windows 7/Vista and
installing the
with the
for Widows 7/Vista)

Easy Display Manager

system software media disk

program

. (Only

Battery Usage Time Information

A battery is an expendable supply, so when
using it over a long time, the capacity/battery
life is shortened. If the battery life is reduced
to under half of its initial time, we recommend
purchasing a new battery.

When not using the battery for a long time,
store the battery after charging it to 30-40%
of its capacity. This extends the battery life
time.

Extending the Battery Usage

Press the

The remaining battery charge (%) will
displayed for a moment.

Fn

+ keys on the keyboard.

Battery Warning

If the battery residual amount is
3~5%, the computer automatically
shuts down after saving the data.
The battery residual amount may
vary depending on the computer
model.

Time

Decreasing the LCD Brightness

Press the Fn + keys on the keyboard to
decrease the LCD brightness to extend the
battery usage time.

You can only use this function after
installing Windows XP or Windows
7/Vista and installing the

Display Manager

ystem software media disk

s
for Widows 7/Vista

program with the

Easy

.(Only

Using the Battery Calibration
Function

When charging/discharging the battery
repeatedly for a short time only, the battery
usage time may be reduced by the difference
between the actual battery charge and the
remaining charge display.

In this case, the actual battery charge and
the remaining charge display will be the
same by discharging the battery completely
using the Battery Calibration function, and
then recharging it again.

Disconnect the AC power adapter after

1

turning off the computer.

Move to the

3

Calibration

keys and press <

Boot > Smart Battery

item using the direction

Enter

>.

Restart your computer and press the

2

F2

button when the Samsung logo

appears, to start the BIOS Setup.

Highlight

4

Conrmation

<

Enter

The Battery Calibration function is
activated and the battery is forcefully
discharged. To stop the operation, press
the <

This operation requires 3~5 hours
depending on the battery capacity and
the remaining battery charge.

Yes

>.

Esc

> button.

in the

window and press

Battery Calibration

Using the Security Lock Port

You can connect a Kensington lock to the Security Lock port to prevent your computer
from being stolen when you have to use the computer in a public place.

To use this feature, you have to purchase the Kensington lock additionally.
To use the Kensington lock, refer to the product manual.

Tie the Kensington lock cable to a xed object and install the other end of the cable to the

Security Lock port.

Chapter 4.

Appendix

Product Speci cations 82

Product Specications

The system specications may differ depending on the derived models.
For detailed system specications, refer to the product catalogue.

NF108/NF208/NF308

CPU

Main Memory (Optional)

Main Chipset

Hard Disk Drive

Graphics

Operating Environment

Operating Voltage

Frequency

Output Power

Output Voltage

Intel ATOM™ Processor

Memory type: DDR2 SODIMM

DDR3 SODIMM

Intel NM10 Express

7mmH SATA HDD

Intel GMA 3150 (Internal)

Temperature : -5~40°C for storage, 10~32°C when operating

Humidity : 5~90% for storage, 20~80% when operating

100 - 240VAC

50/60Hz

40W

19VDC 2.1A(40W)

 Optional components may not be provided or different components may be provided

depending on the computer model.

 The system specications are subject to change without notice.

Registered Trademarks

Samsung is a registered trademark of Samsung Co., Ltd.

Intel, ATOM/Pentium/Celeron are registered trademarks of the Intel Corporation.

Microsoft, MS-DOS, and Windows are registered trademarks of the Microsoft Corporation.

All other product or company names mentioned herein are registered trademarks of their
respective companies.

ENERGY STAR® Partner

As an ENERGY STAR® Partner, SAMSUNG has determined that this product

meets the ENERGY STAR® guidelines for energy efciency.
