Rode M1 User Manual

M1

Instruction Manual

www.rodemic.com

(

)

EMC, LVD

Specifi cations

Acoustic Principle: Dynamic

Polar Pattern: Cardioid (see graph below)

Frequency Range: 75Hz ~ 18,000Hz (see graph below)

Output Impedence: 320Ω

Sensitivity: -56dB ± 2 dB re 1V/Pa

Output Connection: 3-pin XLR balanced output between

Net Weight: 360g (0.79lb)

Packed Weight: 700g (1.54lb)

Dimensions: Length: 171mm (6.73”)

Accessories

(1.6mV @ 94 dB SPL) @ 1 kHz

pin 2(+), pin 3(-) and pin 1 (ground)

Width: 51.5mm (2.03”)

Polar ResponseFrequency Response

RM1

stand mount

ZP1

zip pouch

- 2 -
