Outstanding New Sounds
----------------------------------------------------------------------------------------------------------------------------
Make no mistake. The RS-70 and -50 are full of new sounds.
And not just new Patches, but an entirely new set of waveforms
sampled at 44.1kHz. Put simply, these keyboards sound
amazing. From the delicate nuances of the acoustic piano
and Rhodes Patches to the rich tones of the strings and
new synthesizer sounds,
you’ll immediately hear
the difference. Bundled
editor software makes it
easy to dive in and program
your own sounds.
----------------------------------------------------------------------------------------------------------------------------
Made for Performance
----------------------------------------------------------------------------------------------------------------------------
With the new Multi Chord Memory function, musicians can
play a variety of complex chords using a single note. Or trigger
phrases at the touch of a key using the Phrase/Arpeggio
Generator, which on the RS-70, can be fully programmed and
even recorded to the sequencer. The RS-50 also features a
Rhythm Guide metronome with preset rhythm patterns in a
variety of styles.
----------------------------------------------------------------------------------------------------------------------------
Loaded with Extras
----------------------------------------------------------------------------------------------------------------------------
Both the RS-70 and RS-50 feature Roland's popular D Beam
Controller for controlling functions like pitch or filter cutoff
using an infrared beam of light. The D Beam can also be used
to control Roland's unique Active Expression feature, which
makes it easy to fade in a second sound or change the volume
and timbre. The RS-70 also includes a built-in floppy drive for
directly playing GM/GM-2-compatible Standard MIDI Files—
plus Roland's exclusive V-LINK technology for triggering
video clips*.
*V-LINK requires the Edirol DV-7PR Digital Video Workstation (sold separately) with software
version 1.50 or higher.
----------------------------------------------------------------------------------------------------------------------------
Easy Instrument-Based Sequencing
----------------------------------------------------------------------------------------------------------------------------
Instead of using complicated concepts like MIDI channels and
tracks, the RS-70’s Loop Sequencer is based on sounds. To create
a sequence, simply choose a sound and record. As the recording
loops, additional sounds can be selected and overdubbed
until all parts are entered. Realtime and step recording are
both supported, along with Microscope editing.
RS-70/-50
Synthesizers
■ Affordable 61-note synthesizers with easy
access to Roland’s latest sounds
■ Hundreds of all-new Patches based on
CD-quality waveforms
■ Direct Access Buttons permit easy sound
selection by category
■ New Loop Sequencer simplifies recording—
just choose a sound and go! (RS-70)
■ Phrase/Arpeggio Generator (programmable
on RS-70) and Multi Chord Memory
■ Rhythm Guide metronome with preset
patterns and several variations (RS-50)
■ D Beam Controller for realtime control using
an infrared beam of light
■ Built-in 3.5” floppy drive for direct SMF playback
from disk (RS-70)
■ V-LINK function for controlling Edirol video
equipment (RS-70)
■ Includes editor software for Mac and PC
■ Onboard USB-MIDI interface (RS-70)
32
Just Play.
Roland’s new RS-70 and RS-50 Synthesizers are designed so musicians can forget about MIDI and
focus on playing. Both models sport an all-new collection of CD-quality sounds, cool performance
features and simple Direct Access buttons for selecting Patches—all at an entry-level price. The
flagship RS-70 even includes a Loop Sequencer that takes the mystery out of multi-track recording.
■ Keyboard 61 keys (with velocity) ■ Maximum Polyphony 64 voices
■ Multitimbral Parts 16 parts ■ Wave Memory (16-bit linear equivalent) RS-70:
64MB, RS-50: 32MB
■ Preset Memory Patches: RS-70: 768 (RS-70 Original: 512,
GM2: 256), RS-50: 512 (RS-50 Original: 256, GM2: 256), Rhythm Sets: RS-70: 30
(RS-70 Original: 21, GM2: 9), RS-50: 20 (RS-50 Original: 11, GM2: 9)
■User Memory
Patches: 128, Rhythm Sets: 16 ■ Effects Multi-effects: 47 types, Reverb: 8 types,
Chorus: 8 types
■ Multi Chord Memory Preset Chord: 16 sets x 12 chord forms,
User Chord: 8 sets x 12 chord forms
■Phrase/Arpeggio Phrase Template: over 200,
User Style (RS-70 only): 8, User Arpeggio: 8
■Storage (RS-70 only) 3.5 inch floppy
disk (2HD/2DD)
■Display 20 characters, 2 lines (Backlit LCD) ■ Controllers Pitch
Bend / Modulation Lever, 1, D Beam Controller: 1, Control Knobs: 5
■Connectors
Output Jack: L (MONO), R, Phones Jack: 1, Hold Pedal Jack: 1, Control Pedal Jack: 1,
MIDI Connector: IN, OUT, USB Connector: 1 (USB-MIDI, RS-70 only)
■ Power
Supply
DC 9V (AC adaptor) ■ Current Draw RS-70: 2,000 mA, RS-50: 1,000 mA
■ Dimensions 1,033 (W) x 294 (D) x 103 (H) mm, 40-1/16 (W) x 11/9/16 (D) x
4-1/16 (H) inches
■Weight RS-70: 5.8 kg, 12 lbs. 13 oz., RS-50: 5.5 kg, 12 lbs. 2 oz.
* The specifications are subject to change without notice.
RS-70/-50 Specifications
■
RS Editor:
Performance Mixer Window
*Product pictured are prototype models. Actual product appearance may be subject to change.
Page 2
RD-170
Digital Piano
■ Affordable 64-voice digital piano ideal for
students and stage performers alike
■ 88-note weighted hammer-action keyboard
with improved touch response
■ 64 high-quality Tones including an amazing
stereo grand piano and more
■ New Master Keyboard functions for controlling
external MIDI modules
■ 16 Programmable Setups allow instant recall
of custom settings
■ New half-pedal recognition for sustained playing
just like an acoustic piano
■ Split and Layer functions for dividing the
keyboard or playing two Tones at once
■ Onboard 2-track recorder makes recording
performances easy
54
----------------------------------------------------------------------------------------------------------------------------
Professional Quality
at an Affordable Price
----------------------------------------------------------------------------------------------------------------------------
The RD-170 is a marvel of design. Inside this sleek, lightweight
package is a surprisingly powerful digital piano with features
that rival instruments costing much more. From its improved
weighted hammer-action keyboard to the simplified front panel
and classy wooden end bells, the RD-170 simply outshines
the competition.
----------------------------------------------------------------------------------------------------------------------------
Legendary RD Piano Sounds and More
----------------------------------------------------------------------------------------------------------------------------
As one might expect, the RD-170’s piano sounds are nothing
less than phenomenal. The acoustic grand piano is a real
standout; thanks to stereo sampling, every nuance can be
faithfully captured. Of course, there’s also a selection of fine
instrument Tones ranging from electric piano and strings to
organs, mallets and more—64 Tones in all.
----------------------------------------------------------------------------------------------------------------------------
Convenient Master Keyboard
Functions
----------------------------------------------------------------------------------------------------------------------------
Whether taking advantage of the onboard Split and Layer
functions to play the internal sounds, or controlling a rack of
MIDI modules, you’ll love using the RD-170 as your master
keyboard. With controller functions built-in, you can play
and control external MIDI modules simultaneously—all with
minimal fuss. The RD-170’s 16 programmable setup memories
make it easy to save and recall custom settings—great for
performance.
----------------------------------------------------------------------------------------------------------------------------
New Half-Damper Capabilities
----------------------------------------------------------------------------------------------------------------------------
With new half-pedal recognition, the RD-170 takes on all the
expressiveness of an acoustic grand piano. When used with
the supplied Damper Pedal, this technology allows the RD170 to sense pedal positions other than just “On” and “Off.”
The result is more natural sustained playing that captures the
true spirit of an acoustic piano.
----------------------------------------------------------------------------------------------------------------------------
Built-In Song Recorder and More
----------------------------------------------------------------------------------------------------------------------------
The RD-170’s onboard 2-track recorder makes capturing a
performance ultra-intuitive. Or if you don’t feel like playing,
simply listen to one of 16 outstanding demo songs. A built-in
metronome makes it easy for students to stay on beat while
practicing. Whether for home use or on stage, the RD-170
has the features you need most at a price you can afford.
The Perfect Stage Piano
for Beginner or Pro.
With its attractive looks, improved weighted hammer-action keyboard and 64 world-class piano
and instrument sounds, the new RD-170 Digital Piano is a worthy addition to Roland’s acclaimed
stage piano lineup. New half-pedal recognition and Master Keyboard functions make this lightweight
instrument perfect for professional players, while the RD-170’s affordable price keeps it within
reach of all musicians.
■Keyboard 88-key hammer-action (new) ■ Max polyphony 64 (Max.) ■ Tones 64
TONES, 16 Family. 4 tones for each family
■ Slider Controls Master Volume,
Brilliance, Volume Upper/Layer
■Display 7-seg (3-digit) LED ■Play mode Split, Dual,
Full
■Master Tuning (0.1 Hz Steps) 415.3Hz, 466.2 Hz ■Transpose (-6 / +5 Semitone
step)
■Effects Reverb 8 levels, Chorus 8 levels, Resonance 8 levels ■ Touch control
4 types of Touch Sensitivity ■Tuning 7 Temperament Scale ■Pedals Damper (Half
damper recognition), Soft/Sostenuto (selectable) - Expression (auto detected)
■Sequencer
tracks
2 tracks ■Sequencer note 5,000 notes ■ Metronome Beat: 0/4, 2/4, 3/4, 4/4,
5/4, 6/4, 3/8, 6/8, 9/8, 8 volume levels
■Setup (Perform.) Ye s ■ Master kbd. func. Yes
■Demo 16 ■ Connectors Pedal jack x2, Headphone Jack x 2 (Stereo), MIDI In/Out,
Output L/M-R
■Power supply AC mains ■ Dimensions (mm) TBD ■Weight 18.0 Kg
■Supplied accessories Owner’s Manual, Power cable, Music rest, Damper Pedal
* The specifications are subject to change without notice.
RD-170 Specifications
*Product pictured is a prototype model. Actual product appearance may be subject to change.
Page 3
F-100-BK
Digital Piano
■ 64-voice digital piano with stylish, contemporary
design and built-in speakers
■ 88-note Progressive Hammer-Action Keyboard
for realistic touch
■ Includes 20 of Roland’s finest piano and
instrument sounds
■ Superior sound quality via high-performance
speakers built into the stand
■ Transparent acrylic music stand and removable
keyboard cover
■ Fixed damper and soft pedals for more
expressive playing
■ Onboard reverb for true concert hall sound
■ 60 preset songs, Rhythm function, song recorder
and dual headphone jacks
■ Available in new black cabinet (F-100-BK)
or original simulated maple finish (F-100)
76
----------------------------------------------------------------------------------------------------------------------------
Two Eye-Catching Colors
----------------------------------------------------------------------------------------------------------------------------
With a choice of two cabinet finishes, there’s an F-100 Digital
Piano that’s right for you. The original F-100’s maple finish looks
great with contemporary interiors, while the new F-100-BK’s
traditional looks work well in a variety of settings. The choice
is yours…
----------------------------------------------------------------------------------------------------------------------------
Realistic Sounds and Keyboard Touch
----------------------------------------------------------------------------------------------------------------------------
Playing the F-100-BK is a truly exhilarating experience, thanks
to Roland’s next-generation stereo-sampled piano sounds.
Every nuance of an acoustic grand has been faithfully
captured—from the strongest forté to the most delicate
pianissimo. To complement these sounds, the F-100-BK features
an 88-note Progressive Hammer-Action Keyboard. Developed
through years of research, this exclusive
key mechanism uses real hammers with
a touch that’s heavier in the lower
range and lighter in the upper range.
----------------------------------------------------------------------------------------------------------------------------
A Variety of Instruments and
Practice Features
----------------------------------------------------------------------------------------------------------------------------
In addition to piano sounds, the F-100-BK features a range of
realistic-sounding instrument Tones ranging from electric piano
and strings to choir and bass—20 sounds total! Convenient
Split Preset and Layer functions let you play duos or layer
sounds. For practice, the F-100-BK features a built-in metronome
with 16 rhythm variations and an easy 2-track Song Recorder.
A stereo Line input lets you play along with CDs, while 60
preset piano pieces offer instant listening enjoyment.
The Popular F-100 In Black!
The F-100-BK Digital Piano is a new black cabinet version of the original F-100. While the color is new,
this compact and stylish piano still sounds and feels like a fine concert grand—thanks to an 88-note
Progressive Hammer-Action Keyboard, fixed pedals and a specially designed speaker system. The
F-100 also includes a matching keyboard cover and cool acrylic music rest, plus a built-in Song
Recorder, onboard rhythms and more.
[Keyboard] ■ Keyboard 88 keys (Progressive Hammer Action Keyboard) ■ Touch
Sensitivity
Light, Medium, Heavy, Fixed■ Keyboard Mode Whole, Dual (adjustable
volume balance)
[Sound Generator] ■Maximum Polyphony 64 voices ■ Tones
[F-100-BK]: 5 groups 20 variations, [F-90-BK]: 10 ■Effects Reverb (5 levels), Chorus
(fixed for E. Piano only), Sympathetic Resonance (fixed for Piano only)
■ Key
Transposition
-6 to +5 (in units of semitone) ■Master Tuning 415.3 Hz to 466.2 Hz
(adjustable in increments of 0.1 Hz)
[Metronome, Rhythm] ■Beat 0, 2, 3, 4, 6
■Rhythm (F-100-BK only) 16 patterns ■ Volume 5 levels [Recorder (F-100-BK
only)]
■Tracks 2 tracks ■Song 1 song ■ Note Storage Approx. 5,000 notes ■Tempo
Quarter note = 20 to 250 ■Resolution 96 ticks per quarter note ■ Control Play/Stop,
Rec, Tempo, All Song Play, Track Select
[Preset Songs] 60 songs [Others] ■Speakers
12 cm x 2 ■Rated Power Output 5 W x 2 ■ Pedals [F-100-BK]: Damper, Soft (fixed
dual pedal), [F-90-BK]: Damper (detachable single pedal)
■Connectors Headphones
Jack (Stereo miniature phone type) x 2, MIDI Connectors (In, Out), Output Jacks
(L/Mono, R), Input Jacks (L/Mono, R), Pedal Jacks (Damper, Soft)
■ Power Supply
DC 9 V (AC Adaptor) ■ Current Draw 2,000 mA ■ Dimensions (without the
music stand)
1,337 (W) x 295 (D) x 772 (H) mm, 52-11/16 (W) x 11-5/8 (D) x 30-7/16
(H) inches
■Weight [F-100-BK]: 39 kg / 86 lbs. [F-90-BK]: 36 kg / 79 lbs. 6 oz.
* The specifications are subject to change without notice.
F-100/90-BK Specifications
F-90-BK
Digital Piano
■
■
■
■
■
Affordable 88-note digital piano with premium features
and modern style
High-quality piano sounds and exclusive Progressive
Hammer-Action Keyboard
Onboard instrument sounds like electric piano,
organ and strings
Metronome function and dual headphone jacks for practice
Special dual-speaker system designed to compliment
cabinet acoustics
*Actual product appearance may be subject to change.
Space-Saving Cabinet Design.
The F-90-BK Digital Piano puts Roland’s Progressive HammerAction Keyboard, stereo-sampled piano sounds, onboard
speakers and more in a sleek, modern-looking cabinet
designed to occupy minimal space in your home.
Page 4
9
----------------------------------------------------------------------------------------------------------------------------
Tight, Punchy Sound
----------------------------------------------------------------------------------------------------------------------------
The Cube-30 Bass gives bass players loud and punchy bass
tones despite its compact size. Using a 30-watt amp and 10-inch
coaxial speaker system—with powerful low end and an individual
tweeter for clearer highs—this compact amp will knock your
socks off! Onboard compression and 3-band EQ let you shape
the tone any way you want.
----------------------------------------------------------------------------------------------------------------------------
COSM Bass Amp Modeling
----------------------------------------------------------------------------------------------------------------------------
Thanks to Roland’s COSM technology, the Cube-30 Bass can
convincingly model six of your favorite bass amps—like
“Bass360,” “Concert 810,” “Flip Top,” “B Man” and more.
There’s even an “Octave Bass” setting which adds a tone one
octave below the original note for truly earth-shaking sound.
Cube-30 Bass
----------------------------------------------------------------------------------------------------------------------------
Onboard DSP Effects
----------------------------------------------------------------------------------------------------------------------------
With onboard DSP effects, you can plug in your bass without
complicated setups. The Cube-30 Bass includes everything
you need: pro-quality reverb and delay, plus essentials like
chorus and flanger. There’s even a T-Wah effect for adding a
sweeping filtered sound to your tone—great for funk bass.
----------------------------------------------------------------------------------------------------------------------------
A Marvel of Convenience
----------------------------------------------------------------------------------------------------------------------------
Whether practicing at home or tracking in the studio, the
Cube-30 Bass can get the job done. With a 1/4-inch
Recording/Headphones output, you can connect directly to a
mixing console or to a pair of headphones. A dedicated
Shape switch makes it easy to instantly change your tone.
Nothing else compares to the Cube-30 Bass!
A Compact Bass Amp with COSM Modeling
and More!
When it comes to compact bass amplifiers, the Roland Cube-30 Bass is in a class all its own. This
powerful and lightweight amp combines a 30-watt/10-inch 2-way speaker with DSP modeling to
crank out a range of popular bass amp sounds. There’s also onboard compression, 3-band EQ and
digital effects—making the Cube-30 Bass an incredible value.
■Rated Power Output 30W ■Nominal Input Level (1 kHz) INPUT: -20dBu/1MΩ,
AUX IN: -10dBu
■ Speaker 10" (25cm) + Tweeter (Coaxial type) ■ Controls
COMPRESSION knob, SHAPE button, COSM AMP TYPE knob (OCTAVE BASS, FLIP
TOP, B MAN, T.E, BASS360, SESSION, CONCERT810), GAIN knob, VOLUME knob, BASS
knob (EQUALIZER), MIDDLE knob (EQUALIZER), TREBLE knob (EQUALIZER), EFX
(CHORUS, FLANGER, T-WAH) knob, DELAY/REVERB, POWER switch
■ Indicators
COMPRESSION, EFX, POWER ■Connectors INPUT jack (1/4" phone type), AUX IN
jack (stereo 1/4" phone type), RECORDING OUT/HEADPHONE jack (stereo 1/4" phone
type), FOOT SW jack (EFX on/off, DELAY/REVERB on/off) (stereo 1/4" phone type)
■Power Supply AC117V, 230V or 240V■ Power Consumption 34W ■Dimensions
385 (W) x 300 (D) x 380 (H) mm, 15-13/16 (W) x 11-13/16 (D) x 15 (H) inches ■Weights
13 kg/28 lbs 11 oz ■Accessories Owner's Manual ■Options Footswitch FS-5U (BOSS),
Connection cable PCS-31
* 0 dBu = 0.775V rms
* The specifications are subject to change without notice.
Cube-30 Bass Specifications
These Guitar Amps Can Pack a Punch!
■ Compact guitar amps in 30-watt/10” speaker (Cube-30)
or 15-watt/8” speaker (Cube-15) design
■ 2-channel configuration with incredible overdrive
and distortion sounds
■ 3-band EQ for precise tone shaping
■ Recording/Headphone output for silent recording and practice
■ Auxiliary input for connecting audio sources like CD players
or drum machines
8
*Product pictured is a prototype model. Actual product appearance may be subject to change.
■ Compact bass amplifier with 30-watt/10” coaxial
2-way speaker design
■ 6 types of COSM
®
bass amp models including
octave bass sound
■ Convenient Shape switch for easy tonal variation
■ 5 high-quality DSP effects: reverb, delay, chorus,
flanger and T-Wah
■ Onboard 3-band EQ and compression with
simple knob-based controls
■ Recording/Head phones output; Auxiliary and
Footswitch inputs
Page 5
BR-864
8-Track Digital Studio
■ Compact 8-track digital recording studio
with intuitive BOSS-style operation
■ Uses 128MB Compact Flash media (included)
for over 60 minutes of recording time
■ 8-track simultaneous playback; 64 Virtual Tracks
(V-Tracks) for recording
■ Insert/Loop effects with COSM Guitar Amp
Modeling and Bass Simulator, plus new wah
effects, guitar synth and Harmonist
■ Programmable Rhythm Guide drum track
with Tone Load function
■ New dedicated track EQ for all 8 playback tracks
■ Instrument/Hi-Z Instrument input, XLR and 1/4”
Microphone inputs, plus stereo RCA Line input
■ USB port for .WAV/AIFF file exchange with PCs;
S/PDIF digital output
■ Built-in microphone and battery power
for recording any time, any place
1110
----------------------------------------------------------------------------------------------------------------------------
Affordable and Portable
----------------------------------------------------------------------------------------------------------------------------
The BR-864 is not only BOSS’ smallest 8-track recorder, but it’s
also our most affordable. With 64 Virtual Tracks, there’s plenty
of room to track multiple overdubs, vocals and instruments.
A 128MB Compact Flash card comes standard, giving you
over an hour’s worth of high-quality recording time.
----------------------------------------------------------------------------------------------------------------------------
Easy USB File Exchange
and Data Backup
----------------------------------------------------------------------------------------------------------------------------
A built-in USB port makes it easy to import and export audio
with USB-equipped computers. Now you can load and convert
.WAV/AIFF files from your Mac or PC directly into a track, or
export your song for CD-burning and MP3 creation. The USB port
also makes for a great way to archive and back up recordings
to your computer’s hard drive.
----------------------------------------------------------------------------------------------------------------------------
A World of High-Quality Effects
----------------------------------------------------------------------------------------------------------------------------
Thanks to COSM modeling, guitarists can plug right into the
BR-864 and get killer tone every time. Simply choose from
several COSM Amp Models and you’ll sound huge. There’s even
a Bass Simulator that lets you lay down bass from a guitar—
plus several new effects like wah, guitar synth and a Harmonist
for scale-intelligent pitch shifting.
----------------------------------------------------------------------------------------------------------------------------
Rhythm Guide Redux
----------------------------------------------------------------------------------------------------------------------------
The Rhythm Guide function has been beefed up considerably
for the BR-864. First, BOSS added full programmability,
meaning you can tap in your own drum patterns in addition
to the dozens of great-sounding presets. A new Tone Load
function lets you add custom drum sounds by importing
.WAV/AIFF files. Best of all, the Rhythm Guide doesn’t use
any of the 64 recording tracks, so you still get eight playback
tracks and drums.
----------------------------------------------------------------------------------------------------------------------------
Guitar-Friendly Features
----------------------------------------------------------------------------------------------------------------------------
While anyone can benefit from the BR-864’s portability and
power, guitarists in particular will appreciate having a dedicated
Hi-Z input and onboard tuner. There’s also a Phrase Trainer
function that lets you slow down riffs, making them easier to
learn. And since the BR-864 runs on batteries, you can take
this little 8-track studio anywhere.
8-Track Digital Recording to Go.
The BOSS BR-864 puts 8-track digital recording in the palm of your hand. Never has so much power
been available in such a small package. With features like 64 Virtual Tracks, onboard COSM
®
effects,
Compact Flash media for recording and a built-in USB port, the BR-864 has everything guitarists
and songwriters need to turn ideas into songs.
■ Tracks Track: 8, V-Track: 64 (8 V-Tracks per each Track) * Up to 2 tracks can be
recorded simultaneously, and up to 8 tracks can be played back simultaneously.
■ Useful Capacity CompactFlash: 32MB to 1 GB ■ Data Type HiFi (MT2). STAN-
DARD (LV1), LONG (LV2)
■Sample Rate 44.1 kHz ■ Frequency Response 20 Hz
to 20 kHz (+1/-3 dBu)
jack: -44 dBu, LINE jack: -16 dBu
■ Input Impedance GUITAR/BASS jack: 1 M Ω,
MIC (Phone/XLR) jack: 8.9 k Ω (HOT-COLD), 8.2 k Ω (HOT-GND, COLD-GND). LINE
jack: 15 k Ω
■ Nominal Output Level LINE OUT jack: -10 dBu ■ Output
Impedance
LINE OUT jack: 2 k Ω, Headphonejack: 147 Ω ■ Recommended Load
Impedance
LINE OUT jack: 20 k Ω or greater, Headphonejack: 8 to 50 Ω ■Residual
Noise Level
LINE OUT jack: -85 dBu or less (INPUT SELECT: GUITAR/BASS, input
terminated with 1 k Ω, INPUT SENS: CENTER, IHF-A, typ. EFFECT: off)
■ Interface
USB Connector, DIGITAL OUT (Optical type) ■Connectors GUITAR/BASS jack (1/4
inch phone type), MIC jacks (TRS Balanced 1/4 inch phone type/XLR type), LINE IN
jack L/R (RCA Phono type), LINE OUT jack L/R (RCA Phono type), DIGITAL OUT
Connector (Optical type), FOOT SW/ EXP Pedal jack (stereo 1/4 inch phone type),
MIDI OUT Connector, Headphone Jack (Stereo 1/4 inch phone type)
■ Power
Supply
DC 9 V; Supply AC Adaptor (PSA series), Dry batteries x 6 ■Current Draw
200 mA * Expected battery life under continuous use: Alkaline: 5 hours, These figures
will vary depending on the actual conditions of use.
■Dimensions 322 (W) x 225
(D) x 69 (H) mm, 12-11/16 (W) x 8-7/8 (D) x 2-11/16 (H) inches
■Weight 1.65 kg/3
lbs. 10oz. (excluding batteries)
* 0 dBu = 0.775V rms
* The specifications are subject to change without notice.
BR-864 Specifications
■Recording Time (1 track)
* The above-listed recording times are approximate. Times may be slightly shorter depending on the
number of songs that were created.
* The above number is the total for all the tracks that are used. If each of the eight tracks contain
an equal amount of data, the length of the resulting song will be approximately 1/8 of the above.
32 MB 64 MB 128 MB 256 MB 512 MB 1 GB
HiFi (MT-2) 16 min 32min 65 min 130 min 260 min 520 min
Standard (LV1) 19 min 39 min 78 min 156 min 312 min 624 min
Long (LV2) 24 min 49 min 98 min 196 min 392 min 784 min
*Product pictured is a prototype model. Actual product appearance may be subject to change.
■Nominal Input Level (Variable) GUITAR/BASS jack: -24 dBu, MIC (Phone/XLR)
Page 6
Printed in Japan Mar. 2003 RAM-3674 PBL-ISI-SE C-4
Visit us online at www.Roland.com
www.BOSScorp.co.jp
All specifications and appearances are subject to change.
All trademarks used in this catalog are the property of their respective companies.
INDEX
-------------------------------------------------------------------------------------------------------------------------products pages
--------------------------------------------------------------------------------------------------------------------------
BR-864 8-Track Digital Studio ---------------------------- 10-11
Cube-30 Bass Bass Amplifier --------------------------------- 8-9
F-100-BK Digital Piano ----------------------------------------- 6-7
RD-170 Digital Piano ------------------------------------------- 4-5
RS-70/-50 Synthesizers ----------------------------------------- 2-3
NEW PRODUCT CATALOG
2003 VOL. 2
