Samsung BE50T-H, BE75T-H, BE65T-H, BE55T-H User Manual

USER MANUAL

Thank you for purchasing this Samsung product.

To receive more complete service, please register your product at www.samsung.com

Model Serial No.

BET-H

Before Reading This User Manual

This TV comes with this user manual and an embedded e-Manual. Before reading this user manual, review the following:

User Manual

e-Manual

On the website (www.samsung.com), you can download the manuals and see its contents on your PC or mobile device.

Read this provided user manual to see information about product safety, installation, accessories, initial configuration, and product specifications.

For more information about this TV, read the e-Manual embedded in the product.

• To open the e-Manual,

> Settings > Support > Open e-Manual

Learning the e-Manual's assistance functions

• Some menu screens cannot be accessed from the e-Manual.

Index

Select an item from the search results to load the corresponding page.

Select a keyword to navigate to the relevant page.

Sitemap

Learning the functions of the buttons that appear on e-Manual topic pages

Try Now

Link

English - 2

Allows you to access the corresponding menu item and try out the feature right away.

Access an underlined topic referred to on an e-Manual page immediately.

Warning! Important Safety Instructions

Please read the Safety Instructions before using your TV. Refer to the table below for an explanation of symbols which may be on your Samsung product.

CAUTION

RISK OF ELECTRIC SHOCK. DO NOT OPEN.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to make any kind of contact with any internal part of this product.

This symbol indicates that this product has included important literature concerning operation and maintenance.

Class II product: This symbol indicates that a safety connection to electrical earth (ground) is not required. If this symbol is not present on a product with a power cord, the product MUST have a reliable connection to protective earth (ground).

AC voltage: Rated voltage marked with this symbol is AC voltage.

DC voltage: Rated voltage marked with this symbol is DC voltage.

Caution. Consult instructions for use: This symbol instructs the user to consult the user manual for further safety related information.

• The slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation. To ensure reliable operation of this apparatus and to protect it from overheating, these slots and openings must never be blocked or covered.

– Do not place this apparatus in a confined space, such as a bookcase or built-in cabinet, unless proper

ventilation is provided.

– Do not place this apparatus near or over a radiator or heat register, or where it is exposed to direct

sunlight.

– Do not place vessels (vases etc.) containing water on this apparatus, as this can result in a fire or

electric shock.

• Do not expose this apparatus to rain or place it near water (near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc.). If this apparatus accidentally gets wet, unplug it and contact an authorized dealer immediately.

• This apparatus uses batteries. In your community, there might be environmental regulations that require you to dispose of these batteries properly. Please contact your local authorities for disposal or recycling information.

• Do not overload wall outlets, extension cords, or adaptors beyond their capacity, since this can result in fire or electric shock.

• Power-supply cords should be placed so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords at the plug end, at wall outlets, and at the point where they exit from the appliance.

English - 3

• To protect this apparatus from a lightning storm, or when left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the set due to lightning and power line surges.

• Before plugging in the AC power cord of the TV, make sure that the operational voltage of the TV matches the voltage of your local electrical power supply. Refer to the power specifications section of the manual and/or the power supply label on the product for voltage and amperage information.

• Never insert anything metallic into the open parts of this apparatus. This may cause electric shock.

• To avoid electric shock, never touch the inside of this apparatus. Only a qualified technician should open this apparatus.

• Be sure to plug in the power cord until it is firmly seated. When unplugging the power cord from a wall outlet, always pull on the power cord's plug. Never unplug it by pulling on the power cord. Do not touch the power cord with wet hands.

• If this apparatus does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately and contact an authorized dealer or Samsung service center.

• Be sure to pull the power plug out of the outlet if the TV is to remain unused or if you are going to leave the house for an extended period of time (especially when children, elderly, or disabled people will be left alone in the house).

– Accumulated dust can cause an electric shock, an electric leakage, or a fire by causing the power cord

to generate sparks and heat or by causing the insulation to deteriorate.

• Be sure to contact an authorized Samsung service center for information if you intend to install your TV in a location with heavy dust, high or low temperatures, high humidity, chemical substances, or where it will operate 24 hours a day such as in an airport, a train station, etc. Failure to do so may lead to serious damage to your TV.

• Use only a properly grounded plug and wall outlet.

– An improper ground may cause electric shock or equipment damage. (Class l Equipment only.)

• To turn off this apparatus completely, disconnect it from the wall outlet. To ensure you can unplug this apparatus quickly if necessary, make sure that the wall outlet and power plug are readily accessible.

• Store the accessories (batteries, etc.) in a location safely out of the reach of children.

• Do not drop or strike the product. If the product is damaged, disconnect the power cord and contact a Samsung service center.

• To clean this apparatus, unplug the power cord from the wall outlet and wipe the product with a soft, dry cloth. Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air fresheners, lubricants, or detergents. These chemicals can damage the appearance of the TV or erase the printing on the product.

• Do not expose this apparatus to dripping or splashing.

• Do not dispose of batteries in a fire.

• Do not short-circuit, disassemble, or overheat the batteries.

• CAUTION: There is danger of an explosion if you replace the batteries used in the remote with the wrong type of battery. Replace only with the same or equivalent type.

• WARNING - TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES AND OTHER ITEMS WITH OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES.

Figures and illustrations in this User Manual are provided for reference only and may differ from the actual product appearance. Product design and specifications may change without notice.

English - 4

Contents

Before Reading This User Manual ---------------------------------------------------------------------------- 2 Warning! Important Safety Instructions

01 Package Content

02 TV Installation

Mounting the TV on a wall ---------------------------------------------------------------------------- 7 Providing proper ventilation for your TV Safety Precaution: Securing the TV to the wall to prevent falling

03 The Remote Control

About the buttons on the remote control ---------------------------------------------------------------------------- 10 Installing batteries into the remote control

04 Running the Initial Setup

Using the TV Controller ---------------------------------------------------------------------------- 12

---------------------------------------------------------------------------- 9

---------------------------------------------------------------------------- 3

---------------------------------------------------------------------------- 8

---------------------------------------------------------------------------- 11

05 Connecting to a Network

Network Connection - Wireless ---------------------------------------------------------------------------- 13 Network Connection - Wired

---------------------------------------------------------------------------- 13

06 Troubleshooting and Maintenance

Troubleshooting ---------------------------------------------------------------------------- 14 What is Remote Support? Eco Sensor and screen brightness Caring for the TV

---------------------------------------------------------------------------- 17

---------------------------------------------------------------------------- 16

07 Specifications and Other Information

Specifications ---------------------------------------------------------------------------- 18 Environmental Considerations Decreasing power consumption Licenses Important Warranty Information Regarding Television Format Viewing

---------------------------------------------------------------------------- 19

---------------------------------------------------------------------------- 20

---------------------------------------------------------------------------- 19

English - 5

01 Package Content

Make sure the following items are included with your TV. If any items are missing, contact your dealer.

• Remote Control & Batteries (AA x 2)

• User Manual

• The items’ colors and shapes may vary depending on the models.

• Cables not included can be purchased separately.

• Check for any accessories hidden behind or in the packing materials when opening the box.

The screen can be damaged from direct pressure when handled incorrectly. As shown in the figure, make sure to grip the edges of the screen when you lift the TV.

• Warranty Card / Regulatory Guide (Not available in some locations)

• Power Cord

Do Not Touch This Screen!

English - 6

02 TV Installation

Mounting the TV on a wall

If you mount this TV on a wall, follow the instructions exactly as set out by the manufacturer. If it is not correctly mounted, the TV may slide or fall and cause serious injury to a child or adult and serious damage to the TV.

• You can mount the TV on the wall using a wall mount kit (sold separately).

• Refer to the installation manual included with the Samsung wall mount kit.

TVWall mount bracket

• Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you choose to install the wall mount on your own.

• You can install your wall mount on a solid wall perpendicular to the floor. Before attaching the wall mount to surfaces other than plaster board, contact your nearest dealer for additional information. If you install the TV on a ceiling or slanted wall, it may fall and result in severe personal injury.

• When installing a wall mount kit, we recommend you fasten all four VESA screws.

• If you want to install a wall mount kit that attaches to the wall using two top screws only, be sure to use a Samsung wall mount kit that supports this type of installation. (You may not be able to purchase this type of wall mount kit, depending on the geographical region.)

• Standard dimensions for wall mount kits are shown in the table on the next page.

• If you are installing a third-party wall mount, note that the length of the screws you can use to attach the TV to the wall mount is shown in column C in the table on the next page.

English - 7

TV size in

inches

50-55 200 x 200

75 400 x 400

• Do not use screws that are longer than the standard dimension or do not comply with the VESA standard screw specifications. Screws that are too long may cause damage to the inside of the TV set.

• For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ depending on the wall mount specifications.

• Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents.

• Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or when the consumer fails to follow the product installation instructions.

• Do not mount the TV at more than a 15 degree tilt.

• Always have two people mount the TV onto a wall.

VESA screw hole specs (A * B)

in millimeters

Do not install your wall mount kit while your TV is turned on. This may result in personal injury from electric shock.

C (mm)

20-22 M8 465 400 x 300

Standard

Screw

Quantity

Providing proper ventilation for your TV

When you install your TV, maintain a distance of at least 10 cm between the TV and other objects (walls, cabinet sides, etc.) to ensure proper ventilation. Failing to maintain proper ventilation may result in a fire or a problem with the product caused by an increase in its internal temperature.

• When you install your TV with a stand or a wall mount, we strongly recommend you use parts provided by Samsung Electronics only. Using parts provided by another manufacturer may cause difficulties with the product or result in injury caused by the product falling.

English - 8

Installation with a stand Installation with a wall mount

10 cm

10 cm10 cm

10 cm

10 cm10 cm
