T R A N S L A T I O N
Declaration of Conformity as per Directive 2014/68/EU
The manufacturer
Pfeiffer Chemie-Armaturenbau GmbH, 47906 Kempen, Germany
PTFE-lined shut-off butterfly valves
•
• with lever for 90° operation
1. The valves are pressure accessories within the meaning of the Pressure Equipment Directive 2014/68/EU
(See section 2.3 for butterfly valves intended for dead-end service)
Applied standards:
EN 593
AD2000 Regulations
Product standard for butterfly valves
Regulations for pressurized valve body parts
Type designation and technical features:
TB10a
TB10e>
Applied conformity assessment procedure:
Conforming to Annex III of the Pressure Equipment Directive 2014/68/EU, Module H
Name of notified body:
Identification number of the notified body:
TÜV Rheinland Service GmbH
Germany
Kempen, 28. November 2017
Marcus Miertz, Chief Executive Officer
Stefan Czayka, IMS Representative
declares that:
and conform with the requirements of this Directive,
2. They may only be operated observing the operating instru cti o ns <BA10a-01> delivered together with the
valve.
Pfeiffer data sheets <
NOTE: This Manufacturer’s Declaration applies to all valve types listed in this catalogue.
BR 10a and BR 10e, with PTFE liner and shaft packing
with worm gear and handewheel
and
Am Grauen Stein
51101 Köln
These Declarations become invalid when modifications are made to the shut-off butterfly valves and/or assemblies that affect
the technical data of the shut-off butterfly valve or the <Intended use> described in section 1 of the operating instructions, and
considerably change the valve or an assembly delivered with it.
1 of 9
November 2017 Operating instructions BA 10a-02_
0035
Specifications subject without notice
Edition:
EN
Operating instructions
Shut-off butterfly valve with PTFE lining
manually operated
Contents
0. Introduction 3
1. Intended use 3
2. Safety instructions 3
2.1 General safety instructions 3
2.2 Safety instructions for the operator 3
2.3 Particular hazards 4
2.4 Designation of the shut-off butterfly valve 5
3. Transport and storage 5
4. Installation in the pipeline 6
4.1 General 6
4.2 Installation instructions 6
5. Pressure check in pipeline section 7
6. Standard operation and maintenance 8
7. Troubleshooting 8
8. Further information 9
2 of 9
November 2017 Operating instructions BA 10a-02_
Specifications subject without notice
Edition
EN
Note
Do not operate a shut-off butte r fly valve when its permissible pressure/temperature rating is not sized for the
installed in the pipeline.
Pfeiffer valves do not have their own potential ignition source according to the risk assessment in the rare incident
Relating to this directive, CE marking is not permissible. The integration of valves into the equipotential bonding of
DIN EN 13463-1.
0. Introduction
These instructions are designed to assist the user during installation, operation and maintenance of shut-off butterfly valves with
PTFE lining from the BR10a and BR10e.
The WARNING and CAUTION notes must be strictly adhered to. Otherwise this may lead to personal injury and
equipment damage and the manufacturer’s warranty may become void.
Please contact the manufacturer if you have any queries, see section 8 for contact address.
1. Intended use
After installing the valve in the pipeline and connecting the actuator to the control equipment, these shut-off butterfly valves are
designed exclusively for shutting off or controlling media (often corrosive) within the permissible pressure and temperature
ranges.
The permissible pressure and temperature ranges for these shut-off butterfly valves are specified in the data sheets <TB10a or
TB10e>.
operating conditions specified in the data sheets <TB10a or TB10e>.
Danger
Observation of conformity with the Directive 2014/34/EU:
Failure to follow these safety precautions may result in personal injury and can damage equipment
of an operating fault in accordance with DIN EN 13463-1 and therefore do not fall within the scope of the Directive
2014/34/EU.
a plant applies to all metallic parts in hazardous areas regardles s of the directiv e.
Note
Valves with plastic lining (PFA, PTFE) in applications with chargeable media have to be lined with conductive
plastic lining with a surface resistance less than 1 Gigaohm (10
9
Ohm) in accordance with paragraph 6.7.5a of
Refer to the limitations in the above mentioned data sheets if the shut-off butterfly valve is intended for throttling services.
Parts subject to wear are not covered by the warranty.
Observance of section 2 <Safety instructions> is presumed for the Intended use.
2. Safety instructions
2.1 General safety instructions
For shut-off butterfly valves, the same safety regulations apply as for the pipelines in which they are installed. These instructions
only specify those safety instructions which need to be additionally observed concerning shut-off butterfly valves.
2.2 Safety instructions for the operator
The manufacturer does not assume any responsibility. Therefore, on using the shut-off butterfly valve, make sure the following
instructions are observed:
The valve is to be used only for its intended use as described in section 1.
3 of 9
: November 2017 Operating instructions BA 10a-02_
Specifications subject without notice
Edition:
EN
Preventing misuse of the shut-off butterfly valve:
installed in the pipeline. The manufacturer does not assume any final responsibility.
The valve should only be operated and serviced by personnel appropriately qualified for pressurized pipelines:
assigned to them and are able to recognize possible dangers.
We recommend to open and close the valve regularly. Depending on the valve model, we recommend opening
considerably than those specified in the data sheet.
Attention
90°. Turning the butterfly valv e
Danger
Should it be necessary to remove a shut-off butterfly valve from the pipeline, process medium may escape from
Take special care concerning any remaining media that may still be in the pipeline or have collected in the cavities
of the valve.
Warning
For shut-off butterfly valves intended for dead-end service:
operation.
Warning
It is especially important to make sure that the selected lining for wetted parts in the shut-off butterfly valve is
suitable for the media used as well as the prevailing pressures and temperatures.
Warning
Danger
A gear mounted subsequently onto the valv e mus t fit the shut-off butterfly valve properly and its final positions, especially
the open position, need to be correctly adjusted.
Make sure that the pipeline and control equipment have been installed correctly and are checked at regular intervals. The
valve body wall thickness must be designed to take into account an additional load Fz in the usual order
(Fz = π/4•DN²•PS) for a correctly sized pipeline.
The valve needs to be connected correctly to the pipeline and to the control equipment.
Make sure the usual flow velocities are not exceeded in continuous service in this pipeline. Exceptio nal operating
conditions such as oscillations, w ater hammeri ng, cav itation and large proportions of solid matter in the proc es s medium,
especially abrasive, must be clarified beforehand with the manufacturer.
Warning
Failure to follow these safety precautions may result in personal injury and can damage equipment
Skilled staff in the sense of these operating instructions is persons who, as a result of their training, their
knowledge and their experience, as well as their knowledge of the relevant standards, are able to judge the tasks
and closing the valve at least once a year.
Depending on how long the valve remains in one position, breakaway and operating torques may differ
For double eccentric valves:
Make sure, that the butterfly disc is always operated within a range of between 0° over 0° leads to irreparable damage to the sealing ring e.g. sealing strip, this must therefore be avoided.
Shut-off butterfly valves that are operated at temperatures greater than +50°C or lower than -20°C must be protecte d,
together with the pipeline connections, against being touched.
2.3 Particular hazards
Prior to unscrewing the bonnet or removing the shut-off butterfly valve from the pipeline, relieve pressure entirely
in the pipeline to ensure the process medium cannot escape uncontrollably from the pipeline.
the pipe or out of the shut-off butterfly valve. In the case of process media that can damage health or are
dangerous, drain the pipeline completely before removing the shut-off butterfly valve from the pipeline.
Warning
Warning
Only unscrew or loosen any screws or bolts connecting the body parts after the valve has been removed from the
pipeline. Tighten the screws on reassembly with a torque wrench according to repair instructions <EB10a or
EB10e>.
During standard operation, in particular, with gases or hot and/or dangerous media, mount a blank flange at the
free end connection or ensure that the shut-off butterfly valve is properly protected against unauthorized
If a shut-off butterfly valve used for dead-end service must be opened in a pressurized pipeline, special care must
be taken to ensure that any process media escaping under pressure do not cause any damage.
Take into consideration that in most cases the process medium is a dangerous substance!
4 of 9
November 2017 Operating instructions BA 10a-02_
Specifications subject without notice
Edition
EN
Details
Designation
Comments
Manufacturer
Pfeiffer
Address see section 8 <Information>
Valve type
BR (and number)
e.g. BR 10a = BR 10a, see Pfeiffer catalogue
Body material
e.g.: EN-JS 1049
Material number acc. to DIN EN 1563 (formerly GGG 40.3)
Size
DN (and number)
Value in mm, e.g. DN100
Maximum pressure
PN (and number)
Value in bar at room temperature
Perm. temperature
TS (and number)
PS and TS are associated values at maximum permissible operating
temperature and maximum permissible operating pressure.
Perm. pressure
PS (and number)
27
1234
/001
/001
Valve No. into the Item
Item in Commission
Commission
year of manufacture (e.g. 27=2017)
207
0153
/001
/001
Valve No. into the Item
Item in Commission
Commission
year of manufacture (e.g. 207=2007)
On request of customer the year of manufacture is stamped on the
valve.
Conformity
CE
Conformity is certified separately by the manufacturer
Identification no.
0035
Notified body as per EU Directive = TÜV Anlagentechnik GmbH
Direction of flow
Note: see note in section 4.2 <Installation instructions>
Warning
2.4 Designation of the shut-off butterfly valve
The designation of the shut-off butterfly valve includes the following details:
Serial no.
2009 onwards
Serial no.
up to 2008
Year of manufacture
Table 1 – Designation of the butterfly valve
e.g.: 211234/001/001
e.g.: 2070153/001/001
e.g.: 2017
Keep the labeling on the valve body and on the nameplate to ensure that the valve can be identified at all times.
3. Transport and storage
Shut-off butterfly valves with lining s must be caref ully hand le d, tran spor ted and stored:
Store the valve with its protective packing and/or with its protective caps in place in the end connections. Store and
transport the shut-off butterfly valves that weigh over approx. 10 kg on pallets (or a similar type of support) right up to the
point of installation. The packing is designed to protect the valve’s plastic lining, that is prone to scratching, against being
damaged.
Store the valve in a closed room before it is installed. Protect it against damaging influences such as dirt or moisture.
Make sure, in particular, that the plastic-lined facings of the flanges intended to connect the valve to the pipeline are not
damaged through mechanical or other influe nce s. Do not sta ck shut-off butterfly valves!
As a rule, shut-off butterfly valves of the BR10a series and shut-off butterfly valves of the BR 10e series in the slightly open
position. Store the valves in the condition they were delivered in. Do not operate the valve.
Valves delivered without a lever/gear:
The butterfly disc is not safeguarded against alteration of its position. Do not allow the disc to be opened from the
closed position by external influences (e.g. shock, vibrations).
5 of 9
: November 2017 Operating instructions BA 10a-02_
Specifications subject without notice
Edition:
EN
Caution
Note
Note
In exceptional cases, when a valve is installed into a pipeline without an actuator unit mounted, make sure that
installed in the pipeline.
Warning
Warning
Note
tallation. Remove packaging first at the point
Do not install a shut-off butterfly valve if its permissible pressure/temperature ranges do not apply to the operating
installed in the pipeline.
4. Installation in the pipeline
4.1 General
The same instructions apply for installing the shut-off butterfly valves in the pipeline as for connecting pipes and similar pipeline
equipment. The following instructions additionally apply for shut-off butterfly valves. Also observe section 3 for transporting the
shut-off butterfly valve to the point of installation.
The valve is lined with PTFE:
Handle with special care and follow the instructions for flange connection.
The facings of the valve body are lined with plastic:
If additional flange gaskets are used, we recommend using gaskets made of PTFE.
The mating flanges must have smooth facings. Contact the manufacturer if you intend to use other flange forms.
The actuating device is set for the operating data specified in the order:
Do not alter the settings for the final positions OPEN and CLOSED without the manufact ur er’s prior con se nt.
pressure is not applied to these valves.
If an actuator unit has been mounted subsequently, torque, direction of rotation, operating angle as well as the
Danger
final positions OPEN and CLOSED must be adapted to the shut-off butterfly valve.
Failure to follow these safety precautions may result in personal injury and can damage equipment
The following warnings are to be observed for gears:
Gears are not designed to be used as step-ladders:
Do not apply any weight/load to the gears. This can damage or destroy the shut-off butterfly valve.
Gears that weigh more than the shut-off butterfl y valve:
Support any gears which due to its size and/or mounting situation would otherwise cause the valve to bend under
the load.
4.2 Installation instructions
Lined surfaces of the valve must be specially protected before/during installation:
Transport the valve in its original packaging right up to the point of ins
of installation.
Check valve and gear for signs of damage that may have occurred during transportation. Do not install a damaged shut-off
butterfly valve.
Prior to installation, carry out a function check. The valve must open and close properly. Any function errors that are
recognized must be remedied before commis sio ning . See als o secti on 7 <T rouble sho otin g>.
Make sure that only shut-off butterfly valves are installed when their pressure rating, end connections and fac e to face
dimensions match the conditions of application. See the designation of the shut-off butterfly valve.
conditions. The limits of application are marked on the valve, see section 2.4 <Designation>. The permissible
range is determined in section 1 <Intended use>.
Danger
Failure to follow these safety precautions may result in personal injury and can damage equipment
Make sure the end connections of the pipeline are aligned with the shut-off butterfly valve’s end connections and their ends
have parallel planes. Connecting flanges that are not parallel can damage the PTFE lining during installation!
6 of 9
November 2017 Operating instructions BA 10a-02_
Specifications subject without notice
Edition
EN
Note
Note
BR10a
- - -
76,5 - 126
175
222
274
326
366
465
573
763
BR10e
45
45
62
86
116
140
187
238
282 - 390 - -
-
Note
Caution
the
DN [mm]
50
65
80
100
125
150
200
250
300
350
400
500
600
800
MA [Nm]
45
45
65
75
55
140
170
140
170
170
240
240
310
480
DN [Zoll]
3“
4“
6“
8“
10“
12“
14“
16“
20“
24“
32“
MA [Nm]
65
50
100
150
140
160
160
230
240
300
470
Warning
Prior to installation, carefully clean the valve and the connecting section of the pipeline from dirt, especially hard foreign
material.
Make sure, in particular, that flange facings and any flange gaskets used are free from any dirt prior to installation.
The valve must be inserted in the gap between the pipe flanges with the butterfly disc in the closed position.
Otherwise, the butterfly disc could be damaged and the valve will not shut tightly.
The inside diameter of the mating flanges must leave sufficient room for the
opened butterfly disc to ensure that it cannot be damaged on swinging out. See
Table 2.
DN 50 65 80 100 125 150 200 250 300 350 400 500 600 800
Di
Table 2 - Minimum required inside diameter of the mating flanges
The process medium can flow through the valve in either direction. The preferable mounting position for shut-off butterfly
valves is with a shaft in a horizontal position. However, if possible, the gear should not be located directly underneath the
shut-off butterfly valve.
Make sure the arrow on the valve body corresponds with the direction of flow in the pipeline.
In special cases, it may be necessary for the valve to be tightly shut against the direction of flow. The installation
in such special cases must be determined by the operator of the pipeline (e.g. to protect a pump).
On inserting the valve (and flange gaskets) into a ready mounted pipeline, keep a certain clearance between the pipeline
ends to ensure that all facings (and gaskets) remain undamaged.
Tighten the flange bolts evenly and in a criss-cross pattern in at least three steps. Tighten all flange bolts using
torques specified in Tables 2 or 3.
Use a torque wrench to ensure that the torque specified is reached, yet not exceeded.
Table 3 – Flange torques for DIN-Flanges
Table 4 – Flange torques for ANSI-Flanges
Since PTFE plastic facings have a tendency to creep, we strongly recommend after installation to retighten the
bolted joint of the valve body using the tightening torques in Table 2 if the valves have been in storage for a long
time.
5. Pressure check in pipeline section
The pressure check of valves has already been carried out by the manufacturer. To check the pressure of a section of pipeline
with installed valves, the following point s mus t be observ ed:
7 of 9
: November 2017 Operating instructions BA 10a-02_
Specifications subject without notice
Edition:
EN
Note
Shut-off butterfly valves with lever:
Lever parallel to the pipeline: Valve OPEN.
Shut-off butterfly valves with lever:
personal injury and can damage equipment installed in the pipeline.
Warning
Type of fault
Action to be taken
Comment
Tighten flange bolts.
associated flange gasket.
Carefully flush newly installed pipes to remove any foreign material.
Valve OPEN: The test pressure should not exceed the value 1.5 x PN (see nameplate).
Valve CLOSED: The test pressure should not exceed the value 1.1 x PN (see nam epl ate) .
If a valve leaks, see section 7 <Troubleshooting>.
6. Standard operation and maintenance
Due to the fact of flowing plastic flange facings we strongly recommend to check flange bolt torques acc. to specified
figures in section 4.2 after commissioning and normal operation temperature has been reached.
The shaft is sealed with a V-ring packing preloaded with a set of spring washers and does not require any maintenance.
Normal manual force is sufficient to operate the manual override on the actuator (if required). It is not permissible to use
extensions to increase the operating torque.
The position of the lever indicates the valve’s position:
Lever at a 90° angle to the pipeline: Valve CLOSED,
Do not open and close the valve with sudden movements, but quick enough to prevent pressure surges and/or
temperature shocks occurring in the pipeline. Failure to follow these safety precautions may result in
Danger
Regular maintenance work on the shut-off butterfly valves is not necessary.
The shut-off butterfly valve from the BR10e Series with an additional packing can be fitted with a leak-off connection
If a valve leaks, proceed as described in section 7 <Troubleshooting>.
(e.g. ¼“) at the valve neck, on request. This allows you to check whether the packing is leaking.
7. Troubleshooting
Observe the safety instructions listed in section 2 on troubleshooting.
To remove a valve from a pipeline containing dangerous media and to take it out of the plant:
Decontaminate the valves properly first.
Caution:
The permissible tightening torque of the flange bolts is restricted. See table 3
or 4 in section 4.2 <Installation instructions>.
If the medium leaks out at the flanges of the lined valve:
Leak at the
connection to the
pipeline
8 of 9
Retighten the flange bolts using the torque specified in Table 2 or 3 in section 4.2
<Installation instructions>. If necessary, the torque may be increased by
max. 20 %.
If the medium leaks out at the flanges even after tightening the flange bolts:
Unscrew the flange bolts and remove the valve (on doing so, observe the instructions in
section 2.3 <Particular hazards>).
Check the parallel planes of the flanges and, if necessary, correct them. Also check the
facing of all the flanges. If the plastic lining is damaged, replace it together with the
Note 1:
When ordering spare parts,
include all the specifications
listed in the valve
designation. Only use
original parts from Pfeiffer.
Note 2:
If, after removing the valve
from the pipeline, it is found
that the PTFE/PFA lining is
not sufficiently resistant to
the process medium, select
parts made of a suitable
material.
For further help see next Page
November 2017 Operating instructions BA 10a-02_
Specifications subject without notice
Edition
EN
Type of fault
Action to be taken
Comment
Check whether the actuator closes completely the valve.
for spare parts and necessary instructions.
Note 1:
material.
If it must be repaired, replace the shaft, observing section 2.3 <Particular hazards>.
Contact Pfeiffer for spare parts and necessary instructions.
600633 / PDF=285
When ordering spare parts,
include all the specifications
listed in the valve
designation. Only use
original parts from Pfeiffer.
Note 2:
If, after removing the valve
from the pipeline, it is found
that the PTFE/PFA lining is
not sufficiently resistant to
the process medium, select
parts made of a suitable
Leak at the seat
seal
Leak at the shaft
Malfunction
If the shut-off butterfly valve has been closed under the full torque:
Open and close the valve under a pressure drop several times.
If the valve still leaks:
If it is must be repaired, replace the plastic lining of the valve body and/or butterfly disc,
observing observe the instructions in section 2.3 <Particular hazards>). Contact Pfeiffer
If the valve is damaged:
If it must be repaired, remove the valve, observing section 2.3 <Particular hazards>.
Contact Pfeiffer for spare parts and necessary instructions.
8. Further information
Contact the address below for the listed <Data sheets> and <Repair instructions> as well as further information.
Pfeiffer Chemie-Armaturenbau GmbH
Hooghe Weg 41 • 47906 Kempen • Germany
Phone: +49 21 52 20 05 - 0 • Fax: +49 21 52 15 80
E-mail: vertrieb@pfeiffer-armaturen.com • Internet: www.pfeiffer-armaturen.com
9 of 9
: November 2017 Operating instructions BA 10a-02_
Loading...
