Samsung HT-SK5 User Manual

DIGITAL HOME
THEATER SYSTEM

HT-SK5

V I D E O

COMPACT

DIGITAL AUDIO

COMPACT

DIGITAL VIDEO

Instruction Manual

AH68-01241T

SAMSUNG ELECTRONICS AMERICA, INC.

SERVICE DIVISION

400 Valley Road, Suite 201

Mount Arlington, NJ 07856

1-800-SAMSUNG (1-800-726-7864)

www.samsungusa.com

12

Safety Warnings

CLASS 1 LASER PRODUCT

This Compact Disc player is classified as a CLASS 1
LASER product.

Use of controls, adjustments or performance of
procedures other than those specified herein may result
in hazardous radiation exposure.

CAUTION-INVISIBLE LASER RADIATION WHEN OPEN

AND INTERLOCKS DEFEATED, AVOID
EXPOSURE TO BEAM.

This symbol indicates that dangerous voltage which can cause electric shock is present inside
this unit.

This symbol alerts you to important operating and maintenance instructions accompanying
the unit.

WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY

INSERT.

CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LASER CLASE 1

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE REAR COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

CAUTION

Note to CATV system installer :

This reminder is provided to call the CATV system
installer’s attention to Section 820~40 of the NEC
which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical

Precautions

Ensure that the AC power supply in your house complies with the identification sticker located on the back of your player. Install your
player horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4inches). Make sure the ventilation slots
are not covered. Do not stack anything on top of the player. Do not place the player on amplifiers or other equipment which may become
hot. Before moving the player, ensure the disc tray is empty. This player is designed for continuous use. Switching off the DVD player to
the stand-by mode does not disconnect the electrical supply. In order to disconnect the player completely from the power supply,
remove the main plug from the wall outlet, especially when left unused for a long period of time.

Protect the player from moisture(i.e. vases) , and excess
heat(e.g.fireplace) or equipment creating strong magnetic or electric
fields (i.e.speakers...). Disconnect the power cable from the AC supply if
the player malfunctions. Your player is not intended for industrial use.

Use of this product is for personal use only.
Condensation may occur if your player or disc have been stored in cold

temperatures.
If transporting the player during the winter, wait approximately 2 hours

until the unit has reached room temperature before using.

During thunderstorms, disconnect AC main plug from the
wall outlet.
Voltage peaks due to lightning could damage the unit.

Do not expose the unit to direct sunlight or other heat
sources.

This could lead to overheating and malfunction of the unit.

The battery used with this product contain chemicals that
are harmful to the environment.
Do not dispose of batteries in the general household trash.

PREPARATION

Phones

4

Safety Instructions

3

READ INSTRUCTIONS

All the safety and operating instructions should be
read before the appliance is operated.

RETAIN INSTRUCTIONS

The safety and operating instructions should be
retained for future reference.

HEED WARNINGS

All warnings on the appliance and in the operating
instructions should be adhered to.

FOLLOW INSTRUCTIONS

All operating and use instructions should be
followed.

WATER AND MOISTURE

Do not use this video product near water­for example, near a bathtub, wash bowl,
kitchen sink, or laundry tub, in a wet basement,
or near a swimming pool, and the like.

OVERLOADING

Do not overload wall outlets and extension cords as
this can result in the risk of fire
or electric shock.

VENTILATION

Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of the
video product and to protect it from overheating
these openings must not be blocked or covered.
The openings should never be blocked
by placing the video product on a bed, sofa, rug, or
other similar surface. This video product
should never be placed near or over a radiator or
heat register.
This video product should not be placed
in a built-in installation such as a bookcase
or rack unless proper ventilation is provided
or the manufacturer's instructions have been
followed.

POWER CORD PROTECTION

Power-supply cords should be routed so that
they are not likely to be walked on or pinched
by items placed upon or against them paying
particular attention to cords at plugs,
convenience receptacles, and the point where
they exit from the appliance.

CLEANING

Unplug this video product from the wall outlet
before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.

LIGHTNING

For added protection of this video product
receiver during a lightning storm, or when
it is left unattended and unused for long
periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system.
This will prevent damage to the video product
due to lightning and power-line surges.

OBJECT AND LIQUID ENTRY

Never push objects of any kind into this
product through openings as they may touch
dangerous voltage points or short-out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the video
product.

ACCESSORIES

Do not place this video product on an unstable cart,
stand, tripod, bracket, or table.
The video product may fall, causing serious injury to
a child or adult, and serious damage
to the appliance.
Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer,
or sold with the video product. Any mounting
of the appliance should follow the manufacturer's
instructions and should use a mounting accessory
recommended by the manufacturer.

CART

An appliance and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart
combination to overturn.

POWER SOURCES

This video product should be operated only from the
type of power source indicated
on the marking label. If you are not sure
of the type of supply to your home, consult your
appliance dealer or local power company.
For video products intended to be operated from
battery power, or other sources, refer
to the operating instructions.

POWER LINES

An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits,
or where it can fall into such power lines
or circuits. When installing an outside antenna
system, extreme care should be taken to keep from
touching such power lines or circuits as contact with
them might be fatal.

POLARIZATION

This video product is equipped with a polarized
alternating current line plug (a plug having one blade
wider than the other.) This plug will fit into the power
outlet only one way.
This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing

the
plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.

OUTDOOR ANTENNA GROUNDING

•

If an outside antenna is connected to the
antenna terminal, be sure the antenna system
is grounded so as to provide some protection
against voltage surges and built-up static
charges.

•

In the U.S.A section 810 of the National
Electrical Code, ANSI/NFPA No. 70-1984,
provides information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors location of antenna discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
See the figure below.

ATTACHMENTS

Do not use attachments not recommended
by the video product manufacturer as they may
cause hazards.

SERVICING

•

Do not attempt to service this product yourself
as opening or removing covers may expose
you to dangerous voltage or other hazards.

•

Refer all servicing to qualified service personnel.

REPLACEMENT PARTS

When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer or having the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or other
hazards.

SAFETY CHECK

Upon completion of any service or repairs
to this video product, ask the service technician to
perform safety checks to determine that the video
product is in proper operating condition.

DAMAGE REQUIRING SERVICE

Unplug this video product from the wall outlet

and

refer servicing to qualified service personnel

under the
following conditions.
a.

When the power-supply cord or plug is damaged.

b. If liquid has been spilled, or objects have

fallen into the video product.

c. If the video product has been exposed to rain

or water

d.

If the video product does not operate normally
by following the operating instructions.
Adjust only those controls that are covered
by the operating instructions as an improper
adjustment of other controls may result
in damage and will often require extensive
work by a qualified technician to restore
the video product to its normal operation.

e. If the video product has been dropped

or the cabinet has been damaged.

f. When the video product exhibits a distinct

change in performance - this indicates
a need for service.

HEAT

This video unit should be situated away from heat
sources such as radiators, stoves, or other products
(including amplifiers) that produce heat.

ANTENNA
LEAD IN WIRE

ANTENNA
DISCHARGE UNIT
(NEC SECTION. 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

GROUND
CLAMP

ELECTRIC
SERVICE
EQUIPMENT

PREPARATION

6

Features

5

Multi-Disc Playback & AM/FM Tuner

The HT-SK5 combines the convenience of multi-disc playback capability,
including DVD, VCD, CD, MP3-CD, CD-R, CD-RW, and DVD-RW, with a
sophisticated AM/FM tuner, all in a single player.

Dolby Pro Logic II

Dolby Pro Logic II is a new form of multi-channel audio
signal decoding technology that improves upon existing
Dolby Pro Logic.

Built-in 5.1-Channel Amplifier

The HT-SK5 comes with a built-in 5.1-channel amplifier, allowing
you to enjoy dynamic sound.

DTS (Digital Theater Systems)

DTS is an audio compression format developed by Digital Theater
Systems Inc. It delivers full-frequency 5.1 channel sound.

Power Saving Function

The HT-SK5 automatically shuts itself off after 20 minutes in
the stop or pause mode.

TV Screen Saver Function

The HT-SK5 automatically brightens and darkens the brightness of the
TV screen after 2 minutes in the stop or pause mode.
The HT-SK5 automatically switches itself into the power saving mode
after 20 minutes in the screen saver mode.

Customized TV Screen Display

The HT-SK5 allows you to select your favorite image during JPEG, DVD,
or VCD playback and set it as your background wallpaper.

PREPARATION

Contents

PREPARATION

Safety Warnings..................................................................................................................................................................1

Precautions.........................................................................................................................................................................2

Safety Instructions ..............................................................................................................................................................3

Features..............................................................................................................................................................................5

Notes on Discs....................................................................................................................................................................7

Description..........................................................................................................................................................................9

CONNECTIONS

Connecting the Speakers....................................................................................................................................................13

Connecting the Video to TV................................................................................................................................................15

P.SCAN(Progressive Scan) Function.................................................................................................................................16

Connecting External Components......................................................................................................................................17

Connecting the Antennas....................................................................................................................................................19

Before Using Your DVD Player...........................................................................................................................................21

OPERATION

Disc Playback .....................................................................................................................................................................23

Selecting a Disc in the Disc changer ..................................................................................................................................24

Displaying Disc Information ................................................................................................................................................25

Checking the Remaining Time............................................................................................................................................26

Fast/Slow Playback.............................................................................................................................................................27

Skipping Scenes/Songs......................................................................................................................................................28

Repeat Playback.................................................................................................................................................................29

A-B Repeat Playback..........................................................................................................................................................30

Angle Function....................................................................................................................................................................31

Zoom Function....................................................................................................................................................................32

Selecting Audio/Subtitle Language.....................................................................................................................................33

Moving Directly to a Scene/Song........................................................................................................................................34

JPEG File Playback............................................................................................................................................................35

Using Disc Menu.................................................................................................................................................................37

Using the Title Menu...........................................................................................................................................................38

SETUP

Setting the Language..........................................................................................................................................................39

Setting TV Screen type.......................................................................................................................................................41

Setting Parental Controls (Rating Level).............................................................................................................................43

Setting the Password..........................................................................................................................................................45

Setting the Wallpaper..........................................................................................................................................................47

Setting the Speaker Mode ..................................................................................................................................................49

Setting the Test Tone..........................................................................................................................................................50

Setting the Delay Time........................................................................................................................................................51

Setting the Audio Quality........................................................................................................................................................................53

Setting the DRC (Dynamic Range Compression)...............................................................................................................55

Sound Field (DSP)/EQ Function.........................................................................................................................................56

Dolby Pro Logic II Mode......................................................................................................................................................57

Dolby Pro Logic II Effect .....................................................................................................................................................58

RADIO OPERATION

Listening to Radio...............................................................................................................................................................59

Presetting Stations..............................................................................................................................................................60

MISCELLANEOUS

Convenient Functions.........................................................................................................................................................61

Operating the TV with the Remote Control.........................................................................................................................63

Before Calling for Service...................................................................................................................................................65

Cautions on Handling and Storing Discs ............................................................................................................................67

Specifications......................................................................................................................................................................68

Notes on Terminology.........................................................................................................................................................69

Warranty .............................................................................................................................................................................70

CD-R Discs

•

Depending on the disc recording device (CD-Recorder or PC ) and the condition of the disc, some CD-R discs
may not be playable.

•

Use a 650MB/74 minute CD-R. Avoid CD-R media, as they may not be playable.

•

If possible, do not use CD-RW (Rewritable) media, as they may not be playable.

•

Only the CD-Rs that are properly "closed" can be fully played. If the session is closed but the disc is left open,
you may not be able to fully play the disc.

CD-R JPEG Discs

•

Only files with the ".jpeg" and ".JPEG" extensions can be played.

•

If the disc is not closed, it will take longer to start playing and not all of the recorded files may be played.

•

Only CD-R discs with JPEG files in ISO 9660 or Joliet format can be played.

•

JPEG file names should be 8 characters or less in length and contain no blank spaces or special characters (. / = +).

•

Only a consecutively written multi session disc can be played. If there is a blank segment in the multi session disc, the
disc can be played only up to the blank segment.

•

A maximum of 9,999 images can be stored on a single CD.

•

When playing a Kodak/Fuji Picture CD, only the JPEG files in the picture folder can be played.

•

Picture discs other than Kodak/Fuji Picture CDs may take longer to start playing or may not play at all.

Disc Recording Format

8

CD-R MP3 Discs

•

Only CD-R discs with MP3 files in ISO 9660 or Joliet format can be played.

•

MP3 file names should be 8 characters or less in length and contain no blank spaces or special characters (. / = +).

•

If the name of a file is in Korean, the name will be displayed on the TV screen in Korean and * will be shown in the
display of the main unit.

•

Use discs recorded with a compression/decompression data rate greater than 128Kbps.

•

Only files with the ".mp3" and ".MP3" extensions can be played.

•

Only a consecutively written Multi session disc can be played. If there is a blank segment in the Multi session disc,
the disc can be played only up to the blank segment.

•

If the disc is not closed, it will take longer to begin playback and not all of the recorded files may be played.

•

For files encoded in Variable Bit Rate (VBR) format, i.e. files encoded in both low bit rate and high bit rate (e.g.,
32Kbps ~ 320Kbps), the sound may skip during playback.

•

If more than 500 tracks are recorded on a single CD, a maximum of 500 tracks can be played.

•

If more than 300 folders are recorded on a single CD, a maximum of 300 folders can be played.

What is MP3?

MP3 is short for MPEG-1 Audio Layer 3 and MPEG is an acronym for Moving Pictures Experts
Group. MP3 is a file format with compression ratio of 1:12 (128 Kbps*) That is, you can use MP3
format to record about 12 times the usual amount of data on a regular CD.

DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital

surround sound and MPEG-2 video compression technology. Now you can enjoy these
realistic effects in the home, as if you were in a movie theater or concert hall.

V I D E O

DVD players and the discs are coded by region. These regional codes must match in order
for the disc to play. If the codes do not match, the disc will not play.
The Region Number for this player is given on the rear panel of the player.

(Your DVD player will only play DVDs that are labeled with identical region codes.)

1 6

~

Mark (Logo)

Audio + Video

DVD

VIDEO-CD

AUDIO-CD

5"

Approx. 240 min. (single-sided)

Approx. 480 min. (double-sided)

Approx. 80 min. (single-sided)

Approx. 160 min. (double-sided)

74 min.
20 min.
74 min.
20 min.

3 1/2"

5"

3 1/2"

5"

3 1/2"

Audio + Video

Audio

Recorded Signals

Disc Type Disc Size Max. Playing Time

•

LD, CD-G, CD-I, CD-ROM and DVD-ROM cannot be played on this player.
If such discs are played, a "WRONG DISC FORMAT" message appears on the TV screen.

•

DVD discs purchased abroad may not play on this player.
If such discs are played, a "WRONG REGION CODE" message appears on the TV screen.

7

Notes on Discs

DIGITAL
SOUND

NTSC

STEREO

Dolby Digital

disc

DTS disc Digital Audio

disc

Stereo disc

NTSC video format

NTSC is used in all of North

America, the Philippines,
South Korea and Japan.

MP3 disc

Playable Discs

Do not use the following types of disc!

•

Many DVD discs are encoded with copy protection. Because of this, you should only connect your
DVD player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture
from copy-protected DVD discs.

•

This product incorporates copyright protection technology that is protected by methods claims of certain
U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.

Copy Protection

PREPARATION

V I D E O

DIGITAL VIDEO

DIGITAL AUDIO

COMPACT

COMPACT

—Rear Panel—

Audio Cable

(AH39-40001U)

Video Cable

(AH39-40001V)

Remote Control

(AH59-01169U)

FM Antenna

(AH42-00004A)

User's Manual

(AH68-01241T)

AM Antenna

(AH42-20001P)

10

PHONES

FUNCTION

OPEN/CLOSE

DIRECT PLAY

12345

DISC CHANGE

VOLUME

—Front Panel—

DVD-A
TITLE

PRGM
CHAP TUNED

REPEAT 1
ALL DISC

5.1
CH

TITLE PBC

CHAP

PRGM

RDS

RT

TA

EX

CMX

L C R

SW

LS S RS

ST

kHz

MHz

LINEAR PCM
MPEG-2AAC

MPEG

PBC

SURROUND

A B
DSP

DOLBY DIGITAL indicator

PRO LOGIC indicator

P.SCAN indicator

SURROUND indicator

TITLE indicator

DVD-A indicator

PRGM indicator

CHAPTER indicator

DISC(1~5) indicator

5.1CH indicator

REPEAT indicator

DISC indicator

TUNER indicator

DSP indicator

9

Description

Power ( ) button

Standby indicator

Function button

Headphone Jack

Disc Tray

Open/Close button

Direct Play button

Volume control

Disc Change button

Tuning Down & Skip ( ) buttons

Tuning Up & Skip ( ) buttons

Play/Pause ( ) button

Stop ( ) button

AM Antenna
Connector

FM Antenna

Connector

External Video Component
Input Connectors

External Audio Component
Input Connector

5.1 Channel Speaker
Output Terminals

COMPONENT VIDEO

OUTPUT/INPUT jacks

Connect a TV with component

video inputs to these jacks.

S-Video Output Connector

If the TV is equipped with an S-Video input
connector (S-VIDEO IN), connect it to the
player's S-Video output jack.

Video Output Connector

Connect the TV's video input jacks

(VIDEO IN) to the VIDEO OUT connector.

External Digital Component Input

Connector

Use this to connect external equipment

capable of digital output.

Accessories

RADIO FREQUENCY

indicator

System Status Display
SPEAKER indicator
DTS Disc indicator

LINEAR PCM indicator

MPEG-2 AAC indicator

MPEG indicator

PBC indicator

PREPARATION

To open the remote control cover, push the
top of the cover, then slide downward.

12

Insert Remote Batteries

The remote control can be used up to approximately 23
feet/7 meters in a straight line. It can also be operated at
a horizontal angle of up to 30° from the remote control
sensor.

Range of Operation of the Remote Control

Remove the battery
cover on the back of
the remote by
pressing down and
sliding the cover in
the direction of the
arrow.

1

Insert two 1.5V AAA
batteries, paying
attention to the correct
polarities (+ and –).

2

Replace the battery
cover.

3

Follow these precautions to avoid leaking or cracking cells:

•

Place batteries in the remote control so they match the polarity:(+) to (+)and (–)to (–).

•

Use the correct type of batteries.Batteries that look similar may differ in voltage.

•

Always replace both batteries at the same time.

•

Do not expose batteries to heat or flame.

TV DVD RECEIVER

OPEN/CLOSE

DVD TUNER AUX

EZ VIEW SLOW DISC SKIP

STEP

TUNING/CH

PL II

R

E

T

U

R

N

MENU

INFO

MUTE

MODE

ENTER

P.SCAN

SOUND EDIT

TEST TONE

SLEEP

LOGO DIGEST

SLIDE MODE

CANCEL ZOOM

REMAIN

TUNER

MEMORY

PL II

EFFECT

VOLUME

DSP/EQ REPEAT

BAND

MO/ST

TV/VIDEO MODE
DIMMER

PL II MODE button

TUNING/CH button

MENU button

DVD POWER button

OPEN/CLOSE button

STEP button

DSP/EQ button

EZ VIEW button

RETURN button

Number(0~9) buttons

SLEEP button

SLIDE MODE button

LOGO button

TV indicator
DVD RECEIVER indicator

TV/VIDEO, DIMMER button

MODE button

Direction/Enter button

DIGEST button

REMAIN button

CANCEL button

ZOOM button

TUNER MEMORY, P.SCAN button

SOUND EDIT button

TEST TONE button

MUTE button

INFO button

VOLUME button

REPEAT button

SLOW, MO/ST button

DISC SKIP button

PL II EFFECT button

—Remote Control—

DVD button

Play/Pause button

Tuning Preset/CD Skip button

Stop button

AUX button

11

TUNER BAND button

Description

Caution

PREPARATION

RSLS

C

L

SW

R

14

Rear Speakers

•

Place these speakers behind your listening position.

•

If there isn't enough room, place these speakers to face each other.

•

Place them about 60 to 90cm (2 to 3feet) above your ear, facing
slightly downward.

*

Unlike the front and center speakers, the rear speakers are used
to handle mainly sound effects and sound will not come from
them all the time.

Subwoofer

•

The position of the subwoofer is not so critical.
Place it anywhere you like.

•

Usually, it is placed by a corner near the front speakers.

Front Speakers

•

Place these speakers in front of your listening
position, facing inwards (about 45°) toward you.

•

Place the speakers so that their tweeters will be at
the same height as your ear.

•

Align the front face of the front speakers with the
front face of the center speaker or place them
slightly in front of the center speakers.

Center Speaker

•

It is best to install it at the same height as the front
speakers.

•

You can also install it directly over or under the TV.

Position of the DVD Player

•

Place it on a stand or cabinet shelf, or under
the TV stand.

Selecting the Listening Position

The listening position should be located about 2.5 to 3
times the distance of the TV's screen size away from the
TV. Example: For 32" TVs 2~2.4m (6~8feet)

For 55" TVs 3.5~4m (11~13feet)

13

Connecting the Speakers

Before moving or installing the product, be sure to turn off the power and disconnect the power cord.

CONNECTIONS

R

L

C

RS

LS

SW

•

Make sure the colors of the speaker terminals
match the colors of the connecting jacks.

•

Make sure the polarities (+ and -) are correctly.

•

Insert the black wire into he black (-)
terminal and the gray wire into the
gray (+) terminal.

•

Make sure the polarities (+ and -)
are correctly.

Black

Press down the terminal
tab on the back of the
speaker.

1

Insert the wire into the
terminal and release the
terminal tab.

2

Connect the connecting jacks (6)
to the back of the DVD player.

3

Gray

Back of the Speakers Back of the Main Unit

Rear Speaker

(L)

Rear Speaker

(R)

Subwoofer

Center Speaker

Front Speaker (L)

Front Speaker (R)

Blue

Gray

Purple

White

Red

Green

16

Connecting the Video to TV

15

Composite Video (Good Quality)

Connect the supplied video cable from the VIDEO OUT jack on the back panel of the
system to the VIDEO IN jack on your television.

S-Video (Better Quality)

If you television is equipped with an S-Video input, connect an S-Video cable (not supplied)
from the S-VIDEO OUT jack on the back panel of the system to the S-VIDEO IN jack on
your television.

Component Video (Best Quality)

If your television is equipped with Component Video inputs, connect a component video
cable (not supplied) from the Pr, Pb and Y jacks on the back panel of the system to the
corresponding jacks on your television.

Composite

Video

Component

Video

S-Video

TV

•

When the Progressive scan mode is selected, the VIDEO and S-VIDEO outputs do not feed
any signals. See page 16 to select Progressive Scan.

*

Depending on your TV, Component Video input connectors may be marked as DVD Video input connectors.

Note

P.SCAN(Progressive Scan) Function

Unlike a regular Interlace Scan in which two fields of picture information are alternated to
create the entire picture (odd scan lines, then even scan lines), Progressive Scan uses one
field of information (all lines displayed in one pass) to create a clear and detailed picture
without visible scan lines.

While the player is in the Stop mode, hold the P.SCAN button down for longer
than 1 second.

•

The selection switches back and forth between "P.SCAN" and "I.SCAN" each time the button is held
down for a minimum of 1 second.

•

The previous mode is indicated in the display first, followed by the selected mode in about a second.

In interlaced-scan video, a frame consists of two
interlaced fields (odd and even), where each field
contains every other horizontal line in the frame.
The odd field of alternating lines is displayed first, and
then the even field is displayed to fill in the alternating
gaps left by the odd field to form a single frame.
One frame, displayed every 1/30th of a second, contains
two interfaced fields, thus a total of 60 fields are
displayed every 1/60th of a second each.
The interlaced scanning method is intended for capturing
a still object.

Interlaced Scan (1 FRAME = 2 FIELDS)

The progressive scanning method scans one full frame of
video consecutively down the screen, line by line.
As opposed to the interlaced scanning process by which a
video image is drawn in a series of passes, you get an
entire image drawn at one time.
The progressive scanning method is desirable for dealing
with moving objects. A camera that has the ability to
capture moving objects is called a "full frame shutter
camera".

Progressive Scan (FULL FRAME)

What is Progressive (or Non-Interlaced) Scanning?

•

This function works only on TVs equipped with component video inputs (Y, Pr, Pb) that support Progressive
Video. (It does not work on TVs with conventional component inputs, i.e., non-progressive scan TVs.)

•

Depending on the brand and model of your TV, this function may not work.

Note

CONNECTIONS

Press AUX on the remote control to select AUX 1
or AUX 2.

•

Each time the button is pressed, the selection changes as
follows: DIGITAL IN AUX 1 AUX 2.

•

You can also use the FUNCTION button on the main unit.
The mode switches as follows: DVD/CD ➝ DIGITAL IN ➝
AUX1 ➝ AUX2 ➝ FM ➝ AM.

•

If you have connected an external digital
component and Video In (1, 2) at the
same time, there will be video from AUX 1
even when you select DIGITAL IN.

•

If you have connected Audio In (L, R) to
1, connect Video In to 1 as well, and if
you have connected Audio In (L, R) to 2,
connect Video In to 2 also.

Connect Audio In on the DVD player to Audio
Out on the external analog component.

•

Be sure to match connector colors.

Connect Video Out on the DVD player to Video
In on the TV.

1

Connect Video In on the DVD player to Video
Out on the external analog component.

2
3

4

18

Example: Analog signal components such as a VCR, Camcorder, and TV.

Connecting an External Analog Component

Video Cable

Audio Cable

If the external

analog component
has only one Audio
Out, connect either

left or right.

Press AUX on the remote control to select ‘DIGITAL IN’.

•

Each time the button is pressed, the selection changes as follows: DIGITAL IN ➝ AUX 1 ➝ AUX 2.

•

You can also use the FUNCTION button on the main unit.
The mode switches as follows: DVD/CD ➝ DIGITAL IN ➝ AUX1 ➝ AUX2 ➝ FM ➝ AM.

Connecting External Components

Connect Video Out on the DVD player to Video In on the TV.

1

Connect the Digital Input (OPTICAL) to the Digital Output on the external
digital component.

2
3

17

Example: Digital signal components such as a DVD or CD Recorder.

Connecting an External Digital Component

Optical Cable
(not included)

Note

CONNECTIONS

VIDEO IN

R

DIGITAL OUTVIDEO OUT

L

VIDEO IN

VIDEO OUT

The cooling fan dissipates the heat generated inside the unit so that the unit can be operated
normally. The cooling fan is activated automatically to supply cool air to the unit.

Please observe the following cautions for your safety.

•

Make sure the unit is well-ventilated. If the unit has poor ventilation, the temperature inside the unit could rise
and may damage it.

•

Do not obstruct the cooling fan or ventilation holes. (If the cooling fan or ventilation holes are covered with a
newspaper or cloth, heat may build up inside the unit and fire may result.)

Cooling Fan

20

Connecting the Antennas

19

Connect the FM antenna supplied to the FM 75Ω COAXIAL terminal as a
temporary measure.

Slowly move the antenna wire around until you find a location where reception
is good, then fasten it to a wall or other rigid surface.

• If reception is poor, connect an outdoor antenna.
Before attaching a 75Ω coaxial cable (with a standard
type connector), disconnect the supplied FM antenna

(not supplied).

CONNECTIONS

FM antenna connection

1
2

Connect the AM loop antenna supplied to the AM and terminals.

If reception is poor, connect an outdoor single vinyl-covered wire to the AM
terminal. (Keep the AM loop antenna connected).

AM(MW) antenna connection

123

1
2

FM Antenna (supplied)

Snap the tabs on the loop into the
slots of the base to assemble the
AM loop antenna.

AM Loop Antenna
(supplied)

If AM reception is poor, connect an outdoor AM
antenna(not supplied).
