XM-360 Process Module

User Guide

Firmware Revision 5

1440-TPR06-00RE

Important User Information

WARNING

IMPORTANT

ATTENTION

SHOCK HAZARD

BURN HAZARD

Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://literature.rockwellautomation.com wired electromechanical devices. Because of this difference, and also because of the wide variety of uses for solid state equipment, all persons responsible for applying this equipment must satisfy themselves that each intended application of this equipment is acceptable.

In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.

The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for actual use based on the examples and diagrams.

No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software described in this manual.

Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is prohibited.

Throughout this manual, when necessary, we use notes to make you aware of safety considerations.

Identifies information about practices or circumstances that can cause an explosion in a hazardous environment, which may lead to personal injury or death, property damage, or economic loss.

) describes some important differences between solid state equipment and hard-

Identifies information that is critical for successful application and understanding of the product.

Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence

Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous voltage may be present.

Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may reach dangerous temperatures.

Allen-Bradley, Rockwell Automation, and XM are trademarks of Rockwell Automation, Inc.

Trademarks not belonging to Rockwell Automation are property of their respective companies.

Safety Approvals

WARNING

AVERTISSEMENT

IMPORTANT

The following information applies when operating this equipment in hazardous locations.

Products marked "CL I, DIV 2, GP A, B, C, D" are suitable for use in Class I Division 2 Groups A, B, C, D, Hazardous Locations and nonhazardous locations only. Each product is supplied with markings on the rating nameplate indicating the hazardous location temperature code. When combining products within a system, the most adverse temperature code (lowest "T" number) may be used to help determine the overall temperature code of the system. Combinations of equipment in your system arfe subject to investigation by the local Authority Having Jurisdiction at the time of installation.

EXPLOSION HAZARD -

•Do not disconnect equipment unless power has been removed or the area is known to be nonhazardous.

•Do not disconnect connections to this equipment unless power has been removed or the area is known to be nonhazardous. Secure any external connections that mate to this equipment by using screws, sliding latches, threaded connectors, or other means provided with this product.

•Substitution of components may impair suitability for Class I, Division 2.

•If this product contains batteries, they must only be changed in an area known to be nonhazardous.

Informations sur l’utilisation de cet équipement en environnements dangereux.

Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne conviennent qu'à une utilisation en environnements de Classe I Division 2 Groupes A, B, C, D dangereux et non dangereux. Chaque produit est livré avec des marquages sur sa plaque d'identification qui indiquent le code de température pour les environnements dangereux. Lorsque plusieurs produits sont combinés dans un système, le code de température le plus défavorable (code de température le plus faible) peut être utilisé pour déterminer le code de température global du système. Les combinaisons d'équipements dans le système sont sujettes à inspection par les autorités locales qualifiées au moment de l'installation.

RISQUE D’EXPLOSION –

•Couper le courant ou s'assurer que l'environnement est classé non dangereux avant de débrancher l'équipement.

•Couper le courant ou s'assurer que l'environnement est classé non dangereux avant de débrancher les connecteurs. Fixer tous les connecteurs externes reliés à cet équipement à l'aide de vis, loquets coulissants, connecteurs filetés ou autres moyens fournis avec ce produit.

•La substitution de composants peut rendre cet équipement inadapté à une utilisation en environnement de Classe I, Division 2.

•S'assurer que l'environnement est classé non dangereux avant de changer les piles.

Wiring to or from this device, which enters or leaves the system enclosure, must utilize wiring methods suitable for Class I, Division 2 Hazardous Locations, as appropriate for the installation in accordance with the product drawings as indicated in the following table.

Model Catalog Number Haz Location Drawings* Model Catalog Number Haz Location Drawings*

w/o Barriers

XM-120 1440-VST0201RA XM-121 1440-VLF0201RA XM-360 1440-TPR0600RE XM-122 1440-VSE0201RA XM-361 1440-TUN0600RE XM-123 1440-VAD0201RA XM-361 1440-TTC0600RE XM-160 1440-VDRS0600RH XM-161 1440-VDRS0606RH XM-441 1440-REX0004RD 48241-HAZ N/A XM-162 1440-VDRP0600RH XM-442 1440-REX0304RG 48642-HAZ N/A XM-220 1440-SPD0201RB 48640-HAZ 48641-HAZ

48178-HAZ 48179-HAZ

51263-HAZ 51264-HAZ

* Drawings are available on the included CD

w/ Barriers

w/o Barriers

XM-320 1440-TPS0201RB 48238-HAZ 48239-HAZ

48295-HAZ 48299-HAZ

XM-440 1440-RMA0004RC 48240-HAZ N/A

w/ Barriers

Introduction

Installing the XM-360 Process Module

Chapter 1

Introducing the XM-360 Process Module . . . . . . . . . . . . . . . . . . . . . . . 1

XM-360 Module Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Using this Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Organization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 2

XM Installation Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Wiring Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Grounding Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Mounting the Terminal Base Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

DIN Rail Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Interconnecting Terminal Base Units. . . . . . . . . . . . . . . . . . . . . . . 15

Panel/Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting Wiring for Your Module . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Terminal Block Assignments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting the Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Connecting the 4-20mA Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Connecting a Remote Relay Reset Signal . . . . . . . . . . . . . . . . . . . . 22

Connecting the Inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

PC Serial Port Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

DeviceNet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Mounting the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Module Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Basic Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Powering Up the Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Manually Resetting Relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Chapter 3

Configuration Parameters

v Publication GMSI10-UM006C-EN-P - August 2010

General Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Channel Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Alarm Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Relay Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

4-20mA Output Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Triggered Trend Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

I/O Data Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Data Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Channel Data Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Alarm and Relay Status Parameters . . . . . . . . . . . . . . . . . . . . . . . . 59

Device Mode Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Table of Contents vi

Specifications

DeviceNet Information

DeviceNet Objects

Appendix A

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Appendix B

Electronic Data Sheets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Changing Operation Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Transition to Program Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Transition to Run Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

XM Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Invalid Configuration Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

XM-360 I/O Message Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Poll Message Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

COS Message Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Bit-Strobe Message Format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

ADR for XM Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Appendix C

Identity Object (Class ID 01H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Instance Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

DeviceNet Object (Class ID 03H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Instance Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Assembly Object (Class ID 04H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Instances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Instance Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Assembly Instance Attribute Data Format. . . . . . . . . . . . . . . . . . . 84

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Connection Object (Class ID 05H). . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Instances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Instance Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Analog Input Point Object (Class ID 0AH). . . . . . . . . . . . . . . . . . . . . 90

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Instances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Instance Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Publication GMSI10-UM006C-EN-P - August 2010

Table of Contents vii

Parameter Object (Class ID 0FH). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Instances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Instance Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Acknowledge Handler Object (Class ID 2BH) . . . . . . . . . . . . . . . . . . 96

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Instances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Instance Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Alarm Object (Class ID 31DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Instances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Instance Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Device Mode Object (Class ID 320H) . . . . . . . . . . . . . . . . . . . . . . . . . 99

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Instance Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Relay Object (Class ID 323H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Instances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Instance Attributes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

4-20mA Output Object (Class ID 32AH) . . . . . . . . . . . . . . . . . . . . . 103

Class Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Instances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Instance Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Glossary

Index

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Publication GMSI10-UM006C-EN-P - August 2010

Table of Contents viii

Publication GMSI10-UM006C-EN-P - August 2010

Chapter

Introduction

This chapter provides an overview of the XM-360 Process module. It also discusses the components of the modules.

For information about See page

Introducing the XM-360 Process Module 1 XM-360 Module Components 2 Using this Manual 2

Introducing the XM-360 Process Module

The XM-360 Process module is an intelligent 6-channel general-purpose

process monitor. It is a member of the Allen-Bradley™ XM of DIN rail mounted condition monitoring and protection modules that operate both in stand-alone applications or integrate with Programmable Logic Controllers (PLCs) and control system networks.

The XM-360 is a complete process monitoring system. The module can be configured to measure a DC voltage or a loop current input on each channel. It will report both the data value, in engineering units, and the rate of change for each channel.

For applications where it is not possible to integrate XM data directly via DeviceNet, the XM-360 provides separate 4-20mA outputs for each channel. And for applications requiring relays, the XM-360 supports connecting up to two XM-441 Expansion Relay modules, providing a total of eight relays. The XM-360 can also collect trend data on an event such as a relay actuation.

The module can operate stand-alone, or it can be deployed on a standard or dedicated DeviceNet network where it can provide real-time data and status information to other XM modules, PLCs, distributed control systems (DCS), and Condition Monitoring Systems.

The XM-360 can be configured remotely via the DeviceNet network, or locally using a serial connection to a PC or laptop. Refer to Chapter 3 for a list of the configuration parameters.

Series, a family

1 Publication GMSI10-UM006C-EN-P - August 2010

2 Introduction

XM-944 Temperature Module Terminal Base Unit

Cat. No. 1440-TB-E

XM-360 Process Module

Cat. No. 1440-TPR06-00RE

IMPORTANT

XM-360 Module Components

The XM-360 consists of a terminal base unit and an instrument module. The XM-360 Process Module and the XM-944 Temperature Terminal Base are shown below.

Figure 1.1 XM-360 Module Components

• XM-944 Temperature Module Terminal Base - A DIN rail mounted base unit that provides terminations for all field wiring required by XM Temperature/Process modules, including the XM-360.

Using this Manual

• XM-360 Process Module - The module mounts on the XM-944 terminal base via a keyswitch and a 96-pin connector. The module contains the measurement electronics, processors, and serial interface port for local configuration.

Up to two XM-441 Expansion Relay modules may be connected to the XM-360 module via the XM-944 terminal base.

When connected to the module, the Expansion Relay modules simply “expand” the capability of the XM-360 by providing a total of up to eight relays. The XM-360 controls the operation of the Expansion Relay modules.

This manual introduces you to the XM-360 Process module. It is intended for anyone who installs, configures, or uses the XM-360 Process module.

Publication GMSI10-UM006C-EN-P - August 2010

Introduction 3

TIP

EXAMPLE

Organization

To help you navigate through this manual, it is organized in chapters based on these tasks and topics.

Chapter 1 “Introduction” contains an overview of this manual and the XM-360 module.

Chapter 2 “Installing the XM-360 Process Module” describes how to install, wire, and use the XM-360 module.

Chapter 3 “Configuration Parameters” provides a complete listing and description of the XM-360 parameters. The parameters can be viewed and edited using the XM Serial Configuration Utility software and a personal computer.

Appendix A “Specifications” lists the technical specifications for the XM-360 module.

Appendix B “DeviceNet Information” provides information to help you configure the XM-360 over a DeviceNet network.

Appendix C “DeviceNet Objects” provides information on the DeviceNet objects supported by the XM-360 module.

For definitions of terms used in this Guide, see the Glossary at the end of the Guide.

Document Conventions

There are several document conventions used in this manual, including the following:

The XM-360 Process module is referred to as XM-360, Process module, device, or module throughout this manual.

A tip indicates additional information which may be helpful.

This convention presents an example.

Publication GMSI10-UM006C-EN-P - August 2010

4 Introduction

Publication GMSI10-UM006C-EN-P - August 2010

Chapter

ATTENTION

Installing the XM-360 Process Module

This chapter discusses how to install and wire the XM-360 Process module. It also describes the module indicators and the basic operations of the module.

For information about See page

XM Installation Requirements 6 Mounting the Terminal Base Unit 13 Connecting Wiring for Your Module 17 Mounting the Module 38 Module Indicators 39 Basic Operations 41

Environment and Enclosure

This equipment is intended for use in a Pollution Degree 2 Industrial environment, in overvoltage Category II applications (as defined in IED publication 60664–1), at altitudes up to 2000 meters without derating.

This equipment is supplied as “open type” equipment. It must be mounted within an enclosure that is suitably designed for those specific environmental conditions that will be present, and appropriately designed to prevent personal injury resulting from accessibility to live parts. The interior of the enclosure must be accessible only by the use of a tool. Subsequent sections of this publication may contain additional information regarding specific enclosure type ratings that are required to comply with certain product safety certifications.

See NEMA Standards publication 250 and IEC publication 60529, as applicable, for explanations of the degrees of protection provided by different types of enclosures.

5 Publication GMSI10-UM006C-EN-P - August 2010

6 Installing the XM-360 Process Module

ATTENTION

XM Installation Requirements

This section describes wire, power and grounding requirements and instructions for an XM system.

Wiring Requirements

Use solid or stranded wire. All wiring should meet the following specifications:

• 14 to 22 AWG copper conductors without pretreatment; 8 AWG required for grounding the DIN rail for electromagnetic interference (emi) purposes

• Recommended strip length 8 millimeters (0.31 inches)

• Minimum insulation rating of 300V

• Soldering the conductor is forbidden

• Wire ferrules can be used with stranded conductors; copper ferrules

recommended

See the XM Documentation and Configuration Utility CD for Hazardous Locations installation drawings. The XM Documentation and Configuration Utility CD is packaged with the XM modules.

Power Requirements

Before installing your module, calculate the power requirements of all modules interconnected via their side connectors. The total current draw through the side connector cannot exceed 3A. Refer to the specifications for the specific modules for power requirements.

A separate power connection is necessary if the total current draw of the interconnecting modules is greater than 3A.

Figure 2.1 is an illustration of wiring modules using separate power connections.

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 7

Any limited power source that satisfies the requirements specified below

Figure 2.1 XM Modules with Separate Power Connections

Power Supply Requirements

XM Power Supply Requirements

Listed Class 2 rated supply, or

Protection

Fused* ITE Listed SELV supply, or

Fused* ITE Listed PELV supply Output Voltage 24 Vdc ± 10% Output Power 100 Watts Maximum (~4A @ 24 Vdc) Static Regulation ± 2% Dynamic Regulation ± 3% Ripple < 100mVpp Output Noise Per EN50081-1 Overshoot < 3% at turn-on, < 2% at turn-off Hold-up Time As required (typically 50mS at full rated load) * When a fused supply is used the fuse must be a 5 amp, listed, fast acting fuse such as

provided by Allen-Bradley part number 1440-5AFUSEKIT

Publication GMSI10-UM006C-EN-P - August 2010

8 Installing the XM-360 Process Module

IMPORTANT

See Application Technique "XM Power Supply Solutions", publication ICM-AP005A-EN-E, for guidance in architecting power supplies for XM systems.

Grounding Requirements

Use these grounding requirements to ensure safe electrical operating circumstances, and to help avoid potential emi and ground noise that can cause unfavorable operating conditions for your XM system.

Din Rail Grounding

The XM modules make a chassis ground connection through the DIN rail. The DIN rail must be connected to a ground bus or grounding electrode conductor using 8 AWG or 1 inch copper braid. See Figure 2.2.

Use zinc-plated, yellow-chromated steel DIN rail (Allen-Bradley part no. 199-DR1 or 199-DR4) or equivalent to assure proper grounding. Using other DIN rail materials (e.g. aluminum, plastic, etc.), which can corrode, oxidize, or are poor conductors can result in improper or intermittent platform grounding.

Publication GMSI10-UM006C-EN-P - August 2010

Figure 2.2 XM System DIN Rail Grounding

Power Supply

DYNAMIC MEASUREMENT

1440-VST02-01RA

DYNAMIC MEASUREMENT

1440-VST02-01RA

POSITION

1440-TSP02-01RB

MASTER RELAY

1440-RMA00-04RC

EXPANSION RELAY

1440-REX00-04RD

EXPANSION RELAY

1440-REX00-04RD

EXPANSION RELAY

1440-REX00-04RD

EXPANSION RELAY

1440-REX00-04RD

Power Supply

DYNAMIC MEASUREMENT

1440-VST02-01RA

DYNAMIC MEASUREMENT

1440-VST02-01RA

EXPANSION RELAY

1440-REX00-04RD

EXPANSION RELAY

1440-REX00-04RD

Installing the XM-360 Process Module 9

1 Use 14 AWG wire.

The grounding wire can be connected to the DIN rail using a DIN Rail Grounding Block (Figure 2.3).

Publication GMSI10-UM006C-EN-P - August 2010

10 Installing the XM-360 Process Module

Figure 2.3 DIN Rail Grounding Block

Panel/Wall Mount Grounding

The XM modules can also be mounted to a conductive mounting plate that is grounded. See Figure 2.5. Use the grounding screw hole provided on the terminal base to connect the mounting plate the Chassis terminals.

Figure 2.4 Grounding Screw on XM Terminal Base

Publication GMSI10-UM006C-EN-P - August 2010

Figure 2.5 Panel/Wall Mount Grounding

Power Supply

Installing the XM-360 Process Module 11

1 Use 14 AWG wire.

Publication GMSI10-UM006C-EN-P - August 2010

12 Installing the XM-360 Process Module

IMPORTANT

To Ground Bus

24V Common Grounding

24 V power to the XM modules must be grounded. When two or more power supplies power the XM system, ground the 24 V Commons at a single point, such as the ground bus bar.

If it is not possible or practical to ground the -24Vdc supply, then it is possible for the system to be installed and operate ungrounded. However, if installed ungrounded then the system must not be connected to a ground through any other circuit unless that circuit is isolated externally. Connecting a floating system to a non-isolated ground could result in damage to the XM module(s) and/or any connected device. Also, operating the system without a ground may result in the system not performing to the published specifications regards measurement accuracy and communications speed, distance or reliability.

The 24 V Common and Signal Common terminals are internally connected. They are isolated from the Chassis terminals unless they are connected to ground as described in this section. See Terminal Block Assignments on page 17 for more information.

DeviceNet Grounding

The DeviceNet network is functionally isolated and must be referenced to earth ground at a single point. XM modules do not require an external DeviceNet power supply. Connect DeviceNet V- to earth ground at one of the XM modules, as shown in Figure 2.6.

Figure 2.6 Grounded DeviceNet V- at XM Module

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 13

ATTENTION

Use of a separate DeviceNet power supply is not permitted. See Application Technique "XM Power Supply Solutions", publication ICM-AP005A-EN-E, for guidance in using XM with other DeviceNet products.

For more information on the DeviceNet installation, refer to the ODVA Planning and Installation Manual - DeviceNet Cable System, which is available on the ODVA web site (http://www.odva.org).

Mounting the Terminal Base Unit

The XM family includes several different terminal base units to serve all of the measurement modules. The XM-944 terminal base, Cat. No. 1440-TB-E, is the only terminal base unit used with the XM-360.

The terminal base can be DIN rail or wall/panel mounted. Refer to the specific method of mounting below.

The XM modules make a chassis ground connection through the DIN rail. Use zinc plated, yellow chromated steel DIN rail to assure proper grounding. Using other DIN rail materials (e.g. aluminum, plastic, etc.), which can corrode, oxidize or are poor conductors can result in improper or intermittent platform grounding.

You can also mount the terminal base to a grounded mounting plate. Refer to Panel/Wall Mount Grounding on page 10.

Publication GMSI10-UM006C-EN-P - August 2010

14 Installing the XM-360 Process Module

Position terminal base at a slight angle and hook over the top of the DIN rail.

DIN Rail Mounting

Use the steps below to mount the XM-944 terminal base unit on a DIN rail (A-B pt no. 199-DR1 or 199-DR4).

1. Position the terminal base on the 35 x 7.5mm DIN rail (A).

2. Slide the terminal base unit over leaving room for the side

connector (B).

3. Rotate the terminal base onto the DIN rail with the top of the rail hooked under the lip on the rear of the terminal base.

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 15

IMPORTANT

4. Press down on the terminal base unit to lock the terminal base on the DIN rail. If the terminal base does not lock into place, use a screwdriver or similar device to open the locking tab, press down on the terminal base until flush with the DIN rail and release the locking tab to lock the base in place.

Interconnecting Terminal Base Units

Follow the steps below to install another terminal base unit on the DIN rail.

Make certain you install the terminal base units in order of left to right.

1. Position the terminal base on the 35 x 7.5mm DIN rail (A).

2. Make certain the side connector (B) is fully retracted into the base unit.

3. Slide the terminal base unit over tight against the neighboring terminal

base. Make sure the hook on the terminal base slides under the edge of the terminal base unit.

5. Gently push the side connector into the side of the neighboring terminal base unit to complete the backplane connection.

Publication GMSI10-UM006C-EN-P - August 2010

16 Installing the XM-360 Process Module

Side Connector

Panel/Wall Mounting

Installation on a wall or panel consists of:

• laying out the drilling points on the wall or panel

• drilling the pilot holes for the mounting screws

• installing the terminal base units and securing them to the wall or panel

Use the following steps to install the terminal base on a wall or panel.

1. Lay out the required points on the wall/panel as shown in the drilling dimension drawing below.

Publication GMSI10-UM006C-EN-P - August 2010

2. Drill the necessary holes for the #6 self-tapping mounting screws.

3. Secure the terminal base unit using two #6 self-tapping screws.

4. To install another terminal base unit, retract the side connector into the base unit. Make sure it is fully retracted.

5. Position the terminal base unit up tight against the neighboring terminal

base. Make sure the hook on the terminal base slides under the edge of the terminal base unit.

6. Gently push the side connector into the side of the neighboring terminal base to complete the backplane connection.

7. Secure the terminal base to the wall with two #6 self-tapping screws.

Installing the XM-360 Process Module 17

ATTENTION

WARNING

XM-944, Cat. No. 1440-TB-E

Connecting Wiring for Your Module

Wiring to the module is made through the terminal base unit on which the module mounts. The XM-360 is compatible only with the XM-944 terminal base unit, Cat. No. 1440-TB-E.

Figure 2.7 XM-944 Terminal Base Unit

Terminal Block Assignments

The terminal block assignments and descriptions for the XM-360 module are shown below.

The terminal block assignments are different for different XM modules. The following table applies only to the XM-360. Refer to the installation instructions for the specific XM module for its terminal assignments.

EXPLOSION HAZARD

Do not disconnect equipment unless power has been removed or the area is known to be nonhazardous.

Do not disconnect connections to this equipment unless power has been removed or the area is known to be nonhazardous. Secure any external connections that mate to this equipment by using screws, sliding latches, threaded connectors, or other means provided with this product.

Terminal Block Assignments

No. Name Description

0 Chassis Connection to DIN rail ground spring or panel mounting hole 1 Chassis Connection to DIN rail ground spring or panel mounting hole 2 Chassis Connection to DIN rail ground spring or panel mounting hole

Publication GMSI10-UM006C-EN-P - August 2010

18 Installing the XM-360 Process Module

Terminal Block Assignments

No. Name Description

3 Input RTN 1 Current return when channel configured as a loop current 4 Input RTN 1

input Redundant terminal used to jumper terminal to channel Vin (-)

terminal, a requirement for loop current input 5 Input RTN 2 Current return when channel configured as a loop current 6 Input RTN 2

input

Redundant terminal used to jumper terminal to channel Vin (-)

terminal, a requirement for loop current input 7 Input RTN 3 Current return when channel configured as a loop current 8 Input RTN 3

input

Redundant terminal used to jumper terminal to channel Vin (-)

terminal, a requirement for loop current input 9 Input RTN 4 Current return when channel configured as a loop current 10 Input RTN 4

input

Redundant terminal used to jumper terminal to channel Vin (-)

terminal, a requirement for loop current input 11 Input RTN 5 Current return when channel configured as a loop current 12 Input RTN 5

input

Redundant terminal used to jumper terminal to channel Vin (-)

terminal, a requirement for loop current input 13 Input RTN 6 Current return when channel configured as a loop current 14 Input RTN 6

input

Redundant terminal used to jumper terminal to channel Vin (-)

terminal, a requirement for loop current input 15 Chassis Connection to DIN rail ground spring or panel mounting hole 16 4-20mA 1 (+) 4-20mA output 1, positive side 17 4-20mA 2 (+) 4-20mA output 2, positive side 18 4-20mA 3 (+) 4-20mA output 3, positive side 19 Vin (+) / Input In 1 Voltage Input 1, positive side when channel configured as a

voltage input

Current Input 1 when channel configured as a current input 20 Vin (-) / Iin Sense 1 Voltage Input 1, negative side when channel configured as a

voltage input

Current sensing 1 terminal when channel configured as a

current input, must be jumpered to channel Input RTN 21 Vin (+) / Input In 2 Voltage Input 2, positive side when channel configured as a

voltage input

Current Input 2 when channel configured as a current input 22 Vin (-) / Iin Sense 2 Voltage Input 2, negative side when channel configured as a

voltage input

Current sensing 2 terminal when channel configured as a

current input, must be jumpered to channel Input RTN 23 Vin (+) / Input In 3 Voltage Input 3, positive side when channel configured as a

voltage input

Current Input 3 when channel configured as a current input

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 19

Terminal Block Assignments

No. Name Description

24 Vin (-) / Iin Sense 3 Voltage Input 3, negative side when channel configured as a

voltage input

Current sensing 3 terminal when channel configured as a

current input, must be jumpered to channel Input RTN 25 Vin (+) / Input In 4 Voltage Input 4, positive side when channel configured as a

voltage input

Current Input 4 when channel configured as a current input 26 Vin (-) / Iin Sense 4 Voltage Input 4, negative side when channel configured as a

voltage input

Current sensing 4 terminal when channel configured as a

current input, must be jumpered to channel Input RTN 27 Vin (+) / Input In 5 Voltage Input 5, positive side when channel configured as a

voltage input

Current Input 5 when channel configured as a current input 28 Vin (-) / Iin Sense 5 Voltage Input 5, negative side when channel configured as a

voltage input

Current sensing 5 terminal when channel configured as a

current input, must be jumpered to channel Input RTN 29 Vin (+) / Input In 6 Voltage Input 6, positive side when channel configured as a

voltage input

Current Input 6 when channel configured as a current input 30 Vin (-) / Iin Sense 6 Voltage Input 6, negative side when channel configured as a

voltage input

Current sensing 6 terminal when channel configured as a

current input, must be jumpered to channel Input RTN 31 4-20mA 4 (+) 4-20mA output 4, positive side 32 4-20mA 5 (+) 4-20mA output 5, positive side 33 4-20mA 6 (+) 4-20mA output 6, positive side 34 4-20mA 1 (-) 4-20mA output 1, negative side 35 4-20mA 2 (-) 4-20mA output 2, negative side 36 4-20mA 3 (-) 4-20mA output 3, negative side 37 +24V In Connection to primary external +24V power supply, positive

side 38 24V Common Connection to external +24V power supply, negative side

(internally DC-coupled to circuit ground) 39 Reserved 40 Common Internally DC-coupled to circuit ground 41 Chassis Connection to DIN rail ground spring or panel mounting hole 42 Chassis Connection to DIN rail ground spring or panel mounting hole 43 Chassis Connection to DIN rail ground spring or panel mounting hole 44 CAN_High DeviceNet bus connection, high differential (white wire) 45 CAN_Low DeviceNet bus connection, low differential (blue wire) 46 CAN Shield DeviceNet bus connection to chassis ground (bare wire)

Publication GMSI10-UM006C-EN-P - August 2010

20 Installing the XM-360 Process Module

24V dc Power Supply

IMPORTANT

Terminal Block Assignments

No. Name Description

47 DNet V (+) DeviceNet bus power input, positive side (red wire) 48 DNet V (-) DeviceNet bus power input, negative side (black wire) 49 4-20mA 4 (-) 4-20mA output 4, negative side 50 4-20mA 5 (-) 4-20mA output 5, negative side 51 4-20mA 6 (-) 4-20mA output 6, negative side

Connecting the Power Supply

Power supplied to the module must be nominally 24 Vdc (±10%) and must be a Class 2 rated circuit.

Wire the DC-input power supply to the terminal base unit as shown in Figure

2.8.

Figure 2.8 DC Input Power Supply Connections

A Class 2 circuit can be provided by use of an NEC Class 2 rated power supply, or by using a SELV or PELV rated power supply with a 5 Amp current limiting fuse installed before the XM module(s).

24Vdc needs to be wired to terminal 37 (+24 V In) to provide power to the device and other XM modules linked to the wired terminal base via the side connector.

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 21

ATTENTION

IMPORTANT

The power connections are different for different XM modules. Refer to the installation instructions for your specific XM module for complete wiring information.

Connecting the 4-20mA Outputs

The module includes six 4-20mA output channels into a maximum load of 600 ohms each. The 4-20mA outputs are arranged into two isolated banks of three outputs each. Each bank of 4-20mA outputs is electrically isolated from the other bank and from circuit power and ground. The isolation provided is up to 250V.

The measurements that the 4-20mA output tracks and the signal levels that correspond to the 4mA and 20mA are configurable. Refer to 4-20mA Output Parameters on page 53 for a description of the 4-20mA parameters.

Wire the 4-20mA outputs to the terminal base unit as shown in Figure 2.9 and Figure 2.10.

The 4-20mA output shields must be grounded at a single point. It is recommended that where possible the cable shield be grounded at the equipment wired to the 4-20mA output and not at the XM-360 terminal base.

In order to utilize a loop current input, a jumper must be installed between the Input RTN terminal and the Iin Sense terminal. See Terminal Block Assignments on page 17.

Publication GMSI10-UM006C-EN-P - August 2010

22 Installing the XM-360 Process Module

Figure 2.9 4-20mA Output Connections

Figure 2.10 4-20mA Output Connections cont.

Publication GMSI10-UM006C-EN-P - August 2010

Connecting a Remote Relay Reset Signal

If you set the relay to latching and the relay activates, the relay stays activated even when the condition that caused the alarm has ended. The remote relay reset signal enables you to reset the relay remotely after you have corrected the alarm condition.

Installing the XM-360 Process Module 23

IMPORTANT

TIP

ATTENTION

The XM-360 does not have an on-board relay. The relays are added when an Expansion Relay (XM-441) module is connected to the XM-360. The XM-360 supports two Expansion Relay modules for a total of eight relays..

You must enable the Enable Relay Reset Switch Ter mi na ls parameter to make the Channel 6 input terminals available to wire the external relay reset switch. Refer to General Parameters on page 44.

The module provides remote reset functionality by setting the Channel 6 4-20mA output to a fixed (12mA) level, and setting the Channel 6 input channel to measure that current. The switch is wired in series to allow the current to flow, or to break the flow.

If you set a module relay to latching, make sure that any linked relays, such as relays in an XM-440 Master Relay Module, are not configured as latching. When both relays are set to latching, the relay in each module will have to be independently reset when necessary.

You can discretely reset a relay using the serial or remote configuration tool.

Wire the Remote Relay Reset Signal to the terminal base (Channel 6 input, Channel 6 4-20mA output terminals) as shown in Figure 2.11.

Figure 2.11 Remote Relay Reset Signal Connection

The switch power supply is isolated, but shares common with Channel 4 and Channel 5 4-20mA outputs. Care should be taken as to how these are grounded, if at all.

Publication GMSI10-UM006C-EN-P - August 2010

24 Installing the XM-360 Process Module

ATTENTION

IMPORTANT

TIP

A single switch contact can also be shared by multiple XM-360 modules wired in series as shown in Figure 2.12. When multiple modules are wired to a single switch, only one 4-20mA output channel is necessary to supply all the modules.

The relay reset connections may be different for different XM modules. Figure 2.12 applies only to the XM-360 module. Refer to the installation instructions for the module for its terminal assignments.

The XM-360/361/362 relay reset signal is not compatible with other XM module’s relay reset input. Use of a single switch requires a multi-pole switch. Refer to the XM Module User Manual for more information about the other XM modules.

Up to 24 XM-360 modules can be wired in series in a single loop.

Figure 2.12 Typical Multiple XM Modules Remote Relay Reset Signal Connection

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 25

IMPORTANT

ATTENTION

TYPICAL WIRING FOR VOLTAGE INPUT

TO XM-360 PROCESS MODULE CHANNEL 1

Process Output Voltage

Com

V out

SHIELD

RED

BLK

RED BLK

Connecting the Inputs

The XM-360 will accept signals from loop currents or voltage inputs. All six input channels are electrically isolated from each other and from circuit power and ground. The isolation provided is up to 250V.

With all the cable shields connected (six individual input cables and six output cables), there are not enough chassis terminals for each shield. Therefore, the cable shields should be paired as depicted in the following illustrations. Recommended practice is to use a crimp ferrule. Alternatively, you can use a separate grounding block mounted next to the module.

Connecting a Voltage Input

Figures 2.13 to 2.18 show the wiring from a voltage input to the terminal base unit of the XM-360 module.

Figure 2.13 0-5V Voltage Input to Channel 1 Wiring

You may ground the cable shield at either end of the cable. Do not ground the shield at both ends. Recommended practice is to ground the cable shield at the XM-360 terminal base and not at the field device. Any convenient Chassis terminal may be used (see Terminal Block Assignments on page 17).

Publication GMSI10-UM006C-EN-P - August 2010

26 Installing the XM-360 Process Module

TYPICAL WIRING FOR VOLTAGE INPUT

TO XM-360 PROCESS MODULE CHANNEL 2

Process Output Voltage

Com

V out

SHIELD

RED

BLK

RED BLK

TYPICAL WIRING FOR VOLTAGE INPUT

TO XM-360 PROCESS MODULE CHANNEL 3

Process Output Voltage

Com

V out

SHIELD

RED

BLK

RED BLK

Figure 2.14 0–5V Voltage Input to Channel 2 Wiring

Figure 2.15 0–5V Voltage Input to Channel 3 Wiring

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 27

TYPICAL WIRING FOR VOLTAGE INPUT

TO XM-360 PROCESS MODULE CHANNEL 4

Process Output Voltage

Com

V out

BLK

RED

SHIELD

RED

BLK

TYPICAL WIRING FOR VOLTAGE INPUT

TO XM-360 PROCESS MODULE CHANNEL 5

Process Output Voltage

Com

V out

RED

SHIELD

BLK

RED

BLK

Figure 2.16 0–5V Voltage Input to Channel 4 Wiring

Figure 2.17 0–5V Voltage Input to Channel 5 Wiring

Publication GMSI10-UM006C-EN-P - August 2010

28 Installing the XM-360 Process Module

TYPICAL WIRING FOR VOLTAGE INPUT

TO XM-360 PROCESS MODULE CHANNEL 6

Process Output Voltage

Com

V out

RED

SHIELD

BLK

RED BLK

ATTENTION

TIP

Figure 2.18 0–5V Voltage Input to Channel 6 Wiring

Connecting a Loop-Powered 4-20mA Input

Figures 2.19 to 2.24 show the wiring from a loop-powered 4-20mA input to the terminal base unit of the XM-360.

The XM-360 loop-current inputs are low impedance, approximately 50 ohms. Field devices providing digital

communications (such as HART

) on top of their 4-20mA analog signal may require a minimum loop impedance to function. This is typically 250 ohms, minimum. If the sum of the XM-360 input impedance, field wiring impedance, and other device impedance (such as displays) in the loop don’t meet this minimum requirement, additional resistance should be added. Typically this is accomplished by simply adding a 250 ohm resistor in the loop. Refer to the field device user manual for details and recommendations.

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 29

TYPICAL WIRING FOR LOOP-POWERED 4-20mA

TO XM-360 PROCESS MODULE CHANNEL 1

4-20mA Transmitter

Loop Power Supply 24V

BLK

RED

BLK

SHIELD

TYPICAL WIRING FOR LOOP-POWERED 4-20mA

TO XM-360 PROCESS MODULE CHANNEL 2

4-20mA Transmitter

Loop Power Supply 24V

BLK

RED

BLK RED

SHIELD

Figure 2.19 Loop-powered 4-20mA to Channel 1 Wiring

Figure 2.20 Loop-powered 4-20mA to Channel 2 Wiring

Publication GMSI10-UM006C-EN-P - August 2010

30 Installing the XM-360 Process Module

TYPICAL WIRING FOR LOOP-POWERED 4-20mA

TO XM-360 PROCESS MODULE CHANNEL 3

4-20mA Transmitter

Loop Power Supply 24V

BLK

RED

BLK

RED

SHIELD

TYPICAL WIRING FOR LOOP-POWERED 4-20mA

TO XM-360 PROCESS MODULE CHANNEL 4

4-20mA Transmitter

Loop Power Supply 24V

BLK RED

SHIELD

RED

BLK

Figure 2.21 Loop-powered 4-20mA to Channel 3 Wiring

Figure 2.22 Loop-powered 4-20mA to Channel 4 Wiring

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 31

TYPICAL WIRING FOR LOOP-POWERED 4-20mA

TO XM-360 PROCESS MODULE CHANNEL 5

4-20mA Transmitter

Loop Power Supply 24V

BLK

RED

BLK

RED

SHIELD

TYPICAL WIRING FOR LOOP-POWERED 4-20mA

TO XM-360 PROCESS MODULE CHANNEL 6

4-20mA Transmitter

Loop Power Supply 24V

BLK

RED

BLK

RED

SHIELD

Figure 2.23 Loop-powered 4-20mA to Channel 5 Wiring

Figure 2.24 Loop-powered 4-20mA to Channel 6 Wiring

Publication GMSI10-UM006C-EN-P - August 2010

32 Installing the XM-360 Process Module

ATTENTION

TIP

TYPICAL WIRING FOR NON-LOOP POWERED 4-20mA INPUT

TO XM-360 PROCESS MODULE CHANNEL 1

4-20mA Transmitter

RED

BLK

RED

SHIELD

BLK

Connecting a 4-20mA / 0-20mA Input

Figures 2.25 to 2.30 show the wiring from a non-loop powered 4-20mA input to the terminal base unit of the XM-360.

The XM-360 loop-current inputs are low impedance, approximately 50 ohms. Field devices providing digital

communications (such as HART analog signal may require a minimum loop impedance to function. This is typically 250 ohms, minimum. If the sum of the XM-360 input impedance, field wiring impedance, and other device impedance (such as displays) in the loop don’t meet this minimum requirement, additional resistance should be added. Typically this is accomplished by simply adding a 250 ohm resistor in the loop. Refer to the field device user manual for details and recommendations.

) on top of their 4-20mA

Figure 2.25 Non-loop Powered 4-20mA Input to Channel 1 Wiring

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 33

TYPICAL WIRING FOR NON-LOOP POWERED 4-20mA INPUT

TO XM-360 PROCESS MODULE CHANNEL 2

4-20mA Transmitter

RED

BLK

RED BLK

SHIELD

TYPICAL WIRING FOR NON-LOOP POWERED 4-20mA INPUT

TO XM-360 PROCESS MODULE CHANNEL 3

4-20mA Transmitter

RED

BLK

RED BLK

SHIELD

Figure 2.26 Non-loop Powered 4-20mA Input to Channel 2 Wiring

Figure 2.27 Non-loop Powered 4-20mA Input to Channel 3 Wiring

Publication GMSI10-UM006C-EN-P - August 2010

34 Installing the XM-360 Process Module

TYPICAL WIRING FOR NON-LOOP POWERED 4-20mA INPUT

TO XM-360 PROCESS MODULE CHANNEL 4

4-20mA Transmitter

RED

BLK

RED BLK

SHIELD

TYPICAL WIRING FOR NON-LOOP POWERED 4-20mA INPUT

TO XM-360 PROCESS MODULE CHANNEL 5

4-20mA Transmitter

RED

BLK

RED BLK

SHIELD

Figure 2.28 Non-loop Powered 4-20mA Input to Channel 4 Wiring

Figure 2.29 Non-loop Powered 4-20mA Input to Channel 5 Wiring

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 35

TYPICAL WIRING FOR NON-LOOP POWERED 4-20mA INPUT

TO XM-360 PROCESS MODULE CHANNEL 6

4-20mA Transmitter

RED

BLK

RED BLK

SHIELD

PROCESS

1440-TPR06-00RE

mini-connector

Figure 2.30 Non-loop Powered 4-20mA Input to Channel 6 Wiring

PC Serial Port Connection

The XM-360 includes a serial connection that allows you to connect a PC to it and configure the module’s parameters. The connection is through a mini-connector that is located on top of the XM-360, as shown below.

Figure 2.31 Mini-Connector

A special cable (Cat. No. 1440-SCDB9FXM2) is required for this serial connection. The connector that inserts into the PC is a DB-9 female

Publication GMSI10-UM006C-EN-P - August 2010

36 Installing the XM-360 Process Module

WARNING

IMPORTANT

connector, and the connector that inserts into the module is a USB Mini-B male connector.

If you connect or disconnect the serial cable with power applied to the module or the serial device on the other end of the cable, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding.

If 24V Common is not referenced to earth ground, we recommend you use an RS-232 isolator, such as Phoenix PSM-ME-RS232/RS232-P (Cat. No. 1440-ISO-232-24), to protect both the XM module and the computer.

DeviceNet Connection

The XM-360 includes a DeviceNet™ connection that allows the module to communicate directly with a programmable controller, DCS, or another XM module.

DeviceNet is an open, global, industry-standard communications network designed to provide an interface through a single cable from a programmable controller to a smart device such as the XM-360 module. As multiple XM modules are interconnected, DeviceNet also serves as the communication bus and protocol that efficiently transfers data between the XM modules.

Connect the DeviceNet cable to the terminal base unit as shown.

Connect To Terminal Base Unit

Red Wire DNet V+ 47 (Optional - see note) White Wire CAN High 44 Bare Wire Shield (Chassis) 46 Blue Wire CAN Low 45 Black Wire DNet V- 48

The DeviceNet power circuit through the XM module interconnect, which is rated at only 300 mA, is not intended or designed to power DeviceNet loads. Doing so could damage the module or terminal base.

Publication GMSI10-UM006C-EN-P - August 2010

To preclude this possibility, even unintentionally, it is recommended that DeviceNet V+ be left unconnected.

Installing the XM-360 Process Module 37

ATTENTION

IMPORTANT

You must ground the DeviceNet shield at only one location. Connecting the DeviceNet shield to terminal 46 will ground the DeviceNet shield at the XM-360 module. If you intend to terminate the shield elsewhere, do not connect the shield to terminal 46.

The DeviceNet network must also be referenced to earth at only one location. Connect DNet V- to earth or chassis at one of the XM modules.

The DNet V+ and DNet V- terminals are inputs to the XM module. Do not attempt to pass DeviceNet power through the XM terminal base to other non-XM equipment by connecting to these terminals. Failure to comply may result in damage to the XM terminal base and/or other equipment.

Terminate the DeviceNet network and adhere to the requirements and instructions in the ODVA Planning and Installation Manual - DeviceNet Cable System, which is available on the ODVA web site (http://www.odva.org).

The device is shipped from the factory with the network node address (MAC ID) set to 63. The network node address is software settable. You can use the XM Serial Configuration Utility or RSNetWorx for DeviceNet (Version 3.0 or later) to set the network node address. Refer to the appropriate documentation for details.

The baud rate for the XM-360 is set by way of "baud detection" (Autobaud) at power-up.

Publication GMSI10-UM006C-EN-P - August 2010

38 Installing the XM-360 Process Module

ATTENTION

WARNING

IMPORTANT

Mounting the Module

The XM-360 mounts on the XM-944 terminal base unit, Cat. No. 1440-TB-E. You should mount the module after you have connected the wiring on the terminal base unit.

The XM-360 is compatible only with the XM-944 terminal base unit. The keyswitch on the terminal base unit should be at position 5 for the XM-360.

Do not attempt to install XM-360 modules on other terminal base units.

Do not change the position of the keyswitch after wiring the terminal base.

This module is designed so you can remove and insert it under power. However, when you remove or insert the

module with power applied, I/O attached to the module can change states due to its input/output signal changing conditions. Take special care when using this feature.

When you insert or remove the module while power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before proceeding.

Install the overlay slide label to protect serial connector and electronics when the serial port is not in use.

1. Make certain the keyswitch (A) on the terminal base unit (C) is at position 5 as required for the XM-360.

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 39

PROCESS

1440-TPR06-00RE

Module Indicators

2. Make certain the side connector (B) is pushed all the way to the left. You cannot install the module unless the connector is fully extended.

3. Make sure that the pins on the bottom of the module are straight so they

will align properly with the connector in the terminal base unit.

4. Position the module (D) with its alignment bar (E) aligned with the groove (F) on the terminal base.

5. Press firmly and evenly to seat the module in the terminal base unit. The module is seated when the latching mechanism (G) is locked into the module.

6. Repeat the above steps to install the next module in its terminal base.

Module Indicators

The XM-360 has eight LED indicators, which include a module status (MS) indicator, a network status (NS) indicator, and a status indicator for each channel (CH1 to CH6). The LED indicators are located on top of the module.

Figure 2.32 LED Indicators

The following tables describe the states of the LED status indicators.

Publication GMSI10-UM006C-EN-P - August 2010

40 Installing the XM-360 Process Module

Module Status (MS) Indicator

Color State Description

No color Off No power applied to the module. Green Flashing Red Module performing power-up self test.

Flashing

Solid

Module operating in Program Mode

Module operating in Run Mode

Red Flashing • Application firmware is invalid or not loaded.

Download firmware to the module.

• Firmware download is currently in progress.

• The module power voltage is incorrect.

Solid An unrecoverable fault has occurred. The module may

need to be repaired or replaced.

1 Program Mode - Typically this occurs when the module configuration settings are being updated with the XM

Serial Configuration Utility. In Program Mode, the module does not perform its usual functions. The signal processing/measurement process is stopped, and the status of the alarms is set to the disarm state to prevent a false alert or danger status.

2 Run Mode - In Run Mode, the module collects measurement data and monitors each measurement device.

Network Status (NS) Indicator

Color State Description

No color Off Module is not online.

• Module is autobauding.

• No power is applied to the module, look at Module

Status LED.

Green Flashing Module is online (DeviceNet) but no connections are

currently established.

Solid Module is online with connections currently

established.

Red Flashing One or more I/O connections are in the timed-out state.

Solid Failed communications (duplicate MAC ID or bus-off).

1 Normal condition when the module is not a slave to an XM-440, PLC, or other master device.

Publication GMSI10-UM006C-EN-P - August 2010

Installing the XM-360 Process Module 41

Channel Status Indicator (6 in all)

Color State Description

No Color Off • Normal operation within alarm limits on the channel.

• No power applied to the module, look at Module

Status LED.

Yellow Solid An alert level alarm condition exists on the channel

(and no sensor-out-of-range or danger level alarm condition exists).

Red Solid A danger level alarm condition exists on the channel

(and no sensor-out-of-range condition exists).

Flashing A sensor-out-of-range condition exists on the channel.

Basic Operations

Powering Up the Module

The XM-360 performs a self-test at power-up. The self-test includes an LED test and a device test. During the LED test, the indicators will be turned on independently and in sequence for approximately 0.25 seconds.

The device test occurs after the LED test. The Module Status (MS) indicator is used to indicate the status of the device self-test.

MS Indicator State Description

Flashing Red and Green Device self test is in progress. Solid Green or Flashing Green Device self test completed successfully, and the

firmware is valid and running.

Flashing Red • Device self test completed, the hardware is OK, but

the firmware is invalid.

• Firmware download is in progress.

• Module power voltage is incorrect.

Solid Red Unrecoverable fault, hardware failure, or Boot Loader

program may be corrupted.

Refer to Module Indicators on page 39 for more information about the LED indicators.

Publication GMSI10-UM006C-EN-P - August 2010

42 Installing the XM-360 Process Module

IMPORTANT

PROCESS

1440-TUN06-00RE

Press the Reset Switch to reset the relays

Manually Resetting Relays

The XM-360 has an external reset switch located on top of the module, as shown in Figure 2.33.

Figure 2.33 Reset Switch

The switch can be used to reset all latched relays in the Expansion Relay module when it is connected to the XM-360.

The Reset switch resets the relays only if the input is no longer in alarm or the condition that caused the alarm is no longer present.

Publication GMSI10-UM006C-EN-P - August 2010

Chapter

IMPORTANT

Configuration Parameters

This chapter provides a complete listing and description of the XM-360 parameters. The parameters can be viewed and edited using the XM Serial Configuration Utility software and a personal computer. If the module is installed on a DeviceNet network, configuring can also be performed using a network configuration tool such as RSNetWorx (Version 3.0 or later). Refer to your configuration tool documentation for instructions on configuring a device.

For information about See page

General Parameters 44 Channel Parameters 44 Alarm Parameters 46 Relay Parameters 49 4-20mA Output Parameters 53 Triggered Trend Parameters 54 I/O Data Parameters 57 Data Parameters 58 Device Mode Parameters 60

The appearance and procedure to configure the parameters

The

may differ in different software.

43 Publication GMSI10-UM006C-EN-P - August 2010

44 Configuration Parameters

XM Configuration Utility

EDS File

Enable Relay Reset Switch Term ina ls

Relay Reset Switch Enable

XM Configuration Utility

EDS File

Check to enable Enabled Clear to disable Disabled

TIP

General Parameters

Use the general parameters to configure the sensor out-of-range allowance and to enable the relay reset switch terminals on the XM-360 module.

General Parameters

Parameter Name Description Values/Comments Sensor OOR Allowance The margin beyond the Input Range (as a

percentage of full scale) that will be considered valid and will not cause a sensor out-of-range fault.

This parameter allows you to extend the sensor out-of-range limits beyond the sensor input range. For example, if the Input Range is set to "4-20mA" and the Sensor OOR Allowance is set to "2%," then values between 3.68mA and 20.32mA will be valid and will not cause a fault.

Enable/disable the relay reset switch terminals on the XM-360 module. When this parameter is enabled, the Channel 6 input terminals and Channel 6 4-20mA output terminals are made available to wire an external relay reset switch for remote reset. See page 22 for wiring details.

Note that Channel 6 is not available for configuration if the Enable Relay Reset Switch is enabled.

0 to 5%

Channel Parameters

The channel parameters define the characteristics of the inputs you will be using with the XM-360. Use the parameters to configure the sensor input range, output scaling, and time constant. There are six instances of the channel parameters, one for each channel.

The Channel LED will flash red when a sensor-out-ofrange condition exists on the channel even if you are not using the channel. You can keep the Channel LED from flashing red on unused channels by setting the channel’s Sensor Input Range to "-5 to 5 Volts."

Channel 6 is not available for configuration if the Enable Relay Reset Switch parameter is enabled.

Channel Parameters

Parameter Name Description Values/Comments Channel Name (XM Serial

Configuration Utility only)

A descriptive name to help identify the channel in the XM Serial Configuration Utility.

Maximum 18 characters

Publication GMSI10-UM006C-EN-P - August 2010

Configuration Parameters 45

Data Units Options

Quantity of Measure

Deg C Deg F

Temperature

PSI inHg mbar Pa kPa

Pressure

CFM Flow m/s2

g gSE

Acceleration

mA Electrical Current RPM

Frequency

ips mm/s

Velocity

mm um (micro meter) in mil

Displacement

V Voltage radian

revolution degree

Rotational Angle

percent percent unspecified unspecified

Channel Parameters

Parameter Name Description Values/Comments Sensor Input Range Defines the valid range of the input signal. Options: 0 to 5 Volts

0 to 10 Volts 4 to 20 mA

-5 to 5 Volts 1 to 5 Volts 0 to 20 mA 0 to 1 Volt

Data Units Defines the data units of the measured value.

High Scale Limit Sets the output value corresponding to the high end

Low Scale Limit Sets the output value corresponding to the low end

of the Sensor input range.

Defines how the input signal should be scaled into a measurement value.

Note: A sensor-out-of-range condition exists when the output value is outside this range.

Publication GMSI10-UM006C-EN-P - August 2010

46 Configuration Parameters

XM Configuration Utility

EDS File

Seconds Milliseconds

Channel Parameters

Parameter Name Description Values/Comments Measurement Time Constant The time constant used for smoothing (low-pass

filtering) of the measurement value.

Note: The greater the measurement time constant, the slower the response of the measured value to change in the input signal (less sensitive to noise in the signal).

Rate Time Constant The time constant used for smoothing (low-pass

filtering) of the rate value.

Seconds

Note: The greater the rate time constant, the slower the response of the measured rate of change in the input signal (less sensitive to noise in the signal).

Alarm Parameters

The Alarm parameters control the operation of the alarms (alert and danger level) and provide alarm status. The XM-360 provides a total of 12 alarms. Each alarm is permanently associated with a corresponding measurement (for example, Channel 1 Value alarm, Channel 2 Rate Alarm, and so on). Use the parameters to configure which measurement the alarm is associated with, as well as the behavior of the alarm.

Publication GMSI10-UM006C-EN-P - August 2010

Configuration Parameters 47

XM Configuration Utility

EDS File

Check to Enable Enabled Clear to Disable Disabled

Alarm Parameters

Parameter Name Description Values/Comments Number (XM Serial Configuration

Utility only)

Sets the type of measurement and channel that is associated with the alarm. There are 12 alarms in the XM-360. Each alarm is associated with a measurement.

Note: Channel 6 is not available if the Enable Relay Reset Switch Terminals parameter is

enabled. See page 44.

Name (XM Serial Configuration Utility only)

A descriptive name to identify the alarm in the XM Serial Configuration Utility.

Enable Enable/disable the selected alarm.

Options: Channel 1 Value

Channel 2 Value Channel 3 Value Channel 4 Value Channel 5 Value Channel 6 Value Channel 1 Rate Channel 2 Rate Channel 3 Rate Channel 4 Rate Channel 5 Rate Channel 6 Rate Channel 1 Difference (Ch1 minus Ch6) Channel 2 Difference (Ch2 minus Ch1) Channel 3 Difference (Ch3 minus Ch2) Channel 4 Difference (Ch4 minus Ch3) Channel 5 Difference (Ch5 minus Ch4) Channel 6 Difference (Ch6 minus Ch5)

Maximum 18 characters

Note: The Alarm Status is set to "Disarm" when the alarm is disabled.

Publication GMSI10-UM006C-EN-P - August 2010

48 Configuration Parameters

Alarm Parameters

Parameter Name Description Values/Comments Condition Controls when the alarm should trigger.

Options: Greater Than

• Greater than - Triggers the alarm when the measurement value is greater than or equal to the Alert and Danger Threshold values.

The Danger Threshold value must be greater than or equal to the Alert Threshold value for the trigger to occur.

• Less than - Triggers the alarm when the measurement value is less than or equal to the Alert and Danger Threshold values.

The Danger Threshold value must be less than or equal to the Alert Threshold value for the trigger to occur.

• Inside range - Triggers the alarm when the measurement value is equal to or inside the range of the Alert and Danger Threshold values.

The Danger Threshold (High) value must be less than or equal to the Alert Threshold (High) value AND the Danger Threshold (Low) value must be greater than or equal to the Alert Threshold (Low) value for the trigger to occur.

• Outside range - Triggers the alarm when the measurement value is equal to or outside the range of the Alert and Danger Threshold values.

The Danger Threshold (High) value must be greater than or equal to the Alert Threshold (High) value, AND the Danger Threshold (Low) value must be less than or equal to the Alert Threshold (Low) value for the trigger to occur.

Alert Threshold (High)

The threshold value for the alert (alarm) condition.

Note: This parameter is the greater threshold value when Condition is set to "Inside Range" or "Outside

Same measurement unit as Data Units selection for the specified channel. Note that for rate alarms, it is unit per minute.

Range."

Danger Threshold (High) The threshold value for the danger (shutdown)

condition.

Same measurement unit as Data Units selection for the specified channel. Note that for rate alarms, it is

Note: This parameter is the greater threshold value

unit per minute.

when Condition is set to "Inside Range" or "Outside Range."

Alert Threshold (Low) The lesser threshold value for the alert (alarm)

condition.

Same measurement unit as Data Units selection for the specified channel. Note that for rate alarms, it is

Note: This parameter is not used when Condition is

unit per minute.

set to "Greater Than" or "Less Than."

Danger Threshold (Low) The lesser threshold value for the danger (shutdown)

condition.

Same measurement unit as Data Units selection for the specified channel. Note that for rate alarms, it is

Note: This parameter is not used when Condition is

unit per minute.

set to "Greater Than" or "Less Than."

Less Than Inside Range Outside Range

Publication GMSI10-UM006C-EN-P - August 2010

Configuration Parameters 49

IMPORTANT

Alarm Parameters

Parameter Name Description Values/Comments Hysteresis The amount that the measured value must fall

(below the threshold) before the alarm condition is cleared. For example, Alert Threshold = 120 and Hysteresis = 2. The alarm (alert) activates when the measured value is 120 and will not clear until the measured value is 118.

Note: The Alert and Danger Thresholds use the same hysteresis value.

Note: For the Outside Range condition, the hysteresis value must be less than Alert Threshold (High) – Alert Threshold (Low).

Same measurement unit as Data Units selection for the specified channel. Note that for rate alarms, it is unit per minute.

Relay Parameters

The Relay parameters control the operation of the relays. The XM-360 module does not have an on-board relay. The relays are added when an Expansion Relay (XM-441) module is connected to the XM-360. The XM-360 supports two Expansion Relay modules for a total of eight relays. Use these parameters to configure which alarm(s) the relay is associated with, as well as the behavior of the relay.

A relay can be defined, regardless of whether or not it is physically present. A non-physical relay is a virtual relay. When a relay (physical or virtual) activates, the module sends a Change of State (COS) message to its master, which acts on the condition as necessary. An XM-440 Master Relay Module can activate its own relays in response to a relay (physical or virtual) activation at any of its slaves.

Relay Parameters

Parameter Name Description Options/Comments Number (XM Serial Configuration

Utility only)

Sets the relay to be configured in the XM Serial Configuration Utility.

The relays are either relays on the Expansion Relay module when it is connected to the XM-360 or virtual relays.

Virtual relays are non-physical relays. Use them when you want the effect of the relay (monitor alarms, delay, and change status) but do not need an actual contact closure. For example, a PLC or controller monitoring the relay status.

Note: The Relay Installed parameter indicates whether a relay is a virtual relay or a physical relay on a module.

Publication GMSI10-UM006C-EN-P - August 2010

50 Configuration Parameters

XM Configuration Utility

EDS File

Check to Enable Enabled Clear to Disable Disabled

XM Configuration Utility

EDS File

Latching Latching

Option

XM Configuration Utility

EDS File

Check means latching (relay must be explicitly reset)

Latching

Clear means non-latching (relay is reset once the alarm condition has passed)

Nonlatching

XM Configuration Utility

EDS File

Activation Logic Logic

Relay Parameters

Parameter Name Description Options/Comments Name (XM Serial Configuration

Utility only)

A descriptive name to help identify the relay in the XM Serial Configuration Utility.

Maximum 18 characters

Enable Enable/disable the selected relay.

Note: The Relay Current Status is set to "Not

Activated" when the relay is disabled. See page 58.

Controls whether the relay must be explicitly reset after the alarm subsides.

Activation Delay Enter the length of time for which the Activation

Publication GMSI10-UM006C-EN-P - August 2010

Logic must be true before the relay is activated. This reduces nuisance alarms caused by external noise and/or transient events.

Sets the relay activation logic.

• A or B - Relay is activated when either Alarm A or Alarm B meets or exceeds the selected Alarm Status condition(s).

• A and B - Relay is activated when both Alarm A and Alarm B meet or exceed the selected Alarm Status condition(s).

• A Only - Relay is activated when Alarm A meets or exceeds the selected Alarm Status condition(s).

Enter a value from 0 to 25.5 seconds, adjustable in increments of 0.1 seconds.

Default is 1 second Options: A only

A or B A and B

Configuration Parameters 51

XM Configuration Utility

EDS File

Alarm A/B Alarm

Identifier A/B

XM Configuration Utility

EDS File

Alarm Status to Activate On

Alarm Levels

XM Configuration Utility

EDS File

Check = Physical Relay

Installed = Physical Relay

Clear = Virtual Relay Not Installed =

Virtual Relay

Relay Parameters

Parameter Name Description Options/Comments

Sets the alarm(s) that the relay will monitor. The alarm must be from the same device as the relay. When the Activation Logic is set to "A and B" or "A or B," you can select an alarm in both Alarm A and Alarm B. The system monitors both alarms. When the Activation Logic is set to "A Only," you can select an alarm only in Alarm A.

Options: Channel 1 value alarm

Channel 2 value alarm Channel 3 value alarm Channel 4 value alarm Channel 5 value alarm Channel 6 value alarm Channel 1 rate alarm Channel 2 rate alarm Channel 3 rate alarm Channel 4 rate alarm Channel 5 rate alarm Channel 6 rate alarm Channel 1 difference alarm (Ch1 minus Ch6) Channel 2 difference alarm (Ch2 minus Ch1) Channel 3 difference alarm (Ch3 minus 2) Channel 4 difference alarm (Ch4 minus 3) Channel 5 difference alarm (Ch5 minus 4) Channel 6 difference alarm (Ch6 minus Ch5)

Sets the alarm conditions that will cause the relay to activate. You can select more than one.

• Normal - The current measurement is not within excess of any alarm thresholds.

• Alert - The current measurement is in excess of the alert level threshold(s) but not in excess of the danger level threshold(s).

• Danger - The current measurement is in excess of the danger level threshold(s).

• Disarm-The alarm is disabled or the device is in Program mode.

• Sensor OOR - The signal from the sensor is outside the Input Range.

• Module Fault - Hardware or firmware failure, or an error has been detected and is preventing proper operation of the device.

Relay Installed Indicates whether the relay is a physical relay on a

module or a virtual relay. If the relay is a physical relay, then you can set the Failsafe parameter.

If the relay is a virtual relay, the Failsafe parameter is not used or it is disabled.

Note: You can only select an alarm that is enabled.

Options: Normal

Danger Sensor OOR Alert Disarm Module Fault

Check to enable. Clear to disable.

Publication GMSI10-UM006C-EN-P - August 2010

52 Configuration Parameters

XM Configuration Utility

EDS File

Failsafe Relay Failsafe

Option

XM Configuration Utility

EDS File

Check means failsafe

Failsafe

Clear means nonfail-safe

Nonfailsafe

Relay Parameters

Parameter Name Description Options/Comments

Determines whether the relay is failsafe or nonfail-safe.

Failsafe operation means that when in alarm, the relay contacts are in their "normal," de-energized, or "shelf-state" positions. In other words, normally closed relays are closed in alarm, and normally open relays are open in alarm. With failsafe operation, a power failure equals an alarm.

The following are true of a relay in failsafe operation:

• The relay is energized when power is applied to the module.

• The relay in a nonalarmed condition has power applied to the coil.

• In alarm condition, power is removed from the relay coil, causing the relay to change state.

For nonfail-safe operation, the following are true:

• Under nonalarm conditions, the relay closes the circuit between the common and the N.C. (normally closed) terminals.

• Under alarm conditions, the relay changes state to close the circuit between the common and the N.O. (normally open) terminals.

For failsafe operation, the following are true:

• Under nonalarm (with power applied to the unit) conditions, the relay closes the circuit between the common and the N.O. terminals.

• Under alarm or loss-of-power conditions, the relay changes state to close the circuit between the common and the N.C. terminals.

Publication GMSI10-UM006C-EN-P - August 2010

Configuration Parameters 53

IMPORTANT

XM Configuration Utility

EDS File

Check to enable Enabled Clear to disable Disabled

IMPORTANT

4-20mA Output Parameters

The 4-20mA output parameters define the characteristics of the 4-20mA output signals. The XM-360 supports a total of six 4-20mA outputs. Each output is permanently associated with a corresponding channel. The parameters are the same for each output.

If the Enable Relay Reset Switch Terminals parameter is enabled, Channel 6 is not available for configuration, and the Channel 6 4-20mA output is set to a fixed (12mA) level. See page 44 and page 22 for details.

4-20mA Parameters

Parameter Name Description Options/Comments 4-20mA Output (XM Serial

Configuration Utility only) Enable Enables/disables the 4-20mA output.

Sets the 4-20mA output to be configured in the XM Serial Configuration Utility.

Each output is associated with a corresponding channel.

Measurement Sets the measurement value that the 4-20mA output

will track.

Min Range The measured value associated with the 4mA. Same measurement unit as Data Max Range The measured value associated with the 20mA.

Options: Value

Difference

Units selection for the specified channel.

Measured values between Min Range and Max Range are scaled into the range from 4.0 to 20.0 to produce the output value. The Min Range value does not have to be less than the Max Range value. If the Min Range value is greater than the Max Range value, then the output signal is effectively inverted from the input signal.

Publication GMSI10-UM006C-EN-P - August 2010

54 Configuration Parameters

IMPORTANT

The 4-20mA outputs are either on or off. When they are on, the 4-20mA outputs overshoot the 4 and 20mA limits by 10% when the measurement exceeds the minimum and maximum range. This means the minimum current produced is 3.6mA and the maximum current produced is 22mA.

When the 4-20mA outputs are off, they produce a current approximately 2.9mA. The 4-20mA outputs are off under the following conditions:

• The 4-20mA outputs are set to "Disable" (see Enable above).

• The module is in Program mode.

• A sensor out-of-range error occurs that affects the

corresponding measurement.

Triggered Trend Parameters

The XM-360 module can collect a triggered trend. A triggered trend is a time-based trend that is collected when a relay is activated, or the module receives a trigger event.

Once the triggered trend is configured, the XM-360 continuously monitors the trended measurements. When a trigger occurs, the XM-360 collects additional data as specified by the Post Trigger parameter.

The XM-360 can only store one triggered trend. Unless the triggered trend is latched, the trend data is overwritten with new data when the next trigger occurs.

The triggered trend parameters define the trend data that is collected by the module. Use these parameters to select the measurements included in the

Publication GMSI10-UM006C-EN-P - August 2010

Configuration Parameters 55

IMPORTANT

trend records, the interval between trend records, and which relay triggers (activates) the collection of the trend data.

The Triggered Trend parameters are not included in the EDS file and cannot be edited using generic configuration tools such as RSNetWorx for DeviceNet.

Triggered Trend Parameters

Parameter Name Description Values/Comments Enable Triggered Trend

Measurements

Select Measurements Sets the measurements to be collected and stored in

Enables/disables the triggered trend measurements. Select to configure the triggered trend measurements.

the module.

Check to enable. Clear to disable.

More than one measurement can be selected.

Number of Records The maximum number of measurement sets that can

be collected in the trend buffer. The measurement sets make up the trend data.

Latch Enable Determines whether the trigger trend is latched or

unlatched.

Latched means that subsequent triggers are ignored after the initial trigger. This prevents the trend data from being overwritten with new data until the trigger is manually reset (click Reset Trigger button).

Unlatched means that the trend data is overwritten with new data every time a trigger occurs.

Relay Number Sets the relay that triggers the trend to be collected. None means that the trend can only be

Record Interval The amount of time between consecutive trend

records.

The Number of Records is automatically calculated based upon the number of Trended Measurements selected.

Check means latched Clear means unlatched

triggered manually or by a trigger event (for example, XM-440).

Relay Numbers 1 through 5 are either relays on the Expansion Relay module when it’s connected to the module or virtual relays.

Note: The relay must be enabled. Refer to Relay Parameters on page 49.

1 to 3600 seconds

Note: If you enter a Record Interval, the Trend Span is automatically updated.

Trend Span The total amount of time that can be covered by the

trend data (Number of Records x Record

Interval).

Note: If you edit the Trend Span, the Record Interval is automatically updated.

Publication GMSI10-UM006C-EN-P - August 2010

Seconds

56 Configuration Parameters

Triggered Trend Parameters

Parameter Name Description Values/Comments Post Trigger The percentage of records to be collected once the

0 to 100 Percent trigger occurs. For example, if you set Post Trigger to 20%, then 80% of the records in the trend are before the trigger occurs, and 20% of the records in the trend are after the trigger occurs.

This allows you to evaluate what happened after the trigger occurred.

Status Shows the status of the trend data. Possible status values:

• Not collected - No trend data is currently collected.

• Collecting - A trigger has occurred and data (including post-trigger data) is being collected.

• Collected - A trend has been saved to the buffer and is available to view and upload.

View Trend Data Displays a plot of the collected trend data. Reset Trigger Resets the trigger if Latch enabled is selected. This

allows the module to overwrite the previous trend data when the next trigger occurs.

Manual Trigger Triggers the module to collect the trend data without

relay activation.

Publication GMSI10-UM006C-EN-P - August 2010

Configuration Parameters 57

IMPORTANT

XM Configuration Utility

EDS File

Poll Output Poll

Response Assembly

I/O Data Parameters

The I/O data parameters are used to configure the content and size of the DeviceNet I/O Poll response message.

The XM-360 must be free of Poll connections when configuring the Poll Output (Poll Response Assembly) and Poll Size. Any attempt to download the parameters while a master device has established the Poll connection with the XM-360 will result in an error.

To close an existing Poll connection with an XM-440, switch the XM-440 from Run mode to Program mode. Refer to Changing Operation Modes on page 67.

To close an existing Poll connection with other master devices, remove the XM-360 from the scanlist or turn off the master device.

I/O Data Parameters

Parameter Name Description Values/Comments COS Size (XM Serial

Configuration Utility only) COS Output (XM Serial

Configuration Utility only)

Poll Size Sets the size (number of bytes) of the Poll response

The size (number of bytes) of the Change of State (COS) message.

The Assembly instance used for the COS message. The COS message is used to produce the Alarm and Relay status for the module.

message. Decreasing the maximum size will truncate data from the end of the Assembly structure.

The COS Size cannot be changed.

The COS Output cannot be changed. Refer to COS Message Format on page 73 for more information.

The minimum size is 4 bytes and the maximum size is 124 bytes.

Assembly Instance Table (XM Serial Configuration Utility only)

Custom Assembly (XM Serial Configuration Utility only)

Important: If you set the Poll Output to "Custom

Assembly," the poll size is automatically set to the actual size of the customized Poll response.

Sets the Assembly instance used for the Poll response message. Each Assembly instance contains a different arrangement of the Poll data.

The Poll response message is used by the XM module to produce measured values. It can contain up to 31 REAL values for a total of 124 bytes of data.

Displays the format of the currently selected COS or Poll Assembly instance.

Defines a custom data format for the Poll response. The custom assembly can contain any of the measurement parameters included in Assembly instance 101, as well as alarm and relay configuration parameters.

Publication GMSI10-UM006C-EN-P - August 2010

Options: Assembly Instance 101

Assembly Instance 102 Assembly Instance 103 Custom Assembly

Refer to Poll Message Format on page 71 for more information.

The highlighted (yellow) Assembly structure bytes are included in the I/O message.

You can select up to 20 parameters.

Refer to Poll Message Format on page 71 for more information.

58 Configuration Parameters

TIP

XM Configuration Utility

EDS File

Value Measurement

Value

XM Configuration Utility

EDS File

Rate Rate of

Change

Data Parameters

The Data parameters are used to view the measured values of the input channels and the 4–20mA outputs, as well as to monitor the status of the channels, alarms, and relays.

To view all the data parameters in the XM Serial Configuration Utility, click the View Data tab.

Channel Data Parameters

Parameter Name Description Values/Comments Channel Status States whether a fault exists on the associated

channel. If a fault exists, the measurement and rate of change values may not be accurate.

Shows the current measurement value for the channel.

Shows the current rate of change value for the channel.

Possible status values: No Fault

Important: Channel 6 data values are not available if the Enable Relay Reset Switch Terminals parameter is enabled. (Refer to General Parameters on page 44.) The Channel 6 measurement Value will display "Open" if the measurement value is <0.5, or "Closed" if the measurement value is ≥ 0.5.

Fault

Difference Shows the current difference value for the channel.

Publication GMSI10-UM006C-EN-P - August 2010

This value is calculated by subtracting the previous channel's measurement from this channel’s measurement.

Configuration Parameters 59

Alarm and Relay Status Parameters

Parameter Name Description Values/Comments Alarm Status States the current status of the measurement value,

rate of change and difference alarm.

Possible status values:

• Normal - The alarm is enabled, the device is in Run mode, there is no sensor-out-of-range error, and the current measurement is not within the Alert or Danger Threshold value(s).

• Alert - The alarm is enabled, the device is in Run mode, there is no sensor-out-of-range error, and the current measurement is in excess of the Alert Threshold value(s) but not in excess of the Danger Threshold value(s).

• Danger - The alarm is enabled, the device is in Run mode, there is no sensor-out-of range error, and the current measurement is in excess of the Danger Threshold value(s).

• Disarm-The alarm is disabled or the device is in Program mode.

• Sensor OOR - The alarm is enabled, the device is in Run mode, and a sensor-out-of-range error is detected for the associated sensor.

• Module Fault - Hardware or firmware failure, or an error has been detected and is preventing proper operation of the device.

Relay Status States the current status of the relay. Possible status values: Activated

Not Activated

Publication GMSI10-UM006C-EN-P - August 2010

60 Configuration Parameters

IMPORTANT

Device Mode Parameters

The Device Mode parameters are used to control the functions and the behavior of the device.

The XM Serial Configuration Utility handles these parameters automatically and transparently to the user.

Device Mode Parameters

Parameter Name Description Values/Comments Device Mode Sets the current operation mode of the device. Refer

to Changing Operation Modes on page 67 for more information.

Autobaud Enables/disables autobaud.

When autobaud is set to "Enabled," the module will listen to other devices on the network to determine the correct baud rate to use for communications. When autobaud is set to "Disabled," the module baud rate must be set manually.

Options: Run Mode

Options: Enabled

Program Mode

Disabled

Publication GMSI10-UM006C-EN-P - August 2010

Appendix

Specifications

Appendix A lists the technical specifications for the XM-360 Process module.

XM-360 Technical Specifications

Product Feature Specification

Communications

DeviceNet

Standard DeviceNet protocol for all functions

NOTE: The XM-360 uses only the DeviceNet protocol, not power. Module power is provided independently.

Available Electronic Data Sheet (EDS) file provides support for most DeviceNet compliant systems Baud rate automatically set by bus master to 125kb, 250kb, 500kb Configurable I/O Poll Response message helps optimize space utilization within scanner input tables.

Selectable Poll Response Assembly Selectable Poll Response Size (bytes)

Side Connector

Serial

All XM measurement and relay modules include side connectors that allow interconnecting adjacent modules, thereby simplifying the external wiring requirements. The interconnect provides primary power, DeviceNet communications, and the circuits necessary to support expansion modules, such as the XM-441 Expansion Relay module.

RS-232 via mini-connector Baud rate fixed at 19200

NOTE: Local configuration via Serial Configuration Utility.

61 Publication GMSI10-UM006C-EN-P - August 2010

62 Specifications

XM-360 Technical Specifications

Product Feature Specification

Inputs

6 Channels

1 to 6 process DC voltage inputs or loop current inputs

Outputs

Indicators

Isolation

Sensitivity

Input Range

Input Impedance

4-20mA Outputs

Accuracy

Isolation

8 LEDs Module Status - red/green

Up to 250 Volts of isolation for each input

User configurable in software.

User configurable per channel as:

0 to 5 Volts 0 to 10 Volts 4 to 20mA

-5 to 5 Volts 1 to 5 Volts 0 to 20mA

50 ohm Current input / 1 Mohm voltage input

Two isolated banks of three outputs (one per channel) 600 ohm max load

±1% of full scale max ±0.2% of full scale typical

250 Volts

Network Status - red/green Channel 1 Status - yellow/red Channel 2 Status - yellow/red Channel 3 Status - yellow/red Channel 4 Status - yellow/red Channel 5 Status - yellow/red Channel 6 Status - yellow/red

Publication GMSI10-UM006C-EN-P - August 2010

XM-360 Technical Specifications

Product Feature Specification

Signal Conditioning

Accuracy

1% of full scale max ±0.2% of full scale typical

Specifications 63

Measured Parameters

Delta Time Buffer

Low Pass Filter

Resolution

Measurement Units

Measured Value

Rate of Change Per minute

Number or Records

User configurable for the measurement value and rate of change value from each channel

0.05% of input range

Deg C PSI Deg F inHg CFM mbar m/s2 Pa g kPa gSE mA RPM ips Hz mm/s mm V um radian in revolution mil degree percent unspecified

Updated once per second

2048

Alarms

Delta Time Interval

Trigger Mode

Number

Alarm Parameters

Operators

Hysteresis

1 to 3600 seconds

Relay on the XM-441 Expansion Relay module is activated, or by a trigger event (for example, DeviceNet command from a controller or host).

The data collected in the buffer is user configurable in software.

12 alarm and danger pairs

Measurement value and rate of change value from each channel

Greater than Less than Inside range Outside range

User configurable in software

Publication GMSI10-UM006C-EN-P - August 2010

64 Specifications

XM-360 Technical Specifications

Product Feature Specification

Relays

Number

Up to eight relays when interconnected to one or two XM-441 Expansion Relay modules, or Eight virtual relays whose status can be used by remote control systems

Failsafe

Normally energized (failsafe), or Normally de-energized (non-fail-safe)

Latching

Latching, or Non-latching

Time Delay

0 to 25.5 seconds, adjustable in 100msec increments

Voting Logic

Single or paired "And" or "Or" logic applied to any alarm

Local reset switch on top of module

Reset

Digital reset command via serial or DeviceNet interface

Activation On

Alarm Status:

Normal Alert Danger Disarm Sensor-out-of-range Module fault

Non-Volatile Configuration A copy of the module configuration is

retained in non-volatile memory from where it is loaded upon power up*.

Publication GMSI10-UM006C-EN-P - August 2010

Power

Module

Consumption

Heat Production

*The configuration stored in non-volatile

memory can be deleted only by a module-reset command sent via the serial interface, using the Serial Configuration Utility, or via DeviceNet from any compliant software application.

+21.6 to 26.4V dc

Maximum: 300mA Typical: 170mA

Maximum: 7.20 Watts (24.6 BTU/hr) Typical: 4 Watts (14 BTU/hr)

XM-360 Technical Specifications

UL UL Listed for Ordinary

Locations

UL UL Listed for Class I, Division 2

Group A, B, C, and D Hazardous Locations

CSA CSA Certified Process Control

Equipment

CSA CSA Certified Process Control

Equipment for Class I, Division 2 Group A, B, C, and D Hazardous Locations

EEX* European Union 94/9/EEC ATEX

Directive, compliant with EN 50021; Potentially Explosive Atmospheres, Protection “n”

CE* European Union 89/336/EEC

EMC Directive

C-Tick* Australian

Radiocommunications Act, compliant with: AS/NZS 2064, Industrial Emissions

Product Feature Specification

Environmental

Operating Temperature

-20 to +65°C (-4 to +149°F)

Specifications 65

Storage Temperature

Relative Humidity

Conformal Coating

Physical

Dimensions

Terminal Screw Torque

Approvals (when product or packaging is marked)

-40 to +85°C (-40 to +185°F)

95% non-condensing

All printed circuit boards are conformally coated in accordance with IPC-A-610C,

Height: 3.8in (97mm) Width: 3.7in (94mm) Depth: 3.7in (94mm)

7 pound-inches (0.6Nm)

*See the Product Certification link at

www.rockwellautomation.com for Declarations of Conformity, Certificates and other certification details.

Publication GMSI10-UM006C-EN-P - August 2010

66 Specifications

Publication GMSI10-UM006C-EN-P - August 2010

DeviceNet Information

IMPORTANT

Appendix

Electronic Data Sheets

Changing Operation Modes

Electronic Data Sheet (EDS) files are simple text files used by network configuration tools such as RSNetWorx (Version 3.0 or later) to help you identify products and easily commission them on a network. The EDS files describe a product’s device type, product revision, and configurable parameters on a DeviceNet network.

The EDS files for the XM modules are installed on your computer with the XM configuration software. The latest EDS files can also be obtained at http://www.ab.com/networks/eds/ or by contacting your local Rockwell Automation representative.

Refer to your DeviceNet documentation for instructions on registering the EDS files.

XM modules operate in two modes.

Mode Description

Run The XM measurement modules collect measurement data and

monitor each measurement device. The XM-440 establishes I/O connections with the XM measurement modules in its scan list and monitors their alarms, and controls its own relay outputs accordingly.

Program The XM module is idle.

The XM measurement modules stop the signal processing/measurement process, and the status of the alarms is set to the disarm state to prevent a false alert or danger status. The XM-440 closes the I/O connections with the XM measurement modules in its scan list and stops monitoring their alarms, relays are deactivated unless they are latched. Configuration parameters can be read, updated and downloaded to the XM module.

To change the operation mode of the XM module, use the Device Mode parameter in the EDS file. Note that the Stop and Start services described on page 69 can also be used to change the operation mode.

The XM Serial Configuration Utility software automatically puts XM modules in Program mode and Run mode without user interaction.

67 Publication GMSI10-UM006C-EN-P - August 2010

68 DeviceNet Information

TIP

Transition to Program Mode

Parameter values can only be downloaded to an XM module while the module is in Program mode. Any attempt to download a parameter value while the module is in Run mode will result in a Device State Conflict error.

To transition an XM module from Run mode to Program mode on a DeviceNet network, set the Device Mode parameter to "Program mode" and click Apply. Note that you cannot change any other parameter until you have downloaded the Program mode parameter.

The Module Status indicator flashes green when the module is in Program mode.

Refer to your DeviceNet documentation for specific instructions on editing EDS device parameters.

You can also use the Stop service described on page 69 to transition XM modules to Program mode.

Transition to Run Mode

In order to collect data and monitor measurement devices, XM modules must be in Run mode. To transition an XM module from Program mode to Run mode on a DeviceNet network, set the Device Mode parameter to "Run mode" and click Apply.

The Module Status indicator is solid green when the module is in Run mode.

Refer to your DeviceNet documentation for specific instructions on editing EDS device parameters.

You can also use the Start service described on page 69 to transition XM modules to Run mode.

Publication GMSI10-UM006C-EN-P - August 2010

DeviceNet Information 69

XM Services

Action

Transition to Run Mode Start

Transition to Program Mode Stop

Save configuration to non-volatile memory (EEPROM)

Delete saved configuration from non-volatile memory (EEPROM)

Reset a specific latched relay Reset

Reset all latched relays Reset

The table below defines the services supported by the XM modules. The table includes the service codes, classes, instances, and attributes by their appropriate hexidecimal codes. Use the Class Instance Editor in RSNetWorx to execute these services, as illustrated in the example below.

Service Code (Hex)

(06)

(07) Save

(16) Delete

(09)

(05)

Class (Hex) Instance Attribute Data

Device Mode Object (320)

Relay Object (323)

1 None None

Relay number 1-C for XM-440, 1-5 for XM-12X, XM-320 and XM-220, 1-8 for XM-36X and XM-16X

0 None None

None None

Reset the Peak Speed (XM-12X only)

Close the virtual setpoint multiplier switch to activate the alarm setpoint multipliers (not applicable to all XM modules)

Open the virtual setpoint multiplier switch to start the setpoint multiplier timers and eventually cancel alarm setpoint multiplication (not applicable to all XM modules)

Reset (05)

Other (33)

Other (32)

Speed Measurement Object (325)

Discrete Input Point Object (08)

1, 2 for XM-220 None None

1 None None

Publication GMSI10-UM006C-EN-P - August 2010

70 DeviceNet Information

Select the Save

service code

Clear Send the attribute ID and then enter the Class (320

hex

) and

Instance (1)

Click Execute to initiate the action

Example

To save the configuration parameters to the non-volatile memory (EEPROM), fill in the Class Instance Editor as shown below.

Invalid Configuration Errors

A Start or Save service request to an XM module may return an Invalid Device Configuration error when there is a conflict amongst the configuration settings.

The general error code for the Invalid Device Configuration error is D0

hex

An additional error code is returned with the general error code to specify which configuration settings are invalid. The table below lists the additional error codes associated with the Invalid Device Configuration error.

Additional Error Codes returned with the Invalid Device Configuration Error (0xD0)

Error Code (Hex) Description

01 No specific error information is available. 02 Mismatched transducer, channel, and/or measurement unit. 03 Inverted transducer fault high/low values. 04 Alarm thresholds conflict with the alarm condition. 05 Alarm speed range is invalid. 06 Band minimum frequency is greater than maximum frequency. Or,

07 Relay is associated with an alarm that is not enabled. 08 Tachometer must be enabled for alarm or channel settings. 09 A senseless speed range is enabled on a speed alarm.

maximum frequency is greater than FMAX.

Publication GMSI10-UM006C-EN-P - August 2010

DeviceNet Information 71

Additional Error Codes returned with the Invalid Device Configuration Error (0xD0)

Error Code (Hex) Description

0A Too many alarms associated with a single measurement. 0B Invalid node address in the alarm list. 0C Too many alarms in the alarm list. Or, no alarms in the alarm list. 0D Alarm levels cannot be zero for alarms that are enabled. 0E Too many slaves in the scanner’s input data table. 0F The FMAX and Number of Lines do not yield correct vector calculations. 10 Phase (vector) alarms prohibited with synchronous sampling and more

than 1 tachometer pulse per revolution. 11 Order-base bands are prohibited on asynchronous channel. 12 Unsupported Sensor Type and Channel ID combination. 13 Invalid Alarm Type for the associated measurement ID. 14 Synchronous sampling is required for alarm on synchronous

measurements. 15 Integration is not supported with the Bypass High Pass Filter option.

XM-360 I/O Message Formats

The XM-360 module supports Poll, Change of State (COS), and Bit-Strobe I/O messages. The Poll response message is used by the XM module to produce measured values, and the COS message is used to produce the Alarm

and Relay Status. The Bit-Strobe message is used by a master device to send a trigger event to all the XM slaves on the network.

Poll Message Format

The XM-360 Poll request message contains no data. The XM-360 Poll response message can contain up to 12 REAL values for a total of 48 bytes.

The XM-360 provides three pre-defined (static) data formats of the Poll response, as defined in Assembly instance 101–103. It also provides a dynamic Assembly instance, instance 199, with which you can define a custom data format for the Poll response. The dynamic Assembly instance can contain any of the measurement parameters included in Assembly instance 101, as well as several of the alarm and relay configuration parameters.

The default Assembly instance is 101 and the default size is 48 bytes. You can change the Assembly instance and define the dynamic Assembly using the configuration software. Refer to I/O Data Parameters on page 57 for details.

Publication GMSI10-UM006C-EN-P - August 2010

72 DeviceNet Information

The Poll response data can also be requested explicitly through Assembly Object (Class ID 0x4), Instance 101 (0x65) – 103 (0x67), Data Attribute (3).

The following tables show the static data format of Assembly instance 101–

103.

XM-360 Assembly Instance 101 Data Format

Byte Definition

0–3 Channel 1 measurement value 4–7 Channel 2 measurement value 8-11 Channel 3 measurement value 12-15 Channel 4 measurement value 16-19 Channel 5 measurement value 20-23 Channel 6 measurement value 24-27 Channel 1 rate of change value 28-31 Channel 2 rate of change value 32-35 Channel 3 rate of change value 36-39 Channel 4 rate of change value 40-43 Channel 5 rate of change value 44-47 Channel 6 rate of change value

XM-360 Assembly Instance 102 Data Format

Byte Definition

0–3 Channel 1 rate of change value 4–7 Channel 2 rate of change value 8-11 Channel 3 rate of change value 12-15 Channel 4 rate of change value 16-19 Channel 5 rate of change value 20-23 Channel 6 rate of change value 24-27 Channel 1 measurement value 28-31 Channel 2 measurement value 32-35 Channel 3 measurement value 36-39 Channel 4 measurement value 40-43 Channel 5 measurement value 44-47 Channel 6 measurement value

Publication GMSI10-UM006C-EN-P - August 2010

XM-360 Assembly Instance 103 Data Format

Byte Definition

0–3 Channel 1 measurement value 4–7 Channel 1 rate of change value 8-11 Channel 2 measurement value 12-15 Channel 2 rate of change value 16-19 Channel 3 measurement value 20-23 Channel 3 rate of change value 24-27 Channel 4 measurement value 28-31 Channel 4 rate of change value 32-35 Channel 5 measurement value 36-39 Channel 5 rate of change value 40-43 Channel 6 measurement value 44-47 Channel 6 rate of change value

DeviceNet Information 73

COS Message Format

The XM-360 COS message contains eight bytes of data as defined in the table below. The COS data can also be requested explicitly through Assembly Object (Class ID 0x4), Instance 100 (0x64), Data Attribute (3).

XM-360 COS Message Format

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 Relay 1

Status

1 Relay 2

Status

2 Relay 3

Status

3 Relay 4

Status

4 Relay 5

Status

5 Relay 6

Status

6 Relay 7

Status

Reserved Alarm 2 Status Alarm 1 Status

Reserved Alarm 4 Status Alarm 3 Status

Reserved Alarm 6 Status Alarm 5 Status

Reserved Alarm 8 Status Alarm 7 Status

Reserved Alarm 10 Status Alarm 9 Status

Reserved Alarm 12 Status Alarm 11 Status

Reserved Reserved Reserved

7 Relay 8

Status

Reserved Reserved Reserved

Publication GMSI10-UM006C-EN-P - August 2010

74 DeviceNet Information

XM Status Values

The following tables describe the XM Status values that are included in the COS messages.

Alarm Status Descriptions

Alarm Status Value Description

0Normal 1Alert 2 Danger 3Disarm 4 Transducer Fault (Sensor OOR) 5 Module Fault 6 Tachometer Fault 7 Reserved

Relay Status Descriptions

Relay Status Value Description

0 Not Activated 1 Activated

Bit-Strobe Message Format

The Bit-Strobe command sends one bit of output data to each XM slave whose node address appears in the master’s scanlist.

The Bit-Strobe command message contains a bit string of 64 bits (8 bytes) of output data, one output bit per node address on the network. One bit is assigned to each node address supported on the network (0...63) as shown in Figure B.1.

Publication GMSI10-UM006C-EN-P - August 2010

DeviceNet Information 75

IMPORTANT

Figure B.1 Bit-Strobe Command

The XM modules use the bit received in a Bit-Strobe connection as a trigger event. When the bit number corresponding to the XM module’s node address is set, the XM module will collect the triggered trend data.

ADR for XM Modules

Note that the XM modules do not send data in the Bit-Strobe response.

Automatic Device Replacement (ADR) is a feature of an Allen-Bradley DeviceNet scanner. It provides a means for replacing a failed device with a new unit, and having the device configuration data set automatically. Upon replacing a failed device with a new unit, the ADR scanner automatically downloads the configuration data and sets the node address.

It is recommended that ADR not be used in safety related applications. If the failure of the ADR server, and a subsequent power cycle, would result in the loss of protection for a machine, then ADR should not be implemented.

ADR can be used with XM modules but keep the following in mind when setting up the XM modules.

Publication GMSI10-UM006C-EN-P - August 2010

76 DeviceNet Information

TIP

• The ADR scanner can not download the configuration data to an XM module if the module has a saved configuration in its non-volatile memory. This happens because the saved configuration is restored and the module enters Run mode when the power is cycled. (Configuration parameters cannot be downloaded while an XM module is in Run mode.) XM modules must be in Program mode for the ADR configuration to be downloaded and this occurs only when there is no saved configuration.

To delete a saved configuration from non-volatile memory, use the Delete service in RSNetWorx for DeviceNet or perform the following steps in the XM Serial Configuration Utility.

1. Save the current configuration to a file. From the File menu, click Save As and enter a file name for

the configuration.

2. Reset the module to factory defaults. Click the Module tab and click the Reset button.

3. Reload the saved configuration. From the File menu, click Open and select the configuration file.

4. Make certain to disable auto save. From the Device

menu, clear the Auto Save Configuration check mark.

• An XM module will enter Run mode automatically after the ADR scanner restores the module’s configuration only if the module is in Run mode at the time the configuration is saved to the scanner. If the module is in Program mode when the configuration is saved, then the module will remain in Program after the configuration is downloaded by the ADR scanner.

• The ADR scanner saves and restores only the configuration parameters contained in the module’s EDS file. Some XM parameters are not included in the EDS file because they are not supported by either the EDS specification or the tools that read the EDS files, for example RSNetWorx for DeviceNet. These configuration parameters will not be restored with ADR.

Below is a list of the configuration parameters that are not included in the EDS file and can not be saved or restored with ADR.

Publication GMSI10-UM006C-EN-P - August 2010

– Channel Name – Tachometer Name – Alarm Name – Relay Name – All Triggered Trend related parameters (see page 54)

DeviceNet Information 77

– All SU/CD Trend related parameters – Custom Assembly structure (see page 57)

• The ADR and trigger group functions cannot be used together. A module can have only one primary master so a module cannot be both configured for ADR and included in a trigger group. The ADR scanner must be the primary master for the modules configured for ADR. The XM-440 Master Relay module must be the primary master for modules included in a trigger group.

Publication GMSI10-UM006C-EN-P - August 2010

78 DeviceNet Information

Publication GMSI10-UM006C-EN-P - August 2010

Appendix

TIP

DeviceNet Objects

Appendix C provides information on the DeviceNet objects supported by the XM-360 module.

For information about See page

Identity Object (Class ID 01H) 80 DeviceNet Object (Class ID 03H) 81 Assembly Object (Class ID 04H) 83 Connection Object (Class ID 05H) 88 Analog Input Point Object (Class ID 0AH) 90 Parameter Object (Class ID 0FH) 92 Acknowledge Handler Object (Class ID 2BH) 96 Alarm Object (Class ID 31DH) 97 Device Mode Object (Class ID 320H) 99 Relay Object (Class ID 323H) 101 4-20mA Output Object (Class ID 32AH) 103

Refer to the DeviceNet specification for more information about DeviceNet objects. Information about the DeviceNet specification is available on the ODVA web site (http://www.odva.org).

79 Publication GMSI10-UM006C-EN-P - August 2010

80 DeviceNet Objects

Identity Object (Class ID 01

)

The Identity Object provides identification and general information about the device.

Class Attributes

The Identity Object provides no class attributes.

Instance Attributes

Table C.1 Identity Object Instance Attributes

Access

Attr ID

1 Get Vendor ID UINT 668 = Entek 2 Get Device Type UINT 109 (Specialty I/O) 3 Get Product Code UINT 22 (0x16) XM-360 4 Get Revision:

5 Get Status WORD

Rule Name Data Type Default Value

STRUCT OF Major Minor

USINT

Value varies with each firmware revision. Value varies with each firmware revision.

6 Get Serial Number UDINT 7 Get Product Name SHORT_

STRING

Status

The Status is a 16 bit value. The following bits are implemented.

Table C.2 Identity Object Status

Bit Name Description

0 Owned TRUE indicates that the module has an owner. More

specifically, the Predefined Master/Slave Connection Set

has been allocated to a master. 1 Reserved, set to 0 2 Configured This bit is set whenever a saved configuration is

successfully loaded from non-volatile memory. This bit is

cleared whenever the default configuration is restored or

loaded. 3 Reserved, set to 0

"XM-360 Process Module"

Publication GMSI10-UM006C-EN-P - August 2010

DeviceNet Objects 81

Table C.2 Identity Object Status

Bit Name Description

4 Boot Program Vendor-specific, indicates that the boot program is

running. The Main Application must be corrupt or

missing. 5 - 7 Vendor-specific, not implemented 8 Minor Recoverable

Fault

9 Minor Unrecoverable

Fault

10 Major Recoverable

Fault

11 Major Unrecoverable

Fault

12 - 15 Reserved, set to 0

Set whenever there is a sensor out of range. Also set if

the ambient temperature is measured to be outside of

the module’s operating range.

Set when one of the cold junction temperature sensors in

the terminal base is judged to be bad.

Set when the module detects a major problem that the

user may be able to recover from. The Module Status

LED will flash red. An example of this condition is when

the boot program is running.

Set when there is a module status fault (Module Status

LED is solid red).

Services

Table C.3 Identity Object Services

Service Code Class/Instance Usage Name

01 05 0E 10

Instance Get_Attributes_All Instance Reset Instance Get_Attribute_Single Instance

Set_Attribute_Single

DeviceNet Object (Class ID 03

)

1 Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object

for more information.

The DeviceNet Object is used to provide the configuration and status of a physical attachment to DeviceNet.

Publication GMSI10-UM006C-EN-P - August 2010

82 DeviceNet Objects

Class Attributes

Table C.4 DeviceNet Object Class Attributes

Access

Attr ID

1 Get Revision UINT 2

Rule Name Data Type Default Value

Instance Attributes

Table C.5 DeviceNet Object Instance Attributes

Access

Attr ID

1 Get/Set

2 Get/Set

3 Get Bus-Off Interrupt BOOL 0 4 Get/Set Bus-Off Counter USINT 0

Rule Name Data Type Default Value

MAC ID

Baud Rate

USINT 63

USINT 0

5 Get Allocation Information STRUCT of

BYTE USINT

100 Get/Set Autobaud Disable BOOL 0 (Ignore attribute 2 and always autobaud)

1 Setting the MAC ID causes the device to reset automatically, after which it will go online with the new MAC

ID.

2 The Baud Rate setting can not be set while Autobaud Disable is equal to 0. The new baud rate will not take

effect until the module is reset.

0 255

The MAC ID, Baud Rate, and Autobaud Disable settings are stored in non-volatile memory so they do not reset to the default with each power cycle. The Baud Rate attribute supports the following settings.

• 0 = 125 kbps

• 1 = 250 kbps

• 2 = 500 kbps

The Baud Rate setting is used only when automatic baud rate detection is disabled (Autobaud Disable = 1). When Autobaud Disable is set to zero (0), the module ignores its Baud Rate setting and performs automatic baud rate detection instead. This means that the module will determine the network baud rate by listening for network traffic before attempting to go online.

Publication GMSI10-UM006C-EN-P - August 2010

DeviceNet Objects 83

Services

Table C.6 DeviceNet Object Services

Service Code Class/Instance Usage Name

1 Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object

for more information.

Class/Instance Get_Attribute_Single Instance

Instance Allocate_Master/Slave_Connetion_Set Instance Release_Group_2_Identifier_Set

Set_Attribute_Single

Assembly Object (Class ID 04

)

Table C.7 Assembly Object Class Attributes

Attr ID

1 Get Revision UINT Revision of the

The Assembly Object binds attributes of multiple objects to allow data to or from each object to be sent or received in a single message.

The XM-360 module provides both static and dynamic assemblies.

Class Attributes

Access Rule Name Data Type Description Semantics

implemented object.

Instances

Table C.8 Assembly Object Instances

Instance Name Type Description

100 Default COS Message Input Alarm and Relay Status values 101 Default Poll Response

Message

102 - 103 Alternate Poll Response

Message

Input Measurement values

199 Alternate Dynamic Poll

Response Message

Input User configurable

measurement values and configuration parameters

Publication GMSI10-UM006C-EN-P - August 2010

84 DeviceNet Objects

Table C.9 Assembly Object Instance Attributes

Attr ID

1 Get Number of Members in list UINT Only supported for Dynamic Assembly

2 Set Member List Array of STRUCT: Only supported for Dynamic Assembly

3 Get Data Defined in tables

Instance Attributes

Access Rule Name Data Type Value

instance

instance Member Data Description UINT Size of member data value in bits Member Path Size UINT Member Path Packed EPATH

on the following pages.

Assembly Instance Attribute Data Format

Instance 100 - Alarm and Relay Status

This assembly is sent using COS messaging when any of the Alarm or Relay Status values change.

Table C.10 Instance 100 Data Format (Alarm and Relay Status Values Assembly)

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 Relay 1

Status

1 Relay 2

Status

2 Relay 3

Status

3 Relay 4

Status

4 Relay 5

Status

5 Relay 6

Status

6 Relay 7

Status

0 Alarm 2 Status

(Channel 2 value)

0 Alarm 4 Status

(Channel 4 value)

0 Alarm 6 Status

(Channel 6 value)

0 Alarm 8 Status

(Channel 2 rate)

0 Alarm 10 Status

(Channel 4 rate)

0 Alarm 12 Status

(Channel 6 rate)

0 Alarm 14 Status

(Channel 2 difference)

Alarm 1 Status

(Channel 1 value)

Alarm 3 Status

(Channel 3 value)

Alarm 5 Status

(Channel 5 value)

Alarm 7 Status

(Channel 1 rate)

Alarm 9 Status

(Channel 3 rate)

Alarm 11 Status (Channel 5 rate)

Alarm 13 Status

(Channel 1 difference)

7 Relay 8

Status

8 0 0 Alarm 18 Status

Publication GMSI10-UM006C-EN-P - August 2010

0 Alarm 16 Status

(Channel 4 difference)

(Channel 6 difference)

Alarm 15 Status

(Channel 3 difference)

Alarm 17 Status

(Channel 5 difference)

DeviceNet Objects 85

Instance 101 - Measurement Values

This assembly instance can be selected to be sent in response to an I/O Poll Request from a Master. This instance is the default Poll response selection.

Table C.11 Instance 101 Data Format (Measurement Values Assembly)

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 - 3 Channel 1 Process (DC) Measurement value 4 - 7 Channel 2 Process (DC) Measurement value 8 - 11 Channel 3 Process (DC) Measurement value 12 - 15 Channel 4 Process (DC) Measurement value 16 - 19 Channel 5 Process (DC) Measurement value 20 - 23 Channel 6 Process (DC) Measurement value 24 - 27 Channel 1 Rate of Change value 28 - 31 Channel 2 Rate of Change value 32 - 35 Channel 3 Rate of Change value 36 - 39 Channel 4 Rate of Change value 40 - 43 Channel 5 Rate of Change value 44 - 47 Channel 6 Rate of Change value 48 - 51 Channel 1 - Channel 6 Difference 52 - 55 Channel 2 - Channel 1 Difference 56 - 59 Channel 3 - Channel 2 Difference 60 - 63 Channel 4 - Channel 3 Difference 64 - 67 Channel 5 - Channel 4 Difference 68 - 71 Channel 6 - Channel 5 Difference

Instance 102 - Measurement Values

This assembly instance can be selected to be sent in response to an I/O Poll request from a Master.

Table C.12 Instance 102 Data Format (Measurement Values Assembly)

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 - 3 Channel 1 Rate of Change value 4 - 7 Channel 2 Rate of Change value 8 - 11 Channel 3 Rate of Change value 12 - 15 Channel 4 Rate of Change value 16 - 19 Channel 5 Rate of Change value 20 - 23 Channel 6 Rate of Change value 24 - 27 Channel 1 Process (DC) Measurement value

Publication GMSI10-UM006C-EN-P - August 2010

86 DeviceNet Objects

Table C.12 Instance 102 Data Format (Measurement Values Assembly)

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

28 - 31 Channel 2 Process (DC) Measurement value 32 - 35 Channel 3 Process (DC) Measurement value 36 - 39 Channel 4 Process (DC) Measurement value 40 - 43 Channel 5 Process (DC) Measurement value 44 - 47 Channel 6 Process (DC) Measurement value 48 - 51 Channel 1 - Channel 6 Difference 52 - 55 Channel 2 - Channel 1 Difference 56 - 59 Channel 3 - Channel 2 Difference 60 - 63 Channel 4 - Channel 3 Difference 64 - 67 Channel 5 - Channel 4 Difference 68 - 71 Channel 6 - Channel 5 Difference

Instance 103 - Measurement Values

This assembly instance can be selected to be sent in response to an I/O Poll request from a Master.

Table C.13 Instance 103 Data Format (Measurement Values Assembly)

Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

0 - 3 Channel 1 Process (DC) Measurement value 4 - 7 Channel 1 Rate of Change value 8 - 11 Channel 2 Process (DC) Measurement value 12 - 15 Channel 2 Rate of Change value 16 - 19 Channel 3 Process (DC) Measurement value 20 - 23 Channel 3 Rate of Change value 24 - 27 Channel 4 Process (DC) Measurement value 28 - 31 Channel 4 Rate of Change value 32 - 35 Channel 5 Process (DC) Measurement value 36 - 39 Channel 5 Rate of Change value 40 - 43 Channel 6 Process (DC) Measurement value 44 - 47 Channel 6 Rate of Change value 48 - 51 Channel 1 - Channel 6 Difference 52 - 55 Channel 2 - Channel 1 Difference 56 - 59 Channel 3 - Channel 2 Difference 60 - 63 Channel 4 - Channel 3 Difference 64 - 67 Channel 5 - Channel 4 Difference 68 - 71 Channel 6 - Channel 5 Difference

Publication GMSI10-UM006C-EN-P - August 2010

Instance 199 - Dynamic Assembly

This Assembly instance can be created and configured with the XM Serial Configuration Utility or RSMACC Enterprise Online Configuration Utility. Using the configuration software, you determine the format of the data. This assembly instance can be selected to be sent in response to an I/O Poll request from a Master.

The dynamic Assembly can include all of the measurement values included in Assembly instance 101. In addition, the dynamic Assembly can include the following configuration parameters.

Table C.14 Instance 199 Component Mapping

DeviceNet Objects 87

EPATH (where ii = instance number)

Class Name

Class Number

21 1D 03 24 ii 30 04 Alarm 31D 21 1D 03 24 ii 30 07 Alarm 31D 21 1D 03 24 ii 30 08 Alarm 31D 21 1D 03 24 ii 30 09 Alarm 31D

21 1D 03 24 ii 30 0A Alarm 31D 21 1D 03 24 ii 30 0B Alarm 31D 21 1D 03 24 ii 30 0C Alarm 31D 21 23 03 24 ii 30 04 Relay 323 21 23 03 24 ii 30 05 Relay 323 21 23 03 24 ii 30 06 Relay 323 21 23 03 24 ii 30 07 Relay 323 21 23 03 24 ii 30 09 Relay 323 21 0F 00 24 ii 30 01 Param 0F

21 0F 00 24 ii 30 01 Param 0F

21 23 03 24 ii 30 0C Relay 323 21 23 03 24 ii 30 0E Relay 323

Instance Number

1 - 18 Alarm Enable 4 BOOL 1 - 18 Condition 7 USINT 1 - 18 Alert Threshold (High) 8 REAL 1 - 18 Danger Threshold

Attribute Name

Attribute Number

9REAL

(High)

1 - 18 Hysteresis 12 REAL

1 - 8 Failsafe Enable 6 BOOL

1 - 18 Alert Threshold Low 10 REAL 1 - 18 Danger Threshold Low 11 REAL

1 - 8 Relay Enable 4 BOOL 1 - 8 Latch Enable 5 BOOL

1 - 8 Delay 7 UINT 1 - 8 Alarm Level 9 BYTE 7 - 14 Parameter Value

1USINT

(Alarm Identifier A)

15 -22 Parameter Value

1USINT

(Alarm Identifier B)

1 - 8 Logic 12 USINT 1 - 8 Relay Installed 14 BOOL

Data Ty pe

The dynamic Assembly instance must be instantiated with a call to the class level Create service. Then the structure can be defined with the Set_Attribute_Single service for the Member List attribute. Only one dynamic Attribute instance is supported so subsequent calls to the Create service will return a Resource Unavailable (0x02) error. The Delete service can be used to destroy the dynamic Assembly instance so that it can be re-created.

Publication GMSI10-UM006C-EN-P - August 2010

88 DeviceNet Objects

Services

Table C.15 Assembly Object Services

Service Code Class/Instance Usage Name

0E 10 08 09

Class/Instance Get_Attribute_Single Instance Set_Attribute_Single Class Create Instance Delete

Connection Object (Class ID 05

)

The Connection Object allocates and manages the internal resources associated with both I/O and Explicit Messaging Connections.

Class Attributes

The Connection Object provides no class attributes.

Instances

Table C.16 Connection Object Instances

Instance Description

1 Explicit Message Connection for pre-defined connection set 2 I/O Poll Connection 3 I/O Strobe Connection 4 I/O COS (change of state) Connection 11 - 17 Explicit Message Connection

Publication GMSI10-UM006C-EN-P - August 2010

DeviceNet Objects 89

Instance Attributes

Table C.17 Connection Object Instance Attributes

Access

Attr ID

1 Get State USINT State of the object. 2 Get Instance Type USINT Indicates either I/O or Messaging

3 Get Transport Class Trigger BYTE Defines behavior of the Connection. 4 Get Produced Connection ID UINT Placed in CAN Identifier Field when the

5 Get Consumed Connection IDUINT CAN Identifier Field value that denotes

6 Get Initial Comm

7 Get Produced Connection

Rule Name Data Type Description

Connection.

Connection transmits.

message to be received.

BYTE Defines the Message Group(s) across

Characteristics

UINT Maximum number of bytes transmitted

Size

which productions and consumptions

associated with this Connection occur.

across this Connection.

8 Get Consumed Connection

Size

9 Get/Set Expected Packet Rate UINT Defines timing associated with this

12 Get/Set Watchdog Time-out

Action

13 Get Produced Connection

Path Length

14 Get Produced Connection

Path

15 Get Consumed Connection

Path Length

16 Get Consumed Connection

Path

17 Get Production Inhibit Time UINT Defines minimum time between new data

UINT Maximum number of bytes received across

this Connection.

Connection.

USINT Defines how to handle Inactivity/Watchdog

timeouts.

UINT Number of bytes in the

production_connection_path attribute.

Array of USINT

UINT Number of bytes in the

Array of USINT

Specifies the Application Object(s) whose

data is to be produced by this Connection

Object. See DeviceNet Specification

Volume 1 Appendix I.

consumed_connection_path attribute.

Specifies the Application Object(s) that are

to receive the data consumed by this

Connection Object. See DeviceNet

Specification Volume 1 Appendix I.

production.

Publication GMSI10-UM006C-EN-P - August 2010

90 DeviceNet Objects

Services

Table C.18 Connection Object Services

Service Code Class/Instance Usage Name

05 0E 10

Instance Reset Instance Get_Attribute_Single Instance Set_Attribute_Single

Analog Input Point Object (Class ID 0A

)

Table C.19 Analog Input Point Object Class Attributes

Access

Attr ID

1 Get Revision UINT Revision of the

Rule Name Data Type Description Semantics

The Analog Input Point Object models simple analog measurements performed by the XM-360 module. There are six instances of the Analog Input Point object, one for each input channel.

Class Attributes

implemented object.

Instances

Table C.20 Analog Input Point Object Instances

Instance Name Description

1 Channel 1 Measurements Process (DC) measurement and Rate of

Change for channel 1.

2 Channel 2 Measurements Process (DC) measurement and Rate of

Change for channel 2.

Publication GMSI10-UM006C-EN-P - August 2010

3 Channel 3 Measurements Process (DC) measurement and Rate of

Change for channel 3.

4 Channel 4 Measurements Process (DC) measurement and Rate of

Change for channel 4.

5 Channel 5 Measurements Process (DC) measurement and Rate of

Change for channel 5.

6 Channel 6 Measurements Process (DC) measurement and Rate of

Change for channel 6.

Instance Attributes

Table C.21 Analog Input Point Object Class Attributes

Access

Attr ID

3 Get Value REAL

Rule Name Data Type Description Semantics

DeviceNet Objects 91

4 Get Status BOOL Indicates if a fault or

alarm has occurred.

7 Get/Set Input Range USINT Valid range of the input

signal.

8 Get Value Data Type USINT Determines the data type

of the Value.

101 Get/Set Low

Engineering

103 Get/Set High

Engineering

116 Get/Set Digital Filter UINT Controls the time

143 Get/Set Sensor Tag STRING2 A descriptive name for the

147 Get/Set Data Units ENGUNIT The data units of Value,

150 Get/Set Rate Value REAL The rate of change of the

REAL Low scaling value The measurement value

REAL High scaling value The measurement value

constant of the digital filter.

sensor or channel.

Low Engineering, and High Engineering.

analog input value.

0 = Operating without alarms or faults 1 = Alarm or fault condition exists. The Value attribute may not represent the actual field value.

1 = 0 to 5 Volts 2 = 0 to 10 Volts 3 = 4 to 20 mA 6 = -5 to 5 Volts 7 = 1 to 5 Volts 8 = 0 to 20 mA 131 = 0 to 1 Volts

1 = REAL

(measurement units) that corresponds to either the low Input Range (signal units) or the sensor underrange fault.

(measurement units) that corresponds to either the high Input Range (signal units) or the sensor overrange fault.

Milliseconds

Data Units per minute

151 Get/Set Rate Filter REAL Controls the time

constant of the rate filter.

Seconds

Publication GMSI10-UM006C-EN-P - August 2010

92 DeviceNet Objects

Services

Table C.22 Analog Input Point Object Services

Service Code Class/Instance Usage Name Description

Class/Instance Get_Attribute_Single Returns the contents of the

specified attribute.

Instance Set_Attribute_Single Sets the contents of the

specified attribute.

1 Attributes can only be set while the device is in Program Mode. See the description of the Device Mode Object

for more information.

Parameter Object (Class ID 0F

)

Table C.23 Parameter Object Class Attributes

Attr ID

2 Get Max Instance UINT Maximum instance

8 Get Parameter Class

9 Get Config.

The Parameter Object provides the interface to the XM-360 configuration data. There are 38 Parameter Object instances implemented in the XM-360 modules.

Parameter Object instances 1-22 and 31-36 are implemented to provide an alternate method of setting the configuration parameters with EPATH or ENGUNIT data types. And Parameter Object instances 23 and 24 provide an alternate method of setting the Produced Connection Size and Produced Connection Path attributes for the Poll Connection because these attributes can be difficult to get/set directly through the Connection Object.

Class Attributes

Access Rule Name Data Type Description Semantics

Total number of parameter

Descriptor

Assembly Instance

number of an object in this class.

WORD Bits that describe the

parameter.

UINT Set to 0

object instances.

Bit 0 Supports Parameter Instances Bit 1 Supports Full Attrib. Bit 2 Must do non-volatile store Bit 3 Params in non-volatile

Publication GMSI10-UM006C-EN-P - August 2010

Rockwell Automation 1440-TPR06-00RE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Introduction

Introducing the XM-360 Process Module

XM-360 Module Components

Using this Manual

Organization

Document Conventions

Installing the XM-360 Process Module

XM Installation Requirements

Wiring Requirements

Power Requirements

Grounding Requirements

Mounting the Terminal Base Unit

DIN Rail Mounting

Interconnecting Terminal Base Units

Panel/Wall Mounting

Connecting Wiring for Your Module

Terminal Block Assignments

Connecting the Power Supply

Connecting the 4-20mA Outputs

Connecting a Remote Relay Reset Signal

Connecting the Inputs

PC Serial Port Connection

DeviceNet Connection

Mounting the Module

Module Indicators

Basic Operations

Powering Up the Module

Manually Resetting Relays

Configuration Parameters

General Parameters

Channel Parameters

Alarm Parameters

Relay Parameters

4-20mA Output Parameters

Triggered Trend Parameters

I/O Data Parameters

Data Parameters

Channel Data Parameters

Alarm and Relay Status Parameters

Device Mode Parameters

Specifications

DeviceNet Information

Electronic Data Sheets

Changing Operation Modes

Transition to Program Mode

Transition to Run Mode

XM Services

Invalid Configuration Errors

XM-360 I/O Message Formats

Poll Message Format

COS Message Format

Bit-Strobe Message Format

ADR for XM Modules

DeviceNet Objects

Class Attributes

Instance Attributes

Status

Services

Class Attributes

Instance Attributes

Services

Class Attributes

Instances

Instance Attributes

Assembly Instance Attribute Data Format

Services

Class Attributes

Instances

Instance Attributes

Services

Class Attributes

Instances

Instance Attributes

Services

Class Attributes
