* Some of the contents of this manual may differ from your phone,

depending on the software installed or your service provider.

World Wide Web http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-06599A

English. 07/2005. Rev 1.2

SGH-D500C User’s Guide

Important

safety

precautions

Failure to comply with the following precautions may be dangerous or illegal.

Use road safety at all times

Do not use a hand-held phone while driving. Park the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them in an aircraft is both illegal and dangerous.

Switch off the phone near all medical equipment

Hospitals or health care facilities may be using equipment that could be sensitive to external radio frequency energy. Follow any regulations or rules in force.

Interference

All wireless phones may be subject to interference, which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid unnecessary contact with the antenna when the phone is switched on.

Emergency call

Key in the emergency number for your present location, then press .

Keep your phone away from small children

Keep the phone and all its parts, including accessories, out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and batteries. Use of any unauthorised accessories could damage your phone and may be dangerous.

• The phone could explode if the battery is replaced with an incorrect type.

• Dispose of used batteries according to the manufacturer’s instructions.

Qualified service

Only qualified service personnel may repair your phone.

For more detailed safety information, see "Health and safety information" on page 89.

Important safety precautions

About this Guide

This User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your phone, please refer to “Get started.”

In this guide, the following instruction icons appear:

Indicates that you need to pay careful attention to the subsequent information regarding safety or phone features.



[

Indicates that you can get more information on the referenced page.

Indicates that you need to press the Navigation

→

keys to scroll to the specified option and then select it.

Indicates a key on the phone. For example,

]

[]

Indicates a soft key, whose function is displayed

on the phone screen. For example, <

• Camera and camcorder

Use the camera module on your phone to take a photo or record a video.

Special

features of your phone

•MP3 player

Play MP3 music files using your phone as an MP3 player.

•Bluetooth

Send photos, images, videos, and other personal data, and connect to other devices using free, wireless Bluetooth technology.

•IrDA

Send and receive Phonebook and Organiser data via an infrared port.

• Plug-in speaker

Use the included external speaker to talk without having to hold the phone.

• Voice clarity

Use the voice clarity feature to increase the volume and clarity of an incoming call, even in the midst of a crowd.

• Get Personal with photo caller ID

See who’s calling you when their very own photo displays.

• Name card

Create name cards with your number and profile. Whenever introducing yourself to others, use this convenient electronic name card.

• Multimedia Message Service (MMS)

Deliver MMS messages with a combination of text, images, video, and audio.

•E-mail

Deliver e-mails with images, video, and audio attachments.

•Java

Enjoy Java™-based embedded games and download new games.

•Organiser

Keep track of your daily, weekly, and monthly schedule.

• Voice recorder

Record memos or sounds.

Special features of your phone

Contents

Unpack 6

Make sure you have each item

Your phone 6

Buttons, features, and locations

Get started 7

First steps to operate your phone

Install and charge the phone ................................... 7

Power on or off ...................................................... 8

Keys and display .................................................... 9

Access menu functions.......................................... 11

Customise your phone .......................................... 12

Make/answer calls ................................................ 13

Step outside the phone 14

Begin with your camera, music, games, and other special features

Use camera ......................................................... 14

Play MP3s ........................................................... 15

Play games.......................................................... 16

Browse WAP ........................................................ 16

Use Phonebook .................................................... 17

Send messages.................................................... 18

View messages .................................................... 19

Use Bluetooth wireless .......................................... 20

Enter text 21

Pinyin, Stroke, English, Quick English (T9), Number, and Symbolic modes

Call function 25

Menu functions 30

All menu options listed

Solve problems 87

Help and personal needs

Health and safety information 89

Overview of menu functions

To access Menu mode, press <

1 Call records

1 All calls 2 Dialled calls 3 Received calls 4 Missed calls 5 Delete all 6 Call time 7 Call costs

2 Phonebook

1 Contact list 2 Add new contact 3 Group 4 Speed dial 5 My name card 6 Own number 7 Management

3 Applications

1 Java world 2 MP3 Player 3 Voice recorder 4 World time 5 Alarm 6 Calculator

> from the idle screen.



p.30



p.30



p.30



p.30



p.31



p.31



p.31



p.31



p.32



p.32



p.32



p.33



p.34



p.34



p.35



p.35



p.35



p.35



p.37



p.39



p.40



p.41



p.41

3 Applications

7 Converter 8 Timer 9 Stopwatch 10 SIM AT*

4 Browser

1 Home 2 Bookmarks 3 Go to URL 4 Clear cache 5 Profile settings 6 Current proxy

5 Messages

1 Short messages 2 Multimedia messages 3 Email 4 Push messages 5 Voice mail 6 Text template 7 Broadcast messages 8 Memory status

(continued)

   



     



       

6 Funbox

p.42

Images

p.42

Videos

p.42

Music

p.43

Sounds Memory status

p.43

7 Organiser

p.43 p.44

1 Month view

p.45

2 Week view

p.45

3 Day view

p.45

4 Schedule

p.46

5 Anniversary 6 Miscellaneous

p.46

7 To do

p.46

8 Missed alarm events

p.49

9 Memo

p.55

10 Memory status

p.60 p.61 p.61 p.61 p.62



p.62

    



         

8 Camera

p.62

1 Take a photo

p.62

2 Record video

p.63

3 Photos

p.64

4 My photos

p.64

5 Video clips 6 My video clips

p.64

9 Settings

p.64 p.67

1 Time & Date

p.67

2 Phone settings

p.67

3 Display settings

p.67

4 Sound settings

p.67

5 Network services

p.68

6 Connectivity

p.68

7 Security 8 Memory status

p.68

9 Reset settings

p.69

* Shows only if supported by your

SIM card.



p.69



p.69



p.72



p.74



p.75



p.75



p.76



p.76



p.76



p.76



p.78



p.79



p.80



p.82



p.85



p.87



p.87

Unpack

Make sure you have each item

Your pho ne

Buttons, features, and locations

Camera

lens

Flash

Earpiece

Phone

Battery User’s Manual External

Travel Adapter

Speaker

You can obtain various accessories from your local Samsung dealer.

The items supplied with your phone and the accessories at your Samsung dealer may vary, depending on your country or service provider.

Volume keys

Left soft key

Dial key

IrDA port

Special

function keys

Display

Navigation keys (Up/Down/Left/ Right)

WAP access/ Confirm key

Right soft key

Power on/off/ Menu exit key

Cancel/Correct key

Alphanumeric keys

Microphone

Headset jack

Camera key

Get started

First steps to operate your phone

SIM card information

When you subscribe to a cellular network, you receive a plug-in SIM (Subscriber Identity Module) card loaded with your subscription details, such as your PIN, and available optional services.

Install and charge the phone

Remove the battery.

1 2

If the

phone is already on, first turn it off by holding [ ].

Insert the SIM card.

Make sure that the goldcoloured contacts on the card face down into the phone.

Install the battery. Plug the travel adapter

3 4

Plug the adapter into a standard AC wall outlet.

When the phone is completely charged (the battery

icon stops blinking), unplug the adapter from the power outlet.

into the phone.

Get started

Remove the adapter from the phone.

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone automatically turns off. Recharge your battery.

Power on or off

Power on

Do not turn on the phone when mobile phone use is prohibited.

Power off

Keypad lock

When you close the phone, the keypad lock feature locks the exposed keys so that nothing will happen if the keys are accidentally pressed.

To unlock the keypad, press the left soft key and press <OK>.

1. Open the phone.

2. Press and hold the phone.

3. If necessary, enter the phone password and press <OK>.

4. If necessary, enter the PIN and press <OK>

1. Open the phone.

2. Press and hold

[]

to turn on

[]

Keys and display

Key(s) Description

Perform the function indicated on the bottom line of the display.

In Idle mode, access menu options



directly. In Menu mode, scroll through the menu

options.

In Idle mode, launches the Wireless Application Protocol (WAP) browser.

In Menu mode, selects the highlighted menu option.

Sends or answers a call. In Idle mode, retrieves the last number

dialled, missed, or received.

Deletes characters from the display. In Menu mode, returns to the previous menu

level.

Ends a call. Hold down to switch the phone on and off. In Menu mode, cancels input and returns the phone to Idle mode.

page 77

Key(s) Description

Enter numbers, letters, and some special characters. In Idle mode, hold voicemail.

Enter special characters. Hold [

Quiet mode.

Adjusts the phone volume. In Idle mode, with the phone open, adjusts the keypad tone volume. With the phone

(on the left)

(on the right)

closed, hold down to turn on the backlight. In Menu mode, scrolls through the menu

options.

In Idle mode, hold down to turn on the camera. In Camera mode, takes a photo or starts recording a video.

[1]

down to access your

]

down to activate or deactivate

Get started

Display

Layout

Icons

The display has the three areas.

Icons

displays various icons.

Text and graphics

displays messages, instructions, and information you enter.

Soft key function

Contacts

Received signal strength

Call in progress

Out of your service area; you cannot send or receive calls

Alarm set

New text message

New voicemail message

New multimedia message

indicators

shows the current functions assigned to the two soft keys.

Icons

(continued)

New e-mail received or being sent

One of the message Inboxes is full

Call diverting feature is active



page 80

IrDA port is active

Bluetooth feature is active



page 82

Synchronised with a PC

GPRS network

Home Zone, if you have registered for the appropriate service

Office Zone, if you have registered for the appropriate service

Set to vibrate call ringer



page 79

Quiet mode is active

Battery power level



page 85

page 79

Access menu functions

Use the soft keys

The roles of the soft keys vary depending on the function you are using. The bottom line of the display indicates their current role.

Menu Contacts

Press the left soft key to access

mode.

Press the right soft key to access

Contact list Phonebook

in the menu.

Select an option

Use shortcuts

1. Press the appropriate soft key.

2. Press the Navigation keys to move to the next or previous option.

3. Press <

Select

> or [ ] to confirm the function displayed or option highlighted.

4. To exit, choose either of the following methods:

•Press <

Back

> or [C] to

move up one level.

•Press

[]

to return to Idle

mode.

Press the number key corresponding to the option you want.

Get started

Customise your phone

Display language

Call ringer melody

1. In Idle mode, press < and select

settings → Language

2. Select a language.

1. In Idle mode, press < and select

settings → Incoming call → Ring tone

2. Press [Left] or [Right] to select a ringer category.

3. Press [Up] or [Down] to select a ringer melody.

4. Press

Save

Settings → Phone

Settings → Sound

Idle mode Wallpaper

Menu mode Skin colour

You can set a wallpaper for the idle screen.

1. In Idle mode, press < and select

settings → Wallpaper

2. Select an image category.

3. Press scroll key to select an image.

You can change the colour for the display components, such as title bars and highlight bars.

1. In Idle mode, press < and select

settings → Skin

2. Select a colour pattern.

Settings → Display

Quiet mode

You can switch the phone to Quite mode to avoid disturbing other people with your phone sounds.

Press and hold

[

]

in Idle mode.

Phone lock

You can protect the phone against unauthorised use with a phone password.

1. In Idle mode, press < and select

Security → Change password

2. Enter the default password, “00000000” and press <OK>.

3. Enter a new 4- to 8- digit password and press <OK>.

4. Enter the new password again and press <OK>.

5. Select

6. Select

7. Enter the password and press <OK>.

Settings →

Phone lock

Enable

Make/answer calls

Make a call

Answer a call

Adjust the volume during a call

1. Enter an area code and phone number.

2. Press [ ].

3. To end the call, press

1. When the phone is ringing, press [ ].

2. To end the call, press

Press [ / ].

[]

Get started

Step outside the phone

Begin with your camera, music, games, and other special features

Use camera

Take a photo

View a photo

1. Open the phone.

2. In Idle mode, press and hold [ ] to turn on the camera.

3. Aim the lens at the subject and adjust the image.

4. Press [ ] to take a photo. The photo is saved automatically.

5. Press [C] to take another photo.

1. In Idle mode, press [ ] and select

Photos

2. Select the photo you want.

Record a video

Play a video

1. In Idle mode, press and hold [ ] to turn on the camera.

2. Press [1] to switch to Record mode.

3. Press [ ] to start recording.

4. Press [ ] to stop recording. The video is saved automatically.

5. Press [C] to record another video.

1. In Idle mode, press [ ] and select

Video clips

2. Select the thumbnail image of the video you want.

Play MP3s

Copy MP3 files to the phone

Create a play list

Use these methods:

• Download from the wireless webpage 43

• Download from a computer using EasyStudio II



EasyStudio II User’s Guide

• Receive via IrDA or Bluetooth



page 82

1. In Idle mode, press < and select

MP3 player

2. Press <

Add to list → Add all file

3. For and press < step 2.

Applications →

Options

Add a file

Add

Menu>

> and select

Add a

, scroll to a file

>. Repeat from

Play MP3 music

1. From the MP3 player screen, press

[]

2. During playback, use the following onscreen keys:

• pauses playback.

• resumes.

• goes back to the

previous file.

• skips to the next file.

•// changes

the repeat mode.

• stops playback. To select a key, press [Left] or

[Right], then press To adjust the volume, use [ /

[]

Step outside the phone

Play games Browse WAP

Select a game

Play ForgottenWarrior

Play Freekick

1. In Idle mode, press < and select

Java world → Downloads → ForgottenWarrior Freekick

2. Press any key once or twice to launch the game.

1. Press <

2. Select

1. Select you want → a team → a player.

2. Press

Applications →

Play

StartGame

Game →

[]

Menu>

the game mode

Launch the browser

Navigate the web

In Idle mode, press

• To scroll through browser items, press [Up] or [Down].

• To select an item, press < >.

• To return to the previous page, press <

Back

• To return to the home page, hold down [C].

[]

> or [C].

Use Phonebook

Add an entry

To the phone’s memory

1. In Idle mode, enter a phone

2. Select

3. Specify the contact information:

4. Press

To t h e S I M c ard

1. In Idle mode, enter a phone

2. Select

3. Enter a name.

4. Press

number and press <

Phone →

Last name, First name, Mobile, Home, Office, Fax, Other, Email, Graphic ID, Alert, Group, and Notes.

[]

number and press <

SIM

[]

Save

a number type.

to save the entry.

Save

to save the entry.

Find an entry

Create and send a name card

1. In Idle mode, press <

Contacts

2. Select an entry.

3. Select a number and press [ ] to dial, or < options.

1. In Idle mode, press < and select

name card

2. Specify your contact information.

3. Press < name card.

4. To send the name card to other people, press < select

Email/Bluetooth/infrared

Options

Phonebook → My

Save

Send → via SMS/MMS

> to access

> to save the

Options

> and

Step outside the phone

Send messages

Send a text message (SMS)

1. In Idle mode, press <

2. Enter the message text.

3. Press <

4. Enter destination numbers.

5. Press <

and select

messages → Create

Send and save

Send

Messages → Short

Options

> and select or

> and select

Send only

5. Add a media file.

6. Select

7. Enter the message text and

8. Press <

9. Enter destination numbers or

10. Press <

Message

press

[]

Options

Send

e-mail addresses.

Options

Send

> and select

Send a multimedia message (MMS)

1. In Idle mode, press < and select

Multimedia messages → Create

2. Select

3. Enter the message subject and press

4. Select

Sound

Messages →

Subject

[]

Picture & video

Send an e-mail

1. In Idle mode, press < and select

→ Create

2. Select

3. Enter the e-mail subject and press

4. Select

5. Enter the e-mail text and press []

Messages → Email

Subject

[]

Message

Menu>

6. Select

7. Add image, video, music, or

8. Press <

9. Enter e-mail addresses.

10. Press <

View messages

View a text message

When a notification appears: Press <

displays.

From the Inbox:

1. In Idle mode, press <

2. Select a message.

File Attach

sound files.

Options

Send

Options

Send

View

>. The message

and select

messages → Inbox

> and select

Messages → Short

View a multimedia message

View an e-mail

When a notification appears:

1. Press <

2. Press <

From the Inbox:

1. In Idle mode, press <

2. Select a message.

1. In Idle mode, press <

2. Select

3. Select an e-mail or header.

4. If you selected a header, press

View

Options

Retrieve

displays.

and select

Multimedia messages → Inbox

and select

→ Inbox

Check new mail

Options

Retrieve

> and select

. The message

Messages →

Messages → Email

> and select

Step outside the phone

Use Bluetooth wireless

Your phone is equipped with Bluetooth technology which enables you to connect the phone wirelessly to other Bluetooth devices and exchange data with them, talk hands-free, or control the phone remotely.

Turn on Bluetooth

Search for and pair with a Bluetooth device

In Idle mode, press < select

Settings → Connectivity →

Bluetooth → Activation → On

1. In Idle mode, press < and select

Connectivity → Bluetooth → My devices → Search new device

2. Select a device.

3. Enter a Bluetooth PIN code or the other device’s Bluetooth PIN code, if it has one, and press <OK>.

When the owner of the other device enters the same code, the pairing is complete.

Settings →

> and

Menu>

Send data

Receive data

1. Access an application,

Phonebook, Funbox Camera

2. Select the item you want to send.

3. Press <

Send → via Bluetooth

4. Select a device.

5. If necessary, enter the Bluetooth PIN and press <OK>.

To receive data via Bluetooth, your phone’s Bluetooth feature must be active.

If necessary, press < confirm the reception.

, or

Organiser

Options

> and select

Yes

> to

Enter text

Pinyin, Stroke, English, Quick English (T9), Number, and Symbolic modes

You can enter text for some features such as messaging, Phonebook, or Organiser, using Chinese Pinyin mode, Chinese Stroke modes, English mode, Quick English mode, Number mode, and Symbolic mode.

Changing the text input mode

The text input mode indicator displays when the cursor is in a text field.

■

Press the right soft key to change the input mode.

Example:

Enter the last name

: Pinyin mode

S STR

: Simplified Stroke mode

T9 ENG

: Quick English mode

ABC

: English mode

T STR

: Traditional Stroke mode

NUM

: Number mode

SYM

: Symbolic mode

Text input mode indicator

Using Pinyin mode

Pinyin is a system to mark Chinese pronunciation in Latin alphabets. With the pinyin input method, you can enter Chinese characters by entering the pinyin string from the phone keypad.

Entering characters in Pinyin mode

Press the keys corresponding to the phonetic spelling, using the one key per letter.

Example:

If necessary, press [Left] or [Right] to select the pinyin you want.

If necessary, press [Up] or [Down] to scroll through choices in the character selection field.

Press [1] or [ ] to activate the character selection field. A number, 1 to 5, is added to the characters.

Press the number key, [1] to [5], corresponding to the character you want.

Tips for using Pinyin mode

• Press [ ] to insert a space between characters.

• Press [Left] or [Right] to move the cursor.

To enter “ ” (li), press [5] and [4].

Enter text

•Press [C] to remove strokes to the left. Holding [C] removes all of entered key strokes or characters.

Using Chinese Stroke modes

These modes allow you to enter individual Chinese strokes, in written order, from top to bottom and from left to right. Your phone provides Simplified Stroke mode and Traditional Stroke mode.

The Chinese strokes are classified into five basic categories; heng, shu, pie, dian and zhe. The basic strokes are printed on the keypad, on keys [1] to [5].

The following table shows the stroke/key relationship:

Catetory Keys Strokes represented in each category

Entering strokes and characters in a Stroke mode

Press the keys corresponding to its component strokes in the order that you would write the strokes.

Example: To enter “ ,” press [5] to enter “ ” and then [3] to enter “

If necessary, press [Up] or [Down] to scroll through choices in the character selection field.

If you are uncertain of the order of strokes, press [6] in place of each questionable stroke. Continue entering strokes until the character displays or until you finish the character.

Press the number key, [7] to [0], corresponding to the character you want.

.”

Tips for using Stroke modes

• Press [ ] to insert a space between characters.

• Press [Left] or [Right] to move the cursor.

• Press [C] to remove strokes to the left. Holding [C] removes all of entered key strokes or characters.

Using English mode

Press the appropriate key until the character you want appears on the screen.

Keys

Tips for using English mode

• To enter the same letter twice or to enter a different letter on the same key, wait for the cursor to move to the right automatically or press [Right]. Then, enter the next letter.

•Press

Characters in the order displayed

Upper case

[

]

to insert a space.

Lower case

•Press

[

]

to shift case. Lower case (No indicator), Initial capital ( ), and Capital lock ( ) are available.

• Press [Left] or [Right] to move the cursor.

• Press [C] to delete characters one by one. Press and hold [C] to clear the display.

Using Quick English (T9) mode

Quick English is a predictive text input mode that allows you to key in any character using single keystrokes.

Entering a word in Quick English mode

Press [2] to [9] to start entering a word. Press each key once for each letter.

For example, press [4], [3], [5], [5], and [6] to enter HELLO in Quick English mode.

T9 predicts the word that you are typing, and it may change with each key that you press.

Enter the whole word before editing or deleting the characters.

Enter text

When the word displays correctly, go to step 4. Otherwise, press [0] to display alternative word choices for the keys that you have pressed.

For example, OF and ME use [6] and [3].

Press

[

]

word.

Tips for using Quick English mode

•Press [1] to enter periods or apostrophes automatically.

•Press Initial capital ( ), and Capital lock ( ) are available.

• Press [Left] or [Right] to move the cursor.

•Press [C] to delete characters one by one. Press and hold [C] to clear the display.

Adding a new word to the T9 dictionary

This feature may not be available for some languages.

Enter the word that you want to add.

Press [0] to display the alternative words for your key presses. When there are no more alternative words,

to insert a space and enter the next

[

]

to shift case. Lower case (No indicator),

Spell

displays on the bottom line.

Press <

Spell

Enter the word you want using English mode and press <OK>.

Using Number mode

Number mode enables you to enter numbers.

■

Press the keys corresponding to the digits you want.

Using Symbolic mode

Symbolic mode enables you to insert symbols.

To Press

display more symbols

select a symbol the corresponding

clear the symbol(s) [C].

insert the symbol(s) <OK>.

[Up]

or [Down].

number key.

Call function

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone number.

2. Press [ ].

Press [C] to clear the last digit or press and hold [C] to clear the whole display. You can move the cursor to edit an incorrect digit.

Making an international call

1. In Idle mode, press and hold [0]. The + character appears.

2. Enter the country code, area code, and phone number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of recent numbers.

2. Scroll to the number you want and press [ ].

Making a call from Phonebook

Once you have stored a number in Phonebook, you can dial the number by selecting it from Phonebook.p. 32

You can also use the speed dial feature to assign your most frequently called numbers to specific number keys.



p. 34

Dialling a number from the SIM card

You can dial stored phone numbers easily and quickly by using the locataion numbers.

1. In Idle mode, enter the location number for the phone number you want and press the[ ]key.The entry appears.

2. Press [Left] or [Right] to scroll through other numbers.

3. Press <

Dial

> or [ ] to dial the number you want.

Ending a call

Close the phone or press [ ].

Call function

Answering a call

When you receive an incoming call, the phone rings and displays the incoming call image.

Press [ ] or <

> to answer the call.

Tips for answering a call

• When

•Press <

• Press and hold [ / ] to mute the ringer.

Anykey answer

menu is active, you can press any key to answer a call, except for [ ] and <

Reject

> or [ ] to reject a call.

in the

Reject

Extra settings

>.p. 77

Viewing missed calls

If you have missed calls, the screen displays how many calls you have missed.

1. Press <

2. If necessary, scroll through the missed calls.

3. Press [ ] to dial the number you want.

View

Using the headset

Use the headset to make or answer calls without holding the phone.

Connect the headset to the jack on the right side of the phone.

The buttons on the headset work as listed below:

To Press

redial the last call the buttom once and hold.

answer a call and hold the button.

end a call and hold the button.

Using the external speaker

Use the external speaker that came with your phone to talk and listen with the phone a short distance away. First, you must plug the speaker into the phone.

1. During a call, press [ ] to listen and talk to the other person hands-free. The icon appears.

2. Press [ ] again to return to normal phone mode. The icon appears.

Options during a call

You can access a number of functions during a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during a call.

Press [ ] to increase the volume level and [ ] to decrease the volume level.

Placing a call on hold/Retrieving

Press <

Hold

> or <

or retrieve the call.

Retrieve

> to place the call on hold

4. Press <

5. To end the current call, press [ ].

Options

the call on hold.

> and select

End held call

to end

Answering a second call

You can answer an incoming call while already on the phone, if your network supports it and you have activated the call waiting feature.p. 81

1. Press [ ] to answer the call. The first call is automatically put on hold.

2. Press <

3. Press <

4. To end the current call, press [ ].

Swap

> to switch between the calls.

Options

the call on hold.

> and select

End held call

to end

Call function

Making a second call

You can make another call if your network supports it.

1. Press <

2. Make the second call in the normal way.

3. Press <

Hold

> to put the call on hold.

Swap

> to switch between the calls.

Using a Bluetooth headset

Use an optional Bluetooth headset to talk on the phone without holding the phone to your ear. To use this feature, you first need to register your headset and connect it to the phone.p. 82

Press <

Options

Switch to phone

> and select

Switch to headset

Using the voice clarity feature

This feature increases the microphone’s sensitivity so that the person with when you are speaking can hear you clearly even though you may be whispering.

Press <

Options

Voice clarity off

Switching off the microphone

You can temporarily switch off your phone’s microphone so that the person on the phone cannot hear you.

Press <

Options

> and select

Voice clarity on

(Mute mode)

Mute

Unmute

Sending a sequence of DTMF tones

Dual tone multi-frequency (DTMF) tones are the tones used in phones for tone dialling.

You can send DTMF tones as a group after entering the entire number you need to send or retrieving a number from Phonebook. This feature is helpful for entering a password or an account number when you call an automated system, like a banking service.

1. When connected with a teleservice system, press <

Options

2. Enter the number you need to send and press <OK>.

> and select

Send DTMF

Muting or sending key tones

You can turn the key tones off or on.

Press <

keys

Options

> and select

Mute keys

Using Phonebook

You can access the store entries.p. 32

Press <

Options

Phonebook

> and select

Phonebook

Send

menu to locate or

Using the message service

You can access the incoming message and send a new message.p. 46

Press <

Options

Messages

> and select

menu to read an

Message

Using SIM services

The

SIM service

card in your phone. A SIM card provides services such as news, weather, sports, entertainment, and location services.

menu is available if you use a SIM

For details, see your SIM card instructions or contact your service provider.

Making a multi-party call

Use this feature to allow as many as six people to join a multi-party call, or conference call.

Your service provider must support multi-party calls for you to use this feature.

Setting up a multi-party call

1. Call the first participant.

2. Call the second participant. The first call is automatically put on hold.

3. Press <

4. If desired, call another person or answer an

5. Press <

6. Repeat steps 4 and 5 as desired.

Options

participant is added to the multi-party call.

incoming call.

Options

> and select

Join

. The first

Having a private conversation with one participant

1. Press <

2. Select a name or number from the participant list.

3. To return to the multi-party call, press <

Options

You can talk privately with that person, while the other participants converse with each other.

and select

> and select

Join

Split

Options

Dropping one participant

1. Press <

2. Select a name or number from the participant list.

3. Close the phone or press [ ] to end the multi-

Options

The participant is dropped from the call, but the call continues with the other parties.

party call.

> and select

Remove

Call function

Menu functions

All menu options listed

Call records

Use this menu to view the calls you have dialled, received, or missed, the length of your calls, and the cost of your calls.

To access this menu, press < select

Call records

All calls

This menu displays the 20 most recent calls dialled, received, or missed.

Accessing a call record

1. Press [Left] or [Right] to select a call type.

2. Press [Up] or [Down] to scroll through the call list.

3. Press [ ] to dial a number, or [ ] to view the details of a call.

(Menu 1.1)

(Menu 1)

> in Idle mode and

Using call record options

While viewing the call list, press < the following options:

•

Details

: view the details of the selected call.

•

Call back

•

Paste

•

Send message

•

Delete

•

Delete all

call records.

Dialled calls

This menu displays the 20 most recent calls you have dialled.

Received calls

This menu displays the 20 most recent calls you have received.

: dial the number.

: save the number in Phonebook.

: send an SMS or MMS message.

: delete the selected call record.

: delete all dialled, received, and missed

(Menu 1.2)

(Menu 1.3)

Options

> to access

Missed calls

This menu displays the 20 most recently received calls that you did not answer.

Delete all

Use this menu to delete all of the records in each call type.

1. Press [ ] to check the call type(s) to clear.

2. Press <

3. Press <

Call time

This menu displays the time log for calls made and received. The actual time invoiced by your service provider will vary.

•

Last call time

•

Total sent

you have dialled.

(Menu 1.4)

(Menu 1.5)

Delete Yes

(Menu 1.6)

> to confirm the deletion.

: check the length of your last call.

: check the total length of all the calls

•

Total received

you have calls received.

•

Reset timers

enter the phone password.

The password is preset to change this password.p. 86

Call costs

This network feature displays the cost of calls. This menu is available only if your SIM card supports this feature. Note that this is not intended to be used for billing purposes.

•

Last call cost

•

Total cost

If the total cost exceeds the maximum cost set in

Set max cost

you can make another call.

•

Max cost Set max cost

: check the total length of all the

: reset the call timers. You need to

00000000

(Menu 1.7)

: check the maximum cost limit set in

: check the cost of your last call.

: check the total cost of all of your calls.

, you must reset the counter before

. You can

Menu functions

Call records

(Menu 1)

Menu functions

•

Reset counters

need to enter your PIN2.

•

Set max cost

for your calls. You need to enter your PIN2.

•

Price/Unit

when the cost of your calls is calculated. You need to enter your PIN2.

Phonebook

You can store phone numbers on your SIM card and in your phone’s memory. The SIM card and phone’s memory are physically separate, but they are used as a single entity called Phonebook.

To access this menu, press < select

Phonebook

Contact list

Use this menu to search for numbers in Phonebook.

Press <

Contacts

this menu.

: reset the cost counters. You

: set the maximum cost authorised

: set the price per unit that is applied

(Menu 2)

(Menu 2.1)

> in Idle mode to quickly access

> in Idle mode and

Finding an entry

1. Enter the first few letters of the name that you want to find.

2. Select the name you want from the list.

3. Press [ ] to dial the number, or < access Phonebook options.

Options

> to

Using Phonebook options

While viewing a contact in Phonebook, press <

Options

•

Add new contact

Use this menu to add a new contact to Phonebook.

> to access the following options:

Edit

: edit the contact information.

Send message Copy

: copy the number to the phone’s memory or

SIM card.

Send

: send the contact via SMS, MMS, e-mail,

Bluetooth, or infrared port.

Delete

: deletes the selected contact list.

: send an SMS or MMS.

(Menu 2.2)

Storing a number in the phone’s memory

1. Select

2. Press [Down] and change the settings or enter

3. Press [ ] to save the contact.

Phone

information about the contact.

•

Last name/First name

•

Mobile/Home/Office/Fax/Other

number in any category.

•

: assign an e-mail address.

Graphic ID

image to alert you to a call from the number.

Alert

you to a call from the number.

Group Notes

: assign an image as a caller ID

: assign a unique ringer melody to alert

: assign the number to a caller group.

: add a memo about the person.

: assign a name.

: add a

Storing a number on the SIM card

1. Select

2. Press [Down] and enter a phone number.

3. If necessary, press [Down] and change the location

4. Press [ ] to save the contact.

number.

SIM

and enter a name.

Group

Use this menu to organise your contacts in caller groups.

(Menu 2.3)

Creating a new caller group

1. Press <

2. Enter a name for your group.

3. Select the graphic ID line and select an image.

4. Select the alert line and select a melody.

5. Press <

Options

Save

> and select

> to save the group.

Add

Adding members to a caller group

1. Select a group.

2. Press [ ] to open the Contact list screen.

3. Select the contact you want to add to the group.

4. To add more members, press < select <

Add> →

a contact.

5. Repeat step 4 as desired.

Options

> and

Managing caller groups

From the group list, press < following options:

Options

> to access the

Menu functions

Phonebook

(Menu 2)

Menu functions

•

View

: display the members of the selected group.

•

Add

: add a new group.

•

Edit

: change the properties of the selected group.

•

Delete

: delete the group, but the members of the

group are not deleted from Phonebook.

Speed dial

Use this menu to assign speed dial numbers (2 to 9) for eight of your most frequently called numbers.

Assigning speed dial entries

1. Select a key location from 2 to 9. Key 1 is reserved for your voice mail server.

2. Select the contact you want from the contact list.

Managing speed dial entries

While viewing the Speed dial screen, press <

Options

•

Add

•

Change

key.

•

Remove

(Menu 2.4)

> to access the following options:

: assign a number to an unassigned key.

: assign a different number to an assigned

: clear all speed dial settings.

Dialling speed dial entries

Press and hold the appropriate key in Idle mode.

My name card

Use this menu to create a name card and send it to other people.

(Menu 2.5)

Saving your name card

The procedure for creating your name card is the same as the one for saving a number in the phone’s memory.p. 32

Using name card options

After saving your name card, press < access the following options:

•

Edit

: edit the name card.

•

Send

: send the name card via SMS, MMS, e-mail,

Bluetooth, or infrared port.

•

Exchange name card

with another person’s name card via the Bluetooth feature.

•

Delete

: delete the name card.

: exchange the name card

Options

> to

Own number

Use this feature to check your phone numbers, or to assign a name to each of the numbers.

Changes made here do not affect the actual subscriber numbers on your SIM card.

Management

Use this menu to manage Phonebook.

•

Default saving

to save contacts. If you select

you to select a memory location when saving a number.

•

Copy all to phone

on the SIM card to the phone’s memory.

•

Delete all

phone’s memory, your SIM card, or both.

1. Press [ ] to check the location(s) to clear.

2. Press <

3. Press <

(Menu 2.6)

(Menu 2.7)

Ask on saving

: delete all of the contacts from your

Delete Yes

> to confirm the deletion.

: select a default memory location

, the phone will ask

: copy all of the contacts stored

4. Enter the phone password and press <OK>. The password is preset to

change this password.p. 86

•

Memory status

you have stored in Phonebook.

Applications

Use this menu to play Java games, to play MP3 music files, to record a voice memo, to set time zones and alarms, or to use the phone as a calculator, timer, or stopwatch.

To access this menu, press < select

Applications

Java world

Use this menu to access and play Java games and to change the DNS setting required for accessing Java services.

: display the number of contacts

(Menu 3)

(Menu 3.1)

00000000

> in Idle mode and

. You can

Using Java game options

From the Java world screen, select press <

Options

> to access the following options:

Downloads

and

Menu functions

Applications

(Menu 3)

Menu functions

•

Launch

: launch the selected MIDlet.

•

Application Settings

when a call comes in or an alarm sounds during the game. You can also set the phone to exchange game information with the network while playing an online game or when you need to connect to the Internet.

•

Delete

: delete the MIDlet.

•

Properties

: view the MIDlet properties.

Playing ForgottenWarrior

1. From the

ForgottenWarrior

2. press any key.

3. Press <

4. Select

5. Press <OK> to start a game.

Java world

PLAY

StartGame

During a game, press < options.

: set a game to be continued

menu, select

OPTIONS

Downloads →

> to access game

Playing Freekick

1. From the

Freekick

2. Press any key.

3. Select

team → a player.

4. Press [ ] to start a game.

During a game, press [ ] to access game options.

Java world

Game →

menu, select

the game mode you want → a

Changing Java settings

You can change the settings for accessing Java services.

1. From the

2. Change the following settings:

•

Java world

APN

: enter the access point name.

: enter the User ID.

menu, select

: enter the password.

Downloads →

Settings

•

Proxy

: select whether or not you use a proxy server to access network services. Depending on this setting, options in

•

Proxy settings

options:

When the proxy is set to

IP address Port

: enter the port number.

When the proxy is set to

DNS1

: Enter the primary DNS address.

DNS2

: Enter the secondary DNS address.

: provide you with the following

: enter the HTTP proxy address.

Proxy settings

Enable

Disable

vary.

Checking memory status

You can view the amount of total and used memory for Java games.

From the

Java world

menu, select

Memory status

MP3 Player

Use this menu to enjoy music. First, you need to save MP3 files in your phone’s memory.

(Menu 3.2)

Downloading or receiving MP3 music files

Use these methods to save MP3 files to your phone:

• Download from the wireless webp. 43

• Download from a computer using the EasyStudio II programmeEasyStudio II User’s Guide

• Via an active IrDA or Bluetooth connection



p. 82

The downloaded or received files are stored in the

Music

folder.p. 63

Creating a play list

Add the MP3 files to the play list so you can play them.

1. From the MP3 player screen, press < and select

2. Select either of the following options:

•

Add to list

Add all

: add all of the files in the phone’s

memory to the play list.

Add a file

: add one file to the play list.

Options

Menu functions

Applications

(Menu 3)

Menu functions

3. If you selected <

Add

>. Repeat from step 1.

4. Press < screen.

Playing MP3 files

From the MP3 player screen, press [ ].

During playback:

• Use the following buttons on the display:

Buttons Function

/ / Changes the repeat mode

To select a button, press [Left] or [Right] to highlight it and press [ ].

Add a file

Back

> to go back to the MP3 player

, scroll to a file and press

Pauses

Resumes

Stops

Returns to the previous file

Skips to the next file

• Press [ / ] to adjust the volume.

• Press <

Stop

> to stop playback.

Using MP3 file options

From the MP3 player screen, press < access the following options:

•

Play/Pause

•

Send

Bluetooth, or infrared port.

•

Open play list

•

Set as

alert melody for a Phonebook entry.

•

Delete

•

Settings

MP3 files.

Repeat Shuffle Volume Lock volume key

prevent an accidental press of the keys from affecting playback.

: begin/pause playback.

: send the currently selected file via e-mail,

: go to the play list.

: set the file as your ring tone or as a caller

: delete the file.

: change the default settings for playing

: select a repeat mode. : select a playing order.

: select a volume level.

: lock [ / ] so that you can

Options

> to

Equalizer value

•

Properties

: select an equalizer setting.

: view the properties of the file.

Changing the play list

1. From the MP3 player screen, press < and select

2. Press <

•

Voice recorder

Use this menu to record voice memos. A voice memo can be up to one hour long.

Open play list

Options Play Add to list Move list

position you want within the play list.

Remove Remove all

> to access the following options:

: play the currently selected file.

: add files to the play list.

: move the selected file to the

: remove the file from the play list.

: remove all files from the play list.

(Menu 3.3)

to access the play list.

Options

Recording a voice memo

1. Press [ ] to start recording.

2. Speak into the microphone.

• Select to pause the recording.

• Select to resume the recording.

3. When you finish, press < voice memo is automatically saved.

4. Press <

Options

•

Play

•

Send

Bluetooth, or infrared port.

•

Rename

•

Delete

•

Protection

being deleted.

•

Properties

mail.

> to access the following options:

: play back your voice memo.

: send the voice memo via MMS, e-mail,

: change the name of the voice memo.

: delete the voice memo.

: protect the voice memo from

: view the properties of the voice

Stop

> or select . The

Playing a voice memo

1. From the Voice record screen, press < and select

2. Select a voice memo. The memo plays.

Go to voice list

Options

Menu functions

Applications

(Menu 3)

Menu functions

During playback:

• Use the following buttons on the display.

Buttons Function

Pauses

Resumes

Stops

To select a button, press [Left] or [Right] to highlight it and press [ ].

• Press [ / ] to adjust the volume.

•Press <

Using voice memo options

From the Voice record screen, press < access the following options:

•

Stop

> or to stop playback.

Record

: record a new voice memo.

Settings

recording a voice memo.

Recording time Volume

: change the default settings for

: select a recording time.

select a volume level.

Options

> to

Default name

voice memo.

Equalizer value

•

Go to voice list

have recorded.

World time

Use this menu to set your local time zone and find out what time it is in another part of the world.

: change the default prefix of the

: select an equalizer setting.

: go to the list of voice memos you

(Menu 3.4)

Setting your local time zone

1. From the world map, press [Left] or [Right] to select the city that corresponds to your home time zone. As the time line moves, the time and date of the given zone display.

2. Press [ ] to save the time zone.

Viewing and setting a foreign time zone

1. From the world map, press [Down].

2. Press [Left] or [Right] to select the foreign time zone you want to view.

3. Press [ ] to save the time zone.

Applying Daylight Savings Time

1. From the world map, press <

Set daylight saving time

2. Press [ ] to check the time zone(s) you want.

3. Press <

Alarm

Use this menu to set alarms to ring at a specific time.

Save

(Menu 3.5)

Options

> and select

Setting an alarm

1. Select the type of alarm.

2. Press [Left] or [Right] to select On on the line and press [Down].

3. Enter the time for the alarm to sound and press [Down].

4. Select AM or PM in 12-hour time format.

Your phone is preset to a 24-hour format. You can change the time format.p. 76

5. Select the

6. Press [ ] to check the day(s) for the alarm.

7. Press <OK>.

Alarm day

line.

Alarm

8. Select the melody.

9. Press <

Alarm tone

Save

> and then <

line and select an alarm

Yes

Stopping an alarm (for Moning call)

When the alarm sounds, choose either of the following options to stop the alarm:

• Press <

Confirm Snooze

5 minutes. You can do this a maximum of 5 times.

> or any key to stop the alarm for

Setting the alarm to ring even if the phone is off

From the Alarm screen, select

If the phone is off when it is time for the alarm to ring, the phone switches on and sounds the alarm.

Calculator

Use this menu to perform basic arithmetic functions such as addition, subtraction, multiplication, and division.

1. Enter the first number. Press [ ] to insert a decimal point.

(Menu 3.6)

Auto power → On

Menu functions

Applications

(Menu 3)

Menu functions

2. Press [ ] to access the math function you want.

3. Enter the second number.

4. Press <

Converter

Use this menu for common conversions, such as weight and temperature.

1. Select the converter type you want.

2. Press [Left] or [Right] to select the original unit

3. Enter the value to be converted and press [Down].

4. Press [Left] or [Right] to select the unit you want

Equal

> to view the result.

(Menu 3.7)

and press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature to above zero (+) or below zero (-).

to convert to. The equivalent value for the amount you entered

displays.

Timer

Use this menu to set a period of time for the phone to count down. The phone will sound an alarm when the specified period of time has expired.

(Menu 3.8)

Starting the timer

1. Press <

2. Enter the length of time you want to count down.

3. Press [ ] to start counting down.

Set

Stopping the timer

• Press any key to stop the timer when it rings.

• Press [ ] on the Timer screen to stop the timer before it rings.

Stopwatch

Use this menu to measure elapsed time. The precision of the stopwatch is one one-hundredth of a second. The maximum measurement time is 10 hours.

1. Press [ ] to start the timer.

2. Press [ ] to check an interval. You can repeat this step for a total of 4 intervals.

(Menu 3.9)

3. Press the <

To exist, press the <

SIM AT

This menu is available if you use a SIM AT card that provides additional services, such as news, weather, sports, entertainment, and location services. Available services may vary, depending on your service provider’s plans.

For details, see your SIM card instructions or contact your service provider.

Browser

The Wireless Application Protocol (WAP) browser on your phone allows you to access the wireless web. Using the WAP browser, you can access updated information and a wide variety of media content, such as wallpapers, ring tones, and music files.

To access this menu, press < select

Browser

Reset

(Menu 3.10)

(Menu 4)

> soft key to reset.

Back>

soft key or the [C] key.

> in Idle mode and

Home

(Menu 4.1)

Use this menu to connect your phone to the network and load the homepage of the wireless web service provider. You can also press [ ] in Idle mode.

Navigating with the WAP browser

To Press

scroll through browser items [Up] or [Down].

select a browser item < >.

return to the previous page <

return to the homepage and hold [C].

Back

> or [C].

Selecting and using browser menu options

1. Press

2. Select one of the following browser options:

key

screen.

•

Back

•

Home

•

Exit

or select the on the top of the

: go back to the previous page.

: go back to the homepage.

: exit the WAP browser.

Menu functions

Browser

(Menu 4)

Menu functions

•

Reload

•

Using WAP page options

From any WAP page, press [ ] to access the following options:

•

Go to URL

•

Bookmarks

•

Messages

box in the create and send a new SMS message.p. 46

•

Funbox

Exiting the WAP browser

Press [ ] to exit the browser.

: reload the current page.

Show URL

current web page. You can also set the current page as the homepage for the WAP browser.

About...

WAP browser.

: display the URL address of the

: view version information for your

: enter a URL address manually.

: switch to the

: check the

Short messages

: switch to the

Bookmarks

Inbox, Outbox

menu. You can also

Funbox

menu.p. 62

menu.

, and

Draft

Bookmarks

Use this menu to save URL addresses to quickly access a website.

(Menu 4.2)

Adding a bookmark

1. Select an empty location.

2. Enter a name for the bookmark and press [Down].

3. Enter a URL address.

4. Press <

Options

bookmark.

> and select

save

to save the

Accessing a bookmarked page

Scroll to a bookmark item and press [ ].

Using bookmark options

After saving an item, press < following options:

•Go: access the website.

•

Edit

: edit the address and name of the bookmark.

•

Delete

: delete the bookmark.

Options

> to access the

Go to URL

(Menu 4.3)

Use this menu to manually enter the URL address of a website and access the website.

Clear cache

(Menu 4.4)

Use this menu to clear the cache, which is the temporary memory that stores the web pages you have recently accessed.

Profile settings

(Menu 4.5)

Use this menu to set up servers for the WAP browser. Contact your service provider for details about your settings options.

For each server, the following options are available:

•

Profile name

•

Home URL

•

Bearer

: assign a name to the server profile.

: set the address of your homepage.

: select a bearer for each type of network

address accessed.

•

Proxy

: select whether or not the phone uses a proxy server to launch the WAP browser. Your service provider can tell you if your network

requires a proxy server, and they can give you the appropriate settings.

•

GPRS settings

: customise the following GPRS

network settings:

When the proxy is set to

IP address Port APN

: enter the WAP gateway address. : enter the port number. : enter the access point name of the GPRS

Enable

network gateway.

When the proxy is set to

DNS 1 DNS 2 APN

: enter the User ID.

: enter the password.

Disable

: enter the primary address. : enter the secondary address

: enter the access point name of the GPRS

network gateway.

•

GSM settings

: enter the user ID

: enter the password

: customise the following GSM

network settings:

Menu functions

Browser

(Menu 4)

Menu functions

When the proxy is set to

IP address Port Dial number Login ID Password Data call type

: enter the WAP gateway address.

: enter the port number.

: enter the PPP server phone number.

: enter the user ID.

: enter the password.

: select a data call type.

When the proxy is set to

DNS 1

: enter the primary address.

DNS 2

: enter the secondary address.

Dial number Login ID Password Data call type

Current proxy

: enter the PPP server phone number.

: enter the user ID.

: enter the password.

: select a data call type.

(Menu 4.6)

Use this menu to activate one of the proxy servers you have set up.

Enable

Disable

Messages

Use the

(Menu 5)

Messages

menu to send and receive short messages, multimedia messages, and e-mails. You can also use WAP push message, Voice mail, and Cell broadcast message features.

To access this menu, press < select

Messages

Short messages

(Menu 5.1)

> in Idle mode and

Short Message Service (SMS) allows you to send or receive text messages including pictures, audio clips, and animated images.

The maximum number of characters allowed in a short message varies by service provider. If your message exceeds the maximum number of characters, the phone will split the message.

Creating an SMS message

1. From the

Short messages

menu, select

Create

2. Enter your message.

3. Press <

•

Text style

Options

> to access the following options:

: change the text attributes.

•

Add media

: add a picture, animated image, or

a melody to the message.

•

Text template

:preset the frequently used

messages.

•

Save message Draft

box.

4. When you finish, press <

Send and save

: save the message in the

Options

Send only

> and select

5. Enter a destination number. To send the message to more than one recipient,

press [Down] and fill in the destination fields.

6. Press <

Options

> and select

Send

Viewing received SMS messages

1. From the

Short messages

menu, select

2. Select a message.

While viewing the message list, press <

Options

access the following options:

•

View

: display the message.

•

: reply to the sender.

•

Send

: forward the message.

Inbox

> to

•

Delete

: delete the message.

•

Delete all

•

Call back

•

Block number

: delete all messages.

: call the sender.

: add the sender’s number to the

Menu functions

Blocked number list.

While viewing a message, press <

Options

> to access

the following options:

•

: reply to the sender.

•

Send

: forward the message.

•

Call back

•

Edit

•

Delete

•

Cut media

to your phone’s memory.

•

Cut address

: call the sender.

: edit the message.

: delete the message.

: save media items from the message

: extract URLs, e-mail addresses, or

Messages

(Menu 5)

phone numbers from the message.

•

Transfer

: move the message between the SIM

card and the phone’s memory.

•

Block number

: add the sender’s number to the

Blocked number list.

Menu functions

•

Protection

deleted.

Viewing sent or saved SMS messages

1. From the or

Draft

2. Select a message.

While viewing the message list, press < access the following options:

•

View

•

Send

•

Edit

•

Delete

•

Delete all

While viewing a message, press < the following options:

•

Send

•

Edit

•

Delete

•

Cut address

phone numbers from the message.

: protect the message from being

Short messages

: open the message.

: send or resend the message.

: edit the message.

: delete the message.

: delete all messages.

: send or resend the message.

: edit the message.

: delete the message.

: extract URLs, e-mail addresses, or

menu, select

Options

Outbox

Options

> to access

> to

•

Transfer

card and the phone’s memory.

•

Protection

deleted.

: move the message between the SIM

: protect the message from being

Changing SMS settings

1. From the

Settings

2. Select a setting profile to be customised. The last setting profile accessed will be activated for sending subsequent messages.

3. Change the following settings:

•

Short messages

The setting options available in this menu may vary depending on your service provider.

Reply path

through your message centre.

Delivery report

you when your message has been delivered.

Validity period

messages are stored in the message centre while the network attempts to deliver them.

Message type

: allow the recipient to reply to you

: set the default message type.

menu, select

: set the network to inform

: set the length of time your

•

Service centre

: store or change the number

of your message centre.

Setting up the Blocked number list

Use the Blocked number list to reject SMS messages from specific phone numbers.

1. From the

number

Short messages

menu, select

Block

2. Enter the phone number you want to block. Press [Down] and add up to ten phone numbers.

3. Press <

Options

> and select

Save

Clearing SMS message boxes

1. From the

all

Short messages

menu, select

Delete

2. Press [ ] to check the message box(es) to be cleared.

3. Press <

4. Press <

Delete

Yes

> to confirm the deletion.

Multimedia messages

(Menu 5.2)

Multimedia Message Service (MMS) delivers messages containing a combination of text, image, video, and audio, from phone to phone or from phone to e-mail.

Creating an MMS message

1. From the

Create

2. Select the

3. Select the

Multimedia messages

Subject

Picture & Video

menu, select

line and enter the subject.

Sound

line and add

an image, a video, or an audio file.

The maximum size allowed for an MMS message can differ depending on the country. If you cannot attach another file, add another page.

4. Select the

5. Press <

•

Message

Options

Edit

: edit the subject or text of your message.

Add media/sound

line and enter the text.

> to access the following options:

: add more photos, videos,

or sounds to the message.

•

Preview

: display the message you have

created.

Menu functions

Messages

(Menu 5)

Menu functions

•

Add page

pressing [Left] or [Right] on the message screen.

•

Page timing

displays. After the specified time, the display automatically scrolls to the next page.

•

Text style

attributes.

•

Clear subject/Picture & Video/sound message

text.

•

Delete page

•

Save message Draft, My folder

6. When you have finished, press < select

7. Enter a phone number or e-mail address. To send the message to more than one recipient,

press [Down] and fill in additional destination fields.

8. Press <

: add pages. Move to each page by

: specify how long a page

: format the text colour, size, or

: clear the subject, images, audio, or

: delete an added page.

: save the message in the

, or

Template

Send

Options

> and select

Options

Send

box.

> and

Viewing received MMS messages

1. From the

Inbox

This menu displays MMS messages that you have received. The following icons tell you the message status:

• has been read

• has not been read

• is being retrieved from the server

• Notification that you have read

• Notification that you have not read

2. Select a message.

While viewing the message list, press < access the following options:

•

View

•

Reply all

recipients in the To, Cc fields.

•

Forward

If the message contains media purchased on the Internet, forwarding is not available.

Multimedia messages

: open the message.

: send a reply to the sender.

: send a reply to the sender and all of the

: forward the message to another person.

menu, select

Options

> to

•

Call back

•

Delete

•

Delete all

•

Save as template

the

•

Properties

: call the sender.

: delete the message.

: delete all messages.

: save a copy of the message in

Template

folder.

: view the message properties.

When you select a notification, you can access

Retrieve

to retrieve the message from the MMS

server.

While viewing a message, press <

Options

> to access

the following message options:

•

Replay

: replay the message.

•

: send a message to the sender.

•

Reply all

: send a reply to the sender and all of the

recipients in the To, Cc fields.

•

Forward

: forward the message to another person. If the message contains media content purchased on the Internet, forwarding is not available.

•

Call back

•

Delete

: call the sender.

: delete the message.

•

Cut media

: save media items from the message

to your phone’s memory.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Move to My folder folder

box.

•

Save as template

the

Template

•

Properties

: move the message to the

: save a copy of the message in

box.

: (except

Draft

) view the message

properties.

Viewing sent or saved MMS messages

1. From the

Outbox, Draft

Multimedia messages

, or

My folder

menu, select

2. Select a message.

While viewing the message list, press <

Options

access the following options:

•

View

: open the message.

•

Send

: send or resends the message.

•

Edit

: edit the message.

•

Delete

: delete the message.

•

Delete all

: delete all of messages.

> to

Menu functions

Messages

(Menu 5)

Menu functions

•

Properties

properties.

While viewing a message, press < the following options:

•

Replay

•

Send

•

Edit

•

Delete

•

Cut media

from the message to your phone’s memory.

•

Cut address

address, or phone number from the message.

•

Move to My folder

message to the

•

Save as template

save a copy of the message in the

•

Properties

properties.

Using MMS templates

Your phone has 11 preset messages that you can use when composing a message.

(except

: replay the message.

: send or resends the message.

: edit the message.

: delete the message.

: (for

: (except

My folder

:(except

: (except

My folder

:(except

Draft

) : display the message

Options

) save media items

Draft

) extract a URL, e-mail

My folder

box.

Draft, My folder

Draft

) display the message

> to access

)move the

Template

)

box.

1. From the

Template

2. Select an MMS template.

While viewing the template list, press < access the following options:

•

View

•

Send

•

Edit

•

New

•

Delete

•

Delete all

While viewing a message, press < the following options:

•

Replay

•

Send

•

Edit

•

Delete

Multimedia messages

: display the template.

: send the template.

: edit the template.

: add a new template.

: delete the template.

: delete all of templates.

: replay the template.

: send the template.

: edit the template.

: delete the template.

menu, select

Options

> to access

> to

Changing MMS settings

You can customise the settings for sending and receiving MMS messages.

1. From the

Settings

Multimedia messages

menu, select

2. Select a setting category and change the settings.

Send settings

•

Priority

: set the priority level of your messages.

•

Validity period

: set the length of time your

messages are stored in the message centre.

•

Delivery after

: set the time delay before

messages are sent.

•

Address hiding

: hide your phone number on the

recipient’s phone.

•

Delivery report

: set the network inform to you

when your message has been delivered.

•

Read reply

Receive settings

•

Home reception

: request a reply from the recipient.

: determine if your phone retrieves new messages automatically when you are in your home service area.

•

Roaming reception

: determine if your phone retrieves new messages automatically when you are roaming in another network.

Home reception and Roaming reception have the following options:

Automatic

: the phone automatically retrieves

messages from the server.

Reject

: the phone rejects all messages.

Manual

: the phone displays notifications. Use the

Retrieve

option to manually download new

messages.

•

Anonymous reject

: reject messages from

anonymous senders.

•

Adverts reject

•

Report allowed

: reject advertisements.

: send a delivery report from the

network to the sender.

MMS profiles

You can configure required network settings for MMS. The last profile accessed is automatically activated for sending or receiving subsequent messages.

Menu functions

Messages

(Menu 5)

Menu functions

Check with your service provider before you change any MMS settings on your phone.

•

Current profile

•

Profile setting

for each profile:

Profile name Server URL

server.

Proxy

: connect to the GPRS network using the

proxy server.

GPRS settings

for connecting to the GPRS network.

IP address

enter the gateway address.

Port

: (when the proxy is set to

the port number.

DNS1

: (when the proxy is set to

the primary address.

DNS2

: (when the proxy is set to

the secondary address.

: select a profile.

: customise the following options

: assign a name to the MMS profile.

: enter the address of your MMS

: customise the settings required

: (when the proxy is set to

Enable

) enter

Disable

)

) enter

APN

: enter the access point name used for the

address of the GPRS network.

Password

Version

maximum size limit for sending or receiving messages.

: enter the user ID.

: enter the password.

: select an available OMA version and

Depending on your service provider, it may not be possible to support the maximum limit 295KB. In this case, try again after changing the setting to 100KB.

Clearing MMS message boxes

1. From the

Delete all

2. Press [ ] to check the message box(es) to be cleared.

3. Press <

4. Press <

Multimedia messages

Delete

Yes

> to confirm the deletion.

menu, select

(Menu 5.3)

You can send and receive e-mails that include text, audio, and images. To use this feature, you need to subscribe to an e-mail service and set up your e-mail profile and account.p. 58, p. 59

Creating an e-mail

1. From the

2. Select the

Subject

menu, select

Create

line and enter the subject of

your e-mail.

3. Select the

4. Select the

5. Add

6. Press <

•

Message File attach

Images, Videos, Music

Options

Add:

adds a subject, text, or media files.

Edit:

edits the subject or text.

View:

displays the attached file.

Save Email: My folder Clear subject/message:

line and enter the e-mail text.

line.

, or

> to access the following options:

saves the e-mail in the

box.

clears the subject or

Sound

Draft

text.

•

Remove attachment

: delete the selected

attachment.

•

Remove all attachments

: delete all

attachments.

7. When you finish, press <

Send

Options

> and select

8. Enter an e-mail address. To send the e-mail to more than one recipient,

press [Down] and fill in additional destination fields.

9. Press <

Options

> and select

Send

Viewing received e-mails

1. From the

2. Select

menu, select

Check new mail

Inbox

to get new mails from

your server. The phone checks for new e-mails and retrieves

received e-mails. The icons tell you the status of each e-mail:

• retrieved from the e-mail server

• retrieved e-mail with attachment.

• not retrieved

Menu functions

Messages

(Menu 5)

Menu functions

• T he ic o n ch ange s to a n op e n en vel o pe w hen you read the e-mail.

• An ! icon shows that an e-mail was sent with high priority. A grey icon means that the e-mail is of low priority.

3. Scroll to an e-mail or header and press [ ].

4. If the e-mail has more than one page, press [ / ] to scroll through pages one by one.

Press [ ] or [ ] to move to the first or last page.

5. Select an attached file to view or play it.

While viewing the e-mail list, press < access the following options:

Options may vary depending on the status of the e-mail.

•

View

: open the selected item.

•

Retrieve

e-mail server.

recipients.

: retrieve one or all e-mails from the

: send a reply to the sender or to all of the

Options

> to

•

Forward

•

Delete

•

Delete all

•

Sort

senders’ e-mail addresses.

•

Block

Blocked address list.

•

Properties

While viewing a header or e-mail, press < access the following options:

•

Retrieve

•

Open file

•

Save file

memory.

•

and all of the recipients.

•

Forward

•

Delete

•

Cut address

phone numbers.

: forward the e-mail.

: delete the currently selected item.

: delete all e-mails.

: sort the e-mails by size, subject, data, or

: add the sender’s e-mail address to the

: display the properties of the e-mail.

: retrieve one or all e-mails.

: open the attached file.

: save the attached file in your phone’s

: send a reply to the sender or to the sender

: forward the e-mail.

: delete the e-mail.

: extract e-mail addresses, URLs, and

Options

> to

•

Block

: add the sender’s e-mail address to the

Blocked address list.

•

Move to My folder folder

box.

•

Properties

: move the e-mail to the

: display the properties of the e-mail.

Viewing sent or saved e-mails

1. From the

My folder

menu, select

Outbox, Draft

2. Select an e-mail.

While viewing the e-mail list, press < access the following options:

•

View

: open the e-mail.

•

Send

: send or resends the e-mail.

•

Cancel

:(for

outbox

) stop sending the e-mail.

•

Edit

: edit the e-mail.

•

Delete

: delete the e-mail.

•

Delete all

•

Sort

: delete all e-mails.

: sort the e-mails by size, subject, date, or

senders’ e-mail addresses.

•

Properties

: display the properties of the e-mail.

Options

, or

> to

While reading a message, press <

Options

> to access

the following options:

•

Open file

•

Save file

memory.

•

Cancel

•

Send

•

Edit

•

Delete

•

Cut address

: open the attached file.

: save the attached file in your phone’s

:(for

outbox

) stop sending the e-mail.

: send or resent the e-mail.

: edit the e-mail.

: delete the e-mail.

: (for

My folder

) extract e-mail

Menu functions

Messages

addresses, URLs, and phone numbers.

•

Move to My folder folder

box.

•

Properties

: move the e-mail to the

: view the properties of the e-mail.

(Menu 5)

Changing e-mail settings

1. From the

menu, select

Settings

2. Select a setting category and change the settings.

Menu functions

Send settings

•

Send copy to self

your own e-mail address.

•

Delivery confirm

when your e-mail has been delivered.

•

Read confirm

with your e-mail.

•

Priority

: select the priority level of your e-mail.

•

Include signature

number, a simple memo, or tag line to your e-mail.

Receive settings

•

Check interval

checks the server for incoming e-mails. If you set this option to

Check new mail

manually.

•

Read reply

sends a read-reply request. When this option is set to

reminds you to send a read-reply request with your e-mail address.

: send a copy of your e-mail to

: set the network to inform you

: send a request for a reply along

: attach your name, phone

: determine how often the phone

Not used

feature to check your e-mail

: determine whether or not the phone

, you can use the

Announce

, the phone

•

Retrieve option

retrieves headers only or the entire e-mail.

•

Delete option

deleted immediately or the next time you connect to the server.

•

Reject if over

incoming e-mails. Your phone will reject e-mails that exceed the specified size.

•

Leave a copy of messages on the server

determine whether or not to delete the messages in the server when retrieve them.

E-mail account

Set up your e-mail account(s) and select the one to be used:

You cannot change e-mail account settings while an e-mail is being sent or retrieved. Your e-mail service provider can give you the information needed for the below settings.

•

Current account

: determine whether the phone

: determine whether e-mails are

: determine the maximum size for

: select an account.

•

Account setting

: configure up to five e-mail accounts using different e-mail servers. The following options are available for each account:

Account name

: enter a name for the currently

selected account.

In use

: select this option to use the account and

to display the account in the

User name

: enter a name to be displayed as the

Inbox

sender’s name in your outgoing e-mails.

Email address Reply address SMTP server

: enter your e-mail address. :enter your reply address

: enter the IP address or domain

name of the outgoing e-mail server.

SMTP port Protocol type

: enter the SMTP port number.

: select the protocol for the incoming e-mail server. The remaining options depend on the protocol type setting.

When the protocol type is

POP3 server:

enter the IP address or domain

POP3

name of the server that receives your e-mail.

POP3 port

: enter the POP3 port number.

APOP login

: connect to the server by using the

APOP login scheme when this option is selected.

User ID Password

When the protocol type is

IMAP4 server

: enter your e-mail ID.

: enter your e-mail password.

IMAP4

: enter the IP address or domain

name of the server that receives your e-mail.

IMAP4 port Retrieve headers

: enter the IMAP4 port number.

: set the number of headers you

will retrieve from the server.

Retrieve attachments

: select this option to

receive attachments with e-mails.

User ID Password

: enter your e-mail ID.

: enter your e-mail password.

Email profile

You can configure the network settings required to send or receive e-mails.

You cannot change e-mail profile settings while an e-mail is being sent or retrieved.

Menu functions

Messages

(Menu 5)

Menu functions

The following options are available:

•

Current profile

•

Profile setting

profiles. For each profile, the following options are required to connect to the GPRS network:

Profile name APN

: enter the access point name used for the

GPRS network address.

: enter the primary address.

DNS2

: enter the secondary address.

Setting up the Blocked address list

Use the Blocked address list to reject messages from e-mail addresses that you specify.

1. From the

2. Select

3. Enter an e-mail address or subject you want to

4. Add as many as ten items.

Block address

block.

: select a profile.

: configure up to five e-mail

: enter a name for the e-mail profile.

: enter the User ID.

: enter the password.

menu, select

Block list

Block subject

5. Press <

Options

> and select

Save

Clearing e-mail boxes

1. From the

2. Press [ ] to check the message box(es) to be cleared.

3. Press <

4. Press <

You cannot clear the e-mail is being sent or retrieved.

Push messages

Use this menu to access messages from the WAP server.

•

Inbox

•

Settings

receives push messages.

Always Never Optional

the service centre set in this option.

•

Delete all

menu, select

Delete

Yes

> to confirm the deletion.

Inbox

(Menu 5.4)

: view push messages you have received.

: determine whether or not your phone

: the phone receives push messages.

: the phone rejects push messages.

: the phone receives push messages from

: delete all of push messages.

Delete all

Outbox

while an

Voice mail

Use this menu to store the number of the voice mail server and access your voice mails.

You must enter the voice server number before you can access your voice mails. Your service provider can give the voice server number.

•

Connect to voice mail

server to allow you to listen to your messages. You can also connect to the voice mail server by pressing and holding [1] in Idle mode.

•

Voice server number

server name or number.

Text template

Use this menu to preset a maximum of ten frequently used messages.

(Menu 5.5)

: connect to the voice

: change the voice mail

(Menu 5.6)

Adding a text template

1. Select an empty location.

2. Enter the message and press [ ].

Using template options

From the template list, press < the following options:

•

Edit

: add a template or change the selected one.

•

Send message

MMS or e-mail message.

•

Delete

: delete the template.

: send the template as an SMS ,

Broadcast messages

The Cell Broadcast service delivers short messages on various topics such as the weather or traffic.

Use this menu to change the settings for the service and to access broadcast messages.

•

Read

: open received messages.

The

Temporary

the phone is switched off. The

Archive

box saves network messages until

box saves network messages

box.

(Menu 5.7)

Options

> to access

> and select

Save

Menu functions

Messages

(Menu 5)

Menu functions

•

Receive

broadcast messages.

•

Channel

receive broadcast messages.

•

Language

messages display.

Please contact your service provider for details.

Memory status

Use this menu to view the memory status for text, multimedia, e-mail, or push messages.

Funbox

The videos, music, and sounds stored in the phone’s memory.

To access this menu, press < select

: enable or disable the reception of

: specify the channels from which you

: select the language in which broadcast

(Menu 5.8)

(Menu 6)

Funbox

menu allows you to access images,

Funbox

> in Idle mode and

Images

This menu displays photos you have taken and images downloaded or received in messages.

(Menu 6.1)

Viewing an image

1. Select an image folder,

Downloaded images

A list of images displays. For downloaded images, the icons tell you the status of the files:

• you can forward to other people

• you are unable to forward to other people

2. Scroll to an image and press [ ].

Photos, My photos

, or

Using image options

While viewing the image list or an image, press <

Options

Videos

This menu displays video clips you have recorded, downloaded, or received in messages.

> to access the options.p. 74

(Menu 6.2)

Playing a video clip

1. Select a video folder, or

Downloaded video

A list of videos displays. For downloaded videos, the icons tell you the status of the files:

• you can forward to other people

• you are unable to forward to other people

2. Scroll to a video clip and press [ ].p. 75

Video clips, My video clips

Using video options

While viewing the video list, press < access the options.p. 75

Music

(Menu 6.3)

This menu displays MP3 music files you have downloaded or imported from your computer.

Options

> to

Playing a music file

Scroll to a file and press [ ].p. 38

Using music options

While viewing the music list, press < access the following options:

Available options vary depending on whether or not playback is in progress.

•

Play/Pause

•

Send

Bluetooth, or infrared port.

•

Add play list

•

Open play list

•

Set as

alert melody for a Phonebook entry.

•

Rename

•

Delete

•

Settings

files.

Repeat Shuffle Volume

: begin/pause playback.

: send the currently selected file via e-mail,

: add a file to the play list.

: go to the play list.

: set the file as your ring tone or as a caller

: change the file name.

: delete the file.

: change the default settings for playing

: select a repeat mode. : select a playing order.

: select a volume level.

Options

> to

Menu functions

Funbox

(Menu 6)

Menu functions

Lock volume key

prevent an accidental press of the keys from affecting playback.

Equalizer value

•

Delete all

•

Protection

•

Properties

Sounds

This menu displays the sound files you have recorded, downloaded, or received in messages.

(Menu 6.4)

Playing a sound clip

1. Select a sound folder,

sounds

A list of sound clips displays. For downloaded sounds, the icons tells you the status of the files:

• you can forward to other people

• you are unable to forward to other people

2. Scroll to a sound clip and press [ ].p. 39

: lock [ / ] so that you can

: select an equalizer setting.

: delete all of files.

: protect the file from being deleted. : display the properties of the file.

Voice list

Downloaded

Using sound options

While viewing the sound list, press < access the options.p. 40

Memory status

You can check the total amount of memory for media items and the amount of memory currently in use in each media box.

Organiser

The Organiser feature enables you to keep track of your schedule and tasks, to view missed alarm events, and to make a memo.

To access this menu, press < select

Organiser

Month view

Use this menu to keep track of your monthly schedule.

(Menu 6.5)

(Menu 7)

(Menu 7.1)

Options

> in Idle mode and

> to

Consulting the calendar

When you select today’s date is marked with a red box.

Month view

to display the calendar,

The number of events displays at the bottom of the calendar. The following icons indicate the type of event:

• Scheduled events • Anniversaries

• Tasks • Miscellaneous events

Press <

•

Options View Create

> to access the following options:

: access the stored memo(s) for that date.

: add a new event, anniversary,

miscellaneous event, or task.

•

Week view

•

Go to today

•

Go to date

•

Delete Selected date

: switch to the week view screen.

: access the current date.

: enter a specific date.

: access the following deleting options:

: delete items stored on the

currently selected date.

Preceding events

•

Delete all

: delete all of scheduled events.

: delete events on past dates.

You can schedule up to 400 events on the calendar, and schedule more than one event per day.

Entering a new scheduled event

1. Select a date on the calendar.

2. Press <

Options

Miscellaneous

> and select

Create → Schedule

3. Enter information or change the settings in the following entry fields:

•

Subject

•

: enter the title of the event.

Details

: enter event details.

Start date

and

End date

: enter the starting

and ending dates for the event.

•

Start time

and

End time

: enter the starting

and ending times for the event.

•

AM/PM

: select AM or PM in 12-hour time

format.

•

Location

: (for

Schedule

) enter information

about the event location.

•

Alarm

: set an alarm for the event.

•

Before

•

: set the time for the alarm.

Alarm tone Repeat

: select an alarm tone.

: (for

Schedule

) set the event to recur,

and set a repeat unit.

Menu functions

Organiser

(Menu 7)

Menu functions

•

Until

: (for

set the ending date.

4. Press <

Schedule

Save

> to save the event.

Entering a new anniversary

1. Select a date on the calendar.

2. Press <

3. Enter information or change the settings in the

Options

Anniversary

following entry fields:

•

Occasion

anniversary.

•

Date

•

Alarm

•

Before

week

•

Alarm time

sound.

•

AM/PM

format.

•

Alarm tone

•

Repeat every year

remind you of the anniversary every year.

> and select

: enter information about the

: enter the date.

: set an alarm for the anniversary.

: set the time for the alarm. Select

: enter the time for the alarm to

: select AM or PM in 12-hour time

: select an alarm tone.

) if the event will recur,

Create →

: you can set the phone to

day

4. Press <

Save

> to save the event.

Entering a task

1. Select a date on the calendar.

2. Press <

3. Enter information or change the settings in the

4. Press <

Options

following entry fields:

•

To do

•

Start date

•

Due date

•

Priority

Save

> and select

: enter information about the task.

: enter the starting date.

: enter the ending date.

: select a priority level.

> to save the event.

Create → To do

Viewing an event

Square brackets on a calendar date indicate the following type of events scheduled for that day:

• Blue: scheduled • Orange: anniversary

• Red: task • Green: miscellaneous event

1. Select a date on the calendar to display the events for that day.

2. Select an event to view its details.

3. Press <

Options

> to access the following options:

•

View

•

Week View

Use this menu to view events for the selected week. The current date is marked in red. Blue boxes indicate scheduled events, and green boxes indicate miscellaneous events. Select the cell that contains the event you want.

: access the selected event.

Edit

: edit the event.

Send

: send the event via SMS, MMS, e-mail,

Bluetooth, or infrared port.

Create

: add a new event.

Month view Week view Done/Undone

event.

Delete Delete all

selected date.

: switch to the month view screen.

: switch to the week view screen.

: change the status of the

: delete the event.

: delete all of the events for the

(Menu 7.2)

Day view

Use this menu to view events for the selected date. Select an event to view its details.

Schedule

This menu displays the scheduled events. If you have set the Repeat and Alarm options, the and icons are activated. Select an event to view its details.

Anniversary

This menu displays anniversaries you have created. If you have set the Repeat and Alarm options, the and icons are activated. Select an event to view its details.

Miscellaneous

This menu displays miscellaneous events you have created. If you have set the Alarm option, the icon is activated. Select an event to view its details.

(Menu 7.3)

(Menu 7.4)

(Menu 7.5)

(Menu 7.6)

Menu functions

Organiser

(Menu 7)

Menu functions

To do

(Menu 7.7)

Use this menu to display tasks you have created. The colours of status check boxes indicate the importance:

•Red ! for high priority

• Blue for normal priority

• Grey for low priority.

A check mark appears in the status check box if the task has been completed. The options you can use are the same as in Day view.

Missed alarm events

When you are unable to acknowledge an alarm, the phone displays a missed alarm notification.

Press <

View

> to view the corresponding event.

(Menu 7.8)

Viewing a missed event alarm

1. From the

events

2. Select an event.

3. Press <

Organiser

Confirm

menu, select

> to confirm and delete the event.

Missed alarm

Using missed alarm options

From the event list, press < following options:

•

View

: access the event.

•

Delete

: delete the event.

•

Delete all

Memo

Use this menu to create memos and view memos you have stored.

: delete all events.

(Menu 7.9)

Options

> to access the

Creating a new memo

1. Press [ ].

2. Enter the memo text and press [ ].

Viewing a memo

Select a memo to view its details.

Using memo options

From the memo list, press < following options:

•

Edit

: edit the memo.

Options

> to access the

•

Create

: add a new memo.

•

Delete

: delete the selected memo.

•

Delete all

Memory status

: delete all memos.

(Menu 7.10)

This menu displays the total amount of memory for the calendar, the number of events you have created, and the total number of events you can store.

Camera

(Menu 8)

You can use the camera module embedded in your phone to take photos and record videos.

To access this menu, press < select

Camera

• Do not take photos of people without their

, or press [ ].

permission.

> in Idle mode and

• Do not take photos in a place where cameras are not allowed.

• Do not take photos in a place where you may interfere with another person’s privacy.

Take a photo

(Menu 8.1)

The camera produces JPEG photos.

When you take a photo in direct sunlight or in bright conditions, shadows may appear on the photo.

Taking a photo

1. If the phone is closed, open the phone.

2. Press and hold [ ]. The image to be captured appears on the display.

3. Adjust the image by aiming the camera lens at the subject.

• Press the left soft key to use the camera

options.p. 70

• Use the keypad to change the camera settings

or switch to other modes.p. 71

4. Press [ ] to take a photo. The photo is saved in the

Photos

folder.

Hold the phone still for one or two seconds after pressing the camera shutter key to allow the image data to process.

Menu functions

Camera

(Menu 8)

Menu functions

To Press

use photo options <

delete the photo <

return to Capture mode [C] or [ ].

Using camera options in Capture mode

In Capture mode, press the left soft key to access the following options:

•

Shooting mode

modes:

Single shot Multi shot

number of photos the camera will take.

Mosaic shot

one frame. Select the number of still images the camera will take.

Night shot

lighting conditions.

Automatic save

save a photo after taking the photo.

: take a photo in the following

: take a photo in the normal mode.

: take a series of action stills. Select the

: take several stills and save them in

: take a high quality photo in low

: set the phone to automatically

Options

Delete

>.p. 71

•

Effects

: change the colour tone or apply a special

effect to the photo.

•

Frames

: apply a decorative frame.

•

Timer

: set a time delay before the camera takes a

photo.

•

Go to photo album

the

Photos

•

Settings

photo.

Size Quality Shutter sound

when you press the shutter, [ ] or [ ].

Spot focus

specific area of the image. Select On to display the spot focus frame in the middle of the image, and change the exposure according to the brightness of the image fragment in the frame.

ISO

sensitivity of your camera. For low light situations, lower the ISO number to increase the quality.

: change the default settings for taking a

: select an image size.

: select an image quality.

: adjust the exposure based on a

: change the ISO setting, which controls the

: display the photos stored in

My photos

: select the sound that you hear

folder.

The higher the ISO number, the faster the camera shutter functions and the more sensitive the camera is to light. Higher ISO settings may bring some distortion to an image.

Default name

: change the default prefix of the

photo name.

•

Flash

: turn the flash on or off.

•

Camera short cuts

: view the functions of the

keys you can use.

Using the keypad in Capture mode

You can use the keypad to customise your camera settings in Capture mode.

Key Function

Flips the image vertically.

Shows the mirror image.

Left/

Adjusts the brightness of the image.

Right

Up/

Zooms in or out.

Down

Switches to Record mode.p. 72

Key Function

Changes the image size.

Changes the image quality.

Changes the camera mode.

Changes the colour tone or applies a special effect to the photo.

Reduces the distortion on the image to maximise detail and sharpness.

Selects a decorative frame.

Sets the timer.

Shows the photos stored in the

My photos

folder.

Turns the flash on or off.

Shows the real image size to be captured.

Using photo options

After saving a photo, press < following options:

•

Take another

: return to Capture mode.

Options

Photos

> to access the

Menu functions

Camera

(Menu 8)

Menu functions

•

Send

: send the photo via MMS, e-mail, Bluetooth,

or infrared port.

•

Set as

: set the photo as your wallpaper or as a

caller ID image for a Phonebook entry.

•

Go to photo album

the

Photos

•

Rename

•

Protection

•

Properties

: change the name of the photo.

: protect the photo from being deleted. : view the properties of the photo.

Record video

You can record a video of what is displayed on the camera screen and save it as a .3gp file.

Recording a video

1. Turn the camera on, and aim the lens at the subject. Adjust the image.

• Press the left soft key to use the camera

options.

• Use the keypad to change the camera settings

or switch to other modes.p. 73

2. Press [ ] to start recording.

: display the photos stored in

My photos

(Menu 8.2)

folder.

3. Press <

Stop

saved in the

> or [ ]. The video is automatically

Video clips

folder.

To Press

play back the video clip [ ].

use the video options <

delete the video clip <

Options

Delete

return to Record mode [C].

Using camera options in Record mode

In Record mode, press <

Options

> to access the

following options:

•

Effects

: change the colour tone or apply a special

effect to a video.

•

Timer

: set a time delay before the camera starts

recording a video.

•

Go to video album

in the

Video clips

•

Settings

: change the following settings for

: display the video clips stored

My video clips

folder.

recording a video:

>.p. 74

Recording mode

Select

Limit of MMS

: select a video recording mode.

to record a video suitable for

an MMS message. Select

Normal

to record a video within the limit of

the currently available memory.

Size

: select an image size.

Quality

: select an image quality.

Audio rec Default name

.: record audio with a video clip.

: change the default prefix of the

video name.

•

Flash

: turn the flash on or off.

•

Camcorder short cuts

: view the functions of the

keys you can use.

Using the keypad in Record mode

You can use the keypad to customise your camera settings in Record mode:

Key Function

Flips the image vertically.

Shows the mirror image.

Key Function

Left/

Adjusts the brightness of the image.

Right

Up/

Zooms in or out.

Down

Switches to Capture mode.p. 69

Changes the frame size.

Changes the image quality.

Changes the video recording mode.

Changes the colour tone or applies a special effect to the photo.

Reduces the distortion on the image to maximize detail and sharpness.

Mutes or unmutes the audio.

Sets the timer.

Shows the video clips stored in the

clips

My video clips

Menu functions

Camera

(Menu 8)

Video

folder.

Menu functions

Key Function

Turns the flash on or off.

Using video options

Press <

Options

the following options:

•

Record another

•

Send

Bluetooth, or infrared port.

•

Go to video album My video clips

•

Rename

•

Protection

deleted.

•

Properties

Photos

Use this menu to access a list of photos you have taken.

> after saving a video clip to access

: return to Record mode.

: send the video clip via MMS, e-mail,

: move to the

folder.

: change the name of the video clip.

: protect the video clip from being

: view the properties of the video clip.

(Menu 8.3)

Video clips

Viewing the photos

1. Scroll to a photo and press [ ].

2. To go back to the photo list, press [ ] or

Using photos options

Press <

Options

Available options vary depending on whether you are looking at the photo list or viewing a photo.

•

View

•

List

: return to the photo list.

•

Send

or infrared port.

•

Move to My photos photos

•

Set as

caller ID image for a Phonebook entry.

•

Edit Emoticons

one and move it by pressing the Navigation keys.

Frames

> to access the following options:

: open the photo.

: send the photo via MMS, e-mail, Bluetooth,

: move the photo to the

folder.

: set the photo as your wallpaper or as a

: access the following options:

: add an emoticon to the photo. Select

: select a decorative frame.

Back

Effects

: change the colour tone or apply a special

effect to the photo.

•

Slide show

show. You can select a time interval between photos.

•

Rename

•

Delete

•

Delete all

•

Protection

•

Properties

My photos

Use this menu to view photos you have moved from the

Photos

Video clips

Use this menu to access a list of videos you have recorded.

: set all photos to display as a slide

: change the name of the photo.

: delete the photo.

: delete all of photos.

: protect the photo from being deleted. : view the properties of the photo.

(Menu 8.4)

folder.

(Menu 8.5)

Playing a video clip

Scroll to a video clip and press [ ].

During playback:

• Use the following buttons on the display:

Buttons Function

Pauses

Resumes

Stops

Skips backward through a file

Skips forward through a file

Repeats the file

To select a button, press [Left] or [Right] to highlight it and press [ ].

• Press [ / ] to adjust the volume.

Using video options

Press <

Options

•

Play

•

Send

Bluetooth, or infrared port.

> to access the following options:

: play the video clip.

: send the video clip via MMS, e-mail,

Menu functions

Camera

(Menu 8)

Menu functions

•

Move to My video clips

the

My video clips

•

Rename

•

Delete

•

Delete all

appears on the video clip list.

•

Protection

deleted.

•

Properties

My video clips

Use this menu to access video clips you have moved from the

: change the name of the video clip.

: delete the video clip.

: delete all video clips. This option

: protect the video clip from being

: view the properties of the video clip.

(Menu 8.6)

Video clips

: move the video clip to

folder.

Time & Date

Use this menu to change the time and date displayed on your phone. Before setting the time and date, specify your time zone in the 40

•

Set time

keys.

•

AM/PM

•

Time format

format.

•

Set date

keys.

•

Date format

(Menu 9.1)

World time

: enter the current time using the number

: select AM or PM in 12-hour time format.

: select 12-hour or 24-hour time

: enter the current date using the number

: select a date format.

menu. p.

Settings

Use this menu to customise your phone settings. You can also reset the settings to their default values.

To access this menu, press < select

(Menu 9)

Settings

> in Idle mode and

Phone settings

Many different features of your phone’s system can be customised to suit your preferences.

Language

Use this menu to select one of several languages for the display text.

(Menu 9.2)

(Menu 9.2.1)

Greeting message

(Menu 9.2.2)

Use this menu to enter the greeting that is displayed briefly when the phone is switched on.

Slide settings

(Menu 9.2.3)

Use this menu to set how the phone reacts when you open it for an incoming call, and when you close it while using a function.

•Up: set whether or not to answer a call by opening the phone.

•

Down

: set whether or not the phone maintains

the menu you are using when you close the phone.

When you set

Down

Continue operation

, the

keypad lock works only in Idle mode.

Short cut

(Menu 9.2.4)

You can use the Navigation keys as shortcut keys to access specific menus directly from Idle mode. Use this menu to change these shortcut assignments.

Assigning a shortcut to a key

1. Select the key to be used as a shortcut key.

2. Scroll to the menu that will be assigned to the key.

3. Press <

Save

Using shortcut options

Press <

•

Options Change Remove

> to access the following options:

: change a shortcut menu.

: deactivate the shortcut assignment to

the selected key.

•

Remove all

Extra settings

: deactivate all shortcut assignments.

(Menu 9.2.5)

You can turn the automatic redialing or answering features on or off.

•

Auto redial

: set the phone to make up to ten attempts to redial a phone number after an unsuccessful call.

•

Anykey answer

pressing any key, except [ ] or < When this option is set to

or <

•

Voice clarity

: answer an incoming call by

Reject

Off

, you must press [ ]

> to answer a call.

: increase the microphone’s

sensitivity to allow the other person on the phone

Menu functions

Settings

(Menu 9)

Menu functions

to hear your voice clearly, even though you may be whispering.

Display settings

Use this menu to change settings for the display and light.

Wallpaper

You can change the background image that is displayed in Idle mode.

Select an image from the following image categories.

•

Default wallpapers

•

Photos

: select one of the photos you have taken.

•

My photos My photos

•

Downloaded images

you have downloaded.

Text display

You can change the display settings for the text displayed on the idle screen.

(Menu 9.3)

(Menu 9.3.1)

: select one of preset images.

: select one of the photos stored in the folder.

: select one of the images

(Menu 9.3.2)

•

Text position

want text to display in Idle mode, select

•

Text style

•

Text colour

Skin

(Menu 9.3.3)

You can select a skin colour pattern for Menu mode.

LCD brightness

You can adjust the brightness of the display for varying lighting conditions.

Backlight

You can select the length of time the backlight and the display stay on.

•

: select the length of time the backlight is on at

times of inactivity.

•

Dim

: select the length of time the display is in Dimming mode after the backlight turns off. After a specified time, the display turns off and the clock displays.

: select a position. If you do not

: select a style.

: select a colour.

(Menu 9.3.4)

(Menu 9.3.5)

Off

Sound settings

(Menu 9.4)

Use this menu to customise various sound settings.

Incoming call

(Menu 9.4.1)

Use this menu to select a volume level and alert type for incoming calls.

•

Ring tone

•

Volume

•

Alert type

: select a ring tone for the call ringer.

: select a ringer volume.

: specify how you are to be informed of

incoming calls.

Melody

: the phone rings using the selected ring

tone.

Vibration Vibration then melody

: the phone vibrates but not rings.

: the phone vibrates three

times and then starts ringing.

Keypad tone

(Menu 9.4.2)

Use this menu to select the tone that the phone sounds when you press a key.

You can adjust the keypad tone volume using

[/]

in Idle mode.

Message tone

(Menu 9.4.3)

Use this menu to set up the ringer for incoming SMS messages, MMS messages, and e-mails.

•

Tone

: select one of several message tones.

•

Alert type

: specify how you are informed of any

incoming messages.

•

Repetition

: specify how often the phone informs

you of a new message.

Power on/off

(Menu 9.4.4)

Use this menu to select the melody that the phone sounds when it is switched on or off.

Slide tone

(Menu 9.4.5)

Use this menu to select the tone that the phone sounds when you open or close the phone.

Quiet mode

(Menu 9.4.6)

Use this menu to select an alert type for incoming calls or messages when the phone is in Quiet mode.

•

Vibration

•

Mute:

: vibrates the phone.

mutes all of sound settings.

Menu functions

Settings

(Menu 9)

Menu functions

Extra tones

Use this menu to customise additional tones for the phone.

•

Minute minder

minute during an outgoing call to keep you informed of the length of your call.

•

Connection tone

it is connected to the system.

•

Alerts on call

receive a new message or when the time for an alarm comes during a call.

•

Indicative tones

pop-up window displays.

Network services

Use this menu to access network services. Please contact your service provider to check their availability and subscribe to them, if you wish.

Call diverting

This network service reroutes incoming calls to a phone number that you specify.

(Menu 9.4.7)

(Menu 9.5.1)

:causes the phone to beep every

: causes the phone to beep when

: set the phone to beep when you

: set the phone to beep when a

(Menu 9.5)

1. Select a call diverting option:

•

Divert always

•

Busy

: divert calls when you are on another

call.

•

No reply

the phone.

•

Unreachable

an area covered by your service provider or when your phone is switched off.

•

Cancel all

2. Select the type of calls to be diverted.

3. To activate call diverting, select Otherwise, select

4. Move to the

5. Enter the number to which calls are to be diverted and press <

6. If you selected select the length of time the network delays before diverting a call.

Call barring

This network service allows you to restrict your calls.

: divert all calls.

: divert calls when you do not answer

: divert calls when you are not in

: cancel all call diverting options.

Deactivate

Divert to

Select

No reply

(Menu 9.5.2)

Activate

line.

, move to the

Sec

line and

1. Select a call barring option:

•

All outgoing

•

International

•

International except to home

: prohibit all outgoing calls.

: prohibit international calls.

: only allow calls to numbers within the current country when you are abroad, and to your home country, defined as where your home network provider is located.

•

All incoming

•

Incoming while abroad

: prohibit incoming calls.

: prohibit incoming calls when you use your phone outside of your home country.

•

Cancel all

: cancel all call barring settings,

allowing to be sent and received normally.

•

Change barring password

: change the call barring password obtained from your service provider.

2. Select the type of calls to be barred.

3. Press < press <

Activate

>. To deactivate call barring,

Deactivate

4. Enter the call barring password supplied by your service provider and press <OK>.

Call waiting

(Menu 9.5.3)

This network service informs you when someone is trying to reach you while you are on another call.

1. Select the type of calls to which the call waiting option will apply.

2. Press <

Network Selection

press <

Activate

>. To deactivate call waiting,

Deactivate

(Menu 9.5.4)

This network service allows you to either automatically or manually select the network used when roaming outside of your home area.

You can select a network other than your home network only if there is a valid roaming agreement between the two.

•

Automatic

: connect to the first available network

when roaming.

•

Manual

: select the network you want.

Caller ID

(Menu 9.5.5)

This network service allows you to prevent your phone number from being displayed on the phone of the

Menu functions

Settings

(Menu 9)

Menu functions

person being called. However, some networks do not allow the user to change this setting.

•

Default

: use the default setting provided by the

network.

•

Hide number

display on the other person’s phone.

•

Send number

make a call.

Band selection

For the phone to make and receive phone calls, it must register with an available network.

Your phone can handle any of the following types of networks: GSM 1900, Combined GSM 900/1800, and GSM 900/1800/1900.

The country where you purchased your phone determines the default band that it uses. When you travel abroad, you must remember to change to an appropriate band.

When you select a new band, your phone automatically searches for all available networks. Your

: ensure your number does not

: send your number each time you

(Menu 9.5.6)

phone registers with a preferred network within the band.

Active line

Some SIM cards may be used with two subscriber numbers. If your SIM card supports it, use this menu to select the line that is used to make calls. Calls can be answered on both lines, regardless of the selected line.

Connectivity

Use this menu to activate the IrDA port or the Bluetooth feature.

Bluetooth

Using Bluetooth wireless, you can connect the phone wirelessly to other Bluetooth devices and exchange data with them, talk hands-free, or control the phone remotely.

(Menu 9.5.7)

(Menu 9.6)

You cannot use the Bluetooth and IrDA features while using multimedia features such as voice recorder, camera, and MP3 player, or vice versa.

(Menu 9.6.1)

Bluetooth technology allows free wireless connections between all Bluetooth-compliant devices within a range of 10 metres. Since the devices communicate using radio waves, they do not need to be in line of sight to each other.

Setting up the Bluetooth feature

The

Bluetooth

•

Activation

menu provides the following options:

: activate or deactivates the Bluetooth

feature.

•

My devices

: search for connectable Bluetooth

devices. p. 83

•

My phone’s visibility

: allow other Bluetooth

devices to connect to your phone.

•

My phone’s name

: assign a Bluetooth device name to your phone, which is then displayed on other devices.

•

Secure mode

: determine if the phone asks for your confirmation when other devices access your data.

•

Bluetooth services

: display available Bluetooth

services.

Searching for and pairing with a Bluetooth device

1. From the Bluetooth setting options, select

devices

2. Select

Search new device

If you have searched for devices before, the phone displays

More devices

along with the devices you have searched for previously. To search for new devices, select

More devices

After searching, a list of devices to which you can connect displays. The following icons indicate the kind of device:

• Hands-free or headset

• Mobile phone

• Computer

• PDA

• Unknown device The colour of the icon indicates the status of the

device:

• Grey for unpaired devices

• Blue for paired devices

Menu functions

Settings

(Menu 9)

Menu functions

• Red for devices that are currently connected to your phone

3. Select a device.

4. Enter a Bluetooth PIN code of up to 16 digits and press <OK>. don’t need to memorise it.

When the owner of the other device enters the same code, pairing is finished.

Some devices, especially headsets or hands-free car kits, may have a fixed Bluetooth PIN, such as

0000

the code.

Using device options

From the device list, press < following options:

•

Connect

You need to enter the Bluetooth PIN.

•

Disconnect

•

Browse files

import data directly to your phone.

•

Rename

This code is used just once and you

. If the other device has one, you must enter

Options

: connect to the currently selected device.

: end the connection with the device.

: search for data from the device and

: rename the paired device.

> to access the

•

Authorise device/Unauthorise device

determine if the phone asks you to permit connection when other devices try to connect to your phone.

•

Delete

: delete the device.

•

Delete all

: delete all devices.

Sending data via Bluetooth

1. Activate the Bluetooth feature.

2. Select the application in which the item you want to send is stored.

3. Scroll to the item you want and press <

4. Select

5. Select a device.

6. If necessary, enter the Bluetooth PIN needed for

Send → via Bluetooth

The phone searches for devices within range and displays a list of available devices.

pairing and press <OK>.

Options

Receiving data via Bluetooth

To receive data via Bluetooth, your phone’s Bluetooth feature must be active.

If an unauthorised Bluetooth device sends data to your phone, the phone displays a confirmation message. To receive data, press <

Infrared

Use this feature to send and receive data through the infrared port. To use an infrared connection, you must do the following:

• Configure and activate an IrDA-compliant infrared

• Activate the infrared feature on your phone (the

• Align the IrDA port on the

If there is no communication between your phone and the other IrDA-compliant device within 60 seconds of activating the feature, it is automatically deactivated.

(Menu 9.6.2)

port on the other device.

IrDA icon displays on the top line).

phone with the IrDA port on the other device.

Yes

Security

Use this menu to protect the phone against unauthorised use by managing the several access codes of your phone and SIM card.

PIN check

The 4-to 8-digit PIN (Personal Identification Number) protects your SIM card against unauthorised use. When this feature is enabled, the phone requires your PIN each time it is switched on.

Change PIN

Use this menu to change your PIN. The PIN Check feature must be enabled to use this feature.

(Menu 9.7)

If you enter an incorrect PIN /PIN 2 three times in succession, the SIM card is blocked. To unblock it you need to enter your PUK/PUK2 (Personal Unblocking Key). The codes are supplied by your network operator.

(Menu 9.7.1)

(Menu 9.7.2)

Menu functions

Phone Lock

The Phone Lock feature locks the phone from unauthorised use.

When this feature is enabled, you must enter a 4- to 8-digit phone password each time the phone is switched on.

The password is preset to password, use the

Change Password

Use this menu to change your phone password. The password is preset to

Privacy

Use this menu to lock your media contents, including MMS messages, e-mails, images, videos, music files, and sounds.

1. Press [ ] to check the item(s) to lock.

2. Press <

3. Enter the phone password and press <OK>.

(Menu 9.7.3)

(Menu 9.7.5)

Save

> to lock the marked items.

00000000

Change password

(Menu 9.7.4)

00000000

. To change the

menu.

To access a locked item, you need to enter the phone password.

SIM Lock

The SIM Lock feature allows your phone to work only with the current SIM by assigning a SIM lock code. You must enter the SIM lock code to use a different SIM card.

FDN mode

If supported by your SIM card, Fixed Dialing Number (FDN) mode restricts your outgoing calls to a limited set of phone numbers. When this feature is enabled, you can make calls only to phone numbers stored in Phonebook. To use this feature, you must enter your PIN2.

Change PIN2

If supported by your SIM card, the Change PIN2 feature changes your current PIN2.

(Menu 9.7.6)

(Menu 9.7.7)

(Menu 9.7.8)

Memory status

Use this menu to check the amount of memory being used for storing data in

Funbox, Organiser, Phonebook

Reset settings

Use this menu to reset the phone settings, display settings, and sound settings individually. You can also reset all the settings in your phone at the same time.

1. Press [ ] to check the setting category(ies) to be reset.

2. Press <

3. Enter the phone password and press <OK>.

Reset

The password is preset to change this password p. 86

(Menu 9.8)

(Menu 9.9)

> to reset the marked items.

Shared Memory, Messages

, and

Java world

00000000

. You can

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service call, perform the simple checks in this section before contacting a service professional.

When you switch on your phone, the following messages may appear:

“Insert SIM ”

• Be sure that the SIM card is correctly installed.

“Phone lock”

• The automatic locking function has been enabled. You must enter the phone’s password before you can use the phone.

“Enter PIN”

• You are using your phone for the first time. You must enter the PIN supplied with the SIM card.

• The PIN Check feature is enabled. Every time the phone is switched on, the PIN has to be entered. To disable this feature, use the

PIN check

menu.

Solve problems

“Enter PUK”

• The PIN code has been entered incorrectly three times in succession, and the phone is now blocked. Enter the PUK supplied by your service provider.

“No Service,” “Network Failure,” or “Not Done” displays

• The network connection has been lost. You may be in a weak signal area. Move and try again.

• You are trying to access an option for which you have no subscription with your service provider. Contact the service provider for further details.

You have entered a number but it was not dialled

• Be sure that you have pressed [ ].

• Be sure you have accessed the right cellular network.

• Be sure that you have not set an outgoing call barring option.

Your correspondent cannot reach you

• Be sure your phone is switched on. ([ ] pressed for more than one second.)

• Be sure you are accessing the correct cellular network.

• Be sure that you have not set an outgoing call barring option.

Your correspondent cannot hear you speaking

• Be sure you have switched off the microphone.

• Be sure you are holding the phone close enough to your mouth. The microphone is located at the bottom of the phone.

The phone starts beeping and “Battery low” flashes on the display

• Your battery is insufficiently charged. Recharge the battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display ( ). The number of bars indicates the signal strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a window if you are in a building.

No number is dialled when you re-call a Contacts entry

• Use the Contact Search feature to ensure the number has been stored correctly.

• Re-store the number, if necessary.

If the above guidelines do not help you to solve the problem, take note of:

• The model and serial numbers of your phone

•Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung after-sales service.

Health and safety information

SAR certification information

This phone meets European Union (EU) requirements concerning exposure to radio waves.

Your mobile phone is a radio transmitter and receiver. It is designed and manufactured to not exceed the limits for exposure to radio-frequency (RF) energy, as recommended by the EU Council. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines were developed by independent scientific organisations through the periodic and thorough evaluation of scientific studies. The limits include a substantial safety margin designed to ensure the safety of all persons, regardless of age and health.

The exposure standard for mobile phones employs a unit of measurement known as Specific Ab so rptio n R at e (SAR). The SAR limit recommended by the EU Council is 2.0W/

kg.

The highest SAR value for this model phone was 0.310W/ kg

Health and safety information

SAR tests are conducted using standard operating positions with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a base station, the lower the power output of the phone.

Precautions when using batteries

• Never use a charger or battery that is damaged in any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network’s base station, it uses less power. Talk and standby time are greatly

* The SAR limit for mobile phones used by the public is 2.0

watts/kilogram (W/kg) averaged over ten grams of body tissue. The limit incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements. The SAR values may vary, depending on national reporting requirements and the network band.

affected by the signal strength on the cellular network and the parameters set by the network operator.

• Battery charging time depends on the remaining battery charge, the type of battery, and the charger used. The battery can be charged and discharged hundreds of times, but it will gradually wear out. When the operation time is noticeably shorter than normal, it is time to buy a new battery.

• If left unused, a fully charged battery will discharge itself over time.

• Use only Samsung-approved batteries, and recharge your battery only with Samsung-approved chargers. Disconnect the charger from the power source when it is not in use. Do not leave the battery connected to a charger for more than a week, since overcharging may shorten its life.

• Extreme temperatures will affect the charging capacity of your battery: it may require cooling or warming first.

• Do not leave the battery in hot or cold places because the capacity and lifetime of the battery will be reduced. Try to keep the battery at room temperature. A phone with a hot or cold battery may not work temporarily, even when the battery is fully charged. Li-

ion batteries are particularly affected by temperatures below 0°C (32°F).

• Do not short-circuit the battery. Accidental shortcircuiting can occur when a metallic object like a coin, clip or pen causes a direct connection between the + and – terminals of the battery (metal strips on the battery). For example, do not carry a spare battery in a pocket or bag where the battery may contact metal objects. Short-circuiting the terminals may damage the battery or the object causing the short-circuiting.

• Dispose of used batteries in accordance with local regulations. Always recycle. Do not dispose of batteries in a fire.

Road safety

Your wireless phone gives you the powerful ability to communicate by voice, almost anywhere, anytime. But an important responsibility accompanies the benefits of wireless phones, one that every user must uphold.

When driving a car, driving is your first responsibility. When using your wireless phone while driving, follow local regulations in the country or region you are in.

Operating environment

Remember to follow any special regulations in force in the area you are in, and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger.

When connecting the phone or any accessory to another device, read its user’s guide for detailed safety instructions. Do not connect incompatible products.

As with other mobile radio transmitting equipment, users are advised that for the satisfactory operation of the equipment and for the safety of personnel, it is recommended that the equipment should only be used in the normal operating position(held to your ear with the antenna pointing over your shoulder).

Health and safety information

Electronic devices

Most modern electronic equipment is shielded from radio frequency (RF) signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone. Consult the manufacturer to discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a minimum distance of 15 cm (6 inches) be maintained between a wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research and recommendations of Wireless Technology Research. If you have any reason to suspect that interference is taking place, switch off your phone immediately.

Hearing aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may wish to consult your hearing aid manufacturer to discuss alternatives.

Other medical devices

If you use any other personal medical devices, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy.

Your physician may be able to assist you in obtaining this information.

Switch off your phone in health care facilities when regulations posted in these areas instruct you to do so.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle.

You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted facilities

Switch off your phone in any facility where posted notices require you to do so.

Potentially explosive environments

Switch off your phone when in any area with a potentially explosive atmosphere, and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Users are advised to switch off the phone while at a refuelling point (service station). Users are reminded of the need to observe restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas), chemical plants, or where blasting operations are in progress.

Areas with a potentially explosive atmosphere are often but not always clearly marked. They include the areas below decks on boats, chemical transfer or storage facilities, vehicles using liquefied petroleum gas, such as propane or butane, areas where the air contains chemicals or particles, such as grain, dust or metal powders, and any other area where you would normally be advised to turn off your vehicle engine.

Emergency calls

This phone, like any wireless phone, operates using radio signals, wireless, and landline networks as well as userprogrammed functions, which cannot guarantee connection in all conditions. Therefore, you should never rely solely on any wireless phone for essential communications like medical emergencies.

To make or receive calls, the phone must be switched on and in a service area with adequate signal strength. Emergency calls may not be possible on all wireless phone networks or when certain network services and/or phone features are in use. Check with local service providers.

To make an emergency call:

1. Switch on the phone.

2. Key in the emergency number for your present location. Emergency numbers vary by location.

3. Press [ ].

Certain features like Call Barring may need to be deactivated before you can make an emergency call. Consult this document and your local cellular service provider.

Health and safety information

Other important safety information

• Only qualified personnel should service the phone or install the phone in a vehicle. Faulty installation or service may be dangerous and may invalidate any warranty applicable to the device.

• Check regularly that all wireless phone equipment in your vehicle is mounted and operating properly.

• Do not store or carry flammable liquids, gases, or explosive materials in the same compartment as the phone, its parts, or accessories.

• For vehicles equipped with an air bag, remember that an air bag inflates with great force. Do not place objects, including installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. Improperly installed wireless equipment could result in serious injury if the air bag inflates.

• Switch off your phone before boarding an aircraft. It is dangerous and illegal to use wireless phones in an aircraft because they can interfere with the operation of the aircraft.

• Failure to observe these instructions may lead to the suspension or denial of telephone services to the offender, or legal action, or both.

Care and maintenance

Your phone is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfill any warranty obligations and allow you to enjoy this product for many years.

• Keep the phone and all its parts and accessories out of the reach of small children.

• Keep the phone dry. Precipitation, humidity, and liquids contain minerals that corrode electronic circuits.

• Do not use the phone with a wet hand. Doing so may cause an electric shock to you or damage to the phone.

• Do not use or store the phone in dusty, dirty areas, as its moving parts may be damaged.

• Do not store the phone in hot areas. High temperatures can shorten the life of electronic devices, damage batteries, and warp or melt certain plastics.

• Do not store the phone in cold areas. When the phone warms up to its normal operating temperature,

moisture can form inside the phone, which may damage the phone’s electronic circuit boards.

• Do not drop, knock, or shake the phone. Rough handling can break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone. Wipe it with a soft cloth slightly dampened in a mild soap-and-water solution.

• Do not paint the phone. Paint can clog the device’s moving parts and prevent proper operation.

• Do not put the phone in or on heating devices, such as a microwave oven, stove, or radiator. The phone may explode when overheated.

• Use only the supplied or an approved replacement antenna. Unauthorised antennas or modified accessories may damage the phone and violate regulations governing radio devices.

• If the phone, battery, charger, or any accessory is not working properly, take it to your nearest qualified service facility. The personnel there will assist you, and if necessary, arrange for service.

Health and safety information

Samsung CH88-06500A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Unpack

Your pho ne

Get started

Step outside the phone

Enter text

Changing the text input mode

Using Pinyin mode

Using Chinese Stroke modes

Using Quick English (T9) mode

Using Number mode

Using Symbolic mode

Call function

Advanced calling features

Making a call

Ending a call

Answering a call

Viewing missed calls

Using the headset

Using the external speaker

Options during a call

Adjusting the volume during a call

Placing a call on hold/Retrieving

Answering a second call

Making a second call

Using a Bluetooth headset

Using the voice clarity feature

Sending a sequence of DTMF tones

Muting or sending key tones

Using Phonebook

Using the message service

Using SIM services

Making a multi-party call

Menu functions

Solve problems

Health and safety information

SAR certification information

Precautions when using batteries

Road safety

Operating environment

Electronic devices

Potentially explosive environments

Emergency calls

Other important safety information

Care and maintenance
