Ricoh MPC3003 User Manual

Multifunction Color

RICOH
MP C3003/MP C3503/
MP C4503/MP C5503/
MP C6003

SERIES

Copier Printer Facsimile Scanner

MP C3003

monochrome

30

and full-color

ppm

MP C3503

monochrome

35

and full-color

ppm

MP C5503

monochrome

55

and full-color

ppm

MP C4503

monochrome

45

and full-color

ppm

MP C6003

monochrome

60

and full-color

ppm

Power, precision and productivity — just for you

The RICOH® MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 series of Multifunction

Products (MFPs) is engineered to work the way you do. It combines high-quality, full-color output

with productivity-enhancing capabilities so you can leverage a wider range of information in newer,

smarter ways. Transform your MFP into an information portal by connecting to the cloud from your

smartphone, tablet or other mobile device and use these powerful systems to print, share and discover

the value of customized convenience. Packed with advanced versatility and energy-saving features in

a space-saving design, it’s ideal for fast-paced offices with heavy workloads. Choose it as the primary

system for your workgroup or as an integral part of the Ricoh Managed Document Services (MDS)

strategy and boost productivity throughout your organization.

• High-performance and convenience in a quiet, compact design

• Mobile connectivity for faster, more efficient workflow

• Intuitive, familiar controls for versatile, multifunction performance

• A single solution for smarter printing, copying, scanning and optional faxing

• Measurable eco-performance saves energy, reduces consumption and lowers operating costs

Streamline workflow to improve productivity

Advanced capabilities for convenient control

Fast, reliable production

This powerful and innovative MFP series delivers high-quality, monochrome
or color output at up to 60 ppm for incredible throughput. The Ricoh
MP C3003 and MP C3503 feature a 100-Sheet Automatic Reversing
Document Feeder (ARDF) while the MP C4503, MP C5503 and
MP C6003 come standard with a 220-Sheet Single Pass Document
Feeder (SPDF) for fast-paced 180 ipm duplex scanning. Select the
Internal Finisher* to save floor space or choose from a wide range of
external finishers to expedite workflow.

*Not available on the MP C6003

Functionality made to look easy

Complete even the most complex tasks with ease. The MFP’s
9-inch, full-color, tiltable control panel allows you to easily access
a host of features. Remove paper misfeeds quickly by following
synchronized animated guides or LED lights** that help identify the
source of the problem. Plus, the Auto Drawer feature completes
the paper tray retraction automatically once the user begins to
push the drawer closed.

**LED lights are not available on the MP C3003/MP C3503

Anytime, anywhere performance

The Ricoh MP C3003/MP C3503/MP C4503/MP C5503/MP C6003
can print from many mobile devices, including smartphones, tablets
or laptops, without device-specific drivers for incredible on-the-go
convenience. For organizations seeking even more secure mobile
printing, the optional Ricoh HotSpot
server software can be installed to help improve mobile productivity
without compromising data, document or user security. Plus, users
can print JPEGs, TIFFs and PDFs using a USB drive or SD card right
at the device without LAN access or native applications.

®

MFP, or Ricoh HotSpot® Enterprise

Print at your pace — with Ricoh quality

Where power meets convenience

With a powerful processor and ample RAM, the Ricoh MP C3003/
MP C3503/MP C4503/MP C5503/MP C6003 enables your entire
workgroup to produce impressive, fast-paced output. Streamline
workflow and simplify execution with the one-click, preset interface
driver or optional Adobe
administrative controls, quotas can be set to limit outputs for
specific users or workgroups.

®

PostScript® 3™ driver. With advanced

When quality is the first choice

The MFP recalibrates as documents are processed for more stability
with minimal color deterioration. Every page is delivered with crisp,
vibrant, affordable color using patented PxP

®

-EQ toner at up to 1200 dpi
— even on thicker paper stocks up to 300 gsm/110 lb. cover. Paper
capacity is an astounding 4,700 sheets with optional sources and the
standard paper tray accepts a wide range of paper sizes, including
envelopes. Plus, optional SRA3/12.6" x 17.7" support gives in-house
graphic designers the ability to print crop marks for full-bleed printing.

How organizations maintain better print
control

Choose the optional Fiery® Controller for compelling, professional­grade output — including photos, brochures, flyers and more —
on a wider range of paper stocks. Ideal for graphics-intensive
environments, the controller offers exceptional enhanced spot-color
reproduction with RGB, CMYK and PANTONE
easy-to-use Command WorkStation utility simplifies even the most
complex print tasks, so documents can be created, reprinted or
combined with ease.

®

colors. Plus, its

PATIO

SILVER GREEN CONSTRUCTION

ADDRESS: 123 Countryside Road, Madison, NY 12345

CONTRACTOR: Logan Smith

CONTACT: 1-123-456-7890

PROJECT: AP-JY-SC-3567-098754-XYF

LIVING ROOM

FLOOR PLAN

Customization for faster, smarter workflow

Capture and share documents

Choose the Ricoh MP C3003/MP C3503/MP C4503/MP C5503/
MP C6003 to share your best ideas in better ways. Monochrome
and color scanned documents can be sent to multiple recipients
with Scan-to-Email/Folder/URL/FTP. Compress file sizes for full-color
scans and send them easily without compromising image quality.
Take advantage of centralized Distributed Scan Management (DSM)
while following specific preferences and rules to automate document
tasks and improve productivity. The innovative MFP also lets you
send faxes directly from a PC and automatically routes inbound faxes
to e-mail addresses or network folders for fast, secure delivery.

Work quickly, efficiently

Greater productivity comes automatically with the Ricoh MP C3003/
MP C3503/MP C4503/MP C5503/MP C6003. With optional embedded
OCR, users can retrieve documents quickly by searching for specific
words in PDF text in up to 14 languages. The optional built-in Web
browser connects to Ricoh’s Integrated Cloud Environment (ICE) so
users can scan documents, share files, print on the move and more
without expensive, onsite software solutions. Users can also work
more efficiently by copying the front and back sides of identification
cards and other documents onto one side to save paper and time.

Customized for your office

The Ricoh MP C3003/MP C3503/MP C4503/MP C5503/MP C6003
comes standard with a large 9", tiltable Color Control Panel with
a customizable home screen and the ability to create one-click
shortcuts for frequently used applications. Plus, you can take
advantage of a wide range of optional software, including
GlobalScan
into personalized workflows and simplify the most complex tasks.

®

NX and eCopy® to integrate advanced capabilities

Flexibility leads to productivity

Step up your productivity with Ricoh’s
leading edge display technology

Ricoh’s optional 10.1" Wide Super VGA Smart Operation Panel
offers the functionality and performance of today’s smartphones
and tablets. Featuring drag-and-drop, pinch-and-flick functionality
and swipe scrolling, it allows users to quickly move from one task
to the next with unprecedented ease. It even includes convenient
widgets for quick updates on the date, time and toner levels.

Simplicity at its best

Ricoh’s new Quick User Interface feature simplifies the choices
for the most frequently used functions for Copy, Scanner and Fax.
They can be used with intuitive touch gestures, such as flicking to
select addresses, and pinching to zoom in or pan out on a preview.

The smarter way to work

For workgroups requiring enhanced feature functionality, it is easy
to switch between the Quick User Interface functions and Ricoh’s
traditional user interface. Plus the new panel also offers advanced
Web Browser functionality on par with today’s mobile devices.

Multifunction performance for today’s
business challenges

Manage to improve performance

Simplify administrative tasks with a wide range of convenient controls
for system management, device monitoring and troubleshooting.
Use a Web browser to access system settings and address books
or configure and monitor an entire fleet of Ricoh devices — right
from your desktop. Get alerts and up-to-the-minute data when the
device is low on supplies, experiences an error or needs firmware
updates. Plus with @Remote
to maximize administrative efficiency.

Strong commitment to the environment
with eco-conscious design

Make an impact with customers — and the environment. The Ricoh
MP C3003/MP C3503/MP C4503/MP C5503/MP C6003 includes
a host of features for an incredibly low TEC value*. It can be
programmed to power on and off with a Weekly Timer to conserve
energy when not in use. It recovers from sleep mode with a fast, less
than 10-second recovery time to preserve resources and productivity.
The innovative PxP
less energy and minimizes operating costs. In addition, automatic
duplexing minimizes paper consumption and operating costs.

*Sourc e: ENERGY STAR Imaging Equipment Pr oduct L ist posted on June, 19, 2013.

®

-EQ toner melts at lower temperatures, requires

®

, you can even automate meter reads

Unrivaled security to protect your greatest
assets

The Ricoh MP C3003/MP C3503/MP C4503/MP C5503/MP C6003
includes user authentication to help prevent unauthorized access.
It enables users to store documents at the MFP until an ID Card* is
swiped or password is entered to release them. A watermark can be
added to confidential documents that will appear when unauthorized
users attempt to copy them. Encrypted PDF transmission scrambles
data on confidential PDFs to help prevent unauthorized access.
In addition, the MFP includes the standard DataOverwriteSecurity
System (DOSS) that automatically overwrites any files on the hard
drive to render them unreadable. HDD encryption adds another layer
of protection against hackers.

*Requires opti onal card read er and softwa re.

Full-featured, multifunction
performance for any office

2

5

1

3

4

6

6

8

6

Ricoh MP C6003 shown with optional
SR3160 Finisher, 1 Bin Tray (BN3110),
Two-Tray Paper Bank (PB3160) and
Side LCT (RT3030)

7

7

1

3,000-Sheet Stapler Finisher:

Accommodate up to 50-sheet
document sets with a choice of three single staple positions or
a double staple. An optional 2/3-Hole Punch Unit installs inside
the finisher.

2

220-Sheet Single Pass Document Feeder (SPDF):

The standard
SPDF for the MP C4503/MP C5503/MP C6003 offers high-speed,
single-pass color and black-and-white duplex copying and scanning.

3

Full-Color 9" Control Panel with SD/USB Slot:

Navigate from job to
job easily with the tiltable touch screen featuring a user-friendly slot
for SD/USB cards, a customizable home screen to link to commonly
performed jobs and more.

4

Automatic Duplexing:

Save paper and filing space with standard

automatic duplexing that runs at the same speed as one-sided output.

5

125-Sheet One Bin Tray:

Separate output and simplify document

retrieval for prints up to 12.6" x 17.7".

6

Paper Trays (Standard):

Standard paper sources include two
550-Sheet Paper Trays and a 100-Sheet Bypass Tray for a total
capacity of 1,200 sheets. Tray 2 accommodates envelopes for
in-house printing and a wide variety of mailing applications.

7

Two-Tray Paper Feed Unit (Optional):

Expand paper capacity by
1,100 sheets and support paper sizes up to 12" x 18" & SRA3.
A One-Tray PFU (550 sheets), Tandem LCT (2000 sheets) and
Cabinet (Type F) are also available as options.

8

1,500-Sheet Side Large Capacity Tray (Optional):

Minimize
re-loading of 8.5" x 11"/A4 paper sizes and expand the system’s
total paper capacity with the Side Large Capacity Tray.

For professional grade image quality, the MFP continually
calibrates as documents are printed to ensure stable image
quality with minimal color deterioration.

Comprehensive features
in a compact design

2

5

1

3

4

6

6

8

6

Ricoh MP C3503 shown with optional

7

SR3150 Booklet Finisher, 1 Bin Tray
(BN3110), Tandem Large Capacity Tray
(PB3170) and Side LCT (RT3030)

1

1,000-Sheet Booklet Finisher (Optional):

three destinations for output, including the ability
to produce paginated, saddle-stitched, punched
and folded booklets, greatly expanding your
in-house capabilities.

2

100-Sheet Automatic Reversing Document Feeder
(ARDF): The standard ARDF for the MP C3003/

MP C3503 handles multi-page, multi-sized originals
with ease.

3

Full-Color 9" Control Panel with SD/USB Slot:

Navigate from job to job easily with the tiltable
touch screen featuring a user-friendly slot for
SD/USB cards, a customizable home screen to
link to commonly performed jobs and more.

4

Automatic Duplexing:

with standard automatic duplexing that runs at the
same speed as one-sided output.

Save paper and filing space

Provides

5

125-Sheet One Bin Tray:

document retrieval for prints up to 12.6" x 17.7".

6

Paper Trays (Standard):

include two 550-Sheet Paper Trays and a 100-Sheet
Bypass Tray for a total capacity of 1,200 sheets.
Tray 2 accommodates envelopes for in-house
printing and a wide variety of mailing applications.

7

Large Capacity Tray (Optional):

and copy runs, choose the 2,000-Sheet LCT to
handle 8.5" x 11"/A4 paper sizes. A One-Tray PFU
(550 sheets), Two-Tray PFU (2 x 550 sheets) and
Cabinet (Type F) are also available as options.

8

1,500-Sheet Side Large Capacity Tray (Optional):

Minimize reloading of 8.5" x 11"/A4 paper sizes and
expand the system’s total paper capacity with the
Side Large Capacity Tray.

Separate output and simplify

Standard paper sources

For extended print

Finish in style

Choose from five powerful finishers to give every project a professional-grade touch. Each finisher offers a wide range of
advanced capabilities to produce almost any type of document with less labor for less cost. Select the finishing unit and
Ricoh multifunction color system that accommodates your unique workplace requirements.

SR3130 Internal Finisher SR3140 Stapler Finisher SR3160 Stapler Finisher SR3150 Booklet Finisher SR3170 Booklet Finisher

Finisher Paper Capacity Hole-Punch Saddle Stitch Supported Systems

SR3130 Internal Finisher

500 Sheets Optional N/A MP C3003/MP C3503/MP C4503/MP C5503

SR3140 Stapler Finisher 1,000 Sheets Optional N/A All

SR3160 Stapler Finisher 3,000 Sheets Optional N/A MP C4503/MP C5503/MP C6003

SR3150 Booklet Finisher 1,000 Sheets Optional

SR3170 Booklet Finisher 2,000 Sheets Optional

General Specifications

Printing Process 4-Drum Method
Output Speed MP C3003: 30-ppm B&W & FC (LTR)
(Copy/Print) MP C3503: 35-ppm B&W & FC (LTR)

MP C4503: 45-ppm B&W & FC (LTR)
MP C5503: 55-ppm B&W & FC (LTR)

Warm-Up Time Less than 20 seconds
Recovery from Less than 10 seconds
Sleep Mode
First Copy Time (FC/B&W) 7.1/4.6 seconds (MP C3003/MP C3503)

5.7/4 seconds (MP C4503)

4.5/3.1 seconds (MP C5503/MP C6003)

Copy Resolution 600 dpi
Quantity Indicator Up to 999 copies

Document Feeder (Standard on MP C3003/MP C3503)

Automatic Reversing Original Capacity: 100 sheets
Document Feeder Original Size: 5.5" x 8.5" – 11" x 17"
(ARDF) (A5 – A3)
Paper Weight:

Document Feeder (Standard on MP C4503/MP C5503/MP C6003)

Single Pass Document Original Capacity: 220 sheets
Feeder (SPDF) Original Size: 5.5" x 8.5" – 11" x 17"
(A5 – A3)

Paper Weight:

Paper Capacity Standard: 2 x 550 sheets + 100-Sheet

Supported Paper Sizes 1st Paper Tray: 8.5" x 11" (A4)

2nd Paper Tray: 5.5" x 8.5" – 12" x 18",

Supported Paper Standard Trays: 14 – 80 lb. Bond/
Weights 166 lb. Index (52 – 300 g/m

Paper Types Plain, Recycled, Letterhead, Cardstock,

*Bypass Tray Only

MP C6003: 60-ppm B&W & FC (LTR)

Simplex: 11 – 34 lb. Bond (40 – 128 g/m2)
Duplex: 14 – 34 lb. Bond (52 – 128 g/m2)

Simplex: 11 – 34 lb. Bond (40 – 128 g/m2)
Duplex: 14 – 34 lb. Bond (52 – 128 g/m2)

Bypass Tray, Maximum: 4,700 sheets
(w/Tandem LCT + Side LCT)

Envelopes
Bypass: Up to 12" x 18", Envelopes
Custom Sizes: Width: 3.5" – 12.6"
(90 – 320 mm), Length: 5.8" – 23.6"
(148 – 600 mm) Fax/Printer; 5.8" – 18"
(148 – 457 mm) Copy/Document Server

Bypass Tray: 14 – 80 lb. Bond/
166 lb. Index (52 – 300 g/m2)
Duplex Unit: 14 – 68 lb. Bond/
142 lb. Index (52 – 256 g/m2)

Preprinted Paper, Bond Paper, High-Gloss
Coated Paper, Color Paper, Envelopes,
Labels* & OHP*

2

)

Auto Duplex Standard
Output Capacity Standard: 500 sheets

Maximum: 1,625 sheets (MP C3003/

Zoom 25% – 400% in 1% increments
Dimensions (WxDxH) MP C3003/MP C3503:
(Includes Feeder) 23.1" x 27.0" x 35.9" (587 x 685 x 912 mm)

MP C4503/MP C5503/MP C6003:

Weight MP C3003/MP C3503: 205.1 lbs. (93.1 kg)
MP C4503/MP C5503: 220.2 lbs. (99.9 kg)
MP C6003: 221.3 lbs. (100.4 kg)

Power Requirements 120V – 127V, 60Hz, 12A
Power Consumption 1,584W or less
TEC Value* MP C3003: 1.16 kWh/week

MP C3503: 1.32 kWh/Week

MP C5503: 2.58 kWh/Week
MP C6003: 2.77 kWh/Week

* Typical Electricity Consumption by ENERGY STAR Qualified Imaging

Equipment Test Procedure

Printer Specifications (Standard)

CPU PMC-Sierra RM7035 600 MHz

Memory 1.5 GB RAM/250GB HDD Standard &

2GB RAM/250GB HDD Standard &

Page Description Standard: PCL5c, PCL6, PDF Direct
Languages Print, Media Print & XPS

Optional: Adobe PostScript3, IPDS &

Font Support Standard: PCL: 45 Scalable fonts +

Optional: PostScript 3: 136 Roman fonts;

Max. Print Resolution 1200 x 1200 dpi
Network Interfaces Standard: 1000Base-T/100Base-TX/

Network Protocol Support TCP/IP (IPv4, IPv6), IPX/SPX*
Network/OS Windows XP/Vista/7/8/Server 2003/

4

4

MP C3503); 3,625 sheets (MP C4503/
MP C5503/MP C6003)

23.1" x 27.0" x 37.9" (587 x 685 x 963 mm)

MP C4503: 1.85 kWh/Week

(MP C3003/MP C3503)
Intel Celeron Processor U3405 1.07GHz
(MP C4503/MP C5503/MP C6003)

2GB RAM/250 GB HDD Maximum
(MP C3003/MP C3503)

Maximum (MP C4503/MP C5503/
MP C6003)

PictBridge

International 13 fonts

IPDS: 108 Roman fonts

10Base-T Ethernet, USB2.0 Type A
(3 Ports), USB2.0 Type B & SD Slot
on Operation Panel

Server 2008/Server 2008R2/Server
2012, Netware 6.5*

All

MP C4503/MP C5503/MP C6003

Unix; Sun Solaris, HP-UX, SCO

Mac OS X v.10.5 or later,
SAP R/3, NDPS Gateway,
IBM iSeries AS/400-using OS/400

Utilities

Web SmartDeviceMonitor

Web Image Monitor, @Remote

Document Server Specifications (Standard)

Max. Stored Documents 3,000 documents
Max. Page Capacity 9,000 pages

OpenServer, RedHat Linux, IBM AIX,

Host Print Transform

Scanner Specifications (Standard)

Scanner Resolution B&W and FC scanning at 100 – 600

Scanning Speed 200/300 dpi: 79 ipm (MP C3003/
(B&W & Color LTR) MP C3503) and 110 ipm Simplex/

Scan Area 11.7" x 17" (297 mm – 432 mm)
Compression Method B&W: MH, MR, MMR, JBIG2, JPEG

Supported File Single/Multi-Page TIFF, PDF,
Formats High Compression PDF & PDF/A

Single Page JPEG
Scan Modes Scan-to-Email (with LDAP support)
Scan-to-Folder (SMB/FTP/NCP*)
Scan-to-URL
Scan-to-Media (USB/SD Card)

*Netware option is required

dpi, Up to 1200 dpi for TWAIN scanning

180 ipm Duplex (MP C4503/MP C5503/
MP C6003)

Color: JPEG

Network TWAIN Scanning

Facsimile Specifications (Optional)

Type Fax Option Type M4 (MP C4503/

Resolution 200 x 100 dpi, 200 x 200 dpi, 400 x

Modem Speed 33.6K – 2,400 bps w/Auto Fallback
Compression Method MH, MR, MMR, JBIG
Transmission Speed G3: Approximately 2 seconds/page (JBIG)
Scanning Speed Up to 68 spm (MP C3003/MP C3503)

Auto Dialing 2,000 Quick/Speed Dial numbers;

Memory Capacity

(SAF)

MP C5503/MP C6003) and Fax Option
Type M3 (MP C3003/MP C3503)

400 dpi (with optional SAF memory)

and 82 spm (MP C4503/MP C5503/
MP C6003)

100 Group Dial numbers

Standard: 4 MB (approx. 320 pages),

Optional: 28 MB (approx. 2,240 pages)
with optional SAF memory

™

Ricoh MP C3003/MP C3503/MP C4503/MP C5503/MP C6003

SYStem SpecificationS

Security Features (Standard)

DataOverwriteSecurity System (DOSS), HDD Encryption, User Codes,
SNMP v3 Support, Encryption, Locked Print, User Authentication,

802.1x Wired Authentication, Quota Setting/Account Limit, Digitally
Signed PDF, and more

Hardware Accessories

Paper Handling Options

Two-Tray Paper Bank (PB3160)

Tray Capacity 1,100 sheets (550 sheets x 2 trays)
Paper Size 7.25" x 10.5" to 12" x 18" (A5 – A3)
Paper Weight 14 – 80 lb. Bond/166 lb. Index (52 – 300 g/m
Dimensions (WxDxH) 23.1" x 27" x 9.7" (587 x 685 x 247 mm)

One-Tray Paper Bank (PB3150)

Tray Capacity 550 sheets x 1 tray
Paper Size 7.25" x 10.5" to 12" x 18" (A5 – A3)
Paper Weight 14 – 80 lb. Bond/166 lb. Index (52 – 300 g/m
Dimensions (WxDxH) 23.1" x 27" x 4.7" (587 x 685 x 120 mm)

Requires installation of Caster Table Type M3

Tandem Large Capacity Tray (PB3170)

Tray Capacity 2,000 sheets (1,000 sheets x 2)
Paper Size 8.5" x 11" (A4)
Paper Weight 14 – 80 lb. Bond/166 lb. Index (52 – 300 g/m
Dimensions (WxDxH) 23.1" x 27" x 9.7" (587 x 685 x 247 mm)

Side Large Capacity Tray (RT3030)

Tray Capacity 1,500 sheets
Paper Size 8.5" x 11" (A4)
Paper Weight 14 – 80 lb. Bond/166 lb. Index (52 – 300 g/m
Dimensions (WxDxH) 13.4" x 21.4" x 11.4" (340 x 545 x 290 mm)

Requires installation of Two-Tray Paper Bank (PB3160) or Tandem LCT (PB3170)

Output Trays & Finisher Options

Internal Shift-Sort Tray (SH3070)3

Tray Capacity 250 sheets (8.5" x 11" or smaller) (A4 – A5)
125 sheets (8.5" x 14" or larger) (B4 – A3)

Paper Size 5.5" x 8.5" to 12" x 18" (A6 – A3)
Paper Weight 14 – 80 lb. Bond/166 lb. Index (52 – 300 g/m

Cannot be installed with any Finisher

1 Bin Tray (BN3110)

Paper Size 5.5" x 8.5" to 12.6" x 17.7" (A6 – A3)
Paper Weight 14 – 80 lb. Bond/166 lb. Index

Tray Capacity 125 Sheets

500-Sheet Internal Finisher (SR3130)3

Paper Size 5.5" x 8.5" to 12" x 18" (A6 – A3)
Paper Weight 14 – 80 lb. Bond/166 lb. Index (52 – 300 g/m
Stack Capacity 500 sheets (8.5" x 11" or smaller) (A4)

Staple Paper Size 7.25" x 10.5" to 11" x 17" (A4 – A3)
Staple Paper Weight 14 – 28 lb. Bond (52 – 105 g/m
Staple Capacity 50 sheets (8.5" x 11") (A4)

Staple Positions Top, Bottom, 2 Staples
Dimensions (WxDxH) 21.5" x 20.6" x 6.7" (546 x 523 x 170 mm)

Not available on MP C6003

2-/3-Hole Punch Unit (PU3040NA)

(

Optional; Installs inside SR3130 Internal Finisher)

Punch Paper Sizes 7.25" x 10.5" to 11" x 17" (A4 – A3)
Punch Paper Weight 14 – 43 lb. Bond/90 lb. Index (52 – 163 g/m

1,000-Sheet Finisher (SR3140)

Paper Size Proof Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Shift Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Paper Weight Proof Tray: 14 – 45 lb. Bond/93 lb. Index

Shift Tray: 14 – 80 lb. Bond/166 lb. Index

Stack Capacity Proof Tray: 250 sheets (8.5" x 11") (A4)
50 sheets (8.5" x 14" or larger) (B4)
Shift Tray: 1,000 sheets (8.5" x 11") (A4)
500 sheets (8.5" x 14" or larger) (B4)

Staple Capacity 50 sheets (8.5" x 11") (A4)

Staple Paper Size 8.5" x 11" to 12" x 18" (A4 – A3)
Staple Paper Weight 14 – 28 lb. Bond (52 – 105 g/m
Staple Positions Top, Bottom 2 Staples
Dimensions (WxDxH) 25.4" x 24.4" 37.8" (646 x 620 x 960 mm)

1

1

1

(52 – 300 g/m2)

250 sheets (8.5" x 14" or larger) (B4 – A3)

2

)

30 sheets (8.5" x 14" or larger, and/or
Mixed Sizes) (B4 – A3)

2 3 4

(52 – 169 g/m

(52 – 300 g/m

30 sheets (8.5" x 14" or larger) (B4)

2

)

2

)

2

)

1,000-Sheet Booklet Finisher (SR3150)

Paper Size Proof Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Shift Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Booklet Tray: 8.5" x 11" to 12" x 18" (A4 – A3)
Paper Weight Proof Tray: 14 – 45 lb. Bond (52 – 169 g/m
Shift Tray: 14 – 80 lb. Bond/166 lb. Index

Booklet Tray: 14 – 28 lb. Bond (52 – 105 g/m
Stack Capacity Proof Tray: 250 sheets (8.5" x 11" or

50 sheets (8.5" x 14" or larger) (B4 – A3)

2

)

500 sheets (8.5" x 14" or larger) (B4 – A3)

Staple Capacity Normal Staple: 50 sheets (8.5" x 11") (A4)

2

)

Staple Paper Size Normal Staple: 8.5" x 11" to 12" x 18"

Staple Paper Weight 14 – 28 lb. Bond (52 – 105 g/m

2

)

Staple Positions Top, Bottom, 2 Staples, Booklet
Dimensions (WxDxH) 25.4" x 24.4" x 37.8" (646 x 620 x 960 mm)

2-/3-Hole Punch Unit (PU 3050NA)

(

Optional; Installs inside SR3150 or SR3140 Finishers)

Punch Paper Sizes 5.5" x 8.5" to 11" x 17" (A5 – A3)

2

)

Punch Paper Weight 14 – 68 lb. Bond/142 lb. Index (52 – 256 g/m

2,000-Sheet Booklet Finisher (SR3170)

Paper Size Proof Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Shift Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Booklet Tray: 8.5" to 12" x 18" (A4 – A3)
Paper Weight Proof Tray: 14 – 58 lb. Bond/122 lb. Index

Shift Tray: 14 – 80 lb. Bond/166 lb. Index

2

)

Booklet Tray: 17 – 28 lb. Bond (64 – 105 g/m
Stack Capacity Proof Tray: 250 sheets (8.5" x 11" or

Booklet Tray: 30 sets (2 – 5 sheets) or

2

)

Staple Capacity Normal Staple: 50 sheets (8.5" x 11" to

Saddle Stitch: 20 sheets
Staple Paper Size Normal Staple: 8.5" x 11" to 11" x 17"

Saddle Stitch: 8.5" x 11" to 12" x 18"

Staple Paper Weight 14 – 28 lb. Bond (52 – 105 g/m
Staple Positions Top, Bottom, 2 Staples, Top Slant,

Dimensions (WxDxH) 25.9" x 24.1" x 37.8" (657 x 613 x 960 mm)

Not available on MP C3003/MP C3503

3,000-Sheet Finisher (SR3160)

Paper Size Proof Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)

2

)

Shift Tray: 5.5" x 8.5" to 12" x 18" (A6 – A3)
Paper Weight Proof Tray: 14 – 58 lb. Bond/122 lb. Index

Shift Tray: 14 – 80 lb. Bond/166 lb. Index

Stack Capacity Proof Tray: 250 sheets (8.5" x 11" or

50 sheets (8.5" x 14" or larger) (B4)
Shift Tray: 3,000 sheets (8.5" x 11") (A4)
1,500 sheets (8.5" x 14" or larger) (B4)

Staple Capacity 50 sheets (8.5" x 11" to 11" x 17" or

Staple Paper Size 8.5" x 11" to 11" x 17" (A4 – A3)
Staple Paper Weight 14 – 28 lb. Bond (52 – 105 g/m
Staple Positions Top, Bottom, 2 Staples, Top Slant
Dimensions (WxDxH) 25.9" x 24.1" x 37.8" (657 x 613 x 960 mm)

Not available on MP C3003/MP C3503

2-/3-Hole Punch Unit (PU3060NA)

(Optional; Installs inside SR3160 or SR3170 Finishers)

Punch Paper Sizes 5.5" x 8.5" to 11" x 17" (A5 – A3)
Punch Paper Weight 14 – 68 lb. Bond/142 lb. Index (52 – 256 g/m

(52 – 300 g/m

smaller) (A4)

Shift Tray: 1,000 sheets (8.5" x 11" or
smaller) (A4)

Booklet Tray: 20 Sets (2 – 5 sheets), 10 Sets
(6 – 10 sheets) & 7 Sets (11 – 15 sheets)

30 sheets (8.5" x 14" or larger) (B4 – A3)
Saddle Stitch: 15 sheets

(A4 – A3)
Saddle Stitch: 8.5" x 11" to 12" x 18"
(A4 – A3)

(52 – 220 g/m

(52 – 300 g/m

smaller) (A4)
50 sheets (8.5" x 14" or larger) (B4)
Shift Tray: 2,000 sheets (8.5" x 11" or
smaller) (A4)
1,000 sheets (8.5" x 14" or larger) (B4)

15 sets (6 – 10 sheets) or 10 sets (11 – 15
sheets) or 6 sets (16 – 20 sheets)

11" x 17" and Mixed Sizes) (A4 – A3)

(A4 – A3)

(A4 – A3)

Booklet

(52 – 220 g/m

(52 – 300 g/m

smaller) (A4)

Mixed Sizes) (A4 – A3)

2 3 4

2

)

2 3 4

2

)

2

)

2 3 4

2

)

2

)

Color Controller E-22C

Controller Type Embedded Type
Fiery Platform FS100
CPU Intel Processor G850 2.9GHz

2

)

Host Interface 1000Base-T/100Base-TX/10Base-T
Memory 2 GB
Internal HDD 500 GB

2

)

Operating System Linux
Network Protocol TCP/IP (IPv4/IPv6), SMB, Bonjour
Printer Description Standard: PostScript 3 & PCL6/5c
Language
Max Print Resolution Up to 1200 dpi (2 bit)
Max Scan Resolution Up to 600 dpi
Fonts PS3: 138 fonts/PCL: 81 AGFA fonts
Utilities Standard: Command WorkStation 5,

Optional: Fiery Impose, Fiery Compose,

2

)

Color Management Tools ICC Profile, Color Chart, CMYK Color

Fiery Scan, Printer Delete Utility, Fiery
Web Tools, Fiery Bridge, Secure Erase
and Fiery VUE

Fiery Auto Trap, EFI Spot-On, Fiery Hot
Folders, Fiery Color Profiler Suite v4.0,
Fiery ES-2000 Spectrophotometer and
EFI Productivity Pack

Reference Pages, RGB Color Tests,
Trapping Support and ColorWise Pro Tools

Additional Accessories
for MP C3003/MP C3503

2

)

Bridge Unit BU3070, Browser Unit Type M3, Cabinet Type F, Camera
Direct Print Card Type M3, Card Reader Bracket Type 3352, Color
Controller Connection Board Type M3, Copy Data Security Unit Type
G, ESP XG-PCS-15D, External Keyboard Bracket Type M3, Fax
Connection Unit Type M3, File Format Converter Type E, G3 Interface
Unit Type M3, HotSpot MFP Option Type S, IEEE 802.11a/g/n
Interface Unit Type M2, IEEE 1284 Interface Board Type A, Imageable
Area Extension Unit Type M3, IPDS Unit Type M3, Key Counter
Bracket Type M3, Memory Unit Type B 32MB, Memory Unit Type

2

M3 2GB, OCR Unit Type M2, Optional Counter Interface Unit Type

)

A, Postscript3 Unit Type M3, SD Card for NetWare Printing Type M3,
Smart Card Reader Built-in Unit Type M2 & Smart Operation Panel
Type M3

Additional Accessories
for MP C4503/MP C5503/MP C6003

Bridge Unit BU3070, Browser Unit Type M4, Cabinet Type F, Camera
Direct Print Card Type M4, Card Reader Bracket Type 3352, Color
Controller Connection Board Type M4, Copy Data Security Unit Type
G, ESP XG-PCS-15D, External Keyboard Bracket Type M3, Fax
Connection Unit Type M4, File Format Converter Type E, G3 Interface
Unit Type M4, HotSpot MFP Option Type S, IEEE 802.11a/g/n
Interface Unit Type M2, IEEE 1284 Interface Board Type A, Imageable
Area Extension Unit Type M3, IPDS Unit Type M4, Key Counter
Bracket Type M3, Memory Unit Type B 32MB, OCR Unit Type M2,

2

)

Optional Counter Interface Unit Type A, Postscript3 Unit Type M4,
SD Card for NetWare Printing Type M4, Smart Card Reader Built-in
Unit Type M2 & Smart Operation Panel Type M3

Consumables
for MP C3003/MP C3503

Item Yield

Black Toner 29,500 pages
Cyan Toner 18,000 pages
Magenta Toner 18,000 pages
Yellow Toner 18,000 pages

Consumables
for MP C4503/MP C5503/MP C6003

Item Yield

Black Toner 33,000 pages
Cyan Toner 22,500 pages
Magenta Toner 22,500 pages
Yellow Toner 22,500 pages

1

2

)

Either the Cabinet Type F or one of the paper options must be installed.

2

Requires configuration with Bridge Unit BU3070.

3

Cannot be installed together.

4

Requires installation of Two-Tray Paper Bank (PB3160) or Tandem Large
Capacity Tray (PB3170).

Some options may not be available at the time of market release.

Specifications are subject to change without notice.

2

For maximum performance and yield, we recommend using genuine Ricoh

)

parts and supplies.

www.ricoh-usa.com

Ricoh Ameri cas Corporation, 70 Valley Stream Pa rkway, Malvern, PA 19355, 1-800- 63-RICOH
Ricoh® and the Ricoh Lo go are registered tradema rks of Ricoh Company, Ltd. All other t rademarks are the prope rty of their respec tive owners. ©2013 Ricoh A mericas Corporation. A ll rights
reserved . The content of this document , and the appearance, features a nd specifications of Ri coh products and ser vices are subject to chang e from time to time without not ice. Products are
shown with opt ional features. While car e has been taken to ensure the accu racy of this information, Ri coh makes no representatio n or warranties about the ac curacy, completeness or ad equacy
of the informati on contained herein, and shal l not be liable for any errors or o missions in these materia ls. Actual results will v ary depending upon use o f the products and ser vices, and the
conditions an d factors affecting p erformance. The only war ranties for Ricoh product s and services are as se t forth in the express warr anty statements accom panying them.

R3444
