Salora LCD1520TN-BL Instruction Manual

INSTRUCTION MANUAL

065 001 055 770

LCD 1520TN black

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 1

2

WHAT TO DO FOR SAFETY OF YOUR TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

WHICH PART OF YOUR TV PERFORMS WHAT FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

AERIAL CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

VCR, DVD, COMPUTER AND DECODER CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

AUDIO/VIDEO CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

TV FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

TV FUNCTIONS (MENUS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

VOLUME ADJUSTMENT MENU, EQUALIZER, HEADPHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

PICTURE SETTINGS MENU, PROGRAM TABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

SETTINGGS MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

PROGRAM SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

EXTERNAL DEVICE MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

TELETEXT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

CONTENTS

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 2

WHAT TO DO FOR SAFETY OF YOUR TV

3

PPOOWWEERR SSOOUURRCCEE
You should only plug this TV into a 230-240V AC 50Hz
mains supply.

MMAAIINNSS AANNDD OOTTHHEERR LLEEAADDSS
Position the mains supply lead and other leads so that they
are not likely to be walked on, pinched by things or placed
on or against them. Pay particular attention to leads where
they enter a power socket and at the point where they come
out of the TV.

MMOOIISSTTUURREE AANNDD WWAATTEERR
Do not use the TV in a humid or damp area. The equipment
must not be exposed to dripping or splashing, as this may be
extremely dangerous. Objects filled with liquids, such as vases,
must not be placed on this equipment.

NNOO NNAAKKEEDD FFLLAAMMEESS
Naked flame sources, such as lighted candles, must not be
placed near this equipment, or on top of it.

CCLLEEAANNIINNGG
Always unplug the TV before cleaning it. Do not use liquid or
aerosol cleaners. Clean your TV with a soft damp cloth.

BBAATTTTEERRYY DDIISSPPOOSSAALL
Your attention is drawn to the environmental aspects of infrared
remote control battery disposal.
Please dispose of depleted batteries responsibly and ensure you
follow the battery manufacturers disposal instructions.

VVEENNTTIILLAATTIIOONN
The slots and openings on the TV are for ventilation.
Please ensure that there is enough space to allow for adequate
ventilation around the TV (at least 10cm).
Do not block or cover these holes as overheating could occur.

RREEPPLLAACCEEMMEENNTT PPAARRTTSS
The person carrying out the job must use parts that are specified
by the manufacturer or have the same specifications as the
original parts. The use of other parts may cause fire, electric
shock or other hazards.

SSEERRVVIICCIINNGG
Ensure the person carrying out repairs to your TV is qualified to
do so.

PPlleeaassee rreeffeerr ttoo sseeppaarraattee sseerrvviiccee iinnffoorrmmaattiioonn ssuupppplliieedd wwiitthh

tthhiiss pprroodduucctt..

Never remove the cover yourself, there are
dangerous voltages inside and you could receive an electric
shock.

CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED PERSONNEL.

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 3

SAFETY INFORMATION (continued)

4

LLIIGGHHTTNNIINNGG
In the event of a lightning storm, unplug your TV from the wall
socket.
Always unplug the TV if going away on holiday.

GGEENNEERRAALL

• Do not connect or adjust cables while the TV is
plugged into the mains supply.

• Do not leave your TV in a hot, cold or humid area.

• Batteries in remote handsets can leak. Please check the
batteries regularly if they have not been replaced
recently.

• Never let anyone, especially children, push objects into
holes and ventilation slots.

• Don't continue to use your unit if you have spilt liquids
in it, if it is damaged in any way or if it does not work
normally. Immediately unplug the unit and get expert
advice.

• This product is only designed for household or similar
general use. Any other use may invalidate the guarantee
and might be dangerous.

• We are proud to offer this high quality product. To keep
this equipment at this level of quality, this equipment
should only be serviced at your authorised service
centre.

NNoottee:: TThhee uunniitt mmuusstt bbee ccoonnnneecctteedd wwiitthh ttoo tthhee ggrroouunndd ooff
ppoowweerr..

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 4

WHICH PART OF YOUR TV PERFORMS WHAT FUNCTION

5

FFRROONNTT ::

11

Standby button

22

Remote control sensor

33

Speaker(s)

44

P+ / – Program up and down buttons

55

e + / – Volume up and down buttons

66

AV in / Headphone in / SVHS in

BBAACCKK ::

77

Aerial in

88

“Scart in” (Using this entry, you can connect to your TV

such devices as computer, decoder and VCR)

99

Component Audio in (L+R)

1100

Component YPbPr input

1111

PC input

1122

PC Audio in

1133

DC 12V in

DC 12V

EURO AV

Y

PC INPUT

PC

AUDIO IN

8

10

11

12

13

RL

AUDIO IN

9

Pb Pr

IN

7

AUDIO in

R

L

VIDEO in

6

S-VIDEO

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 5

REMOTE CONTROL

6

1. Switching off (stand-by button)

2. Direct program selection buttons

3. Swap button

4. Mute button

5. Main Menu Button

6. TV button (to shift to TV from AV)

7. Program ± in TV setting, Teletext page ± in teletext setting, menu ± in menu setting

8. Volume ± and menu setting button

9. Menu leave button (EXIT or TV button leaves from the menu)

10. User normalization button

11. Status button (i)

12. Volume setting button DUAL I, DUAL II, Stereo, Mono
(DUAL I, II, ST/MONO) (Memory Button in Mono Models)

13. To reach Setup Menu

14. AV Button

15. (Blue button) incred.stereo/mono-normal Audio select

16. (Yellow button)

17. (Green button) Picture preliminary values

18. (Red button) Volume preliminary values

19. Picture format selection (In some models)

Note: In order to use other functions on the remote controller, please see the remote
controller figure described in the TELETEXT section.

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 6

REMOTE CONTROL

7

Never drop your Remote Control.

Do not attempt to open your Remote Control.

Do not press any 2 buttons on Remote Control.
simultaneously

If you do not use your Remote Control. for a long time,
remove the batteries.

NNoottee::

Your Remote Control controls your TV at 7 meters far

and 30 degrees of an angle

.

BBAATTTTEERRYY IINNSSEERRTTIIOONN ((11..55VV AAAAAA xx 22 ppiieecceess))

• Remove battery cover

• Place the batteries properly.

• Close the cover.

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 7

AERIAL CONNECTION

8

OOUUTTDDOOOORR AAEERRIIAALL CCOONNNNEECCTTIIOONN

Optimum good picture and colour reception requires a good outdoor aerial.

Using a coaxial cable (75 ohm Fig A-2) for a aerial, connect the plug (refer to Fig.
A-1) into the aerial input of the set.

Alternatively you may connect the aerial via a video recorder by using the video
recorder Rf Input and Rf Output connections as shown.

AERIAL Socket

(Fig.A-1)

Coaxial cable(75 ohm)

Fig. A-2

Back cover

AERIAL Connection with video recorder

RF input

RF output

Aerial input

Scart socket

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 8

EURO AV

AUDIO IN

RL

VCR, DVD, SATELLITE DECODER AND COMPUTER CONNECTIONS

9

EEUURROO--SSCCAARRTT SSOOCCKKEETT

A Video Cassette Recorder, DVD Player, Games Console or Satellite Decoder may be connected to the scart socket with an
appropriate connecting cable. Select programme mode AV to access the signal being received through the SCART Socket.

VVCCRR OOPPEERRAATTIIOONN BBYY UUSSIINNGG TTHHEE
RRFF OOUUTT

• Alternatively to connect a VCR to your
LCD TV using the RF sockets, connect
a coaxial cable from the RF Out socket
of the VCR to the aerial input socket of
your TV. Then connect the caxial cable
from your TV aerial to the RF In socket
of the VCR.

• Select programme no. 0 on your LCD
TV.

• Insert a video tape into the VCR and
press the “play” key.

• Use the instructions under “Manual
Programming” (found later in this
Instruction Book) to search and store
the VCR’s RF Output channel in
Channel 0 on your LCD TV.

VVCCRR AANNDD DDVVDD PPLLAAYYEERR
OOPPEERRAATTIIOONN BBYY UUSSIINNGG TTHHEE
EEUURROO--SSCCAARRTT SSOOCCKKEETT

• Connect the SCART socket on your

VCR or DVD Player to the SCART
Socket on your LCD TV

• Select AV Channel on your LCD TV by

pressing the AV selection key on your
remote control handset.

• Press the PLAY key on your VCR or

DVD Player

• The advantage of this connection is a
superior quality of picture and sound
during play back.

PPCC CCOONNNNEECCTTIIOONN ((OOppttiioonnaall))

You may use your LCD TV as a PC
monitor by connecting the VGA cable of
your PC into the LCD TV’s PC socket.
Supported PC resolutions:
VGA 640 x 480

AC230V~
50Hz/30W

AC230V~
50Hz/30W

To “RF IN”

Coaxial cable
From “RF OUT”

Aerial

To aerial socket

To “RF IN”

To “EURO SCART”(VCR)

To “EURO SCART”(TV)

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 9

EURO AV

AUDIO IN

RL

AUDIO IN

RL

EURO AV

EURO AV

TV

Y

Pb Pr

RL

AUDIO IN

TV

VOL

TV/AV

P P

PC INPUT

IN

VOL

AUDIO IN

PC

DC 12V

PC

AUDIO/VIDEO CONNECTIONS

10

aa)) WWiitthh SSCCAARRTT CCoonnnneeccttoorr

• Connect the SCART socket on the receiver to the SCART socket
on your LCD TV using the appropriate SCART connecting cable.

• Select AV Channel on your LCD TV by pressing the AV
selection key on your remote control handset. Your LCD TV will
now display the signal from your Satellite or Cable Receiver.

bb)) CCoommppoonneenntt YYPPbbPPrr iinnppuutt::

• If your Video Source has a YPbPr component video output, you
can connect this to your LCD TV’s YPbPr input using 3-Way chinch
cable by refering connector colours. This method will carry the
image to your LCD TV.

• For audio connection use a 2-Way AV connecting lead to
connect left and right audio outputs to your LCD TV’s left and
right audio inputs.

• Select YPbPr Channel on your LCD TV by pressing AV
selection key on your Remote Control handset.

L

DC 12V

EURO AV

Y

PC INPUT

PC

AUDIO IN

RL

AUDIO IN

Pb Pr
IN

DECODER SCART TV SCART

OUT

SVSH V L R

TV

AERIAL

DISH
LNB

AUDIO OUT

RL

DC 12V

EURO AV

Y

PC INPUT

PC

AUDIO IN

RL

AUDIO IN

Pb Pr
IN

DECODER SCART TV SCART

OUT

SVSH V L R

TV

AERIAL

DISH
LNB

RECEIVER

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 10

TV FUNCTIONS

11

11.. OOPPEERRAATTIIOONN
aa.. SSwwiittcchhiinngg oonn tthhee TTVV
Plug the power cable of the TV set into the wall outlet.
* Your set works on 12V DC power. For this purpose, use the
adapter provided within your TV set.

bb..SSttaanndd--BByy MMooddee
While your TV is at stand-by mode, you can operate your TV
using one of the program selection buttons on the RC (0 to 9)
or the P± on the TV set

22.. SSWWIITTCCHHIINNGG OOFFFF
aa.. SSwwiittcchhiinngg OOFFFF tthhee TTVV
When you want to switch off the TV completely,
remove the power cable from the wall outlet.
bb.. SSttaannddbbyy MMooddee
To turn your TV off for a short time press the standby
button on the remote control.

NNoottee:: RRCC mmeeaannss RReemmoottee CCoonnttrroolllleerr

11.. PPRROOGGRRAAMM NNUUMMBBEERR SSEELLEECCTTIIOONN
* You can select the program you want by increasing
the program number pressing the P± button.

* Select the program no. 0 – 9 with the single number
keys (0-9) on the Remote control.

* To select a “double digit” number, simply press the
two required digits consecutively, within a short time.
EExxaammppllee::

To shift to the program No. 14, first press 1
button. In this case, the "1-" message appears on the left
corner of the screen. If you keep the button pressed,
you shift to the program No.1. As long as this message
appears on the screen (3 seconds) without pressing 4,
the TV shifts to the program No. 1

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 11

TV FUNCTIONS

12

22.. MMUUTTEE
In order to mute the sound immediately, press the mute
button on the RC. Pressing this button again will allow
you to hear the sound at the same volume as before.

33.. SSTTAATTUUSS BBuuttttoonn::

( ) Shows the program number,
volume level and audio system info for 3 seconds on
the screen

44.. PPPP BBuuttttoonn ((NNoorrmmaalliizzaattiioonn)) ::

It brings the settings made
on the menu related to the picture and sound in the form
they have been saved by the user.

55.. SSWWAAPP BBuuttttoonn::

Provides swapping to the previously

watched channel

66.. SSMMDD BBuuttttoonn::
MMoonnoo::

This button is not operative on TVs or mono
broadcastings
SStteerreeoo::

This button is used to select mono or DUAL

volume outputs in TV sets

77.. AAVV BBuuttttoonn::

In order to select the AV Mode, press the AV
button on the RC. To come back to the TV mode again,
enter the program number or press TV button. As long as
there is a menu on the screen, you cannot take your TV
set to AV mode. While on AV Mode, you cannot enter
into the Program Table menu. In the AV mode, you can

watch the external devices connected through the scart
(Video, DVD, VCD etc.). Each time you press the AV
button, the modes that you can connect to your device
are displayed.

88..AAUUTTOOMMAATTIICC SSHHUUTT OOFFFF..
If the Tv receives no signal for 5 minutes it will
automatically switch to Stand - By. This feature is not
enabled in AV mode.

99.. MMEENNUU BBuuttttoonn::

When you press this botton you can
reach the Main Menu.If you press again you will leave the
Main Menu. Besides for returning the preceeding menu
from the sub menus you have to use this button.

1100.. TTVV ((EEXXIITT)) BBuuttttoonn::

Provides exit from the menus

1111..1166::99 BBuuttttoonn::

This is used to change the screen

format from 4 : 3 to 16 : 9

1122.. AAUUTTOO ZZAAPP::

Pressing P± button for 3 to 4 seconds and
releasing will cause automatic channel search. On the
upper right corner "Auto Zap" appears.

1133..

RReedd BBuuttttoonn::

You can select the preset "Sound" values
by using the Red button. The "Personal" value is the
adjustments which you were made on your apparatus.

1144..

GGrreeeenn BBuuttttoonn::

You can select the preset "Picture"
values by using the green button. The "Personal" value is
the adjustments which you were made on your apparatus.

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 12

SETUP

13

If you assemble your apparatus according to the
explanations from the preview pages "Automatic Search"
(Welcome) will appear on the screen. At this menu;

1- Use "P+/P-" button for "Country" option and choose the
country's abbreviation with "V+/V-" button.
2- Use "P+/P-" button for "Language" option and adjust
the menu language with "V+/V-" button.
3- Use "P+/P-" button for "Auto store" and initiate the
automatic search with the "V+" button. Please do not press
any button during automatic search. Your apparatus will
find the channels and record the memory automatically.

If "Welcome" menu does not appear you can search the
channels as below:
1- Press "Menu" button
2- Use "P+/P-" for "Settings" and enter the menu with "V+"
button.

3- Choose "Language" option with "P+/P-" button and
adjust you rdesired menu language with "V+/V-" button.
4- Use "P+/P-" button for "Country" option and choose the
country's abbreviation with "V+/V-" button.
5- Press "MENU" button and return to the main menu.

6- Use "P+/P-" button for "Program Settings" and enter the
menu with "V+" button.
7- Use "P+/P-" button for "Auto store" and start the search
with the "V+" button. Do not press any button during the
automatic search. Your apparatus will find the channels
and record the memory automatically.

Program nr. 2
Program name
System standard Europe
Autostore
Frequency 182.25 MHz
Fine tune

Source OSD Off
Language English
Country GB
Child lock
Timers
Teletext lang Pan European

Country GB
Language English
Autostore

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 13

SETUP

14

Use P+,P-,V+,V- for changing the menu language and the
manual adjustments processes at Program adjustments
Menu.
Use P+,P-,V+,V- for changing the order of the program,
naming the program, deleting the program and skipping
process at Program table Menu. These processes had been
mentioned at further pages.

Leave this menu pressing “TV” button.

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 14

TV FUNCTIONS (MENUS)

15

MMaaiinn MMeennuu::

To access this menu, press menu button.
You can come on the options in the main menu using
P± buttons and activate the options pressing V±
buttons.

11.. VVOOLLUUMMEE AADDJJUUSSTTMMEENNTT MMEENNUU
Using the MENU button, you can access to volume
adjustment menu. In this menu, volume settings are
selected or memorized using P± buttons and can be
changed using V± buttons.

VVoolluummee::

The TV set's volume can be adjusted

BBaallaannccee::

The balance between left and right channel
outputs is shown
BBaassss::

The user can adjust the bass level at this option

TTrreebbllee::

The user can adjust the treble at this option
Stereo models have AVL property. This is not shown on the
menus. This is for automatic volume limitation, i.e. it
keeps the volume level at the optimum level when shifting
from one channel to another. Because of this, the volume
comes after the display in case a channel is shifted.

EEqquuaalliizzeerr::
You can enter the Equalizer menu with the" V+" button
while you are in the Equalizer line. When you are in
this menu you can select (personal, voice, Music,
theatre) one of the equalizer adjustments with the "P+,
P-" buttons. For the personal equalizer settings P±, V±
buttons.

HHeeaaddpphhoonnee:: ((OOppttiioonnaall))
When a headphone is inserted, no volume comes from
the speakers. The volume is only through the
headphones. Using the volume menu, headphone can
be set. You can change the volume as
Mono/Stereo/Dual using the S/M/D button.

Personal

100 300 1k 3k 8k

Volume
Balance
Bass
Treble
Equalizer

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 15

TV FUNCTIONS (MENUS)

16

22.. PPIICCTTUURREE SSEETTTTIINNGGSS MMEENNUU
Using the MENU button, you can access to picture

settings menu. In the picture settings menu, you can
alter many parameters related to display. Brightness,
Contrast, Colour, Sharpness, Dyn. Skin tone and White
tone settings can be made according to your
requirements. Using the P± buttons on the RC, highlight
the option you want to set and change the setting value
or the option pressing the V± buttons.

The changes are automatically memorized.

If you press MENU button, you can access to former menu,
while you can leave all menus if you press TV button.

33.. PPRROOGGRRAAMM TTAABBLLEE ::

Using menu buttons, you can

access to program table.

The channel number and name in the program table
appear in different colors. You can access to other
channels using P± and V± buttons in the program table.

33..11..

Blue button is for naming. When pressing the blue
button in the current channel, a small box appears.
The character can be changed pressing P± buttons. You
can access to the following or previous characters using
V± buttons. When the naming is over, press the blue
button again to memorize.

33..22..

You can move by pressing the green button. Access
the channel you want to move pressing P± and V±
buttons and press the green button. Again, access to
the place where you want to move pressing P± and V±
buttons and press green button. Moving process has
been completed (The moved program is inserted
between the others, increasing the number of the
following programs by one)

1
2
3
4
5
6

7
8
9
10
11
12

Name
Move
Delete
Skip

Brightness
Contrast
Colour
Sharpness Normal
Dyn. skin tone Off
White tone Normal

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 16

TV FUNCTIONS (MENUS)

17

33..33..

Red button is for deletion. Access the channel you
want to delete pressing P± and V+ buttons and press
the red button. On the right side of the menu, the
channel number appears with a red button. Pressing
the red button once more will delete the channel. The
following channel will replace the deleted one.

33..44..

You can skip using the yellow button. When on the
channel to be skipped, press the yellow button, there
by you can adjust the skip function on that channel.
After you leave the program table; if you use the
buttons "P+, P-" for passing the channels, the channels
which you skip with these buttons cannot be seen. You
can access to that channel using numbers, the name
and number of the channel appears in a different color.
To cancel the skip function, you can press yellow
button on the channel, again in the prog. table.

44.. SSEETTTTIINNGGSS MMEENNUU::

In this menu;

44..11.. SSoouurrccee OOSSDD::

The source OSD option can be
adjusted as Open / Closed. It provides continuous
display of the current channel.

44..22.. LLaanngguuaaggee::

Using this option, you can change the

language in the menus.

44..33..CCoouunnttrryy::

Your apparatus finds the channel and
choose the system according to the determined country
during the automatic search. For this reason it is
essential to enter the right code of the country.

Please do not forget to choose the country's
abbreviation with "V+/V-" button. ( if you do not have a
country name choose another country which has the
same system).

44..44.. CChhiilldd LLoocckk::

In this menu "Lock and Password"
appears. When the Lock function is on with by using
the V+ button, a password will be asked when the TV

Source OSD Off
Language English
Country GB
Child lock
Timers
Teletext lang Pan European

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 17

TV FUNCTIONS (MENUS)

18

set is switched on from the standby position and will
operate if the password is correctly entered. To change
the password, you can enter a 4 digit number in the
password line, between "0000" and "9999".

NNoottee:: IIff yyoouu ffoorrggeett tthhee ppaasssswwoorrdd,, ttyyppee 44771111

44..55.. TTiimmeerrss::

In this menu, Sleep timer, Reminder timer,
OFFF timer, Switch timer and the Switch program are
shown.

44..55..11.. SSlleeeepp TTiimmeerr::

You can adjust the Sleep timer
functions between 5 to 120 minutes with the V+
button. When the time is over, Your TV will close
automatically. The closing time can be increased or

reduced with 5 minutes intervals. At the end of the
adjusted period, you can watch the last 60 seconds
period on the screen.
You can leave this menu pressing TV button.

44..55..22.. RReemmiinnddeerr TTiimmeerr::

You can adjust the recall period
between 5 to 120 minutes with the V+ button. At the
end of the set period, a warning message appears on
the screen. Pressing any button, this message will
disappear. Reminder time may be increased or
decreased by 5 minutes steps.

44..55..33.. OOFFFF TTiimmeerr::

You can set the switching off time.

NNoottee::

Check from the RT clock menu if the time is

correct

44..55..44.. SSwwiittcchh pprrooggrraamm::

After setting the switch time in
the switch option, the TV sets switches to the set
program when the time comes. After adjusting the
switch, when your TV set is in Stand by position, it is
switched on the adjusted time and program when the
time comes. When the switch is to be set to AV mode,
press the AV button in the switch Program option. The
other modes are displayed in order.

44..66.. TTeelleetteexxtt LLaanngguuaaggee::

You can set the teletext
language depending on the teletext received by your
TV set.

Sleep timer Off
Reminder timer Off
Off timer - -:- ­Switch timer - -:- ­Switch program 5

Lock Off
Lock code 1111

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 18

TV FUNCTIONS (MENUS)

19

44..77.. TTeelleetteexxtt EE//WW::

This selects the characters peculiar to
Eastern Europe and Western Europe countries for
teletext

44..88.. RRTT CClloocckk::

The clock is adjusted as "24 hours, 12
hours or closed". In the lower line, the current time is
adjusted.

55.. PPRROOGGRRAAMM SSEETTTTIINNGGSS
In the program settings menu are the options "Prog.
No., Channel Name, System, Sound System, Auto
Prog., Frequency, Fine Tuning, AFC, Skip and Lock".

PPrrooggrraamm nnrr..::

Shows the number of the current channel.

The Prog. No. can be changed using V± and numbers.

PPrrooggrraamm nnaammee::

The name of the current channel
appears. Press V± to enter the channel name. You can
change the character using P± buttons. You can access
the following and previous characters using V±. When
the naming is over, you can leave from there using V±.

SSyysstteemm SSttaannddaarrdd::

You can choose the country’s system
standard with the "V+/V-". ( The European countries
except France ; can choose the "Europe" option)

AAuuttoo SSttoorree::

This provides automatic finding of the
programs. When the search begins, the message "Busy"
is displayed. When the transaction is over, the "Busy"

Program nr. 2
Program name
System standard Europe
Autostore
Frequency 182.25 MHz
Fine tune

Clock Off
Time 01:22

Country GB
Child Lock
Timers
Teletext lang. Pan European
Teletext E / W West
RT Clock

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 19

TV FUNCTIONS (MENUS)

20

message disappears. After the Auto store is over, it
displays until the found program numbers.

FFoorr eexxaammppllee::

If there are 50 programs in the Auto Store,
it hides after 50. When P+ is pressed in the 50th
program, it proceeds to PC instead of 51.

FFrreeqquueennccyy::

In the frequency option, the frequency of
the current channel is displayed. You can change the
frequency using V± or numerical buttons.

FFiinnee TTuunnee::

You can fine tune the channels pressing V±

AAFFCC::

This operates ON/OFF. When ON, Its follows or
corrects the possible small frequency distortions in the
channels.

LLoocckk::

This provides locking of the current channel.
When the locked channel is accessed, a password is
asked. If the password is entered correctly ( the password

which is entered at the option of child lock), the channel
appears. After entering the password, the channel
appears. When the channel is changed and this channel
is revisited, the password appears as off. You should
adjust "Off" in the Program Settings in order to close.

SSttoorree::

You can save the adjustments.

NNoottee::

The Child Lock should be On in order to this lock

be functional.

AFC On
Lock Off
Store

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 20

EXTERNAL DEVICE MODES

21

NNoott aallll mmeennuuss aappppeeaarr iinn tthhee eexxtteerrnnaall ddeevviiccee mmooddeess,, tthheessee
ccaann bbee ddiiffffeerreenntt ffrroomm TTVV mmeennuuss..
FFoorr eexxaammppllee::

YYPPbbPPrr mmooddee
In this mode, some of the menus are closed. Volume,
Picture and Settings menus are operative
There is no change in the

VVoolluummee MMeennuu

IInn tthhee PPiiccttuurree mmeennuu,,

the "dyn.skin tone" has been removed.

Info options have been added.

IInnffoo::

The information on the display resolution appears

The options related to text have been removed in the
settings menu.

PPCC mmooddee
Some of the menus have been closed in this menu. Sound,
Picture and Settings menus are preserved.
TToo tthhee SSoouunndd MMeennuu,,

the Audio option is added. When the
Audio is On, you can hear the sound of your computer
from the TV speakers. When it is off, you cannot hear
your computer's voice from your TVs speakers.
IInn tthhee PPiiccttuurree MMeennuu,,

"dyn.skin tone" option has been
removed. Position, Video noise, Auto adjust, Information,
Factory and Color temp options have been added.

PPoossiittiioonn::

Adjust horizontal and vertical position of the
picture.
VViiddeeoo NNooiissee::

In the video noise, there are "Phase and
Clock" options. Using these options, you can make the
display more clear.
AAuuttoo AAddjjuusstt::

Adjusts the picture clearness automatically

IInnffoo::

The information on the display resolution appears

FFaaccttoorryy::

Provides restoration of the picture settings to
factory settings.
CCoolloorr tteemmpp::

Sets the picture heat. When USER is
selected, the message "White tone RGB" appears at the
lower part. The user can do the adjustments.

The text related options have been removed in the settings
menu.

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 21

TELETEXT

22

TTEELLEETTEEXXTT MMOODDEE
If the channel you are watching has a teletext
broadcasting, you can perform various transactions by
shifting to teletext mode using the below described
buttons:

11.. TTeelleetteexxtt

: Provides shifting to teletext

broadcasting in the current channel

22.. TTVV ::

Used for shifting to TV broadcasting while you

are in Teletext mode

33.. RReevveeaall // CCoonncceeaall ((RReessppoonnddiinngg))

: Provides
displaying or re-saving of some information hidden in
the teletext broadcasting while in teletext mode

44.. TTeelleetteexxtt TTiimmeerr ((CCaalllliinngg tthhee ssuubbppaaggeess))

: While in
TV mode, this mode displays the timer of your TV set
on the upper right corner of the screen. In the Teletext
mode, this is used for a direct access to the subpages of
the current page.

FFoorr EExxaammppllee::

You are in the teletext page No. 500. If the
message 1/2 appears, the number 1 shows the subpage
number and the number 2 shows the total number of
subpages. Pressing teletext timer button in this case, the
SS -- -- -- --

marks will replace the teletext page number.
Using the number 0 to 9 on the RC, you can access the
subpage you would like to. For instance, if you want to
access the second subpage, press the numbers 0, 0, 0, 2.
.

11..

Teletext key

22..

TV key

33..

Reveal/Conceal
(answering) key

44..

Teletext timer (calling

sub pages) key

55..

Cancel (updating) key

66..

Size (page expanding)
key

77..

Mix (viewing TV and
Teletext information
together) key

88..

Hold (holding sub
page) key

99..

Index (main page) key

1100..

Colour (red, green,
yellow, blue) keys

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 22

TELETEXT

23

55.. CCaanncceell ((UUppddaattiinngg))

: While in teletext mode,
pressing this button will bring TV broadcasting, but
teletext is still active and if a new page number is
entered, page search will continue. When the required
page comes, a message for page number is displayed.
Pressing this button once more, the teletext page

66.. SSiizzee ((PPaaggee eexxppaannddiinngg))

: This button is used for
displaying the current teletext page in 3 different
formats. This converts the display in normal size, upper
half doubled or lower half doubled format

77.. MMiixx ((SSiimmuullttaanneeoouuss TTVV aanndd TTEELLEETTEEXXTT bbrrooaaddccaassttiinngg))

: This provides simultaneous broadcasting of the
current channel and the related teletext data. Pressing
the mix button again will shift the TV to normal teletext
mode.

88.. HHoolldd ((HHoollddiinngg ssuubb ppaaggee))

: If a teletext page has
subpages, such subpages are displayed from time to
time. In such a case, this button is pressed to hold that
page continuously on the screen. When the page is
held pressing "HOLD", the HOLD script appears on the
upper left corner of the screen. Pressing this button
again will release the page from the hold position.

99.. IInnddeexx ((HHoommee PPaaggee))

: This button provides

direct access to the teletext index page

1100)) CCoolloouurr KKeeyyss ((RREEDD//GGRREEEENN//YYEELLLLOOWW//BBLLUUEE))
You can scan the teletext information more easily using these
four colour text buttons.

EEXXAAMMPPLLEE::

TTVV GGUUIIDDEE SSPPOORRTTSS NNEEWWSS WWEEAATTHHEERR

The above given information are given for instance.
The color may change depending on the searched
page.

NNoottee::

Some models do not have TELETEXT feature.

Press

RREEDD
button to
receive TV
information

Press

GGRREEEENN
key to receive
Sports
Information

Press
YYEELLLLOOWW

key
to receive the
news

Press

BBLLUUEE
key to receive
weather
forecast

065001055770 15" FRAME LOC1 ING 30/5/06 13:34 Page 23
