Russound SRC2 User Manual

INTRODUCTION

The SRC2 Remote Control is the complete solution for all of your remote control requirements.It is designed to operate source devices and Russound audio system keypads. The SRC2 controls up to eight devices. For best results, please read and follow all the remaining instructions and keep this guide for future reference.

FEATURES AND FUNCTIONS

NOTE: key functions may vary from device to device. The following Key Chart provides a general description of functions.

Select a local device.

Activates control of Russound system controller and keypads, and its connected sources.

Use these keys to select specific sources.

Turn the selected device on or off.

Program sequences.

Select next/previous. Select the next/previous chapter on some models of DVD players. Press LAST to recall the last-viewed channel.

Raise or lower the sound level.

Press MUTE to turn the sound off or on.

Move the cursor in the menu screens.

Press OK to choose the high lighted menu option.May perform “Enter” function for devices.

Press Enter to choose the highlighted menu option .May per form “OK” function for devices.

Skip backward, rewind, fast forward, skip forward, stop pause, or play tracks on disc.

Use Page Up/Down with cable or satellite boxes.Note: May have to

learn in these functions.

View the current channel and program information .

Display the menu for the selected device.

Exit the selected device’s menu,g uide, or progr am wit hout making a menu selection.

Display the program guide for the selected device.

Sw it ch t he TV ’s, VCR ’s, S AT ’s or DVD ’s input to view TV or video programs.

Direct disc selection.

Press LAST once to recall the last channel; page back one screen in the main menu.

Select and save favorite presets.

Directly enter channels (e.g., 09 or 31). Press OK to send channel number entries on some TV models.

INSTALLING BATTERIES

1. On the back of the SRC2,push the tab and lift off the battery cover.

2. Obtain two (2) fully-charged AA alkaline batteries. Match the + and – marks on the batteries to the + and – marks in the battery case, then insert the new batteries.

3. Press the battery cover back into place.The tab should click when the cover is locked.

4. Test the unit by pressing Power and any mode key. If the batteries are inserted correctly, the LED will blink once.

PROGRAMMING A DEVICE

To control Universal TV,VCR or DVD,Cable or Satellite Receivers,Amplifier or tuner, and Auxiliary devices, follow these steps. Before proceeding, find the codes for the devices you want to program in “Manufacturer’s Codes” in this manual.

1. Turn on the device (e.g., DVD player) and if

needed, load media.

2. Press a device key.

3. Press and hold SET until the red LED blinks

twice, then release.

4. Enter the first five-digit code for your device.

The LED blinks once as each digit is entered. If the code is correct, the LED blinks twice.

Note: If the LED does not blink twice, repeat step 4 and try entering the code again.

5. Aim the remote at the device and press

POWER. The device should turn off. If it does not, repeat steps 3-5,tr ying each code for your brand until you find one that works. If you cannot find a code that works see “Searching for Your Code”in this manual.

6. Repeat steps 1-5 for the other devices you

want to c ontrol. For future reference, wri te down each working device code.

SEARCHING FOR YOUR CODE

If your device does not respond to the remote after trying all codes listed for our brand, or if your brand is not listed, try searching for your code:

1. Press a device key once.

2. Press and hold SET until the red LED blinks

twice, then release.

3. Enter 9-9-1, then the device group number

(see below). The LED blinks twice.

0 Cable (Cable Converters,

Video Accessories, Satellite

Receiver s) 1 TV (TVs) 2 VCR (VCRs, DVD players) 3 Audio (Audio Amplifiers,

Audio Amp/Tuners,

CD players)

4. Aim the remote at the device and press POWER.The remote sends IR codes from its library to the selected device, starting with the most popular code first.If the device responds,go to step 6.

5. If the device does not respond, press CH+. the remote will try the next code. Continue until the device responds.Press CH- to try the previous code.

6. Press SET to lock in code.To search for other devic e codes, repeat steps 1-5.

CHECKING THE CODES

If you have set up the remote using the procedure in “Searching for Your Code,” you may need to find out which five-digit code is operating your equipment. For example,to find out which code is assigned to your TV:

1. Press the key to which the TV is assigned.

2. Press and hold SET until the red LED blinks twice, then release.

3. Enter 9 9 0. The LED blinks twice.

4. To view the code’s first digit, press 1.Count the LED blinks (e.g., three blinks =3),and enter the number in the appropriate de vice list in step 8 of “Programming a Device.” If a code digit is 0,the LED does not blink.

5. Repeat step 4 for the remaining digits, using 2 for the second digit,and so on.

6. To check for other device codes, repeat steps 1-5, using the appropriate key.

CHANGING VOLUME LOCK

The SRC2 remote comes preset to allow independent volume control of each selected device (Global Volume Unlock).However, you may change the Volume Lock setting to Global Volume Lock so that one device’s volume will control volume in all other modes. After that , you can perform Individual Volume Unlock on a selected device to set its volume control for independent operation or Global Volume Unlock to remove all volume locking.

Locking Volume Control to One Mode (Global Volume Lock)

1. Press and hold SET until the red LED blinks twice, then release.

2. Enter 9 9 3 and then press the mode key for the device you want to control volume (e.g., TV). The LED blinks twice. Now when you press VOL+, VOL-,or Mute,the selected device will control the volume regardless of the current mode.

Unlocking All Volume Control (Restoring Global Unlock)

1. Press and hold SET until the red LED blinks twice, then release.

2. Enter 9 9 3 and then press VOL+. The LED blinks four times.Volume is independently controlled for all programmed devices.

Unlocking a Single Device’s Volume Control

1. Press a device key (VID,DVD, etc.).

2. Press and hold SET until the red LED blinks twice, then release.

3. Enter 9 9 3 and then press VOL-. The LED blinks four times.Volume is independently controlled for the selected devices.

USING LEARNING

The SRC2 includes a Learning feature so you can add functions that are unique to your home entertainment devices (e.g.,VCR Tracking Up or Down). The following precautions apply.

• The original remote controls must be in working order for learning to work properly.

• Learned keys are mode specific,so each one can store a unique function for each mode.

• Do not use the following keys for learning: Device Keys ,S ET, Back , or Reco rd.

• Learning capacity is approximately 40 to 100 keys, depending on the code being learned.

• Certain device codes are not learnable including multi-frequency types, some high frequency ones, and other unusual formats.

• For optimum learning,avoid high levels of ambient light such as natural sunlight or energy-efficient fluorescent lights.

• Have the original remote controls handy before programming learning.

Programming a learned key

Note: If more than 15 seconds pass between key presses,the remote exits programming.

1. Press and hold SET until LED flashes twice.

2. Press 9 7 5.

3. Press a device key once to assign a mode for learning.

4. Place the SRC2 head-to-head (about 2” apart) from your original remote control.Also locate the key (on original remote control) that will serve as the teaching function.

5. On the SRC2,press a key where the learned function will be stored.

6. On the original remote,press and hold the the key to be learned. The SRC2 LED will turn off. Continue holding the key on the original remote until the SRC2 LED blinks twice.

Note: If the LED displays one long blink,a learning error has occurred.Try repeating this step again until a successful capture occurs. If the function is still not captured,press and hold SET to exit programming. Review the learning precautions listed above, or the Troubleshooting tip s below, before beginning again at step 1.

7. Repeat steps 4-6 for another key on same device, or repeat steps 1-6 for another device.

Deleting a s ingle learning key

1. Select a source

2. Press and hold SET until the LED flashes twice. NOTE: If more than 15 seconds passes between key

presses,the remote exits programming.

3. Press 9 7 6.

4. Press the key (twice) containing the learned function to be deleted. The remote blinks twice.

5. Repeat steps 1-4 for another key on the same source, or press and hold SET to exit programm ing.

Deleting all learned keys in a specific mode

1. Press and hold SET until the LED blinks twice. Note: If more than 15 seconds pass between key

presses,the remote exits programming.

2. Press 9 7 6.

3. Press a device key tw ice to delete all the learned keys for that mode.The LED blinks twice.

4. Repeat steps 1-3 for another set of keys for a device, or press and hold SET to exit progr amming.

TROUBLESHOOTING

Problem: LED does not blink when you press a key. Solution: Replace battery with two new AA batteries. Problem: LED blinks when you repress a key, but

device does not respond. Solution: Make su re the remote is aimed at your device or system keypad and is not more than 15 feet away.

Problem: LED blinks one long blink. Solution: An entry error has occurred (e.g., wrong

key). Try entry sequence again. Problem: Remote does not control devices or commands are not working properly. Solutions: Try all listed codes for the device. Make sure the device operates with an infrared remote control. Problem: CH+, CH- and LAST do not work for your RCA TV. Solution: Due to RCA design from 1983 to 1987,only the original remote control will operate these function.

Problem: Channels do not change properly. Solution: If the original remote control required you

to press ENTER to change channels., press enter on this remote after enter ing the channel number.

ADDITIONAL INFORMATION

The SRC2 does not have any user-serviceable parts. Opening the case,except for the battery cover, may cause permanent damage to the SRC2.

603.659-5170 www.russound.com

28-1206 REV.1 11/30/05

MANUFACTURER’S CODES

Setup Codes for Audio Amplifiers

Bose 30674 GE 30078 JVC 30331 Marantz 30321 Nakamichi 30321 NEC 30264 Optimus 30395 Realistic 30395 Sansui 30321 Shure 30264 Sony 30689 Soundesign 30078 Victor 30331 Wards 30078 Yamaha 30354, 30133

Setup Codes for Audio Amp/Tuners

ADC 30531 Aiwa 31405,31243, 30121 Anam 31609, 31074 Audiotronic 31189 Bose 31229 Capetronic 30531 Carver 31189 Coby 31263 Denon 31360, 31142,30904

Fonmix 31360 Glory Horse 31263 Harman/Kardon 30110 Hitachi 31273 Inkel 30027 Integra 30135 JBL 30110 JVC 30074,31263 Kenwood 31313, 31570,30027 KLH 31428 Magnavox 31189, 31269, 30531 Marantz 31189, 31269, 30039 MCS 30039 Onkyo 30842, 30135 Optimus 31023, 30670,30531, 31074 Panasonic 31518, 30039 Philips 31189, 31269 Pioneer 31023, 30150, 30014, 30630, 30531 Proscan 31254 Qisheng 31609 Quasar 30039 RadioShack 31263 RCA 31023, 31609,31254, 30531, 31074 Sharper Image 31263 Silsonic 30176 Sony 31058, 31441,31258, 31759 Soundesign 30670 Stereophonics 31023 Sunfire 31313 Teac 31074, 31267 Technics 31308, 31518, 30039 Thorens 31189 Victor 30074 Wards 30014 Yamaha 30176, 31276,31176

Setup Codes for Cable Converters

ABC 00003, 00008, 00014 Americast 00899 Bell & Howell 00014 Bell South 00899 Clearmaster 00883 ClearMax 00883 Coolmax 00883 Daeryung 01877,00877, 00477, 00008 Digi 00637 Director 00476 Dumont 00637 Gehua 00476 General Instrument00476, 00810,00276, 00003, 00014 GoldStar 00144 Hamli 00009, 00273 Hitachi 00014 Jerrold 00476,00810, 00276, 00003, 00012,

00014 KNC 00008 LG 00144 Memorex 00000 Motorola 00476, 00810,00276, 01254, 01376 MultiVision 00012 Pace 01877, 00237 Panasonic 00000, 00008,00107 Panther 00637 Paragon 00000 Philips 00317, 01305 Pioneer 01877, 00877, 00144, 00533 Pulsar 00000 Quasar 00000 RadioShack 00883 Regal 00279, 00273 Runco 00000 Samsung 00000, 00144 Scientific Atlanta 01877, 00877, 00477,00008 Sony 01006 Starcom 00003, 00014 Supercable 00276 Supermax 00883 Tocom 00012 Torx 00003 Toshiba 00000 Trans PX 00276 Tristar 00883 TS 00003 V2 00883 Viewmaster 00883 Vision 00883 Vortex View 00883 Zenith 00000, 00525,00899

Setup Codes for CD Players

Aiwa 30157 Burmester 30420 California Audio Labs30029 Carver 30157,30179

Denon 30873 DKK 30000 DMX Electronics 30157 Dynamic Bass 30179 Fisher 30179 Garrard 30420 Genexxa 30032 Harman/Kardon 30157, 30173 Hitachi 30032 Integra 30101 JVC 30072 Kenwood 30826, 30626, 30028,30037, 30036,

30190 Krell 30157 Linn 30157 Magnavox 30157 Marantz 30626, 30029, 30157 MCS 30029 Miro 30000 Mission 30157 MTC 30420 NSM 30157 Onkyo 30868, 30101 Optimus 31063, 30000, 30032,30037, 30420,

30179, 31075,30145 Panasonic 30029 Parasound 30420 Philips 30626, 30157 Pioneer 31063, 31062, 30032 Polk Audio 30157 Proton 30157 QED 30157 Quad 30157 Quasar 30029 RadioShack 31075 RCA 31062, 30032, 30420,30179, 30053 Realistic 30420,30179 Rotel 30157,30420 SAE 30157 Sansui 30157 Sanyo 30179 SAST 30157 Sharp 30861, 30037 Silsonic 30888,30036 Sonic Frontiers 30157 Sony 30490,30000, 30100 Soundesign 30145 TAG McLaren 30157 Tascam 30420 Teac 30420 Technics 30029 Victor 30072 Wards 30157, 30053 Yamaha 30888, 30036 Zonda 30157

Setup Codes for DVD Players

Aiwa 20641,21912 Akai 20770 Allegro 20869 Apex Digital 20672, 20717, 20797,21061, 20796,

21056, 21937,20794, 21020, 21915 Blaupunkt 20717 Blue Parade 20571 Broksonic 20695 Changhong 20627,21061 CineVision 20869 Coby 21086 Curtis Mathes 21087 CyberHome 21024,21023, 21129, 20816, 21117 Daewoo 20833, 21172, 20869 Denon 20490 DVD2000 20521 Emerson 20591, 20675 Enterprise 20591 Fisher 21919 Funai 20675 Gateway 21158, 21073 GE 20522, 20717 Go Video 20744, 20833, 21099, 20783, 21075,

20869, 21730 Greenhill 20717 Harman/Kardon 20582, 20702 Hitachi 20573, 20664, 21919 Hiteker 20672 Initial 20717 Integra 20627,21924 JBL 20702 JVC 20558, 20623, 20867 Kenwood 20490, 20534 KLH 20717, 21020,21149 Koss 20651,21980 Lasonic 20798 LG 20591, 20869,20801 Liquid Video 21980 Lite-On 21158, 21058 Loewe 20511 Magnavox 20503, 20539,21976, 21914, 20675

Marantz 20539 Memorex 20695 Microsoft 20522 Mintek 20717 Mitsubishi 21521, 20521 Nesa 20717 Norcent 21003 Onkyo 20503, 20627, 21924,20792 Oritron 20651, 21980 Panasonic 20490,21762, 21990 Philips 20503, 20539, 20646,21914 Pioneer 20525, 20571 Polaroid 21086, 21061 Polk Audio 20539 Portland 20770 Proscan 20522 Qwestar 20651 RCA 20522, 20571, 20717,20822 Rio 20869 Rotel 20623 Sampo 20752, 20698 Samsung 20490, 20573,21932, 21075, 20820 Sansui 20695 Sanyo 20695 Sharp 20630, 20752 Sharper Image 21117 Sherwood 20770 Shinco 20717 Shinsonic 20533 Sonic Blue 20869, 21099 Sony 20533,20864, 21033, 21904, 21903 SVA 20717 Sylvania 20675 Symphonic 20675 Teac 20717, 21984, 20809 Technics 20490 Theta Digital 20571 Toshiba 20503, 20695 Urban Concepts 20503 Xbox 20522 Yamaha 20490, 20539, 20545 Zenith 20503, 20591,20869

Setup Codes for Satellite Receivers

AlphaStar 00772 Chaparral 00216 Crossdigital 01109 DirecTV 00392, 00566,00639, 01142, 00247,

00749, 01749,00724, 00819, 01856, 01076, 01109,00099, 01392, 01640,

01442, 01414,01108 Dish Network System 01005, 00775,01505 Dishpro 01005,00775, 01505 Echostar 01005,00775, 01505 Expressvu 00775 GE 00566 General Instrument 00869 GOI 00775 Goodmans 01246 Hisense 01535 Hitachi 00819, 00222, 01250 HTS 00775 Hughes Network Systems 01142,00749, 01749, 01442 I-Lo 01535 JVC 00775 LG 01414, 01226 Magnavox 00724, 00722 Memorex 00724 Mitsubishi 00749 Motorola 00869 NEC 01270 Next Level 00869 Panasonic 00247,00701 Paysat 00724 Philips 01142, 00749, 01749,00724, 01076,

00722, 00099,01442 Proscan 00392,00566 Proton 01535 RadioShack 00869 RCA 00392, 00566, 00855,00143, 01392 Samsung 01276, 01109,01108 Sanyo 01219 SKY 00856 Sony 00639,01640 Star Choice 00869 Tivo 01142,01442 Toshiba 00749, 01749, 00790,01285 UltimateTV 01640, 01392 Uniden 00724, 00722 US Digital 01535 USDTV 01535 Voom 00869 Zenith 00856, 01856

Setup Codes for TVs

Addison 10092 Admiral 10093, 10463 Advent 10761, 10842 Aiko 10092 Aiwa 11914 Akai 10812, 10702, 10030, 10672, 11903 Albatron 10700, 10843 America Action 10180 Anam 10250, 10180, 10700 Anam National 10250,10650 Anhua1 0051 AOC 10451, 10093, 10180,10060, 10030,

10178, 10092 Apex Digital 10748, 10765, 10879,10767, 11943 Audiovox 10451, 10180, 10875,10092, 10623 Baile 10661 Beijing 10812, 10661 Bell & Howell 10154 BenQ 11032 Bradford 10180 Broksonic 10236,10463, 11911, 11938, 11905,

11935, 11929 Cailing 10748 Candle 10030 Carnivale 10030 Carver 10054 Celebrity 10000 Celera 10765 Changcheng 10051,10661 Changhong 10156,10765, 11156, 10767 Ching Tai 10092 Chun Yun 10000, 10180, 10700,10092, 10843 Chung Hsin 10180, 10053 Cinema 10672 Citizen 10060, 10030, 11928,10092 Clarion 10180 Commercial Solutions11447,10047 Conrowa 10156, 10145, 11156 Contec 10180 Craig 10180 Crosley 10054 Crown 10180 Curtis Mathes 10047,10054, 10154, 10451, 10093,

10060, 10702,10030, 10145, 10166 CXC 10180 Daewoo 10154, 10451, 10180, 10030,10178,

10672, 11928,10092, 10661, 11909,

10623, 10700 Dayu 10661 Dell 11080 Denon 10145 Dumont 10017 Durabrand 10463,10180, 10178, 10171, 11034 Electroband 10000 Emerson 10154, 10236, 10463, 10180,10178,

10171, 11944,11909, 11929, 11905,

11928, 10623,11911 Envision 10030 Ether 10030 Firstar 10236 Fisher 10154 Fortress 10093 Fujitsu 10809, 10853 Funai 10180, 10171, 11904 Furi 10145 Futuretech 10180 Gateway 11756, 11755 GE 11447, 10047,11454, 10051, 10451,

10180, 10030,10178, 11917, 10092,

11907, 11922 Gibralter 10017,10030 GoldStar 10154, 10030, 10178,11926 Grunpy 10180 Haier 11034 Hallmark 10178 Hankook 10180, 10030,10178 Harley Davidson 11904 Harman/Kardon 10054 Harvard 10180 Havermy 10093 Helios 10865 Hello Kitty 10451 Hisense 10156, 10748,10145, 11156 Hitachi 10156, 10030, 10178, 11145,10145,

10092, 11904,11156 Hongmei 10093 Huafa 10145 Huari 10145 Huodateji 10051 Imperial Crown 10661 Infinity 10054 Inteq 10017 JBL 10054 JCB 10000 Jean 10156,10051, 10236, 10092 Jensen 10761 Jiahua 10051 Jinfeng 10051 Jinxing 10054,10156, 10145 JVC 10053, 11923, 11253 Kangli 10661

SRC2

ADVANCED LEARNING &

PRE-PROGRAMMED REMOTE CONTROL

USER GUIDE

KEC 10180 Kenwood 10030 KLH 10765, 10767 Kolin 10180,10150, 10053 KTV 10180, 10030 Kunlun 10051, 10661 LG 10060, 10030,10178, 10856, 10700,

10025 Lloyd's 11904 LXI 10047, 10054, 10154,10156, 10178 Magnasonic1 1928, 11913 Magnavox 11454, 10054,10030, 10706, 11931,

11254, 11913,11904, 11944 Magnin 11907 Marantz 10054, 10030, 10704 Matsushita 10250, 10650 Maxent 11755 Megapower 10700 Megatron 10178, 10145 Memorex 10154, 10463,10150, 10178, 11911,

11926, 11924,11920, 11927 MGA 10150, 10030, 10178,11907 Midland 10047, 10017, 10051 Mitsubishi 10154, 10250, 10093, 10236,10180,

11250, 10150,10030, 10178, 11917,

10836 Monivision 10843, 10700 Motorola 10093 MTC 10060, 10030 Mudan 10051 Multitech 10180 NAD 10156, 10178, 10866 National 10051 NEC 10154, 10156, 10051,10053, 10030,

10178, 11704 Newave 10093, 10178, 10092 Nikko 10030, 10178, 10092 Norcent 10748, 10824 NTC 10092 Onwa 10180 Optimus 10154, 10250, 10166,10650, 11927, 11924,

11913 Optonica 10093 Orion 10236, 10463, 11929,11911, 11905 Panasonic 10054,10250, 10051, 10650, 11941, 11927,

11924 Panda 10051, 10706 Penney 10047, 10156,10051, 10060, 10030, 10178,

11926, 11907 Philco 10054, 10180, 10030, 10178 Philips 11454, 10054, 10000,10051, 10030, 10178,

10092, 10690 Pilot 10030 Pioneer 10166, 10866, 10679 Portland 10092 Prima 10761 Princeton 10700 Prism 10051 Proscan 11447, 10047, 11922 Proton 10030, 10178 Pulsar 10017 Qingdao 10051 Quasar 10250, 10051, 11924, 10650 RadioShack 10047, 10154, 10180, 10030, 10178,11920,

11904 RCA 11447, 10047, 11454,10000, 10030, 10178,

11547, 11922,11917, 10092, 11907, 11948,

10090, 10679 Realistic 10154,10180, 10030, 10178 Rowa 10748 Runco 10017, 10030 Sampo 10154, 10093, 10030, 10178, 10171,10700,

10650, 11755,10092 Samsung 10154, 10156,10060, 10812, 10702, 10030,

10178, 11060,10814, 10092, 11903, 10090,

10766 Sansui 10463,11904, 11935, 11929, 11911 Sanyo 10154, 10156, 10180, 10145,11907 Sanyuan 10093 Scotch 10178 Scott 10236, 10180,10178 Sears 10047, 10054,10154, 10156, 10178, 10171,

11926, 11904 Shaofeng 10145 Sharp 10093, 10030,10650, 11917 Shen Ying 10092 Shencai 10145 Sheng Chia 10093, 10236 Skygiant 10180 Skyworth 10748 Sony 11100,10000, 10650, 11925, 11904 Soundesign 10180, 10178 Sowa 10156,10051, 10060, 10178, 10092 Squareview 10171 SSS 10180 Starlite 10180 Studio Experience 10843 Supreme 10000 SVA 10748, 10865 Sylvania 10054, 10030, 10171,11944, 11931 Symphonic 10180,10171, 11913, 11904 Synco 10000, 10451, 10093, 10060, 10178,10092 Tacico 10178, 10092 Tandy 10093

Tashiko 10092, 10650 Tatung 10054, 10154, 10156,10051, 10060, 11156,

11756, 11254 Technics 10250, 10051 Techwood 10051 Teco 10051, 10093, 10178, 10092 Teknika 10054, 10180, 10150,10060, 10092 Telefunken 10702 Tera 10030 Thomas 11904 Tiane 10093 TMK 10178 TNCi 10017 Tobo 10748 Toshiba 10154, 10156, 10060,10145, 11945, 11704,

11936, 11156,11935, 10650, 11918 Tuntex 10030, 10092 TVS 10463 V Inc. 11756, 10885, 10864 Vector Research 10030 Victor 10250, 10053, 10650 Vidikron 10054 Vidtech 10178 Viewsonic 11755,10885, 10864 Wards 10054, 10030,10178, 10866, 11156 Warumaia 10661 Waycon 10156 White Westinghouse 10463, 11909, 10623 Yamaha 10030 Yapshe 10250 Zenith 10017, 10463,10178, 11904, 11929,11911,

11909, 10092

Setup Codes for VCRs

ABS 21972 Admiral 20048, 20209 Aiko 20278 Aiwa 20037,20479 Alienware 21972 America Action 20278 American High 20035 Amoisonic 20479 Anam 20162, 20037, 20240, 20278 Anam National 20162 Asha 20240 Audiovox 20037, 20278 Beaumark 20240 Bell & Howell 20104 Broksonic 20184,20121, 20209, 20002, 20479 Calix 20037 Canon 20035 Carver 20081 CCE 20072, 20278 Changhong 20048,20081 Citizen 20037, 20278 Colt 20072 Craig 20037, 20047, 20240,20072 Curtis Mathes 20060,20035, 20162 Cybernex 20240 CyberPower 21972 Daewoo 20045, 20104, 20278 Dell 21972 Denon 20042 DirecTV 20739 Durabrand 20039,20038 Electrohome 20037 Electrophonic 20037 Emerex 20032 Emerson 20035, 20037, 20184, 20240,20045, 20121,

20043, 20209,20002, 20278, 20479 Fisher 20047, 20104 Fuji 20035,20033 Fujitsu 20045 Gateway 21972 GE 20060, 20035,20240 General 20045 Go Video 20432 GoldStar 20037, 20209, 20038,20225 Haojie 20240 Harman/Kardon 20081,20038 Harwood 20072 Hewlett Packard 21972 HI-Q 20047 Hitachi 20037, 20042, 20055 Howard Computers 21972 HP 21972 Hughes Network Systems 20042,20739 iBUYPOWER 21972 JVC 20045, 20067 KEC 20037, 20278 Kenwood 20067, 20038 KLH 20072 Kodak 20035, 20037 Kolin 20043 LG 20037, 20045,20042, 20209, 20038 Logik 20072 LXI 20037 Magnavox 20035, 20039,20081

Magnin 20240 Marantz 20035, 20081 Marta 20037 Matsushita 20035, 20162 Media Center PC 21972 MEI 20035 Memorex 20035, 20162,20037, 20048, 20039,20047,

20240, 20104,20209, 20479 MGA 20240, 20043 MGN Technology 20240 Microsoft 21972 Mind 21972 Minolta 20042 Mitsubishi 20067, 20043 Motorola 20035, 20048 MTC 20240 Multitech 20072 NEC 20035, 20037, 20048,20104, 20067, 20038 Newave 20037 Nikko 20037 Noblex 20240 Northgate 21972 Olympus 20035 Optimus 21062, 20162, 20037,20048, 20104, 20432 Orion 20184, 20209, 20002,20479 Panasonic 21062,20035, 20162, 20616, 20225 Penney 20035, 20037,20240, 20042, 20038 Pentax 20042 Philco 20035, 20479 Philips 20035, 20081, 20739,20618 Pilot 20037 Pioneer 20042, 20067 Polk Audio 20081 Profitronic 20240 Proscan 20060 Protec 20072 Pulsar 20039 Qisheng 20060 Quasar 20035, 20162 Radix 20037 Randex 20037 RCA 20060, 20035, 20240,20042, 20880 Realistic 20035,20037, 20048, 20047, 20104 ReplayTV 20616 Runco 20039 Sampo 20037, 20048 Samsung 20240, 20045,20432 Sanky 20048, 20039 Sansui 20067,20209, 20479 Sanyo 20047, 20240, 20104 Scott 20184, 20045, 20121, 20043 Sears 20035, 20037,20047, 20042, 20104 Sharp 20048, 20209 Shintom 20072 Shogun 20240 Singer 20072 Sonic Blue 20616 Sony 20035,20032, 20033, 20636, 21972 STS 20042 Sylvania 20035, 20081, 20043 Systemax 21972 Tagar Systems 21972 Tashiko 20037 Tatung 20045, 20067 Technics 20035, 20162 Teco 20035, 20037, 20048, 20038 Teknika 20035, 20037 Tivo 20636,20618, 21503, 20739 TMK 20240 Toshiba 20045, 20042, 20067,20043, 21503, 21008,

21972 Totevision 20037, 20240 Touch 21972 Unitech 20240 Vector 20045 Vector Research 20038 Victor 20067 Video Concepts 20045 Videomagic 20037 Videosonic 20240 Viewsonic 21972 Wards 20060, 20035,20048, 20047, 20081, 20240,

20042, 20072 White Westinghouse 20209, 20072 XR-1000 20035, 20072 Yamaha 20038 Zenith 20039, 20033,20209, 20479 ZT Group 21972
