Samsung DVDS222, DVDS321 User guide

D

D

VD PLA

VD PLA

YER

YER

D VD-S221
D VD-S222
D VD-S320
D VD-S321

2

Precautions

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE
COVER(OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.

This symbol indicates important
instructions accompanying the
product.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: DVD PLAYERS USE AN INVISIBLE LASER BEAM WHICH CAN

CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED.
BE SURE TO OPERATE PLAYER CORRECTLY AS INSTRUCTED.

CAUTIONS

Caution: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
Attention: Pour éviter les chocs électriques, introduíre la lame la plus large de la fiche dans la borne correspondante

de la prise et pousser jusqu au fond.
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to
other equipment. To prevent electromagnetic interference with electric appliances, such as radios and televisions,
use shielded cables and connectors for connections.

FCC NOTE (for U.S.A):

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the inter ference by one or
more of the following measures.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect this equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This class B digital apparatus meets all requirements of the Canadian Interference -­Causing Equipment Regulations

.

CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LÁSER CLASE 1

3

Precautions

WARNING

To reduce the risk of fire
or shock hazard, do not
expose this DVD player
to rain or moisture.

CAUTION

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT
OPEN COVER AND DO NOT REPAIR YOURSELF. REFER SERVICING TO
QUALIFIED PERSONNEL.

Note:

• This unit can be used only where the power supply is AC 120V, 60Hz. It cannot be used elsewhere.

• This DVD player is designed and manufactured to respond to the Region Management Information.
If the Region number of a DVD disc does not correspond to the Region number of this DVD player,
the DVD player cannot play the disc.

• This device is protected by U.S. patent numbers 4,631,603, 4,577,216, 4,819,098 and 4,907,093
and other intellectual property rights. The use of Macrovision’s copy protection technology in the
device must be authorized by Macrovision and is intended for home and other limited pay-per-view
uses only, unless otherwise authorized in writing by Macrovision.
Reverse engineering or disassembly is prohibited.

Handling Cautions

Disc Storage

Maintenance of Cabinet

• Before connecting other components to this player, be sure to turn them all off.

• Do not move the player while a disc is being played, or the disc may be scratched or broken, and the player’s
internal parts may be damaged.

• Do not put a flower vase filled with water or any small metal objects on the player.

• Be careful not to put your hand into the disc tray.

• Do not place anything other than the disc in the disc tray.

• Exterior interference such as lightning and static electricity can affect normal operation of this player. If this
occurs, turn the player off and on again with the POWER button, or disconnect and then reconnect the
AC power cord to the AC power outlet. The player will operate normally.

• Be sure to remove the disc and turn off the player after use.

• Disconnect the AC power cord from the AC outlet when you don’t intend to use the player for long
periods of time.

• Clean the disc by wiping in a straight line from the inside to the outside of the disc.

Be careful not to harm the disc because the data on these discs is highly vulnerable to the environment.

• Do not keep under direct sunlight.

• Keep in a cool ventilated area.

• Store vertically.

• Keep in a clean protection jacket.

For safety reasons, be sure to disconnect the AC power cord from the AC outlet.

• Do not use benzene, thinner, or other solvents for cleaning.

• Wipe the cabinet with a soft cloth.

4

1. Read Instructions-All the safety and operating instructions should be read before the product is operated.

2. Retain Instructions-The safety and operating instructions should be retained for future reference.

3. Heed Warnings-All warnings on the product and in the operating instructions should be adhered to.

4. Follow Instructions-All operating and using instructions should be followed.

5. Cleaning-Unplug this product from the wall outlet before cleaning.Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.

6. Attachments-Do not use attachments not recommended by the product manufacturer as they may cause
hazards.

7. Water and Moisture-Do not use this product near water-for example near a bath tub, wash bowl, kitchen
sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.

8. Accessories-Do not place this product on an unstable cart, stand, tripod, bracket,

or table.
The product may fall, causing serious injury to a child or adult, and serious damage
to the product. Use only with a cart, stand, tr ipod, bracket, or table recommended by
the manufacturer or sold with the product.Any mounting of the product should follow
the manufacturer’s instructions and should use a mounting accessory recommended
by the manufacturer.

9. Cart Usage-A product and cart combination should be moved with care. Quick stops, excessive force, and

uneven surfaces may cause the product and cart combination to overturn.

10. Ventilation-Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of

the product and to protect it from overheating.These openings must not be blocked or covered.
The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions have been adhered to.

11. Power Sources-This product should be operated only from the type of power source indicated on the

marking label. If you are not sure of the type of power supplied to your home, consult your product dealer or
local power company.For products intended to operate from battery power, or other sources, refer to the
operating instructions.

12. Grounding or Polarization-This product may be equipped with a polarized alternating-current line plug (a

plug having one blade wider than the other).This plug will fit into the power outlet only one way.This is a
safety feature.If you are unable to insert the plug fully into the outlet, try reversing the plug.If the plug
should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.

13. Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or

pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.

14. Lightning-For added protection for this product during a lightning storm or when it is left unattended and

unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system.
This will prevent damage to the product due to lightning and power-line surges.

Safety Instructions

5

15. Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal.

16. Overloading-Do not overload wall outlets, extension cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.

17. Object and Liquid Entry-Never push objects of any kind into this product through openings as they may
touch dangerous voltage points or shor t-out par ts that could result in a fire or electr ic shock. Never spill
liquid of any kind on the product.

18. Servicing-Do not attempt to service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards.Refer all servicing to qualified service personnel.

19. Damage Requiring Service-Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:

a When the power-supply cord or plug is damaged.
b If liquid has been spilled or objects have fallen into the product.
c If the product has been exposed to rain or water.
d If the product does not operate normally by following the operating instructions. Adjust only those

controls that are covered by the operating instructions as an improper adjustment of other controls may
result in damage and will often require extensive work by a qualified technician to restore the product
to its normal operation.

e If the product has been dropped or damaged in any way.
f When the product exhibits a distinct change in performance-this indicates a need for service.

20. Replacement Parts-When replacement parts are required, be sure the ser vice technician has used
replacement parts specified by the manufacturer or that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.

21. Safety check-Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks to determine that the product is in proper operating condition.

22. Heat-The product should be situated away from heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.

Safety Instructions

Before You Start

Accessories

Install Batteries in the

Remote

If remote doesn’t operate

properly:

Remote Control

User’s Manual

Batteries for

Remote Control (AA Size)

Easy Remote Control

(DVD-S320/DVD-S321 only)

Video/Audio Cable

1

1

Open the battery cover on the
back of the remote.

2

2

Insert two AA batteries. Make
sure that the polarities (+ and -)
are aligned correctly.

3

3

Replace the battery cover.

• Check the polarity + - of the batteries
(Dry-Cell)

• Check if the batteries are drained.

• Check if remote sensor is blocked by
obstacles.

• Check if there is any fluorescent
lighting nearby.

6

TABLE OF CONTENTS

General Features

..............................................................................................

8

Disc Type and Characteristics .......................................................................... 9

Description-Front Panel ..................................................................................10

Display Indicators ..........................................................................................12

Description-Rear Panel ..................................................................................13

Tour of the Remote Control..............................................................................14

Choosing a Connection ..................................................................................20

Playing a Disc................................................................................................22

Using the Search & Skip Functions ............................................................

24

Using the Display Function..............................................................................25

Repeat Play ..................................................................................................26

Program Play & Random Play ........................................................................27

S.FIT Play ......................................................................................................28

Digest Play ....................................................................................................29

Using the Disc View Function ..........................................................................30

Slow Repeat play ..........................................................................................31

Selecting the Audio Language ........................................................................32

Selecting the Subtitle Language ......................................................................33

Changing the Camera Angle ..........................................................................34

Using the Instant Replay Function ....................................................................35

Using the Bookmark Function..........................................................................36

Using the Zoom & 3D Sound Functions ..........................................................................37

MP3 Play ......................................................................................................38

Using the Setup Menu ....................................................................................40

Setting Up the Language Features ..................................................................41

Setting Up the Parental Control ......................................................................43

Setting Up the Audio Options ........................................................................44

Setting Up the Display Options ......................................................................45

Controlling a TV with the Remote ..................................................................46

Troubleshooting..............................................................................................47

Specifications ................................................................................................48

Warranty ......................................................................................................49

7

SETUP

SETUP

CONNECTIONS

BASIC

FUNCTIONS

ADVANCED

FUNCTIONS

CHANGING

SETUP MENU

REFERENCE

General Features

Excellent Sound

Dolby Digital, a technology
developed by Dolby Laboratories provides
crystal clear sound reproduction.

Screen

Both regular and widescreen(16:9) pictures
can be viewed.

Slow Motion

An important scene can be viewed in slow
motion.

Programmed Play

You can program tracks to play in desired
order.

Parental Control

The parental control allows users to set the
level necessary to prohibit children from
viewing harmful movies such as those with
violence, adult subject matter, etc.

Various On-Screen Menu Functions

You can select various
languages(Audio/Subtitle) and screen angles
while enjoying movies.

Repeat

You can repeat a song or movie simply by
pressing the REPEAT button.

MP3

This unit can play discs created from MP3
files.

Instant Replay

This function is used to replay the previous
10 seconds of the movie from the current
position.

Easy Remocon (DVD-S320/DVD-S321 only)

You can easily operate this player by
combining only the functions that are
frequently used.

COPY PROTECTION

• Many DVD discs are encoded with copy protection. Because of this, you should only connect your DVD player
directly to your TV, not to a VCR. Connecting to a VCR results in a distor ted picture from copy-protected DVD

discs.

• This product incorporates copyright protection technology that is protected by methods claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering
or disassembly is prohibited.

8

* Discs which cannot be played with this player.

• DVD-ROM • DVD-RAM

• CD-ROM • CDV

• CDI

• HD layer of super Audio CD

• CDGs play audio only, not graphics.

* Ability to play back may depend on recording

conditions.

• DVD-R • CD-RW

• DVD+RW, -RW

NOTE

Disc Type and Characteristics

Disc Markings

Play Region Number

This DVD player is capable of playing the following types of discs with the
corresponding logos:

5"

3

1/2"

Single-sided

240 min.

Double-sided

480 min.

Single-sided

80 min.

Double-sided

160 min.

Audio

+

Video

Audio

+

Video

Audio

• CD is recorded as a
Digital Signal with better
audio quality, less
distortion and less
deterioration of audio
quality over time.

• Video with CD sound, VHS

quality & MPEG-1
compression technology.

• DVD contains excellent sound

and video due to Dolby Digital
and MPEG-2 system.

• Various screen and audio

functions can be easily
selected through the on­screen menu.

VIDEO-CD

AUDIO-CD

5"

31/2"

74 min.

20 min.

5"

31/2"

74 min.

20 min.

Disc Types

(Logos)

Recording

Types

Disc Size

Max.

Playing Time

Characteristics

DVD

~

DIGITAL

SOUND

STEREO

NTSC

• Play
Region
Number

• NTSC broadcast
system in U.S.A,
Canada, Korea,
Japan, etc.

• Dolby
Digital disc

• Stereo disc

• Digital
Audio disc

• DTS disc

• MP3 disc

Both the DVD player and the discs are coded by region. These regional codes must match in order for the disc
to play. If the codes do not match, the disc will not play.

The Region Number for this player is described on the rear panel of the player.

9

SETUP

SETUP

Description-Front Panel

OPEN/CLOSE

OPEN/CLOSE

STOPPLAY/PAUSE

OPEN/CLOSE

JOG / SHUTTLE

SKIP

DVD-S221

DVD-S222/DVD-S320

DVD-S321

10

123 4567891011

1456789

1

4

56789

Description-Front Panel

Front Panel Controls

1. STANDBY / ON

•

When the unit is first plugged in, the indicator lights. When STANDBY/ON is pressed on
again, the light goes out and the player is turned on.

2. HEADPHONES JACK

•

You can attach headphones here for private listening.

3. HEADPHONES VOLUME

•

Use to adjust headphones volume level.

4. DISC TRAY

•

Load the disc here.

5. DISPLAY

•

Operation indicators are displayed here.

6. OPEN/CLOSE

•

Press to open and close the disc tray.

7. PLAY/PAUSE

• Begin or pause disc play.

8. STOP

• Stops disc play.

9. SKIP

• Use to skip a scene or music.

10. JOG

• Use to access certain Shuttle features with the Shuttle dial : When JOG is pressed, indicator
lights up.

11. SHUTTLE

• Use during DVD and CD play to fast forward or reverse. In JOG mode(JOG button pressed),
used for frame advance/CD track selection.

SETUP

SETUP

11

Display Indicators

12

Front Panel Display

1. Angle indicator. You can select multiple angles of a scene recorded by different cameras.

2. Disc type indicators

3. Play /

Pause / Forward play

4. DVD : Title, Chapter number.

5. Video/Audio CD : Track number

6. Repeat play mode

7. MP3 indicators

8. Displays various messages concerning operations such as PLAY, STOP, LOAD ...

no DISC : No disc loaded.
OPEN : The disc tray is open.
LOAD : Player is loading disc information.

1

245 6 7

38

Description-Rear Panel

Rear Panel

1. DIGITAL AUDIO OUT JACKS

• Use either an optical or coaxial digital cable to connect to a compatible Dolby Digital receiver.
Use to connect to an A/V Amplifier that contains a Dolby Digital or DTS decoder.

2. ANALOG AUDIO OUT JACKS

• Connect to the Audio input jacks of your television, audio/video receiver, or VCR.

3. VIDEO OUT JACK

• Use a video cable to connect to the Video input jack on your television.

4. S-VIDEO OUT JACK

• Use the S-Video cable to connect this jack to the S-Video jack on your television for a higher quality
picture. The S-Video must be selected in the VIDEO OUT SELECT.

5. COMPONENT VIDEO OUT JACKS

• Use these jacks if you have a TV with Component Video in jacks. These jacks provide Pr, Pb and Y
video. Along with S-Video, Component Video provides the best picture quality. The Y, Pb, Pr must be
selected in the VIDEO OUT SELECT.

6. VIDEO OUT SELECT SWITCH

• Use the switch to set video out.

• If Y, Pb or Pr is selected, S-Video will not work.

• If S-Video is selected, Y, Pb or Pr will not work.

13

SETUP

SETUP

* Select the VIDEO OUT SELECT switch in the Stop or Power Off mode.

NOTE

123456

Tour of the Remote Control

(DVD-S221/DVD-S222)

14

113

14

15

16
17
18

19
20

21
22

23
24

25
26

27

2

3
4

5
6

7
8

9

10

11
12

Tour of the Remote Control

DVD Function Buttons

1. DVD POWER Button

2. NUMBER Buttons

3. STEP Button

• Advances play one frame at a time.

4. ZOOM Button

5. S.FIT Button

6. SEARCH Buttons

•

Allows you to search forward/backward through a disc.

7. STOP Button

8. MENU Button

• Brings up the Disc menu.

9. TOP MENU Button

10. CLEAR Button

•

Use to remove menus or status displays from the screen.

11. BOOKMARK Button

12. SETUP Button

• Brings up the DVD player’s Setup menu.

13. OPEN/CLOSE Button

14. 3D Button

15. DIGEST Button

16. PLAY/PAUSE Button

• Begin/Pause disc play.

17. SKIP Buttons

• Use to skip the title, chapter, or track.

18. RETURN Button

• Returns to a previous menu.

19. DISPLAY Button

• Displays the current disc mode.

20. ENTER/DIRECTION Button
(UP/DOWN or LEFT/RIGHT Buttons)

• This button functions as a toggle switch.

21. ANGLE Button

• Use to access various camera angles on a DVD.

22. MODE Button

• Allows you to program a specific order.

23. SUBTITLE Button

24. AUDIO Button

•

Use this button to access various audio functions on a disc.

25. REPEAT A-B Button

• Use to mark a segment to repeat between A and B.

26. REPEAT Button

•

Allows you to repeat play a title, chapter, track, or disc.

27. I.REPLAY Button

•

This function is used to replay the previous 10 seconds of
the movie from the current position.

15

SETUP

SETUP
