Samsung HT-D5100-ZC User Manual

Download

HT-D5100

5.1CH Blu-ray™

Home Entertainment System

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service,

please register your product at

www.samsung.com/register

HT-D5100_XAA_1224.indd 1HT-D5100_XAA_1224.indd 1 2011-12-24  12:29:552011-12-24  12:29:55

Safety Information

Safety Warnings

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lighting ﬂ ash and Arrowhead within Triangle Is awarning sign alerting you of dangerous voltage Inside the product.

CAUTION :

SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

TO REDUCE THE RISK OF ELECTRIC

The explanation point within the triangle is a warning sign alerting you of important instructions accompanying the product.

WARNING

To reduce the risk of ﬁ re or electric shock, do not

•

expose this appliance to rain or moisture.

CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT LUOKAN 1 LASER LAITE KLASS 1 LASER APPARAT PRODUCTO LÁSER CLASE 1

CLASS 1 LASER PRODUCT

This product is classiﬁ ed as a CLASS 1 LASER

•

product. Use of controls, adjustments or performance of procedures other than those speciﬁ ed herein may result in hazardous radiation exposure.

•

Complies with 21CFR 1040.10 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.

This product satisﬁ es FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances, such as radios and televisions, use shielded cables and connectors for connections.

CAUTION

Apparatus shall not be exposed to dripping or splashing and

•

no objects ﬁ lled with liquids, such as vases, shall be placed on the apparatus.

The Mains plug is used as a disconnect device and shall stay

•

readily operable at any time.

DANGER

VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM. (FDA 21 CFR)

CAUTION

CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION

•

WHEN OPEN. AVOID EXPOSURE TO THE BEAM (IEC 60825-1)

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS

•

OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVER AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

FCC NOTE (for U.S.A)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

CAUTION : FCC regulations state that any unauthorized changes or modifications to this equipment may void the user’s

authority to operate it.

2 English

HT-D5100_XAA_1224.indd 2HT-D5100_XAA_1224.indd 2 2011-12-24  12:30:112011-12-24  12:30:11

Important Safety Instructions

Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference.

1) Read these instructions.

2) Keep these Instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁ ers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not ﬁ t into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachment/accessories speciﬁ ed by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table speciﬁ ed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualiﬁ ed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Precautions

Ensure that the AC power supply in your house

•

complies with speciﬁ cations listed on the identiﬁ cation sticker located on the back of your product.

Install your product horizontally, on a suitable base

•

(furniture), with enough space around it for ventilation (7.5~10cm / 20~25 inches).

Do not place the product on ampliﬁ ers or other

•

equipment which may become hot. Make sure the ventilation slots are not covered.

Do not stack anything on top of the product.

•

Before moving the product, ensure the Disc Insert

•

Hole is empty.

To disconnect the product completely from the

•

power supply, remove its plug from the wall outlet.

- If you leave the product unused for a long period of time, disconnect the plug from the wall outlet.

During thunderstorms, disconnect the AC plug

•

from the wall outlet. Voltage spikes caused by lightning could damage the product.

Do not expose the product to direct sunlight or

•

other heat sources. This could cause the product to overheat and malfunction.

Protect the product from moisture, excess heat,

•

and equipment creating strong magnetic or electric ﬁ elds (i.e. speakers.).

Disconnect the power cable from the AC supply if

•

the product malfunctions.

Your product is not intended for industrial use. It is

•

for personal use only.

Condensation may occur if you store your product

•

or a disc in cold temperatures. If transporting the product during the winter, wait approximately 2 hours until the product has reached room temperature before using.

The batteries used with this product contain

•

chemicals that are harmful to the environment. Do not dispose of batteries in the general household trash.

English 3

HT-D5100_XAA_1224.indd 3HT-D5100_XAA_1224.indd 3 2011-12-24  12:30:112011-12-24  12:30:11

Safety Information

Cautions on Handling and Storing Discs

Small scratches on the disc may reduce sound and picture quality or cause skipping.

Be especially careful not to scratch discs when handling them.

Holding discs

Do not touch the playback side of the disc.

•

Hold the disc by the edges so that

•

ﬁ ngerprints will not get on the surface.

Do not stick paper or tape on the disc.

•

Disc Storage

Do not keep in direct sunlight

•

Keep in a cool ventilated area

•

Keep in a clean protection jacket and store

•

vertically.

NOTE

✎

Do not allow the discs to become contaminated with



dirt.

Do not load cracked or scratched discs.



Handling and Storing Discs

If you get fingerprints or dirt on the disc, clean it with a mild detergent diluted in water and wipe with a soft cloth.

When cleaning, wipe gently from the inside to

•

the outside of the disc

NOTE

✎

Condensation may form if warm air comes into



contact with cold parts inside the product. When condensation forms inside the product, it may not operate correctly. If this occurs, remove the disc and let the product stand for 1 or 2 hours with the power on.

Dolby and the double-D symbol are registered trademarks of Dolby

•

Laboratories.

•

"Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929; 7,212,872 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks, & DTS-HD, DTS-HD Master Audio | Essential and the DTS logos are trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved."

•

"ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is an ofﬁ cial DivX Certiﬁ ed® device that plays DivX video. Visit www. divx.com for more information and software tools to convert your ﬁ les into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certiﬁ ed® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

DivX Certiﬁ ed® to play DivX® video up to HD 1080p, including premium content. DivX®, DivX Certiﬁ ed® and associated logos are trademarks of DivX, Inc. and are used under license."

Covered by one or more of the following U.S. patents : 7,295,673; 7,460,668; 7,515,710; 7,519,274

•

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

•

Oracle and Java are registered trademarks of Oracle and/or its afﬁ

•

This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

•

Blu-ray Disc™, Blu-ray™, and the logos are trademarks of Blu-ray Disc Association.

•

iPod is a trademark of Apple Inc., registered in the U.S. and other countries. iPhone is a trademark of Apple Inc.

< Open Source License Notice >

•

In the case of using open source software, Open Source Licenses are available on the product menu.

License

liates. Other names may be trademarks of their respective owners.

4 English

HT-D5100_XAA_1224.indd 4HT-D5100_XAA_1224.indd 4 2011-12-24  12:30:112011-12-24  12:30:11

Contents

SAFETY INFORMATION

GETTING STARTED

CONNECTIONS

SETUP

2 Safety Warnings 3 Important Safety Instructions 3 Precautions 4 Cautions on Handling and Storing Discs 4 License 4 Copyright

7 Key features of your new Blu-ray Home Theater 8 Icons that will be used in manual 9 Disc Types and Characteristics 13 Accessories 14 Description 14 Front Panel 15 Rear Panel 16 Remote Control

18 Connecting the Speakers 20 Connecting the Optional Wireless Receiver Module 21 Attaching the Toroidal Ferrite Core to the Power Cord of

the Main Unit 22 Connecting the Video Out to your TV 24

Connecting Audio from External Components 25 Connecting to a Network 26 Connecting the FM Antenna

27 Initial Settings 28 Accessing the Settings Menu 29 Display 29 TV Aspect (Picture Size and Format) 29 Smart Hub Screen Size 29 BD Wise (Samsung Products only) 29 Resolution 31 HDMI Color Format 31 Movie Frame (24 Fs) 31 HDMI Deep Color 31 Still Mode 31 Progressive Mode 32 Audio 32 Speaker Settings 33 Musical Room Calibration 33 User EQ 34 HDMI Audio 34 Audio Return Channel 34 Digital Output 35 Dynamic Range Control 36 Audio Sync 36 Network 36 Network Settings 39 Network Status 39 BD-LIVE Internet Connection 39 System 39 Initial Settings 40 Anynet+ (HDMI-CEC) 40 BD Data Management 40 Time Zone 40 DivX® Video On Demand 40 Reset 41 Language

ENGLISH

English 5

HT-D5100_XAA_1224.indd 5HT-D5100_XAA_1224.indd 5 2011-12-24  12:30:112011-12-24  12:30:11

Contents

SETUP

BASIC FUNCTIONS

NETWORK SERVICES

41 Security 41 BD Parental Rating 41 DVD Parental Rating 41 Change Password 41 General 41 Front Display 41 Network Remote Control 42 Support 42 Software Upgrade 43 Contact Samsung

44 Playing a Disc 44 Using the Disc menu / Title menu / Popup menu 45 Playing the Title List 45 Using the Search and Skip Functions 46 Slow Motion Play/Step Motion Play 46 Repeat Playback 47 Using the TOOLS button 49 Listening to Music 51 Sound Mode 52 Playing back a Picture 53 Playing back a USB Storage Device 54 Listening to Radio 54 Connecting an iPod/iPhone Using the USB Cable 54 Use iPo d/iPhone with a Wireless Dock Cradle (sold

separately) for iPod/iPhone 55 iPod/iPhone Models You Can Use with This Product 56 How to Link the Wireless Transmitter with the Main Unit

57 Using Smart Hub 64 Samsung Apps 66 BD-LIVE™ 66 Using the AllShare Function

OTHER INFORMATION

67 Troubleshooting 70 Index 71 Speciﬁ cations

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product

• appearance.

6 English

HT-D5100_XAA_1224.indd 6HT-D5100_XAA_1224.indd 6 2011-12-24  12:30:122011-12-24  12:30:12

Getting Started

Key features of your new Blu-ray Home Theater

Product Features

Smart Hub

You can download various for pay or free-of charge applications through a network connection. These applications provide a range of Internet services and content including news, weather forecasts, stock market quotes, games, movies, and music.

AllShare

You can play videos, music and photos saved on your devices (such as your PC, mobile phones or NAS) through the home theater via a network connection.

Audio Sync function

Video may lag behind the audio if the product is connected to a digital TV. To compensate for this, you can adjust the audio delay time so that the audio syncs with the video.

iPod & iPhone support

If you have connected an iPod player to the home theater using the iPod/iPhone specific USB cable or wireless transmitter (sold separately), you can play the music files in the iPod/iPhone through the connected speakers.

BD Wise

BD Wise automatically adjusts BD Wise-compliant Samsung products to their optimal settings. This feature is enabled only if BD Wise-compliant Samsung products are connected to each other using an HDMI cable.

01 Getting Started

Virtual 7.1

Applies the 7.1 CH sound effect using the 5.1 CH speaker system.

ARC (Audio Return Channel)

You can enjoy TV sound from the Home Theater speakers by using just one HDMI cable.

English 7

HT-D5100_XAA_1224.indd 7HT-D5100_XAA_1224.indd 7 2011-12-24  12:30:122011-12-24  12:30:12

Getting Started

Icons that will be used in manual

Make sure you understand the following terms before reading the rest of the user manual.

Term Logo Icon Definition

BD-ROM

BD-RE/-R

DVD-VIDEO

DVD-RW(V)

DVD-R

DVD+RW

DVD+R

Audio CD

MP3

WMA

JPEG

DivX MKV MP4

USB storage

device

CAUTION

NOTE

Shortcut Key

DivX

h z Z

o w G

Indicates a function available on a BD-ROM.

Indicates a function available on a BD-RE/-R disc recorded in the BD-RE format.

Indicates a function available on a DVD-VIDEO.

Indicates a function available on recorded DVD+RW or DVD-RW(V)/DVDR/+R discs that have been recorded and ﬁ nalized.

Indicates a function available on an audio CD-RW/-R (CD-DA format).

Indicates a function available in a CD-RW/-R, DVD-RW/-R disc or a USB storage media containing MP3 or WMA contents.

Indicates a function available in a CD-RW/-R, DVD-RW/-R disc or a USB storage media containing JPEG contents.

Indicates a function available in a CD-RW/-R, DVD-RW/-R disc or a USB storage media containing DivX contents.

Indicates a function available on a USB storage device.

Indicates a situation where a function does not operate or settings may be

cancelled.

Indicates tips or instructions that can help you operate a function better.

✎

Indicates that you can access this function quickly and easily by pressing a button on the remote control.

This product is compatible with the NTSC color system only.

•

PAL discs will not play.

•

8 English

HT-D5100_XAA_1224.indd 8HT-D5100_XAA_1224.indd 8 2011-12-24  12:30:122011-12-24  12:30:12

01 Getting Started

Disc Types and Characteristics

Blu-ray Disc Compatibility

Blu-ray is a new and evolving format. Accordingly, disc compatibility issues are possible. Not all discs are compatible and not every disc will play back. For additional information, refer to the Disc Types and Characteristics section of this Manual.

NOTE

✎

Playback may not work for some types of discs or



when you use speciﬁ c functions such as angle change and aspect ratio adjustment. Information about the discs is written in detail on the box. Please refer to this if necessary. Do not allow discs to become dirty or scratched.



Fingerprints, dirt, dust, scratches, or deposits of cigarette smoke on the recording surface may make it impossible to playback a disc. When you play a BD-Java title, loading may take



longer than a normal title or some functions may perform slowly.

Discs that cannot be played

HD DVD Disc

•

DVD-RAM

•

3.9 GB DVD-R Disc for Authoring.

•

DVD-RW(VR mode)

•

Super Audio CD(except CD layer)

•

DVD-ROM/PD/MV-Disc, etc CVD/CD-ROM/

•

CDV/CD-G/CD-I/LD CDGs play audio only, not graphics.

•

Logos of Discs that can be played

Blu-ray Disc Dolby Digital Plus

NTSC broadcast system in

U.S.A, Canada, Korea,

Japan

DTS-HD High Resolution

Audio

DTS-HD Master Audio |

Essential

Dolby TrueHD

Java

BD-LIVE

NOTE

✎

Some commercial discs and DVD discs purchased



outside your region may not play on this product. If a DVD-R/-RW disc has not been recorded properly



in DVD video format, it will not play on this product.

English 9

HT-D5100_XAA_1224.indd 9HT-D5100_XAA_1224.indd 9 2011-12-24  12:30:142011-12-24  12:30:14

Getting Started

Region Code

Both the product and the discs are coded by region. These regional codes must match for the product to play the disc.If the codes do not match, the disc will not play.

Disc Type

Blu-ray

DVD-VIDEO

Region

Code

North America, Central America, South America, Korea, Japan,

Taiwan, Hong Kong and South East Asia.

Europe, Greenland, French territories, Middle East, Africa,

Australia and New Zealand.

India, China, Russia, Central and

South Asia.

The U.S., U.S. territories and

Canada

Europe, Japan, the Middle East,

Egypt, South Africa, Greenland

Taiwan, Korea, the Philippines,

Indonesia, Hong Kong

Mexico, South America, Central America, Australia, New Zealand,

Paciﬁ c Islands, Caribbean

Russia, Eastern Europe, India, most of Africa, North Korea,

Mongolia

China

Area

Disc Types

BD-ROM

Blu-ray discs can only be played back. This product can play back pre-recorded commercial BD-ROM discs.

BD-RE/-R

Blu-ray RE/-R discs can be recorded and played back. This product can play back a BD-RE/-R disc recorded by other compatible Blu-ray disc recorders.

DVD-VIDEO

This product can play back pre-recorded commercial

•

DVD discs (DVD-VIDEO discs) with movies. When switching from the ﬁ rst layer to the second

•

layer of a dual-layered DVD-VIDEO disc, there may be momentary distortion in the image and

product

sound. This is not a malfunction of the

DVD-RW/-R/+R

This

product recorded and ﬁ nalized with a DVD video recorder. The ability to play back may depend on recording conditions.

DVD+RW

•

This product can play back a DVD+RW disc recorded with a DVD Video recorder. The ability to play back may depend on recording conditions.

Audio CD (CD-DA)

•

This CD-RW/-R discs.

•

The product may not be able to play some CDRW/-R discs due to the condition of the recording.

CD-RW/-R

•

Use 700MB (80 minute) CD-RW/-R discs. Do not use 800MB (90 minute) or larger discs, as these discs may not play back.

•

If the CD-RW/-R disc was not recorded as a closed session, you may experience delays when playing back the beginning of the disc or all recorded ﬁ les may not play.

Some CD-RW/-R discs may not play on this

•

product, depending on the device which was used to burn them. For contents recorded on CDRW/-R media from CDs for your personal use, playability may vary depending on the contents and discs.

can play back a DVD-RW/-R/+R disc

product

can play back CD-DA format audio

10 English

HT-D5100_XAA_1224.indd 10HT-D5100_XAA_1224.indd 10 2011-12-24  12:30:152011-12-24  12:30:15

Disc Format

Using JPEG discs

The home theater can play back D-R/-RW, DVD-RW/-R discs recorded in the UDF or JOLIET format.

•

Only JPEG ﬁ les with the ".jpg", ".JPG", ".jpeg" or "JPEG" extension can be displayed.

•

Progressive JPEG is supported.

•

DVD-RW/-R (V)

•

This format is used for recording data on DVD-RW or DVD-R discs. This product can play DVD-RW or DVD-R discs if they have been ﬁ nalized.

•

If a disc that has been recorded in Video Mode by a different maker’s recorder but has not been ﬁ nalized, it cannot be played by this product.

Supported File Formats

Video File Support

File Extension Container Video Codec Audio Codec Resolution

*.avi

*.mkv

*.asf

*.wmv

*.mp4

*.3gp

DivX 3.11/4.x/5.1/6.0

AVI

MKV

ASF

ASF Window Media Video v9

MP4

3GPP

H.264 BP/MP/HP

MPEG4 SP/ASP

Motion JPEG

DivX 3.11/4.x/5.1/6.0

H.264 BP/MP/HP

MPEG4 SP/ASP

Motion JPEG

DivX 3.11/4.x/5.1/6.0

H.264 BP/MP/HP

MPEG4 SP/ASP

Motion JPEG

H.264 BP/MP/HP

MPEG4 SP/ASP

H.264 BP/MP/HP

MPEG4 SP/ASP

MP3 AC3

LPCM

ADPCM

DTS Core

MP3 AC3

LPCM

ADPCM

DTS Core

MP3 AC3

LPCM

ADPCM

WMA

WMA 1920x1080

MP3

ADPCM

AAC

ADPCM

AAC

HE-AAC

1920x1080

01 Getting Started

English 11

HT-D5100_XAA_1224.indd 11HT-D5100_XAA_1224.indd 11 2011-12-24  12:30:152011-12-24  12:30:15

Getting Started

File Extension Container Video Codec Audio Codec Resolution

AC3 MPEG LPCM

AAC

AC3

AAC

MP3 DD+

HE-AAC

*.vro

*.mpg

*.mpeg

*.ts *.tp

*.trp

VRO VOB

MPEG2

MPEG1

MPEG2

H.264

MPEG2

H.264

VC1

Restrictions

Some of the Codecs listed above will not play if there is a problem with the contents.

• Corrupt video sources or sources with incorrect container information will not play properly.

• AV sources that exceed the standard bit rate or frame rate may not play properly.

• If the index table is corrupt, the Seek (Jump) function will not be supported.

• If you play a video via the network, it may not play properly depending on the network status.

•

Video decoder

Up to H.264 Level 4.1 supported.

• H.264 FMO/ASO/RS, VC1 SP/MP/AP L4, AVCHD not supported.

• MPEG4 SP, ASP :

•

- Below 1280 x 720: 60 frame max

- Above 1280 x 720: 30 frame max GMC 2 or higher not supported.

•

1920x1080

352x288

1920x1080

Audio decoder

Up to WMA 7,8,9 supported.

• WMA 9 PRO with more than two channels (multi-channel) not supported.

• WMA 9 Lossless, Voice not supported.

• WMA sampling rate at 22050Hz mono not supported.

•

Music File Support

File Extension Container Audio Codec Support Range

*.mp3

*.wma

MP3

WMA

MP3 -

Compliant with WMA version 10

WMA

* Sampling rates (in kHz) - 8, 11, 16, 22, 32,

44.1, 48

* Bit rates - All bit-rates in the range 5kbps to

384kbps

12 English

HT-D5100_XAA_1224.indd 12HT-D5100_XAA_1224.indd 12 2011-12-24  12:30:162011-12-24  12:30:16

Connect USB devices directly to the

Notes on the USB connection

6) product's USB port. Connecting through a

Supported devices:

USB storage media, MP3 player, digital camera, USB card reader

The product does not support folder or ﬁ le names longer than 125 characters.

A subtitle ﬁ le bigger than 300 KB may not be properly displayed.

Some USB/digital camera devices may not be compatible with the product.

The praoduct supports the FAT16 and FAT32 ﬁ le systems.

Photo (JPEG), music (MP3,) and video ﬁ les

USB cable may cause compatibility problems.

Inserting more than one memory device into

7) a multi-card reader may cause the reader to operate improperly.

The product does not support the PTP

8) protocol for digital cameras

Do not disconnect a USB device during a

9) "loading" process.

The bigger the image resolution, the longer

10)

This player cannot play MP3 ﬁ les with DRM

11)

must have Korean or English ﬁ le names. Otherwise, the ﬁ les will not play.

Accessories

Check the box for the supplied accessories listed below.

01 Getting Started

the image takes to display.

(Digital Rights Management) downloaded from commercial sites.

Video Cable (AH39-40001V) FM Antenna (AH42-00017A) User's Manual (AH68-02322R)

FUNCTION

POWER

TV SOURCE

RECEIVER SLEEP

BD TV

123 456 7809

REPEATFULL SCREEN

MUTE

TUNING

VOL

/CH

SFE MODE

DISC MENU MENU TITLE MENU

POPUP

TOOLS

INFO

RETURN

EXIT

TUNER MEMORY

iPod SYNC

DSP

SMART SEARCH

NETFLIX

HUB

MO/ST

Remote Control (AH59-02333A)/

Batteries (AAA size) (4301-000116)

ASC Microphone (AH30-00099A) Toroidal Ferrite Core (3301-000144)

(For Power cord)

Wireless Dock Cradle for iPod/iPhone : HT-WDC10 (sold separately)

CHAR

L I

N K

S T A

N D

B Y

Wireless Transmitter

(AH96-00641A)

Charging Cradle

(AH96-00641B)

DC Power Cord

(AH96-00647A)

DC Power Adapter

(BN44-00388D)

English 13

HT-D5100_XAA_1224.indd 13HT-D5100_XAA_1224.indd 13 2011-12-24  12:30:162011-12-24  12:30:16

Getting Started

Front Panel

Description

1 3 4 5 6 7

REMOTE CONTROL SENSOR

DISC TRAY

2 3

POWER BUTTON ( )

FUNCTION BUTTON

DISPLAY

STOP BUTTON

PLAY/PAUSE BUTTON

ENTER BUTTON

OPEN/CLOSE BUTTON

ASC IN JACK

VOLUME CONTROL

USB PORT

Detects signals from the remote control.

Opens to accept a disc.

Turns the product on and off.

The mode switches as follows : BD/DVD  D. IN  AUX  R. IPOD  W. IPOD  FM

Displays the playing status, time, etc.

Stops disc playback.

Plays a disc or pauses playback.

Selects menu items or starts a Blu-ray disc. (It will not start a DVD disc.)

Opens and closes the disc tray.

Used to connect the ASC Microphone for setting up MRC (Musical Room Calibration).

Volume adjustment.

You can connect a USB memory ﬂ ash stick here and use it as storage when the product is connected to BD-LIVE. You can also use the USB Host for software upgrades and MP3/JPEG/ DivX/MKV/MP4 playback. And also it is possible to use R. IPOD when iPod is connected.

10911

ASC IN

5V 500mA

NOTE

✎

You must use a USB memory ﬂ ash stick to perform a software upgrade using the USB Host jack.



When the product displays the Blu-ray disc menu, you cannot start the movie by pressing the PLAY button on the



product or the remote. To play the movie, you must select Play Movie or Start in the disc menu, and then press the ENTER button.

14 English

HT-D5100_XAA_1224.indd 14HT-D5100_XAA_1224.indd 14 2011-12-24  12:30:182011-12-24  12:30:18

Rear Panel

01 Getting Started

3 4

2 5 76

LAN

WIRELESS LAN

LAN TERMINAL

WIRELESS LAN JACK

EXTERNAL DIGITAL AUDIO IN JACK

(OPTICAL)

HDMI OUT JACK

FM ANTENNA JACK

TX CARD CONNECTION (WIRELESS)

AUX IN JACKS

COMPONENT VIDEO OUT JACKS

VIDEO OUT JACK

5.1 CHANNEL SPEAKER OUTPUT

CONNECTORS

COOLING FAN

DIGITAL AUDIO IN

OPTICAL

HDMI OUT

FM ANT

WIRELESS

COMPONENT OUT

AUX IN

VIDEO OUT

SPEAKERS OUT

CENTER SURROUNDFRONT

SUBWOOFER SURROUND

FRONT

SPEAKER IMPEDANCE : 3

Can be used for network based services (see pages 57~64), BD-LIVE and software upgrade under the network connection.

Can be used for network based services (see pages 57~64), BD-LIVE and software upgrade with a wireless LAN adapter.

Connect to the Digital Optical out jack of an external device using a Digital Optical cable.

Use an HDMI cable, connect this HDMI output terminal to the HDMI input terminal on your TV for the best quality picture.

Connect the FM antenna.

The TX card enables communication between the product and the optional wireless receiver module.

Connect to the 2CH analog output of an external device (such as a VCR)

Connect a TV with Component video inputs to these jacks.

Connect your TV's Video Input jack (VIDEO IN) to the VIDEO OUT Jack on this product.

Connect the front, center, surround, subwoofer speakers.

The cooling fan supplies cool air to the product to prevent overheating and always revolves when the power is on.

CAUTION

Ensure a minimum of 4 inches of clear space on all sides of the home theater to ensure adequate



ventillation. Do not obstruct the cooling fan or ventilation holes.



English 15

HT-D5100_XAA_1224.indd 15HT-D5100_XAA_1224.indd 15 2011-12-24  12:30:212011-12-24  12:30:21

Getting Started

Tour of the Remote Control

Remote Control

Turn the product on and off.

To change to TV mode, press the TV

button.

To change to Home Theater, press the

BD button.

Press numeric buttons to operate options.

Press to see the full screen on a TV.

Press to skip backwards or forwards.

Press to stop/play a disc.

Cut off the sound temporarily.

Adjust the volume.

Press to move to the home menu.

Press to view the disc menu.

Press to use the Tools menu.

Select on-screen menu items and

change menu value.

Return to the previous menu.

These buttons are used both for menus

on the product and also several

Blu-ray Disc functions.

Press to use the Netflix.

Press to use Smart Hub.

This button is not available to use.

Select the desired Dolby Pro Logic II

audio mode.

POWER

RECEIVER SLEEP

BD TV

FUNCTION

TV SOURCE

123 456 7809

REPEATFULL SCREEN

MUTE

VOL

DISC MENU MENU TITLE MENU

TOOLS

RETURN

SMART SEARCH

NETFLIX

HUB

TUNING

SFE MODE

/CH

POPUP

INFO

EXIT

TUNER

MEMORY

DSP

MO/ST

Press to select Blu-ray's mode. or Press to select TV's video mode.

Set a Sleep time to shut off the product.

To open and close the disc tray.

Allows you to repeat a title, chapter, track or disc.

Press to search backwards or forwards.

Press to pause a disc.

Search for active FM stations and change channels.

You can set the SFE (Sound Field Effect) mode best suited for the type of music you are listening to.

Use to enter the popup menu/title menu.

Use to display the playback information when playing a Blu-ray/DVD disc.

Press to exit the menu.

Used to set a preset radio frequency.

Regulate and stabilize the volume level. (Digital Signal Processor)

Press to search contents.

This button is not available to use.

Select MONO or STEREO for radio broadcasting.

16 English

HT-D5100_XAA_1224.indd 16HT-D5100_XAA_1224.indd 16 2011-12-24  12:30:212011-12-24  12:30:21

01 Getting Started

Installing batteries in the Remote Control

* Battery size: AAA

NOTE

✎

Make sure to match the “+” and “–” ends of



the batteries with the diagram inside the compartment.



Assuming typical TV usage, the batteries last for about one year. The remote control can be used up to



approximately 23 feet (7 meters) in a straight line.

Setting the Remote Control

You can control certain functions of your TV with this remote control.

When operating a TV with the remote control

Press the TV button to set the remote control

to TV mode.

Turn on your TV.

While holding down the POWER button, enter the code corresponding to your brand of TV.

•

If there is more than one code listed for your TV in the table, enter one at a time to determine which code works.

•

Example : For a Samsung TV

While holding down the POWER button, use the number buttons to enter 00. If that does not work, try 15, then 16, etc.

If the TV turns off, the setting is complete.

•

You can use the TV POWER, VOLUME, CHANNEL, and Numeric buttons (0~9).

NOTE

✎

The remote control may not work on some



brands of TV's. Also, some operations may not be possible, depending on your brand of TV.



The remote control will work with Samsung TVs by default.

TV Brand Code List

Brand Code

Admiral

(M.Wards)

A Mark

Anam

AOC

Bell &

Howell

(M.Wards)

Brocsonic

Candle

Cetronic

Citizen

Cinema

Classic

Concerto

Contec

Coronado

Craig

Croslex

Crown

Curtis

Mates

CXC

Daewoo

Daytron

Dynasty

Emerson

Fisher

Funai

Futuretech

General

Electric (GE)

Hall Mark

Hitachi

Inkel

JC Penny

JVC

KTV

KEC

KMC

(Goldstar)

Luxman

LXI

(Sears)

Magnavox

Marantz

Matsui

MGA

56, 57, 58

01, 15

01, 02, 03, 04, 05, 06, 07, 08, 09, 10,

11, 12, 13, 14

01, 18, 40, 48

57, 58, 81

59, 60

03, 18, 25

03, 05, 61, 82, 83, 84

59, 61, 63

02, 03, 04, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 32,

34, 35, 36, 48, 59, 90

03, 15, 40, 46, 59, 61,

64, 82, 83, 84, 85

19, 65

06, 40, 56, 59,

66, 67, 68

15, 18, 50, 59, 69

56, 59, 67, 86

59, 61, 87, 88

03, 15, 40

01, 15, 16, 17, 37, 38, 39, 40, 41, 42, 43, 44

19, 54, 56, 59,

60, 62, 63, 65, 71

15, 17, 18, 48, 54,

59, 60, 62, 72, 89

40, 54

18, 40

Brand Code

Mitsubishi/

MTC

NEC

Nikei

Onking

Onwa

Panasonic

Penney

Philco

Philips

Pioneer

Portland

Proton

Quasar

Radio

Shack

RCA/

Proscan

Realistic

Sampo

Samsung

Sanyo

Scott

Sears

Sharp

Signature

2000

(M.Wards)

Sony

Soundesign

Spectricon

Sylvania

Symphonic

Tatung

Techwood

Teknika

TMK

Toshiba

Vidtech

Videch

Wards

Yamaha

York

Yupiteru

Zenith

Zonda

Dongyang

MGA

SSS

18, 40, 59, 60, 75

18, 19, 20, 40, 59, 60

06, 07, 08, 09, 54,

66, 67, 73, 74

03, 15, 17, 18, 48, 54, 59, 62, 69, 90

15, 17, 18, 40,

48, 54, 62, 72

63, 66, 80, 91

15, 18, 59

06, 66, 67

17, 48, 56, 60,

61, 75

18, 59, 67, 76, 77,

78, 92, 93, 94

03, 19

00, 15, 16, 17, 40, 43, 46, 47, 48, 49,

59, 60, 98

19, 61, 65

03, 40, 60, 61

15, 18, 19

15, 57, 64

57, 58

50, 51, 52, 53, 55

03, 40

18, 40, 48, 54,

59, 60, 62

61, 95, 96

03, 15, 18, 25

18, 40

19, 57, 63, 71

59, 60, 69

15, 17, 18, 40,

48, 54, 60, 64

58, 79

03, 54

English 17

HT-D5100_XAA_1224.indd 17HT-D5100_XAA_1224.indd 17 2011-12-24  12:30:222011-12-24  12:30:22

Connections

This section describes various methods of connecting the product to other external components. Before moving or installing the product, be sure to turn off the power and disconnect the power cord.

Connecting the Speakers

Position of the product

Place it on a stand or cabinet shelf, or under the TV stand.

Selecting the Listening Position

The listening position should be located about 2.5 to 3 times the distance of the TV's screen size away from the TV. Example : For 32" TV's 6.56 ~ 7.87 feet(2~2.4m)

For 55" TV's 11.5 ~ 13.1 feet(3.5~4m)

Front Speakers

Place these speakers in front of your listening position, facing inwards (about 45°) toward you. Place the speakers so that their tweeters will be at the same height as your ear. Align the front face of the front speakers with the front face of the center speaker or place them slightly in front of the center speakers.

Center Speaker

Surround Speakershj

Subwoofer

CAUTION

Do not let children play with or near the speakers. They could get hurt if a speaker falls.



When connecting the speaker wires to the speakers, make sure that the polarity (+/ –) is correct.



Keep the subwoofer speaker out of reach of children to prevent children from inserting their hands or



alien substances into the duct (hole) of the subwoofer speaker. Do not hang the subwoofer on the wall through the duct (hole).



NOTE

✎

If you place a speaker near your TV set, the screen color may be distorted because of the magnetic



ﬁ eld. If this occurs, place the speaker away from your TV set.

It is best to install the Center Spealer at the same height as the front speakers. You can also install it directly over or under the TV.

Place these speakers to the side of your listening position. If there isn't enough room, place these speakers so they face each other. Position them about 2 to 3 feet (60 to 90cm) above your ear, facing slightly downward.

Unlike the front and center speakers, the surround speakers are used mainly

for sound effects. Sound will not come from them all the time.

The position of the subwoofer is not so critical. Place it anywhere you like.

18 English

HT-D5100_XAA_1224.indd 18HT-D5100_XAA_1224.indd 18 2011-12-24  12:30:232011-12-24  12:30:23

Speaker Components

SPEAKERS OUT

SPEAKER IMPEDANCE : 3

NENT OUT

VIDEO OUT

SUBWOOFER SURROUND

CENTER SURROUNDFRONT

FRONT

OUT

VIDEO OUT

SPEAKERS OUT

SPEAKER IMPEDANCE : 3

SUBWOOFER SURROUND

CENTER SURROUNDFRONT

FRONT

02 Connections

(L) (R)

FRONT

(L) (R)

SURROUND

CENTER

SUBWOOFER

Connecting The Speakers

Connect the connecting plugs to the back of the product by matching the colors of the speaker

plugs to the speaker jacks.

Front Speaker (L)

Center Speaker

Subwoofer

Surround Speaker (L)

Front Speaker (R)

Surround Speaker (R)

English 19

HT-D5100_XAA_1224.indd 19HT-D5100_XAA_1224.indd 19 2011-12-24  12:30:242011-12-24  12:30:24

Connections

SPEAKERS OUT

SPEAKER IMPEDANCE : 3

COMPONENT OUT

VIDEO OUT

AUX IN

SUBWOOFER SURROUND

CENTER SURROUNDFRONT

FRONT

COMPONENT OUT

VIDEO OUT

AUX IN

SPEAKERS OUT

SPEAKER IMPEDANCE : 3

SUBWOOFER SURROUND

CENTER SURROUNDFRONT

FRONT

FM ANT

AUX IN

Connecting the Optional Wireless Receiver Module

To connect the surround speakers wirelessly, you have to purchase the wireless receiver module and TX card from your Samsung retailer.

This product should be connected with the SWA-5000 only.

•

Center Speaker

Subwoofer

Surround Speaker (L)

Surround Speaker (R)

Wireless Receiver Module

Wireless Receiver Module (SWA-5000)

Press down the terminal tab on the back of the speaker.

Insert the black wire into the black terminal (–) and the red wire into the red terminal (+), and then release the tab.

Connect the speaker wire plugs to the back of the product by matching the colors of the speaker plugs to the speaker jacks.

With the product turned off, insert the TX card into the

TX Card Connection (WIRELESS) on the back of the product.

Hold the TX card so that the label "WIRELESS" faces upward

•

and insert the card into the port. The TX card enables communication between the product and

•

the wireless receiver module.

Connect the left and right surround speakers to the wireless Receiver module.

Plug the power cord of the wireless Receiver module in the wall outlet .

Front Speaker (L)

Front Speaker (R)

Black

FM ANT

WIRELESS

Red

COMPONENT OUT

AUX IN

TX card

VIDE

20 English

HT-D5100_XAA_1224.indd 20HT-D5100_XAA_1224.indd 20 2011-12-24  12:30:282011-12-24  12:30:28

CAUTION

Do not insert any other card except the TX card dedicated to the product.



If you insert a different TX card, you can damage the product and may not be able to remove the card easily.

Do not insert the TX card upside down or in the reverse direction.



Insert the TX card when the product is turned off. Inserting the card when it is turned on may



cause a problem. If the TX Card is inserted and wireless receiver module setting is complete, sound is not output



from the Surround Speaker connectors on the product. The wireless receiving antenna is built into the wireless receiver module. Keep it away from water



and moisture. For optimal listening performance, make sure that the area around the wireless receiver module



location is clear of any obstructions.

If no sound is heard from the wireless surround speakers, switch the mode to Dolby Pro



Logic II.

In 2-CH mode, you will hear no sound from the wireless surround speakers.



NOTE

✎

Place the wireless receiver module at the rear of the listening position. If the wireless receiver module is



too close to the product, sound from the speakers may be disrupted because of interference. If you use a device such as a microwave oven, wireless LAN Card, or any other device that uses



the 2.4/5.8GHz frequencies near the product, sound from the speakers may be disrupted because of interference.

The maximum transmission distance from the product to the wireless receiver module is about 33



feet (10m), but may vary depending on your operating environment. If a steel-concrete wall or metallic wall is between the product and the wireless receiver module, the system may not operate at all, because the radio wave cannot penetrate metal.

If the product doesn't make a wireless connection, you need to run an ID Set between the



product and wireless receiver module. With the product turned off, press "0""1""3""5" on the remote control. Turn on the wireless receiver module. Then, press and hold the "ID SET" button on the back of the wireless receiver module for 5 seconds, and then turn the product on.

02 Connections

Attaching the Toroidal Ferrite Core to the Power Cord of the Main Unit

If you attach a Toroidal ferrite core to the power cord of the man unit, it will help to prevent RF interference from radio signals.

Pull the ﬁ xing tab of the Toroidal ferrite core to

open it. Make a loop twice in the main unit power cord.

Attach the Toroidal ferrite core to the main unit power

FM ANT

WIRELESS

COMPONENT OUT

AUX IN

VIDEO OUT

SPEAKERS OUT

CENTER SURROUNDFRONT

SUBWOOFER SURROUND

FRONT

SPEAKER IMPEDANCE : 3

cord as the ﬁ gure shows and press it until it clicks.

English 21

HT-D5100_XAA_1224.indd 21HT-D5100_XAA_1224.indd 21 2011-12-24  12:30:312011-12-24  12:30:31

Connections

WIRELESS LAN

OPTICAL

LAN

HDMI OUT

DIGITAL AUDIO IN

FM ANT

WIRELESS

Connecting the Video Out to your TV

Choose one of the three methods for connecting to a TV.

METHOD 1

DIGITAL AUDIO IN

IRELESS

HDMI OUT

HDMI IN

METHOD 1 : HDMI

Connect an HDMI cable (not supplied) from the HDMI OUT jack on the back of the product to the HDMI IN jack on your TV.

NOTE

✎

Certain HDMI output resolutions may not work, depending on your TV.



After making the video connection, set the Video input source on your TV to match the corresponding Video



output (HDMI, Component or Composite) on your product. See your TV owner's manual for more information on how to select the TV's Video Input source. If you have set the product's remote control to operate your TV, press the TV SOURCE button on the remote



control and select HDMI as the external source of the TV.

HDMI Auto Detection Function

Using an HDMI cable, connect the HDMI OUT terminal on the rear of the product to the HDMI IN

terminal of your TV. Turn on the product and TV.

For possible HDMI resolutions, see page 30.

•

This function is not available if the HDMI cable does not support CEC. HDMI is an interface that enables the digital transmission of video and audio data with just a single connector.

•

Using HDMI, the product transmits a digital video and audio signal and displays a vivid picture on a TV having an HDMI input jack.

•

HDMI connection description

- HDMI outputs only a pure digital signal to the TV.

- If your TV does not support HDCP, random noise appears on the screen.

•

What is the HDCP?

HDCP (High-band width Digital Content Protection) is a system for protecting BD/DVD content outputted via HDMI from being copied. It provides a secure digital link between a video source (PC, DVD. etc) and a display device (TV, projector. etc). Content is encrypted at the source device to prevent unauthorized copies from being made.

(BEST QUALITY)

22 English

HT-D5100_XAA_1224.indd 22HT-D5100_XAA_1224.indd 22 2011-12-24  12:30:382011-12-24  12:30:38

SPEAKERS OUT

SPEAKER IMPEDANCE : 3

COMPONENT OUT

VIDEO OUT

AUX IN

SUBWOOFER SURROUND

CENTER SURROUNDFRONT

FRONT

AUX IN

Red

Blue

02 Connections

Green

METHOD 2

PEAKERS OU

METHOD 2 : Component Video (BETTER QUALITY)

If your television is equipped with Component Video inputs, connect a Component video cable (not supplied) from the Component Video Output (P Component Video Input Jacks on your TV.

✎



METHOD 3 : Composite Video

Connect the supplied Video cable from the VIDEO OUT jack on the back of the product to the VIDEO IN jack on your TV.

✎



Yellow

PEAKER IMPEDANCE : 3

R, PB and Y) Jacks on the back of the product to the

METHOD 3

NOTE

You can select from a variety of resolution settings such as 1080i, 720p, 480p and 480i, depending on the disc type. (See page 30) The actual resolution may differ from the setting in the Setup menu if both Component and HDMI cables are connected. The resolution may also be different depending on the disc. (See page 30) After making the video connection, set the Video input source on your TV to match the corresponding Video output (HDMI, Component or Composite) on your product. See your TV owner's manual for more information on how to select the TV's Video Input source. If you have set the product's remote control to operate your TV, press the TV SOURCE button on the remote control and select COMPONENT as the external source of the TV. In DVD playback, if both HDMI and Component jacks are connected and you select the Component 1080p, 1080i, 720p or 480p mode, the Display Setup menu will show the output resolution as 1080p, 1080i, 720p or 480p in the menu. The resolution is actually 480i.

(GOOD QUALITY)

NOTE

The VIDEO source always outputs in 480i resolution regardless of the resolution set in the Setup menu. (See page 30) After making the video connection, set the Video input source on your TV to match the corresponding Video output (HDMI, Component or Composite) on your product. See your TV owner's manual for more information on how to select the TV's Video Input source. If you have set the product's remote control to operate your TV, press the

TV SOURCE

button on

the remote control and select VIDEO as the external source of the TV.

CAUTION

Do not connect the unit through a VCR. Video signals fed through VCRs may be affected by copyright protection systems and the picture will be distorted on the television.

English 23

HT-D5100_XAA_1224.indd 23HT-D5100_XAA_1224.indd 23 2011-12-24  12:30:402011-12-24  12:30:40

Connections

This system supports Digital sampling frequencies of 32 kHz or higher from external digital components.

OPTICAL

HDMI OUT

DIGITAL

AUDIO IN

COMPONENT OUT

FM ANT

WIRELESS

VIDEO OUT

AUX IN

Connecting Audio from External Components

DMI OU

COMPONENT OU

Optical Cable

IRELES

Red

IDEO OU

White

(not supplied)

Audio Cable

(not supplied)

If the external analog

component has only one

Set-Top Box

OPTICAL

Audio Out, connect either

left or right.

VCR

AUX

OPTICAL : Connecting an External Digital Component

Digital signal components such as a Cable Box/Satellite receiver (Set-Top Box).

Connect the Digital Input (OPTICAL) on the product to the Digital Output of the external digital

component.

Press the FUNCTION button to select D. IN input.

The mode switches as follows : BD/DVD  D. IN  AUX  R. IPOD  W. IPOD  FM

•

NOTE

✎

To see video from your Cable Box/Satellite receiver, you must connect it's video output to a TV.



This system supports Digital sampling frequencies of 32 kHz or higher from external digital components.



This system supports only DTS and Dolby Digital audio, MPEG audio which is bitstream cannot be supported.



AUX : Connecting an External Analog Component

Analog signal components such as a VCR.

Connect AUX IN (Audio) on the product to the Audio Out of the external analog component.

Be sure to match connector colors.

•

Press the FUNCTION button to select AUX input.

The mode switches as follows : BD/DVD  D. IN  AUX  R. IPOD  W. IPOD  FM

•

NOTE

✎

You can connect the Video Output jack of your VCR to the TV, and connect the Audio Output jacks of



HT-D5100_XAA_1224.indd 24HT-D5100_XAA_1224.indd 24 2011-12-24  12:30:402011-12-24  12:30:40

the VCR to this product.

24 English

Connecting to a Network

You can connect this product to a network and use network based services such Smart Hub and BDLIVE (See pages 57~64), as well as receive software upgrades through the network connection. We recommend using a wireless router or IP router for the connection.

For more information on router connection, refer to the user manual of the router or contact the router

manufacturer for technical assistance.

Cable Network

Using the Direct LAN Cable (UTP cable), connect the LAN terminal of the product to the LAN

1. terminal of your modem.

Set the network options. (See page 36)

02 Connections

LAN

WIRELESS LAN

DIGITAL

IGITAL

AUDIO IN

UDIO I

OPTICAL

HDMI OUT

DMI OU

Router

Broadband modem

(with integrated router)

Broadband

service

Broadband modem

Broadband

service

Networking with PC for

AllShare function

(See page 66)

NOTE

✎

Internet access to Samsung’s software update server may not be allowed, depending on the router



you use or the ISP’s policy. For more information, contact your ISP (Internet Service Provider). DSL users, please use a router to make a network connection.



To use the AllShare function, you must connect your PC to the network as shown in the ﬁ gure.



English 25

HT-D5100_XAA_1224.indd 25HT-D5100_XAA_1224.indd 25 2011-12-24  12:30:432011-12-24  12:30:43

Connections

Wireless Network

You can connect the home theater to your network through a wireless IP sharer (router).

A wireless AP/IP router is required to make a wireless network connection. Connect the wireless LAN adapter to the Wireless LAN Adapter on the rear panel of the product.

Set the network options. (See page 36)

Broadband

service

LAN

DIGITAL

IGITAL

AUDIO IN

OPTICAL

Wireless IP sharer

WIRELESS LAN

Wireless LAN Adapter (not supplied)

Networking with PC for AllShare function

(See page 66)

NOTE

✎

This product is compatible with only Samsung's Wireless LAN Adapter. (not supplied) (Model name: WIS09ABGN).



- The Samsung Wireless LAN Adapter is sold separately. Contact a Samsung Electronics retailer for purchasing. You must use a wireless IP sharer that supports IEEE 802.11 a/b/g/n. (n is recommended for stable operation of



the wireless network.) Wireless LAN, by its nature, may cause interference, depending on the use condition (router performance,



distance, obstacles, interference by other radio devices, etc). Set the wireless IP sharer to Infrastructure mode. Ad-hoc mode is not supported.



The home theater supports the following security protocols only:



Authentication Mode : WEP, WPAPSK, WPA2PSK

1) Encryption Type : WEP, AES



For the AllShare function, a PC must be connected in the network as shown in the ﬁ gure.

Connecting the FM Antenna

FM Antenna (supplied)

Connect the FM antenna supplied to the FM

ANTENNA Jack.

Slowly move the antenna wire around until you

ﬁ nd a location where reception is good, then

FM ANT

fasten it to a wall or other rigid surface.

NOTE

✎

This product does not receive AM broadcasts.



WIRELESSWIRELE

26 English

HT-D5100_XAA_1224.indd 26HT-D5100_XAA_1224.indd 26 2011-12-24  12:30:452011-12-24  12:30:45

Setup

Initial Settings

Turn on your TV after connecting the product.

When you connect and turn on the product to a TV for the ﬁ rst time, the Initial Settings screen appears.

Initial Settings | On-Screen Language

Select a language for the on-screen displays.

Български Hrvatski Čeština Dansk Nederlands English Eesti Suomi Français Deutsch Ελληνικά Magyar Indonesia Italiano 한국어

Press the ▲▼◄► buttons to select the desired language, and then press the ENTER button.

Press the ENTER button to select Start.

Press the ▲▼ buttons to select the desired TV

Aspect Ratio, and then press the ENTER button. (See page 29) If you press the BLUE (D) button to skip Musical Room Calibration or Network Setup, you can access the Home menu even if the Calibration or the Network Setup is not completed.

Plug the ASC microphone into the ASC IN jack

on the product. (See page 33)

Press the ENTER button to select the Start

button. Setting the Musical Room Calibration function takes about 3 minutes.

Press the ▲▼ buttons to select the desired

Network Settings : Wired, Wireless (General), WPS(PBC) or One Foot Connection, and then press the ENTER

button. If you do not know the details of your Network Settings, press the BLUE (D) button on your remote instead to skip Network Settings here, ﬁ nish the Initial Settings, and go to the Home menu. If you selected a Network Settings, go to pages 36~39 for more information about the Network settings. When done, go to Step 8.

The Home menu appears. (For more

information about the Home menu, please see page 28.)

Move " Enter

•

Home Menu

My Contents

Videos

Photos

Music

My Devices Internet Settings

Function

d WPS(PBC)

NOTE

✎

The Home menu will not appear if you do not



conﬁ gure the initial settings except as noted below.

If you press the BLUE (D) button during the



Musical Room Calibration/network setup, you can access the Home menu even if the network setup is not completed yet.

If you want to display the Initial Setting screen



again to make changes, select the Initial Settings. (See page 39)

If you use an HDMI cable to connect the



product to an Anynet+ (HDMI-CEC)compliant Samsung TV and 1.) You have set the Anynet+ (HDMI-CEC) feature to On in both the TV and the product and 2.) You have set the TV to a language supported by the product, the product will select that language as the preferred language automatically.

If you leave the product in the stop mode for



more than 5 minutes without using it, a screen saver will appear on your TV. If the product is left in the screen saver mode for more than 20 minutes, the power will automatically turn off.

03 Setup

English 27

HT-D5100_XAA_1224.indd 27HT-D5100_XAA_1224.indd 27 2011-12-24  12:30:482011-12-24  12:30:48

Setup

INFO

POPU

Accessing the Settings Menu

DISC MENU MENU TITLE MENU

DISC MEN

TOOLS

OOL

RETURN

MENU Button : Press to move to the Home menu.

RETURN Button : Return to the previous menu.

ENTER / DIRECTION Button :

Move the cursor or select an item. Activate the currently selected item. Conﬁ rm a setting.

EXIT Button : Press to exit the current menu.

To access the Settings menu and sub-menus, follow these steps:

Press the POWER button. The Home Menu appears.

Home Menu

•

TITLE MEN

POPUP

INFO

EXIT

Press the ◄► buttons to select Settings,

and then press the ENTER button.

Press the ▲▼ buttons to select the desired

submenu, and then press the ENTER button.

Press the ▲▼ buttons to select the desired

item, and then press the ENTER button.

Press the EXIT button to exit the menu.

NOTE

✎

When the product is connected to a network,



select Internet from the Home menu. Download the desired content from Samsung Apps. (See pages 64~66)

The access steps may differ depending on the



menu you selected.

The OSD (On Screen Display) may change in



this product after you upgrade the software version.

My Contents

Videos

Function

My Devices Internet Settings

Selects My Devices.

Selects Function.

Selects My Contents.

Selects Internet.

Selects Settings.

Displays the buttons available.

Photos

Music

WPS(PBC)

3 4

28 English

HT-D5100_XAA_1224.indd 28HT-D5100_XAA_1224.indd 28 2011-12-24  12:30:502011-12-24  12:30:50

03 Setup

Display

You can conﬁ gure various display options such as the TV Aspect Ratio, Resolution, etc.

TV Aspect (Picture Size and Format)

Depending on the type of television you have, you may want to adjust the screen size setting.

16:9 Original : Select when you connect the

•

product to a 16:9 TV screen. The product will display all content in its original aspect ratio. Content formatted in 4:3 will be displayed with black bars on the left and right.

16:9 Full : Select when you connect the product

•

to a 16:9 TV screen. All content will ﬁ ll the full screen. Content formatted in 4:3 will be stretched.

4:3 Letter Box : Select when you connect the

•

product to a 4:3 TV screen. The product will display all content in its original aspect ratio. Content formatted in 16:9 will be displayed with black bars on the top and bottom.

4:3 Pan-Scan : Select when you connect the

•

product to a 4:3 TV screen. 16:9 content will have the extreme left and right portions cut off.

NOTE

✎

Depending on the disc type, some aspect ratios



may not be available. If you select an aspect ratio and option which is



different than the aspect ratio of your TV screen, then the picture might appear to be distorted.

If you select the 16:9 Original, your TV may



display 4:3 Pillarbox (black bars on sides of picture).

Smart Hub Screen Size

Set the Smart Hub Screen to the optimal size.

Size 1 : The Smart Hub screen size will be smaller

•

than the default. You may see some black on sides of screen.

Size 2 : This is the default setting for Smart Hub.

•

The product displays the normal Smart Hub screen size.

Size 3 : This will display a larger Smart Hub screen

•

size. The image may be too large for your TV screen.

BD Wise (Samsung Products only)

BD Wise is Samsung’s latest inter-connectivity feature.

When you connect a Samsung product and a Samsung TV with BD Wise to each other via HDMI, and BD Wise is on in both the product and TV, the product outputs video at the video resolution and frame rate of the BD/DVD disc.

Off : The output resolution stays ﬁ xed at the

•

resolution you set previously in the Resolution menu, regardless of the resolution of the disc. See Resolution below.

On : The product outputs video at the original

•

resolution and frame rate of the BD/DVD disc.

NOTE

✎

When BD Wise is on, the Resolution setting



automatically defaults to BD Wise and BD Wise appears in the Resolution menu. If the product is connected to a device that



does not support BD Wise, you can not use the BD Wise function.

For proper operation of BD Wise, set the BD



Wise menu of both the product and the TV to On.

Resolution

Lets you set the output resolution of the Component and HDMI video signal to Auto, 1080p, 1080i, 720p, 480p, or 480i. The number indicates the number of lines of video per frame. The i and p indicate interlaced and progressive scan, respectively. The more lines, the higher the quality.

Auto : Automatically sets the output resolution to

•

the connected TV’s maximum resolution. BD Wise :

•

resolution of the BD/DVD disc if you have connected the product via HDMI to a TV with the BD Wise feature. (The BD Wise menu item appears only if BD Wise is set to On. See BD Wise above.)

•

1080p : Outputs 1080 lines of progressive video. (HDMI only)

•

1080i : Outputs 1080 lines of interlaced video.

•

720p : Outputs 720 lines of progressive video.

•

480p : Outputs 480 lines of progressive video.

•

480i : Outputs 480 lines of interlaced video. (VIDEO only)

Automatically sets the resolution to the

English 29

HT-D5100_XAA_1224.indd 29HT-D5100_XAA_1224.indd 29 2011-12-24  12:30:522011-12-24  12:30:52

Setup

Resolution according to the output mode

Blu-ray Disc/E-contents/Digital Contents playback

•

HDMI / connected HDMI / not connected

Output

Setup

BD Wise

Auto

1080p@60F 1080p@60F 1080p@60F 480i - - -

Movie Frame :

Auto (24Fs)

1080i 1080i 1080i 480i 480i 1080i 480i

720p 720p 720p 480i 480i 720p 480i

480p 480p 480p 480i 480i 480p 480i

480i - - - 480i 480i 480i

DVD playback

•

Setup

BD Wise 480i 480i - -

Auto

1080p@60F 1080p@60F 480i - -

1080i 1080i 480i 480p 480i

720p 720p 480i 480p 480i

480p 480p 480i 480p 480i

480i - - 480i 480i

HDMI Mode

Blu-ray Disc

Resolution of

Blu-ray Disc

Max.

Resolution of

TV input

1080p@24F 1080p@24F 480i - - -

Output

E-contents/

Digital

contents

1080p@60F 480i - - -

Max.

Resolution of

TV input

HDMI / connected HDMI / not connected

HDMI Mode

Max. Resolution of

TV input

Component/

VIDEO Mode

480i - - -

Component/VIDEO

Mode

480i - -

Component Mode

Blu-ray Disc

Component Mode VIDEO Mode

E-contents/

Digital

contents

VIDEO Mode

30 English

HT-D5100_XAA_1224.indd 30HT-D5100_XAA_1224.indd 30 2011-12-24  12:30:522011-12-24  12:30:52

NOTE

✎

If the TV you connected to the product does



not support Movie Frame or the resolution you selected, the message “If no pictures are shown after the selection, please wait for 15 seconds. And then, the resolution will be reverted to the previous value automatically. Would you like to make a selection?” appears. If you select Yes, the TV’s screen will go blank for 15 seconds, and then the resolution will revert to the previous resolution automatically.



If the screen stays blank after you have changed the resolution, remove all discs, and then press and hold the STOP () button on the front of the product for more than 5 seconds. All settings are restored to the factory default. Follow the steps on the previous page to access each mode and select the Display Setup that your TV will support.



When the factory default settings are restored, all stored user BD data is deleted.



The Blu-ray Disc must have the 24 frame feature for the product to use the Movie Frame (24Fs) mode.



If both HDMI and Component jacks are connected and you are currently viewing Component output, the resolution is ﬁ xed to 480i.

HDMI Color Format

Lets you set the color space format for HDMI output to match the capabilities of the connected device (TV, monitor, etc).

•

Auto : Automatically sets the product to the optimum format supported by your device.

•

YCbCr (4:4:4) : If your TV supports the YCbCr color space via HDMI, select this to output the normal YCbCr color gamut.

•

RGB (Standard) : Select RGB (Standard) to output the normal RGB color gamut.

•

RGB (Enhanced) : If you have connected the product to a DVI display device such as a monitor, select RGB (Enhanced) to output the enhanced RGB color gamut.

03 Setup

Movie Frame (24 Fs)

Setting the Movie Frame (24Fs) feature to Auto allows you to adjust the product’s HDMI output to 24 frames per second for improved picture quality. You can enjoy the Movie Frame (24Fs) feature only on a TV supporting this frame rate. You can select Movie Frame only when the product is in the HDMI 1080i or 1080p output resolution modes.

Auto : Movie Frame (24Fs) functions work.

•

Movie Frame (24Fs) functions are off.

Off :

•

HDMI Deep Color

Lets you output video from the HDMI OUT jack with Deep Color. Deep Color provides more accurate color reproduction with greater color depth.

Auto: The product outputs video with Deep

•

Color to a connected TV which supports HDMI Deep Color.

Off : The picture is output without Deep Color.

•

Still Mode

Lets you set the type of picture the product displays when you pause DVD playback.

Auto: Automatically shows the best still picture

•

depending on the content. Frame : Select when pausing a scene with a

•

little action. Field : Select when pausing a scene with a lot

•

of action.

Progressive Mode

Lets you improve picture quality when viewing DVDs.

Auto : Select to have the product automatically

•

select the best picture quality for the DVD you’re watching.

Video : Select for the best picture quality from

•

concert or TV show DVDs.

English 31

HT-D5100_XAA_1224.indd 31HT-D5100_XAA_1224.indd 31 2011-12-24  12:30:522011-12-24  12:30:52

Setup

Audio

Speaker Settings

Settings

Display

Audio

Network System Language Security General Support

Level

You can adjust the balance and level for each speaker.

Adjusting Front /Center/Surround/Subwoofer Speaker Level

• You can adjust the volume level in steps from

-6dB to +6dB.

• The sound gets louder as you move closer to +6dB and quieter as you get closer to -6dB.

Settings

Display

Audio

Network System Language Security General Support

Speaker Settings

Level |

Distance

Test Tone : Off

Front L

◄

Front R : 0 dB Center : Surround L : 0 dB Surround R : Subwoofer : Test Tone :

0 dB |

0 dB

0 dB 0 dB

Off

Move < Change ' Return

Move " Enter ' Return

Level

Distance

If you cannot place the speakers at equal distances from the listening position, you can adjust the delay time of the audio signals from the front, center, surround and subwoofer speakers.

•

You can set the Speaker Distance between 1ft (0.3m) and 30ft (9.0m).

Settings

Display

Audio

Network System Language Security General Support

Front L Front R : 10(ft) 3.0(m) Center : 10(ft) 3.0(m) Surround L : 10(ft) 3.0(m) Surround R : 10(ft) 3.0(m) Subwoofer : 10(ft) 3.0(m) Test Tone : Off

Distance

◄

10(ft) 3.0(m) |

Move < Change ' Return

Test Tone

Use the Test Tone feature to check the speaker connections.

Press the ◄, ► buttons to select ON.

•

A test tone will be sent to Front L  Center  Front R  Surround R  Surround L  Subwoofer in order so you can make sure the

speakers are set up correctly.

To stop the test tone, press the ◄, ► buttons to select Off.

Settings

Display

Audio

Network System Language Security General Support

Speaker Settings

Level

Distance

Test Tone ◄ On

Move " Enter ' Return

NOTE

✎

When HDMI Audio is ON (audio is produced



through TV speakers), the Test Tone function is not available.

32 English

HT-D5100_XAA_1224.indd 32HT-D5100_XAA_1224.indd 32 2011-12-24  12:30:522011-12-24  12:30:52

Musical Room Calibration

500mA

ASC IN

By setting the Musical Room Calibration (MRC) function just once when you relocate or install the product, you can have the product automatically recognize the distance between speakers, levels between channels, and frequency characteristics to create a 5.1-channel sound ﬁ eld optimized for your environment.

ASC

microphone

Musical Room Calibration Mode

You will hear either the Musical Room Calibration mode or the User Speaker Settings.

Off: You will hear sound in the Speaker Setting

•

value. On : You will hear sound in the Musical Room

•

Calibration mode.

Measurement

Plug the ASC microphone into the ASC IN jack.

Place the ASC microphone at the listening position.

•

Musical Room Calibration will be automatically set up in the following sequence:

Front L  Center  Front R  Surround R  Surround L  Subwoofer

•

Press the RETURN button to cancel the Musical Room Calibration Setting.

NOTE

✎

Running the Musical Room Calibration



function takes about 3 minutes. Make sure there is no disc in the product when



you run the Musical Room Calibration function. If the ASC microphone is disconnected during the



Musical Room Calibration setup, the setup will be canceled. When the Musical Room Calibration function is



activated, the DSP, Dolby Pro Logic ll and SFE Mode will not work. If the product is connected to external devices or



other components (such as an iPod, AUX, D. IN), the Musical Room Calibration Setup may not work properly. Noise may result in incorrect measurements.



Ensure the room is quiet when you run the Musical Room Calibration. Place the microphone in the main listening



position. Make sure there are no objects between the



speakers and microphone. Note that the test tones of the speakers may be



loud. Do not place the microphone behind furniture or



too close to the wall. Otherwise, it can produce an incorrect test result.

User EQ

You can conﬁ gure the equalizer settings manually to your preference.

Settings

Display

Audio

Network System Language Security General Support

· 0

-6

User EQ

250Hz0600Hz01kHz03kHz06kHz010kHz015kHz

Reset > Adjust < Move ' Return

03 Setup

English 33

HT-D5100_XAA_1224.indd 33HT-D5100_XAA_1224.indd 33 2011-12-24  12:30:582011-12-24  12:30:58

Setup

HDMI Audio

The audio signals transmitted over the HDMI Cable can be toggled On/Off.

•

Off : Video is transmitted over the HDMI connection cable only, and audio is output through your product speakers only.

•

Both video and audio signals are transmitted

On :

over the HDMI connection cable, and audio is output through your TV speakers only.

NOTE

✎

HDMI Audio is automatically down-mixed to



2ch for TV speakers.

Audio Return Channel

You can enjoy TV sound from the Home Theater speakers by using just one HDMI cable.

Auto : Listen to TV sound from the Home

•

Theater speakers if your TV is compatible with the Audio Return Channel function.

Off : Turn the Audio Return Channel function

•

off.

NOTE

✎

When Anynet+ (HDMI-CEC) is Off, the Audio



Return Channel function is not available.



Using an ARC (Audio Return Channel) uncertiﬁ ed HDMI cable may cause a problem in compatibility.



ARC function is only available if an ARCcompliant TV is connected.

Digital Output

You can set the Digital Output to match the capabilities of the AV receiver you’ve connected to the product :

PCM : Choose if you have connected an HDMI

•

supported AV receiver. Bitstream (Unprocessed) : Select if you have

•

connected an HDMI supported AV receiver with Dolby TrueHD and DTS-HD Master Audio decoding capabilities.

Bitstream (Re-encoded DTS) : Choose if you

•

have connected an AV receiver using a Digital Optical input that can decode DTS.

Bitstream (Re-encoded Dolby D) : Select if

•

you don’t have an HDMI supported AV receiver, but have an AV receiver with Dolby Digital decoding capabilities.

For more details, please refer to the digital output selection table. (See page 35)

Blu-ray Discs may include three audio streams :

- Main Feature Audio : The audio soundtrack of the main feature.

BONUSVIEW audio : An additional soundtrack such as the director or actor’s commentary.

- Navigation Sound Effects : When you choose some menu navigation, Navigation Sound Effects may sound. Navigation Sound Effects are different on each Blu-ray Disc.

NOTE

✎

Digital Output can be activated when HDMI



Audio is ON.

Be sure to select the correct Digital Output or



you will hear no sound or just loud noise.

If the HDMI device (AV receiver, TV) is not



compatible with compressed formats (Dolby digital, DTS), the audio signal outputs as PCM.

Regular DVDs do not have BONUSVIEW audio



and Navigation Sound Effects.

Some Blu-ray Discs do not have BONUSVIEW



audio and Navigation Sound Effects.

This Digital Output setup does not effect the



analog (L/R) audio or HDMI audio output to your TV. It effects the optical and HDMI audio output when your product is connected to an AV receiver.

If you play MPEG audio soundtracks, the audio



signal outputs as PCM regardless of your Digital Output selections (PCM or Bitstream).

34 English

HT-D5100_XAA_1224.indd 34HT-D5100_XAA_1224.indd 34 2011-12-24  12:31:002011-12-24  12:31:00

Digital Output Selection

03 Setup

Setup PCM

Connection

Audio Stream on

Blu-ray Disc

Audio Stream

on DVD

Deﬁ nition for Blu-ray Disc

Bitstream

(Unprocessed)

HDMI supported

AV receiver

PCM Up to 7.1ch PCM DTS re-encoded

Dolby Digital Up to 7.1ch Dolby Digital DTS re-encoded

Dolby Digital Plus Up to 7.1ch Dolby Digital Plus DTS re-encoded

Dolby TrueHD Up to 7.1ch Dolby TrueHD DTS re-encoded

DTS Up to 6.1ch DTS DTS re-encoded

DTS-HD HRA Up to 7.1ch DTS-HD HRA DTS re-encoded

DTS-HD MA Up to 7.1ch DTS-HD MA DTS re-encoded

PCM PCM 2ch PCM 2ch PCM 2ch PCM 2ch

Dolby Digital Up to 5.1ch Dolby Digital Dolby Digital Dolby Digital

DTS Up to 6.1ch DTS DTS DTS

Decodes the main

feature audio and

Any

BONUSVIEW audio

stream together

into PCM audio and

adds Navigation

Sound Effects.

HDMI supported

AV receiver

Outputs only the

main feature audio

stream so that your

AV receiver can

decode the audio

bitstream.

You will not hear

BONUSVIEW

audio or Navigation

Sound Effects.

Bitstream

(Re-encoded

DTS)

HDMI supported

AV receiver

Decodes the main

feature audio and

BONUSVIEW audio

stream together

into PCM audio and

adds Navigation

Sound Effects, then

re-encodes the

PCM audio into DTS

bitstream.

Bitstream

(Re-encoded

Dolby D)

HDMI supported

AV receiver

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Re-encoded

Dolby Digital *

Decodes the main

feature audio and

BONUSVIEW audio

stream together into

PCM audio and adds

Navigation Sound

Effects, then re-

encodes the PCM

audio into Dolby digital

bitstream or PCM.

* If the Source Stream is 2ch, “Re-encoded Dolby D” Setting are not applied. Ouput will be LPCM 2ch.

Off : Movie soundtracks are played using the

Dynamic Range Control

•

standard Dynamic Range.

You can listen at low volumes, but still hear dialog clearly. This is only active if your product detects a Dolby Digital signal.

Auto : The Dynamic Range Control will be set

•

automatically based on the information provided by the Dolby TrueHD Soundtrack.

On : When Movie soundtracks are played at

•

low volume or through smaller speakers, the system can apply appropriate compression to make low-level content more intelligible and prevent dramatic passages from getting too loud.

English 35

HT-D5100_XAA_1224.indd 35HT-D5100_XAA_1224.indd 35 2011-12-24  12:31:002011-12-24  12:31:00

Setup

Audio Sync

Video may fall out of sync with the audio when the product is connected to a digital TV. If this occurs, adjust the audio delay time to match the audio to the video.

•

You can set the audio delay time between 0 msec and 300 msec. Set it to the optimal status.

Network

Before you begin, contact your ISP to ﬁ nd out if your IP address is static or dynamic. If it is dynamic, and you are using a wired or wireless connection, we recommend using the Auto procedures. If you are using a wireless connection and your router has the capability, you can use WPS(PBC) or One Foot Connection.

If your IP address is static, you must use the manual set up procedure for both wired and wireless connections.

Network Settings

To begin setting up the network connection for your product, follow these steps:

In the Home menu, press the ◄► buttons to select Settings, and then press the ENTER button.

Press the ▲▼ buttons to select Network, and then press the ENTER button.

Press the ▲▼ buttons to select Network Settings, and then press the ENTER button.

Press the ▲▼ buttons to select Wired, Wireless (General), WPS(PBC) or One Foot Connection,

and then press the ENTER button.

If you have a wired network, go to Wired Network

below. If you have a wireless network, go to Wireless Network on pages 37~39.

Wired Network

Setting Up a Wired Connection - Auto

Press the ▲▼ buttons to select Wired.

Settings

Display Audio

Network

System Language Security General Support

Press the ENTER button.

Network Settings

Select a network connection type.

Wired

Wireless

(General)

Connect to the network using LAN cable. Please make

WPS(PBC)

sure that the LAN cable is connected.

One Foot

Connection

Move " Enter ' Return

The Network Status screen appears. The product connects to the network after the network connection is veriﬁ ed.

Setting Up a Wired Connection - Manual

If you have a static IP address or the Auto Setting does not work, you’ll need to set the Network settings values manually.

To view your Network settings values on most Windows computers, follow these steps:

Right click the Network icon on the bottom

right of the Windows desktop.

In the pop-up menu, click Status.

On the dialog that appears, click the Support

tab.

On the Support tab, click the Details button.

The Network settings are displayed.

To enter the Network settings into your product, follow these steps:

Press the ▲▼ buttons to select Wired, and

then press the ENTER button.

Press the ◄► buttons to select IP Settings,

and then press the ENTER button.

36 English

HT-D5100_XAA_1224.indd 36HT-D5100_XAA_1224.indd 36 2011-12-24  12:31:002011-12-24  12:31:00

03 Setup

Settings

Display Audio

IP Mode Manual

Network

System Language

DNS Mode Manual

Security General Support

Press the ENTER button to select IP Mode.

Press the ▲▼ buttons to select Manual,

IP Address Subnet Mask Gateway

DNS Server

IP Settings

0.0.0.0

Move " Enter ' Return

and then press the ENTER button.

Press the ▼ button to go to the ﬁ rst entry

ﬁ eld (IP Address).

Use the number buttons on your remote to

enter numbers.

When done with each ﬁ eld, press the ►

button to move successively to the next ﬁ eld. You can also use the other arrow buttons to move up, down, and back.

Enter the IP Address, Subnet Mask, and

Gateway values.

Press the ▼ button to go to DNS Mode.

Press the ▼ button to go to the ﬁ rst DNS

10.

entry ﬁ eld. Enter the numbers as above.

Press the ENTER button to select OK.

11.

The Network Status screen appears. The product connects to the network after the network connection is veriﬁ ed.

Wireless Network

You can setup a wireless network three ways:

•

Wireless (General)

•

Using WPS(PBC).

•

One Foot Connection

Wireless (General) includes both Automatic and Manual setup procedures.

Setting Up the Wireless Network Connection

- Auto

Most wireless networks have an optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security Key. The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a speciﬁ ed length you were asked to enter when you set up security for your wireless network. If you use this method of setting up the network connection, and have a Security Key for your wireless network, you will have to enter the Pass Phrase during the Auto setup process.

Press the ▲▼ buttons to select Wireless

(General).

Settings

Display

Select a network connection type.

Audio

Network

Wired

System

Wireless

Language

(General)

Security

WPS(PBC)

General

One Foot

Connection

Support

Press the ENTER button.

Network Settings

Set up wireless network by selecting your Wireless Router. You may need to enter security key depending on the setting of the Wireless Router.

Move " Enter ' Return

When done, it displays a list of the available networks.

Press the ▲▼ buttons to select the desired

network, and then press the ENTER button. The Security screen appears.

On the Security screen, enter your network’s

Pass Phrase. Enter numbers directly using your remote control. To select a letter, press the ▲▼◄► buttons to move the cursor, then press the ENTER button.

English 37

HT-D5100_XAA_1224.indd 37HT-D5100_XAA_1224.indd 37 2011-12-24  12:31:012011-12-24  12:31:01

Setup

Settings

Display Audio

Network

System Language Security General Support

NOTE

✎

You should be able to ﬁ nd the Pass Phrase on



Network Settings

Enter security key. 0 entered

b c d e f 1 2 3

h i j k l 4 5 6

n o p q r 7 8 9

t u v w x y z 0

a/A * Delete Space Done

Previous m Move " Enter ' Return

one of the set up screens you used to set up your router or modem.

When done, press the ▲▼◄► buttons to

move the cursor to Done, and then press the ENTER button.

The Network Status screen appears. The product connects to the network after the network connection is veriﬁ ed.

Setting Up the Wireless Network Connection

- Manual

If the Auto Setting does not work, you need to enter the Network settings values manually.

To view the Network settings values on most Windows computers, follow these steps:

Right click the Network icon on the bottom

right of the screen.

In the pop-up menu, click Status.

On the dialog that appears, click the Support

tab.

On the Support tab, click the Details button.

The Network settings are displayed.

To enter the Network settings into your product, follow these steps:

Follow Steps 1 through 5 in the ‘Setting Up

the Wireless Network Connection - Auto’ procedure.

When done, press the ▲▼◄► buttons to

move the cursor to Done, and then press the ENTER button. The Network Status screen

appears.

Settings

Display Audio

IP Mode Manual

Network

System Language

DNS Mode Manual

Security General Support

On the Network Status screen, select

IP Address Subnet Mask Gateway

DNS Server

IP Settings

0.0.0.0

Move " Enter ' Return

Cancel, and then press Enter.

Press the ◄► buttons to select IP Settings,

and then press the ENTER button.

Press the ENTER button to select IP Mode.

Press the ▲▼ buttons to select Manual,

and then press the ENTER button.

Press the ▼ button to go to the ﬁ rst entry

ﬁ eld (IP Address).

Use the number buttons to enter numbers.

When done with each ﬁ eld, press the ►

button to move successively to the next ﬁ eld. You can also use the other arrow buttons to move up, down, and back.

10.

Enter the IP Address, Subnet Mask, and Gateway values.

11.

Press the ▼ to go to DNS Mode.

12.

Press the ▼ button to go to the ﬁ rst DNS entry ﬁ eld. Enter the numbers as above.

13.

The Network Status screen appears. The product connects to the network after the network connection is veriﬁ ed.

WPS(PBC)

The easiest way to set up the wireless network connection is using the WPS(PBC) function or the One Foot Connection function.

If your wireless router has a WPS(PBC) button, follow these steps:

Press the ▲▼ buttons to select WPS(PBC).

38 English

HT-D5100_XAA_1224.indd 38HT-D5100_XAA_1224.indd 38 2011-12-24  12:31:032011-12-24  12:31:03

03 Setup

Settings

Display

Select a network connection type.

Audio

Network

Wired

System

Wireless

Language

(General)

Security

WPS(PBC)

General

One Foot

Connection

Support

Press the ENTER button.

Press the WPS(PBC) button on your router

Network Settings

Connect to the Access Point easily by pressing the WPS(PBC) button. Choose this if your Access Point supports Push Button Conﬁ guration(PBC).

Move " Enter ' Return

within two minutes. Your product displays the Network Selection Screen, and automatically acquires all the network settings values it needs and connects to your network. When it is done, it displays an OK button. Press the ENTER button on your remote.

One Foot Connection

You can set up the wireless connection automatically if you have a Samsung Wireless Router which supports One Foot Connection. To connect using the One Foot Connection function, follow these steps:

Press the ▲▼ buttons to select One Foot

Connection.

Settings

Display

Select a network connection type.

Audio

Network

Wired

System

Wireless

Language

(General)

Security

WPS(PBC)

General

One Foot

Connection

Support

Network Settings

Connect to your wireless network automatically if your Wireless Router supports One Foot Connection. Select this connection type after placing the Wireless Router within 10 inches(25cm) of Samsung Wireless LAN Adapter.

Move " Enter ' Return

Network Status

Check whether a connection to the network and the Internet have been established.

Settings

Display Audio

Network

System

Internet is connected successfully.

Language

If you have a problem using any Internet services, contact your Internet service provider.

Security General Support

KT_WLAN

Network Status

MAC Address XX:XX:XX:XX:XX:XX IP Address 0.0.0.0 Subnet Mask 0.0.0.0 Gateway 0.0.0.0 DNS Server 0.0.0.0

IP Settings Retry OKNetwork Settings

< Move " Enter ' Return

BD-LIVE Internet Connection

Set to allow or prohibit an Internet connection when you use the BD-LIVE service.

Allow (All) : The Internet connection is allowed

•

for all BD-LIVE contents. Allow (Valid Only) : The Internet connection is

•

allowed only for BD-LIVE contents containing a valid certiﬁ cate.

Prohibit : No Internet connection is allowed for

•

any BD-LIVE content.

NOTE

✎

What is a valid certiﬁ cate?



When the product uses BD-LIVE to send the disc data and a request to the server to certify the disc, the server uses the transmitted data to check if the disc is valid and sends the certiﬁ cate back to the product.

The Internet connection may be restricted



while you are using BD-LIVE contents.

System

Press the ENTER button.

Place the Samsung Wireless Router within 25 cm (10 inches) of Samsung Wireless LAN Adapter to connect.

Wait until the connection is automatically established.

Initial Settings

By using the Initial Settings function, you can set the language, Musical Room Calibration, Network Settings, etc. For more information about the Initial Settings function, refer to the Initial Settings section of this user manual. (See page 27)

English 39

HT-D5100_XAA_1224.indd 39HT-D5100_XAA_1224.indd 39 2011-12-24  12:31:042011-12-24  12:31:04

Setup

Anynet+ (HDMI-CEC)

Anynet+ is a convenient function that offers linked operations with other Samsung products that have the Anynet+ feature. To operate this function, connect this product to a Samsung TV with an HDMI cable. With Anynet+ on, you can operate this product using a Samsung TV remote control and start disc playback simply by pressing the PLAY (►) button on the TV’s remote control. For more information, please see the TV user manual.

Off : Anynet+ functions will not work.

•

On : Anynet+ functions will work.

•

NOTE

✎

This function is not available if the HDMI cable



does not support CEC. If your Samsung TV has an Anynet+ logo, then



it supports the Anynet+ function. Depending on your TV, certain HDMI output



resolutions may not work. Please refer to the user manual of your TV.

BD Data Management

Lets you manage the downloaded contents you accessed through a Blu-ray Disc that supports the BD-LIVE service and stored on an attached Flash memory device.

You can check the device’s information including the storage size, delete the BD data, or change the Flash memory device.

BD Data Management Screen Information :

•

Current Device : Display the selected device.

•

Total Size : Total memory size of the device.

•

Available Size : Available memory in the device.

Delete BD Data : Delete all BD data in the

•

storage. Select Device : Change location of desired

•

memory to store BD data.

NOTE

✎

In the external memory mode, disc playback



may be stopped if you disconnect the USB device in the middle of playback. Only those USB devices formatted in the FAT



ﬁ le system (DOS 8.3 volume label) are supported. We recommend you use USB devices that support USB 2.0 protocol with 4 MB/sec or faster read/write speed. The Resume Play function may not work after



you format the storage device. The total memory available to BD Data



Management may differ, depending on the conditions.

Time Zone

You can specify the time zone that is applicable to your area.

Settings

Display Audio Network

System

Language Security General Support

Time Zone

GMT + 00:00

London, Lisbon, Casablanca

Change " Save ' Return

DivX® Video On Demand

Shows the registration code authorized for the product. If you connect to the DivX web site and register using that code, you can download the VOD registration ﬁ le. If you activate the VOD registration using My Contents, the registration is completed.

NOTE

✎

For more information about DivX(R) VOD, visit



“http://vod.divx.com”.

Reset

All settings will revert to the default except for the network and Smart Hub settings. You need enter the password for this function.

NOTE

✎

The default password is 0000.



40 English

HT-D5100_XAA_1224.indd 40HT-D5100_XAA_1224.indd 40 2011-12-24  12:31:082011-12-24  12:31:08

03 Setup

Language

You can select the language you prefer for the Home menu, disc menu, etc.

On-Screen Menu : Select the language for the

•

on-screen displays. Disc Menu : Select the language for the disc

•

menu displays. Audio : Select the language for disc audio.

•

Subtitle : Select the language for disc subtitles.

•

NOTE

✎



The selected language will only appear if it is supported on the disc.

Security

This function works in conjunction with Blu-ray and DVD discs that have been assigned an age rating or numeric rating that indicates the maturity level of the content. These numbers help you control the types of Blu-ray and/DVD discs that your family can watch.

When you access this function for the ﬁ rst time, the password setup screen appears. Enter a desired 4-digit password using the number buttons. (The default password is 0000.)

After you have set your password, select an age rating you want to set for the BD Parental Rating and a rating level you want to set for the DVD Parental Rating. The product will only play Blu-ray discs rated at or below the age rating and DVD discs rated below the numeric rating unless the password is entered.

Larger numbers indicate more mature content.

BD Parental Rating

This will prohibit playback of Blu-ray disc rated above Parental Rating.

DVD Parental Rating

Prevent playback of DVD discs with speciﬁ c numerical ratings unless a password is entered.

Change Password

Change the 4-digit password used to access security functions.

If you forgot your password

Remove the disc.

Press and hold the STOP () button on the

front panel for 5 seconds or more. All settings will revert to the factory settings.

NOTE

✎

When the factory default settings are restored,



all the user stored BD data will be deleted.

General

Front Display

Change the brightness display of the front panel.

Auto : Dim during playback.

•

Dim : Dim the display window.

•

Bright : Brighten the display window.

•

NOTE

✎

You cannot change the brighness of the



Power button and the Function button.

Network Remote Control

The Network Remote Control function lets you control your Blu-ray Home Theater from a remote device such as a smart phone through a wireless connection to your local area network.

To use the Network Remote Control function, follow these steps:

Select On in the Network Remote Control

menu.

Install the Samsung network remote control

application to control your product on your compatible portable device.

Make sure your portable device and your

product are connected to the same wireless router.

Start the application on your portable device.

The application should ﬁ nd your product and display it on a list.

Select the product.

English 41

HT-D5100_XAA_1224.indd 41HT-D5100_XAA_1224.indd 41 2011-12-24  12:31:092011-12-24  12:31:09

Setup

If this is the ﬁ rst time you are using the

function, it will ask you to allow or deny remote control of the product. Select Allow.

Follow the instructions that came with the

application to control the product.

Support

Software Upgrade

The Software Upgrade menu allows you to upgrade the product’s software for performance improvements or additional services. You can upgrade in four ways:

By Internet

•

By USB

•

By Disc

•

By Downloaded (File)

•

The four methods are explained below.

By Internet

To upgrade by Internet, follow these steps:

Select By Internet, and then press the

ENTER button. The Connecting to Server message appears.

If there is a download available, the

Download pop-up appears with a progress bar and the download starts.

When the download is complete, the

Upgrade Query window appears with three choices: Upgrade Now, Upgrade Later, or Don’t Upgrade.

If you select Upgrade Now, the product

upgrades the software, turns off, and then turns on automatically.

If you do not make a selection in one minute

or select Upgrade Later, the product stores the new upgrade software. You can upgrade the software later using the By Downloaded function.

If you select Don’t Upgrade, the product

cancels the upgrade.

NOTE

✎

Your product must be connected to the



Internet to use the By Internet function.

The upgrade is complete when the product



turns off, and then turns on again by itself.

Never turn the product off or back on



manually during the update process.

Samsung Electronics shall take no legal



responsibility for product malfunction caused by an unstable Internet connection or consumer negligence during a software upgrade.

If you want to cancel the upgrade while the



upgrade software is downloading, press the

ENTER button.

By USB

To upgrade by USB, follow these steps:

Visit www.samsung.com/bluraysupport

Download the latest USB software upgrade

zip archive to your computer.

Unzip the zip archive to your computer. You

should have a single folder with the same name as the zip ﬁ le.

Copy the folder to a USB ﬂ ash drive.

Make sure the disc tray is empty, and then

insert the USB ﬂ ash drive into the USB port of the product.

In the product’s menu, go to Settings >

Support > Software Upgrade.

Select By USB.

NOTE

✎

The disc tray must be empty when you



upgrade the software using the USB Host jack.

When the software upgrade is done, check



the software details in the software Upgrade menu.

Do not turn off the product during the



software upgrade. It may cause the product to malfunction.

Software upgrades using the USB Host jack



must be performed with a USB memory ﬂ ash stick only.

42 English

HT-D5100_XAA_1224.indd 42HT-D5100_XAA_1224.indd 42 2011-12-24  12:31:092011-12-24  12:31:09

03 Setup

By Disc

To upgrade by Disc, follow these steps:

Visit www.samsung.com/bluraysupport.

Download the latest disc software upgrade

zip archive to your computer.

Unzip the zip archive to your computer. You

should have a single folder with the same name as the zip ﬁ le.

Write the folder onto a disc. We recommend

a CD-R or DVD-R.

Finalize the disc before you remove it from

your computer.

Insert the disc into product.

In the product’s menu, go to Settings >

Support > Software upgrade.

Select By Disc.

NOTE

✎

When the system upgrade is done, check the



software details in the software Upgrade menu.

Do not turn off the product during the Software



Upgrade. It may cause the product malfunction.

By Downloaded

The By Downloaded option lets you upgrade using a ﬁ le the product downloaded earlier but you decided not to install immediately or a ﬁ le downloaded by the product in Standby Mode (See Download in Standby Mode below).

To upgrade By Downloaded, follow these steps:

If upgrade software has been downloaded,

you will see the software version number to the right of By Downloaded.

Select By Downloaded, and then press the

ENTER button.

The product displays a message asking if

you want to upgrade. Select Yes. The product begins the upgrade.

When the update is complete, the product

turns off automatically, and then turns on.

NOTE

✎

When the system upgrade is done, check the



software details in the software Upgrade menu.

Do not turn off the product during the software



Upgrade. It may cause the product to malfunction.

To use the By Downloaded function, your



product must be connected to the Internet.

Download in Standby Mode

You can set the Download in Standby Mode function so that the product downloads new upgrade software when it is in Standby mode. In Standby mode, the product is off, but its Internet connection is active. This allows the product to download upgrade software automatically, when you are not using it.

To set Download in Standby Mode, follow these steps:

Press the ▲▼ buttons to select Download

in Standby Mode, and then press the ENTER button.

Select On or Off.

Off : If you select Off, the product will notify

•

you with a pop up message when new upgrade software is available.

On : If you select On, the product will

•

automatically download new upgrade software when it is in Standby mode with the power off. If it downloads new upgrade software, the product will ask you if you want to install it when you turn the product on.

NOTE

✎

To use the Download in Standby Mode



function, your product must be connected to the Internet.

Contact Samsung

Provides contact information for assistance with your product.

English 43

HT-D5100_XAA_1224.indd 43HT-D5100_XAA_1224.indd 43 2011-12-24  12:31:092011-12-24  12:31:09

Basic Functions

Playing a Disc

Playback

Press the OPEN/CLOSE ( ) button to open

the disc tray. Place a disc gently into the tray with the

disc’s label facing up.

Press the OPEN/CLOSE ( ) button to close the disc tray.

Press the PLAY (►) button.

Playback related buttons

PLAY ( ►)

STOP (  )

PAUSE (  )

NOTE

✎

For some discs, the product may not



memorize the stop positon when you press the STOP ( Video ﬁ les with high bit rates of 20Mbps or



more strain the product’s capabilities and may stop playing during play back.

Starts playback.

Stops playback.

•

If you press the button once : The stop position is memorized.

•

If you press the button twice : The stop position is not memorized.

Pauses playback.



) button.

Disc Structure

The content of discs are usually divided as shown below.

Blu-ray Disc, DVD-VIDEO

•

title 1 title 2

chapter 1 chapter 2 chapter 1 chapter 2 chapter 3

•

Audio CD (CD-DA)

track 1 track 2 track 3 track 4 track 5

•

MP3, WMA, DivX, MKV and MP4

folder (group) 1 folder (group) 2

ﬁ le 1 ﬁ le 2 ﬁ le 1 ﬁ le 2 ﬁ le 3

Using the Disc menu/Title menu/

Popup menu

Using the Disc Menu

During playback, press the DISC

MENU button on the remote control.

Press the

a selection, and then press the

ENTER button.

NOTE

✎

Depending on the disc, the menu items may



differ and this menu may not be available.

◄ ►

buttons to make

DISC MENU

44 English

HT-D5100_XAA_1224.indd 44HT-D5100_XAA_1224.indd 44 2011-12-24  12:31:092011-12-24  12:31:09

04 Basic Functions

Using the Title Menu

During playback, press the TITLE

MENU button on the remote control.

Press the

make the desired selection, then press the ENTER button.

NOTE

✎

Depending on the disc, the menu items may



differ and this menu may not be available. The Title Menu will only be displayed if there



are at least two titles on the disc.

Using the Popup Menu

During playback, press the POPUP

button on the remote control.

Press the

ENTER button to select the desired menu.

NOTE

✎

Depending on the disc, the menu items may



differ and this menu may not be available.

◄ ►

buttons to

◄ ►

Playing the Title List

buttons or

TITLE MENU

POPUP

TITLE MENU

POPUP

Using the Search and Skip Functions

During playback, you can search quickly through a chapter or track, and use the skip function to jump to the next selection.

Searching for a Desired Scene

hzZyx

During playback, press the SEARCH ()

•

button. Each time you press the button, the playback speed will change as follows.

BD-ROM,

BD-RE/-R,

DVD-RW/-R,

DVD+RW/+R,

DVD-VIDEO

DivX, MKV, MP4

To return to normal speed playback, press the

•

PLAY (►) button.

NOTE

✎

The home theater does not play sound in



search mode. If you press the  or  button too quickly



this product might think you are just holding the button down. This will lead to improper operation. Be sure to not press these buttons too rapidly.

) )

( (

)

(

SEARCH (

)



2  ) 3 

)



5  ) 6  ) 7

(



2  ( 3 

(



5  ( 6  ( 7

)



2  ) 3

(



2  ( 3

)

During playback, press the DISC

MENU or TITLE MENU button.

Press the

an entry you want to play from Title List, then press the ENTER button.



buttons to select

DISC MENU

TITLE MENU

POPUP

Skipping Chapters

hzZyx

During playback, press the SKIP (#$)

•

button. If you press the SKIP ($) button, it moves to the next chapter. If you press the SKIP (#) button, it moves to the beginning of the chapter. One more press makes it move to the beginning of the previous chapter.

English 45

HT-D5100_XAA_1224.indd 45HT-D5100_XAA_1224.indd 45 2011-12-24  12:31:112011-12-24  12:31:11

Basic Functions

Slow Motion Play/Step Motion Play

Slow Motion Play

hzZyx

In pause (  ) mode, press the SEARCH ()

•

button. If you press the SEARCH () button, the playback speed is reduced to * 1/8 * 1/4 * 1/2

To return to normal speed playback, press the

•

PLAY (► ) button.

NOTE

✎

The product does not play sound in slow



mode. Slow motion operates only in the forward



direction.

Step Motion Play

hzZyx

In pause mode, press the PAUSE (  ) button.

•

Each time the PAUSE (  ) button is pressed, a new frame will be appear.

To return to normal speed playback, press the

•

PLAY ( ► ) button.

Repeat > Off

To return to normal play, press the REPEAT

button again.

Press the ▲▼ buttons to select Off, then

press the ENTER button.

NOTE

✎

Depending on the disc, the Repeat function



may not be available.

Repeat the Section

hzZy

During playback, press the REPEAT

button on the remote control.

Press the ▲▼ buttons to select REPEAT A-B.

Repeat > Repeat A-B : Off " Mark A

REPEAT

NOTE

✎

The product does not play sound in step



mode. Step motion operates only in the forward



direction.

Repeat Playback

Repeat the Title or Chapter

hzZyx

Repeat the disc title or chapter.

During playback, press the REPEAT

button on the remote control.

Press the ▲▼ buttons to select

Chapter or Title, then press the ENTER button.

REPEAT

Press the ENTER button at the point where you want repeat play to start (A).

Press the ENTER button at the point where you want repeat play to stop (B).

To return to normal play, press the REPEAT button again.

Press the ENTER button.

NOTE

✎

If you set point (B) before 5 seconds has



elapsed, a prohibition message will appear. Depending on the disc, the Repeat function



may not be available.

46 English

HT-D5100_XAA_1224.indd 46HT-D5100_XAA_1224.indd 46 2011-12-24  12:31:132011-12-24  12:31:13

Using the TOOLS button

During playback, you can operate the disc menu by pressing the TOOLS button.

TOOLS Menu Screen

•

Tools

Title Search 1/2 Chapter Search : 1/20 Time Search : 00:00:13/01:34:37 Picture Settings : Normal Audio : 1/4 ENG Multi CH User EQ Subtitle : 0/7 Off Angle : 1/1

Change "

NOTE

✎

Depending on the disc, the TOOLS menu

▪

may differ.

TOOLS

Enter ' Return

Moving to a Desired Scene Directly

hzZy

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Title

Search, Chapter Search or Time Search.

Enter the desired Title, Chapter or Playing

Time using the number buttons, then press the ENTER button.

Selecting the Audio Language

hzZx

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Audio.

Press the ENTER button.

Press the ▲▼ buttons to select the audio language you want.

Information about the primary / secondary



audio modes will be also displayed if the Bluray Disc has a BONUSVIEW section. Use the ◄► button to switch between primary and secondary audio modes. The languages available depend on the



languages that are encoded on the disc. This function or certain languages may not be available. Some Blu-ray Discs may allow you to select



either the multi-channel LPCM or Dolby digital audio soundtrack in English.

Selecting the Subtitle Language

hZx

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Subtitle.

Press the ◄► buttons to select the desired subtitle language.

NOTE

✎

Depending on the Blu-ray Disc / DVD, you may



be able to change the subtitle language in the Disc Menu. Press the DISC MENU button. The subtitle languages available depend on the



subtitle languages encoded on the disc. This function or certain languages may not be available on all Blu-ray Discs/DVDs. Information about the primary / secondary



subtitle modes will also be displayed if the Bluray Disc has a BONUSVIEW section. This function changes both the primary and



secondary subtitles at the same time. The total number of subtitles is the sum of the



primary and secondary subtitles.

04 Basic Functions

NOTE

✎

The ◄► indicator will not be displayed on the



screen if the BONUSVIEW section does not contain any BONUSVIEW audio settings.

English 47

HT-D5100_XAA_1224.indd 47HT-D5100_XAA_1224.indd 47 2011-12-24  12:31:182011-12-24  12:31:18

Basic Functions

Caption Function

You must have some experience with video

•

extraction and editing in order to use this feature properly.

To use the caption function, save the caption

•

ﬁ le (*.smi) with the same ﬁ le name as that of the DivX media ﬁ le (*.avi) within the same folder. Example. Root Samsung_007CD1.avi Samsung_007CD1.smi

•

You can use up to 60 alphanumeric characters or 30 East Asian characters (2 byte characters such as Korean and Chinese) for the ﬁ le name.

Changing the Camera Angle

When a Blu-ray Disc/DVD contains multiple angles of a particular scene, you can use the ANGLE function.

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Angle.

Press the ◄► buttons to select the desired

Angle.

User : The user can adjust the Sharpness,

•

Noise reduction, Contrast, Brightness, Color, Tint function respectively.

NOTE

✎

If the system is connected to a BD Wise-



compliant TV that has set BD Wise to On, the picture setting menu will not appear.

Setting the BONUSVIEW

The BONUSVIEW feature allows you to view additional content (such as commentaries) in a small screen window while the movie is playing. This function is only available if the disc has the Bonusview feature.

Selecting the Picture Settings

hzZy

This function enables you to adjust video quality.

During playback, press the TOOLS button.

Press the ▲▼ buttons to select Picture Settings, then press the ENTER button.

Press the ◄► buttons to select the desired Mode.

•

Dynamic : Choose this setting to increase Sharpness.

•

Normal : Choose this setting for most viewing applications.

•

Movie : This is the best setting for watching movies.

Primary a audio/video

During playback, press the TOOLS button.

Press the ▲▼ buttons to select BONUSVIEW Video or BONUSVIEW Audio.

Press the ◄► buttons to select the desired bonusview.

NOTE

✎

If you switch from BONUSVIEW Video,



BONUSVIEW Audio will change automatically in accordance with BONUSVIEW Video.

Tools

BONUSVIEW Video Off

BONUSVIEW Audio : 0/1 Off

Picture Settings

< Change "

Secondary a audio/video

Enter

48 English

HT-D5100_XAA_1224.indd 48HT-D5100_XAA_1224.indd 48 2011-12-24  12:31:192011-12-24  12:31:19

04 Basic Functions

FULL SCREEN

RETURN

EXIT

TUNER

Listening to Music

Buttons on the Remote Control used for Music Playback

123 456

7809

TOOLS

OOL

RETURN

TUNER

NETFLIX

NETFLIXHU

MEMORY

SMART SEARCH

MART

HUB

REPEATFULL SCREEN

1 2

INF

INFO

EXIT

DSP

ENTER button : Plays the selected track.

► button : During playback, moves to the next page in the Music List or moves to the next track in the Playlist.

◄

button : During playback, moves to the previous page in the Music List or moves to the previous track in the Playlist.

STOP button :

button : Plays the

button : Plays the previous track.

Stops a

next track.

track

If you press this button after three seconds of playback in the Playlist, the current track will be

replayed from the beginning. But, if you press this button within three seconds after playback starts in the Playlist, the previous track will be played.

NUMBER button : During the Playlist playback, press the desired track number. The selected

track will be played. (only Audio CD(CD-DA))

REPEAT button : Selects the play mode in the

Playlist.

SEARCH buttons : Audio CD (CD-DA) - Fast Play.

MP3 - Jump Play. (10 seconds)

PAUSE button : Pauses playback.

PLAY button : Plays the currently selected track.

▲▼ buttons : Selects a track in the Music List

or Playlist.

YELLOW (C) button : Select Edit Mode or Play

Mode.

English 49

HT-D5100_XAA_1224.indd 49HT-D5100_XAA_1224.indd 49 2011-12-24  12:31:202011-12-24  12:31:20

Basic Functions

Playing an Audio CD (CD-DA)/MP3

Insert an Audio CD (CD-DA) or an MP3 Disc

into the disc tray.

For an Audio CD (CD-DA), the ﬁ rst track will

•

be played automatically. For an MP3 disc, press the ◄► buttons to

•

select Music, then press the ENTER button.

Audio CD (CD-DA)/MP3 Screen Elements

Music

TRACK 001

00:13 / 00:43

Audio CD

Displays the music information.

Displays the playlist.

Shows the current track/total tracks.

Displays buttons available.

Shows the current play time/total play time.

Displays the current playback status.

Displays the repeated playback status.

Press the ▲▼ buttons to select the track

you want to play, and then press the ENTER button.

TRACK 001

00:43

TRACK 002

03:56

TRACK 003

04:41

TRACK 004

04:02

Enter < Page Tools ' Return

1/13

Repeat an Audio CD (CD-DA)/MP3

During the Playlist playback, press

the REPEAT button.

Select the desired play mode by

pressing the REPEAT button repeatedly.

Audio CD

Off

(CD-DA)/MP3

(

) One

Song

(

NOTE

✎



Audio CD (CD-DA)/MP3

Audio CD

) All

(CD-DA)/MP3

During playback, press the TOOLS button and

Tracks on a disc are played in the order in which they were recorded on the disc.

Current track is repeated.

All tracks are repeated.

set Shufﬂ e Mode to On. You can play the tracks in a random order.

REPEAT

Playlist

Insert an Audio CD (CD-DA) or an MP3 Disc

into the disc slot.

For an Audio CD (CD-DA), the ﬁ rst track will

•

be played automatically.

For an MP3 disc, press the ◄► buttons to

•

select Music, then press the ENTER button.

To move to the Music List, press the STOP () or RETURN button. The Music List screen is displayed.

Press the YELLOW (C) button to switch to Edit Mode.

Press

▲▼◄►

to select a desired track, and

then press ENTER. Repeat this procedure to select additional tracks.

•

The selected ﬁ le will be checked.

•

To cancel your selection, press ENTER again to uncheck the track.

50 English

HT-D5100_XAA_1224.indd 50HT-D5100_XAA_1224.indd 50 2011-12-24  12:31:222011-12-24  12:31:22

04 Basic Functions

Audio CD | Music

TRACK 001

00:43

TRACK 003

04:41

TRACK 005

03:43

TRACK 007

04:06



Close Edit Mode

Selected Items : 3

TRACK 002

03:56

TRACK 004

04:02

TRACK 006

03:40

TRACK 008

03:52

( )

Page Tools " Select ' Return

1/2 Page

• SMART SOUND : Regulates and stabilizes the

volume level and prevents a drastic volume change when you change channels or during a scene transition.

• MP3 ENHANCER : This also helps enhance

your sound experience (ex. mp3 music). You can upscale your MP3 level sound (24 kHz, 8bit) to CD level sound (44.1 kHz, 16bit).

• POWER BASS : This function stresses low

tones and provides thudding sound effects.

When done, press the TOOLS button.

To play the selected track(s), select Play

Selected in the Tools menu, and then press ENTER.

• VIRTUAL 7.1 : Applies the 7.1 CH sound

effect using the 5.1 CH speaker system.

• USER EQ : You can conﬁ gure the equalizer

settings manually to your preference.

SFE (Sound Field Effect) MODE

Music

TRACK 001

00:13 / 00:43

Audio CD

To return to the Edit Mode, press STOP or

TRACK 001

00:43

TRACK 002

03:56

TRACK 003

04:41

Enter Tools ' Return

RETURN.

To exit Edit Mode, press the YELLOW (C)

button.

NOTE

✎

You can create a playlist with up to 99 tracks



on Audio CD (CD-DA).

Sound Mode

1/3

You can set the SFE mode best suited for the type of music you are listening to.

Press the SFE MODE button.

Symphony

Hall in Boston

Phillharmonic

Bratislava

Jazz Club in

Church in

Amphitheater

DSP (Digital Signal Processor) Function

(Hall 1)

Hall in

(Hall 2)

Seoul B

Seoul

(Rock)

Off

SFE MODE

Provides a clear vocal as if you are listening in a concert hall.

Also provides a clear vocal as if you are listening in a concert hall but, less powerful than HALL1.

Recommended setting for Jazz.

Gives the feel of being in a grand church.

Recommended setting for Rock.

Select this for normal listening.

You can select mode to optimize the sound for sound based on your tastes.

Press the DSP button.

DSP

SMART SOUND  MP3 ENHANCER  POWER BASS  VIRTUAL 7.1  USER EQ  DSPOFF

English 51

HT-D5100_XAA_1224.indd 51HT-D5100_XAA_1224.indd 51 2011-12-24  12:31:232011-12-24  12:31:23

Basic Functions

Dolby Pro Logic II Mode

You can select the desired Dolby Pro Logic II audio mode.

Press the

MUSIC

MOVIE

PROLOGIC

MATRIX

STEREO

NOTE

✎

Before selecting Dolby Pro Logic II mode,



connect your external device to the AUDIO INPUT jacks (L and R) on the product. If you connect to only one of the inputs (L or R), you cannot listen to surround sound.

PL II button.

When listening to music, you can experience sound effects as if you are listening to the actual performance.

Adds realism to the movie soundtrack.

You can listen to a 2CH sound source in 5.1CH surround sound with all speakers active.

- A speciﬁ c speaker(s) may not output depending on the input signal.

You will hear multi channel surround sound.

Select this to listen to sound from the front left and right speakers and the subwoofer only.

Playing back a Picture

Viewing Photo Files

Connect a USB memory that contains JPEG

ﬁ les or insert a disc that contains JPEG ﬁ les.

Press the ◄► buttons to select the My

Contents, and then press the ENTER button after press the ▲▼ buttons to select the Photos.

Press the ▲▼◄► buttons to select the

folder you want to play, and then press the ENTER button.

Press the ▲▼◄► buttons to select the

photo you want to play, and then press the

ENTER button.

NOTE

✎

You can’t enlarge PG graphic in the full screen



mode.

Using the TOOLS button

During the slide show playback, you can use various function by pressing the TOOLS button.

Tools

Pause Slide Show Slide Show Speed : Normal Slide Show Effect : Blind Background Music : Off Background Music Setting Zoom Rotate Picture Settings Information

Enter ' Return

TOOLS

Pause Slide Show : Select to pause the slide

•

show. Slide Show Speed : Select to adjust the slide

•

show speed. Slide Show Effect : Select to set the slide

•

show effects.

52 English

HT-D5100_XAA_1224.indd 52HT-D5100_XAA_1224.indd 52 2011-12-24  12:31:272011-12-24  12:31:27

Background Music : Select to listen to music

•

while viewing a slide show. Background Music Setting : Select to set the

•

background music. Zoom : Select to enlarge the current picture.

•

(Enlarge up to 4 times)

•

Rotate : Select to rotate the picture. (Rotate the picture either clockwise or counter clockwise.)

•

Picture Settings : Select to adjust the picture quality.

•

Information : Shows the picture information including the name and size, etc.

NOTE

✎

If the system is connected to a BD Wise



compliant TV that has set BD Wise to On, the Picture Settings menu will not appear.

Before you can enable the background music



function, the photo ﬁ le should exist in the same storage media with the music ﬁ le. However, the sound quality can be affected by the bit rate of the MP3 ﬁ le, the size of the photo and the encoding method.

Playing back a USB Storage Device

You can use the USB connection to play multimedia ﬁ les (MP3, JPEG, DivX, etc) downloaded from the USB storage device.

Move to the home menu.

In Stop mode, connect the USB storage

device to the USB port on the front panel of the product.

My Contents

Videos

Connected Device

Photos

USB

Music

My Devices Internet Settings

Function

Press the ENTER button.

Press the ▲▼◄► buttons to select Videos, Music or Photos, and then press the ENTER button.

For playing back Video, Music or Photo ﬁ les, refer to pages 44~52.

NOTE

✎

You must remove the USB storage device



safely (by performing the “Safely Remove USB” function) to prevent possible damage to the USB memory. Press the MENU button to move to the home menu, select the YELLOW (C) button, and then press the ENTER button.



If you open the tray when playing USB storage device, the device mode is changed to “BD/DVD” automatically.

Enter ' Return



Safely Remove USB d WPS(PBC)

04 Basic Functions

My Contents

Videos

Photos

Music

My Devices Internet Settings

Function

d WPS(PBC)

English 53

HT-D5100_XAA_1224.indd 53HT-D5100_XAA_1224.indd 53 2011-12-24  12:31:292011-12-24  12:31:29

Basic Functions

Listening to Radio

Using buttons on the Remote Control

Press the FUNCTION button to select FM.

Tune in to the desired station.

Preset Tuning 1 : You must ﬁ rst add a desired

•

frequency as a preset. Press the STOP () button to select PRESET and then press the TUNING/CH (

) button to select the preset

station. Manual Tuning : Press the STOP () button to

•

select MANUAL and then press the TUNING/CH (

) button to tune in to a lower

or higher frequency. Automatic Tuning : Press the STOP () button

•

to select MANUAL and then press and hold the TUNING/CH (

) button to automatically

search the band.

Setting Mono/Stereo

Press the MO/ST button.

Each time the button is pressed, the

•

sound switches between STEREO and MONO.

In a poor reception area, select MONO

•

for a clear, interference-free broadcast.

Presetting Stations

Example : Presetting FM 89.10 into memory

Press the FUNCTION button to select FM.

Press the

TUNING/CH

) button to select

(

<89.10>. Press the TUNER MEMORY button.

•

NUMBER ﬂ ashes on the display.

Press the TUNER MEMORY button again.

•

Press the TUNER MEMORY button before NUMBER

•

NUMBER

disappears from the display. disappears from the display and

the station is stored in memory.

To preset another station, repeat steps 2 to 4.

•

To tune in to a preset station, press the TUNING/CH ( )

button to select a

channel.

54 English

TUNER

MEMORY

Connecting an iPod/iPhone Using the

USB Cable

If the home theater is connected to an iPod/iPhone, you can play music in iPod/iPhone through the home theater.

5V 500mA

ASC INASC I

Connect an iPod/iPhone using the USB

cable to the front USB port.

Your iPod is automatically turned on.

•

The “iPod” message appears on the TV

•

screen.

Press the ENTER button.

Select the music ﬁ le to play.

You can use the remote control or the product to control simple playback functions such as the PLAY, PAUSE, STOP,

and /buttons. (See page 16.)

NOTE

✎

You can play a video only when you use the iPod



Dock. If you want to return to the iPod menus while the



iPod player is connected using the USB cable, press FUNCTION on the remote control or press

on the front panel of the system and select

R. IPOD. The FUNCTION mode switches as follows:

BD/DVD  D. IN  AUX  R. IPOD



W. IPOD  FM

Use iPod/iPhone with a Wireless Dock

Cradle (sold separately) for iPod/iPhone

You can enjoy ﬁ ner quality music through the speakers by transmitting an iPod/iPhone’s audio signal using a Wireless Transmitter.

To connect the Cradle to the main unit when you use the Cradle the ﬁ rst time, you have to set the Linking ID manually. (see page 55) After you set the Linking ID, the Cradle will connect to the Wireless Transmitter automtically when you turn it on.

HT-D5100_XAA_1224.indd 54HT-D5100_XAA_1224.indd 54 2011-12-24  12:31:332011-12-24  12:31:33

04 Basic Functions

STANDB

To use the Wireless Dock Cradle:

iPod/iPhone Models You Can Use with

Turn on the main unit and connect the iPod/ iPhone to the Wireless transmitter. Then, press the button on the product to select "W.IPOD" mode. The FUNCTION mode of the main unit switches as follows: BD/DVD  D. IN  AUX  R. IPOD

 W. IPOD  FM ( See page 14)

How to charge the Wireless Transmitter

󱳝

󱳛

LINK

ST AN

D B

CHARGE

Connect the Wireless Transmitter to the

Charging Cradle.

Connect the DC power adapter to a wall socket.

•

The charging indicator lights and charging starts. After the battery is fully charged, the charging indicator turns Green.

Operation status of the charging cradle's LED

Display Function

GREEN LED ON

RED LED ON

Power on /Charging

completed

Charging.

iPod touch (3rd generation)



iPod touch (2nd generation)



iPod touch (1st generation)



iPod classic



iPod with video



iPod with dock connector



iPod with Click Wheel



iPod nano (5th generation) iPod nano (4th generation)



iPod nano (3rd generation)



iPod nano (2nd generation)



iPod nano (1st generation)



iPhone 4



iPhone 3GS



iPhone 3G



iPhone



NOTE

✎

“Made for iPod” means



that an electronic accessory has been designed to connect speciﬁ cally to iPods and has been certiﬁ ed by the developer to meet Apple performance standards. “Made for iPhone” means that an electronic



accessory has been designed to connect speciﬁ cally to iPhones and has been certiﬁ ed by the developer to meet Apple performance standards. Apple is not responsible for the operation of



this device or its compliance with safety and regulatory standards.



The volume control may not operate normally with iPod and iPhone models not listed above. If you have a problem with any

NOTE

✎

The LED indicates the charging state of the



built-in battery in the wireless iPod transmitter. Check the charging state of iPod/iPhone by checking the charging indication of its battery.

The Wireless Dock links with the Home



Theater when you use the SWA-5000. The charger can only recharge Samsung



wireless transmitters whose speciﬁ cations are compliant with the charger.

of the models listed above, please update the software of the iPod/iPhone to the lastest version.

Depending on the software version of the



iPod, control problems may occur. This is not a malfunction of the Home Theater.

Depending on the software version or the



type of the iPod, some operations may differ. Install the latest iPod software. (recommended)

This Product

HT-D5100_XAA_1224.indd 55HT-D5100_XAA_1224.indd 55 2011-12-24  12:31:372011-12-24  12:31:37

English 55

Basic Functions

STANDBY

LINK

Playback of applications' contents through



the product is not guaranteed. We recommend playing contents downloaded to the iPod.

If you have a problem using your iPod,



please visit www.apple.com/support/ipod

Operation status of the wireless transmitter's LED

How to Link the Wireless Transmitter

with the Main Unit

Turn off your Home Theater.

Press the 4, 7, 6, 3 buttons on the remote

control in order.

•

The Power LED blinks once.

Connect the iPod/iPhone to the Wireless transmitter.

S T

A N

B Y

C H A

G E

Turn on the iPod/iPhone. Press the "ID SET" button on the back of the Wireless transmitter for 5 seconds. The link light on the wireless transmitter blinks rapidly.

Turn on your product.

•

To listen to music from your iPod/iPhone over the product, press the button to select "W. IPOD" mode.

After you select "W. IPOD" mode, turn the

•

volume of the product down to avoid hearing damage.

You can control the speaker volume of the

•

iPod/iPhone with a volume wheel or a volume bar.

When the iPod/iPhone is stopped or in a

•

power saving mode, the Wireless transmitter enters Sleep Mode. When iPod/iPhone is set to Deep Sleep Mode, the Wireless transmitter turns off.

I N

STANDB

A RGE

Function

Display

LINK

(Blue LED)

STANDBY (Red LED)

Pairing

LED ON

successfully

STANDBY

completed

LED BLINK

(Long blink)

LED BLINK

(Short blink)

CAUTION

If you use a wireless device such as a laptop



Processing iPod/

iPhone

Processing

pairing

LOW BATTERY

Pairing failed

computer, an AP, or Wiﬁ , near the main home theater unit, an unstable operation error can occur.

Do not pair the SWA-5000 and iPod/iPhone at



the same time. If you pair them at the same time, the iPod/iPhone and SWA-5000 may not connect to the product.



The maximum transmission distance from the product to the wireless transmitter is about

16.4 feet, but may vary depending on your operation environment.

The audio signal may be weakened or even



lost where there is an obstacle such as a wall or partition between the product and wireless transmitter. You can also weaken or lose signal if you move the wireless transmitter around.

56 English

HT-D5100_XAA_1224.indd 56HT-D5100_XAA_1224.indd 56 2011-12-24  12:31:382011-12-24  12:31:38

Network Services

05 Network Services

You can enjoy various network services such as Smart Hub or BD-LIVE by connecting the product to your network.

Read the following instructions before using any network service.

Connect the product to the network.

(see pages 25~26)

Conﬁ gure the network settings.

(see pages 36~39)

Using Smart Hub

Using Smart Hub, you can stream movies, videos, and music from the Internet, access various for pay or free-of-charge applications and view them on your TV. Application content includes news, sports, weather forecasts, stock market quotes, maps, photos, and games.

You can also start this function by pressing the SMART HUB button on the remote control.

Starting Smart Hub the First Time

To start Smart Hub for the ﬁ rst time, follow these steps :

The Smart Hub screen appears.

NOTE

✎

Certain applications are available only in certain



countries.

The Terms of Service Agreement screen

appears. If you want to agree, press the ◄► buttons to select Agree, then press the ENTER button.

NOTE

✎

Screens can take a few seconds to appear.



The Service Update screen appears and

installs a number of services and applications. When done, it closes. The applications and services downloaded are displayed on the Smart Hub screen. This may take some time.

NOTE

✎

Smart Hub may close momentarily during the



installation process.

A number of screens may appear after



installation. You can press the ENTER button to close them or let them close on their own.

To start an application, press the ▲▼◄►

buttons to highlight an application, then press the ENTER button.

Go to the Home menu.

My Contents

Videos

Photos

Music

My Devices Internet Settings

Function



Safely Remove USB d WPS(PBC)

Press the ◄► buttons to select Internet,

and press the ENTER button.

English 57

HT-D5100_XAA_1224.indd 57HT-D5100_XAA_1224.indd 57 2011-12-24  12:31:432011-12-24  12:31:43

Network Services

Smart Hub at a Glance

1 2 3 5

Your Video

Recommended

Contents 1

Contents 2

xxxxxxxx

Contents 7

xxxxxxxx

Contents 1

xxxxxxxx

Contents 8

xxxxxxxx

Contents 2

xxxxxxxx

Contents 9

xxxxxxxx

Contents 4

Contents 3

xxxxxxxx

Contents 10

xxxxxxxx

7 6

Commercial : Displays the Smart Hub Guide, an introduction to the product, and new

application introductions.

Your Video : Provides recommendations for videos based on your tastes.

Lets you see movie recommendations

•

based on your previous preferences. Lets you select a movie, displays a list of

•

VOD (Video on Demand) providers that

have the movie, and then lets you choose a provider for streaming. (Streaming is unavailable in some areas.)

•

For instructions to use Your Video, please visit www.samsung.com.

•

This feature is limited to certain regions.

Search : Provides an integrated search of your video providers and connected AllShare devices.

Usable while using Smart Hub (except

•

when you are watching a Blu-ray Disc).

For easy access, use the SEARCH button

•

on the remote control. For instructions to use search function,

•

please visit www.samsung.com.

Samsung Apps : You can download various for

pay or free-of-charge application services.

Recommended : Displays recommended

contents managed by Samsung.

Samsung Apps

Contents 1 Contents 2 Contents 3 Contents 4

Contents 3

Contents 4

xxxxxxxx

Contents 5

xxxxxxxx

Contents 11

xxxxxxxx

Contents 5

xxxxxxxx

Contents 12

xxxxxxxx

Contents 6

xxxxxxxx

Contents 13

Contents 6

xxxxxxxx

Navigation Help : Displays the remote control buttons you can use to navigate in Smart Hub.

•

RED (A) : To log in to Smart Hub.

•

GREEN (B) : To sort the applications.

YELLOW (C) : To edit the applications.

•

BLUE (D) : To change the settings of Smart

•

Hub.

My Applications : Displays your personal gallery of applications which you can add to, modify, and

delete.

NOTE

✎

Samsung Electronics takes no legal



responsibility for any interruption of the Smart Hub service caused by the service provider for any reason.

The Smart Hub service downloads and



processes data via the Internet so that you can enjoy the Internet contents on your TV screen. If the Internet connection is unstable, the service may be delayed or interrupted. Furthermore, the product may turn off automatically in response to conditions on the Internet. If this occurs, check the Internet connection and try again.

Application services may be provided in



English only and the contents available may vary, depending on your area.

For more information about a Smart Hub



service, visit the web site of the applicable service provider.

The services provided are subject to change



by the Smart Hub service provider without notice.

The Smart Hub service contents may differ



depending on the product’s ﬁ rmware version.

For pay DivX contents with copy protection



can only be played through an HDMI cable.

58 English

HT-D5100_XAA_1224.indd 58HT-D5100_XAA_1224.indd 58 2011-12-24  12:31:452011-12-24  12:31:45

05 Network Services

xxxxxxxx

Contents 1

xxxxxxxx

Contents 6

xxxxxxxx

Contents 5

xxxxxxxx

Contents 4

xxxxxxxx

Contents 3

xxxxxxxx

Contents 2

xxxxxxxx

Contents 7

xxxxxxxx

Contents 8

xxxxxxxx

Contents 9

xxxxxxxx

Contents 10

xxxxxxxx

Contents 11

xxxxxxxx

Contents 12

xxxxxxxx

Contents 1

xxxxxxxx

Contents 2

xxxxxxxx

Contents 3

xxxxxxxx

Contents 4

xxxxxxxx

Contents 5

Contents 1 Contents 2 Contents 3 Contents 4

Using the Keypad

Through your remote, you can use the On-Screen Keypad to enter letters, numbers, and symbols.

Creating an Account

To establish your own, exclusive, conﬁ guration of Smart Hub, create your own Smart TV Account.

To create an account, follow these steps:

123

. , –

abc def

456

ghi jkl mno

789

pqrs tuv wxyz

Shift Delete

ab Ab AB 1 

Input Method / Language: English

4 5

The current keypad.

Use to enter letters, numbers, and symbols.

Press the FULL SCREEN button on the remote control to shift the input mode.

: ab, Ab, AB, numbers or icons.

Displays the current input mode.

Press the GREEN (B) button on the remote

control to change the input method. (T9 or ABC)

Press the TOOLS button on the remote control

to change the language.

Press the REPEAT button on the remote control

to delete a character.

Press the RED (A) button on your remote control. The Login screen appears.

Your Video

Recommended

Smart TV ID

Password

Press the ▲▼◄► buttons to select Create

Press [Enter]

Remember my Smart TV ID and password



Create Account Forgot Password

Samsung Apps

Account, and then press the ENTER button.

On the next screen, select Smart TV ID, and then press the ENTER button. An entry screen and keypad appear.

Use the keypad to enter your e-mail address. This will serve as your ID.

NOTE

✎

The keypad works like the keypad on a cell



phone.

When done, press the ENTER button to

select OK, and then press the ENTER

Entering Text, Numbers and Symbols

To enter text, press the number button on the remote that corresponds to the letter you want to enter. Press the button rapidly to enter a letter that is not the ﬁ rst letter listed on the On-Screen keypad button. For example, if you want to enter the letter b, press the 2 button on your remote rapidly twice. To enter the ﬁ rst letter listed on a button, press, release, and then wait.

To move within the text, use the Arrow buttons. To delete text, move the cursor to the right of the character you want to delete, and then press the REPEAT button. To change case or enter numbers or punctuation, press the FULL

button again. The Create Account screen reappears.

Select Password, and then press the

ENTER button. The Password screen and a keypad appear.

Use the keypad to enter a password.

The password can be any combination of letters, numbers, and symbols.

NOTE

✎

Press the RED (A) button on your remote to



show or hide the password as you enter it.

SCREEN button.

HT-D5100_XAA_1224.indd 59HT-D5100_XAA_1224.indd 59 2011-12-24  12:31:462011-12-24  12:31:46

English 59

Network Services

When done, press the ENTER button to

select OK, and then press the ENTER button again. The Login screen re-appears.

Select Conﬁ rm password, and then press

the ENTER button.

Repeat Steps 7 and 8.

10.

When the Login screen re-appears, select

11.

Create Account, and then press the ENTER button. The Conﬁ rmation window

appears.

Select OK, and then press the ENTER

12.

button. The Continue to Register Service window appears.

Select Go Register, and then press the

13.

ENTER button.

The Register Service Account Window

14.

appears.

If you have existing accounts with any of

•

the listed providers, you can associate the provider account and the provider account password with your Smart TV Account. Registration makes it easier to access the providers web site. For registration instructions, go to Step 2 in Account Management under the Settings Menu.

If you don’t have existing provider accounts

•

or do not want to register existing accounts at this time, select Register Later, and then press the ENTER button. You can also let the window close on its own in about a minute.

NOTE

✎

You must use an e-mail address as an ID.



You can register up to 10 User Accounts.



You do not need an account to use Smart



Hub.

Account Log In

To log in to your Smart TV Account, follow these steps:

With the Smart Hub main screen displayed on your TV, press the RED (A) button on your remote. The Login screen appears.

Select the Down Arrow next to the Smart

TV ID ﬁ eld, and then press the ENTER button.

Select your ID from the list that appears, and

then press the ENTER button. The Login screen re-appears.

Select Password, and then press the

ENTER button. The Password window and a keypad appears.

Using the keypad and your remote, enter

your password. When done, press the ENTER button, select OK, and then press the ENTER button again.

NOTE

✎

If you want Smart Hub to enter your password



automatically, select Remember my Smart TV ID and password after you have entered your password, and then press the ENTER button. A check appears. Smart Hub will now enter your password automatically when you select or enter your ID.

The Settings Menu - BLUE (D)

The Settings Menu Screen gives you access to account management, account reset, and account properties functions.

To access the Settings Menu, and then select a menu item, follow these steps:

Press the BLUE (D) button on your remote.

Press the ▲▼ to select a menu item, and

then press the ENTER button.

The functions on the Settings Menu screen are described below.

NOTE

✎

The Service Manager item listed in the Settings



Menu is not available for Blu-ray Home Theaters.

Account Management

The Account Management Menu contains functions that let you register your service provider accounts, change your Smart Hub password, and delete or deactivate your Smart TV Account.

60 English

HT-D5100_XAA_1224.indd 60HT-D5100_XAA_1224.indd 60 2011-12-24  12:31:492011-12-24  12:31:49

05 Network Services

If you have existing accounts with any of the providers listed by the Register Service Account function, you can associate the provider account and the provider account password with your Smart TV Account. If you associate the account, you will be able to log onto the account through Smart Hub easily, without entering your account name or password.

To use the Register Service Account function, follow these steps:

In the Settings menu, select Register Service

Account, and then press the ENTER button. The Register Service Account Window appears.

Press the ▲▼ arrow buttons to select a

Service Provider you want to associate with your Smart TV Account, and then press the

ENTER button.

NOTE

✎

If you have a Samsung account and you want



to use the Samsung Apps function in Smart Hub, you must register your Samsung Apps account here. See page 64 for more information.

Using your remote and the on-screen

Keypad, enter your site ID and password. When done, press the ENTER button.

NOTE

✎

This is the ID and password you normally use



to access your account on this site.

If you have entered the ID and password

correctly, the Registered Successfully message appears.

If you pressed ENTER, repeat Steps 2

through 4 to associate another Service Provider.

When you are done, press the RETURN

button.

Change Password

The Change Password function lets you change your Smart Hub password. To change the password, follow these steps:

Select Change Password, and then press

the ENTER button.

Enter your current password. The next

screen appears.

On the next screen, enter a new password

on the ﬁ rst line. Enter it again on the second line to conﬁ rm.

The Changing Password Complete message

screen appears. Press the ENTER button or wait for the screen to close - about 5 seconds.

Remove from TV Account List

The Remove from TV Account List function cancels all your current registered Service Accounts that you registered on the Register Service Account screen.

Deactivate Account

The Deactivate Account function deactivates your Smart TV Account and deletes it and all your account settings entirely from Smart Hub.

Service Manager

This menu is for setting the service of the special application. (Application-related is like AP New,Ticker etc.)

NOTE

✎

This function operates only when special



application is installed.

Reset

The Reset function initializes all downloaded application, erases all user accounts and settings from the product, and resets all Smart Hub settings to the factory default settings. It then restarts Smart Hub as if it were starting for the ﬁ rst time. Your account, however, remains on the Smart Hub server. To log into your account, enter your ID and password on the Create Account screen.

English 61

HT-D5100_XAA_1224.indd 61HT-D5100_XAA_1224.indd 61 2011-12-24  12:31:492011-12-24  12:31:49

Network Services

To use the Reset function, follow these steps:

In the Account Management menu, select

Reset, and then press the ENTER button. The Reset screen appears.

Enter the your Security password. This is the

password you entered if you set up a BD or DVD Parental rating (See page 41). If you did not, enter 0000.

After a few moments, Smart Hub

automatically resets. The screen may go black, then Smart Hub re-appears. In a few moments, it starts the re-initialization procedure.

To complete the re-initialization, go to Step 4

in Starting Smart Hub for the First Time. (See page 57)

NOTE

✎

If you forgot your password, press the STOP



(  ) button on the front panel of the product for more than 5 seconds with no disc inserted.

Properties

The Properties menu item lists three functions that display information about Smart Hub :

Detail

Lists information about Smart Hub including version number, the number of services installed, memory usage, and the unique product ID.

Displays the Terms of Service Agreement.

The Edit Mode Menu - YELLOW (C)

The functions in the Edit Mode menu let you manipulate the application in the My Applications section of the Smart Hub screen. Using these functions, you can lock and unlock access to some application, New Folder and move application to them, rename folders, delete application, and change the position of application on the screen.

To access the Edit Mode Menu, and then select a menu item, follow these steps:

Press the YELLOW (C) button on your

remote. The Edit Mode menu bar appears on the bottom of the screen.

Press the ▲▼◄► to select a menu item,

and then press the ENTER button.

The functions in the Edit Mode Menu bar are described below.

NOTE

✎

Some menu items may not appear on the



screen. To see these items, press the ◄► to move to the screen edge, and then press one more time to reveal the items.

You can close the bar by highlighting the X on



the bottom right side, and then pressing the

ENTER button.

Move

The Move function lets you change the screen position of a application. To use the Move function, follow these steps:

Press the YELLOW (C) button on your

remote.

Select a application, and then press the

ENTER button. A check appears above the application.

Press the ▲▼◄► to select Move, and

then press the ENTER button. A position change icon appears above the application.

Press the ▲▼◄► to move the icon. Press

the ENTER button when the icon is in the position of your choice. The application moves to its new location.

62 English

HT-D5100_XAA_1224.indd 62HT-D5100_XAA_1224.indd 62 2011-12-24  12:31:492011-12-24  12:31:49

05 Network Services

New Folder

The New Folder function lets you create and name new folders. Once you have created a folder, you can move application into it. To use the New Folder function, follow these steps:

Press the YELLOW (C) button on your

remote.

Press the ▲▼◄► to move the cursor to

New Folder, and then press the ENTER button. The New Folder window and a keypad appear.

Use the keypad to enter the name of the

folder, and then press the ENTER button. The New Folder screen closes and the New Folder appears on the Smart Hub screen.

Move to Folder

The Move to Folder function lets you move a application to a folder. To use the Move to Folder function, follow these steps:

Press the YELLOW (C) button on your remote.

Select a application, and then press the ENTER button.

Press the ▲▼◄► to select Move to Folder, and then press the ENTER button. The Move to Folder window opens.

Press the ▲▼◄► to select a folder, and then press the ENTER button. The Moved to Folder message appears, and then closes. The application has been moved to the folder.

To Access Application in a Folder

Close the Edit Mode menu.

In My Applications, press the ▲▼◄► to select a folder, and then press the ENTER button. The folder opens.

Select a application, and then press the

ENTER button. The application’s application or service starts.

To Edit Items in a Folder

Select a folder, and then press the ENTER button. The folder opens.

Press the YELLOW (C) button on your remote. The Edit buttons appear at the bottom of the screen.

These buttons work the same as the Edit Mode menu buttons on the main screen. For example, to move a application back to the My Applications main screen:

Select the application.

Select Move to Folder, and then press the ENTER button. The Move to Folder window appears.

Select My Apps, and then press the ENTER button. The Move to Folder window closes and the application returns to the main My Applications screen.

Rename Folder

The Rename Folder function lets you rename folders. To use the Rename Folder function, follow these steps:

Press the YELLOW (C) button on your remote.

Press the ▲▼◄► to select a folder, and then press the ENTER button.

Press the ▲▼◄► to select Rename a Folder, and then press the ENTER button. The Folder Rename window and a keyboard appears.

Use the key board to enter a new name, and then press the ENTER button. The Rename window closes and the new name appears below the folder.

Lock

The Lock function lets you lock some application in My Applications so they can not be opened without entering the Parental Security Code.

English 63

HT-D5100_XAA_1224.indd 63HT-D5100_XAA_1224.indd 63 2011-12-24  12:31:492011-12-24  12:31:49

Network Services

To use the Lock function, follow these steps:

Press the YELLOW (C) button on your

remote.

Press the ▲▼◄► to select a application, and then press the ENTER button. If the application can be locked, the Lock menu item is enabled.

Press the ▲▼◄► to select Lock, and then press the ENTER button. The Security window appears.

Enter your Parental Security Code (See page

41). If you have not created a Parental Security Code, enter 0000.

Press the ENTER button. The Lock Service window appears conﬁ rming the lock, and then closes. A lock symbol appears next to the application.

Unlock

Press the YELLOW (C) button on your remote.

Press the ▲▼◄► to select a locked application, and then press the ENTER button.

Press the ▲▼◄► to select Unlock, and then press the ENTER button. The Security window appears.

Enter the Parental Security Code (See page

41). If you have not created a Parental Security Code, enter 0000.

Press the ENTER button. The Lock Service Released window appears conﬁ rming the lock has been release, and then closes.

Press the ▲▼◄► to select Delete, and

then press the ENTER button. The message, “Do you want to delete the selected item(s)?” appears.

Select Yes, and then press the ENTER

button. The application is deleted.

The Sort by Menu - GREEN (B)

The functions in the Sort Menu let you sort the application in My Applications by Default, Name, Date, Frequency, Category, User Deﬁ ned. If you manually change the position of a application, the Sort Menu automatically highlights User Deﬁ ned when you start it.

To sort the application in My Applications, follow these steps:

Press the GREEN (B) button on your remote.

Press the ◄► to select a sorting method, and then press the ENTER button. Smart Hub sorts the application by the method you have chosen.

Samsung Apps

Samsung Apps lets you download for pay or free-of-charge applications and services to your Blu-ray Home Theater and view or use them on your TV.

These applications and services include videos, music, photos, games, news, sports, etc. Application for the new apps appear in My Applications.

Additional applications and services are added regularly.

Delete

The Delete function lets you delete application from My Applications. To use the Delete function, follow these steps:

Press the YELLOW (C) button on your remote.

Press the ▲▼◄► to select a application, and then press the ENTER button.

For Pay Apps

To download for pay apps, you need to create a Samsung Account and add a credit card to the account.

To create a Samsung account, please visit www. samsung.com

NOTE

✎

This service may not provided in some



countries.

64 English

HT-D5100_XAA_1224.indd 64HT-D5100_XAA_1224.indd 64 2011-12-24  12:31:502011-12-24  12:31:50

05 Network Services

Accessing the Samsung Apps Screen

To access Samsung Apps, press the ▲▼◄► buttons to navigate to the Samsung Apps area on the Smart Hub main screen, and then press the ENTER button. The Samsung Apps screen appears.

NOTE

✎

If this is the ﬁ rst time you are accessing this



screen, the terms of service window appears. Select Agree, and then press the ENTER button.

Using the Samsung Apps Screen

To use the Samsung Apps screen, follow these steps:

Press the ◄► buttons to move to the

category list on the left.

Press the ▲▼ to hig hlight a category. In a

few seconds, the Samsung Apps screen displays the applications in that category. The Sort tabs appear across the top.

Press the ► button to move to the displayed

applications or services.

Press the ▲▼◄► buttons to select an

application or service, and then press the ENTER button. The Application Details screen appears describing the service or application.

Select Download Now, and then press the

ENTER button. If the application or service is free, it downloads and runs. If not, and there is a fee, follow the directions on the screen to complete the download.

NOTE

✎

Some apps are free to download, but require



registration with the provider or a paid account with the provider to use. Application for applications and services you



have downloaded from Samsung Apps appear in My Applications.

Sort By Tabs

You can access the Sort By tabs on the top of the screen using the ▲▼◄► buttons. Each tab displays the services or applications in the category you chose, sorted by the criteria on the tab (Recommended, Most Downloaded, Most Recent, Name).

You can also use the BLUE (D) button on your remote to access the Sort By tabs. Each time you press the BLUE (D) button, you change the display from one sort tab to the next.

Samsung Apps by category

The following categories are available:

What’s New? : Displays newly registered

•

applications.

Video : Displays various video media such as

•

movies, TV shows, and short length videos.

Game : Displays various games such as sudoku

•

and chess.

Sports : Displays various sports media services

•

such as match information, images, and short length videos.

Lifestyle : Includes various lifestyle media services

•

such as music, personal photo management tools, and social networking such as Facebook and Twitter.

Information : Includes various information services

•

such as news, stocks, and weather.

Other : Includes other miscellaneous services.

•

My Account

My Account gives you access to your Samsung Apps order and download history, and to the My Apps Cash screen. You must have a Samsung account to access this information.

English 65

HT-D5100_XAA_1224.indd 65HT-D5100_XAA_1224.indd 65 2011-12-24  12:31:502011-12-24  12:31:50

Network Services

Help

If you have questions about Samsung Apps, check Help ﬁ rst. If none of the tips apply, please visit www.samsung.com.

To use the Help function, follow these steps:

Press the ▲▼◄► buttons to select Help,

and then press the ENTER button.

Press the ◄► to enter Help after it appears.

Press the ▲▼ to scroll the Help text.

Press the ◄ to exit Help.

Using the colored buttons on your remote with Samsung Apps

RED (A) (Login) : To log into your Smart TV

•

Account.

GREEN (B) (Thumbnail/List View) : To toggle

•

applications between Thumbnail and List view.

BLUE (D) (Sort By) : To sort the applications in a

•

category by Recommended, Most Downloaded, Most Recent, or Name.

Return : To return to the previous menu.

•

NOTE

✎

The Internet contents services may be added



or deleted by providers without notice.

For instructions to use Your Video or Search Function, please visit www.samsung.com

BD-LIVE™

Once the product is connected to the network, you can enjoy various movie-related service contents using a BD-LIVE compliant disc.

Attach a USB memory stick to the USB jack

on the front of the product, and then check its remaining memory. The memory device must have at least 1GB of free space to accommodate the BD-LIVE services.

Insert a Blu-ray disc that supports BD-LIVE.

Select an item from various BD-LIVE service

contents provided by the disc manufacturer.

NOTE

✎

The way you use BD-LIVE and the provided



contents may differ, depending on the disc manufacturer.

Using the AllShare Function

AllShare lets you play music, video, and photo ﬁ les located in your PC or your DLNA compatible mobile phone or NAS on the product.

To use AllShare with your product, you must connect the product to your network (See pages 25~26). To use AllShare with your PC, you must install AllShare software on your PC.

If you have a DLNA compatible mobile phone or NAS, you can use AllShare without any additional software.

You can download the PC software and get detailed instructions for using AllShare from the Samsung. com web site.

66 English

HT-D5100_XAA_1224.indd 66HT-D5100_XAA_1224.indd 66 2011-12-24  12:31:502011-12-24  12:31:50

06 Other Information

Other Information

Troubleshooting

Refer to the chart below when this product does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, turn off the product, disconnect the power cord, and contact Samsung Electronics at 1-800-SAMSUNG (1-800-726-7864).

Symptom Check/Remedy

I cannot eject the disc.

The iPod fails to connect.

Playback does not start.

Playback does not start immediately when the Play/Pause button is pressed.

Sound is not produced.

Sound can be heard only from a few speakers and not all 6.

Dolby Digital 5.1 CH Surround Sound is not produced.

The remote control does not work.

• Disc is rotating but no picture is produced.

• Picture quality is poor and picture is shaking.

Audio language and subtitles do not work.

Menu screen does not appear even when the menu function is selected.

• Is the power cord plugged securely into the outlet?

• Turn off the power and then turn it back on.

• Check the condition of the iPod connector.

• Keep the iPod software version up to date.

• Check the region number of the BD/DVD. BD/DVD discs purchased from abroad may not be playable.

• CD-ROMs and DVD-ROMs cannot be played on this product.

• Make sure that the rating level is correct.

• Are you using a deformed disc or a disc with scratches on the surface?

• Wipe the disc clean.

The home theater does not play sound during fast playback, slow playback,and step

• motion playback.

•

Are the speakers connected properly? Is the speaker setup correctly customized?

• Is the disc severely damaged?

• On certain BD/DVD discs, sound is output from the front speakers only.

• Check if the speakers are connected properly.

• Adjust the volume.

• When listening to a CD, radio or TV, sound is output to the front speakers only. Select "PRO LOGIC control to use all six speakers.

•

Is there "Dolby Digital 5.1 CH" mark on the disc? Dolby Digital 5.1 CH Surround Sound is produced only if the disc is recorded with 5.1 channel sound.

• Is the audio language correctly set to Dolby Digital 5.1-CH in the information display?

• Are you operating the remote within its operational range and within the proper angle relative to the sensor?

• Are the batteries drained?

• Have you selected the mode (TV/BD) functions of the remote control (TV or BD) correctly?

• Is the TV power on?

• Are the video cables connected properly?

• Is the disc dirty or damaged?

• A poorly manufactured disc may not be playable.

•

Audio language and subtitles will not work if the disc does not contain them.

• Are you using a disc that does not contain menus?

" by pressing PL II (Dolby Pro Logic II) on the remote

English 67

HT-D5100_XAA_1224.indd 67HT-D5100_XAA_1224.indd 67 2011-12-24  12:31:502011-12-24  12:31:50

Other Information

Symptom Check/Remedy

Aspect ratio cannot be changed.

• The product is not working. (Example: The power goes out or a strange noise is heard.)

The Product is not working

• normally.

You have forgotten the rating level password.

Can't receive radio broadcasts.

While listening to TV audio through the Product, no sound is heard.

"Not Available" appears on screen.

If the HDMI output is set to a resolution your TV cannot support (for example, 1080p), you may not see a picture on your TV.

No HDMI output.

• You can play 16:9 BD/DVDs in 16:9 Wide mode, 4:3 Letter Box mode, or 4:3 Pan - Scan mode, but 4:3 BD/DVDs can be seen in 4:3 ratio only. Refer to the Blu-ray Disc jacket and then select the appropriate function.

• Press and hold the romote control's STOP (  ) button for 5 seconds in STANDBY mode.

- Using the RESET function will erase all stored settings.

Do not use this unless necessary.

• With no disc in the product, press and hold the product's STOP (  ) button for longer than 5 seconds. INIT appears on the display and all settings will return to the default values. And then press the POWER button.

- Using the RESET function will erase all stored settings.

Do not use this unless necessary.

• Is the antenna connected properly?

• If the antenna's input signal is weak, install an external FM antenna in an area with good reception.

If the OPEN/CLOSE ( ) button is pressed while listening to TV audio using the

• D. IN or AUX functions, the BD/DVD functions are turned on and the TV audio is muted.

• The features or action cannot be completed at this time because:

1. The BD/DVD’s software restricts it.

2. The BD/DVD’s software doesn’t support the feature (e.g., angles)

3. The feature is not available at the moment.

You’ve requested a title or chapter number or search time that is out of range.

• Press and hold the STOP (  ) button on front panel for more than 5 seconds with no disc inserted. All settings will revert to the factory settings.

• Check the connection between the TV and the HDMI jack of the product.

• Check if your TV supports 480p/720p/1080i/1080p HDMI input resolution.

Abnormal HDMI output screen.

• If random noise appears on the screen, it means that TV does not support HDCP (High-bandwidth Digital Content Protection).

68 English

HT-D5100_XAA_1224.indd 68HT-D5100_XAA_1224.indd 68 2011-12-24  12:31:502011-12-24  12:31:50

Symptom Check/Remedy

PC Share Manager function

06 Other Information

I can see folders shared through the PC Share Manager, but I cannot see the ﬁ les.

AllShare function

Video is played intermittently.

AllShare connection between TV and PC is unstable.

BD-LIVE

I cannot connect to the BD-LIVE server.

When using the BD-LIVE service, an error occurs.

• Since it shows only ﬁ les corresponding to the Image, Music, and Movie categories, ﬁ les that do not correspond to these categories may not be displayed.

• Check if the network is stable.

• Check if the network cable is properly connected and if the network is not overloaded.

• Wireless connection between the server and the product is unstable. Check the connection.

IP address under the same subnetwork should be unique, otherwise IP collision

• can results in such a phenomenon.

•

Check if you have a ﬁ rewall enabled. If so, disable the ﬁ rewall function.

• Check whether the network connection is successful or not by using Network Test menu.

• Check whether the USB memory device is connected with product or not.

• The memory device must have at least 1GB of free space to accommodate the BD-LIVE service. You can check the available size in BD Data Management. (See page 40)

• Please check whether the BD-LIVE Internet Connection menu is set to Allow(All).

• If all above fails, contact the contents provider or update the latest ﬁ rmware.

•

The memory device must have at least 1GB of free space to accommodate the BD-LIVE service. You can check the available size in BD Data Management. (See page 40)

NOTE

✎

When the factory default settings are restored, all the user data stored in the BD data will be deleted.



Repairs

If you contact us to repair your player, an administration fee may be charged if either:

An engineer is called out to your home at your request and there is no defect in the product.

You bring the unit to a repair center and there is no defect in the product.

We will provide you with the amount of the administration fee before we make a home visit or begin any work on your product. We recommend you read this manually thoroughly, search for a solution on line at www.samsung. com, or contact Samsung Customer Care at 1-800-SAMSUNG (726-7864) before seeking to repair your product.

English 69

HT-D5100_XAA_1224.indd 69HT-D5100_XAA_1224.indd 69 2011-12-24  12:31:512011-12-24  12:31:51

Other Information

Index

Accessories 13 Ad-hoc 26 AllShare 66 Anynet+ (HDMI-CEC) 40 Audio 32 Audio Language 47 Audio Return Channel 34 Audio Sync 36

Background Music 53 BD-LIVE 66 BD Data Management 40 BD Parental Rating 41 BD Wise 29 BONUSVIEW 48

Camera Angle 48 Change Password 41 Connections 18

Speaker 18 Wireless receiver module TV 22 HDMI 22 Component 23 Composite 23 Set-Top Box 24 OPTICAL 24 AUX 24 Network 25 LAN Cable 25 Wireless Network 26 Wireless LAN Adapter 26 FM Antenna 26

Contact Samsung 43

Digital Output 34 Disc menu 44 Disc Structure 44 Display 29 DivX® Video On Demand 40 Dolby Pro Logic ll Mode 52 DSP 51 DVD Parental Rating 41 Dynamic Range Control 35

Front Display 41

General 41

HDMI Audio 34 HDMI Color Format 31 HDMI Deep Color 31

Initial Settings 27, 39 iPod 54

Language 41

Mono/Stereo 54 Movie Frame (24 Fs) 31 Musical Room Calibration 33

Network Remote Control 41 Network Setup 36 Network Status 39

Picture Setting 48 Playlist 50 Popup menu 45 Progressive Mode 31

Region Code 10 Remote Control 16 Remote Control Sensor 14 Repeat 46, 50 Reset 40 Resolution 29

Search and Skip 45 Security 41 Setting the Menu 28 Setup 27 SFE 51 Slow and Step 46 Smart Hub 57 Smart Hub Screen Size 29 Software Upgrade 42 Speaker Setting 32 Still Mode 31 Subtitle Language 47 Support 42 System 39

Time Zone 40 Title menu 45 Title list 45 TV Aspect 29 TV Screen Saver 27

USB Storage Device 53 User EQ 33

Zoom 53

70 English

HT-D5100_XAA_1224.indd 70HT-D5100_XAA_1224.indd 70 2011-12-24  12:31:512011-12-24  12:31:51

General

FM Tuner

Disc

Video Output

Video/Audio

Amplifier

Speciﬁ cations

Power Requirements AC 120V, 60Hz

Power Consumption 70 W

Weight 7.7 Ibs

Dimensions 16.9 (W) x 2.3 (H) x 12.8 (D) inches

Operating Temperature Range +41°F to +95°F

Operating Humidity Range 10 % to 75 %

Signal/noise ratio

Usable sensitivity 12 dB

Total harmonic distortion

BD (Blu-ray Disc) Reading Speed : 9.834 m/sec

DVD (Digital Versatile Disc)

CD : 5 inches (COMPACT DISC)

CD : 3 1/2 inches (COMPACT DISC)

Composite Video

Component Video

HDMI

Front speaker output 165W x 2(3Ω)

Center speaker output 170W(3

Surround speaker output 165W x 2(3Ω)

Subwoofer speaker output 170W(3Ω)

Frequency response

S/N Ratio 70dB

Channel separation 60dB

Input sensitivity (AUX)500mV

55 dB

0.5 %

Reading Speed : 6.98 ~ 7.68 m/sec.

Approx. Play Time (Single Sided, Single Layer Disc) : 135 min.

Reading Speed : 4.8 ~ 5.6 m/sec.

Maximum Play Time : 74 min.

Reading Speed : 4.8 ~ 5.6 m/sec.

Maximum Play Time : 20 min.

1 channel : 1.0 Vp-p (75 Ω load)

Blu-ray Disc : 480i DVD : 480i

Y : 1.0 Vp-p (75 Ω load)

Pr : 0.70 Vp-p (75 Ω load)

Pb : 0.70 Vp-p (75 Ω load)

BD : 480i DVD : 480p, 480i

1080p, 1080i, 720p, 480p

PCM multichannel audio, Bitstream audio, PCM audio

)

Analog input 20Hz~20kHz (±3dB)

Digital input 20Hz~40kHz (±-4dB)

06 Other Information

English 71

HT-D5100_XAA_1224.indd 71HT-D5100_XAA_1224.indd 71 2011-12-24  12:31:512011-12-24  12:31:51

Other Information

Speaker system

Impedance 3 Ω 3 Ω 3 Ω 3 Ω

Frequency range 140Hz~20kHz 140Hz~20kHz 140Hz~20kHz 40Hz ~ 160Hz

Output sound pressure level 86dB/W/M 86dB/W/M 86dB/W/M 88dB/W/M

Speaker

- Samsung Electronics Co., Ltd reserves the right to change the speciﬁ cations without notice.

- Weight and dimensions are approximate.

- Design and speciﬁ cations are subject to change without prior notice.

- Dispose unwanted electronics through an approved recycler. To ﬁ nd the nearest recycling location, go to our website: www.samsung.com/recyclingdirect Or call, (877) 278 - 0799

Rated input 165W 165W 170W 170W

Maximum input 330W 330W 340W 340W

Dimensions (W x H x D)

Weights

Front Surround Center Subwoofer

Front : 3.54 x 5.5 x 2.75 inches Surround : 3.54 x 5.5 x 2.75 inches Center : 8.97 x 3.03 x 2.75 inches Subwoofer : 6.61 x 13.78 x 11.22 inches

Front : 0.94 Ibs, Surround : 0.94 Ibs Center : 1.06 Ibs, Subwoofer : 8.38 Ibs

5.1ch speaker system

*: Nominal speciﬁ cation

72 English

HT-D5100_XAA_1224.indd 72HT-D5100_XAA_1224.indd 72 2011-12-24  12:31:512011-12-24  12:31:51

Español

Aviso de Cinavia: Este producto utiliza tecnología

Cinavia para limitar el uso de copias no autorizadas de algunas películas de producción comercial, videos y sus bandas sonoras. Cuando se detecta el uso de una copia no autorizada, aparecerá un mensaje y se interrumpirá la reproducción o la copia. Información adicional sobre la tecnología Cinavia se facilita en el Centro de información al cliente en línea de Cinavia en http://www.cinavia.com. Para solicitar información adicional sobre Cinavia por correo, envíe una tarjeta con su dirección postal a: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, EE.UU. Este producto incorpora tecnología de propietario bajo licencia de Verance Corporation y está protegido mediante la patente en EE.UU.

7.369.677 y otras patentes en EE.UU. y en otros países pendientes, así como por copyright y la protección de secreto comercial de ciertos aspectos tecnológicos. Cinavia es una marca comercial de Verance Corporation. Copyright 2004-2010 Verance Corporation. Todos los derechos reservados por Verance. La ingeniería inversa o desensamblaje están prohibidos.

Français

Avis Cinavia : Ce produit utilise la technologie Cinavia

pour limiter l’utilisation de copies illégales de certains lms et vidéos disponibles dans le commerce et de leur bande sonore. Lorsqu’une utilisation illégale ou une reproduction interdite est détectée, un message s’afche et la lecture ou la reproduction s’interrompt. De plus amples renseignements sur la technologie Cinavia sont disponibles auprès du Centre d’information des consommateurs en ligne de Cinavia sur http://www.cinavia.com. Pour obtenir des renseignements supplémentaires par la poste sur Cinavia, envoyez votre demande avec votre adresse au : Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA. Ce produit intègre une technologie sous licence de Verance Corporation protégée par le brevet américain 7,369,677 et d'autres brevets américains et internationaux déposés ou en attente, de même que par des droits d'auteur et le secret industriel pour certains aspects de cette technologie. Cinavia est une marque de commerce de Verance Corporation. Copyright 2004-2010 Verance Corporation. Tous droits réservés par Verance. Il est interdit de tenter de démonter l’appareil et d’en étudier le fonctionnement en vue de le reproduire.

Português

Nota da Cinavia: Esse produto usa tecnologia

Cinavia para limitar o uso de cópias não autorizadas de lmes e vídeos produzidos comercialmente e sua trilha sonora. Quando se detecta o uso proibido de uma cópia não autorizada, aparece uma mensagem e a reprodução ou cópia é interrompida. Há mais informações sobre a tecnologia Cinavia na Central Cinavia on-line de informações ao cliente, em http://www.cinavia.com. Para solicitar mais informações sobre a Cinavia pelo correio, envie um cartão postal com seu endereço para: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Esse produto incorpora tecnologia proprietária sob licença da Verance Corporation e protegida pela Patente 7.369.677 dos EUA e outras patentes nos EUA e no mundo todo, emitidas e pendentes, além de direitos autorais e proteção ao segredo comercial de certos aspectos dessa tecnologia. Cinavia é uma marca registrada da Verance Corporation. Copyright 2004-2010 Verance Corporation. Todos os direitos reservados à Verance. É proibido realizar engenharia reversa ou desmontagem.

English

limit the use of unauthorized copies of some commercially-produced film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be in interrupted. More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA. This product incorporates proprietary technology under license from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004 - 2010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

Cinavia Notice : This product uses Cinavia technology to

Français

Avis de Cinavia : Ce produit utilise la technologie

Cinavia pour limiter l'utilisation de copies non autorisées de certains lms et vidéos commerciaux ainsi que leurs bandes son. Lorsqu'une copie non autorisée est détectée, un message est afché et la lecture ou la copie est interrompue. Des informations complémentaires concernant la technologie Cinavia sont disponibles sur le site http:// www.cinavia.com du Centre d'information consommateur Cinavia. Pour toute demande d'informations complémentaires concernant Cinavia par courrier, veuillez écrire à l'adresse suivante : Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Ce produit intègre la technologie de protection de la propriété sous licence Verance Corporation protégée par les brevets américains 7,369,677 et d’autres brevets américains et internationaux accordés et en attente ainsi que la protection des droits d'auteur et de l'information commerciale condentielle pour certains aspects de cette technologie. Cinavia est une marque commerciale de Verance Corporation. Copyright 2004-2010 Verance Corporation. Tous droits réservés par Verance. Il est interdit de tenter de démonter l’appareil et d’en étudier le fonctionnement en vue de le reproduire.

Italiano

Avvertenza Cinavia : Questo prodotto utilizza

tecnologia Cinavia per limitare l'uso di copie non autorizzate di lm e video commerciali e relative tracce audio. Se viene rilevato l'uso proibito di una copia non autorizzata, viene visualizzato un messaggio che interrompe la riproduzione o la copia. Per maggiori informazioni sulla tecnologia Cinavia consultare il centro online di informazioni ai consumatori di Cinavia all'indirizzo http://www.cinavia.com. Per richiedere maggiori informazioni su Cinavia per e-mail, inviare un messaggio con il proprio indirizzo a: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Questo prodotto è dotato di tecnologia proprietaria di Verance Corporation ed è protetto dal brevetto U.S.A. 7.369.677 e da altri brevetti U.S.A. e di altri Paesi registrati e in attesa di registrazione, di una protezione del copyright e del segreto aziendale per alcuni aspetti di tale tecnologia. Cinavia è un marchio di Verance Corporation. Copyright 2004-2010 Verance Corporation. Verance. Tutti i diritti riservati. Sono vietati il reverse engineering o lo smontaggio.

Português

Aviso Cinavia : Este produto utiliza tecnologia Cinavia

para limitar a utilização não autorizada de cópias de alguns lmes e vídeos produzidos comercialmente e respectivas bandas sonoras. Quando a utilização proibida de uma cópia não autorizada é detectada, é apresentada uma mensagem e a reprodução ou cópia é interrompida. Poderá obter mais informações sobre a tecnologia Cinavia no Centro de Informação ao Consumidor Online da Cinavia em http://www.cinavia. com. Para solicitar informações adicionais sobre a Cinavia por correio, envie um bilhete postal com a sua morada para: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Este produto incorpora tecnologia proprietária ao abrigo da licença da Verance Corporation e protegida pela patente americana, 7,369,677 e outras patentes dos EUA e de outros países, emitidas ou cuja aprovação esteja pendente, bem com direitos de autor e protecção de segredo comercial para determinados aspectos da tecnologia mencionada. A Cinavia é uma marca comercial da Verance Corporation. Direitos de autor 2004-2010 Verance Corporation. Todos os direitos reservados pela Verance. É proibido qualquer procedimento de desmontagem ou montagem.

Español

Aviso de Cinavia : Este producto utiliza tecnología

Cinavia para limitar el uso de copias no autorizadas de algunas películas de producción comercial, vídeos y sus bandas sonoras. Cuando se detecta el uso de una copia no autorizada, aparecerá un mensaje y se interrumpirá la reproducción o la copia. Información adicional sobre la tecnología Cinavia se facilita en el Centro de información al cliente en línea de Cinavia en http://www.cinavia.com. Para solicitar información adicional sobre Cinavia por correo, envíe una tarjeta con su dirección postal a: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, EE.UU. Este producto incorpora tecnología de propietario bajo licencia de Verance Corporation y está protegido mediante la patente en EE.UU.

Nederlands

Opmerking betreffende Cinavia : Dit product

maakt gebruik van Cinavia-technologie om het gebruik van illegale exemplaren van sommige commercieel geproduceerde lms en video's en de soundtracks ervan te beperken. Wanneer wordt gedetecteerd dat een illegale kopie wordt gebruikt, wordt een bericht weergegeven en zal het afspelen of kopiëren worden onderbroken. U vindt meer informatie over Cinavia-technologie bij het Cinavia Online Consumer Information Centre op http://www.cinavia.com. Als u aanvullende informatie over Cinavia via de post wenst te ontvangen, stuurt u een postkaart met uw postadres naar: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Dit product omvat bedrijfseigen technologie onder licentie van de Verance Corporation en wordt beschermd door U.S. Patent 7.369.677 en andere Amerikaanse en internationale patenten die zijn verstrekt of nog in behandeling zijn, naast de bescherming van copyrights en bedrijfsgeheimen voor bepaalde aspecten van dergelijke technologie. Cinavia is een handelsmerk van Verance Corporation. Copyright 2004-2010 Verance Corporation. Alle rechten voorbehouden door Verance. Reverseengineering of demontage is verboden.

Dansk

Bemærkning vedr. Cinavia : Dette produkt anvender

Cinavia-teknologi til begrænsning af ikkeautoriseret kopiering af visse kommercielt producerede lm og videoer samt deres lydspor. Når forbudt anvendelse af en ikke-autoriseret kopi detekteres, vises en meddelelse, og afspilning eller kopiering bliver afbrudt. Flere informationer om Cinavia-teknologi fås hos Cinavias onlineforbrugerinformationscenter på http:// www.cinavia.com. For at få ere informationer om Cinavia pr. post kan du sende et postkort med din postadresse til: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Dette produkt anvender producentspecik teknologi under licens fra Verance Corporation og er beskyttet af USA-patent 7.369.677 og andre USA- og vendensomfattende patenter, både allerede udstedte og under ansøgning, samt copyright og beskyttelse af handelshemmeligheder for visse dele af sådan teknologi. Cinavia er et varemærke tilhørende Verance Corporation. Copyright 2004-2010 Verance Corporation. Alle rettigheder forbeholdes Verance. Reverse engineering eller adskillelse er forbudt.

Suomi

Cinavia-ilmoitus: Tämä tuote käyttää Cinavia-

tekniikkaa rajoittaakseen joidenkin kaupallisesti tuotettujen elokuvien ja videoiden sekä niiden ääniraitojen luvattomien kopioiden käyttöä. Kun luvattoman kopion kielletty käyttö tunnistetaan, viesti tulee näkyviin ja toisto tai kopiointi keskeytetään. Saat lisätietoja Cinavia-tekniikasta Cinavia Online Consumer Information Centre -kuluttajakeskuksesta osoitteessa http://www.cinavia.com. Voit pyytää lisätietoja Cinaviasta postitse lähettämällä postikortin, joka sisältää postiosoitteesi, osoitteeseen: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Tässä tuotteessa käytetään valmistajien tekniikkaa Verance Corporationin lisenssillä. Käyttöä suojaavat USA:n patentin 7,369,677 ja muut USA:n sekä maailmanlaajuiset myönnetyt ja vireillä olevat patentit sekä tiettyjen tekniikan osien tekijänoikeus- ja kauppasalaisuussuojat. Cinavia on Verance Corporationin tavaramerkki. Copyright 2004-2010 Verance Corporation. Verance pidättää kaikki oikeudet. Käytetyn salaustekniikan purkaminen on kielletty.

Norsk

Cinavia-merknad : Dette produktet bruker Cinavia-

teknologi for å begrense bruken av uautoriserte kopier av enkelte kommersielt produserte lmer, videoer og deres lydspor. Når det detekteres forbudt bruk av en uautorisert kopi, vises en melding og avspillingen eller kopieringen vil bli avbrutt. Mer informasjon om Cinaviateknologien nner du hos Cinavias forbrukersenter på http://www. cinavia. com. For mer informasjon om Cinavia via regulær post, send et postkort med din postadresse til: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Dette produktet innbefatter proprietær teknologi på lisens fra Verance Corporation og er beskyttet av amerikansk patent 7,369,677 og andre amerikanske og verdensomfattende patenter og patentsøknader, samt beskyttelse av copyright og forretningshemmeligheter for visse aspekter av slik teknologi. Cinavia er et varemerke som tilhører Sony Corporation. Copyright 2004-2010 Verance Corporation. Alle rettigheter forbeholdt for Verance. Omvendt utvikling eller demontering er forbudt.

Svenska

Cinavia-meddelande : Den här produkten använder

Cinavia-teknik för att begränsa antalet obehöriga kopior på vissa kommersiellt producerade lmer och videor och deras ljudspår. Om en förbjuden användning av en obehörig kopia upptäcks visas ett meddelande och uppspelningen eller kopieringen avbryts. Mer information om Cinavia-tekniken erbjuds av Cinavia Online Consumer Information Centre på adressen http://www.cinavia.com. För att begära ytterligare information om Cinavia via post, skicka ett vykort med din adress till: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Den här produkten införlivar egendomsteknik på licens från Verance Corporation och skyddas av det amerikanska patentet 7,369,677 och andra patent i USA och internationellt och väntande patent, samt upphovsrätt och varumärkesskydd för vissa delar av sådan teknik. Cinavia är ett varumärke som tillhör Verance Corporation. Upphovsrätt 2004-2010 Verance Corporation. Med ensamrätt för Verance. Reverse engineering och nedmontering är förbjudet.

Česky

Upozornění k technologii Cinavia : Tento

přístroj využívá technologii Cinavia k omezení použití neoprávněných kopií některých komerčních lmů a videí a jejich zvukových stop. Při zjištění zakázaného použití neautorizované kopie se zobrazí hlášení a přehrávání nebo kopírování je přerušeno. Další informace o technologii Cinavia naleznete v Online středisku informací pro spotřebitele na webu http://www.cinavia.com. Další informace o technologii Cinavia si můžete vyžádat také poštou. Pošlete svou korespondenční adresu na adresu: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Tento přístroj využívá proprietární technologii licencovanou společností Verance Corporation a je chráněn patentem USA č. 7 369 677 a dalšími vydanými a přihlášenými patenty ve Spojených státech amerických a dalších zemích. Na některé aspekty této technologie se také vztahuje ochrana autorských práv a obchodního tajemství. Cinavia je ochranná známka společnosti Verance Corporation. Copyright 2004-2010 Verance Corporation. Všechna práva vyhrazena společností Verance. Zpětná analýza a převod do strojového kódu jsou zakázány.

Deutsch

Cinavia Hinweise : Dieses Gerät nutzt die Cinavia

Technologie um die Erstellung illegaler Kopien kommerziell produzierter Filme und Videos sowie deren Soundtracks zu verhindern. Wenn die verbotene Nutzung einer illegalen Kopie festgestellt wird, erscheint eine Meldung und die Wiedergabe bzw. der Kopiervorgang werden abgebrochen. Mehr Informationen über die Cinavia Technologie nden Sie im Online Kundeninformationszentrum unter http://www.cinavia. com. Wenn Sie zusätzliche Informationen über Cinavia über E-Mail erhalten möchten, senden Sie bitte eine Postkarte mit Ihrer E-Mail Adresse an: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Dieses Gerät nutzt geschützte Technologie unter der Lizenz von Verance Corporation und ist durch das U.S. Patent 7.369.677 und andere in der USA und weltweit ausgestellten & angemeldeten Patenten sowie durch die Urheberrechte und die Sicherung von Betriebsgeheimnissen bestimmter Aspekte dieser Technologie geschützt. Cinavia ist eine Handelsmarke von Verance Corporation. Copyright 2004-2010 Verance Corporation. Alle Rechte vorbehalten für Verance Reverse Engineering oder Demontage sind verboten.

Magyar

Cinavia gyelmeztetés : A készülék a

Cinavia technológiáját használja a kereskedelmi forgalomban lévő lmek és videók, valamint hangsávjaik illetéktelen másolásának megakadályozására. Ha illetéktelen másolat tiltott használatát érzékeli, a készülék megjelenít egy üzenetet, és a lejátszás vagy másolás félbeszakad. A Cinavia technológiáról további információkat a Cinavia Online ügyfélszolgálaton kaphat a http:// www.cinavia.com címen. További információk a Cinaviáról postai úton küldjön egy levelezőlapot a postacímével a következő címre: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. A termék egy szerzõi jogvédelmi technológiát alkalmaz, mely eljárást a Verance Corporation birtokol, és az USA-ban bejegyzett 7,369,677 számú szabadalom, illetve más, az USÁban és máshol bejegyzett szabadalmak és szerzõi jogok védenek, és az ilyen technológiákra vonatkozó kereskedelmi titkok. A Cinavia a Verance Corporation védjegye. Copyright 2004-2010 Verance Corporation. A Verance minden jogot fenntart. A rendszer visszafejtése vagy visszafordítása tilos.

Polski

Komentarz Cinavia : Urządzenie to korzysta z

technologii Cinavia w celu ograniczenia wykorzystania nieupoważnionych kopii pewnych lmów i obrazów wideo wyprodukowanych w celach komercyjnych, oraz ich ścieżek dźwiękowych. W przypadku wykrycia zakazanego użycia nieautoryzowanej kopii, zostanie wyświetlony komunikat i proces odtwarzania i kopiowania zostanie zatrzymany. Więcej informacji o technologii Cinavia można uzyskać w Centrum obsługi klienta Cinavia online: http:// www.cinavia.com. Aby poprosić o przesłanie dodatkowych informacji o Cinavia pocztą, wyślij kartkę ze swoim adresem pocztowym na adres: Centrum informacji konsumenta Cinavia, P.O. Box 86851, San Diego, CA, 92138, USA. Urządzenie to zostało wyprodukowane z zastosowaniem technologii własnościowej na licencji rmy Verance Corporation, i jest chronione amerykańskim patentem 7,369,677 oraz innymi patentami Stanów Zjednoczonych i innych krajów, wydanymi i wydawanymi, oraz prawami autorskimi, a także chroniony tajemnicą handlową obejmującą określone aspekty takiej technologii. Cinavia jest znakiem towarowym rmy Verance Corporation. Copyright 2004–2010 Verance Corporation. Wszystkie prawa zastrzeżone przez rmę Verance. Niedozwolone jest odtwarzanie wsteczne (ang. reverse engineering) i rozmontowywanie urządzenia.

Slovensky

Upozornenie na technológiu Cinavia : Tento

výrobok využíva technológiu Cinavia na obmedzenie používania neoprávnených kópií niektorých komerčne vyrábaných lmov a videí a ich zvukových záznamov. Keď sa zistí, že došlo k zakázanému použitiu neoprávnenej kópie, zobrazí sa správa a prehrávanie alebo kopírovanie sa preruší. Viac informácií o technológií Cinavia nájdete na on-line informačnom centre pre spotrebiteľov Cinavia na lokalite http://www.cinavia.com. Ak chcete požiadať o zaslanie ďalších informácií o technológii Cinavia poštou, zašlite list s vašou poštovou adresou na adresu: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Tento výrobok obsahuje súkromnú technológiu na základe licencie od spoločnosti Verance Corporation, ktorá je chránená americkým patentom č. 7 369 677 a ďalšími patentmi a patentovými prihláškami v USA a na celom svete, pričom niektoré aspekty tejto technológie podliehajú aj ochrane autorským právom a ochrane obchodného tajomstva. Cinavia je obchodná značka spoločnosti Verance Corporation. Autorské práva 2004 - 2010 Verance Corporation. Spoločnosť Verance si vyhradzuje všetky práva. Spätná analýza alebo prevod do strojového kódu sú zakázané.

Slovenščina

Obvestilo o tehnologiji Cinavia: Ta izdelek

uporablja tehnologijo Cinavia za omejitev uporabe nepooblaščenih kopij nekaterih komercialno posnetih lmov in videoposnetkov ter njihovih zvočnih posnetkov. Kadar naprava zazna uporaba nepooblaščene kopije, se bo prikazalo sporočilo in predvajanje ali kopiranje se bo prekinilo. Več informacij o tehnologiji Cinavia najdete v spletnem informacijskem središču za stranke Cinavia na http://www.cinavia.com. Če želite prejeti dodatne informacije o tehnologiji Cinavia po pošti, nam pošljite svoj domači naslov na: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Ta izdelek vsebuje lastniško tehnologijo z licenco družbe Verance Corporation in je zaščiten z ameriškim patentom 7,369,677 ter drugimi izdanimi ali vloženimi ameriškimi in svetovnimi patenti, kot tudi z zakoni o varstvu pravic in nerazkrivanju poslovnih skrivnosti za določene vidike takšne tehnologije. Cinavia je blagovna znamka družbe Verance Corporation. Avtorske pravice 2004-2010 Verance Corporation. Vse pravice si pridržuje družba Verance. Obratno inženirstvo in razstavljanje sta prepovedana.

Български

Бележка за Cinavia : Този продукт използва

технологията Cinavia, за да ограничи използването на неоторизирани копия на някои филми, видеоклипове и саундтраци. Когато се засече забранено ползване на неоторизирано копие, ще се покаже съобщение и възпроизвеждането или копирането ще се прекъсне. Повече информация за технологията Cinavia се предоставя от онлайн центъра за информация за клиенти на Cinavia на http://www.cinavia.com. За да поискате допълнителна информация от Cinavia по пощата, изпратете запитванията с вашия пощенски адрес на: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Този продукт използва фирмена технология под лиценз от Verance Corporation и е защитен с патент на САЩ 7,369,677 и други издадени и заявени патенти в САЩ и по целия свят, както и от защита на авторското право и търговските тайни за определени аспекти от такава технология. Cinavia е търговска марка на Verance Corporation. Copyright 2004-2010 Verance Corporation. Всички права запазени от Verance. Забранен е инженеринг или демонтиране в обратен ред.

Română

Notă din partea Cinavia : Acest aparat utilizează

tehnologie Cinavia pentru a limita utilizarea unor copii neautorizate ale unor lme sau materiale video produse spre comercializare, precum şi a coloanelor sonore asociate acestora. Dacă este detectată utilizarea ilegală sa unei copii neautorizate, va  aşat un mesaj şi redarea sau copierea este întreruptă. Pentru informaţii suplimentare despre tehnologia Cinavia, consultaţi Centrul online de informaţii pentru consumatori Cinavia, la adresa http://www.cinavia.com. Pentru a solicita prin poştă informaţii suplimentare despre Cinavia, trimiteţi un plic timbrat cu adresa dvs. la: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Acest aparat încorporează tehnologie de proprietate sub licenţă de la Verance Corporation şi este protejat de către brevetul SUA 7.369.677 şi de către alte brevete din SUA şi din întreaga lume emise şi în curs de emitere, precum şi de către legea drepturilor de autor şi a secretului comercial privind anumite aspecte ale acestei tehnologii. Cinavia este o marcă comercială a Verance Corporation. Copyright 2004-2010 Verance Corporation. Toate drepturile sunt rezervate de Verance. Este interzisă demontarea sau dezasamblarea produsului.

Ελληνικά

Ειδοποίηση τεχνολογίας Cinavia : Αυτό το

προϊόν χρησιμοποιεί τεχνολογία Cinavia για τον περιορισμό της χρήσης μη εξουσιοδοτημένων αντιγράφων ορισμένων ταινιών και βίντεο που διατίθενται στο εμπόριο, καθώς και της ηχητικής επένδυσής τους. Αν ανιχνευτεί απαγορευμένη χρήση ενός μη εξουσιοδοτημένου αντιγράφου, εμφανίζεται ένα μήνυμα και διακόπτεται η αναπαραγωγή ή αντιγραφή. Περισσότερες πληροφορίες για την τεχνολογία Cinavia παρέχονται στο Διαδικτυακό κέντρο πληροφόρησης πελατών της Cinavia, στη διεύθυνση http://www.cinavia.com. Για να ζητήσετε πρόσθετες πληροφορίες σχετικά με την τεχνολογία Cinavia μέσω ταχυδρομείου, στείλτε μια κάρτα με την ταχυδρομική διεύθυνσή σας στο: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Το προϊόν αυτό ενσωματώνει αποκλειστική τεχνολογία που χρησιμοποιείται κατόπιν αδείας από τη Verance Corporation, η οποία προστατεύεται από το δίπλωμα ευρεσιτεχνίας Η.Π.Α. με αριθμό 7.369.677 και άλλα διπλώματα ευρεσιτεχνίας που έχουν εκδοθεί και εκκρεμούν στις Η.Π.Α. και διεθνώς, καθώς και από προστασία πνευματικών δικαιωμάτων και εμπορικών μυστικών για ορισμένα στοιχεία της συγκεκριμένης τεχνολογίας. Η επωνυμία Cinavia είναι εμπορικό σήμα της Verance Corporation. Πνευματικά δικαιώματα 2004-2010 Verance Corporation. Με την επιφύλαξη παντός δικαιώματος από τη Verance. Απαγορεύεται η αποσυμπίληση ή ανακατασκευή κώδικα.

Hrvatski

Obavijest o tehnologiji Cinavia : ovaj proizvod rabi

tehnologiju Cinavia kako bi se ograničila uporaba neovlaštenih kopija nekih komercijalno proizvedenih lmova i videozapisa i njihovih zvučnih zapisa. Kada se otkrije zabranjena uporaba neovlaštene kopije, prikazat će se poruka i prekinut će se reproduciranje i kopiranje. Ostale informacije o tehnologiji Cinavia dostupne su u mrežnom informacijskom centru za korisnike tvrtke Cinavia na http://www.cinavia. com. Kako biste zatražili dodatne informacije o tehnologiji Cinavia putem pošte, pošaljite nam dopis na poštansku adresu: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, SAD. Ovaj proizvod sadržava zakonom zaštićenu tehnologiju pod licencom korporacije Verance i zaštićen je američkim patentom 7,369,677 i ostalim američkim i svjetskim patentima koji su izdanje i čije je izdanje u tijeku, kao i zaštitama autorskih prava i poslovnih tajni za određene aspekte te tehnologije. Cinavia je zaštitni znak korporacije Verance. Autorsko pravo 2004-2010 Verance Corporation. Sva prava pridržava Verance. Zabranjeni su obrnuti inženjering i rastavljanje.

Srpski

Cinavia obaveštenje : Ovaj proizvod koristi

Cinavia tehnologiju za ograničenje upotrebe neovlašćenih kopija nekih komercijalno proizvedenih lmova i video zapisa i zvučnih zapisa. Kada se otkrije upotreba neovlašćene kopije, prikazaće se poruka i reprodukcija ili kopiranje će biti prekinuto. Više informacija o Cinavia tehnologija dostupne su na internet informacionom centru za potrošače Cinavia na adresi http://www.cinavia. com. Da biste zatražili dodatne informacije o Cinavia-i putem pošte, pošaljite razglednicu sa vaše e-adrese: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, SAD. Ovaj proizvod sadrži tehnologiju u vlasništvu pod licencom kompanije Verance Corporation i zaštićen je američkim patentom 7,369,677 i drugim američkim i svetskim patentima koji su potvrđeni ili su na čekanju, kao i zaštitom autorskih prava i poslovne tajne za određene aspekte takve tehnologije. Cinavia je zaštitni znak kompanije Verance Corporation. Copyright 2004-2010 Verance Corporation. Sva prava zadržana od strane kompanije Verance. Reinženjering ili demontaža su zabranjeni.

Қазақша

Cinavia ескертуі : Бұл өнімде коммерциялық

фильм мен бейнелердің және олардың саунд-тректерінің рұқсатсыз көшірмелерін шектеу үшін Cinavia технологиясы пайдаланылады. Пайдалануға тыйым салынған рұқсатсыз көшірмені пайдалану анықталса, хабар көрсетіледі және ойнату немесе көшіру үзіледі. Cinavia технологиясы туралы қосымша ақпарат http : //www.cinavia.com торабындағы Cinavia желілік тұтынушылар туралы ақпарат орталығында берілген. Cinavia туралы қосымша ақпаратты пошта арқылы сұрау үшін пошта мекенжайыңыз бар ашықхатты мына мекенжайға жіберіңіз : Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Бұл Verance корпорациясының лицензиясы бар жекеменшік технологияны қамтиды және АҚШ-тың 7,369,677 патентімен, әрі шығарылған және күтудегі басқа АҚШ және дүниежүзілік патенттермен, сондай-ақ, авторлық құқықтармен және осындай технологияның белгілі бір жақтарын құпия қорғаныспен қорғалған. Cinavia – Verance корпорациясының сауда белгісі. Авторлық құқықтар, 2004-2010 Verance корпорациясы. Барлық құқықтар Verance корпорациясымен қорғалған. Кері жобалауға және бөлшектеуге тыйым салынады.

Русский

Уведомление о Cinavia: Данный продукт оснащен

технологией Cinavia, которая не позволяет использовать незаконно сделанные копии серийно изготавливаемых записей фильмов и видео, а также музыку из этих фильмов и видео. В случае обнаружения использования незаконно сделанной копии на экране появится соответствующее сообщение, и процесс воспроизведения или копирования будет прерван. Дополнительные сведения о технологии Cinavia представлены на сайте Центра информации для потребителей Cinavia по адресу: http://www.cinavia.com. Чтобы запросить дополнительные сведения о технологии Cinavia по почте, отправьте нам открытку с вашим почтовым адресом: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. Данный продукт оснащен запатентованной технологией с лицензией от Verance Corporation и защищенной патентом США 7,369,677 и другими патентами США и международными патентами, изданными и рассматриваемыми, а определенные аспекты этой технологии – авторскими правами и охраной секретов производствам. Cinavia является товарным знаком корпорации Verance Corporation. Verance Corporation, 20042010 гг. Все права защищены корпорацией Verance. Инженерный анализ и разборка запрещены.

Українська

Зауваження щодо Cinavia: у цьому продукті

використовується технологія Cinavia, що обмежує використання несанкціонованих копій деяких комерційних кінофільмів і відеозаписів, а також використаних у них звукових доріжок. У разі виявлення забороненого використання несанкціонованої копії, відобразиться відповідне повідомлення, а відтворення або копіювання буде призупинено. Додаткові відомості про технологію Cinavia можна знайти в Інформаційному онлайн-центрі Cinavia за веб-адресою http://www.cinavia.com. Щоб надіслати запит на отримання додаткової інформації про Cinavia поштою, надішліть поштову листівку зі своєю поштовою адресою на таку адресу: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. У цьому продукті використано запатентовану технологію, ліцензовану компанії Verance Corporation і захищену патентом США 7 369 677 та іншими всесвітніми патентами, виданими та такими, що очікують затвердження, а також авторським правом і принципами охорони таємниць виробництва певних аспектів цієї технології. Cinavia є торговельною маркою Verance Corporation. Авторське право належить корпорації Verance Corporation, 2004-2010 рр. Усі права належать корпорації Verance. Забороняється вносити зміни до конструкції продукту або розбирати його.

繁體中文

Cinavia 聲明：本產品使用 Cinavia 技術來限制使用某些商業製造的電影和視訊及其聲道的未經授權副本。當偵測到禁止使用的未經授權副本時，將會顯示一則訊息，並且播放或複製動作將會中斷。 Cinavia 技術的詳細資訊在 Cinavia 線上消費者資訊中心中提供，網址為：http://www. cinavia.com。若要透過郵件請求關於 Cinavia 的其他資訊，請將含有您的郵寄地址的明信片寄往：Cinavia

Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA.

本产品融合了在获得 Verance Corporation 许可并且受美国专利 7,369,677 以及其他在盖和世界各地已公布和正在申请的专利保护，并且受此类技术特定方面的版权和商业秘密保护。

保留一切权利。严禁进行逆向工程和反汇编。

中国语

Cinavia 声明：本产品使用 Cinavia 技术来限制使用一些商业制造的电影和视频及其声道的未获得授权的副本。检测到禁止使用未获得授权的副本的情况时，将会显示消息，并且播放或复制将会中断。有关 Cinavia 技术的更多信息，在 Cinavia 在线消费者信息中心提供，网址如下：http://www. cinavia.com。要通过邮件请求关于 Cinavia 的更多信息，请将含有您的邮寄地址的明信片寄往：Cinavia

Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. 本产品融合了在获得 Verance Corporation 许可并且受美国专利 7,369,677 以及其他在盖和世界各地已公布和正在申请的专利保护

，并且受此类技术特定方面的版权和商业秘密保护。

保留一切权利。严禁进行逆向工程和反汇编。

תירבע

הודעה בנוגע ל-Cinavia : מוצר זה משתמש

בטכנולוגית Cinavia כדי להגביל את השימוש בהעתקים בלתי חוקיים של סרטים בהפקה מסחרית ופסי הקול שלהם. כאשר יזוהה שימוש אסור בעותק בלתי חוקי, תוצג על כך הודעה וכל הפעלה או העתקה יופסקו. מידע נוסף אודות טכנולוגית Cinavia ניתן למצוא במרכז המידע המקוון לצרכן של Cinavia בכתובת http://www.cinavia.com. לקבלת מידע נוסף אודות Cinavia בדואר, שלח גלויה עם כתובתך אל: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. מוצר זה משלב טכנולוגיה קניינית תחת רישיון מטעם תאגיד Verance והוא מוגן על ידי פטנט אמריקאי 7,369,677 ופטנטים אמריקאים ועולמיים אחרים שהתקבלו או שהם עומדים ותלויים, כמו גם על ידי הגנה על זכויות יוצרים וסודות מסחריים עבור הבטים מסוימים של טכנולוגיה כזו. Cinavia הוא סמל מסחרי של תאגיד Verance. זכויות יוצרים 2004 - 2010 תאגיד Verance. כל הזכויות שמורות ל-Verance. חל איסור לבצע הנדסה לאחור או פירוק המוצר.

Thai

ประกาศเกี่ยวกับ Cinavia :

ผลิตภัณฑ์นี้ใช้เทคโนโลยี Cinavia เพื่อจำกัดการใช้งานแผ่น ที่ไม่ได้รับอนุญาตของฟิล์มและวิดีโอและแทร็กเสียงที่ผลิตม าเพื่อการค้าบางแผ่น เมื่อพบการใช้งานต้องห้ามของแผ่นที่ไ ม่ได้รับอนุญาต ข้อความจะปรากฏขึ้นและการเล่นหรือการคัด ลอกจะหยุดทำงาน

ข้อมูลเพิ่มเติมเกี่ยวกับเทคโนโลยี Cinavia มีให้ที่ศูนย์ ข้อมูลลูกค้าทางออนไลน์ของ Cinavia ที่ http://www. cinavia.com หากต้องการขอรับข้อมูลเพิ่มเติมเกี่ยวกับ Cinavia ทางไปรษณีย์ ส่งโปสการ์ดที่มีที่อยู่ของคุณไป ที่: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA ผลิตภัณฑ์นี้รวมเอาเทคโนโลยีเอกสิทธิ์เฉพาะภายใต้การอ นุญาตจาก Verance Corporation และได้รับความคุ้มครอง โดยสิทธิบัตรสหรัฐฯ เลขที่ 7,369,677 และสิทธิบัตรสหรัฐ ฯ อื่นๆ และทั่วโลกที่ประกาศแล้วและรอการพิจารณา รวม ทั้งลิขสิทธิ์และการป้องกันความลับทางการค้าในบางด้าน ของเทคโนโลยีดังกล่าว Cinavia เป็นเครื่องหมายการค้าข อง Verance Corporation ลิขสิทธิ์ 2004-2010 Verance Corporation สงวนสิทธิ์ทั้งหมดโดย Verance ห้ามดำเนิน การทางวิศวกรรมย้อนกลับหรือถอดชิ้นส่วนผลิตภัณฑ์

Türkçe

Cinavia Notice : This product uses Cinavia technology

to limit the use of unauthorized copies of some commercially-produced lm and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be interrupted. More information about Cinavia technology is provided at the Cinavia Online Consumer Information Centre at http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your mailing address to: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. This product incorporates proprietary technology under licence from Verance Corporation and is protected by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation. Copyright 2004-2010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly is prohibited.

Indonesia

Pemberitahuan Cinavia : Produk ini menggunakan

teknologi Cinavia untuk membatasi penggunaan tanpa izin salinan lm dan video tertentu yang diproduksi secara komersial serta soundtracknya. Apabila penggunaan salinan tanpa izin yang dilarang terdeteksi, pesan akan ditampilkan dan pemutaran atau penyalinan akan dihentikan. Informasi selengkapnya tentang teknologi Cinavia tersedia di Pusat Informasi Pelanggan Online Cinavia di http://www.cinavia.com. Untuk meminta informasi tambahan mengenai Conavia melaui pos, kirimkan kartu pos dengan alamat surat Anda ke: Cinavia Consumer Information Centre,P.O.Box 86851, San Diego, CA, 92138, USA. Produk ini menerapkan teknologi milik sendiri berdasarkan lisensi dari Verance Corporation dan dilindungi oleh Paten AS 7,369,677 dan paten AS dan di seluruh dunia lainnya yang terdaftar dan dalam pendaftaran, serta perlindungan hak cipta dan rahasia dagang atas aspek tertentu dari teknologi tersebut. Cinavia adalah merek dagang dari Verance Corporation. Hak Cipta 2004-2010 Verance Corporation. Semua hak dimiliki oleh Verance. Rekayasa balik atau pembongkaran dilarang.

Tiếng Việt

Thông bao cua Cinavia:

San phâm nay sư dung công nghê Cinavia đê han chê viêc sư dung cac ban sao trai phep môt sô bô phim va video đươc san xuât thương mai va cac đoan âm thanh cua chung. Khi bi phat hiên sư dung ban sao trai phep, môt thông bao se đươc hiên thi va viêc phat lai hoăc sao chep se bi gian đoan. Thông tin khac vê công nghê Cinavia đươc cung câp tai Trung tâm thông tin danh cho ngươi tiêu dung trưc tuyên Cinavia ơ đia chi http://www.cinavia.com. Đê yêu câu thông tin khac vê Cinavia qua thư, hay gưi môt danh thiêp kem theo đia chi nhân thư cua ban đên: Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. San phâm nay tich hơp công nghê đôc quyên theo giây phep cua Verance Corporation va đươc bao hô bơi Băng sang chê Hoa Ky 7,369,677 va cac băng sang chê cua Hoa Ky va trên toan thê giơi khac đa đươc câp va đang chơ câp cung như sư bao vê bi mât thương mai va ban quyên đôi vơi cac khia canh cu thê cua công nghê đo. Cinavia la nhan hiêu cua Verance Corporation. Ban quyên 2004-2010 Verance Corporation. Moi quyên đươc bao lưu bơi Verance. Nghiêm câm thiêt kê đôi chiêu va thao rơi san phâm.

ΔϴΑήόϟ΍ΔϐϠϟ΍

LIMITED WARRANTY TO ORIGINAL PURCHASER

This SAMSUNG brand product, as supplied and distributed by SAMSUNG and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:

One (1) Year Parts and Labor*

(*90 Days Parts and Labor for Commercial Use)

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from the service center is the responsibility of the purchaser.

SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer.

SAMSUNG’s obligations with respect to software products distributed by SAMSUNG under the SAMSUNG brand name are set forth in the applicable end user license agreement. Non-SAMSUNG hardware and software products, if provided, are on an “AS IS” basis. Non-SAMSUNG manufacturers, suppliers, publishers, and service providers may provide their own warranties.

This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and except to the extent otherwise expressly provided for in this statement, noncommercial use of this product, and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied and authorized by SAMSUNG, or which damage this product or result in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions, cleaning, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal or reinstallation; reception problems and distortion related to noise, echo, interference or other signal transmission and delivery problems. SAMSUNG does not warrant uninterrupted or error-free operation of the product.

THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.

Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

To obtain warranty service, please contact SAMSUNG customer care center.

HT-D5100_XAA_1224.indd 73HT-D5100_XAA_1224.indd 73 2011-12-24  12:31:512011-12-24  12:31:51

Contact SAMSUNG WORLD WIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.

Area Contact Center

North America

Canada 1-800-SAMSUNG (726-7864) www.samsung.com Mexico 01-800-SAMSUNG (726-7864) www.samsung.com U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com

Latin America

Argentine 0800-333-3733 www.samsung.com Brazil 0800-124-421 / 4004-0000 www.samsung.com Chile 800-SAMSUNG (726-7864) www.samsung.com Colombia 01-8000112112 www.samsung.com Costa Rica 0-800-507-7267 www.samsung.com Dominica 1-800-751-2676 www.samsung.com Ecuador 1-800-10-7267 www.samsung.com El Salvador 800-6225 www.samsung.com Guatemala 1-800-299-0013 www.samsung.com Honduras 800-7919267 www.samsung.com Jamaica 1-800-234-7267 www.samsung.com Nicaragua 00-1800-5077267 www.samsung.com Panama 800-7267 www.samsung.com Peru 0-800-777-08 www.samsung.com Puerto Rico 1-800-682-3180 www.samsung.com Trinidad &

Tobago Venezuela 0-800-100-5303 www.samsung.com

Europe

Albania 42 27 5755 -

Austria

Belgium 02-201-24-18

Bosnia 05 133 1999 Bulgaria 07001 33 11 www.samsung.com Croatia 062 SAMSUNG (062 726 7864) www.samsung.com

Czech

Denmark 70 70 19 70 www.samsung.com Finland 030 - 6227 515 www.samsung.com France 01 48 63 00 00 www.samsung.com

Germany

Hungary 06-80-SAMSUNG (726-7864) www.samsung.com Italia 800-SAMSUNG (726-7864) www.samsung.com Kosovo +381 0113216899 Luxemburg 261 03 710 www.samsung.com Macedonia 023 207 777 Montenegro 020 405 888 -

Netherlands

Norway 815-56 480 www.samsung.com

Poland

Portugal 80820-SAMSUNG (726-7864) www.samsung.com

Rumania

1-800-SAMSUNG (726-7864) www.samsung.com

0810 - SAMSUNG (7267864, € 0.07/min)

800-SAMSUNG (800-726786) Samsung Zrt., česká organizační

složka, Oasis Florenc, Sokolovská394/17, 180 00, Praha 8

01805 - SAMSUNG (726-7864 € 0,14/Min)

0900-SAMSUNG (0900-7267864) (€ 0,10/Min)

0 801 1SAMSUNG (172678) / 022-607-93-33

1. 08010 SAMSUNG (72678) doar din reţeaua Romtelecom, tarif local

2. 021.206.01.10 - din orice reţea, tarif normal



Web Site

www.samsung.com

www.samsung.com/ be (Dutch) www.samsung.com/ be_fr (French)

www.samsung.com

Area Contact Center

Serbia

Slovakia 0800-SAMSUNG (726-7864) www.samsung.com Spain 902-1-SAMSUNG (902 172 678) www.samsung.com Sweden 0771 726 7864 (SAMSUNG) www.samsung.com

Switzerland

U.K 0330 SAMSUNG (7267864) www.samsung.com Eire 0818 717100 www.samsung.com Lithuania 8-800-77777 www.samsung.com Latvia 8000-7267 www.samsung.com Estonia 800-7267 www.samsung.com

CIS

Russia 8-800-555-55-55 www.samsung.com Georgia 8-800-555-555 Armenia 0-800-05-555 Azerbaijan 088-55-55-555 -

Kazakhstan

Uzbekistan 8-10-800-500-55-500 www.samsung.com Kyrgyzstan 00-800-500-55-500 www.samsung.com Tadjikistan 8-10-800-500-55-500 www.samsung.com

Ukraine 0-800-502-000

Belarus 810-800-500-55-500 Moldova 00-800-500-55-500 -

Asia Paciﬁ c

Australia 1300 362 603 www.samsung.com New Zealand China

Hong Kong (852) 3698 4698

India

Indonesia

Japan 0120-327-527 www.samsung.com Malaysia 1800-88-9999 www.samsung.com

Philippines

Singapore 1800-SAMSUNG (726-7864) www.samsung.com Thailand 1800-29-3232 / 02-689-3232 www.samsung.com Taiwan 0800-329-999 www.samsung.com Vietnam 1 800 588 889 www.samsung.com

Middle East

Bahrain 8000-4726 www.samsung.com Egypt 08000-726786 www.samsung.com Jordan 800-22273 www.samsung.com Morocco 080 100 2255 www.samsung.com Oman 800-SAMSUNG (726-7864) www.samsung.com Saudi Arabia 9200-21230 www.samsung.com Turkey 444 77 11 www.samsung.com U.A.E 800-SAMSUNG (726-7864) www.samsung.com

Africa

Nigeria 0800-SAMSUNG (726-7864) www.samsung.com South Africa 0860-SAMSUNG (726-7864 ) www.samsung.com

0700 Samsung (0700 726

7864)

0848-SAMSUNG (7267864, CHF 0.08/min)

8-10-800-500-55-500 (GSM: 7799)

0800 SAMSUNG (0800 726 786) 400-810-5858 / 010-6475 1880

3030 8282 / 1800 110011 / 1800 3000 8282 / 1800 266 8282

0800-112-8888 / 021-5699-7777

1-800-10-SAMSUNG(726-7864) / 1-800-3-SAMSUNG(726-7864) / 1-800-8-SAMSUNG(726-7864) / 02-5805777



Web Site

www.samsung.com

www.samsung.com/ch www.samsung.com/ ch_fr/(French)

www.samsung.com

www.samsung.ua www.samsung.com/ ua_ru

www.samsung.com www.samsung.com www.samsung.com/hk

www.samsung.com/ hk_en/

www.samsung.com

HT-D5100_XAA_1224.indd 74HT-D5100_XAA_1224.indd 74 2011-12-24  12:31:512011-12-24  12:31:51

QUESTIONS OR COMMENTS?

COUNTRY CALL OR VISIT US ONLINE AT WRITE

IN THE US

HT-D5100_XAA_1224.indd 75HT-D5100_XAA_1224.indd 75 2011-12-24  12:31:522011-12-24  12:31:52

1-800-SAMSUNG

(7267864)

www.samsung.com/us

Samsung Electronics America, Inc.

85 Challenger Road Ridgeﬁ eld Park,

NJ 07660-2112

Code No. AH68-02322R

Samsung HT-D5100-ZC User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
