Samsung i80 User Manual

Download

Page 1

Page 2

Getting to Know your cameraInstructions

Use this camera in the following order.

Set up the camera driver

Before connecting the camera to a PC, via the USB cable, you will need to set up the camera driver. Install the camera driver that is contained in Application software CD-ROM. (p.112)

Take a picture

Insert the USB cable

Take a picture. (p.19)

Insert the supplied USB cable into the PC’s USB port and the camera’s USB connection terminal. (p.116)

Check the camera’s power. If the

Check the camera's power

power is turned off, preset the camera button to turn it on.

Check [Removable Disk]

Open Windows’s EXPLORER and search for [Removable Disk]. (p.117)

Thank you for buying a Samsung Digital Camera.



Prior to using this camera, please read the user manual thoroughly.



If you require After Sales service, please bring the camera and the cause of the camera malfunction (such as battery, Memory card etc.) to the A/S centre.



Please check that the camera is operating properly prior to when you intend to use it (e.g. for a trip or an important event) to avoid disappointment. Samsung takes no responsibility for any loss or damage that may result from camera malfunction.



Keep this manual in a safe place.



If you use a card reader to copy the images on the memory card to your PC, the images could be damaged. When transferring the images taken with the camera to your PC, be sure to use the supplied USB cable to connect the camera to your PC. Please note that the manufacturer holds no responsibility for loss or damage of images on the memory card due to the use of a card reader.



The contents and illustrations of this manual are subject to change without prior notice for upgrading the camera functions.

Microsoft, Windows and Windows logo are registered trademarks of Microsoft Corporation incorporated in the United States and/or other countries.

is a trademark of SRS Labs, Inc.

WOW HD technology is incorporated under license from SRS Labs, Inc.

All brand and product names appearing in this manual are registered

trademarks of their respective companies.

Page 3

Danger Warning

DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.



Do not attempt to modify this camera in any way. To do so may

result in ﬁ re, injury, electric shock or severe damage to you or your camera. Internal inspection, maintenance and repairs should only be carried out by your dealer or Samsung Camera Service centre.



Please do not use this product in close proximity to ﬂ ammable or

explosive gases, as this could increase the risk of explosion.



Should any form of liquid or a foreign object enter the camera, do

not use it. Switch off the camera, and then disconnect the power source. You must contact your dealer or Samsung Camera Service centre. Do not continue to use the camera as this may cause a ﬁ re or electric shock.



Do not insert or drop metallic or inﬂ ammable foreign objects into the

camera through access points e.g. the memory card slot and battery chamber. This may cause a ﬁ re or electric shock.



Do not operate this camera with wet hands. This could pose a risk

of electric shock.

WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.



Do not use the ﬂ ash in close proximity to people or animals. Position-

ing the ﬂ ash too close to your subject’s eyes may cause eyesight damage.



For safety reasons keep this product and accessories out of reach of

children or animals to prevent accidents e.g.:

- Swallowing battery or small camera accessories. If an accident should occur, please consult a doctor immediately.

- There is the possibility of injury from the camera’s moving parts.



Battery and camera may become hot during prolonged use and it

may result in camera malfunction. Should this be the case, allow the camera to sit idle for a few minutes to allow it time to cool.



Do not leave this camera in places subject to extremely high tem-

peratures, such as a sealed vehicle, direct sunlight or other places of extremes in temperature. Exposure to extreme temperatures may adversely affect the camera’s internal components and could cause a ﬁ re.



When in use, do not cover the camera or Charger. This may cause

heat to build up and distort the camera body or cause a ﬁ re. Always use the camera and its accessories in a well-ventilated area.

Page 4

Caution

Contents

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in a minor or moderate injury.



Leaking, overheating, or damaged battery could result in ﬁ re or injury.

- Use battery with the correct speciﬁ cation for the camera.

- Do not short circuit, heat or dispose of battery in ﬁ re.

- Do not insert the battery with the polarities reversed.



Remove the battery when not planning to use the camera for a long

period of time. Otherwise the battery may leak corrosive electrolyte and permanently damage the camera’s components.



Do not ﬁ re the ﬂ ash while it is in contact with hands or objects. Do not

touch the ﬂ ash after using it continuously. It may cause burns.



Do not move the camera while it is switched on, if you are using the AC Charger. After use, always switch off the camera before unplugging the cable from the wall socket. Then make sure that any connector cords or cables to other devices are disconnected before moving the camera. Failure to do so may damage the cords or cables and cause a ﬁ re or electric shock.



Take care not to touch the lens or lens cover to avoid taking an un-

clear image and possibly causing camera malfunction.



Avoid obstructing the lens or the ﬂ ash when you capture an image.



When using this camera in low temperatures, you may experience the following. These are not camera malfunctions and usually recover at normal temperature.

- It takes more time to turn on the LCD monitor and the colour may differ from the subject.

- When changing the composition, there may be an after image on the LCD monitor.



Never connect the 20 pin connector to the USB port of a PC. This carries a high risk of computer malfunction.



Credit cards may be demagnetized if left near case. Avoid leaving

magnetic strip cards near the case.

RECORDING

READY

007 System chart 008 Identiﬁ cation of features 008 Front & Top & Bottom 009 Back 010 Side / 5 Function button 010 Self-timer lamp 010 Camera Status Lamp 011 Mode icon 011 Connecting to a Power Source 014 Inserting the battery 014 Inserting the memory card 015 Instructions on how to use the memory card 017 When using the camera for the ﬁ rst time

018 LCD monitor indicator 019 Starting the recording mode 019 Selecting modes 019 How to use the Auto mode 020 How to use the Program mode 020 How to use the DIS mode 020 How to use the FUN mode 021 Using the Photo Help Guide mode 022 How to use the Movie clip mode 022 Recording the movie clip without sound 022 Pausing while recording a movie clip

(Successive Recording)

023 How to use the Scene modes 024

Things to Watch Out for When Taking Pictures

Page 5

Contents

025 Using the camera buttons to set the camera 025 POWER button 025 SHUTTER button 025 ZOOM T/W button 027 Face Detection(FD) button 028 Function Description / Info / Up button 029 Macro / Down button 030 Focus lock 031 Flash / Left button 033 Self-timer / Right button 034 MENU / OK button 035 Fn button 035 How to use the Fn menu 036 Size 036 Quality / Frame rate 037 Metering 037 Drive mode 038 ISO 038 White balance 039 Exposure compensation 040 Movie Clip frame stabiliser 040 Slow shutter speed 040 E (Effect) button 041 E (Effect) button : Photo Style Selector 041 E (Effect) button : Image editing 041 Colour 042 Sharpness 042 Contrast

SETUP

042 Saturation 043 E (Effect) button : FUN 043 Cartoon 044 Pre-set focus frame 045 Composite shooting 048 Photo Frame 049 Colour Mask

050 Using the LCD monitor to adjust the camera

settings

050 Recording

050 Auto Focus type 051 ACB 051 Voice Memo 052 Voice Recording 053 Recording the movie clip without voice 053 Sound menu 054 Sound 054 Volume 054 Start up sound 054 Shutter sound 054 Beep Sound 054 AF sound 054 Self Portrait Sound 055 Setup menu 056 Display 056 Language 056 Setting up the Date / Time / Date type

Page 6

Contents

057 Start up image 057 LCD brightness 057 Quick view 057 LCD save 058 Settings 058 Formatting a memory 058 Initialisation 059 File name 059 Imprinting the recording date 060 Auto power off 060 Selecting Video out type 061 Auto Focus lamp

062 Starting play mode

PLAY

062 Playing back a still image 062 Playing back a movie clip

063 Movie clip capture function 063 On camera movie trimming 064 Playing back a recorded voice 064 Playing back a voice memo 065 LCD monitor Indicator 065 Using the camera buttons to set the camera 065 Play mode button 066 Thumbnail / Enlargement button 067 Info / Up button 068 Play & Pause / Down button 068 Left / Right / Menu / OK button 069 Printer button

069 Delete button 070 E (Effect) button : Resize 071 E (Effect) button : Rotating an image 071 E (Effect) button : Colour 072 E (Effect) button : Image editing 072 ACB 072 Red eye removal 073 Brightness control 073 Contrast control 073 Saturation control 073 Noise effect 074 E (Effect) button : FUN 074 Cartoon 075 Preset focus frames 076 Composite image 078 Photo Frame 079 Sticker 079 Colour Filter 080 Colour mask 081 Setting up the play back function using the

LCD monitor 082 Starting the Multi Slide Show 082 Start the Multi Slide Show 083 Selecting Images 083 Conﬁ gure Multi Slide Show effects 084 Setting play interval 084 Setting Background Music 084 Playback

Page 7

Contents

MULTIMEDIA

084 Voice memo 085 Deleting images 085 Protecting images 086 DPOF 088 Copy To Card 089 PictBridge 090 PictBridge : Picture Selection 090 PictBridge : Print Setting 091 PictBridge : Reset

091 MP3 / PMP / TEXT VIEWER mode 092 Downloading ﬁ les 092

Starting the MP3 / PMP / TEXT VIEWER mode

094 LCD monitor indicator for MP3 / PMP / TEXT

VIEWER mode

095

Using the camera buttons to adjust the camera 095 Volume button 095 Play & Pause / Seeking button 096 Delete button 096 Hold / Equalizer button 097 Playlist button 097 Setting up the playback function using the

LCD monitor 098 Resume 099 Play mode 099 Skin of MP3 player 099 Playing back the slide show

SOFTWARE

110

099 Setting slide show interval 100 Delete all 100 Frame search 100 Display setting 101 Setting up the recording function in the

MP3 mode 101 Auto Scroll 101 MP3 BGM Setting 101 Language setting 102 Important notes 103 Warning indicator 104 Before contacting a service centre 106 Speciﬁ cations

110 Software Notes 110 System Requirements 111 About the software 112 Setting up the application software 116 Starting PC mode 118 Removing the removable disk 119 Setting up the USB Driver for MAC 119 Using the USB Driver for MAC 120

Removing the USB Driver for Windows 98SE 120 Samsung Converter 122 Samsung Master 125 FAQ

Page 8

System chart

Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the optional equipment, contact your nearest Samsung dealer or Samsung service centre.

Included items

01 READY

Camera

Earphones 20 Pin Gender

Optional items

SD/SDHC memory card /

MMC

(see p.16)

Rechargeable battery

(SLB-1137D)

Camera case

AC adapter (SAC-47) /

USB cable (SUC-C3)

Software CD

(see p.111)

AV cable Camera strap

User manual,

Product warranty

READY

Page 9

Identiﬁ cation of features

Front & Top & Bottom

Speaker

_READY

Shutter button

Flash

Self-timer lamp /

AF sensor

Microphone

Power button

FD (Face Detection) button / MP3, PMP hold button

Lens

Tripod socket

Page 10

Identiﬁ cation of features

Back

LCD monitor

Camera status lamp

01 READY

M (Mode) button

Zoom T button (Digital zoom) Strap eyelet E (Effects) button

Zoom W button (Thumbnail)

Fn / Delete button

Play mode / Printer button

5 function button

READY

Page 11

Identiﬁ cation of features

Side / 5 Function button

Battery

chamber slot

Function Description / Information / Up button

Flash /

Left button

Macro / Down button

Play & Pause button

_READY

USB / AV connection terminal

Battery holder

Memory card slot

Battery chamber cover

MENU / OK button

Self-timer / Right button

Self-timer lamp

Icon Status Description









- For the ﬁ rst 7 seconds, the lamp blinks at 1 second

Blinking

intervals.

- For the ﬁ nal 3 seconds, the lamp blinks quickly at

0.25-second intervals.

For the 2 seconds, the lamp blinks quickly at

0.25-second intervals.

A picture will be taken after about 10 seconds and 2 seconds later a second picture will be taken.

The camera detects the subject's movement 6 seconds after pressing the Shutter button, and the picture is taken when the movement is stopped.

Camera Status Lamp

Status Description

Power on

After taking a picture

When the USB cable is inserted to a PC

Transmitting Data with a PC When the USB cable is

inserted into a printer When the printer is printing

When the AF activates

The lamp turns on and off when the camera is ready to take a picture

The lamp blinks while saving the image data and turns off when the camera is ready to take a picture

The lamp lights up (LCD monitor turns off after initializing the device)

The lamp blinks (LCD monitor turns off) The lamp blinks and turns off when the printer is

ready to print a picture. The lamp blinks The lamp turns on

(The camera focuses on the subject) The lamp blinks

(The camera doesn’t focus on the subject)

Page 12

Identiﬁ cation of features Connecting to a Power Source

Mode icon

Refer to page 19 for more information about the camera mode setting.

MODE

Auto Program DIS Fun

SHOOTING


Help

Guide

Movie

Š‰ÿë_†

Nightscene

Portrait Children

Landscape

Close up Text



Sunset Dawn Backlight Firework

SCENE

Beach

&Snow

Self Shot

„

Food Café - - - -

…ˆ

MP3 PMP TextViewer

MULTIMEDIA

You should use the rechargeable battery SLB-1137D supplied with the camera. Be sure to charge the battery before using the camera.



SLB-1137D rechargeable battery Speciﬁ cation

Model SLB-1137D Type Lithium lon Capacity 1100mAh Voltage 3.7V C

harging time



Number of images and battery life: Using the SLB-1137D

Battery life /

Number of images

Still image

Approx. 160 MIN / Approx. 320 shots

Movie Approx. 160 MIN

Approximately 150 Minutes

Conditions

Using the fully charged battery, Auto mode, 8M image size, Fine image quality, Shot to shot interval: 30Sec. Changing the zoom position between the Wide and the Tele after every shot. Using the ﬂ ash on every second shot. Using the camera for 5 minutes and then powering it off for 1 minute.

Using the fully charged battery 640x480 image size 30fps frame rate

READY

01 READY

Page 13

Connecting to a Power Source



Number of images and battery life: Using the SLB-1137D

Battery life / Number

of images

Multi

Media

These ﬁ gures are measured under Samsung’s standard conditions and

MP3 Approx. 400 MIN

PMP Approx. 380 MIN Using the fully charged battery

Conditions

Using the fully charged battery Turning off the LCD monitor

shooting conditions and may vary depending on the user’s methods.

Important information about battery usage.

When camera is not in use, turn off the power.



Please remove the battery if the camera will not be used for long



periods. Batteries can lose power over time and are prone to leaking if kept inside the camera.

Low temperatures (below 0°C) can affect the performance of the



battery and you may experience reduced battery life.

Batteries will usually recover at normal temperatures.



During extended use of the camera, the camera body may become



warm. This is perfectly normal.

When you use earphones, do not remove the battery while the



camera is turning on. It may generate a loud noise.

_READY



You can charge the rechargeable battery (SLB-1137D) by using the SAC-47 KIT which consists of the AC adapter (SAC-47) and the USB cable (SUC-C3). When the SAC-47 and SUC-C3 are combined, they can be used as an AC cable.

- Using an AC cable : Connect the AC adapter to the

USB cable. It can be used as a power cable.

- Using a USB cable : Remove the AC adapter (SAC-47).

You can download stored images to your PC (p.117) or supply the power to your camera through the USB cable.

Page 14

Connecting to a Power Source

Important information about USB cable usage.

Use a USB cable (SUC-C3) with the correct speciﬁ cation.



If the camera is connected to the PC through a USB hub :



connect the camera directly to the PC. If the camera and other devices are connected to the PC at the



same time : remove other device. If the USB cable is connected to a port located on the front of the PC :



remove the cable and connect it to a port located on the back of the PC. If the USB port of the PC doesn’t meet the Power output standard



(4.2V, 400mA), the camera may not be charged.



How to charge the rechargeable battery (SLB-1137D)

Before inserting any cables or AC adapter, check the directions and



do not insert by force. It may cause breakage of cable or camera. If the charging LED of the AC Charger does not turn on or blink after



inserting the rechargeable battery, please check whether the battery is inserted correctly. If you charge the battery with the camera power on, the battery won’t



be fully charged. Turn the camera off while charging the battery.



Charging LED of the AC Adapter

Charging LED

Being Charged Red LED is on

Charging is complete Green LED is on

Charging error Red LED is off or blinking

Being discharged

(Using the AC adapter)



If you insert the fully discharged battery to charge it, do not turn on the

Orange coloured LED is on

camera at the same time. The camera may not be turned on because of the low battery capacity. Charge the battery for more than 10 minutes before using the camera.



Do not use the ﬂ ash frequently or take a movie clip with the fully discharged battery charged for a short time. Even if the charger is inserted, the camera power may be turned off because the rechargeable battery is discharged again.

READY

01 READY

Page 15

Inserting the battery



Insert the battery as shown

- If the camera does not turn on after you have inserted battery, please check whether the battery (+ / -).

When the battery chamber cover is opened, do not force the battery chamber cover, this may damage it.



There are 4 indicators for battery condition that are displayed on the LCD monitor.

Battery

indicator

Battery

status

When using the camera and the battery in a place that is excessively cold or hot,

the battery status on the LCD may be different from the actual battery status.

ihgf

The battery is

fully charged

Low battery

capacity

(Prepare to

recharge or use

spare battery)

Low battery

capacity

(Prepare to

recharge or use

spare battery)

Battery empty.

(Recharge or

use spare bat-

tery)

Inserting the memory card



Insert the memory card as shown.

- Turn off the camera’s power before inserting the memory card.

- Have the front of the memory card facing toward the back of the camera (LCD monitor) and the card pins toward the front of the camera (Lens).

- Do not insert the memory card the wrong way round. Doing so may damage the memory card slot.

_READY

Page 16

Instructions on how to use the memory card



Be sure to format the memory card (see p.58) if you are using a newly purchased memory card for the ﬁ rst time, if it contains data that the camera cannot recognise, or if it contains images captured with a different camera.



Turn off the camera power whenever the memory card is being inserted or removed.



Repeated use of the memory card will eventually reduce the memory card’s performance. Should this be the case, you will need to purchase a new memory card. Wear and tear on the memory card is not covered by the Samsung warranty.



The memory card is an electronic precision device. Do not bend, drop or subject the memory card to any heavy impact.



Do not store the memory card in an environment with strong electronic or magnetic ﬁ elds, e.g. near loud speakers or TV receivers.



Please do not use or store in an environment where there are extremes in temperature.



Do not allow the memory card to become dirty or to come into contact with any liquid. Should this happen, clean the memory card with a soft cloth.



Please keep the memory card in its case when not in use.



During and after periods of extended use, you may notice that the memory card is warm. This is perfectly normal.



Do not use a memory card that is used in another digital camera. To use the memory card in this camera, format the memory card using this camera.



Do not use a memory card formatted by another digital camera or memory card reader.



If the memory card is subjected to any of the following, the recorded data may become corrupted :

- When the memory card is used incorrectly.

- If the power is switched off or the memory card is removed while recording, deleting (formatting) or reading.



Samsung cannot be held responsible for lost data.



It is advisable to copy important data onto other media as back-up e.g. ﬂ oppy disks, hard disks, CD etc.



If there is insufﬁ cient memory available : A [Memory Full!] message will appear and the camera will not operate. To optimise the amount of memory in the camera, replace the memory card or delete unnecessary images stored on the memory card.

Don't remove the memory card when the camera status lamp is blink-



ing as this may cause damage to data in the memory card.

READY

01 READY

Page 17

Instructions on how to use the memory card

The camera can use SD/SDHC Memory Cards and MMC (Multi Media Cards).

When using a 256MB MMC memory, the speciﬁ ed shooting capacity will be as follows. These ﬁ gures are approximate as image capacities can be affected by variables such as subject matter and memory card type.

Card pins

Write protect switch

Label

[SD (Secure Digital) memory card]



The SD/SDHC memory card has a write protect switch that prevents

Recorded

image size

Still


*Movie

clip

image ﬁ les from being deleted or formatted. By sliding the switch to the bottom of the SD/SDHC memory card, the data will be protected. By sliding the switch to the top of the SD/SDHC memory card, the data protection will be cancelled.



Slide the switch to the top of the SD/SDHC memory card before taking a picture.

_READY

Super

About58About89About

About66About

About77About



About91About



About



About



The zoom button doesn’t operate during the movie recording.



The recording times can be changed by the zoom operation.



Fine

100

About

115

About

133

About

155

About

190

About

355

About

414

About

----

---

30 FPS 20 FPS 15 FPS

Normal

137 - - 150 - - 177 - - 198 - - 216 - - 452 - - -

About 10'53” About 12'00"

About 11'41” About 12'58" About 11'23" About 38'51"-About 01:07'31"

About 17'47"

Page 18

When Using the Camera for the First Time



Charge the rechargeable battery fully before using the camera for the ﬁ rst time.



Turning on the camera To turn on the camera, press the Power button (c) or Open the camera (d) as shown.



When closing the camera, handle it as shown in the picture above. Your ﬁ nger could be caught in the top or bottom groove and you could be injured as shown below.

01 READY

READY

Page 19

LCD monitor indicator



The LCD monitor displays information about the shooting functions and selections.

[Image & Full Status]

No. Description Icons Page

1 Recording mode

Optical / Digital Zoom bar /

Digital Zoom rate

3 Voice Memo

Number of available

shots remaining

Remaining time 00:00:00

_RECORDING

00010

p.11

p.25

p.51

p.16

No. Description Icons Page

Memory card icon /

Internal memory icon

6 Battery

7 Image Size

Image Quality / Frame Rate

9 Metering

10 Drive mode

14 Date / Time 2008/03/01 01:00 PM p.56

17 Color / Saturation

18 Contrast

20 Macro

21 Self-timer

22 Flash

ISO

White Balance

Exposure compensation

Camera shake Warning

Auto Focus Frame

Sharpness / Without Sound

Face Detection / Self Portrait

/ Photo Style Selector

p.14

p.36

p.37

p.38

p.39

p.24

p.50

p.41/42

p.42

p.42/22

p.29

p.33

p.31

p.27/28/41

Page 20

Starting the recording mode

Selecting modes

You can select the desired working mode using the M (Mode) button located on the back of the camera.



How to use the M (Mode) button

Press the M button and a menu will be displayed. You can select a menu by pressing the 5 function button.

Nightscene

This mode is appropriate for photographing at

night (use of tripod is recommended)

Movie

In this mode, you can take a video.

Auto

This mode minimizes user settings for quick,

convenient shooting.

MP3

In this mode you can play MP3 ﬁ les.

Directly set various features for shooting.

Auto

This mode minimizes user settings for quick,

convenient shooting.

Program

How to use the Auto mode ( Š )

Select this mode for quick and easy picture taking with minimal user interaction.

1. Insert the batteries (p.14). Insert the batteries taking note of the polarity (+ / -).

2. Insert the memory card (p.14). As this camera has a 40MB internal memory, you do not need to insert the memory card. If the memory card is not inserted, an image will be stored in the internal memory. If the memory card is inserted, an image will be stored on the memory card.

3. Close the battery chamber cover.

4. Press the POWER button to turn on the camera. (If the date/time that is displayed on the LCD monitor is incorrect, reset the date/time before taking a picture.) (p.56)

5. Select the Auto mode by pressing the M(Mode) button.

6. Point the camera towards the subject and compose the image by using the LCD monitor.

7. Press the shutter button to capture an image.

If the auto focus frame turns to red when you press the shutter button down half way, it means that the camera cannot focus on the subject. Should this be the case, the camera is unable to capture an image clearly.

RECORDING_

02 RECORDING

Page 21

Starting the recording mode

How to use the Program mode ( ‰ )

Selecting the automatic mode will conﬁ gure the camera with optimal settings. You can still manually conﬁ gure all functions except the aperture value and shutter speed.

1. Select the Program mode by pressing the M (Mode) button (p.19).

2. Press the Fn button to conﬁ gure advanced functions such as Image Size (p.36), Quality (p.36), Metering (p.37), Drive mode (p.37), ISO (p.38), White Balance (p.38) and Exposure Value(p.39).

How to use the DIS mode ( ÿ )

Digital Image Stabilisation (DIS) mode. This mode will reduce the effect of camera shake and help you get a

well-exposed image in dim conditions.

1. Select the DIS mode by pressing the M (Mode) button. (p.19)

2. Point the camera towards the subject and compose the image by using the LCD monitor.

3. Press the Shutter button to capture an image.



Things to watch out for using the DIS mode

1. The digital zoom will not operate in the DIS mode.

If the lighting conditions are brighter than ﬂ uorescent lighting condi-

tions, the DIS will not activate.

3. If the lighting conditions are darker than in ﬂ uorescent lighting conditions, camera shake warning indicator ( Ã ) will display. For best results only take pictures in situations where the camera shake warning indicator ( Ã ) is not displayed.

4. If the subject is moving, the captured image may be blurred.

5. Avoid moving the camera while the [Capturing!] message is

displayed to achieve a better result.

6. As the DIS uses the camera's digital signal processor, it may take a

little longer for the camera to process and save the images.

If the image size is (¬) or () ,the DIS mode can’t be selected.

How to use the FUN mode ( ë )

In this mode, you can take pictures with various effects easily and simply.

Select the FUN mode by pressing the M (Mode) button.

Refer to page 43-49 for more information.

_RECORDING

Page 22

Starting the recording mode

Using the Photo Help guide mode ( _ )

Helps the user learn the correct picture taking method and includes solutions for potential problems that may occur. This also enables the user to practice the best way to take the pictures.

PHOTO HELP GUIDE Features to use when the image is out of focus Features to counter camera shake Features to use in low light conditions Features to use when adjusting brightness Features to use when adjusting colours



Move Next





Pressing the shutter button

Guide list

Pressing the

Left/Right button

Features to use when the image is out of focus Half press shutter button to focus To focus on a subject 80cm or more away To focus on a subject less than 80 cm away To focus on a subject less than 5cm away To focus on people’s faces

±

Back Next

Pressing the MENU button

Practice begins when you press the shutter.

Guide list

[Function that can be used when focusing is difﬁ cult]

Available functions of the photo help guide

Function that can be used when focusing is difﬁ cult



Functions that can be used when the image is blurred



Function that can be used when ﬁ lming in the dark



Function that can be used when adjusting the picture brightness



Function that can be used when adjusting the picture colour





1/2



±



Pressing the

Left/Right button

Half press shutter button to focus

Focusing status can be checked by half-pressing shutter button

- Green: Focusing successful

- Red: Focusing failed

Back Practice

Pressing the Up/

Down button



2/2



±

Pressing the Right button

Half press shutter button to focus

When focusing is successful, fully press the shutter button to shoot. If focusing fails, half press the button again.

Back Practice

RECORDING_

02 RECORDING

Page 23

Starting the recording mode

How to use the Movie clip mode ( † )

A movie clip can be recorded for as long as the available recording time of the memory capacity allows.

1. Select the Movie clip mode by pressing the M (Mode) button. ( The Movie clip mode icon and available recording time will appear on the LCD monitor.).

Point the camera towards the subject and

2. compose the image by using the LCD monitor.

3. Press the shutter button once and movie clips are recorded for as long as the available recording time allows. Movie clips will still be recorded if the shutter button is released. If you wish to stop recording, press the shutter button again.

Image size and type are listed below.

- Image size : 800x592, 720x480, 640x480, 320x240 (Selectable)

- Movie clip ﬁ le type : AVI (MPEG-4)

- Frame Rate : 30 FPS, 20 FPS, 15 FPS (Selectable)

- The frame rate can be selected when the following image size is

selected. 800x592, 720x480 : 20FPS, 15FPS selectable 640x480, 320x240 : 30FPS, 15FPS selectable

_RECORDING

Recording the movie clip without sound

You can record the movie clip without sound.

See p.53 for further details.

Pausing while recording a movie clip (Successive Recording)

This camera allows you to temporarily stop during unwanted scenes, while recording a movie clip. Using this function, you can record your favourite scenes into a movie clip without having to create multiple movie clips.

Stop REC



Using Successive Recording

Steps from 1-2 are the same as those for MOVIE CLIP mode.

3. Press the shutter button and movie clips are recorded for as long as the available recording time. Movie clips will still be recorded if the shutter button is released.

4. Press the Pause button ( Ø ) to pause recording.

5. Press the Pause button ( Ø ) again to resume the recording.

6. If you wish to stop recording, press the shutter button again.

Page 24

Starting the recording mode

How to use the Scene modes (  )

Use the menu to easily conﬁ gure optimal settings for a variety of shooting situations.

1. Select the Scene mode by pressing the M (Mode) button (p.19).

2. Point the camera towards the subject and compose the image by using the LCD monitor.

3. Press the shutter button to capture an image.

The scene modes are listed below.

[Nightscene] (

[Portrait] ( [Children] (

[Landscape] ( [Close Up] (

[Text] ( [Sunset] ( [Dawn] ( [Backlight] (

[Firework] ( [Beach&Snow] (

[Self Shot] (

[Food] ( [Café] (

) : Use this for shooting still images at night or



in other dark conditions.

) : To take a picture of a person.



) : To take a picture of fast moving objects,



for example, children.

) : To take pictures of distant scenery.



) : Close-up shooting for small objects such as



plants and insects.

) : Use this mode to shoot a document.



) : For taking pictures of sunsets.



) : Daybreak scenes.



) : Portrait without shadows caused by back-



light.

) : Firework scenes.



) : For ocean, lake, beach and snowscape



scenes.

) : Use when the photographer would also like

„

to appear in the image.

) : For taking delicious looking food.

…

) : For taking pictures in cafes and restaurants.

RECORDING_

02 RECORDING

Page 25

Things to Watch Out for When Taking Pictures



Pressing the shutter button down half way. Lightly press the shutter button to conﬁ rm focus and ﬂ ash battery charge. Press the shutter button all way down to take the picture.

[Lightly press the shutter button]



The available memory capacity may vary depending on shooting condi-

tions and camera settings.



When the Flash Off, Slow synchro mode or DIS mode is selected in

a low lighting condition, the camera shake warning indicator ( Ã )

may appear on the LCD monitor. In this case, use a tripod, support the

camera on a solid surface or change to ﬂ ash shot mode.



Shooting against the light : Please do not take pictures against the sun.



Avoid obstructing the lens or the ﬂ ash when you capture an image.



Compose the image by using the LCD monitor.

Doing so may make the picture dark. To take a picture against the light, please use the [Backlight] in scene shooting mode (see page 23), ﬁ ll-in ﬂ ash (see page 32), spot metering (see page 37), exposure compensation (see page 39) or ACB (see page 51) function.

[Press the shutter button]



Under certain conditions the auto focus system may not perform as expected.

- When photographing a subject that has little contrast.

- If the subject is highly reﬂ ective or shiny.

- If the subject is moving at high speed.

- When there is strong reﬂ ected light, or when the background is very bright.

- When the subject matter has only horizontal lines or the subject is very narrow (such as a stick or ﬂ agpole).

- When the surroundings are dark.

_RECORDING

Page 26

Using the camera buttons to set the camera

ZOOM T/W button

The recording mode function can be set up by using the camera buttons.

POWER button

Used for turning the camera’s power on / off. If there is no operation during the speciﬁ ed time, the camera's power will be turned off automatically to save battery life. Refer to page 60 for more information about the auto power off function.

If the menu is not displayed, this button works as the OPTICAL ZOOM or DIGITAL ZOOM button. This camera has a 3X optical zoom and a 5X digital zoom function. Using both will offer a total zoom ratio of 15X.

SHUTTER button

Used for taking an image or recording voice in the RECORDING mode.



In MOVIE CLIP mode Pressing the shutter button down fully starts the process for recording a movie clip. Press the shutter button once and the movie clip is recorded for as long as the available recording time in the memory allows. If you wish to stop recording, press the shutter button again.



In STILL IMAGE mode

Pressing the shutter button down halfway activates the autofocus and checks the condition of the ﬂ ash. Pressing the shutter button down fully takes and stores the image. If you select voice memo recording, the recording will start after the camera has ﬁ nished storing the image data.



TELE Zoom

Optical zoom TELE : Pressing the ZOOM T button. This will zoom into

Digital zoom TELE : When the maximum (3X) optical zoom is

[WIDE zoom]

the subject i.e. the subject will appear nearer.

selected, pressing the ZOOM T button activates the digital zoom software. Releasing ZOOM T button stops the digital zooming at the required setting. Once the maximum digital zoom (5X) is achieved, pressing the ZOOM T button will have no effect.

Pressing

the ZOOM

T button

[TELE zoom] [Digital zoom 5.0X]

Pressing

the ZOOM

T button

RECORDING_

02 RECORDING

Page 27

ZOOM T/W button



WIDE Zoom

Optical zoom WIDE : Pressing the ZOOM W button. This will zoom

out from the subject i.e. the subject will appear further away. Pressing the ZOOM W button continuously will set the camera to its minimum zoom setting i.e. the subject appears at its furthest from the camera.

Pressing

the ZOOM

W button

[TELE zoom] [Optical zoom 2X] [WIDE zoom]

Pressing

the ZOOM

W button

Digital zoom WIDE : When the digital zoom is in operation, press-

Optical zoom

ing the ZOOM W button will reduce the digital zooming in steps. Releasing ZOOM W button stops digital zooming. Pressing the ZOOM W

Digital zoom

button will reduce the digital zoom and then it will continue to reduce the optical zoom until the minimum setting is reached.

Pressing

the ZOOM

W button

[Digital zoom 5.0X] [TELE zoom] [WIDE zoom]

_RECORDING

Pressing

the ZOOM

W button

Images taken using the digital zoom may take a little longer for the



camera to process. Allow time for this to take place. The digital zoom cannot be used in movie clip shots.



You may notice a decrease in image quality when using the digital



zoom. To view a clearer digital zoom image, press the shutter button halfway



at the maximum optical zoom position and press the zoom T button again. The digital zoom can’t be activated in DIS, Nightscene, Portrait, Children,



Text, Close up, Firework, Self-Shot, Food or Movie Clip modes. Take care not to press the lens as this may cause a camera malfunction.



It is possible that beep and button sounds of the camera may be recorded



while shooting the movie clips.

Page 28

Face Detection(FD) button



Face Detection(FD): This mode detects the face position of the sub-

Selectable modes: Auto, Program, DIS, Photo Help Guide, Portrait,

1. Press the FD(Face Detection) button ( ) in the selectable modes. The FD icon will be displayed on the left of the screen.

2. The size and position of the auto focus frame is set on the face of the subject automatically.

3. Press the shutter button halfway. The focus frame turns to green when the focus is activated.

4. Press the shutter button fully to take a picture.

ject automatically and then sets the focus and exposure. Select this mode for quick and easy portraits.

Children, Beach & Snow, Self Shot, Café



This function can detect up to 9 persons.



When the camera recognises many people at the same time, it will focus on the nearest person.



The Digital zoom is not activated in this mode.



The face detection does not work when setting the effect mode.



When the camera detects a target face, the white colour focus frame will be displayed over the target face and the grey colour focus frame appear over the remaining faces(up to 8). Press the shutter button halfway down to focus on the face and the white focus frame turns green.(Total 9)



Return to previous AF mode if face detection failed.



In some conditions this function cannot work properly.

- When a person wears dark glasses or some part of the face is hidden.

- When the person being taken does not look at the camera.

- Camera doesn't detect a face as the brightness is too dark or too bright.

- The distance between the camera and object are far.



The maximum available Face Detection range is 2.5m (Wide).



The nearer the subject, the faster the camera can recognize the subject.

02 RECORDING

RECORDING_

Page 29

Face Detection(FD) button



Self Portrait When taking pictures of yourself, the area of your face is automatically

detected so that you can take self portraits more easily and quickly.

Selectable modes: Auto, Program, DIS, Photo Help Guide, Portrait,

1. When pressing the Face Detection button again on the face location screen, the Self Portrait icon appears (  ).

Beach & Snow, Self Shot, Café

Function Description / Info

( )

/ Up button

While the menu is showing, the Up button operates as a direction button. If the menu screen does not appear, information or function descriptions of the current ﬁ lming image (ﬁ lming mode) can be accessed through the liquid crystal monitor by pressing the Function description/ Information ( ) button.

Display every piece of information

about shooting.

Display the basic information.

Display description for each feature.

Pressing the

FD button

2. For self-ﬁ lming, set the camera lens towards the face of the object. It automatically detects the face of the object, and emits a guiding sound.

3. Start ﬁ lming by pressing the shutter button.



When locating the face in the center of the screen, it repeatedly emits a faster sound unlike the sounds that are emitted when the face is not in the center.



The guiding sound can be set using the sound setting menu. (See p.54)

_RECORDING

[Filming screen] [Information screen] [Function description screen]



Function description : When pressing the Function description but-

ton on the information screen mode, detailed descriptions of the functions can be viewed. The function description can be cancelled by pressing the Function description button again.

Pressing the

Function

description button

Display description for each feature.

[Examples of Function descriptions ]

Pressing the

Fn button

Set the photo size.

3264x2448

SIZE

Page 30

Macro

)

(

/ Down button

While the menu is showing, press the DOWN button to move from the main menu to a sub menu, or to move down the sub menu. When the menu is not showing, you can use the MACRO / DOWN button to take macro pictures. The distance ranges are shown below. Press the Macro button until the desired macro mode indicator appears on the LCD monitor.

[Auto Focus]

[Auto Macro ( d )] [Super Macro (  )]

[Macro (

)]



Types of focus mode and focus range (W : Wide, T : Tele)

Mode Auto ( Š )

Focus Type Auto macro (

Focus range

Mode Program ( ‰ )

Focus Type Super macro (

Focus range

Mode DIS Mode ( ÿ )

Focus Type Auto macro (

Focus range

Mode FUN Mode ( ë )

Focus Type Super macro (

Focus range

When the macro mode is selected, be particularly careful to avoid



camera shake. When you take a picture within 40cm (Wide zoom) or 50cm (Tele zoom)



in the Macro mode, select the FLASH OFF mode. When you take a picture within the 10cm macro range, the autofocus on



the camera will take longer to set the correct focus distance.

W : 5 ~ Inﬁ nity

T : 40 ~ Inﬁ nity

W : 1 ~ 5

(Wide only)

W : 5 ~ Inﬁ nity

T : 40 ~ Inﬁ nity

W : 1 ~ 5

(Wide only)

) Normal

W : 80 ~ Inﬁ nity T : 80 ~ Inﬁ nity

) Macro ( e ) Normal



W : 5 ~ 80

T : 40 ~ 80

) Normal

W : 80 ~ Inﬁ nity T : 80 ~ Inﬁ nity

) Macro ( e ) Normal



W : 5 ~ 80

T : 40 ~ 80

(Unit: cm)

W : 80 ~ Inﬁ nity T : 80 ~ Inﬁ nity

RECORDING_

02 RECORDING

Page 31

Macro

)

(

/ Down button

Focus lock



Available focusing method, by recording mode

Mode Auto macro Super macro Macro Normal

‰ ÿ

ë _ †

Mode

Auto macro Super macro Macro Normal

( o : Selectable, : Inﬁ nity focus range)

ooo

ooo ooo

SCENE

     

     „ …

o o

_RECORDING

To focus on a subject not positioned in the centre of the picture, use the focus lock function.



Using the Focus Lock

1. Ensure the subject is in the centre of the autofocus frame.

2. Press the SHUTTER button halfway. When the green auto focus frame lights up, it means the camera is focused on the subject. Be careful not to press the SHUTTER button all the way down to avoid taking an unwanted picture.

3. With the SHUTTER button still pressed down only halfway, move the camera to recompose your picture as desired, and then press the SHUTTER button completely to take the picture. If you release your ﬁ nger from the SHUTTER button, the focus lock function will be



 



cancelled.

1. The image to be captured.

2. Press the SHUTTER button halfway and focus on the subject.

3. Recompose the picture and fully depress the SHUTTER button.

Page 32



)

(

Flash

When the menu is displayed on the LCD monitor, pressing the LEFT button makes the cursor shift to the left tab. When the menu is not displayed on the LCD monitor, the LEFT button operates as the FLASH button.



Selecting the ﬂ ash mode

1. Press the Mode button to select a RECORDING mode with the exception of the Movie clip mode or the DIS mode.(p.19)

2. Press the Flash button until the desired ﬂ ash mode indicator is displayed on the LCD monitor.

3. A ﬂ ash mode indicator will be displayed on the LCD monitor.

Use the correct ﬂ ash to suit the environment.



Flash range

ISO

AUTO 0.8 ~ 3.2 0.8 ~ 2.5 0.2 ~ 0.8 0.5 ~ 0.8 0.2 ~ 3.2 0.5 ~ 2.5

When the Super Macro is selected, ﬂ ash is ﬁ xed as the Flash Off mode.

/ Left button

[Selecting the Auto ﬂ ash]

(Unit: m)

Normal Macro Auto macro

WIDE TELE WIDE TELE WIDE TELE

If you press the shutter button after selecting the Auto, Fill-in, Slow



synchro ﬂ ash, the ﬁ rst ﬂ ash ﬁ res to check the shooting condition (Flash range and Power ratio of ﬂ ash). Do not move the camera until the second ﬂ ash ﬁ res. Using the ﬂ ash frequently will reduce the life of the battery.



Under normal operating conditions the re-charging time for the ﬂ ash



is usually within 4 seconds. If the battery is weak, the charging time will be longer. In the DIS mode, [Landscape], [Close up], [Text], [Sunset], [Dawn],



[Firework], [Self Shot], [Food], [Café] scene modes and the Movie clip mode, the ﬂ ash will not function. Take photographs within the ﬂ ash range.



The image quality is not guaranteed if the subject is too close or



highly reﬂ ective. When taking an image in poorly lit conditions with the ﬂ ash, there



may be a white speck in the captured image. The speck is caused by the ﬂ ash light reﬂ ecting off atmospheric dust.

02 RECORDING

RECORDING_

Page 33



)

(

Flash



Flash mode indicator

Icon Flash mode Description

]





/ Left button

Auto ﬂ ash

Auto & Red eye

reduction

Fill in ﬂ ash

Slow synchro

Flash off

Red-eye reduction

If the subject or background is dark, the camera ﬂ ash will operate automatically.

If a subject or background is dark, the camera ﬂ ash will work automatically and will reduce the red-eye effect by using the redeye reduction function.

The ﬂ ash ﬁ res regardless of the available light. The intensity of the ﬂ ash will be au- tomatically controlled to suit the prevailing conditions.

The ﬂ ash operates with a slow shutter speed to obtain a balanced correct exposure. In poor lighting conditions the camera shake warning indicator ( on the LCD monitor.

The ﬂ ash does not ﬁ re. Select this mode when capturing images in a place or situation where ﬂ ash photography is prohibited. When you capture an image in poorly lit conditions, the camera shake warning indicator ( LCD monitor.

When a shot with "red eye" is detected, this mode will reduce the red-eye effect automatically.

) will display

) will appear on the



Available ﬂ ash mode, by recording mode

Mode

Š ‰

^]  ª Œ

oo oo oooooo

‚

oooooo oooooo

†

Mode

^]  ª Œ

SCENE

  

ooo ooo

     

 

„ … ˆ

( o : Selectable)



ooo

o o o o o

o o o

_RECORDING

Page 34

Self-timer

When the menu is displayed on the LCD monitor, pressing the Right button makes the cursor shift to the right tab. When the menu is not displayed on the LCD monitor, the RIGHT button operates as the Self-timer (  ) button. This function is used when the photographer would also like to be in the image.



  

( )

/ Right button

If you operate the Self-timer button during the self-timer operation, the self-timer function is cancelled. Use a tripod to prevent the camera from shaking. In Movie Clip mode, only the 10SEC self-timer will work. When you select 2SEC self-timer with ﬂ ash, the delay (2 seconds) can be extended according to the ﬂ ash charging status.



Selecting the self-timer

Select a Recording mode with the exception

1. of Voice recording mode. (p.19)

Press the SELF-TIMER / RIGHT (  ) button

until the desired mode indicator is displayed on the LCD monitor. A 10 second, 2 second, Double self-timer or Motion timer icon appears on the LCD monitor.

3. When you press the SHUTTER button, the picture will be taken after the speciﬁ ed time has elapsed.



Self-timer mode indecator

Icon Mode Description









10SEC

self-timer

Double

self-timer

Motion

Pressing the shutter button will allow an interval of 10 seconds before the image is taken.

2SEC

Pressing the shutter button will allow an interval of 2 seconds before the image is taken.

A picture will be taken after about 10 seconds and 2 seconds later a second picture will be taken.

The camera detects the subject's movement 6 seconds after pressing the Shutter button, and the

Timer

picture is taken when the movement is stopped.

[Selecting the 10 SEC

self-timer]

02 RECORDING

RECORDING_

Page 35

Self-timer



Motion Timer

( )

/ Right button

Motion Icon & Self-timer lamp

Pressing the Shuter button after setting the Motion Timer

Blink (1 second interval)

Detecting the subject's movement Blink (0.25 second interval)

No movement is detected



The Motion Timer ﬂ ows are as followings. (Movie Clip mode excluded) Selecting the Motion Timer  Pressing the Shutter button

Conﬁ rming the composition (Within 6 sec.) (Swing your hands fully)



Taking an image (after 2 sec.)

*1: The camera detects the subject's movement 6 seconds after pressing the Shutter

button, so conﬁ rm the composition within 6 seconds.

*2: Move your body or hands fully.

Turn on and the image is taken after 2 seconds



Stopping the detection (Do not move)

Starting the detection



In the following cases, the Motion Timer may not operate.

The focus distance is over 3m.



The exposure is too bright or dark



In backlight conditions.



The movement is insigniﬁ cant



The movement is detected beyond the



The detection range of

Motion Timer

center part (50%) of the sensor where the movement is recognized. If the camera doesn`t sense any



movement for 30 seconds, or the camera doesn’t sense stillness after sensing movement

_RECORDING

MENU / OK button



MENU button

- When you press the MENU button, a menu related to each camera mode will be displayed on the LCD monitor. Pressing it again will return the LCD to the initial display.

- A menu option can be displayed when the following are selected :

MOVIE CLIP and STILL IMAGE mode. There is no menu available when the Voice recording or Photo Help Guide mode is selected.

RECORDING

ACB Voice Memo Voice Record



OK button

[Pressing the MENU button]

[Menu off]

- When the menu is displayed on the LCD monitor, this button is used for shifting the cursor to the sub menu or for conﬁ rming data.



Exit

[Menu on]

Center AFFocus Area Off Off



Move



Page 36

Fn button

You can use the Fn button to set the following menus.

(o : Selectable)



Š‰ÿë_†

Size ooooooop.36

Quality/

Frame rate

Metering o o o o p.37

Drive o

ISO o o p.38

White

Balance

Stabilizer o p.40

*1: This menu is only available in the Children scene mode. (  ) *2: This menu is only available in the Night scene mode. (  )

oooo oop.36

o o o o p.38

oo oo p.39

Page

op.37

op.40

How to use the Fn menu

1. Press the Fn button in an available mode.

2. Select a desired menu by pressing the Up / Down button. And then a sub menu will be displayed at the bottom right of the LCD monitor.

SIZE

3264x2448

3. Select a desired menu by pressing the Left / Right button and then

press the OK button.

SIZE

3264x2448

Up / Down

button

Left / Right

button

QUALITY

Fine

SIZE

3264x2176

02 RECORDING

RECORDING_

Page 37

Size

You can select the image size appropriate for your application.

(Unit: pixel)

Icon

Still


mode

Movie clip

mode

Ÿ¬

3264 x

2592 x

Size

2448

2176

1824

Icon

800x592 720x480 640x480 320x240

Size

1944

2048 x

1536

1024 x

768

Quality / Frame rate

You can select the compression ratio appropriate for your application of the captured images. The higher the compression ratio, the lower the picture quality.

Mode STILL IMAGE mode MOVIE CLIPO mode

Icon

Sub menu

File

Format

VWX

Super

Fine

jpeg jpeg jpeg avi avi avi

Fine Normal 30 FPS 20 FPS 15 FPS

[ STILL IMAGE mode ]



_RECORDING

SIZE

3264x2448

[ MOVIE CLIP mode ]

SIZE

800x592

The higher the resolution, the lower the number of shots available because high resolution images require more memory.

QUALITY

Fine

[ STILL IMAGE mode ]

This ﬁ le format complies with the DCF (Design rule for Camera File



FRAME RATE

20FPS

[ MOVIE CLIP mode ]

system). JPEG (Joint Photographic Experts Group) :



JPEG is the image compression standard developed by the Joint Photographic Experts Group. This is the most commonly used compression for photos and graphics because of its efﬁ ciency.

Page 38

Metering

If you cannot obtain suitable exposure conditions, you can change the metering method to take brighter pictures.

[Multi] : Exposure will be calculated

[Spot] : Only the rectangular area in the centre of the LCD

[Center We ighted]: Exposure will be calculated based on an average of

If the subject is not the centre of the focus area, do not use the spot

metering as this may result in an exposure error. In this circumstance, it is better to use exposure compensation.

based on an average of the available light in the image area. However, the calculation will be biased towards the centre of the image area. This is suitable

METERING

Multi

for general use.

monitor will be metered for light. This is suitable when the subject in the centre is exposed correctly, regardless of the back lighting.

the available light in the image area. However, the calculation will be biased towards the centre of the image area. This is suitable for taking a picture of small objects like ﬂ owers or insects.

Drive mode

You can select continuous shot, and AEB (Auto Exposure Bracketing).

[Single] : Take one picture only. [Continuous] : Images will be taken

[Motion Capture] : This takes 5 shots per

[AEB] : Take three pictures in a series in different exposures:

High resolution and picture quality increases ﬁ le saving time, which



increases stand-by time. If the [Continuous], [Motion Capture] or [AEB] sub menu is selected,



the ﬂ ash will be off automatically. If less than 3 pictures are available in the memory, the AEB shooting



is not available. If less than 30 pictures are available in the memory, the motion



capture is not available. It is best to use a tripod for the AEB shooting as the time to save each



image ﬁ le is longer and blurring caused by camera shake may occur.

continuously until the shutter button is released.

second, when the shutter

DRIVE

Single

is pressed and held down. After completing the continuous shooting, images are saved and the images play back on the Rear LCD. The maximum number of shots is 30 and the image size is ﬁ xed as VGA.

short exposure (-1/3EV), standard exposure (0.0EV), and over exposure (+1/3EV).

02 RECORDING

RECORDING_

Page 39

ISO

You can select the ISO sensitivity when taking pictures. The speed or speciﬁ c light-sensitivity of a camera is rated by ISO numbers.

White balance

The white balance control allows you to adjust the colours to appear more natural.

[Auto] : The camera's sensitivity is automati-

cally changed by variables such as lighting value or subject brightness.

[ISO 50, 100, 200, 400, 800, 1600, 3200 ] :

You can increase the shutter speed while the same amount of light is present, by increasing the ISO sensitivity. However, the image may be saturated in high luminance. The higher the ISO value, the higher the camera’s sensitivity to light and therefore the greater its capacity to take pictures in dark conditions. However, the noise level in the image will increase as the ISO value increases, making the image appear coarse.

When the ISO 3200 menu is selected, the image size is ﬁ xed as 3M, 1M.

_RECORDING

ISO

Auto

WHITE BALANCE

Auto WB

Mode Icon Description

The camera automatically selects the

Auto WB

Daylight

Cloudy

Fluorescent_H

Fluorescent_L

Tungsten

Custom Set

Different lighting conditions may cause a colour cast on your images.

appropriate white balance settings,

depending on the prevailing lighting conditions.

For taking images outside.

For taking images under a cloudy and



overcast sky. For shooting under daylight ﬂ uorescent types



of three-way ﬂ uorescent lighting. Shooting under white ﬂ uorescent lighting.



For shooting under tungsten (standard light bulb) lighting.

Allows the user to set the white balance

according to the shooting condition.

Page 40

White balance



Using the Custom White Balance White balance settings may vary slightly depending on the shooting

environment. You can select the most appropriate white balance setting for a given shooting environment by setting up the custom white balance.

1. Select the CUSTOM ( Å ) menu of the White Balance and place a sheet of white paper in front of the camera so that the LCD monitor shows only white.

2. MENU/OK button : selects previous

custom white balance.

Shutter button : saves new custom white balance.

- The custom white balance value will be applied, starting with the next picture you take.

- The user conﬁ gured white balance will remain effective until it is overwritten.

White paper

Exposure compensation

This camera automatically adjusts the exposure according to the ambient lighting conditions. You can also select the exposure value by using the Fn button.



Compensating Exposure

1. Press the Fn button, and then use the UP and DOWN buttons to select the exposure compensation icon ( Â ).

2. Use the LEFT and RIGHT buttons to set the desired exposure compensation factor.

3. Press the OK or Fn button. The value you set will be saved and the Exposure Compensation setup mode will be closed. If you change the exposure value, the exposure indicator ( Â ) will be displayed on the bottom of the LCD monitor.

A negative exposure compensation value reduces the exposure.

Note that a positive exposure compensation value increases the exposure and the LCD monitor will appear white or you may not get good pictures.

02 RECORDING

RECORDING_

Page 41

Movie Clip frame stabiliser

This function helps stabilize images captured during movie recording. You can select this menu only in the MOVIE CLIP mode. If the memory card is not inserted, this function will not operate.

[Off] : Movie clip frame stabilizer function is

disabled.

[On] : Prevents camera shake during movie

recording.

A negative exposure compensation value reduces the exposure. Note that a positive exposure compensation value increases the exposure and the LCD monitor will appear white or you may not get good pictures.

STABILIZER

Off

Slow shutter speed

This camera automatically adjusts the shutter speed and aperture values to the shooting environment. However, in Night scene mode, you can set the shutter speed and aperture values to your preference.



Changing the Shutter speed and Aperture value

1. Select the [Nightscene] mode. (p.19)

Press the Fn button and Slow shutter menu will be displayed.

3. Conﬁ gure the Long Time shutter value with the 5 function button.

4. Press the Fn button again. The value you set will be saved and the mode will switch to Night scene mode.

_RECORDING

Aperture Value Wide : Auto, F3.5 ~ F6.3 Tele : Auto, F4.5 ~ F8.0

F 3.5

Shutter Speed

Auto, 1~16s

E (Effect) button

It is possible to add special effects to your images by using this button.



Available Effects, by recording mode ( o : Selectable)

†‰Šë_„…ˆ

oooooooooooo

button

This button will not operate in Auto, DIS, Voice recording mode and



some scene modes (Nightscene, Text, Sunset, Dawn, Backlight, Firework, Beach&Snow). Even if the camera is turned off, the effect setting will be preserved.



Page 42

E (Effect) button: Photo Style Selector

You can add various effects to the image without using image editing software. Press the E button in an available mode.

Selectable modes: Auto, Program

Photo Style Selector

OK E

Set Back

E (Effect) button: Image editing

Press the E button in the [Program], [Movie], [Photo Help Guide], [Portrait], [Children], [Landscape], [Close up], [Self Shot], [Food] and [Café] scene modes.

Colour

1. Select the Colour ( ï ) menu by pressing

1. Select the desired Photo style selector by pressing the Left/Right button and press the OK button.

2. Select the desired sub menu by pressing

2. Press the Shutter button to take an image.

Style mode Icon Description

Normal

Soft

Vivid

Forest

Retro

Cool

Calm

Classic The image will be applied with classic colours.

No style effect is added to the image.

The image will be applied with soft colours.

The image will be applied with vivid colours.

The image will be applied with clear natural colours.

The image will be applied with sepia tones.

The image will be applied with cool colours.

The image will be applied with calm colours.

3. Press the Shutter button to take an image.

the Up/Down button.

the Left/Right button and press the OK button.

Icon Description

No effect is added to the image.

Captured images will be stored in black and white.

Captured images will be stored in a sepia tone

(a gradient of yellowish brown colours).

Captured images will be stored in a red tone.

Captured images will be stored in a green tone.

Captured images will be stored in a blue tone.

Save the image in negative mode. Captured image will be saved in set RGB tone.

Color

OK E

Set Back

02 RECORDING

RECORDING_

Page 43

E (Effect) button: Image editing



Custom colour : You can change the R (Red),

G (Green) and B (Blue) values of the image.

- Up/Down button : Selects R, G, B

- Left/Right button : Changes the values

Custom Color

OK E

Set Back

Custom Color

Press the E button in the [Program] mode.

Sharpness

1. Select ( ) by pressing the Up/Down button and a bar for selecting the sharpness will be displayed.

2. Change the Sharpness by pressing the Left/Right button.

3. Press the Shutter button to take an image.

Sharpness

Set Back

EOK

_RECORDING

OK E

Set Back

Contrast

1. Select (  ) by pressing the Up/Down button and a bar for selecting the contrast will be displayed.

2. Change the contrast by pressing the Left/Right button.

3. Press the Shutter button to take an image.

Saturation

1. Select ( button and a bar for selecting the saturation will be displayed.

2. Change the saturation by pressing the Left/Right button.

3. Press the Shutter button to take an image.

) by pressing the Up/Down

Contrast

Set Back

Saturation

Set Back

EOK

Page 44

E (Effect) button: FUN

Cartoon

You can add a text box to the image to make the image cartoon like.



Press the E button in the FUN recording mode.

)

Cartoon

Frame Set



FUN



Move Exit



Select Cartoon (

Select a desired frame by pressing the Left/Right button and then press the OK button

Capture Edit

SH Fn

Press the Fn button and select a desired text box position by pressing the Left/Right button.

02 RECORDING

Capture Edit

Select the text box position of the third image with the same procedure and take the third image.

Save Delete

OK Fn

Capture Edit

SH Fn

Press the OK button and the ﬁ le is saved as a new ﬁ le name.

Press the Shutter button to take an image.

Capture Move



RECORDING_

Page 45

E (Effect) button: FUN



Changing the cartoon image before taking the last shot Before saving the cartoon image, you can take more images.

1. Select an image to delete by using the Left/Right button.

2. Press the Fn button and the image is deleted.

Pre-set focus frame

You can make the subject stand out from its surroundings. The subject will be sharp and in focus while making the rest out of focus.



Press the E button in the FUN recording mode.

Pressing the Fn

Save Delete

OK Fn



button

Capture Edit

SH Fn



3. To take a new image, press the Shutter button.

If you press the Play mode, MENU, E button or M (Mode) button



during the cartoon shots, each camera working mode is executed. The previously captured images will be deleted.

_RECORDING

FUN

High Light

Select High Light

)



Move Exit



(

Range Set



1. Select a proper menu by pressing the Left/Right button and press the OK button.

High Light

Range Set



[Range 1] [Range 2] [Range 3] [Range 4]

The preset focus frame will appear.

High Light High Light

Range Set



High Light

Range Set



Range Set



Press the shutter button to capture an image.

Capture Edit

SH Fn

Page 46

E (Effect) button: FUN



Moving and changing the focus frame

You can change the focus frame after selecting a Range menu.

Pressing the

Capture Edit

[Point the camera towards the

subject and compose the image

by using the LCD monitor]

Capture Edit

SH Fn

Pressing the Shutter button.

[Final image]

Fn button

Pressing the

Fn button

Capture Move

[The range is activated: The focus

frame is changed to a solid line.]

Capture Move

Pressing Up/ Down/Left/Right button

[After changing the range]

Composite shooting

You can combine 2 - 4 different shots in a still image.



Press the E button in the FUN recording mode.

FUN

Select Composite

( )



Move Exit



1. Select a desired menu by pressing Left/Right button and press the OK button.

Composite Composite Composite



Composite SetOK



Composite SetOK

[Composite 1] [Composite 2] [Composite 3] [Composite 4]

2. After selecting a desired menu, press the shutter button to take a picture.



Composite SetOK

Composite

Composite Set



RECORDING_

Composite



Composite SetOK

02 RECORDING

Page 47

E (Effect) button: FUN

Selecting 2 composite shots

Pressing the

Shutter button.

Capture

[Ready for taking]

Pressing the

OK button

Capture Delete

[First shot]

Pressing the Shutter button.



Changing a part of composite shot before taking the last shot Before taking the last composite shot, you can change a part of composite shot.

1. During the composite shots, press the Fn button.

2. A previous image will be deleted and new frame will be displayed. To delete a previously taken image, press the Fn button again.

Pressing the Fn

button

Capture Delete

[Before selecting the

SH Fn



3rd image]

Capture Delete

SH Fn

[Moving backward to the

2nd image]

Save Delete

[The ﬁ nal picture]

•

After taking the last image, press the OK button to save the image.

You can use the Flash, Self-timer, Macro Focus and the Zoom T/W



OK Fn

[Second shot]

button during the composite shooting. If you press the Play mode, MENU, E button or M (Mode) button



during the composite shots, each camera working mode is executed. The previously captured images will be deleted.

_RECORDING

3. Press the Shutter button to capture a new image.

Page 48

E (Effect) button: FUN



Changing a part of composite shot after taking the last shot After taking the last shot, you can change a part of the composite shot.

1. After taking the last shot, a cursor to select a frame will appear. Press the Up/Down/Left/Right button to select the frame.

2. Press the Fn button and an image will be deleted. Composite frame

will be activated.

3. Press the Shutter button. You can take more images by using the

Up/Down/Left/Right button and Fn button.

4. Press the OK button again to save the captured image.

OK Fn

Save Delete

[After taking 4th shot]

Pressing the Shutter button

OK Fn

Save Delete

[Taking 3nd shot again]

Pressing the

Left button.

Capture

[Deleting 3nd shot]

Pressing the

OK button

OK Fn

Save Delete

[Moving backward to the 3nd shot]

Pressing the Fn button

[Final Image]

02 RECORDING

RECORDING_

Page 49

E (Effect) button: FUN

Photo Frame

You can add 9 types of frame-like borders to a still image you want to capture. Date & Time information will not be printed on the stored image taken with Photo Frame menu.



Press the E button in the FUN recording mode.

FUN

 

_RECORDING

Move Exit

Capture Move

Select Photo

Frame (

Pressing the

Fn button

)

Photo Frame



Frame Set

Capture Frame

Pressing the OK button

1. Select a desired sub menu by pressing the Left/Right button and press the OK button.

2. Press the shutter button to take a picture.

Page 50

E (Effect) button: FUN

Capture

Colour mask

With this menu, you can select a part you want to highlight. The rest of the image will be in black and white.



Press the E button in the FUN recording mode.

Color Mask

OKE

Back Set

[Final image]

Select Color Mask ( ¾ ) by pressing the OK button and the Mask mark will be displayed on the LCD monitor.

Press the Shutter button the mask added image is taken.

FnSH

Capture Edit

FnSH

Capture Edit

[Mask added image]

Press the Fn button. You can change the size and locaton of the mask.

Press the Fn button.

Capture

Move Size

Zoom T/W button : Changing the mask size

Capture

Move Size

Up/Down/Left/Right button: Moving the mask

Capture

Move Size

02 RECORDING

RECORDING_

Page 51

Using the LCD monitor to adjust the camera settings

You can use the menu on the LCD monitor to set up recording functions.



The items indicated by are default settings.

Mode Menu Sub menu Available mode Page

Focus Area

( Recording )

Voice Memo Off On

Voice Record

Center AF Multi AF

ACB Off On

-p.52

Recording ( )

Auto Focus type

You can select your preferred Focus Area according to the shooting conditions.

p.50

p.51

[Center AF] : The rectangular area in the center of the LCD monitor

p.51

[Multi AF] : This camera selects all of available AF point from the 9

will be focused

AF points.

RECORDING Focus Area ACB Voice Memo Voice Record





Center AF



Multi AF



Back Set

Voice Mute Off On

Menus are subject to change without prior notice.

_SETUP

p.53

[Center AF] [Multi AF]

When the camera focuses on the subject, the auto focus frame turns to green. When the camera doesn't focus on the subject, the auto focus frame turns to red.

Page 52

Recording ( )

ACB

This function is to adjust the contrast automatically when taking photos in an environment with big exposure differences, i.e. backlight or contrast. This function adjusts the brightness automatically and allows the subject to be photographed clearly.

- [ACB] Sub menus: [Off], [On].

When using the [Program] mode, the ACB function will operate.

RECORDING Focus Area ACB Voice Memo Voice Record

Back Set





Off



Voice Memo

You can add your voice-over to a stored still image. (Max. 10 sec.)

- If the voice memo indicator is displayed on the LCD monitor, the setting is completed.

- Press the shutter button and take a picture. The picture is stored on the memory card.

- Voice memo will be recorded for ten seconds from the moment the picture is stored. In the middle of the sound recording, pressing the shutter button will stop the voice memo.

RECORDING Focus Area ACB Voice Memo Voice Record

Back Set





Off On

Stop

SETUP_

03 SETUP

Page 53

Recording ( )

Voice Recording

A voice can be recorded for as long as the available recording time (Max. 10 hour) allows.

Press the shutter button to record a voice.

- Press the shutter button once and voice is recorded for as long as the available recording time (max:10 hour) allows. The recording time will be displayed on the LCD monitor. Voice will still be recorded if the shutter button is released.

- If you wish to stop recording, press the shutter button again.

- File type : *.wav

RECORDING

Focus Area

Voice Memo Voice Record

Center AF



OffACB



Off





Move Set



REC Exit

[Voice recording mode]



Pausing while recording a voice

Using this function, you can record your favourite voice clips into a voice recording ﬁ le without having to create multiple voice recording ﬁ les.

1. Press the Pause button ( Ø ) to pause recording.

Stop REC

[Voice recording mode]

2. Press the Pause button ( Ø ) again to resume the recording.

3. If you wish to stop recording, press the shutter button again.

A distance of 40cm between you and the camera (microphone) is



the best distance to record sound. If the camera power is turned off while the voice recording is



paused, the voice recording is cancelled.

_SETUP

Page 54

Recording ( )

Recording the movie clip without voice

You can record the movie without voice.

Select [On] of [Voice Mute] menu in the Movie clip mode. ( Ç ) icon will appear on the LCD monitor. Press the Shutter button and a movie will record for as long as the memory capacity allows without voice.

RECORDING

Voice Mute





Off

Back Set

Sound menu

In this mode, you can set up sound settings. You can use the setup menu in all camera modes, except Voice Recording mode.



The items indicated by

Mode Menu Sub Menu

Volume

Start Sound

Shutter Sound



( Sound )

Beep Sound

AF Sound

are default settings.

Available mode Page

Off

Low

Medium

High

Off Sound 1 Sound 2 Sound 3

Off

p.54

03 SETUP

Self Portrait

Off

SETUP_

Page 55

)

(

Sound



Volume

You can select a volume of start up sound, shutter sound, beep sound and AF sound.

SOUND

- [Volume] sub menu : [Off], [Low], [Medium], [High]

Volume Start Sound Shutter Sound Beep Sound AF Sound Self Portrait

Back Set





Off Low



Medium



High



Start up sound

You can select the sound that is activated whenever the camera is turned on.

- Start up sound : [Off], [Sound 1, 2, 3]

SOUND Volume Start Sound Shutter Sound Beep Sound AF Sound Self Portrait

Back Set





Off Sound 1



Sound 2



Sound 3



Shutter sound

You can select the shutter sound.

- Shutter sound : [Off], [Sound 1, 2, 3]

_SETUP

SOUND Volume Start Sound Shutter Sound Beep Sound AF Sound Self Portrait

Back Set





Off Sound 1



Sound 2 Sound 3



Beep Sound

If you set sound to ON, various sounds will be activated for camera startup, when buttons are pressed, so that you can be aware of the camera operation status.

[Beep Sound] sub menu : [Off], [Sound 1, 2, 3]

AF sound

If you set AF sound to on, AF sound will be activated when the Shutter button is pressed down half way so that you can be aware of the camera operation status.

- [AF sound] sub menu : [Off], [On]

Self Portrait Sound

This occurs when it automatically detects the location of the subject’s face when taking a self-portrait.

- This feature can be set by using the [OFF] and [ON] buttons.

SOUND Volume Start Sound Shutter Sound Beep Sound AF Sound Self Portrait

Back Set



SOUND Volume Start Sound Shutter Sound Beep Sound AF Sound Self Portrait

Back Set



SOUND Volume Start Sound Shutter Sound Beep Sound AF Sound Self Portrait

Back Set





Off



Sound 1



Sound 2 Sound 3



Off On



Off



Page 56

Setup menu

In this mode, you can set up basic settings. You can use the setup menu in all camera modes, except Voice Recording mode.



The items indicated by

Mode

Language p.56

(

Display

)

Date & Time

World Time

are default settings.

Sub menu

yy/mm/dd mm/dd/yy dd/mm/yy Off

London

Athens, Helsinki

Teheran Abu Dhabi

Mumbai, New Delhi

Almaty Yangon

Bangkok, Jakarta

Seoul, Tokyo

Guam, Sydney Okhotsk

Wellington, Auckland

Honolulu, Hawaii

Rome,Paris,Berlin

Moscow

Kabul Tashkent

Kathmandu

Beijing, Hong Kong

Darwin, Adelaide

Samoa, Midway

Alaska

Page

p.56

Mode

(

Display

”

(

Settings

Menus are subject to change without prior notice.

Menu Sub menu Page

LA, San Francisco Denver, Phoenix

Chicago, Dallas

World

Date & Time

Start Image

)

LCD Bright

Quick View

LCD Save Off On p.57

Format No Yes p.58

Reset No Yes p.58

File

Imprint

)

Power Off

Video Out NTSC PAL p.60

AF Lamp Off On p.61

Caracas, La Paz

Time

Buenos Aires Mid-Atlantic

Cape Verde -

Off Logo

User Image -

Auto Dark

Normal Bright

Off 0.5 sec

1 sec 3 sec

Reset Series p.59

Off Date

Date&Time -

Off 1 min

10 min -

New York, Miami

Newfoundland

SETUP_

p.56

p.57

p.59

p.603 min 5 min

03 SETUP

Page 57

Display ( " )

Language

There is a choice of language that can be displayed on the LCD monitor. Even if the battery is removed and inserted again, the language setting will be preserved.

- Language sub menu : English, Korean, French, German,

Spanish, Italian, S.Chinese, T.Chinese, Russian, Portuguese, Dutch, Danish, Swedish, Finnish, Thai, Bahasa (Malay / Indonesian), Arabic, Czech, Polish, Hungarian and Turkish.

_SETUP

DISPLAY

Language Date&Time Start Image LCD Bright

Quick View LCD Save

Back Set





ENGLISH

한국어

FRANÇAIS DEUTSCH ESPAÑOL ITALIANO

Setting up the Date / Time / Date type

You can change the date and time that will be displayed on the captured images and set up the date type. Setting [World Time] enables you to display the local date and time on the LCD monitor when travelling overseas.



Date type : [yy/mm/dd], [mm/dd/yy],

[dd/mm/yy], [Off]



World Time

- Available cities: London, Cape Verde, Mid-Atlantic, Buenos Aires, Newfoundland, Caracas, La Paz, NewYork, Miami, Chicago, Dallas, Denver, Phoenix, LA, San Francisco, Alaska, Honolulu, Hawaii, Samoa, Midway, Wellington, Auckland, Okhotsk, Guam, Sydney, Darwin Adelaide, Seoul, Tokyo, Beijing, Hong Kong, Bangkok, Jakarta, Yangon, Almaty, Kathmandu, Mumbai, New Delhi, Tashkent, Kabul, Abu Dhabi, Teheran, Moscow, Athens, Helsinki, Rome, Paris, Berlin

DST : Daylight Saving Time

DISPLAY

Language



Back Set

Set



London

2008/03/01

yy/mm/dd

DST

Date&Time Start Image LCD Bright Quick View LCD Save



WORLD TIME

London

[ GMT ] 2008 /03 /01 13:00



13:00

Page 58

Display ( " )

Start up image

You can select the image that is ﬁ rst displayed on the LCD monitor whenever the camera is turned on.

- Sub menus : [Off], [LOGO], [User Image]

- Use a saved image for the start-up image with the [Start Image] in the [RESIZE] menu in the play mode.

- The start-up image will not be deleted by [Delete] or [Format] menu.

- The User images will be deleted by [Reset]

DISPLAY Language Date&Time Start Image LCD Bright Quick View LCD Save

Back Set









Off







menu.

LCD brightness

You can adjust the LCD brightness.

- Sub menus : [Auto], [Dark], [Normal], [Bright]

DISPLAY Language Date&Time Start Image LCD Bright Quick View LCD Save

Back Set





Auto



Dark Normal



Bright



Quick view

If you enable Quick View before capturing an image, you can view the image you just captured on the LCD monitor for the duration set in the [Quick View] setup. Quick view is possible only with still images.

- Sub menus [Off] : The quick view function

can’t be activated.

[0.5, 1, 3 sec] : The captured image is

brieﬂ y displayed during the selected time.

DISPLAY Language Date&Time Start Image LCD Bright Quick View LCD Save

Back Set





Off



0.5 sec



1 sec 3 sec



LCD save

If you set the [LCD save] to On and the camera isn't operated during the speciﬁ ed time, the LCD monitor will be turned off automatically.

- Sub menus [Off] : The LCD monitor will not be turned

off.

If the camera isn’t operated during

[On] :

the speciﬁ ed time (about 30 SEC.), the camera power will be idle (Camera status lamp:Blinking) automatically.

DISPLAY Language Date&Time Start Image LCD Bright Quick View LCD Save

Back Set





Off



SETUP_

03 SETUP

Page 59

Settings

(” )

Formatting a memory

This is used for formatting the memory. If you run [Format] on the memory, all ﬁ les which are image, video clip, multimedia and even protected images will be deleted. So be sure to download important ﬁ les to your PC before formatting the memory.

- Sub menus [No] : The memory will not be formatted. [Yes] : A window for conﬁ rming the selection

appears. Select the [Yes] menu. A [Processing!] message appears and the memory will be formatted. If you run FORMAT in Play mode, a [No Image!] message will appear.



Be sure to run [Format] on the following types of memory card.

- A new memory card, or an unformatted memory card

- A memory card that has a ﬁ le this camera can't recognise or one that has been taken from another camera.

- Always format the memory card using this camera. If you insert a memory card that has been formatted using other cameras, memory card readers, or PCs, you will get a [Card Error!] message.

SETTINGS Format Reset File Imprint Power Off Video Out

Back Set





Yes



Initialisation

All camera menu and function settings will be restored to their default values. However, values for DATE / TIME, LANGUAGE, and VIDEO OUT will not be changed.

- Sub menus [No] : Settings will not be restored to their

defaults.

[Yes] : A window to conﬁ rm the selec-

tion will be displayed. Select the [Yes] menu and all settings will be restored to their defaults.

SETTINGS Format Reset File Imprint Power Off Video Out

Back Set





Yes



_SETUP

Page 60

Settings

(” )

File name

This function allows the user to select the ﬁ le naming format.

[Reset] : After using the reset function, the

next ﬁ le name will be set from 0001 even after formatting, deleting all or inserting a new memory card.

[Series] : New ﬁ les are named using numbers

that follow the previous sequence, even when a new memory card is used, or after formatting, or after deleting all pictures.

- The ﬁ rst stored folder name is 100SSCAM, and the ﬁ rst ﬁ le name is SDC10001.

- File names are assigned sequentially from SDC10001  SDC10002



~  SDC19999.

- The folder number is assigned sequentially from 100 to 999 as follows: 100SSCAM  101SSCAM  ~  999SSCAM.

- Maximum numbers of ﬁ les in a folder are 9999.

- The ﬁ les used with the memory card conform to the DCF (Design rule for Camera File systems) format. If you change the image ﬁ le name, the image may not play back.

SETTINGS Format Reset File Imprint Power Off Video Out

Back Set





Reset

Series



Imprinting the recording date

There is an option to include DATE / TIME on still images.

- Sub menus [Off] : The DATE & TIME will not be

imprinted on the image ﬁ le.

[Date] : Only the DATE will be

imprinted on the image ﬁ le.

[Date&Time] : The DATE & TIME will be

imprinted on the image ﬁ le.

The Date & Time are imprinted at the bottom right side of the still image.

The imprint function is applied only to still images.

Depending on the manufacturer and print mode, the date printed on an image may not be printed correctly.

SETTINGS Format Reset File Imprint Power Off Video Out





Off Date



Date&Time



Back Set

03 SETUP

SETUP_

Page 61

Settings

(” )

Auto power off

This function switches the camera off after a set amount of time in order to prevent unnecessary battery drainage.

- Sub menus [Off] : The power off function will

not operate.

[1, 3, 5, 10 min] : The power will turn off

automatically if not used for the period of time speciﬁ ed.

- After replacing the battery, the power off setting will be preserved.

- Note that the automatic power off function will not operate if the

camera is in the PC / Printer mode, slide show, playing back a voice recording and playing back a movie clip.

SETTINGS Format Reset File Imprint Power Off Video Out

Back Set





Off 1 min



3 min



5 min 10 min



Selecting Video out type

The Movie output signal from the camera can be NTSC or PAL. Your choice of output will be governed by the type of device (monitor or TV, etc.) to which the camera is connected. PAL mode can support only BDGHI.



Connecting to an external monitor When the camera is connected to an

external monitor, the image and menus on the LCD monitor will be visible on the external monitor and the LCD monitor of the camera.

SETTINGS Format Reset File Imprint Power Off Video Out



Yellow - Video

White - sound



NTSC



PAL

Back Set

_SETUP

Page 62

Settings

(” )

- NTSC : U.S.A, Canada, Japan, South Korea, Taiwan, Mexico.

- PAL : Australia, Austria, Belgium, China, Denmark, Finland, Ger-

many, U.K., Holland, Italy, Kuwait, Malaysia, New Zealand, Singapore, Spain, Sweden, Switzerland, Thailand, Norway.

- When using a TV as an external monitor, you will need to select the external or AV channel of the TV.

- There will be a digital noise on the external monitor, but it is not a malfunction.

- If the image is not in the centre of the screen, use the TV controls to centre it.

- When the camera is connected to an external monitor, some parts of the image may not be displayed.

- When the camera is connected to an external monitor, the menu will be visible on the external monitor and the menu functions are the same as those indicated on the LCD monitor.

- When you connect the A/V cable in a recording mode, the camera mode is changed to the Playback mode automatically and an image will be displayed.

Auto Focus lamp

You can turn on and off the Auto Focus lamp.

- Sub menus [Off] : The AF lamp will not light up in

low light conditions.

[On] : The AF lamp will light up in low

light conditions.

SETTINGS Reset File Imprint Power Off Video Out AF Lamp





Off



Back Set

03 SETUP

SETUP_

Page 63

Starting play mode

Turn the camera on and select Play mode by pressing the play mode button ( Î ). The camera can now play back the images stored in the memory. If the memory card is inserted in the camera, all the camera functions apply only to the memory card. If the memory card is not inserted in the camera, all the camera functions apply only to the internal memory.

Playing back a still image

1. Select the PLAY mode by pressing the play mode button ( Î ).

2. The last image stored on the memory is displayed on the LCD monitor.

3. Select an image that you want to view by pressing the Left/ Right button.

Press and hold the Left or Right button to play back the images quickly.

Playing back a movie clip

1. Select the recorded movie clip that you want to play back by using the Left/Right button.

2. Press the play & pause button ( Ø ) to play back a movie clip file.

- To pause a movie clip file while playing it back, press the play & pause button (Ø ) again.

- Pressing the play & pause button (Ø) again will cause the movie clip file to restart.

- To rewind the movie clip while it is playing, press the Left button. To fast forward the movie clip, press the Right button.

- To stop playback of the movie clip, press the play & pause button (Ø), and then press the Left or Right button.

Play Capture

PLAY

Page 64

Starting play mode

Movie clip capture function

You can capture still images from the movie clip.



How to capture the movie clip

1. Press the Play / Pause button( Ø ) while playing the movie clip. Then press the E button.

2. The paused movie clip is saved in a new file name.

The captured movie clip file is the same

size as the original movie clip (800x592, 720x480, 640x480, 320x240).

When you press the E button at the beginning of the movie clip, the first frame of the movie clip will be saved as a still image.

Play Capture

[Paused]

[Press the E button]

On camera movie trimming

You can extract desired frames of movie clip during the movie clip play back. If the running time is under 10 seconds, the movie clip can’t be trimmed.

1. Press the Pause button( Ø ) at the point of the movie clip where you want to start extracting.

2. Press the T button.

3. Press the Play & Pause button( Ø ) and the extracted range will be displayed on the status bar.

4. Press the Play & Pause button( Ø ) once more at the point where you wish the extracted file to stop.

5. Press the T button and a confirmation window will be displayed.

6. Select a desired sub menu by pressing the Up/Down button and press the OK button.

[No] : The movie trimming will be

cancelled.

[Yes] : The extracted frames are saved

as a new file name.

If you don't specify the ending point of the movie clip, the



trimming confirmation window will be displayed at the point of the last frame.

Trim Capture

T E

Trim

Trimming?

Yes

Confirm

04 PLAY

PLAY

Page 65

Starting play mode

Playing back a recorded voice

1. Select the recorded voice that you want to play back by using the Left/Right button.

2. Press the play & pause button ( Ø ) to play back a recorded voice file.

- To pause a recorded voice file, while playing it back, press the play & pause button (Ø ) again.

To resume playback of the voice file, press the play & pause button (

- To rewind the voice file while it is playing, press the Left button. To fast forward the voice file, press the Right button.

- To stop playback of the voice memo, press the play & pause button (Ø ) and then press the MENU/OK button.

Play

Playing back a voice memo

1. Select a still image that has the voice memo.

2. Press the play & pause button ( Ø ) to play back the voice memo.

- To pause the voice memo, while playing it back, press the play & pause button (Ø ) again.

- To resume playback of the voice memo, press the play & pause button ( Ø ).

- To stop playback of the voice memo, press the play & pause button ( Ø ) and then press the MENU / OK button.

Pause

Stop Play

PLAY

Page 66

LCD monitor Indicator

The LCD monitor displays shooting information about the displayed image.

Using the camera buttons to set the camera

In Play mode, you can use the buttons on the camera to conveniently set up the Play mode functions.

No. Description Icon Page

1 Playback mode 2 Folder name & File name 100-0010 p.59 3 Memory card indicator 4 Battery p.14 5ISO 50 ~ 3200 p.38 6 Aperture value F3.5 ~ F8.0 p.40 7 Shutter speed 16 ~ 1/2,000 p.40 8 Flash ON / OFF p.31

9 Image size 3264x2448 ~ 320x240 p.36 10 Recording date 2008/03/01 p.56 11 DP OF 12 Protect 13 Voice Memo

p.62

p.86 p.85 p.51

Play mode button



If you have turned on the camera, you can press the PLAY MODE button once to switch to Play mode and press it again to switch to Recording mode.



In the PMP, MP3, Text viewer mode, pressing the Play mode button will display the play list of each mode.

PLAY

04 PLAY

Page 67

Using the camera buttons to set the camera

Thumbnail ( º ) / Enlargement ( í ) button



You can view multiple pictures, enlarge a selected picture, and crop and save a selected area of an image.



In the MP3, PMP, Text Viewer, Movie mode, slide show and when playing back the recorded voice, you can control the volume of multimedia files.



Thumbnail display

1. While an image is displayed on full screen, press the thumbnail button.

2. The thumbnail display will highlight the image that had been showing at the time the thumbnail mode was selected.

3. Press the 5 function button to move to a desired image.

4. To view an image separately, press the enlargement button.

Pressing the thumbnail

button ( º )

Pressing the enlargement

button ( í )

Highlighted image

[Highlighted image]

[ Thumbnail display mode ]



Image enlargement

1. Select an image that you want to enlarge and press the enlargement button.

2. Different parts of the image can be viewed by pressing the 5 function button.

3. Pressing the thumbnail button will zoom back to the original full sized image.

- You can tell whether the image displayed is an enlarged view by checking the image enlargement indicator shown at the top left of the LCD monitor. (If the image is not an enlarged view, the indicator will not be displayed.) You can also check the area of enlargement.

- Movie clips and WAV files can’t be enlarged.

- If an image is enlarged, a loss of quality may occur.

Trim

PLAY

Page 68

Using the camera buttons to set the camera



The maximum enlargement rate in proportion to the image size

Image size

Maximum

enlargement

rate



Trimming : You can extract part of the image that you want and save

Select an image that you want to enlarge

and press the enlargement button. Press the MENU/OK button and a message will be displayed.

2. Select a desired sub menu by pressing the Up / Down button and press the OK button.

- [No] : The trimming menu will disappear.

- [Yes] : The trimmed image will be saved as a new file name, and

If there is not enough memory space to save the trimmed image, the

image can’t be trimmed.

Ÿ¬

X10.2 X8.5 X8.0 X8.1 X6.4 X3.2

it separately.

Trimming?

Yes

Confirm

appear on the LCD monitor.

(î )

Info

When the menu is displayed on the LCD monitor, the UP button operates as a direction button. When the menu is not displayed on the LCD monitor, pressing the Info button will display image information on the LCD monitor.

/ Up button

Info ( î ) button

Info ( î ) buttonInfo ( î ) button

04 PLAY

PLAY

Page 69

(

Play & Pause

In Play mode, the play & pause/ down button works as follows:

- If the menu is displayed Press the DOWN button to move from the main menu to a sub menu, or to move down the sub menu cursor.

- If a still image with a voice memo, a voice file, or a movie clip is playing

·In Stop mode : Plays a still image with a voice memo, a voice file, or a movie clip.

·During playback : Temporarily stops playback.

·In Pause mode : Resumes playback

Play Pause

[ Voice recording is stopped ]

)

/ Down button

[ Voice recording is playing ]

Stop

Play

[ Voice recording is paused ]

Left / Right / Menu / OK button

LEFT / RIGHT / MENU / OK buttons activate the following.

- LEFT button : While the menu is showing, the LEFT button operates

- RIGHT button : While the menu is showing, the RIGHT button oper-

- MENU button : When you press the MENU button, the play mode

- OK button : When the menu is displayed on the LCD monitor, the

as a direction button. While the menu is not showing, press the LEFT button to select the previous image.

ates as a direction button. While the menu is not showing, press the RIGHT button to select the next image.

menu will be displayed on the LCD monitor. Pressing it again will return the LCD to the initial display.

OK button is used for confirming data that is changed by using the 5 function button.

PLAY

Page 70

Printer ( » ) button

When the camera is connected to a PictBridge printer, you can print images by pressing the Printer button.

Delete

(Õ )

button

This deletes images stored on the memory card.

1. Select an image that you want to delete by pressing the Left / Right button and press the DELETE ( Õ ) button.

04 PLAY

Print Menu

Delete ?

Yes

T OK

Select Confirm

[Single Image] [Thumbnail Image]

Delete ?

No Yes

Confirm

2. To delete images, press the T button.

- Left/Right button : Selects images

- T button : checks for deletion

- OK button : deletes the selected images.

Select Delete

3. Select the submenu values by pressing the Up / Down button and then press the OK button.

- If [No] is selected : cancels "Delete Image".

- If [Yes] is selected : deletes the selected images.

PLAY

Page 71

E(Effect) button : Resize

Change the resolution (size) of pictures taken. Select [Start image] to save an image to be the start-up image.

1. Press the play mode button and press the E button.

2. Press the Left / Right button and select the [RESIZE] (  ) menu tab.

3. Select a desired sub menu by pressing the Up / Down button and press the OK button.



Image Resize Types

( o : Selectable)

RESIZE







Move Exit

ð Ÿ   

ooooo

oooo

ooo

“’‘

ooo

{



- A large sized image can be resized to a smaller sized image, but not vice versa.

- Only JPEG images can be resized. Movie clip (AVI), Voice recording (WAV) files can’t be resized.

- You can change the resolution of only those files compressed in the JPEG 4:2:2 format.

- The resized image will have a new file name. The [Start Image] image is stored not on the memory card but on the internal memory.

- If a new user image is saved, one of the two user images will be deleted in order.

- If the memory capacity is insufficient to store the resized image, a [Memory Full!] message will appear on the LCD monitor and the resized image can't be stored.

PLAY

Page 72

E(Effect) button : Rotating an image E (Effect) button : Colour

You can rotate the stored images by various degrees.

1. Press the play mode button and press the E button.

ROTATE

2. Press the LEFT / RIGHT button and select



the [ROTATE] (

) menu tab.

3. Select a desired sub menu by pressing the Up / Down button and press the OK button.

Right 90°

Set Back

OK E

[ô : Right 90˚] : Rotate picture in a

clock-wise direction

Horizontal

OK E

[ö : Horizontal] : Rotate picture horizontally

Left 90°

OK E

[ó : Left 90˚] :

Rotate picture in a counterclock-wise direction

Set Back

Verti cal

OK E

[ : Vertical] : Rotate picture vertically



Move Exit





180°

Set Back

OK E

[õ : 180˚] : Rotate picture 180 degrees

Set Back

If you display the rotated image on the LCD monitor, empty spaces

may appear to the left and right of the image.

It is possible to add colour effects to your images by using this button.

1. Press the play mode button and press the E button.

COLOR

2. Select ( ) menu tab by pressing the Left / Right button.



Move Exit





3. Select a desired sub menu by pressing the Up / Down button and press the OK button.

Icon Descroption

Captured images will be stored in black and white.

Captured images will be stored in a sepia tone

(a gradient of yellowish brown colours). Captured images will be stored in a red tone.

Captured images will be stored in a green tone.

Captured images will be stored in a blue tone.

Saves the image in negative mode.

Captured images will be stored in set RGB tone.

4. The changed image is saved as a new file name.

PLAY

04 PLAY

Page 73

E(Effect) button : Colour

E(Effect) button : Image editing



Custom colour

You can change the R (Red), G (Green) and B (Blue) values of the image.

- OK button : Select / setup the Custom Colour

- Up / Down button : Selects R, G, B

- Left / Right button : Change the values

PLAY

Custom Color

Move Set



Custom Color

Move Set



1. Press the play back button and press the E button.

2. Select (  ) menu tab by pressing the Left/Right button.

ACB

You can alter the exposure of the captured image and automatically adjust the brightness.

1. Select ( ) by pressing the Up/Down button and press the OK button.

The [Processing!] message is displayed

ACB

and the image is saved as a new file name.

Set Back

OK E

Red eye Removal

Red eye effect can be removed from the captured image.

1. Select (  ) by pressing the Up/Down button and press the OK button.

The [Processing!] message is displayed

and the image is saved as a new file name.

Red Eye Fix

Set Back

OK E

Page 74

E(Effect) button : Image editing

Brightness control

You can change the brightness of the image.

1. Select ( z ) by pressing the Up/Down button and a bar for selecting the brightness will be displayed.

2. Change the brightness by pressing the Left/Right button.

3. Press the OK button and the image will be saved as a new file name.

Contrast control

You can change the contrast of the image.

1. Select (  ) by pressing the Up/Down button and a bar for selecting the contrast will be displayed.

2. Change the contrast by pressing the Left/Right button.

3. Press the OK button and the image will be saved as a new file name.

Brightness

Move Set

Contrast

Move Set



Saturation control

You can change the saturation of the image.

1. Select ( ) by pressing the Up/Down button and a bar for selecting the

Saturation

saturation will be displayed.

2. Change the saturation by pressing the Left/Right button.

3. Press the OK button and the image will be

Move Set



saved as a new file name.

Noise effect

You can add noise to an image to add a more classic feel to your photo.

1. Select ( button and press the OK button.

The [Proccessing!] message is displayed

and the image is saved as a new file name.

) by pressing the Up/Down

Add Noise

Set Back

OK E

PLAY

04 PLAY

Page 75

E(Effect) button : FUN

Cartoon

You can add a text box to the image to make the image cartoon like.

FUN

Select Cartoon (



Move Exit

Select Back



Press the OK button and the image is saved. Press the OK button again to open a new

OK E

Select an image by pressing the Up/Down/Left/Right button and press the OK button. Select the third image with the same procedure.

Move Set

image to save.

Select the position of image and text box with the same procedure.

PLAY

)

Cartoon

Frame Set



Search Delete

OK Fn

Select a desired frame by pressing the Left/Right button and then press the OK button

Change the location of the text box by pressing the Left/Right button.

Save Delete

OK Fn

Move Set

Press the OK button and the file is saved as a new file name.



Select a desired position by pressing the Up/Down/ Left/Right button and press the OK button.

Page 76

E(Effect) button : FUN



Changing the cartoon image before taking the last shot Before saving the cartoon image, you can change the selected image.

1. Pressing the Fn button deletes the images in order.

2. Press the OK button and you can select images.

Pressing the Fn

Save Delete

OK Fn

3. After selecting desired images, press the OK button to save the image as a new file name.

button

Search Delete

OK Fn

Preset focus frames

You can make the subject stand out from its surroundings. The subject will be sharp and in focus while making the rest out of focus.

FUN

Select High

Light ( ).



Move Exit



Select a desired frame by pressing the Left/Right button and press the OK button.

High Light

High Light High Light

High Light

Range Set



High Light

04 PLAY

Range Set



Range Set



Range Set



Range Set



[Range 1] [Range 2] [Range 3] [Range 4]

PLAY

Page 77

E(Effect) button : FUN



Moving and changing the focus frame You can change the focus frame after selecting a Range menu.

1. Select a focus frame by pressing the Left/Right button and press the OK button.

2. Move the location of the frame by pressing the Up/Down/Left/Right button.

3. Press the OK button and the file is saved as a new file name.

High Light

Range Set



PLAY

Pressing the

OK button

Pressing the

OK button

Move Save

[The frame is activated]

Pressing Up/ Down/Left/Right button

Move Save

[After changing the frame

position]

Composite image

You can combine 2 - 4 different shots in a still image.

FUN

Select Composite

( )



Move Exit



Press the OK button. (You can select 2-4 composite images)

If you press the Shutter and Play mode button, a capture mode is



executed.

The composite image is saved according to the minimum image



size among the original images.

Composite

Composite Set



Move Set

Page 78

E(Effect) button : FUN

Selecting 2 composite images

Up/Down/Left/Right

Move Set

Select Back

OK E

[Selecting the second image]

Select an image by pressing the 5 function button and press the OK button

Move Set

Pressing the

button

Move Set

[Changing the position]

Pressing the OK button

Pressing the

OK button

Search Delete

Change the location of second image by pressing the press the OK button to save the image.

Up/Down/Left/Right button

OK Fn

and



Before selecting the last composite image, you can change a part of composite image.

1. During the composite image editing, press the Fn button.

2. A previous image will be deleted. Press the OK button and you can select a new image. After selecting an image, press the Fn button again and the image will be deleted again.

Pressing the

Fn button

Search Delete

OK Fn



Search Delete

OK Fn

3. Press the OK button and you can select an image again.

PLAY

04 PLAY

Page 79

E(Effect) button : FUN

Photo Frame

You can add 9 types of frame-like borders to a still image you want to capture. Date & Time information will not be printed on the stored image taken with Photo Frame menu.

FUN



Move Exit



Select Photo

Frame ( ).

Photo Frame

Frame Set



1. Select ( ) by pressing the Up/Down button and press the OK button.

PLAY

2. Select a desired photo frame by pressing the Left/Right button and press the OK button to save the image.

Page 80

E(Effect) button : FUN

Save

Sticker

You can add various stickers to the image.

FUN

Select (

)



Move Exit



Select a location of sticker by pressing the

Save

Move Add

You can add additional stickers by pressing

the Fn button. Press the OK button to store the image.

Up/Down/Left/Right button

Sticker



Sticker Set

Select a desired sticker by pressing the button and press the OK button

Save

Move Add

Left/Right

Colour Filter

With this menu, you can change the colour information of the image (excluding Red, Blue, Green and Yellow) to Black and White.

1. Select ( ½ ) by pressing the Up/Down button.

FUN



Move Exit



2. Press the OK button and the image is saved as a new file name.

Color Filter

Set Back

PLAY

04 PLAY

Page 81

E(Effect) button : FUN

Set

Colour mask

With this menu, you can select a part you want to highlight. The rest of the image will be in black and white.

FUN

PLAY

 

Move Exit

[Final image]

Select ( ¾ ) the selected area will be shown.

Pressing the OK button and the colour mask image will be saved as a new file name. You set the size and location of the part by pressing the E button.

Color Mask

Set Back

OK E

Save Back

OK E

Press the OK button and you can set the size and location of the part to be highlighted.

Pressing the OK button.

Set

Move SizeTW

T/W button : Changing size of

Up/Down/Left/Right button: Changing the location

selected part

Set

Move SizeTW

Set

Move Size

Page 82

Setting up the play back function using the LCD monitor

PLAY mode functions can be changed by using the LCD monitor. In the PLAY mode, pressing the MENU button displays the menu on the LCD monitor. The menus you can set up in Play mode are as follows. To capture an image after setting up the play menu, press the PLAY mode button or shutter button.

Menu Tab Main Menu Sub Menu Secondary Menu Page

MULTI

SLIDE

SHOW

)

(



PLAYBACK

(à )

Show

Images

Effect

Interval 1, 3, 5, 10 sec -

Music

Voice Memo

Delete

Protect

DPOF

Copy To Card

Play / Repeat Play

All -

Select

Off Basic Classic

Memories Rhythmic Delight

Off Panorama First Smile

Remembrance

My Music Off On -

Select -

All No / Yes

Select -

All Unlock / Lock

Standard

Index No / Yes

Size

Yes

- p.82

New Select, Select1,2,3

Select / All Pics /

Cancel

Select / All Pics /

Cancel

p.83Date -

p.83

p.84

p.85

p.86

p.87

p.88

This menu is available while the camera is connected to a PictBridge supporting printer (direct connection to the camera, sold separately) with a USB cable.

Menu Tab Main Menu Sub Menu Secondary Menu Page

Images

Size



Layout

One Pic -

All Pics -

Auto -

PostCard -

Card 4X6 -

L-

2L -

Letter -

A4 A3 -

Auto -

Full -

12489-

16 -

Index -

p.90

PLAY

04 PLAY

Page 83

Setting up the play back function using the LCD monitor

Menu Tab Main Menu Sub Menu Secondary Menu Page

Auto -

Type

Quality



Date

File Name

Reset

Menus are subject to change without prior notice.

Plain -

Photo -

FastPhoto -

Auto Draft -

Normal -

Fine -

Auto -

Off On -

Auto -

Off On No -

Yes -

p.90

p.91

Starting the Multi Slide Show

Images can be displayed continuously at pre-set intervals. You can view the Multi Slide Show by connecting the camera to an external monitor.

1. Press the play mode button and press the menu button.

2. Press the LEFT / RIGHT button and select the [MULTI SLIDE SHOW] menu tab.

Start the Multi Slide Show

The Multi Slide Show can start only in the [Show] menu.

1. Use the Up / Down buttons to select the [Show] menu and press the Right button.

2. Select a desired sub menu by pressing the Up / Down button.

[Play] : The Multi Slide Show is

closed after one cycle.

[Repeat Play] : The Slide show is

repeated until cancelled.

3. Press the OK button and the slideshow will be started.

- To pause the slide shown while playing it back, press the play & pause(Ø ) button again.

- Pressing the play & pause( Ø ) button again will cause the Multi

Slide Show restart.

- To stop playback of the Multi Slide Show, press the play & pause (Ø ) button, and then press the OK / Menu button.



)

(

MULTI SLIDE SHOW

Images Effect Interval 

Music

Back Set





 





PlayShow Repeat Play

PLAY

Page 84



Starting the Multi Slide Show

(

Selecting Images

You can select image to view

1. Use the Up / Down buttons to select the [Images] menu and press the Right button.

2. Select a desired sub menu by pressing the Up / Down button.

[All] : All images saved in the Memory

are played back.

[Date] : Images taken in a specified date

are played back.

[Select] : Play only the selected images.

If you press the Right button, you can select the desired images to play back. The selected image can be saved as [Select1], [Select2] and [Select3]. If you save the selected image with the [New Select] command, it will be saved as [Select1]. But when a new image is saved again using [New Select], the former image which had been saved as [Select1] will be saved as [Select2] automatically. You can change and cancel the images which were saved as [Select1], [Select2] and [Select3].

3. Press the OK button and the settings are saved.

MULTI SLIDE SHOW Show

Effect Interval 

Music



)







AllImages

Date



Select



Back Set

Configure Multi Slide show effects

Unique screen effects can be used for the Multi Slide Show.

Select the [Effect] sub menu by pressing the

UP / DOWN button and press the RIGHT button.

2. Use the Up / Down button to select the



type of effect.

[Off] : No effect. [Basic] : Fade In/Out effect is added

and the Images are displayed at set interval. [Classic] : You can add noise to the image to give a classic feel. [Memories] : Scratches are added to give an old movie effect. [Rhythmic] : Images are displayed with a special effect. [Delight] : Images are displayed with a special effect.

3. Press the OK button to confirm the setting.

MULTI SLIDE SHOW Show Images Effect Interval 

Music

Back Set





 

 





Off Basic Classic Memories Rhythmic Delight

04 PLAY

PLAY

Page 85



Starting the Multi Slide Show

(

)

Playback

(à )

Setting play interval

Set the Multi Slide Show play interval.

1. Select the [Interval] sub menu by pressing the UP / DOWN button and press the RIGHT button.

2. Use the Up / Down buttons to select the desired interval.

3. Press the OK button to save the configuration.

The loading time depends on the image size and quality.



While the Multi Slide Show is playing, only the first frame of a MOVIE



MULTI SLIDE SHOW Show Images Effect Interval 

Music

Back Set



file is displayed. While the Multi Slide Show is playing, the voice recording file will not



be displayed. The interval menu functions in the [Off], [Basic] menu only.



Setting Background Music

Set the Multi Slide Show music.

1. Select the [Music] sub menu by pressing the UP / DOWN button and press the RIGHT button.

2. Use the Up / Down buttons to select the desired Music.

3. Press the OK button to save the configuration.

PLAY

MULTI SLIDE SHOW Show Images Effect Interval Music

Back Set







1 sec





3 sec



5 sec



10 sec



Off



Panorama



First Smile



Remembrance My Music

Voice memo

You can add your voice to a stored still image.

PLAYBACK





Delete Protect DPOF 

Copy to Card

- Press the shutter button to take a picture. The images are saved

- To stop the recording, press the shutter button.

OffVoice Memo On



  



Back Set



Start

Stop

[Ready for recording] [Voice is recording][Voice memo menu]

on the memory. After saving the image, the voice will record for 10 seconds.

Page 86

Playback

(à )

Deleting images

This deletes images stored on the memory.

1. Press the Up / Down button and select the [Delete] menu tab. And then press the Right button.

2. Select a desired sub menu by pressing the UP / DOWN button and press the OK button.

[Select] : Selection window for an image to

delete is displayed.

- Up/ Down/ Left/ Right : Select an image

- Zoom T Button : Select the image for deletion. ( Ë mark)

- OK Button : Press the OK button to display

the confirmation message. Select the [Yes] menu and press the OK button to delete marked images.

[All] : Displays confirmation window. Select

the [Yes] menu and press the OK button to delete all unprotected images. If there are no protected images, all the images will be deleted and a [No Image!] message will appear.

3. After deletion, the screen will be changed to the play mode screen.



Of all the files stored in the memory card, the unprotected files in the DCIM subfolder will be deleted. Remember that this will permanently delete unprotected images.

Important shots should be stored on a computer before deletion takes place. The startup image is stored in the camera's internal memory (i.e., not on the memory card) and it will not be deleted even if you delete all files on the memory card.

PLAYBACK Voice Memo

 

Delete Protect DPOF Copy to Card

Confirm

Select All



Back Set



Select Delete

T OK

Delete All?

Yes

Protecting images

This is used to protect specific shots from being accidentally erased (Lock). It also unprotects images that have been previously protected (Unlock).

1. Press the Up / Down button and select the [Protect] menu tab. And then press the Right button.

2. Select a desired sub menu by pressing the UP / DOWN button and press the OK button.

[Select ] : Selection window for an image

to be protected / released is displayed.

- Up / Down / Left / Right : Select an image

- Zoom T/W Button : Protect / release the image

- OK button : Your changes will be saved

and the menu will disappear.

[All] : Protect / release all saved images

- If you protect an image, the protect icon

will be displayed on the LCD monitor. (An unprotected image has no indicator)

An image in LOCK mode will be protected

from the delete function or [Delete] functions, but will NOT be protected from the [Format] function.

PLAYBACK Voice Memo Delete Protect DPOF Copy to Card

Back Set



TW OK

Confirm

 





Protect All?

Unlock

Lock

Select All

SetUnlock

PLAY

04 PLAY

Page 87

Playback

(à )

DPOF



DPOF(Digital Print Order Format) allows you to embed printing information on your memory card’s MISC folder. Select the pictures to be printed and how many prints to make.



The DPOF indicator will display on the LCD monitor when an image that has DPOF information plays back. Images can then be printed on DPOF printers, or at an increasing number of photo labs.



This function is not available for Movie clips and Voice recording files.



When the wide angle image is printed as a wide angle print, 8% of the left and right side of the image may not be printed. Check that your printer can support the wide angle image when you print the image. When you print the image at a photo lab, request that the image is printed as a wide angle image. (Some photo labs may not support the wide angle size print.)



Standard

This function allows you to embed printing quantity information on a stored image.

1. Press the Up / Down button and select the [DPOF] menu tab. And then press the Right button.

2. Press the Right button again and [Standard] sub menu will display.

3. Select a desired sub menu by pressing the

PLAYBACK

Index Size









SelectStandard All Pics



Cancel



Back Set

Up / Down button and press the OK button.

[Select] : Selection window for an image to

print is displayed.

Up / Down / Left / Right : Select an image to

print.

Zoom T/W Button : Select the number of

0 Images





Set

prints.

[All Pics] : Configure number of prints for

all pictures except movie and voice files.

0 Images





- T/W button : Select a number of prints

[Cancel] : Cancel the print setup.

4. Press the OK button to confirm the setting.

Set

If an image carries DPOF instructions, the DPOF indicator ( Ñ ) will show.

PLAY

Page 88

Playback



Index

(à )

Images (except for movie clips and voice file) are printed as index

type.

1. Press the Up / Down button and select the [DPOF] menu tab. And then press the Right button.

2. Press the Right button again and [Index] sub menu will display.

3. Select a desired sub menu by pressing the

PLAYBACK Standard Index Size









No Yes



Back Set

UP / DOWN button.

If [No] is selected : Cancel the index print setting. If [Yes] is selected : The image will be printed in index format.

4. Press the OK button to confirm the setting.



Print size You can specify the print size when printing images stored on the memory card. The [Size] menu is available only for DPOF 1.1 compatible printers.

1. Press the Up / Down button and select the [DPOF] menu tab. And then press the Right button.

2. Press the Right button again and select the [Size]. Sub menu will be displayed.

3. Select a desired sub menu by pressing the

PLAYBACK Standard Index Size







Select



All Pics



Cancel



Back Set

UP / DOWN button and press the OK button.

[Select] : Selection window to change the

printed size of the image is displayed.

- Up / Down / Left / Right : Select an image.

- Zoom T/W Button : Change the print size.

W Cancel T

Set

- OK button : Your changes will be saved and the menu will disappear.

[All Pics] : Change print size of all saved

images.

W Cancel T

- T/W button : Select a print size

- OK button : Confirm the changed setting.

[Cancel] : Cancel all of the print size settings.

DPOF [Size] secondary menu : Cancel, 3X5, 4X6, 5X7, 8X10

Depending on the manufacturer and print model, cancelling the print-



Set

ing may take a little longer for the printer to process.

04 PLAY

PLAY

Page 89

Playback

(à )

Copy To Card

This enables you to copy image files, movie clips and voice recording files to the memory card.

1. Select the [Copy To Card] menu tab by pressing the Up / Down button. And then press the Right button.

2. Select a desired sub menu by pressing the UP/ DOWN button and press the OK button.

- [No] : Cancels "Copy to Card".

- [Yes] : All images, movie clips and voice recording files saved in the internal memory are copied to the memory card after the [Processing!] message is displayed. After copying has been completed, the screen will return to play mode.

PLAYBACK Voice Memo Delete Protect DPOF Copy to Card





 

No Yes

Back Set

When this menu is selected without inserting a memory card, the [No



Card] message will be displayed. If there is not enough space available in the memory card to copy



saved images in the internal memory (About 40 MB), the [Copy To Card] command will copy only some of the images and display [Memory Full!] message. Then the system will return to the playback mode. Please be sure to delete any unnecessary files to free up space before inserting the memory card into the camera. When you move the images that are stored in the internal memory



by doing [Copy To Card] to the card, the next number of file names will be created in the card to avoid duplication of the file name.

- When the [Reset] of the [File] setup menu is set : The copied file names start from after the last stored file name.

- When the [Series] of the [File] setup menu is set : The copied file names start from after the last captured file name. After completing [Copy To Card], the last stored image of the last copied folder is displayed on the LCD monitor.

PLAY

Page 90

PictBridge

You can use the USB cable to connect this camera to a printer that supports PictBridge (sold separately) and print the stored images directly. Movie clips and voice files cannot be printed.



Setting up the camera for connection to the printer

1. Connect the camera and printer with USB cable.

2. Select the [Printer] menu by pressing Up / Down button and press the OK button.



Connecting the Camera to a Printer

Select USB

Computer

Printer

Confirm

If the [USB] menu is set to the [Computer], you cannot connect a Pictbridge compatible printer to the camera through USB cable with [Connecting Computer] message. In this case, remove the cable and do steps 1 and 2 again.



Easy printing

When you connect the camera to printer in

the Play back mode, you can print a picture easily.

- Pressing the printer ( » ) button : Currently displayed image will be printed with the printer’s default setting.

Print Menu



- Pressing the Left / Right button :

Selects a previous / next image.

PLAY

04 PLAY

Page 91

PictBridge : Picture Selection

PictBridge : Print Setting

You can select images you want to print.



Setting the Number of Copies to Print

1. Press the Menu button and the PictBridge menu will display.

2. Use the Up / Down buttons to select the [Images] menu and press the Right button.

3. Use the Up / Down buttons to select a desired sub menu and press the OK button.

- Select [One Pic] or [All Pics]. A screen

PICTBRIDGE

Size Layout Type 

Quality Date

Back Set





One PicImages All Pics



  

 

where you can set the number of copies to print will appear as shown below.

SH OK

Exit Set









PrevNext

SH OK

Exit Set

[When [One Pic] is selected]

[When [All Pics] is selected]

- Press the Up / Down button to select the number of prints.

- When [One Pic] is selected : Use the Left / Right button to select another picture. After selecting another picture, select the number of prints for another picture.

- After setting the number of prints, press the OK button to save.

- Press the Shutter button to return to the menu without setting the

number of prints.

4. Press the Print button ( » ) and images will be printed.

PLAY

You can select the Paper Size, Print Format, Paper Type, Print Quality, Date Print, and File Name Print menus for printed pictures.

1. Press the Menu button and the PictBridge menu will display.

2. Use the Up / Down buttons to select the desired menu, and then press the Right button.

3. Use the Up / Down buttons to select the desired sub menu value, and then press the

OK button.

PICTBRIDGE Images Size Layout Type Quality Date

Back Set



 

 





Auto PostCard Card 4 x 6 L 2L

Menu Function Sub menu

Size Set the size of the printing paper

Layout

Type

Quality

Set the number of pictures to be printed on a sheet of paper

Set the quality of the printing paper

Set the quality of the picture to be printed

Auto, PostCard, Card, 4X6, L, 2L, Letter, A4, A3

Auto, Full, 1, 2, 4, 8, 9, 16, Index

Auto, Plain, Photo, FastPhoto

Auto, Draft, Normal, Fine

Date Set whether to print the date Auto, Off, On

File Name

Some menu options are not supported on all printers.

Set whether to print the file name

Auto, Off, On

If not supported, the menus are still displayed in the LCD, but are not selectable.

Page 92

PictBridge : Reset

Initialises user-changed configurations.

1. Use the Up / Down buttons to select the [Reset] menu tab. And then press the Right button.

2. Use the Up / Down buttons to select the desired sub menu value, and then press the OK button.

If [No] is selected : Settings will not be

reset.

If [Yes] is selected : All print and image settings will be reset.

Default print setting varies depending on the printer manufacturer.

For your printer’s default setting, refer to the user’s guide that came with your printer.

PICTBRIDGE Layout Type Quality Date File Name Reset







 

Yes

Back Set

MP3 / PMP / TEXT VIEWER mode



This camera has an embedded MP3, TEXT VIEWER & Portable Media Player program. You can take a picture, listen to the MP3 files and watch the movie clip (Movie and Video clip) whenever you want. To use the PMP mode, you must convert the multimedia file with the Samsung Converter. In the TEXT VIEWER mode you can see the text on the LCD monitor when listening to MP3 music.



If the file or folder name is over 120 (Including 1 Byte/2 Byte language, Korean, Chinese, etc.) characters, the file or folder name doesn’t appear on the play list.

05 MULTIMEDIA

MULTIMEDIA_

Page 93

MP3 / PMP / TEXT VIEWER mode

Starting the MP3 / PMP / TEXT VIEWER mode

Downloading files

To use MP3, PMP and TEXT VIEWER functions, MP3, PMP (multimedia files) and TEXT files must be saved in the internal memory or memory card of this camera.

1. Save the desired files on your PC.

2. Connect the camera to your PC with the USB cable and turn on the camera.

3. Open Windows EXPLORER and search for Removable Disk.

4. Make a folder under the Removable Disk.

MP3 Mode: [MP3] PMP Mode: [PMP]

5. Select files that you want to save and copy them to the desired folder.

_MULTIMEDIA

TEXT VIEWER mode: [TEXT]

Be aware of the illegal duplication of MP3 & multimedia files. It



violates various copyright laws. Without permission of Samsung, you cannot copy, modify and/or



distribute any part or all of MP3, PMP file provided in the internal memory. This camera can only play back MP3 files in the MP3 mode and SDC



files (modified XviD MPEG4 video / MPEG Layer 2 audio type) in the PMP mode. If a file can not be played back on this camera, convert it into the



supported file format by using the Samsung Converter. (p.120) Up to 200 files and 100 sub folders can be saved in a folder.



You can only save a total of 200 files and sub folders at one time. New folders can be created within the MP3, PMP and TEXT folders.



Otherwise any files in other folders that you create cannot be played back.

Page 94

Starting the MP3 / PMP / TEXT VIEWER mode

Insert the memory card that holds MP3, PMP and TEXT files. As this camera has a 40MB internal memory, you can save the files on the internal memory too.

1. Select a desired Multi media mode. (p.19)

2. A menu will display as shown. [Resume] : Memorizes the latest stopped

frame.

MP3 mode : Plays back from the beginning of

the file.

PMP mode : Plays back from the latest

stopped frame.

TEXT VIEWER mode : Plays back from the

latest stopped frame.

[Open] : The browsing menu will be

displayed to select a desired file.

3. Select a desired file and press the OK button.

The file will then be played back.

MP3

In this mode you can play MP3 files.

Resume

Open

Confirm

Move Select

Move Select

Move Select

MULTIMEDIA_

05 MULTIMEDIA

Page 95

Starting the MP3 / PMP / TEXT VIEWER mode

LCD monitor indicator for MP3 / PMP / TEXT VIEWER mode

When the [Resume] menu (p.98) of each mode are set as [Off], the



browsing menu doesn’t open. If the last played file was deleted, the browsing menu opens though the setting is the same as above. The order of play lists on the browsing menu and the order of files



saved in the memory are the same. A title coded with unsupported language is displayed as “--------”.



The automatic power off function will not operate if a file is playing



back. If there are over 100 files or a lot of large files in the sub folder, it



takes a little longer for the camera to process to the MP3 / PMP mode. If there is no operation during the specified time (About 30 sec.) in



the MP3 / TEXT VIEWER mode (B.G.M: Off, Auto scroll: Off), the LCD monitor is turned off automatically and the camera status lamp blinks. To use the camera, press any of the camera buttons except the POWER button. Playing back a VBR (Variable Bit Rate) file. A VBR file varies the



amount of output data in each time segment based on the complexity of the input the data in that segment. When the VBR encoded files are played back, the LCD will appear as shown. – The VBR icon will be displayed instead of the Bit rate icon.

Playing time will be displayed but the total running time will not appear.

– For about 2 seconds of the start and end frames of the PMP file, no



camera button except the POWER button can be operated. When an MP3 file doesn’t play back correctly, download a free MP3



conversion program and convert it before using the MP3 file on the camera. Depending on the file type, the movie may be paused during playing



back in the PMP mode. The movie restarts automatically and it is not a camera malfunction.

_MULTIMEDIA

The LCD monitor displays information about the MP3, multimedia and Text file.

MP3 mode

Battery (p.14)

Lock (p.96) Mute (p.95)

Equalizer (p.96)

Title of ﬁ le

Play&Pause /

Control button (p.95)

Playing time

Bit rate (p.94) Playback mode

(p.97) Volume (p.95)

Volume (p.95)

Time line Status bar

Play&Pause / Control button (p.95)

Caption (p.120)

PMP mode

Battery (p.14)

Search speed

Lock (p.96) Mute (p.95)

Title of ﬁ le

Page 96

LCD monitor indicator for MP3 / PMP / TEXT VIEWER mode

Using the camera buttons to adjust the camera

Indication of present TEXT

TEXT VIEWER mode

Battery (p.14)

TEXT Contents

Encoding Type: ANSI (American National Standards Institute) Type,

- When the ANSI encoding type is displayed:

You should set the Language of the TEXT VIEWER menu to view the text. Set the Language menu as one that is the same as the Operating System language that the text was created.

- When the UNI encoding type is displayed:

The text file will be displayed with any language menu.

If the text file size is over 10MB, it may take a long time or even be

impossible to view the text file. In this case, please divide the text file.

Uni (Unicode) Type

Current page/Whole page

Encoding Type (ANSI, Uni)

Volume Indication (p.95)

Volume button

You can control the volume with this button. There are 0 ~ 30 steps.

-Mute (

): You can mute the MP3

sound with the Up button.

Play & Pause / Seeking button



When a file is playing back, press the Down button to pause the file. Pressing it again will resume playback.



MP3 mode You can search the MP3 files by pressing the Left/Right button.



PMP mode You can search the Multimedia files by pressing the Left/Right button. You can search a desired frame of the file during play back by pressing the Left/Right button. (2X-32X)



TEXT VIEWER mode When the text list menu is displayed: select a text file by pressing

When the text is displayed: press the Up/Down button and previous

the Up/Down button.

/ next page of the file will be displayed. Press and hold the Up/Down button and it will skip 10 pages at a time.

MULTIMEDIA_

05 MULTIMEDIA

Page 97

Using the camera buttons to adjust the camera

Delete button

This deletes files stored on the memory.

1. Select a desired file to delete on the browsing menu and press the Delete button.

2. A message will appear as shown

[No] : Cancels “Delete files” and the

browsing menu will appear.

[Yes] : Deletes the selected file.

Before deleting files from the camera, take care to download files



you want to keep to your computer.

_MULTIMEDIA

Delete?

Yes

Confirm

Hold / Equalizer button



If you press the Hold button for more than 1 second, the camera buttons are locked.

- If the camera buttons are locked, the buttons can’t be operated while playing back. But Power off, Video out, USB connection and LCD on functions can be operated.

- If you press the Lock button again or turn off the camera, the camera is unlocked.



The user can select appropriate sound with this setting.

- Press the E button and select either <SRS>, <Normal>, <Live>, <Classic>, <Jazz>, <Rock> or <Dance>.

Page 98

Using the camera buttons to adjust the camera

Setting up the playback function using the LCD monitor

Playlist button

While a multimedia file is playing back, you can select a desired file by using the browsing menu.

1. While a multimedia file is playing back, press the Playlist ( › ) button.

2. A playlist that is currently playing will be highlighted.

3. Move the cursor to a desired list by pressing the Control button. Pressing the OK button: the selected file is played back.

Move Select Move Select Move Select

MP3 / PMP / Text Viewer mode functions can be changed by using the LCD monitor. Press the MENU button and the menu will be displayed on the LCD monitor.

Icon Main Menu Sub Menu Page

MP3

PMP

RESUME Off On

PLAY MODE

MP3 SKIN

SLIDE SHOW

DELETE ALL No Yes

RESUME Off On p.98

SEEKING

PLAYER

DISPLAY

DELETE ALL No Yes

Play All Repeat One

Repeat All Shuffle

Default 1 Default 2

User Skin 1 User Skin 2

Show Play Play/Repeat Play

Show Interval 2, 3, 5 sec

Normal 30 sec

5 min 10 min

5 sec On

Off -

MULTIMEDIA_

p.98

p.99

p.100

p.1001 min 3 min

p.100

05 MULTIMEDIA

Page 99

Setting up the playback function using the LCD monitor

Icon Main Menu Sub Menu Page

RESUME Off On

Off 0.8 sec

AUTO

SCROLL

1.1 sec 1.4 sec

1.7 sec 2.0 sec

2.3 sec -

MP3 BGM Off On

TEXT

VIEWER

LANGUAGE p.101

DELETE ALL No Yes p.100

Menus are subject to change without prior notice.

_MULTIMEDIA

p.98

p.101

Resume

You can set the playback type.

1. Press the MENU button in each mode.

2. Select a desired playing type in the [Resume] menu by pressing the Up/Down button and pressing the OK button.

RESUME Off On

Exit Move Exit Move Exit Move

[Off] : The browsing menu will be displayed to select a desired file. [On] : When the camera is turned on / off or camera mode is changed,

this camera will memorize the latest stopped frame. MP3 mode: plays back from the beginning of the file. PMP mode: plays back from the lastest stopped frame. TEXT VIEWER mode: plays back from the last stopped frame.

RESUME Off On

Page 100

Setting up the playback function using the LCD monitor

Play mode

You can set various repeat and shuffle options. This function is adopted only in the selected folder.

[Play All] : Plays a single track once. [Repeat One] : Plays a single track

repeatedly.

[Repeat All] : Plays all tracks in the folder

repeatedly.

PLAY MODE Play All Repeat One Repeat All Shuffle

Exit Move

[Shuffle] : Randomly plays all tracks in

the folder repeatedly.

Skin of MP3 player

You can set the skin of MP3 player.

[Default 1, 2] : Default skin will be set. [User Skin 1, 2] : An image created by the

[MP3 Skin] menu (p.70) will be set.

MP3 SKIN Default 1 Default 2 User Skin 1 User Skin 2

Exit Move

Playing back the slide show

While the MP3 file is playing back, captured images are displayed on the LCD monitor continuously.

[Play] : Display the images once. [Repeat Play] : Display the images

continuously.

To stop the slide show, press the E button.

SLIDE SHOW SHOW PLAY SHOW INTERVAL

Back Set

Play Repeat Play

05 MULTIMEDIA

Setting slide show interval

You can set the slide show play interval of MP3 mode.

- Select an interval from 2, 3 or 5 seconds.

SLIDE SHOW SHOW PLAY SHOW INTERVAL

Back Set

MULTIMEDIA_

2 sec 3 sec 5 sec

Samsung i80 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
