Saivod AT 75 User Manual [es]
GB
ES
PT
Instruções para utilização
Instruction for use
Instrucciones de uso
AT-75
GB
Content
ES
Índice
PT
Ín
dice
Advice for recycling of the old appliance /1
Packing Recycling /2
Transport instructions /2
Warnings and special advice /2
Setting up /3
Electric connection /3
Switching off /4
Appliance description /4
Freezer operation /4
Advice for food conservation /5
Use of baskets /5
Defrosting of the appliance /5
Cleaning of the appliance /6
Replacing the interior light bulb /6
Defects finding guide /6
Appliance data sheet /7
Consejos para reciclar el antiguo aparato /8
Reciclado del embalaje /9
Instrucciones de transporte /9
Advertencias y consejos especiales /9
Instalación /10
Conexiones eléctricas /10
Desconexión /10
Descripción del electrodoméstico /11
Funcionamiento del congelador /11
Consejos para la conservación de alimentos /11
Uso de las cestas /12
Deshielo del aparato /12
Limpieza del aparato /13
Sustitución de la bombilla interior /13
Guía de localización de averías /13
Hoja de datos del electrodoméstico /14
Conselhos para a reciclagem do equipamento velho /15
Reciclagem da Embalagem /16
Instruções para transporte /16
Avisos e conselhos especiais /16
Instalação /17
Ligação eléctrica /17
Desligar /18
Descrição do equipamento /18
Funcionamento do congelador /18
Conselhos para a conservação dos alimentos /19
Utilização de cestos /19
Descongelação do equipamento /20
Limpeza do equipamento /20
Substituição da lâmpada interior /20
Guia para localização dos defeitos /21
Folha de dados do equipamento /22
1
2
3
4
7
5
6
This appliance is not intended for use by person with reduced physical, sensory or mental
Children should be supervised to ensure that they do not play with the appliance.
GB Instruction for use
Congratulations for your choice!
The chest freezer you have purchased is one in the SAIVOD
products range and represents a harmonious joinng between
the refrigeration technique with the aestetical outlook. It has a
new and attractive design and is built according to the
European and national standards which guarantee its operation
and safety features. At the same time, the used refrigerant,
R134a, is environment-friendly and it does not affect the ozone
layer.
In order to use the best your freezer, we advise you to read
carefully the information in these user instructions.
Advice for recycling your old appliance
If your newly purchased appliance replaces an older appliance,
you must consider a few aspects.
The old appliances are not valueless scrap. Their disposal,
while preserving the environment, allows the recovery of
important raw materials.
Make your old appliance useless :
- disconnect the appliance from the supply;
- remove the supply cord (cut it);
- remove the eventual locks on the door to avoid the blocking of
children inside, while playing, and the endangering of their lives.
The refrigerating apliances contain insulating materials and
capabilities or lack of experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
refrigerants which require a proper recycling.
1
recyclable. Please help us recycle the packing
efore putting the appliance in operation, read
e appliance if you noticed a
e appliance if it is
immediately after having taken them out of the
GB Instruction for use
Packing Recycling
WAR N ING !
Do not allow children to play with the
packing or with parts of it. There is the risk
of suffocation with parts of corrugated
cardboard and with plastic film.
In order to get to you in good condition, the
appliance was protected with a suitable
packing. All the materials of the packing are
compatible with the environment and
while protecting the environment !
IMP O RTA N T!
B
carefully and entirely these instructions. They
contain important information concerning the
setting up, use and maintenance of the
apliance.
The manufacturer is free of any responsibility if
the information in this document are not
observed. Keep the instructions in a safe place
in order to reach them easily in case of need.
They can also be useful subsequently by
another user.
ATT ENTIO N!
This appliance must be used only for its
intended purpose, (household use), in
suitable areas, far from rain, moisture or
other weather conditions.
Transport instructions
The appliance must be transported, as much
as possible, only in vertical position. The
packing must be in perfect condition during
transport.
If during transport the appliance was put in
horisontal position (only according to the
markings on the packing), it is advised that,
before putting it into operation, the appliance
is left to rest for 12 hours in order to allow the
settling of the refrigerating circuit.
The failure to to observe these instructions
can cause the breakdown of the
motorcompressor and the cancellation of its
warranty.
Warnings and general advice
Do not plug in th
failure.
The repairs must be done only by qualified
personel.
In the following situations please unplug the
appliance from the mains:
- when you defrost completely the appliance;
- when you clean the appliance.
To unplug the appliance, pull by the plug,
not by the cable!
Ensure the minimum space between the
appliance and the wall against which it is
placed.
Do not climb on the appliance.
Do not allow the children to play or hide
inside the appliance.
Never use electric appliances inside the
freezer, for defrosting.
Do not use the appliance near heating
appliances, cookers or other sources of heat
and fire.
Do not leave the freezer door open more
than it is necessary to put in or take out the
food.
Do not leave the food in th
not working.
Do not keep inside products containing
flammable or explosive gases.
Do not keep inside fizzy drinks (juice,
mineral water, champagne, etc.) in the
freezer: the bottle can explode! Do not freeze
drinks in plastic bottles.
Do not eat ice cubes or icecream
freezer because they may cause „freezer
burns”.
Never touch cold metal parts or frozen food
with wet hands because your hands can
quickly freeze on the very cold surfaces.
For the protection of the appliance during
warehousing and transport, it is provided with
spacers between the door and the cabinet (in
the front and rear side). These spacers will be
removed before putting the appliance into
operation.
2
leave the door open to avoid the formation of
100 cm from the cookers working with coal
240V/50 Hz. Before
GB Instruction for use
Excess deposit of ice on the frame and the
baskets should be removed regularly with the
plastic scraper provided. Do not use any
metal parts to remove the ice.
The presence of this ice build-up makes
impossible to close the door correctly.
If you do not use your appliance for a few
days, it is not advisable to switch it off. If you
do not use it for a longer period, please
proceed as follows :
- unplug the appliance;
- empty the freezer;
- defrost it and clean it;
unpleasant smells.
The supply cord can be replaced only by
an authorised person.
If your appliance has a lock, keep it locked
and store the key in a safe place, out of the
reach of children. If you are discarding an
appliance with lock, make sure that, is made
ineffective. This is very important so as to
avoid children being trapped inside, which
may cause their loss of life.
Setting up
This appliance was designed to operate at an
ambient temperature between +180C and
+430C (T class). If the ambient temperature is
above +430C, inside the appliance the
temperature can increase.
Set up the appliance far from any source of
heat and fire. Placing it in a warm room, the
direct exposure to sunbeams or near a heat
source (heaters, cookers, ovens), will
increase the energy consumption and shorten
the product life.
• Please observe the following minimun
distances:
•
or oil;
• 150 cm from the electric and gas cookers.
• Ensure the free circulation of the air around
the appliance, by observing the distances
shown in Item 2.
Assemble on the condenser (in the rear side)
the supplied spacers. (Item 3).
• Place the appliance in a perfectly even, dry
and well ventilated place.
Assemble the supplied accessories.
Electric connection
Your appliance is intended to operate at a
single-phase voltage of 220plugging in the appliance, please make sure
that the parameters of the mains in your house
(voltage, currect type, frequency) comply to the
operation parameters of the appliance.
• The information concerning the supply voltage
and the absorbed power is given on the marking
label placed in the back side of the freezer.
• The electric installation must comply with
the law requirements.
• The earthing of the appliance is
compulsory. The manufacturer has no
responsibility for any damage to persons,
animals or goods which may arise from
the failure to observe the specified
conditions.
• The appliance is endowed with a supply
cord and a plug (European type, marked
10/16A) with double earthing contact for
safety. If the socket is not the same type with
the plug, please ask a specialised electrician
to change it.
•
Do not use extension pieces or multiple
adapters.
3
n and
GB Instruction for use
Switching off
The switching off must be possible by taking
the plug out of the socket or by means of a
mains two-poles switch placed before the
socket.
Operation
Before putting into operation, clean the inside
of the appliance (see chapter „Cleaning").
After finishing this operation please plug
in the appliance, adjust the thermostat
knob to an average position. The gree
red LEDs in the signalling block must light.
Leave the appliance work for about 2
hours without putting food inside it.
The freezing of the fresh food is possible
after min. 20 hours of operation.
Appliance description
(Item. 1)
1. Door handle
2. Door
3. Lamp housing
4. Basket handle
5. Baskets
6. Try
7. Lock housing
8. Thermostat box
9. Spacer for transport
Freezer operation
Temperature adjustment
The temperature of the freezer is adjusted by
means of the knob assembled on the
thermostat (item. 4), position „MAX” being the
lowest temperature.
The achieved temperatures can vary
according to the conditions of use of the
appliance, such as: place of the appliance,
ambient temperature, frequency of door
opening, extent of filling with food of the
freezer. The position of the thermostat knob
will change according to these factors.
Normally, for an ambient temperature of
approx. 320C, the thermostat will be adjusted
on an average position.
The signalling system is placed on the front
side of the freezer (Item 5).
It includes:
1. Thermostat adjustment knob – the inside
temperature is adjusted.
2. green LED – shows that the appliance is
supplied with electric energy.
3. red LED – damage – lights if the
temperature in the freezer is too high. The
LED will operate 15-45 minutes after the
putting into operation of the freezer, then it
must go off. If the LED goes on during the
operation, this means that defects have
occurred.
4. Orange button– fast freeze – by pushing it
the orange led goes on, showing that the
appliance entered into the "fast freeze"
mode . The exit of this mode is done by
pushing the button again, and the orange
led goes off.
The three LEDs give information about the
mode of operation of the freezer.
4
freezing time, push the button for „fast freeze”.
least twice a year or when the ice layer has an
GB Instruction for use
Advice for food conservation
The freezer is intended to keep the frozen
food for a long time, as well as to freeze fresh
food.
One of the main elements for a successful
food freezing is the packing.
The main conditions that the packing must
fulfill are the following: to be airtight, to be
inert towards the packed food, to resist to low
temperatures, to be proof to liquids, grease,
water vapours, smells, to be able to be
washed.
These conditions are fulfilled by the following
types of packings: plastic or aluminium film,
plastic and aliminium vessels, waxed
cardboard glasses or plastic glasses.
IMP O RTA N T!
- For freezing the fresh food please use the
supplied baskets of the appliance.
- Do not place into the freezer a too large
quantity of food at a time. The quality of the
food is best kept if they are deeply frozen as
quickly as possible. This is why it is advisable
not to exceed the freezing capacity of the
appliance specified in the "Appliance data
sheet" (page 7). In order to reduce the
- The fresh food must not come into contact
with the food already frozen.
- The frozen food you have bought can be
placed into the freezer without having to
adjust the thermostat.
- If the freezing date is not mentioned on the
packing, please take into consideration a
period of max. 3 months, as a general guide.
- The food, even partially defrosted, cannot be
frozen again, it must be consumed
immediately or cooked and then refrozen.
- The fizzy drinks will not be kept in the
freezer.
- In case of a power failure, do not open the
door of the appliance. The frozen food will not
be affected if the failure lasts less than 36
hours.
DO NOT F ORGET !
After 24 hours since the food was
placed inside, please cancel the "fast
freeze" mode by pushing again the
button 4, when the orange led goes off.
Use of basket
The basket can be introduced into the
appliance on the bottom of the cabinet liner.
To do so please proceed as follows:
1. Rotate the handle 200 then pull the handle
in the direction shown by the arrow (item
6.1). Following this operation you get the
position of the handle as in item 6.2.
2. Rotate the handle in the direction shown
by the arrow (item 6.2) until it gets the
position in item 6.3.
3. Fasten the handle on the wire by moving it in
the direction shown by the arrow (item 6.3).
4. Thus it is obtained the assembled basket
with the handle in the shown position to be
put inside the cabinet of the appliance
(item 6.4).
Defrosting of the appliance
We advise you to defrost the freezer at
excessive thickness.
The ice build-up is a normal phenomenon.
The quantity and the rapidity of ice build-
up depends on the ambient conditions and on
the frequency of the door opening.
We advise you to defrost the appliance
when the quantity of frozen food is the least.
Before defrosting, adjust the thermostat
knob to a higher position so that the food
stores more cold.
- Unplug the appliance.
- Take out the frozen food, wrap it in several
sheets of paper and put them in refrigerator or
a cool place.
Take the separator panel and put it under the
freezer in the direction of the dripping tube.
Take out the obstructing plug. The water
which results will be collected in the special
tray (separator panel). After the melting of the
ice and the run-off of the water please wipe
with a cloth or with a sponge, then dry well.
Put the obstruction plug back in its place.
(Item. 7)
For a fast thaw please leave the door open.
Do not use sharp metal objects to remove
the ice.
Do not use hairdriers or other electric
heating appliances for defrosting.
5
Loading...
