HILONC V2 PACKAGING
SPECIFICATION
~ Freedom of speech
for smart machines ~
FICHE RECAPITULATIVE / REVISION HISTORY
E
d
1 25/03/2011 AET– M2M– 2011 /
2 01/08/2011 AET– M2M– 2011 /
Date
Date
Référence
Reference
D2108
D2108
Pages
modifiées /
Changed pages
Observations
Comments
Création du document / Document
creation
Update of the pictures
Note d’étude / Technical document :
AET– M2M– 2011 / D2108 Edition 02
HiLoNC V2 PACKAGING
01/08/2011 - page 2/ 8
SOMMAIRE / CONTENTS
Introduction ............................................................................................................................................................................4
HiLoNC V2 Module Labels and Packaging ...........................................................................................................................4
HiLoNC V2 Module references..............................................................................................................................................8
Note d’étude / Technical document :
AET– M2M– 2011 / D2108 Edition 02
HiLoNC V2 PACKAGING
01/08/2011 - page 3/ 8
Introduction
This document contains the description of the packaging of the HiLoNC V2 modules.
HiLoNC V2 Module Labels and Packaging
IMEI number + corresponding 2D bar code
Designation : HILONC V2
Sagemcom Part Number :
253356787 = HiloNC V2 generic alone (*)
FCC ID : VW3HILONCV2
Software reference : HI2N,A.000.07
Date code F326/10 (326th day 2010) + level of manufacturing N2
IMEI + Serial number list can be provided on demand for each shipment
The HiLoNC V2 modules are packaged in a reel of 500 components :
Weight of tape and reel with 500 HiLoNC > 2Kg (HiLoNC V2 weight 2,72g typ.)
Note d’étude / Technical document :
AET– M2M– 2011 / D2108 Edition 02
HiLoNC V2 PACKAGING
01/08/2011 - page 4/ 8
Tape Data sheet :
Tape and reel with identification label :
Note d’étude / Technical document :
AET– M2M– 2011 / D2108 Edition 02
HiLoNC V2 PACKAGING
01/08/2011 - page 5/ 8
Label on the reel = Label on the primary unit (box which contains the reel)
MPN Manufacturing Part Number Designation
253356774 (**) = HiLoNC V2 generic packed
LOT number FCC ID
Software reference HI2N, A.001.00 & Level of manufacturing (N5)
DTE Date code (2 in this case) MSL level (3 ó 168H)
QTY (280pcs in this reel, standard qty=500)
GEN CODE
Start and end of tape will find 10 tapes empty :
Note d’étude / Technical document :
AET– M2M– 2011 / D2108 Edition 02
HiLoNC V2 PACKAGING
01/08/2011 - page 6/ 8
The tape and reel with 500 HiLoNC V2 modules are conditioned in dry pack:
The drypack with the tape and reel are packaged in the box below (primary unit 340x360x77mm) :
Primary unit (top)
Note d’étude / Technical document :
AET– M2M– 2011 / D2108 Edition 02
HiLoNC V2 PACKAGING
01/08/2011 - page 7/ 8
The weight of the primary unit with 500 Modules HiLoNC V2 is > 2,4Kg.
Up to 3 primary units can be included into the loading unit carton (400x400x320mm) which is shipped to our
customers.
Primary unit (side)
HiLoNC V2 Module references
In order to anwer customer demand we have introduced several references and part numbers.
The modules can include a generic software (most recent offical software release and generic parameters) or a
customized software (not necessarily the most recent software and customer’s parameters).
If the module is manufactured with a customized software we create specific part numbers (module alone,
module packed) and designation (eg. HILONC V2 “customer’s name”).
For example, the HILONC V2 generic module is defined by the two part numbers below :
- the part number of the module alone is 253356787 and it can be read on the label of the HiloNC V2 module (*,
on page 4),
- the part number of the module packed is 253356774 and it can be read on the label of the reel and black
carton (**, on page 6),
Our customers shall indicate the part number of the module packed on their PO,
We also put the part number of the module packed on the shipping documents and invoices.
Note d’étude / Technical document :
AET– M2M– 2011 / D2108 Edition 02
HiLoNC V2 PACKAGING
01/08/2011 - page 8/ 8
All rights reserved. The information and specifications included are subject to chan
ge without prior notice. Sagemcom tries to ensure that all information in this document is correct, but does not accept liability for error or
omission. Non contractual document.. All trademarks are registered by their respective owners.
