Page 1
Washing Machine
Owner’s Instructions
B1445AV/
B1245AV/
B1245AS/
B1245A/
B1045A/
R1245AV/
R1045A/
F1245AV/
F1045A
Page 2
Safety Precautions
●
SAVE THESE INSTRUCTIONS
Congratulations on your purchase of this Samsung washing machine. These Owner's
Instructions contain valuable information on the installation, use, and care of this appliance.
Please take the time to read these instructions so that you can take full advantage of the
washing machine's features and enjoy this appliance for many years to come.
Before using the appliance
• Packing materials can be dangerous to children; keep all packing material (plastic bags,
polystyrene, etc.) well out of the reach of children.
• The appliance is designed for home use only.
• Make sure that water and electrical connections are made by qualified technicians,
observing the manufacturer's instructions (see "Installing the Washing Machine" on
page 2) and local safety regulations.
• All packaging and shipping bolts must be removed before the appliance is used. Serious
damage may occur if they are not removed. See "Removing the shipping bolts" on page 3.
• Before washing clothes for the first time, you must run a complete cycle without clothes.
See "Washing for the first time" on page 8.
Safety instructions
• Before cleaning or carrying out maintenance, unplug the appliance from the electrical
outlet or set the (On/Off) button to Off.
• Make sure that the pockets of all clothing to be washed are empty.
Hard, sharp objects, such as coins, safety pins, nails, screws, or stones can cause
extensive damage to the appliance.
• Always unplug the appliance and turn off the water after use.
• Before you open the door of the appliance, check that the water has drained. Do not
open the door if you can still see water.
• Pets and small children may climb into the appliance. Check the appliance before each
use.
• The glass door becomes very hot during the washing cycle. Keep children away from
the appliance while it is in use.
• Do not attempt to repair the appliance yourself. Repairs made by inexperienced or
unqualified persons may cause injury and/or make more serious repairs to the
appliance necessary.
• If the plug (power supply cord) is damaged, it must be replaced by the manufacturer or
its service agent or a similarly qualified person in order to avoid a hazard.
• This appliance should only be serviced by an authorized service center, and only
genuine spare parts should be used.
SAMSUNG
Washing Machine Owner’s Instructions 1
Safety Precautions------------------------------------------- inside cover
lnstalling the Washing Machine
------------------------------------------2
Unpacking the washing machine ----------------------------------------------------2
Overview of the washing machine --------------------------------------------------2
Selecting a location -------------------------------------------------------------------- 3
Adjusting the leveling feet ------------------------------------------------------------3
Removing the shipping bolts --------------------------------------------------------3
Connecting the water supply hose(option) -------------------------------------- 3
Connecting the water supply hose ------------------------------------------------- 4
Positioning the drain hose ----------------------------------------------------------- 4
Plugging in the machine -------------------------------------------------------------5
Washing a Load of Laundry ------------------------------------------------ 6
Overview of the control panel ------------------------------------------------------ 6
Washing for the first time ------------------------------------------------------------- 8
Putting detergent in the washing machine --------------------------------------- 8
Washing clothes using Fuzzy Logic ----------------------------------------------- 9
Washing clothes manually --------------------------------------------------------- 10
Using delay start --------------------------------------------------------------------- 10
Washing tips and hints ------------------------------------------------------------- 11
Maintaining the Washing Machine --------------------------------- 12
Draining the washing machine in an emergency ----------------------------- 12
Repairing a frozen washing machine -------------------------------------------- 12
Cleaning the exterior ---------------------------------------------------------------- 12
Cleaning the detergent drawer and recess ----------------------------------- 13
Cleaning the debris filter ------------------------------------------------------------ 13
Cleaning the water hose mesh filter --------------------------------------------- 14
T r oubleshooting ----------------------------------------------------------------- 15
Problems and solutions ------------------------------------------------------------ 15
Understanding error messages --------------------------------------------------- 15
Programme chart ------------------------------------------------------------- 16
Appendix
------------------------------------------------------------------------------ 18
Fabric care chart --------------------------------------------------------------------- 18
Electrical warnings ------------------------------------------------------------------ 18
Protecting the environment ------------------------------------------------------- 19
Declaration of conformity --------------------------------------------------------- 19
Specification -------------------------------------------------------------------------- 19
Table of Contents
Page 3
Installing the Washing Machine
2
SAMSUNG
Washing Machine Owner’s Instructions
SAMSUNG
Washing Machine Owner’s Instructions 3
Installing the Washing Machine
Unpacking the Washing Machine
Unpack your washing machine and inspect it for shipping damage. Also make sure that
you have received all of the items shown below. If the washing machine was damaged
during shipping or you do not have all of the items, contact your Samsung dealer
immediately.
Overview of the washing machine
Hose guide
Plug
Cold Water
supply hose
Bolt hole
covers
Drain Hose
Detergent
drawer
Door
Worktop
Debris filter
Emergency drain
tube
Filter-cover
Base cover
Adjustable feet
Control panel
Wrench
Drain hose
Selecting a location
Before you install the washing machine, select a location with the following characteristics:
• A hard, level surface (if the surface is uneven, see "Adjusting the leveling feet," below)
• Away from direct sunlight.
• Adequate ventilation
• Room temperature that will not fall below 0 ˚C
• Away from sources of heat such as coal or gas
Make sure that the washing machine does not stand on its power cord.
Ventilation openings must not be obstructed by carpeting when the washing machine is
installed on a carpeted floor.
Adjusting the leveling feet
If the floor is uneven, adjust the feet (do not insert pieces of wood or any other objects under
the feet):
1. Loosen the leg bolt by turning it with your hand until it is at the desired height.
2. Tighten the locking nut by turning it with the supplied wrench.
• Place the washer on a sturdy, flat surface.
If the washer is placed on an uneven or weak surface, noise or vibration occurs.
(Only a l degrees angle is allowed.)
Removing the shipping bolts
Before using the washing machine, you must remove the five shipping bolts from the back
of the unit. To remove the bolts:
1. Loosen all bolts with the supplied wrench before removing them.
2. Take each bolt head and pull it through the wide part of the hole.
Repeat for each bolt.
3. Fill the holes with the supplied plastic covers.
4. Keep the shipping bolts for future use.
Connecting the water supply hose(Option)
NOTICE After completing connection, if water leaks from the hose, then repeat the same steps. Use
the most conventional type of faucet for water supply. In case the faucet is square or too
big, remove the spacing ring before inserting the faucet into the adaptor.
1
2
3
1. Remove the adaptor from the
water supply hose.
2. First, using a “+” type screw driver, loosen the
four screws on the adaptor. Next, take the
adaptor and turn part(b) following the arrow until
there is a 5mm gap.
4. Connect the water supply hose to the adaptor.
Pull down part (c) of the water supply hose.
When you release part (c) the hose automatically
connects to the adaptor making a ’click’ sound.
5. Connect the other end of the water supply hose
to the inlet water valve at the top of the washer.
Screw the hose clockwise all the way in.
•
If the water tap has a screw type faucet, connect
the water supply hose to the tap as shown.
3. Connect adaptor to the water tap by tightening
the screws firmly.
Then, turn part (b) following the arrow and put(a)
and (b) together.
a
b
c
Page 4
SAMSUNG
Washing Machine Owner’s Instructions 5
Installing the Washing Machine
4
SAMSUNG
Washing Machine Owner’s Instructions
Installing the Washing Machine
Connecting the water supply hose
The water supply hose must be connected to the washing machine at one end and to the
water faucet at the other. Do not stretch the water supply hose. If the hose is too short and
you do not wish to move the water faucet, replace the hose with a longer, high pressure
hose.
To connect the water supply hose:
1. Take the L-shaped arm fitting for the cold
water supply hose and connect to the cold
water supply intake on the back of the
machine. Tighten by hand.
2. Connect the other end of the cold water supply hose to your sink's cold water faucet and
tighten it by hand. If necessary, you can reposition the water supply hose at the washing
machine end by loosening the fitting, rotating the hose, and retightening the fitting.
Option: 1. Take the red L-shaped arm fitting for the hot water supply hose and connect
to the red hot water supply intake on the back of the machine. Tighten by
hand.
2. Connect the other end of the hot water supply hose to your sink's hot water
faucet and tighten it by hand.
3. Use a Y-piece if you only want to use cold water.
Note: The appliance is to be connected to the water mains using new hose-sets and that
old hose-sets should not be used.
Positioning the drain hose
The end of the drain hose may be positioned in three ways:
Over the edge of a sink
The drain hose must be placed at a height of
between 60 and 90 cm. To keep the drain hose
spout bent, use the supplied plastic hose
guide. Secure the guide to the wall with a
hook or to the faucet with a piece of string to
prevent the drain hose from moving.
ln a sink drain pipe branch
The drain pipe branch must be above the sink siphon so that the end of the hose is at least
60 cm above the ground.
ln a drain pipe
Samsung recommends that you use a 65 cm high vertical pipe; it must be no shorter than 60
cm and no longer than 90 cm.
Plugging in the machine
For European Users. You will NOTneed to ground the plug of the washing machine.
For U.S. Users. You MUSTground the plug of the washing machine.
Check with a licensed electrician before using the machine to make sure it is properly
grounded.
For U.K. Users.
Wiring lnstructions
WARNING THIS APPLIANCE MUST BE EARTHED.
This appliance must be earthed. In the event of an
electrical short circuit, earthing reduces the risk of electric
shock providing an escape wire for the electric current.
The appliance is equipped with a mains lead which
includes an earth wire for connecting to the earth terminal of
your mains plug.
The plug must be plugged into a socket that is properly
installed and earthed.
*The wires in this mains lead are coloured in accordance
with the following code:
• Green and yellow : Earth
• Blue : Neutral
• Brown : Live
• AS the colours of the wires in the mains lead of this
appliance may not correspond with the coloured
markings indentifying the terminals in your plug,
proceed as follows.
• Connect the green and yellow wire to the terminal
in the plug marked with the letter E or the earth
symbol ( ) or coloured green or green-andyellow.
• Connect the blue wire to the terminal marked
with the letter N or coloured black.
• Connect the brown wire to the terminal marked
with the letter L or coloured red.
* Consult a qualified electrician or service technician if
in doubt about any of these instructions.
The manufacturer of this washing machine will
not accept any liability for damage to persons or
material for non observance of these requirements.
There are no user serviceable parts inside the
washing machine and if the mains lead of this
appliance is damaged, it must only be replaced by
qualified service personnel approved by the
manufacturer because special tools are required.
GREEN AND
YELLOW
13 AMP
FUSE
BROWN
BLUE
WARNING
Ensure that the plug and power
cord are not damaged before use. If
you have any reason to remove the
moulded plug from this appliance,
immediately remove the fuse and
dispose of the plug.
Do not connect the plug to a mains
socket under any circumstances as
there is a danger of electric shock.
CIRCUITS
Your washing machine should be
operated on a separate circuit
from other appliances. Failure to
do this may cause the circuit
breaker to trip or the fuse to blow.
Page 5
Washing a Load of Laundry
6
SAMSUNG
Washing Machine Owner’s Instructions
Washing a Load of Laundry
SAMSUNG
Washing Machine Owner’s Instructions 7
Overview of the control panel
1. Digital graphic display
Displays the remaining wash cycle time,all of washing information and error messages.
2. Prewash selection button
Press the button to select pre-wash. Pre-wash is available only with Cotton, Coloureds,
Synthetics, Delicates,baby programs.
3. Temperature selection button
Press the button repeatedly to cycle through the available water temperature options
(cold water( ), 30 ˚C, 40 ˚C , 60 ˚C and 95 ˚C).
4. Rinse selection button
Press the rinse button to add rinse cycles. Maximum number of rinse cycles is five.
5. Spin selection button
Press the button repeatedly to cycle through the available spin speed options.
No spin
The laundry remains in the drum without being spun after the final drain
Rinse Hold
The laundry remains soaking in the final rinse water.
Before the laundry can be unloaded, either “Drain” or the “Spin” program must be run.
6. Delay Start selection button
Press the button repeatedly to cycle through the available delayed start options (from 3
hour to 24 hours in one hour increments).
Displayed hours means the time of finished washing-cycle.
B1445AV
,
, 400, 800, 1200, 1400 rpm
B1245AV/B1245AS/B1245A/R1245AV/F1245AV
,
, 400, 800, 1000, 1200 rpm
B1045A /R1045A /F1045A
,
, 400, 600, 800, 1000 rpm
: no spin, : rinse hold
7. Silver Nano selection button
Silver Nano water is supplied in washing as well as the last rinse, featuring sterilization
and antibacterial coating.
8. Half Load selection button
Press the button in case of half load(about 1~4kg) washing. This function saves washing
time and energy.
9. Child Lock selection button
This is a button for preventing children from manipulating the washing machine.
On/Off - To set the program on: Press the Start/Pause button to turn on the washing
machine. Press and hold down the [Rinse] + [Spin] button for 2-3 seconds. It can only be
activated when the machine is turned on. Once you set the baby program on while in
washing, no button is activated until you set if off. Even the POWER button will not be
activated. The Baby Program lamp lights on. To set the program off: Press and hold down
the [Rinse] + [Spin] button again for 2-3 seconds, then the lamp lights off and is set off.
Note: Check out the Baby Program button first when no button is activated while the
washing machine is working.
10. Fuzzy Control dial
Turn the dial to select one of the 14 available wash programs.
11. Start/Pause selection button
Press to pause and restart programs.
12. (On/Off) selection button
Press once to turn the washing machine on, press again to turn the washing machine off.
If the washing machine power is left on for longer than 10 minutes without any buttons
being touched, the power automatically turns off.
Cotton, Coloureds, Synthetics, Delicates, Wool, Hand wash, Quick,
Rinse+Spin, Spin, Drain, Baby Program(Stains, Delicates, Coloreds, Cotton)
Page 6
Washing a Load of Laundry
SAMSUNG
Washing Machine Owner’s Instructions 9
Washing a Load of Laundry
8
SAMSUNG
Washing Machine Owner’s Instructions
Washing clothes using Fuzzy Logic
Your new washing machine makes washing clothes easy, using Samsung's "Fuzzy Logic"
automatic control system. When you select a wash program, the machine will set the correct
temperature, washing time, and washing speed.
To wash clothes using the Fuzzy Logic programs:
1. Turn on your sink's water faucet.
2. Press the (On/Off) button.
3. Open the door.
4. Load the articles one at a time loosely into the drum, without overfilling.
5. Close the door.
6. Add the detergent, softener, and pre-wash detergent (if necessary) into the appropriate
compartment.
Note: Pre-wash is only available when washing Duvet, Bedding, Towel, Curtain,
Cotton, Coloureds, Synthetics and Delicates programs.
It is only necessary if your clothing is heavily soiled.
7. Turn the Fuzzy Control dial to select the
appropriate program for the type of
clothes Cotton, Coloureds, Synthetics,
Delicates, Wool, Hand wash, Quick,
Rinse+Spin, Spin, Drain, Baby
Program(Stains, Delicates, Coloreds,
Cotton)
You will see the indicators light up on
the control panel.
8. At this time, you can control the wash temperature, rinsing times, spin speed, delay time
by pressing the appropriate option button.
9. Press the Start/Pause button on the Fuzzy Control dial and the wash cycle will begin.
The process indicator will light up and the remaining time for the cycle will appear in the
display.
When the cycle is finished:
After the total cycle has finished, the power will turn off automatically.
1. Open the door.
Note: The door will not open untill 3 minutes after the machine stops or the power turns
off.
2.Remove laundry.
Washing for the first time
Before washing clothes for the first time, you must run a complete cycle without clothes.
To do this:
1. Press the (On/Off) button.
2. Pour a little detergent into compartment in the
detergent drawer.
3. Turn on the water supply to the washing machine.
4. Press the Temperature button repeatedly until
40 ˚C is displayed.
5. Press the Start/Pause button.
•
This will remove any water from the manufacturer’s
test run remaining in the machine.
Dispender :Detergent for prewash or starch.
Dispenser : Detergent for main wash, water softener,pre-soaking agent, bleach and stain removal product.
Dispenser : Additives,e.g.fabric softener or former (fill no higher than lower edge of insert “ A”)
Putting detergent in the washing machine
1. Pull out the detergent drawer.
2. Add laundry detergent into compartment .
3. Add softener into compartment (if you desire).
4. Add prewash detergent into compartment (if you desire).
Caution :
Concentrated or thick fabric softener and
conditioner must be diluted with a little water
before being poured into the dispenser (prevents
the overflow from becoming blocked.)
Page 7
Washing a Load of Laundry
10
SAMSUNG
Washing Machine Owner’s Instructions
SAMSUNG
Washing Machine Owner’s Instructions 11
Washing a Load of Laundry
Washing clothes manually
You can wash clothes manually without using the Fuzzy Logic feature. To do so:
1. Turn the water supply on.
2. Press the (On/Off) button on the washing machine.
3. Open the door.
4. Load the articles one at a time loosely into the drum, without overfilling.
5. Close the door.
6. Put the detergent and, if necessary, softener or prewash detergent, in the appropriate
compartments.
7. Press the Temperature button to select the temperature
(cold water, 30˚C, 40˚C, 60˚C, 95˚C)
8. Press to rinse button to select the required number of rinse cycles.
Maximum number of rinse cycles is five.
The washing duration will be prolonged accordingly.
9. Press the Spin button to select the spin speed.
Note: The rinse hold program allows you to take clothes that are dripping wet
out of the washing machine.
: No Spin, : Rinse Hold.
10. Press the button repeatedly to cycle through the available delayed start options
(from 3 hour to 24 hours in one hour increments). Displayed hours means the time
of finished washing-cycle.
11. Press the Start/Pause button and the machine will begin the cycle.
Using Delay Start
You can set the washing machine to finish your wash automatically at a later time, choosing
from 3 to 24 hour delay (in 1 hour increments). Displayed hours means the time of finished
washing-cycle.
To do this:
1. Manually or automatically set your washing machine for the type of clothes you are
washing.
2. Press the Delay Start button repeatedly until the delay time is set.
3. Press the Start/Pause button. The Delay Start indicator will light, and the clock will
begin counting down until it reaches your finish time.
4. To cancel Delay Start, press the (On/Off) button, then turn the washing machine
on again.
Washing tips and hints
Sorting your laundry : Sort your laundry according to the following characteristics:
•
Type of fabric care label symbol : Sort laundry into cottons, mixed fibers, synthetics,
silks, wools and rayon.
•
Colour : Divide whites and colours. Wash new, coloured items separately.
•
Size: Placing items of different sizes in the same load will improve the washing action.
•
Sensitivity: Wash delicate items separately, using the Delicate wash program for pure
new wool, curtains and silk articles. Check the labels on the items you are washing or
refer to the fabric care chart in the appendix.
Emptying pockets : Coins, safety pins and similar items can damage linen, the
washing machine drum, and the water tank.
Securing fasteners : Close zippers and fasten buttons or hooks; loose belts or ribbons
should be tied together.
Prewashing cotton : Your new washing machine, combined with modern detergents,
will give perfect washing results, thus saving energy, time, water and detergent. However,
if your cotton is particularly dirty, use a prewash with a protein-based detergent.
Determining load capacity: Do not overload the washing machine or your laundry
may not wash properly. Use the chart below to determine the load capacity for the type of
laundry you are washing.
Fabric Type Load Capacity
B1445AV/B1245AV/B1245AS/ R1245AV/R1045A F1245/F1045
B1245A/B1045A/
Coloured/cotton
-average/lightly soiled 6.5 kg 5.2 kg 4.5 kg
-heavily soiled 6.5 kg 5.2 kg 4.5 kg
Synthetics 3.0 kg 3.0 kg 3.0 kg
Delicates 2.5 kg 2.0 kg 2.0 kg
Wools 2.0 kg 1.5 kg 1.5 kg
Detergent tips: The type of detergent you should use is based on the type of fabric
(cotton, synthetic, delicate items, wool), colour, wash temperature, degree and type of
soiling. Always use "low suds" laundry soap, which is designed for automatic washing
machines.
Follow the detergent manufacturer's recommendations based upon the weight of the
laundry, the degree of soiling, and the hardness of the water in your area. If you do not
know how hard your water is, ask your water authority.
Note: Keep detergents and additives in a safe, dry place out of the reach of children.
Page 8
SAMSUNG
Washing Machine Owner’s Instructions 13
Maintaining the Washing Machine
12
SAMSUNG
Washing Machine Owner’s Instructions
Draining the washing machine in an emergency
B1445AV/B1245AV/B1245AS/B1245A/B1045A
1. Unplug the washing machine
from the power supply.
2. Open the filter-cover by using
a coin or a key.
3. Unscrew the emergency drain cap
by turning left. Grip the cap on the
end of the emergency drain tube
and slowly pull it out about 15 cm.
4. Allow all the water to flow into a bowl.
5. Reinsert the drain tube and screw the cap back on.
6. Replace the filter-cover.
Repairing a frozen washing machine
If the temperature drops below freezing and your washing machine is frozen:
1. Unplug the washing machine.
2. Pour warm water on the source faucet to loosen the water supply hose.
3. Remove the water supply hose and soak it in warm water.
4. Pour warm water into the washing machine drum and let it sit for 10 minutes.
5. Reconnect the water supply hose to the water faucet and check if the water supply
and drain operations are normal.
Cleaning the exterior
1. Wipe the washing machine surfaces, including the control panel, with a soft cloth
and non-abrasive household detergents.
2. Use a soft cloth to dry the surfaces.
3. Do not pour water on the washing machine.
Cleaning the detergent drawer and recess
1. Press the release lever on the inside
of the detergent drawer and pull it out.
2. Remove the cap from compartment .
3. Wash all of the parts under running water.
4. Clean the drawer recess with an old toothbrush.
5. Reinsert the cap (Pushing it firmly into place)
and replace the liquid detergent divider into the drawer.
6. Push the drawer back into place.
7. Run a rinse program without any laundry in the drum.
Cleaning the debris filter
Clean the debris filter 5 or 6 times a year, or when you see the following error message on
the display:
1. Open the filter-cover,
See “Draining the washing machine in an emergency" on page 12.
2. Unscrew emergency drain cap by turning left and drain off all the water.
See "Draining the washing machine in an emergency" on page 12.
3. Unscrew the filter cap and take it out.
4. Wash any dirt or other material from the filter. Make sure the drain pump propeller
behind the filter is not blocked. Replace the filter cap.
5. Replace the filter-cover.
Maintaining the Washing Machine
Page 9
Maintaining the Washing Machine
14
SAMSUNG
Washing Machine Owner’s Instructions
SAMSUNG
Washing Machine Owner’s Instructions 15
Cleaning the water hose mesh filter
You should clean the water hose mesh filter at least one time per year, or when you see the
following error message on the display:
To do this:
1. Turn off the water source to the washing machine.
2. Unscrew the hose from the back of the washing machine.
3. With a pair of pliers, gently pull out the mesh filter from the end of the hose and rinse
it under water until clean. Also clean the inside and outside of the threaded
connector.
4. Push the filter back into place.
5. Screw the hose back onto the washing machine.
6. Turn on the faucet and make sure the connections are watertight.
Troubleshooting
Problems and solutions
The washing machine will not start
• Make sure the door is firmly closed.
• Make sure the washing machine is plugged in.
• Make sure the water source faucet is turned on.
• Make sure to press the Start/Pause button.
No water or insufficient water supply
• Make sure the water source faucet is turned on.
• Make sure the water source hose is not frozen.
• Make sure the water intake hose is not bent.
• Make sure the filter on the water intake hose is not clogged.
Detergent remains in the detergent drawer after the wash
program is complete
• Make sure the washing machine is running with sufficient water pressure.
• Put the detergents in the inner parts of the detergent drawer(away from the
outside edges).
Washing machine vibrates or is too noisy
• Make sure the washing machine is set on a level surface. If the surface is not level,
adjust the washing machine feet to level the appliance (see page 3).
• Make sure that the shipping bolts are removed (see page 3).
• Make sure the washing machine is not touching any other object.
• Make sure the laundry load is balanced.
The washing machine does not drain and/or spin
• Make sure the drain hose is not squashed or bent.
• Make sure the debris filter is not clogged
(see page 14).
The Door does not open
• The door will not open until 3 minutes after the machine stops or the power turns off.
Understanding error messages
Error displayed Solution
Before contacting After-Sales service:
1. Try to remedy the problem (See "Troubleshooting" on this page).
2. Restart the programme to see if the fault is repeated.
3. If the malfunction persists, call after-sales service and describe the problem.
• Close the door.
• Make sure the source water faucet is turned on.
• Check the water pressure.
• Clean the debris filter.
• Make sure the drainage hose is installed correctly.
• Call after-sales service.
• Laundry load is unbalanced; loosen any tangled laundry.
If only one item of clothing needs washing, such as a bathrobe or
jeans, the final spin result might be unsatisfactory and an "UE"
error message will be shown in the display window.
Page 10
SAMSUNG
Washing Machine Owner’s Instructions 17
16
SAMSUNG
Washing Machine Owner’s Instructions
Programme Chart
PROGRAM Type of WASH
Baby Cotton Averagely or lightly soiled baby cottons, bed linen, table linen, underwear,
towels, shirts, etc.
Baby Coloureds Averagely or lightly soiled baby cottons, bed linen, table linen, underwear,
towels, shirts, etc.
Baby Delicates Delicate baby dresses, skirts, shirts and blouses.
Baby Stains Stains on cottons, bed lined, underwear, towels, etc. caused by food spills and
urine.
Programme Chart
Cotton 6.5 5.2 4.5 ✽ yes ✽ 95 1400 1200 1000 ✽✽
Coloureds 6.5 5.2 4.5 ✽ yes ✽ 60 1400 1200 1000 ✽✽
Synthetics 3.0 3.0 3.0 ✽ yes ✽ 60 800 800 800 ✽✽
Delicates 2.5 2.5 2.0 ✽ yes ✽ 40 800 800 600 ✽✽
Wool 2.0 1.5 1.5 - yes ✽ 40 400 400 400 ✽✽
Handwash 2.0 1.5 1.5 - yes ✽ 40 400 400 400 ✽✽
Quick
2.0 1.5 1.5 - yes ✽ 60 1400 1200 1000 ✽✽
PROGRAM Type of WASH
Cotton Averagely or lightly soiled cottons, bed linen, table linen, underwear, towels,
shirts, etc.
Coloureds Averagely or lightly soiled cottons, bed linen, table linen, underwear, towels,
shirts, etc.
Synthetics Averagely or lightly soiled blouses, shirts, etc., Made of polyester
(diolen, trevira), polyamide (perlon, nylon) or other similar blends.
Delicates Delicate curtains, dresses, skirts, shirts and blouses.
Wool Only machine washable woolens with pure new wool label.
Handwash
Very light wash course like hand wash.
Quick
Lightly soiled cottons or linen blouses, shirts, dark coloured terry cloth,
coloured linen articles, jeans, etc.
1. Programme with prewash lasts approx. 15 minutes longer.
2. The programme duration data has been measured under the conditions specified in
Standard IEC 456.
3. Consumption in individual homes may differ from the values given in the table
due to variations in the pressure and temperature of the water supply, the load and
the type of laundry.
PRO-
GRAM
DETERGENT
AND ADDITIVES
Spin Speed(MAX)rpm
Half
Load
Tem
(˚C)
Max load
(kg)
Pre-
wash
Sof-
tener
Max
wash
B1445AV
B1245AV
B1245AS
B1245A
R1245AV
F1245AV
B1045A
R1045A
F1045A
B1445AV
B1245AV
B1245AS
B1245A
B1045A
F1245AV
F1045A
R1245AV
R1045A
Delay
start
Baby Cotton 6.5 5.2 4.5 ✽ yes ✽ 95 1400 1200 1000 ✽✽
6.5 5.2 4.5 ✽ yes ✽ 60 1400 1200 1000 ✽✽
2.5 2.0 2.0 ✽ yes ✽ 60 800 800 600 ✽✽
Baby Stains 6.5 5.2 4.5 ✽ yes ✽ 40 1400 1200 1000 ✽✽
PRO-
GRAM
DETERGENT
AND ADDITIVES
Spin Speed(MAX)rpm
Half
Load
Tem
(˚C)
Max load
(kg)
Pre-
wash
Sof-
tener
Max
wash
B1445AV
B1045A
R1045A
F1045A
R1245AV
R1045A
F1245AV
F1045A
Delay
start
Baby
Coloureds
Baby
Delicates
(
✽
user option) (
✽
user option)
B1445AV
B1245AV
B1245AS
B1245A
B1045A
B1245AV
B1245AS
B1245A
R1245AV
F1245AV
Page 11
SAMSUNG
Washing Machine Owner’s Instructions 19
18
SAMSUNG
Washing Machine Owner’s Instructions
Appendix
Protecting the environment
• This appliance is manufactured from recyclable materials. If you decide to dispose of
this appliance, please observe local waste disposal regulations. Cut off the power
cord so that the appliance cannot be connected to a power source. Remove the door
so that animals and small children cannot get trapped inside the appliance.
• Do not exceed the detergent quantities recommended in the detergent manu-
facturers' instructions.
• Use stain removal products and bleaches before the wash cycle only when strictly
necessary.
• Save water and electricity by only washing full loads (the exact amount depends
upon the program used).
Declaration of conformity
This appliance complies with European safety standards, EC directive 93/68 and EN
Standard 60335.
Specification
Appendix
Fabric care chart
Electrical warnings
To reduce the risk of fire, electrical shock, and other injuries, keep these safety precautions in
mind:
• Operate the appliance only from the type of power source indicated on the marking
label. If you are not sure of the type of power supplied to your home, consult your
appliance dealer or local power company.
• Use only a grounded or polarized outlet. For your safety, this appliance is equipped
with a polarized alternating current line plug having one blade wider than the other.
This plug will fit into the power outlet only one way. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug still doesn't fit, contact
your electrician to replace your outlet.
• Protect the power cord. Power supply cords should be routed so that they are
unlikely to be walked on or pinched by items placed on or against them. Pay
particular attention to cords at plugs, convenience receptacles, and the point where
they exit from the unit.
• Do not overload the wall outlet or extension cords. Overloading can result in fire or
electric shock.
Resistant material
Delicate fabric
Item may be washed at 95 ˚C
Item may be washed at 60 ˚C
Item may be washed at 40 ˚C
Item may be washed at 30 ˚C
Item may be hand washed
Dry clean only
Can be bleached in cold water
Do not bleach
Can be ironed at 200 ˚C max
Can be ironed at 150 ˚C max
Can be ironed at 100 ˚C max
Do not iron
Can be dry cleaned using any solvent
Dry clean with perchloride, lighter fuel,
pure alcohol or R113 only
Dry clean with aviation fuel,
pure alcohol or R113 only
Do not dry clean
Dry flat
Can be hung to dry
Dry on clothes hanger
Tumble dry, reduced heat
Do not tumble dry
Tumble dry, normal heat
TYPE FRONT LOADING WASHER
DIMENSION
B1445AV,B1245AV,B1245AS,B1245A,B1045A
W598mm × D550mm ×H844mm W598mm × D404mm ×H844mmW598mm × D450mm ×H844mm
F1245AV,F1045AR1245AV,R1045A
WATER PRESSUERE
50 kPa ~ 800 kPa
WATER VOLUME
54L 48L
NET WEIGHT
PACKAGE Wt
SPIN REVOLUTION
POWER
CONSUMPTION
75kg
2.5kg
1.0kg
1.9kg
0.8kg
62kg
WASH and SPIN CAPACITY
6.5kg (DRY LAUNDRY)
49L
66kg
5.2kg (DRY LAUNDRY)
MODEL
MODEL
MODEL
PUMPING
PLASTIC
PAPER
SPIN
MODEL
230V 550W
240V
220V
2000W
2400W
500W 250W
34W
500W 220W
240V 2100W
220V 1800W
B1445AV
B1445AV B1045A,R1045A,F1045A
1400rpm 1200 1000
B1245AV,B1245AS,
B1245A
B1045A F1045A
WASHING AND
HEATING
F1245AV,F1045A
550W 500W
240V 2200W
220V 1900W
R1245AV,R1045A
F1245AV,F1045A
2.1kg
0.9kg
R1245AV,R1045A
4.5
kg (DRY LAUNDRY)
B1445AV,B1245AV,B1245AS,B1245A,B1045A
F1245AR1245A R1045A
B1445AV,B1245AV,B1245AS,B1245A,B1045A
B1445AV,B1245AV,B1245AS,B1245A,B1045A
Page 12
IN CASE THE NEED FOR
SERVICING ARISES
-Don't hesitate to call any AS center nearby
with your name, address, telephone number,
model number and serial number of your machine
when anything wrong with your product occurs.
Code No.: DC68-01986U
GB+INNE
Loading...
