Roadstar CLR-2496P operation manual

is a registered Trademark of Roadstar S.A. - Switzerland All rights reserved

www.roadstar.com

CLR-2496P

Instruction manual
Bedienungsanleitung
Manuel d’instructions
Manuale d’istruzioni
Manual de instrucciones
Manual de instruções

CLR-2496P

INDEX

English Page 1
Deutsch Seite 7
Francais Page 13
Italiano Pagina 19
Español Página 25
Português Pagina 31

 Your new unit was manufactured and assembled

under strict ROADSTAR quality control.

Thank-you for purchasing our product for your
music enjoyment.
Before operating the unit, please read this instruc­tion manual carefully. Keep it also handy for fur­ther future references.

 Votre nouvel appareil a été fabriqué et monté en

étant soumis aux nombreaux tests ROADSTAR.
Nous espérons que cet appareil vous donnera
entière satisfaction.

Avant de vous adonner à ces activités, veuillez
lire attentivement ce manuel d’instructions. Con­servez-le à portée de main à fin de référence
ultérieure.

 Vuestro nuevo sistema ha sido construido según

las normas estrictas de control de calidad ROAD­STAR.

Le felicitamos y le damos las gracias por su elec­ción de este aparado. Por favor leer el manual
antes de poner en funcionamiento el equipo y
guardar esta documentación en case de que se
necesite nuevamente.

 Ihr neues Gerät wurde unter Beachtung der stren-

gen ROADSTAR-Qualitätsvorschriften gefertigt.

Wir danken Ihnen für den Kauf unseres Produktes
und wünschen Ihnen optimalen Hörgenuss. Bitte
lesen Sie diese Bedienungsanleitung durch, und
heben Sie sie auf, um jederzeit darin nachschla­gen zu können.

 Il vostro nuovo apparecchio é stato prodotto ed

assemblato sotto lo stretto controllo di qualità
ROADSTAR.

Vi ringraziamo di aver acquistato un nostro pro­dotto per il vostro piacere d’ascolto.
Prima di procedere all'utilizzo dell'apparecchio,
leggete attentamente il manuale d’istruzioni e
tenetelo sempre a portata di mano per futuri
riferimenti.

 Seu novo aparelho foi construido e montado sob o

estrito controle de qualidade da ROADSTAR.

Agradecemos por ter comprado nosso produto
para a sua diversão.
Antes de usar esta unidade é necessário ler com
atençâo este manual de instruções pare que
possa ser usada apropriadamente; mantenha o
manual ao seu alcance para outras informações.

English English 1 2

LOCATION OF CONTROLS

1. MODE / OFF / ON SWITCH (RADIO)

2. SLEEP BUTTON

3. SET CLOCK BUTTON

4. TUNING DOWN

5. CLOCK LCD DISPLAY

6. MEMO BUTTON

7. VOLUME DOWN

8. VOLUME UP

9. TUNING UP

10. SNOOZE / LIGHT BUTTON

11. ALARM 1 BUTTON

12. ALARM 2 BUTTON

13. IMAGE ROTATION

14. FOCUS PROJECTION

POWERSUPPLY

This unit operates from a main supply of 230V ~ 50Hz. Connect the AC power
cord to the AC household main outlet. Ensure that the voltage
is as indicated on the rating plate on the rear of the unit.

BATTERY BACK-UP POWER FAILURE PROTECTION

This radio has a battery back up circuit that will keep the correct time and alarm
settings in the event of a temporary power interruption. Install a 3V battery (type
CR-2032), not included, into the battery compartment (11) located on the bot-
tom of the unit.

Note: We recommend an alkaline battery for longer usable life. Change the

battery every 9 to 12 months for best result and avoid possible battery leakage.
If power is temporarily interrupted the display will blink and the radio will not
play. However, the battery back-up circuit will continue to maintain the clock and
alarm settings. When power is restored the clock will display the correct time
and alarm settings, and no adjustment is necessary.

Note: If pow er is interrupted and there is no battery in the compartment or

WARNINGS

The exclamation point within the triangle is a warning sign alerting
the user of important instructions accompanying the product.

The lightening flash with arrowhead symbol within the triangle is a
warning sign alerting the user of “dangerous voltage” inside the unit.

To reduce the risk of electric shock, do not remove the cover. No
user serviceable parts inside the unit. Refer all servicing to quali­fied personnel.

This unit operates on 230V ~ 50Hz. If the unit is not used for a
long period of time, remove the plug from the AC mains.

Ensure all connections are properly made before operating the
unit.

This unit must not be exposed to moisture or rain.

This unit should be positioned so that it is properly ventilated.
Avoid placing it, for example, close to curtains, on the carpet or in
a built-in installation such as a bookcase.

Do not expose this unit to direct sunlight or heat radiating sources.

English English 3 4

the battery is exhausted. The time and alarm settings will be lost. When power
is restored the clock will begin to flash indicating that the time and alarm set­tings must be corrected.

DISPLAY

1. Normally the LCD DISPLAY indicates the DATE, which shows the MONTH,
YEAR, TIME and DAY.

2. Press SOOZE / LIGHT button (13) to increase the brightness of the LCD
display.

SETTING THE LCD DISPLAY

1. In the normal Display mode, to set the TIME, keep pressed SET (3) Button
until the 24H digits will flash. Press SCAN + / - (4-9) to adjust the 12/24 di­gits.

2. To set the TIME, press SET (3) once more and the HOUR digits will flash.

Press SCAN + / - (4-9) to adjust the HOUR digits.

3. To set the MINUTE, press SET (3) once more and the MINUTE (3) digits
will flash. Press SCAN + / - (4-9) to adjust the MINUTE digits.

4. To set the YEAR, press SET (3) once more and the Year digits will flash.
Press SCAN + / - (4-9) to adjust the YEAR.

5. To set the MONTH, press SET (3) again and the MONTH digits will flash.
Press SCAN + / - (4-9) adjust the MONTH digit.

6. To set the DAY, press SET (3) again one more and the DAY digit will flash.
Press SCAN + / - (4-9) to adjust the DAY digit.

7. Press the SET (3) button to conclude the setting.

SETTING THE ALARM (BUZZER OR RADIO)

1. In the normal Display mode, press ALARM 1 (7) or ALARM 2 (8) button on-
ce and the display will show the ALARM TIME. The "AL" icon indicates that
the display is showing the ALARM TIME.

2. To set the ALARM TIME, press ALARM 1 (7) or ALARM 2 (8) button for 4
seconds and the OUR digits will flash. Press SCAN + / - (4-9) to adjust the
HOUR digits.

3. To set the ALARM MINUTE, press ALARM 1 (7) or ALARM 2 (8) button
once more and the MINUTE digits will flash. Press SCAN + / - to adjust the
MINUTE digits.

4. To set the BUZZER or RADIO Alarm Mode, press ALARM 1 (7) or ALARM
2 (8) button sequentially to select betwen BI (Buzzer) RAD (Radio) or OFF

mode.

5. To disable the Alarm mode, during normal display mode keep press se-
quentially the Alarm 1 (7) or Alarm 2 (8) buttons seconds until OFF compare
in the display.

DIMMER FUNCTION

Press quickly the SNOOZE/LIGHT (2) button to change the Display intensity.

LED BACKLIGHT

When it is not in the wake up time, the SNOOZE/LIGTH button is for tuning on

the LCB Backlight & Time Projector.

1. Press once for the light ON for 60 seconds.

2. Press and Hold for the lights always ON. LCD backlight will flash once for
indication. Press & hold again until the LCD flash once then release to disa­bling this function.

FM PLL RADIO

1. Make sure the antenna wire (10 is completely unrolled and extended.

2. In normal clock mode, press the MODE button (1) to switch on the radio.

3. Press the SCAN + / - (4-9) button to search for the station. Short press mo-
de is MANUAL research, press and hold that the search mode is automatic.

4. To save the channel, press the MEMO (3 ) 5 seconds toenter the memory

of the radio station , then press SCAN + / - (4-9) to select the desired chan­nel number where you want to save the station.

5. After selecting the desired channel , press the MEMO button (3) to confirm
the location of the memory.

6. To recall radio stations , press the MEMO button (3) sequentially until the
desired channel is displayed.

English English 5 6

TIME PROJECTOR

Time projector could be adjusted by scrolling the FOCUS & IMAGE ROTATION.
Scroll the FOCUS (14) for tuning the clear time projection image. Scroll the IMA­GE ROTATING (13) for tuning the best time projection angle.

SNOOZE FUNCTION

When the alarm sounds, pressing the SNOOZE Button (2) will temporary stop
about 9 minutes then the alarm sounds again.

SLEEP FUNCTION

This function enables you to go to sleep listening to the Radio.

1. Press the SLEEP Button (2). The clock display will show 90 minutes. The
Radio turns on and will turn off automatically after 90 minutes.

2. To select a shorter time press the SLEEP Button (2) while holding until the
desired sleep time is displayed.

3. To turn off the Radio at any time during the Sleep period, press the SNOO-
ZE Button (2).

CARE AND MAINTENANCE

To prevent fire or shock hazard, do not allow this clock radio to be exposed to
rain or moisture.
This clock radio should not be exposed to direct sunlight, very high or low tem­perature, moisture, vibration, or placed in a dusty environment. Do not use abra­sives, benzine, thinners, or other solvents to clean the surfaces of the clock ra­dio. To clean it, wipe with a mild non-abrasive detergent solution on a clean soft
cloth.
Never attempt to insert wires, pins, or other objects into the venlilation holes or
openings on the clock radio.

AC POWER

For your own safety read following instructions carefully before attempting to
connect this clock radio to the mains.
This unit is designed to operate on a 230V~50Hz supply onl. Connecting it to
other power sources may damage it.
Ensure that supply corresponds to the information on the rating label on the
bottom of the unit.

RESET (RESET OPERATION)

Remove the memory Back- Up battery and cord for three minutes.

SPECIFICATIONS

FM Band: 87,5 to 108 MHz
Power Supply: 230VAC, 50 Hz
Back-up Battery: 3V CR-2032 (not included)
Specifications subject to change without notice.

This marking shown on the product or its literature, indicates that it should not be di­sposed with other household wastes at the end of its working life. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources. Househol d users shoul d contact ei ther the
retai l er where they purchased this product, or their local government office, for details
of where and how they can take this item for environmentally safe recycling. Business
users should contact their supplier and check the terms and conditions of the purchase
contract. This product should not be mixed with other commercial wastes for disposal.

Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)

Deutsch Deutsch 7 8

LAGEDERBEDIENUNGSELEMENTE

1. MODE / EIN / AUS (RADIO) -TASTE

2. SLEEP-TASTE

3. UHREINSTELLUNG-TASTE

4. RÜCKWÄRTS-TUNING

5. LCD-UHR-DISPLAY

6. MEMO-TASTE

7. LAUTSTÄRKE-REGLER (-) -TASTE

8. LAUTSTÄRKE-REGLER (+) -TASTE

9. TUNING-UP-TASTE

10. SNOOZE / LIGHT-TASTE

11. ALARM 1-TASTE

12. ALARM 2-TASTE

13. BILDDREHUNG-TASTE

14. BILDSCHÄRFE-TASTE

SPEISUNG

Dieses Gerät funktioniert mit Netzstrom von 230V ~ 50Hz. Schließen Sie das
AC-Netzkabel an eine AC-Netzsteckdose an. Vergewissern Sie sich, daß die
Spannung mit der auf dem Typenschild angegebenen

ANZEIGE

1. Normalerweise wird die LCD-Anzeige zeigt das Datum, die den Monat,
Jahr, Tag und Uhrzeit zeigt.

2. Drücken Sie die SNOOZE/LIGHT-Taste (13), um die Helligkeit des LCD­Displays zu erhöhen.

LCD-ANZEIGE EINSTELLEN

1. Im normalen Anzeigemodus, um die 12/24 einzustellen, gedrückt halten die
SET (3)-taste, bis die 12/24 blinkt. Drücken Sie SCAN + / -(4-9), um die
12/24 anzupassen.

2. Um den Stundenanzeige einzustellen, drücken Sie SET (3) taste noch ein­mal und der Zeit blinken. Drücken Sie SCAN + / - (4-9) um dieStundenziffer.

SICHERHEITSHINWEISE

Das Ausrufszeichen im Dreieck weist den Benutzer auf
wichtige Bedienungs- und Wartungsanweisungen (Service)

in diesem Handbuch hin, die unbedingt zu befolgen sind.

Um die Gefahr elektrischer Schläge auszuschliessen,
Gehäuse auf keinen Fall abnehmen.

Im Innem befinden sich keine vom Benutzer selbst instand­setz-baren Teile. Reparaturen dürfen nur von einer autori­sierten Fachwerkstatt durchgeführt werden.

Dieses Gerät ist für 230V ~ 50Hz Netzspannung ausgelegt.
Bei längerer Nichtbenutzung des Geräts ziehen Sie den
Stecker aus der Steckdose.

Setzen Sie das Gerät weder Feuchtigkeit noch Regen aus.

Schalten Sie das System erst dann ein, wenn Sie alle Ver­bindungen genau geprüft haben.

Stellen Sie das Gerät so auf, dass immer eine ungestörte
Frischluftzufuhr sichergestellt ist. Es ist zum beispiel kei­nesfalls auf Teppiche und in der Nähe von Gardinen zu stel­len oder in Bücherregale einzubauen.

Setzen Sie das Gerät weder direkter Sonneneinstrahlung
noch Wärmequellen aus.
