ENGLISH

You have just purchased a SAGEM phone, we congratulate you; it is recommended that you read this handbook carefully in order to use your phone efficiently and in the best conditions. Your phone can be used internationally in the various networks (EDGE, GSM 900 MHz and DCS 1800 MHz or PCS 1900 MHz) depending on the roaming arrangements with your operator. We remind you that this phone is approved to meet European standards. Depending on the model, network configuration and associated subscription cards, certain functions may not be available.

SAGEM™ is a trademark of Sagem Communication, SAFRAN group. T9™ Text Input is a trademark of ©Tegic Communications Inc. Java™ and all Java™ based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The WAP navigator and some message softwares (i-mode) are under licence Openwave. The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all or part of these softwares. Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. miniSD™ is a trade mark of SD Card Association. Windows is a trade mark of Microsoft Corporation.

Care and safety information....................... 6

Environment.................................................... 7

Description .................................................. 8

First use: installing the SIM card and the battery 9

Removing the back cover .............................10

Necklace attachment ....................................10

Inserting the memory card ............................ 11

Getting started........................................... 11

Network......................................................... 11

First call ........................................................12

Receiving a call............................................. 12

Using your phone...................................... 12

Improving antenna performance...................12

Increase the battery life of your phone .........13

Charging the battery .....................................13

Phonebook................................................. 14

Using the phonebook.................................... 14

Storing a new contact ...................................14

Calling a contact ...........................................14

Contact options.............................................14

Mailing lists ...................................................15

Messages ................................................... 15

Creating a text message (SMS or MMS) ...... 15

Saving the message .....................................16

Sending the message................................... 16

Receiving messages .................................... 16

Messages menu ...........................................16

e-mail .......................................................... 18

Photo .......................................................... 18

Taking and saving a photo ........................... 18

Video........................................................... 19

Taking a video .............................................. 19

Multimedia.................................................. 20

Connectivity............................................... 20

Bluetooth ...................................................... 20

Car kit or headset .........................................21

USB mode ....................................................21

SyncML......................................................... 21

Music Player .............................................. 21

FM Radio .................................................... 22

WAP ............................................................ 23

The WAP Menu ............................................ 23

WAP Logging on........................................... 23

Downloading objects .................................... 23

WAP Logging off........................................... 23

GPRS/EDGE ................................................23

Games ........................................................ 24

Applications............................................... 24

Applications...................................................24

Calendar .......................................................24

Alarm - Timer ................................................25

Calculator...................................................... 25

ToDo .............................................................25

Services ........................................................25

Settings ...................................................... 26

Phone settings ..............................................26

Display ..........................................................26

Calls ..............................................................27

Networks .......................................................28

Security .........................................................28

Player settings ..............................................29

Browser settings ...........................................29

Camera .........................................................29

Video settings ...............................................29

Shortcuts....................................................... 29

Storage .........................................................30

Keys checking............................................... 30

Help...............................................................30

Technical features..................................... 30

Conformance Document .......................... 31

Care and safety information..................... 32

SAR...............................................................32

Advice for limiting exposure to radiofrequency

(RF) fields .....................................................32

End User Licence Agreement (EULA), for

the software ............................................... 33

Java™......................................................... 36

Warranty..................................................... 39

Troubleshooting ........................................ 41

Customer care ........................................... 43

Index........................................................... 44

Care and safety information

Never attempt to disassemble your phone. You alone are responsible for how you use your phone and any consequences of its use.

As a general rule, always switch off your phone wherever the use of a phone is prohibited. Use of your phone is subject to safety measures designed to protect users and their environment. Do not use your phone in damp areas (bathroom, swimming pool…). Protect it from liquids and other moisture. Do not expose your phone to extreme temperatures lower than - 10°C an higher than + 55°C. The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone automatically protects the batteries in extreme temperatures. Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested).

Electrical safety

Only use the chargers listed in the manufacturer’s catalogue. Using any other charger may be dangerous; it would also invalidate your warranty. Line voltage must be exactly the one indicated on the charger’s serial plate.

Aircraft safety

When travelling by plane, you will need to switch your phone off when so instructed by the cabin crew or the warning signs. Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations.

Explosive materials

Please comply with warning signs at petrol station asking you to switch your phone off. You will need to comply with radio equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are under way.

Electronic equipment

To avoid the risk of demagnetisation, do not let electronic devices close to your phone for a long time.

Electronic medical equipment

Your phone is a radio transmitter which may interfere with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin pumps, etc. It is recommended that a minimum separation of 15 cm be maintained between the phone and an implant. Your doctor or the manufacturers of such equipment will be able to give you any advice you may need in this area.

Hospitals

Always make sure that your phone is switched off in hospitals when so instructed by warning signs or by medical staff.

Road safety

Do not use your phone when driving. In order to give your full attention to driving, stop and park safely before making a call. You must comply with any current legislation.

Distance of operation

This phone model has been tested and meets radiofrequency exposure guidelines when used as follows:

- against the ear: place or receive a phone call and hold

the phone as you would a wireline telephone,

- body worn: when transmitting, place the phone in a carry

accessory that contains no metal and positions the phone a minimum of 1.5 cm form your body. Use of other accessories may not ensure compliance with radiofrequency exposure guidelines. If you do not use a body worn accessory and are not holding the phone at the ear, position the phone a minimum of 1.5 cm from your body,

- data operation: when using a data feature, position the

phone a minimum of 1.5 cm from your body for the whole duration of the data transmission.

Environment

Packaging

To facilitate the recycling of packaging materials, please obey the sorting rules instituted locally for this type of waste.

Batteries

Spent batteries must be deposited at the designated collection points.

The product

The crossed-out waste bin mark affixed to the product means that it belongs to the family of electrical and electronic equipment.

To promote the recycling and recovery of waste electrical and electronic equipment (WEEE) and at

the same time safeguard the environment, European regulations require you to obey the sorting rules instituted locally for this type of waste.

Description

Red key

: Long press: Switch on/off. In a call context: Reject a call - hang up

In menus: Return to idle screen

Green key

: In call context: Call/Receiving a call/Hands-free mode

WARNING:

do not use the phone in hands-free mode near to your ear, or

you may suffer hearing loss.

Right programmable key:

In idle screen: Access to certain functions (shortcuts) In menus: Access to the selection shown on screen in the tab (*)

Left programmable key:

In idle screen: Access to certain functions (shortcuts) In menus: Access to the selection shown on screen in the tab (*)

The navigator allows you:

- to navigate in the various functions pressing the relevant part (up, down,

right, left)

- to confirm your selection pressing the central part

In idle screen, pressing the navigator displays the main menus icons Pressing the navigator followed by one of the twelve keys of the keypad, you can display a menu directly.

When composing a message: Short press: switches from one input mode to

∗

another (upper case/lower case, 123 mode). Long press: activate/deactivate T9 mode

When composing a message: Long press: modifies the T9 mode language.

Short press: displays the symbol table.

In idle screen: Long press: Silent mode. In call reception mode: Short press: stops ring tone. In ring tone setting mode: Short press: Activate / deactivate ring tone

Long press: Stops sound in video or message playing, or in a game A long press on the keys 2 to 9 directly displays the phonebook

2 to 9

(*) In this manual, when a function is chosen by pressing on this key,

square brackets are used (e.g.: [

(Function available depending on model)

Save

]).

The side keys

Set the volume (short press) Change to the next or last piece of music (long

press)

access music player mode (long press) play or pause music (short press)

Idle screen

The idle screen may contain the following information:

The title bar icons

Battery (if it flashes red, the battery must be charged immediately)

Silent mode (the ringtone is off)

Only emergency call is possible

Signal strength level (between 0 and 5 bars)

Message received (read your message), flashing:

memory full (delete some messages)

Grey: EDGE network unavailable

Black: EDGE connection Flashing: Connection on hand

Grey: GPRS unavailable

Black: GPRS connection Flashing: GPRS connection on hand

WAP connection

First use: installing the SIM card and the battery

To use your phone, you need a card called SIM card. Ensure that your SIM card is a 3 V SIM type that is

compatible with your phone. Inserting an incompatible card will be indicated by a message when your phone is switched on. Contact your operator.

WARNING

This card must be handled and stored with care in order not to be damaged. If you should lose your SIM card, contact your network provider immediately. Please keep your SIM card out of reach of young children.

Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may be asked for it in the event of your phone being stolen, in order to prevent it from being used, even with a different SIM card. In order to display the IMEI on your phone's screen, type: *#06#.

The SIM card is inserted under the phone's battery. Ensure that the phone is switched off and the charger disconnected.

1 Slide the SIM card, with cut corner as shown on the

phone, into the card holder with fold face down.

2 Place the battery by positioning first the top of it, as

shown on the battery.

3 Place the back cover, clicking in first the upper part

then the lower part.

Removing the back cover

Proceed as follows to remove the back cover (in case of replacement of the battery or the SIM card, for instance): Turn the phone back. Use the notch (1) as a lever to lift the cover (2).

Necklace attachment

You can insert a necklace or wrist strap into the notch located in the right bottom of the inside part of the phone.

Inserting the memory card

- Open the protective cover of the slot located on the side

of the phone and insert the memory card pushing it until it clicks into place.

- To remove the card, first make sure that no application is

accessing the card, then slightly push the top edge of the card to release it and pull it out of the slot..

WARNING

The memory card is very fragile. Take care when you insert or remove the memory card. Some memory cards must be formatted with a PC before first use with the phone.

Getting started

When you switch on your phone for the first time, follow instructions displayed on the screen.

If access to the SIM card is protected, the device prompts you to enter the PIN number:

Enter the code SIM card was issued. These digits do not appear on the screen for security reasons. After pressing [ settings and switches on again ; enter your PIN code again then the date and time, make your choice for the following settings: time zone, daylight savings, skin, wallpaper, screensaver, ring tone, volume, vibrate and voicemail number. If there are contacts saved in your SIM card, you are invited, if you wish, to copy them in the phone contacts memory.

Network

If the network’s name appears, calls are possible on your operator's network. If the letter R and a network name are displayed, calls are possible on a roaming network provider.

between 4 and 8 digits given to you when the

], the phone activates the SIM card

WARNING

If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:

- Enter the PUK (Personal Unblocking Key) code

provided by your operator, and validate.

- Enter your PIN number and validate.

- Enter your PIN number again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the SIM card is definitely locked. You must then contact your operator to obtain a new card.

If the letter E is displayed without any network name, only the emergency services are accessible (ambulance, police, fire brigade). If the network icon flashes, the phone is in permanent search mode. There is no network available. The signal strength indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better reception in order to call in good conditions.

First call

Dial the number you want to ring. Press the green key. During the call, the call in progress icon flashes on screen and tones may indicate the establishment of the call. While a call is connecting, the phone icon is flashing. You can adjust the sound level (volume) using the navigator

or the side keys. At the end of the conversation press the red key to hang up.

International call

Press 0 (hold down) to display « + », then dial the country code without waiting for the dial tone, then the number of the called party.

Emergency services

Depending on the network you can obtain the emergency service with or without SIM card or when the keypad is locked. It is enough to be in an area served by a network. To obtain the international emergency service, dial

112

then press the green key.

Receiving a call

When you receive a call, the number of your caller is displayed when it is presented by the network.

Press the green key to answer, and speak. To refuse the call, press the red key.

To stop the ring tone or the vibrate, without refusing the call,

press

Hands-free mode

To change to hands-free mode during a call, make a short press on the green key then press [ confirm activation of the amplified mode.

WARNING:

in this mode do not bring the phone up to

your ear.

All the numbers corresponding to incoming and outgoing calls are logged in the list of recent calls.

When on a call, pressing [ access to different functions.

Pressing [

Mute

temporarily when you want that your correspondent does not listen.

] allows you to switch off the microphone

Options

Yes

] to

] allows you to have

Using your phone

Improving antenna performance

The antenna is integrated in your phone, under the back cover at the top. Avoid putting your fingers on this area when the phone is switched ON.

Increase the battery life of your phone

- Don't press the keys when not necessary: each keypress

activates the backlight, and uses much power.

- Activation Bluetooth function reduces the phone battery

life. We advise you to deactivate it when not in use.

Charging the battery

Your phone is powered by a rechargeable battery. A new battery must be charged for 4 hours at least before being used for the first time.

When your battery has been discharged, the empty battery icon flashes. In this case recharge your battery for at least 15 minutes before making any calls in order not to be cut off quickly.

To recharge the battery:

Connect the charger to a socket. Plug the end of the cable into the bottom connector of the

phone. The phone is then charging up. The battery icon scrolls up and down to indicate that it is charging. When the battery is

fully charged, the charging stops on its own. Disconnect the cable.

When charging, the battery may warm up, this is normal.

WARNING

If the battery has entirely discharged, the phone cannot start. Plug the phone to the charger. The phone will switch on after a few minutes of charge. You can use the phone again when the displayed on the screen.

WARNING

There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire. Do not short circuit it. The battery does not have any part that you can change. Do not try to open the battery casing. Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue. The use of other types of chargers or batteries may be dangerous or invalidate the warranty. Used batteries must be disposed of in the appropriate places. We advise you to take the battery out if you plan not to use the phone for extended periods. You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery. The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power supply plug, etc).

Start

option is

Phonebook

Using the phonebook

According to the selection made in the Settings/Display/Contacts menu, the phonebook displays:

- the list of the SIM card contacts (icon when a contact

- the list of the phone contacts (icon when a contact is

- all the contacts.

You can search for a contact quiclky by typing the first letters (up to three). You can display it by pressing OK.

Storing a new contact

By default, the contact is stored in the list of the phonebook which is displayed (SIM or phone). When there are both lists, you must select the list to store it.

- Press

- Enter the last name and press

- Enter the number and press OK.

Note:

phone memory (email, address, ringtone, photo, etc.).

- Press [

Calling a contact

Several ways:

- Select a contact. Press

- Select a contact, press OK, his number is displayed,

- Direct call from the idle screen (only for the contacts

is selected) or

selected)) or

Add contact

you can fill other fields if you store the contact in the

Save

press [

Call

stored in the SIM card memory): type the number with which the contact was saved then the number then

] to store it.

the green key to start the call.

] to start the call.

, the number is displayed, confirm.

∗

(example : 21 ∗) or

Contact options

To display the various options, select a contact and press [

Options

Modifying a contact

Modify what you want and validate then select the modifications completed.

Sending a message

To send a SMS or a MMS to a contact (see chapter

Messages

Sending by

To send a contact details by SMS, MMS or Bluetooth (see chapters

Messages

and

Connectivity

Copy to SIM / Copy to mobile

This allows you to copy your phonebook contacts from one memory to the other. Only the name and the first phone number will be copied.

Export

The contact details are copied as a visit card in a Multimedia directory.

Memory

Select

SIM

Phone

Phone: the screen displays the amount of memory used. The memory capacity is shared between the phonebook and various other features. If you lack memory, check if you can free some space. SIM: available memory only for contacts.

Delete/Delete all

This allows you to delete the contact selected or all the contacts.

and validate.

Save

once

Set as my card/Business card

The details of a contact stored in the phone memory can be saved in a business card.

- Select a contact and press [

- Select

Set as my card

Business card

send it by SMS or MMS.

Copy SIM Æphone / Copy phoneÆSIM

This allows you to copy all the SIM card contacts to the phone memory and vice versa.

Add to mailing list

This allows you to add a contact to a mailing list.

Settings

List choice

: This menu allows you to select the default phonebook (SIM, Phone, SIM and Phone) displayed when the phone switches on.

Sorting

: This menu allows you to select the way to sort

contacts in the phonebook (by name or first name).

Mailing lists

A mailing list allows you to group contacts: this list can be used to send messages easily to all the list contacts.

- In the phonebook, select the

the navigator rightwards.

Options

- Press [

- Select

Add mailing list

- Select the list type (SMS or MMS).

- Enter a name and press the navigator.

- Then, on a list press [

each time you want to add a contact in the list.

Options

and [OK]. The details are saved

. Then you can read it, modify it or

Options

Mailing Lists

]. Select

tab pressing

Add contact

Messages

From this menu, you are able to send SMS, MMS and email. MMS is a Multimedia Message Service, which allows you to enclose photos, audio files, and others rich contents to your messages; these messages can even be composed of several slides. MMS are differently charged to SMS are. Please contact your network provider to get more information on their cost and the service availability.

Creating a text message (SMS or MMS)

- Select

Messages/Create message

- Type your text. The T9 mode is applied by default.

Using T9 Mode

The Easy Message T9™ mode helps you to easily write your messages.

The language used is the one selected on the display of the phone (if the language selected is not compatible with the Easy Message T9™, the English language will be automatically selected).

Press once the key corresponding to the letter chosen and compose the word by continuing to press the keys corresponding to the various letters without paying attention to the display: the word is highlighted.

The same sequence of keys pressed can correspond to several words, existing on the dictionary. If the word that appears is not the word you expected, press the navigator upwards to scroll through the words corresponding to this key sequence.

then

SMS

MMS

Once you agree on the word proposed on the screen, press the navigator rightwards to validate it or on the validates and inserts a space after the word), and go on writing the next word. If the word you are expected is not proposed, please add characters until you get the message [

Yes

] and validate if the word displayed suits you or modify

this word before adding it in the dictionary.

Notes:

- You may change to capital letter, small letter or 123

(digit) mode at any time by pressing and releasing the

key.

- You may also obtain the digits by pressing and holding

the key you want.

- Changing the language in T9 mode: press and hold the

key.

Using another mode

To deactivate T9 mode press and hold the key. The ABC mode then applies: each time you press a key this corresponds to the letters indicated on the key (for example, press 2 twice to display B). As in T9 mode, you may change to capital letter, small letter or 123 (digit) mode at any time by pressing and releasing the key.

Note

: you may change mode by pressing [

Punctuation characters

Punctuation characters are obtained by pressing the 1 key (except in

123

mode), or with the help of

access by briefly pressing

Accented characters

Accented characters are generated automatically in T9 mode.

key (which

Add a word

Options

Insert

mode (fast

? Press

In ABC mode accented characters are available by pressing the key supporting the non-accented character repeatedly.

Saving the message

- Select

Save

immediately or if you want to send it several times. It is saved in the or

- Select

is saved in the

Sending the message

- Once the text entered, press the navigator or press

[

Options

- Enter the receiver’s number or take it in your phonebook

pressing [ contacts list in your phonebook.

- Select

Receiving messages

When you receive a message, the phone plays the ring tone that you selected, and a message icon comes on the screen of your phone. If you do not read the messages, this icon remains displayed on the screen. When it flashes, the memory is full. Note that you have two different possibilities for receiving MMS: automatically or manually; if « manual mode » is activated, then you will receive only a notification in your Inbox, meaning that a MMS is available on the MMS Server; select Retrieve in the options when you want to retrieve the MMS from the network.

if you do not want to send the message

Drafts

menu.

Save as template

Options

Send

to use it again as a template. It

Templates

menu.

Contacts

. You can also select a

Messages menu

Inbox

Messages are listed in chronological order, the latest one being displayed first.

The quantity of Not Read and Not Retrieved messages is shown. Not Retrieved and Not Read messages are shown in bold.

Outbox

This menu displays the messages that have not been sent. You can therefore send them again.

Sentbox

The

Sentbox

if you activated the option

Options

Too many messages saved will quickly fill up the available memory and no further messages will be received.

Drafts

This menu contains all the messages saved. If you select a message and press the navigator, you can modify it.

If you want to send it, select and select

Tem pla te s

When composing a message, if you selected the

template

e-mail

This menu contains the e-mails received, sent, not sent, the drafts and a personal directory to sort them.

Options

This menu allows you to select various sending and receiving options.

menu is used to store all your sent messages

menu.

Send

option, the template is saved in this menu.

Store sent messages

Modify

then press [

in the

Options

Save as

]

Memory

SMS

: displays the memory available in the SIM card and in

the phone for saving SMS.

MMS and email

MMS and emails saved.

Local info.

This menu is used to activate reception of information broadcast by the network. You can choose whether you want to receive this information or not (please contact your network provider).

Call voicemail

This function allows you to call your voicemail. This number depends on the operator.

Mailing lists

This menu displays the mailing lists created in the phonebook. To display the different options, press [

Add mailing list

Modify name

name.

Add contact

list.

Properties

the number of contacts.

Delete

: displays how much memory is used by the

: allows you to create a new mailing list.

: allows you to modify the mailing list

: allows you to add a contact to the mailing

: allows you to see the type of mailing list and

: allows you to delete the mailing list.

Options

e-mail


Before you can use the e-mail function you must create an account and, depending on the operator, a connection profile.

Ask your operator for the conditions of use for the e-mail service. You can consult other e-mailboxes from your phone.

Procedure to follow from an operator's server

The procedure to follow to open an account may vary according to the operator and country. Ask your operator.

Procedure to follow from your mobile phone

The first time you use it, your phone automatically suggests creating one. Enter a name and press Press [

Options

parameters to be filled in for the account:

- e-mail address (example: 0612345678@operator.country)

- SMTP server (examples: authentication: yes, domain:

operator, server: smtp.operator.country, port number: 25)

- reception server: POP3

- download mode: choice to receive e-mails

- POP3 server: (examples: login: 0612345678, password

(information provided by the access provider), authentication: yes, server: POP3, port number: 110)

Save once all the parameters have been entered.

Accessing the e-mail functions

To write and send an e-mail: then

To access your accounts:

Accounts

To access your sent, received or draft e-mail folders:

Messages/email

] then select

Modify

to access the list of

Messages/Create message

Messages/Options/email

This menu allows you to take photos and use them for different purposes. For instance, you can send them to another phone or an Internet address, store them, use them as wallpapers or screen savers.

Taking and saving a photo

Settings before taking a photo

Zoom

: To activate zoom, use the navigator upwards or downwards or the side keys (

Note: if the zoom selected does not match with the storing

format, the photo is automatically saved in an appropriate format

Other settings

Activate timer

time delay.

Modes

taken in four shots (useful for taking pictures of moving subjects, for example).

Effects

Exposure

Save new pictures

the photo will be saved (phone or memory card).

Click sound

taking a photo.

Photo quality Photo format

will be saved

Go to video

and -).

(pressing [

Options

: to take a photo with a 5, 10 or 15 second

(normal or burst): in burst mode, the photo will be

: to select an effect.

: to select luminosity.

: to select the sound you will hear when

: to select the photo quality. : to select the format in which your photo

: to take a video.

]):

: used to select the location where

Taking a photo

- Select the

- Press the navigator or on the side key, the photo is taken

Warning:

previous screen and lose the photo you have just taken.

- Press the navigator if you want to send the photo

- Press

Options once the photo taken

Camera

into your phone display and position your subject. Move your phone to position your photo.

and stays on the phone display.

immediately by MMS.

Save

then different options are displayed.

•

Send By:

e-mail or Bluetooth.

•

Rename Add to contact

•

contact saved in the phonebook.

•

Use as

or screensaver.

Editor

•

Zoom: allows you to magnify certain parts of your photo,

Adjustment: allows you to improve contrast, Emboss: allows you to modify a photo with an

embossed grey tint,

Negative: allows you to change a photo into negative, Grey Scale: allows you to change color into black and

white, Contrast: allows you to increase or decrease the contrast of your photo,

Sharpen: allows you to sharpen a photo, Blur: allows you to add blur to a photo, Sepia: allows you to change colors into sepia, Shape: allows you to shape a photo, Brigthness: allows you to increase or decrease the

brightness of a photo,

menu. The camera is now on. Look

if you press [

: allows you to select the photo as a wallpaper

: various options to modify a photo.

Back

], you will go back to the

to save your photo, a progress bar animates

allows you to send the photo by MMS,

: allows you to modify the name of a photo.

: allows you to assign a photo to a

Solarize: allows you to increase or decrease the solarize of a photo, Saturation: allows you to increase or decrease the

color saturation. If there is not enough memory to save the photo, a warning message appears, prompting you to confirm whether you want to go on.

Note:

using the camera during a call may disturb the call quality.

Video

Taking a video

- Select the

- If necessary, select the following settings pressing

Press the navigator to record then press [ want to stop recording.

Note

maximum size available is reached. Press [

Note:

Video

menu.

[

Options

Video sound

•

sound when recording a video.

•

Video restriction Save new videos to...

•

video is saved (phone or memory card).

•

Go to camera

: the phone automatically stops recording when the

Options

•

Record a video Playback

•

Send By

or Bluetooth.

Rename

•

Delete

the videos are saved in the phone with a .3gp format.

: allows you to record wether not the

: allows you to choose a video size.

: allows you to select where the

: to take a photo.

] to display the options:

: allows you to take a new video.

: allows you to play the video.

: allows you to send a video by MMS, e-mail

: allows you to modify a video name.

: allows you to delete a video.

Stop

] when you

Multimedia

The

Multimedia

multimedia objects recorded in your phone and the downloaded objects (photos, videos, ringtones, musics, etc.).

There are two tabs that you can select pressing the navigator rightwards or leftwards:

Phone

My miniSD™

memory card in your phone).

You can copy the multimedia objects from the card to your phone.

To display the various options of each directory, press

Options

[

Browse

Rename Delete

by the user).

New folder New

a sound.

Format

phone. memory will be deleted.

Memory

the multimedia objects.

For each object a list of options is available (view, send, delete, etc.).

menu contains the directories of all the

tab (phone memory)

tab (available if you have inserted a

: displays the list of the objects.

: modifies the directory name.

: deletes the directory (only the directories created

: create a new directory.

: allows you to take a new photo or video or to record

: this option deletes all the internal memory of the

Warning

: all the multimedia objects saved in this

: displays the memory used and available for

Connectivity

You can exchange with other devices (PC, mobile phones, personal assistants, printers, etc.) various data: pictures, sounds, photos, videos, ToDo tasks, organiser events, contacts, etc.

Data exchange can be done through:

- a USB cable,

- a Bluetooth connection.

Note

: see chapter compatibilities of the accessories with your phone. If you have inserted a memory card in your phone, it is considered as an additional memory in the Windows explorer files directory; you can copy/paste. If you want to exchange objects between the phone's memory and a PC, you simply need to connect the phone to the PC with a USB cable. A removable disc appears in the Windows Explorer tree structure; you may copy/and paste into it.

Note

: If a call comes in during an exchange of data with your PC, the link will be interrupted and will have to be manually re-started.

Bluetooth

This menu allows you to set your phone Bluetooth connection in order to communicate with other devices equipped with Bluetooth: for example, an audio connection with a headset, a stereo headset, a car kit or a data connection with a PC.

Bluetooth is a free wireless connection, with a 10 metre maximum range.

Paired devices

may connect with Bluetooth link with your phone (for instance: headset).

Technical features

: allows you to search for devices which

to know the

Mode

: allows you to activate the phone Bluetooth

connection.

- Off: Bluetooth connection impossible.

- On and hidden: your phone is not detected by the other

devices but the phone detects the other devices.

- On and visible: your phone can be detected by another

device.

- On and always: your phone can be detected by another

device and remains detected as soon as the Bluetooth connection is activated.

My Bluetooth name

phone for the Bluetooth connection. This name is displayed on the devices connected.

: allows you to assign a name to your

Car kit or headset

This menu allows you to configure the options of the phone with a pedestrian kit or a car kit (Automatic response, Switch off, Kit volume).

USB mode

This menu allows you to select a mode to connect the phone to a peripheral with the USB cable available as an accessory.

At plugging-in

connecting a USB cable, the phone asks you to select the mode you want.

Modem

and a PC.

Pictbridge

photos) without using a PC.

Mass storage for PC

phone (memory card inserted in the phone or phone internal memory) and a PC.

: if you select this option, when

: to exchange data between the phone memory

: to connect the phone to a printer (printing

: to exchange data between the

SyncML

You can synchronize your phonebook, your organizer or your ToDos with your archives stored in your operator’s

network depending on the options offered by your operator. The local synchronisation with your computer is only computer originated, from Wellphone software (available

from http://www.wellphone.com); you have only to activate Bluetooth, or configure your USB connection in your phone.

Music Player

In this menu, you can listen to music and access all the functions associated with it..

Important note

You can still use your phone’s other functions while you are listening to music.

If you haven’t yet stored any music, the phone will ask if you want to download some music. If you answer Yes, it connects to the WAP.

You may also download music by connecting your phone to a PC using a USB cable or Bluetooth.

Music player mode

You can listen to music either through the menu or by pressing the side key. When you listen to music its title is displayed on the idle screen. You may use the side keys for the following functions:

set the volume (short press)

change to the next or last piece of music (long press)

access the music player (long press) play or pause music (short press)

Music Player

Operation of the keys in the Music player

Back

[ listen to music.

Various options to listen to music

Play options

music.

Repeat options

replay a list.

Equalizer

View

Sound effect

Library

- used to create playlists.

- used to sort music by album, artist or genre.

- contains various music directories. The

Recently played, Most played

directories are filled automatically by the phone.

Accessories

You may also listen to music using a hands-free kit or Bluetooth stereo headset (AADP profile).

1 - next/last piece (short press)

2 - fast forward/rewind (long press) 3 - play/pause

]: used to exit music player mode while continuing to

: used to select a play order for listening to

: used to choose whether or not to

: used to modify the high and low settings.

: used to view the music as a bar chart.

: used to choose various sound effects.

Downloaded

and

All my tracks

FM Radio

Important

: you must connect the hands-free kit to operate the FM radio. The radio antenna is contained in the hands-free kit wire.

Note

: frequency range available: 87.5 MHz to 108 MHz (in

steps of 100 KHz).

Music player mode

Once you have connected the hands-free kit, select the Music player menu then Radio FM.

Options

] is used to access the different radio functions:

[ select a frequency, save several stations in a list (3 lists of 10 stations), mono or stereo mode.

When you listen to the radio, the station number is displayed on the idle screen. The side key functions are identical to those used to listen to music. Operation of the keys while listening to FM radio:

1 - next/last station (short press)

Back

[ the radio.

2 - change in steps of 0.1 MHz (short

press) - find stations (long press) 3 - play/pause

]: used to exit the menu while continuing to listen to

WAP

WAP (Wireless Application Protocol): a protocol that translates the Internet language into WML and HTML languages that can be read by a phone. The WAP function allows you to log onto certain Internet sites. You can log onto sites that allow you to download ringtones, icons, animated screensavers, Java™ applications, videos to your phone.

The WAP Menu

The WAP navigator is under licence:

The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all or part of these softwares.

Go to URL

: this menu allows you to input an Internet

address directly.

Bookmarks

: allows to store bookmarks (addresses of Internet sites). You can receive bookmarks and add them to this list.

History

: backward and forward navigation of the pages

displayed are kept in memory.

Browser settings Profiles

configuration settings or to configure others providers’settings.

: allows you to select or modify your provider’s

Connection time out:

which the call is automatically disconnected if you have forgotten to log off from a service.

is used to choose the time after

WAP Logging on

The connection to a WAP service on the GPRS network is not cut if an incoming call is received. You can answer the call.

If you are logging onto the GSM, GPRS or EDGE network, the @ symbol flashes, the metering of the cost of the call starts as soon as it stops flashing.

Downloading objects

Some WAP sites allow you to download ringtones, icons, animated screensavers, games or JAVA™ applications.

WAP Logging off

To log off, press the red key. The logoff happens automatically after a few seconds of inactivity if you forget to log off. This period is defined by the linger time setting.

GPRS/EDGE

A flashing icon indicates that the phone is logging onto a GPRS or EDGE network. A non-flashing icon indicates that the GPRS or EDGE network is available; if the icon is dark, it indicates that the phone is logged onto the GPRS or EDGE network.

This icon is not displayed if the GPRS or EDGE network is not available or if the SIM card inserted in your phone does not include the GPRS or EDGE service. It may also disappear when accessing WAP services if the connection uses the GSM network instead of the GPRS or EDGE network.

Games

Applications

Your phone contains one game. You can download more. You are the owner of a SAGEM mobile phone which gives you the ability to download applications and games to be executed on your phone thanks to the built-in Java™ engine.

However, receiving applications from everywhere implies some basic knowledge of the possible effects of such

We advise you to dwonload certified games or applications from your operator sites or from www.planetsagem.com. By default, the connection URL of your operator or of PlanetSagem is configured in your phone. If no connection URL is configured, by selecting the

games

new profiles which allow you to download games or applications.

When you select a game or an application, the

Settings/Connection

allows you to configure a profile which only be used by the game or application to connect to the network (to exchange scores for example) but is not used to download new games or applications.

download.

General

Options

] key)

menu, you display the WAP function to configure

menu (displayed with [

Applications

(see chapter

Calendar

This menu gives you access to your diary and get to a day, week, month or specific date. It lets you add events, access the global actions for all the events and manage them by event category. This menu lets you add events, manage events by category, see the available memory and delete all the events.

Games

Add Written Event/Add Vocal Event

events of the text or voice type. Fill in the different items. Save the event.

Delete

: allows you to schedule the deletion of events

that took place more than one day, week or month ago.

Memory

: allows you to view the memory capacity used

by the different functions of your diary.

Delete all

: allows you to delete all the events from your

diary.

Settings

Phone settings

Silent mode

This menu allows you to switch to Silent mode. Silent mode can also be accessed via the idle screen by

holding down the

When the phone is in silent mode, this relevant icon appears on the idle screen. In this mode, the ring tone will not function, except for the alarm clock.

Note:

remain after switching off your phone.

Ring tones

This menu allows you to allocate a ring tone to different functions (call receiving, message receiving, alarm).

Vibrate

This menu allows you to activate the vibrate mode for calls.

Languages

This menu allows you to choose your phone's display language.

Beeps

This menu allows you to activate a beep for the battery, the keypad or the network.

Date / Time

These menus allow you to set the various date and time settings (format, display, time zone, daylight savings,etc).

key.

if you have activated the silent mode, it does not

Display

This menu allows you to customize your screen by choosing a different presentation.

Wallpape r

This menu allows you to display the background picture of the idle screen.

Skins

This menu allows you to select the background picture when displaying menus.

Screensaver

This menu allows you to display an animation when the phone is in standby mode.

Operator logo

This menu allows you to display your operator's logo on the idle screen.

Energy saving

Economic mode

You can select one of the following eco modes:

double lock

the battery life. The screen is off and the keypad is locked. To exit this mode: press OK, the red or green key to turn on the backlight and display time. Press ∗ OK to unlock the keypad.

unlocked

screen is off and the keypad is always active. To exit this mode: press press any key to light up the screen.

none single lock

To exit this mode: press the red key. To turn on the backlight and display time, press OK.

: this mode gives the maximum efficiency of

: this mode decreases the battery life. The

: the economic mode is deactivated.

: the screen is off and the keypad is locked.

Backlight

Screen only

Full backlight

up.

Note:

backlight will be automatically turned off to save battery life.

Contacts

This menu allows you to select the way to sort contacts in the phonebook (by name or first name) and the filter applied on the contacts list display (SIM contacts, phone memory or both).

Calls

The Calls menu allows you to manage all the calls functions (call forward, displaying numbers, call waiting, voicemail number, etc.).

Call forward

Depending on your subscription, this service allows you to forward incoming calls to a different number or to the voice mailbox.

View last calls

This menu allows you to display the calls log (dialled, received or missed calls).

Fast access to the calls log from the idle screen: press the green key.

Counters

This menu allows you to consult the duration of the up calls. It can also be used to check the volume of data exchanged

in GPRS.

Display numbers

This menu allows you to modify the status of the display

: only the screen is lit up.

: both the screen and the keypad are lit

in any case, after a certain time of inactivity, the

number function. Select one of the options given: Anonymous mode, My number, Callers’ number.

Anonymous mode

You have the ability to mask your number on the phone of the person you are calling.

Preset:

network default mode.

No:

you choose not to activate anonymous mode and

then to display your number.

Yes:

you choose to active anonymous mode and then

not to display your number.

Call waiting

(Operator-dependent service) During a call, you may be informed that a caller is trying to

reach you: you hear a special tone. The caller's identity is displayed on the screen (name or number).

activate, deactivate, or status

You can service in order to check if it is active or not.

During a call, if a second caller tries to contact you, the screen displays the call warning.

Auto redial

This menu allows you to call back a caller you have not managed to reach.

You can set the redial function to inactive, on request or systematic. If you choose your caller automatically if his number is busy.

On demand

, your phone will offer to redial

of the call waiting

Blacklist

The blacklist is used to limit failures on automatic calls (calls generated by the automatic redial function or by applications: data, fax for example).

When several automatic calls failed with a number (number busy or unknown), this number is put in the blacklist and no automatic call will be done with this number any more until you delete it from the blacklist.

Note

: this function does not apply to the calls performed

manually.

Voicemail

This function is used to record your voicemail access number.

This number will be used during a call to the voice mailbox using the programmable keys.

New number

After an incoming or outgoing call with a number not stored in the phonebook, this option allows you to activate or deactivate a request to store the number in the phonebook.

Networks

This menu allows you to configure network preferences. Choose

Selection

one of the networks accessible in the area in which your are located.

Choose Choose

PCS (depending on model). Choose the GPRS network: always, or only when needed (when

launching a data connection).

to activate (automatically or manually)

Preferred

to view all the pre-registered networks.

Network type

GPRS

to select your network: GSM-DCS or

to select the way you want to be attached on

Security

This menu allows you to configure your phone's security settings.

PIN number

This menu allows you to activate and modify your phone's PIN. To modify the PIN, select Enter old PIN and validate. Enter new PIN twice and validate. To activate or deactivate the PIN, select the menu and [

Select

Enter PIN and validate. Select

Activate

PIN2 number

You have a second PIN number to allow you to access certain functions.

These functions may or may not be available depending on your SIM card.

Proceed as above in order to activate, deactivate or modify PIN number 2 of your phone.

Phone code

The Phone code menu allows you to activate the phone code so that it is requested and checked whenever the phone is switched on if a different SIM card is used. This code is automatically linked to the SIM card installed when the phone is activated, for example to protect the phone if stolen.

Check

Select Enter 0000 (the factory code, by default) and validate. Select

Activate

To modify the phone code, select

and [

Deactivate

Select

Deactivate

Modify PIN code

and validate.

Modify

and [

Select

Control PIN

and validate.

Enter old phone code and validate. Enter new phone code and validate. Enter phone code again to confirm it and validate.

Confidentiality

This menu allows the activation or deactivation of automatic deletion, after power off/on, of outgoing calls, messages stored or organizer events.

Operator

This menu allows you to modify the call barring. Access to this service depends on your type of subscription.

Call barring

This menu allows you to block the sending or receiving of certain calls.

Before you can use this service, a password will be provided by your operator when you take out your subscription. Access to this service depends on your subscription type. To activate call barring :

- Select incoming or outgoing calls.

- Select the call type on which you want to activate call

barring.

- Select:

• either All,

• or If roaming, if you are away from your home country

and if roaming is available, only incoming calls will be blocked.

- Select Activation and enter password.

Fixed dialling

This menu allows you to restrict the outgoing calls. The availability of this menu depends on your SIM. Proceed as for any other phonebook.

When activating this function, only the numbers stored in the phonebook can be called. This phonebook is linked to the SIM card, and its size depends on the card's capacity.

Cost

This menu allows you to control the cost of your calls. These functions may or may not be available depending on

your SIM card.

Player settings

This menu allows you to select the play, view and repeat music options.

Browser settings

This menu allows you to set various parameters needed for WAP connection (see chapter

WAP

Camera

This menu allows you to set the camera features (timer, click sound, format, quality).

Video settings

This menu allows you to set the video features of your phone.

Video sound:

sound when recording a video.

Video size restriction:

a video size.

Shortcuts

(Function available depending on model) This menu allows you to allocate functions to the left and

right programmable keys.

This menu allows you to select or not the

This menu allows you to choose

Storage

This menu allows you:

- to format the internal phone memory.

- to select (phone memory or memory card) where the

multimedia objects are saved.

Keys checking

When activating this choice, you will be warned when a using right of a multimedia object (ringtone or wallpaper for instance) will soon expire.

Help

This menu allows you to activate or deactivate the display of the help in the phone.

Technical features

Weight

: 95 g

Size

: 106 x 46 x 15,4 mm

Original battery Camera Video camera Multimedia objects supported

- Audio formats: iMelody, Midi, wave, MP3, AAC, AAC+,

enhanced AAC+, AMR

- Graphic formats: wbmp, bmp, png, gif, gif animés, jpeg,

3gp, mpeg4 depending on model

Size of memory available for messages

Size of memory available for MMS, the phonenook and the multimedia objects: up to 32 Mb

Maximum size of each message

- SMS: < 160 characters

- MMS: < 100 Kb for outgoing messagezs, 300 Kb for

incoming messages (depends on the phone configuration and on the operator reservations)

FM frequencies Compatible profiles for accessories

- File transfer: FTP

- Stereo headset: AADP

- Car kit - Headset - Hands-free kit: HSP and HFP

- Object transfer: OPP

- Modem: SPP/DUNP

Using temperature

: Li-ion 950 mAh

: 1.3 megapixels (interpolated to 2 megapixels)

: 87.5 MHz to 108 MHz (100 KHz step).

: from - 10 °C to + 55 °C

: 100 SMS

Conformance Document

Care and safety information

SAR

THIS MODEL MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES

Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organization ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health.

The guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest SAR value for this device when tested at the ear was devices offer a range of functions, they can be used in other positions, such as on the body as described in this user guide (**).

As SAR is measured utilizing the devices highest transmitting power the actual SAR of this device while operating is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum level required to reach the network.

The World Health Organization has stated that present scientific information does not indicate the need for any special precautions for the use of mobile devices. They note that if you want to reduce your exposure then you can do so

(*) The tests are carried out in accordance with

international guidelines for testing.

(**) Please see the Distance of operation section about

body worn operation, page 7.

XXX

W/kg (*). As mo bile

by limiting the length of calls or using a 'hands-free' device to keep the mobile phone away from the head and body. Additional Information can be found on the websites of the World Health Organization (http://www.who.int/emf

)

Advice for limiting exposure to radiofrequency (RF) fields

For individuals concerned about limiting their exposure to RF fields, the World Health Organization (WHO) provides the following advice:

Precautionary measures: Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If individuals are concerned, they might choose to limit their own or their children’s’ RF exposure by limiting the length of calls, or using "hands-free" devices to keep mobile phones away from the head and body.

Further information on this subject can be obtained from the WHO home page http://www.who.int/peh-emf sheet 193: June 2000.

To promote the recycling and recovery of waste electrical and electronic equipment (WEEE) and at the same time safeguard the environment, European regulations require you to obey the sorting rules instituted locally for this type of waste.

WHO Fact

End User Licence Agreement (EULA), for the software

CONTEXT AND ACCEPTATION OF THE AGREEMENT

You have acquired a Mobile Phone device ("DEVICE"), manufactured by Sagem Communication (SAGEM), that includes software either developed by SAGEM itself or licensed third party Software suppliers ("SOFTWARE COMPANIES") to SAGEM with the rights to sub-license it to the purchaser of the device. Those installed software products whatever their company of origin, and wherever the name of the company of origin is indicated of not in the DEVICE documentation, as well as associated media, printed materials, and "online" or electronic documentation ("SOFTWARE") are protected by international intellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights reserved. IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT ("EULA"), DO NOT USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY CONTACT SAGEM FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND.

OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATI ON OF ANY PREVIOUS CONSENT)

SOFTWARE includes software already installed on the DEVICE ("DEVICE Software") and Software contained on the CD-ROM disk ("Companion CD"), if any is supplied with the product.

GRANT OF SOFTWARE LICENCE

This EULA grants you the following licence:

DEVICE Software

installed on the DEVICE. All or certain portions of the

. You may use the DEVICE Software as

ANY USE

DEVICE Software may be inoperable if you do not have and maintain a service account with an appropriate Mobile Operator, or if the Mobile Operator's network facilities are not operating or configured to operate with the DEVICE software.

COMPANION CD

your personal computer is included with your DEVICE. You may install and use the software component(s) contained in the Companion CD only in accordance with the terms of the printed or online end user license agreement(s) provided with such component(s). In the absence of an end user license agreement for particular component(s) of the Companion CD, you may install and use only one (1) copy of such component(s) on the DEVICE or a single computer with which you use the DEVICE.

Security Updates

rights management technology. If SOFTWARE does contain digital rights management technology, content providers are using the digital rights management technology ("DRM") contained in the SOFTWARE to protect the integrity of their content ("Secure Content") so that their intellectual property, including copyright, in such content is not misappropriated. Owners of such Secure Content ("Secure Content Owners") may, from time to time, request manufacturers or SOFTWARE SUPPLIERS to provide security related updates to the DRM components of the SOFTWARE ("Security Updates") that may affect your ability to copy, display and/or play Secure Content through the SOFTWARE or third party applications that utilise the DRM.

You therefore agree that, if you elect to download a licence from the Internet which enables your use of Secure Content, Suppliers may, in conjunction with such licence, also download onto your DEVICE such Security Updates that a Secure Content Owner has requested that SOFTWARE SUPPLIERS distribute. SAGEM and

. If any is supplied, additional software for

. The SOFTWARE may include digital

SOFTWARE SUPPLIERS will not retrieve any personally identifiable information, or any other information, from your DEVICE by downloading such Security Updates.

DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS COPYRIGHT

to the SOFTWARE (including but not limited to any images, photographs, animations, video, audio, music, text and "applets," incorporated into the SOFTWARE), the accompanying printed materials, and any copies of the SOFTWARE, are owned by SAGEM or the SOFTWARE SUPPLIERS. You may not copy the printed materials accompanying the SOFTWARE. All title and intellectual property rights in and to the content which may be accessed through use of the SOFTWARE is the property of the respective content owner and may be protected by applicable copyright or other intellectual property laws and treaties. This EULA grants you no rights to use such content. All rights not specifically granted under this EULA are reserved by SAGEM and the SOFTWARE SUPPLIERS

Limitations on Reverse Engineering, Decompilation and Disassembly

decompile, or disassemble the SOFTWARE, except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation.

Single DEVICE

DEVICE as a single integrated product. The DEVICE Software installed in the memory of the DEVICE may only be used as part of the DEVICE.

Single EULA

multiple versions of this EULA, such as multiple translations and/or multiple media versions (e.g., in the user documentation and in the software). Even if you receive multiple versions of the EULA, you are licensed to use only one (1) copy of the DEVICE Software.

Software Transfer

. All title and intellectual property rights in and

. You may not reverse engineer,

. The DEVICE Software is licensed with the

. The package for the DEVICE may contain

. You may not permanently transfer any

of your rights under this EULA with regard to the DEVICE Software or Companion CD, except as permitted by the applicable Mobile Operator. In the event that the Mobile Operator permits such transfer, you may permanently transfer all of your rights under this EULA only as part of a sale or transfer of the DEVICE, provided you retain no copies, you transfer all of the SOFTWARE (including all component parts, the media and printed materials, any upgrades , this EULA and, if applicable, the Certificate(s) of Authenticity), and the recipient agrees to the terms of this EULA. If the SOFTWARE is an upgrade, any transfer must include all prior versions of the SOFTWARE.

Software Rental

SOFTWARE.

Speech/Handwriting Recognition

includes speech and/or handwriting recognition component(s), you should understand that speech and handwriting recognition are inherently statistical processes; that recognition errors are inherent in the processes; and that errors can occur in the component's recognition of your handwriting or speech, and the final conversion into text.. Neither SAGEM nor its suppliers shall be liable for any damages arising out of errors in the speech and handwriting recognition processes.

NOTICE REGARDING THE MPEG-4 VISUAL STANDARD

visual decoding technology. MPEG LA, L.L.C. requires the following notice:

USE OF THIS SOFTWARE IN ANY MANNER THAT COMPLIES WITH THE MPEG-4 VISUAL STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO (A) DATA OR INFORMATION (i) GENERATED BY AND OBTAINED WITHOUT CHARGE FROM A CONSUMER NOT THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND (ii) FOR PERSONAL USE ONLY; AND (B) OTHER USES SPECIFICALLY AND

. You may not rent or lease the

. If the SOFTWARE

. The SOFTWARE may include MPEG-4

SEPARATELY LICENSED BY MPEG LA, L.L.C. If you have questions regarding this Notice, please contact

MPEG LA, L.L.C., 250 Steele Street, Suite 300, Denver, Colorado 80206; Telephone 303 331.1880; FAX 303

331.1879

Termination

SAGEM may terminate this EULA if you fail to comply with the terms and conditions of this EULA. In such event, you must destroy all copies of the SOFTWARE and all of its component parts.

Consent to Use of Data

SUPPLIERS may collect and use technical information gathered in any manner as part of product support services related to the SOFTWARE. SOFTWARE SUPPLIERS may use this information solely to improve their products or to provide customised services or technologies to you. SOFTWARE SUPPLIERS may disclose this information to others, but not in a form that personally identifies you.

Internet Gaming/Update Features

provides, and you choose to utilise, the Internet gaming or update features within the SOFTWARE, it is necessary to use certain computer system, hardware, and software information to implement the features. By using these features, you explicitly authorise SOFTWARE SUPPLIERS to use this information solely to improve their products or to provide customised services or technologies to you. SOFTWARE SUPPLIERS may disclose this information to others, but not in a form that personally identifies you.

Internet-Based Services Components

may contain components that enable and facilitate the use of certain Internet-based services. You acknowledge and agree that SOFTWARE SUPPLIERS may automatically check the version of the SOFTWARE and/or its components that you are utilising and may provide upgrades or supplements to the SOFTWARE that may be automatically downloaded to your Device.

. Without prejudice to any other rights,

. You agree that SOFTWARE

. If the SOFTWARE

. The SOFTWARE

Links to Third Party Sites

you with the ability to link to third party sites through the use of the SOFTWARE. The third party sites are not under the control of SAGEM. Neither SAGEM nor its affiliates are responsible for (i) the contents of any third party sites, any links contained in third party sites, or any changes or updates to third party sites, or (ii) webcasting or any other form of transmission received from any third party sites. If the SOFTWARE provides links to third party sites, those links are provided to you only as a convenience, and the inclusion of any link does not imply an endorsement of the third party site by SAGEM or its affiliates.

Additional Software/Services

permit SAGEM to provide or make available to you SOFTWARE updates, supplements, add-on components, or Internet-based services components of the SOFTWARE after the date you obtain your initial copy of the SOF TWARE ("Supplemental Components").

If SAGEM provides or makes available to you Supplemental Components and no other EULA terms are provided along with the Supplemental Components, then the terms of this EULA shall apply. SAGEM reserves the right to discontinue any Internet-based services provided to you or made available to you through the use of the SOFTWARE.

EXPORT RESTRICTIONS

SOFTWARE is subject to U.S. export jurisdiction. You agree to comply with all applicable international and national laws that apply to the SOFTWARE, including the U.S. Export Administration Regulations, as well as end-user, end-use and destination restrictions issued by U.S. and other governments.

UPGRADES AND RECOVERY MEDIA

DEVICE Software

by SAGEM separate from the DEVICE on media such as a ROM chip, CD ROM disk(s) or via web download or

. The SOFTWARE may provide

. The SOFTWARE may

. You acknowledge that

. If the DEVICE Software is provided

other means, and is labelled "For Upgrade Purposes Only", you may install one copy of such DEVICE Software onto the DEVICE as a replacement copy f or the existing DEVICE Software and use it in accordance with this EULA, including any additional EULA terms accompanying the upgrade DEVICE Software.

COMPANION CD

is provided by SAGEM separate from the DEVICE on CD ROM disk(s) or via web download or other means, and labelled "For Upgrade Purposes Only" , you may (i) install and use one copy of such component(s) on the computer(s) you use to exchange data with the DEVICE as a replacement copy for the existing Companion CD component(s).

RESPONSIBILITIES SUPPORT AND INFORMATION

questions concerning this EULA, or if you desire to contact SAGEM ]for any other reason, please refer to the address provided in the documentation for the DEVICE.

NO LIABILITY FOR CERTAIN DAMAGES

PROHIBITED BY LAW, SAGEM SHALL HAVE NO LIABILITY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES ARI SING FROM OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THE SOFTWARE. THIS LIMITATION SHALL APPLY EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE.

FOR APPLICABLE LIMITED WARRANTIES AND SPECIAL PROVISIONS PERTAINING TO YOUR PARTICULAR JURISDICTION, PLEASE REFER TO YOUR WARRANTY BOOKLET INCLUDED WITH THIS PACKAGE OR PROVIDED WITH THE SOFTWARE PRINTED MATERIALS.

. If any Companion CD component(s)

Should you have any

. EXCEPT AS

Java™

When running a Java™ application, you may be prompted to grant access to protected features. These features are protected because using them could incur you cost, or involve your personal data. In case of doubt, don't hesitate to refuse access by selecting the "No" button!

The security configuration menu is an expert feature! You must know exactly what you are doing before attempting to change security parameters of a MIDlet. Misunderstanding changes may render MIDlet non functional and/or lead to higher risks for your private data or impact your airtime consumption. Any changes in the security configuration are done under your responsibility. In no case shall Sagem Communication and/or your network provider be liable for any damages deriving from or arising out of such changes in the security configuration.

You must be aware that applications downloaded to your phone could cause the phone to perform actions for which you will be billed, like making calls and sending SMS. Depending on your operator's billing policy, you may also be charged to download the application because of airtime consumption.

Security considerations

Java™ MIDP technology is an efficient way to provide powerful applications in mobile phones. All these MIDP 2.0 features cannot be simply exposed to any MIDlet installed in the handset: a careful access control system is implemented in the device to protect your private data and airtime consumption. Access controls are gathered in 9 security groups:

- Network access

- Auto invocation

- Phone call

- Local connectivity

- Messaging receive

- Messaging sending

- Read User data

- Write User data

- Multimedia recording

Each of these security groups has one among 5 possible authorizations levels (listed from the more restrictive to the more permissive):

- Never: The security group completely prevents access to

the protected features.

- Per use: Each time MIDlet tries to use protected feature,

user is prompted to grant access.

- Per session: First time a MIDlet uses a protected

function, user is prompted to grant access like in "Per use" authorization but access is granted until the MIDlet terminates.

- Single confirmation: The first time in the whole MIDlet life

a MIDlet uses a protected feature, user is prompted to grant access. It remains valid until the MIDlet is removed from the handset.

- Always: The security group unconditionally grants

access to protected features.

A MIDlet has a security status which is either "uncertified", or else "certified". An "uncertified" status means that the source of the MIDlet could not be verified by the mobile phone at installation time. As far as the phone knows, the MIDlet could have been written by anyone. A "certified" status means that the MIDlet was digitally signed by a known party, whose name is displayed by the mobile phone. Security permissions are different for "uncertified" or "certified" MIDlets.

Security configuration menu

When a MIDlet is installed in the mobile phone, default security authorizations are applied. This default security configuration may be altered through the "Settings/Security" menu of an installed MIDlet.

Once in the "Security" menu, the security status of the MIDlet is displayed.

If you do not want to enter the security menu, simply select "Back" button. You can proceed by selecting "Ok" button.

The menu displayed allows you to increase or decrease permissions currently applied to the current MIDlet for each of the security groups. When you set a more permissive authorization to a security group than the current value, mobile phone asks you to confirm your increased risk exposure. The maximum risk exposure increase is limited by the security status.

What is Java™?

Business applications and games are easily downloadable by the end-user on a Java™ featured handset.

Your mobile phone is a MIDP 2.0 compliant Java™ platform which implements WMA (SMS support) and MMAPI (Multimedia support) options, providing an exciting environment to run highly graphical, networked and intuitive MIDP applications.

What is a MIDlet?

A Java™ application or a game designed to run in a mobile phone is named a MIDlet (MIDP applet).

A MIDlet is usually made of 2 files:

- The JAD file

- The JAR file

JAD file stands for small file describing the content of a JAR file.

JAR file stands for

ava™ Application Descriptor. It is a

ava™ Archive. It refers to the

application data themselves (program, images, sound). A JAR file may be up to 200 kilo-bytes large.

Note

: In rare circumstances, MIDlet vendors may provide

no JAD file and the MIDlet is the JAR file alone. In such a case it is your only responsibility to evaluate the risk to download the JAR file without possibility of consulting the JAD file.

Downloading a MIDlet (Java™ game or application)

MIDlets are easily downloaded in the mobile phone through the Games or Applications menus or through the WAP browser. In almost all cases, you will first receive a JAD file which will be displayed on the screen.

When you select a JAD file, your mobile phone downloads it, displays data contained and prompts you to acknowledge the JAR file download.

The popup displays information below:

- Name of the MIDlet, Version, Size, Name, Security

status, URL.

If you do not want to download the main data (JAR file), you shall refuse to acknowledge further airtime consumption by selecting "Cancel".

If you agree on the MIDlet installation, just select "Ok". The MIDlet is installed with security levels set to default values associated with its security status.

Before downloading an application, such a message may appear: "Your handset cannot identify the application, please be sure of the source of the application before installing the application".

Trademarks

Java™ and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

Disclaimer

Some downloaded items may contain data or may induce actions which may cause malfunctioning of your mobile phone or loss or corruption of data or abnormal increase of your airtime consumption. You expressly acknowledge that the download of any applications including Java done under your exclusive responsibility. In no event shall Sagem Communication, your network service provider or their affiliates be liable for any lost profits or costs of procurement of substitute goods or services, loss of profits, interruptions of business, loss of data or for any special, indirect, incidental, economic, or consequential damages arising under contract, tort, negligence, or other theory of liability relating to the download of any application by any means, including Java devices. You expressly acknowledge that any applications including JavaTM applications or games are provided strictly «as is». Sagem Communication and/or your network service provider extend no warranty whatsoever thereto. Sagem Communication and/or your network service provider disclaim any express, implied or statutory warranty of merchantability, fitness of any applications including

applications or games for a specific purpose,

Java satisfactory quality, security or otherwise.

applications or games is

applications or games in SAGEM

Warranty

You must always use your phone for the purpose for which it was designed, under normal operating conditions. Sagem Communication declines all responsibility for any use outside of the scope of its designed purpose and for any consequences of this use. The software program developed by SAGEM remains the exclusive property of Sagem Communication. It is therefore highly prohibited to modify, translate, de-compile or disassemble this software program or any part thereof.

Usage precautions

Your phone allows you to download ring tones, icons and animated screensavers. Some of these items may contain data that may cause malfunctions of your phone or data losses (virus for example). For this reason, Sagem Communication rejects all responsibility concerning (1) the reception of downloaded data or losses of the said data, (2) the impact on the operation of the phone and (3) damages resulting from receiving the said downloaded data or loss of said data. In addition, Sagem Communication states that a failure caused by receiving downloaded data that do not comply with the specifications set by Sagem Communication is excluded from the warranty. Consequently, the diagnosis and repair of a phone infected by the said downloaded data will be at the expense of the customer. Any content that you download to your phone may be protected by copyright belonging to third parties and consequently you may not have the right to use this content or its use may be restricted. Consequently it is up to you to ensure that you have permission, such as under the terms of a license agreement, to use any content that you download. Furthermore, Sagem Communication does not guarantee the accuracy nor the quality of any content that

you download. You alone are responsible for the content that you download to your mobile phone and how you use it. Sagem Communication cannot be held responsible for this content nor for its use. It is your responsibility to ensure compliance, at your own expense, with the laws and regulations applicable in the country where you use your phone.

Warranty conditions

Whenever you wish to make use of the warranty, please contact your vendor and present him with the purchasing paperwork that he gave you. If a fault occurs, he will advise you.

The new phone (excluding consumables), including new accessories bundled with the phone, are guaranteed by Sagem Communication, parts and labour (apart from travel) against any manufacturing fault for a period of twelve (12) months with effect from the sale of the phone to the customer, on presentation of the paperwork stating the purchase date of the phone. Phones that have been repaired or replaced as standard during the warranty period stated above are guaranteed (parts and labour) until the later of these two dates: Expiry of the guarantee period of twelve (12) months stated above or three (3) months with effect from the date of support provided by Sagem Communication. Your legal rights under the terms of applicable national law as well as your rights in relation to your retailer, as set out in the sales contract, remain applicable and are not in any way affected by this guarantee. In any disputes, the phone is covered by the legal warranty against the consequences of faults or hidden defects in compliance with articles 1641 and subsequent of the French civil code.

All faulty phones under warranty will be replaced or repaired free of charge at Sagem Communication's option (with the exclusion of repair of any other damage), once it has been specified that the work required for the application of the warranty will be done in a workshop and that the return costs (transport and insurance) of the phone to the address to be indicated to it by the Sagem Communication after-sales service, whose phone number will appear on the delivery note, will be charged to the customer. Subject to essential legal provisions, Sagem Communication does not accept any warranty, explicit or implicit, other than the warranty provided expressly in this chapter, nor shall Sagem Communication accept responsibility for any immaterial and/or indirect damages (such as loss of orders, loss of profit or any other financial or commercial damage) under the warranty or not.

The acceptance of a phone under warranty demands that a purchase document that is legible and without modi-fication, stating vendor's name and address, date and place of purchase, type of phone and IMEI, are attached to the warranty, and that the information on the phone identification label is legible and that this label or any other seal has not been tampered with. The warranty applies in normal conditions of use. Prior to sending the phone for repair, it is the customer's responsibility to backup at his expense the customized data stored in the phone (phonebook, settings, wallpaper s). A list of backup facilities can be provided by Sagem Communication on request. The responsibility of Sagem Communication cannot be invoked if damage occurs to customer files, programs or data. The information or operating elements and the contents of files will not be re-installed in any case in the event of loss. Sagem Communication may decide, at its option, to repair

the phone with new or reconditioned parts, replace the phone with a new phone or, in any dispute, a phone in good working condition. During its work Sagem Communication reserves the facility to make, where necessary, any technical modifications to the phone where these modifications doe not adversely affect its initial purpose. Faulty parts to be replaced during a repair under warranty will become the property of Sagem Communication. The phone repair and standstill time during the warranty period may not lead to an extension of the warranty period as stated in article 1 above, provided no other vital provisions have been agreed. The application of the warranty is subject to the full payment of the sums due for the phone when the request for support is made.

The following are excluded from the warranty: Breakdowns or malfunctions due to non-compliance with the installation and use instructions, to an external cause of the phone (shock, lightning, fire, vandalism, malice, water damage of any type, contact with various liquids or any harmful agent, unsuitable electric current...), to modifications of the phone made without the written consent of Sagem Communication, to a servicing fault, as described in the documentation supplied with the phone, to lack of supervision or care, to poor environmental conditions of the phone (especially temperature and hygrometry, effects of variations in electric voltage, interference from the mains network or earth) or even due to a repair, a call-out (opening or trying to open the phone) or to servicing done by personnel not approved by Sagem Communication. Damage resulting from inadequate packaging and/or poor packing of the phone sent back to Sagem Communication. Normal wear and tear of the phone and accessories.

Communication problems linked with a poor environment, especially: Problems accessing and/or logging onto the Internet, such as breakdowns of the access network, the failure of the subscriber's or his correspondent's line, transmission fault (poor geographic coverage by radio transmitters, interference, disturbance, fai-lure or poor quality of phone lines...), a fault inherent to the local network (cabling, file server, user phone) and/or transmission network fault (interference, disturbance, failure or poor quality of the network...). Change of parameters of the cellular network made after the phone was sold. Supply of new software versions. Current servicing work: delivery of consumables, installation or replacement of these consumables... Call-outs for phone or software modified or added without the written consent of Sagem Communication. Faults or disruptions resulting from the use of products or accessories not compatible with the phone. Phones returned to Sagem Communication without having complied with the return procedure specific to the phone cove-red by this warranty. The opening or closing of a SIM operator key and call-outs resulting in the non-operation of the phone resulting from the opening or closing of SIM operator key done without the agreement of the original operator.

In the cases of warranty exclusion and of expiry of the warranty period, Sagem Communication shall draw up an estimate to be given to the customer for acceptance before any call-out. The repair and carriage costs (there and back) given in the accepted estimate will be charged to the customer. These provisions are valid unless a special written agreement has been made with the customer. If one of the

provisions turns out to infringe a legally essential rule that consumers could have the benefit of under the national legislation, this provision will not be applied, but all other provisions will remain valid.

Troubleshooting

The phone won’t start and/or won’t take a charge

The battery has completely lost its charge. Connect the phone to the charger for between 5 and

30 minutes. The phone will only switch on after it has been charging for a few minutes. You may use the phone again when the Start option is displayed on the screen. If the phone still won't start after 30 minutes’ charging, contact customer service.

SIM not present

Check if the SIM card is present and properly positioned / inserted.

Check the condition of the SIM card. If damaged, please go back to the operator's shop for advice. Contact your after-sales service if the message persists.

Incorrect PIN code

An incorrect PIN code has been entered. Be careful! Three incorrect PIN codes will block the SIM Card.

SIM BLOCKED

If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:

- Enter the PUK (Personal Unblocking Key) code provided

by your operator, and validate.

- Enter your PIN number and validate.

- Enter your PIN number again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the SIM card is definitely locked. You must then contact your operator to obtain a new card.

SIM LOCKED

In certain cases, the handset can only be used with some types of SIM cards. This message means that the SIM card you are using does not fit with the phone. Take the SIM card out, and switch it back on. If the message appears on the screen, you will need to check its compatibility next to the place where you bought it. If not, please contact your after-sales service.

No call connection

Check that the number you have dialled is correct. If the letter R is displayed on the top right corner of the screen, without any network name displayed, only

emergency services can be called. Check the status of your credit. Check that the SIM Card you are using offers the service

you are requesting; check if its validity has not expired. Check and deactivate the outgoing calls restriction when necessary. The network could be saturated. Try later. If the problem persists, please contact your Technical

Helpdesk.

No receiving calls

Try to make a call in order to check that the phone and the network are operational.

Check and deactivate the permanent call forwarding (permanent call forwarding icon displayed on the screen).

Check and deactivate the incoming calls restriction when necessary. If the problem persists, please contact your Technical Helpdesk.

SIM not present

Quality reception when calling

Avoid placing your fingers on the top of the phone, where the aerial is integrated: the phone will have to use full strength to establish a quality transmission.

Impossible to send message

Check that your SIM card does offer this service. Try to make a call to check that phone and network are operational.

Check if the voicemail number is properly configured Check that the message centre number is correctly entered. To do so, go to the

Message centre number

No voicemail

Check that your subscription does offer this service. Program the call to be forwarded to voicemail using the

information provided by the operator.

Operator name does not appear on screen

Go into the

Selection

validate. If the Operator logo is present (depending on model), activate the display (

How can I increase the efficiency of my phone?

Activate the eco mode (see

saving

Messages/Options/SMS

and check the number.

Settings

. Wait until the operator appears, select it and

menu, select

Settings/Display/Operator logo

menu, select

Networks

, then

Settings/Display/Energy

Customer care

Austria Belgium Czech Republic Denmark France Germany Greece Hungary Ireland Italy Netherlands Poland Portugal Romania Russia Slovakia South Africa Spain Sweden Switzerland United Kingdom

Customer Care e-mail address:

Web sites:

01 36 02 77 16 64 02 62 77 016 844 555 600 0 82 33 28 52 0 892 701 799 (0,34 €/mn) 01805 843 850 0800 44 14 20 38 06 1 7774 839 0 160 58 355 800 800 485 020 65 45 724 0801 801 101 21 316 41 35 0800 89 45 21 095 258 54 33 (421) 02 68 629 355 0800 99 14 17 91 375 3376 08 519 923 21 02 25 67 53 99 0870 24 05 613

support.mobiles@sagem.com

www.sagem.com/mobiles www.planetsagem.com www.sagem-online.com

Index

Alarm 25 Automatic redial 27

Battery 10, 13 Beeps 26 Bluetooth 19, 20

Calculator 25 Calendar 25 Call barring 29 Call forward 27 Call waiting 27 Calls 12 Camera 19, 29 Car kit 21 Confidentiality 29 Connectivity 20 Contacts 11, 19, 20 Cost 29 Counters 27 Customer care 43

Date / Time 26 Display 26 Display number 27 Downloaded objects 20

EDGE 23 e-mail 18 Energy saving 26

Fixed dialling 29

Games 24 Getting started 11 GPRS 23

Help 30

Icons 9

Keys 8

Languages 26

MMS 15, 19 Multimedia 20 Multimedia objects 20

Navigator 8 Necklace 10 Network 11, 28

Operator 29 Operator logo 26 Organiser 20

Phone code 28 Phone description 8 Phonebook 15 Photo 18, 20 PIN number 28 PIN2 number 28

Ring tones 26

Safety information 6, 32 Screensaver 26 Security 28 Settings 26 Shortcut keys 29 Side keys 9 Silent mode 26 SIM card 9 Skins 26 SMS 15

T9 15

Technical features 30 Timer 25 ToDo 20, 25 Troubleshooting 41, 42

USB cable 20

Vibrate 26 Video 19, 20, 29 View last calls 27 Voicemail 17, 28

Wallpaper 26 WAP 23



Mobile Communication Business Group

Le Ponant de Paris - 27, rue Leblanc - 75512 PARIS CEDEX 15 - FRANCE

www.sagem.com/mobiles

Société Anonyme

Capital 300 272 000 € - 480 108 158 RCS PARIS

04/2006

Sagem MY700X, MY700X ROLAND GARROS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Care and safety information

Description

Getting started

Using your phone

Phonebook

Messages

e-mail


Video

Multimedia

Connectivity

Music Player

FM Radio

Games

Applications

Settings

Technical features

Conformance Document

Care and safety information

End User Licence Agreement (EULA), for the software

Java™

Warranty

Troubleshooting

Customer care

Index
