Samsung LE37A556, LE40A556, LE46A557, LE37A557, LE32A557 User Manual

...

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.

Country

EIRE 0818 717 100 www.samsung.com/ie U.K 0845 SAMSUNG (7267864) www.samsung.com

Customer Care Centre

Web Site

LCD TV

user manual

BN68-01409D-00

imagine the possibilities

Thank you for purchasing this Samsung product. To receive more complete service, please register your product at

www.samsung.com/global/register

Model Serial No.

Precautions When Displaying a Still Image

A still image may cause permanent damage to the TV screen.

WARNINGS:

Image retention, commonly known as screen burn-in, can occur on most types of television if the same image is displayed continuously. The most common causes of image retention are logos that remain stationary on the TV screen. These logos are common on many programmes received via a Setop Box. To reduce this risk, avoid displaying still images for long durations and lower the brightness or contrast settings to decrease the intensity of the picture. Extended viewing of movies and programs in aspect ratios that are different from the aspect ratio of the TV may cause image retention. Always endeavour to avoid black borders top or bottom by using the zoom function. This will help eliminate the black

borders and t the picture to the entire area of the screen. Using a video game console may cause

image retention and is not recommended. When using a PC input, avoid displaying still images for long durations and reduce the brightness or contrast settings to decrease the intensity of the picture.

IMPORTANT:

Image retention issues are not covered by your Samsung® warranty.

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. (See back cover for more informations.)

Precautions When Displaying a Still Image

A still image may cause permanent damage to the TV screen.

Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image

• retention. This image retention is also known as "screen burn". To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image.

Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders

•

caused by the above effect are not covered by the Warranty.

Displaying still images from Video games and PC for longer than a certain period of time may produce

• partial after-images. To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.

displayed on the left, right and center of the screen caused by the difference of light emission on the screen. Playing a DVD or a game console may cause a similar effect to the screen. Damages

Contents

CONNECTING AND PREPARING YOUR TV

List of Parts ........................................................ 3



Installing the Stand ............................................. 3



Installing the Wall Mount Kit ............................... 3



Viewing the Control Panel .................................. 4



Viewing the Connection Panel ........................... 5



Viewing the Remote Control ............................... 8



Installing Batteries in the Remote Control .......... 9



Switching On and Off ......................................... 9



Placing Your Television in Standby Mode........... 9



Viewing the Menus ........................................... 10



Using the TOOLS Button .................................. 10



Plug & Play ........................................................11



SETTING THE CHANNELS

Storing Channels Automatically ....................... 12



Storing Channels Manually .............................. 13



Adding / Locking Channels .............................. 14



Sorting the Stored Channels ............................ 15



Assigning Channels Names ............................. 15



Fine Tuning Channel Reception ....................... 16



LNA (Low Noise Amplier) ............................... 16



SETTING THE PICTURE

Changing the Picture Standard ........................ 17



Adjusting the Custom Picture ........................... 18



Conguring Detailed Settings on the Picture ... 18



Resetting the Picture Settings to the Factory



Defaults ............................................................ 19

Conguring Picture Option ............................... 20



Viewing the Picture In Picture (PIP) ................. 22



SETTING THE SOUND

Sound Features ................................................ 23



Selecting the Sound Mode ............................... 24



Connecting Headphones (Sold separately) ..... 24



FUNCTION DESCRIPTION

Choosing Your Language ................................. 26



Setting the Light Effect



(depending on the model) ................................ 27

Melody / Entertainment / Energy Saving ......... 27



Selecting the Source ........................................ 29



Editing the Input Source Names ...................... 29



USING THE DTV FEATURE

Previewing the DTV Menu System .................. 30



Updating the Channel List Automatically .......... 31



Updating the Channel List Manually ................ 31



Editing Your Favourite Channels ...................... 32



Selecting Channel List ..................................... 34



Displaying Programme Information .................. 34



Viewing the EPG (Electronic Programme Guide)



Information ....................................................... 35

Using the Scheduled List ................................. 36



Setting the Default Guide ................................. 36



Viewing All Channels and Favourite Channels 37



Adjusting the Menu Transparency .................... 37



Setting up the Parental Lock ............................ 38



Setting the Subtitle ........................................... 39



Setting the Subtitle Mode ................................. 39



Selecting the Audio Format .............................. 39



Selecting the Audio Description ....................... 40



Selecting the Digital Text (UK only) .................. 40



Selecting the Time Zone (Spain only) .............. 41



Viewing Product Information ............................ 41



Checking the Signal Information ...................... 42



Upgrading the Software ................................... 42



Viewing Common Interface .............................. 43



Selecting the CI (Common Interface) Menu ..... 43



Resetting .......................................................... 44



Selecting the Preferred Language



(Subtitle , Audio or Teletext) ............................. 44

Preference ........................................................ 45



SETTING THE TIME

Setting and Displaying the Current Time .......... 25



Setting the Sleep Timer .................................... 25



Switching the Television On and Off



Automatically .................................................... 26

English - 1

SETTING THE PC

Setting up Your PC Software



(Based on Windows XP) .................................. 46

Display Modes .................................................. 46



Setting up the TV with your PC ........................ 47



WISELINK

Using the WISELINK Function ......................... 48



Using the WISELINK Menu .............................. 49



Using the PHOTO (JPEG) List ......................... 50



Using the MP3 List ........................................... 53



Using the Setup Menu ...................................... 54



RECOMMENDATIONS FOR USE

Teletext Feature ............................................... 61



Auto Wall-Mount (Sold separately) ................... 63



Using the Anti-Theft Kensington Lock



(depending on the model) ................................ 64

Troubleshooting: Before Contacting Service



Personnel ......................................................... 65

Technical and Environmental Specications ... 66



Warning! Important Safety Instructions



Wiring the Mains Power Supply Plug (UK Only)



Warranty Card



ABOUT ANYNET

What is Anynet+? ............................................ 55



Connecting Anynet+ Devices ........................... 55



Setting Up Anynet+ .......................................... 56



Scanning and Switching between Anynet+



Devices ............................................................ 57

Recording ......................................................... 59



Listening through a Receiver ........................... 59



Check Points before Requesting Service ......... 60



Symbol Press Note One-Touch

English - 2

Button

List of Parts

Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer.

M4 X L16

Remote Control

& Batteries

(AAA x 2)

Registration Cards (Not available in all locations)

➣

Power Cord Cover-Bottom

Owner’s Instructions

•

Stand Screw

X 4

Stand Cleaning Cloth

Registration Cards

•

Installing the Stand

1. Connect your LCD TV and the stand. Two or more people should carry the TV.

➣

Make sure to distinguish between the front and back of the stand when assembling them.

➣

2. Fasten two screws at position 1 and then fasten two screw at position 2. Stand the product up and fasten the screws. If you fasten the screws with the LCD TV placed

➣

down, it may lean to one side. The stand is installed for models with the screen size of 37 inch and above.

➣

Installing the Wall Mount Kit

Wall mount items (sold separately) allow you to mount the TV on the wall. For detailed information on installing the wall mount, see the instructions provided with the Wall Mount items. Contact a technician for assistance when installing the wall mounted bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.

➣

English - 3

Do not install your Wall Mount Kit while your TV is turned on. It may result in personal injury due to

electric shock. Remove the stand and cover the bottom hole with a cap and fasten with two screws.

Viewing the Control Panel

8 8

5 6

58 8

Front Panel buttons Touch each button to operate.

Side Panel buttons

The product colour and shape may vary depending on the model.

➣

SOURCE

Toggles between all the available input sources (TV, Ext.1, Ext.2, AV, S-Video, Component, PC, HDMI1, HDMI2, HDMI3, DTV). In the on-screen

menu, use this button as you use the

ENTER

button on the remote control.

Press to see an on-screen menu of your TV’s features.

Press to decrease or increase the volume. In the on-screen menu, use the buttons as you

use the ◄ and ► buttons on the remote control.

Press to change channels. In the on-screen menu, use the buttons as you use the ▼ and ▲ buttons on the remote control. (Without the Remote Control, you can turn on the TV by using the Channel buttons.)

English - 4

Power Indicator

Blinks and turns off when the power is on and lights up in stand-by mode.

(Power)

Press to turn the TV on and off.

Remote Control Sensor

Aim the remote control towards this spot on the TV.

Speakers

Viewing the Connection Panel

1 2 3 4 5

[Side Panel Jacks]

Power Input

The product colour and shape may vary depending on the model.

Whenever you connect an external device to your TV, make sure that power on the unit is turned off

➣

When connecting an external device, match the colour of the connection terminal to the cable.

➣

1 PC IN [PC] / [AUDIO]

Connect to the video and audio output jack on your PC.

2 COMPONENT IN

Connect component video cables (optional) to component connector ("PR", "PB", "Y") on the rear of

your set and the other ends to corresponding component video out connectors on the DTV or DVD. If you wish to connect both the Set-Top Box and DTV (or DVD), you should connect the Set-Top Box

to the DTV (or DVD) and connect the DTV (or DVD) to component connector ("PR", "PB", "Y") on your set. The PR, PB and Y connectors on your component devices (DTV or DVD) are sometimes labeled Y,

B-Y and R-Y or Y, Cb and Cr. Connect RCA audio cables (optional) to "R - AUDIO - L" on the rear of your set and the other ends to

corresponding audio out connectors on the DTV or DVD.

3 HDMI IN 1, HDMI IN 2, HDMI IN 3

Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players)

No additional Audio connection is needed for an HDMI to HDMI connection.

When using an HDMI/DVI cable connection, you must use the HDMI IN 2 jack.

!@#

English - 5

What is HDMI?

➣

“High Denition Multimedia interface” allows the transmission of high denition digital video data

and multiple channels of digital audio.

The HDMI/DVI terminal supports DVI connection to an extended device with the appropriate

cable (not supplied). The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth Digital Copy Protection) coding feature installed, and supports multi - channel digital audio.

The TV may not output sound and pictures may be displayed with abnormal colour when DVD

➣

players/Cable Boxes/Satellite receivers supporting HDMI versions older than 1.3 are connected. When connecting an older HDMI cable and there is no sound, connect the HDMI cable to the HDMI IN 2 jack and the audio cables to the DVI IN (HDMI2) [R-AUDIO-L] jacks on the back of the TV. If this happens, contact the company that provided the DVD player/Cable Box/Satellite

receiver to conrm the HDMI version, then request a rmware update. HDMI cables that are not

1.3 may cause annoying icker or no screen display.

DVI IN(HDMI2) [R-AUDIO-L]

DVI audio outputs for external devices.

Supported modes for HDMI/DVI and Component

➣

HDMI/DVI 50Hz X X X O O O O HDMI/DVI 60Hz X O X X O O O

Component O O O O O O O

4 ANT IN

To view television channels correctly, a signal must be received by the set from one of the following sources:

An outdoor aerial / A cable television network / A satellite network

5 SERVICE

Connect this to the jack on the optional wall mount bracket. This will allow you to adjust the TV viewing angle using your remote control.

6 COMMON INTERFACE Slot

When not inserting "CI CARD" in some channels,"Scrambled Signal" is displayed on the screen.

The pairing information containing a telephone number, CI CARD ID, Host ID and other information

will be displayed in about 2~3 minutes. If an error message is displayed, please contact your service provider.

When the channel information conguration has nished, the

message "Updating Completed" is displayed, indicating that the channel list is now updated.

You must obtain a CI CARD from a local cable service

➣

provider. Remove the CI CARD by carefully pulling it out with your hands since dropping the CI CARD may cause damage to it. Insert the CI-Card in the direction marked on it.

➣

The place of the COMMON INTERFACE Slot may be different depending on its model.

➣

7 WISELINK

Connect a USB mass storage device to view photo les (JPEG) and play audio les (MP3)

480i 480p 576i 576p 720p 1080i 1080p

English - 6

8 S-VIDEO or VIDEO / R-AUDIO-L

Connect RCA or S-VIDEO cable to an appropriate external A/V device such as VCR, DVD or

Camcorder. Connect RCA audio cables to "R-AUDIO-L" on your set and the other ends to corresponding audio

out connectors on the A/V device.

9 Headphones jack

Headphone may be connected to the headphone output on your set. While the head phone is

connected, the sound from the built-in speakers will be disabled.

0 AUDIO OUT [R-AUDIO-L]

Connect RCA audio cables to AUDIO OUT [R-AUDIO-L] on the rear of your set and the other ends to

corresponding audio in connectors on the Amplier or DVD Home Theatre.

! DIGITAL AUDIO OUT (OPTICAL)

Connect to a Digital Audio Component.

When the HDMI IN jacks are connected, the DIGITAL AUDIO OUT (OPTICAL) jack on the TV

➣

outputs 2 channel audio only. If you want to hear 5.1 channel audio, connect the Optical jack on

the DVD player or Cable/Satellite Box directly to an Amplier or Home Theater, not the TV.

@ EXT 1, EXT 2

Connector

EXT 1 O O O Only TV or DTV output is available. EXT 2 O O Output you can choose.

Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players.

Video Audio (L/R) RGB Video + Audio (L/R)

Input Output

# Kensington Lock (depending on the model)

The Kensington lock (optional) is a device used to physically x the system when used in a public

place.

If you want to use a locking device, contact the dealer where you purchased the TV.

The location of the kensington lock may be different depending on its model.

English - 7

Viewing the Remote Control

1 Television Standby button

2 Selects the TV and DTV

mode directly

3 Number buttons for directNumber buttons for direct

channel access

4 One/Two-digit channel

selection

5 +: Volume increase

-: Volume decrease 6 Temporary sound switch-Temporary sound switch-

off

7 Electronic Program GuideElectronic Program Guide

(EPG) display

8 Use to quickly selectUse to quickly select

frequently used functions.

9 Use to see information onUse to see information on

the current broadcast

0 Colour buttons :Colour buttons :

Use these buttons in the Channel list and WISELINK, etc.

@ Press to select the optionalPress to select the optional

display and sound modes for sports, cinema and games.

# Use these buttons in the

DMA, WISELINK, and Anynet+. ( : This remote can be used to control recording on Samsung recorders with the Anynet+ feature)

$ Available source selectionAvailable source selection % Previous channel ^ P<: Next channel

P>: Previous channel & Displays the main on-Displays the main on-

screen menu

* This function enables youThis function enables you

to view and play photo and music files from an external device.

( Returns to the previousReturns to the previous

) Control the cursor in theControl the cursor in the

a Exit the on-screen menuExit the on-screen menu b Use this when connecting

a SAMSUNG DMA (Digital Media Adapter) device through an HDMI interface and switching to DMA mode. (The DMA button is optional.) For more information on the operating procedures, refer to the user manual of the DMA. This button is available when “Anynet+(HDMI-CEC)" is

“On” (see page 56)

c Picture size selectionPicture size selection d Digital subtitle displayDigital subtitle display e It display "Channel List"It display "Channel List"

on the screen.

Teletext Functions

2 Exit from the teletext display

7 Teletext store

8 Teletext size selection

9 Teletext reveal

0 Fastext topic selection

! Alternately select Teletext,

Double, or Mix.

$ Teletext mode selection (LIST/FLOF)

% Teletext sub page

^ P<: Teletext next page

P>: Teletext previous page

& Teletext index

( Teletext hold

a Teletext cancel

The performance of the remote control may be affected by bright light.

➣

English - 8

Installing Batteries in the Remote Control

1. Lift the cover at the back of the remote control upward as shown in the

gure.

2. Install two AAA size batteries. Make sure to match the "+" and "–" ends of the batteries with the

➣

diagram inside the compartment.

3. Replace the cover. Remove the batteries and store them in a cool, dry place if you won’t be

➣

using the remote control for a long time.

If the remote control doesn’t work, check the following:

➣

1. Is the TV power on?

2. Are the plus and minus ends of the batteries reversed?

3. Are the batteries drained?

4. Is there a power outage, or is the power cord unplugged?

5. Is there a special uorescent light or neon sign nearby?

Switching On and Off

The mains lead is attached to the rear of your set.

1. Plug the mains lead into an appropriate socket.

The standby indicator lights up

➣

2. Press the P button You also can press the POWER button or the TV/DTV button on the remote control to turn

➣

the TV on. The programme that you were watching last is reselected automatically.

➣

3. Press the numeric button (0~9) or channel up/down (</>) button on the remote control or

button

on your set.

When you switch the set on for the very rst time, you will be asked to choose language in which the

➣

menus are to be displayed.

4. To switch your set off, press the POWER button again.

on your set.

Placing Your Television in Standby Mode

Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when you wish to interrupt viewing temporarily (during a meal, for example).

1. Press the POWER button on the remote control.

The screen is turned off and a red standby indicator appears on your set.

➣

2. To switch your set back on, simply press the POWER , numeric buttons (0~9), TV/DTV button or

channel up/down (</>) button again.

Do not leave your set in standby mode for long periods of time (when you are away on holiday, for

➣

example). It is best to unplug the set from the mains and aerial.

English - 9

Viewing the Menus

1. With the power on, press the MENU button.

The main menu appears on the screen. The menu’ s left side has

icons: Picture, Sound, Channel, Setup, Input, Digital Menu.

2. Press the ▲ or ▼ button to select one of the icons.

Then press the

ENTER

button to access the icon’s sub-menu.

3. Press the EXIT button to exit. The on-screen menus disappear from the screen after about

➣

one minute.

Using the TOOLS Button

You can use the TOOLS button to select your frequently used functions quickly and easily. The “Tools” menu change depending on which external input mode you are viewing.

1. Press the TOOLS button.

The “Tools” menu will appear.

2. Press the ▲ or ▼ button to select a menu.

3. Press the ▲/▼/◄/►/

use the selected items. For a more detailed description of each function, refer to the corresponding page.

Anynet+ (HDMI-CEC), see page 56

♦

Picture Mode, see page 17

♦

Sound Mode, see page 23

♦

Sleep Timer, see page 25

♦

SRS TS XT, see page 23

♦

Energy Saving, see page 28

♦

Dual l-ll, see page 24

♦

PIP, see page 22

♦

Auto Adjustment, see page 47

♦

ENTER

buttons to display, change, or

Mode : Standard  Backlight 7 Contrast 95 Brightness 45 Sharpness 50 Colour 50

Tint G50 R50

Detailed Settings  sMore

Move Enter Return

Anynet+ (HDMI-CEC) Picture Mode : Standard Sound Mode : Custom Sleep Timer : Off SRS TS XT : Off Energy Saving : Off Dual l-ll : Mono

Move Enter Exit


Tools

English - 10

Plug & Play

When the TV is initially powered on, several basic settings proceed automatically and subsequently. The following settings are available.

The Screen Saver is activated if there is no remote control key

➣

input for longer than 1 minute while "Plug & Play" is running. The Screen Saver is activated if there is no operating signal for

➣

longer than 15 minutes. Any functions related to Digital TV (DVB) will only work in

➣

countries or areas where DVB-T (MPEG2) digital terrestrial

signals are broadcasted. Please conrm with your local dealer if you can receive DVB-T signals. Although this TV set follows the DVB-T specication, maintaining compatibility with the future coming

DVB-T digital terrestrial broadcasts is not guaranteed. Several functions may not be available in some countries.

1. Press the POWER button on the remote control.

The message "Start Plug & Play" is displayed with "OK" selected.

2. Select the appropriate language by pressing the ▲ or ▼ button.

Press the

3. Press the ◄ or ► button to select “Store Demo” or “Home Use”, then the

➣

➣ ➣

4. The message "Check antenna input." is displayed with "OK" selected.

Press the

➣

5. Select the appropriate country by pressing the▲ or ▼ button.

Press the

6. The message “Some DTV functions may not be available. Digital Scan?” is displayed.

Press the ◄ or ► button to select “Yes” or “No”, then press the

♦ ♦

➣

The "Auto Store" menu is displayed with the "Start" selected. Press the

➣

➣ ➣

8. Press the

Select the "Month", "Day", "Year", "Hour", or "Minute" by pressing the ◄ or ► button. Set the "Month", "Day", "Year", "Hour", or "Minute" by pressing the ▲ or ▼ button.

➣

ENTER

We recommend setting the TV to "Home Use" mode for the best picture in your home environment. "Store Demo" mode is only intended for use in retail environments. If the unit is accidentally set to “Store Demo” mode and you want to return to “Home Use” (Standard): Press the Volume button on the TV. When the volume OSD is displayed, press and hold the MENU button on the TV for 5 seconds.

ENTER

Please check that the antenna cable is connected correctly.

ENTER

Yes: First an ATV search is performed and then a DTV ch. auto search is performed. No: Only an ATV search is performed.

This function is supported for all countries except for the following countries: France, Germany, Italy, Netherlands, Spain, Switzerland, United Kingdom, Austria.

The channel search will start and end automatically. The DTV channel scan menu appears and the DTV channel is automatically updated. If the DTV channel is updated, the Source in the source list of the Input menu is automatically changed to DTV.

Press the For detailed descriptions about DTV channel update, refer to page 31 of this manual. After all the available digital channels are stored, the screen to select a time zone is displayed depending on the country.

ENTER

You can also set the “Month”, “Day”, “Year”, “Hour” and "Minute" by pressing the number buttons on the remote control.

button to conrm your choice.

button.

button to conrm your choice.

ENTER

After all the available channels are stored, the "Clock Set" menu appears.

ENTER

button at any time to interrupt the memorization process.

button.

Enter

ENTER

Plug & Play

Start Plug & Play.

button.

English - 11

9. Press the

When you have nished, press the

➣

ENTER

Even if the

button to conrm your setting. The message “Enjoy your viewing” is displayed.

ENTER

button is not pressed, the message will automatically disappear after

ENTER

button.

several seconds.

Language: Select your language.

♦

Country: Select your country.

♦

Auto Store: Automatically scans for and stores channels available in the local area.

♦

Clock Set: Sets the current time for the TV clock.

♦

If you want to reset this feature...

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Setup", then press the

ENTER

2. Press the

button.

ENTER

button again, to select "Plug & Play".

For further details on setting up options, refer to the page 11.

The “Plug & Play” feature is only available in the TV mode.

➣

Storing Channels Automatically

Storing Channels Manually

Plug & Play  Language : English  Time  Light Effect :

Auto Wall-Mount 

Melody : Off  Entertainment : Off  Energy Saving : Off 

PIP 

Move Enter Return

Start Plug & Play.

Enter Return

Country : Auto Store  Manual Store  Channel Manager  Sort  Name  Fine Tune  LNA : Off 

Move Enter Return

Setup

In Watching TV

Plug & Play

Enter Return

Channel

United Kingdom 



Storing Channels Automatically

You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated programme numbers may not correspond to actual or desired programme numbers. However, you can sort numbers manually and clear any channels you do not wish to watch.

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Channel", then press the

2. Press the

ENTER

button to select "Country".

3. Select the appropriate country by pressing the ▲ or ▼ button.

Press the

➣

ENTER

button to conrm your choice.

Even though you have changed the country setting in this menu, the country setting for DTV is not changed. (Refer to page 31)

4. Press the ▲ or ▼ button to select "Auto Store", then press the

5. Press the

➣ ➣

ENTER

button.

The TV will begin memorizing all of the available channels. Press the

ENTER

button at any time to interrupt the memorization process and return to the

"Channel" menu.

6. After all the available channels are stored, the "Sort" menu appears. (refer to page 15)

English - 12

ENTER

button.

Storing Channels Manually

Not available in DTV or external input mode.

➣

You can store television channels, including those received via cable networks. When storing channels manually, you can choose:

♦ Whether or not to store each of the channels found. ♦ The programme number of each stored channel which you wish

Country : Auto Store  Manual Store  Channel Manager  Sort  Name  Fine Tune  LNA : Off 

to identify.

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Channel", then press the

ENTER

button.

2. Press the ▲ or ▼ button to select "Manual Store", then press

the

ENTER

button.

3. Select the required option by pressing the ▲ or ▼ button, then

press the

ENTER

button.

Move Enter Return

Programme : P 2 Colour System : Auto  Sound System : BG  Channel : C 3 Search : 77 MHz Store : ?

4. When you are satised with your setting, press the

ENTER

5. Press the EXIT button to exit.

Programme (Programme number to be assigned to a channel)

♦

➣

Colour System: Auto/PAL/SECAM/NTSC4.43

♦

Sound System: BG/DK/I/L

♦

Channel (When you know the number of the channel to be stored)

♦

➣ ➣

Search (When you do not know the channel numbers)

♦

button.

Move Enter Return

Press the ▲ or ▼ button until you nd the correct number.

You can also select the channel number directly by pressing the numeric buttons (0~9).

Press the ▲ or ▼ button to select the required colour standard.

Press the ▲ or ▼ button to select the required sound standard.

Press the ▲ or ▼ button to select C (Air channel) or S (Cable channel). Press the ► button, then press the ▲ or ▼ button to select the required number.

You can also select the channel number directly by pressing the numeric buttons (0~9). If there is abnormal sound or no sound, re-select the sound standard required.

Press the ▲ or ▼ button to start the search.

The tuner scans the frequency range until the rst channel or the channel that you selected is

received on the screen.

Store (When you store the channel and associated programme number)

♦

Set to "OK" by pressing the

Channel mode

➣

P (Programme mode): When completing tuning, the broadcasting stations in your area have been

ENTER

button.

assigned to position numbers from P00 to P99. You can select a channel by entering the position number in this mode.

C (Air channel mode): You can select a channel by entering the assigned number to each air

broadcasting station in this mode.

S (Cable channel mode): You can select a channel by entering the assigned number for each cable

channel in this mode.

Channel

Manual Store

United Kingdom 

English - 13

Adding / Locking Channels

Not available in DTV or external input mode.

➣

Using the Channel Manager, you can conveniently lock or add channels.

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Channel", then press the

ENTER

2. Press the ▲ or ▼ button to select "Channel Manager", then

press the

♦ Adding channels

Using the Channel List, you can add channels.

3. Select Channel List by pressing the

4. Move to the ( ) eld by pressing the ▲, ▼, ◄ or ►

button, select a channel to be added, and press the

ENTER

➣

button.

ENTER

button.

ENTER

button.

button to add the channel.

If you press the

ENTER

button again, the ( ) symbol

next to the channel disappears and the channel is not added. “ ” is active when "Child Lock" is selected to "On".

Country : Auto Store  Manual Store  Channel Manager  Sort  Name  Fine Tune  LNA : Off 

Move Enter Return

Channel List  Child Lock : Off 

Move Enter Return

Channel

Channel Manager

United Kingdom 

♦ Locking channels

This feature allows you to prevent unauthorized users, such as

children, from watching unsuitable programmes by muting out video and audio.

5. Press the ▲ or ▼ button to select "Child Lock", then press the

ENTER

button.

6. Select "On" by pressing the ▲ or ▼ button, then press the

ENTER

button.

7. Press the ▲ or ▼ button to select "Channel List", then press

the

ENTER

button.

8. Move to the ( ) eld by pressing the ▲, ▼, ◄ or ► button,

select a channel to be locked, and press the

ENTER

button.

If you press the

➣

ENTER

button again, the ( ) symbol next to the channel disappears and the channel lock is cancelled. A blue screen is displayed when "Child Lock" is activated.

➣

9. Press the EXIT button to exit. Select "On" or "Off" in "Child Lock" to easily turn the channels

➣

which selected on " " to be active or inactive.

You can select these options by simply pressing the CH LIST

button on the remote control

Channel List

P 1 C3

1 / 10

Prog.

0 C--

1 C3

2 BBC 1

3 C74

4 C75

5 C76

6 S3

7 S4

8 S6

9 S7

Add Lock

Move Enter

Page Return

English - 14

Sorting the Stored Channels

This operation allows you to change the programme numbers of the stored channels. This operation may be necessary after using the auto store.

Not available in DTV or external input mode.

➣

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Channel", then press the

ENTER

button.

2. Press the ▲ or ▼ button to select "Sort", then press the

ENTER

button.

3. Select the channel number that you wish to change by

pressing the ▲ or ▼ button repeatedly. Press the

➣

ENTER

button. The selected channel number and name are moved to right side.

4. Press the ▲ or ▼ button to move to the position in which you

would like to change and then press the

The selected channel is exchanged with the one

➣

ENTER

button.

previously stored to the chosen number.

5. Repeat steps 3 to 4 for another channel to be sorted.

6. Press the EXIT button to exit.

Country : Auto Store  Manual Store  Channel Manager  Sort  Name  Fine Tune  LNA : Off 

Move Enter Return

Prog. Ch. Name  0 C--

1 C23 

2 C16 3 C3 4 S1 s

Move Enter Return

Assigning Channels Names

Channel names will be assigned automatically when channel information is broadcast. These names can be changed, allowing you to assign new names.

Not available in DTV or external input mode.

➣

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Channel", then press the

ENTER

button.

2. Press the ▲ or ▼ button to select "Name", then press the

ENTER

button.

3. If necessary, select the channel to be assigned to a new

name by pressing the ▲ or ▼ button. Press the

ENTER

button

The selection bar is displayed around the name box.

➣

To... Then...

Select a letter, number or symbol Press the ▲ or ▼ button

Move on the next letter Press the ► button

Move back the previous letter Press the ◄ button

Conrm the name

The following characters are available: Letters of the alphabet (A~Z) / Numbers (0~9) / Special

➣

Press the

ENTER

button

characters (+, -, *, /, space)

5. Repeat steps 3 to 4 for each channel to be assigned to a new name.

6. Press the EXIT button to exit.

Country : Auto Store  Manual Store  Channel Manager  Sort  Name  Fine Tune  LNA : Off 

Move Enter Return

Prog. Ch. Name  0 C-- -----

1 C23 -----

2 C16 ----3 C3 ----4 S1 ---- s

Move Enter Return

Channel

United Kingdom 

Sort

Channel

United Kingdom 

Name

English - 15

Fine Tuning Channel Reception

Use fine tuning to manually adjust a particular channel for optimal reception.

Not available in DTV or external input mode.

➣

1. Use the number buttons to directly select the channel that

you want to ne tune.

2. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Channel", then press the

ENTER

button.

3. Press the ▲ or ▼ button to select "Fine Tune", then press

the

ENTER

button.

4. Press the ◄ or ► button to adjust the ne tuning.

Press the

ENTER

button.

5. Press the EXIT button to exit. Fine tuned channels that have been saved are marked with

➣

an asterisk "*" on the right-hand side of the channel number in the channel banner. And the channel number turns red.

To reset the ne-tuning, select "Reset" by pressing the ▲ or ▼

➣

button and then press the

ENTER

button.

LNA (Low Noise Amplier)

If the TV is operating in a weak-signal area, the LNA function

can improve the reception (a low-noise preamplier boosts the

incoming signal).

Not available in DTV or external input mode.

➣

1. Press the MENU button to display the menu.

Press the ▲ or ▼ button to select "Channel", then press the

ENTER

2. Press the ▲ or ▼ button to select "LNA", then press the ENTER

3. Press the ▲ or ▼ button to select "Off" or "On". Press the ENTER

4. Press the EXIT button to exit.

button.

Fine Tune

Reset

Channel

United Kingdom 

Channel

United Kingdom 

Channel

United Kingdom

Country : Auto Store  Manual Store  Channel Manager  Sort  Name  Fine Tune  LNA : Off 

Move Enter Return

P 1

Adjust Save Return

Country : Auto Store  Manual Store  Channel Manager  Sort  Name  Fine Tune  LNA : Off 

Move Enter Return

Country : Auto Store Manual Store Channel Manager Sort Name Fine Tune

LNA : Off

Move Enter Return

Off

English - 16

Changing the Picture Standard

You can select the type of picture which best corresponds to your viewing requirements.

1. Press the MENU button to display the menu.

Press the

2. Press the

3. Press the ▲ or ▼ button to select the desired picture effect.

Press the

4. Press the EXIT button to exit.

♦

The Picture mode must be adjusted separately for each input

➣

source.

Easy Setting

1. Press the TOOLS button on the remote control.

2. Press the ▲ or ▼ button to select “Picture Mode”.

3. Press the ◄ or ► button to select the desired picture mode.

4. Press the EXIT or TOOLS button to exit.

ENTER ENTER

ENTER

button, to select "Picture". button again, to select "Mode".

button.

Dynamic: Selects the picture for high-definition in a bright room.

Standard: Selects the picture for optimum display in a normal environment.

Movie: Selects the picture for comfortable display in a dark room.

Mode : Standard  Backlight 7 Contrast 95 Brightness 45 Sharpness 50 Colour 50

Tint G50 R50

Detailed Settings  sMore

Move Enter Return

Mode : Standard

Backlight 7 Contrast 95 Brightness 45 Sharpness 50 Colour 50

Tint G50 R50

Detailed Settings sMore

Move Enter Return

Anynet+ (HDMI-CEC) Picture Mode ◄ Standard ► Sound Mode : Custom Sleep Timer : Off SRS TS XT : Off Energy Saving : Off Dual l-ll : Mono

Move Adjust Exit

Tools


Dynamic

Standard

Movie

English - 17

Adjusting the Custom Picture

Your set has several settings which allow you to control picture quality.

1. To select the desired picture effect, follow the

"Changing the Picture Standard" instructions number 1 to 3.

2. Press the ▲ or ▼ button to select a particular item. Press the ENTER

button.

3. Press the ◄ or ► button to decrease or increase the value of a

particular item. Press the

ENTER

button.

4. Press the EXIT button to exit.

Backlight: Adjusts the screen brightness by adjusting the LCD

♦

backlight brightness. (0~10)

♦

Contrast: Adjusts the lightness and darkness between objects and the background.

♦

Brightness: Adjusts the brightness of the whole screen. Sharpness: Adjusts the outline of objects to either sharpen them

♦

or make them more dull. Colour: Adjusts the colours, making them lighter or darker.

♦

Tint: Adjusts the colour of objects, making them more red or

♦

green for a more natural look.

The adjusted values are stored according to the selected Picture mode.

➣

In PC mode, you can only make changes to "Backlight”, “Contrast" and “Brightness”.

➣

In Analogue TV, Ext., AV, S-Video modes of the PAL system, you cannot use the "Tint" Function.

➣

You can return to the factory defaults picture settings by selecting the "Reset".

➣

(Refer to "Resetting the Picture Settings to the Factory Defaults" on page 19)

Mode : Standard  Backlight 7 Contrast 95 Brightness 45 Sharpness 50 Colour 50

Tint G50 R50

Detailed Settings  sMore

Move Enter Return

▲

Backlight

▼

Move Adjust Return

Conguring Detailed Settings on the Picture

You can set detailed picture settings.

1. Press the MENU button to display the menu.

Press the

2. Press the

ENTER ENTER

button, to select "Picture".

button to select “Mode”.

Press the ▲ or ▼ button to select “Standard” or “Movie”, then

press the

ENTER

button.

3. Press the ▲ or ▼ button to select "Detailed Settings", then press

the

ENTER

button.

4. Select the required option by pressing the ▲ or ▼ button, then

press the

5. When you are satised with your setting, press the

ENTER

button.

ENTER

button.

6. Press the EXIT button to exit. "Detailed Settings" is available in "Standard" or "Movie" mode.

➣

In PC mode, you can only make changes to “Dynamic Contrast”,

➣

“Gamma” and “White Balance” from among the “Detailed Settings” items.

Mode : Standard  Backlight 7 Contrast 95 Brightness 45 Sharpness 50 Colour 50

Tint G50 R50

Detailed Settings  sMore

Move Enter Return

Detailed Settings

Black Adjust : Off  Dynamic Contrast Gamma : 0  Colour Space : Custom White Balance  Flesh Tone : 0  Edge Enhancement

xvYCC

Move Enter Return


: Medium 



: On 

: Off 

Black Adjust: Off/Low/Medium/High

♦

You can directly select the black level on the screen to adjust the screen depth.

Dynamic Contrast: Off/Low/Medium/High

♦

You can adjust the screen contrast so that the optimal contrast is provided.

English - 18

Gamma: -3 ~ +3

♦

You can adjust the Primary Colour (Red, Green, Blue) Intensity.

Press the ◄ or ► button until you reach the optimal setting.

Colour Space: Auto/Native/Custom

♦

Colour space is a Colour matrix composed of “Red”, “Green” and “Blue” Colours.

Select your favourite Colour space to experience the most natural Colour.

♦ Auto: Auto Color Space automatically adjusts to the most natural color tone based on program

sources.

♦ Native: Native Color Space offers deep and rich color tone. ♦ Custom: Adjusts the color range to suit your preference.

Customizing the Colour Space

➣

Colour: Red/Green/Blue/Yellow/Cyan/Magenta

Adjusts the Colour range to suit your preference.

“Colour” is available when “Colour Space” is set to “Custom”. Press the ▲ or ▼ button to select “Red”, “Green”, “Blue”, “Yellow”, “Cyan” or “Magenta”.

Press the ENTER button. Red/Green/Blue: In “Colour”, you can adjust the RGB values for the selected colour.

Press the ▲ or ▼ button to select "Red", "Green" or "Blue" to change it. Press the ENTER button.

Press the ◄ or ► button to decrease or increase the value of a particular item. Press the

ENTER button. Reset: Resets the colour space to the default values.

White Balance: R-Offset/G-Offset/B-Offset/R-Gain/G-Gain/B-Gain/Reset

♦

You can adjust the colour temperature for more natural picture colours. R-Offset/G-Offset/B-Offset/R-Gain/G-Gain/B-Gain: Changing the adjustment value will refresh the

adjusted screen.

Select the required option by pressing the ▲ or ▼ button, then press the

ENTER

button.

Press the ◄ or ► button until you reach the optimal setting.

Reset: The previously adjusted white balance will be reset to the factory defaults.

Flesh Tone: -15 ~ +15

♦

You can emphasize the pink 'flesh tone' in the picture.

Press the ◄ or ► button until you reach the optimal setting.

Changing the adjustment value will refresh the adjusted screen.

➣

Edge Enhancement: Off/On

♦

You can emphasize object boundaries in the picture.

xvYCC: Off/On

♦

Setting the xvYCC mode to On increases detail and colour space when watching movies from an external device (ie. DVD player) connected to the HDMI or Component IN jacks. You must set the Picture Mode to Movie to enjoy this feature.

Only available in "HDMI" and "Component" on "Movie" mode.

➣

If xvYCC function is active, PIP cannot be selected.

➣

Resetting the Picture Settings to the Factory Defaults

You can return to the factory defaults picture settings.

1. To select the desired picture effect, follow the "Changing the

Picture Standard" instructions number 1 to 3 (On page 17).

2. Press the ▲ or ▼ button to select "Reset", then press the

ENTER

button.

3. Press the ▲ or ▼ button to select "OK" or "Cancel".

Press the

ENTER

button.

4. Press the EXIT button to exit.

The "Reset" will be set for each "Picture" mode.

➣

English - 19

More Picture Options

Reset : OK

Move Enter Return


Cancel

Conguring Picture Option

1. Press the MENU button to display the menu.

Press the

ENTER

button, to select "Picture".

2. Press the ▲ or ▼ button to select "Picture Options", then press

the

ENTER

button.

More Picture Options  Reset : OK 

3. Select the required option by pressing the ▲ or ▼ button, then

press the

4. When you are satised with your setting, press the

button.

5. Press the EXIT button to exit.

➣

Colour Tone: Cool2/Cool1/Normal/Warm1/Warm2

♦

You can select the most comfortable colour tone to your eyes.

➣

ENTER

button.

ENTER

In PC mode, you can only make changes to the “Colour

Tone” and “Size” from among the items in “Picture Options”.

The adjusted values are stored according to the selected

Move Enter Return

Colour Tone : Normal  Size Screen Mode : 16:9  Digital NR : Auto 

DNIe HDMI Black Level

Movie Plus Blue Only Mode

Move Enter Return

"Picture" mode.

“Warm1” or “Warm2” is only activated when the picture mode is "Movie".

➣

Size: Auto Wide/16:9/Wide Zoom/Zoom/4:3/Just Scan

♦

You can select the picture size which best corresponds to your viewing requirements.

Auto Wide: Automatically adjusts the picture size to the "16:9" aspect ratio.

♦

16:9: Adjusts the picture size to 16:9 appropriate for DVDs or wide broadcasting.

♦

Wide Zoom: Magnify the size of the picture more than 4:3.

♦

Zoom: Magnifies the 16:9 wide picture (in the vertical direction) to fit the screen size.

♦

4:3: This is the default setting for a video movie or normal broadcasting.

♦

Just Scan: Use the function to see the full image without any cutoff when HDMI (720p/1080i/

♦

1080p) or Component (1080i/1080p) signals are input.

"Auto Wide" function is available only in "TV", "DTV", "Ext.1", "Ext.2", "AV", and "S-Video" mode.

➣

In PC Mode, only "16:9" and "4:3" mode can be adjusted.

➣

Settings can be adjusted and stored for each external device you have connected to an input of

➣

the TV. Temporary image retention may occur when viewing a static image on the set for more than two

➣

hours. "Wide Zoom": Move the screen up/down using the ▲ or ▼ button after selecting the by

➣

pressing the ► or ENTER button. "Zoom": Select by pressing the ◄ or ►button. Use the ▲ or ▼ button to move the picture up

➣

and down. After selecting , use the ▲ or ▼ button to magnify or reduce the picture size in the vertical direction. When Double ( , ) mode has been set in PIP, the Picture Size cannot be set.

➣

After selecting “Just Scan” in HDMI (1080i/1080p) or Component (1080i/1080p) mode:

➣

Select by pressing the ◄ or ►button. Use the ▲, ▼, ◄ or ► button to move the picture. Reset: Press the ◄ or ► button to select “Reset”, then press the ENTER button. You can initialize the setting.


Picture Options

: Auto Wide 

: Off 

: Normal 

: Low 

: Off 

You can select these options by simply pressing the P.SIZE button on the remote control.

English - 20

Screen Mode: 16:9/Wide Zoom/Zoom/4:3

♦

When setting the picture size to "Auto Wide" in a 16:9 wide TV, you can determine the picture size you want to see the 4:3 WSS (Wide Screen Service) image or nothing. Each individual European country requires different picture size so this function is intended for users to select it.

16:9: Sets the picture to 16:9 wide mode.

♦

Wide Zoom: Magnify the size of the picture more than 4:3.

♦

Zoom: Magnify the size of the picture vertically on screen.

♦

4:3: Sets the picture to 4:3 normal mode.

♦

This function is available in "Auto Wide" mode.

➣

This function is not available in "PC", "Component" or "HDMI" mode.

➣

Digital NR: Off/Low/Medium/High/Auto

♦

If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction feature to help reduce any static and ghosting that may appear on the screen.

When the signal is weak, select one of the other options until the best picture is displayed.

➣

DNIe: Off/ Demo/On

♦

This TV includes the DNIe function so as to provide a high visual quality. If you set DNIe to on, you can view the screen with the DNIe feature activated. If you set the DNIe to Demo, you can view the applied DNIe and normal pictures on the screen, for demonstration purposes. Using this function, you can view the difference in the visual quality.

DNIe™ (Digital Natural Image engine)

➣

This feature brings you more detailed image with 3D noise reduction, detail enhancement, contrast enhancement and white enhancement. New image compensation Algorithm gives brighter, clearer, more detailed image to you. eyes. This function is not available in "Movie" and "Standard" mode.

➣

HDMI Black Level: Normal/Low

♦

You can directly select the black level on the screen to adjust the screen depth.

This function is active only when the external input connects to HDMI(RGB signals).

➣

Movie Plus: Off/Low/Medium/High/Demo

♦

You can view more natural skin and clear text even in fast moving scenes.

Use this function when watching movies.

➣

This function is not available in “Wide Zoom” and “Zoom” modes.

➣

This function is not available when "PIP" is set to "On".

➣

It is not supported in HDMI 1080p/24Hz mode.

➣

Blue Only Mode: Off/On

♦

This function is for AV device measurement experts. This function displays the blue signal only by removing the red and green signals from the video signal so as to provide a Blue Filter effect that is used to adjust the Colour and Tint of video equipment such as DVD players, Home Theaters, etc.

Using this function, you can adjust the Colour and Tint to preferred values appropriate to the signal level of each video device using the Red/Green/Blue/ Cyan/Magenta/Yellow Colour Bar Patterns, without using an additional Blue Filter.

“Blue Only Mode” is available when the picture mode is set to “Movie” or “Standard”.

➣

DNIe™ technology will t every signal into your

English - 21

+ 52 hidden pages
