Page 1
16
1. MAIN ASSEMBLY
1-1
1-2
1-5
1-5
1-4
1-3
Page 2
17
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
1-1 Q9007214101A FRONT COVER ASS'Y-DIGIMAX U-CA 401 1
Q9007214201A FRONT COVER ASS'Y-KENOX ME-4 1
1-2 Q9007214301A REAR COVER ASS'Y 1
1-3 Q6003043501A SCREW 1
1-4 Q6003043401A SCREW 1
1-5 Q6003043701A SCREW 5
Page 3
1818
2. BODY ASSEMBLY
2-53
2-50
2-
2-56
2-8
2-12
2-7
2-6
2-29
2-10
2-51
2-52
2-39
2-40
2-41
2-46
2-43
2-44
2-42
2-54
1
3
2-
2-48
2-55
1
2-3
2-24
2-11
2-37
2-9
2-36
2-38
2-47
2-34
2-45
2-31
2-23
2-22
2-13
2-49
2-33
2-1
2-4
2-2
2-35
2-24
2-3
2-
2-33
2-15
2-18
2-14
2-17
2-31
2-28
2-6
2-27
2-5
2-31
2-16
2-19
2-20
2-21
2-30
2-32
2-26
2-25
Page 4
19
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
2-1 Q7211070401A FRAME 1
2-2 Q7411111001A HAND_TRIP_SHAFT 1
2-3 Q7211070501A HAND_TRIP_HOLDER 1
2-4 Q6003043301A SCREW 2
2-5 Q6107057701A RELEASE_SPRING 1
2-6 Q7409166601A SHT_SHIELD_GASKET 2
2-7 Q9008075401A PCB_SHT SMD 1
2-8 Q7409166301A BAT_CAPTION_A 1
2-9 Q7409165801A SHT_PORON 1
2-10 Q7211070601A SHUTTER_KEY 1
2-11 Q7211070701A POWER_KEY 1
2-12 Q7211070801A SHUTTER_HOLDER 1
2-13 Q7011047801A K_SHELL 1
2-14 Q7409165901A BAT_PORON 1
2-15 Q7211070901A RELEASE_KNOB 1
2-16 Q9008075501A PCB_PW SMD 1
2-17 Q7409166701A PW-MIC_SHIELD_GASKET 1
2-18 Q4102008801A PW-BAT FPC 1
2-19 Q7409166801A PW-D_SHIELD_GASKET 1
2-20 Q7409166901A PW&D_SHIELD_GASKET 3
2-21 Q7011047901A EE_PW_PLATE 1
2-22 Q9008075601A PCB_D SMD 1
2-23 Q7409166101A K_CAPTION 1
2-24 Q7409165301A SR&K_TAPE 2
2-25 Q7411111101A BAT_SHAFT 1
2-26 Q6107057801A BAT_SPRING 1
2-27 Q7011048001A BAT_FRAME 1
2-28 Q7211071001A BAT_COVER 1
2-29 Q6107057901A LENS_RING 1
2-30 Q7309043201A IO_COVER 1
2-31 Q6003043401A SCREW 5
2-32 Q6003043501A SCREW 1
2-33 Q6003043601A SCREW 3
2-34 Q6003043701A SCREW 1
2-35 Q9002130401A LENS_UNIT 1
2-36 Q7409165401A LDF_MASK 1
2-37 Q2904002401A LDF 1
2-38 Q7309043301A LDF_RUBBER 1
2-39 Q7012081401A CCD_PLATE 1
2-40 Q9008075701A CCD SMD 1
2-41 Q9004016801A STROBE ASS'Y 1
2-42 Q9008075801A PCB_ST SMD 1
2-43 Q7211071101A ST_HOLDER 1
2-44 Q7011048101A ST_TERMINAL 1
2-45 Q7011048201A ST_METAL_COVER 1
2-46 Q7409165701A ST_TUBE 1
2-47 Q7011048301A ST_PLATE 2
2-48 Q7409166201A ST_CAPTION 1
2-49 Q7211071201A ST_COVER 1
2-50 Q9008075901A PCB_BAT SMD 1
2-51 Q7409166301A BAT_CAPTION_A 1
2-59 Q7409166501A BAT_CAPTION_C 2
2-53 Q6107058001A BATTERY_SPRING_A 4
2-54 Q7409167001A SHT_SHIELD_GASKET 1
2-55 Q7409167101A BAT_SHIELD_GASKET_A 1
2-56 Q7409167201A BAT_SHIELD_GASKET_B 2
Page 5
2020
3. FRONT COVER ASSEMBLY
3-1
3-9
3-3
3-2
3-8
3-4
3-5
3-6
3-4
3-7
Page 6
2121
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
3-1 Q9007214101A FRONT COVER ASS'Y-DIGIMAX U-CA 401 1
Q9007214201A FRONT COVER ASS'Y-KENOX ME-4 1
3-2 Q7217321801A FRONT COVER 1
3-3 Q7217321901A VIEW_FINDER_WIN 1
3-4 Q7409165101A FRONT_SHIELD 2
3-5 Q7217322001A FRONT_MIRROR 1
3-6 Q7217322101A FRONT_COSMETIC_A 1
3-7 Q7017041501A FRONT_COSMETIC-DIGIMAX U-CA 401 1
Q7017041601A FRONT_COSMETIC-KENOX ME-4 1
3-8 Q7409166001A PW_CAPTION 1
3-9 Q7217322601A SAMSUNG_LOGO 1
Page 7
2222
4. REAR COVER ASSEMBLY
4-1
4-19
4-6
4-18
4-17
4-15
4-5
4-16
4-14
4-9
4-3
4-11
4-2
4-4
4-8
4-12
4-7
4-10
4-13
Page 8
2323
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
4-1 Q9007214301A REAR COVER ASS'Y 1
4-2 Q7217322201A REAR COVER 1
4-3 Q7217322301A LED_PIPE_R 1
4-4 Q7217322401A FUNCTION_KEY 1
4-5 Q7017041401A FUNCTION_KEY_SHEET 1
4-6 Q6107058101A FUNCTION_KEY_SPRING 1
4-7 Q0704010101A SONY_LCD_PANEL 1
4-8 Q7217322501A DP_HOLDER 1
4-9 Q6003043801A SCREW 1
4-10 Q7409165501A K_SPONGE 1
4-11 Q7409165601A LCD_K_TAPE 1
4-12 Q2209002801A MICROPHONE 1
4-13 Q4719003301A SPEAKER 1
4-14 Q9008076001A PCB_K 1
4-15 Q7409167301A D&K_SHIELD_GASKET 1
4-16 Q7409165301A SR&K_TAPE 1
4-17 Q9007214401A PLAY/BACK_KEY ASS'Y 1
4-18 Q9007214501A 5WAYKEY_KEY ASS'Y 1
4-19 Q9007214601A REAR COVER SUB ASS'Y 1
Page 9
2424
5. PACKING ITEM
5-13 5-14 5-15
5-9
5-19
5-18
5-1
5-16
5-10
5-11
5-12
5-17
5-3
5-4
5-7
5-6
5-5
5-8
5-2
Page 10
2525
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
5-1 QP960210101A PE BAG (FOR CAMERA) 1
5-2 Q6909011601A PE BAG (FOR ACCESSORY) 1
5-3 Q6901187401A INNER PAD_U-CA 401 1
5-4 Q6904025501A POUCH_U-CA 401 1
5-5 Q6806188901A Q/GUIDE_KENOX CD4_KOR 1
Q6806189001A Q/GUIDE_U-CA 401_ENG 1
Q6806189101A Q/GUIDE_U-CA 401_GER 1
Q6806189201A Q/GUIDE_U-CA 401_FRA 1
Q6806189301A Q/GUIDE_U-CA 401_SPA 1
Q6806189401A Q/GUIDE_U-CA 401_ITA 1
Q6806189501A Q/GUIDE_U-CA 401_CHI(T) 1
Q6806189601A Q/GUIDE_U-CA 401_DUT 1
Q6806189701A Q/GUIDE_U-CA 401_POR 1
Q6806189801A Q/GUIDE_U-CA 401_SWE 1
Q6806189901A Q/GUIDE_U-CA 401_DEN 1
Q6806190001A Q/GUIDE_U-CA 401_FIN 1
Q6806190101A Q/GUIDE_U-CA 401_RUS 1
Q6806190201A Q/GUIDE_U-CA 401_CHI(S) 1
5-6 Q6806190301A U/MANUAL_KENOX CD4_KOR 1
Q6806190401A U/MANUAL_U-CA 401_ENG 1
Q6806190501A U/MANUAL_U-CA 401_GER 1
Q6806190601A U/MANUAL_U-CA 401_FRA 1
Q6806190701A U/MANUAL_U-CA 401_SPA 1
Q6806190801A U/MANUAL_U-CA 401_ITA 1
Q6806190901A U/MANUAL_U-CA 401_CHI(T) 1
Q6806191001A U/MANUAL_U-CA 401_DUT 1
Q6806191101A U/MANUAL_U-CA 401_POR 1
Q6806191201A U/MANUAL_U-CA 401_SWE 1
Q6806191301A U/MANUAL_U-CA 401_DEN 1
Q6806191401A U/MANUAL_U-CA 401_FIN 1
Q6806191501A U/MANUAL_U-CA 401_RUS 1
Q6806191601A U/MANUAL_U-CA 401_CHI(S) 1
Page 11
2626
Fig.No. Parts No. Parts Name Q'ty Remarks
5-7 Q6807002601F WARRANTY CARD_KOREA 1
Q6807003003S WARRANTY CARD_EXP 1
Q6807003802D WARRANTY CARD_UK 1
Q6807010902B WARRANTY CARD_RUS(3 YEARS) 1
Q6807011301B WARRANTY CARD_TSOE(CHINA) 1
5-8 Q6901188401A G/T BOX_KENOX CD4_KOR_Li-ion 1
Q6901187601A G/T BOX_U-CA 401_EXP/AUS 1
Q6901187701A G/T BOX_U-CA 401_USA/CAN 1
Q6901188501A G/T BOX_U-CA 401_EXP/AUS_Li-ion 1
Q6901188601A G/T BOX_U-CA 401_USA/CAN_Li-ion 1
5-9 Q4301002601A DURACELL_LITHIUM BATTERY_CP1 1
5-10 Q4302000201A LITHIUM-ION_SLB-1037(SDI) 1
5-11 Q3719003301A AC Adapter 5V low cost(SAC-51) 1
5-12 Q3801003001A AC CODE CABLE_KOR-D1 1
Q3801003201A AC CODE CABLE_EXP-D1 1
Q3801003101A AC CODE CABLE_USA-D1 1
Q3801001001A AC CODE CABLE_UK-DSC220SE 1
5-13 Q7409145001A STRAP_DIGIMAX_UCA 3_KOR/EXP 1
5-14 Q3802002001A USB CABLE_V4/V3 1
5-15 Q3802001901A A/V CABLE_V4/V3 1
5-16 Q4602000901A MEMORY STICK_DUO CARD(32MB) 1
5-17 Q4609007201A DRIVER + Digimax Viewer 2.1+ Arcsoft PI 4.0 1
Q4609007301A DRIVER + Digimax Viewer 2.1+ Arcsoft PI 3.0(Walmart) 1
5-18 Q7409155001A FCC LABEL_U-CA 401_EXP (MADE IN CHINA) 1
Q7409155101A FCC LABEL_U-CA 401_EXP (MADE BY SAMSUNG) 1
Q7409155201A MIC LABEL_KENOX CD4_KOR (MADE IN CHINA) 1
5-19 Q6804055401A PRODUCT STICKER_U-CA 401 1
