Printer/Scanner Unit

Preparing the Machine

Setting Up the Printer Driver

Type 2500

Operating Instructions

Printer Reference

Other Print Operations

Appendix

Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use, be sure to read the

Safety Information in "About This Machine" before using the machine.

Introduction

This manual contains detailed instructions and notes on the operation and use of this machine. For your safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy place for quick reference.

Important

Contents of this manual are subject to change without prior notice. In no event will the company be liable for direct, indirect, special, incidental, or consequential damages as a result of handling or operating the machine.

Do not copy or print any item for which reproduction is prohibited by law.

Copying or printing the following items is generally prohibited by local law:

bank notes, revenue stamps, bonds, stock certificates, bank drafts, checks, passports, driver's licenses.

The preceding list is meant as a guide only and is not inclusive. We assume no responsibility for its completeness or accuracy. If you have any questions concerning the legality of copying or printing certain items, consult with your legal advisor.

Notes:

Some illustrations in this manual might be slightly different from the machine.

Certain options might not be available in some countries. For details, please contact your local dealer.

Two kinds of size notation are employed in this manual. With this machine refer to the inch version.

Caution:

Use of controls or adjustments or performance of procedures other than those specified in this manual might result in hazardous radiation exposure.

Manuals for This Machine

Refer to the manuals that are relevant to what you want to do with the machine.

Important

❒ Media differ according to manual.

❒ The printed and electronic versions of a manual have the same contents.

❒ Adobe Acrobat Reader/Adobe Reader must be installed in order to view the

manuals as PDF files.

❒ Depending on which country you are in, there may also be html manuals. To

view these manuals, a Web browser must be installed.

❖ About This Machine

Be sure to read the Safety Information in this manual before using the machine. This manual provides an introduction to the functions of the machine. It also explains the control panel, preparation procedures for using the machine, how to enter text, and how to install the CD-ROMs provided.

❖ General Settings Guide

Explains User Tools settings, and Address Book procedures such as registering fax numbers, e-mail addresses, and user codes. Also refer to this manual for explanations on how to connect the machine.

❖ Troubleshooting

Provides a guide to solving common problems, and explains how to replace paper, toner, and other consumables.

❖ Security Reference

This manual is for administrators of the machine. It explains security functions that you can use to prevent unauthorized use of the machine, data tampering, or information leakage. For enhanced security, we recommend the following settings.

• Install the Server Certificate.

• Enable SSL(Secure Sockets Layer) Encryption.

• Change the user name and password of the administrator using Web Image Monitor.

For details, see “Setting Up the Machine”, Security Reference. Be sure to read this manual when setting the enhanced security functions, or user and administrator authentication.

❖ Copy Reference

Explains Copier functions and operations. Also refer to this manual for explanations on how to place originals.

❖ Facsimile Reference

Explains Facsimile functions and operations.

❖ Printer Reference

Explains Printer functions and operations.

❖ Scanner Reference

Explains Scanner functions and operations.

❖ Network Guide

Explains how to configure and operate the machine in a network environment, and use the software provided. This manual covers all models, and includes descriptions of functions and settings that might not be available on this machine. Images, illustrations, and information about operating systems that are supported might also differ slightly from those of this machine.

❖ Other manuals

• PostScript 3 Supplement

•UNIX Supplement

• Manuals for DeskTopBinder Lite

• DeskTopBinder Lite Setup Guide

• DeskTopBinder Introduction Guide

•Auto Document Link Guide

Note

❒ Manuals provided are specific to machine types.

❒ For “UNIX Supplement”, please visit our Web site or consult an authorized

dealer.

❒ “PostScript3 Supplement” and “UNIX Supplement” include descriptions of

functions and settings that might not be available on this machine.

Manuals for This Machine ......................................................................................i

Notice ......................................................................................................................1

How to Read This Manual .....................................................................................3

Symbols .....................................................................................................................3

Display Panel..........................................................................................................4

Reading the Display and Using Keys.........................................................................5

Printer Features Menu ...........................................................................................6

Setting Paper on the Bypass Tray......................................................................10

Setting the Paper Size Using the Control Panel ......................................................13

Setting the Custom Size Paper Using the Control Panel.........................................14

Setting Thick Paper or OHP Transparencies Using the Control Panel ....................16

Setting Envelope Using the Control Panel ...............................................................17

1. Preparing the Machine

Confirming the Connection Method...................................................................19

Network Connection.................................................................................................19

Local Connection .....................................................................................................22

Installing the Printer Driver.................................................................................23

Quick Install..............................................................................................................23

Installing the Printer Driver under Windows Vista ....................................................24

Installing the Printer Driver for the Selected Port.....................................................26

Using as a Windows Network Printer ................................................................36

Using as a NetWare Print Server / Remote Printer ........................................... 39

Form Feed................................................................................................................41

Banner Page ............................................................................................................41

Printing after Resetting the Printer ...........................................................................41

Installing the Printer Driver Using USB .............................................................42

Windows Me - USB ..................................................................................................42

Windows 2000 - USB ...............................................................................................44

Windows XP, Windows Server 2003 - USB .............................................................45

Printing with Parallel Connection.......................................................................47

Printing with Bluetooth Connection...................................................................49

Supported Profiles....................................................................................................49

Printing with Bluetooth Connection ..........................................................................49

Configuring Security Mode Settings.........................................................................51

Printing in the Security Mode ...................................................................................51

Making Option Settings for the Printer..............................................................52

Conditions for Bidirectional Communication ............................................................52

If Bidirectional Communication Is Disabled..............................................................53

Installing Font Manager 2000..............................................................................55

Using Adobe PageMaker Version 6.0, 6.5, or 7.0.............................................. 56

iii

2. Setting Up the Printer Driver

PCL - Accessing the Printer Properties.............................................................57

Windows 95 / 98 / Me - Accessing the Printer Properties........................................57

Windows 2000 - Accessing the Printer Properties ...................................................58

Windows XP, Windows Server 2003 - Accessing the Printer Properties .................60

Windows NT 4.0 - Accessing the Printer Properties ................................................61

RPCS - Accessing the Printer Properties.......................................................... 64

Windows 95 / 98 / Me - Accessing the Printer Properties........................................64

Windows 2000 - Accessing the Printer Properties ...................................................66

Windows XP, Windows Server 2003 - Accessing the Printer Properties .................68

Windows NT 4.0 - Accessing the Printer Properties ................................................70

3. Other Print Operations

Printing a PDF File Directly.................................................................................73

Printing Method........................................................................................................73

Using DeskTopBinder Lite .......................................................................................73

Using commands .....................................................................................................76

Unauthorized Copy Control ................................................................................77

Using [Data security for copying] .................................................................................78

Using [Mask type:] .....................................................................................................80

Important Notice.......................................................................................................81

Form Feed.............................................................................................................82

Printing from a Selected Tray...................................................................................82

Canceling a Print Job ...............................................................................................83

Canceling a Print Job ..........................................................................................85

Canceling a Print Job Using the Control Panel ........................................................85

Windows - Canceling a Print Job from the computer...............................................86

Checking the Error Log .......................................................................................87

Printing with the Finisher....................................................................................88

Collate ...................................................................................................................89

Collate ......................................................................................................................89

Rotating Collate........................................................................................................89

Shift Collate..............................................................................................................90

Staple ....................................................................................................................91

Staple Position .........................................................................................................91

Stapling Precautions ................................................................................................92

4. Appendix

Specifications.......................................................................................................93

Options.....................................................................................................................94

INDEX......................................................................................................... 96

Notice

Note to users in the United States of America

Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio /TV technician for help.

Caution:

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Declaration of Conformity

Product Name: Printer/Scanner Unit

Model Number: 7025/DSm625/LD125/Aficio MP 2500

Responsible party: Ricoh Americas Corporation

Address: 5 Dedrick Place, West Caldwell, NJ 07006

Telephone number: 973-882-2000

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. this device must accept any interference received, including interference that

may cause undesired operation.

Note to users in Canada

Note:

This Class B digital apparatus complies with Canadian ICES-003.

Remarque concernant les utilisateurs au Canada

Avertissement:

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

How to Read This Manual

Symbols

This manual uses the following symbols:

Indicates important safety notes.

Ignoring these notes could result in serious injury or death. Be sure to read these notes. They can be found in the “Safety Information” section of About This Machine.

Indicates important safety notes.

Ignoring these notes could result in moderate or minor injury, or damage to the machine or to property. Be sure to read these notes. They can be found in the “Safety Information” section of About This Machine.

Indicates points to pay attention to when using the machine, and explanations of likely causes of paper misfeeds, damage to originals, or loss of data. Be sure to read these explanations.

Indicates supplementary explanations of the machine’s functions, and instructions on resolving user errors.

This symbol is located at the end of sections. It indicates where you can find further relevant information.

[ ]

Indicates the names of keys that appear on the machine’s display panel.

{ }

Indicates the names of keys on the machine’s control panel.

Display Panel

This section describes configuration using the display panel when the printer function is selected.

ASC009S

1. Operational status or messages

Displays current machine status, such as “Ready”, “Offline”, and “P lease wait...”.

2. [JobReset]

Press to cancel the current print job. If you press it when the machine is offline and Hex Dump is selected, Hex Dump is canceled.

Note

3. [Menu]

Press to display the menu to select the following options:

• [FormFeed]

Press to print all the data left in the machine's input buffer.

• [Error Log]

Displays the error logs of print jobs that are sent from a computer.

❒ When the power is turned on, the copier display is shown. This is a factory

default. This initial setting can be changed. See “System Settings”, General Settings Guide.

Reading the Display and Using Keys

This section explains how to read the display and using the selection key for the initial display.

ASC010S

1. Scroll keys

Press to move the cursor in each direction, step by step.

When the {U}, {T}, {V}, or {W} key appears in this manual, press the scroll key of the same direction.

2. {OK} key

Press to set a selected item or entered numeric value.

3. {Escape} key

Press to cancel an operation or return to the previous display.

4. Selection keys

Correspond to the function items at the bottom line on the display. Example: Basic screen When the instruction “press [JobReset]” appears in this manual, press the left selection key.

Printer Features Menu

The following explains settings and meanings of functions on Printer Feature. Printer Feature screen appears when you press the {User Tools/Counter} key. For details, see “Printer Features”, General Settings Guide.

❖ List/Test Print

Menu Description

Multiple Lists You can print the configuration page and er-

ror log.

Config. Page You can print the machine's current configu-

ration values.

Error Log You can print error logs listing all errors that

occurred during printing.

Menu List You can print a Menu List showing the ma-

chine's function menus.

PCL Config./Font Page You can print the current configuration and

installed PCL font list.

PS Config./Font Page You can print the current configuration and

installed PostScript font list.

PDF Config./Font Page You can print the current configuration and

installed PDF font list.

This menu can be selected only when the optional PostScript 3 unit is installed.

Hex Dump You can print in the Hex Dump mode.

❖ Maintenance

Menu Description

Menu Protect This function lets you protect menu settings

from accidental change. It makes it impossible to change menu settings with normal procedures unless you perform the required key operations.

In a network environment, only administrators can make changes to menu settings.

List/Test Print Lock You can lock the [List/Test Print] menu.

❖ System

Menu Description

Print Error Report You can print an error report when a printer

or memory error occurs.

Auto Continue You can select this to enable Auto Continue.

When it is On, printing continues after a system error occurs.

Memory Overflow Select this to have a memory overflow error

report printed.

Menu Description

Job Separation You can enable Job Separation.

This menu can be selected only when a finisher (optional) is installed.

Memory Usage You can select the amount of memory used

in Font Priority or Frame Priority, according to paper size or resolution.

Duplex You can select to have print on both sides of

each page.

Copies You can specify the number of print sets.

This setting is disabled if the number of pages to print has been specified with the printer driver or another command.

Blank Page Print You can select whether or not to print blank

pages.

Edge Smoothing Set this to enable Edge Smoothing.

• On (Default)

•Off

If Toner Saving is set to On, Edge Smoothing is ignored even if it is set to On.

Toner Saving Set this to enable Toner Saving.

• On (Default)

•Off

Printer Language You can specify the printer language.

Sub Paper Size You can enable the Auto Substitute Paper

Size (A4, LT) feature.

Page Size You can select the default paper size.

Letterhead Setting

Bypass Tray Priority You can specify which of the two options,

Edge to Edge Print You can select whether or not to print on the

Default Printer Lang. You can set the default printer language if

Tray Switching You can set to switch the paper tray.

You can rotate original images when printing.

When printing, original images are always rotated by 180 degrees. Therefore, output might not be as expected when printing onto letterhead or preprinted paper requiring orientation. Using this function, you can specify image rotation.

(Printer) Driver / Command or Machine Settings, has priority for determining the paper size for the bypass tray.

entire sheet.

the machine cannot find the printer language automatically.

RAM Disk You can change the settings of the RAM disk.

❖ Host Interface

Menu Description

I/O Buffer You can set the size of the I/O Buffer. Nor-

mally it is not necessary to change this setting.

I/O Timeout You can set how many seconds the machine

should wait before ending a print job. If data from another port usually arrives in the middle of a print job, you should increase this timeout period.

❖ PCL Menu

Menu Description

Orientation You can set the page orientation.

Form Lines You can set the number of lines per page.

Font Source You can set the storage location of the de-

fault font.

Font Number You can set the ID of the default font you

want to use.

Point Size You can set the point size you want to use for

the selected font.

Font Pitch You can set the number of characters per

inch for the selected font.

Symbol Set You can specify the set of print characters for

the selected font. The available options are as follows:

Courier Font You can select a courier font type.

Ext. A4 Width You can extend the printing area width

when printing on A4 sheet with PCL.

Append CR to LF

Resolution

When set to On, a carriage return will follow each line feed: CR=CR, LF=CR-LF, FF=CR-FF.

You can set the print resolution in dots per inch.

❖ PS Menu (optional)

Menu Description

Data Format You can select a data format.

Resolution

You can set the print resolution in dots per inch.

❖ PDF Menu (optional)

Menu Description

Change PDF Password You can set the password for the PDF file ex-

ecuting PDF Direct Print.

PDF Group Password You can set the group password already

specified with DeskTopBinder Lite.

Resolution

You can set the print resolution in dots per inch.

Note

❒ Depending on which optional units you have installed or the printer lan-

guage you have selected, some options are not displayed.

❒ Depending on the security settings, you might not be able to set certain op-

tions.

Reference

For details, see “Printer Features”, General Settings Guide.

For more information about copier features and system settings, see Copy Reference and General Settings Guide.

Setting Paper on the Bypass Tray

This section gives instructions for setting paper on the bypass tray.

For details about paper size and paper type, see “Recommended Paper Sizes and Types”, About This Machine.

Important

❒ The following functions are disabled when printing from the bypass tray:

• Duplex printing

•Auto Tray Select

•Auto Tray Switching

• Rotating Collate

• Staple (when the finisher installed)

❒ When printing using the printer function, original images are always rotated

by 180 degrees (the orientation of images to be printed is opposite to that of the copier function). When printing onto paper with specific orientation requirements, such as envelopes and letterheads, be sure to rotate the paper feed orientation to 180 degrees.

❒ Be sure to set the paper size using the printer driver when printing data from

the computer. The paper size set using the printer driver has priority over the one set using the control panel.

❒ Paper that is thicker than 162 g/m

tray.

(max.) cannot be printed from the bypass

A Open the bypass tray.

BAE001S

B Lift up the paper guide release lever.

ARB017S

1. Paper guide release lever

C Adjust the paper guides to the paper size, and then gently insert paper face

down into the bypass tray.

AYM004S

1. Extender

2. Paper guides

Open out the extender to support paper sizes larger than A4 L, 81/2 ×11 L.

•

• If the paper guides are not flush against the paper, skewing and misfeeds

might occur.

• Gently insert paper until it stops.

• Load only as much paper as can be held between the guides on the bypass

tray. Overloading the bypass tray can result in misfeeds and skewed images.

• Fan the paper to get air between the sheets to avoid a multi-sheet feed.

• When setting an OHP transparency, make sure that its front and back sides

are properly positioned.

D Push down the paper guide release lever.

AYM005S

E Set the paper size using the printer driver or the control panel.

Note

❒ Paper within the following dimensions can be set in the bypass tray:

• Vertical: 90 - 297 mm (3.55 - 11.69 in.)

• Horizontal: 148 - 600 mm (5.83 - 23.62 in.)

❒ Be sure to set the paper with the side you want to print facing down in the

bypass tray.

❒ The number of sheets that can be loaded in the bypass tray depends on the

paper type.

❒ When loading OHP transparencies or thick paper in the bypass tray, make

the paper setting using the control panel or printer driver.

Reference

For details about setting the paper size, see p.13 “Setting the Paper Size Using the Control Panel”.

For details about setting paper in the regular paper tray, see Copy Reference and General Settings Guide.

When loading custom size paper, see p.14 “Setting the Custom Size Paper Using the Control Panel”.

Select paper type when printing onto OHP transparencies or thick paper (over 105.1 g/m parencies Using the Control Panel”.

Select paper type when printing onto envelopes. For details, see p.17 “Setting Envelope Using the Control Panel”.

When loading letterhead paper, pay attention to its orientation. See Copy Reference and General Settings Guide.

). For details, see p.16 “Setting Thick Paper or OHP Trans-

Setting the Paper Size Using the Control Panel

This procedure describes how to set paper size of the bypass tray using the control panel. If you select the printer driver to set paper size, this procedure is not necessary.

A Press the {User Tools/Counter} key.

ASC011S

B Select [System Settings] using {T} or {U}, and then press the {OK} key.

C Select [Tray Paper Settings] using {T} or {U}, and then press the {OK} key.

D Select [Printer Bypass Paper Size] using {T} or {U}, and then press the {OK}

key.

E Select the paper size using the scroll keys, and then press the {OK} key.

F Press the {User Tools/Counter} key to return to the default screen.

Reference

See the printer driver Help about the settings from the printer drivers.

Select paper type when printing onto OHP transparencies or thick paper. For details, see p.16 “Setting Thick Paper or OHP Transparencies Using the Control Panel”.

Select paper type when printing onto envelopes. For details, see p.17 “Setting Envelope Using the Control Panel”.

Setting the Custom Size Paper Using the Control Panel

The following procedures are not required if you select the printer driver for the settings. In that case, set the paper size using the printer driver.

Important

❒ Custom size settings set using the printer driver have priority over those set

using the machine's control panel.

❒ When the printer driver is not used, make settings using the control panel.

A Press the {User Tools/Counter} key.

ASC011S

B Select [System Settings] using {T} or {U}, and then press the {OK} key.

C Select [Tray Paper Settings] using {T} or {U}, and then press the {OK} key.

D Select [Printer Bypass Paper Size] using {T} or {U}, and then press the {OK}

key.

E Select [Custom Size] using the scroll keys, and then press the {OK} key.

F Enter the horizontal size of the paper using the number keys, and press

{q}.

Available size: 148 - 600 mm (5.83 - 23.62 in.)

G Enter the vertical size of the paper using the number keys, and press {q}.

Available size: 90 - 297 mm (3.55 - 11.69 in.)

H Press the {User Tools/Counter} key to return to the default screen.

Note

❒ If the printer driver is not used, select [Machine Settings] from [Bypass Tray

Priority] in [System] of [Printer Features] (see “Printer Features”, General Set-

tings Guide). Set paper size using the control panel.

Reference

For printer driver settings, see the printer driver Help.

Setting Thick Paper or OHP Transparencies Using the Control Panel

The following procedures are not required if you select the printer driver for the settings. In that case, set the paper size using the printer driver.

Important

❒ Paper size settings set using the printer driver have priority over those set us-

ing the machine's control panel.

❒ When the printer driver is not used, make settings using the control panel.

A Press the {User Tools/Counter} key.

ASC011S

B Select [System Settings] using {T} or {U}, and then press the {OK} key.

C Select [Tray Paper Settings] using {T} or {U}, and then press the {OK} key.

D Select [Paper Type: Bypass Tray] using {T} or {U}, and then press the {OK}

key.

E Select paper type from the menu using {T} or {U}, and then press the {OK}

key.

F Press the {User Tools/Counter} key to return to the default screen.

Note

❒ The settings made will remain valid until they are reset again. After print-

ing on thick paper or OHP Transparencies, be sure to clear settings for the next user.

Reference

For the printer driver settings, see the printer driver Help.

For details about printing onto envelopes, see p.17 “Setting Envelope Using the Control Panel”.

Setting Envelope Using the Control Panel

A Press the {User Tools/Counter} key. B Select [System Settings] using the {U} or {T} key, and then press the {OK}

key.

C Select [Tray Paper Settings] using the {U} or {T} key, and then press the {OK}

key.

D Select [Paper Type:Bypass Tray] using the {U} or {T} key, and then press the

{OK} key.

E Select [Thick Paper] using the {U} or {T} key, and then press the {OK} key.

F Select [Printer Bypass Paper Size] using the {U} or {T} key, and then press the

{OK} key.

G Select the paper envelope size, and then press the {OK} key.

H Press the {User Tools/Counter} key to return to the default screen.

1. Preparing the Machine

Confirming the Connection Method

This machine supports network and local connection.

Before installing the printer driver, check how the machine is connected. Follow the driver installation procedure that is appropriate to the connection method.

Network Connection

This machine can be used as a Windows printing port or network printer.

Using This Machine as the Windows Printing port

Network connections can be established through Ethernet and IEEE 802.11b.

Available ports are determined based on the combination of Windows operating system version and connection method used.

❖ Windows 95 / 98

Connection Method Available Ports

Ethernet / IEEE 802.11b SmartDeviceMonitor for Client port

❖ Windows Me

Connection Method Available Ports

Ethernet / IEEE 802.11b SmartDeviceMonitor for Client port

BAE003S

Preparing the Machine

❖ Windows 2000/Windows XP/Windows Server 2003

Connection Method Available Ports

Ethernet / IEEE 802.11b SmartDeviceMonitor for Client port

Standard TCP/IP

LPR port

❖ Windows Vista

Connection Method Available Ports

Ethernet / IEEE 802.11b Standard TCP/IP

LPR port

❖ Windows NT 4.0

Connection Method Available Ports

Ethernet / IEEE 802.11b SmartDeviceMonitor for Client port

LPR port

Reference

See the explanation about how to install the printer driver for each type of port. For the SmartDeviceMonitor for Client port, see p.26 “Using the SmartDeviceMonitor for Client Port”.

For the Standard TCP/IP port, see p.32 “Using the Standard TCP/IP Port”.

For the LPR port, see p.34 “Using the LPR Port”.

For details about installation under Windows Vista, see p.24 “Installing the Printer Driver under Windows Vista”.

Confirming the Connection Method

Using as a network printer

This machine can be used as the Windows network printer, the NetWare print server, or the NetWare remote printer.

Note

❒ In an IPv6 environment, NetWare servers cannot be used.

Reference

See the explanation about how to install the printer driver for each type of network printer.

For the Windows network printer, see p.36 “Using as a Windows Network Printer”.

For the NetWare print server and remote printer, see p.39 “Using as a NetWare Print Server / Remote Printer”.

For details about installation under Windows Vista, see p.24 “Installing the Printer Driver under Windows Vista”.

BAE004S

Preparing the Machine

Local Connection

Local connections can be established via parallel, USB, and Bluetooth connections.

Windows operating system version determines the available connection methods.

•Windows 95: Parallel connections

•Windows 98: Parallel connections

• Windows 98 SE / Me: USB and Parallel connections

• Windows 2000: USB, Parallel, and Bluetooth connections

•Windows XP: USB, Parallel, and Bluetooth connections

• Windows Server 2003: USB, Parallel, and Bluetooth connections

•Windows Vista: USB and Parallel connections

• Windows NT 4.0: Parallel connections

Reference

See the explanation about how to install the printer driver for each method of connection.

For the USB connection, see p.42 “Installing the Printer Driver Using USB”.

For the parallel connection, see p.47 “Printing with Parallel Connection”.

For the Bluetooth connection, see p.49 “Printing with Bluetooth Connection”.

For details about installation under Windows Vista, see p.24 “Installing the Printer Driver under Windows Vista”.

Installing the Printer Driver

This section explains how to install the printer driver. There are two ways to install the printer driver: using Quick Install, which installs the settings at once, or installing the appropriate driver according to the port you want to use.

Important

❒ The printer driver for Windows NT 4.0 is not included on the supplied CD-

ROM. If your operating system is Windows NT4.0, download printer driver for Windows NT4.0 from the supplier's Web site. For details, ask your sales/service representatives.

Quick Install

Windows 95 / 98 / Me / 2000 / XP and Windows Server 2003 users can easily install this software using the supplied CD-ROM.

Using Quick Install, the PCL printer driver and/or RPCS printer driver, DeskTopBinder Lite and SmartDeviceMonitor for Client are installed under network environment, and the TCP/IP port will be set.

Important

❒ To install printer driver under Windows 2000 / XP Professional, Windows

Server 2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log on as an Administrator.

❒ If you connect using USB, refer to p.42 “Installing the Printer Driver Using

USB” and install the printer driver.

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

Auto Run may not work with certain operating system settings. If this happens, launch “Setup.exe” on the CD-ROM root directory.

C Select an interface language, and then click [OK].

The default interface language is English.

D Click [Quick Install].

The software license agreement appears in the [License Agreement] dialog box.

After reading the agreement, click [I accept the agreement.], and then click [Next >].

F Select the machine model you want to use in the [Select Printer] dialog box.

For network connection via TCP/IP, select the machine whose IP address is displayed in [Connect To].

For parallel connection, select the machine whose printer port is displayed in [Connect To].

Preparing the Machine

G Click [Install].

The printer driver installation starts.

H Click [Finish].

A message about restarting the computer appears. Restart the computer to complete installation.

I Click [Exit] in the first dialog box of the installer, and then take out the CD-

ROM.

Note

❒ To stop installation of the selected software, click [Cancel] before installa-

tion is complete.

❒ Select a machine to whose IP address is displayed in [Connect To] to install

SmartDeviceMonitor for Client when using TCP/IP.

Reference

Quick Install is not available unless bidirectional communication between the machine and computer is enabled via parallel connection. See p.53 “If Bidirectional Communication Is Disabled” for details about bidirectional communication between the machine and computer.

Installing the Printer Driver under Windows Vista

Use the following procedure to install and set up the printer driver under Windows Vista.

Important

❒ The printer driver Help cannot be displayed on computers running Windows

Vista.

❒ SmartDeviceMonitor for Client cannot be installed on computers running

Windows Vista.

Windows Vista users can install the PCL or RPCS printer driver using the supplied CD-ROM.

The printer driver installers can be found in the following locations:

Example (the “D” drive is the CD-ROM drive):

•RPCS

D:\DRIVERS\RPCS\XP_VISTA\(Language)\DISK1

• PCL (PCL5E/PCL6)

D:\DRIVERS\PCL(PCL5E or PCL6)\XP_VISTA\(Language)\DISK1

Install and set up the printer driver as follows:

A Install the printer driver.

B Specify the port settings.

C Configure the properties.

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

Installing the Printer Driver

C Launch the Add Printer Wizard to install the PCL or RPCS printer driver.

Click [Control Panel] on the [Start] menu, click [Hardware and Sound], click [Print- er], and then click [Add a Printer] to launch the Add Printer Wizard.

D Specify the required port.

You can change the port settings on the [Ports] tab in the printer properties dialog box.

For details about the printer properties, see p.25 “Windows Vista - Accessing the Printer Properties”.

For details about the available ports, see p.19 “Confirming the Connection Method”.

E Configuring the properties.

If necessary, configure the settings in the printer properties dialog box.

If bidirectional communication has been enabled, the options are automatically configured.

If bidirectional communication has not been enabled, you must configure the options manually.

Windows Vista - Accessing the Printer Properties

To make the printer default settings, open the printer properties dialog box from the [Printers] window.

A On the [Start] menu, point to [Control Panel], and then click [Hardware and

Sound]-[Printer].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [Organize] menu, click [Properties]. D Make the necessary settings, and then click [OK].

Reference

p.19 “Confirming the Connection Method”

p.52 “Making Option Settings for the Printer”

Preparing the Machine

Installing the Printer Driver for the Selected Port

Using the SmartDeviceMonitor for Client Port

Important

❒ To install SmartDeviceMonitor for Client under Windows 2000 / XP Profes-

sional, Windows Server 2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log on as an Administrator.

❒ Install SmartDeviceMonitor for Client before installing the printer driver

when using the SmartDeviceMonitor for Client port.

Installing SmartDeviceMonitor for Client

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

C Select an interface language, and then click [OK].

The default interface language is English.

D Click [DeskTopBinder - SmartDeviceMonitor for Client]. E The message to quit all other applications appears. Quit all applications,

and then click [Next >].

F The software license agreement appears in the [License Agreement] dialog

box. After reading through its contents, click [Yes].

G Click [Full install] or [Custom Install].

[Full install] installs all required applications: DeskTopBinder Lite and Smart-

DeviceMonitor for Client.

[Custom Install] installs selected applications.

H Follow the instructions on the display and click [Next >] to proceed next

step.

I After the installation is completed, select one of the options to restart the

computer either now or later, and click [Complete].

Restart the computer to complete installation.

Note

❒ To stop installation of the selected software, click [Cancel] before installa-

tion is complete.

❒ Auto Run may not work with certain operating system settings. If this hap-

pens, launch “Setup.exe” on the CD-ROM root directory.

Installing the Printer Driver

Changing the Port Settings for SmartDeviceMonitor for Client

Follow the procedure below to change the SmartDeviceMonitor for Client settings, such as TCP/IP timeout, recovery/parallel printing, and printer groups.

Windows 95 / 98:

A Open the [Printers] window from the [Start] menu. B In the [Printers] window, click the icon of the printer you want to use. On

the [File] menu, click [Properties].

C Click the [Details] tab, and then click [Port Settings].

The [Port Settings] dialog box appears.

Windows 2000 / Windows NT 4.0:

A Open [Printers] window from [Start] menu.

B In the [Printers] window, click the icon of the printer you want to use. On

the [File] menu, click [Properties].

C On the [Ports] tab, click [Configure Port].

The [Configuration] dialog box appears.

Windows XP, Windows Server 2003:

A Open the [Printers and Faxes] window from the [Start] menu.

The [Printers and Faxes] window appears.

B Click the icon of the machine you want to use. On the [File] menu, click

[Properties]. The printer properties appear.

C Click the [Ports] tab, and then click [Configure Port].

The [Port Configuration] dialog box appears.

Preparing the Machine

Note

❒ For TCP/IP, timeout setting can be configured.

❒ User, proxy, and timeout settings can be configured for IPP.

❒ If no settings on the [Recovery/Parallel Printing] tab are available, follow the

procedure below.

A Click [Cancel] to close the [Port Configuration:] dialog box.

B Start SmartDeviceMonitor for Client, and then right-click the SmartDe-

viceMonitor for Client icon on the tasktray.

C Point to [Properties], and then click [Extended Features Settings].

D Select the [Set Recovery/Parallel Printing for each port] check box.

E Click [OK] to close the [Extended Features Settings] dialog box.

Reference

For information about these settings, see “Using SmartDeviceMonitor for Client”, Network Guide, or SmartDeviceMonitor for Client Help.

Installing the PCL or RPCS Printer Driver (TCP/IP)

Important

❒ To install this printer driver under Windows 2000 / XP Professional, Win-

dows Server 2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log on as an Administrators or Power Users group member.

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

C Select an interface language, and then click [OK].

The default interface language is English.

D Click [PCL/RPCS Printer Drivers]. E The software license agreement appears in the [License Agreement] dialog

box.

After reading the agreement, click [I accept the agreement.], and then click [Next >].

F Select the printer driver you want to use in the [Select Program] dialog box.

You can select several printer drivers.

G Click [Next >]. H Select the machine model you want to use.

The printer name can be changed in the [Change settings for 'Printer Name'] box.

Installing the Printer Driver

I Double-click the printer name to display the printer settings.

The details shown in [Comment], [Driver], and [Port] vary depending on the operating system, printer model, and port.

J Click [Port], and then click [Add]. K Click [SmartDeviceMonitor], and then click [OK]. L Click [TCP/IP], and then click [Search].

A list of printers using TCP/IP appears.

M Select the printer you want to use, and then click [OK].

Only printers that respond to a broadcast from the computer appear. To use a machine not listed here, click [Specify address], and then enter the IP address or host name of the machine.

N Check that the port of the selected printer is displayed in [Port]. O Set a user code, if necessary.

Up to 8 numeric characters can be entered. No alphabetic character or symbol can be entered.

P Select the [Default Printer] check box to configure the printer as default. Q Click [Continue].

Installation starts.

R After the installation is completed, select one of the options to restart the

computer either now or later, and then click [Finish].

Restart the computer to complete installation.

Note

❒ Setting a user code allows a SmartDeviceMonitor for Admin user to dis-

play and check statistics about the number of sheets which each user prints. For details, see SmartDeviceMonitor for Admin Help.

❒ Auto Run may not work with certain operating system settings. If this hap-

pens, launch “Setup.exe” on the CD-ROM root directory.

❒ Under Windows 95 / 98 / Me, you cannot add an IP address partially sim-

ilar to the one already used. For example, if “192.168.0.2” is in use, “192.168.0.2xx” cannot be used. Similarly, if “192.168.0.20” is in use, “192.168.0.2” cannot be used.

Reference

A message appears if there is a newer version of the printer driver already installed. If there is, you cannot install the printer driver using Auto Run. If you still want to install the printer driver, use [Add Printer]. See “When a Message Appears during Installation of the Printer Driver”, Troubleshooting.

Preparing the Machine

Installing the PCL or RPCS Printer Driver (IPP)

Important

❒ To install printer driver under Windows 2000 / XP Professional, Windows

Server 2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log on as an Administrators or Power Users group member.

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

C Select an interface language, and then click [OK].

The default interface language is English.

D Click [PCL/RPCS Printer Drivers]. E The software license agreement appears in the [License Agreement] dialog

box.

After reading the agreement, click [I accept the agreement.], and then click [Next >].

F Select a printer driver you want to use in the [Select Program] dialog box.

You can select several printer drivers.

G Select the machine model you want to use.

The printer name can be changed in the [Change settings for 'Printer Name'] box.

H Double-click the printer name to display the printer settings.

The details shown in [Comment], [Driver], and [Port] vary depending on the operating system, printer model, and port.

I Click [Port], and then click [Add]. J Click [SmartDeviceMonitor], and then click [OK]. K Click [IPP]. L In the [Printer URL] box, enter “http://printer's address/printer” as the print-

er's address.

If the server authentication is issued, to enable SSL (a protocol for encrypted communication), enter “https://printer's address/printer” (Internet Explorer 5.01, or a higher version must be installed).

(example IP address: 192.168.15.16)

http://192.168.15.16/printer

https://192.168.15.16/printer

You can enter “http://printer's address/ipp” as the printer's address.

Installing the Printer Driver

M Enter a name for identifying the printer in [IPP Port Name]. Use a name dif-

ferent from the one of any existing port.

If a name is not specified here, the address entered in the [Printer URL] box becomes the IPP port name.

N Click [Detailed Settings] to make necessary settings.

For information about the settings, see SmartDeviceMonitor for Client Help.

O Click [OK]. P Check that the port of the selected printer is displayed in [Port]. Q Set a user code, if necessary.

Up to 8 numeric characters can be entered. No alphabetic characters or symbols can be entered.

R Select the [Default Printer] check box to configure the printer as default. S Click [Continue].

Installation starts.

T After the installation is completed, select one of the options to restart the

computer either now or later, and then click [Finish].

Restart the computer to complete installation.

Note

❒ To stop installation of the selected software, click [Cancel] before installa-

tion is complete.

❒ Auto Run may not work with certain operating system settings. In that

case, launch “Setup.exe” on the CD-ROM root directory.

❒ Setting a user code allows a SmartDeviceMonitor for Admin user to dis-

play and check the number of sheets each user prints. For details, see SmartDeviceMonitor for Admin Help.

Reference

Preparing the Machine

Using the Standard TCP/IP Port

This describes how to install the PCL or RPCS printer driver using the TCP/IP port.

Important

❒ To install this printer driver under Windows 2000 / XP Professional, and

Windows Server 2003, you must have an account that has Manage Printers permission. Log on as an Administrators or Power Users group member.

Installing the PCL or RPCS Printer Driver

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

C Select an interface language, and then click [OK].

The default interface language is English.

D Click [PCL/RPCS Printer Drivers]. E The software license agreement appears in the [License Agreement] dialog

box.

After reading the agreement, click [I accept the agreement.], and then click [Next >].

F Select a printer driver you want to use in the [Select Program] dialog box.

You can select several printer drivers.

G Click [Next >]. H Select the machine model you want to use.

The printer name can be changed in the [Change settings for 'Printer Name'] box.

I Double-click the printer name to display the printer settings.

The details shown in [Comment], [Driver], and [Port] vary depending on the operating system, printer model, and port.

J Click [Port], and then click [Add]. K Click [Standard TCP/IP Port], and then click [OK].

Configure the Standard TCP/IP port settings, and then see Windows Help if [Standard TCP/IP Port] does not appear.

L Click [Next >] in the [Add Standard TCP/IP Printer Port Wizard] dialog box.

Installing the Printer Driver

M Enter the printer name or IP address in the [Printer Name or IP Address] box.

The [Port Name] text box automatically obtains a port name. Change this name if necessary.

When the device selection appears, select “RICOH NetworkPrinter Driver C Model”.

N Click [Next >]. O Click [Finish] in the [Add Standard TCP/IP Printer Port Wizard] dialog box.

The installation start dialog box reappears.

P Check that the port of the selected printer is displayed in [Port]. Q Configure the default printer as necessary. R Click [Continue].

The printer driver installation starts.

S After the installation is completed, select one of the options to restart the

computer either now or later, and then click [Finish].

Restart the computer to complete installation.

Note

❒ To stop installation of the selected software, click [Cancel] before installa-

tion is complete.

❒ Auto Run may not work with certain operating system settings. In that

case, launch “Setup.exe” on the CD-ROM root directory.

Reference

Preparing the Machine

Using the LPR Port

This describes how to install the PCL or RPCS printer driver using the LPR port.

Important

❒ To install this printer driver under Windows 2000 / XP Professional, Win-

dows Server 2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log on as an Administrators or Power Users group member.

Installing the PCL or RPCS Printer Driver

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

C Select an interface language, and then click [OK].

The default interface language is English.

D Click [PCL/RPCS Printer Drivers]. E The software license agreement appears in the [License Agreement] dialog

box.

After reading the agreement, click [I accept the agreement.], and then click [Next >].

F Select a printer driver you want to use in the [Select Program] dialog box.

You can select several printer drivers.

G Select the machine model you want to use.

The printer name can be changed in the [Change settings for 'Printer Name'] box.

H Click [Next >]. I Double-click the printer name to display the printer settings.

The details shown in [Comment], [Driver], and [Port] vary depending on the operating system, printer model, and port.

J Click [Port], and then click [Add]. K Click [LPR Port], and then click [OK].

If [LPR Port] does not appear, see Windows Help and install it.

L Enter the printer's IP address in the [Name or address of server providing lpd]

box.

M Enter “lp” in the [Name of printer or print queue on that server] box, and then click

[OK].

The port is added.

Installing the Printer Driver

N Check that the port of the selected printer is displayed in [Port]. O Configure the default printer as necessary. P Click [Continue].

The printer driver installation starts.

Q After the installation is completed, select one of the options to restart the

computer either now or later, and then click [Finish].

Restart the computer to complete installation.

Note

❒ To stop installation of the selected software, click [Cancel] before installa-

tion is complete.

❒ Auto Run may not work with certain operating system settings. In that

case, launch “Setup.exe” on the CD-ROM root directory.

Reference

Preparing the Machine

Using as a Windows Network Printer

This describes how to install the PCL or RPCS printer driver when using the printer as a Windows network printer.

To use the print server, install the printer driver by selecting “Network printer server”, and then select the Windows 2000 / XP, Windows Server 2003, Windows Vista, or Windows NT 4.0 shared printer.

This section assumes that the client has already been configured to communicate with a Windows 2000 / XP, Windows Server 2003, Windows Vista, or Windows NT 4.0 print server. Do not begin the following procedure before the client is set up and configured correctly.

Important

❒ The printer driver for Windows NT 4.0 is not included on the supplied CD-

ROM. If your operating system is Windows NT4.0, download printer driver for Windows NT4.0 from the supplier's Web site. For details, ask your sales/service representatives.

❒ To install the printer driver under Windows 2000 / XP Professional, Win-

dows Server 2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log on as an Administrators or Power Users group member.

❒ If you print with a print server connected to the printer using the SmartDe-

viceMonitor port, Recovery Printing and Parallel Printing cannot be used from the client.

❒ If you print with a Windows XP or Windows Server 2003 print server, notifi-

cation functions of SmartDeviceMonitor may not be used with the client.

❒ The machine’s print server supports computers running Windows Vista,

SmartDeviceMonitor for Client cannot be installed on computers running Windows Vista.

❒ If you print with a Windows NT 4.0 print server, install the printer driver be-

fore you connect the print server to the printer.

❒ If your operating system is Windows NT4.0, download printer driver for

Windows NT4.0 from the supplier's Web site.

Installing the PCL or RPCS Printer Driver

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

C Select an interface language, and then click [OK].

The default interface language is English.

D Click [PCL/RPCS Printer Drivers].

Using as a Windows Network Printer

E The software license agreement appears in the [License Agreement] dialog

box.

After reading the agreement, click [I accept the agreement.], and then click [Next >].

F Select the printer driver you want to use in the [Select Program] dialog box.

You can select several printer drivers.

G Click [Next >]. H Select the [Printer Name] check box to select the printer models you want to

use.

The printer name can be changed in the [Change settings for 'Printer Name'] box.

I Double-click the printer name to display the printer settings.

The details shown in [Comment], [Driver], and [Port] vary depending on the operating system, printer model, and port.

J Click [Port], and then click [Add]. K Click [Network Printer], and then click [OK]. L Double-click the computer name you want to use as a print server in the

[Browse for Printer] window.

M Select the printer you want to use, and then click [OK]. N Check that the port of the selected printer is displayed in [Port].

O Configure the user code as necessary.

For an RPCS printer driver, a user code can be set after the printer driver installation. For information about user code, see the printer driver Help.

P Select the [Default Printer] check box to configure the printer as default. Q Click [Continue].

The printer driver installation starts.

R After the installation is completed, select one of the options to restart the

computer either now or later, and then click [Finish].

Restart the computer to complete installation.

Note

❒ To stop installation of the selected software, click [Cancel] before installa-

tion is complete.

❒ Auto Run may not work with certain operating system settings. In that

case, launch “Setup.exe” on the CD-ROM root directory.

Preparing the Machine

Reference

Using as a NetWare Print Server / Remote Printer

This describes how to set up the Windows computer used as the NetWare client.

Important

❒ The printer driver for Windows NT 4.0 is not included on the supplied CD-

ROM. If your operating system is Windows NT4.0, download printer driver for Windows NT4.0 from the supplier's Web site. For details, ask your sales/service representatives.

❒ To install this printer driver under Windows 2000 / XP Professional, Win-

dows Server 2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log on as an Administrators or Power Users group member.

❒ In an IPv6 environment, NetWare servers cannot be used.

The following explanation assumes NetWare Client is installed on the client computer and the NetWare server environment is correctly set up. Install all necessary client applications before following this procedure.

Set up the printer driver while logging on to the NetWare file server.

The following values are used in the example:

• Operating system: Windows 98

•NetWare version: 4.1

• File server name: CAREE

• Queue name: R-QUEUE

A Insert the CD-ROM into the CD-ROM drive.

The installer starts.

Auto Run may not work with certain operating system settings. In that case, launch “Setup.exe” on the CD-ROM root directory.

B Select an interface language, and then click [OK].

The default interface language is English.

C Click [PCL/RPCS Printer Drivers]. D The software license agreement appears in the [License Agreement] dialog

box.

After reading the agreement, click [I accept the agreement.], and then click [Next >].

E Select the printer driver you want to use in the [Select Program] dialog box.

You can select several printer drivers.

F Click [Next >].

Preparing the Machine

G Select the [Printer Name] check box to select the printer model you want to

use.

The printer name can be changed in the [Change settings for 'Printer Name'] box.

H Double-click the printer name to display the printer settings.

The details shown in [Comment], [Driver], and [Port] vary depending on the operating system, printer model, and port.

I Click [Port], and then click [Add]. J Click [Network Printer], and then click [OK]. K Double-click the name of the NetWare file server on the network tree.

The created queue is displayed.

L Select the print queue, and then click [OK]. M Check that the port of the selected printer is displayed in [Port]. N Click [Continue].

The printer driver installation starts.

O Click [Finish] in the [Select Program] dialog box. P After the installation is completed, select one of the options to restart the

computer either now or later, and then click [Finish].

Restart the computer to complete installation.

Q After restarting the computer, launch the [Printers] window, and then open

the printer properties.

Under Windows XP or Windows Server 2003, open the printer properties from the [Printers and Faxes] window.

R On the [Printer Settings] tab, clear the [Form Feed] and [Enable Banner] check

boxes.

Under Windows 2000 / XP, Windows Server 2003, or Windows NT 4.0, click the [NetWare setting] tab.

Do not select these check boxes since they are automatically selected by the printer driver. If you select the check boxes, the printer may not print correctly.

S Click [OK] to close the printer properties dialog box.

Note

❒ To stop installation of the selected software, click [Cancel] before installa-

tion is complete.

❒ The protocol is set to inactive as default. Enable it using Web Image Mon-

itor or Telnet.

Using as a NetWare Print Server / Remote Printer

Form Feed

Do not use NetWare to configure form feed. Form feed is controlled by the printer driver on Windows. If NetWare form feed is configured, the printer may not print properly.

Follow the procedure below to disable form feed according to the operating system used:

• Under Windows 95 / 98 / Me, clear the [Form feed] check box on the [Printer Settings] tab in the printer properties dialog box.

• Under Windows 2000 / XP, Windows Server 2003, or Windows NT 4.0, clear the [Form feed] check box on the [NetWare Settings] tab in the printer properties dialog box.

Banner Page

Do not use NetWare to configure a banner page.

Follow the procedure below to disable banner pages according to the operating system used:

• Under Windows 95 / 98 / Me, clear the [Enable banner] check box on the [Print- er Settings] tab in the printer properties dialog box.

• Under Windows 2000 / XP, Windows Server 2003, or Windows NT 4.0, clear the [Enable banner] check box on the [NetWare Settings] tab in the printer properties dialog box.

Printing after Resetting the Printer

Printer to print server connection requires 30 - 40 seconds to resume after the printer is reset. During this period, jobs may be accepted (depending on NetWare specifications) but not printed.

To print after resetting the printer as the remote printer, check on the print server that the remote printer is disconnected, or wait for two minutes before trying to print.

Preparing the Machine

Installing the Printer Driver Using USB

This section explains how to install printer drivers using USB.

Before installing, check that only the operating system is running on the computer and no print jobs are in progress.

The printer drivers can be installed from the supplied CD-ROM provided with this machine.

Windows Me - USB

Important

❒ Installation via USB is not possible under Windows 95 / 98. Upgrade to Win-

dows Me or later.

❒ Download USB Printing Support for Windows Me from the supplier's Web

site.

When USB is first used, the plug and play function starts and the [New Hardware Found], [Device Driver Wizard], or [Add New Hardware Wizard] dialog box appears, de- pending on the operating system.

If the printer driver has already been installed, plug and play is enabled, and the icon of the printer connected to the “USB” port is added to the [Printers] window.

A Download USB Printing Support from the supplier's Web site.

Use a search to find the model name, and then download USB Printing Support from the supplier's Web site.

Save it where you can locate it easily.

B Connect the machine to the computer using the USB cable.

Connect the USB cable firmly.

C In the Found New Hardware Wizard display, click [Search for a suitable driver

for my device [recommended]], and then click [Next >].

D Select the [Specify a location:] check box, and then click [Browse...].

The [Browse for Folder] dialog box appears.

E Specify the location where USB Printing Support is located, and then click

[Next >].

F Check the location, and then click [Next >].

USB Printing Support is installed.

G Click [Finish].

If the printer driver has already been installed, plug and play is enabled, and the icon of the printer connected to the “USB001” port is added to the [Printers] window.

Installing the Printer Driver Using USB

H Install the printer driver. Click [Search for the best driver for your device. [Recom-

mended]], and then click [Next >].

I Select the [Specify a location:] check box, and then click [Browse...].

The [Browse for Folder] dialog box appears.

J Insert the CD-ROM into the CD-ROM drive.

Note

❒ When Auto Run starts, click [Exit]. ❒ To disable Auto Run, press the {Shift} key when inserting the CD-ROM

into the drive and keep it pressed until the computer finishes reading from the CD-ROM.

K Specify the location where the source files of the printer driver are stored,

and then click [Next >].

If the CD-ROM drive is D, the source files of the printer driver are stored in the following location:

•RPCS

D:\DRIVERS\RPCS\WIN9X_ME\(Language)\DISK1

•PCL 5e

D:\DRIVERS\PCL5E\WIN9X_ME\(Language)\DISK1

•PCL 6

D:\DRIVERS\PCL6\WIN9X_ME\(Language)\DISK1

• PostScript 3 (“Printer Drivers and Utilities” CD-ROM)

D:\DRIVERS\PS\WIN9X_ME\(Language)\DISK1

L Check the location, and then click [Next >].

Add Printer Wizard starts.

M Click [Finish].

Installation is complete. If installation is successful, the icon of the printer connected to the “USB001” port is added to the [Printers] window.

Note

❒ The number after “USB” varies depending on the number of printers con-

nected.

❒ It is not necessary to reinstall USB Printing Support when connecting a dif-

ferent machine via USB interface when USB Printing Support is installed.

❒ After installing USB Printing Support, if the printer driver is not installed,

follow the plug-and-play instructions of the printer.

Preparing the Machine

Windows 2000 - USB

Important

❒ Installing a printer driver requires Administrator permission. Log on using

an account that has Administrator permission.

When USB is first used, Found New Hardware Wizard starts, and USB Printing Support is installed automatically.

If the printer driver has already been installed, plug and play is enabled, and the icon of the printer connected to the “USB” port is added to the [Printers] window.

If the printer driver is not installed, follow the plug-and-play instructions of the printer to install it from the supplied CD-ROM.

A Connect the machine to the computer using the USB cable.

Connect the USB cable firmly.

B In the Found New Hardware Wizard display, click [Search for a suitable driver

for my device [recommended]], and then click [Next >].

C Select the [Specify location] check box, and then click [Next >]. D Insert the CD-ROM into the CD-ROM drive.

When Auto Run starts, click [Exit]. To disable Auto Run, press the left {Shift} key when inserting the CD-ROM

into the drive and keep it pressed until the computer finishes reading from the CD-ROM.

E Specify the location where the source files of the printer driver is stored.

If the CD-ROM drive is D, the source files of the printer driver are stored in the following location:

•RPCS

D:\DRIVERS\RPCS\XP_VISTA\(Language)\DISK1

•PCL 5e

D:\DRIVERS\PCL5E\XP_VISTA\(Language)\DISK1

•PCL 6

D:\DRIVERS\PCL6\XP_VISTA\(Language)\DISK1

• PostScript 3 (“Printer Drivers and Utilities” CD-ROM)

D:\DRIVERS\PS\WIN2K_XP\(Language)\DISK1

F Check the printer driver location, and then click [OK]. G Click [Next >]. H Click [Finish].

If the printer driver has already been installed, plug and play is enabled, and the icon of the printer connected to the “USB001” port is added to the [Printers] window.

Installing the Printer Driver Using USB

Note

❒ The number after “USB” varies depending on the number of printers con-

nected.

Windows XP, Windows Server 2003 - USB

Important

❒ Installing a printer driver requires Administrators permission. Log on using

an account that has Administrators permission.

When USB is first used, Found New Hardware Wizard starts, and USB Printing Support is installed automatically.

If the printer driver has already been installed, plug and play is enabled, and the icon of the printer connected to the “USB” port is added to the [Printers] window.

The printer drivers can be installed from the supplied CD-ROM provided with this machine.

If the printer driver is not installed, follow the plug-and-play instructions of the printer to install it from the supplied CD-ROM.

A Connect the machine to the computer using the USB cable.

Connect the USB cable firmly.

B In the Found New Hardware Wizard display, click [Search for a suitable driver

for my device [recommended]], and then click [Next >].

C Insert the CD-ROM into the CD-ROM drive.

If Auto Run starts, click [Cancel], and then [Exit]. To disable Auto Run, press the left {Shift} key when inserting the CD-ROM

into the drive and keep it pressed until the computer finishes reading from the CD-ROM.

D Select the [Include this location in the search] check box under [Search for the best

driver in these location], and then click [Browse] to select the printer driver lo-

cation.

If the CD-ROM drive is D, the source files of the printer driver are stored in the following location:

•RPCS

D:\DRIVERS\RPCS\XP_VISTA\(Language)\DISK1

•PCL 5e

D:\DRIVERS\PCL5E\XP_VISTA\(Language)\DISK1

•PCL 6

D:\DRIVERS\PCL6\XP_VISTA\(Language)\DISK1

• PostScript 3 (“Printer Drivers and Utilities” CD-ROM)

D:\DRIVERS\PS\WIN2K_XP\(Language)\DISK1

E Check the printer driver location, and then click [Next >].

Preparing the Machine

F Click [Continue]. G Click [Finish].

If installation is successful, the icon of the printer connected to the “USB001” port is added to the [Printers and Faxes] window.

Note

❒ The number after “USB” varies depending on the number of printers con-

nected.

Printing with Parallel Connection

This describes how to install the PCL or RPCS printer driver when using the parallel port.

To use a machine connected using a parallel interface, click [LPT1] when installing the printer driver.

Important

❒ To install this printer driver under Windows 2000 / XP Professional, Win-

dows Server 2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log on as an Administrators or Power Users group member.

❒ If your operating system is Windows NT4.0, download printer driver for

Windows NT4.0 from the supplier's Web site.

Installing the PCL or RPCS Printer Driver

A Quit all applications currently running.

B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

C Select an interface language, and then click [OK].

The default interface language is English.

D Click [PCL/RPCS Printer Drivers]. E The software license agreement appears in the [License Agreement] dialog

box.

After reading the agreement, click [I accept the agreement.], and then click [Next >].

F Select the printer driver you want to use in the [Select Program] dialog box.

You can select several printer drivers.

G Click [Next >]. H Select the [Printer Name] check box to select the printer model you want to

use.

The printer name can be changed in the [Change settings for 'Printer Name'] box.

I Double-click the printer name to display the printer settings.

The details shown in [Comment], [Driver], and [Port] vary depending on the operating system, printer model, and port.

J Check that [LPT1:] is shown in [Port]. K Select the [Default Printer] check box to configure the printer as default.

Preparing the Machine

L Click [Finish].

The printer driver installation starts.

M After the installation is completed, select one of the options to restart the

computer either now or later, and then click [Finish].

Restart the computer to complete installation.

Note

❒ To stop installation of the selected software, click [Cancel] before installa-

tion is complete.

❒ Auto Run may not work with certain operating system settings. In that

case, launch “Setup.exe” on the CD-ROM root directory.

Reference

Printing with Bluetooth Connection

This describes how to print using with Bluetooth devices.

Supported Profiles

Refer the following supported profiles for Bluetooth connection.

❖ SPP, HCRP

• A maximum of two Bluetooth adaptor or Bluetooth-equipped computers

can be connected at the same time using the Bluetooth interface: one by SPP, one by HCRP.

• When connecting more than one Bluetooth adaptor or Bluetooth-equipped

computer at the same time, the first device that establishes connection is selected. When selecting the connection between the other devices, cancel the first established connection.

• SPP connection does not support bidirectional communications.

• HCRP connection supports bidirectional communications.

❖ BIP

• For BIP connection, a module including PostScript 3 must be installed in

the machine.

• Only one Bluetooth adaptor or Bluetooth-equipped computer can be con-

nected via BIP.

• Only JPEG images that can be printed using BIP.

• User codes are disabled for BIP.

You cannot print if print functions are restricted.

• Some printers do not support BIP.

Note

❒ In this manual, the instruction referred to print using SPP. To print using

HCRP or BIP, see the Help supplied with the Bluetooth adapter you use.

Printing with Bluetooth Connection

To install the printer driver, follow the procedure used to install parallel interface.

Important

❒ To install the printer driver under Windows 2000 / XP Professional or Win-

dows Server 2003, you must have an account that has Manage Printers permission. Log on as an Administrators or Power Users group member.

A Start 3Com Bluetooth Connection Manager.

Preparing the Machine

B Check that the printer you want to use appears in 3Com Bluetooth Connec-

tion Manager.

C On the [Tool] menu, click [COM port].

D Check that the message “Bluetooth Serial Client (COMx) “ appears under

Client Ports. (X indicates the COM port number used by Bluetooth.)

E Click [Close]. F On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

G Click the icon of the printer you want to use. H On the [File] menu, click [Properties]. I Click the [Ports] tab. J Under [Port], select the [COMx:] check box. X indicates the COM port num-

ber used by Bluetooth.

K Click [OK].

Close the [Printers] window.

Note

❒ To always use the same printer, select the [Always use for this connection]

check box.

❒ System requirements vary depending on the Bluetooth standard and spec-

ifications. For details, see the manuals supplied with each product.

❒ For information about setting up Bluetooth under other operating systems

or using it with different utilities, see the manuals supplied with those operating systems or utilities.

❒ If a dialog box appears while transmitting a print job, reestablish network

connection as follows:

A Select the printer you want to use in the [Printers and Faxes] box.

B Click [Connect].

Reference

For details, see the manuals supplied with the Bluetooth adaptor or computer equipped with Bluetooth.

Printing with Bluetooth Connection

Configuring Security Mode Settings

This describes how to configure the security mode settings.

A Start 3Com Bluetooth Connection Manager. B On the [Tools] menu, click [Security Mode].

The [Security Mode] dialog box appears.

C Select the security mode in the [Security Mode:] list.

If you click [High], or [Custom], and specify [Link] in the [Custom Settings] dialog box, enter the Bluetooth password. For information about entering the password, see p.51 “Printing in the Security Mode”.

For all other security modes and custom settings, no password is required.

For information about each mode, see the manuals supplied with the utility.

D Click [OK].

Close the [Security Mode] dialog box.

Reference

For details about the security mode, see 3Com Bluetooth Connection Manager Help. For details about the password entry which is required to transmit print jobs, see p.51 “Printing in the Security Mode”.

Printing in the Security Mode

This describes how to print in the security mode.

A Send the print job to the printer in use.

Depending on the computer configuration, the [Connect] dialog box may appear. If it does, use it to establish the network connection.

B The [Authentication] dialog box appears. C Enter the Bluetooth password, and then click [OK].

As the Bluetooth password, enter the last four digits of the machine's serial number. You can find the serial number on the label attached to the back of the machine. For example, if the serial number is 00A0-001234, the Bluetooth password is 1234.

D The print job is sent.

Note

❒ The Bluetooth password differs for each machine and cannot be changed.

Preparing the Machine

Making Option Settings for the Printer

Make option settings for the machine using the printer driver when bidirectional communication is disabled.

Reference

For details about making option settings for the printer, see p.53 “If Bidirectional Communication Is Disabled”.

Conditions for Bidirectional Communication

Bidirectional communication allows information about paper size and feed direction settings to be automatically sent to the printer. You can check machine status from your computer.

Bidirectional communication is supported by Windows 95 / 98 / Me / 2000 /

• XP,

Windows Server 2003, Windows Vista, and Windows NT 4.0.

• If you use the RPCS printer driver and bidirectional communication is enabled under Windows 2000, the [Change Accessories] tab is unavailable.

Note

❒ The RPCS printer driver supports bidirectional communications and updates

the machine status automatically.

❒ The PCL printer driver supports bidirectional communications. You can up-

date the machine status manually.

To support bidirectional communication, the following conditions must be met:

❖ When connected with parallel cables

• The computer must support bidirectional communication.

• The machine must support bidirectional communication.

• The interface cable must support bidirectional communication.

• The machine must be connected to the computer using the standard paral-

lel cables and parallel connectors.

• Under Windows 2000, [Enable bidirectional support] must be selected, and

[Enable printer pooling] must not be selected on the [Ports] tab with the RPCS printer driver.

Making Option Settings for the Printer

❖ When connected with the network

• DeskTopBinder Lite must be installed, or the Standard TCP/IP port must

be used.

• Under Windows 2000/XP, Windows Server 2003, or Windows Vista, [En-

able bidirectional support] must be selected, and [Enable printer pooling] must not be selected on the [Ports] tab with the RPCS printer driver.

If the Standard TCP/IP port is not being used, one of the following conditions must be met in addition to the two above:

• The SmartDeviceMonitor for Client port and the TCP/IP protocol must be

used.

• The standard TCP/IP port must be used without changing the default port

name (for Windows 2000 / XP, Windows Server 2003 and Windows Vista).

• Microsoft TCP/IP print IP address must be specified for use (for Windows

NT 4.0).

• When using IPP protocol with the PCL printer driver, the IPP port name

must include the IP address.

❖ When connected with USB

The machine must be connected to the computer's USB port using the USB interface cable. The computer must support bidirectional communication.

Note

❒ Install SmartDeviceMonitor for Client from the supplied CD-ROM.

If Bidirectional Communication Is Disabled

Set up option settings when bidirectional communications are disabled.

Important

❒ Under Windows 2000 / XP and Windows Server 2003, Manage Printers per-

mission is required to change the printer properties in the [Printers] folder. Log on as an Administrators or Power Users group member.

❒ Under Windows NT 4.0, Full Control permission is required to change the

printer properties in the [Printers] (Windows 2000) or [Printers and Faxes] (Windows XP / Windows Server 2003) folder. Log on as an Administrators or Power Users group member.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

When using Windows XP or Windows Server 2003, point to [Settings] on the [Start] menu, and then click [Printers and Faxes]. The [Printers and Faxes] window appears.

When using Windows Vista, click [Control Panel] on the [Start] menu, click [Hardware and Sound], and then click [Printer]. The [Printers] window opens.

Preparing the Machine

B Click the icon of the printer you want to use. C On the [File] menu, click [Properties].

D Click the [Change Accessories] tab.

If options in the [Change Accessories] tab are disabled, bidirectional connection is enabled. In this case, no change is necessary for option settings.

If you are using the RPCS printer driver, click the [Change Accessories] tab.

E Select options installed from the options area, and then make the necessary

settings.

F Select the total amount of the memory in [Total memory:] when the optional

SDRAM module is added.

G Under [Paper source tray settings:], click and highlight the tray to be used, and

then select the appropriate size, position, and type for the tray. Select the [Do not use Auto Tray Select] check box to exclude the tray from the targets of automatic tray selection.

H Click [OK] to close the printer properties dialog box.

Installing Font Manager 2000

Important

❒ Under Windows 2000 / XP, Windows Server 2003, or Windows NT 4.0, in-

stalling applications by Auto Run requires administrator permission. To install a printer driver by Auto Run, log on using an account that has administrator permission.

A Quit all applications currently running. B Insert the CD-ROM into the CD-ROM drive.

The installer starts.

C Click [Font Manager 2000]. D Follow the instructions on the screen.

Preparing the Machine

Using Adobe PageMaker Version 6.0, 6.5, or 7.0

Under Windows 95 / 98 / Me / 2000 / XP, Windows Server 2003, or Windows NT 4.0 with Adobe PageMaker, you need to copy PPD files to the PageMaker folder.

PPD files have the .ppd extension in the folder “DRIVERS\PS\WIN9X_ME\(Language)\DISK1” on the CD-ROM.

The “WIN9X_ME” folder inside the “PS” folder is for Windows 95 / 98 / Me. Use the folder at this level that is appropriate for the operating system you are currently using.

The third folder “(Language)” may be substituted by an appropriate language name.

Copy the .ppd file to the PageMaker folder.

• For PageMaker 6.0 default installation The directory is “C:\PM6\RSRC\PPD4”.

• For PageMaker 6.5 default installation The directory is “C:\PM65\RSRC\USENGLISH\PPD4”. The “USENGLISH” may vary depending on your language selection.

• For PageMaker 7.0 default installation The directory is “C:\PM7\RSRC\USENGLISH\PPD4”. The “USENGLISH” may vary depending on your language selection.

Note

❒ If the driver is not set correctly after copying the “.ppd” file, printing may not

be performed properly.

❒ When using PageMaker, the optional features that can be selected by the

printer driver will not be active. The following procedure describes how to activate the optional printer features.

A On the [File] menu, click [Print].

The [Print Document] dialog box appears.

B Make the necessary settings in the [Features] box.

2. Setting Up the Printer Driver

PCL - Accessing the Printer Properties

Windows 95 / 98 / Me - Accessing the Printer Properties

There are two methods to open the printer properties dialog box.

Making Printer Default Settings

To make the printer default settings, open the printer properties dialog box from the [Printers] window.

Important

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Properties]. D Make the necessary settings, and then click [OK].

Note

❒ With some applications, the printer driver settings are not used, and the

application's own default settings are applied.

Reference

For details, see the printer driver Help.

Making Printer Settings from an Application

You can make printer settings for a specific application.

To make printer settings for a specific application, open the printer properties dialog box from that application. The following explains how to make settings for the WordPad application provided with Windows 95 / 98 / Me.

A On the [File] menu, click [Print...].

The [Print] dialog box appears.

B Select the printer you want to use in the [Name] list, and then click [Proper-

ties].

The printer properties dialog box appears.

Setting Up the Printer Driver

C Make the necessary settings, and then click [OK]. D Click [OK] to start printing.

Note

❒ The procedure to open the printer properties dialog box may vary depend-

ing on the application. For details, see the manuals provided with the application you use.

❒ With some applications, the printer driver settings are not used, and the

application's own default settings are applied.

❒ Any settings you make in the following procedure are valid for the current

application only.

❒ General users can change the properties displayed in the [Print] dialog box

of an application. Settings made here are used as defaults when printing from this application.

Reference

For details, see the printer driver Help.

Windows 2000 - Accessing the Printer Properties

Making Printer Default Settings - The Printer Properties

Important

❒ To change the printer default settings including option configuration settings,

log on using an account that has Manage Printers permission. Members of the Administrator and Power Users groups have Manage Printers permission by default.

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Properties].

The printer properties dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

PCL - Accessing the Printer Properties

Making Printer Default Settings - Printing Preferences

Important

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Printing Preferences...].

The [Printing Preferences] dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Settings from an Application

You can make printer settings for a specific application.

To make printer settings for a specific application, open the [Printing Preferences] dialog box from that application. The following explains how to make settings for the WordPad application provided with Windows 2000.

A On the [File] menu, click [Print...].

The [Print] dialog box appears.

B Select the printer you want to use in the [Select Printer] list. C Make the necessary settings, and then click [Print] to start printing.

Note

❒ The procedure to open the [Printing Preferences] dialog box may vary de-

pending on the application. For details, see the manuals provided with the application you use.

❒ Any settings you make in the following procedure are valid for the current

application only.

❒ General users can change the properties displayed in the [Print] dialog box

of an application. Settings made here are used as defaults when printing from this application.

Reference

For details, see the printer driver Help.

Setting Up the Printer Driver

Windows XP, Windows Server 2003 - Accessing the Printer Properties

Making Printer Default Settings - The Printer Properties

Important

❒ To change the printer default settings including option configuration settings,

log on using an account that has Manage Printers permission. Members of the Administrators and Power Users groups have Manage Printers permission by default.

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, click [Printers and Faxes].

The [Printers and Faxes] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Properties].

The printer properties dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Default Settings - Printing Preferences

Important

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, click [Printers and Faxes].

The [Printers and Faxes] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Printing Preferences...].

The [Printing Preferences] dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

PCL - Accessing the Printer Properties

Reference

For details, see the printer driver Help.

Making Printer Settings from an Application

You can make printer settings for a specific application.

A On the [File] menu, click [Print...].

The [Print] dialog box appears.

B Select the printer you want to use in the [Select Printer] list. C Make the necessary settings, and then click [Print] to start printing.

Note

❒ The procedure to open the [Printing Preferences] dialog box may vary de-

pending on the application. For details, see the manuals provided with the application you use.

❒ Any settings you make in the following procedure are valid for the current

application only.

❒ General users can change the properties displayed in the [Print] dialog box

of an application. Settings made here are used as defaults when printing from this application.

Reference

For details, see the printer driver Help.

Windows NT 4.0 - Accessing the Printer Properties

Making Printer Default Settings - The Printer Properties

Important

❒ To change the printer default settings including option configuration settings,

log on using an account that has Full Control permission. Members of the Administrators, Server Operators, Print Operators, and Power Users groups have Full Control permission by default.

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use.

Setting Up the Printer Driver

C On the [File] menu, click [Properties].

The printer properties dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Default Settings - Default

Important

❒ To change the printer default settings including option configuration settings,

log on using an account that has Full Control permission. Members of the Administrators, Server Operators, Print Operators, and Power Users groups have Full Control permission by default.

❒ You cannot change the printer default settings for each user. Settings made in

the [Document Defaults...] dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Document Defaults...].

The [Default] dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

PCL - Accessing the Printer Properties

Making Printer Settings from an Application

You can make printer settings for a specific application.

A On the [File] menu, click [Print...].

The [Print] dialog box appears.

B Select the printer you want to use in the [Name] list, and then click [Proper-

ties].

The printer properties dialog box appears.

C Make the necessary settings, and then click [OK]. D Click [OK] to start printing.

Note

❒ The procedure to open the printer properties dialog box may vary depend-

ing on the application. For details, see the manuals provided with the application you use.

❒ With some applications, the printer driver settings are not used, and the

application's own default settings are applied.

❒ Any settings you make in the following procedure are valid for the current

application only.

❒ General users can change the properties displayed in the [Print] dialog box

of an application. Settings made here are used as defaults when printing from this application.

Reference

For details, see the printer driver Help.

Setting Up the Printer Driver

RPCS - Accessing the Printer Properties

Windows 95 / 98 / Me - Accessing the Printer Properties

There are two dialog box types of the printer properties dialog box.

“Multi-tab” is used as an example in this manual. For details about changing the dialog box types, see the printer driver Help.

❖ Multi-tab

This dialog box type is designed for users who often change print settings to perform various printing operations.

❖ Custom Setting

This dialog box type is designed for users who rarely change print settings. This type of dialog box may vary depending on the installed options.

Making Printer Default Settings

To make the printer default settings, open the printer properties dialog box from the [Printers] window.

Important

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Properties].

When you open the printer properties dialog box initially after installing the RPCS printer driver, a confirmation message appears. After clicking [OK], the printer properties dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ With some applications, the printer driver settings are not used, and the

application's own default settings are applied.

Reference

For details, see the printer driver Help.

RPCS - Accessing the Printer Properties

Making Printer Settings from an Application

You can make printer settings for a specific application.

A On the [File] menu, click [Print...].

The [Print] dialog box appears.

B Select the printer you want to use in the [Name] list, and then click [Proper-

ties].

The printer properties dialog box appears.

C Make the necessary settings, and then click [OK]. D Click [OK] to start printing.

Note

❒ The procedure to open the printer properties dialog box may vary depend-

ing on the application. For details, see the manuals provided with the application you use.

❒ With some applications, the printer driver settings are not used, and the

application's own default settings are applied.

❒ Any settings you make in the following procedure are valid for the current

application only.

❒ General users can change the properties displayed in the [Print] dialog box

of an application. Settings made here are used as defaults when printing from this application.

Reference

For details, see the printer driver Help.

Setting Up the Printer Driver

Windows 2000 - Accessing the Printer Properties

This describes how to launch printer driver's properties.

Making Printer Default Settings - The Printer Properties

Important

❒ To change the printer default settings including option configuration settings,

log on using an account that has Manage Printers permission. Members of the Administrators and Power Users groups have Manage Printers permission by default.

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Properties].

The printer properties dialog box appears.

When you open the printer properties dialog box initially after installing the RPCS printer driver, a confirmation message appears. After clicking [OK], the printer properties dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Default Settings - Printing Preferences

Important

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Printing Preferences...].

The [Printing Preferences] dialog box appears.

RPCS - Accessing the Printer Properties

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Settings from an Application

You can make printer settings for a specific application.

A On the [File] menu, click [Print...].

The [Print] dialog box appears.

B Select the printer you want to use in the [Select Printer] list. C Make the necessary settings, and then click [Print] to start printing.

Note

❒ The procedure to open the [Printing Preferences] dialog box may vary de-

pending on the application. For details, see the manuals provided with the application you use.

❒ Any settings you make in the following procedure are valid for the current

application only.

❒ General users can change the properties displayed in the [Print] dialog box

of an application. Settings made here are used as defaults when printing from this application.

Reference

For details, see the printer driver Help.

Setting Up the Printer Driver

Windows XP, Windows Server 2003 - Accessing the Printer Properties

Making Printer Default Settings - The Printer Properties

Important

❒ To change the printer default settings including option configuration settings,

log on using an account that has Manage Printers permission. Members of the Administrators and Power Users groups have Manage Printers permission by default.

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, click [Printers and Faxes].

The [Printers and Faxes] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Properties].

The printer properties dialog box appears.

When you open the printer properties dialog box initially after installing the RPCS printer driver, a confirmation message appears. After clicking [OK], the printer properties dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Default Settings - Printing Preferences

Important

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, click [Printers and Faxes].

The [Printers and Faxes] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Printing Preferences...].

The [Printing Preferences] dialog box appears.

RPCS - Accessing the Printer Properties

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Settings from an Application

You can make printer settings for a specific application.

A On the [File] menu, click [Print...].

The [Print] dialog box appears.

B Select the printer you want to use in the [Select Printer] list. C Make the necessary settings, and then click [Print] to start printing.

Note

❒ The procedure to open the [Printing Preferences] dialog box may vary de-

pending on the application. For details, see the manuals provided with the application you use.

❒ Any settings you make in the following procedure are valid for the current

application only.

❒ General users can change the properties displayed in the [Print] dialog box

of an application. Settings made here are used as defaults when printing from this application.

Reference

For details, see the printer driver Help.

Setting Up the Printer Driver

Windows NT 4.0 - Accessing the Printer Properties

Making Printer Default Settings - The Printer Properties

Important

❒ To change the printer default settings including option configuration settings,

log on using an account that has Full Control permission. Members of the Administrators, Server Operators, Print Operators, and Power Users groups have Full Control permission by default.

❒ You cannot change the printer default settings for each user. Settings made in

the printer properties dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use. C On the [File] menu, click [Properties].

The printer properties dialog box appears.

When you open the printer properties dialog box initially after installing the RPCS printer driver, a confirmation message appears. After clicking [OK], the printer properties dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Default Settings - Default

Important

❒ To change the printer default settings including option configuration settings,

log on using an account that has Full Control permission. Members of the Administrators, Server Operators, Print Operators, and Power Users groups have Full Control permission by default.

❒ You cannot change the printer default settings for each user. Settings made in

the [Document Defaults...] dialog box are applied to all users.

A On the [Start] menu, point to [Settings], and then click [Printers].

The [Printers] window appears.

B Click the icon of the printer you want to use.

RPCS - Accessing the Printer Properties

C On the [File] menu, click [Document Defaults...].

The [Default] dialog box appears.

D Make the necessary settings, and then click [OK].

Note

❒ Settings you make here are used as the default settings for all applications.

Reference

For details, see the printer driver Help.

Making Printer Settings from an Application

You can make printer settings for a specific application.

A On the [File] menu, click [Print...].

The [Print] dialog box appears.

B Select the printer you want to use in the [Name] list, and then click [Proper-

ties].

The printer properties dialog box appears.

C Make the necessary settings, and then click [OK]. D Click [OK] to start printing.

Note

❒ The procedure to open the printer properties dialog box may vary depend-

ing on the application. For details, see the manuals provided with the application you use.

❒ With some applications, the printer driver settings are not used, and the

application's own default settings are applied.

❒ Any settings you make in the following procedure are valid for the current

application only.

❒ General users can change the properties displayed in the [Print] dialog box

of an application. Settings made here are used as defaults when printing from this application.

Reference

For details, see the printer driver Help.

Setting Up the Printer Driver

3. Other Print Operations

Printing a PDF File Directly

You can send PDF files directly to the machine for printing, without having to open a PDF application.

Important

❒ The function can be used with genuine Adobe PDF files only.

❒ This function supports version 1.3, 1.4, and 1.5 PDF files.

❒ PDF files created using the transparency function of PDF version 1.4 may not

be printed.

❒ PDF files created using Crypt Filter and/or the 16 bit color image function of

PDF version 1.5 cannot be printed.

❒ PDF version 1.6 (Acrobat 7.0) files created without any functions that are ex-

clusive to PDF version 1.6 can be printed.

❒ Some types of High Compression PDF files may not be printed. Consult your

sales representative about the supported file types.

Note

❒ Paper size errors may occur when printing on custom size paper.

Printing Method

The following procedures explain the two methods of direct PDF printing - using Auto Document Link or by entering commands.

Using DeskTopBinder Lite

Installing DeskTopBinder Lite

Follow the procedure below to install DeskTopBinder Lite.

A Quit all applications currently running. B

Insert the “Scanner Driver and Utilities” CD-ROM into the CD-ROM drive.

The installer starts.

Auto Run may not work under certain operating system settings. In this case, launch “Setup.exe” located on the CD-ROM root directory.

C Select an interface language, and then click [OK]. D Click [DeskTopBinder Lite].

Other Print Operations

E Follow the instructions on the display to install DeskTopBinder Lite.

If you are required to restart the computer after installing DeskTopBinder Lite, restart the computer and continue the configuration.

DeskTopBinder Lite Enhancements

Follow the DeskTopBinder Lite enhancement procedure to print PDF files directly.

A On the [Start] menu, click [Programs], [DeskTopBinder], and [Extended Features

Wizard].

B When [Extended Features Wizard] appears, select [Start], and then click [Next]

repeatedly until the [Printing Function2] screen appears.

C On the [Printing Function2] screen, click [Add...] to display [PDF Direct Print Prop-

erties].

D Select Driver for This Machine, click [OK], and then click [Next] repeatedly

until [Finish] is displayed.

Click [Finish].

Function Palette

The Function palette contains buttons for functions that are already configured through DeskTopBinder Lite enhancement. Using these buttons, you can print Windows files, preview printouts, convert images, and register scanners for documents without having to open DeskTopBinder Lite. You can also use these functions simply by dragging a target file to the button corresponding to the required function and dropping it there.

A On the [Start] menu, click [Programs], [DeskTopBinder], and [Function Palette].

An icon for the Function palette is added to the tasktray displayed at the bottom right of the screen.

B Right-click the icon that is added to the tasktray, and then click [Properties]

to display the Properties screen.

C Click the [Contents] tab, select the [PDF Direct Print] check box at the center,

and then click [OK].

The [Properties] screen closes and the [PDF Direct Print] icon is added to the palette.

Printing a PDF File Directly

PDF Direct Printing

Use the method below to print PDF files directly.

A Drag the PDF file you want to print to the PDF Direct Printing icon in the

palette and drop it there.

B [Output File List-PDF Direct Print] is displayed.

Highlight the PDF you want to print, and then click [OK].

The PDF file is printed.

Printing PDF Password-Protected Documents

Follow the procedure below to print password-protected PDF files.

A In the Windows [Start] menu, click [Programs], [DeskTopBinder], and [Extended

Features Wizard].

B When [Extended Features Wizard] appears, select [Start], and then click [Next].

C On the [Printing Function2] screen, click [Properties] to display [PDF Direct Print

Properties].

D Select the [Use PDF Password] check box at the bottom right of the screen, and

then click [OK].

Click [Next] repeatedly until [Finish] appears.

Click [Finish] to close the [Extended Features Wizard] screen.

E Move the PDF file you want to print to the PDF Direct Printing icon on the

palette using a drag-and-drop operation.

F [Output File List-PDF Direct Print] is displayed.

Select the PDF file you want to output to make it reverse video, and then click [OK].

G The [PDF Direct Print Properties] screen opens.

Enter the password for the PDF file you want to print in the [PDF Password] field at the bottom right of the screen, and then click [OK].

The password-protected PDF file is printed.

Note

❒

Before printing a password-protected PDF file, perform one of the following:

• Enter the PDF password in the PDF Direct Printing Properties screen.

• Specify a PDF password by selecting [Change PDF Password] in the [PDF Menu] on the control panel of this machine

❒ If a [PDF Group Password] for the [PDF Menu] menu is assigned to either

DeskTopBinder Lite or the control panel of this machine, a same group password needs to be assigned to the other.

Other Print Operations

PDF Direct Print Properties

BAE002S

1. Setting name:

Displays the plug-in configuration name (up to 63 single byte characters)

2. Change Icon...

Changes the icon displayed on the tool bar.

3. Printer:

Displays a list of RPCS drivers that support PDF direct printing.

4. Duplex

Prints on both sides of sheets.

5. Layout

Prints multiple pages on a single sheet.

6. Staple

Applies stapling to printout.

7. Display this dialog box before

printing

Appears in PDF direct printing mode if this check box is selected.

9. Number of copies

Specifies the number of copies to print.

10. Collate

Sorts printed sheets.

11. Range

Specify the pages you want to print.

12. Printout paper size

Specifies the size of the printout paper.

13. Resolution

Specifies a print resolution.

14. PDF Password

If the PDF file is password-protected, enter the password in this field. Otherwise, the file cannot be printed.

15. Group Password

If a group password is assigned to DeskTopBinder Lite and this machine, enter the group password in this field. Otherwise, printing cannot start.

8. Orientation

Specifies the original's orientation.

Using commands

You can print PDF files directly, using commands such as “ftp”, “sftp”, and “lpr”.

Reference

For details about UNIX commands, see Network Guide and UNIX Supplement.

Unauthorized Copy Control

To prevent unauthorized copying, you can embed patterns and text beneath the print. You do not need a special paper to use this function. If a paper with text or image patterns is copied by a copier or a multi-function printer, either the patterns are printed vividly or the copy is grayed out, so as to protect the information on the original from leaking. To print with protection against unauthorized copying, you can use [Data security for copying] and [Mask type:].

Important

❒ This function is designed to discourage copying of confidential documents; it

does not prevent unauthorized use of information.

❒ You must install the Copy Data Security Unit to gray out files protected by

Data Security for Copying that are stored in the document server or printed. You do not have to install the unit to print files that are protected by Data Security for Copying.

❒ You can use this machine to print files that are protected by data security for

copying. However, because you cannot install the Copy Data Security unit on this machine, copies of files cannot be grayed out when using data security for copying.

❒ Data security for copying cannot be used together Toner saving.

❒ Use the following setting to make the embedded pattern or text for prevent-

ing unauthorized copying more visible:

•Under [Copier Features], [Original Type Setting], set [Original Type 1 (Text)] to [Special Mode 1].

• Note that if you make this setting, gray-scale images in documents that do not contain embedded patterns or text might not be copied properly.

❒ To use the Unauthorized Copy Control function, configure the RPCS printer

driver settings as shown below. This function cannot be selected if other settings are applied.

•In the [Paper Type:] list, select [Plain/Recycled].

Opening the Unauthorized Copy Control Window

A In the RPCS printer driver, open the [Printing Preference] window. B Click [Add/Change Custom Settings...]. C Select the [Unauthorized copy...] check box. D Click [Control Settings...].

The Unauthorized Copy Control window appears.

Note

❒ For details, see the printer driver Help.

Other Print Operations

Using [Data security for copying]

If a document printed with data security for copying is copied by or stored in the Document Box of a copier or multi-function printer with the copy data security unit, the copy or stored file is grayed out. This section explains how to specify the printer driver setting for printing using [Data security for copying].

❖ Setting [Data security for copying] in the printer driver

• Select the [Data security for copying] check box. You can also enter the text in the [Text:] box.

• You cannot select the [Mask type:] check box at the same time.

• To print a document protected by gray overprint, the machine must be set up correctly. Consult an administrator.

❖ Printing a document using [Data security for copying]

Cop

ing

n y p

Unauthorized Copy Control

No g No Copy ng No Copying N

ing No Copying N ying No Copying pying No Copyin opying No Copyin

opying No Copyi

1. The pattern and text you have set

is printed.

No Cop

AJL030S

3. The document is blanked by gray

overprint.

2. The document is copied or stored

in copiers / multifunction machines which the Copy Data Security unit is installed.

Note

❒ This machine can print only as described in Step 1.

❒ Only the RPCS printer driver is supported.

❒ You cannot partially embed a pattern and text in a document.

❒ Use 182 × 257 mm (7

❒ Use ordinary or recycled paper of at least 70% whiteness.

❒ Duplex printing may interfere with this function as a result of text and pat-

terns being visible through the paper.

❒ Printing with background patterns and text may be slower than normal print-

ing.

/4 × 101/2 in.) or larger paper.

Reference

For details about setting [Data security for copying], see the printer driver Help.

Other Print Operations

Using [Mask type:]

You can embed patterns and text in a document by setting in the printer driver to prevent unauthorized copying.

❖ Setting [Mask type:] in the printer driver

• Select a pattern from [Mask type:], and then enter text in the [Text:] box.

Note

❒ You can set only [Text:], but [Mask type:] and [Text:] must be set together.

❒ To switch text and background patterns, select the [Reverse patterns:

text/background] check box.

❖ Printing a document using [Mask type:]

1. The pattern and text you have set

is printed palely.

2. The document is copied, scanned,

or stored in copiers / multifunction machines.

AJL031S

3. The pattern and text you have set

appear clearly.

Unauthorized Copy Control

Note

❒ Only the RPCS printer driver is supported.

❒ You cannot partially embed patterns and text strings in a document.

❒ To make the embedded pattern clear, set the character size at least 50 pt (pref-

erably 70 to 80 pt) and character angle to between 30 and 40 degrees.

❒ Due to the effects of the settings, the results of copying, scanning, and saving

documents in the document server may vary depending on the machine model and setting conditions.

❒ Printing with background patterns and text may be slower than normal print-

ing.

Reference

For details about setting [Mask type:], see the printer driver Help.

Important Notice

• The supplier does not provide warranty regarding the appearance of print patterns and other copy protection features. The appearance of the print patterns and the performance of Unauthorized Copy Control may vary depending on the quality of paper used and the machine model and settings.

• The supplier takes no responsibility for any damages sustained in connection with use of or inability to make use of Unauthorized Copy Control print patterns.

Other Print Operations

Form Feed

This section gives instructions for operating the machine when there is no tray for the selected paper size or type, or when paper loaded in the machine has run out.

Important

❒ The tray cannot be changed if the following functions are set:

• Duplex Print to a tray that does not support duplex printing

•Staple

Note

❒ If form feed is selected for a tray with the following settings, you can change

the tray by canceling the settings:

• Duplex Print

•Staple

❒ If [Auto Continue] is selected, form fed paper is printed after a set interval. See

“Printer Features”, General Settings Guide.

Printing from a Selected Tray

If the machine does not have a tray for the selected paper size or paper type, or if the selected paper loaded in the machine has run out, a caution message appears. If this message appears, do the following procedure.

A When the caution message appears, press [FormFeed].

B On the confirmation screen, press {OK}.

If you want to stop printing, press [Cancel].

Form Feed

C Select the tray for form feed using {T} or {U} from those that appear on the

display panel, and then press the {OK} key.

If you want to print after adding paper to the tray, select the tray after loading the correct paper.

The machine prints using the selected tray.

Note

❒ If a tray with a smaller paper size is selected, the print job may be cut short,

or other problems may occur.

Canceling a Print Job

Follow this procedure for canceling the print job if the message prompting form feed appears.

A Press [JobReset].

B Press [Current].

The confirmation message appears.

To cancel all jobs (current and queued), press [All Jobs].

To resume printing jobs, press [Resume].

C Press [Yes] to cancel the print job.

Press [No] to return to the previous display.

Other Print Operations

Note

❒ If the machine is shared by multiple computers, be careful not to acciden-

tally cancel someone else's print job.

❒ Under Windows, If the machine is connected to the computer using a par-

allel cable, sent print jobs may be canceled if [JobReset] is pressed while “Waiting...” is displayed on the control panel. After the interval set in [I/O Timeout] in Printer Features has passed, the next print job can be sent. A print job sent from a different client computer will not be canceled in this case.

❒ You cannot stop printing data that has already been processed. For this

reason, printing may continue for a few pages after you press [JobReset].

❒ A print job containing a large volume of data may take considerable time

to stop.

Reference

For details, see p.85 “Canceling a Print Job”.

Canceling a Print Job

This section gives instruction to stop printing from the computer or the control panel.

Canceling a Print Job Using the Control Panel

A Press [JobReset] on the display panel.

A confirmation message appears.

B Press [Current].

To cancel all jobs (current and queued), press [All Jobs].

To resume printing jobs, press [Resume].

C Press [Yes] to cancel the print job.

Press [No] to return to the previous display.

Other Print Operations

Windows - Canceling a Print Job from the computer

You can cancel a print job from the computer if transferring print jobs is not completed.

A Double-click the printer icon on the Windows task tray.

A window appears, showing all print jobs currently queued for printing. Check the current status of the job you want to cancel.

B Select the name of the job you want to cancel.

C On the [Document] menu, click [Cancel Printing]. D Press the {Printer} key on the machine's control panel.

Note

❒ If the machine is shared by multiple computers, be careful not to acciden-

tally cancel someone else's print job.

❒ If the machine is connected to the computer using a parallel cable, sent

print jobs may be canceled if [JobReset] is pressed while “Waiting...” is displayed on the control panel. After the interval set in [I/O Timeout] in Printer Features has passed, the next print job can be sent. A print job sent from a different client computer will not be canceled in this case.

❒ In Windows XP, Windows Server 2003, Windows Vista, and Windows NT

4.0, click [Cancel] on the [Document] menu.

❒ In Windows 95 / 98 / Me / 2000 or Windows NT 4.0, you can also open

the print job queue window by double-clicking the machine icon in the [Printers] machine window (the [Printers and Faxes] window under Windows XP and Windows Server 2003, or the [Hardware and Sound] under Windows Vista).

❒ You cannot stop printing data that has already been processed. For this

reason, printing may continue for a few pages after you press [JobReset].

❒ A print job containing a large volume of data may take considerable time

to stop.

Checking the Error Log

If files could not be stored due to printing errors, identify the cause of the errors by checking the error log on the control panel.

Important

❒ The most recent 30 errors are stored in the error log. If a new error is added

when there are 30 errors already stored, the oldest error is deleted.

❒ If the main power switch is turned off, the log is deleted.

A Press the {Printer} key to display the Printer screen. B Press [Menu].

C Select [Error Log] and then press the {OK} key.

D Select the error log you want to check using {T} or {U}, and then press the

{OK} key.

A detailed error log appears.

Note

❒ Press the {Escape} key until the Printer screen appears after checking the

log.

❒ To print files that appear in the error log, resend them after stored files

have been printed or deleted.

Other Print Operations

Printing with the Finisher

You can collate or staple by installing the optional finisher. Make sure you read the following precautions when using the optional finisher.

Important

❒ Make option settings for the machine using the printer driver when bidirec-

tional communication is disabled.

❒ Be sure to set the paper size and paper orientation in the printer driver when

using duplex printing, combined printing (layout) and staple functions.

Note

❒ Depending on the application, print settings may not be enabled and printed

output may not be as expected.

❒ When setting Staple or Collate in the printer driver, make sure that the Collate

check box is cleared in the application's [Print] dialog box. If Collate is enabled in the application, printing will not be as intended.

❒ When printing restarts after removing jammed paper, the printing position

may be different, depending on the location of the jam.

• If the paper jam occurred in the optional finisher, printing will restart from

the top page of the data currently being printed, or from the page where the paper jam occurred.

• If the paper jam occurred in the machine, printing will restart from the

page where the paper jam occurred.

• Even if the paper jam occurred in the machine, the error will not be cleared

unless the cover of the finisher is opened and closed.

Reference

For details about duplex printing, or combined printing (layout), see the printer driver Help.

For information about optional finisher, see About This Machine, General Settings Guide and Copy Reference.

To remove paper misfeeds, see Troubleshooting.

Collate

When printing multiple documents such as handouts for meetings, you can separate sets into order. This function is known as “Collate”. Collate stores data transmitted from a computer to the printer memory. The following are the three types of Collate:

Important

❒ If Auto Continue occurs on the first set, Collate will be canceled.

❒ If forced printing occurs on the first set, Collate will be canceled.

❒ When setting Collate in the printer driver settings, make sure that a collate

option is not selected in the application's print settings. If a collate option is selected, printing will not be as intended.

Note

❒ Set Collate and Rotating collate when using the RPCS printer driver.

❒ Follow the procedure below when using the printer driver other than the

RPCS:

• Set Collate and Rotating Collate in the printer driver.

• If you cannot make Shift Collate even with the optional finisher installed,

options may not be set up correctly in the printer driver. Correct the printer driver's option settings.

• For details, see the printer driver Help.

Collate

Printed output is assembled as sets in sequential order.

AEU016S

Rotating Collate

Every other print set is rotated by 90 degrees.

AEU017S

Other Print Operations

Important

❒ The Rotating Collate function requires two paper trays containing same size

paper but in different orientations.

❒ If the output tray has shift function, Shift Collate will be applied even if Ro-

tating Collate is selected.

❒ If a document with mixed paper sizes or sizes larger than A4, 8

/2 × 11 is set,

it can only be collated, even if Rotating Collate has been selected.

❖ When Rotate Collate is cancelled

If the following functions are selected, Collate or Shift Collate will be applied even if Rotating Collate is selected:

• When combined with staple function.

• If jobs containing pages of various sizes are set.

• If custom size paper is set.

Note

❒ When Rotating Collate has been selected, printing speed will be slower than

with other collate functions.

Shift Collate

The optional finisher is required for this function.

The finisher shift tray moves backward or forward when a job or set is output, causing the next to shift, so you can separate them.

AEU018S

Important

❒ This function is not available when you select the following paper type;

• Label paper

• OHP paper

Note

❒ If you select the thick paper in this function, the paper is delivered to the Fin-

isher shift tray.

Reference

For details about paper sizes and the number of sets you can use Collate or Rotating Collate with in every option, see Copy Reference. For details about printing methods, see the printer driver Help.

Staple

With the optional finisher sets can be stapled individually when printing multiple sets.

Staple Position

The specified staple position varies depending on paper size, type, quantity and feed orientation. The following table shows staple positions:

AYM001S

Note

❒ Stapling might not be in the specified position if combine (layout) and duplex

printing are both selected. After setting the staple position, use the printer driver's preview icon to check the position before printing.

Reference

For paper sizes and maximum numbers of sheets available for stapling, see “Specifications for Options”, About This Machine.

For details about the types of paper that can be used with the stapling function, see “Supplementary Information”, Copy Reference.

For printing methods, see the printer driver Help.

Other Print Operations

Stapling Precautions

Important

❒ Stapling can be done only with the optional finisher installed.

❖ Staple printing will be canceled under the following conditions:

• If the number of pages to staple exceeds maximum.

• If a paper size that cannot be stapled is selected.

• If a paper type that cannot be stapled is selected.

• If positions other than those fixed for stapling are specified.

• If there are inconsistencies between the orientation in the duplex mode and

the staple position.

• If there are inconsistencies between the orientation in letterhead mode and

the staple position.

• If paper sizes are mixed when a different paper size is specified during a

print job.

• When feeding paper from the bypass tray.

• When combined with Rotating Collate.

• When staples have run out and Auto Continue is set (printing will contin-

ue without stapling after the message has been displayed).

• When only 1 page is printed.

• When staples have run out.

Note

❒ When the stapling is cancelled, “Staple Cancelled” appears.

❒ If Staple is selected with the optional finisher installed, the paper will be out-

put to the finisher shift tray irrespective of the setting.

❒ When printing on letterhead, stapling may not be at the specified position.

❒ If you cannot make staple settings even with finisher installed, options may

not be set correctly in the printer driver. Correct option settings in the printer driver. For details, see the printer driver Help.

❒ When the finisher is being used for another function's job (for example, a copy

job), printing will start after that job ends.

❒ Be sure to set paper size and orientation in the printer driver when stapling.

❒ When duplex printing is selected, adjust staple positions to the binding orien-

tation.

❒ Depending on the software you are using, print settings may not be saved

and the printed result may not be as expected.

❒ When setting Staple in the printer driver settings, make sure that a collate op-

tion is not selected in the print settings of the application. If a collate option is selected in the application, printing will not be as intended.

4. Appendix

Specifications

This section contains the machine's electrical and hardware specifications, including information about its options.

Component Specifications

Resolution 600/300 dpi

Printing speed 25 ppm

(A4K, 8

Interface Standard:

• Ethernet interface (100 BASE-TX / 10 BASE-T)

• USB 2.0 interface

Option:

• IEEE 1284 parallel interface

• IEEE 802.11b wireless LAN interface

• Bluetooth interface

/2 × 11 K plain paper)

Use a standard 36-pin printer cable not longer than 3 meters (10 feet).

Network protocol TCP/IP, IPX/SPX, AppleTalk

Printer language Standard: RPCS, PCL 5e, PCL XL

Option: PostScript 3, PDF

Fonts PCL XL/5e :

Monotype Imaging 35 Intellifonts, 10 TrueType fonts, 13 International fonts, and 1 Bitmap font.

PostScript 3 :

136 fonts (Type 2:24, Type 14:112)

Memory 384 MB

Network cable 100 BASE-TX / 10 BASE-T shielded twisted-pair (STP, Catego-

ry/Type5) cable.

USB Interface (Standard) • Supported Operating System:

Windows Me / 2000 / XP, Windows Server 2003, Windows Vista, MacOS 9.2.2, MacOS 10.3.3 or later

• Transmission spec. USB 2.0 Standard

• Connectable Device: Devices corresponding to USB 2.0 Standard

Appendix

Note

❒ When using MacOS, use only the standard USB interface. The optional USB

interface board is not supported.

❒ When using the USB Interface (Standard) with MacOS 9.2.2, only USB 1.1 is

supported.

❒ When using the USB Interface (Standard) with Windows Me, install USB

Printing Support. Windows Me only supports USB 1.1 speed.

Options

Important

❒ The IEEE 802.11b interface unit, the IEEE 1284 interface board, and Bluetooth

interface unit cannot be installed concurrently.

IEEE 1284 Interface Board Type A

❖ Transmission spec.:

IEEE 1284

❖ Required cable:

Standard IEEE 1284 compliant Micro Centronics 36 pin cable

IEEE 802.11b Interface Unit Type H

❖ Transmission spec.:

Based on IEEE 802.11b (wireless LAN)

❖ Protocol:

TCP/IP, IPX/SPX, AppleTalk

Note

❒ SmartDeviceMonitor and Web Image Monitor are supported.

❖ Data transfer speed:

Auto select from below speed 1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps

❖ Frequency range:

• Inch version: 2412 - 2462 MHz (1 - 11 channels)

•Metric version: 2412 - 2472 MHz (1 - 13 channels)

Ricoh Type 2500 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Important

Notes:

Caution:

Manuals for This Machine

TABLE OF CONTENTS

Notice

How to Read This Manual

Symbols

Display Panel

Reading the Display and Using Keys

Printer Features Menu

Setting Paper on the Bypass Tray

Setting the Paper Size Using the Control Panel

Setting the Custom Size Paper Using the Control Panel

Setting Thick Paper or OHP Transparencies Using the Control Panel

Setting Envelope Using the Control Panel

1. Preparing the Machine

Confirming the Connection Method

Network Connection

Using This Machine as the Windows Printing port

Using as a network printer

Local Connection

Installing the Printer Driver

Quick Install

Installing the Printer Driver under Windows Vista

Windows Vista - Accessing the Printer Properties

Installing the Printer Driver for the Selected Port

Using the SmartDeviceMonitor for Client Port

Changing the Port Settings for SmartDeviceMonitor for Client

Installing the PCL or RPCS Printer Driver (TCP/IP)

Installing the PCL or RPCS Printer Driver (IPP)

Using the Standard TCP/IP Port

Using the LPR Port

Using as a Windows Network Printer

Using as a NetWare Print Server / Remote Printer

Form Feed

Banner Page

Printing after Resetting the Printer

Installing the Printer Driver Using USB

Windows Me - USB

Windows 2000 - USB

Windows XP, Windows Server 2003 - USB

Printing with Parallel Connection

Printing with Bluetooth Connection

Printing with Bluetooth Connection

Supported Profiles

Configuring Security Mode Settings

Printing in the Security Mode

Making Option Settings for the Printer

Conditions for Bidirectional Communication

If Bidirectional Communication Is Disabled

Installing Font Manager 2000

Using Adobe PageMaker Version 6.0, 6.5, or 7.0

2. Setting Up the Printer Driver

PCL - Accessing the Printer Properties

Windows 95 / 98 / Me - Accessing the Printer Properties

Making Printer Default Settings

Making Printer Settings from an Application

Windows 2000 - Accessing the Printer Properties

Making Printer Default Settings - The Printer Properties

Making Printer Default Settings - Printing Preferences

Making Printer Settings from an Application

Windows XP, Windows Server 2003 - Accessing the Printer Properties

Making Printer Default Settings - The Printer Properties

Making Printer Default Settings - Printing Preferences

Making Printer Settings from an Application

Windows NT 4.0 - Accessing the Printer Properties

Making Printer Default Settings - The Printer Properties

Making Printer Default Settings - Default

Making Printer Settings from an Application

RPCS - Accessing the Printer Properties

Windows 95 / 98 / Me - Accessing the Printer Properties

Making Printer Default Settings

Making Printer Settings from an Application

Windows 2000 - Accessing the Printer Properties
