R&S
NGE100
Power Supply
Getting Started
(Æ1=82)
5601.1308.02 ─ 05
Getting Started
Test & Measurement
This manual describes the following R&S®NGE100 models and options:
●
R&S®NGE102 2-Channel PSU (5601.1414.02)
●
R&S®NGE103 3-Channel PSU (5601.1414.03)
●
R&S®NGE-K101 Ethernet Remote Control (5601.2204.03)
●
R&S®NGE-K102 Wireless LAN Remote Control (5601.2210.03)
●
R&S®NGE-K103 Digital Trigger I/O (5601.2227.03)
The contents of this manual correspond to firmware version 1.00 or higher.
The software contained in this product uses several valuable open source software packages. For information, see the "Open Source Acknowledgment" document, which is available for download from the R&S
NGE100 product page at www.rohde-schwarz.com/product/nge100 > "Downloads" > "Firmware".
Rohde & Schwarz would like to thank the open source community for their valuable contribution to embedded computing.
© 2017 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: +49 89 41 29 - 0
Fax: +49 89 41 29 12 164
Email: info@rohde-schwarz.com
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of their owners.
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g.
R&S®NGE100 is indicated as R&S NGE100.
1
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent electric shock, fire,
personal injury or instrument damage.
● Do not open the instrument casing.
● Read and observe the "Basic Safety Instructions" delivered as printed brochure with
the instrument.
● Read and observe the safety instructions in the following sections.
Note that the data sheet may specify additional operating conditions.
● Keep the "Basic Safety Instructions" and the product documentation in a safe place
and pass them on to the subsequent users.
Riesgo de lesiones y daños en el instrumento
El instrumento se debe usar de manera adecuada para prevenir descargas eléctricas,
incendios, lesiones o daños materiales.
● No abrir la carcasa del instrumento.
● Lea y cumpla las "Instrucciones de seguridad elementales" suministradas con el
instrumento como folleto impreso.
● Lea y cumpla las instrucciones de seguridad incluidas en las siguientes secciones.
Se debe tener en cuenta que las especificaciones técnicas pueden contener
condiciones adicionales para su uso.
● Guarde bien las instrucciones de seguridad elementales, así como la
documentación del producto, y entréguelas a usuarios posteriores.
Safety Instructions
Instrucciones de seguridad
Sicherheitshinweise
Consignes de sécurité
1171.1307.52 - 05
2
Gefahr von Verletzungen und Schäden am Gerät
Betreiben Sie das Gerät immer ordnungsgemäß, um elektrischen Schlag, Brand,
Verletzungen von Personen oder Geräteschäden zu verhindern.
● Öffnen Sie das Gerätegehäuse nicht.
● Lesen und beachten Sie die "Grundlegenden Sicherheitshinweise", die als
gedruckte Broschüre dem Gerät beiliegen.
● Lesen und beachten Sie die Sicherheitshinweise in den folgenden Abschnitten;
möglicherweise enthält das Datenblatt weitere Hinweise zu speziellen
Betriebsbedingungen.
● Bewahren Sie die "Grundlegenden Sicherheitshinweise" und die
Produktdokumentation gut auf und geben Sie diese an weitere Benutzer des
Produkts weiter.
Risque de blessures et d'endommagement de l'appareil
L'appareil doit être utilisé conformément aux prescriptions afin d'éviter les
électrocutions, incendies, dommages corporels et matériels.
● N'ouvrez pas le boîtier de l'appareil.
● Lisez et respectez les "consignes de sécurité fondamentales" fournies avec
l’appareil sous forme de brochure imprimée.
● Lisez et respectez les instructions de sécurité dans les sections suivantes. Il ne faut
pas oublier que la fiche technique peut indiquer des conditions d’exploitation
supplémentaires.
● Gardez les consignes de sécurité fondamentales et la documentation produit dans
un lieu sûr et transmettez ces documents aux autres utilisateurs.
1171.1307.52 - 05
Customer Support
Technical support – where and when you need it
For quick, expert help with any Rohde & Schwarz equipment, contact one of our Customer
Support Centers. A team of highly qualified engineers provides telephone support and will
work with you to find a solution to your query on any aspect of the operation, programming
or applications of Rohde & Schwarz equipment.
Up-to-date information and upgrades
To keep your instrument up-to-date and to be informed about new application notes related
to your instrument, please send an e-mail to the Customer Support Center stating your
instrument and your wish.
We will take care that you will get the right information.
Europe, Africa, Middle East
North America
Latin America
Asia/Pacific
China
Phone +49 89 4129 12345
customersupport@rohde-schwarz.com
Phone 1-888-TEST-RSA (1-888-837-8772)
customer.support@rsa.rohde-schwarz.com
Phone +1-410-910-7988
customersupport.la@rohde-schwarz.com
Phone +65 65 13 04 88
customersupport.asia@rohde-schwarz.com
Phone +86-800-810-8228 /
+86-400-650-5896
customersupport.china@rohde-schwarz.com
1171.0500.22-06.00
R&S®NGE100
Contents
Contents
1 Preface....................................................................................5
1.1 Documentation Overview.....................................................................5
1.2 Conventions Used in the Documentation...........................................6
1.2.1 Typographical Conventions.................................................................... 6
2 Welcome to R&S NGE100..................................................... 7
3 Putting into Operation...........................................................8
3.1 Safety..................................................................................................... 9
3.2 Intended Operation............................................................................. 10
3.3 Unpacking and Checking the Instrument......................................... 12
3.4 Setting Up the Instrument.................................................................. 13
3.4.1 Bench Operation................................................................................... 13
3.4.2 Rack Mounting...................................................................................... 14
4 Instrument Tour................................................................... 15
4.1 Overview of Controls..........................................................................15
4.1.1 Front Panel........................................................................................... 15
4.1.2 Rear Panel............................................................................................ 17
4.2 Switching On the Instrument............................................................. 18
5 Trying Out the Instrument...................................................20
5.1 Selecting the Channels...................................................................... 20
5.2 Setting the Output Voltage and Current Limit..................................20
5.3 Activating the Channels Output........................................................ 21
3Getting Started 5601.1308.02 ─ 05
R&S®NGE100
5.4 Storing / Recalling of Instrument Settings....................................... 21
Contents
6 Maintenance......................................................................... 22
Index..................................................................................... 23
4Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Preface
Documentation Overview
1 Preface
1.1 Documentation Overview
This section provides an overview of the R&S NGE100 user documentation. You
find it on the product page at:
http://www.rohde-schwarz.com/product/nge100 > "Downloads"
Getting started manual
Introduces the R&S NGE100 and describes how to set up and start working with
the product. A printed version is included in the delivery.
User manual
The user manual contains the description of all instrument modes and functions.
It also provides an introduction to remote control, a complete description of the
remote control commands with programming examples, and information on maintenance, instrument interfaces and error messages.
Basic safety instructions
Contains safety instructions, operating conditions and further important information. The printed document is included in the delivery.
Brochure
The brochure provides an overview of the R&S NGE100 and shows its specific
characteristics. The technical specifications of the R&S NGE100 are included in
the brochure. It also lists the options and their order numbers as well as optional
accessories.
Release notes and open source acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current firmware version, and describe the firmware installation.
The open source acknowledgment document provides verbatim license texts of
the used open source software.
See http://www.rohde-schwarz.com/product/nge100 > "Downloads" > "Firmware".
5Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Preface
Conventions Used in the Documentation
Application notes, application cards, white papers, etc.
These documents contain information about possible applications and background information on various topics, see www.rohde-schwarz.com/appnotes.
1.2 Conventions Used in the Documentation
The following conventions are used throughout the R&S NGE100 manual.
1.2.1 Typographical Conventions
Convention Description
Keys Name of key is bolded.
Links Links are displayed as underlined.
"References" References to other parts of the documenta-
tion are enclosed by quotation marks.
6Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Welcome to R&S NGE100
2 Welcome to R&S NGE100
The two or three-channel power supply series are based on a classical transformer concept with high efficiency electronic pre-regulators and secondary linear
regulators. This concept allows the instrument to achieve the high output power
within a minimum space, high efficiency and lowest residual ripple.
The R&S NGE100 power supply series feature galvanically isolated, floating overload and short-circuit proof outputs with adjustable power ratings. The outputs
can be connected in series or in parallel, thus making high currents and voltages
available.
Multi-purpose protection functions are available for each channel which you can
set separately, such as overcurrent protection (FUSE), overvoltage protection
(OVP), overpower protection (OPP) and overtemperature protection (OTP). If
such a limit is reached, the affected output channel is automatically turned off and
an indicator message (FUSE, OVP, OPP or OTP) is displayed. The overcurrent
protection can be linked to other channel (FuseLink function). In this case, all
linked channels are turned off when the set channel reaches its limit.
The EasyArb function allows channel 1 (Ch 1) to have a freely definable voltage
and current sequences with a timeframe as short as 10 ms. It allows you to vary
the voltage or current limit during a test sequence, for example to simulate different charging conditions of a battery. With EasyRamp function, the R&S NGE100
provides the operating condition to simulate the continuous rise of the supply voltage within a defined timeframe of 10 ms to 10 s.
Four data lines of the digital I/O interface are mutually independent and can be
used as trigger input or trigger output separately. Various trigger conditions (e.g.
fuse tripped, voltage, current, indicator messages) can be used to turn off, on or
invert the output state when the trigger condition is met.
All R&S NGE100 power supply series are equipped with a color LCD display (320
x 240 pixels). The R&S NGE100 comes with a USB interface and optional LAN
(LXI) and wireless LAN (WLAN) interface.
For models with WLAN, network connection can also be established wirelessly.
This user manual contains a description of the functionalities that the instrument
provides. The latest version is available for download at the product homepage
(http://www.rohde-schwarz.com/product/nge100).
7Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Putting into Operation
3 Putting into Operation
This chapter describes the steps to set up the R&S NGE100 for the first time.
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent electric
shock, fire, personal injury, or damage.
●
Do not open the instrument casing
●
Read and observe the "Basic Safety Instructions" delivered as a printed
brochure with the instrument. Note that the basic safety instructions also
contain information on operating conditions that prevent damage to the
instrument
In addition, read and observe the safety instructions in the following sections. Notice that the data sheet may specify additional operating conditions.
Risk of instrument damage during operation
An unsuitable operating site or test setup can cause damage to the instrument and the connected devices. Ensure the following operating conditions
before you switch on the instrument:
●
The instrument is dry and shows no sign of condensation
●
The instrument is positioned as described in Chapter 3.4.1, "Bench
Operation", on page 13
●
The ambient temperature does not exceed the range specified in the
data sheet
●
Signal levels at the input connectors are all within the specified ranges
●
Signal outputs are correctly connected and not overloaded
8Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Putting into Operation
Safety
EMI impact on measurement results
Electromagnetic interference (EMI) may affect the measurement results.
To suppress the generated EMI:
●
Use suitable shielded cables of high quality, for example, LAN cables
●
Note the EMC classification in the data sheet
● Safety................................................................................................................9
● Intended Operation......................................................................................... 10
● Unpacking and Checking the Instrument........................................................ 12
● Setting Up the Instrument............................................................................... 13
3.1 Safety
This instrument was built in compliance with DIN EN 61010-1 (VDE 0411 part 1),
safety regulations for electrical instruments, control units and Iaboratory equipment. It has been tested and shipped from the plant in safe condition. It is also in
compliance with the regulations of the European standard EN 61010-1 and the
international standard IEC 61010-1.
To maintain this condition and ensure safe operation, you must observe all
instructions and warnings given in this user manual. Casing, chassis and all measuring ports are connected to a protective earth conductor. The instrument is
designed in compliance with the regulations of protection class I.
For safety reasons, the instrument may only be operated with authorized safety
sockets. The power cord must be plugged in before signal circuits may be connected.
Never use the product if the power cable is damaged. Check regularly that the
power cables are in perfect condition. Choose suitable protective measures and
installation types to ensure that the power cord cannot be damaged and that no
harm is caused by tripping hazards or from electric shock, for instance.
9Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Putting into Operation
Intended Operation
Risk of electric shock
It is prohibited to disconnect the earthed protective connection inside or outside of the instrument!
If it is assumed that a safe operation is no longer possible, the instrument must be
shut down and secured against any unintended operation.
Safe operation can no longer be assumed as follows:
●
Instrument shows visible damage
●
Instrument includes loose parts
●
Instrument no longer functions properly
– After an extended period of storage under unfavorable conditions (e.g. out-
doors or in damp rooms)
– After rough handling during transport (e.g. packaging that does not meet
the minimum requirements by post office, railway or forwarding agency)
Exceeding the Low Voltage Protection
Use insulated wires and not bare wires for the terminal connection.
For the series connection of all output voltages, it is possible to exceed the
low voltage protection of 42 V. Please note that in this case any contact
with live components is life-threatening. It is assumed that only qualified
and trained personnel service the power supplies and the connected loads.
Prior to switching on the product, it must be ensured that the nominal voltage setting on the product matches the nominal voltage of the AC supply network. If it is
necessary to set a different voltage, the power fuse of the product must be
changed accordingly.
3.2 Intended Operation
The instrument is intended only for use by personnel familiar with the potential
risks of measuring electrical quantities.
10Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Putting into Operation
Intended Operation
For safety reasons, the instrument may only be connected to properly installed
safety socket outlets. Separating the ground is prohibited.
The power plug must be inserted before signal circuits may be connected.
Use only the power cord included in the delivery package. See "Delivery
package" on page 13.
Before each measurement, measuring cables must be inspected for damage and replaced if necessary. Damaged or worn components can damage
the instrument or cause injury.
The product may be operated only under the operating conditions and in the positions specified by the manufacturer, without the product's ventilation being
obstructed. If the manufacturer’s specifications are not observed, this can result in
electric shock, fire and/or serious personal injury, and in some cases, death.
Applicable local or national safety regulations and rules for the prevention of accidents must be observed in all work performed.
The instrument is designed for use in the following sectors: Industrial, residential,
business and commercial areas and small businesses.
The instrument is designed for indoor use only. Before each measurement, you
need to verify at a known source if the instrument functions properly.
To disconnect from the mains, the low-heat device socket on the back
panel has to be unplugged.
See Table 3-1 for the general data on the instrument specification. For more information, see the instrument product brochure (PN: 5214.8748.12).
Table 3-1: General data on instrument specification
General data
Mains nominal voltage AC 115 / 230 V (±10 %) 50 / 60
Hz
Power consumption Maximum input power 180 W
Mains fuses 115 V AC IEC 60127-2 / 5 T 5 A 250 V
Temperature Operating temperature range 0 °C to + 40 °C
230 V AC IEC 60127-2 / 5 T 2.5 A 250 V
11Getting Started 5601.1308.02 ─ 05
R&S®NGE100
General data
Putting into Operation
Unpacking and Checking the Instrument
Humidity Non-condensing 5 % to 80 %
Display
Rack mount capability ½ 19 " R&S HZC95 option
Dimensions W x H x D 222 mm x 88 mm x 280 mm
Weight R&S NGE102 4.4 kg (9.70 lb)
3.3 Unpacking and Checking the Instrument
Storage temperature range - 20 °C to + 70 °C
R&S NGE103 4.5 kg (9.92 lb)
3.5" (QVGA)
(8.74 in x 3.46 in x 11.02 in)
Check the equipment for completeness using the delivery note and package contents list for the various items. Check the instrument for any damage and loose
parts. If there is any damage, immediately contact the carrier who delivered the
instrument.
Packing material
Retain the original packing material. If the instrument needs to be transported or shipped at a later date, you can use the material to protect the control
elements and connectors.
12Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Putting into Operation
Setting Up the Instrument
Risk of damage during transportation and shipment
Insufficient protection against mechanical and electrostatic effects during
transportation and shipment can damage the instrument.
●
Always ensure that sufficient mechanical and electrostatic protection are
provided
●
When shipping an instrument, the original packaging should be used. If
you do not have the original packaging, use sufficient padding to prevent the instrument from moving around inside the box. Pack the instrument in antistatic wrap to protect it from electrostatic charging
●
Secure the instrument to prevent any movement and other mechanical
effects during transportation
Delivery package
The package contents contain the following items:
●
R&S NGE100 power supply preloaded with two 230 V fuses
●
Four power cables
●
Two 115 V fuses (replace the preloaded fuses with these fuses depending on
the mains voltage, see Chapter 4.2, "Switching On the Instrument",
on page 18 for more information)
●
One Getting Started manual
●
One document folder containing safety instructions and calibration certificate
3.4 Setting Up the Instrument
The R&S NGE100 is designed for benchtop and rackmount.
3.4.1 Bench Operation
On a benchtop, the R&S NGE100 can either lie flat or stand on its feet. As shown
in Figure 3-1, feet on the bottom can be folded out to set the instrument in an
inclined position.
13Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Figure 3-1: Operating positions
Positioning of instrument
The instrument must be positioned in a manner that allows the user to disconnect the unit from the mains at any time and without restrictions.
Putting into Operation
Setting Up the Instrument
3.4.2 Rack Mounting
The instrument can be installed in a 19" rack-mount using a rack adapter kit.
Ambient temperature
Place the R&S NGE100 in an area where the ambient temperature is within
+0 °C to +40 °C. The R&S NGE100 is fan-cooled and must be installed with
sufficient space on the top to ensure a free flow of air. Required minimum
distance: 1 rack unit (RU).
Figure 3-2: Rack mounting
14Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Instrument Tour
Overview of Controls
4 Instrument Tour
This chapter provides an overview of all the controls available in the R&S
NGE100 models and steps to switch on the instrument for the first time.
● Overview of Controls.......................................................................................15
● Switching On the Instrument...........................................................................18
4.1 Overview of Controls
4.1.1 Front Panel
The front panel of the R&S NGE100 is as shown in Figure 4-1. The function keys
and navigation controls are located beside the display. The various connectors
are located below the display and function keys.
Figure 4-1: Front panel of R&S NGE100
1 = Display
2 = Function keys
3 = Rotary knob and arrow keys
15Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Instrument Tour
Overview of Controls
4 = Output channels (three for NGE103 and two for NGE102)
5 = USB connector
6 = Power key
Display
The display is a color LCD screen. Depending on the instrument type, up to three
channels are shown on the screen. The respective measurement settings and
functions are displayed in the individual channel section. There is a status bar
above the channels to show whether a certain function is enabled, disabled or
operating in a certain mode.
For a detailed description on-screen layout, see section "Screen Layout" in the
User Manual.
Function keys
Function keys are means of input for manual operation of the instrument functions. When a function key is pressed, all the related keys are also illuminated.
For detailed description on function keys, see section "Function Keys" in the User
Manual.
Rotary knob and arrow keys
Rotary knob and arrow keys are means of navigation and adjustment. When
pressed or rotated, they perform tasks like navigation around the screen, adjustment of parameter values or confirmation of entries.
For detailed description on rotary knob and arrow keys, see section "Navigation
Controls" in the User Manual.
Output channels
Depending on the instrument type, up to three output channels are available for
output of power to the connected load. They are Ch 1, Ch 3 and Ch 3 (0 V to 32
V / 0 A to 3 A).
USB connector
The USB connector is a Type-A connector. You can connect a USB flash drive to
this connector to perform a firmware update. See section "Firmware Update" in
the release notes for the update procedure.
For screenshot and firmware update, USB flash drive file system supports FAT32
only.
16Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Power key
The Power key switches the instrument on and off.
Instrument Tour
Overview of Controls
4.1.2 Rear Panel
Figure 4-2 shows the rear panel of the R&S NGE100 with its connectors.
Figure 4-2: Rear panel of R&S NGE100
7 = AC inlet with fuse holder
8 = Voltage selector
9 = Ethernet (LAN) connector
10 = USB connector
11 = Digital I/O connector
AC inlet with fuse holder
Main supply cord
Do not use detachable mains supply cord with inadequate rating.
For safety reasons, the instrument can only be operated with authorized safety
sockets.
17Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Instrument Tour
Switching On the Instrument
The power cable must be plugged in before signal circuits can be connected.
Never use the product if the power cable is damaged. See Chapter 4.2, "Switch-
ing On the Instrument", on page 18 for more information.
Voltage selector
The voltage selector selects the mains voltage between 115 V and 230 V.
Ethernet connector
This connector is used for establishing remote control via SCPI or LXI. See section "Ethernet Setup" in the user manual for more information on the connection
setup.
The Ethernet option NGE-K101 must be installed for this function to be available
in the instrument.
USB connector
The USB connector is a Type-B connector for remote control operation.
Digital I/O connector
The Digital I/O connector is a terminal block for external trigger input or output.
Measurement control can be achieved by means of an external input signal or
using an external output signal to trigger other instruments for some measurements.
The Digital Trigger I/O option (NGE-K103) must be installed for this function to be
available in the instrument.
4.2 Switching On the Instrument
Prior to switching on the instrument, check if the value on the voltage selector
corresponds to the mains voltage (115 V or 230 V). Switch it, if necessary, and
change the power fuse of the instrument accordingly.
To change the power fuse:
1. Peel off the yellow label sticker on the AC inlet.
2. Pull out the fuse holder which is located directly on top of the socket.
18Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Switching On the Instrument
3. Remove the preloaded fuses from the fuse holder.
4. Check the caps of both fuses that you want to change to for their ratings.
There should be written either T5A250V for 115 V or T2.5A250V for 230 V.
The fuse size is 5 x 20 mm.
5. Once verified, insert the fuses into each groove of the fuse holder.
6. Return the fuse holder to its position in the panel.
To switch on the instrument:
1. Connect the power cable to the AC inlet and switch on the mains power.
2. Press Power key on the front panel.
The instrument performs a system check, boots the operating system, and
starts the R&S NGE100 firmware.
By default, all output channels are off when the instrument is switched on to
prevent connected loads from being damaged unintentionally.
Instrument settings from memory location M1 and auto saved parameters are
loaded during the instrument startup.
For more information on the store/recall instrument settings, see the "Store
and Recall" chapter in the user manual.
Instrument Tour
To switch off the instrument, press Power key again.
19Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Trying Out the Instrument
Setting the Output Voltage and Current Limit
5 Trying Out the Instrument
This chapter describes some basic functions that you can perform with the R&S
NGE100.
5.1 Selecting the Channels
To select a channel, press the corresponding channel key. The key illuminates.
5.2 Setting the Output Voltage and Current Limit
To set the output voltage and current limit via Live-Mode:
1. Long press the rotary knob to enter into the setting mode. The font color of
channel 1 voltage setting changes to blue.
2. Move to the desired parameter via the arrow keys.
3. On the desired parameter, rotate the knob to adjust its value.
Alternatively:
1. Press Voltage or Current key on the front panel.
2. Press the desired channel key to activate the respective voltage or current
limit setting for that channel. The value on the respective channel becomes
editable (in blue) and the digit for adjustment is indicated by a cursor.
3. Press the right or left arrow key to move the cursor.
4. Press the up / down arrow key or turn the rotary knob to change the value of
the digit indicated by the cursor. The new value registers immediately.
20Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Trying Out the Instrument
Storing / Recalling of Instrument Settings
5.3 Activating the Channels Output
The output voltages can be switched on or off irregardless of the operating mode
the instrument is in.
To activate the channel output, press Output key on the front panel followed by
the desired channel key or vice versa. The font color of that channel section
changes to green or red depending on the operating mode the instrument is in.
5.4 Storing / Recalling of Instrument Settings
The instrument settings can be stored in the instrument memory by long pressing
Store Recall key and selecting the memory location (M1 to M5) key. The previous setting is overwritten.
To retrieve the desired saved settings, press Store Recall key and select the
memory location (M1 to M5) key.
21Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Maintenance
6 Maintenance
Before cleaning the instrument, ensure that it has been switched off and power
cable is disconnected.
Clean the outer case of the instrument at regular intervals, using a soft, lint-free
dust cloth.
Instrument damage caused by cleaning agents
Cleaning agents contain substances that may damage the instrument. For
example, cleaning agents that contain a solvent may damage the front
panel labeling, plastic parts, or the display.
Never use cleaning agents such as solvents (thinners, acetone, etc.), acids,
bases, or other substances.
The display may only be cleaned with an appropriate glass cleaner. Rub the display down with a dry, clean and lint-free cloth. Do not allow cleaning fluid to enter
the instrument.
22Getting Started 5601.1308.02 ─ 05
R&S®NGE100
Index
Index
A
Application cards ....................................... 6
Application notes ....................................... 6
B
Brochure ....................................................5
C
Controls ................................................... 15
Conventions .............................................. 6
D
Data Sheet ................................................ 5
F
Front Panel
Display ................................................ 15
Function keys ......................................15
Output channels ..................................15
Power key ........................................... 15
Rotary knob and arrow keys ............... 15
USB connector ....................................15
Setting Up the Instrument
Bench Operation .................................13
Rack Mounting ....................................13
Switching On the Instrument ................... 18
T
Trying Out the Instrument
Activating the Channels Output .......... 20
Selecting the Channels .......................20
Setting the Output Voltage and Current
Limit .................................................... 20
Storing / Recalling of Instrument Settings
............................................................ 20
U
Unpacking and checking the instrument . 12
User Manual .............................................. 5
W
White papers ............................................. 6
G
Getting Started .......................................... 5
M
Maintenance ............................................22
O
Open Source Acknowledgment .................5
P
Package contents ....................................12
R
Rear Panel
AC inlet with fuse holder ..................... 17
Digital I/O connector ........................... 17
Ethernet connector ............................. 17
USB connector ....................................17
Voltage selector .................................. 17
Release notes ........................................... 5
S
Safety instructions ..................................... 5
23Getting Started 5601.1308.02 ─ 05
Loading...
