OPERATOR’S MANUAL
18 VOLT POLE PRUNER
P2500
BATTERIES AND CHARGERS
SOLD SEPARATELY
Your pole pruner has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
TABLE OF CONTENTS
n Introduction ..................................................................................................................................................................... 2
�n General Safety Rules....................................................................................................................................................... 3
�n Specific Safety Rules.................................................................................................................................................... 3-4
n Safety Rules for Charger ................................................................................................................................................. 5
�n Symbols........................................................................................................................................................................ 6-7
��n Features........................................................................................................................................................................... 8
��n Assembly ......................................................................................................................................................................... 9
�n Operation.................................................................................................................................................................. 10-14
�n Maintenance.................................................................................................................................................................. 15
�n Parts Ordering / Service ................................................................................................................................................ 16
INTRODUCTION
This tool has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have
been given top priority in the design of this product making it easy to maintain and operate.
2 3
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS. Fail-
ure to follow all instructions listed below, may result in
electric shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
n Know your tool. Read and understand the operator’s
manual and observe the warnings and instruction labels
affixed to the tool.
n Stay alert, watch what you are doing, and use common
sense when operating a power tool. Do not use tool
while tired or under the influence of drugs, alcohol,
or medication. A moment of inattention while operating
power tools may result in serious personal injury.
n Do not allow children or untrained individuals to use
this unit.
n Store idle tools out of reach of children and other
untrained persons. Tools are dangerous in the hands
of untrained users.
n Wear safety glasses or goggles that are marked to
comply with ANSI Z87.1 standards and hearing protection when operating this unit.
n Wear heavy long pants, boots, and gloves. Do not wear
loose fitting clothing, short pants, jewelry of any kind, or
go barefoot.
n Secure long hair so it is above shoulder level to prevent
entanglement in any moving parts.
n Keep all bystanders, children, and pets at least 50 feet
away.
n Do not force tool. Use the correct tool for your appli-
cation. The correct tool will do the job better and safer
at the rate for which it is designed.
n Do not overreach. Keep proper footing and balance at all
times. Proper footing and balance enables better control
of the pole pruner in unexpected situations. Do not use
on a ladder or unstable support.
n Do not operate in poor lighting.
n Keep all parts of your body away from any moving
part.
n Do not use tool if switch does not turn it on or off. A
tool that cannot be controlled with the switch is dangerous and must be repaired.
n Avoid accidental starting. Be sure switch is in the
locked or off position before inserting battery pack.
Carrying tools with your finger on the switch or inserting
the battery pack into a tool with the switch on invites
accidents.
n Avoid dangerous environments. Do not use the at-
tachment in damp or wet locations. Do not use in rain.
n Maintain tools with care. Keep cutting tools sharp
and clean. Properly maintained tools with sharp cutting
edges are less likely to bind and are easier to control.
n Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the tool’s operation. If damaged, have the tool
serviced before using. Many accidents are caused by
poorly maintained tools.
n Keep the tool and its handle dry, clean, and free from
oil and grease. Always use a clean cloth when clean-
ing. Never use brake fluids, gasoline, petroleum-based
products, or any strong solvents to clean your tool. Following this rule will reduce the risk of loss of control and
deterioration of the enclosure plastic.
n Use only accessories that are recommended by the
manufacturer for your model. Accessories that may be
suitable for one tool may create a risk of injury when used
on another tool.
n Tool service must be performed only by qualified re-
pair personnel. Service or maintenance performed by
unqualified personnel may result in a risk of injury.
n When servicing a tool, use only identical replacement
parts. Follow instructions in the Maintenance section
of this manual. Use of unauthorized parts or failure to fol-
low Maintenance instructions may create a risk of shock
or injury.
SPECIFIC SAFETY RULES
n Before you start the unit, make sure the blade is not
contacting any object.
n Stop the unit, remove the battery pack, and make sure
the blade has stopped before setting the unit down.
n Never cut any material with a diameter greater than
4 in.
n To protect yourself from electrocution, do not operate
within 50 feet of overhead electrical lines.
n To protect yourself from falling branches, do not stand
directly under the branch or limb being cut. This unit
should not be held at an angle over 60° from ground
level.
n Replace any blade that has been damaged. Always
make sure blade is installed correctly and securely fastened before each use. Failure to do so can cause serious
injury.
SPECIFIC SAFETY RULES
PRECAUTIONS AGAINST KICKBACK
Kickback is a dangerous reaction that can lead to serious
injury.
n Keep a firm grip on the unit with both hands when
operating the unit. Place your right hand on the rear
handle and your left hand on the front handle. A firm grip
will help you reduce kickback and maintain control of the
unit.
n Make sure that the area in which you are cutting is
free from obstructions. Do not let the blade come in
contact with any obstruction while operating the unit.
n Always cut with the unit at full speed. Fully squeeze
the trigger and maintain a steady cutting speed.
n Use only the replacement blade specified for your
unit.
ELECTRICAL SAFETY
n A battery operated tool with integral batteries or a
separate battery pack must be recharged only with
the specified charger for the battery. A charger that
may be suitable for one type of battery may create a risk
of fire when used with another battery.
n Use battery operated tool only with specifically
designated battery pack. Use of any other batteries
may create a risk of fire.
n Use battery only with charger listed.
MODEL BATTERY PACK (P100) CHARGER (P110)
P2500 130255004 1423701, 140237023
or 130224028 or 140237021
n Battery tools do not have to be plugged into an elec-
trical outlet; therefore, they are always in operating
condition. Be aware of possible hazards when not
using your battery tool or when changing accessories.
Following this rule will reduce the risk of electric shock,
fire, or serious personal injury.
n Disconnect battery pack from tool or place the switch
in the locked or off position before making any adjustments, changing accessories, or storing the tool. Such
preventive safety measures reduce the risk of starting the
tool accidentally.
n Do not place battery tools or their batteries near fire
or heat. This will reduce the risk of explosion and pos-
sibly injury.
n Do not mutilate the battery pack. Released electrolyte
is corrosive and may cause damage to the eyes or skin.
It may be toxic if swallowed.
n Never use a battery that has been dropped or
received a sharp blow. A damaged battery is subject
to explosion. Properly dispose of a dropped or damaged
battery immediately.
n Batteries vent hydrogen gas and can explode in the
presence of a source of ignition, such as a pilot light.
To reduce the risk of serious personal injury, never use
any cordless product in the presence of open flame. An
exploded battery can propel debris and chemicals. If
exposed, flush with water immediately.
n Do not charg e batt er y tool in a damp or wet
location. Following this rule will reduce the risk of electric
shock.
n For best results, your battery tool should be charged
in a location where the temperature is more than
50°F but less than 100°F. Do not store outside or in
vehicles.
n Under extreme usage or temperature conditions, bat-
tery leakage may occur. If liquid comes in contact with
your skin, wash immediately with soap and water, then
neutralize with lemon juice or vinegar. If liquid gets
into your eyes, flush them with clean water for at least
10 minutes, then seek immediate medical attention.
n When battery pack is not in use, keep it away from
other metal objects like: paper clips, coins, keys, nails,
screws, or other small metal objects that can make
a connection from one terminal to another. Shorting
the battery terminals together may cause sparks, burns,
or a fire.
4 5
SAFETY RULES FOR CHARGER
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS.
Failure to follow all instructions listed below, may result in
electric shock, fire and/or serious personal injury.
n Before using battery charger, read all instructions and
cautionary markings in this manual, on battery charger,
battery, and product using battery to prevent misuse of
the products and possible injury or damage.
CAUTION:
To reduce the risk of electric shock or damage to
the charger and battery, charge only nickel-cadmium
rechargeable batteries as specifically designated on your
charger. Other types of batteries may burst, causing personal injury or damage.
n Do not use charger outdoors or expose to wet or damp
conditions. Water entering charger will increase the risk
of electric shock.
n Use of an attachment not recommended or sold by the
battery charger manufacturer may result in a risk of
fire, electric shock, or injury to persons. Following this
rule will reduce the risk of electric shock, fire, or serious
personal injury.
n Do not abuse cord or charger. Never use the cord to
carry the charger. Do not pull the charger cord rather than
the plug when disconnecting from receptacle. Damage
to the cord or charger could occur and create an electric
shock hazard. Replace damaged cords immediately.
n Make sure cord is located so that it will not be stepped
on, tripped over, come in contact with sharp edges
or moving parts or otherwise subjected to damage or
stress. This will reduce the risk of accidental falls, which
could cause injury, and damage to the cord, which could
result in electric shock.
n Ke ep cord an d cha rg er from he at to p re vent
damage to housing or internal parts.
n Do not let gasoline, oils, petroleum-based products,
etc. come in contact with plastic parts. They contain
chemicals that can damage, weaken, or destroy plastic.
n An e xtension cord sho uld not be used unless
absolutely necessary. Use of improper extension
cord could result in a risk of fire and electric shock. If
extension cord must be used, make sure:
a. That pins on p lug of extens ion c ord ar e t he
same number, s ize and s hape as those of
plug on charger.
b. That e xt en sion cor d is properly wir ed an d in
good electrical condition; and
c. That wire size is large enough for AC am pere
rating of charger as specified below:
Cord Length (Feet) 25' 50' 100'
Cord Size (AWG) 16 16 16
NOTE: AWG = American Wire Gauge
n Do not operate charger with a damaged cord or
plug, which could cause shorting and electric shock. If
damaged, have the charger replaced by an authorized
serviceman.
n Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. Take
it to an authorized serviceman for electrical check to
determine if the charger is in good working order.
n Do not disassemble charger. Take it to an authorized
serviceman when service or repair is required. Incorrect
reassembly may result in a risk of electric shock or fire.
n Unplug char ger fro m outlet before attempting
any maintenance or cleaning to reduce the risk of
electric shock.
n Disconnect charger from the power supply when
not in use. This will reduce the risk of electric shock or
damage to the charger if metal items should fall into the
opening. It also will help prevent damage to the charger
during a power surge.
n Risk of electric shock. Do not touch uninsulated portion
of output connector or uninsulated battery terminal.
n Save these instructions. Refer to them frequently
and use them to instruct others who may use this
tool. If you loan someone this tool, loan them these
instructions also to prevent misuse of the product and
possible injury.
SYMBOLS
50'
15m
50'
15m
Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation
of these symbols will allow you to operate the tool better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
V Volts Voltage
Hz Hertz Frequency (cycles per second)
A Amperes Current
W Watt Power
min Minutes Time
Alternating Current Type of current
Direct Current Type or a characteristic of current
n
o
.../min Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
No Load Speed Rotational speed, at no load
Class II Construction Double-insulated construction
Wet Conditions Alert Do not expose to rain or use in damp locations.
Read The Operator’s Manual
Eye, Hearing, and Head
Protection
To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Wear eye, hearing, and head protection when operating this
equipment.
Safety Alert Precautions that involve your safety.
Gloves
Wear non-slip, heavy-duty protective gloves when handling the
pole pruner and the blade.
Safety Footwear Wear non-slip safety footwear when using this equipment.
Moving Parts Keep hands away from moving parts.
Keep Bystanders Away Keep all bystanders at least 50 ft. away.
Kickback DANGER! Beware of kickback.
Hot Surfaces
To reduce the risk of injury or damage, avoid contact with any
hot surface.
Risk of Electrocution DANGER! Risk of electrocution!
No Hands Symbol
Failure to keep your hands away from the blade will result in serious
personal injury.
6 7
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER:
WARNING:
CAUTION:
CAUTION:
Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, may result
in minor or moderate injury.
(Without Safety Alert Symbol) Indicates a situation that may result in property damage.
SERVICE
Servicing requires extreme care and knowledge and should
be performed only by a qualified service technician. For
service we suggest you return the product to the nearest
AUTHORIZED SERVICE CENTER for repair. When servicing,
use only identical replacement parts.
WARNING:
The operation of any power tool can result in foreign objects being thrown into your eyes, which can
result in severe eye damage. Before beginning power tool operation, always wear safety goggles,
safety glasses with side shields, or a full face shield when needed. We recommend Wide Vision Safety
Mask for use over eyeglasses or standard safety glasses with side shields. Always use eye protection
which is marked to comply with ANSI Z87.1.
WARNING:
To avoid serious personal injury, do not attempt to use
this product until you read thoroughly and understand
completely the operator’s manual. Save this operator’s
manual and review frequently for continuing safe operation
and instructing others who may use this product.
SAVE THESE INSTRUCTIONS
FEATURES
PRODUCT SPECIFICATIONS
Motor..................................................................18 Volt DC
Blade Length ................................................................ 5 in.
Cutting Capacity................................................... Max 4 in.
HEX KEY AND
STORAGE AREA
SHAFT
ADJUSTMENT
COLLAR
Net Weight............................................................... 7.37 lb.
Charger Input ................................... 120 V, 60 Hz, AC only
Charge Rate ..............................................................1 hour
TRIGGER LOCK
CUTTING GUIDE
BLADE
KNOW YOUR POLE PRUNER
See Figure 1.
Before attempting to use this product, familiarize yourself
with all operating features and safety rules.
BLADE COVER
The blade cover protects the blade when the tool is being
stored or transported.
CUTTING GUIDE
The cutting guide helps to steady a limb when making
cuts.
BLADE COVER
Fig. 1
HEX KEY AND STORAGE AREA
The hex key provided with your pole pruner can be used for
quick blade changes and returned to a convenient storage
area.
SHAFT ADJUSTMENT COLLAR
The shaft adjustment collar easily locks and unlocks for toolfree adjustments to the length of your pole pruner.
TRIGGER LOCK
The trigger lock prevents unintentional starting of the pole
pruner.
8 9
ASSEMBLY
UNPACKING
This product requires assembly.
n Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list are
included.
n Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
n Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the tool.
n If any parts are damaged or missing, please call
1-800-860-4050 for assistance.
PACKING LIST
Pole Pruner
Blade
Blade Cover
Hex Key
Operator’s Manual
Warranty Registration Card
WARNING:
If any parts are damaged or missing do not operate this
tool until the damaged or missing parts are replaced.
Failure to do so could result in possible serious personal
injury.
INSTALLING/REMOVING THE BLADE
See Figures 2 - 3.
INSTALLING THE BLADE:
n Remove the battery pack from the pole pruner.
n Remove the hex key from the storage area.
n Place the hex key in the access hole and loosen the blade
retaining screw.
n Install the blade into the mounting clamp.
NOTE: Make sure the mounting clamp pin is positioned
correctly in the positioning pin hole of the blade. If not
positioned correctly the mounting clamp will not hold the
blade securely.
n Tighten the blade retaining screw securely with the hex
key.
n Return the hex key to the storage area.
n Reinstall the battery pack in the tool.
REMOVING THE BLADE
n Remove the battery pack from the pole pruner.
n Remove the hex key from the storage area.
n Place the hex key in access hole and remove the blade
retaining screw.
n Remove the blade from the unit, making sure the blade
clears the mounting clamp pin.
n Reinstall the battery pack in the tool.
WARNING:
Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any such
alteration or modification is misuse and could result in a
hazardous condition leading to possible serious personal
injury.
WARNING:
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from the
tool when assembling parts.
WARNING:
Blades are sharp. When installing and removing the
blade, wear non-slip, heavy-duty protective gloves. Do
not place your hand or fingers in any position where they
could get cut. NEVER touch the blade or service the unit
with the battery pack installed.
HEX KEY
STORAGE
MOUNTING
CLAMP PIN
POSITIONING
PIN HOLE
HEX KEY
Fig. 2
MOUNTING
CLAMP
Fig. 3
OPERATION
WARNING:
Do not allow familiarity with tools to make you careless. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear safety goggles or safety glasses with side
shields when operating tools. Failure to do so could result in objects being thrown into your eyes, resulting in
possible serious injury.
WARNING:
Do not use any attachments or accessories not recommended by the manufacturer of this tool. The use of attachments or accessories not recommended can result
in serious personal injury.
APPLICATIONS
You may use this tool for the purpose listed below:
n Limbing and pruning small branches and limbs up to 4
in. in diameter
CAUTION:
If at any point during the charging process none of the
LEDs are lit, remove the battery pack from the charger
to avoid damaging the product. DO NOT insert another
battery. Return the charger and battery to your nearest
service center for service or replacement.
LED FUNCTIONS OF CHARGER
LED WILL BE ON TO INDICATE STATUS OF
CHARGER AND BATTERY PACK:
n Red LED on = Fast charging mode.
n Green LED on = Fully charged and in maintenance charge
mode.
n Green LED on = When battery pack is inserted into
charger, indicates hot battery pack or that battery pack
is out of normal temperature range.
n Yellow and Green LEDs on = Deeply discharged or
defective battery pack.
n No LED on = Defective charger or battery pack.
CHARGING THE BATTERY PACK
Battery packs for this tool are shipped in a low charge condition to prevent possible problems. Therefore, you should
charge it until the green LED on the front of the charger
comes on.
NOTE: Batteries will not reach full charge the first time they
are charged. Allow several cycles (operation followed by
recharging) for them to become fully charged.
CHARGING A COOL BATTERY PACK
If battery pack is within normal temperature range, the red
LED on charger will come on.
NOTE: If the charger does not charge the battery pack
under normal circumstances, return both the battery pack
and charger to your nearest Authorized Service Center for
electrical check.
n Charge the battery pack only with the charger provided.
n Make sure the power supply is normal household
voltage, 120 volts, 60 Hz, AC only.
n Connect the charger to the power supply.
n Place the battery pack in the charger aligning raised rib
on the battery pack with the groove in the charger. See
Figure 4.
n Press down on the battery pack to be sure contacts on
the battery pack engage properly with contacts in the
charger.
n Normally the red LED on charger will come on. This
indicates the charger is in fast charging mode.
n Red LED should remain on for approximately 1 hour
then the green LED will come on. Green LED on
indicates battery pack is fully charged and charger is
in maintenance charge mode.
NOT E: Th e green LED will rema in on until the
battery pack is removed from the charger or charger is
disconnected from the power supply.
n If both yellow and green LEDs come on, this indi-
cates a deeply discharged or defective battery pack.
Allow the battery pack to remain in the charger for 15
to 30 minutes. When the battery pack reaches normal
voltage range, the red LED should come on. If the
red LED does not come on after 30 minutes, this may
indicate a defective battery pack that should be
replaced.
n After normal usage, a minimum of 1 hour of charging time
is required to fully recharge battery pack.
n The battery pack will become slightly warm to the
touch while charging. This is normal and does not
indicate a problem.
n Do not place the charger and battery pack in an area of
extreme heat or cold. They will work best at normal room
temperature.
NOTE: The charger and battery pack should be placed
in a location where the temperature is more than 50°F
but less than 100°F.
n When batteries become fully charged, unplug the
charger from power supply and remove the battery
pack.
10 11
OPERATION
CHARGING A HOT BATTERY PACK
When using the tool continuously, the batteries in the battery
pack will become hot. You should let a hot battery pack cool
down for approximately 30 minutes before attempting to
recharge. When the battery pack becomes discharged and
is hot, this will cause the green LED to come on instead of
the red LED. After 30 minutes, reinsert the battery pack in
the charger. If the green LED continues to remain on, return
battery pack to your nearest Authorized Service Center for
checking or replacing.
NOTE: This situation only occurs when continuous use of the
tool causes the batteries to become hot. It does not occur
under normal circumstances. Refer to CHARGING A COOL
BATTERY PACK for normal recharging of batteries. If the
charger does not charge your battery pack under normal circumstances, return both the battery pack and charger to your
nearest Authorized Service Center for electrical check.
TO INSTALL BATTERY PACK
See Figure 5.
n Place the battery pack in the pole pruner. Align the raised
rib on the battery pack with groove in pole pruner’s battery port.
n Make sure the latches on each side of the battery pack
snap in place and that the battery pack is secured in the
pole pruner before beginning operation.
P100
BATTERY PACK
YELLOW LED
BATTERY
PACK
P110
CHARGER
RED LED
GREEN
LED
Fig. 4
CAUTION:
When placing battery pack in the tool, be sure raised
rib on battery pack aligns with the bottom of the pole
pruner and latches into place properly. Improper installation of the battery pack can cause damage to internal
components.
TO REMOVE BATTERY PACK
See Figure 5.
n Locate the latches on the side of the battery pack and
depress both sides to release the battery pack from the
pole pruner.
LATCHES
Fig. 5
OPERATION
U
L
C
L
N
O
K
WARNING:
Battery tools are always in operating condition. Therefore,
switch should always be locked when not in use or
carrying at your side.
ADJUSTING THE SHAFT
See Figures 6 - 8.
n Rotate the lower portion of the shaft adjustment collar to
the “Unlock” position.
n The lower shaft should now be free to slide down from
inside the upper shaft. Make sure the shaft is pulled out
to the desired position.
n Rotate the shaft adjustment collar to the “Lock” position
and tighten securely.
SHAFT
ADJUSTMENT
COLLAR
TO UNLOCK
COLLAR
LOWER PORTION
OF SHAFT
ADJUSTMENT
COLLAR
Fig. 6
SLIDE OUT TO
DESIRED POSITION
Fig. 7
SHAFT
ADJUSTMENT
COLLAR
TO LOCK
LOWER PORTION
COLLAR
OF SHAFT
ADJUSTMENT
COLLAR
Fig. 8
12 13
OPERATION
STARTING AND STOPPING THE POLE
PRUNER
See Figures 9 - 10.
STARTING THE POLE PRUNER
n Hold the pole pruner as shown and ensure that you are
well away from anything that may contact the blade.
n Press and hold the trigger lock.
n Depress the switch trigger.
n Release the trigger lock. Continue to depress the trigger
for extended operation.
STOPPING THE POLE PRUNER
n Release the trigger to stop the pole pruner.
n Up on release of the t ri gg er, the trigger loc k will
automatically reset to the locked position.
60° MAXIMUM
PROCEDURES FOR CUTTING
PROPER GRIP ON HANDLES
See Figure 9.
n Wear non-slip gloves for maximum grip and protection.
n Maintain a proper grip on the unit when in operation. Use
your right hand to firmly grip the rear handle while your
left hand has a firm grip on the front handle.
n Never stand directly under the limb you are cutting.
BASIC CUTTING PROCEDURE
See Figures 11 - 12.
n Cut only wood or materials made from wood: no sheet
metal, no plastics, no masonry, no non-wood building
materials.
n Accelerate the unit to full speed just before entering the
cut by squeezing the trigger.
n Do not use a back-and-forth sawing-type motion for
cutting.
To prevent damage to tree or shrub bark:
n The first cut should be a shallow cut (1/4 of the limb
diameter) on underside of limb or trunk.
n The second cut should be made from the top side of the
limb outboard from first cut.
n Make the final cut close to the trunk and from the top of
the branch.
LOAD
Fig. 9
TRIGGER
LOCK
SWITCH
TRIGGER
Fig. 10
SECOND
CUT
FIRST CUT
1/4 DIAMETER
FINAL
CUT
Fig. 11
OPERATION
(
)
( )
n Keep the unit at full speed the entire time you are
cutting.
n For second and final cuts (from top of limb or branch),
hold the front cutting guide against the limb being cut.
This will help steady the limb and make it easier to cut.
n Allow the blade to cut for you; exert only light downward
pressure. If you force the cut, damage to the blade or unit
can result.
n Release the trigger as soon as the cut is completed,
allowing the unit to stop.
LIMBING AND PRUNING
See Figures 13 - 14.
This unit is designed for trimming small branches and limbs
up to 4 in. in diameter.
n Plan the cut carefully. Be aware of the direction in which
the branch will fall.
n Branches may fall in unexpected directions. Do not stand
directly under the branch being cut.
n The pole pruner should typically be positioned at an angle
of 60° or less, depending on the specific situation.
n As the boom-to-ground angle of the unit increases, the
difficulty of making the first cut (from the underside of
limb) increases. Failure to keep the tool at the correct
angle can result in the blade binding and becoming
pinched or trapped in the limb. If this should happen:
• Stop the unit and remove the battery pack.
• Remove the blade retaining screw, using the hex
key supplied, then remove the unit from the trapped
blade.
• Lift the limb while holding the blade. This should
release the “pinch” and free the blade.
• If the blade or pole pruner is still trapped, call a
professional for assistance.
The long reach of the unit allows the operator to prune
branches or limbs that are normally out of reach.
n Long branches should be removed in several stages.
n Cut lower branches first to allow the top branches more
room to fall.
n Work slowly, keeping both hands on the pole pruner with
a firm grip. Maintain secure footing and balance.
n Keep the tree between you and the blade while limbing.
Cut from the side of the tree opposite the branch you are
cutting.
n Do not cut from a ladder. This is extremely dangerous.
Leave this operation for professionals.
n Do not use for felling or bucking.
n When pruning trees, it is important not to make the flush
cut next to the main limb or trunk until you have cut off
CUTTING GUIDE
Fig. 12
60° MAXIMUM
Fig. 13
Fig. 14
the limb further out to reduce the weight. This prevents
stripping the bark from the main member. Underbuck the
branch 1/4-way through for your first cut. Your second cut
should overbuck to drop the branch off. Now make your
final cut smoothly and neatly against the main member
so the bark will grow back to seal the wound.
n To prevent electrocution, do not operate within 50 feet
of overhead electrical lines.
n Keep all bystanders at least 50 ft. away.
n Never climb into a tree to limb or prune. Do not stand on
ladders, platforms, or a log, or in any position which can
cause you to lose your balance or control of the unit.
14 15
MAINTENANCE
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
WARNING:
Always wear safety goggles or safety glasses with side
shields during power tool operation or when blowing
dust. If operation is dusty, also wear a dust mask.
WARNING:
To avoid serious personal injury, always remove the
battery pack from the tool when cleaning or performing
any maintenance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleumbased products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal
injury.
Only the parts shown on the parts list are intended to be
repaired or replaced by the customer. All other parts should
be replaced at an Authorized Service Center.
TRANSPORTING AND STORING
n Always place the blade cover on the blade before storing
or transporting the pole pruner. Use caution to avoid the
sharp teeth of the blade.
n Clean the pole pruner thoroughly before storing. Store
the pole pruner indoors, in a dry place that is inaccessible to children. Keep away from corrosive agents such
as garden chemicals and de-icing salts.
BLADE REPLACEMENT
When replacing the blade on this unit, use only replacement
blade part no. 6968001.
BATTERIES
The battery pack for this tool is equipped with nickel-cadmium
rechargeable batteries. Length of service from each charging
will depend on the type of work you are doing.
The batteries in this tool have been designed to provide
maximum trouble-free life. However, like all batteries, they
will eventually wear out. Do not disassemble battery pack
and attempt to replace the batteries. Handling of these
batteries, especially when wearing rings and jewelry, could
result in a serious burn.
To obtain the longest possible battery life, we suggest the
following:
n Remove the battery pack from the charger once it is fully
charged and ready for use.
For battery storage longer than 30 days:
n Store the battery pack where the temperature is below
80°F.
n Store battery packs in a “discharged” condition.
BATTERY PACK REMOVAL AND PREPARATION
FOR RECYCLING
To preserve natural resources, please
re cy cle or d ispose of batteri es
properly.
This product contains nickel-cadmium
batteries. Local, state or federal laws
may prohibit disposal of nickel-cadmium
batteries in ordinary trash.
Consult your local waste authority for information regarding
available recycling and/or disposal options.
WARNING:
Up on removal, c ov er the battery pack’s term inals with heavy-duty adhesive tape. Do not attempt to destroy or disassemble battery pack or
remove any of its components. Nickel-cadmium
batteries must be recycled or disposed of properly. Also,
never touch both terminals with metal objects and/or
body parts as short circuit may result. Keep away from
children. Failure to comply with these warnings could
result in fire and/or serious injury.
OPERATOR’S MANUAL
18 VOLT POLE PRUNER
P2500
• SERVICE
Now that you have purchased your tool, should a need ever exist for repair parts or service,
simply contact your nearest Authorized Service Center. Be sure to provide all pertinent
facts when you call or visit. Please call 1-800-860-4050 for your nearest Authorized
Service Center. You can also check our web site at www.ryobitools.com for a complete
list of Authorized Service Centers.
• MODEL NO. AND SERIAL NO.
The model number of this tool will be found on a plate attached to the motor housing.
Please record the model number and serial number in the space provided below.
• HOW TO ORDER REPAIR PARTS
When ordering repair parts, always give the following information:
• MODEL NUMBER
• SERIAL NUMBER
Ryobi® is a registered trademark of Ryobi® Limited used under license.
RYOBI TECHNOLOGIES, INC.
1428 Pearman Dairy Road, Anderson, SC 29625
Post Office Box 1207, Anderson, SC 29622-1207
P2500
Phone 1-800-860-4050
www.ryobitools.com
983000-845
10-05
16
Loading...
