Samsung AC401B, AC401BR-HAC User Manual

Air Cleaner

E

DB98-13331A(1)

OWNER’S
INSTRUCTIONS

AC401B
AC401BR
AC401BG

E-2

Safety Precautions

The following safety precautions must be taken into account when using this product.

◆ Do not install this product in places where it will come into contact with
combustible gases such as sulfuric gas, hydrogen gas, methane gas, etc.

◆ Do not install this product in places that are exposed to direct sunlight,
near heating equipments and wet places.

◆ When installing the electric wires, do not bend the wire excessively
or place a heavy object on it. The wires may be disconnected or
damaged.

◆ Avoid using inflammable spray gases such as insecticides near
this product.

◆ Prevent children from inserting their fingers or objects into the air inlet
and outlet.

◆ Do not attempt to install or repair this product by yourself. If the
product needs repairing, consult an authorized service personnel.

WARNING

◆ Do not install this product on surfaces that are not even or slant.
This may cause the product to malfunction or make a strange noise
due to vibration.

◆ Make sure that the product is installed in a location that ensures
enough space(at least 5 cm) in front of the air inlet.

◆ Make sure that there are no obstacles near the air inlet and
outlet of the product.

◆ If a strange noise, burning smell or smoke come from the product,
immediately disconnect the power supply and consult an authorized
service personnel.

◆ Do not use this product for other purposes.

◆ Do not spill any kind of liquids into the product.

◆ Do not place containers containing liquid substances on top of the

product.

◆ Do not apply excessive impact on the product.

◆ When using this product in a closed area that combustible fuels are

fired, make sure to ventilate the air occasionally.

◆ Do not use the product in places that have a high temperature and
humidity level, such as a bathroom or a sauna.

◆ Before attempting to clean or repair the product, make sure that the
power supply is disconnected and the fan has stopped rotating.

◆ Do not use substances such as benzene, thinner or alcohol to clean
the surface of the product.

◆ Do not open the filter box when the product is in operation.

◆ When drying the washable filters, do not expose it to direct sunshine.

The powerful sunshine may affect the transformation of the filter case.

◆ Do not touch the filter section with wet hands because the user may be
electrocuted. This is especially true for the Washable Filter section
where a high voltage current flows.

CAUTION

E-3

Contents

◆

P

REPARING THE

A

IRCLEANER

■ Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

■ View of the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

■ Remote Control-Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

■ Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

■ Inserting the Battery into the Remote Control . . . . . . . . . . . . . . . . 8

■ Keeping the Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

UU

UU

SSSSIIIINNNNGGGGTTTTHHHHEEEECCCCOOOONNNNTTTTRRRROOOOLLLLPPPPAAAANNNNEEEELL

LL

◆

O

PERATING THEAIRCLEANER

■ Selecting the Automatic Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

■ Selecting the Pollen Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

■ Selecting the Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

■ Selecting the Odor Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

◆

O

THERFUNCTIONS

■ Generating Anions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

■ Adjusting the Clean Level (Fan Speed) . . . . . . . . . . . . . . . . . . . . . 15

UU

UU

SSSSIIIINNNNGGGGTTTTHHHHEEEERRRREEEEMMMMOOOOTTTTEEEECCCCOOOONNNNTTTTRRRROOOOLL

LL

◆

O

PERATING THE

AIRC

LEANER WITH AREMOTECONTROL

■ Adjusting the Air Flow Direction . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

■ Adjusting the Display Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . 18

■ Adjusting the Clean Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

■ Selecting the Operating Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

■ Generating Anions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

◆

R

ECOMMENDATIONS FORUSE

■ Operating Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

■ Cleaning the Air Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

■ Solving Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

◆

T

ECHNICALSPECIFICATIONS

E-4

View of the Unit

Control panel

Odor sensor

Dust sensor

Remote control case

Air outlet

Air flow direction blade

Filter box

Front panel

Power plug

Pre-filter Ionizer Electrostatic

filter

Nano
silver

formula

HEPAfilter

VOCs filter TiO

2

photocatalyst
filter

Anion

generator

Anti-bacterial

fan

Metal

filter

Washable Filter Section Fixed Filter Section

Replacement Filter

Section

UV Lamp

11 Step Cleaning System

Main Unit

The Metal filter is coated with the Nano-silver particles.

NNNNoooottttee

ee

E-5

Indicator

Anion Indicator

Filter Reset Button & Indicator

Anion Button

Remote Control
Sensor

Clean level Indicator

Operating Mode Indicator

Contamination Level Indicator

◆ Indicator

- Displays the Clean Level by differing its blinking speed.

- If the air cleaner is operating at the Pollen Mode, the Indicator shows

the image of big dust particles by blinking.

◆ Contamination Level Indicator

- Classifies the various contaminants in the indoor air, as Odor, Mote and Dust,

and up to 8 levels can be displayed.

- Green indicates that the indoor air is clean. Red means that the indoor
air is contaminated.

- During the first two minutes after the air cleaner is turned on, the contamination level

will move up and down because the sensor will be in the
process of analyzing the contamination level of the indoor air.
So it is recommended that you check the contamination level
in 2 minutes.

NNNNoooottttee

ee

Power Button

Clean Level Selection Button

Operating Mode Selection Button

Control Panel

Remote Control - Buttons

E-6

Power Button

Air Flow Blade Swing Button

Dimmer Button

Clean Level Selection Button

Operating Mode Selection Button

Anion Button

G

etting Started

You have just purchased an air cleaner and it has to be installed according
to the safety precautions of page 2.

This manual contains important information
concerning the use of your air cleaner. Please take some time to
read this booklet as it will help you take full advantage of the product's features.

The booklet is organized as follows.

◆ The following figures are shown from page 4 to 6 :

- View of the Unit

- Remote control(buttons)
They will help you find the buttons and understand the symbols
that are displayed.

◆ In the manual, you will find a series of step-by-step

procedures for each function available.

Three types of symbols are used to help you understand the illustrations
in the step-by-step procedures :

PRESS PUSH HOLD DOWN

E-7

Inserting the Battery into the Remote Control

◆ Always direct the remote control towards the Remote Control
Sensor on the air cleaner when operating it from a distance.

◆ When you press a button on the remote control and the air cleaner
makes a ringing sound, it means the function has been chosen.

◆ If other electric appliances are affected by the remote control,
consult an authorized service personnel.

You must insert or replace the remote control battery when:

◆ You purchase the air cleaner.

◆ The remote control does not work properly.

NNNNoooottttee

ee

E-8

Push the section marked with the dotted lines towards the direction of the
arrow(①), and then pull out the battery case in the direction of the arrow(②).

Insert the battery(Lithium Ion), after confirming polarities of the battery :

◆ + side on the battery with the + side on the remote control.

◆ - side on the battery with the - side on the remote control.

1

2

Slide back the battery cover until it clicks.

3

1

2

Keeping the Remote Control

Keep the remote control in the remote control case of the air cleaner when
it is not being used.

As shown in the figure, place the remote control in the remote control case.

This chapter indicates how to operate your air cleaner with the
buttons on the control panel.

UU

UU

SS

SSIIII

NN

NN

GG

GG

TTTTHH

HHEEEE

CC

CC

OO

OO

NN

NNTTTT

RR

RR

OO

OOLLLL

PP

PP

AA

AA

NN

NNEEEELLLL

E-9

Selecting the Automatic Mode

E-10

In the Automatic Mode, the air cleaner automatically adjusts the clean level according
to the signal of the more contaminated level after comparing the dusts and motes
contamination level with the odor contamination level in the indoor air. Anions are
generated into an air automatically and the air flow blade does not move.

1

If the is not displayed on the display, select the Auto mode by pressing
the button until it is displayed on the display of the air cleaner.

Result

: ◆ The air cleaner beeps.

◆ The air cleaner operates in the Auto mode.

2

To control the direction of the air flow, refer to page 17.
To adjust the clean level, refer to page 15.
To adjust the generating anions, refer to page 14.

3

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

You can change modes at any time.

NNNNoooottttee

ee

Selecting the Pollen Mode

E-11

The Pollen Mode can eliminate pollen and dust particles effectively in the indoor
air. In this operating mode, the air cleaner automatically adjusts the clean level
according to the dusts or motes contamination level without the odor
contamination level in the indoor air. Anions are generated automatically
and the air flow blade moves automatically.

1

If the is not displayed on the display, select the Pollen mode by pressing
the button until it is displayed on the display.

Result

: ◆ The air cleaner beeps.

◆ The air cleaner operates in the Pollen mode.

2

To control the direction of the air flow, refer to page 17.
To adjust the clean level, refer to page 15.
To adjust the generating anions, refer to page 14.

3

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

You can change modes at any time.

NNNNoooottttee

ee

Selecting the Sleep Mode

If you wish the air cleaner to clean the air in your room quietly, select the
Sleep Mode. In this operating mode, the air cleaner runs in "Low Speed"
which is the quietest clean level setting. Anions are generated into an air
automatically and the air flow blade does not move.

1

If the is not displayed on the display, select the Sleep mode by pressing
the button until it is displayed on the display.

Result

: ◆ The air cleaner beeps.

◆ The air cleaner operates in the Sleep mode.

2

To control the direction of the air flow, refer to page 17.
To adjust the clean level, refer to page 15.
To adjust the generating anions, refer to page 14.

3

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

You can change modes at any time.

NNNNoooottttee

ee

E-12

The brightness of the display during the Sleep Mode

◆ In the Sleep Mode, the brightness of the display decreases so that

it may not disturb your sleep.

◆ If you wish to turn off the display completely, press the Dimmer

button on the remote control.
However, the Nano e-HEPA indicator cannot be turned off.

NNNNoooottttee

ee

Selecting the Odor Mode

If you select the Odor Mode, the air cleaner can eliminate airborne contaminants and
harmful smells effectively in the indoor air. In this operating mode, the air cleaner
automatically adjusts the clean level according to the signal of the odor contamination
level without the dusts and motes contamination level in the indoor air. Anions are
generated automatically and the air flow blade moves automatically.

1

If the is not displayed on the display, select the Odor mode by pressing
the button until it is displayed on the display.

Result

: ◆ The air cleaner beeps.

◆ The air cleaner operates in the Odor mode.

2

To control the direction of the air flow, refer to page 17.
To adjust the clean level, refer to page 15.
To adjust the generating anions, refer to page 14.

3

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

You can change modes at any time.

NNNNoooottttee

ee

E-13

◆ VOCs(Volatile Organic Compounds) are substances which are

evaporated easily at the room temperature. Common sources
which emit VOCs into the indoor air include housekeeping
products, building and furnishing materials. In sufficient quantities,
VOCs can have direct adverse effects on human health. Many
VOCs have been classified as toxic and carcinogenic substances.
Therefore it is harmful to be exposed to these compounds for a
long period.

NNNNoooottttee

ee

Generating Anions

The Anion Generator generates anions, which are beneficial to the human body.
Use this function if you want to feel refreshed both physically and mentally,
just as if you were in the midst of a forest.
If the air cleaner is turned on, anions are generated automatically.

1

If the Anion Indicator is not displayed on the display, select the Anion
Generation function by pressing the button.

Result

: ◆ The air cleaner beeps.

◆ The Anion Indicator lights up on the display.

◆ The air cleaner generates anions into the indoor air.

2

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

If you wish to turn off the Anion Generation function, press the button
again.

Result

: ◆ The Anion Indicator disappears on the display.

◆ The air cleaner stops generating anions into the indoor air.

3

◆ Anions are ultra-fine particles charged negatively in the air.

There are vast quantities of them in nature, for example near
waterfalls or in the midst of a forest. When inhaled in sufficient
quantities, anions can enhance the metabolism of your blood cells,
help you recover from fatigue faster, and calm your nerves.
Thus anions are beneficial to you both physically and mentally.

NNNNoooottttee

ee

E-14

Adjusting the Clean Level (Fan Speed)

The air cleaner automatically adjusts the clean level according to the
contamination levels of the indoor air. It is also possible for you to
manually select the clean level.

1

If you wish to manually select the clean level, press the button one
or more times until the desired clean level is selected.

Result

: ◆ The air cleaner beeps.

◆ The air cleaner operates in the clean level that was selected.

2

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

If you wish the air cleaner to automatically adjust the clean level for you,
press the button until the Auto mode is selected.

Result

: ◆ The clean level that was selected is canceled.

◆ The air cleaner operates in the Auto mode.

◆ The air cleaner automatically chooses the appropriate clean

level according to the levels of contamination in the indoor air.

3

HH (Turbo)
H (High)
M (Medium)
L (Low)

E-15

This chapter indicates how to operate your air cleaner with
a remote control.

UU

UU

SS

SSIIII

NN

NN

GG

GG

TTTTHH

HHEEEE

RR

RREEEE

MM

MM

OO

OOTTTTEEEE

CC

CC

OO

OO

NN

NNTTTT

RR

RR

OO

OOLLLL

E-16

Adjusting the Air Flow Direction

The movement of the air flow blade changes according to the operating
modes. The air flow blade swings automatically in the Pollen and Odor
mode, but it is fixed in one position in the Auto and Sleep mode.
The air flow blade can only be controlled with the remote control.

1

Press the button on the remote control.
Result

: ◆ The blade automatically begins to swing.

◆ The air cleaner beeps.

2

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

To stop the blade from swinging, press the button again.
To fix the blade in certain position, press the button again when the
blade is in the required position.

3

E-17

When the air cleaner is turned on, the air blade
automatically starts to move.

IMPORTANT

Adjusting the Display Brightness

1

Select the brightness level of the display by pressing the button on
the remote control one or more times until the desired brightness is
displayed.

There are three brightness levels that you can choose from:

- Press the button once: The display becomes dim.

- Press the button twice: The display turns off.

2

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

◆ By simply pressing the Dimmer button, you can check the level of

contamination in the room with your eye.
This can be done even though the air cleaner is not in operation.

NNNNoooottttee

ee

E-18

The indicator is always lighted brightly.

IMPORTANT

You can adjust the brightness of the display of the air cleaner according to
your desire. The brightness can only be controlled with a remote control.

Adjusting the Clean Level (Fan Speed)

1

If you wish to manually select the clean level, press the button
one or more times until the desired clean level is selected.

Result

: ◆ The air cleaner beeps.

◆ The air cleaner operates in the clean level that was selected.

2

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

If you wish the air cleaner to automatically adjust the clean level for you,
press the button on the remote control until the Auto mode is selected.

Result

: ◆ The clean level that was selected is canceled.

◆ The air cleaner operates in the Auto mode.

◆ The air cleaner automatically chooses the appropriate clean

level according to the levels of contamination in the indoor air.

3

HH (Turbo)
H (High)
M (Medium)
L (Low)

E-19

The air cleaner automatically adjusts the clean level according to the
contamination levels of the indoor air. It is also possible for you to
manually select the clean levels.

Selecting the Operating Mode

1

If the desired operating mode is not displayed on the display, select an operating
mode by pressing the button on the remote control until it is displayed on
the display.

Result

: ◆ The air cleaner beeps.

◆ The air cleaner operates in the desired operating mode.

2

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

You can change modes at any time.

NNNNoooottttee

ee

E-20

You can select the operating mode with a remote control among the Auto,
Pollen, Sleep and Odor mode.

Generating Anions

1

If the Anion Indicator is not displayed on the display, select the Anion
Generation function by pressing the button on the remote control.

Result

: ◆ The air cleaner beeps.

◆ The Anion Indicator lights up on the display.

◆ The air cleaner generates anions into the indoor air.

2

If necessary, press the (Power) button.
Result

: ◆ The Power indicator on the display comes on.

◆ The air cleaner runs in the Auto Mode.

◆ The air cleaner makes a ringing sound.

If you wish to turn off the Anion Generation function, press the button
again.

Result

: ◆ The Anion Indicator disappears on the display.

◆ The air cleaner stops generating anions into the indoor air.

3

E-21

The Anion Generator generates anions, which are beneficial to the human
body. Use this function if you want to feel refreshed both physically and
mentally, just as if you were in the midst of a forest.
If the air cleaner is turned on, anions are generated automatically.

Operating Recommendations

Here are a few recommendations that you should follow when using
your air cleaner.

Topic Recommendation

Wash indicator

If the light on the "Wash" indicator comes on, the
washable filters must be cleaned. The washable
filters must be cleaned more often in environments
that include large amounts of dust in the air.

Replace indicator

If the light on "Replace" indicator comes on,
the replacement filters must be replaced.
If the replacement filters are not replaced,
the product's air filtering function may decrease.

Closing the air flow blade

If you want to close the air flow blade, use the Power
button on the control panel or the remote control.
Do not close the air flow blade with your hands.

E-22

Cleaning the Air Cleaner

E-23

Cleaning the Lens of the Dust Sensor

To get the best possible result from your air cleaner, you must clean
the lens of the dust sensor regularly. The dust sensor is responsible
for sensing the accumulation level of small and big dust particles in
the air in your room.

1 Open the front panel.

2 Clean the lens of the Dust Sensor thoroughly with a cotton stick.

2

1

Dust Sensor

Dust Sensor Lens

Slightly pull out the bottom part of the front panel

(①)

, lift it up

(②)

and then separate it from the unit.

NNNNoooottttee

ee

If the lens of the Dust Sensor is cleaned with a sharp or rough
object, the lens is damaged, so the Dust Sensor may not work
properly.

NNNNoooottttee

ee

◆ You must clean the lens of the Dust Sensor every six months.

However, this may vary according to the time and place that the air
cleaner was operated. So the air cleaner must be cleaned more
often in environments that have a high level of dust accumulation.

◆ The Odor Sensor does not have a lens. So you do not need to

clean the Odor Sensor.

NNNNoooottttee

ee

3 After you have cleaned the lens of the Dust Sensor, put the front panel

back into the place.

Cleaning the Air Cleaner (cont.)

E-24

3 Leave the Washable Filter Section in the shade to dry for over 12 hours.

5 Press the control panel’s button for 2 seconds.

Result

: ◆ The Wash Indicator on the control panel turns off.

It will light up again when the time for the next filter
washing comes.

◆ The air cleaner beeps.

4 Put the Washable Filter Section back into the place and close the Filter

Box.

During this process, make sure that the filter is not exposed to
direct sunlight because the sun's rays may affect the
transformation of the filter case.

NNNNoooottttee

ee

Cleaning the Washable Filters

Washable Filters are responsible for eliminating fine particles of dust,
molds and mites in the air that are as small as 0.5 microns. It also has the
function of sterilizing virus or bacteria in the air in your room. You must
clean the Washable Filters every 3 months or whenever the Wash
Indicator comes on. The cleaning frequency of the Washable Filters may
vary according to the time and place that the air cleaner is operated.

1 Open the Filter Box and pull out the Washable Filter Section towards the

direction of the arrow.

2 Wash the Washable Filter Section under lukewarm tap water.

◆If the filter is too contaminated, leave it in warm water mixed with
neutral detergent for 30 minutes, and brush the contaminants off
with a soft brush.

◆The Pre-Filter is easy to clean because it can be taken out of the
Washable Filter Section and washed separately.

NNNNoooottttee

ee

Washable Filter
Section

Pre-Filter

Even though the Wash Indicator does not light up,
always press the button after washing the
Washable Filter Section.

IMPORTANT

E-25

3 Replace the old HEPA Filter with new one, and place it back into the

Replacement Filter Section.

5 Press the control panel’s button for 2 seconds.

Result

: ◆ The Replace Indicator on the control panel turns off.

It will light up again when the time for the next filter
replacement comes.

◆ The air cleaner beeps.

4 After pushing the Replacement Filter Section back into the place, close

the Filter Box.

Replacing the Replacement Filter

The Replacement Filter eliminate finer particles of dust, molds and
mites in the air in your room that are as small as 0.3 microns.

1 Open the Filter Box and pull out the Replacement Filter Section towards

the direction of the arrow.

2 Detach the HEPAFilter from the Replacement Filter Section.

◆ You only need to replace the Replacement Filter once in five years or

when the Replace Indicator lights up. However, the replacing
frequency of the Replacement Filter may vary according to the time
and place that the air cleaner is operated.

◆ You can purchase new HEPA Filters in an authorized service center.

NNNNoooottttee

ee

Replacement
Filter Section

HEPAFilter

Even though the Replace Indicator does not light up,
always press the button after replacing the
Replacement Filter.

IMPORTANT

Solving Common Problems

E-26

Explanation/Solution

◆ Check for a power failure.

◆ Check that the power plug is plugged in tightly.

◆ Check that the power outlet is not of a poor quality.

◆ Check that the Filter Box is closed properly.

Problem

The air cleaner does not
operate.

Before contacting the after-sales service, perform the following simple checks.
This may prevent you from making an unnecessary call and wasting your time and money.

◆ Check whether the Filter Box was opened during operation.
Press the Power button if you wish to restart the air cleaner.

The air cleaner stops its
operation abruptly

◆ Check the remote control battery and replace it if it has expired.

◆ Check that there are no obstacles between the remote control and

the control panel of the air cleaner.

◆ Make sure that there are no strong sources of lighting near the air
cleaner. The strong light of three way fluorescent lamps or neon
signs can obstruct the transmission of data from the remote control
to the control panel.

The air cleaner cannot be
operated with the remote
control.

◆ Make sure that the air cleaner is used in places that have
a high level of odor permeating contaminants in the air.
The air cleaner cannot fully function in an environment where the
level of contamination is too high.

◆ Check whether the source of the unpleasant odor is the unclean
filters in the Filter Box.

Unpleasant odors can be
detected coming from the air
cleaner.

◆ Check whether the air cleaner is operating in the Sleep Mode.
In the Sleep Mode, the display automatically diminishes its
brightness to ensure a comfortable sleeping setting.

◆ Check that the brightness of the display has been adjusted.
If so, press the Dimmer button and increase the brightness of the
display.

The Display Brightness is too
dim.

◆ Check whether the lens of the Dust Sensor is unclean.

◆ Check whether the filters in the Wash and Replace Filter Section

have been cleaned and replaced regularly.

◆ Check that there are no additional contaminants entering the room
through open windows and doors.

The air in the room still feels
unclean.

◆ Make sure that you have pressed the Filter Reset button after you
have cleaned the Washable Filters or finished replacing the
Replacement Filters.

The Wash and Replace Indicators
stay on.

◆ Close the air flow blade by using the Power button on the control
panel or the remote control. Do not close the air flow blade with
your hands.

The air flow blade does not close.

◆ Check that the air cleaner is in the Auto or Sleep Mode.

- In the Auto or Sleep Mode, the air cleaner automatically does not

move the air flow blade.

◆ Make sure that you have pressed the Air Swing button.

- Please press the Air Swing button on the remote control to move the

air flow blade.

The air flow blade does not
move.

Technical Specifications

E-27

Model

AC401B
AC401BR
AC401BG

220-240V~, 50/60Hz

Power Supply

ELECTRONICS

Printed in Korea

THIS AIR CLEANER IS MANUFACTURED BY:
