RIGOL
Quick Guide
Oscilloscope
RIGOL TECHNOLOGIES, INC.
Jun. 2017
RIGOL
English

Guaranty and Declaration

Copyright
© 2017 RIGOL TECHNOLOGIES, INC. All Rights Reserved.
Trademark Information
RIGOL is a registered trademark of RIGOL TECHNOLOGIES, INC.
Publication Number
QGA23101-1110
Notices
RIGOL products are co vere d by P.R.C. and forei gn patents, issued and
pending.
RIGOL reserves the right to modify or change parts of or all the
specifications and pricing policies at the company’s sole decision.
Information in this publication replaces all previously released materials. Information in this publication is subject to change without notice. RIGOL shall not be liable for either incidental or consequential losses in
connection with the furnishing, use, or perform a nce of this manual, as well as any information contained.
Any part of this document is forbidden to be copied, photocopied, or
rearranged without prior written approval of RIGOL.
Product Certification
RIGOL guarantees that this product conforms to the national and industrial standards in China as well as the ISO9001:2008 standard and the ISO14001:2004 standard. Other international standard conformance certifications are in progress.
Contact Us
If you have any problem or requirement when using our products or this manual, please contact RIGOL. E-mail: service@rigol.com Website: www.rigol.com
DS2000E Quick Guide 1
RIGOL
English
WARNING
CAUTION
DANGER
It calls attention to an operation, if not correctly performed,

General Safety Summary

1. Only the exclusive power cord designed for the instrument and authorized for use within the local country could be used.
2. Ensure that the instrument is safely grounded.
3. Observe all terminal ratings.
4. Use proper overvoltage protection.
5. Do not operate without covers.
6. Do not insert objects into the air outlet.
7. Use the proper fuse.
8. Avoid circuit or wire exposure.
9. Do not operate the instrument with suspected failures.
10. Provide adequate vent il at io n .
11. Do not operate in wet conditions.
12. Do not operate in an explosive atmosphere.
13. Keep instrument surfaces clean and dry.
14. Prevent electrostatic impact.
15. Handle with caution.

Safety Notices and Symbols

Safety Notices in this Manual:
Indicates a potentially hazardous situation or pr actice which, if not avoided, will result in serious injury or death.
Indicates a potentially hazardous situation or practice which, if not avoided, could result in damage to the product or loss of important data.
Safety Terms on the Product:
could result in injury or hazard immediately.
WARNING It calls attention to an operation, if not correctly performed,
could result in potential injury or hazard.
CAUTION
2 DS2000E Quick Guide
It calls attention to an operation, if not correctly performed, could result in damage to the product or other devices connected to the product.
English
Safety Symbols on the Product:
RIGOL
Hazardous
Voltage
Warning
Safety
Protective Earth
Terminal
Chassis Ground Test Ground

Care and Cleaning

Care
Do not store or leave the instrument where it may be exposed to direct sunlight for long periods of time.
Cleaning
Clean the instrument regularly according to its operating conditions.
1. Disconnect the instrument from all power sources.
2. Clean the external surfaces of the instrument with a soft cloth dampened with mild detergent or water. When cleaning the LCD, take care to avoid scarifying it.
CAUTION
To avoid damage to t he instrument, do not expose it to c austic liquids.
WARNING
To avoid short-circuit resulting from moisture or personal injuries, ensure that the in strum en t is c om pletely dry b efore c onn ect ing it to the power supply.
DS2000E Quick Guide 3
RIGOL
English
Tip
RIGOL
Model
Analog Bandwidth
No. of Channels

Document Overview

This manual gives you a quick review about the front and rear panel of DS2000E series, the user interface, and the basic operation method.
For the latest version of this manual, download it from the official website of
Format Conventions in this Manual
1. Front panel key: The key on the front pane l is denoted by the f orm a t of "Key Name (Bold) + T ext Box" in the manual. For example, Utility indicates the "Utility" key on the front panel.
2. Menu softkey: The menu softkey is denoted by the format of "Menu Word (Bold) + Character Shading". For example, System denotes the "System" menu softkey under Utility.
3. Operation step: The next step of operation is denoted by an arrow "". For example, Utility System denotes that first press Utility, and then press the System softkey.
Content Conventions in this Manual
DS2000E series includes the following models. Unless otherwise specified, this manual takes DS2202E as an example to introduce DS2000E series and its basic operations.
(www.rigol.com).
DS2102E 100 MHz DS2202E 200 MHz 2
4 DS2000E Quick Guide
2
English

General Inspection

1 Inspect the packaging
If the packaging has been damaged, do not dispose the damaged packaging or cushioning materials until the shipment has been check e d for completeness and has passed both electrical and mechanical tests.
The consigner or carrier shall be liable for the damage to the instrument resulting from shipment. RIGOL would not be responsible for free maintenance/rework or replacement of the instrument.
2 Inspect the instrument
In case of any mechanical damage, missing parts, or failure in passing the electrical and me chanical tests, contact your RIGOL sales representative.
3 Check the accessories
Please check the accessories according to the packing lists. If the accessories are damaged or incomplete, please contact your RIGOL sales representative.
RIGOL
DS2000E Quick Guide 5
RIGOL
English
20 19 18 17 16 15 14 13 12 11

Product Over v iew

Based on the UltraVision technology, DS2000E is a digital oscilloscope with high performance. It is equipped with extremely high memory depth, wide dynamic range, superb waveform capture rate, and comprehensive trigger functions. It also features hardware waveform recording function and good display effects. As a rare debugging instrument, it has been widely applied to various industries and fields, such as communications, aerospace, defense, embedded systems, computers, research, and education. It is the excellent representative of the 200 MHz digital oscilloscope type with the most comprehensive functions and excellent specifications.
For descriptions of the front panel, refe r to Figure 1 and Table 1; for descriptions of the rear panel, refer to Figure 2 and Table 2; and for descriptions of the main interface (display screen), refer to Figure 3 and Table
3.
1 2 3 4 5 6 7 8 9 10
Figure 1 Front Panel
6 DS2000E Quick Guide
English
Table 1 Front Panel Description
No.
Description
No.
Description
Help/Print Key
Power Key
RIGOL
1 Measurement Menu Softkeys 11
2 LCD 12
Compensation Signal Output
Terminal/Ground Terminal
External Trigger Input
Terminal
3 Multi-function Knob 13 Trigger Control Area 4 Function Keys 14
5 Navigation Knob 15
Waveform
Recording/Playback Keys
Analog Channel Input
Terminals 6 Clear Key 16 Vertical Control Area 7 AUTO Key 17 Function Menu Softkeys 8 Run/Stop Key 18 Horizontal Control Area 9 Single Trigger Control Key 19 USB HOST Interface
10
20
1 2 3
7 6 5 4
Figure 2 Rear Panel
DS2000E Quick Guide 7
RIGOL
English
No.
Description
15 14 13 12 11
Table 2 Rear Panel Description
1 2 3 4
USB DEVICE Interface
Trigger Output Interface 5 6 7
AC Power Cord Connector
Handle
LAN Interface
Lock Hole
Fuse
1 2 3 4 5 6 7 8 9 10
Figure 3 User Interface
8 DS2000E Quick Guide
English
Table 3 User Interface Icons
No.
Description
No.
Description
Analog Channel Label
and Waveforms
RIGOL
1 2 Company Logo 10 Trigger Setting
3 4 Operating Status 12 Notification Area
5 Horizontal Time Base 13 Message Box 6 7 Wavef orm Memory 15 CH1 Status Label
8 Trigger Position
Auto Measurement
Option
Sample Rate and
Memory Depth
9 Horizontal Position
11 Operation Menu
14 CH2 Status Label

To Prepare for Use

To Adjust the Supporting Legs
Adjust the supporting legs properly to use them as stands to tilt the oscilloscope upwards for stable placement of the oscilloscope as well as better operation and observation.
DS2000E Quick Guide 9
Figure 4 T o Adjust the Supporting Legs
RIGOL
English
To Connect to AC Power
The power requirements of the oscilloscope are 100-240 V, 45-440 Hz. Please use the power cord provided in the accessories to connect the oscilloscope to the AC power source, as shown in the figure below. After you turn on the power switch, the oscilloscope is connected to power, and the Power key located at the lower left corner of the front panel
is blinking.
Power Cord Connector
Figure 5 T o Connect to AC Power
Turn-on Checkout
When the oscilloscope is connected to power, press the Power key at the lower-left corner of the front panel to start the oscilloscope. During the start-up process, the oscilloscope performs a series of self-tests. You can hear the switching sound of the relay. After the self-test, the welcome screen is displayed. The "Current Options" dialog box will be displayed if your instrument currently has installed the trial versions of the options. From this dialog box, you can view the type, the name, the version, and the remaining trial time of the option currently installed. The instrument is installed with the trial versions of the options before leaving factory. Its remaining trial time is about 2,000 minutes.
10 DS2000E Quick Guide
RIGOL
English
To Connect the Probe
RIGOL's DS2000E series is equipped with a passive probe. For details about the models of the probe, refer to information of the probes, please refer to the corresponding Probe User’s Guide.
To Connect the Probe:
1. Connect the BNC terminal of the probe to an analog channel input of the oscilloscope at the front panel.
2. Connect the ground alligator clip of the probe to the circuit ground terminal and then connect the probe tip to the circuit point under test.
DS2000E DataSheet
. For detailed technical
Figure 6 T o Connect the Probe
DS2000E Quick Guide 11
RIGOL
English
Function Inspection
1. Press Storage Default to restore the oscilloscope to its default configuration.
2. Connect the ground alligator clip of the probe to the "Ground Terminal" as shown in the figure below.
3. Use the probe to connect the input terminal of CH1 of the oscilloscope and the "Compensation Signal Output Terminal" of the probe.
Compensation Signal Output Terminal
Ground Terminal
Figure 7 Compensation Signal Output Terminal /Ground Terminal
4. Set the probe attenuation to 10X, and then press AUTO.
5. Observe the waveform on th e display. In normal condition, the squ are waveform as shown in the figure below should be displayed.
Figure 8 Square Waveform Signal
6. Use the same method to test the other channels. If the square waveforms actually show n do not match that in the figure abo ve, please perform "Probe Compensation" introduced in the next section.
12 DS2000E Quick Guide
RIGOL
English
to high voltage source.
Tip
WARNING
To avoid electric shock when using the probe, please make sure that the insulated wire of the probe is in good condition. Do not touch the metallic part of the probe when the probe is connected
The probe compensation signal can only be used for probe compensation adjustment and cannot be used for calibration.
Probe Compensation
When the probes are used for the first time, you should compensate the probes to make them match the input channels of the oscilloscope. Non-compensated or poorly compensated probes may cause measurement inaccuracy or errors. The probe compensation procedures are as follows:
1. Perform Step 1, 2, 3, and 4 in "Function Inspection".
2. Check the displayed waveforms and compare them with the following figures.
Over compensated Perfectly compensated Under compensated
3. Use a nonmeta llic sc rew dri ver to adju st the lo w-frequen cy co mpen sat ion adjustment hole on the probe until the waveform is displayed as "Perfectly compensated" in the figure above.
DS2000E Quick Guide 13
Figure 9 Probe Compensation
RIGOL
English
Help Options Help Display Area

To Use the Built-in Help System

The help system of this oscilloscope provides instructions for all the function keys (including the menu keys) on the front panel. Press Help to open the help interface. Press it again to close the interface. The help interface mainly consists of two sections. The left section is "Help Options", and you can select the "Button" or "Index" tab. The right section is "Help Display Area", which displays the help information.
Figure 10 Help Information
Button:
By default, the "Button" tab is selected. Under the tab, you can view the corresponding help information in the "Help Display Area" by pressing the keys or menu softkeys (except the Power key the Page Up/Down key
multi-function knob to select the desired key name (the item currently selected is displayed with brown shading) in the "Help Options" area and then pressing down the knob.
To switch to the Index tab, use the multi-function knob Index" and then press down the knob.
14 DS2000E Quick Guide
/ ) on the front p a ne l di rectly or rotating the
, the multi-function knob , and
to select "To
RIGOL
English
Index:
Under the tab, you can use the multi-function knob
to select the desired item (e.g. BW). The item currently selected is displayed with brown shading in the "Help Options" area. Then press down the knob to obtain the help information about the item.
To switch to the Button tab, use the multi-function knob
to select "To
Button" and then press down the knob.
DS2000E Quick Guide 15
RIGOL
English
Tip

Parameter Setting Method

The commonly used parameter setting methods for the DS2000E series are follows:
Method 1: For the parameters with the sign
on the front panel directly to select the parameter item or modify the
parameter value.
Method 2: For the parameters with the sign
on the front panel to select one item from the available choices, and then press down the multi-function knob
Method 3: For the parameters with the sign panel to increase or decrease the value of the para meter. Use the inner knob to make a fine adjustment, the outer knob to make a coarse adjustment.
Method 4: For the parameters without the above signs, press the desired menu softkey to switch between the parameter items. This method is applicable to the parameters with only two available options.
or , rotate the multi-function knob
, first rotate the multi-function knob
to select the item.
, rotate the navigation knob on the front
The above methods are commonly used in parameter settings. For other setting methods of certain parameters, refer to details in relevant chapters of
DS2000E User's Guide
16 DS2000E Quick Guide
.
RIGOL
English

Remote Control

DS2000E series digital oscilloscope can be connected to the PC via the USB, LAN, or GPIB interface to set up communication and realize remote control through the PC. The remote control can be realized by using SCPI (Standard Commands for Programmable Instruments) commands. DS2000E series digital oscilloscope supports two ways of remote control: user-defin ed programming and PC software (e.g. RIGOL Ultra Sigma).

More Product Information

1. Obtain the device information
Press Utility System System Info to obtain the information of the instrument, including the manufacturer, model, serial number, software version number, and hardware version number.
2. Check the option installation status
Press Utility Options Installed to view the options currently installed on the oscilloscope and their information. Press Setup to enter the option activation operation menu and input the serial number of the option that you've purchased.
For more information about this instrument, refer to the relevant manuals by logging in to the official website of RIGOL (
DS2000E User's Guide
operation methods, remote control methods, possible failures and solutions in using the instrument, the technical specifications, and order information;
DS2000E Programming Guide
commands and programming examples of the instrument.
DS2000E Datasheet
the instrument.
: introduces the functions of the instrument and the
: provides detailed descriptions of SCPI
: provides the main features and technical specifications of
www.rigol.com) t o download the m.
DS2000E Quick Guide 17
中文
RIGOL
快速指南
DS2000E 系列数字示波器
RIGOL TECHNOLOGIES, INC.
2017 6
RIGOL
中文

保证和声明

版权
© 2017 北京普源精电科技有限公司
商标信息
RIGOL 是北京普源精电科技有限公司的注册商标。
文档编号
QGA23001-1110
声明
本公司产品受中国及其他国家和地区的专利(包括已取得的和正在申请的
专利)保护。
本公司保留改变规格及价格的权利。 本手册提供的信息取代以往出版的所有资料。 本手册提供的信息如有变更,恕不另行通知。 对于本手册可能包含的错误,或因手册所提供的信息及演绎的功能以及因
使用本手册而导致的任何偶然或继发的损失,RIGOL 概不负责。
未经 RIGOL 事先书面许可,不得影印、复制或改编本手册的任何部分。
产品认证
RIGOL 认证本产品符合中国国家产品标准和行业产品标准及 ISO9001:2008 准和 ISO14001:2004 标准,并进一步认证本产品符合其他国际标准组织成员的 相关标准。
联系我们
如您在使用此产品或本手册的过程中有任何问题或需求,可与 RIGOL 联系: 电子邮箱:service@rigol.com 网址:www.rigol.com
DS2000E 快速指南 1
RIGOL
中文
1.
9.
警告 注意
WARNING
CAUTION

一般安全概要

请使用所在国家认可的本产品
专用电源线。
2. 请确保产品可靠接地。
3. 查看所有终端额定值。
4. 请使用合适的过压保护。
5. 请勿开盖操作。
6. 请勿将异物插入排风口。
7. 请使用合适的保险丝。
8. 避免电路外露。

安全术语和符号

本手册中的安全术语:
警告性声明指出可能会造成人身伤害或危及生命安全的情况或操 作。
注意性声明指出可能导致本产品损坏或数据丢失的情况或操作。
产品上的安全术语:
DANGER
产品上的安全符号:
表示您如果不进行此操作,可能会立即对您造成危害。 表示您如果不进行此操作,可能会对您造成潜在的危害。 表示您如果不进行此操作,可能会对本产品或连接到本产品 的其他设备造成损坏。
怀疑产品出故障时,请勿进行操
作。
10. 请保持适当的通风。
11. 请勿在潮湿环境下操作。
12. 请勿在易燃易爆的环境下操作。
13. 请保持产品表面的清洁和干燥。
14. 请注意防静电保护。
15. 请注意搬运安全。
高电压
2 DS2000E快速指南
安全警告
保护性接地端
壳体接地端
测量接地端
RIGOL
中文
注意
警告

保养与清洁

保养 请勿将仪器放置在长时间受到日照的地方。
清洁 请根据使用情况定期对仪器进行清洁。方法如下:
1. 断开电源。
2. 用柔和的清洁剂或清水浸湿软布擦拭仪器外部。清洁带有液晶显示屏的仪
器时,请注意不要划伤液晶显示屏。
请勿使任何腐蚀性的液体沾到仪器上,以免损坏仪器。
重新通电之前,请确认仪器已经干透,避免因水分造成电气短路甚 至人身伤害。
DS2000E 快速指南 3
RIGOL
中文
提示
型号
模拟带宽
通道数

文档概述

本文档用于指导用户快速了解DS2000E系列数字示波器的前后面板、用户界面 及基本操作方法等。
本手册的最新版本可登陆 RIGOL 网址(www.rigol.com)进行下载。
文档格式的约定
1. 前面板按键:用带文本框的字符表示,例如:Utility
2. 菜单软键:用带底纹并加粗的文本表示,例如:系统
3. 操作步骤:用箭头“”表示,例如:Utility 系统
文档内容的约定
DS2000E系列数字示波器包含以下型号。如无特殊说明,本手册以DS2202E 例说明DS2000E系列及其基本操作。
DS2102E 100 MHz DS2202E 200 MHz 2
4 DS2000E快速指南
2
中文

一般性检查

1 检查运输包装
如运输包装已损坏,请保留被损坏的包装或防震材料,直到货物经过完全 检查且仪器通过电性和机械测试。
因运输造成仪器损坏,由发货方和承运方联系赔偿事宜。RIGOL公司恕不 进行免费维修或更换。
2 检查整机
若存在机械损坏或缺失,或者仪器未通过电性和机械测试,请联系您的 RIGOL 经销商。
3 检查随机附件
请根据装箱单检查随机附件,如有损坏或缺失,请联系您的RIGOL经销商。
RIGOL
DS2000E 快速指南 5
RIGOL
中文
编号
说明
编号
说明
5
15
1
2
3 4 5 6 7 8 9 10

产品简介

DS2000E 系列是一款基于 UltraVision 技术的高性能数字示波器,它具有极高的 存储深度、超宽的动态范围、优异的波形捕获率和全面的触发功能,同时兼具硬 件波形录制功能和良好的显示效果,是通信、航天、国防、嵌入式系统、计算机、 研究和教育等众多行业和领域不可多得的调试仪器,是 200 MHz 带宽以内数字 示波器中功能最齐全、指标最为优秀的代表。
前面板、后面板和主界面(显示屏)的简要介绍请分别参考图 1(具体说明见表
1)、图 2(具体说明见表 2)和图 3(具体说明见表 3)。
20 19 18 17 16 15 14 13 12 11
1 前面板
1 前面板说明
1 测量菜单软键 11 探头补偿信号输出端/接地端 2
LCD
12 外触发输入端 3 多功能旋钮 13 触发控制区 4 功能按键 14 波形录制/回放控制键
导航旋钮
6 DS2000E快速指南
模拟通道输入端
RIGOL
中文
6
16
8
18
编号
说明
1
6
全部清除键
垂直控制区
7 波形自动显示 17 功能菜单软键
9
10
运行/停止控制键
单次触发控制键
19
内置帮助/打印键 20 电源键
水平控制区
USB HOST 接口
1 2 3
7 6 5 4
2 后面板
2 后面板说明
手柄
2 LAN 接口 3 USB DEVICE 接口 4 触发输出接口 5 锁孔
保险丝
7 AC 电源连接器
DS2000E 快速指南 7
RIGOL
中文
编号 说明
编号
说明
1
9
3
11
5
13
1 2 3 4 5 6 7 8 9 10
15 14 13 12 11
3 用户界面
3 用户界面标识
自动测量选项
水平位移
2 公司商标 10 触发设置
通道标签和波形
操作菜单
4 运行状态 12 通知区域
水平时基
消息框
6 采样率和存储深度 14 CH2 状态标签 7 波形存储器 15 CH1 状态标签 8 触发位置
8 DS2000E快速指南
RIGOL
中文

使用前准备

调节支撑脚
适当的调整支撑脚,将其作为支架使示波器向上倾斜,以稳定放置示波器,便于 更好的操作和观察显示屏。
4 调节支撑脚
连接电源
本示波器可输入交流电源的规格为:100-240 V,45-440 Hz。请使用附件提供的 电源线按下图所示将示波器连接到电源中。示波器处于通电状态,前面板左下角 的电源键
呈呼吸状态。
电源插孔
5 连接电源
DS2000E 快速指南 9
RIGOL
中文
开机检查
当示波器处于通电状态时,按前面板左下角的电源键 即可启动示波器。开 机过程中示波器执行一系列自检,您可以听到继电器切换的声音。自检结束后出 现开机画面,如果您的仪器安装有选件的试用版本,屏幕将弹出“当前选件”对 话框,您可以查看当前安装的选件类型、选件名称、选件版本和剩余时间。仪器 出厂时我们将为用户提供选件的试用版本,剩余时间约为 2000 分钟。
连接探头
RIGOL DS2000E 系列示波器提供无源探头,探头的具体型号请参考DS2000E 系列数据手册》。有关探头的详细技术信息请参考相应的探头用户 手册。
连接探头:
1. 将探头的 BNC 端连接至示波器前面板的模拟通道输入端。
2. 将探头接地鳄鱼夹连接至电路接地端,将探针连接至待测电路测试点。
6 连接探头
10 DS2000E 快速指南
RIGOL
中文
警告
提示
功能检查
1. 按 Storage 默认设置,将示波器恢复为默认配置。
2. 将探头的接地鳄鱼夹连接至如下图所示的“接地端”。
3. 使用探头连接示波器的通道 1(CH1)输入端和“补偿信号输出端”。
补偿信号输出端 接地端
7 补偿信号输出端/接地端
4. 将探头衰减比设定为 10X,然后按 AUTO 键。
5. 观察示波器显示屏上的波形,正常情况下应显示下图所示的方波:
8 方波信号
6. 用同样方法检查其他通道。如实际显示的方波形状与上图不相符,请执行
下一节“
探头补偿”。
为避免使用探头时被电击,请首先确保探头的绝缘导线完好,并 且在连接高压源时不要接触探头的金属部分。
探头补偿信号仅作探头补偿调整之用,不可用于校准。
DS2000E 快速指南 11
RIGOL
中文
探头补偿
首次使用探头时,应进行探头补偿调节,使探头与示波器输入通道匹配。未经 补 偿或补偿偏差的探头会导致测量误差或错误。探头补偿步骤如下:
1. 执行上一节“
2. 检查所显示的波形形状并与下图对比。
补偿过度
3. 用非金属质地的改锥调整探头上的低频补偿调节孔,直到显示的波形如上 图“补偿正确”。
功能检查”中的步骤 123 4
补偿正确
9 探头补偿
补偿不足
12 DS2000E 快速指南
RIGOL
中文

使用内置帮助系统

本示波器的帮助系统提供了前面板各功能键(包括菜单键)的说明。按 Help 键 打开帮助界面,再次按下则关闭。帮助界面主要分两部分,左边为“帮助选项”, 可使用“Button”或“Index”方式选择,右边为“帮助显示区”。
Button
默认方式。该方式下,您可以直接按前面板上的按键(电源键 、多功能旋 钮 和菜单翻页键 / 除外),或者旋转多功能旋钮 选择按键名
称,即可在“帮助显示区”中获得相应的帮助信息。 旋转多功能旋钮
Index
该方式下,使用多功能旋钮 选择需要获得帮助的选项(例如“带宽限制”), 当前选中的选项显示为棕色,按下旋钮,即可在“帮助显示区”中获得相应的帮 助信息。
旋转多功能旋钮
帮助选项 帮助显示区
图 10 帮助信息
方式:
选择“To Index”后按下旋钮可切换到 Index 方式。
方式:
选择“To Button”后按下旋钮可切换到 Button 方式。
DS2000E 快速指南 13
RIGOL
中文
提示

参数设置方法

DS2000E 系列数字示波器常用的参数设置方法如下。
方法一: 对于菜单上显示
选择参数项或修改参数值。
方法二: 对于菜单上显示 的参数,请首先旋转前面板上的多功能旋钮 进行选
择,然后再按下多功能旋钮
方法三: 对于菜单上显示 内层旋钮可微调,外层旋钮可粗调。
方法四: 对于菜单上无图标显示的参数,直接按相应的菜单软键即可切换设置所需的参数 (此方法适用于只有两个可选选项的参数)。
上述方法是示波器常用的参数设置方法。若某些参数有其他设置方法,将在 《DS2000E系列用户手册》的相关章节中详细介绍。
的参数,直接旋转前面板上的多功能旋钮 即可
选中参数。
的参数,表示可旋转前面板上的导航旋钮增大或减小数值;
14 DS2000E 快速指南
RIGOL
中文

远程控制

DS2000E 系列数字示波器支持通过 USB 接口、LAN 接口和 GPIB 接口与计算机 进行通信从而实现远程控制。远程控制基于 SCPIStandard Commands for Programmable Instruments)命令集实现。DS2000E 系列数字示波器支持两种 远程控制方式:用户自定义编程和使用 PC 软件(如 RIGOL Ultra Sigma)。

更多产品信息

1. 获取设备信息
Utility 系统 系统信息,您可获取设备信息,包括厂商、产品型 号、产品序列号和软硬件版本号。
2. 查看选件安装状态 Utility 选件,按 当前选件 软键,可查看示波器当前已安装的选件 及其相关信息;按 选件安装 软键,输入新购买的选件序列号进行选件安 装。
欲了解本产品更多信息,请查阅相关手册(您可登录RIGOL网站
www.rigol.com)下载)。
( 《DS2000E系列用户手册》:提供本产品的功能介绍及操作方法、远程控制方 法、在使用过程中可能出现的故障及处理方法、性能指标以及订货信息。 《DS2000E系列编程手册》:提供本产品的SCPI命令集以及编程实例。
DS2000E系列数据手册》:提供本产品的主要特色和技术指标。
DS2000E 快速指南 15
Loading...
