Ryobi BT300 User Manual

OPERATOR'S MANUAL WIDE TABLE KIT 4730300
FOR USE WITH RYOBI BT3000 TABLE SAW
WIDE TABLE KIT SHOWN
ATTACHED TO BT3000 TABLE SAW
LUMBER NOT INCLUDED WITH THIS KIT
TABLE SAW AND STAND NOT INCLUDED WITH THIS KIT
Your new Wide Table Kit has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a Ryobi accessory kit.
SAVE THIS MANUAL FOR FUTURE REFERENCE
TABLE OF CONTENTS
Introduction....................................................................................................................................................................... 2
Rules For Safe Operation .................................................................................................................................................2
Symbols............................................................................................................................................................................ 3
Unpacking......................................................................................................................................................................... 3
Loose Parts ...................................................................................................................................................................... 4
Tools Needed.................................................................................................................................................................... 4
Assembly.......................................................................................................................................................................5-8
Parts Ordering / Service ................................................................................................................................................... 9
INTRODUCTION
This Wide Table Kit has many features for making the use of your table saw more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate.
WARNING:
The operation of any tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage. Before beginning operation, always wear safety goggles or safety glasses with side shields and a full face shield when needed. We recommend Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with side shields. Always wear eye protection which is marked to comply with ANSI Z87.1.
Look for this symbol to point out important safety precautions. It means attention!!! Your safety is involved.
RULES FOR SAFE OPERATION
Safe operation of this accessory requires that you read and understand this operator's manual, the operator’s manual for the table saw and all labels afxed to the tool.
READ ALL INSTRUCTIONS
KNOW YOUR ACCESSORY. Read the operator's manual
carefully. Learn the product's applications and limitations as well as the specic potential hazards related to this product.
KEEP THE WORK AREA CLEAN. Cluttered work areas
and work benches invite accidents. DO NOT leave tools or pieces of wood on the saw while operating.
ALWAYS WEAR SAFETY GLASSES WITH SIDE
SHIELDS. Everyday eyeglasses have only impact- resistant lenses; they are NOT safety glasses.
DO NOT USE THIS PRODUCT WITH OTHER EQUIP-
MENT or for other purposes.
ALWAYS DISCONNECT THE SAW FROM THE POWER
SUPPLY BEFORE ASSEMBLING THIS KIT. Make sure
the switch is off when reconnecting the saw to a power supply.
WARNING:
Do not attempt to use this product until you read thoroughly and understand completely the operator’s manual. Pay close attention to the safety rules, including Dangers, Warnings, and Cautions. If you use your product properly and only as intended, you will enjoy years of safe, reliable service.
BEFORE MAKING A CUT, BE SURE ALL ADJUST-
MENTS ARE SECURE.
SAVE THESE INSTRUCTIONS. Refer to them frequently
and use them to instruct other users. If you loan someone this product, also loan these instructions.
WARNING:
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber. Your risk from these exposures varies, depending on how often you do this type of work. To reduce your exposure to these chemicals: work in a well ventilated area, and work with approved safety equipment, such as those dust masks that are specially designed to lter out microscopic particles.
2
SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols, and the explanations with them, deserve your careful attention and understanding. The safety warnings do not by themselves eliminate any danger. The instructions or warnings they give are not substitutes for proper accident prevention measures.
SYMBOL MEANING
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious
injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result in death or seri-
ous injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moder-
ate injury. It may also be used to alert against unsafe practices that may cause property damage.
Note:
Advises you of additional information concerning the operation or maintenance of the equipment.
SAFETY AND INTERNATIONAL SYMBOLS
This operator's manual describes safety and international symbols and pictographs that may appear on this product. Read the operator's manual for complete safety, assembly, operating and maintenance, and repair information.
SYMBOL NAME
Wet Condition Alert
No Hands Symbol
Read the Operator’s Manual
Eye Protection
SAVE THESE INSTRUCTIONS
MEANING
Do not expose to rain or use in damp locations.
Failure to keep your hands away from the blade
will result in serious personal injury.
• To reduce the risk of injury, the user must read and
understand the operator’s manual before using this product.
Always wear safety goggles or safety glasses with side
shields and a full face shield when operating this product.
UNPACKING
Your new Wide Table Kit includes two 41 in. extension rails, plus the necessary brackets and connecting hardware required to make one wide support base and a rear extension table for your BT3000 table saw. All you have to supply is the lumber required for table tops and table legs, plus the wood screws, nails, bolts, etc. required to secure the table legs to the table top.
Remove the parts from the box. Make sure that all items
listed in the loose parts list are included.
Inspect all parts carefully to make sure no breakage or
damage occured during shipping.
If any parts are damaged or missing, please call 1-800-
525-2579 for assistance.
WARNING:
If any parts are missing do not assemble the kit until the missing parts are replaced. Failure to do so could result in serious personal injury
3
