User manual for
Telematics Control Unit
H913ET
Ver 1.0
Date: 2008/9/24
Contact Information
Masaki Mori Engineer
Bentendori Naka-ku 7F
4-59, Yokohama City
Kanagawa Pref 231-0007
Sage Co.,Ltd.
Sep 24, 2008
m-mori@jsage.co.jp
Sage Co.,Ltd.
Contents
GENERAL
FCC Rules
Safty Instructions
1. H913ET data sheet
2. Appearance
3. Componets
4. Installation/Operation
Sage Co.,Ltd.
Bentendori Naka-ku 7F
Yokohama City
4-59,
Kanagawa Pref 231-0007
1
Sage Co.,Ltd.
Bentendori Naka-ku 7F
Yo koh ama C ity
4-59,
Kanagawa Pref 231-0007
General
This document content describes the overview of the Telematics Control Unit H913ET.
The H913ET is designed to operate only in the United States with GPRS (General Packet
Radio Services) and EDGE (Enhanced Data rates for GSM Evolution) networks.
Users do not need to operate the device directly because the device is fully automatic.
However, users must comply with safety instructions. Please contact your sales
representative of Honda America if you have any problems.
FCC Rules
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
2
Sage Co.,Ltd.
Bentendori Naka-ku 7F
Yo koh ama C ity
4-59,
Kanagawa Pref 231-0007
Safety instructions
In August 1996, the Fed eral Communications Commission (FCC) of the U.S. adopted an
updated safety standard for human exposure to the radio frequency electromagnetic
energy emitted by FCC regulated transmitters.
The design of this Car Telematics Control Unit complies with the FCC guidelines and those
standards. The installation of the device is performing by the manufacturer at the rear
window of the car and ensures at least 20cm distance to any person inside or outside of
the car.
Modifications or antenna replacement not expressly approved by, Honda R&D Co., Ltd.
could void the user's authority to operate the equipment. To comply with RF safety
requirements please follow the installation instructions provided by the manufacture and
maintain a minimum separation distance of 20cm. from the antenna to any human body.
3
Bentendori Naka-ku 7F
Yo koh ama C ity
4-59,
Kanagawa Pref 231-0007
1 H913ET data sheet
Physical
Size D138, W145, H35
Weight 330g (Without Antenna, Cable)
Environment（without SIM card）
Operating temperature -20 degrees C to +60 degrees C
Storage temperature -40 degrees C to +85 degrees C
Performance
Maximum electric power consumption 630mA / 14V
Standby electric power consumption 120mA / 14V
Dark current electric power consumption Under 0.1mA
Version
Hardware version 1.30
Software version 1.00
Sage Co.,Ltd.
4
2 Appearance
Sage Co.,Ltd.
Bentendori Naka-ku 7F
Yo koh ama C ity
4-59,
Kanagawa Pref 231-0007
5
3 Components
Sage Co.,Ltd.
Bentendori Naka-ku 7F
Yo koh ama C ity
4-59,
Kanagawa Pref 231-0007
2
1
3
1: Telecommunication module (g24 E)
2: SIM socket
3: CAN (Car Area Network) connector, Power connector
4: Antenna connector
4
6
Bentendori Naka-ku 7F
Yo koh ama C ity
4-59,
Kanagawa Pref 231-0007
4 Installation/Operation
4.1 Installtion
H913ET is installed at the left side of the trunk. All installation is performed by authorized
Honda America engineers, and the user of the car will not be installing or touching the device
at any conditions.
Sage Co.,Ltd.
4.2 Opration
Users do not need to operate H913ET directory because H913ET is a full automatic. H913ET
will be turned on when the car ignition is on.
