RPI Industries SCBC48R Service Manual

IMPORTANT:

THE FOLLOWING INFORMATION SHOULD BE RETAINED FOR FUTURE

REFERENCE

RPI Industries, Inc.

“building a better case for sales”

CONFECTIONERY

USE & SERVICE MANUAL

WARRANTY INFORMATION

For Models

Bradford Continental Double

SCBC48R SCCC48R SCDC48R
SCBC60R SCCC60R SCDC60R
SCBC72R SCCC72R SCDC72R
SCBC96R SCCC96R SCDC96R

LaRond Monarch Regency

SCLC48R SCMC48R SCRC48R
SCLC60R SCMC60R SCRC60R
SCLC72R SCMC72R SCRC72R
SCLC96R SCMC96R SCRC96R

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE

220 Route 70, Medford, NJ 08055

PHONE: [phone] FAX: [phone]

RPI Industries, Inc.

Congratulations, you have just purchased the finest candy case available. RPI
Industries, Inc. development of an exclusive humidity and temperature control
system insures product shelf life and enticing displays, which leads to a better
bottom line. We at RPI Industries, Inc. hope you are satisfied with your case for
many years to come.

IMPORTANT IMPORTANT IMPORTANT

Controls are pre-set at our factory. Please consult our refrigeration service
department at [phone] if setting changes are required.

TAMPERING WITH CONTROLS WITHOUT PRIOR AUTHORIZATION

FROM RPI Industries, Inc. MAY VOID YOUR WARRANTY

Please consult your use and service manual for proper care of your case.

2

RPI Industries, Inc.

REFRIGERATED CANDY CASE

SERVICE & MAINTENANCE INFORMATION

1. Temperature of case is controlled by temperature control in storage area.

Cases are pre-set at factory.

2. Humidity control should be set at 55% RH located in compressor

compartment.

3. Condensing unit is 115 volt, 60 cycle, single phase, air cooled or equal.

4. Refrigerant: R134A.

5. Air temperature on discharge should be between 55 & 60 degrees.

6. Average case temperature with light on should be 64 degrees.

7. Make certain that the drain pan on refrigerated cases is checked weekly.

8. Brush out and vacuum condenser (looks like a black radiator) once a

month for efficient operation. (When the condenser is clogged with dirt
and dust, the case looses its efficiency, causing the unit to operate
without stopping).

9. Do not store packages against blower (evaporator coils) so airflow is not

impeded.

10. Do not block airflow inside display area over front and back grill.

11. Keep the flow area around the fixture clean and orderly.

12. Tracks and sliding door fixtures should be cleaned and lubricated

periodically.

13. Check inside cooling coil housing to be certain that it is free of ice debris.

14. Replace any malfunctioning parts as soon as possible.

15. It is most important that the interior of the fixture be cleaned periodically.

HOW TO CLEAN: Remove the product load and all shelving. Use only
mild soap or detergent to wash the interior panels. Rinse with clean,
warm water, and dry with a soft absorbent cloth.

3
