Salus RT310i Installation Manual

Model: RT310i

Smartphone Controlled Thermostat

Installation Manual

Contents

Product Compliance ................................................................................................ 3

Safety Information .................................................................................................... 3

Introduction .................................................................................................................. 4

Overview ........................................................................................................................ 5

Box contents ................................................................................................................. 5

Features ........................................................................................................................... 5

Connecting the RXRT510 receiver .................................................................. 6

Installation ..................................................................................................................... 6

RT310i thermostat ..................................................................................................... 7

Connecting the iTG310 Gateway .................................................................... 7

Test Pairing Function ............................................................................................... 7

Registration ................................................................................................................... 8

Button functions and keys ................................................................................... 9

LCD and App icons ................................................................................................... 10

Operations ..................................................................................................................... 11

Temperature, clock, time format ...................................................................... 11

Heat/Cool Mode ........................................................................................................ 12

Setting schedules ...................................................................................................... 14

Temporary or Permanent Override program mode ............................ 15

Frost Protection ........................................................................................................... 16

Holiday Mode .............................................................................................................. 17

Distance alerts ............................................................................................................. 17

Other functions .......................................................................................................... 18

LCD backlight .............................................................................................................. 18

Low battery detection ............................................................................................ 18

Temperatures outside operating range ...................................................... 18

Operating in Offline Mode .................................................................................. 19

Reviewing Setpoint Temperature via device ........................................... 19

Adjusting setpoint via device ............................................................................ 19

Factory reset ................................................................................................................. 20

Technical info ............................................................................................................... 21

Warranty ......................................................................................................................... 22

02 RT310i Installation Manual

Product Compliance

This product complies with the essential requirements and other relevant provisions of the following EU
Directives: 2014/30/EU, 2014/35/EU, 2014/53/EU and 2011/65/EU. The full text of the EU Declaration of
Conformity is available at the following internet address: www.saluslegal.com.

Safety Information

Use in accordance with the EU and national regulations. For indoor use only. Keep your device completely dry.
This product must be installed by a competent person and in accordance with all the EU and national regulations.

Always isolate the AC Mains supply before installing or working on any components that
require 230 VAC 50Hz supply.

RT310i Installation Manual 03

Introduction

A room thermostat simply switches the heating system on and off as necessary. It works by sensing the air
temperature, switching on the heating when the air temperature falls below the thermostat setting, and
switching it off once this set temperature has been reached.

The SALUS RT310i is a Smart phone controlled programmable thermostat. The RT310i thermostat will switch
your heating system on or off, as needed, in accordance with the temperature set by you, locally on the device
or remotely using the dedicated app.

Turning a room thermostat to a higher setting will not make the room heat up any faster. How quickly the room
heats up depends on the design of the heating system, for example, the size of boiler and radiators. Neither
does the setting affect how quickly the room cools down. Turning a room thermostat to a lower setting will
result in the room being controlled at a lower temperature, and saves energy.

The heating system will not work if a time switch or programmer has switched it off.

The way to set and use your room thermostat is to find the lowest temperature setting that you are comfortable
with, and then leave it alone to do its job. The best way to do this is to set the room thermostat to a low
temperature – say 18⁰C – and then turn it up by one degree each day until you are comfortable with the
temperature.

Room thermostats need a free flow of air to sense the temperature, so they must not be covered by curtains
or blocked by furniture. Nearby electric fires, televisions, wall or table lamps may prevent the thermostat from
working properly.

04 RT310i Installation Manual

Overview

Head Oce

SALUS Controls plc

SALUS House

Dodworth Business Park South,

Whinby Road,

Dodworth, Barnsley S75 3SP, UK.

T: [phone]

E: [e-mail]

DE / NL / FR:

[e-mail]

tel: [phone]

DK: [e-mail]

Tel: [phone]

UK: [e-mail]

tel: [phone]

For PDF Installation guide please go to

www.salus-controls.com

SALUS Controls is a member of the Computime Group

Maintaining a policy of continuous product development SALUS Controls plc reserve the right to

change specification, design and materials of products listed in this brochure without prior notice.

ON

AUTO

OFF

MANUAL

TEST/PAIRING TEST/PAIRING

The RT310i is a stylish thermostat with easy readable LCD and a user-friendly interface. The Receiver is used
for wiring connections and heat on/off control. The thermostat provides the user interface and temperature
sensing / control. The two units are linked together by a Radio Frequency (RF) signal. The Gateway has a
futuristic design and helps connect your devices to the Internet, so that they can be controlled over the
RT310i App on your smart-phone.

Box contents

RT310 thermostat 4x screws and plugs

iTG310

RXRT510 receiver

ADSL Cable Quick Guide

Features

• Remote control via App

• 5/2 days or 24hrs programming flexibility via App

• Built-in start up programming for quick installation

• Frost protection

• Eco Mode

• Holiday Mode

• Large, easy to read LCD with blue backlight

• User friendly

• Stylish casing

• Geo Location

• Pre-paired from Factory

• RF Test Mode

Gateway Adaptor suitable

for UK and EU

2xAA batteries

RT310i Smartphone Controlled
Programmable Thermostat

Quick Guide

RT310i Installation Manual 05

Connecting the RXRT510 receiver

Unscrew the backplate of the RXRT510 receiver in order to do the wiring connections. After that please switch
the receiver ON.

COMNO L N

ON

AUTO

OFF

MANUAL

Terminal Description Receiver Terminals

NO

COM

L

N

Wiring

Switch Terminal

Common Switch
Terminal

COMNO L N

Mains Live (230VAC)

Mains Neutral

Electrical diagram

NO COM L N

L N

Wall mounting

Fix the backplate to the wall Align the front housing

06 RT310i Installation Manual

at the top edge.

Fit the front housing.

Press lightly

RT310i thermostat

Before inserting the batteries, please make a note of your SRT number and register your device on the App.

1 2

SRT00000000 - 00

S R T

Connecting the iTG310 Gateway

Plug in your gateway and attach the Ethernet cable and plug in into your router. The Led on the gateway will
flash red 3 times, then it should be steady green.

Gateway is ready

for pairing

Test Pairing Function

Press the button once to test the connection between the thermostat and the receiver. If the devices are paired
the ON and AUTO LEDs will both flash. You can wait 9 minutes for the process to end or can press the button
again to stop.

TEST/PAIRING

TEST/PAIRING TEST/PAIRING

TEST/PAIRING

ON

AUTO

ON

AUTO

OFF

MANUAL

OFF

MANUAL

RT310i Installation Manual 07

Registration

Download the RT310i App and create
an account to start controlling your
thermostat via the App. Please follow
the steps below.

1

Tap register to create

a new account

6

2 3 4 5

Enter email and

password, tap Next

Enter the code you

received via email

Enter name and

address and tap Next

code. Read and accept

the terms. Tap Submit

7 8 9

Enter the SRT device

Your device appears

on the screen. Tap Edit

to rename it.

Name the device

When the thermostat is connected to the App, the icon will appear on the App screen and the icon
will appear on the thermostat screen. Also, the hand icon will show on the thermostat LCD.

08 RT310i Installation Manual

and tap Save

Tap anywhere on

tile to enter the

thermostat interface

Thermostat interface in

schedule mode

Button functions and keys

There are few user controls for the RT310i, making this thermostat very easy to operate. These controls are
shown below, along with a description of each of their functions. The temperature displayed on the LCD is the
current room temperature. All the buttons on the thermostat and receiver with a description are shown below.

Thermostat

Key Function

Turn on the LCD backlight

Turn On/Off the Frost Mode

Press to increase setpoint temperature, press and hold
to enter fast advance.

Press to decrease setpoint temperature, press and hold
to enter fast advance.

1. Press once to enter/exit in RF Test Mode

2. Press for 3 seconds to enter/exit Pairing Mode

Receiver

AUTO

Key/LED Function
AUTO System receiver output will switch on and off in

relation to the command from the RT310i transmitter.

Manual System receiver output is controlled by the On/Off

slide switch.

ON When in Manual Mode, ON will turn on the boiler.

ON

OFF

MANUAL

OFF When in Manual Mode, OFF will turn off the boiler.

Red Led Receiver On, paired.

Green Led Command from thermostat received.

RT310i Installation Manual 09

LCD and App icons

Heating Mode On

Cooling Mode On

ON when thermostat is connected
to the ITG310 gateway

Frost Protection On

Schedule Mode On

Thermostat name

Manual Override
(Permanent/Temporary override)

ON when battery is weak
before battery life end

ON during RF signal
transmission to RX boiler

Holiday Mode On

Temperature display

Menu button

Temperature increase/decrease

RF Signal Strength

Schedule/Manual Mode

10 RT310i Installation Manual

Setpoint temperature

Heating/Cooling Mode

Room temperature

Frost Protection Mode

Operations

Temperature, clock, time format

When you first enter the application, your home screen will display the
room temperature, the set temperature (it will operate based on the default
set schedule). the thermostat will be operating in schedule mode. You
can easily control your thermostat using the application. By default, the
thermostat operates in heating mode, that’s why you will have the flame
icon on the screen. You can now start setting the time zone, changing
modes, and adding schedules

Features available only on the App:

- Temperature format

- Clock format

- Time zone

- Schedule/Manual/Off Mode

- Holiday Mode

- Frost Mode*

- Daylight Saving Time

- Heating or Cooling Mode

* Also available on the device

Note: Time and date will be automatically added once you connected to the internet, based on your
geo-location. What you have to do manually, though, is to select your temperature format, clock format and
time zone. This can be easily done by following these steps:

1

2 33

4

Tap menu icon Go to settings Select temperature

5 6 7

Select time zone

Select clock format

format

After you adjust all
of your settings, tap
Save. The app will
then return to the
home screen where
you can start adding
programs.

DST on/off Tap Save

RT310i Installation Manual 11

Heat/Cool Mode

You can ONLY shuffle between heat/cool mode from the App. If you want to choose a temperature that is
higher than the current room temperature, make sure the thermostat is running in heat mode. If you want to
set a temperature that is lower than the current room temperature, make sure you switch to cool mode.

Changing to Cool Mode

1

2 3 4

Tap menu icon Go to settings Select Cool Mode

5 6

Tap Save

Using the cursor, set the

temperature

ON

OFF

AUTO

MANUAL

TESTING/PAIRING

The antenna icon appears

on the LCD - command

received

The frost icon will turn

blue and animated

meaning thermostat

is calling for cooling.

The cool mode icon

will appear on the LCD,

meaning thermostat is

calling for cooling.

After the thermostat is calling for cooling, the green light on the RXRT510 receiver
will go on steady green.

12 RT310i Installation Manual

Changing to Heat Mode

1

2 3

Tap menu icon Go to settings Select Heat Mode

5

6

4

Tap Save

Using the cursor, set

the temperature

TESTING/PAIRING

The antenna icon appears

on the LCD - command

received

The Flame icon will

turn orange and

animated meaning

the thermostat

The heat mode icon

will appear on the LCD,

meaning thermostat

is calling for heat.

TESTING/PAIRING

is calling for heat.

After the thermostat is calling for heat, the green light on the RXRT510 receiver will
go on steady green.

ON

OFF

AUTO

MANUAL

Note: You can ONLY shuffle between heat/cool mode from the App. When the Internet connection is lost
and the thermostat is not communicating to the gateway and App it switches to Local mode. RT310i can still
run temperature control, auto program, manual override, and control RXRT510 directly. You can still change
the setpoint directly from the thermostat, by pressing the or keys directly from the thermostat.

RT310i Installation Manual 13

Setting schedules

You can switch from Manual Mode to Schedule Mode and start adjusting programs. That’s very easy to do
and you need to follow the next steps. Note that there are 3 types of scheduling available, with 6 time intervals per day.

• 5+2 (Mon-Fri same, Sat-Sun same)

• Each day individual

• All week the same

1

2

3

3a

3b

Tap schedule

Tap Arrow

Select Type: 5+2 All/Individual

5 6 7 8 9

4

Tap first interval

Adjust time Follow the same procedure

Adjust temperature Tap Save Tap next time interval.

You need to follow the same steps for all intervals and all days in order to set schedules for the weekend days. Also, you
can copy the schedules from one day to another, which comes very handy if you are setting your days individually. Please
see below to see how to copy the schedules from one day to another.

1

Select day Tap Copy

2

3

Selected day will be

marked with blue. Tap

the day you want to

paste into

3a

Tap Paste

4

Schedule is saved

14 RT310i Installation Manual

Temporary or Permanent Override program mode

Temporary Override

Normally thermostat is running in schedule mode.
Manual and schedule mode can only be changed in the App
In schedule mode , pressing UP or DOWN on the thermostat changes setpoint. This is Temporary Override.
You can also change the temperature directly from the App.
During Temporary Override, manually override setpoint will expire by next program P1-P6
During Temporary Override, Calendar & HAND icons are turned ON.

Via App Via device

TESTING/PAIRING

TESTING/PAIRING

Temporary override mode Temporary override mode

Permanent Override

In manual mode, pressing UP or DOWN changes setpoint. This is Permanent Override.
You can also change the temperature directly from the App.
During Permanent Override, manually override setpoint will run forever, until schedule model is selected from
App again, or another temperature is set.
During Permanent Override, HAND icon is turned ON

Via deviceVia App

Permanent override mode

TESTING/PAIRING

Permanent override mode

RT310i Installation Manual 15

TESTING/PAIRING

Frost Protection

Press FROST button to activate Frost Protection.
The Setpoint temperature is automatically set to frost setpoint to prevent pipes from frosting. If the room
temperature is lower than the frost setpoint, frost protection will be enabled.
Press FROST button again to de-activate Frost Protection.

Frost Protection ON Frost Protection OFF

TESTING/PAIRINGTESTING/PAIRING

Actual room temperature Actual room temperature

Frost Mode activated

Via App

Frost Protection ON Frost Protection OFF

1 1

Tap menu icon

2

Go to settings

Select temperature

format

TESTING/PAIRINGTESTING/PAIRING

Frost Mode deactivated

2

Select clock format

Frost Protection Setpoint

You can adjust the Frost Protection setpoint using the App. The setpoint range is between 5-9 ⁰C

1

Tap menu icon

2 3 4

Go to Frost Protection

16 RT310i Installation Manual

Adjust temperature

Default 5⁰C

Tap Save

Holiday Mode

You can set your RT310i to holiday mode. Thermostat will be turned OFF during this mode and no commands
will be sent to the heating unit. During this mode, the thermostat will run like in Frost Protection Mode. When
activated, an airplane icon appears on the display of your device You can set Holiday mode from the App
only. It can be set for maximum 31 days.

1

Tap menu icon

2 3 4

Go to Holiday Mode

Enter holiday dates

Tap Save

Distance Alerts

You can set your RT310i to notify you whenever you are a certain distance away from your home.

1

2 3 4

Tap menu icon

Go to Distance Alerts

You can also choose to deactivate Distance Alerts in one easy step.

Choose miles/km and

set a distance

Tap Save

RT310i Installation Manual 17

Other functions

LCD backlight

• LCD backlight is activated when or any key is pressed. The backlight will be turned off in 15 seconds
after all keys are released.

• LCD backlight will not operate when battery is low.

Low battery detection

Battery voltage is checked every minute. When the battery voltage drops to a certain level, the Low-Battery
warning indicator appears.

• The thermostat functions normally during low battery. However, user must change the batteries as soon
as possible before the battery is too weak for the normal operation to be assured.

• When you change the batteries, you have about 30 seconds to to do so without losing your settings.

Temperatures outside operating range

Temperatures below 10 °C are displayed without the leading ‘0’. Temperatures exceeding the measurable range
will be indicated by ‘HI’ for temperatures above the upper limit, and ‘LO’ for temperatures below the lower limit,
as shown in the images.

18 RT310i Installation Manual

Operating in O-line Mode

If the Internet connection is lost and the thermostat is not communicating with the App or with the gateway,
it can still be operable in off-line mode. When in off-line mode:

• The thermostat will follow the last set schedule

• Setpoint can be changed and reviewed via device

Reviewing Setpoint Temperature via device

Press or to review Setpoint temperature. The flame icon won’t be turned on.

TESTING/PAIRINGTESTING/PAIRING

Actual room temperature Setpoint temperature

When operating in Frost protection mode, the LCD will show frost setpoint with the Frost Protection
indicator displayed.

Press Backlight or wait 2 seconds without key press to return to normal operation, room temperature will be
displayed.

Adjusting setpoint via device

By changing the Setpoint temperature, you are permanently altering your temperature. You can change the
set point temperature very easily while you are reviewing the set point temperature. Press the UP or DOWN
keys repeatedly to change the temperature setting. The set point temperature will flash to indicate that it can
be changed: the temperature will be changed in 0.5°C steps per key press.
The RT310i will return to Normal mode if no keys are pressed for more than 2 seconds. Once the new Setpoint
has been implemented, the change is permanently overridden until a new Setpoint is set again. Setpoint
temperature cannot be changed if Frost Protection mode is enabled.

Actual room temperature Setpoint temperature 2 seconds timeout Actual room temperature

TESTING/PAIRINGTESTING/PAIRING

TESTING/PAIRING

TESTING/PAIRING

RT310i Installation Manual 19

Factory reset

Remove the batteries without pressing any button. Wait 2 minutes and insert the batteries again.

Via App

1

Tap menu icon

2 3 4

Go to Manage devices

Tap delete

After that you will need to add and set your thermostat all over again.

Tap Yes

20 RT310i Installation Manual

Technical info

Product Specication

Model: RT310iRF
Type: Wireless Heating/Cooling Thermostat
Frequency: 868MHz
Temperature
Scale: °C
Range: 5.0°C - 35.0°C

Resolution: 0.1/0.5°C and 0.5°C default
Temperature Measurement

Accuracy:
Display Range: 5.0°C - 35.0°C
Display Resolution: 0.1/0.5°C and 0.5°C default
Frost Protection
Setting: 5 ºC
Setpoint Temperature Range: 5 ºC to 9ºC
thermostat
Power Source: 2 AA-sized Alkaline Batteries for a minimum of 12 months operation.
Receiver
Power Source: 230Vac 50Hz
Switch Rating
Switching Voltage: 230V/50Hz
Switching Current: 16A resistance 8A inductance
Protection Rating: IP 30
Environment
Operating Temperature/

Humidity:
Storage Temperature/

Humidity:

Maximum +/-0.25°C at 20°C

0°C ~ 50°C, 10% – 90% non-condensing

-20°C~- 60°C, 10% – 90% non-condensing

RT310i Installation Manual 21

Warranty

SALUS Controls warrants that this product will be free from any defect in materials or workmanship,
and shall perform in accordance with its specification, for a period of two years from the date of installation.
SALUS Controls sole liability for breach of this warranty will be (at its option) to repair or replace the defective
product.

Customer Name: ..................................................................................................................................................................

Customer Address: .............................................................................................................................................................

................................................................................................................ Post Code: ...............................................................

Tel No: ................................................................... Email: ......................................................................................................

Company Name: ...................................................................................................................................................................

Tel No: .................................................................. Email: ........................................................................................................

Installation Date: ...................................................................................................................................................................

Installer Name: .......................................................................................................................................................................

Installer Signature: ...............................................................................................................................................................

22 RT310i Installation Manual

SALUS Controls PLC
SALUS House

Dodworth Business Park South,
Whinby Road, Dodworth,
Barnsley S75 3SP, UK.

Sales: T: [phone]
E: [e-mail]

Technical: T: [phone]
E: [e-mail]

www.salus-controls.com

SALUS Controls is a member of the Computime Group

Maintaining a policy of continuous product development, SALUS Controls plc reserves the right to
change specification, design and materials of products listed in this brochure without prior notice.

Issue Date: April 2017, V001
