Ricoh P 502 User Manual

Page 1
RICOH P 502
Printer
Enterprise print solution
Endlessly productive, Ricoh’s new P502 responds quickly to workgroup black and white print requirements, producing
high quality office documents.
Impressive quality and performance
1,200 x 1,200 dpi quality
First page ready in 5 sec.
Fast 43 ppm throughput
Up to four paper trays
exceptional speed, quality and reliability throughout long runs.
Its powerful Intel 1.3 GHz processor effortlessly processes
complex jobs and eliminating bottlenecks, the printer delivers
its first pristine 1,200 x 1,200 dpi print in under 5 seconds.
Multi-page document sets are produced at a blistering 43
pages per minute.
Page 2
Compact, quiet and economical
Space-saving design
Up to four paper trays
Low cost of ownership
17.400 pages starter toner
Fast, easy to use and secure, the Ricoh P502 can meet ALL
enterprise black and white print requirements. The intuitive
PCL and PostScript drivers simplify operation, employees can
print directly from their iOS and Android devices, and it is
easy to password protect and lock confidential documents.
And, what is more, to safeguard business security, the
intelligent platform supports the use of integrated workflow
solutions, such as Ricoh StreamLine NX.
Optional paper trays enhance productivity. Envelopes,
letterheads and forms can be fed automatically and with the
printer switching seamlessly between trays, it need never run
out of paper. Thanks to its compact design and quiet
operation, the Ricoh P502 can be positioned on a desk or
under a counter, within easy reach of workgroup users. And,
with its smart energy saving features and high yield toner
cartridges, the Ricoh P502 offers a low Total Cost of
Ownership.
Secure desktop and mobile printing
PCL and PS3 drivers
iOS and Android support
Confidential printing
Enterprise-level security
Page 3
RICOH P 502
MAIN SPECIFICATIONS
GENERAL
Warm-up time 19 seconds
First output speed: B/W 5 seconds
Continuous output speed 43 ppm
Memory: standard 2 GB
HDD: maximum 320 GB
Weight 19.3 kg
Dimensions: W x D x H 375 x 412 x 311 mm
Power source 220 - 240 V, 50/60 Hz
PRINTER
Printer language: standard PCL5e
Printer language: option Genuine Adobe ®PostScript®3™
Print resolution: maximum 1,200 x 1,200 dpi
Network interface: standard Ethernet 10 base-T/100 base-TX/1000 base-T
Network interface: option Bi-directional IEEE 1284/ECP
Wireless LAN (IEEE 802.11a/b/g/n)
Mobile printing capability Apple AirPrint™
Ricoh Smart Device Connector
Network protocol TCP/IP (IP v4, IP v6)
Windows® environments Windows® 7
Mac OS environments Macintosh OS X v10.10 or later
SAP® environments SAP® R/3®, SAP® S/4®
Other supported environments NDPS Gateway
AS/400® using OS/400 Host Print Transform
PAPER HANDLING
Recommended paper size A4, A5, A6, B4, B5, B6
Paper input: standard 500 sheets
Paper input: maximum 2,100 sheets
Paper output: standard 250 sheets
Paper weight 52 - 220 g/m²
Paper types Plain paper
ECOLOGY
Power consumption: max. Less than 1,260 W
TEC 1.7 kWh
OUTPUT TRAYS OPTIONS
3x 250-sheet Paper tray 3x 500-sheet Paper tray
OTHER OPTIONS
Hard Disk Drive VM card IPDS unit Genuine PostScript 3 IEEE 1284 I/F IEEE 802.11 a/b/g/n I/F USB Device Server
PCL6
PostScript 3 (emulation)
PDF direct (emulation)
IPDS
PDF Direct from Adobe®
USB2.0 Type B
USB Host 2.0
Additional NIC (2nd port)
Mopria
Google Cloud Print
NFC
Windows® 8.1
Windows® 10
Windows® Server 2008
Windows® Server 2008R2
Windows® Server 2012
Windows® Server 2012R2
Windows® Server 2016
Device Option Utility (Citrix)
Linux environment
Recycle paper
Preprinted paper
Envelope
Label paper
OHP
Page 4
RICOH P 502
MAIN SPECIFICATIONS
CONSUMABLES
Starter toner 17,400 prints
Drum 70,000 sheets
Toner (regular yield) 17,400 prints
Photo conductor/developer unit Black (70,000 sheets)
Consumable yield measuring method ISO/IEC 19752
