Samsung DM75E User Guide

User Manual
The colour and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.
Recommended hours of use per day for the DBE models is less than 16 hours.
If the product is used for longer than 16 hours a day, the warranty may be void.
Table of contents
Before Using the Product
Copyright 7
Safety Precautions 8
Symbols 8 Cleaning 8
Storage 9
Electricity and Safety 9 Installation 10 Operation 12
Preparations
Checking the Components 15
Components 15
Parts 16
Control Panel 16 Reverse Side 18 Plug In Module (Sold separately) 21 Anti-theft Lock 21 Spacer logo 22 Remote Control 23 Connection Using an IR Stereo Cable
(sold separately) 25
Before Installing the Product (Installation Guide) 26
Tilting Angle and Rotation 26 Ventilation 26
Using the COVER-JACK 28
Installing the Wall Mount 29
Preparing before installing Wall-Mount 29 Installing the Wall Mount 29 Wall Mount Kit Specifications (VESA) 30
Remote Control (RS232C) 31
Cable Connection 31 Connection 34 Control Codes 35
Connecting and Using a Source Device
Before Connecting 44
Pre-connection Checkpoints 44
Connecting to a PC 44
Connection using the D-SUB cable (Analogue type) 44
Connection using a DVI cable (Digital type) 45 Connection Using an HDMI-DVI Cable 45 Connection Using an HDMI Cable 46 Connection Using an DP Cable 46
Connecting an External Monitor 47
Connecting to a Video Device 48
Connection Using the AV Cable 48 Connection Using the component Cable 48 Connection Using an HDMI-DVI Cable 49 Connection Using an HDMI Cable 50
Connecting the LAN Cable 51
Changing the Input source 52
Source 52
Using MDC
MDC Programme Installation/Uninstallation 53
Installation 53 Uninstallation 53
Connecting to MDC 54
Using MDC via RS-232C (serial data communications standards) 54
Using MDC via Ethernet 55
Home feature
Player 57
Approving a connected device from the server 58 Network Channel 62 Local Channel 62 Published Content 62 My Templates 62 Available features in the Player page 63 Player page Settings menu 64 When Content is Running 66 File Formats Compatible with Player 68 File Formats Compatible with Videowall 73
Schedule 75
Available features in the Schedule page 75
2
Table of contents
Template 77
Clone Product 80
ID Settings 81
Device ID 81 PC Connection Cable 81 Device ID Auto Set 81
Video Wall 82
Apply to 82 Video Wall 83
Network Status 84
Picture Mode 85
On/Off Timer 86
On Timer 86 Off Timer 87 Holiday Management 87
Ticker 88
More settings 88
URL Launcher 89
Screen Adjustment
Picture Mode 90
Backlight / Contrast / Brightness / Sharpness / Colour / Tint (G/R)
Colour Temperature 92
White Balance 93
2 Point 93 10 Point 93
Gamma 94
Calibrated value 94
Advanced Settings 95
Dynamic Contrast 96 Black Tone 96 Flesh Tone 96 RGB Only Mode 96 Colour Space 96 Motion Lighting 96
Picture Options 97
Colour Tone 98 Digital Clean View 98 MPEG Noise Filter 98 HDMI Black Level 99 Film Mode 99 Motion Plus 100 Dynamic Backlight 100
91
Position 102 Zoom/Position 102 Resolution 103
Auto Adjustment 104
PC Screen Adjustment 104
Picture Off 105
Reset Picture 105
OnScreen Display
PIP 106
PIP Settings 106
Display Orientation 108
Onscreen Menu Orientation 108 Source Content Orientation 108 Aspect Ratio 108
Screen Protection 109
Auto Protection Time 109 Screen Burn Protection 109
Message Display 112
Source Info 112 No Signal Message 112 MDC Message 112 Download Status Message 112
Picture Size 101
Picture Size 101
Menu Language 113
Reset OnScreen Display 113
3
Table of contents
Sound Adjustment
Sound Mode 114
Sound Effect 115
Virtual Surround 115 Dialog Clarity 115 Equaliser 115
HDMI Sound 116
Sound on Video Call 116
Dolby Digital Comp 117
Speaker Settings 117
Sound Output 117
Auto Volume 118
Reset Sound 118
Network
Network Status 119
Network Settings 119
Network type 119 Network Settings (Wired) 120 Network Setting (Wireless) 122 WPS(PBC) 124
Wi-Fi Direct 125
Multimedia Device Settings 125
Screen Mirroring 126
Screen Mirroring 126
Server Network Settings 126
Connect to server 126 MagicInfo Mode 126 Server Access 126 FTP Mode 126
Device Name 127
System
Accessibility 128
Menu Transparency 128 High Contrast 128 Enlarge 128
Setup 129
Initial settings (System) 129
Touch Control 131
Touch Control Lock 131 Admin Menu Lock 131
Time 132
Clock Set 132 DST 132 Sleep Timer 132 Power On Delay 132
Auto Source Switching 133
Auto Source Switching 133 Primary Source Recovery 133
Primary Source 133 Secondary Source 133
Power Control 134
Auto Power On 134 PC module power 134 Max. Power Saving 134 Standby Control 135 Power Button 135 Network Standby 135
Eco Solution 136
Energy Saving 136 Eco Sensor 136 Screen Lamp Schedule 136 No Signal Power Off 137 Auto Power Off 137
Temperature Control 137
Device Manager 138
Keyboard Settings 138 Mouse Settings 139 Pointer Settings 140
Play via 141
Change PIN 141
Security 142
Safety Lock 142 Button Lock 142 USB Auto Play Lock 143 Mobile Connection Lock 143
General 144
4
Table of contents
Smart Security 144 BD Wise 145 Anynet+ (HDMI-CEC) 146 Troubleshooting for Anynet+ 148 HDMI Hot Plug 150 DivX® Video On Demand 150 Game Mode 150
Reset System 151
Support
Software Update 152
Update now 152 Auto update 152
Contact Samsung 153
Go to Home 154
Player 154 Schedule 154 Template 154 Clone Product 154 ID Settings 154 Video Wall 155 Network Status 155 Picture Mode 155 On/Off Timer 155 Ticker 155 More settings 155
Playing photos, videos and music (Media Play)
Read the following before using media play with a USB device 157
Using a USB device 159 Playing media content from a PC/mobile device 160
Features provided in the media content list page 161
Menu items in the media content list page 162
Available buttons and features during photo playback 163
Available buttons and features during video playback 164
Available buttons and features during music playback 165
Supported Subtitle and Media play file formats 166
Subtitle 166 Supported image resolutions 166 Supported music file formats 167 Supported Video Formats 167
Troubleshooting Guide
Requirements Before Contacting Samsung Customer Service Centre 169
Testing the Product 169 Checking the Resolution and Frequency 169 Check the followings. 170
Q & A 177
Specifications
General 179
Preset Timing Modes 182
Reset All 156
5
Table of contents
Appendix
Responsibility for the Pay Service (Cost to Customers) 184
Not a product defect 184 A Product damage caused by customer's fault 184 Others 184
WEEE 185
Correct Disposal of This Product (Waste Electrical & Electronic Equipment) 185
Correct disposal of batteries in this product 185
Optimum Picture Quality and Afterimage Burn-in Prevention 186
Optimum Picture Quality 186 Prevention of Afterimage Burn-in 186
Licence 188
Terminology 189
6
Chapter 01
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2015 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
An administration fee may be charged if either
-
(a) an engineer is called out at your request and there is no defect in the product (i.e. where you have failed to read this user manual).
-
(b) you bring the unit to a repair centre and there is no defect in the product (i.e. where you have failed to read this user manual).
The amount of such administration charge will be advised to you before any work or home visit is carried out.
7
Safety Precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been included with this product.
Symbols
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Power off the product and computer.
1
Disconnect the power cord from the product.
2
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
Wipe the product with a clean, soft and dry cloth.
3
Do not use detergents that contain alcohol, solvent or surface-active agents.
!
Do not spray water or detergent directly on the product.
Warning
A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
Wet a soft and dry cloth in water and wring thoroughly to clean the
4
exterior of the product.
Connect the power cord to the product when cleaning is finished.
5
Power on the product and computer.
6
8
Storage
Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white­coloured stains on the product.
Contact Customer Service Centre if the inside of the product needs cleaning (service fee will be
charged).
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
An electric shock or fire may result.
Do not use multiple products with a single power socket.
Overheated power sockets may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices only).
An electric shock or injury may result.
!
Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy object.
Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
A fire or electric shock may result.
Clean any dust around the pins of the power plug or the power socket with a dry cloth.
A fire may result.
!
Do not touch the power plug with wet hands. Otherwise, an electric shock may result.
Insert the power plug all the way in so it is not loose.
An unsecure connection may cause a fire.
!
9
Caution
!
!
!
Do not disconnect the power cord while the product is being used.
The product may become damaged by an electric shock.
Only use the power cord provided with your product by Samsung. Do not use the power cord with other products.
A fire or electric shock may result.
Keep the power socket where the power cord is connected unobstructed.
The power cord must be disconnected to cut off power to the product when an issue occurs.
Note that the product is not completely powered down by using only the power button on the remote.
Hold the plug when disconnecting the power cord from the power socket.
An electric shock or fire may result.
Installation
Warning
!
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
A fire may result.
Have a technician install the wall-mount hanger.
Installation by an unqualified person can result in an injury.
Only use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or closet.
An increased internal temperature may cause a fire.
Install the product at least 10 cm away from the wall to allow ventilation.
An increased internal temperature may cause a fire.
!
Keep the plastic packaging out of the reach of children.
Children may suffocate.
!
10
Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.)
The product may fall and become damaged and/or cause an injury.
Using the product in an area with excess vibration may damage the product or cause a fire.
Caution
Do not drop the product while moving.
Product failure or personal injury may result.
Do not install the product in a vehicle or a place exposed to dust, moisture
!
(water drips, etc.), oil, or smoke.
A fire or electric shock may result.
!
Do not set down the product on its front.
The screen may become damaged.
Do not expose the product to direct sunlight, heat, or a hot object such as a stove.
The product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
The product may fall and injure children.
As the front is heavy, install the product on a flat and stable surface.
Edible oil, such as soybean oil, can damage or deform the product. Do not
!
When installing the product on a cabinet or shelf, make sure that the bottom edge of the front of the product is not protruding.
The product may fall and become damaged and/or cause an injury.
Install the product only on cabinets or shelves of the right size.
Set down the product gently.
Product failure or personal injury may result.
install the product in a kitchen or near a kitchen counter.
Installing the product in an unusual place (a place exposed to a lot of fine dust, chemical substances, extreme temperatures or a significant presence of moisture, or a place where the product will operate continuously for an
SAMSUNG
!
extended period of time) may seriously affect its performance.
Be sure to consult Samsung Customer Service Centre if you want to install the product at such a place.
11
Operation
Warning
Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the product.
The product or heavy objects may fall as children try to reach for the toys or sweets resulting in a serious injury.
There is a high voltage inside the product. Never disassemble, repair or modify the product yourself.
A fire or electric shock may result.
Contact Samsung Customer Service Centre for repairs.
!
Before moving the product, turn off the power switch and disconnect the power cable and all other connected cables.
Damage to the cord may result in a fire or electric shock.
!
If the product generates abnormal sounds, a burning smell or smoke, disconnect the power cord immediately and contact Samsung Customer Service Centre.
An electric shock or fire may result.
!
Do not let children hang from the product or climb on top of it.
Children may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power switch and disconnect the power cord. Then contact Samsung Customer Service Centre.
Continued use can result in a fire or electric shock.
!
!
GAS
During a lightning or thunderstorm, power off the product and remove the power cable.
A fire or electric shock may result.
Do not drop objects on the product or apply impact.
A fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
Product failure, an electric shock or fire may result from a damaged cable.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate the area immediately.
Sparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
Product failure, an electric shock or fire may result from a damaged cable.
12
Do not use or keep combustible spray or an inflammable substance near the product.
An explosion or fire may result.
!
Ensure the vents are not blocked by tablecloths or curtains.
An increased internal temperature may cause a fire.
100
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn easily (paper, matches, etc) into the product (via the vent or input/ output ports, etc).
Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product. Then contact Samsung Customer Service Centre.
Product failure, an electric shock or fire may result.
Caution
!
-_-
!
!
Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels.
Activate power-saving mode or a moving-picture screen saver if you will not be using the product for an extended period of time.
Disconnect the power cord from the power socket if you do not plan on using the product for an extended period of time (vacation, etc).
Dust accumulation combined with heat can cause a fire, electric shock or electric leakage.
Use the product at the recommended resolution and frequency.
Your eyesight may deteriorate.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the product.
Be sure to power off the product and disconnect the power cord when water or other foreign substances have entered the product. Then contact Samsung Customer Service Centre.
Product failure, an electric shock or fire may result.
Do not hold the product upside-down or move it by holding the stand.
The product may fall and become damaged or cause an injury.
Looking at the screen too close for an extended period of time can deteriorate your eyesight.
!
Do not use humidifiers or stoves around the product.
A fire or electric shock may result.
13
Rest your eyes for more than 5 minutes for every 1 hour of product use.
Eye fatigue will be relieved.
!
Be careful that children do not place the battery in their mouths when removed from the remote control. Place the battery in a location that children or infants cannot reach.
If children have had the battery in their mouths, consult your doctor immediately.
Do not touch the screen when the product has been turned on for an extended period of time as it will become hot.
Store small accessories out of the reach of children.
!
Exercise caution when adjusting the product angle or stand height.
Your hand or finger may get stuck and injured.
Tilting the product at an excessive angle may cause the product to fall
!
and an injury may result.
Do not place heavy objects on the product.
Product failure or personal injury may result.
When using headphones or earphones, do not turn the volume too high.
Having the sound too loud may damage your hearing.
!
!
When replacing the battery, insert it with the right polarity (+, -).
Otherwise, the battery may become damaged or it may cause fire, personal injury or damage due to leakage of the internal liquid.
Use only the specified standardized batteries, and do not use a new battery and a used battery at the same time.
Otherwise, the batteries may be damaged or cause fire, personal injury or damage due to a leakage of the internal liquid.
The batteries (and rechargeable batteries) are not ordinary refuse and must be returned for recycling purposes. The customer is responsible for returning the used or rechargeable batteries for recycling.
The customer can return used or rechargeable batteries to a nearby public recycling centre or to a store selling the same type of the battery or rechargeable battery.
14
Chapter 02
Preparations
-
Contact the vendor where you purchased the product if any components are missing.
-
A stand is not provided with the product. To install a stand, you can purchase one separately.
-
The RS232C adapter can be used to connect to another monitor using the D-SUB (9-pin) type RS232C cable.
-
For LH32DMEPLGP/EN model, Power cord, Quick Setup Guide, and Warranty card are provided only.
Checking the Components
Components
Components may differ in different locations.
Quick Setup Guide
-
-
Batteries
(Not available in some locations)
+
+
Warranty card
(Not available in some locations)
Remote Control D-SUB cable RS232C(IN) adapter
Regulatory guide Power cord
COVER-JACK
(The DM65E and DM75E models are not supported.)
Screw (M3L8, 1EA) (M4L8, 4EA)
(The DM65E and DM75E models are not supported.)
Holder-Ring (4EA)
(DM65E, DM75E models are only supported.)
15
Parts
Control Panel
Panel Key
DB32E DM32E
Speaker
The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to
improve quality.
Panel Key
Buttons Description
Power on the product.
If you press the button when the product is turned on, the control menu will be displayed.
To exit the OSD menu, press and hold the panel key for at least one second.
Move to the upper or lower menu. You can also adjust the value of an option.
Move to the left or right menu.
You can adjust the volume by moving the panel key left or right when the control
menu is not displayed.
Press a button on the remote control pointing at the sensor on the front of the
Remote sensor
product to perform the corresponding function.
Using other display devices in the same space as the remote control of this
product can cause the other display devices to be inadvertently controlled.
Speaker
Remote sensor
Use the remote control within 7 m to 10 m from the sensor on the product at an angle of 30
Store used batteries out of reach of children and recycle.
Do not use a new and used battery together. Replace both batteries at the same time.
Remove batteries when the remote control is not to be used for an extended period of time.
from the left and right.
16
If you press the button on the panel key when the product is turned on, the
control menu will be displayed.
Control menu
Buttons Description
Select the connected input source.
Source
Menu
Move the panel key right to select Source input sources is displayed, move the panel key left or right to select the desired input source. Next, press the panel key.
Display the OSD menu.
Move the panel key left to select Menu screen will appear. Move the panel key right to select the desired menu. You can select a sub-menu item by moving the panel key up, down, left, or right. To change settings, select the desired menu and press the panel key.
in the control menu. When the list of
in the control menu. The OSD control
Return
Home
Power o
Return
Enter Go to Home mode.
Move the panel key up to select Home
Power off the product.
Move the panel key down to select the panel key.
Exit the control menu.
Power o
in the control menu.
in the control menu. Next, press
17
Reverse Side
Port Description
The colour and shape of parts may differ from what is shown. Specifications are
subject to change without notice to improve quality.
Models DB32E, DB40E, DB48E, DB55E and DM32E are only supported.
RS232C IN
RS232C OUT
RGB / DVI / HDMI / AV /
COMPONENT
AUDIO IN
AUDIO OUT
SD CARD
USB
DVI /
MAGICINFO IN
RS232C IN
RS232C OUT
RGB / DVI / HDMI / AV / COMPONENT
AUDIO IN
AUDIO OUT
SD CARD
USB
DVI / MAGICINFO IN
HDMI IN
AV IN / COMPONENT IN
IR / AMBIENT SENSOR IN
RGB IN
RJ45
Connects to MDC using an RS232C adapter.
Receives sound from a PC via an audio cable.
Connects to the audio of a source device.
Connect to an SD memory card.
Connect to a USB memory device.
DVI: Connects to a source device using a DVI cable or HDMI-DVI cable.
MAGICINFO IN: Use the (dedicated) DP-DVI cable when connecting a network box (sold separately).
Connects to a source device using an HDMI cable.
Connects to a source device using the AV/Component adapter.
Supplies power to the external sensor board or receives the light sensor signal.
Connects to a source device using a D-SUB cable.
Connects to MDC using a LAN cable.
HDMI IN
COMPONENT IN
RGB IN RJ45
18
Reverse Side
Port Description
The colour and shape of parts may differ from what is shown. Specifications are
subject to change without notice to improve quality.
Models DM40E, DM48E, DM55E, DM65E and DM75E are only supported.
RS232C IN
RS232C OUT
IR / AMBIENT
SENSOR IN
RGB / DVI / HDMI / AV /
COMPONENT
AUDIO IN
AUDIO OUT
DM65E DM75E
SD CARD
USB
DVI /
MAGICINFO IN
USB (5V, 1.5A)
RS232C IN
RS232C OUT
IR / AMBIENT SENSOR IN
RGB / DVI / HDMI / AV / COMPONENT
AUDIO IN
AUDIO OUT
SD CARD
USB
DVI / MAGICINFO IN
DP IN
HDMI IN 1 / HDMI IN 2
RGB IN
DP OUT
Connects to MDC using an RS232C adapter.
Supplies power to the external sensor board or receives the light sensor signal.
Receives sound from a PC via an audio cable.
Connects to the audio of a source device.
Connect to an SD memory card.
Connect to a USB memory device.
DVI: Connects to a source device using a DVI cable or HDMI-DVI cable.
MAGICINFO IN: Use the (dedicated) DP-DVI cable when connecting a network box (sold separately).
Connects to a PC using a DP cable.
Connects to a source device using an HDMI cable.
Connects to a source device using a D-SUB cable.
Connects to another product using a DP cable.
DP IN
HDMI IN 1
RGB IN RJ45DP OUT
HDMI IN 2
COMPONENT IN
OUT
AV IN / COMPONENT IN
IR OUT
IR
RJ45
Connects to a source device using the AV/Component adapter.
Receives the remote control signal via the external sensor board and outputs the signal via LOOP OUT.
Connects to MDC using a LAN cable.
19
Reverse Side
Port Description
The colour and shape of parts may differ from what is shown. Specifications are
subject to change without notice to improve quality.
Models DH40E, DH48E and DH55E are only supported.
RS232C IN
RS232C OUT
IR / AMBIENT
SENSOR IN
RGB / DVI / HDMI / AV /
COMPONENT
AUDIO IN
AUDIO OUT
SD CARD
USB
DVI /
MAGICINFO IN
RS232C IN
RS232C OUT
IR / AMBIENT SENSOR IN
RGB / DVI / HDMI / AV / COMPONENT
AUDIO IN
AUDIO OUT
SD CARD
USB
DVI / MAGICINFO IN
DP IN
HDMI IN 1
RGB IN
DP OUT
Connects to MDC using an RS232C adapter.
Supplies power to the external sensor board or receives the light sensor signal.
Receives sound from a PC via an audio cable.
Connects to the audio of a source device.
Connect to an SD memory card.
Connect to a USB memory device.
DVI: Connects to a source device using a DVI cable or HDMI-DVI cable.
MAGICINFO IN: Use the (dedicated) DP-DVI cable when connecting a network box (sold separately).
Connects to a PC using a DP cable.
Connects to a source device using an HDMI cable.
Connects to a source device using a D-SUB cable.
Connects to another product using a DP cable.
DP IN
HDMI IN 1
RGB IN RJ45DP OUT
COMPONENT IN
OUT
AV IN / COMPONENT IN
IR OUT
IR
RJ45
Connects to a source device using the AV/Component adapter.
Receives the remote control signal via the external sensor board and outputs the signal via LOOP OUT.
Connects to MDC using a LAN cable.
20
Plug In Module (Sold separately)
PIM Slot
To use Plug In Module, make sure you connect a Samsung PIM (sold separately).
To connect a device made by another manufacturer, ensure the device is compatible with Open Pluggable Specification (OPS) standards.
For details on how to connect a device, refer to the user manual provided with the PIM upon
purchase.
To obtain optimum audio quality, configure the HDMI audio settings using the Windows Control Panel
on the OPS device. For products made by other manufacturers, this only applies to HDMI compatible devices.
To enable sound output from the product with an OPS device that does not support HDMI, configure
the analogue audio settings using the Windows Control Panel, go to Plug In Module > Edit Name and set the input source to PC, DVI PC or DVI.
Only DM65E, DM75E and DHE models are supported.
To use the WoL (Wake on Lan) feature on the DH55* model, set Network Standby to On.
Menu System Power Control Network Standby On
Anti-theft Lock
An anti-theft lock allows you to use the product securely even in public places.
The locking device shape and locking method depend on the manufacturer. Refer to the user guide
provided with your anti-theft locking device for details.
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
To lock an anti-theft locking device:
Fix the cable of your anti-theft locking device to a heavy object such as a desk.
1
Put one end of the cable through the loop on the other end.
2
Insert the locking device into the anti-theft lock slot at the back of the product.
3
Lock the locking device.
4
-
An anti-theft locking device can be purchased separately.
-
Refer to the user guide provided with your anti-theft locking device for details.
-
Anti-theft locking devices can be purchased at electronics retailers or online.
21
Spacer logo
Do not pull on the spacer logo using force. The logo may tear or break off.
22
Remote Control
CH
DEL-/--
CH LIST
Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.
A button without a description in the image below is not supported on the product.
Power on the product.
Adjust the volume.
Change the input source.
Display or hide the onscreen display menu, or
return to the previous menu.
.QZ
1
GHI
4
PRS
7
VOL
MENU
ABC
2
JKL
5
TUV
8
SYMBOL
0
MUTE
SOURCE
HOME
POWER
OFF
DEF
3
MNO
6
WXY
9
MagicInfo
Player I
Power off the product.
Number buttons Enter the password in the OSD menu.
Mute the sound. Unmuting the sound: Press MUTE again or press
the volume control(+ VOL -) button.
Use this hotkey to directly access MagicInfo. This hotkey is available when a network box or PIM (Plug In Module) is connected.
Go to Home Launch Button.
-
Remote control button functions may differ for different products.
23
Quickly select frequently used functions.
TOOLS INFO
Display information about the current input source.
Move to the upper, lower, left or right menu, or adjust an option's setting.
Confirm a menu selection.
Return to the previous menu.
It sets safe lock function.
If multiple products are connected through the
Video Wall feature, press the SET button and
enter a product ID using the number buttons.
Control the product using the remote control.
Cancel a value that has been set using the
SET button and control all connected products
using the remote control.
To place batteries in the remote control
PC
A
SET
IR control
DVI
B
UNSET
HDMI
C
LOCK
EXITRETURN
DP
D
Exit the current menu.
Manually select a connected input source from
PC, DVI, HDMI or DisplayPort.
The DP button is not available with the DBE
and DM32E models.
-
Remote control button functions may
Used in Anynet+ mode and multimedia mode.
differ for different products.
24
Connection Using an IR Stereo Cable (sold separately)
The DBE and DM32E models do not support the IR OUT port.
Make sure to connect the External ambient sensor while the product is powered off. Then, power on the product.
Controlling more than one display product using your remote control
Connect the IR OUT port on the product to the IR / AMBIENT SENSOR IN port on the other display product using the dedicated stereo cable.
A command sent from the remote control pointed at product
1
received by both display products
The appearance may differ depending on the product.
and 2.
1
will be
1 2
IR OUT IR / AMBIENT
SENSOR IN
Controlling more than one display product using an External ambient sensor (sold separately)
A command sent from the remote control pointed at product the External ambient sensor is connected) will be received by both display
products
The appearance may differ depending on the product.
1
and 2.
1
(to which
POWER
SOURCE
IR / AMBIENT SENSOR IN
1 2
IR OUT IR / AMBIENT
SENSOR IN
25
Before Installing the Product (Installation Guide)
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
Ensure that an authorized installation company installs the wall mount.
Otherwise, it may fall and cause personal injury.
Make sure to install the specified wall mount.
15˚
Tilting Angle and Rotation
Contact Samsung Customer Service Centre for further details.
The product can be tilted at a maximum angle of 15
To use the product vertically (portrait), turn it clockwise so that the LED is pointing down.
from a perpendicular wall surface.
Ventilation
Installation on a Perpendicular Wall
A Minimum 40 mm
B Ambient temperature: Under 35
A
When installing the product on a perpendicular wall, allow at least 40 mm of space between the product and wall surface for ventilation and ensure that the ambient A temperature is kept below 35
C
C.
B
Figure 1.1 Side view
26
Figure 1.3 Side view
B
Installation on an Indented Wall
Contact Samsung Customer Service Centre for further details.
A
C
E
Figure 1.2 Side view
D D
Plane view
A Minimum 40 mm
B Minimum 70 mm
C Minimum 50 mm
D Minimum 50 mm
E Ambient temperature: Under 35
When installing the product on an indented wall, allow at least the space specified above between the product and wall for
ventilation and ensure that the ambient temperature is kept below 35
C
C.
27
Using the COVER-JACK
DB40E / DB48E / DB55E / DM40E / DM48E / DM55E / DH40E / DH48E / DH55E
The DM65E and DM75E models are not supported.
To prevent theft of the SD memory card or any other USB device, install the COVER-JACK.
The following images are for reference only. Real-life situations may differ from what is shown in the images.
When using a DVI cable, make sure to cut off the side of the COVER-JACK first.
Cut out the Cover-Jack according to the DVI cable size before use.
28
Installing the Wall Mount
Preparing before installing Wall-Mount
To install a wall-mount from another manufacturer, use the Holder-Ring(1).
DM65E, DM75E models are only supported.
Installing the Wall Mount
1
The wall mount kit (sold separately) allows you to mount the product on the wall.
For detailed information on installing the wall mount, see the instructions provided with the wall mount.
We recommend you contact a technician for assistance when installing the wall mount bracket.
Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own.
29
Wall Mount Kit Specications (VESA)
Install your wall mount on a solid wall perpendicular to the floor. Before
attaching the wall mount to surfaces other than plaster board, please contact your nearest dealer for additional information.
If you install the product on a slanted wall, it may fall and result in severe personal injury.
Samsung wall mount kits contain a detailed installation manual and all parts necessary for assembly are provided.
Do not use screws that are longer than the standard length or do not comply with the VESA standard screw specifications. Screws that are too long may cause damage to the inside of the product.
For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ depending on the wall mount specifications.
Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents.
Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
Do not mount the product at more than a 15 degree tilt.
Always have two people mount the product on a wall.
Standard dimensions for wall mount kits are shown in the table below.
Unit: mm (inches)
Model name VESA screw hole
Standard Screw Quantity specs (A * B) in millimeters
DB32E / DB40E / DM32E / DM40E / DH40E
DB48E / DB55E / DM48E / DM55E / DM65E / DM75E / DH48E / DH55E
Do not install your Wall Mount Kit while your product is turned on. It may result in personal injury due to electric shock.
200 × 200 (7.9 × 7.9)
M8 / L14 ~ 16 4
400 × 400 (15.7 × 15.7)
30
Loading...
+ 159 hidden pages
