Sagem 926, 912, 920, 910, 919 User Manual

...
ENGLISH
910
912
916
919
920
922
926
929
Couv. LU A6 tdpote 238204111 26/10/00 11:18 Page 1
Switch on
Open the flap (depending on the model) and press .
Call
Dial the number then press .
Answer
Press (or open thee flap depending on the model).
1
Lock the keyboard
Choose ACTIVE in the SECURITY/LOCK K. PAD menu or press
✱✱
then Ok.
✱✱
Unlock the keyboard
✱✱
Press
then Ok.
✱✱
Redial last number
Press .
Enter a number into the directory
Press Ok.
Hang up
Press (or close the flap depending on the model).
Switch off
Press (long press).
Hands free
To communicate, press .
Make a call from the directory
By name: enter the first letters of the name, press , scroll down the list to find your correspondent then press to call.
By location in the directory: enter the number of the location then press # to call.
Briefly, the functions
MENUS
Enter using
and
Navigate using and
Validate using OK Quit using C
DIRECTORY MESSAGES CALLS RNG & BEEP SETTINGS SECURITY ACCESSORY
2
Briefly, the menus
You have just bought a mobile phone and we congratulate you on your choice.
Your phone will allow you to use different international networks depending on the roaming agreements between the operators.
We would like to remind you that this phone is approved to European standards.
In order to use your phone effectively and in the best conditions, we advise you to read this manual written for your attention carefully.
WARNING
According to the configuration of the networks and associated subscriptions, certain functions may not be available (indicated by *).
If an incompatible SIM card is inserted, a message will be displayed when switching on your phone. For further information, contact your Operator.
The SAGEM logo and trademark are the property of SAGEM SA. T9 Text Input is a registered trademark of ©Tegic Communications Inc. T9 is licensed under one or more of the following U.S. Patents: 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and additional patents are pending worldwide.
Compatibility of your SIM card
Your phone is compatible with SIM 3V cards only.
3
GLOSSARY
Outgoing call A call made from your phone.
Incoming call A call received by your phone.
SIM card The card containing your
subscription and access rights to services. The detachable part is the micro-SIM.
PIN The personal code linked to your
SIM card.
PIN2 The second personal code
linked to your SIM card to access certain functions (*).
Phone code The phone code is a secret code
intended to protect the phone in case of theft.
IMEI The identification number of your
phone.
SMS Short Message Service: for
sending and receiving short text messages.
1. Presentation of the phone ..................................... 6
2. Getting started ....................................................... 8
2.1 Information on the SIM card ................................ 8
2.2 Installing the SIM card ........................................ 9
2.3 Charging the battery ......................................... 10
2.4 Switching on/switching off, starting up .............. 10
2.5 Menu access .................................................... 11
2.6 Deleting characters........................................... 11
3. Initial communication - Hands free mode ............ 12
3.1 Making a call ..................................................... 12
3.2 Receiving a call ................................................ 12
3.3 Volume control .................................................. 13
3.4 Hands free mode .............................................. 13
3.5 Ending a call ..................................................... 13
4. Menu list .............................................................. 14
How to use the directory ...................................... 15
5.
5.1 Directory capacity and display .......................... 15
5.2 Sorting .............................................................. 15
5.3 Storing a number .............................................. 16
5.4 Deleting a number ............................................ 16
5.5 Making a call to a stored number ...................... 16
5.6 Accessing services provided by the Operator ... 17
5.7 Displaying your phone numbers ....................... 17
5.8 Directory occupation ......................................... 17
6. How to use the written message function ............ 18
6.1 Creating new short messages using Easy Message T9
TM
................................................... 19
Summary
4
6.2 Receiving short messages ................................ 21
6.3 Reading short messages .................................. 21
6.4 Sending short messages .................................. 21
6.5 Memory occupancy rate ................................... 22
6.6 Clearing short messages .................................. 22
6.7 Information distribution ..................................... 22
7. How to use the call related features .................... 23
7.1 Forwarding calls ............................................... 23
7.2 Viewing the list of the last numbers used .......... 24
7.3 Erase numbers ................................................. 25
7.4 Caller identity .................................................... 25
7.5 Auto redial ........................................................ 26
7.6 Call waiting ....................................................... 26
7.7 Call hold ........................................................... 26
7.8 Multi-conference ............................................... 27
7.9 Checking call duration ...................................... 28
7.10 Charge-checking ............................................. 28
7.11 Message centre ............................................... 29
8. How to adjust the ringing tones and the
vibrator ................................................................. 30
8.1 Selecting silent mode ........................................ 30
8.2 Setting the vibrator ............................................ 30
8.3 Selecting the volume and the type of
ringing tone ....................................................... 31
8.4 Setting the alarm ............................................... 31
8.5 Setting the timer ................................................ 32
8.6 Settings the beeps ............................................ 32
8.7 Deleting DTMF tones ........................................ 32
9. How to adjust your phone .................................... 33
9.1 Programmine the «One Touch» keys ................ 33
9.2 Personalising the welcome screen ................... 34
9.3 Selecting the display language ......................... 34
9.4 Select the type of automatic response .............. 34
9.5 Selecting the network ....................................... 35
9.6 Setting the date and time .................................. 36
9.7 Adjusting the contrast ....................................... 36
9.8 Install energy saving mode ............................... 36
9.9 Standard configuration...................................... 36
10. How to use the security features of
your phone ........................................................... 37
10.1 Locking the keyboard ...................................... 37
10.2 Changing the PIN number ............................... 37
10.3 Activating the PIN code ................................... 38
10.4 Activating the phone code ............................... 38
10.5 Changing the phone code ............................... 38
10.6 Changing the PIN2 code ................................. 39
10.7 Creating a fixed numbering phone book .......... 39
10.8 Charge-checking ............................................. 39
10.9 Call barring ...................................................... 39
11. Other functions .................................................... 41
11.1 Calculator ........................................................ 41
11.2 Converter ........................................................ 42
5
12. Available accessories ......................................... 43
13. Upkeep ................................................................ 44
Recommendations .............................................. 45
14.
Answers to your questions ........................................ 48
Summary
Antenna
Ear phone/speaker
Screen
One Touch 1
Scrolling arrow
Stop/End call
6
COk
Light indicator
One Touch 3
One Touch 2
Operate/Call
Activation of hands free
Correction
Battery charging and accessories socket
1. Presentation of the phone
Validate
Scrolling arrow
Microphone
Function keys
7
Display
Stop  Reject a call  Hang up
Go  Call a number  Receive a call  Hands free mode
C Short press: Return to the previous menu 
Delete a character Long press: Exit menu mode  Complete deletion of the entry
Ok Validate
Programmable keys for direct access to the functions that you have selected  Control volume
and Entry and scrolling through the menus.
Various icons provide information, for example:
Alphanumeric keyboard
Made up of 12 keys: 0 to 9, and #.
To obtain a letter, hold down the relevant key, the number and the letters will appear; stop pressing when the required letter appears.
Letters with accents are obtained by a long press on after entering the letter with no accent.
Punctuation marks and special symbols are obtained by a long press on the # key.
Battery charge indicator (black if charged, clear if discharged)
Received signal strength indicator (maximum strength: 5 bars)
Hands-free loudspeaker
Alarm
Call in progress
Silent mode
1. Presentation of the phone
8
2.1 Information on the SIM card
2. Getting started
2. Getting started
To use your phone, you have a small card called a SIM card. This card contains all the information necessary for the network as well as other information that belongs to you and that you can modify:
 secret codes (PIN code(s) -
Personal Identification Number),  directory,  mini-messages,  functioning of specific services.
SIM card
This card must be handled and stored with care in order to avoid excessive stresses or scratches that would damage it. If your SIM card is lost, contact your Operator or Service Provider immediately. Note: Do not leave your SIM card within the reach of small children.
PIN code
This is the personal code for your SIM card. This code could be requested of you when you switch on your phone.
Enter the code of between 4 and 8 digits given to you by your operator. These digits will not be displayed on the screen for security reasons.
Press # or Ok to validate.
PIN2 code (*)
This second code if it was given to you by your operator, provides security of access to certain functions.
Attention
If the wrong PIN code is entered three times in a row, the card will be blocked. To unlock your card, call the organisation from which you obtained this card, they will guide you on the procedure to use. If your SIM card is permanently locked, contact your Operator or your Service Provider to obtain a new card.
9
2.2 Installing the SIM card
Switch off your phone; disconnect the charger.
The SIM card is inserted beneath the phones battery.
Turn your phone over and
remove the battery by pulling on
the strip on the lower part of the
phone: it lifts up and you can
release it.
Slide the card along the base
beneath the retaining plate, with
the gold coloured sections facing
towards the phone and the cut-
off corner lined up to match the
drawing on the phone.
Replace the battery by first
positioning the upper section
then pressing it until it locks.
2. Getting started
2.3 Charging the battery
Your phone is powered by a rechargeable battery. A new battery must be charged for at least 4 hours before it is used for the first time. It will reach its nominal capacity after several usage cycles.
When your battery has run down, the phone displays it and cuts out.
To recharge your battery:
Connect the charger to a mains socket.
Connect the end of the charging cable to the bottom of your phone. The phone will start charging, the battery charging indicator indicates the level of charge.
Charging stops by itself. Unplug the cable.
It is possible that during charging, the battery may heat up slightly; this is normal.
2. Getting started
Attention
The battery does not contain any components that can be changed by you. Do not attempt to open the battery case. Only use the appropriate chargers and batteries as specified in the manufacturers catalogue. Spent batteries must be collected at the appropriate sites.
There is a risk of explosion if the battery is incorrectly replaced.
10
2.4 Switching on/switching
off, starting up
To make your first call:
Press to switch on your
phone.
If access to the SIM card is
protected by a secret code, the
phone will ask you to enter your
PIN code.
Enter the code of between 4 and
8 digits given to you when you
were given your SIM card. These
digits will not be displayed on the
screen for security reasons.
Press # or Ok to validate.
Control of the PIN code
If your phone displays SIM MISSING, press
(long press) to switch off your phone and check that your SIM card is correctly positioned.
Searching for a network
The phone then searches for a network on which it can communicate:
If it finds it, it displays the name of the network on the screen and the light indicator flashes green.
You are ready to make or receive a call.
If it finds another network, only emergency services will be accessible (police, ambulance, fire brigade).
If it cannot find a network, it will keep searching.
Network indicator
The indicator of the level of network signal received enables you to visualise the quality of reception. If it shows less than three bars, look for better reception to make your call in good conditions.
11
2.5 Menu access
The menu functions permit you to verify or modify the various functions of your phone to adapt it to your requirements.
Press the scrolling arrows or to access the menus.
Scroll through the menus using the scrolling arrows then press Ok to access the selected menu.
Each time you want to validate an action, press Ok.
To abandon an action, press C. To exit the menu mode, press
and hold C.
Direct access to menus
To directly access a menu, press then enter the number of the selected menu.
Switching off
Hold down the key until the end message is displayed.
Release the key, the phone switches off.
2.6 Deleting characters
You can cancel an entry error:
Press quickly on C to delete the last character.
If you press for longer on this key: you will delete the previous word.
2. Getting started
3. Initial communication Hands free mode
3. Initial communication
12
3.1 Making a call
The network is displayed.
Dial the number with the area code (if necessary).
Press .
During the call, flashes on the screen and tones signal the establishment of communication.
When the person you have called answers, speak.
To call the international emergency service, dial 112 then press .
3.2 Receiving a call
When you receive a call:
Press (or open the flap, depending on the model) then speak.
The callers number is displayed when it is presented to the network. This number is automatically registered whether you answered the call or not.
International call
Press 0 (long press) to display + then dial the country code without waiting for a tone, then the number you require.
Emergency services
Depending on the operator, you can contact the emergency services with or without a SIM card or when the keyboard is locked. It is sufficient to be in a zone served by the network. Other emergency service numbers may exist, depending on the country.
3.3 Volume control
Increase or decrease the volume during a conversation by pressing the or keys.
3.4 Hands free mode
During a call, you can transfer from handset mode to hands free mode by simply pressing one key and the reverse to switch back.
Press .
The screen displays for handset mode and for «hands free» mode.
Before putting the phone to your ear, check the
!
volume control settings as well as the selected listening method, especially if using integrated hands free mode, which could cause ear damage if used incorrectly.
The Hands free mode enables you to have a conversation with several people and be free to move, for example, to take notes during your conversation.
13
3.5 Ending a call
Press (or close the flap depending on the model).
The end of call message appears on the screen.
3. Initial communication
4. Menu list
According to your phone model, to the configuration of the networks and associated subscriptions, certain functions may not be available (indicated by *).
4. Menus
14
Directory
A
LPHA SORT
P
OSITION
S
ERVICES
(*)
Y NUMBER
M
USE
(*)
Messages
R
EAD
S
END
U
SE
C
LEAR
C
ELL.INFO
. (*)
CALLS
C
ALL FRW
.
AST
L C
LEAR
S
END N
o (*)
UTO RDIAL
A D
BLE CALL
(*)
URATION
D C
OST
(*)
SG CENTER
M
Rng & beep
S
ILENCE
?
V
IBRATOR
H
ANDSET
H
ANDSET
F
REE HAND
A
LARM
T
IMER
B
EEPS
S
END DTMF
Settings
P
ROG. KEY
G
REETING
L
ANGUAGE
A
NSWER
N
ETWORK
D
ATE/TIME
M
ISC
Security
L
OCK K.PAD
PIN
CODE
PIN
CHECK
.
HONE CODE
P P
HONE CHCK
PIN2
CODE
(*)
IXED REP
. (*)
F
OST
(*)
C L
IMIT
Accessory
C
ALCULATOR
XCHANGE
E
(*)
15
5.1 Directory capacity and display
You can store the phone numbers that you call regularly.
Different icons will inform you of the directory location where the number is stored:
SIM card directory
The number of telephone numbers stored in the SIM card directory varies depending on the capacity of the card; your supplier will be able to inform you.
5. How to use the directory
Your phones directory (depending on the model)
SIM card pre-set directory.
5.2 Sorting
DIRECTORY/ALPHA SORT
In this menu, the stored numbers are sorted in alphabetical order.
5. Directory
5.3 Storing a number
16
5.4 Deleting a number
DIRECTORY/POSITION
Using this menu, display a screen with MEM001 (first position of SIM card). Press to access the first available location in the directory.
Press Ok, then enter the name to be stored (the number of characters accepted depends on the SIM card).
Press Ok, then enter the phone number to be stored preceded by the area code if necessary (up to 20 characters). Validate by pressing Ok.
You can introduce pauses in the number (indicated by comas ,) by holding down or # (including on the standby screen). The numbers dialled after a pause are used in DTMF sequences (which can be used after a call number).
5. Directory
It is advisable to store numbers in their international format (+, country code, and number).
Pressing on the key launches a search for the first available location.
To cancel the content of a directory address, erase the name and the call number at that address, then press Ok.
5.5 Making a call to a stored number
Enter the memory number in
which you stored the required phone book references, then press # (quick call).
Type in the first letter(s) of the
required name stored in the phone book, then press ,
Enter the memory number in
which you stored the required references in the phone book then press ; then you can modify or complete the phone number (the prefix can be a phone extension, for example).
Press
or
or
to initiate the call.
Modification of a stored number
When the number is displayed, press ✱, you can then modify or add to the number (prefix to add for an extension number for example).
5.6 Accessing services provided by the Operator
DIRECTORY/SERVICES (*)
With this menu, you can access to certain services provided by your Operator.
5.7 Displaying your phone numbers
DIRECTORY/MY NUMBER (*)
This menu displays your phone number.
5.8 Directory occupation
DIRECTORY/USE
This menu shows how many memory locations are occupied in your directory.
17
5. Directory
6. How to use the written
message function
6. Written message function
18
This service allows you to send and receive messages in plain text, usually called short messages.
Your frequently used short messages can be stored:
- in the SIM card: in this case, the number storable depends on the capacity of the card; for details, contact your service provider;
- in the phone itself (depending on the model).
Various icons provide information on:
Position of the message in the phone (depending on the model).
flashing At least one message not
completely read. steady Messages all read. flashing Memory full with at least on
message not completely read. steady Memory full.
Access to this service depends on the network; for more information, consult your Operator or your Service Provider.
6.1 Creting new short messages using Easy Message T9
(Function available depending on model)
TM
The Easy Message T9 activated as soon as you want to create or modify a message (Menus: MESSAGES/ SEND/NEW MSG and MESSAGES/SEND/ EXISTING).
The Easy Message T9 briefly to indicate that the function is available in the message creation mode.
In the input screen, when you are in mode T9
the following keys: are used to:
and move from word to
C correct the last word
Ok validate the message
quick press change the input mode
software is
TM
heading is displayed
word in the text typed in
or erase the last character
and send it or save it
TM
TM
19
quick press go through the list of
words in the dictionary that correspond to the input sequence
long press change the input
language (according to model).
Operation
 Press once on the key which corresponds to
the letter chosen and create the word by pressing on each letter of the word, without paying any attention to the screen, until the whole word has been input: the word then
,
flashes.
 As the text progresses and according to the
keys pressed, the software searches through a dictionary for the most frequently used corresponding word(s).
 If the word suggested corresponds to the
word you want to input, just press on 0 to validate it, put in a space then move on to the next word.
6. Written message function
 It may be that several words in the
dictionary correspond to the sequence of characters keyed in. If the word that appears is not the word you want, just press on the key to go through the words in the dictionary that correspond to that particular sequence. When you find the right word, press on the 0 key to validate it, put in a space then move on to the next word.
 If the word you want to input is not
included in the dictionary, there are several additional modes that can be used to vary the type of words chosen.
Additonal input modes
The Easy Message T9 as soon as you create or modify a message. There are also other modes which complete the functions of that mode.
The key is used to switch from one mode to another; the active mode is indicated at the bottom of the screen (according to model).
TM
mode is activated
6. Written message function
20
 The 123 (Number) mode is used to insert
numbers.
 The ABC (Multi-Tap) mode is used to enter
words not found in the dictionary or words in another language. To obtain a letter, press and hold the corresponding key. The letters and number will scroll down. Stop pressing when the desired letter appears.
Capitals
You can type letters in capitals by pressing on the key before keying in the particular character. Subsequent characters automatically revert to lowercase.
You can also chose to type a whole word in capitals by pressing twice on the key before typing in the word. To return to the lowercase mode, press once on the key.
Symbol
To enter a symbol, press the # key then simply key in the number indicated above the desired character, e.g. 3 instead of ?. The symbol is inserted in the text, then you automatically return to the Easy Message T9
TM
mode. Several lists are accessible by using the scroll arrows.
Punctuation
The punctuation characters are obtained either by using key 1, or through the Symbol menu (various punctuation characters).
Accented characters
Accented characters are automatically produced in the word in the Easy Message T9
TM
mode. In the Multi-Tap mode, all you have to do is wait for the display of the accented character corresponding to the key pressed.
6.2 Receiving short messages
When you receive a short message, the indicator flashes on your phone screen and an audio tone is heard. (This tone is selected using the menu RNG & BEEP/HANDSET/ MESSAGES). The screen displays: MESSAGE RECEIVED. The LED flashes red.
6.3 Reading short messages
MESSAGES/READ
This menu allows to read the received short messages. Your phone displays:
21
 New message or message not completely
read.  Message number.  The date and time of arrival of the message.
To read the selected message,
press Ok.
Your phone displays the number
of the sender of the message.
Scroll them with the scrolling
arrows until CLEAR.
Your phone indicates OLD (out of
the menu) once the message
has been completely read.
During reading of messages, any messages not read completely are displayed first. When all messages have been read in full, the indicator remains continuously visible.
6.4 Sending short messages
MESSAGES/SEND Several options are available:
MESSAGES/SEND/NEW MSG
Enter the text of your new
message. After validating, you
can choose from several options:
- Send your message.
- Save your message.
- Modify the text of your message.
Attention
To use this service, you must know the number of your messaging centre to which you send your messages in order for them to be rerouted to your contacts.
6. Written message function
MESSAGES/SEND/EXISTING
This menu allows you to work on already saved messages. Processing is identical to that for a new message. Select the message by pressing the scrolling arrows.
If the network allows, the message sender may offer you a reply possibility.
MESSAGES/SEND/VALIDITY
Select a validity length for your message by pressing the arrow keys; this determines how long the messaging center will keep the message while attempting to forward it to the recipient (if this function is supported by the network).
MESSAGES/SEND/FORMATS
Choose the format of your message by pressing the arrow keys: text, fax, E-mail, voice msg, pager, X.400 or ERMES.
Attention
The network may support only one or other of these formats.
The phone will automatically return to text format after switching off
MESSAGES/SEND/MSG CENTRE
This menu allows you to enter the number of «your» messaging centre.
6. Written message function
22
MESSAGES/SEND/OFFER REP
If the network allows, you may
offer the recipient number of your
message a reply possibility.
Attention
The reply will be charged on your subscription.
6.5 Memory occupancy rate
MESSAGES/USE This menu allows you to determine the
memory occupancy rate. When no more space is available, the display reads MESSAGE
FULL upon receiving a message.
6.6 Clearing short messages
MESSAGES/CLEAR
This menu allows you to clear the short messages already read, in order to free-up memory space.
6.7 Information distribution
MESSAGES/CELL.INFO. (*)
This menu allows you to activate and select reception of information distributed by the network.
Contact your Dealer or Operator for further details.
7. How to use the call related features
23
7.1 Forwarding calls
CALLS/CALL FRW.
If allowed by your subscription, this service allows you to forward the received calls (incoming calls) to another number.
CALLS/CALL FRW./ACTIVATE
Scroll the menu to activate the type of call forwarding required.
 UNCONDITIONAL call
forwarding: all your incoming calls will be forwarded to the number you have chosen.
 BUSY: incoming calls will be
forwarded only when your phone is BUSY.
 NO REPLY calls are forwarded when your
caller gets no answer from your phone after a period of time you can set by answering the questions asked by the menu.
 NOT REACHABLE calls are forwarded
when your phone is not reachable, either outside network coverage or switched off.
Look out for incompatibilities; for more information, consult your Operator or your Service Provider.
7. Call related features
Dial the number to which you want your calls to be forwarded to, giving the same area codes as if you were calling from your phone.
A screen message confirms activation of call forwarding.
CALLS/CALL FRW./DEACTIVATE
Scroll the menu to deactivate the type of call forwarding required.
CALLS/CALL FRW./STATUS
This menu allows you to consult the status of the call-forwarding option and check whether it is active or not. This function is also of use when checking the number your calls are forwarded to. The displayed information is given by the network in real time.
7. Call related features
The forwarding number is attached to the subscription number of your SIM card and not to your phone.
You can deactivate ALL call forwarding options.
Attention
Cancellations of forwarding can cause particular reactions in certain voice mailbox systems on the network.
24
7.2 Viewing the list of the last numbers used
The last phone numbers (outgoing and incoming if available) are automatically stored in memory.
To redial a phone number:
Press ,
or
CALLS/LAST
With this menu, the last numbers stored are displayed. You may choose among the list by pressing the arrow keys.
Press to call the selected number.
Or press Ok to store this number in the directory.
Storing a number in the list
Enter the number then press Ok. You can do this during a call.
7.3 Erase numbers
CALLS/CLEAR/LAST
This menu allows you to trigger immediate clearing of the last­numbers list.
Validate by pressing Ok.
CALLS/CLEAR/AUTO.
You can also program the automatic erasing of numbers, which is effective when the phone is switched ON/OFF.
Display ACTIVE by pressing the scrolling arrows, then validate.
7.4 Caller identity
CALLS/SEND No (*)
This menu allows you to know the status for the number presentation function:
- your identity (phone number)
- caller identity. Validate by pressing Ok.
Attention
This list is automatically erased if the SIM card is changed.
25
CALLS/SEND No/YOUR ID.
Your number
 On outgoing call, you can check if your
phone number is displayed on the phone of the person you are calling (CLIR deactivated).
 On incoming call, you can check if, when
you forward the calls you receive to another number, you prevent this number to be displayed on the caller's phone (COLR).
CALLS/SEND No/CORRESP.ID
Your correspondents number
 On outgoing call, you can to be aware of
the phone number your call is forwarded to (COLP). This function is possible only if the called party allows its identity to be displayed, by deactivating its COLR option.
 On incoming call, when activated, this
function allows you to have your caller's ID displayed on your phone (CLIP). This function is possible only if the caller authorized it by deactivating its CLIR option.
7. Call related features
CALLS/SEND No/ANONYMOUS
Your phone number is not shown to the person you are calling. When you switch your phone off, it is automatically deactivated.
7.5 Auto redial
CALLS/AUTO RDIAL
You can activate auto redial systematically or on demand if your call did not complete. Any action on the keyboard will cancel it.
7.6 Call waiting
(Service depending on the operator)
CALLS/DBLE CALL
During a conversation, you may be warned that someone is trying to reach you. You will hear a special tone.
7. Call related features
When you switch your phone off, this menu is automatically deactivated.
You can activate, deactivate, consult the status ot the call waiting service and check whether it is active or not.
26
The message CALL WAIT followed by the call sequence number (and possibly the callers phone number if stored) are displayed on screen.
Depending on your network, you can then:
Cancel the waiting call by pressing C. The caller then hears a busy tone.
Switch call by pressing Ok. The current call is put on hold and you can answer the new call.
Unite this call in conference by pressing . All the parties can communicate (MULTI-CONFERENCE) according to the capacity of the network.
Terminate the current call by pressing . Your phone rings normally to indicate the waiting call.
7.7 Call hold
(Service depending on the operator)
During a conversation, you can put the current call ON HOLD by pressing Ok.
The screen displays the message ON HOLD followed by the hold sequence number (and possibly the phone number if stored).
You can then:
Initiate a new call
then:
Switch between the calls by pressing Ok.
Cancel the call on hold by pressing C.
Merge several calls by pressing . All the parties can communicate (MULTI­CONFERENCE).
Attention
In this case, pressing ends all calls.
7.8 Multi-conference
(Service depending on the operator and depending on model)
This service allows you to be in relation with several persons, according to the capabilities of the network.
If you have established a MULTI­CONFERENCE, the screen displays MULTIPARTY followed by the sequence number assigned to each caller. You can:
27
Cancel a call on hold or waiting by pressing C.
Switch between the multi-conference call and
a call on hold or waiting by pressing Ok or make a further call.
Make all the parties communicate by pressing (A multi-conference is limited to 6 persons: 5 in multi-conference and one separate call).
Standard commands
Sequences of standard keys also permit access to services such as call notification, call holding, multi-conferencing, and open up additional possibilities:
0 Reject a call holding or waiting (or
1
1 X
multi-conference calls).
End the current call holding or waiting (or the multi-conference calls if there are any) and accept the call (or multi-conference calls).
End the current call order number X.
7. Call related features
2 Place on hold the current call (or
multi-conference calls) and accept the call holding or waiting (or multi­conference calls).
2 X Place on hold the multi-conference
calls except for the current call order number X (private call).
3
Add a call holding (or multi­conference calls) to the current call (or to the multi-conference).
Tel N° Place on hold the current call (or
the multi-conference calls) and call another telephone number.
Note: However, it is preferable to place
the call on hold then dial, then call; this guarantees comfort and confidentiality (does not allow the call holding to hear the dialling tones whatever the configuration of the phone).
End all calls except for a possible call waiting.
7. Call related features
28
7.9 Checking call duration
CALLS/DURATION/COUNTERS This menu allows you to check the duration
of the last call. To check the cumulated duration of all calls since the last counter reset, press the scrolling arrows.
CALLS/DURATION/CLEAR
This menu allows you to clear the duration of the last call and to reset the call counter.
7.10 Charge-checking (*)
CALLS/COST/COUNTERS
If the network allows, you can check the charge for the last call. To check the cumulated charge for all calls since the last counter reset:
Press the scrolling arrows.
CALLS/COST/CLEAR
This menu allows you to clear the cost of the last call and to reset the call counter after entering your PIN2 code.
Attention
This data is purely indicative and cannot constitute a basis of proof: the network metering criteria may be quite different (indivisible minutes etc.).
7.11 Message centre
CALLS/MSG CENTER
To program a special call number, type in this number and validate.
This number is used when calling the message centre with the programmable keys.
Attention
For network specific services, such as message centre, speed dialing is valid only if the area you are calling from is covered by the network. In certain cases, it is better to use an international phone number. This memory is linked to the phone and not to the SIM card.
29
7. Call related features
30
8.1 Selecting silent mode
8. How to adjust the ringing
tones and the vibrator
8. Ringing tones and vibrator
RNG & BEEP/SILENCE?
If you wish, you can replace your phones ring-tone feature by a vibrating device or the silent mode. In this case, all tones are deactivated, except for wake-up calls.
Select ACTIVE by pressing the
arrow keys, then validate.
This mode is indicated by the
symbol on the display.
8.2 Setting the vibrator
RNG & BEEP/VIBRATOR
Select one of the following options by scrolling with the arrow keys: vibrating device only, vibrating device and ringing, vibrating device then ringing.
Validate.
The SILENT mode is automatically deactivated during connection/ disconnection of the hands-free kit, and when turning the phone on or off.
Wherever you require your calls to arrive discreetly, you can use the vibrator.
8.3 Selecting the volume and
the type of ringing tone
You can command your phone to ring when receiving calls and/or short messages.
RNG & BEEP/HANDSET/
OUT.CALLS
Select melody for calls to handset. RNG & BEEP/HANDSET/MESSAGES
Select melody for messages to handset.
RNG & BEEP/FREE HAND/OUT.CALLS Select melody for calls in hands-free mode.
RNG & BEEP/FREE HAND/MESSAGES Select melody for messages in hands-free mode.
For each of the above selections, the middle option - AUDIBLE or MUTE ­allows you to listen to or bypass the tone test during the setting phase.
Select the desired tone by pressing the scrolling arrows, then validate.
Select the desired volume by pressing the scrolling arrows, then validate (from 1 to 4 and + for crescendo setting).
A wide variety of melodies are available (including a silent ring) as well as a number of settings, including a crescendo.
31
8.4 Setting the alarm
RNG & BEEP/ALARM
To use your phone for wake-up calls:
With the scrolling arrows, set the
waking time (hours), validate by pressing Ok then set the minutes and validate.
Display ACTIVE by pressing the
scrolling arrows.
Validate.
Ringing stops by pressing any key; the wake-up time remains programmed.
The wake-up function remains active even with the phone OFF. Neither is it affected by the SILENT ringing mode.
The alarm function is represented on the screen by the symbol . Permanent flashing of this symbol indicates that an alarm time has been programmed but the date and time clock has not been initialised.
8. Ringing tones and vibrator
8.5 Setting the timer
RNG & BEEP/TIMER
The same procedure is applied as for the alarm function, but in this case you start a time clock running against a defined value. The phone must remain switched on.
8.6 Setting the beeps
Setting the keypad tones
RNG & BEEP/BEEPS/KEY. TONE
Choose the required tone by pressing the scrolling arrows, then validate.
Setting the network tone
RNG & BEEP/BEEPS/NETW. BEEP
This menu allows your phone to emit a warning beep when it finds a network on which it may operate:
Display ACTIVE with the scrolling arrows, then validate.
You can select the tones produced by your keypad: Beep, DTMF (musical keys) or non active tones (in this last case, when you press your keyboard, it does not make a noise).
8. Ringing tones and vibrator
32
Setting the low battery tone
RNG & BEEP/BEEPS/BATT. BEEP
This menu allows your phone to emit a warning beep when the battery is low:
Display ACTIVE with the scrolling arrows, then validate.
8.7 Deleting DTMF tones
RNG & BEEP/SEND DTMF
This menu allows you to disable the transmission of DTMF tones during a conversation. You can therefore enter a number to be memorized in the phone book conveniently and discreetly.
Select ACTIVE or INACTIVE by pressing the scrolling arrows, then validate.
33
9.1 Programming the «One Touch» keys
9. How to adjust your phone
SETTINGS/PROG. KEY
This menu, accessible directly by a short press on a One Touch key from the standby screen, enables you to configure the One Touch keys. There are different possibilities for each of the keys:
MEMORY
Validate MEMORY
When you press the key, you can see the names in the directory.
REDIAL
Validate REDIAL
When you press the key, you will be able to look through the last­numbers list.
9. Phone adjustment
The action allocated to a One Touch key is triggered by a long press or two short presses only from the standby screen.
MEM000 to  (depends on the SIM card used)
Select a number from the phone book and validate.
When you press the key, you will automatically call up the chosen number.
READ MSG
Validate READ MSG
When you press the key you will be able to read any short messages memorized in the SIM card or in the phone itself.
CALL MSG.CTR.
Validate CALL MSG. CTR
When you press the key, you will automatically call up the message-centre number, which is programmed into the CALLS/MSG CENTER menu.
SILENT MODE
Validate SILENT MODE
The ringing tone of your phone will be automatically replaced by the vibrator or by the silent ringing tone and all the beeps will be suppressed (except for the alarm).
Silent mode
This mode, indicated on the screen saver, is automatically deactivated/ activated when the hands-free kit is connected.
9. Phone adjustment
34
9.2 Personalising the welcome screen
SETTINGS/GREETING
You can personalise the welcome screen of your phone by typing a text.
Validate.
9.3 Selecting the display language
SETTINGS/LANGUAGE
This menu allows to choose your phone display language:
Select AUTOMATIC, the display language will be that of your SIM card (if available).
Otherwise select a language of your choice by pressing the scrolling arrows, and validate.
9.4 Select the type of automatic response
SETTINGS/ANSWER
To answer a phone call, you can either:
automatically be connected, if you selected Y (yes) to the question: auto (for hands-free kit) ; validate.
or press any numerical key if you replied: key: ALL ; validate.
or press if you replied: key: SEND ; validate.
9.5 Selecting the network
Every SIM subscription card can store an ordered list of preferred networks.
If the list has not been programmed, or if none of the networks on the list are available or authorised, the phone searches for an authorised network providing the highest level of signal.
If none of the available networks are authorized, the phone switches itself to emergency calls only until here is sufficient signal. In this case, the only authorized number is the number for calling the international emergency service.
Network
When your home network is not accessible (abroad, for example), your phone automatically searches for another available and authorised network in the order of preference indicated by the list on the SIM card.
35
If no network is available, your phone continues to search.
In all cases, the phone always searches, as priority, for its home network.
In specific cases, manual forcing is possible.
Using the scrolling arrows, you can select:
Available networks
SETTINGS/NETWORK/SELECT NET
This menu enables you to start a search for all available networks at the present location and to display them.
To manually force the chosen network, use the scrolling arrows and validate.
Preferred networks
SETTINGS/NETWORK/NETW.LIST
To program, into your SIM card, a list of preferred networks:
Use the scrolling arrows to select from the list.
Validate.
9. Phone adjustment
If the network is not on the list, select the country code then the network code (ask the organisation from which you obtained the SIM card).
9.6 Setting the time and date
SETTINGS/DATE/TIME/SET
To set the date and time on your phone:
The time flashes, adjust the time as required by pressing the scrolling arrows or by typing the desired digits. Validate.
The minutes flash and can be adjusted by pressing the scrolling arrows or by typing the desired digits. Validate.
Adjust the day, the month, the year. Validate after each proposal.
SETTINGS/DATE/TIME/DISPLAY
To display the date and time on the screen on a permanent way:
Choose ACTIVE by pressing the scrolling arrows. Validate.
9. Phone adjustment
36
9.7 Adjusting the contrast
SETTINGS/MISC/CONTRAST
This menu allows to adjust the contrast of the screen of your phone.
Adjust the contrast with the scrolling arrows, then validate.
9.8 Install energy saving mode
SETTINGS/MISC/SAVING MODE
You can switch your phone into a special standby mode, increasing its standby-time.
Using the scrolling arrows, you can change the level of light and the standby screen.
If you want to increase standby-time, select N with the scrolling arrows. Validate.
To reactivate the screen, press .
9.9 Standard configuration
SETTINGS/MISC/INITIAL
This menu allows you to return your phone to a standard configuration.
10.How to use the security features of your phone
37
10.1 Locking the keyboard
SECURITY/LOCK K.PAD
This menu allows you to lock your keypad to prevent accidental dialing in your briefcase or pocket.
Choose ACTIVE, the keypad is automatically locked after a certain period of non-use.
To unlock your keypad: Press then Ok.
10.2 Changing the PIN number
SECURITY/PIN CODE
You can change your PIN code:
In reply to the question: OLD PIN ?, type in your old PIN code and validate.
10. Security
Locked keyboard
You can still make emergency calls and answer calls.
Attention
If the wrong PIN code is entered three times in a row, the card will be blocked. To unlock your card, call the organisation from which you obtained this card, they will guide you on the procedure to use. If your SIM card is permanently locked, contact your operator or your Service Provider to obtain a new card.
In reply to the question: NEW PIN ?, type in your new PIN code (4 to 8 digit number) and validate.
In reply to the question: CHECK PIN ?, type in your new PIN code a second time for verification and validate.
10.3 Activating the PIN code
SECURITY/PIN CHECK.
This menu allows you to have the PIN code requested and checked at each startup so that if lost or stolen, your SIM card will be unusable:
In reply to the question: PIN ?, type in your PIN code and validate.
Display ACTIVE by pressing the scrolling arrows, then validate.
10.4 Activating the phone code
SECURITY/PHONE CHCK
The SECURITY/PHONE CHCK menu allows you to have the PHONE code requested and checked at each startup, in case someone tries to use a different SIM card.
10. Security
38
To activate:
In reply to the question: CODE ?, type in 0000 and validate.
Display ACTIVE by pressing the scrolling arrows, then validate.
To deactivate:
In reply to the question: CODE ?,
The phone code is a secret code, intended to protect the phone in the event of theft. It is linked automatically to the SIM card present on activation.
type in your code (may have been changed) and validate.
Display INACTIVE with the scrolling arrows, then validate. The code is reset to 0000.
10.5 Changing the phone code
SECURITY/PHONE CODE
When active, you can modify the PHONE code:
In reply to the question: OLD CODE ?, type in your old PHONE code and validate.
In reply to the question: NEW CODE ?, type in your new PHONE code (a 4 to 8 digit number) and validate.
In reply to the question: CHECK CODE ?, type in your new PHONE code a second time for verification and validate.
10.6 Changing the PIN2 code
SECURITY/PIN2 CODE (*)
You have a second PIN code. The change procedure for this PIN2 code is identical to the procedure given for the PIN code, menu SECURITY/PIN CODE.
10.7 Creating a fixed numbering phone book
SECURITY/FIXED REP. (*)
The pre-set directory allows you to limit calls. When you activate this directory, only the numbers you store in this directory can be called.
The menu MEM LOCK. allows you to ACTIVATE the fixed phone book in SIM card, after entering your PIN2 code. When ACTIVE, only the numbers already entered can be called.
The menu NUM. LIST allows you to navigate in the phone book by scrolling or by entering the required memory number in order to create and change the calling numbers.
This phone book will automatically be related to the SIM card, which means that its format will depend on the SIM cards format.
39
10.8 Charge-checking
SECURITY/COST/SETTINGS
After entering your PIN2 code, you can select the type of charge indication:
 CURRENCY: enter the currency
name (maximum 3 characters) and charge per unit. Ask your Operator for this value.
 PHONE UNIT
SECURITY/COST/LIMITATION
This menu is used to activate the credit function in the selected currency, after entering your PIN2 code.
10.9 Call barring
If allowed by your subscription, you can prevent your phone from making certain outgoing calls or receiving certain incoming calls.
10. Security
Attention
These functions depend on the ability of the network to send charge data to your phone in real time, and on the capacity or options on your SIM card.
If you can access the service, you will be given a password with your subscription. You will need this password in order to activate the function, failing which you will only be able to find out whether or not call barring is active (Menu:
Access to this service depends on your subscription type. For more information contact your Operator or Service Provider.
SECURITY/LIMIT/STATUS).
SECURITY/LIMIT
This menu allows you to activate, cancel and consult the status of the call barring service.
SECURITY/LIMIT/ACTIVATE
Scroll the menu to activate the type of call barring required:
- Bar outgoing calls, that is calls made from your phone. You can choose ALL outgoing calls, outgoing INTERNATIONAL calls or outgoing international calls, EXCEPT those sent to your home country (NOT HPLMN).
10. Security
40
- Bar incoming calls, that is received calls. Barring can concern ALL incoming calls or incoming calls when you are outside your home country (IF ROAMING).
In any case, you must enter your password. A screen message confirms activation of call barring.
SECURITY/LIMIT/DEACTIVATE
Scroll the menu to cancel the type of call barring required. You can also deactivate ALL call barring types. A screen message confirms deactivation of call barring.
SECURITY/LIMIT/STATUS
By scrolling through this menu, you can consult the status of a type of call barring, to check whether it is active or not.
SECURITY/LIMIT/PASSWORD
This menu allows you to change the password needed to activate the call barring function. The menu acts as a guide. A screen message confirms that the new password is active.
11. Other functions
41
11.1 Calculator
(Function available depending on model)
ACCESSORY/CALCULATOR
You can operate the calculator using the following keys:
Add
Subtract
Multiply
# Divide
Ok Equals
C Delete
Long press on
#
Decimal point
11. Other functions
11.2 Converter
ACCESSORY/EXCHANGE
This menu allows you to convert between different currencies.
ACCESSORY/EXCHANGE/ SETTINGS/MODE
Select ACTIVE, the converter will operate from the standby screen entering the figures selected and pressing the scrolling arrows to convert.
ACCESSORY/EXCHANGE/ SETTINGS/CURR. SYMB
Enter the codes for the two currencies to convert. Press C 3 times to return to the beginning of the line to type (if the lines are not blank).
ACCESSORY/EXCHANGE/ SETTINGS/RATE
Enter the exchange rate for the two currencies selected.
11. Other functions
INACTIVE mode
From the standby screen entering figures and pressing the scrolling arrows, you will display the menus.
42
ACCESSORY/EXCHANGE/CONVERT
Enter the value to convert, then press one of the scrolling arrows to run the conversion in whichever direction you require.
If you make a mistake, pressing C displays the original value entered, and you can then immediately reverse the calculation.
12.Available accessories
43
A range of accessories are available for your phone:
Supplementary batteries. Supplementary chargers. Desk charger. Cigarette lighter adapters. Hands free kits for pedestrians.
12. Available accessories
13.Upkeep
13. Upkeep
44
Upkeep
Clean your phone using a soft slightly damp non fluffy cloth.
Battery
After a long period of non use (several months), when the charger is being connected, the unit might not switch on.
In this case:
disconnect the charger, wait a few seconds and plug it in again.
It may be necessary to try this several times.
Maintenance menu
This menu contains information that you could be asked for to perform specific operations. If they are needed, you will be shown how to find them.
Attention
Certain chemical products can damage plastic. Do not use aerosols, certain special cleaning products, corrosive products, solvents, alcohol and detergents.
14.Recommendations
45
The use of your phone is controlled by safety regulations intended to protect both the user and his/her environment.
Electrical safety
Only use the appropriate chargers contained in the manufacturers catalogue. Using another charger could be dangerous; and will lead to the guarantee for your phone being rendered invalid.
The main plug socket must be easily accessible.
The mains voltage should correspond to that given on the manufacturers plate on the charger.
14. Recommendations
CE marking on the
unit conforms to directives 91/263/ CEE - 89/336/CEE ­73/23/CEE, 93/68/ CEE modified
Airplane safety
In an airplane, your phone must be switched off to ensure that it does not interfere with the planes systems. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations.
Areas containing combustibles
It is advisable to switch your phone off in the vicinity of petrol stations.
Regulations limit the use of radio equipment in chemical factories, petrol depots and any area where there are mines. You are advised to abide by these rules.
14. Recommendations
46
Road safety
Except in an emergency, do not use your phone when driving without a hands free kit that enables you to maintain your freedom of movement. In order not to diminish your attention, stop safely to make a call. Abide by the current laws.
If there is insufficient protection, some of the electronic equipment in the vehicle may be affected by the micro-waves given off by the phone. We would advise you to only use your phone in a vehicle fitted with an external aerial and if your phone may be connected to this antenna.
Installation of your phone in a vehicle must only be performed by qualified personnel.
Attention
Ensure that no part of your body is permanently close to the aerial unless there is a metal screen (e.g.: a vehicle roof, ).
Non ionising radiation
To obtain maximum satisfaction from your phone, use it in a vertical position. Your personal safety can only be improved.
If your phone is installed in a car, ensure that there is a non radiating cable for connecting your radio equipment to the aerial.
Electronic medical equipment
Your phone emits radio waves that could possible interfere with electronic medical equipment, for example an auditory prosthesis, heart pacemakers,  Your doctor or the manufacturer of the medical item will be able to advise you.
General precautions
Do not attempt to open your phone and repair it yourself. The manufacturer cannot be held responsible for any damage/ accident that may result from this.
Any work carried out by non-authorised personnel will result in your guarantee being rendered invalid.
47
Do not use your phone in damp areas (bathroom, swimming pool, ). Protect it from water and other liquids.
Do not expose your phone to extreme temperatures.
Do not leave your phone within the reach of small children.
Only use your phone with original accessories. If you do not your guarantee will be rendered invalid.
The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone automatically protects the batteries in the extreme temperatures.
Removing the battery for a long period will mean that the time is lost.
You are strongly advised not to connect your phone to the charger if it doesnt contain a battery.
To avoid the risk of demagne­tisation, do not place diskettes, credit cards etc. close to your phone.
14. Recommendations
Attention
The manufacturer cannot be held responsible if the above recommendations are not followed or if the phone is incorrectly used.
Answers to your questions
The telephone does not turn on
- Remove the battery and then replace it. or
- Connect the telephone to the charger (check that this is plugged in) for approximately 5 minutes.
No network recognised
- Remove the SIM card. Check that there is no dust or grit in the SIM slot. Replace the SIM card being sure to push it right up to the stop point.
Calls to a messaging service or voice server do not get through
- Check in the RNG & BEEP / SEND DTMF menu that the box is ticked.
Answers to your questions
48
*238204111A*
SAGEM
SA
MOBILE PHONES DIVISION
6, avenue d'Iéna - 75783 PARIS CEDEX 16 - FRANCE
S.A. au capital de 37 890 522 - 562 082 909 R.C.S PARIS
238204111A
DATASUBJECT TO CHANGE WITHOUT NOTICE
Couv. LU A6 tdpote 238204111 10/11/00 15:48 Page 2
Loading...
