SAMSUNG CS-15N11MJQ Service Manual Part List
Electrical Parts List
Samsung Electronics 7-1
CBF POWER CORD
1 T0077 AA39-10001G CBF POWER CORD;-,KKP-419C,KLCE-2F ,2.286m
ASSY COVER FRONT
1 M0001 AA90-04888B ASSY COVER FRONT;21M06,SV012P,KS1A S.N.A
..2 T0081 6002-000515 SCREW-T APPING;RH,+,2,M4,L15,ZPC(WHT),SWR
..2 T0081 6002-000515 SCREW-T APPING;RH,+,2,M4,L15,ZPC(WHT),SWR
..2 T0081 6003-001268 SCREW-T APTITE;TH,+,B,M4,L12,ZPC(YEL),SWR S.N.A
..2 SC016 AA60-10050Q SCREW-ASSY;-,SWRCH18A,M5,L26.5,HH,+,WC,- S.N.A
..2 AA65-30110A CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, S.N.A
..2 qms HA83-00052A LP-TAPE-INK;,WIDTH 55 MM S.N.A
..2 T0245 HA61-00711C HOLDER-PCB;29K8,HIPS,HB,GRY S.N.A
...3 HA83-00006A LP-RESIN HIPS;,BASF495F ,NTR,HB S.N.A
...3 HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY S.N.A
..2 T0003 AA96-01883B ASSY C P-FRONT;21M06,HIPS,HB,KS1A,SV
...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR S.N.A
...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR S.N.A
...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR S.N.A
...3 CIS7 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, S.N.A
...3 T0023 AA64-04054A KNOB POWER;21M06,HIPS,HB,SLV,HIGH GLOS S.N.A
....4 HA83-00040B LP-MARKING PAINT;,METALLIC SILVER,SV-012 S.N.A
....4 HA83-00006A LP-RESIN HIPS;,BASF495F ,NTR,HB S.N.A
....4 HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY S.N.A
...3 T0022 AA64-04011A KNOB CONTROL;M06,HIPS,HB,SV012P,ALL,SEH S.N.A
....4 HA83-00040B LP-MARKING PAINT;,METALLIC SILVER,SV-012 S.N.A
....4 HA83-00006A LP-RESIN HIPS;,BASF495F ,NTR,HB S.N.A
....4 HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY S.N.A
...3 T0057 AA64-70123B BADGE-BRAND;ALL,AL,8.5,L50,BLK,SILVER,SA S.N.A
...3 T0299 AA64-04013A WINDOW-RMC,LED;M06,ACRYL,HB,CLEAR,SEH S.N.A
....4 HA83-00010A LP-RESIN;,OROGLAS,VM-100 ZHN 2 S.N.A
...3 CIS3 AA64-03877B CABINET FRONT;21M06,HIPS,HB,SV012P,SEH,K S.N.A
....4 HA83-00040B LP-MARKING PAINT;,METALLIC SILVER,SV-012 S.N.A
....4 AA81-00106A A/S-MARKING PAINT;,P432U,DARK GREY,TPC S.N.A
....4 HA83-00006A LP-RESIN HIPS;,BASF495F ,NTR,HB S.N.A
....4 HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY S.N.A
...3 HA83-00049A LP-ADHESIVE-HM;12MM,NTR S.N.A
...3 AA65-30105A CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, S.N.A
...3 T0082 3001-000274 SPEAKER;5W,8OHM,90DB,160HZ
...3 T0245 AA39-20505M LEAD CONNECTOR-ASSY;,4P,350,700MM,YSH025
...3 T0245 HA61-00711C HOLDER-PCB;29K8,HIPS,HB,GRY S.N.A
....4 HA83-00006A LP-RESIN HIPS;,BASF495F ,NTR,HB S.N.A
....4 HA83-00011A LP-RESIN;,M BATCH,WILSON 6007-GY-60,GRY S.N.A
..2 AA81-00129A A/S-TAPE-INK;ALL,BLK,W100MM S.N.A
ASSY PACKING
1 AA90-03234A ASSY PACKING;21M6 S.N.A
..2 T0214 AA60-40006A PIN-STAPLE;AUTO,33X17.8X2.4,H18,33X17.8X S.N.A
...3 HA83-00058A LP-RESIN-EPS;,CHEIL SF-301V ,WHT S.N.A
..2 6902-000006 BAG PE;HDPE/NITRON/HDPE,T0.02/T0.5/T0.2, S.N.A
..2 HA83-00046A LP-TAPE INK;,WIDTH 105 MM S.N.A
..2 acc-ba HA83-00047A LP-TAPEACET ATE;T0.1MM,W20MM,L200MM S.N.A
ASSY COVER REAR
1 M0002 AA90-04982A ASSY COVER REAR;21M06,SEH S.N.A
..2 T0015 AA64-04019A CABINET BACK;21M06,SEH
...3 AA81-00096A RESIN-A;VL-1823,G5433,A S.N.A
..2 T0214 AA65-30008A CLAMPER CORE-CORD;-,PE,HB,-,BLK,- S.N.A
..2 AA65-30009A CLAMPER CORE-FBT;-,ABS,V0,-,BLK,- S.N.A
ASSY ETC-PCB,A/V SIDE
1 T0756 AA95-01709A ASSY ETC-PCB,A/V SIDE;,21D8,KS1A,STEREO
..2 HA99-200105 ASSY-PCB,A/V SIDE(ACI);-,21D8,KS1A,ST
...3 R075 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
...3 R075 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
...3 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF ,10%,50V,Y5P,TP
...3 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF ,10%,50V,Y5P,TP
...3 C689 2202-000222 C-CERAMIC,MLC-AXIAL;3.3nF ,20%,16V,Y5P,TP
...3 C689 2202-000222 C-CERAMIC,MLC-AXIAL;3.3nF ,20%,16V,Y5P,TP
...3 C701 2401-000025 C-AL;100uF ,20%,16V,GP,TP,6.3x11,5
...3 C701 2401-000025 C-AL;100uF ,20%,16V,GP,TP,6.3x11,5
...3 LE04 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534
...3 LE05 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534
...3 LE01 2701-000158 INDUCTOR-AXIAL;22uH,10%,2534
...3 LE02 2701-000158 INDUCTOR-AXIAL;22uH,10%,2534
...3 PCB AA41-00567B PCB-SIDE A V;CS21D8,FR-1,1L,B,245X245,KS1 S.N.A
..2 T0245 AA39-00094A LEAD CONNECTOR-ASSY;,3(2)P,200MM,YBNH250
..2 JE601 3722-000143 JACK-PHONE;1P(VER),3.4PI,AG,BLK,NO
..2 JR01 3722-001031 JACK-PIN;3P,3.6mm,#18,AU
..2 T0245 AA39-20461C LEAD CONNECTOR-ASSY;,11P,300MM,YBNH250-1
..2 0202-000187 SOLDER-WIRE FLUX;-,-,D1.2,63SN/37PB RA,- S.N.A
ASSY CPT
1 T0521 AA91-07378A ASSY CPT;A51QDX993X011,21,400MG,KS1A S.N.A
..2 T0063 AA03-00414A CRT COLOR;A51QDX993X011,400mG,2.47,18.0,
..2 T0089 AA27-00130A COIL DEGAUSSING;-,-,-,-,40T,9ohm,-,21inc
..2 T0527 AA65-30107A CLAMPER CORE-D,COIL;20~22 INCH,NYLON 66, S.N.A
..2 T0271 AA98-70030A ASSY TBC WIRE(P);DP,21,AA98-70014C,1P,TV S.N.A
ASSY PCB MAIN
1 T0073 AA94-13711A ASSY PCB MAIN;CZ21A08XEC,SDIHU,MST,KS1A
..2 AA97-14576A ASSY AUTO;CZ21A08XEC,SDIHU,MST,KS1A S.N.A
...3 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
...3 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
...3 CISS 0401-000006 DIODE-SWITCHING;BAV21,250V,200MA,DO-35,T
...3 T0083 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP
...3 T0083 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP
...3 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
...3 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
...3 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
...3 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
...3 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
...3 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
...3 T0083 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1A,TS-1
...3 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V ,1.5A,-,TP
...3 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V ,1.5A,-,TP
...3 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V ,1.5A,-,TP
...3 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V ,1.5A,-,TP
...3 T0083 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
7-1 CZ21M063NSXXEC
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
7. Electrical Parts List
You can search for the updated part code through ITSELF web site.
URL : http://itself.sec.samsung.co.kr
...3 T0083 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
...3 T0083 0402-001352 DIODE-RECTIFIER;GUF15G-20A,400V,1.5A,MEL
...3 T0083 0402-001470 DIODE-RECTIFIER;RU2BV1,800V,1A,DO-204AC,
...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
...3 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
...3 DZ016 0403-000700 DIODE-ZENER;TZP33A,5%,1000MW,DO-41,TP
...3 DZ016 0403-000700 DIODE-ZENER;TZP33A,5%,1000MW,DO-41,TP
...3 DZ016 0403-000700 DIODE-ZENER;TZP33A,5%,1000MW,DO-41,TP
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
...3 DZ016 0403-001140 DIODE-ZENER;RD10ESAB-T4,9.7-10.2V,400MW,
...3 DZ016 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D
...3 DZ016 0403-001317 DIODE-ZENER;MTZJ3.0B,3.01-3.22V,500MW,DO
...3 DZ016 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO
...3 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO
...3 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO
...3 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO
...3 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO
...3 DZ016 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500MW,DO
...3 DZ016 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500MW,D
...3 DZ016 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.2V,500MW,DO
...3 DZ016 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.2V,500MW,DO
...3 T0156 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
...3 T0156 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
...3 T0156 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO...3 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
...3 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
...3 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
...3 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
...3 VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP
...3 R125 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
...3 R125 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
...3 R125 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
...3 R125 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R075 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM
...3 R075 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM
...3 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M
...3 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M
...3 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M
...3 R075 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M
...3 R075 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4
...3 R125 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000490 R-CARBON;200OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000689 R-CARBON;390KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
...3 R125 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R125 2001-001035 R-CARBON;91OHM,5%,1/8W,AA,TP,1.8X3.2MM
...3 R075 2001-001037 R-CARBON(S);0.39OHM,5%,1/2W,AA,TP,2.4X6.
...3 R075 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4
...3 R075 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP,2.4X6.4
...3 R075 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP,2.4X6.4M
...3 R075 2001-001108 R-CARBON(S);22KOHM,5%,1/2W,AA,TP,2.4X6.4
...3 R075 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA,TP,2.4X6.4
...3 R075 2001-001116 R-CARBON(S);27OHM,5%,1/2W,AA,TP,2.4X6.4M
...3 R075 2001-001122 R-CARBON(S);3.9KOHM,5%,1/2W,AA,TP,2.4X6.
...3 R075 2001-001138 R-CARBON(S);390OHM,5%,1/2W,AA,TP,2.4X6.4
...3 R075 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
...3 R075 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6.
...3 R501H 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
...3 R502H 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
...3 R503 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7
...3 RX801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP ,3.7x
...3 RY801S 2002-001012 R-COMPOSITION;8.2Mohm,5%,1/2W,AA,TP ,3.7x
...3 R827 2003-000652 R-METAL OXIDE(S);330ohm,5%,2W,AF,TP,4x12
...3 R315 2003-000652 R-METAL OXIDE(S);330ohm,5%,2W,AF,TP,4x12
...3 R316 2003-000652 R-METAL OXIDE(S);330ohm,5%,2W,AF,TP,4x12
...3 R403 2003-000784 R-METAL OXIDE(S);7.5Kohm,5%,2W,AF,TP,4x1
...3 R413 2003-001035 R-METAL OXIDE(S);27ohm,5%,2W,AF,TP,3.9x1
Electrical Parts List
7-2 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
Electrical Parts List
Samsung Electronics 7-3
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
...3 R834 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x
...3 R837 2003-002064 R-METAL OXIDE;7.5ohm,5%,2W,AF,TP,10x3.9m
...3 R838 2003-002064 R-METAL OXIDE;7.5ohm,5%,2W,AF,TP,10x3.9m
...3 R839 2003-002064 R-METAL OXIDE;7.5ohm,5%,2W,AF,TP,10x3.9m
...3 R801 2003-002171 R-METAL OXIDE(S);150ohm,5%,2W,AG,TP ,3.9x
...3 R402 2003-002178 R-METAL OXIDE(S);1Kohm,5%,2W,AG,TP ,3.9x1
...3 R407 2003-002209 R-METAL OXIDE(S);47Kohm,5%,2W,AG,TP ,3.9X
...3 R814 2003-002228 R-METAL OXIDE(S);0.47ohm,5%,2W,AG,TP ,3.9
...3 R815 2003-002228 R-METAL OXIDE(S);0.47ohm,5%,2W,AG,TP ,3.9
...3 R811 2003-002239 R-METAL OXIDE(S);100KOHM,5%,2W,AF,TP,3.9
...3 R812 2003-002239 R-METAL OXIDE(S);100KOHM,5%,2W,AF,TP,3.9
...3 R024 2004-001373 R-METAL(S);100Kohm,1%,1/2W ,AA,TP,2.4x6.4
...3 R024 2004-001402 R-METAL(S);6.8Kohm,1%,1/2W ,AA,TP,2.4x6.4
...3 R219 2004-001914 R-METAL;39Kohm,2%,1/8W ,AA,TP,1.8x3.5mm
...3 R304 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m
...3 R305 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m
...3 R825 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm
...3 R824 2008-000294 R-FUSIBLE(S);33ohm,5%,2W,AF,TP,3.9x10mm
...3 R421 2008-000254 R-FUSIBLE(S);0.68ohm,5%,2W,AF,TP,3.9x10m
...3 R420 2008-001110 R-FUSIBLE(S);68ohm,5%,2W,AG,TP,3.9X12mm
...3 RW701 2011-001133 R-NET;33K/24K/75x3,5%,1/8W ,X,SIP,6P,
...3 C598 2201-000259 C-CERAMIC,DISC;0.18NF ,10%,500V,Y5P,TP,5.
...3 C598 2201-000556 C-CERAMIC,DISC;0.47NF ,10%,500V,Y5P,TP,5.
...3 C598 2201-000556 C-CERAMIC,DISC;0.47NF ,10%,500V,Y5P,TP,5.
...3 C598 2201-000573 C-CERAMIC,DISC;0.047NF ,5%,50V,C0G,TP,5X3
...3 C598 2201-000573 C-CERAMIC,DISC;0.047NF ,5%,50V,C0G,TP,5X3
...3 C598 2201-000599 C-CERAMIC,DISC;0.56NF ,10%,500V,Y5P,TP,5.
...3 C598 2201-000639 C-CERAMIC,DISC;0.68NF ,10%,2KV,Y5P,TP,9X5
...3 C598 2201-000723 C-CERAMIC,DISC;4.7NF ,20%,3KV,Y5U,TP,16X5
...3 C598 2201-000991 C-CERAMIC,DISC;0.56NF ,10%,2KV,Y5P,TP,7.5
...3 C598 2201-000991 C-CERAMIC,DISC;0.56NF ,10%,2KV,Y5P,TP,7.5
...3 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF ,10%,50V,Y5P,TP
...3 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF ,10%,50V,Y5P,TP
...3 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF ,10%,50V,Y5P,TP
...3 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF ,+80-20%,25V,Y5V
...3 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF ,+80-20%,25V,Y5V
...3 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF ,+80-20%,25V,Y5V
...3 C689 2202-000210 C-CERAMIC,MLC-AXIAL;270pF ,10%,50V,Y5P,TP
...3 C689 2202-000279 C-CERAMIC,MLC-AXIAL;47pF ,5%,50V,SL,TP,3.
...3 C689 2202-000632 C-CERAMIC,MLC-AXIAL;100nF ,20%,50V,Z5U,TP
...3 C689 2202-000632 C-CERAMIC,MLC-AXIAL;100nF ,20%,50V,Z5U,TP
...3 C689 2202-000632 C-CERAMIC,MLC-AXIAL;100nF ,20%,50V,Z5U,TP
...3 C689 2202-000796 C-CERAMIC,MLC-AXIAL;1NF ,10%,50V,Y5P,TP,3
...3 C689 2202-000796 C-CERAMIC,MLC-AXIAL;1NF ,10%,50V,Y5P,TP,3
...3 C689 2202-000796 C-CERAMIC,MLC-AXIAL;1NF ,10%,50V,Y5P,TP,3
...3 C689 2202-000825 C-CERAMIC,MLC-AXIAL;680pF ,10%,50V,Y5P,TP
...3 C2560 2301-000213 C-FILM,LEAD-PEF;220nF,5%,250V,TP,21.5x11
...3 C2560 2301-000224 C-FILM,LEAD-PEF;22nF,5%,50V,TP,7.4x3.9x1
...3 C2560 2301-000224 C-FILM,LEAD-PEF;22nF,5%,50V,TP,7.4x3.9x1
...3 C2560 2301-000235 C-FILM,LEAD-PEF;3.9nF,5%,50V,TP,6.5x3.0x
...3 C2560 2301-000254 C-FILM,LEAD-PEF;39nF,5%,50V,TP,7.5x3.5x6
...3 C2560 2301-000289 C-FILM,LEAD-PEF;5.6nF,5%,50V,TP,7x6x3,5
...3 C2560 2301-000289 C-FILM,LEAD-PEF;5.6nF,5%,50V,TP,7x6x3,5
...3 C2560 2301-000342 C-FILM,LEAD-PEF;2.2nF,5%,50V,TP,7.4x3.9x
...3 C2560 2301-000342 C-FILM,LEAD-PEF;2.2nF,5%,50V,TP,7.4x3.9x
...3 C2560 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
...3 C2560 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
...3 C2560 2301-000445 C-FILM,LEAD-PEF;4.7nF,5%,50V,TP,5.5x7x3m
...3 C2560 2301-000445 C-FILM,LEAD-PEF;4.7nF,5%,50V,TP,5.5x7x3m
...3 C2560 2305-001003 C-FILM,LEAD-PEF;10nF,5%,250V,TP,13x4.5x9
...3 C806 2301-001435 C-FILM,LEAD-PPF;1.5nF ,5%,1.2kV,TP,15x8x1
...3 C2560 2305-000285 C-FILM,LEAD-PEF;220NF,5%,100V,TP,10.5X5.
...3 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
...3 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
...3 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
...3 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
...3 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
...3 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
...3 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V,TP,-,5mm
...3 C2560 2305-000382 C-FILM,LEAD-PEF;4.7nF,5%,400V,TP,-,5mm
...3 C2560 2305-000412 C-FILM,LEAD-PEF;470nF,5%,63V,TP,-,5mm
...3 C2560 2305-000412 C-FILM,LEAD-PEF;470nF,5%,63V,TP,-,5mm
...3 C2560 2305-000412 C-FILM,LEAD-PEF;470nF,5%,63V,TP,-,5mm
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
...3 C225 2301-001664 C-FILM,MPE-PPF;100nF ,3%,50V,TP,20x16x8.5
...3 C701 2401-002075 C-AL;4.7uF ,20%,50V,GP,TP,5x11,5
...3 C701 2401-002075 C-AL;4.7uF ,20%,50V,GP,TP,5x11,5
...3 C701 2401-000262 C-AL;100uF ,20%,160V,HR,TP,16x25,7.5
...3 C701 2401-000302 C-AL;100uF ,20%,25V,GP,TP,6.3x11,5
...3 C701 2401-000302 C-AL;100uF ,20%,25V,GP,TP,6.3x11,5
...3 C701 2401-000302 C-AL;100uF ,20%,25V,GP,TP,6.3x11,5
...3 C701 2401-000360 C-AL;100uF ,20%,50V,GP,TP,8x11.5,5
...3 C701 2401-000360 C-AL;100uF ,20%,50V,GP,TP,8x11.5,5
...3 C701 2401-000430 C-AL;10uF ,20%,250V,GP,TP,10x16mm,5m
...3 C701 2401-000480 C-AL;10uF ,20%,50V,GP,TP,5x11,5
...3 C701 2401-000480 C-AL;10uF ,20%,50V,GP,TP,5x11,5
...3 C701 2401-000560 C-AL;1uF ,20%,160V,GP,TP,6.3x11,5
...3 C701 2401-000603 C-AL;1UF ,20%,50V,GP,TP,5X11,2
...3 C701 2401-000660 C-AL;2.2uF ,20%,50V,GP,TP,5x11,5
...3 C701 2401-000660 C-AL;2.2uF ,20%,50V,GP,TP,5x11,5
...3 C701 2401-000660 C-AL;2.2uF ,20%,50V,GP,TP,5x11,5
...3 C701 2401-000711 C-AL;2200uF ,20%,25V,GP,TP,16x25,7.5
...3 C701 2401-000758 C-AL;0.22UF ,20%,50V,GP,TP,5X11,5
...3 C701 2401-000927 C-AL;22uF ,20%,250V,GP,TP,13x20,5
...3 C701 2401-000962 C-AL;22uF ,20%,50V,GP,TP,5x11,5
...3 C701 2401-001101 C-AL;330uF ,20%,16V,GP,TP,8x11.5,5
...3 C701 2401-001192 C-AL;33uF ,20%,50V,GP,TP,6.3x11,5
...3 C701 2401-001232 C-AL;4.7uF ,20%,250V,GP,TP,10x12.5,5
...3 C701 2401-000025 C-AL;100uF ,20%,16V,GP,TP,6.3x11,5
...3 C701 2401-000025 C-AL;100uF ,20%,16V,GP,TP,6.3x11,5
...3 C701 2401-000025 C-AL;100uF ,20%,16V,GP,TP,6.3x11,5
...3 C701 2401-000025 C-AL;100uF ,20%,16V,GP,TP,6.3x11,5
...3 C701 2401-000025 C-AL;100uF ,20%,16V,GP,TP,6.3x11,5
...3 C701 2401-000025 C-AL;100uF ,20%,16V,GP,TP,6.3x11,5
...3 C701 2401-001998 C-AL;1000uF ,20%,25V,GP,TP,10x20,5mm
...3 C701 2401-000050 C-AL;10uF ,20%,16V,GP,TP,5x11,2.5
...3 C701 2401-002288 C-AL;470uF ,20%,25V,WT ,TP,10x20,5
...3 C701 2401-002288 C-AL;470uF ,20%,25V,WT ,TP,10x20,5
...3 C701 2401-002290 C-AL;47uF ,20%,160V,GP,TP,13x20,5
...3 C701 2401-002619 C-AL;47uF ,20%,25V,GP,TP,5x11,5
...3 C701 2401-003028 C-AL;100uF ,20%,25V,WT ,TP,6.3x11,5
...3 C701 2401-003028 C-AL;100uF ,20%,25V,WT ,TP,6.3x11,5
...3 C701 2401-003028 C-AL;100uF ,20%,25V,WT ,TP,6.3x11,5
...3 L103 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534
...3 L202 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534
...3 L902 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534
...3 L904 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534
...3 J142 2701-000115 INDUCTOR-AXIAL;10uH,10%,3070
...3 L301 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534
...3 L302 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534
...3 L404 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534
...3 L903 2701-000158 INDUCTOR-AXIAL;22uH,10%,2534
...3 L102 2701-000159 INDUCTOR-AXIAL;22uH,10%,4298
...3 L201 2701-000159 INDUCTOR-AXIAL;22uH,10%,4298
...3 L205 2701-000159 INDUCTOR-AXIAL;22uH,10%,4298
...3 L405 2701-000159 INDUCTOR-AXIAL;22uH,10%,4298
...3 L104 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2534
...3 L101 2701-000171 INDUCTOR-AXIAL;0.33uH,10%,2534
...3 L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
...3 L701 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
...3 L702 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
...3 L703 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
...3 L704 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
...3 L804 2701-001030 INDUCTOR-AXIAL;43uH,10%,4514
...3 L807 2701-001030 INDUCTOR-AXIAL;43uH,10%,4514
...3 X901 2801-003937 CRYSTAL-UNIT;12MHz,25ppm,28-AAM,30pF,30o
...3 F101 2901-000297 FIL TER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,...3 F101 2901-000297 FIL TER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,...3 F101 2901-000297 FIL TER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,...3 Z202 2903-000181 FILTER-CERAMIC;BR,5.5MHz,-,-,-,TP,TPS5.5
...3 Z203 2903-001040 FILTER-CERAMIC;TR,5.5/6.0/6.5MHz,-,1dB,...3 L2514 3301-000287 BEAD-AXIAL;,3.5x1.0x6.0mm,3000mA,TP ,,,50
...3 L2514 3301-000287 BEAD-AXIAL;,3.5x1.0x6.0mm,3000mA,TP ,,,50
...3 L2514 3301-000287 BEAD-AXIAL;,3.5x1.0x6.0mm,3000mA,TP ,,,50
...3 SW901 3404-000244 SWITCH-TACT ;15V,20mA,90-170gf,7.5x7mm,SP
...3 SW902 3404-000244 SWITCH-TACT ;15V,20mA,90-170gf,7.5x7mm,SP
...3 SW903 3404-000244 SWITCH-TACT ;15V,20mA,90-170gf,7.5x7mm,SP
...3 SW904 3404-000244 SWITCH-TACT ;15V,20mA,90-170gf,7.5x7mm,SP
...3 SW905 3404-000244 SWITCH-TACT ;15V,20mA,90-170gf,7.5x7mm,SP
...3 FP801S 3601-000281 FUSE-CARTRIDGE;250V,4A,TIME-LAG,GLASS,5.
...3 FD801S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M
...3 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm
...3 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm
...3 IC063 AA13-20004W IC HYBRID;-,PAP103T,SIP,6P,PRE-AMP,TP
...3 PCB AA41-00131H PCB-MAIN;CS21D8,FR-1,1L,H,1.6T,245X245, S.N.A
...3 EY101 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY401 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY402 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY403 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY404 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY405 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY406 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY407 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY408 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY409 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY410 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY411 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY412 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY414 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY415 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY416 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY417 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY419 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY420 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY421 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY422 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY423 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY501 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY801 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY802 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY803 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY807 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY808 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY809 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY810 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY813 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY818 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY819 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY821 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY822 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY823 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY824 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY825 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY827 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY828 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY829 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY830 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY833 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY850 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY851 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY852 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY853 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY860 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EY861 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A
...3 EL301 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL302 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL403 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL404 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL407 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL408 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL501 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL502 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL601 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL602 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL603 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL604 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL801 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL802 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 EL804 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/ S.N.A
...3 GT101 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT501 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT502 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT801 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT802 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT803 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT804 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT805 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT806 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 GT807 AA60-40014A PIN-GT,ASSY;AUTO S.N.A
...3 R303 2008-001133 R-FUSIBLE(S);0.75ohm,5%,2W,AF,TP,3.9x10m
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
Electrical Parts List
7-4 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
Electrical Parts List
Samsung Electronics 7-5
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 M0125 BH39-40362W CBF-HARNESS;-,JUMPER,0.6PHI,ROLL-TYPE,-,
...3 C701 2401-002462 C-AL;33uF ,20%,16V,GP,TP,5x11,5
...3 C598 2201-000192 C-CERAMIC,DISC;0.01NF ,0.25PF,500V,C0G,TP
...3 R024 2004-001390 R-METAL(S);1Kohm,2%,1/2W ,AA,TP,2.4x6.4mm
...3 R024 2004-001390 R-METAL(S);1Kohm,2%,1/2W ,AA,TP,2.4x6.4mm
...3 R505 2008-001076 R-FUSIBLE(S);1.8ohm,5%,2W,AF,TP,3.9x10mm
...3 C598 2201-000406 C-CERAMIC,DISC;0.27NF ,10%,2KV,Y5P,TP,6.3
...3 CR403S 2301-001259 C-FILM,LEAD-PPF;100nF,5%,400V ,TP,19x8x16
..2 T0524 AA95-03087A ASSY SUB-PCB NICAM;CZ21S4,STEREO
...3 HA99-200104 ASSY -PCB,NICAM(ACI);,ALL,KS1A
....4 ICS02 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 C598 2201-000112 C-CERAMIC,DISC;1.5NF ,10%,50V,Y5V,TP ,5X3.
....4 C598 2201-000180 C-CERAMIC,DISC;10NF ,10%,50V,Y5V,TP ,7X3MM
....4 C598 2201-000304 C-CERAMIC,DISC;0.001NF ,0.25PF,50V,C0G,TP
....4 C598 2201-000304 C-CERAMIC,DISC;0.001NF ,0.25PF,50V,C0G,TP
....4 C598 2201-000472 C-CERAMIC,DISC;0.33NF ,5%,50V,SL,TP,8.5X3
....4 C598 2201-000472 C-CERAMIC,DISC;0.33NF ,5%,50V,SL,TP,8.5X3
....4 C598 2201-000982 C-CERAMIC,DISC;10NF ,+80-20%,50V,Y5V,TP ,4
....4 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF ,10%,50V,Y5P,TP
....4 C689 2202-000286 C-CERAMIC,MLC-AXIAL;56pF ,5%,50V,SL,TP,1.
....4 C2560 2301-000111 C-FILM,LEAD-PEF;1.8nF,5%,50V,TP,6.5x3.0x
....4 C2560 2301-000111 C-FILM,LEAD-PEF;1.8nF,5%,50V,TP,6.5x3.0x
....4 C2560 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP,6x7x3.2mm
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x
....4 C701 2401-002075 C-AL;4.7uF ,20%,50V,GP,TP,5x11,5
....4 C701 2401-002075 C-AL;4.7uF ,20%,50V,GP,TP,5x11,5
....4 C701 2401-000480 C-AL;10uF ,20%,50V,GP,TP,5x11,5
....4 C701 2401-000480 C-AL;10uF ,20%,50V,GP,TP,5x11,5
....4 C701 2401-000480 C-AL;10uF ,20%,50V,GP,TP,5x11,5
....4 C701 2401-000480 C-AL;10uF ,20%,50V,GP,TP,5x11,5
....4 C701 2401-000480 C-AL;10uF ,20%,50V,GP,TP,5x11,5
....4 C701 2401-001026 C-AL;3.3UF ,20%,50V,GP,TP,5X11,5
....4 C701 2401-001026 C-AL;3.3UF ,20%,50V,GP,TP,5X11,5
....4 C701 2401-002144 C-AL;47uF ,20%,16V,GP,TP,5x11,5
....4 C701 2401-002144 C-AL;47uF ,20%,16V,GP,TP,5x11,5
....4 C701 2401-002594 C-AL;220uF ,20%,16V,GP,TP,8x11.5,5
....4 LS03 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534
....4 LS01 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
....4 LS04 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
....4 PCB AA41-00139A PCB-STEREO/LINE-ST/MTS-M;DREAM-1,1L,FR-1 S.N.A
...3 ICS01 1204-002038 IC-SOUND PROCESSOR;MSP3410G-PO-83V3,PSDI
...3 CN906 3711-002706 CONNECTOR-HEADER;NOWALL,8P,1R,2.5mm,ANGL
...3 CN906 3711-002708 CONNECTOR-HEADER;NOWALL,10P,1R,2.5mm,ANG
...3 T0245 AA39-00276A LEAD CONNECTOR-ASSY;,UL1185#26,UL/CSA,6P
...3 T0245 AA39-00095A LEAD CONNECTOR-ASSY;,3(2)P,200MM,YBNH250
...3 CIS1 AA98-00253A ASSY SUB PART;KS1A,NICAM MODULE S.N.A
....4 0202-000187 SOLDER-WIRE FLUX;-,-,D1.2,63SN/37PB RA,- S.N.A
...3 XS01 2801-004020 CRYSTAL-UNIT;18.432MHz,30ppm,28-AAM,12pF
..2 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T
..2 P803T 1404-001156 THERMISTOR-PTC;9OHM,+30%/-20%,220VRMS,27
..2 CX801S 2306-000318 C-FILM,LEAD-PPF;220NF,20%,250V ,BK,-,22.5
..2 SF101S 2904-000302 FILTER-SA W AV;38.9MHz,SIP5K,ST ,15.4dB,B/
..2 SF102S 2904-001224 FILTER-SA W AV;38.9MHz,SIP5K,ST ,16.3dB,B/
..2 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,-,-,7.1mH,-,-,102uH,
..2 LX801S AA29-30001D FILTER LINE NOISE;SQ1913,-,6.0MH,0.8A,..2 TU01S AA40-00110A TUNER;TECC0949PG40A(S),TECC0949PG40A(S),
..2 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN S.N.A
..2 IC501 AA96-00842A ASSY H/S;,VIDEO,AA62-30175D,TDA6107Q S.N.A
...3 T0074 1201-001159 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA
...3 T0081 6003-000334 SCREW-T APTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
...3 H/S501 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 S.N.A
..2 V999S 3704-001105 SOCKET -CRT;11P,20PI,26.5PI,NI,..2 D0254 AA32-00015A MODULE REMOCON;FRP-3521H31,38KHZ,940MM,M
..2 IC801S AA96-00845A ASSY H/S;,POWER,AA62-30186B,KA5Q0765R S.N.A
...3 T0086 1203-001932 IC-PWM CONTROLLER;5Q0765,TO-220F,5P,185M
...3 T0081 6003-000333 SCREW-T APTITE;RH,+,2S,M3,L10,ZPC(YEL),SW S.N.A
...3 H/S801 AA62-30186B HEAT SINK-ES;-,-,-,SILVER,171J + COVER-H S.N.A
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 IC802 AA96-00846A ASSY H/S;,POWER,AA62-00055A,KA7632 S.N.A
...3 T0087 1203-001939 IC-POSI.FIXED REG.;7632,SIP,10P,-,PLASTI
...3 H/S802 AA62-00055A HEAT SINK-PS;-,-,T1.0,-,35*15*25,D1,-,-, S.N.A
...3 T0081 6003-000334 SCREW-T APTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
..2 IC112 1103-001106 IC-EEPROM;24C080,1Kx8Bit,DIP,8P,9.6x6.4m
..2 SW801S 3403-001134 SWITCH-PUSH;250V,5A,DPST ,ON-OFF,..2 T0090 0502-001160 TR-POWER;2SD2499,NPN,50000mW,TO-3P,BK,8
..2 JS701 3722-000183 JACK-SCART;21P,4mm,SN,BLK,NO
..2 T0245 AA39-20010D LEAD CONNECTOR-ASSY;,1P,400,YFH800-01,S,
..2 T0245 AA39-20010D LEAD CONNECTOR-ASSY;,1P,400,YFH800-01,S,
..2 T0245 AA39-20620C LEAD CONNECTOR-ASSY;,9P,500MM,YBNH250-09
..2 IC301 AA96-00847A ASSY H/S;,AA62-00046A,LA7840 S.N.A
...3 T0088 1204-001483 IC-VERTICAL PROCESSO;LA7840,SIP,7P,708MI
...3 AA62-00064A HEAT SINK-PS;DP,-,-,-,AA62-00046A,-,-,-, S.N.A
...3 T0081 6003-000334 SCREW-T APTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
..2 C701 2401-002219 C-AL;220uF ,20%,400V,GP,BK,25x40,10
..2 CR402S 2306-001021 C-FILM,LEAD-PPF;100NF,5%,630V ,BK,26X8.5X
..2 T0616 AA26-00116A TRANS FBT;FSV-14A004H(S),CT15A8,3.24MH,1
..2 CIS1 AA98-00079A ASSY SUB PART;KS1A,MAIN(OPT),PAL,- S.N.A
...3 0202-000187 SOLDER-WIRE FLUX;-,-,D1.2,63SN/37PB RA,- S.N.A
..2 T0296 AA27-00122A COIL LINEARITY;90UH,90UH,L81 DR10x10,7.5
..2 CR410S 2306-000326 C-FILM,LEAD-PPF;4.7NF,5%,1.6KV ,BK,28.5X1
..2 LW01 AA27-40001N COIL HORIZ. WIDTH;-,90/260uH,SB-5S620,PI
..2 C598 2201-000446 C-CERAMIC,DISC;3.3NF ,20%,400V,Y5U,BK,15X
..2 T801S AA26-00134A TRANS SWITCHING;,CS21S5T,160V~260V,PM2 P
..2 T101 AA26-00025A TRANS RF;7MG,-,-,-,10pF,-,58.35MHz,7.7x
..2 IC601 AA96-00923A ASSY H/S;,AUDIO,AA62-00064A,TDA8944,BRK S.N.A
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 T0085 1201-001741 IC-AUDIO AMP;TDA8944J,DBS,17P,937MIL,DUA
...3 T0081 6003-000334 SCREW-T APTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
...3 AA61-10162B BRACKET-IC;-,SBHG-1,T1.0,-,-,-,100 S.N.A
...3 AA62-00064A HEAT SINK-PS;DP,-,-,-,AA62-00046A,-,-,-, S.N.A
..2 D806 AA96-00922A ASSY H/S;,BRIDGE,AA62-00065A,D06U20S,KS S.N.A
...3 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
...3 T0083 0402-001374 DIODE-RECTIFIER;FFPF06U20S,200V,6A,TO-22
...3 T0081 6003-000334 SCREW-T APTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
...3 AA62-00065A HEAT SINK-PS;DP,-,-,-,AA62-00045A,-,-,-, S.N.A
..2 IC101 1204-001583 IC-IF CIRCUIT;U4468B,DIP,16P,-,PLASTIC,5
..2 CN906 3711-000628 CONNECTOR-HEADER;BOX,11P,1R,2.5MM,STRAIG
..2 CN906 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH
..2 CN906 3711-002645 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,STRAIGH
..2 T0090 0502-000242 TR-POWER;KSA614,PNP,25W,TO-220,TP,40-24
..2 T0119 AA09-00418A IC MICOM;TDA9351PS/N2/3I,SPM-802EW5,64P,
..2 CN401 AA60-40012D PIN-GT,ASSY;T1.6,6-12.5-,NYLON66 S.N.A
..2 C1 AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A
..2 C2 AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A
..2 C3 AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A
REMOCON
1 T0074 AA59-00312A REMOCON;DEEP IMPACT,TM75,36,TTX,EX,PAL
ASSY ACCESSORY
1 M0245 AA94-05765A ASSY ACCESSORY;20-21,KS1A,XEC S.N.A
Electrical Parts List
7-6 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
Electrical Parts List
Samsung Electronics 7-7
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
ASSY COVER FRONT
1 M0001 AA90-03291Z ASSY COVER FRONT;CS21H4ML0X/TRI S.N.A
..2 T0081 6003-001268 SCREW-T APTITE;TH,+,B,M4,L12,ZPC(YEL),SWR S.N.A
..2 SC016 AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,- S.N.A
..2 T0003 AA96-00958G ASSY COVER P-C/FRONT;21H4,HIPS HB,BLK,SP
...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR S.N.A
...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR S.N.A
...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR S.N.A
...3 T0607 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- S.N.A
...3 CIS7 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, S.N.A
...3 T0578 AA64-01309S INLAY AV;21D8,PS SHEET,T0.3,BLK,GOLD,S/T S.N.A
...3 T0003 AA64-02795J CABINET-FRONT;21H4,HIPS,HB,BLK,BK708P S.N.A
...3 T0023 AA64-02798A KNOB-POWER;21H4,ABS,HB,BLK,NO-SILK S.N.A
...3 T0022 AA64-02800A KNOB-CONTROL;21H4,ABS,HB,BLK S.N.A
...3 T0299 AA64-02802A WINDOW-RMC,LED;21H4,ACRYL,CLR S.N.A
...3 T0057 AA64-70123D BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,GOLD,R S.N.A
...3 AA65-30105A CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, S.N.A
...3 T0522 AA96-10146C ASSY SPEAKER;-,8ohm,5W,3001-000274,350/7
....4 T0082 3001-000274 SPEAKER;5W ,8OHM,90DB,160HZ
....4 T0245 AA39-20505M LEAD CONNECTOR-ASSY;,4P,350,700MM,YSH025
...3 T0156 AA61-00721C HOLDER-RAIL;H4,HIPS,V0,GRAY S.N.A
...3 T0382 BP61-00509A HOLDER-CARE;PJT ,ACRYL-FOAM,T0.25,W20.0mm S.N.A
..2 T0382 BP61-00495A HOLDER-CARE;PJT ,ACRYL-FOAM,T0.25,W30.0mm S.N.A
ASSY COVER REAR
1 M0002 AA90-03294F ASSY COVER REAR;21H4,HIPS,HB,BLK,KS1A,SC S.N.A
..2 T0069 AA60-00091J SP ACER-FELT;-,FELT ,330X10,-,-,BLK,T0.5,- S.N.A
..2 T0081 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, S.N.A
..2 T0015 AA64-02830D CABINET-BACK;21H4,HIPS HB,BLK
..2 T0214 AA65-30008A CLAMPER CORE-CORD;-,PE,HB,-,BLK,- S.N.A
ASSY FIXING
1 AA91-06569K ASSY FIXING;CS14V5MJ0X/AWE,KS1A,MAC S.N.A
..2 T0245 AA39-20010D LEAD CONNECTOR-ASSY;,1P,400,YFH800-01,S,
..2 AA65-30009A CLAMPER CORE-FBT;-,ABS,V0,-,BLK,- S.N.A
..2 CLAMP AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A
..2 AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A
..2 AA65-30111A CLAMPER CORE-WIRE;ALL MODEL,NYLON,V0,-,W S.N.A
..2 T0066 AA96-20109B ASSY POWER CORD;-,CP2/NO(4.0),H/C250,KKP S.N.A
...3 3811-001609 WIRE-PVC CU;BCWA,300V,ROLL,-,#22,BLK S.N.A
...3 T0077 AA39-10006X CBF POWER CORD;-,KKP419C,KLCE-2F,2.286MT
...3 AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 S.N.A
..2 AA61-01364A HOLDER-COVER;KS1A,NYLON66,BLK,V2 S.N.A
ASSY CHASSIS
1 M0017 AA91-06570Q ASSY CHASSIS;CS21V10ML0XAWE,KS1A,MAC S.N.A
..2 T0073 AA94-13238D ASSY PCB MAIN;MAC,KS1A
...3 0202-000187 SOLDER-WIRE FLUX;-,-,D1.2,63SN/37PB RA,- S.N.A
...3 T0090 0502-001160 TR-POWER;2SD2499,NPN,50000mW ,TO-3P,BK,8...3 PC801S 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST
...3 IC112 1103-001106 IC-EEPROM;24C080,1Kx8Bit,DIP,8P,9.6x6.4m
...3 IC101 1204-001583 IC-IF CIRCUIT;U4468B,DIP,16P,-,PLASTIC,5
...3 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T
...3 P803T 1404-001265 THERMISTOR-PTC;4.5OHM/100OHM,+30/-20%,22
...3 C598 2201-000446 C-CERAMIC,DISC;3.3NF ,20%,400V,Y5U,BK,15X
...3 CR410S 2303-001015 C-FILM,LEAD-PPF;5.5NF,5%,1.6KV ,BK,29X9.5
...3 CR402S 2306-000188 C-FILM,LEAD-PPF;330NF,5%,400V ,BK,26X19.5
...3 CX801S 2306-000318 C-FILM,LEAD-PPF;220NF,20%,250V ,BK,-,22.5
...3 C701 2401-003339 C-AL;220uF ,20%,400V,GP,BK,30x35,10
...3 SF101S 2904-001143 FILTER-SAW AV;38.9MHz,SIP5K,ST,18dB,B/G,
...3 SF102S 2904-001224 FILTER-SAW AV;38.9MHz,SIP5K,ST,16.3dB,B/
...3 SW801S 3403-001134 SWITCH-PUSH;250V,5A,DPST,ON-OFF,...3 FP801S 3601-000281 FUSE-CARTRIDGE;250V,4A,TIME-LAG,GLASS,5.
...3 V999S 3704-001105 SOCKET-CRT ;11P,20PI,26.5PI,NI,...3 CN906 3711-000628 CONNECTOR-HEADER;BOX,11P,1R,2.5MM,STRAIG
...3 JS701 3722-000183 JACK-SCART;21P ,4mm,SN,BLK,NO
...3 T801S AA26-00043A TRANS SWITCHING;-,-,-,AC90~260V,125/12.5
...3 T0616 AA26-00201A TRANS FBT;FCA173B,KS1A-1,3.8mH,FERRITE,1
...3 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,-,-,7.1mH,-,-,102uH,
...3 T0296 AA27-00053A COIL LINEARITY;-,193uH,DR10X10 C:4.35,7.
...3 LX801S AA29-30001D FILTER LINE NOISE;SQ1913,-,6.0MH,0.8A,...3 D0254 AA32-00015A MODULE REMOCON;FRP-3521H31,38KHZ,940MM,M
...3 T0245 AA39-20620C LEAD CONNECTOR-ASSY;,9P,500MM,YBNH250-09
...3 TU01S AA40-00076A TUNER;TECC0949PG35A(S),PAL,181CH,38.9MHZ
...3 GT301 AA60-40012D PIN-GT ,ASSY;T1.6,6-12.5-,NYLON66 S.N.A
...3 CIS1 AA95-03139A ASSY SUB PCB-LINE STEREO;14S4,,KS1A,LINE
....4 0202-000187 SOLDER-WIRE FLUX;-,-,D1.2,63SN/37PB RA,- S.N.A
....4 ICS01 1204-001713 IC-SOUND PROCESSOR;MSP3465G-B8-V3,DIP,52
....4 CN906 3711-002706 CONNECTOR-HEADER;NOWALL,8P,1R,2.5mm,ANGL
....4 CN906 3711-002708 CONNECTOR-HEADER;NOWALL,10P,1R,2.5mm,ANG
....4 T0245 AA39-00276A LEAD CONNECTOR-ASSY;,UL1185#26,UL/CSA,6P
....4 T0245 AA39-20005A LEAD CONNECTOR-ASSY;,3P,500,YBNH025-03,6
....4 AA63-10002A BAND-TIE;NYLON66 V2,L100,NTR S.N.A
....4 XS01 2801-004020 CRYSTAL-UNIT;18.432MHz,30ppm,28-AAM,12pF
....4 AA97-05522A ASSY AUTO-SUB;14S4,39,KS1A ,A2,BILINGUAL S.N.A
.....5 ICS02 1203-000515 IC-VOL. DETECTOR;7042,TO-92,3P,177MIL,PL
.....5 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 R125 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP ,1.8X3.2MM
.....5 C598 2201-000112 C-CERAMIC,DISC;1.5NF,10%,50V ,Y5V,TP,5X3.
.....5 C598 2201-000180 C-CERAMIC,DISC;10NF,10%,50V ,Y5V,TP,7X3MM
.....5 C598 2201-000304 C-CERAMIC,DISC;0.001NF,0.25PF ,50V,C0G,TP
.....5 C598 2201-000304 C-CERAMIC,DISC;0.001NF,0.25PF ,50V,C0G,TP
.....5 C598 2201-000472 C-CERAMIC,DISC;0.33NF,5%,50V ,SL,TP,8.5X3
.....5 C598 2201-000472 C-CERAMIC,DISC;0.33NF,5%,50V ,SL,TP,8.5X3
.....5 C598 2201-000982 C-CERAMIC,DISC;10NF,+80-20%,50V ,Y5V,TP,4
.....5 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V ,Y5P,TP
.....5 C689 2202-000286 C-CERAMIC,MLC-AXIAL;56pF,5%,50V ,SL,TP,1.
.....5 C2560 2301-000111 C-FILM,LEAD-PEF;1.8nF,5%,50V,TP ,6.5x3.0x
.....5 C2560 2301-000111 C-FILM,LEAD-PEF;1.8nF,5%,50V,TP ,6.5x3.0x
.....5 C2560 2301-000383 C-FILM,LEAD-PEF;10nF,5%,50V,TP ,6x7x3.2mm
.....5 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP ,7.5x4.0x
.....5 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP ,7.5x4.0x
.....5 C701 2401-002075 C-AL;4.7uF,20%,50V ,GP,TP,5x11,5
.....5 C701 2401-002075 C-AL;4.7uF,20%,50V ,GP,TP,5x11,5
.....5 C701 2401-000480 C-AL;10uF,20%,50V ,GP,TP,5x11,5
.....5 C701 2401-000480 C-AL;10uF,20%,50V ,GP,TP,5x11,5
.....5 C701 2401-000480 C-AL;10uF,20%,50V ,GP,TP,5x11,5
.....5 C701 2401-000486 C-AL;10uF,20%,50V ,GP,TP,6.3x7mm,5
.....5 C701 2401-000486 C-AL;10uF,20%,50V ,GP,TP,6.3x7mm,5
.....5 C701 2401-001026 C-AL;3.3UF,20%,50V ,GP,TP,5X11,5
.....5 C701 2401-001026 C-AL;3.3UF,20%,50V ,GP,TP,5X11,5
.....5 C701 2401-002144 C-AL;47uF,20%,16V ,GP,TP,5x11,5
.....5 C701 2401-002144 C-AL;47uF,20%,16V ,GP,TP,5x11,5
.....5 C701 2401-002594 C-AL;220uF,20%,16V ,GP,TP,8x11.5,5
.....5 LS03 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534
.....5 LS01 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
.....5 LS04 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534
.....5 PCB AA41-00139A PCB-STEREO/LINE-ST/MTS-M;DREAM-1,1L,FR-1 S.N.A
7-2 CS21H4ML0X/TRI
You can search for the updated part code through ITSELF web site.
URL : http://itself.sec.samsung.co.kr
...3 IC801S AA96-00242D ASSY H/S;SCREWAA62-30186B,5Q0765RTH,OIL S.N.A
....4 CIS 0205-001027 OIL-SILICON;G746,-,- S.N.A
....4 T0086 1203-002916 IC-PWM CONTROLLER;KA5Q0765RTH-YDTU,TO-22
....4 T0081 6003-000333 SCREW-T APTITE;RH,+,2S,M3,L10,ZPC(YEL),SW S.N.A
....4 CIS AA62-30186B HEAT SINK-ES;-,-,-,SILVER,171J + COVER-H S.N.A
....4 CIS AA63-30189A COVER-HEATSINK;-,PC-ABS,T0.8,-,-,V0,NTR, S.N.A
...3 D806 AA96-00243D ASSY H/S;-,BRIDGE,AA62-00045A,D06U20S,DR S.N.A
....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
....4 T0083 0402-001374 DIODE-RECTIFIER;FFPF06U20S,200V,6A,TO-22
....4 T0081 6003-000335 SCREW-T APTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A
....4 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, S.N.A
...3 IC601 AA96-00244G ASSY H/S;-,AUDIO,AA62-00046A,TDA8944J,BR S.N.A
....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A
....4 T0085 1201-001741 IC-AUDIO AMP;TDA8944J,DBS,17P,937MIL,DUA
....4 T0081 6003-000335 SCREW-T APTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A
....4 AA61-10162B BRACKET-IC;-,SBHG-1,T1.0,-,-,-,100 S.N.A
....4 AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X S.N.A
...3 IC301 AA96-00244M ASSY H/S;SCREWAA64-00046A,LA78040N,OIL S S.N.A
....4 CIS 0205-001027 OIL-SILICON;G746,-,- S.N.A
....4 T0088 1204-002121 IC-VERTICAL DEF.;LA78040N,TO220,7P,-,PLA
....4 T0081 6003-000335 SCREW-T APTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A
....4 CIS AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X S.N.A
...3 IC802 AA96-00245A ASSY H/S;-,-,AA62-00055A,KA7632,- S.N.A
....4 T0087 1203-001939 IC-POSI.FIXED REG.;7632,SIP,10P,-,PLASTI
....4 T0081 6003-000334 SCREW-T APTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
....4 AA62-00055A HEAT SINK-PS;-,-,T1.0,-,35*15*25,D1,-,-, S.N.A
...3 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN S.N.A
...3 IC501 AA96-50311A ASSY H/S;-,VIDEO,AA62-30175D,TDA6107Q,- S.N.A
....4 T0074 1201-001159 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA
....4 T0081 6003-000334 SCREW-T APTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A
....4 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 S.N.A
...3 AA97-14170K ASSY AUTO-MAIN;CS21H4ML0X/AWE,KS1A,MAC S.N.A
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
....4 CISS 0401-000005 DIODE-SWITCHING;1N4148,75V ,150MA,DO-35,T
....4 T0083 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP
....4 T0083 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP
....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP
....4 T0083 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,TO-220F,TP
....4 T0083 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,TO-220F,TP
....4 T0083 0402-001352 DIODE-RECTIFIER;GUF15G-20A,400V,1.5A,MEL
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO
....4 DZ016 0403-000510 DIODE-ZENER;MTZJ6.2B,5.96-6.27V,500MW,DO
....4 DZ016 0403-000699 DIODE-ZENER;TZP27B,27-30.8V,1000MW,DO-41
....4 DZ016 0403-000700 DIODE-ZENER;TZP33A,5%,1000MW,DO-41,TP
....4 DZ016 0403-000700 DIODE-ZENER;TZP33A,5%,1000MW,DO-41,TP
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO
....4 DZ016 0403-001140 DIODE-ZENER;RD10ESAB-T4,9.7-10.2V,400MW,
....4 DZ016 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D
....4 DZ016 0403-001317 DIODE-ZENER;MTZJ3.0B,3.01-3.22V,500MW,DO
....4 DZ016 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO
....4 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO
....4 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO
....4 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO
....4 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO
....4 DZ016 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500MW,DO
....4 DZ016 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500MW,D
....4 DZ016 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.2V,500MW,DO
....4 DZ016 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.2V,500MW,DO
....4 T0156 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
....4 T0156 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
....4 T0156 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T
....4 T0156 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO-
....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T
....4 T0090 0502-000242 TR-POWER;KSA614,PNP,25W,TO-220,TP,40-24
....4 Q902 0504-001159 TR-DIGITAL;SRC1211M,NPN,400MW,10KOHM,TO-
....4 IC012 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL
....4 VX801S 1405-000187 V ARISTOR;750V,1250A,12.5x7mm,TP
....4 R125 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R125 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R125 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm
....4 R125 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R075 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM
....4 R075 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM
....4 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R075 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M
....4 R075 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R075 2001-000109 R-CARBON(S);470OHM,5%,1/2W,AA,TP,2.4X6.4
....4 R125 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
....4 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
Electrical Parts List
7-8 Samsung Electronics
Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark
Loading...
