Roadmaster VKC140 User Manual

Main Menu

GIVE US A CALL, WE'LL HELP YOU INSTALL.

1-800-445-1797

PLEASE DO NOT RETURN PRODUCT TO STORE.

Visit us on the WEB

www.vr-3.com

For Information and Technical Assistance,

Call Toll-Free in U.S.A. and Canada.

Power OFF
Delete Image
Display Mode
Clock Set
Clock Display
Language
Exit

Fig. 1

Auto Slide
Manual Slide

Fig. 2

Photo Key chain

USB Cable

Photo Viewer Ver 2.4 CD

PhotoViewer Browser

The PhotoViewer browser is divided in half.
The computer’s window is on the left side, and
the VKC140’s window is on the right side.
Each Window has its own icons for performing
functions related to it.

If the VKC140 is disconnected from the com­puter, then re-connected, the software must be
re-started.

Charging The Battery

USB Charge

USB Connect

Fig. 6

Computer VKC140

Auto Slide Time

05 Seconds

Fig. 3

2007-08-07

14:21:07

Saturday

Fig. 4

The battery will have a nominal charge from the factory. We recommend fully charging
the unit before use.

1. To charge the unit’s battery, insert the supplied USB cable into your computers USB
port, then insert the other end into the port on the side of the VKC140. The VKC140 will
display the photos that are stored on it while charging.
The battery takes about 3.5 hours to charge. The battery will last up to 5 hours on a single
charge.

2. After the battery is charged disconnect the unit.

3. Press the power button once to access the menu.

3. Use the Up & Down button to navigate the menu to Power OFF, then press the Power/
Select button once to shut the unit off.

GIVE US A CALL, WE'LL HELP YOU INSTALL.

1-800-445-1797

PLEASE DO NOT RETURN PRODUCT TO STORE.

Visit us on the WEB

www.vr-3.com

For Information and Technical Assistance,

Call Toll-Free in U.S.A. and Canada.

Language Select

English

French

Fig. 5

Folder List

(On computer)

Selection Area

(Red Dotted Line)

Preview
Pane

Computer Drive Drop Down Menu

Creates Largest Selection Area
Deletes Selection Area
Rotates Preview 90° Clockwise

Rotates Preview 90° Counter Clockwise

Chooses Preview to Move to VKC140

File List

(On computer)

Saves a photo to your computer
Deletes photo from VKC140
Rotates photo 90° clockwise
Rotates photo 90° counter clockwise

Synchronizes
computer
with VKC140

VKC140
Preview
Pane
