User Guide
Page 2
Contents
Chapter 1. Getting Started
3 Before You Start
6 Safety Precautions
18 Proper Posture During Computer Use
21 Overview
27 Turning the Computer On and O
Chapter 1
Getting Started
75 Using the Remote Control (Optional)
77 Using the Multimedia App (Optional)
81 Sharing content using the AllShare Play app (Optional)
90 Samsung Software Update
91 Diagnosing the Computer Status and Troubleshooting
92 Using the Security Slot
Chapter 4. Settings and Upgrade
1
Chapter 2. Using Windows 8
30 What is Microsoft Windows 8?
31 Screen At a Glance
33 Using the Charms
35 Using Apps
38 Windows Hot Key Function
39 Using a Touch Screen (Touch screen models only)
Chapter 3. Using the computer
47 Using a wireless keyboard/mouse (Optional)
54 Using hand gestures (Optional)
57 CD Drive (ODD, Optional)
59 Multi Card Slot (Optional)
61 Using the product as a monitor (Optional)
62 Adjusting the Volume
63 LCD Instruction
64 Wired Network
67 Wireless Network (Optional)
69 Using the TV (Optional)
94 BIOS Setup
97 Setting a Boot Password
100 Changing the Boot Priority
Chapter 5. Troubleshooting
102 Recovering/Backing up the Computer (Optional)
109 Reinstalling Windows (Optional)
112 Q&A
Chapter 6. Appendix
116 Important Safety Information
118 Replacement Parts and Accessories
120 Regulatory Compliance Statements
136 WEEE Symbol Information
137 Samsung Packaging Take-Back Program
138 Product Specications
140 Glossary
144 Index
Page 3
Chapter 1. Getting Started
Before You Start 3
Safety Precautions 6
Proper Posture During Computer Use 18
Overview 21
Turning the Computer On and O 27
Page 4
Before You Start
Chapter 1
Getting Started
3
Before reading the User Guide, rst check the following
information.
Optional items, some devices and software referred to in •
the User Guide may not be provided and/or changed by
upgrade.
Note that the computer environment referred in the User
Guide may not be the same as your own environment.
The pictures used for the cover and the main body in the •
User Manual are those of the representative model of each
series and may dier from the actual appearance of the
product.
This guide decribes procedures for using both the mouse •
and the touchpad.
This manual has been written for the Windows 8 operating •
system. The descriptions and gures may dier depending
on the installed operating system.
Using the software
From the • Start Screen, right-click any area and select All
apps in the bottom right corner.
Then, click a desired program.
Or you can simply launch Quick Starter to do the same.
You can install • Quick Starter from SW Update.
The User guide supplied with this computer may vary •
depending on your model.
Page 5
4
Chapter 1
Getting Started
Before You Start
Safety Precaution Notations
Icon Notation Description
Failure to follow instructions marked with
Warning
Caution
this symbol, may cause personal injury
and or fatality.
Failure to follow instructions marked with
this symbol, may cause slight injury to
yourself or damage your property.
Text Notations
Copyright
© 2012 Samsung Electronics Co., Ltd.
Samsung Electronics Co., Ltd. owns the copyright of this manual.
No part of this manual may be reproduced or transmitted in any
form or by any means, electronic or mechanical, without the
consent of Samsung Electronics Co., Ltd.
The information in this document is subject to change without
notice due to improving the performance of the product.
Samsung Electronics shall not be liable for any data loss. Please
take care to avoid losing any important data and backup your data
to prevent any such data loss.
OS and Software Support
Icon Notation Description
Content included in this section includes
Caution
information required about the function.
Content included in this section includes
Note
helpful information to use the function.
If you change the product’s factory OS (Operating System) to
another OS or if you install software which is not supported by the
product’s original factory OS, you will not receive any technical
support, product exchange or refund. And a fee will be charged
when requesting a service.
Please use your computer with the original factory OS. If you
install an OS other than the factory OS, data may be deleted or the
computer may not start.
Page 6
5
Chapter 1
Getting Started
Before You Start
About the Product Capacity Representation
Standard
About the capacity representation of the storage
The capacity of the storage device (HDD, SSD) of the manufacturer
is calculated assuming that 1KB=1,000 Bytes.
However, the operating system (Windows) calculates the storage
device capacity assuming that 1KB=1,024 Bytes, and therefore the
capacity representation of the HDD in Windows is smaller than the
actual capacity due to the dierence in capacity calculation.
(E.g. For a 80GB HDD, Windows represents the capacity as 74.5GB,
80x1,00 0x1,000x1,0 00 by te/(1,024x1,024x1,024)by te = 74.505GB)
In addition, the capacity representation in Windows may be even
smaller because some programs such as Recovery may reside in a
hidden area of the HDD.
About Memory Capacity Representation
The memory capacity reported in Windows is less than the actual
capacity of memory.
This is because BIOS or a video adapter uses a portion of memory
or claims it for further use.
(E.g. For 1GB(=1,024MB) memory installed, Windows may report
the capacity as 1,022MB or less)
Page 7
6
Chapter 1
Getting Started
Safety Precautions
For your security and to prevent damage, please read the
following safety instructions carefully.
Since this is commonly applied to Samsung Computers,
some pictures may dier from actual products.
Warning
Failure to follow instructions marked with this symbol may
cause personal injury and even fatality.
Installation Related
Do not install the computer on a slant or a
place prone to vibrations, or avoid using the
computer in that location for a long time.
This increases the risk that a malfunction or
damage to the product will occur.
Be careful that people are not exposed to
the computer’s ventilator, adapter, etc., as
they generate heat over a long period of
time when your PC is powered on.
Do not install the product in places exposed
to humidity such as a bathrooms.
There is a danger of electric shock. Use the
product within the operating conditions
specied in the Manufacturers User Guide.
Keep the plastic bags out of the reach of
children.
There is a danger of suocation.
Keep a distance of 15cm or more between
the computer and the wall and do not place
any objects between them.
This may increase the internal temperature of
the computer and may cause an injury.
Exposing a part of your body close to the heat
from the vent or AC adapter for long periods of
time may cause a burn.
Avoid blocking the vent at the bottom or
side of the computer when using it on a bed
or cushion.
If the vent is blocked, there is a danger of
damaging the computer or overheating the
inside of the computer.
Ver 3.2
Page 8
7
Chapter 1
Getting Started
G
Safety Precautions
Warning
Failure to follow instructions marked with this symbol may
cause personal injury and even fatality.
Power Related
The power plug and wall outlet gures may dier
depending on the country specications and the product
model.
Do not touch the main plug or power cord
with wet hands.
There is a danger of electric shock.
Do not exceed the standard capacity
(voltage/current) of a multiplug or power
outlet extension when using it for the
product.
There is a danger of electric shock or re
hazard.
If the power cord or power outlet makes a
noise, disconnect the power cord from the
wall outlet and contact a service center.
There is a danger of electric shock or re
hazard.
Do not use a damaged or loose main plug or
power cord or power outlet.
There is a danger of electric shock or re
hazard.
Plug the power cord rmly into the power
outlet and AC adapter.
Failure to do so may cause re hazard.
Do not unplug the power cord by pulling
the cable only.
If the cord is damaged, it may cause electric
shock.
Do not bend the power cord excessively or
do not place a heavy object over the power
cord. It is especially important to keep the
power cord out of reach of infants and pets.
If the cord is damaged, it may cause electric
shock or re.
Page 9
8
Chapter 1
Getting Started
Safety Precautions
Warning
Failure to follow instructions marked with this symbol may
cause personal injury and even fatality.
Connect the power cord to an outlet or
multiple power plug (extended cable) with
a ground terminal.
Failure to do so may result in electric shock.
When the power supply is ungrounded, the
current may leak resulting in electric shock.
If water or another substance enters
the power input jack, AC adapter or the
computer, disconnect the power cord and
contact the service center.
If the notebook computer has an external
type (removable) battery, separate the
battery also.
Damage to the device within the computer
may cause electric shock or re hazard.
Keep the power cord or outlet clean so that
they are not covered with dust.
Failure to do so may result in re.
AC Adapter Usage Precautions
Connect the power cord to the AC adapter
rmly.
Otherwise, there is a danger of re due to an
incomplete contact.
Use only the AC adapter supplied with the
product.
Using another adapter may cause the screen to
icker.
Do not place heavy objects or step onto
the power cord or AC adapter to avoid
damaging the power cord or AC adapter.
If the cord is damaged, there is a danger of
electric shock or re.
Unplug the wall-mount AC adapter (adapter
and plug intergrated type) from the wall
outlet while holding the body and pulling it
in the direction of the arrow.
If you unplug the adapter by holding and
pulling the cable, the adapter may be damaged
and an electric shock, explosive sound or spark
may occur as a result.
Page 10
9
Chapter 1
Getting Started
Safety Precautions
Warning
Failure to follow instructions marked with this symbol may
cause personal injury and even fatality.
Battery Usage Related
Please charge the battery fully before using the
computer for the rst time.
Keep the battery out of the reach of infants
and pets, as they could put the battery into
their mouths.
There is a danger of electric shock or choking.
Use an authorized battery and AC adapter
only.
Please use an authorized battery and adapter
approved by Samsung Electronics.
Unauthorized batteries and adapters may not
meet the proper safety requirements and may
cause problems or malfunctions and result in
an explosion or re.
Do not use the computer in a badly
ventilated location such as on bedding, on a
pillow or cushion, etc, and do not use it in a
location such as room with oor heating as
it may cause the computer to overheat.
Take care that the computer vents (on the side
or the bottom) are not blocked especially in
these environments. If the vents are blocked,
the computer may overheat and it may cause a
computer problem, or even an explosion.
Do not use the computer in a humid
location such as a bathroom or sauna.
Please use the computer within the
recommended temperature and humidity
range (10~32ºC, 20~80% RH).
Do not close the LCD panel and put the
computer into your bag to move it when it is
still turned on.
If you put the computer into your bag without
turning it o, the computer may overheat and
there is a danger of re. Shut the computer
down properly before moving it.
Page 11
10
Chapter 1
Getting Started
Safety Precautions
Warning
Failure to follow instructions marked with this symbol may
cause personal injury and even fatality.
Never heat the product(or battery) or put
the product(or battery) into a re. Do not
put or use the product(or battery) in a hot
location such as a sauna, inside a vehicle
exposed to the heat, and so on.
There is a danger of an explosion or re.
Take care not to allow metal objects such as
a key or clip to touch the battery terminal
(metal parts).
If a metal object touches the battery terminals,
it may cause excessive current ow and it may
damage the battery, or result in a re.
If liquid leaks out of the product(or battery)
or there is a funny smell coming from
the product(or battery), remove the the
product(or battery) the computer and
contact a service center.
Usage Related
Disconnect all cables connected to the
computer before cleaning it. If your
notebook is external & removable battery
type, remove the external battery.
There is a danger of electric shock or damage
to the product.
Do not connect a phone line connected to a
digital phone to the modem.
There is a danger of a electric shock, re or
damage to the product.
Do not place any container lled with water or
chemicals over or near the computer.
If water or chemicals enter the computer, this
may cause re or electric shock.
If the computer is broken or dropped,
disconnect the power cord and contact a
service center for a safety check.
There is a danger of an explosion or re.
To use the computer safely, replace a dead
battery with a new, authorized battery.
If the notebook computer has an external
type (removable) battery, separate the
battery also.
Using a broken computer may cause electric
shock or re hazard.
Page 12
11
Chapter 1
Getting Started
Safety Precautions
Warning
Failure to follow instructions marked with this symbol may
cause personal injury and even fatality.
Avoid direct sunlight when the computer
is in an air-tight location such as inside a
vehicle.
There is a danger of a re hazard. The computer
may overheat and also present opportunity to
thieves.
Do not use your computer for long
periods of time while any part of your
body is making direct contact with it. The
temperature of the product may increase
during normal operation.
This may result in harming or burning your skin.
Upgrade Related
Never disassemble the power supply or AC
adapter.
There is a danger of electric shock.
When removing the RTC (Real Time Clock)
battery, keep it out of the reach of children
as they could touch and/or swallow it.
There is a danger of choking. If a child has
swallowed it, contact a doctor immediately.
Use only authorized parts (multiplug, battery and memory) and never
disassemble parts.
There is a danger of damaging the product,
electric shock or re hazard.
Shut down the computer and disconnect
all cables before disassembling the
computer. If there is a modem, disconnect
the phone line. If your notebook is external
& removable battery type, remove the
external battery.
Failure to do so, may cause electric shock.
Page 13
12
Chapter 1
Getting Started
Safety Precautions
Warning
Failure to follow instructions marked with this symbol may
cause personal injury and even fatality.
Security and Movement Related
Follow the instructions for the relevant
location (e.g. airplane, hospital, etc.) when
using a wireless communication device
(wireless LAN, Bluetooth, etc.).
Avoid exposing a drive to magnetic elds.
Security devices with magnetic elds include airport walk-through devices and security wands.
When carrying the notebook computer
with other items, such as the adapter,
mouse, books etc, take care not to press
anything against the notebook computer.
If a heavy object is pressed against the
notebook computer, a white spot or stain may
appear on the LCD. Therefore, take care not to
apply any pressure to the notebook.
In this case, place the notebook computer in
a separate compartment away from the other
objects.
The airport security devices that check carry-on luggage, such as conveyor belts, use
x-rays instead of magnetism and will not
damage a drive.
Page 14
13
Chapter 1
Getting Started
Safety Precautions
Caution
Failure to follow instructions marked with this symbol may
cause slight injury or damage to the product.
Installation Related
Do not block the ports (holes), vents, etc. of the product and
do not insert objects.
Damage to a component within the computer may cause electric
shock or re.
When using the computer with it lying on its side, place it so
that the vents face upwards.
Failure to do so, may cause the internal temperature of the
computer to rise and the computer to malfunction or halt.
Do not place a heavy object over the product.
This may cause a problem with the computer. In addition, the
object may fall and cause injury, or damage the computer.
Battery Usage Related
Dispose of worn-out batteries properly.
There is a danger of re or explosion.•
The battery disposal method may dier depending on •
your country and region. Dispose of the used battery in an
appropriate way.
Do not throw or disassemble the battery and do not put it
into water.
This may cause an injury, re or explosion.
Use only a battery authorized by Samsung Electronics.
Failure to do so may cause an explosion.
Avoid contact with metal objects such as car keys or clips
when keeping or carrying a battery.
Contact with a metal may cause excessive current and a high
temperature and may damage the battery or cause a re.
Charge the battery according to the instructions in the manual.
Failure to do so, may cause an explosion or re from damage to
the product.
Do not heat the product(or battery) or expose it to heat (e.g.
inside a vehicle during the summer).
There is a danger of explosion or re.
Page 15
14
Chapter 1
Getting Started
Safety Precautions
Caution
Failure to follow instructions marked with this symbol may
cause slight injury or damage to the product.
Usage Related
Do not place a candle, light cigar, etc. over or on the product.
There is a danger of re.
Use a wall outlet or multi-plug with a grounding part.
Failure to do so may cause electric shock hazard.
Make sure to have the product tested by a safety service
engineer after repairing the product.
Authorized Samsung Repair Centers will carry out safety checks
after a repair. Using a repaired product without testing it for
safety may cause an electric shock or re.
Connect only permitted devices to the connectors or ports
of the computer.
Failure to do so, may cause electric shock and re.
Close the LCD panel only after checking if the notebook
computer is turned o.
The temperature may rise and it may cause overheating and
deformation of the product.
Do not press the Eject Button while the CD-ROM drive is in
operation.
You might lose data and the disk might be suddenly ejected and
could cause an injury.
Take care not to drop the product while using it.
This may cause personal injury or loss of data.
Do not touch the antenna with electricity facility such as the
power outlet.
In case of lightning, immediately turn the system o,
disconnect the power cord from the wall outlet and phone
line from modem. Do not use a modem or phone.
There is a danger of electric shock or re.
Do not use your computer and AC-Adapter on your lap or
soft surfaces.
If the computer temperature increases, there is a danger of
burning yourself.
There is a danger of electric shock.
When handling computer parts, follow the instructions on
the manual supplied with the parts.
Failure to do so, may cause damage to the product.
Page 16
15
Chapter 1
Getting Started
Safety Precautions
Caution
Failure to follow instructions marked with this symbol may
cause slight injury or damage to the product.
If the computer emits smoke, or there is a burning smell,
disconnect the power plug from the wall outlet and contact
a service center immediately. If your notebook is external &
removable battery type, remove the external battery.
There is a danger of re.
Do not use a damaged or modied CD.
There is a danger of damaging the product or personal injury.
Do not insert your ngers into the PC Card Slot.
There is a danger of injury or electric shock.
Use recommended computer cleansing solution when
cleaning the product and only use the computer when it is
completely dried.
Do not place your face close to the Optical Disk Drive tray
when it is operating.
There is a danger of injury due to an abrupt ejection.
Check CDs for cracks and damage prior to use.
It may damage the disc and cause disorder of device and injury of
user.
Failure to do so may cause electric shock or re.
Emergency disk eject method using paperclip should not
be used while the disk is in motion. Make sure to use the
emergency disk eject method only when the Optical Disk
Drive has stopped.
There is a danger of injury.
Page 17
16
Chapter 1
Getting Started
Safety Precautions
Caution
Failure to follow instructions marked with this symbol may
cause slight injury or damage to the product.
Upgrade Related
Take care when touching the product or parts.
The device may be damaged or you may be injured.
Take care not to throw or drop a computer part or device.
This may cause injury or damage to the product.
Make sure to close the computer cover before connecting
the power after a reassembly.
There is a danger of electric shock if your body touches an
internal part.
Security and Movement Related
When moving the product, turn the power o and separate
all connected cables rst.
The product might be damaged or users may trip over the cables.
For long periods of not using the notebook computer,
discharge the battery and preserve as it is detached.
(For external & removable battery type)
The battery will be preserved at its best condition.
Do not operate or watch the computer while driving a
vehicle.
There is a danger of a trac accident. Please concentrate on
driving.
Use parts authorized by Samsung Electronics only.
Failure to do so, may cause re or damage the product.
Never disassemble or repair the product by yourself.
There is a danger of electric shock or re.
To connect a device that is not manufactured or authorized
by Samsung Electronics, enquire at your service center
before connecting the device.
There is a danger of damaging the product.
Page 18
17
Chapter 1
Getting Started
Safety Precautions
Caution
Failure to follow instructions marked with this symbol may
cause slight injury or damage to the product.
Cautions on Preventing Data Loss
(Hard Disk Management)
Take care not to damage the data on a hard disk drive.
A hard disk drive is so sensitive to external impact that an •
external impact may cause loss of data on the surface of the
disk.
Take extra care, because moving the computer or an impact •
on the computer when it is turned on may damage the data of
the hard disk drive.
The company is not liable for any loss of data on the hard disk •
drive.
Causes that may damage the data of a hard disk drive and
the hard disk drive itself.
The data may be lost when an external impact is applied to the •
disk while disassembling or assembling the computer.
The data may be lost when the computer is turned o or reset •
by a power failure while the hard disk drive is operating.
The data may be lost and irrecoverable due to a computer virus •
infection.
The data may be lost if the power is turned o while running a •
program.
Sudden impact or movement to the computer while the hard •
disk drive is operating, may cause les to be corrupted or bad
sectors on the hard disk.
To prevent data loss due to damage to the hard disk drive,
please backup your data frequently.
Page 19
18
Chapter 1
Getting Started
Proper Posture During Computer Use
Maintaining a proper posture during computer use is very
important to prevent physical harm.
The following instructions are about maintaining a proper posture
during computer use developed through human engineering.
Please read and follow them carefully when using the computer.
Otherwise, the probability of (RSI: Repetitive Strain Injury) from
repeated operations may increase and serious physical harm may
be caused.
The instructions in this manual have been prepared so that •
they can be applied within the coverage of general users.
If the user is not included in the coverage, the •
recommendation is to be applied according to the user’s
needs.
Proper Posture
Do not use the computer while you are lying down, but only •
while you are sitting down.
Do not use the computer on your lap. If the computer •
temperature increases, there is a danger of burning yourself.
Work while keeping your waist straight.•
Use a chair with a comfortable back.•
Keep the center of your leg weight not on the chair but on •
your feet when you are sitting on a chair.
To use the computer while talking over the telephone, use a •
headset. Using the computer with the phone on your shoulder
is bad for posture.
Keep frequently used items within a comfortable work range •
(where you can reach them with your hands).
Adjust the heights of desks and chairs appropriate to your
height.
The heights are to be adjusted so that your arm forms a right
angle when you place your hand over the keyboard while sitting
down on a chair.
Adjust the height of chair so that your heel is comfortably placed
on the oor.
Page 20
19
Chapter 1
Getting Started
Proper Posture During Computer Use
Eye Position
Keep the monitor or LCD away from your eyes by at least
50cm.
Hand Position
Keep your arm at a right angle as shown by the gure.
Adjust the height of the monitor and the LCD screen so that its •
top height is equal to or lower than your eyes.
Avoid setting the monitor and LCD excessively bright.•
Keep the monitor and LCD screen clean.•
If you wear glasses, clean them before using the computer.•
When entering contents printed on a paper into the computer, •
use a static paper holder so that the height of the paper is
almost equal to that of the monitor.
Keep the line from your elbow to your hand straight.•
Do not place your palm over the keyboard while typing.•
Do not hold the mouse with excessive force.•
Do not press the keyboard, touchpad or mouse with excessive •
force.
It is recommended connecting an external keyboard and •
mouse when using the computer for long periods of time.
Page 21
20
Chapter 1
Getting Started
Proper Posture During Computer Use
Volume Control (Headphones and Speakers)
Check your volume rst to listen to music.
Check your
volume!
Check if the volume is too loud before using headphones.•
It is not recommended using headphones for long periods of •
time.
Any deviation from the equalizer default setting could cause •
Use Time (Break Time)
Take a break for 10 minutes or more after a 50-minute period •
when working for more than one hour.
Illumination
Do not use the computer in dark locations. The illumination •
level for computer use must be as bright so for reading a book.
Indirect illumination is recommended. Use a curtain to prevent •
reection on the LCD screen.
Operation Condition
Do not use the computer in hot and humid locations.•
Use the computer within the allowed temperature and •
humidity range specied in the User Guide.
hearing impairment.
The default setting can be changed through software and •
driver updates without your intervention. Please check the
equalizer default setting before rst usage.
Page 22
21
Chapter 1
Getting Started
Overview
Front View
The pictures used for the cover and the main body in the •
User Manual are those of the representative model of each
series. Therefore the colors and appearance of the pictures
may dier from the actual appearance of the product
depending on the model.
The actual color and appearance of the computer may •
dier from the pictures used in this guide.
1 2 3
Camera operating
1
indicator
2 Camera
Remote Control
3
Sensor (Optional)
4
4 Microphone You can use the built-in microphone.
This indicates the camera operating
status.
Using this camera, you can take still
pictures and record video.
You can take a picture or make a movie
using the Charms > Start > Camera.
If a user presses a button on the remote
control, the sensor detects the signal from
the remote control and the computer
performs the corresponding action.
When using the remote control, take
care not to block the sensor.
If the sensor is blocked, the remote
control will not function.
The screen images are displayed here.
LCD or Touch screen
5
6
7
8
9
5
(Optional)
Touch buttons
6
(for corresponding
models only)
HDD/ODD
7
operating indicator
8
Power Button
9 Stand This is the stand supporting the computer.
It works as a touch screen in models
that support the touch screen feature.
(Optional)
You can use the functions by lightly
touching the sensor buttons with your
ngers.
The indicator turns on while the HDD/
ODD is active.
Turns the computer on and o.
Page 23
22
Chapter 1
Getting Started
Overview
Touch buttons (for corresponding models only)
Some touch buttons may not be provided depending on •
the model specications.
Menu, Screen Settings, Volume Control• buttons are only
supported in Monitor Mode.
If you touch the sensor, the touch button works.
3
Menu
4
Screen Settings
Shows or hides the screen settings OSD.
The menu of the mode selected by the user
pressing the button is supported.
The <MagicBright>, <MagicAngle>,
<MagicEco> and <Screen Size> menus are
supported.
<MagicBright>: You can choose the optimal
screen settings for a movie or game.
The <Custom>, <Standard Screen>, <Game>,
<Movie> and <Video Contrast Setting>
screen modes are supported.
<MagicAngle>: You can choose the optimal
screen settings for your viewing angle.
If you congure this setting when you watch
the screen from above, below or the side of
the screen, you can view the screen as if you
were directly in front.
<MagicEco>: This mode provides power-
1 2 3 4 5 6 7
1
Mute
2
Eject CD
This is the button to mute the sound.
Eject the media from the CD drive.
saving mode by decreasing the current to
the display panel.
<Screen Size>: This mode provides various
screen size options.
The terms in this manual may dier
from the actual terms displayed on the
screen.
Page 24
23
Chapter 1
Getting Started
Overview
5
Volume Control
6
Mode Selection
7
LCD On/O
Launches the volume control menu.
When the volume control menu is running,
press to turn the volume up or press
to turn the volume down.
Switches to PC mode or monitor mode.
PC Mode: The mode that maintains the
screen of this product.
Monitor Mode: The mode used when this
product is used as a monitor.
Source is used to switch between PC
and Monitor modes when the system is
in use.
Turns the LCD on or o.
For models that support monitor mode, this
button turns both the LCD and the speaker
on or o at the same time.
When the system is hibernating or
shutdown, press the LCD on/o button
to use the product in Monitor mode.
Caution when using the touch buttons
You can only use the touch buttons when the computer is •
turned on.
Touch the touch buttons with clean, dry hands.•
In a humid environment, use the buttons after rst removing
moisture from your ngers or the touch buttons.
Since the touch buttons will work even if you do not press •
them hard, do not press them excessively.
Since a serious impact may damage the sensor in the touch
button, take care when using the buttons.
Do not press the buttons with sharp objects such as a stylus •
pen, ball-point pen, etc. Sharp objects may damage the touch
buttons.
When you touch the touch buttons, take care not to touch •
another button so that your nger tip touches the touch
buttons precisely corresponding to the required function.
When you are wearing gloves or the touch buttons are covered •
with plastic packaging or some kind of protective covering, the
touch buttons may not work properly.
If a conductive object such as a metal object makes contact •
with the touch buttons, the touch buttons may malfunction.
Therefore, take care not to touch the touch buttons with a
conductive object.
Page 25
24
Chapter 1
Getting Started
Overview
Right View
Plays CD or DVD titles.
A CD Drive is optional. The installed
CD Drive (ODD)
1
(Optional)
1
drive may di er depending on the model
specications.
Blu-ray media can only be played on a BluRay-compliant ODD, and you can use the
Power DVD program to play Blu-ray content.
Page 26
25
Chapter 1
Getting Started
Overview
Left View
1 Multi Card Slot A card slot supports multi cards.
This port is used as a USB port or
chargeable USB port.
Using a chargeable USB port, you can
USB Port
or
2
1
1
2
Chargeable USB
Port
(Optional)
access or charge a USB device.
You can tell the ports apart using the
gures printed on the ports or by the
colors.
USB 2.0 port: black
Chargeable USB 2.0 Port: black
USB 3.0 port: blue
Chargeable USB 3.0 port: blue
3
4
3
Microphone Jack
4
Headphone Jack
A jack used to connect the microphone.
A jack used to connect the headphones.
What is a chargeable USB port?
USB device accessing and charging functions are supported.•
The USB charging function is supported regardless of whether •
the power is turned on or o.
Charging a device through a chargeable USB port may take •
longer than general charging.
Using the Chargeable USB function when the computer is •
running on battery power reduces the battery usage time.
The user cannot evaluate the charging status of the USB device •
from the computer.
This may not be supported for some USB devices.•
You can turn the Chargeable USB function • ON/OFF by selecting
the Settings > Power Management > USB Charging option.
(Optional)
Page 27
26
Chapter 1
Getting Started
Overview
Rear View
Speaker A device used to generate sound.
3
1
2
3 4 5 6 7 8 9 10 11 3
Security Slot
4
TV Antenna Input
5
Port (Optional)
DC Jack
6
7
Wired LAN Port
Digital Vieo/Audio out
8
port (HDMI-OUT)
USB 2.0 Port
9
You can secure the computer by connecting
a lock and cable to the Security Slot.
You can watch TV by connecting the antenna
cable.
Only for models with a TV tuner card.
The shape of the port may dier
depending on the country.
A jack to connect the AC adapter that
supplies power to the computer.
The appearance and size of the jack may
dier depending on the model.
Connect the Ethernet cable to this port.
You can connect an HDMI cable to this port.
You can connect the computer to a TV and
output digital video and audio to the TV.
You can connect USB devices to the USB port
such as a keyboard/mouse, digital camera,
etc.
Fan Vents
1
Memory
2
Compartment Cover
The internal heat of the computer is emitted
through these holes.
If the vents are blocked the computer
may overheat.
Avoid blocking the vents as this may be
dangerous.
The main memory is installed inside the
cover.
Digital Video/
Audio Input Port
10
(HDMI-IN) (Optional)
DP (Display Port)
11
(Optional)
You can connect an HDMI cable to this port.
You can connect the HDMI port to a device
with an HDMI output port and use this
product as a monitor with digital video and
audio output from the device.
Used to connect a DP cable to the product.
Page 28
27
Chapter 1
Getting Started
Turning the Computer On and O
Turning the computer on
Connect the AC adapter.
1
2
Powe Cable
Press the Power button to turn the computer on.
AC Adapter
1
DC-in Jack
2
Power indicator is lit while the computer is turned on.
About Windows Activation
When you turn the computer on for the rst time, the Windows
activation screen appears.
Follow the activation procedures according to the instructions on
the screen to use the computer.
If the screen is not displayed when you turn the
computer on (for corresponding models only)
Press the • touch button to turn the LCD on.
If “HDMI” message is displayed on the screen, press the •
touch button to switch the LCD panel to the
PC mode.
Page 29
áᔪ
Ŗᮁ
᯲
ᰆ⊹
Turning the Computer On and O
Turning the computer o
Since the procedures to turn the computer o may dier •
depending on the installed operating system, please turn
the computer o according to the procedures for the
purchased operating system.
Save all your data before clicking on • Shut down.
Chapter 1
Getting Started
The Charms menu appears when you place your mouse
1
pointer at the edge of the top or bottom right of the screen.
Click Settings
> Power
> Shut down.
2
28
If you want to power o your computer when you are logged
out, unlock the screen and click Power
> Shut down.
Page 30
Chapter 2. Using Windows 8
What is Microsoft Windows 8? 30
Screen At a Glance 31
Using the Charms 33
Using Apps 35
Windows Hot Key Function 38
Using a Touch Screen (Touch screen models only) 39
Page 31
30
Chapter 2
Using Windows 8
What is Microsoft Windows 8?
Microsoft Windows 8 (hereafter referred to as Windows) is an
operating system that is required for operating a computer.
To use your computer optimally, you need to know how to use it
properly. Therefore, It is better to learn how to use Windows by
utilizing Windows Help and Support.
The screen may appear somewhat dierent depending on •
the model and the operating system.
Since this guide has been prepared based on Windows •
8, some of the instructions may dier depending on the
version. It may also be modied without prior notice.
The descriptions here are for using a mouse. For the •
descriptions on using a touch screen, refer to the Using
the Touch Screen section.
Searching
for Help
Displaying Help
Press the F1 Key on the keyboard to display the Help.
Alternatively, place your mouse cursor over the end of the top or
bottom right area on the screen to display the Charms menu.
Click Charms menu > Settings > Help.
If you are connected to the internet, you can access the most
recent online Help.
Get Started
Internet &
networking
Security, privacy,
& accounts
You can view basic instructions on how to use
your computer including new function(s) for the
Windows OS.
After connecting to the network, you can check
the Help section required to use the internet.
You can check the Help information required
to protect your computer and personal
information.
Page 32
31
Chapter 2
Using Windows 8
Screen At a Glance
Windows 8 provides both the new Start screen mode and the
Desktop mode of the existing OS.
1 Start Screen
Refers to the default Start screen of
Windows 8.
Start Screen Desktop
Start Screen
When you turn on the computer, the Start screen is displayed,
which allows you to use the applications (Application, App,
hereafter referred to as an App) at the same location.
1
2
3
4
2 App
Displaying the
3
Charms
4 User Account
5 Charms
6 Desktop Switches to Desktop mode.
Refers to the apps that are currently
installed.
The Charms is hidden at the right of the
screen. Place your mouse pointer at the
edge of the top or bottom right of the
screen to display the Charms.
This refers to the currently used user
account.
This refers to the menu that allows you to
use functions such as Search, Share, Start,
Device and Settings.
7 Camera Allows you to take pictures or make a movie.
5
6
7
3
Page 33
32
Chapter 2
Using Windows 8
Screen At a Glance
Desktop
This provides similar functions to those provided by the Desktop
in prior Windows versions.
1
2
3
4
1 Desktop Refers to the Desktop.
2
Displaying Documents and Files
Click Windows Explorer in the taskbar on the Desktop to
search for documents and les.
Displaying the
2
Charms
3 Charms
Switching to the
4
Start Screen
The Charms is hidden at the right of the
screen. Place your mouse pointer at the
edge of the top or bottom right of the
screen to display the Charms.
This refers to the menu that allows you to
use functions such as Search, Share, Start,
Device and Settings.
Click the corner of the bottom left of the
screen to switch to the Start screen.
Page 34
33
Chapter 2
Using Windows 8
Search
Search
Share
Search
Share
Start
Search
Share
Start
Device
Search
Share
Start
Device
Settings
Using the Charms
The Charms is a new type of menu that combines the Start menu
with the Control Panel of existing Windows.
The Charms allows you to quickly congure the device(s)
connected to your computer, search for App(s)/le(s), and use the
sharing function, etc.
Activating the Charms
If you move your mouse pointer to the top or bottom right corner
of the screen, the Charms appears.
If you want to search for a program or le in the App(s)/
Settings/File(s), simply enter a keyword in the Search
charm and start Search.
You can also search within an App or on the Web.
You can use this menu to transfer a picture or le to
another user. You can easily share pictures or les with
other users simply by associating multiple Apps with the
Share charm.
You can move to the Start screen.
Displaying
the Charms
Menu
Charms
Displaying
the Charms
Menu
As this allows you to move directly to a desired device,
you can handle tasks such as importing pictures from
a digital camera, streaming a video to your TV or
transferring les to a device on the current screen.
The Settings charm allows you to perform basic tasks
such as adjusting the volume, turning o the PC, etc.
If you select the Settings charm while a specic App is
running, the settings for the currently running App are
displayed.
Page 35
34
Chapter 2
Using Windows 8
Using the Charms
⦽
Changing the Settings
Frequently used Windows menus are collected.
Click the Charms > Settings.
Icon Name Function Description
Wireless
Network
Adjusting the
Volume
Notice
Power
Keyboard
You can connect to a wireless network.
Select a wireless network to connect
to.
You can adjust the volume or mute the
sound.
You can set the interval at which an
App sends notices.
You can turn o your computer or
select the Power Options.
You can set the Language or launch
Touch keyboard.
Change PC settings
You can change more settings.
Page 36
35
Chapter 2
Using Windows 8
Using Apps
An App refers to an application program (hereafter referred to as
an App). In a larger sense, it refers to all the software programs
installed on the operating system.
Windows 8 provides basic Apps for frequently performed tasks.
Starting/Exiting an App
Click on an App in the Start screen to activate it.
To exit the App
Move your mouse pointer to the top of the screen.
1
Your mouse pointer changes to a hand shape.
Click and hold your mouse button and then drag it to the
2
bottom of the screen. The App moves downward and
disappears and exits.
Using Apps
Displaying Currently Running App(s)
Move your mouse pointer to the top left corner of the screen
1
to display the last run App.
Then, move your mouse pointer down to display a list of the
2
currently running Apps in order.
Click on an App in that list or drag it to the center of the
3
screen. Now, you can check the selected App which is
currently running.
Right-click over the App in the list and click Close to exit the
App.
1
2
1
2
Page 37
36
Chapter 2
Using Windows 8
Using Apps
Running Two Apps at the Same Time
Select the Apps in the Start screen.
1
Move your mouse pointer to the top of the screen. Your
2
mouse pointer changes to a hand shape.
If you click and hold your mouse button and move left or
3
right, you can split the screen to display multiple Apps.
Move the Screen Split Bar to change the screen split ratio.
4
Supported screen split ratios are 3:7 or 7:3.
Weather
App
Screen
Split Bar
Store App
Adding/Removing an App to/from the Start Screen
Click Start screen > right-click your mouse button.
Click All Apps at the bottom of the screen to display all the
Apps that are currently installed.
If you right-click over the App to be added, the relevant menu
1
is activated at the bottom of your screen.
Click Pin to start or Unpin from Start .
2
Ex) If you run the Weather App and
Store App at the same time
1
2
Ex) When removing an App in the Start screen
Page 38
37
Chapter 2
Using Windows 8
Using Apps
Using the Windows Store
If you run the App Store in the Start screen, the Apps in the
Windows Store are displayed.
However, a Microsoft account is required to purchase App(s) in the
Windows Store.
Continue after registering your Microsoft Account in the
Charms.
Conguring your Microsoft Account
A Microsoft Account allows you to synchronize your settings with
other device(s) running Windows 8 online allowing you to share
le(s) or settings.
You should register a Microsoft Account to download or purchase
App(s) from the Store.
Run the Charms and click Settings > Change PC Settings.
1
Click Users > Your account > Switch to a Microsoft
2
account.
Register your account through the following relevant
3
procedures.
1
2
Page 39
38
Chapter 2
Using Windows 8
Windows Hot Key Function
You can use the following convenient hot keys in Windows 8.
Function Hot Keys Function Description
Displaying the
Start Screen
Displaying the
Desktop
Running the
Charms
Locking the
Screen
Opening the
Ease of Access
Center
Opening the
Second Screen
Settings
Windows Key Switches to Start mode.
Switches to Desktop
Windows Key + D
mode.
Windows Key + C Activates the Charms.
Windows Key + L Locks the screen.
Opens the Ease of Access
Windows Key + U
Center conguration.
Opens the External
Windows Key + P
Monitor Settings menu.
Opening the
Advanced
Windows Key + X
Management
Too l
Exit App Alt + F4
Opens the Advanced
Management Tool.
Exits the currently
running App.
Page 40
39
Chapter 2
Using Windows 8
Using a Touch Screen
A touch screens allows you to use your computer without a keyboard or mouse.
The touch screen instructions also describe the functions which can be activated via the touch screen.
If you are using your computer for a long period of time, it is recommended using a keyboard and mouse.•
Make sure to operate your touch screen using your nger. If you operate your touch screen with a hard object, it will not work.•
If there any foreign substances such as insects or water on the touch screen, your touch screen will not work properly.•
(Touch screen models only)
Using a Touch Screening
This function is supported by Windows 8 touch screen models and is activated by some applications.•
In addition, please note that supported functions may dier depending on the application.•
Learning about Basic Touch Screen Operations
The touch screen interface is supported in Windows 8.
You can easily learn how to use the touch screen conveniently.
Touch Operation Function Description
Dragging from the right edge
toward the center
Displays the Charms menu which is hidden at the right of the screen.
Page 41
40
Chapter 2
Using Windows 8
Using a Touch Screen
Touch Operation Function Description
(Touch screen models only)
Dragging from the left edge
toward the center
Dragging from the bottom edge
upward or from the top edge
downward
Touching slightly
(Clicking)
Touching twice
(Double-clicking)
Displays the last run App.
Displays the options for the currently running application.
Slightly press with your nger to select an item.
(If you slightly touch a specic menu, option, application icon, etc. on
the screen, the corresponding capability is activated.)
Slightly press twice with your nger to select an item.
Touching and dragging
Moves the selected target or moves to the next page.
You can draw a picture or write some letters with this operation.
Page 42
41
Chapter 2
Using Windows 8
Using a Touch Screen
Touch Operation Function Description
Rotating with more than 2 ngers Rotates the selected target.
(Touch screen models only)
Spreading 2 ngers widely or
bringing them towards each other
Touching and holding for a while
(Right-clicking your mouse)
Touching and dragging 2 ngers
up/down, left/right
(Scrolling)
Zooms in or out of the target.
Provides the same function as right-clicking your mouse button.
Displays the additional options which can be set for the selected
target or more detailed information.
Moves up/down, left/right. Provides the same function as scrolling
your mouse.
Page 43
42
Chapter 2
Using Windows 8
Using a Touch Screen
(Touch screen models only)
Calibrating the Screen
If you are using the touch screen for the rst time or the pointer is
not aiming correctly and the accuracy has declined, calibrate your
screen.
The screen calibration process may dier depending on the OS. It
may not be supported by some operating systems.
On the Desktop, press the Charms menu > Settings >
1
Control Panel > Tablet PC Settings > Calibration. Then
press OK.
When the Calibration window appears, press the + mark by
2
following the onscreen instructions.
The input location of your touch screen is calibrated.
3
Page 44
43
Chapter 2
Using Windows 8
Using a Touch Screen
(Touch screen models only)
Entering Characters
You can enter characters using the keyboard and the Tablet PC
Input Panel.
Entering characters may dier depending on the operating system
and is not supported by some operating systems.
If you are using your computer for a long period of time, it is
recommended using the keyboard.
Entering characters is explained using an example with notepad.
Using the Tablet PC Input Panel
The Tablet PC Input Panel is an onscreen keyboard provided by
Windows.
Follow the descriptions and illustrations on how to use the Tou ch
On the Desktop, press the at the right of the taskbar to
3
display the Tablet PC Input Panel.
Touch keyboard
(displays the Numeric
Key Pad in the middle.)
Touch keyboard
Handwriting Mode
keyboard and handwriting mode.
From the Start Screen, right-click any area and select
1
All apps in the bottom right corner.
Then, click Notepad.
Put your hand on the Notepad screen to display the cursor.
2
[Input Mode]
Page 45
44
Chapter 2
Using Windows 8
Using a Touch Screen
(Touch screen models only)
Entering characters using the Touch keyboard
The Touch keyboard has the standard keyboard layout which
allows you to select keys to enter characters.
Press the Touch keyboard icon in the Tablet PC Input
1
Panel.
Press the keys to enter your characters.
2
Entering characters in Handwriting Mode
You can enter characters by writing them in the Handwriting
Mode Input Panel on the touch screen.
Press the Handwriting Mode icon in Tablet PC Input
1
Panel.
Write characters in the input area of the Handwriting Mode
2
Input Panel on the touch screen.
Press the Insert button to enter characters.
3
Page 46
45
Chapter 2
Using Windows 8
Using a Touch Screen
(Touch screen models only)
Note for Using the Touch Screen
When using the touch screen, make sure to keep your hands •
clean and dry.
In humid environments, dry o your hands and the surface of
the touch screen before using the touch screen.
Do not directly spray LCD display cleaner onto the touch •
screen. The cleaner may soak through the bottom of the touch
screen. When using an LCD display cleaner, spray it onto a cloth
to clean your touch screen.
(If you use an abrasive cleaner or cloth, your touch screen may
be damaged.)
Do not apply severe shocks or impacts to the touch screen or •
press on it with a sharp object such as a pen.
This may result in your touch screen being damaged.
Be careful not to damage the edges of the touch screen.•
If the edges of the touch screen are damaged, the touch screen
may not work properly.
If there any foreign substances such as insects or water on the •
touch screen, your touch screen will not work properly. Use
your touch screen after removing all foreign substances.
If you operate your touch screen with a hard object such as a •
nail, pen, etc., it will not work.
If your nger touches the screen too softly, the touch may not •
be recognized.
When touching the screen, press on the item precisely with •
your nger and take care not to touch any other items.
The touch screen sensors are located at the edges of the touch •
screen.
When installing a protective cover and accessory, be careful
not to cover the edges of the touch screen.
Page 47
Chapter 3. Using the computer
Using a wireless keyboard/mouse (Optional) 47
Using hand gestures (Optional) 54
CD Drive (ODD, Optional) 57
Multi Card Slot (Optional) 59
Using the product as a monitor (Optional) 61
Adjusting the Volume 62
LCD Instruction 63
Wired Network 64
Wireless Network (Optional) 67
Using the TV (Optional) 69
Using the Remote Control (Optional) 75
Using the Multimedia App (Optional) 77
Sharing content using the AllShare Play app (Optional) 81
Samsung Software Update 90
Diagnosing the Computer Status and Troubleshooting 91
Using the Security Slot 92
Page 48
Using a wireless keyboard/mouse
(Optional)
Chapter 3.
Using the computer
47
The wireless keyboard and mouse are optional and the
appearance and the color of the provided keyboard and mouse
may dier depending on the model.
Installing the wireless receiver
Open the Battery Cover at the bottom and insert the battery
1
in the right polarity (+,-).
Example) Wireless mouse
CONNECT button
Insert the wireless signal receiver into the USB 2.0 port at the
2
back of the computer.
Slide the power switch at the bottom of the mouse to the ON
3
position.
Example) Wireless mouse
Battery Cover
Power switch
If you set this switch to the OFF
position when not using the mouse,
you can save battery power.
wireless signal
receiver
You can use the wireless keyboard and the mouse without
4
additional settings.
You can use the wireless keyboard and the wireless mouse •
within a 5m distance of the wireless signal sensor.
The distance is subject to the surroundings and if there •
is interference nearby, in particular a wireless LAN AP, the
distance may be decreased.
Page 49
48
Chapter 3.
Using the computer
Using a wireless keyboard/mouse
(Optional)
Wireless keyboard
Locate the battery cover at the bottom back of the
1
keyboard.
Use your ngers to push the cover up.
x
Insert the batteries and then close the battery cover.
2
x
Be sure to conrm that the polarities (+ / -) of the batteries •
are correct.
z
z
Do not recharge the batteries (AAA type) supplied with the •
product.
Page 50
49
Chapter 3.
Using the computer
Using a wireless keyboard/mouse
This indicates when it is time to replace the battery.
If the LED blinks, replace the batteries.
(Optional)
Battery replacement LED
CONNECT button
Windows Key
In Windows 8, the Start screen appears.
Battery cover
Directional keys
Moves the cursor up, down, left or right.
Page 51
50
Chapter 3.
Using the computer
Using a wireless keyboard/mouse
áᔪ
áᔪ
Ŗᮁ
᯲
áᔪ
Ŗᮁ
᯲
ᰆ⊹
Windows 8 Charm Menu Key
(This function is only supported for Windows 8.)
(Optional)
Search
Runs the Search function in the Windows
8 menu.
Share
Runs the Share function in the Windows 8
menu.
Launches the Device function in the
Device
Windows 8 menu.
Launches the Settings in the Windows 8
Settings
menu.
The wireless keyboard automatically enters power-saving
mode if there is no key input for a pre-determined period of
time. Press any key to resume using the keyboard in powersaving mode.
However, a function to turn the keyboard o is not
supported.
Page 52
51
Chapter 3.
Using the computer
Using a wireless keyboard/mouse
Wireless keyboard
(Optional)
Click function
Briey press the left mouse button once.
Left button
Selects and
launches an item.
Wheel button
Moves the pointer up and down.
Right button
Shows the contextsensitive menus of
programs.
If you click this mouse button once, the corresponding program is
selected.
Double-click function
Quickly press the left mouse button twice.
The corresponding program is launched.
Right click function
If you click this mouse button once, the context-sensitive menu of
the current program appears.
Drag function
Dragging refers to clicking an item and moving the item to
another position while holding the mouse button down.
If you move the mouse, the pointer on the screen moves in the
same direction.
Click the left mouse button over an item to be dragged and move
the item to the new position while holding the mouse button
down.
Scroll function
If you turn the wheel button up or down, the screen moves up or
down accordingly.
Page 53
52
Chapter 3.
Using the computer
Using a wireless keyboard/mouse
(Optional)
If the wireless keyboard does not work
Check the batteries.
►
For the keyboard, check if the battery low indicator
the top right blinks.
If the indicator blinks, you need to replace the battery.
Check the status of the wireless signal receiver.
►
Disconnect the wireless receiver from the main body and
1
then reconnect it.
at
Within 30 seconds of reconnecting the receiver, press and
2
hold the CONNECT button for 1 seconds near the receiver.
CONNECT button
Check if the device works properly.
3
Page 54
53
Chapter 3.
Using the computer
Using a wireless keyboard/mouse
(Optional)
If the wireless mouse does not work
When the power switch at the bottom of the mouse is in the
►
OFF position, the mouse does not work.
Turn the switch to the ON position.
Check the batteries.
►
Check the status of the wireless signal receiver.
►
Set the power switch at the bottom of the mouse to the OFF
1
position.
Disconnect and then reconnect the wireless signal receiver to
2
the main body.
Set the power switch at the bottom of the mouse to the ON
3
position.
CONNECT button
Power switch
Within 30 seconds of reconnecting the receiver, press and
4
hold the CONNECT button for 1 seconds near the receiver.
Check if the device works properly.
5
Page 55
54
Chapter 3.
Using the computer
Using hand gestures
(Optional)
You can turn the pages on the screen, and run and exit programs
using hand gestures in front of the computer screen. In addition,
you can turn the volume up or down and zoom in or out the
screen.
Run the hand gesture program (Gesture Control).
1
From the Start Screen, right-click any area and select
all apps in the bottom right corner.
Then, click Gesture Control.
The Hand Gesture window appears on the right side of the
2
screen.
Turning the
volume on/o
CloseHelp
Hand Gesture window
The actual window may dier from the picture in this User
guide.
Page 56
55
Chapter 3.
Using the computer
Using hand gestures
(Optional)
If you place your hand in front of the camera, your hand is
3
recognized when the palm-shaped icon appears on the
screen.
The hand gesture function works within a 50cm~100cm
range from the camera.
Tips
This function only works when a hand icon appears on the •
small window on the right side of the screen. If the function
doesn't work properly, please try to move your hand so that
the hand icon appears in the window.
The function may not work properly depending on the angle •
of your hand movement.
The function may not work properly when the ambient •
illumination is too bright or dim.
You cannot run two camera programs at the same time. •
When you use the hand gesture function, please use only one
program.
Using this function for an extended period of time may strain
your arm.
Page 57
56
Chapter 3.
Using the computer
Using hand gestures
(Optional)
Try to run a function referring to the gure of the gesture below.
Gestures Hand Motions Operating descriptions
Move to the
Left or Right
Fist Fist Click
Rotate
Wave Wave the palm 2~3 times Exit the program
Move the palm to the left /
Move the palm to the right
Rotate the palm counter
clockwise / Rotate the palm
clockwise
Previous screen / Next screen
Turn the volume down / Turn the volume up
Move to the start screen.
Make a st and
move it up
Depending on the program version, some features may be changed or may not be supported without prior notice.
Make a st and move it up
(To the height of the camera)
Start Screen Mode: Move to the most recently
executed application.
Page 58
57
Chapter 3.
Using the computer
CD Drive
(ODD, Optional)
An optical disk drive is optional and may dier depending on
your computer model. For detailed specications, refer to the
catalogue.
Do not insert a cracked or scratched CD.•
Otherwise, the CD may break and damage the optical disk
drive when the CD rotates at a high speed.
When you clean a CD or DVD title, wipe with a soft cloth •
from inside to outside.
Do not hold a CD by touching the bottom of the CD. •
Hold a CD by touching the center and the outer rim of the
CD. A CD contaminated by a foreign substance may result
in the CD not being recognized properly.
Using a CD that is not in the shape of a circle is not •
recommended.
Inserting and Ejecting a CD
Touch the Eject CD touch button .
1
The CD drive opens.
Insert the disc into the CD Drive so that the top of the disc
2
faces upwards.
When 90% of the disc is inserted into the drive, the disc is
automatically loaded into the drive.
A CD drive’s reading and writing speed may dier depending
on the condition and type of the media.
Page 59
58
Chapter 3.
Using the computer
CD Drive
Do not pull or push the disc by force when the disc is •
being automatically ejected or inserted. This may cause a
problem when ejecting or inserting a disc.
To insert a disc, insert the disc into the center of the drive •
with the appropriate pressure. If you insert a disc and apply
excessive force to one side of the tray, it may result in a
problem.
If you eject the disk before the disk is completely •
recognized, ejecting the disk may take longer.
To eject a disc, click Windows Explorer > Computer and
3
right-click over the CD drive and select Eject.
(ODD, Optional)
Alternatively, press the Eject button of the CD drive.
The disc stops and is ejected from the CD drive.
Page 60
59
Chapter 3.
Using the computer
Multi Card Slot
(Optional)
Using the multi card slot, you can read and write data to cards.
You can use a card as a removable disk and conveniently
exchange data with digital devices such as a digital camera, digital
camcorder, MP3, etc..
Supported Cards : SD Card, SDHC card, SDXC card•
You have to additionally purchase a multi card with the •
necessary capacity depending on your requirements.
You can use a multi card just like any data storage device. A •
copyright protection function is not supported.
Since you can lose a card when moving the computer, •
keep the card separately.
The gures used for the description are of a representative •
model. Therefore the gures may dier from the real ones.
Using the card
Insert the card into the multi card slot in the indicated
1
direction.
Example)
SD Card
Page 61
60
Chapter 3.
Using the computer
Multi Card Slot
(Optional)
The following message appears on the top right. Click to
2
open the folder and click View Files.
If a message appears to notify you of any problem, click the
corresponding window > Continue without Scanning. You
can perform the following process described in No. 3.
Windows Explorer runs on the Desktop. You can save, move
3
and delete data on the corresponding drive.
Using a Mini SD
Since the above cards are too small, you cannot insert the cards
into the slot directly.
To format a memory card
When using the memory card for the rst time, you must format
the card before using it.
Formatting a card deletes all data saved on the card. If the
card includes data, backup the data before formatting it.
Click the Windows Explorer icon in the taskbar on the
1
Desktop.
Right-click over a card drive with the touchpad and select
2
Format.
Click Start to the formatting.
3
To use a card to exchange data with a digital device such •
as a digital camera, formatting the data using the digital
device is recommended.
Insert the card into the dedicated adapter (available from most
electronic retailers) and then insert the adapter into the multi card
slot.
To remove a memory card
Take hold of the end of the card and remove the card.
When you try to use a card, which is formatted in the •
computer, in another digital device, you may have to
format the card again in the device.
You cannot format, write or delete data from a SD, or SDHC •
card with a write protection tab when it is in the Lock
position.
Inserting and removing a memory card repeatedly may •
damage the memory card.
Page 62
61
Chapter 3.
Using the computer
Using the product as a monitor
(Optional)
The LCD screen of this product can be used as a monitor using the
Digital Video/Audio Input Port (HDMI-IN).
Try using this product as a monitor by connecting an HDMI device
such as a computer, gaming console, DVD player and so on.
Using the product as a monitor
Connect the external device (HDMI output port) and this
1
product (digital video/audio input port (HDMI-IN)) with the
HDMI cable.
Press the touch button to switch this product to
2
monitor mode.
You can only use monitor mode by connecting the Digital
Video/Audio Input Port (HDMI-IN). The Digital Video/Audio
Out Port (HDMI-OUT) is for output only.
As long as the power cord is connected, you can use the •
LCD of the product as a monitor even when the product is
o.
Even if the product is switched to monitor mode by •
pressing the button during an operation, the
operating system is not terminated. Press the
button again to return to PC mode.
If the product is switched to monitor mode, the audio is •
also switched accordingly.
If no picture is displayed on the LCD screen when the •
product is switched to monitor mode, disconnect and then
reconnect the HDMI port.
Source is used to switch between PC and Monitor modes •
when the system is in use.
When the system is hibernating or shutdown, you can •
switch the mode using the LCD on/o button.
Returning to PC mode
To return to PC mode from monitor mode, press the
touch button.
Page 63
62
Chapter 3.
Using the computer
Adjusting the Volume
áᔪ
Ŗᮁ
᯲
ᰆ⊹
You can control the volume with the volume control program.
Adjusting the Volume using the Volume
Adjustment Program
Click the Charms menu > Settings
bar.
>
Mute
to adjust the control
Page 64
63
Chapter 3.
Using the computer
LCD Instruction
Samsung Computer’s Defective LCD pixel management
standard
Although Samsung Electronics, Co., Ltd. observes strict
quality and condence specications for LCD manufacturing,
the company must inevitably allow a few defective cells in
panels due to a technological limitation of the manufacturing
process.
Therefore Samsung observes and manages the following dot
principles:
- Bright dot : 2 or less
- Black dot : 4 or less
- Combination of Bright and Dark : 4 or less
Instructions for Cleaning the LCD
Clean the LCD panel with a soft cloth lightly moistened with
computer cleansing detergent moving in one direction.
Cleaning the LCD panel with excessive force can damage the
LCD.
Page 65
64
Chapter 3.
Using the computer
Wired Network
áᔪ
Ŗᮁ
᯲
ᰆ⊹
A wired network is a network environment used for a company
network or broadband internet connection at home.
Since these descriptions are written on the basis of the •
latest operating system, Windows 8, some of the content
and the gures of the descriptions may dier depending
on the operating system. Since the procedures for other
Windows operating systems are similar, use the computer
referring to these descriptions.
The gures used for the description are of a representative •
model. Therefore the gures may dier from the real ones.
Connecting to the Wired LAN
Connect the LAN cable to the wired LAN port.
1
Click Charms menu on the Desktop > Settings
2
Control Panel > Network and Internet > Network and
Sharing Center and click on Change adapter settings in
the left menu pane.
Select Ethenet and click the right button of the mouse and
3
select Properties.
>
The LAN Device name may dier depending on your
computer’s Network Device.
Page 66
65
Chapter 3.
Using the computer
Wired Network
Select Internet Protocol Version 4(TCP/IPv4) from the list
4
of Network Components and click Properties.
Congure the IP settings.
5
When using DHCP, select Obtain an IP address
automatically. To use a static IP address, select Use the
following IP address, and set the IP address manually.
The Network Component name may dier depending on •
the Operating System Installed.
To add a network component, click Install in the screen •
shown in the gure above. You can add clients, services,
and protocols.
When not using DHCP, ask your network administrator for the
IP address.
When you have completed the settings, click the OK button.
6
The network settings have been completed.
Page 67
66
Chapter 3.
Using the computer
Wired Network
áᔪ
Ŗᮁ
᯲
ᰆ⊹
Using the WOL (Wake On LAN) function
<Wake On LAN> is a function that activates the system from Sleep
mode when a signal (such as a ping or magic packet command)
arrives over the network (wired LAN).
Click Charms menu on the Desktop > Settings
1
Control Panel > Network and Internet > Network and
Sharing Center and click on Change adapter settings in
the left menu pane.
Right-click on the Wired Ethernet Connection and select
2
Properties.
Click Congure > Power Management tab. Select Allow
3
this device to wake the computer, then click OK. Restart
>
- <Wake On LAN> feature may not work while using Hybrid
power saving feature. Hybrid sleep mode can be disabled
from Power Options under Control Panel.
For Windows 7/8, Wake On LAN is not supported by Ping.
When connected to a 100Mbps/1Gbps wired LAN and the
computer exits Sleep/hibernation mode, a message appears
informing you of a connection to a 10Mbps/100Mbps
wired LAN. This happens because when the computer exits
standby/hibernate mode, restoring the network takes about
3 seconds. When the network is restored, it operates at
100Mbps/1Gbps.
the system.
- If the system wakes up from Sleep mode even though there
is no received signal, use the system after disabling the
<Wake On LAN> function.
- The LAN LED may not be turned o if System is shoutdown
without disabling the WOL (Wake on LAN) option.
Connecting a wired LAN while using a wireless LAN may not
-
activate the
to Disable to use the <Wake On LAN> function.
<Wake On LAN> function. Set the Wireless LAN
Page 68
67
Chapter 3.
Using the computer
Wireless Network
(Optional)
A wireless network (Wireless LAN) environment is a network
environment that enables communicating between multiple
computers at home or a small-size oce through wireless LAN
devices.
The screen gures and terms may dier depending on the •
model.
Depending on the program version, some functions may •
not be provided or dierent functions may be provided.
The descriptions below are for computer models with •
a Wireless LAN card or device. A Wireless LAN device is
optional.
The pictures in this manual may dier from the actual
product depending on your wireless LAN device model.
What is an Access Point (AP)?
An AP is a network device that bridges wired and wireless
LANs, and corresponds to a wireless hub in a wired network.
You can connect multiple wireless LAN installed computers
to an AP.
Page 69
68
Chapter 3.
Using the computer
Wireless Network
áᔪ
Ŗᮁ
᯲
ᰆ⊹
(Optional)
Connecting to a Wireless LAN
If there is an AP, you can connect to the Internet via the AP using
the Wireless LAN connection method provided by Windows.
If you click the Charms menu > Settings
1
Connections icon, a list of available APs appears.
If you select an AP to connect to, the Connect button
appears.
> Network
Click Connect.
2
If a network key is set for the AP, enter the network key and
then click OK.
For the network key, please ask your network administrator.
AP List
When the AP connection is completed, Connected is
3
displayed next to the corresponding AP. You can now you can
use the wireless network.
Page 70
69
Chapter 3.
Using the computer
Using the TV
(Optional)
Products embedded with a TV tuner card (Optional) can use the
TV function.
After connecting to the antenna, you can watch TV by using the
corresponding TV program.
You can only use the TV function when the TV tuner card
(Optional) is installed.
Connecting the TV Antenna
You must connect the TV tuner card (Optional) to the TV
antenna. Connect the antenna cable to the TV antenna input
port.
Conguring the TV
The screenshots and terms used in the user manual may
dier from the actual ones.
Click Start Screen > TV programs (TV ArcSoft).
1
The conguration screen appears. Since the following
2
procedures are displayed sequentially, congure your TV
using the following onscreen instructions.
Select Your Reigion
z
Select Video Device
x
- Digital Tuner
- Analog Tuner
Choose Your TV Signal
c
- Cable TV
- Antena TV
Page 71
70
Chapter 3.
Using the computer
Using the TV
Resetting the channels
(Optional)
Note on Conguration
The setup procedures may dier depending on the current •
type of your TV service.
You should set the product to the region and postal code •
where your computer is currently installed.
If the TV signal provider setup screen appears, select the •
correct provider. If the congured provider is not correct, not
all of the channels will be received or the TV picture quality
may be degraded.
Select Home > Settings > Channel. Then select Scan. The
scanned channels are saved.
If you cannot scan channels easily, select the Reset TV Signal
option in the Channel menu to reset the channels.
Page 72
71
Chapter 3.
Using the computer
Using the TV
(Optional)
TV Program Menu
Exit
Maximize
Minimize
Live TV
Recorded TV
EPG
(Electronic
Program Guide)
Schedule
Settings
You can watch a currently broadcast TV
program.
You can watch a recorded TV program.
An electronic TV program guide which allows
you to watch digital TV broadcasts.
However, it may dier depending on the
corresponding station and the reception. Also,
some functions may not be provided.
You can reserve a TV recording and watch a
recorded TV program.
You can set the TV channels, parent controls,
etc.
Live TV
Schedule
Recorded TV EPG (Electronic Program Guide)
[Home]
Settings
Page 73
72
Chapter 3.
Using the computer
Using the TV
(Optional)
Watching TV
Start the TV program (ArcSoft TV).
1
Select Live TV from the menu.
2
The TV broadcast is displayed immediately. Switch to the
channel you want.
Move your mouse to display the control bar as follows. Then
select a function.
Select Digital TV or Analog TV
Record
Capture a Static Picture
Pause/Play
Channel Controls
Favorites
Display Favorites
Page 74
73
Chapter 3.
Using the computer
Using the TV
(Optional)
Recording TV
You can record a TV program on your computer.
Recording the current program
Move your mouse over the currently viewed screen.
When the control bar appears at the bottom, click
Record .
A red dot appears indicating that a recording is in progress and
the recording begins.
Creating a recording schedule
Click Home > Settings > Schedule > Add.
1
Set your program and the reservation time.
2
Even when the computer is in power-saving (standby) •
mode, if the recording reservation time is reached, the
TV automatically wakes up from power-saving mode and
performs the reserved recording.
While recording a channel, you cannot record or watch •
another channel.
Page 75
74
Chapter 3.
Using the computer
Using the TV
(Optional)
Playing a recorded program
Click Home > Recorded TV.
The recorded programs are displayed. Select a program to watch.
You can list the recorded programs by program, channel or date.
Recorded les are saved in the Computer > Local Disk (C:) >
User > User Folder > My Video folder.
Page 76
75
Chapter 3.
Using the computer
Using the Remote Control
You can use the TV functions with the remote control.
You can run the Live TV program from the desktop.
Check the functions of each button.
The appearance of the remote control may dier from •
the actual one. Some functions may not be provided
depending on the system.
You can turn this product on by pressing the Power button •
on the remote control. However, you cannot turn this
product o with the Power button.
Use your remote control by pointing it toward the remote •
control receiver.
(Optional)
Installing the batteries
Open the cover at the bottom of the remote control and insert the
batteries according to the correct polarities (+,-).
To turn the power on or wake the computer up by pressing
the Power button , you have to change the settings in
the BIOS Setup screen.
However, this feature can only be congured through the
BIOS Setup menu for models equipped with a TV tuner card.
1. After booting up the computer, press the F2 key to enter
the BIOS Setup.
2. Select Advanced > Advanced Environment Control >
Remote Controller Boot from the BIOS Setup menu and
set it to Enabled.
Page 77
76
Chapter 3.
Using the computer
Using the Remote Control
(Optional)
Power
Volume Controls
Stop
TV or Spacebar function (optional): You
can run the TV program from the desktop.
Back
Windows Key
Select
Sleep
Launches Internet Explorer
Mute
Channel Controls
Play Controls
Record
Play / Pause
Tab key
ODD Eject
Go
Switch Application
Windows 8 Share
Close
Windows Hot Key
Windows 8 SettingsWindows 8 Search
Windows 8 Device
Some buttons on the remote control may not work
depending on the installed program.
Page 78
77
Chapter 3.
Using the computer
Using the Multimedia App
(Optional)
You can enjoy photo, video and music les with the S Camera, S
Gallery and S Player apps.
You can take photos and record videos with the S
S Camera
Camera app, and view them directly in this app.
Only photos or videos recorded with the S Camera
S Gallery
app can be viewed with the S Camera app.
You can view the photo, video and music les saved
S Player
on the computer.
Depending on the version of the program, some functions
may not be provided or dierent functions may be provided.
You can launch an app in the Start screen.
Third-party software related services
For descriptions about and service requests for third-party •
software, please contact the relevant manufacturer.
Some troubleshooting actions in response to service •
requests may not work depending on the software
manufacturer.
Page 79
78
Chapter 3.
Using the computer
Using the Multimedia App
áᔪ
Ŗᮁ
(Optional)
Using the S Camera app
Ta p Charm menu > Start
1
> S Camera.
Camera mode (Photo
, Video )
To take a picture, slide the camera mode bar into the Photo
2
position.
To make a video recording, slide the camera mode bar to the
Video position.
Tap on Take a picture/Record a video to take a picture
3
or record a video.
You can view the picture or video using the Picture preview
4
or S Gallery app.
The S Camera app is not available in Desktop mode.
Precautions while taking a picture or video
Zoom in/out
Photo settings
Take a picture/
Record a video
preview
Do not take a picture or video of others without their •
consent.
Do not take a picture or video in locations where this is not •
allowed.
Do not take picture or videos in locations where you may •
infringe on others’ privacy or condential information may
be exposed.
Page 80
79
Chapter 3.
Using the computer
Using the Multimedia App
áᔪ
Ŗᮁ
(Optional)
Using the S Gallery app
Ta p Charm menu > Start
> S Gallery.
1
You can view the pictures and videos taken by the S Camera.
2
In addition, you can apply special eects to the pictures using
the photo editing function.
You can take a picture in the S Gallery app by tapping the
Camera icon.
Editing a photo
Select Picture preview.
1
Drag it upward slightly from the bottom center.
If the options menu appears, select Edit .
Page 81
80
Chapter 3.
Using the computer
Using the Multimedia App
áᔪ
Ŗᮁ
(Optional)
Select an eect to be applied to the photo.
2
E.g. If you select Draw
Color
Using the S Player app
Ta p Charm menu > Start
> S Player.
1
UndoLine preview
My Music
My Photos
My Videos
Erase/Draw
Line thickness Save
Frame
Draw
Stamp
Close
Music playlist Slideshow
Select a menu to enjoy photo, video and music les.
My photo list
2
Some les may not be played depending on their format.
Page 82
81
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
AllShare Play is a content sharing service that enables users to
share and view photos, and play videos and music les saved
on digital devices via the Internet. You can use the web storage
service and share data by registering the network-connected
devices. If your home appliance supports DLNA (Digital Living
Network Alliance), you can also connect it through the home
network system.
Since the descriptions in this manual are based on •
Windows 8, some of the descriptions may dier depending
on the operating system or the device.
Depending on the country or program version, some •
functions may not be provided or dierent functions may
be provided.
The content and images in this manual are subject to •
change for the purpose of performance enhancement.
DLNA (Digital Living Network Alliance) is one of the home •
networking technologies based on an international
standard that enables sharing of digital media between
consumer devices such as computers, printers, digital
cameras, cell phones, TVs, and other multimedia devices.
You can easily share data between the DLNA-compliant
digital devices in your house by connecting them.
For information on whether your device supports DLNA, •
please refer to the user manual of the corresponding
device.
Page 83
82
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
You can learn about data sharing as well as view various tips
through the lecture videos and FAQs provided on the AllShare
Play website (www.allshareplay.com).
AllShare Play is especially useful if you want to
View and play the content saved on your in-house PC with
z
another PC or mobile device outside.
Resume editing presentation documents you created at the
x
oce.
Play photos or videos saved on a PC on a TV’s larger screen.
c
Copy les saved on a mobile device or digital camera to your
v
PC
Page 84
83
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
AllShare Play at a Glance
z
x
c
Registered
z
storage
v
This is an online storage space where you
can store and view les. You need to sign up
to an online storage service in partnership
and then enable it.
bn
Nearby devices
c
Change player
v
FAQ
b
Settings
n
You can only search for a device when the device is
connected to the AP (access point) and is turned on with the
DLNA service running.
This is a device found on the home network
connected to the same AP (access point).
You can search for a DLNA-compliant device
such as a smart phone or PC and retrieve
and play the les saved on the device.
You can search for playing devices, such as
a TV, using the Change player link.
Frequently asked questions and answers are
provided.
Provides additional settings for registering
devices and services.
Registered device
x
This is a PC, laptop, smart phone or tablet
that contains les to be shared. You can
register a device to AllShare Play by running
the AllShare Play app and signing in the
service once. If the device is turned on
without entering the power-saving mode,
you can access the les on the device from
a remote site.
Page 85
84
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
To use the AllShare Play app properly, you need to congure it as
follows:
1. Sign up on the AllShare Play website.
2. Congure PC.
3. Use AllShare Play (Play / Transfer / Upload les)
Sign up on the AllShare Play website
Since AllShare Play is an Internet service, a samsung.com account
is required to use the AllShare Play service.
Double-click AllShare Play app on the Windows Start screen
1
to connect to www.allshareplay.com, or you can access it
directly from the web browser by entering the AllShare Play
Select a language at the bottom right of the screen.
2
Click on Sign in at the top right and sign-in to the service
3
with your samsung.com account.
If you don’t have a samsung.com account, click the Sign up
button to create an account.
address: www.allshareplay.com.
Page 86
85
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
If you are connecting to the website for the rst time, the
4
software installation screen appears.
To use the AllShare Play service, install the PC software.
Register the current PC with the AllShare Play website
5
according to the instructions on the screen.
When the device registration process is completed, install the
6
unied codec according to the instructions on the site.
To use a storage service, click the [+] button and register the
7
storage to use.
You can register storage by signing up for a storage service,
such as SugarSync, that is aligned with AllShare Play.
Since up to 6 PCs can be registered, if 6 PCs have already •
been registered, you have to deregister one of the
registered PCs in order to register a new one.
Up to 5 users can be registered on one PC.•
If you register a smart phone or tablet in the AllShare Play
8
service, run AllShare Play on the device and sign in with your
Samsung account. Whenever the device is turned on, you can
access the les in the device.
Page 87
86
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
Congure PC
Setting the device status
To remotely access the les saved on a device registered with
AllShare Play,
Disable power-saving mode.
1
The PC must be turned on and should not enter the powersaving mode to use the service: click Settings at the top right
of the screen and select the Disable the standby mode of
the PC option.
Need to Keep AllShare Play in signed-in status.
2
Once you sign into AllShare Play on a PC, you can remotely
access the PC for up to 15 days even after signing o.
If the AllShare Play icon appears in the system tray, it
indicates that it is in the signed-in status. Since the AllShare
Play service automatically logs out after 15 days, please sign
in again. When the AllShare Play service is signed out, the
icon will appear gray in color.
Sharing les
Click Settings at the top right of the screen to congure the
folders to be shared with registered devices. Only the photos,
videos, and music les in the folders specied as shared folders
are listed in the le list of AllShare Play.
You can add up to 10 shared folders.
Page 88
87
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
Use AllShare Play (Play / Transfer / Upload Files)
Playing videos or viewing photos on a TV
With AllShare Play, you can play a le saved on a registered device,
nearby device, or Storage on TV. You can search for TVs that satisfy
the following 3 conditions:
The TV must be connected to the same AP (access point).•
The TV must be turned on.•
The DLNA service must be running on the TV.•
Select the checkbox of the video or photo to be displayed.
1
Click Change player at the top of the screen to search for a
2
device.
If the PC and TV are connected, a message asking you to
3
allow access appears from the TV. Allow access.
The video or photo slideshow is played on the device.
4
If the les that you want to play are stored in Registered
Devices or Registered Storage, playing videos or photo
slideshows can be slow when the network connection is
unstable.
Page 89
88
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
Playing a le
In AllShare Play, you can play a le saved on a registered device,
nearby device, or Storage.
Select the checkbox of the video or photo that you want to
1
play.
Click Play at the top of the screen.
2
A player such as Windows Media Player is launched and the
le is played.
Transferring a le
If you select a registered device or nearby device, the les
1
saved on the device are displayed on the screen.
Select a le (or les), and select a destination from the
2
Transfer menu.
You can then copy or move the le(s).
Set the player settings in the options of Windows Media
Player to keep the player on top of other windows to
always view Windows Media Player on top of other windows.
Page 90
89
Chapter 3.
Using the computer
Sharing content using the AllShare Play app
(Optional)
Uploading a le to a SNS
Select the checkbox of the le that you want to upload.
1
Click Share at the top of the screen and select a SNS (social
2
networking site) website (Facebook, Twitter, Flickr, Picasa,
etc.).
Sign in to the SNS.
3
Follow the onscreen instructions to upload the le.
4
Depending on the country, supported SNS services can vary.
Page 91
90
Chapter 3.
Using the computer
Samsung Software Update
SW Update is a software program that searches for Samsung
software programs and drivers installed when you purchased the
computer and helps you update any drivers or programs.
You can check updatable les before performing the •
update only when you are connected to the internet.
SW Update does not provide any updates for device drivers •
or software programs installed separately by the user.
From the Start Screen, right-click any area and select
1
All apps in the bottom right corner.
Then, click SW Update.
If the program is running for the rst time, the User
2
Agreement for personal information use appears.
The SW Update program runs.
3
Select the items that you want to update before proceeding
with the update process.
Software List
Software
Update
Click Agree.
Page 92
91
Chapter 3.
Using the computer
Diagnosing the Computer Status and Troubleshooting
The Support Center program, which is Samsung’s computer’s
troubleshooting guide, supports diagnosing the system and has a
FAQ for frequently occurring problem(s).
Support Center may not be provided or may be a dierent
version depending on the model.
From the Start Screen, right-click any area and select
1
All apps in the bottom right corner.
Then, click Support Center.
Support Center is activated and starts diagnosing your
2
computer.
After the diagnosing process is nished, the System Status
menu displays a list of the current problems to be solved as
shown.
Searching for
computer’s problems
Diagnosing
Computer and
Troubleshooting
FAQ for
computer’s
major problems
You can solve a problem by clicking the Troubleshoot button
3
for the problem.
Page 93
Using the Security Slot
You can secure the computer by connecting a lock and cable to
the Security Slot.
To use this feature, you have to purchase the lock and cable
additionally. To use the lock and cable, refer to the product
manual.
Tie the lock and cable to a xed object and install the other end of
the cable to the security slot.
Chapter 3.
Using the computer
92
Page 94
Chapter 4. Settings and Upgrade
BIOS Setup 94
Setting a Boot Password 97
Changing the Boot Priority 100
Page 95
94
Chapter 4.
Settings and Upgrade
BIOS Setup
The BIOS Setup enables you to congure your computer hardware
according to your needs.
Use the BIOS setup to dene a boot password, change the •
booting priority, or add a new device.
Since incorrect settings may cause your system to •
malfunction or crash, take care when conguring the BIOS.
The functions of the BIOS setup are subject to change for •
product function enhancement purposes.
The BIOS Setup menus and items may dier depending on •
your computer model.
Entering the BIOS Setup
Turn the computer on.
1
Immediately press the F2 key several times.
After a moment, the BIOS setup screen appears.
2
The items in the BIOS setup may dier depending on the
product.
Page 96
95
Chapter 4.
Settings and Upgrade
%,266HWXS
0DLQ$GYDQFHG6HFXULW\%RRW([LW
%,269HUVLRQ
&387\SH
&386SHHG
&38&RUH
7R WDO0HPRU\
0HPRU\6SHHG
0HPRU\0RGH
/DQJXDJH
6\VWHP7LPH
6\VWHP'DWH
'LVN0HQX
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
;;;;
>(QJOLVK@
>@
>@
6HOHFWWKHFXUUHQW
GHIDXOWODQJXDJHXVHG
E\%,26
>)@+HOS
>)@3UHY 9DOXHV
>)@6HWXS'HIDXOWV
>)@ 6DYH([LW
>))@ &KDQJH9DOXHV
>@6HOHFW,WHP
>@6HOHFW0HQX
>(QWHU@
6HOHFW6XE0HQX
>(6&@ ([LW
BIOS Setup
The BIOS Setup Screen
The BIOS Setup menus and items may dier depending on
your computer model.
Setup Menu
Help
Help for the selected
item appears
automatically.
Setup Items
Setup Menu Description
This is a description about the basic
Main
specications of the computer.
Using this menu, you can congure the major
Advanced
chipsets and additional functions.
Used to congure security functions, including
Security
passwords.
This menu enables you to congure
Boot
peripherals and booting related settings such
as the boot priority.
Used to exit the Setup either saving the
Exit
changes or not.
Page 97
96
Chapter 4.
Settings and Upgrade
BIOS Setup
System Setup Keys
In the Setup, you have to use the keyboard.
F1 Press to view the Setup Help.
Up & Down
Keys
F5/F6 Press to change the item value.
F9
ESC
Press to move up and down.
Press to load the default Setup
settings.
Press to return to a higher level
menu or to move to the Exit
menu.
Enter
Press to select an item or to enter
a sub menu.
Press to save the changes and exit
F10
Setup.
The keyboard image may dier from the actual keyboard.
Left & Right
Keys
Press to move to another menu.
Page 98
97
Chapter 4.
Settings and Upgrade
Setting a Boot Password
6XSHUYLVRU3DVVZRUG
FRQWUROVDFFHVVWRWKH
VHWXSXWLOLW\
>)@+HOS
>)@3UHY 9DOXHV
>)@6HWXS'HIDXOWV
>)@ 6DYH([LW
>))@ &KDQJH9DOXHV
>@6HOHFW,WHP
>@6HOHFW0HQX
>(QWHU@
6HOHFW6XE0HQX
>(6&@ ([LW
%,266HWXS
0DLQ$GYDQFHG6HFXULW\%RRW([LW
6HW6XSHUYLVRU3DVVZRUG
6XSHUYLVRU3DVVZRUG,V
6HW8VHU3DVVZRUG
8VHU3DVVZRUG,V
3DVVZRUG2Q%RRW
>+''6HFXULW\&RQILJXUDWLRQ@
&OHDUHG
&OHDUHG
>(QDEOHG@
If you set a password, you have to enter the password when you
turn the computer on or enter the BIOS Setup.
By conguring a password, you can restrict system access to
authorized users only and protect data and les saved on the
computer.
The password setting provides the following 3 sub menus. •
(Supervisor Password, User Password and HDD Password)
Do not lose or forget your password.•
Do not let others know your password.•
If you forget the Supervisor Password or HDD Password, •
you will need to request assistance from the service center.
In this case, a service fee will be charged.
When you forget the User Password, you can disable •
the Supervisor Password, and the User Password is also
automatically disabled.
The screen images and terms may dier from actual •
product depending on the computer model and driver
version.
Setting a Supervisor Password
If you set a Supervisor Password, you need to enter the password
when you turn the computer on or enter the BIOS Setup.
Setting only the Supervisor Password and User Password is not
very secure. You can use an HDD Password as well to increase the
security level.
Select the Security menu in the BIOS Setup.
1
In the Set Supervisor Password item, press <Enter>.
2
Enter a password, press <Enter>, re-enter the password for
3
conrmation, and press <Enter> again.
The password can be up to 8 characters long. You can use
English letters, numbers and special characters.
The supervisor password has been set.
4
The supervisor password is required to turn the computer on
or to enter the BIOS Setup.
For some models, if the password entered message appears
in the Setup Notice window, the settings are not complete
until the <Enter> key is pressed.
Page 99
98
Chapter 4.
Settings and Upgrade
Setting a Boot Password
Setting a User Password
Using the User Password, you can turn the computer on but you
cannot change the major settings of the BIOS Setup because you
cannot enter the BIOS Setup.
Before conguring a user password, a supervisor password must
have been congured. Deactivating the supervisor password also
deactivates the user password.
In the Set User Password item, press <Enter> and complete the
procedures from Step 3 of Setting a Supervisor Password.
Setting Up a Boot Password
To setup a boot password, the administrator password (Set
Supervisor Password) should be set in advance.
Set the Password on boot item to Enabled.
Once a boot password is set, you have to enter a password to boot
up the computer.
Setting up a Hard Disk Drive Password (Optional)
If you set a password for a hard disk drive, it cannot be accessed
from another computer.
Press <Enter> in the Set HDD Password item and dene a
password as described in Step 3 of the Setting up the Supervisor
Password.
The hard disk drive password setting function is not •
provided for some models.
Changing the hard disk drive password•
For security purposes, you can only change a hard disk
drive password after restarting the computer by pressing
the computer Power button.
If you cannot change the hard disk drive password or the
HDD Password Frozen message appears when entering
the BIOS Setup and then selecting Security > HDD
Password, press the Power button to turn the computer
on again.
Be sure to remember the password for later use.
Page 100
99
Chapter 4.
Settings and Upgrade
Setting a Boot Password
Deactivating the Password
Press <Enter> on the password to be deactivated. For
1
example, to deactivate a supervisor password in the Set
Supervisor Password item, press <Enter>.
To deactivate the hard disk drive password completely, you
must restart the system.
In the Enter Current Password item, enter the currently
2
congured password and press <Enter>.
Leave the Enter New Password item eld empty, and press
3
<Enter>.
Leave the Conrm New Password eld empty, and press
4
<Enter>.
The password is deactivated.
For some models the password is only canceled if the
<Enter> key is pressed in the Setup Notice window.
Loading...
