Highlights
Samsung SSD 840 PRO Series
Data Sheet, Rev. 1.2 (August, 2013)
- 2.5” SATA 6Gb/s SSD for Client and Enterprise
computing
- Samsung 3-core MDX controller
- Samsung Toggle DDR 2.0 NAND Flash memory
(2xnm/1xnm)
- Up to 512MB Samsung Low Power DDR2 SDRAM
cache memory
- AES 256-bit Encryption
- Worldwide Name (WWN) and LED Indicator
support
- Magician software for SSD management
- Samsung Data Migration software
- 7mm profile
Unrivaled Performance
The Samsung SSD 840 PRO is a high-performance
SSD designed for power users. Capable of
delivering up to 100,000 IOPS Random Read
Speed and 540MB/s Sequential Read Speed, it is
an SSD of unrivaled high performance. Even better,
the advanced MDX controller delivers these speeds
regardless of data type, unlike some competing
controllers that greatly favor compressible data.
Superior Reliability
As the world’s #1 DRAM, NAND Flash, and SSD
supplier, Samsung has unique, industry-leading
engineering resources, technologies, and
manufacturing processes as well as more stringent
quality and testing standards. All Samsung SSDs
are designed and built completely in-house, rather
than sourcing generic parts from the market. The
Samsung SSD 840 PRO Series is optimized for
exceptional, sustained performance and unrivaled
reliability through its specially-engineered wearleveling and garbage collection algorithms and is
backed by a generous 5-year limited warranty.
Performance Sustainability
The Samsung SSD 840 PRO provides the same
excellent performance throughout its entire
lifetime and under extremely heavy workloads. In
fact, the sophisticated MDX controller is capable of
maintaining peak performance under punishing
conditions for more than twice as long as the
nearest competitor.
1
Business Friendly Features
The 840 PRO Series SSD introduces three
important hardware features for businesses:
Worldwide Name (WWN), LED Indicator support,
and hardware-based AES 256-bit Full Disk
Encryption (FDE). The first two of these features
make it easier to integrate the 840 PRO SSD into
server and storage systems. The third, hardwarebased AES Encryption, helps safeguard data
against attack by encrypting all information on the
disk at the hardware level, which means there is no
detrimental effect on performance. Because the
encryption key is stored on the drive itself, it is not
at risk of interception or outside attack, even if the
drive is placed into a new PC. Also, destroying data
is as easy as performing a Secure Erase using the
Magician software.
In additional to the hardware features mentioned
above, Samsung’s Magician software is being
completely redesigned and will include several
business-friendly new features when version 4.0
becomes available later this year. With the addition
of Drive Health Status, Total Bytes Written (TBW),
and Disk Scan & Error Reporting functionality, it will
be much easier for IT managers to monitor drive
health and plan hardware replacement cycles.
2
Technical Specifications
Samsung SSD 840 PRO Series
Usage Application(s)
Client PCs, Enterprise Computing†
Capacity
128GB, 256GB, 512GB
Dimensions (L x W x H)
100 x 69.85 x 6.8 (mm)
Interface
SATA 6Gb/s (compatible with SATA 3Gb/s and SATA 1.5Gb/s)
Form Factor
2.5-inch
NAND Flash Memory
Samsung Toggle DDR 2.0 NAND Flash Memory (400Mbps, 2xnm/1xnm)
DRAM Cache Memory
256MB (128GB model) or 512MB(256GB & 512GB models) LPDDR2
Performance*
4KB Random Read (QD32):
Max. 100,000 IOPS (256GB/512GB)
Max. 97,000 IOPS (128GB)
4KB Random Write (QD32):
Max. 90,000 IOPS (128GB/256GB/512GB)
4KB Random Read (QD1):
Max. 9,900 IOPS (256GB/512GB)
Max. 9,800 IOPS (128GB)
4KB Random Write (QD1):
Max. 31,000 IOPS (128GB/256GB/512GB)
Sequential Read:
Max. 540 MB/s (256GB/512GB)
Max. 530MB/s (128GB)
Sequential Write:
Max. 520 MB/s (256GB/512GB)
Max. 390 MB/s (128GB)
TRIM Support
Yes (Requires OS Support)
Garbage Collection
Yes
S.M.A.R.T
Yes
Encryption
AES 256-bit Full Disk Encryption (FDE)
Weight
Max. 54g (128GB/256GB/512GB)
Reliability
MTBF: 1.5 million hours
Power Consumption
Average : 0.069W ** (Typical)
Idle : 0.054W (Typical, DIPM ON), 0.349W (Typical, DIPM OFF)
Temperature
Operating:
Non-Operating:
0°C to 70°C
-55°C to 95°C
Humidity
5% to 95%, non-condensing
Vibration
Non-Operating:
20 ~ 2000Hz, 20G
Shock
1500G & 0.5ms (Half sine)
Warranty
5 years limited (client PC use only)***
System Configuration : Intel Core i7-3770 @ 3.4GHz, 4GB DDR3 SDRAM (2GBx2) 1333Mbps; Asus motherboard with Intel 7 Series Z77
†
For enterprise usage (e.g. servers), a minimum of 6.7% over-provisioning (OP) is recommended.
* Sequential performance measurements based on CrystalDiskMark v.3.0.1. Random performance measurements based on
Iometer 2010. Performance may vary based on SSD’s firmware version, system hardware & configuration
** Power consumption measured with MobileMark 2007 in Windows 7. Values calculated using laptop PC and represent system-level
power consumption.
*** For enterprise applications, 5 years limited warranty assumes a maximum average workload of 40GB/day (calculated based on host
writes and on the industry standard of 3-month data retention). Workloads in excess of 40GB/day are not covered under warranty.
Chipset, Windows 7 Ultimate x64 SP1; IRST 11.2, MS performance guide pre-condition.
3
Product Lineup
Density
Model Name
Box Contents
Model Code
128 GB
MZ-7PD128
Drive only
MZ-7PD128BW
Bulk
MZ-7PD128Z
256 GB
MZ-7PD256
Drive only
MZ-7PD256BW
Bulk
MZ-7PD256Z
512 GB
MZ-7PD512
Drive only
MZ-7PD512BW
Bulk
MZ-7PD512Z
Contents
Drive Only
Bulk
Samsung software & manual CD
N/A
SSD Installation Guide (Printed)
N/A
Contents
For more information, please visit www.samsung.com/ssd.
To download the latest software & manuals, please visit www.samsung.com/samsungssd
DISCLAIMER
SAMSUNG ELECTRONICS RESERVES THE RIGHT TO
CHANGE PRODUCTS, INFORMATION AND
SPECIFICATIONS WITHOUT NOTICE.
Products and specifications discussed herein are
for reference purposes only. All information
discussed herein may change without notice and
is provided on an “AS IS” basis, without warranties
of any kind. This document and all information
discussed herein remain the sole and exclusive
property of Samsung Electronics. No license of any
patent, copyright, mask work, trademark or any
other intellectual property right is granted by one
party to the other party under this document, by
implication, estoppels or otherwise. Samsung
products are not intended for use in life support,
critical care, medical, safety equipment, or similar
applications where product failure could result in
loss of life or personal or physical harm, or any
military or defense application, or any
governmental procurement to which special terms
or provisions may apply. For updates or additional
information about Samsung products, contact
your nearest Samsung office.
COPYRIGHT © 2013
This material is copyrighted by Samsung
Electronics. Any unauthorized reproductions, use
or disclosure of this material, or any part thereof, is
strictly prohibited and is a violation under
copyright law.
TRADEMARKS & SERVICE MARKS
The Samsung Logo is the trademark of Samsung
Electronics. Adobe is a trademark and Adobe
Acrobat is a registered trademark of Adobe
Systems Incorporated. All other company and
product names may be trademarks of the
respective companies with which they are
associated.
