Samsung 950p Plus User Manual
SyncMaster 750p
SyncMaster 950p
SyncMaster 950p
Color Monitor
Owners
Instructions
Information in this document is subject to change without notice.
© 1999 Samsung Electronics Co., Ltd. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co.,
Ltd. is strictly forbidden.
Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
The Samsung logo and SyncMaster are registered trademarks of Samsung Electronics Co., Ltd.;
Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation; VESA,
DPMS and DDC are registered trademarks of Video Electronics Standard Association; the E
NERGY STAR
name and logo are registered trademarks of the U.S. Environmental Protection Agency (EPA). As an
E
NERGY STAR
S
TAR
Partner, Samsung Electronics Co., Ltd. has determined that this product meets the E
NERGY
guidelines for energy efficiency. All other product names mentioned herein may be the trademarks
or registered trademarks of their respective owners.
Contents
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Unpacking Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Setting up Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Plug and Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the Video Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Windows
Windows
Self-Test Feature Check (STFC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warm-up Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Adjusting Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
User Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Automatic Save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Direct-Access Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Menu Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
PowerSaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Display Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
®
2000 and Windows® 98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
®
95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
OSD Lock/Unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Parallel/Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pincushion/Trapezoid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pinbalance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Linearity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Clear Moire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Focus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Degauss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
User-Delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Sync. Input Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Video Input Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
D-SUB/BNC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Menu Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Menu Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Languages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
English
1
Safety Instructions
Before connecting the AC power cord to the DC adapter outlet, make sure the voltage designa-
1
tion of the DC adapter corresponds to the local electrical supply.
Never insert anything metallic into the monitor openings. Doing so may create the danger of
2
electric shock.
To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should
3
open the monitors case.
Never use your monitor if the power cord has been damaged. Do not allow anything to rest on
4
the power cord, and keep the cord away from areas where people can trip over it.
Be sure to hold the plug, not the cord, when disconnecting the monitor from an electric socket.
5
Openings in the monitor cabinet are provided for ventilation. To prevent overheating, these
6
openings should not be blocked or covered. Also, avoid using the monitor on a bed, sofa, rug, or
other soft surface. Doing so may block the ventilation openings in the bottom of the cabinet. If
you put the monitor in a bookcase or some other enclosed space, be sure to provide adequate
ventilation.
Put your monitor in a location with low humidity and a minimum of dust.
7
Do not expose the monitor to rain or use it near water (In kitchens, near swimming pools, etc.).
8
If the monitor accidentally gets wet, unplug it and contact an authorized dealer immediately.
You can clean the monitor with a damp cloth when necessary, but be sure to unplug the monitor
first.
Place the monitor on a solid surface and treat it carefully. The screen is made of glass and can
9
be damaged if dropped or hit sharply.
Locate your monitor near an easily accessible AC outlet.
10
If your monitor does not operate normally in particular, if there are any unusual sounds or
11
smells coming from it unplug it immediately and contact an authorized dealer or service
center.
High temperature can cause problems. Dont use your monitor in direct sunlight, and keep it
12
away from heaters, stoves, fireplaces, and other sources of heat.
Unplug the monitor when it is going to be left unused for an extended period of time.
13
Unplug your monitor from the AC outlet before any service.
14
CAUTION
RISK OF ELECRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
2
Unpacking Your Monitor
Please make sure the following items are included with your monitor. If any items are
missing, contact your dealer.
CD-ROM
Manual
Power Cord
English
Warranty Card
(Not available in all areas)
Monitor and Stand
Signal Cable
3
Setting up Your Monitor
Connecting Your Monitor
5
3
B
G
R
6
Figure 1. Cable connections
Turn off your computer and unplug its power cord.
1
Connect the signal cable to the D-SUB or BNC signal port on the back of your monitor.
2
If you are using an IBM-compatible computer, skip to step 5. If you are using a
3
Macintosh computer, connect the other end of the signal cable to a Macintosh
adapter.
Follow the instructions included with your adapter to set the pins on your adapter, if
4
necessary.
Connect the signal cable (with an adapter, if necessary) to the video port on the back
5
of your computer. This port might be directly attached to your computer, or it might be
part of a video adapter, video card, or graphics card.
Connect the power cord for your monitor to the power port on the back of the monitor.
6
Plug the power cords of your computer and your monitor into a nearby outlet.
7
2
7
Turn on your computer and monitor. If your monitor displays an image, installation is
8
complete.
4
Setting up Your Monitor
Plug and Play
Our adoption of the new VESA® Plug and Play solution eliminates complicated and time
consuming setup. It allows you to install your monitor in a Plug and Play compatible system
without the usual hassles and confusion. Your PC system can easily identify and configure
itself for use with your display. This monitor automatically tells the PC system its Extended
Display Identification (EDID) data using Display Data Channel (DDC) protocols so the PC
system can automatically configure itself to use the flat panel display. If your PC system
needs a video driver, following the instructions given below according to the operating
system your computer uses.
Installing the Video Driver
When prompted by the operating system for the monitor driver, insert the Driver diskette
included with this monitor. Driver installation is slightly different from one operating system
to another. Follow the directions as appropriate for the operating system you have.
Windows® 2000 and Windows® 98
Windows® 2000 and Windows® 98 will auto-detect your new monitor and start the
1
Add New Hardware Wizard if the drivers are not already installed. Click the
button to search for drivers.
Check the diskette drive box to install the drivers off the diskette provided with your
2
monitor and click
Confirm that Windows found the driver on the diskette and click
3
the driver.
NEXT
.
NEXT
again to install
NEXT
English
To manually install or update the driver, follow the directions below:
Click on
1
ADVANCED, MONITOR
Wizard.
Follow the same directions as given in the steps in the section above.
2
START, SETTINGS, CONTROL PANEL, DISPLAY SETTINGS
tab,
CHANGE
. This will start the Add New Hardware
tab,
5
Setting up Your Monitor
Windows® 95
To determine the version of Windows®Windows 95 that your computer uses, right click on
the
My Computer
can be seen on the
according to the version of your Windows
Version 4.00.950A
Click on
1
CHANGE DISPLAY TYPE, CHANGE, HAVE DISK
Type the diskette drive letter in the box and click OK.
2
Version 4.00.950B
Click on
1
PROPERTIES, MONITOR
Type the diskette letter in the box and click OK.
2
Self-Test Feature Check (STFC)
Your monitor provides a self test feature that allows you to check whether your monitor is
functioning properly. If your monitor and computer are properly connected but the monitor
screen remains dark and the power indicator is blinking, run the monitor self-test by
performing the following steps:
icon on the Windows desktop and select
General
START, SETTINGS, CONTROL PANEL, DISPLAY SETTINGS
START, SETTINGS, CONTROL PANEL, DISPLAY, ADVANCED
section under System:. Follow the directions given below
tab,
®
95 operating system:
HAVE DISK
.
Properties
.
. The version number
tab,
Turn off both your computer and the monitor.
1
Unplug the video cable from the back of the computer.
2
Turn on the monitor.
3
If the monitor is functioning properly, you will see a white box with a red border and black
text inside as shown in the following illustration:
6
Setting up Your Monitor
No Connection
Check Signal Cable
Figure 2. Monitor self test screen
The three boxes inside the border are red, green and blue. Failure of any of the boxes to
appear indicates a problem with your monitor. This box also appears during normal operation
if the video cable becomes disconnected or damaged.
Turn off your monitor and reconnect the video cable; then turn on both your computer
4
and the monitor.
If your monitor screen remains blank after using the previous procedure, check your video
controller and computer system; your monitor is functioning properly.
Getting Help
English
If your monitor does not display an image, check your cable connections and refer to
Troubleshooting on page 23.
Warm-up Time
All monitors need time to become thermally stable the first time you turn them on each day.
Therefore, to achieve more accurate adjustments for parameters, allow the monitor to warm
(be on) for at least 30 minutes before making any screen adjustments.
7
Adjusting Your Monitor
User Controls
Your samsung SyncMaster computer monitor allows you to easily adjust the characteristics
of the image being displayed. All of these adjustments are made using the control buttons on
the front of the monitor. These buttons operate the on-screen menu, which shows you the
monitors settings and allows you to change those settings.
i
3 421
Figure 3. User control locations
Information ( ) button
1
Use this button to show the horizontal and vertical frequencies and the resolution
received from your computer or video board.
EXIT ( ) button
2
Use this button to Exit the active menu or the OSD.
3
4
5
6
,,,buttons
These buttons allow you to highlight and adjust items in the menu. All menus
automatically save your adjustments 3 seconds after you stop adjusting the setting.
MENU ( ) button
Use this button to open the OSD and activate a highlighted menu item.
Brightness
This rotary control adjusts the overall brightness of the display image. Rotate the
control to the left to increase the level of brightness, or to the right to decrease the
brightness.
Contrast
This rotary control adjusts the monitors contrast. Rotate the rotary control to the left
to increase the contrast between dark colors and light colors, or move it to the right to
decrease the contrast.
i
5 6
8
7
8
Loading...
