SAMSUNG MCD-CM600B Service Manual Part List
Samsung Electronics2-1
****** MCD-CM600 Parts List ******
4302-001087 BATTERY-NIH(2ND);1.2V,1350MAH,RECTANGULA
6801-001066 CARD-REGISTRATION;RUSSIA,CIS(RUSSIA),RUS
6902-000384 BAG PE;LDPE,T0.02,W200,L200,TRP,-,1PE
AH30-00056A PHONE-EAR;LIGHT GRAY,EP-150,16 OHM,1100M
AH41-00667A FPC;MCD-CM600,0,PCB,10,0.3,AH44-00023H ADAPTOR;-,-,230V,50HZ,4.5VDC+/-0.3V,0.
AH46-00029A DISC;120MM,-,CD,MCD-CM600
AH59-01105C DECK-SLIM DECK;KSM1000BAC,MCD-CM600,BALL
AH59-01224D REMOCON-ASS’Y;MCD-CM600S,SAMSUNG,
AH59-01224E REMOCON-ASS’Y;MCD-CM600W,SAMSUNG,
AH59-01224F REMOCON-ASS’Y;MCD-CM600B,SAMSUNG,
AH61-01426A BASE-BATT ASSY;MCD-CM600,ASS’Y,-,-,-,-,-
AH92-01922A ASSY PCB-MAIN(MOT);MCD-CM600,ASS’Y MAIN(
SW302 3409-001081 SWITCH-DETECTOR;12V DC,0.1A,SPST,30gf,PU
JK900 3722-002046 JACK-DC POWER;3P+2P,4.4/2.6PI,AU,BLACK
AH94-01266A ASSY CHIP-MAIN,(MOT);MCD-CM600,MAIN CHIP
D502 0401-001090 DIODE-SWITCHING;1SS355,80V,100MA,SOD-323
D503 0401-001090 DIODE-SWITCHING;1SS355,80V,100MA,SOD-323
D900 0401-001090 DIODE-SWITCHING;1SS355,80V,100MA,SOD-323
D901 0401-001090 DIODE-SWITCHING;1SS355,80V,100MA,SOD-323
D201 0401-001090 DIODE-SWITCHING;1SS355,80V,100MA,SOD-323
D202 0401-001090 DIODE-SWITCHING;1SS355,80V,100MA,SOD-323
D300 0401-001090 DIODE-SWITCHING;1SS355,80V,100MA,SOD-323
D501 0401-001090 DIODE-SWITCHING;1SS355,80V,100MA,SOD-323
ZD901 0403-001306 DIODE-ZENER;MMGDZ3.0B,3.01-3.22V,500MW,L
D702 0404-000145 DIODE-SCHOTTKY;SB07-03C,30V,700MA,SOT-23
D701 0404-000145 DIODE-SCHOTTKY;SB07-03C,30V,700MA,SOT-23
D700 0404-000145 DIODE-SCHOTTKY;SB07-03C,30V,700MA,SOT-23
Q713 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,
Q711 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,
Q708 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,
Q100 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,
Q903 0501-000528 TR-SMALL SIGNAL;KSC2982B,NPN,500mW,SOT-8
Q900 0501-000632 TR-SMALL SIGNAL;2SB1197K,PNP,200mW,SOT-2
Q706 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
Q702 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
Q103 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
Q101 0504-000128 TR-DIGITAL;-,NPN,200MW,22K/22K,SOT-23,TP
Q712 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
Q709 0504-000156 TR-DIGITAL;KSR2103,PNP,200MW,22K/22K,SOT
Q704 0505-001424 FET-SILICON;2SK3065,N,30V,2A,0.45ohm,0.5
Q700 0505-001424 FET-SILICON;2SK3065,N,30V,2A,0.45ohm,0.5
Q902 0505-001426 FET-SILICON;IRLML6401,P,-12V,-4.3A,0.05o
Q901 0505-001426 FET-SILICON;IRLML6401,P,-12V,-4.3A,0.05o
Q707 0505-001426 FET-SILICON;IRLML6401,P,-12V,-4.3A,0.05o
Q102 0505-001426 FET-SILICON;IRLML6401,P,-12V,-4.3A,0.05o
Q701 0505-001426 FET-SILICON;IRLML6401,P,-12V,-4.3A,0.05o
Q705 0505-001426 FET-SILICON;IRLML6401,P,-12V,-4.3A,0.05o
IC502 0801-002870 IC-CMOS LOGIC;TC75S57F,BUFFER,SSOP,5P,2.
IC301 0904-001691 IC-DSP;SCF5249LPV120,16BIT,TQFP,144P,
IC201 0904-001799 IC-DSP;CXD3048R,8BIT,LQFP,120P,16.0X1
IC701 1003-001629 IC-MOTOR DRIVER;BH6570KV,VQFP,48P,7,-,-,
IC501 1003-001630 IC-MOTOR DRIVER;TB2127AFN,SSOP,24P,5.6,IC401 1105-001535 IC-DRAM;M12L128168A-7T,4X2MX16BIT,TSOP
IC402 1107-001257 AC-FLASH MEMORY;39VF160,1Mx16Bit,TSOP,48
IC101 1201-002038 IC-RF AMP;CXA2647N,SSOP,30P,9.7X5.6MM,-,
IC601 1201-002039 IC-POWER AMP;TA2152FN,SSOP,24P,7.8X5.6MM
IC304 1202-001067 IC-VOLTAGE COMP.;NJM2901,SSOP,14P,5X4.4M
IC702 1203-002175 IC-DC/DC CONVERTER;6367,SOT-25,5P,63MIL,
IC703 1203-002394 IC-DC/DC CONVERTER;XC6367,SOT-25,5P,-,PL
IC303 1203-003024 IC-VOL.DETECTOR;XC61CC,SOT-23,3P,2.9X1.
IC704 1203-003025 IC-DC/DC CONVERTER;XC6365,SOT-25,5P,2.9X
L203 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012
R604 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608
R605 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608
R118 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R117 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608
R219 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608
R218 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R208 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608
R340 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R339 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R338 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R329 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R328 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R353 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R352 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R351 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R350 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R343 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R327 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R304 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R303 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R302 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R216 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R215 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R326 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R325 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R324 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R307 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R305 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608
R719 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R717 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R707 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R720 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R901 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R902 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R506 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R210 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R214 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R308 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R321 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R344 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R348 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608
R712 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608
R323 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R504 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R606 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R607 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R708 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R710 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R322 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R205 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R209 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R309 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R317 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R318 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R320 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608
R110 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R108 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R106 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608
R716 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R609 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R608 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R332 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R102 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R103 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R111 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608
R505 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608
R330 2007-000101 R-CHIP;82Kohm,5%,1/10W,TP,1608
R335 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R356 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R355 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R354 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R346 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R345 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R908 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R611 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R610 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R403 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R401 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R319 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R311 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R310 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R201 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R104 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R342 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R341 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R336 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R334 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R333 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608
R204 2007-000104 R-CHIP;150Kohm,5%,1/10W,TP,1608
R109 2007-000104 R-CHIP;150Kohm,5%,1/10W,TP,1608
R107 2007-000104 R-CHIP;150Kohm,5%,1/10W,TP,1608
R711 2007-000107 R-CHIP;470Kohm,5%,1/10W,TP,1608
R709 2007-000107 R-CHIP;470Kohm,5%,1/10W,TP,1608
R613 2007-000107 R-CHIP;470Kohm,5%,1/10W,TP,1608
R502 2007-000107 R-CHIP;470Kohm,5%,1/10W,TP,1608
R217 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R207 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R203 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608
R344 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608
R100 2007-000115 R-CHIP;82ohm,5%,1/10W,TP,1608
R115 2007-000121 R-CHIP;820ohm,5%,1/10W,TP,1608
R906 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
R113 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608
Location no Code no. Description; Specification Remarks
Location no
Code no. Description; Specification Remarks
2. Electrical Parts List
*S.N.A. : Service Not Available
R112 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R114 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608
R907 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R601 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R600 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608
R116 2007-000125 R-CHIP;3.9Kohm,5%,1/10W,TP,1608
R501 2007-000132 R-CHIP;180Kohm,5%,1/10W,TP,1608
R211 2007-000132 R-CHIP;180Kohm,5%,1/10W,TP,1608
R206 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608
R202 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
R503 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608
R101 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608
R904 2007-000310 R-CHIP;10OHM,5%,1/2W,DA,TP,5025
R910 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
R909 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608
R337 2007-000563 R-CHIP;220Kohm,1%,1/10W,TP,1608
R905 2007-000637 R-CHIP;270Kohm,5%,1/10W,TP,1608
R706 2007-000637 R-CHIP;270Kohm,5%,1/10W,TP,1608
R704 2007-000637 R-CHIP;270Kohm,5%,1/10W,TP,1608
R703 2007-000637 R-CHIP;270Kohm,5%,1/10W,TP,1608
R119 2007-000637 R-CHIP;270Kohm,5%,1/10W,TP,1608
R705 2007-000819 R-CHIP;390Kohm,5%,1/10W,TP,1608
R105 2007-001161 R-CHIP;75Kohm,5%,1/10W,TP,1608
R700 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608
C303 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C205 2203-000236 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1608
C331 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C330 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C210 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C207 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608
C211 2203-000357 C-CER,CHIP;0.15NF,5%,50V,C0G,TP,1608
C505 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,C504 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,C503 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,C103 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,TP,1608,FREE 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,C601 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,C600 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,C336 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,C201 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1608,C227 2203-000592 C-CER,CHIP;0.22NF,5%,50V,C0G,TP,1608
C226 2203-000592 C-CER,CHIP;0.22NF,5%,50V,C0G,TP,1608
C225 2203-000592 C-CER,CHIP;0.22NF,5%,50V,C0G,TP,1608
C703 2203-000604 C-CER,CHIP;22nF,10%,25V,X7R,TP,1608
C108 2203-000604 C-CER,CHIP;22nF,10%,25V,X7R,TP,1608
C118 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1608
C716 2203-001071 C-CER,CHIP;0.056NF,5%,50V,C0G,TP,1608
C506 2203-001103 C-CER,CHIP;6.8nF,10%,50V,X7R,TP,1608,C229 2203-001628 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1608
C230 2203-001628 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1608
C613 2203-001630 C-CER,CHIP;330nF,+80-20%,16V,Y5V,TP,1608
C612 2203-001630 C-CER,CHIP;330nF,+80-20%,16V,Y5V,TP,1608
C213 2203-001630 C-CER,CHIP;330nF,+80-20%,16V,Y5V,TP,1608
C212 2203-001630 C-CER,CHIP;330nF,+80-20%,16V,Y5V,TP,1608
C206 2203-001652 C-CER,CHIP;470nF,+80-20%,16V,Y5V,TP,1608
C702 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C204 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C110 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C109 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C107 2203-001656 C-CER,CHIP;0.47nF,5%,50V,NP0,TP,1608
C508 2203-001683 C-CER,CHIP;0.068nF,5%,50V,NP0,TP,1608
C113 2203-001697 C-CER,CHIP;0.082nF,5%,50V,NP0,TP,1608
C405 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C406 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C407 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C408 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C404 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C403 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C402 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C334 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C409 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C905 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C700 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C620 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C618 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C606 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C511 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C502 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C410 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C221 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C215 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C121 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C119 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C115 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C112 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C101 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C228 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C322 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C321 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C317 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C315 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C305 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C309 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C311 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C313 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,TP,1608
C507 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C327 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C326 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C314 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C510 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C512 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C609 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C621 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C701 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C302 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C203 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C208 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C209 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C214 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C219 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C301 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C224 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C223 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C222 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,TP,160
C704 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,TP,3216,C328 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C329 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C401 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C607 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C610 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C615 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C616 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C106 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C111 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C202 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C217 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C220 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C318 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C319 2404-000361 C-TA,CHIP;22uF,20%,4V,GP,TP,3216,C605 2404-000367 C-TA,CHIP;4.7uF,20%,6.3V,-,-,3216
C604 2404-000367 C-TA,CHIP;4.7uF,20%,6.3V,-,-,3216
C509 2404-000367 C-TA,CHIP;4.7uF,20%,6.3V,-,-,3216
C903 2404-001024 C-TA,CHIP;100uF,20%,16V,-,TP,7343H,C900 2404-001024 C-TA,CHIP;100uF,20%,16V,-,TP,7343H,C335 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C411 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C617 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C705 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C708 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C713 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C100 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C102 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C105 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C123 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C117 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C114 2404-001293 C-TA,CHIP;100UF,20%,6.3V,WT,TP,3528
C714 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C717 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C718 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C719 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C901 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C902 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C904 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C711 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C218 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C501 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C611 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C614 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C709 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C706 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
C619 2404-001303 C-TA,CHIP;220UF,20%,4V,WT,TP,6032
L610 2703-000001 INDUCTOR-SMD;10uH,10%,3225
L601 2703-000001 INDUCTOR-SMD;10uH,10%,3225
L600 2703-000001 INDUCTOR-SMD;10uH,10%,3225
L202 2703-000001 INDUCTOR-SMD;10uH,10%,3225
L201 2703-000001 INDUCTOR-SMD;10uH,10%,3225
L101 2703-000001 INDUCTOR-SMD;10uH,10%,3225
L100 2703-000001 INDUCTOR-SMD;10uH,10%,3225
L706 2703-000002 INDUCTOR-SMD;100uH,10%,3225
L702 2703-000002 INDUCTOR-SMD;100uH,10%,3225
L705 2703-001020 INDUCTOR-SMD;47uH,20%,7070
L701 2703-001020 INDUCTOR-SMD;47uH,20%,7070
X201 2802-001218 RESONATOR-CERAMIC;16.934MHZ,0.1%,TP,2.5X
B602 3301-000353 BEAD-SMD;120ohm,2x1.25x0.9mm,200mA,TP,,
B601 3301-000353 BEAD-SMD;120ohm,2x1.25x0.9mm,200mA,TP,,
B608 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
B609 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
B610 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
B613 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
B607 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
B603 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
B604 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
B605 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
B606 3301-001643 BEAD-SMD;-,1500,-,50,TP,-,0.8
SW301 3408-001038 SWITCH-SLIDE;4V,300mA,SPST,ON-ON,-
Location no Code no. Description; Specification Remarks Location no Code no. Description; Specification Remarks
2-2Samsung Electronics
Loading...
