Operating Instructions

VACUUM CLEANER

❈

Before operating this unit, please read the instructions carefully.

❈ For Indoor use only.

Register your product at www.samsung.com/global/register

DJ68-00364D REV(0.1)

IMPORTANT SAFEGUARDS

1. Read all instructions carefully. Before switching on, make sure that the voltage of your
electricity supply is the same as that indicated on the rating plate on the bottom of the
cleaner.

2. WARNING: Do not use the vacuum cleaner when rug or floor is wet.

Do not use to suck up water.

3. This appliance is not intended for use by young children or infirm persons unless they
have been adequately supervised by a responsible person to ensure that they can
use the appliance safely. Young children should be supervised to ensure that they do
not play with the appliance.

4. Do not use the vacuum cleaner without the dust bag. Empty the dust bag before it is
full in order to maintain the best efficiency.

5. Slide to the Stop(or Min)position before inserting a plug into the electrical outlet.

6. Do not use the vacuum cleaner to pick up matches, live ashes or cigarette butts.
Keep the vacuum cleaner away from stoves and other heat sources. Heat can
deform and discolour the plastic parts of the unit.

7. Avoid picking up hard, sharp objects with the vacuum cleaner as they may damage
the cleaner parts. Do not stand on the hose assembly. Do not put a weight on the
hose. Do not block the suction or the exhaustion part.

8. Switch the vacuum cleaner off at the machine before unplugging from the electrical
outlet. Grasp the plug to disconnect cord from the electrical outlet before caring the
dust bag and filters.

9. The plug must be removed from the socket out-let before cleaning or maintaining the
appliance.

10. The use of an extension cord is not recommended.

11. If your vacuum cleaner is not operating correctly, switch off the power supply and

consult an authorized service agent.

12. If the supply cord is damaged, it must be replaced by the manufacturer or its service

agent or a similarly qualified person in order to avoid a hazard.

13. The vacuum cleaner is provided with a self-resetting thermal cut-out protection

which automatically shut off current on over heating. Overheating can be caused by
blockage in the filter, nozzle, tube or hose. After removing the cause and

cooling the motor, vacuum cleaner automatically start again.

1

ASSEMBLING THE CLEANER

1

OPTION

OPTION

1

OPTION

Features may vary according to model.

▼

Parking floor nozzle for easier storage.

2

OPERATING THE CLEANER

2

1

2-1 POWER CORD 2-2 ON/OFF SWITCH

NOTE

Grasp the plug to
disconnect cord from
the electrical outlet.

2-3 POWER CONTROL

1) BODY-CONTROL TYPE
MIN = For delicate surface e.g. net curtains.
MAX = For hard floors and heavily soiled carpets.

2) REMOTE-CONTROL TYPE

CONTROL-BUTTON

SENDER

RECEIVER

Press control button repeatedly
to select correct mode.
(STOP ➝ MIN ➝ MID ➝ MAX ➝ STOP)

POWER LAMP

When pushed the “ON/OFF” switch button,
the Power lamp is turned on automatically.

INFRARED-CONTROL

ON/OFF switch button

2-4 AIR CONTROL

To reduce suction for cleaning draperies, small rugs, and other
light fabrics, pull the tap air until the hole is open.

2-5 USING THE BLOWER

Located on the left rear side of the cleaner.

1) Disconnect the hose from the body of the cleaner.

2) Connect the hose clamper to the blow hole.

3

BODY CONTROL TYPE ONLY

2-6 USING THE ACCESSORIES

• Dusting brush - for furniture, shelves, books,
etc.

• Upholstery brush - for cushions and drapery.

• Crevice tool - for radiators, crevices, comers,
between cushions.

2-7 USING FLOOR TOOLS

OPTION

DUSTING BRUSH

UPHOLSTERY BRUSH

CREVICE TOOL

(

)

HARD FLOOR

PARQUET SPECIALIST

OPTION

(

)

OPTION

4

CREVICE

DUSTING

UPHOLSTERY
