CONGRATULATIONS

You’re holding the ROCCAT™ Kova[+] in your hands – the tuned-up successor to the outstanding Kova Gaming Mouse. Whether you’re left
or right-handed, the Ergo-Stealth design will fi t the way you prefer to hold and game with the mouse. One of the key new features is the
extensive driver package, comprising the driver, Macro Manager, Macro Presets and the revolutionary EasyShift[+] function.

ROCCAT™ Driver & EasyShift[+]

The Kova[+] is enhanced by a feature-rich
driver system. Along with the award-winning
Macro Manager, including Macro Presets for
gaming, multimedia and offi ce apps, the Kova[+]
now also features the innovative EasyShift[+]
button – allowing easy doubling of the number
of functions confi gurable on the mouse.

ROCCAT™ Griptech side areas

The ROCCAT™ Kova[+] features enlarged
Griptech side areas for left and right-handers
alike. These stabilize mouse
boost grip in particularly heated
situations. Along with the side areas, the
mouse body’s surface has also been improved
and now features a smooth, non-slip coating.

handling and

gaming

Customizable light system

Use the driver to change colors or the light
effects in a second. Get your ROCCAT™
Kova[+] to light up in a variety of legendary
colors. The discreetly integrated LEDs on
the sides of the mouse cast an atmospheric
aura over the desktop, particularly when you
activate the ‘breathing’ function.

QUICK INSTALLATION GUIDE

I M P O R TA N T
DOCUMENT

not be reproduced without the express consent of the publisher.
made liable for any errors that may appear in this manual. This publication or parts of it may
Information contained herein is subject to change without notice. ROCCAT GmbH shall not be
may be trademarks or registered trademarks and are the property of their respective owners.
© 2010 ROCCAT GmbH. All rights reserved. Any product names mentioned in this manual

SPECIFICATIONS

PACKAGE CONTAINS

 ROCCAT™ Kova[+]

Max Performance Gaming Mouse

 ROCCAT ID Card
 Quick Install Guide

SYSTEM REQUIREMENTS

 Windows® XP, Windows Vista® 32/64 bit,

Windows® 7 32/64 bi t

 Internet connection (for driver installation)

USB 2.0 Port

TECH SPECS

 3200dpi optical gaming sensor
 130 inches per second maximum speed
 30G acceleration
 1000Hz polling rate
 16-bit data channel
 2m USB cable

ORGANIZE YOUR DESKTOP WITH ROCCAT™ SDMS

MORE INFO ON WWW.ROCCAT.ORG/SDMS

Germany
22761 Hamburg
Gasstrasse 6b, Building N
Otto von Bahrenpark

ROCCAT GmbH

WWW.ROCCAT.ORG/SUPPORT

just send us an email ([e-mail]) or visit our website:
Our support team will help you with any technical problems –

Should you need assistance …

DEFAULT BUTTON ASSIGNMENT

A

(no driver installed)

ROCCAT™ EASYSHIFT

[+]

THE DUAL ASSIGNMENT FUNCTION FOR MOUSE BUTTONS

EASYSHIFT[+] EXAMPLES :

1 = Left mouse button

2 = Right mouse button

3 = Middle mouse button &

universal scroll

1

8

3

4

9

4 = Page forward (Browser)

5 = EasyShift[+] button

6 = Disabled by default

(install the driver to
assign a function)

7 = Disabled by default

(install the driver to
assign a function)

5

8 = Mouse wheel up

9 = Mouse wheel down

B

DEFAULT BUTTON ASSIGNMENT: EASYSHIFT[+]

(no driver installed)

5 + 1 = Page back (Browser)

5 + 2 = Page forward (Browser)

5 + 3 = Mute volume

5 + 4 = Disabled by default

(install the driver to
assign a function)

1

8

3

4

9

2

EASYSHIFT[+]: ASSIGNING DUAL FUNCTIONS TO THE MOUSE BUTTONS

For the fi rst time ever, EasyShif t[+] allows mouse buttons and scr oll-wheel to
perform additional tasks by assigning them two functions. In terms of the way
it works, the Easy Shift [+] but ton is very similar to the Shift key on a keyboard.
For ins tance, if you hold down the EasyShift[+] button on the Kova [+] and press

6

one of the other standard mouse buttons at the same time, you execute a
second function (=dual-assignment).

6

This makes it possible to assign each individual mouse button, as well as all
mousewheel directions (up/down/depressed), not just one, but two indi vidual

7

functions. In doing so, the number of available functions doubles from 8 to 16.

2

8

PRACTICAL MACRO CONTROLS:

A good example of using secondary but ton assignments with the help of Easy­Shif t[+] is when macro controls that are integrated in the driver are selected.

1

Among other examples, here you’ll fi nd multimedia functions which you can use

7

9

3

4

5

Use the EasyShift[+]
button (#5) to access
2nd level functions
on all other mouse
buttons and wheel.

to launch, as well as control, your media player using jus t the mouse. For instance,
the mousewheel can be used to control the volume level as soon as you hold the
EasyShift[+] button depressed.

In keeping with that, the lef t and right mouse bu ttons can then be assigned
‘Previous/Next t rack’ in combination with the EasyShif t [+] button. Doing this

This way you can virtually
duplicate the number of
buttons by assigning two
functions to every single
button.

becomes so intuitive that ROCCAT beta testers no longer wanted to do without
the EasyShif t[+] button after a short while. The best in ergonomics and maximum
functionality can fi nally coexist in harmony.

EasyShift[+] WoW: EasyShift[+] CS:

5 + 1 = Mount up 5 + 1 = Throw HE

5 + 2 = Dismount 5 + 2 = Throw fl ash

5 + 3 = Autorun 5 + 3 = Throw smoke

5 + 4 = Use trinket 5 + 4 = Show scores

5 + 6 = Your macro #1 5 + 6 = Buy CT equipment

5 + 7 = Your macro #2 5 + 7 = Buy T equipment

5 + 8 = Pet attack 5 + 8 = Primary weapon

5 + 9 = Pet follow 5 + 9 = Secondary weapon

EasyShift[+] Multimedia: EasyShift[+] Browser:

5 + 1 = Previous track 5 + 1 = Page back

5 + 2 = Next track 5 + 2 = Page forward

5 + 3 = Mute volume 5 + 3 = New tab

5 + 4 = Switch to full screen 5 + 4 = Add bookmark

5 + 6 = Play or pause 5 + 6 = New window

5 + 7 = Stop playback 5 + 7 = Print page

5 + 8 = Volume up 5 + 8 = Switch to next tab

5 + 9 = Volume down 5 + 9 = Switch to previous tab

DE DK EN ES FI

ANLEITUNG INSTRUKTIONER INSTRUCTIONS INSTRUCCIONES OHJEET

1. Verbinde den USB-Stecker der ROCCAT™ Kova[+] mit
einer freien USB-Schnittstelle.

2

6

2. Starte deinen Computer und stelle eine Verbindung mit
dem Internet her.

3. Gebe in die Adresszeile deines Webbrowsers die folgende
URL ein „www.roccat.org/support“ und drücke Enter.

4. Klicke in der linken Navigationsleiste auf den Punkt
„ROCCAT Kova[+]“. Lade dir auf der sich öffnenden Seite
die neueste Treiber-Software herunter.

5. Starte die Treiber-Installation und folge bitte den weiteren
Anweisungen auf dem Bildschirm.

1. Forbind ROCCAT™ Kova[+] ‚s USB-stik med et ledigt
USB-interface.

2. Start din computer og forbind den med Internettet.

3. Indtast følgende URL i adresselinjen af din webbrowser
„www.roccat.org/support“ og tryk så Enter.

4. Klik i venstre navigantionslinje på punkt „ROCCAT
Kova[+]“. Frau den åbnede side overfører du den nyeste
driversoftware.

5. Start driver-installationen og følg anvisningerne på
billedskærmen.

1. Plug the ROCCAT™ Kova[+]’s USB connector into any
free USB port.

2. Boot your computer and connect to the internet.

3. Enter ‘www.roccat.org/support’ in your browser and
hit the return key.

4. In the navigation bar on the left, go to ‘ROCCAT Kova[+]’.
Download the latest driver from the webpage that opens.

5. Start the driver installation process and follow the
on-screen instructions.

1. Enchufa el conector USB del ROCCAT™ Kova[+] a un
puerto libre USB.

2. Inicia tu ordenador y establece la conexión de Internet.

3. Escribe en tu navegador Web la siguiente URL:
www.roccat.org/support y pulsa Enter.

4. En la barra izquierda de navegación haz clic en el
punto “ROCCAT Kova[+]”. En la página que se abre a
continuación descárga el software de controlador más
actualizado.

5. Inicia la instalación del controlador y sigue las instruccio­nes que aparecen en pantalla.

1. Liitä ROCCAT™ Kova[+]:n USB-pistoke vapaaseen
USB-liitäntään.

2. Käynnistä tietokoneesi ja luo Internet-yhteys.

3. Kirjoita verkkoselaimesi osoiteriville seuraava URL-osoite
„www.roccat.org/support“ ja paina Enter.

4. Napsauta vasemmassa navigaatiopalkissa kohtaa
„ROCCAT Kova[+]“. Lataa avautuvalta sivulta uusin
ajuriohjelmisto.

5. Käynnistä ajurin asennus ja noudata näytöllä näkyviä
lisäohjeita.

5 + 6 = Disabled by default

5 + 7 = Disabled by default

(install the driver to
assign a function)

(install the driver to
assign a function)

5 + 8 = Volume up

5 + 9 = Volume down

5

7

FR PL RU SE

INSTRUCTIONS INSTRUKCJA

1. Relie la fi che USB de la souris ROCCAT™ Kova[+] à une
prise USB libre.

2. Démarre ton ordinateur et connecte-toi à Internet.

3. Entre dans la barre d’adresse de ton navigateur l’URL
« www.roccat.org/support » et appuie sur Enter.

4. Clique dans le menu de navigation de gauche sur
« ROCCAT Kova[+] ». Télécharge la dernière version du
pilote sur la page qui s’ouvre alors.

5. Lance l’installation du pilote et suis les instructions qui
s’affi chent à l’écran.

1. Podłącz wtyk USB ROCCAT™ Kova[+] do wolnego

złącza USB.

2. Uruchom komputer i nawiąż połączenie z Internetem.

3. W wierszu adresowym przeglądarki wpisz adres URL

„www.roccat.org/support“ i naciśnij Enter.

4. W lewym pasku nawigacji kliknij punkt „ROCCAT Kova[+]“.

Z nowo otwartej strony pobierz najnowsze sterowniki.

5. Rozpocznij instalację sterowników i postępuj zgodnie z

instrukcjami na ekranie.

ИНСТРУКЦИИ

1. Соедини USB-штекер ROCCAT™ Kova[+] со свободным

USB-портом.

2. Запусти компьютер и выйди в интернет.

3. Введи в адресной строке браузера адрес

„www.roccat.org/support“ и нажми Enter.

4. Нажми на левой навигационной панели пункт

„ROCCAT Kova[+]“. Загрузи с открывшейся страницы
самые последние драйвера.

5. Запусти инсталляцию драйвера и следуй дальнейшим

указаниям на экране.

INSTRUKTIONER TALIMATLAR

1. Sätt ROCCAT™ Kova[+] USB-kontakt i en ledig USB-port.

2. Starta datorn och koppla upp dig på Internet.

3. Skriv in följande URL i adressfältet på din webbläsare:

4. Klicka på ROCCAT Kova[+] i det vänstra navigationsfältet.

5. Starta installationen av drivrutin och följ anvisningarna

www.roccat.org/support. Tryck på Enter.

Ladda ner den senaste programvaran med drivrutin på
den sida som öppnas.

på skärmen.

TR

1. ROCCAT™ Kova[+] USB fi şini boş bir USB girişine tak.

2. Bilgisayarı başlat ve internete bağlan.

3. Web tarayıcının adres satırına “www.roccat.org/support”

URL adresini gir ve Enter tuşuna bas.

4. Sol navigasyon çubuğundaki “ROCCAT Kova[+]” üzerine

tıkla. Açılan sayfadan en yeni sürücü yazılımını indir.

5. Sürücü kurulumunu başlat ve ekrandaki diğer talimatları

takip et.
