Ricoh FT9101 PARTS CATALOG

FT9101

PARTS CATALOG

LOCATION OF UNIT

1. EXTERIOR (A112)

See Page 10

4. UPPER TRAY (A112)

2. FRAME SECTION 2 (A112)

See Page 12

5. MIDDLE TRAY (A112)

3. FRAME SECTION 2 (A112)

See Page 14

6. LOWER TRAY (A112)

See Page 16

FT9101 3 Parts Location and List

See Page 18

See Page 12

LOCATION OF UNIT

7. 1ST & 2ND PAPER FEED SECTION (A112)

See Page 22

10. VERTICAL TRANSPORT SECTION (A112)

8. 3RD PAPER FEED SECTION (A112)

See Page 24

11. OPTICS SECTION 1 (A112)

9. VERTICAL TRANSPORT SECTION 1 (A112)

See Page 26

12. OPTICS SECTION 2 (A112)

See Page 28

FT9101 4 Parts Location and List

See Page 30

See Page 32

LOCATION OF UNIT

13. OPTICS SECTION 3 (A112)

See Page 34

16. OPC SECTION 2 (A112)

14. MAIN CORONA UNIT (A112)

See Page 36

17. OPC CLEANING UNIT 1 (A112)

15. OPC SECTION 1 (A112)

See Page 38

18. OPC CLEANING UNIT 2 (A112)

See Page 40

FT9101 5 Parts Location and List

See Page 42

See Page 44

LOCATION OF UNIT

19. DEVELOPMENT UNIT 1 (A112)

See Page 46

22. CLEANING UNIT (A112)

20. DEVELOPMENT UNIT 2 (A112)

See Page 48

23. FUSING UNIT 1 (A112)

21. TRANSFER AND SEPERATION (A112)

See Page 50

24. FUSING UNIT 2 (A112)

See Page 52

FT9101 6 Parts Location and List

See Page 54

See Page 56

LOCATION OF UNIT

25. DUPLEX & PAPER EXIT SECTION 1 (A112)

See Page 58

28. DUPLEX & PAPER EXIT SECTION 4 (A112)

26. DUPLEX & PAPER EXIT SECTION 2 (A112)

See Page 60

29. DUPLEX & PAPER EXIT SECTION 5 (A112)

27. DUPLEX & PAPER EXIT SECTION 3 (A112)

See Page 62

30. DRIVE SECTION (A112)

See Page 64

FT9101 7 Parts Location and List

See Page 66

See Page 68

LOCATION OF UNIT

31. ELECTRICAL SECTION 1 (A112)

See Page 70

34. ADF EXTERIOR (A112)

32. ELECTRICAL SECTION 2 (A112)

See Page 72

35. ADF FRAME & ELECTRICAL SECT. (A112)

33. ELECTRICAL SECTION 3 (A112)

See Page 74

36. ADF FEED SECTION (A112)

See Page 76

FT9101 8 Parts Location and List

See Page 78

See Page 80

37. ADF DRIVE SECTION (A112)

38. ADF INVERTER SECTION (A112)

39. ADF TRANSPORT SECTION (A112)

See Page 82

40. ADF INTERMEDIATE TRANSPORT UNIT
(A112)

See Page 88

See Page 84

See Page 86

FT9101 9 Parts Location and List

1. EXTERIOR (A112)

FT9101 10 Parts Location and List

1. EXTERIOR (A112)

Index

No.

1 A028 1394 Filter Holder 1
2 A028 1382 Left Door 1
3 AA01 2021 Dust Filter 1
4 AA14 5070 Hinge Shaft 4
5 A028 1444 Center Door Hinge Holder 2
6 A028 1445 Center Door Hinge 2
7 A028 1453 Door Catch Bracket 2
8 A028 1486 Copy Tray Cover 1
9 A028 1587 Left Cover 1
10 A028 2465 Exhaust Fan Duct 1
11 AG07 0002 Door Catch 1
12 A028 2468 Plate Nut - Door Catch (EU) 1
13 AA01 0045 Ozone Filter - Charge 1
14 A028 2450 Ozone Filter Casing (EU) 1
14 A112 2511 Ozone Filter Casing (USA) 1
15 AA15 1229 Seal - 4x174x12 1
16 A028 1652 Rear Left Cover 1
17 A028 1446 Hinge Support Plate 1
18 A028 1662 Decal - Misfeed Removal - English 1
19 A028 1656 Decal - Adding Toner 2
20 A028 1415 Center Door Panel 1
21 A028 1412 Magnet Shielding Plate 1
22 A028 1428 Toner Supply Cover Guide 1
23 A028 1429 Door Catch Bracket - Toner Cover 1
24 A028 1427 Toner Supply Cover 1
25 AA14 5071 Cover Shaft 1
26 A028 1435 Toner Catch Pan 1
27 A028 1409 Grip Shaft 1
28 A028 1406 Center Door 1
29 A028 1421 Door Catch Bracket 1
30 A028 1434 Toner Supply Cover Shaft 2
31 AG05 1032 Door Grip 1
32 A029 1413 Cap 2

Part No. Description

Q’ty Per

Assembly

Index

No.

33 A028 1419 Door Catch Plate 1
34 A028 1417 Safety Switch Feeler Bracket 1
35 A028 1418 Door Stopper 1
36 A028 1481 Inner Cover - Fan Bracket 1
37 AX04 0006 Blower Fan 2
38 A028 5465 Fan Relay Harness 1
39 A028 2977 Decal - B3 1
40 A028 1479 Inner Cover - Front Left 1
41 A112 1313 Upper Right Door 1
42 A028 7815 Entrance Sensor Sheet 1
43 A028 7816 Registration Sensor Sheet 1
44 A028 7961 Manual Feed Lower Guide 1
45 A028 7962 Belt Entrance Guide 1
46 A028 1655 Decal - Misfeed Removal 1
47 A028 1523 Transport Door Hinge 1
48 A028 1476 Inner Cover - Paper Feed Channel 1
49 A028 2975 Decal - A 1
50 A028 2976 Decal - B1 1
51 A028 3070 Middle Cover 1
52 A028 7822 Original Stopper 1
53 A028 7821 Original Exit Tray 1
54 A028 1375 Left Exposure Glass Cover 1
55 5875 5510 Shoulder Screw - M5 2
56 A028 1369 Front Exposure Glass Cover 1
57 A028 1520 Door Hinge 2
58 A028 1473 Inner Cover - Front Upper Left 1
59 A028 1474 Center Upper Cover 1
60 A028 1370 Rear Exposure Glass Cover 1
61 A028 1373 Rear Upper Cover 1
62 A028 1374 Rear Right Upper Cover 1
63 A028 1644 Rear Right Cover (EU) 1
63 A112 2900 Rear Right Cover (USA) 1
64 A028 1372 Right Exposure Glass Cover 1

Part No. Description

Q’ty Per

Assembly

FT9101 11 Parts Location and List

Index

No.

65 A028 1654 Decal - Misfeed Removal - Duplex 1
66 A028 1483 Upper Right Inner Cover 1
67 A029 1460 Copy Tray 1
68 A028 1477 Transport Inner Cover 1
69 A028 1608 Right Cover 1
70 A028 1466 Transport Support Cover 1
71 A028 1469 Door Catch Click 1
72 A028 1470 Safety Switch Bracket 1
73 A028 1471 Transport Cover Bracket 1
74 A028 7818 Exit Tray Plate 1
75 A028 1565 Cover Bracket 1
76 AA01 2055 Dust Filter 2
77 6802 5703 Grounding Wire 1
78 A028 1637 Optics Filter Cover 2

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0344 0060F Philips Truss Head Screw - M4x6
102 0344 0080F Philips Truss Head Screw - M4x8
103 0344 0120F Philips Truss Head Screw - M4x12
104 0951 4008W Philips Screw with Flat Washer - M4
105 0951 3012W Philips Screw with Flat Washer - M3
106 0314 0060W Philips Pan Head Screw - M4x6
107 0313 0350W Philips Pan Head Screw - M3x35
108 0801 1239 Screw - Inner Cover
109 0313 0060W Philips Pan Head Screw - M3x6
110 0324 0080W Philips Sunken Head Screw - M4x8
111 0720 0030E Retaining Ring - M3
112 1105 0153 Clamp
113 0324 0060G Philips Sunken Head Screw - M4x6
114 0809 0022 Door Catch Magnet
115 0801 1185 Philips Truss Head Screw - M4x8

Part No. Description

Q’ty Per

Assembly

FT9101 11 Parts Location and List

A

2. FRAME SECTION 1 (A112)

FT9101 12 Parts Location and List

2. FRAME SECTION 1 (A112)

Index

No.

1 A028 4133 Filter Cover 1
2 AA01 2034 Filter 1
3 A028 4131 Cleaning Duct 1
4 AA18 0019 Hose Joint 2
5 AA18 0018 Hose - 38x500 1
6 A028 5467 Cleaning Cooling Harness 1
7 A028 4137 Fan Case Stopper 1
8 A028 4136 Cooling Fan Case 1
9 AX64 0007 Cooling Fan - DC24V 1
10 A028 4125 Cooling Duct 1
11 A028 4848 Left Rail Guide 1
12 A028 4851 Connector Guide 1
13 5214 1974 Screw - Slider Stopper 4
14 AA14 3194 Stepped Screw - M4x4.7 8
15 AA07 0007 Slide Rail 1
16 A028 4093 Upper Cleaning Holder 1
17 AA15 1273 Seal - 6x10x550 1
18 A028 4871 Oil Pan Stopper 1
19 AA15 2107 Sheet - 1x28x60 1
20 A028 4460 Fusing Entrance Guide Plate 1
21 A028 4462 Fixing Plate - Entrance Guide 1
22 A028 2352 Main Charge Left Guide 1
23 A028 2354 Spring Bracket 12
24 A028 2353 Spring 1
25 A028 4872 Oil Pan Felt 1
26 A028 4870 Oil Pan 1
27 AA17 2004 Upper Cover 1
28 AX50 0021 Elase Lamp 1
29 A028 2415 Erase Unit Guide 1
30 A028 2421 Potential Sensor Bracket 1
31 AW33 0002 OPC Potential Sensor 1
32 A028 2357 Main Charge Right Guide 1
33 AA07 0008 Slide Rail 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 AA07 0006 Slide Rail 1
35 AA10 1005 Plate Nut 1
36 A028 2697 OPC Belt Unit Fixing Stay 1
37 AA07 0005 Slide Rail 1
38 A028 3456 Right Slider 1
39 AA07 0009 Slide Rail 2
40 A028 3455 Slider Rail Right Bracket 1
41 A028 6688 Duplex Rail 1
42 A028 1190 Right Lower Supply Plate 2
43 5442 1659 Stepped Screw - M4 4
44 A028 7110 Left Sweeper Guide 1
45 AA14 0230 Left Rail Guide Shaft 1
46 AA14 0231 Right Rail Guide Shaft 1
47 A028 5461 Relay Harness 1
48 A028 7105 Right Sweeper Positioning Pin 2
49 A028 3452 Slide Rail Left Bracket 1
50 A028 3453 Left Slider 1
51 A028 1192 Center Stay 1
52 A028 5454 Duplex Unit Relay Harness 1
53 AA14 3062 Shoulder Screw - M4 1
54 A004 1762 Mylar Seal - 40 X 50 mm 1
55 AA14 8176 Rear Positioning Pin 1
56 A028 2416 Spring Plate Bracket 1
57 A028 5385 Bushing 1

Part No. Description

Q’ty Per

Assembly

FT9101 13 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0313 0060W Philips Pan Head Screw - M3x6
104 0313 0300W Philips Pan Head Screw - M3x30
105 0314 0040W Philips Pan Head Screw - M4x4
106 0315 0080W Philips Pan Head Screw - M5x8
107 0315 0100W Philips Pan Head Screw - M5x10
108 0315 0120W Philips Pan Head Screw - M5x12
109 0951 4006W Philips Screw With Flat Washer - M4
110 0951 4008W Philips Screw with Flat Washer - M4
111 0951 4008B Philips Screw With Flat Washer - M4
112 0951 4006B Philips Screw with Flat Washer - M4
113 1105 0008 Nylon Clip - 2N
114 1005 0613 Tylap
115 1105 0011 Nylon Clip - 8N

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 13 Parts Location and List

A

3. FRAME SECTION 2 (A112)

FT9101 14 Parts Location and List

3. FRAME SECTION 2 (A112)

Index

No.

1 A028 2362 Adjusting Cam 1
2 A028 2360 Main Charger Adjusting Bracket 1
3 A028 1550 Door Fixing Bracket 1
4 5013 0568 Roller Catch 1
5 A028 1516 Door Catch - Right Upper Bracket 1
6 A028 5602 Main Control Board Bracket 2
7 A028 2640 Grounding Brush Holder 1
8 AA12 0014 Antistatic Brush 1
9 AG06 1009 Main Control Board Hinge 2
10 5403 2320 Guide Pin - Drum Stay 3
11 AA15 1266 Seal - 1x45x350 1
12 AA14 3103 Front Channel Shaft 3
13 A028 1771 Operation Panel Bracket 3
14 A028 1534 Transport Cover Bracket 1
15 A028 7250 Main Hinge 2
16 A028 1537 ADF Harness Bracket 1
17 A028 1175 Flash Power Supply Duct 1
18 A028 1187 Connector Plate 1
19 A028 1188 Connector Panel - RS232C 1
20 A028 1193 Rear Upper Support Plate - ADF 2
21 A028 5671 Horizontal Rear Harness Guide 2
22 A028 1194 Rear Upper Support Channel 1
23 AA14 3142 Rear Positioning Pin 2
24 AA14 3143 Stud - M5x5 1
25 AA08 4012 Bearing Case 1
26 A028 5673 Drive Harness Guide 1
27 A028 1536 Cover Bracket - Rear Upper 1
28 A028 1182 Rear Right Connector Cover 1
29 A028 6682 Cooling Rear Bracket 1
30 A028 6684 Front Exhaust Duct 1
31 A028 6685 Cooling Guide 1
32 A028 3061 Tray Connector Channel 1
33 A028 1195 Rear Vertical Support Channel 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 1185 Sorter Connector Cover Plate 1
35 A028 1186 LCT Connector Cover Plate 1
36 A028 6671 Cooling Front Seal 1
37 A028 6672 Horizontal Cover 1
38 A028 5672 Paper Feed Rear Harness Guide 1
39 A028 1535 Cover Bracket - Front Upper Right 1
40 A028 5605 DC Control Board Bracket 1
41 A028 5670 Duplex Front Harness Guide 1
42 A028 6670 Cooling Bracket 1
43 A028 1197 Front Right Harness Cover 1
44 AH01 1001 Stand 4
45 0805 5011 Caster - 250 KGF 4
46 AA14 3051 Shoulder Screw - M4 1
47 AA14 3102 Stepped Screw - M6x7 8
48 AA10 1004 Plate Nut - M5 1

Part No. Description

Q’ty Per

Assembly

FT9101 15 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0040W Philips Pan Head Screw - M4x4
104 0313 0140B Philips Pan Head Screw - M3x14
105 0314 0060B Philips Pan Head Screw - M4x6
106 0313 0050G Philips Pan Head Screw - M3x5
107 0324 0080W Philips Sunken Head Screw - M4x8
108 0315 0080W Philips Pan Head Screw - M5x8
109 0315 0100W Philips Pan Head Screw - M5x10
110 0315 0120W Philips Pan Head Screw - M5x12
111 0344 0080F Philips Truss Head Screw - M4x8
112 0951 4008W Philips Screw with Flat Washer - M4
113 0720 0060E Retaining Ring - M6
114 1106 0411 Bushing - 11.5mm
115 0805 3040 Ball Bearing - 6x10x3mm

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 15 Parts Location and List

A

4. UPPER TRAY (A112)

FT9101 16 Parts Location and List

Rev. 6/4/96

4. UPPER TRAY (A112)

Index

No.

1 5446 2638 Decal - Paper Lower Limit 1
2 A028 2824 Sheet 1
3 A028 2825 Sheet - Rear Side Plate 1
4 A028 2848 Side Plate 1
5 5201 2858 Friction Pad 1
6 A112 2830 Bottom Tray - 1st Paper Tray 1
8 A010 5700 Sensor 1
9 A028 3296 Grip - Paper Feed Tray Cover 1
10 A028 5190 Paper Feed Tray Switch 1
11 A028 2858 Upper Cover - Paper Feed Table 1
12 A028 1653 Decal - Paper Tray 1
13 A028 2818 Upper Cover 1
14 A028 2803 Front Side Plate 1
15 5446 2677 Bushing - Paper Tray 2
16 5403 1030 Tension Spring 2
17 AA05 1020 Wire - 500 1
18 5446 2666 Front Stopper - Paper Tray 1
19 5053 0419 Bushing - 10mm 2
20 5446 2671 Drive Pulley - Paper Tray 2
21 5446 2620 Idler Pulley - 20 10
22 5446 2630 Front Wire Tightener 1
23 5446 2621 Idler Pulley - 16 4
24 5446 2676 Actuator - Lower Limit Sensor 1
25 A028 3351 Paper Feed Tray Shaft 1
26 A028 3352 Paper Feed Tray Rear Shaft 1
27 A028 3354 Wire Clamper 1
28 A028 3353 Wire Stopper 1
29 AA05 1004 Grounding Wier 1
30 AA06 0140 Side Fence Spring 1
31 A029 2698 Side Guide Grip 1
32 AA14 0151 Drive Shaft 1
33 A028 2815 Front Guide 1
34 A028 2829 Rear Guide 1

Part No. Description

Q’ty Per

Assembly

Index

No.

35 5446 2663 Spring - Lock Lever 1
36 A029 2760 Lock Lever - 500 1
37 5446 2662 Lock Lever Pin 1
38 A028 3325 Tray Sensor Actuator 1
39 AA14 0152 Side Guide Shaft 1
40 A028 2809 Rear Side Plate 1
41 A028 3329 Rear Stopper 1
42 A028 3356 Rear Wire Tightener 1
43 A028 2813 Rear Cover 1
44 A028 5326 Paper Feed Tray Motor 1
45 5446 2697 Worm Gear 1
46 A028 5155 Paper Feed Control Board 1
47 A028 3398 Side Fence Fixing Plate 1
48 A028 3362 Paper Feed Motor Bracket 1
49 A028 3363 Sensor Bracket 1
50 5205 5250 LED Sensor Type S 1
51 5053 0223 Bushing - 8mm 2
52 5446 2702 Gear - 22T 1
53 5446 2700 Drive Gear Shaft 1
54 A028 5413 1st Paper Feed Tray Harness 1
55 A028 5180 Paper Size Sensor Board 1
56 5446 5463 Dehumidity Heater (EU) 1
57 A028 5185 Optics Sensor 2
58 A028 3301 Paper Feed Tray Base 1
59 5442 2117 Shoulder Screw - Hinge 1
60 5415 2642 Lock Arm 1
61 A028 3262 Paper Feed Table Stopper 1
62 A028 3331 End Fence Rail 1
63 A028 3332 End Fence Sheet 1
64 A028 2819 End Fence 1
65 A028 3341 Paper End Sensor Actuator 2
66 AA07 0004 Slide Rail 1
67 A028 2886 Slide Guide Bracket 1

Part No. Description

Q’ty Per

Assembly

FT9101 17 Parts Location and List

Rev. 6/4/96

Index

No.

68 5446 2569 Spring - Detent 1
69 5446 2566 Detent Arm 1
70 5446 2567 Detent Arm Shaft 1
71 A028 3050 Stay - Paper Feed Tray 1
72 A028 3055 Cushion - Paper Feed Tray 1
73 AA00 0117 Decal - Paper Setting 1
74 A112 2880 Control Board Cover 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0313 0050W Philips Pan Head Screw - M3x5
103 0314 0060B Philips Pan Head Screw - M4x6
104 0313 0060W Philips Pan Head Screw - M3x6
105 0313 0080W Philips Pan Head Screw - M3x8
106 0314 0060M Philips Pan Head Screw - M4x6
107 0314 0100W Philips Pan Head Screw - M4x10
108 0314 0120W Philips Pan Head Screw - M4x12
109 0951 4006W Philips Screw With Flat Washer - M4
110 0314 0500W Philips Pan Head Screw - M4x50
111 0720 0040E Retaining Ring - M4
112 0720 0060E Retaining Ring - M6
113 0805 3270 Ball Bearing - 8x16x5mm
114 1105 0005 Nylon Clip - 3N
115 1105 0008 Nylon Clip - 2N
116 1105 0009 Nylon Clip - 5N
117 1106 0200 Bushing - 19.44mm
118 1105 0196 Harness Clamp
119 1105 0160 Clamp
120 0710 0050B Hexagon Nut - M5
121 0575 0050E Hexagon Headless Set Screw - M5x5
122 0951 4008W Philips Screw with Flat Washer - M4
123 0930 0400G Parallel Key - 4x4x10
124 0344 0060F Philips Truss Head Screw - M4x6
125 0574 0050E Hexagon Headless Set Screw - M4x5
126 0313 0120W Philips Pan Head Screw - M3x12

Part No. Description

Q’ty Per

Assembly

5. MIDDLE TRAY (A112)

FT9101 18 Parts Location and List

5. MIDDLE TRAY (A112)

Index

No.

1 5446 2638 Decal - Paper Lower Limit 1
2 A028 3366 Front Side Sheet 1
3 A028 3367 Rear Side Sheet 1
4 A028 3377 Side Plate 1
5 5201 2858 Friction Pad 1
6 A112 2845 Paper Feed Tray 1
7 5446 2686 Paper End Feeler 1
8 A028 5185 Optics Sensor 1
9 A028 3296 Grip - Paper Feed Tray Cover 1
10 A028 5190 Paper Feed Tray Switch 1
11 A028 2859 Paper Feed Middle Cover 1
12 A028 1653 Decal - Paper Tray 1
13 A028 2834 Upper Cover 1
14 A028 3305 Front Side Plate 1
15 5446 2677 Bushing - Paper Tray 2
16 5403 1030 Tension Spring 2
17 AA05 1005 Wire - 1000 2
18 5446 2666 Front Stopper - Paper Tray 1
19 5053 0419 Bushing - 10mm 2
20 5446 2671 Drive Pulley - Paper Tray 2
21 5446 2620 Idler Pulley - 20 10
22 5446 2630 Front Wire Tightener 1
23 5446 2621 Idler Pulley - 16 4
24 5446 2676 Actuator - Lower Limit Sensor 1
25 A028 3351 Paper Feed Tray Shaft 1
26 A028 3352 Paper Feed Tray Rear Shaft 1
27 A028 3354 Wire Clamper 1
28 A028 3353 Wire Stopper 1
29 AA05 1004 Grounding Wier 1
30 AA06 0140 Side Fence Spring 1
31 A029 2698 Side Guide Grip 1
32 AA14 0151 Drive Shaft 1
33 A028 3326 Front Guide 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 3322 Rear Guide 1
35 5446 2663 Spring - Lock Lever 1
36 A029 2675 Lock Lever - 1000 1
37 5446 2662 Lock Lever Pin 1
38 A028 3325 Tray Sensor Actuator 1
39 AA14 0152 Side Guide Shaft 1
40 A028 3318 Rear Side Plate 1
41 A028 3329 Rear Stopper 1
42 A028 3356 Rear Wire Tightener 1
43 A028 3368 Rear Cover 1
44 A028 5326 Paper Feed Tray Motor 1
45 5446 2697 Worm Gear 1
46 A028 5155 DC Drive Board - Paper Tray 1
47 AA00 0117 Decal - Paper Setting 1
48 A028 3362 Paper Feed Motor Bracket 1
49 A028 3363 Sensor Bracket 1
50 5205 5250 LED Sensor Type S 1
51 5053 0223 Bushing - 8mm 2
52 5446 2702 Gear - 22T 1
53 5446 2700 Drive Gear Shaft 1
54 A028 5410 Paper Feed Tray Harness 1
55 A028 5180 Paper Size Sensor Board 1
56 5446 5463 Dehumidity Heater 1
57 A028 3398 Side Fence Fixing Plate 1
58 A028 3301 Paper Feed Tray Base 1
59 5442 2117 Shoulder Screw - Hinge 1
60 5415 2642 Lock Arm 1
61 A028 3262 Paper Feed Table Stopper 1
62 A028 3331 End Fence Rail 1
63 A028 3332 End Fence Sheet 1
64 A028 3333 End Fence 1
65 A028 3341 Paper End Sensor Actuator 1
66 AA07 0004 Slide Rail 2

Part No. Description

Q’ty Per

Assembly

FT9101 19 Parts Location and List

Index

No.

67 A028 2886 Slide Guide Bracket 1
68 5446 2569 Spring - Detent 1
69 5446 2566 Detent Arm 1
70 5446 2567 Detent Arm Shaft 1
71 A028 3050 Stay - Paper Feed Tray 1
72 A028 3264 Stopper Cushion 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0313 0050W Philips Pan Head Screw - M3x5
103 0314 0060B Philips Pan Head Screw - M4x6
104 0313 0060W Philips Pan Head Screw - M3x6
105 0313 0080W Philips Pan Head Screw - M3x8
106 0314 0060M Philips Pan Head Screw - M4x6
107 0314 0100W Philips Pan Head Screw - M4x10
108 0314 0120W Philips Pan Head Screw - M4x12
109 0951 4006W Philips Screw With Flat Washer - M4
110 0314 0500W Philips Pan Head Screw - M4x50
111 0720 0040E Retaining Ring - M4
112 0720 0060E Retaining Ring - M6
113 0805 3270 Ball Bearing - 8x16x5mm
114 1105 0005 Nylon Clip - 3N
115 1105 0008 Nylon Clip - 2N
116 1105 0009 Nylon Clip - 5N
117 1106 0200 Bushing - 19.44mm
118 1105 0196 Harness Clamp
119 1105 0160 Clamp
120 0710 0050B Hexagon Nut - M5
121 0575 0050E Hexagon Headless Set Screw - M5x5
122 0951 4008W Philips Screw with Flat Washer - M4
123 0930 0400G Parallel Key - 4x4x10
124 0344 0060F Philips Truss Head Screw - M4x6
125 0574 0050E Hexagon Headless Set Screw - M4x5

Part No. Description

Q’ty Per

Assembly

FT9101 19 Parts Location and List

A

6. LOWER TRAY (A112)

FT9101 20 Parts Location and List

6. LOWER TRAY (A112)

Index

No.

1 5446 2638 Decal - Paper Lower Limit 1
2 A028 3366 Front Side Sheet 1
3 A028 3367 Rear Side Sheet 1
4 A028 3377 Side Plate 1
5 5201 2858 Friction Pad 1
6 A112 2845 Paper Feed Tray 1
7 5446 2686 Paper End Feeler 1
8 A028 5185 Optics Sensor 1
9 A028 3296 Grip - Paper Feed Tray Cover 1
10 A028 5190 Paper Feed Tray Switch 1
11 A028 2879 Paper Feed Lower Cover 1
12 A028 1653 Decal - Paper Tray 1
13 A028 2834 Upper Cover 1
14 A028 3305 Front Side Plate 1
15 5446 2677 Bushing - Paper Tray 2
16 5403 1030 Tension Spring 2
17 AA05 1005 Wire - 1000 2
18 5446 2666 Front Stopper - Paper Tray 1
19 5053 0419 Bushing - 10mm 2
20 5446 2671 Drive Pulley - Paper Tray 2
21 5446 2620 Idler Pulley - 20 10
22 5446 2630 Front Wire Tightener 1
23 5446 2621 Idler Pulley - 16 4
24 5446 2676 Actuator - Lower Limit Sensor 1
25 A028 3351 Paper Feed Tray Shaft 1
26 A028 3352 Paper Feed Tray Rear Shaft 1
27 A028 3354 Wire Clamper 1
28 A028 3353 Wire Stopper 1
29 AA05 1004 Grounding Wier 1
30 AA06 0140 Side Fence Spring 1
31 A029 2698 Side Guide Grip 1
32 AA14 0151 Drive Shaft 1
33 A028 3326 Front Guide 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 3322 Rear Guide 1
35 5446 2663 Spring - Lock Lever 1
36 A029 2675 Lock Lever - 1000 1
37 5446 2662 Lock Lever Pin 1
38 A028 3325 Tray Sensor Actuator 1
39 AA14 0152 Side Guide Shaft 1
40 A028 3318 Rear Side Plate 1
41 A028 3329 Rear Stopper 1
42 A028 3356 Rear Wire Tightener 1
43 A028 3368 Rear Cover 1
44 A028 5326 Paper Feed Tray Motor 1
45 5446 2697 Worm Gear 1
46 A028 5155 DC Drive Board - Paper Tray 1
47 AA00 0117 Decal - Paper Setting 1
48 A028 3362 Paper Feed Motor Bracket 1
49 A028 3363 Sensor Bracket 1
50 5205 5250 LED Sensor Type S 1
51 5053 0223 Bushing - 8mm 2
52 5446 2702 Gear - 22T 1
53 5446 2700 Drive Gear Shaft 1
54 A028 5410 Paper Feed Tray Harness 1
55 A028 5180 Paper Size Sensor Board 1
56 5446 5463 Dehumidity Heater 1
57 A028 3398 Side Fence Fixing Plate 1
58 A028 3301 Paper Feed Tray Base 1
59 5442 2117 Shoulder Screw - Hinge 1
60 5415 2642 Lock Arm 1
61 A028 3262 Paper Feed Table Stopper 1
62 A028 3331 End Fence Rail 1
63 A028 3332 End Fence Sheet 1
64 A028 3333 End Fence 1
65 A028 3341 Paper End Sensor Actuator 1
66 AA07 0004 Slide Rail 2

Part No. Description

Q’ty Per

Assembly

FT9101 21 Parts Location and List

Index

No.

67 A028 2886 Slide Guide Bracket 1
68 5446 2569 Spring - Detent 1
69 5446 2566 Detent Arm 1
70 5446 2567 Detent Arm Shaft 1
71 A028 3050 Stay - Paper Feed Tray 1
72 A028 3264 Stopper Cushion 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0313 0050W Philips Pan Head Screw - M3x5
103 0314 0060B Philips Pan Head Screw - M4x6
104 0313 0060W Philips Pan Head Screw - M3x6
105 0313 0080W Philips Pan Head Screw - M3x8
106 0314 0060M Philips Pan Head Screw - M4x6
107 0314 0100W Philips Pan Head Screw - M4x10
108 0314 0120W Philips Pan Head Screw - M4x12
109 0951 4006W Philips Screw With Flat Washer - M4
110 0314 0500W Philips Pan Head Screw - M4x50
111 0720 0040E Retaining Ring - M4
112 0720 0060E Retaining Ring - M6
113 0805 3270 Ball Bearing - 8x16x5mm
114 1105 0005 Nylon Clip - 3N
115 1105 0008 Nylon Clip - 2N
116 1105 0009 Nylon Clip - 5N
117 1106 0200 Bushing - 19.44mm
118 1105 0196 Harness Clamp
119 1105 0160 Clamp
120 0710 0050B Hexagon Nut - M5
121 0575 0050E Hexagon Headless Set Screw - M5x5
122 0951 4008W Philips Screw with Flat Washer - M4
123 0930 0400G Parallel Key - 4x4x10
124 0344 0060F Philips Truss Head Screw - M4x6
125 0574 0050E Hexagon Headless Set Screw - M4x5

Part No. Description

Q’ty Per

Assembly

FT9101 21 Parts Location and List

A

7. 1ST & 2ND PAPER FEED SECTION (A112)

FT9101 22 Parts Location and List

7. 1ST & 2ND PAPER FEED SECTION (A112)

Index

No.

1 A028 5412 Paper Feed Harness 1
2 A028 3151 Paper Feed Stay 1
3 A028 3165 Grip Supporter 2
4 AA06 0137 Spring 1
5 5447 2768 Stepped Screw - M3 1
6 A028 3174 Pick-up Lever 1
7 A028 3173 Paper Feed Solenoid 1
8 A028 3172 Solenoid Bracket 1
9 A028 3264 Stopper Cushion 2
10 5205 5250 LED Sensor Type S 1
11 A028 3181 Paper Feed Cover 1
12 A028 3131 Upper Grip Roller 1
13 A028 3122 Paper Feed Front Side Plate 1
14 A028 3182 Separation Bracket 1
15 5206 2686 Snap Ring 3
16 5447 2726 Paper Feed Roller 1
17 5205 2594 Gear - 18T 1
18 5447 2723 Pick-up Roller 1
19 5447 2706 Gear - 15T 1
20 A028 3160 Pick-up Guide 1
21 A028 3157 Pick-up Arm 1
22 A028 3161 Paper Feed Stopper 1
23 AA14 0148 Feed Roller Shaft 1
24 A028 3137 First Paper Feed Guide 1
25 AF02 0071 Grip Roller 1
26 A028 3123 Paper Feed Rear Side Plate 1
27 A028 3148 Paper Feed Control Board Cover 1
28 A028 5160 Registration Sensor Board 1
29 5446 2824 Screw - Duplex Guide Plate 4
30 AB01 3222 Gear - 20Z 1
31 AB01 3220 Gear - 20Z 1
32 AB01 3230 Gear - 40Z 1
33 A028 3008 Drive Motor Joint 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 3176 Paper Feed Motor Bracket 1
35 A028 5322 Paper Feed Motor 1
36 AA14 0149 Separation Shaft 1
37 A028 3147 Entrance Feed Guide 2
38 A028 3134 First Paper Feed Guide - Upper 1
39 A028 3146 Paper Feed Guide Spacer 2
40 5447 2683 Gear - 18T 1
41 A028 3139 First Paper Feed Guide - Lower 1
42 AA14 0146 Paper Feed Guide Shaft 1
43 A028 3142 Feed Sensor Guide 1
44 AF03 2001 Separation Roller 1
45 A028 3110 Torque Limitter Roller 1
46 AA06 0138 Spring 1
47 A028 3120 Separation Roller Arm 1
48 5447 2684 Gear - 18T 1
49 AB01 3231 Gear - 21Z 1
50 A028 3125 Pressure Arm Stopper 1
51 A028 3103 Paper Separation Stay 1
52 AA06 6204 Spring 1

Part No. Description

Q’ty Per

Assembly

FT9101 23 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0100W Philips Pan Head Screw - M4x10
104 0313 0060W Philips Pan Head Screw - M3x6
105 0951 4006B Philips Screw with Flat Washer - M4
106 0720 0040E Retaining Ring - M4
107 0720 0060E Retaining Ring - M6
108 0805 3307 Ball Bearing - 8x14x4mm
109 0805 3042 Ball Bearing - 6x10x3mm
110 1105 0005 Nylon Clip - 3N
111 0573 0050E Hexagon Headless Set Screw - M3x5

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 23 Parts Location and List

A

8. 3RD PAPER FEED SECTION (A112)

FT9101 24 Parts Location and List

8. 3RD PAPER FEED SECTION (A112)

Index

No.

1 A028 5412 Paper Feed Harness 1
2 A028 3151 Paper Feed Stay 1
3 A028 3165 Grip Supporter 2
4 AA06 0137 Spring 1
5 5447 2768 Stepped Screw - M3 1
6 A028 3174 Pick-up Lever 1
7 A028 3173 Paper Feed Solenoid 1
8 A028 3172 Solenoid Bracket 1
9 A028 3264 Stopper Cushion 3
10 5205 5250 LED Sensor Type S 1
11 A028 3181 Paper Feed Cover 1
12 A028 3131 Upper Grip Roller 1
13 A028 3122 Paper Feed Front Side Plate 1
14 A028 3182 Separation Bracket 1
15 5206 2686 Snap Ring 3
16 5447 2726 Paper Feed Roller 1
17 5205 2594 Gear - 18T 1
18 5447 2723 Pick-up Roller 1
19 5447 2706 Gear - 15T 1
20 A028 3160 Pick-up Guide 1
21 A028 3157 Pick-up Arm 1
22 A028 3161 Paper Feed Stopper 1
23 AA14 0148 Feed Roller Shaft 1
24 A028 3205 Third Paper Feed Guide 1
25 AF02 0071 Grip Roller 1
26 A028 3123 Paper Feed Rear Side Plate 1
27 A028 3148 Paper Feed Control Board Cover 1
28 A028 5160 Registration Sensor Board 1
29 5446 2824 Screw - Duplex Guide Plate 4
30 AB01 3222 Gear - 20Z 1
31 AB01 3220 Gear - 20Z 1
32 AB01 3230 Gear - 40Z 1
33 A028 3008 Drive Motor Joint 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 3176 Paper Feed Motor Bracket 1
35 A028 5322 Paper Feed Motor 1
36 AA14 0149 Separation Shaft 1
37 AA06 6204 Spring 1
38 A028 3203 Third Paper Feed Guide - Upper 1
39 A028 3146 Paper Feed Guide Spacer 2
40 5447 2683 Gear - 18T 1
41 A028 3207 Third Paper Feed Guide - Lower 1
42 AA14 0146 Paper Feed Guide Shaft 1
43 A028 3142 Feed Sensor Guide 1
44 AF03 2001 Separation Roller 1
45 A028 3110 Torque Limitter Roller 1
46 AA06 0138 Spring 1
47 A028 3120 Separation Roller Arm 1
48 5447 2684 Gear - 18T 1
49 AB01 3231 Gear - 21Z 1
50 A028 3125 Pressure Arm Stopper 1
51 A028 3103 Paper Separation Stay 1

Part No. Description

Q’ty Per

Assembly

FT9101 25 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0100W Philips Pan Head Screw - M4x10
104 0313 0060W Philips Pan Head Screw - M3x6
105 0951 4006B Philips Screw with Flat Washer - M4
106 0720 0040E Retaining Ring - M4
107 0720 0060E Retaining Ring - M6
108 0805 3307 Ball Bearing - 8x14x4mm
109 0805 3042 Ball Bearing - 6x10x3mm
110 1105 0005 Nylon Clip - 3N
111 0573 0050E Hexagon Headless Set Screw - M3x5

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 25 Parts Location and List

A

9. VERTICAL TRANSPORT SECTION 1 (A112)

FT9101 26 Parts Location and List

9. VERTICAL TRANSPORT SECTION 1 (A112)

Index

No.

1 5919 2201 Shoulder Screw - M4 1
2 A028 4835 Right Rail Guide 1
3 A028 4830 Fusing Rail Bracket 1
4 AF02 2016 Vertical Transport Roller 3
5 A028 6222 Pressure Lever 6
6 AA06 3058 Spring 6
7 A028 2961 Vertical Transport Knob 1
8 A028 2959 Vertical Transport Front Plate 1
9 A028 2952 Vertical Transport Guide Plate 1
10 A028 2957 Vertical Transport Guide Mylar 1
11 AA07 0004 Slide Rail 3
12 A028 2886 Slide Guide Bracket 3
13 AB01 3229 Gear - 30Z 1
14 A028 2905 Vertical Transport Guide 1
15 A028 2908 Vertical Transport Upper Guide 1
16 AF02 0068 Transport Roller 1
17 A028 2856 Right Stay 1
18 A028 4886 Safety Switch Actuator 1
19 5053 0447 Bushing - 6mm 1
20 A028 4879 Oil Catch 1
21 A028 4876 Oil Supply Nozzle 1
22 A028 1551 Safety Switch Base Bracket 1
23 A028 1499 Safety Switch Bracket 1
24 A028 1500 Safety Switch Lever 1
25 A028 1503 Safety Switch Actuator 1
26 AA06 6043 Spring 1
27 AA14 5067 Actuator Shaft 1
28 AA15 1514 Seal - 10x52x31 1
29 AA18 0036 Tube - 9x170 1
30 AA06 6060 Spring 1
31 A028 4885 Oil Collection 1
32 AA06 3063 Spring 1
33 AA14 3110 Oil Collection Shaft 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 4884 Oil Collection Bracket 1
35 A028 1510 Click Holder 1
36 A028 1509 Door Catch Upper Bracket 1
37 A004 1768 Mylar Seal - Lens Bracket 1
38 A028 2875 Vertical Transport Lock Lever 1
39 A028 2876 Lever Button 1
40 A028 1505 Safety Switch Seal 1
41 5446 4330 Pump Drive Plate 1
42 A028 1513 Door Catch Lower Bracket 1
43 A028 2851 Paper Feed Channel 1
44 5201 1796 Stepped Screw - M4 1
45 5446 4318 Link - Pump Drive 1
46 AA18 0012 Tube - 6x595 1
47 5446 4324 Plate Spring - Oil Pump 1
48 A028 4891 Oil Pump Bracket 1
49 A028 4893 Oil Pump Actuator 1
50 5424 4307 Cam - Oil Pump 1
51 5447 4241 Tube Clamp 2
52 5415 4310 Valve - Oil Pump 2
53 AA18 0035 Sleeve - Oil Pump 1
54 5205 4198 Lower Oil Tube 1
55 AA18 2003 Hose Clamp 1

Part No. Description

Q’ty Per

Assembly

FT9101 27 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0313 0050W Philips Pan Head Screw - M3x5
103 0314 0080W Philips Pan Head Screw - M4x8
104 0315 0080W Philips Pan Head Screw - M5x8
105 0344 0060F Philips Truss Head Screw - M4x6
106 0314 0060M Philips Pan Head Screw - M4x6
107 0323 0060W Philips Sunken Head Screw - M3x6
108 0951 4006W Philips Screw With Flat Washer - M4
109 0720 0030E Retaining Ring - M3
110 0720 0040E Retaining Ring - M4
111 0720 0060E Retaining Ring - M6
112 0805 3307 Ball Bearing - 8x14x4mm
113 0741 3506 Ball Bearing - 6x12x4 mm
114 0742 3808 Ball Bearing - 8x16
115 0809 0022 Door Catch Magnet
116 0314 0050W Philips Pan Head Screw - M4x5
117 1204 1280 Push Switch

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 27 Parts Location and List

A

10. VERTICAL TRANSPORT SECTION 2 (A112)

FT9101 28 Parts Location and List

10. VERTICAL TRANSPORT SECTION 2 (A112)

Index

No.

1 A028 3026 Paper Dust Collector Tray 1
2 A028 3025 Paper Dust Collector Guide 1
3 A028 3023 Paper Dust Collector Bracket 1
4 AF02 0069 Registration Roller 1
5 A028 2943 Registration Left Support Mylar 2
6 A028 2932 Registration Left Guide Plate 1
7 A028 2936 Registration Left Support Guide 1
8 A028 2937 Registration Lower Support Guide 1
9 A028 2942 Registration Right Support Guide 1
10 A028 2939 Registration Right Guide 1
11 A028 2928 Registration Roller Knob 1
12 A028 2925 Registration Front Plate 1
13 A028 2945 Registration Driven Roller 1
14 AA06 3058 Spring 4
15 A028 6222 Pressure Lever 2
16 A028 3008 Drive Motor Joint 1
17 A028 3007 Registration Drive Motor Bracket 1
18 A028 5324 Registration Motor 1
19 A028 3005 Idler Pulley 1
20 AB01 3228 Gear - 30Z 1
21 AB01 7064 Pulley Gear - 30/40Z 2
22 A028 3001 Pulley - 32Z 1
23 A028 3003 Idler 1
24 AB03 0174 Pulley - 40Z 3
25 AB01 3229 Gear - 30Z 5
26 A028 2891 Separation Drive Shaft 3
27 AB01 3364 Gear - 18Z 1
28 A028 2857 Roller Guide 2
29 A028 5515 Feed Motor Harness 1
30 5424 2625 Spring - Connector 2
31 5446 5832 Connector Guide Pin 2
32 AA04 3011 Feed Belt 1
33 A028 2918 Lower Upper Guide Plate 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 2921 Rear Positioning Lever 1
35 A028 2897 Paper Dust Collector Lever 2
36 AA06 0185 Spring 2
37 AA14 0234 Pressure Shaft 1
38 AF02 0114 Transport Roller 1
39 AF02 2015 Idle Roller 1
40 A028 2912 Upper Guide 1
41 A028 2898 Paper Dust Collector Bracket 1
42 A028 2923 Pressure Shaft Bushing 1
43 A028 2922 Pressure Lever 2
44 AA14 0144 Pressure Lever Shaft 1
45 A028 2916 Front Upper Guide Plate 1
46 A028 2915 Registration Sensor Guide 1
47 A028 2920 Front Positioning Lever 1
48 A028 2924 Transport Lever 1
49 A028 4910 Oil Pad - Oil Tank 1
50 AF02 0070 Horizontal Transport Roller 1
51 AF02 1024 Drive Roller 1
52 A028 2901 Lower Guide 1
53 A028 5165 Registration Sensor Relay Board 1
54 AA14 0141 Paper Feed Stay 1
55 A028 2881 Front Side Plate 1
56 5316 3064 Stud - Wiring 1
57 A028 2929 Transport Knob 1
58 A028 4902 Hose Holder 1
59 AA03 1003 Oil Tank 1
60 AA18 2001 Hose Band 1
61 A028 4904 Lower Exit Tube 1
62 AA03 6007 Oil Tank Cap 1
63 A028 2860 Rear Side Plate 1
64 AA06 6135 Spring 1
65 5205 5258 Silicon Oil Sensor 1
66 5446 4278 Bushing - Silicon Oil Sensor 1

Part No. Description

Q’ty Per

Assembly

FT9101 29 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0120W Philips Pan Head Screw - M4x12
104 0951 4006W Philips Screw With Flat Washer - M4
105 0951 4008W Philips Screw with Flat Washer - M4
106 0951 4006B Philips Screw with Flat Washer - M4
107 0313 0060W Philips Pan Head Screw - M3x6
108 0573 0050E Hexagon Headless Set Screw - M3x5
109 0720 0040E Retaining Ring - M4
110 0720 0060E Retaining Ring - M6
111 0805 3428 Ball Bearing - 8x16x5mm
112 0805 3307 Ball Bearing - 8x14x4mm
113 0740 3808 Bearing - 8x16x5mm
114 0740 3008 Ball Bearing
115 0741 3506 Ball Bearing - 6x12x4 mm
116 0742 3808 Ball Bearing - 8x16
117 1105 0005 Nylon Clip - 3N
118 1105 0016 Nylon Clip - 4N

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 29 Parts Location and List

A

11. OPTICS SECTION 1 (A112)

FT9101 30 Parts Location and List

11. OPTICS SECTION 1 (A112)

Index

No.

1 A028 1184 Left Upper Harness Cover 1
2 A028 2204 Exposure Glass (EU) 1
2 A112 2205 Exposure Glass (USA) 1
3 AC04 2009 Exposure Glass Holder 1
4 A028 2182 Exposure Glass Base 1
6 AA14 3086 Stepped Screw - M6x5 1
7 A028 2194 Right Upper Sub-Reflector 1
8 A028 2196 Reflector Holder 1
9 A028 2195 Right Lower Sub-Reflector 1
10 AA15 1215 Seal - 8x550x25 1
11 A028 2193 Rear Sub-Reflector 1
12 A028 2187 Reflector Adjusting Bracket 4
13 A028 2122 Flash Lamp Base Holder 1
14 AA15 1212 Seal - 6x30x52 1
15 AA15 1211 Seal - 4x71x10 1
16 A028 2145 Front Shielding Plate - Optics Unit 1
17 A028 2146 Rear Shielding Plate - Optics Unit 1
18 5415 4125 Nylon Clip 1
19 A028 2171 Thermofuse Spring 1
20 A028 5365 Thermofuse 1
21 AA00 0037 Decal - Thermofuse 1
22 A023 2073 Decal High Temperature (EU) 1
22 5434 7916 High Voltage Decal (USA) 2
23 A028 2166 Flash Lamp Upper Cover 1
24 A028 2165 Flash Lamp Reflector 1
25 A028 2164 Flash Lamp Cover 1
26 A028 2160 Flash Lamp Clamp 2
27 A028 2157 Flash Lamp Holder 1
28 5324 3052 Stepped Screw 2
29 A028 2175 Front Side Plate 1
30 A028 2118 Front Sub-Reflector 1
31 A028 2149 Flash Lamp 1
32 A028 2177 Rear Side Plate 1

Part No. Description

Q’ty Per

Assembly

Index

No.

33 5403 6118 Stepped Screw - Transformer 1
34 A028 2119 Rear Sub-Reflector 1
35 A028 2116 Main Reflector 1
36 5316 7421 O - Ring 2
37 AA14 3203 Stepped Screw 2
38 AZ10 0003 Pulse Transformer 1
39 A028 2117 Reflector Holder 1
40 A028 2126 Trigger Unit Holder 1
41 A028 2128 Flash Power Supply Cover 1
42 AA15 1462 Seal - 0.5x6x215 2
43 A028 2112 Exposure Unit Base Plate 1
44 A028 5441 Fluorescent Lamp Harness 1
45 A028 6829 Upper Seal 1
46 5056 0509 Nut Plate - Microswitch 1
47 A028 2106 Optics Shielding Plate - Lower Rear 1
48 AA15 2042 Seal - 10x20x300 1
49 AA15 1213 Seal - 3x300x10 1
50 A028 2132 Bellows 1
51 AA15 1214 Seal - 3x260x8 2
52 A028 2142 Bellows Guide 2
53 A028 2192 Front Sub-Reflector 1
54 A028 2190 Exposure Glass Base Ass’y 1
55 AA00 1190 Decal - Ground 1

Part No. Description

Q’ty Per

Assembly

FT9101 31 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0080M Philips Pan Head Screw - M5x8
104 0344 0080F Philips Truss Head Screw - M4x8
105 0951 4008W Philips Screw with Flat Washer - M4
106 0951 4006W Philips Screw With Flat Washer - M4
107 0951 4010W Philips Screw With Flat Washer - M4
108 0314 0140W Philips Pan Head Screw - M4x14
109 0313 0140B Philips Pan Head Screw - M3x14
110 0594 0140E Socket Bolt - M4x14
111 1105 0197 Wire Saddle
112 1106 0241 Bushing - 6.7mm
113 1204 1319 Microswitch

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 31 Parts Location and List

A

12. OPTICS SECTION 2 (112)

FT9101 32 Parts Location and List

12. OPTICS SECTION 2 (A112)

Index

No.

1 A028 2061 Second Mirror Bracket 1
2 AA14 3084 Stud - M5x7.5 1
3 AA05 1006 Mirror Wire 1
4 AA10 1002 Adjusting Nut 1
5 A028 2070 Guide Rod Holder 1
6 A028 2015 Main Guide Rod Stopper 2
7 A028 1951 Optics Unit Bracket 1
8 AC05 1007 1st Mirror Guide Rod 1
9 5403 6118 Stepped Screw - Transformer 11
10 A028 2072 Second Mirror Guide Bracket 1
11 A028 2075 Lens Drive Cam 1
12 A028 2016 First Mirror Bracket Guide 1
13 A028 2046 Lens Drive Motor Bracket 1
14 A028 2047 Worm Gear - Lens Drive 1
15 A028 5320 Lens Drive Motor 1
16 AA04 3013 Timing Belt - 210XL 1
17 AB03 0039 Pulley - 50Z 1
18 A028 2030 Worm Wheel - Lens Drive 1
19 AA14 5053 Shaft 1
20 5429 4277 Bushing - 10mm 1
21 A028 2051 Magnification Sensor Bracket 1
22 5205 5250 LED Sensor Type S 1
23 A012 2692 Wave Washer 3
24 5419 5714 Stepped Screw - M4 3
25 A028 2077 Mirror Drive Cam 1
26 5408 2349 Stepped Screw - Cassette Detect 1
27 AA14 3085 Stepped Screw - M5x6.5 1
28 AA06 6055 Spring 1
29 AC05 1008 2nd Mirror Guide Rod 1
30 A028 2066 Second Mirror Cam Follower 1
31 AA14 8079 Adjusting Screw 2
32 A028 2091 Second Mirror Holder 1
33 AA14 8080 Knob Screw 4

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 2094 Second Mirror Guide 2
35 AC03 0036 Lens Ring 1
36 A028 2095 Second Mirror Guard 1
37 A028 2080 Lens 1
38 AA08 0042 Bushing 1
39 A028 1961 Lens Holder Bracket 1
40 A028 1975 Lens Cam Follower 1
41 A028 1965 Upper Lens Shielding Plate 1
42 A028 1971 Lower Lens Shielding Plate 1
43 AA15 0081 Seal - 0.1x35x50 2
44 AA14 3082 Stud -M4X7 2
45 A028 2006 Mirror Bracket Cover 1
46 AA15 2039 Seal - 10x8x110 1
47 AA06 0142 Spring 1
48 AA14 3083 Spring ANCER - M4x6.8 1
49 A028 2034 Pulley Tightener 1
50 AC05 1006 Rear Guide Rod 1
51 A028 2033 Tightener Pulley 1
52 AA15 1220 Seal - 3x37x10 1
53 A028 2008 Lens Guide Rod Bracket 1
54 A028 1956 First Mirror Bracket 1
55 A028 2001 Rear Lens Seal Holder 1
56 A028 1997 Rear Mirror Pulley 1
57 AA14 3080 Stud -M6X10 1
58 AA13 2046 Adjusting Collar 1
59 AA14 3079 Stepped Screw 2
60 A028 1988 First Mirror Bracket 1
61 AC03 0035 Lens Holder 1
62 AA15 1208 Seal - 4x240x7 2
63 A028 1981 First Mirror Holder 1
64 AA15 1207 Seal - 3x280x8 1
65 AC05 1005 Front Guide Rod 2
66 A028 2002 Lower Mirror Seal 1

Part No. Description

Q’ty Per

Assembly

FT9101 33 Parts Location and List

Index

No.

67 A028 2040 Timing Belt Guide 1
68 A028 2010 Mirror Bracket Feeler 1
69 A028 1995 Front Mirror Pulley 1
70 AA14 3081 Stud -M5X7.5 1
71 A028 1977 Guide Rod Stopper 2

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0100W Philips Pan Head Screw - M4x10
103 0315 0100W Philips Pan Head Screw - M5x10
104 0315 0120W Philips Pan Head Screw - M5x12
105 0315 0080W Philips Pan Head Screw - M5x8
106 0803 0021 Positioning Pin
107 0951 4008B Philips Screw With Flat Washer - M4
108 0951 4008W Philips Screw with Flat Washer - M4
109 0951 5008B Philips Screw With Flat Washer - M5
110 0314 0160B Philips Pan Head Screw - M4x16
111 0951 4006W Philips Screw With Flat Washer - M4
112 0575 0050E Hexagon Headless Set Screw - M5x5
113 0720 0040E Retaining Ring - M4
114 0720 0060E Retaining Ring - M6
115 0720 0080E Retaining Ring - M8
116 0725 0100E Retaining Ring C - M10
117 0740 3206 Ball Bearing
118 0805 3357 Bushing - 10x19x22mm
119 0740 3008 Ball Bearing
120 0930 0401G Parallel Key - 4x4x12
121 1106 0193 Bushing - 7.9mm

Part No. Description

Q’ty Per

Assembly

FT9101 33 Parts Location and List

A

13. OPTICS SECTION 3 (A112)

FT9101 34 Parts Location and List

13. OPTICS SECTION 3 (A112)

Index

No.

1 A028 2245 Shielding Unit Left Stay 1
2 A028 2296 Motor Cover 1
3 A028 2291 Left Sensor Bracket 1
4 A028 5440 Shielding Harness 1
5 5205 5250 LED Sensor Type S 2
6 A028 2295 Connector Bracket 1
7 A028 2293 Right Sensor Bracket 1
8 AB03 0041 Pulley - 20Z 4
9 AB01 0020 Gear - 30Z 2
10 5403 2075 Stepped Screw 4
11 AB01 0021 Gear - 48Z 2
12 AB01 7099 Drive Gear 2
13 AA04 3014 Timing Belt - 224-P2-M4 2
14 A028 2271 Left Motor Bracket 1
15 AX06 0022 DC Motor - 24V 2
16 AA06 0143 Spring 2
17 AA04 3015 Timing Belt - 400-P2-M4 1
18 A028 2281 Right Motor Bracket 1
19 A028 2234 Front Side Plate - Shielding Unit 1
20 A028 2250 Shielding Unit Left Sheet 1
21 A028 2267 Belt Holder - Shielding Unit 4
22 A028 2242 Left Guide Sheet - Shielding Unit 2
23 A028 2243 Right Guide Sheet - Shielding Unit 2
24 A028 2260 Shielding Unit Right Sheet 1
25 AA14 0156 Right Shielding Shaft 1
26 A028 2228 Shielding Plate Guide Rail 2
27 AB03 0043 Pulley - 20Z 2
28 A028 2276 Left Tightener Bracket 1
29 A028 2238 Rear Side Plate - Shielding Unit 1
30 A028 2286 Right Tightener Bracket 1
31 AA15 2040 Seal - 5x16x115 2
32 A028 2103 Front Bellows Guide Plate 1
33 A028 2104 Rear Bellows Guide Plate 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 AA15 1209 Seal - 8x550x15 1
35 A028 2102 Partition Plate - Fusing 1
36 AA15 1210 Seal - 4x550x7 1
37 AA15 0084 Seal - 0.1x28x24 1

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0100W Philips Pan Head Screw - M4x10
104 0951 4006W Philips Screw With Flat Washer - M4
105 0951 4010W Philips Screw With Flat Washer - M4
106 0720 0040E Retaining Ring - M4
107 0741 3506 Ball Bearing - 6x12x4 mm

Part No. Description

Q’ty Per

Assembly

FT9101 35 Parts Location and List

14. MAIN CORONA UNIT (A112)

FT9101 36 Parts Location and List

14. MAIN CORONA UNIT (A112)

Index

No.

* AD00 4025 Main Corona Unit 1
1 A028 2392 Magnet Holder - Charger Cleaner 1
2 AA02 1010 Magnetic Plate 1
3 A028 2391 Support Plate - Charger Cleaner 1
4 AA14 3090 Stepped Screw 1
5 A028 2400 Charge Wire Cleaner 1
6 A028 2395 Slider - Charger Cleaner 1
7 A028 2394 Magnet Stopper 1
8 A028 2396 Charger Cleaner Drive Shaft 1
9 AX04 0013 DC Motor - 12V 1
10 A028 2398 Charger Cleaner Drive Joint 1
11 AD02 2111 Front End Block Cover 1
12 A028 2381 Main Charger Upper Casing 1
13 AD02 2112 Rear End Block Cover 1
14 AD02 2113 Motor Cover 1
15 AD02 2114 End Block Cover 1
16 A028 2376 Main Charger Left Casing 1
17 5447 4180 Thermistor Spring 2
18 AD02 2108 Front End Block 1
19 A028 2370 Grid Front Bracket 1
20 AA15 0085 Seal - 0.2x87x56 1
21 A028 9002 Main Corona Wire (10pcs/set) 1
22 A028 2372 Corona Wire Bracket 1
23 A028 2403 Grid Wire Cleaner 1
24 AA06 0148 Spring 21
25 AD02 0019 Grid Wire 1
26 A028 2375 Main Charger Right Casing 1
27 AD02 2110 Rear End Block 1
28 AA14 3088 Corona Wire Terminal 1
29 AA06 3064 Spring 2
30 AA14 3089 Grid Terminal 1
31 A028 2371 Grid Rear Bracket 1
32 AA15 0086 Seal - 0.2x68x52 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0313 0060W Philips Pan Head Screw - M3x6
103 0324 0060W Philips Sunken Head Screw - M4x6
104 0971 4006A Philips Polycarbonate Screw - M4x6
105 0720 0030E Retaining Ring - M3
106 0741 3504 Bushing - 4x8x3mm

Part No. Description

Q’ty Per

Assembly

FT9101 37 Parts Location and List

15. OPC SECTION 1 (A112)

FT9101 38 Parts Location and List

15. OPC SECTION 1 (A112)

Rev. 6/4/96

Index

No.

* A028 2510 OPC Unit 1
1 A112 5345 OPC Drive Motor 1
2 AB03 0078 Pulley - 15Z 1
3 AD01 6006 Drive Roller 1
4 AW02 0018 Photointerruptor 1
5 AB03 0076 Pulley - 28Z 1
6 AA08 4008 Bearing Case 2
7 AA04 3025 Timing Belt - P3M 67 1
8 AD01 6004 Roller 4
9 A028 2690 Slider Rail Support Stay 1
10 AA07 0006 Slide Rail 1
11 AA14 0204 Unlock Shaft 1
12 5214 1974 Screw - Slider Stopper 1
13 A028 2600 Roller Release Cam 2
14 A028 2601 Roller Release Hook 2
15 A028 2674 Rear Side Plate Stopper 1
16 AA06 0163 Spring 1
17 5403 1910 Spring Anchor - Stopper Lever 1
18 A028 2599 Cleaning Pad Holder 1
19 AA16 0005 Pad - 12x12x496 1
20 A028 2627 Pressure Plate - Development 2
21 A028 2595 Development Unit Stopper Bracket 2
22 A028 2630 Plate Spring 1
23 A028 2555 OPC Belt Unit Frame 1
24 A028 2602 Stopper Bracket Holder 2
25 5442 2752 Bushing - Lower Registration Roller 2
26 A029 4997 Middle Tray Knob 1
27 AG05 1033 Drum Unit Knob 2
28 A028 2679 OPC Belt Unit Guide Holder 1
29 A028 2632 Front Stay 1
30 AA13 2051 Plate Flange 1
31 AA14 3111 Knob Shaft 1
32 A028 2633 Front Stay Fixing Knob 1

Part No. Description

Q’ty Per

Assembly

Index

No.

33 AG05 0026 OPC Knob 1
34 A028 9510 OPC Belt 1
35 AA12 0026 Antistatic Brush 1

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0050W Philips Pan Head Screw - M4x5
103 0314 0100W Philips Pan Head Screw - M4x10
104 0951 4006W Philips Screw With Flat Washer - M4
105 0951 4008B Philips Screw With Flat Washer - M4
106 0344 0080F Philips Truss Head Screw - M4x8
107 0344 0060F Philips Truss Head Screw - M4x6
108 0573 0050W Hexagon Headless Set Screw - M3x5
109 0936 0250 Semicircle Key
110 0805 3453 Ball Bearing - 10x26x8mm
111 0805 3429 Ball Bearing - 8x14x4mm
112 0720 0080E Retaining Ring - M8
113 0720 0060E Retaining Ring - M6
114 1105 0197 Wire Saddle
115 1105 0016 Nylon Clip - 4N

Part No. Description

Q’ty Per

Assembly

16. OPC SECTION 2 (A112)

FT9101 40 Parts Location and List

16. OPC SECTION 2 (A112)

Index

No.

1 AA07 0005 Slide Rail 1
2 A028 2690 Slider Rail Support Stay 1
3 AA14 0206 Unlock Shaft 1
4 AD01 6004 Roller 2
5 AA12 0013 Antistatic Brush 1
6 AD01 6002 Roller 1
7 AA14 0205 Unlock Shaft 1
8 5214 1974 Screw - Slider Stopper 1
9 A028 2602 Stopper Bracket Holder 2
10 5442 2752 Bushing - Lower Registration Roller 2
11 A028 2600 Roller Release Cam 4
12 A028 2601 Roller Release Hook 2
13 A028 2674 Rear Side Plate Stopper 1
14 AA06 0163 Spring 1
15 A028 5415 OPC Harness 1
16 AA08 4008 Bearing Case 2
17 A028 2660 Rear Plate Spring - Cleaning 1
18 5403 1910 Spring Anchor - Stopper Lever 1
19 5304 1639 Bushing - 8mm 6
20 A028 2603 Pressure Release Hook 2
21 AA06 0162 Spring 2
22 AA08 4011 Housing 2
23 AZ50 0008 Stabilizer 1
24 A028 2616 Quenching Lamp Stabilizer Bracket 1
25 AA01 1012 Dust Filter 1
26 AX50 0047 Exposure Lamp - 13W 1
27 A028 2615 Quenching Lamp Bracket 1
28 5446 2865 Guide Screw - 6mm 2
29 AD01 6008 Roller 2
30 AA14 0207 Slider Shaft 1
31 A028 2607 Tracking Sensor Actuator 1
32 AB01 3334 Gear - 34Z 1
33 A028 2596 Cleaning Unit Stopper Bracket 4

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A029 4997 Middle Tray Knob 2
35 A028 5306 DC Motor - DC 24V 1
36 A028 2621 Tracking Motor Bracket 1
37 5201 2816 Gear - 16T/40T 1
38 5205 5250 LED Sensor Type S 1
39 A028 2657 Front Plate Spring - Cleaning 1
40 A028 2630 Plate Spring 2
41 A028 2608 Front Pressure Slider 1
42 A028 2643 Tension Adjuster 1
43 AA14 8188 Adjusting Screw 1
44 A028 2679 OPC Belt Unit Guide Holder 1
45 A028 2611 Rear Pressure Slider 1
46 AA00 1190 Decal - Ground 1

Part No. Description

Q’ty Per

Assembly

FT9101 41 Parts Location and List

Index

No.

101 0314 0050W Philips Pan Head Screw - M4x5
102 0314 0060W Philips Pan Head Screw - M4x6
103 0314 0080W Philips Pan Head Screw - M4x8
104 0951 4006W Philips Screw With Flat Washer - M4
105 0313 0080W Philips Pan Head Screw - M3x8
106 0314 0080M Philips Pan Head Screw - M5x8
107 0314 0100W Philips Pan Head Screw - M4x10
108 0951 3005W Philips Screw with Flat Washer - M3
109 0344 0080F Philips Truss Head Screw - M4x8
110 0805 3429 Ball Bearing - 8x14x4mm
111 0805 3428 Ball Bearing - 8x16x5mm
112 1105 0016 Nylon Clip - 4N
113 1105 0008 Nylon Clip - 2N
115 1105 0196 Harness Clamp
116 1105 0120 Wire Clip
117 0720 0040E Retaining Ring - M4
118 0720 0060E Retaining Ring - M6
119 0804 9029 Nut - M6

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 41 Parts Location and List

A

17. OPC CLEANING UNIT 1 (A112)

FT9101 42 Parts Location and List

17. OPC CLEANING UNIT 1 (A112)

Index

No.

* A028 6910 OPC Cleaning Unit 1
1 A028 7027 Cam Shaft Stopper 1
2 A028 7029 Worm Cover 1
3 A028 7022 Cam Bracket Plate 1
4 AB01 1066 Worm Cam 1
5 A028 7023 Motor Cam Bracket 1
6 AB01 7136 Gear - 18Z 1
7 AX04 0024 DC Motor - 12V 1
8 A028 6986 Rear Arm 1
9 AA14 5099 Cam Shaft 1
10 A114 3193 Screw - M5x6 1
11 A028 7005 Sweeper Support Plate 1
12 AA13 4065 Cam Follower 1
13 AA14 8180 Front Support Shaft 1
14 5410 1036 Positioning Pin 2
15 A028 6966 Front Slide Plate 1
16 A028 6995 Front Brush Roller Link 1
17 AA14 3140 Front Positioning Pin 1
18 5304 1639 Bushing - 8mm 4
19 AA14 3148 Fixing Stud 1
20 A028 6985 Front Arm 1
21 AA14 3059 Pin - 6x16 2
22 AA06 6072 Spring 1
23 AA14 8178 Front Support Shaft 1
24 5209 3902 Pin - Pick Off Pawl 1
25 AD04 2007 Brush Roller 1
26 A028 6977 Brush Roller Casing 1
27 A028 6981 Unit Base 1
28 AA14 8150 Drive Shaft 1
29 AA13 2073 Spacer - 4.5x12x2.5 1
30 AA14 3147 Front Positioning Pin 1
31 AA14 0228 Shaft - Link - Brush Roller 1
32 5403 1910 Spring Anchor - Stopper Lever 1

Part No. Description

Q’ty Per

Assembly

Index

No.

33 A028 6971 Rear Side Plate 1
34 AA14 3144 Support Shaft 1
35 A028 6992 Rear Positioning Bracket 1
36 AA13 2072 Spacer - 14x20x1.2 1
37 5350 2466 Spring - Pressure Arm 1
38 A028 7002 Rear Guide Link 1
39 AB01 3361 Gear - 22Z 1

101 0313 0040W Philips Pan Head Screw - M3x4
102 0951 3006W Philips Screw With Flat Washer - M3
103 0951 4008W Philips Screw With Flat Washer - M4
104 0720 0040E Retaining Ring - M4
105 0720 0060E Retaining Ring - M6
106 0740 3506 Ball Bearing - 6x12x4 mm
107 0741 3806 Ball Bearing - 6x13x5mm
108 0573 0040E Hexagon Headless Set Screw - M3x4
109 0574 0040E Hexagon Headless Set Screw - M4x4

Part No. Description

Q’ty Per

Assembly

FT9101 43 Parts Location and List

18. OPC CLEANING UNIT 2 (A112)

FT9101 44 Parts Location and List

18. OPC CLEANING UNIT 2 (A112)

Index

No.

1 A028 7027 Cam Shaft Stopper 1
2 A028 7029 Worm Cover 1
3 A028 7022 Cam Bracket Plate 1
4 AB01 1066 Worm Cam 1
6 A028 7086 Drive Link 1
7 AA14 5092 Link Shaft 1
8 G612 3946 Spring 1
9 A028 7060 Front Gear Bracket 1
10 AA04 3040 Timing Belt - 192P3M6 1
11 AB01 7126 Gear - 30Z 1
12 AB01 7124 Gear - 21/36Z 1
13 A028 7063 Rear Gear Bracket 1
14 AA13 0046 Thightener Pulley 1
15 A028 7056 Tightener Arm 1
16 C200 3638 Lever Spring 1
17 AB03 0099 Pulley - 14Z 1
18 AX02 0042 DC Motor - 24V 1
19 5446 6365 Spring - Discharge Roller 1
20 A028 7041 Drive Support Plate 1
21 A028 7101 Pressure Lever Solenoid 1
22 AA06 0043 Spring - Pressure Cleaning Blade 1
23 A028 7098 Driven Spring Lever 1
24 A028 7096 Pressure Spring Lever 1
25 A028 7092 Pressure Lever Bracket 1
26 A028 5220 Arrester Board 1
27 5918 3120 Stud - M4 1
28 A028 7044 Terminal block Bracket 1
29 A028 7045 Board Bracket 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0315 0060W Philips Pan Head Screw - M5x6
102 0951 4008W Philips Screw with Flat Washer - M4
103 0951 3006W Philips Screw With Flat Washer - M3
104 0951 4005B Philips Screw With Flat Wash.- M4x5
105 0720 0030E Retaining Ring - M3
106 0720 0040E Retaining Ring - M4
107 0720 0060E Retaining Ring - M6
108 0741 3508 Bushing - 8x14x4mm
109 0807 5067 Spacer - 8.1mm x 16mm x 0.5
110 0574 0040E Hexagon Headless Set Screw - M4x4
111 1105 0197 Wire Saddle
112 0314 0080W Philips Pan Head Screw - M4x8
115 1105 0160 Clamp

Part No. Description

Q’ty Per

Assembly

FT9101 45 Parts Location and List

19. DEVELOPMENT UNIT 1 (A112)

FT9101 46 Parts Location and List

19. DEVELOPMENT UNIT 1 (A112)

Index

No.

* A028 3475 Development Unit 1
1 A028 5145 Density Sensor Board - P 1
2 AA14 3117 Stepped Screw - M4 2
3 A028 3685 ID Sensor Bracket 1
4 AA14 3005 Stepped Screw - M4x2.5 4
5 A028 3687 Toner Cartridge Cover Seal 1
6 A028 3686 ID Sensor Duct 1
7 AA12 0014 Antistatic Brush 1
8 A028 3688 ID Sensor Blower Pipe 1
9 AA15 1277 Seal - 8x22x22 1
10 AA14 8149 Pipe Guide Pin 1
11 AA15 1315 Seal - 4x20x25 1
12 AA15 1152 Seal - 3x36.5x45 1
13 A028 3720 Shutter Scraper 1
14 AA06 0229 Spring 2
15 AA05 1011 Hopper Wire 2
16 A028 3625 Wire Hook 1
17 5219 3318 Rubber Seal - Agitator 2
18 AA13 2092 Collar - 6.2x12x2 2
19 AD03 9022 Agitator 1
20 A028 3631 Left Toner Hopper Casing 1
21 A028 3639 Left Hopper Insulating Sheet 1
22 A028 3638 Scraper Holder 1
23 A028 3637 Toner Supply Roller Scraper 1
24 A028 3652 Front Toner Supply Roller Cover 1
25 AA15 1290 Seal - 8x3x50 2
26 A028 3762 Cover Upper Seal 2
27 AA15 2064 Seal - 4x5x526 2
28 A028 3636 Rear Cover - Toner Supply Roller 1
29 AA14 3214 Stepped Screw - M4 2
30 5216 2113 Stepped Screw - Transfer 10
31 A028 3669 Toner Cartridge Seal 1
32 AA15 1408 Seal - 5x9x51 1

Part No. Description

Q’ty Per

Assembly

Index

No.

33 AA15 1288 Seal - 3x7x126.5 1
34 A028 3675 Toner Cartridge Actuator 1
35 AA06 6067 Spring 1
36 A028 3695 Toner Tray Bracket 1
37 A028 3694 Toner Tray 1
38 AX05 0024 DC Motor - 24V 1
39 AX05 0023 DC Motor - 24V 1
40 A028 3677 Toner Supply Motor Bracket 1
41 A028 3700 Toner Supply Motor Joint 2
42 AA08 4018 Bearing Case 4
43 AA08 4020 Bearing Case 2
44 AA15 1294 Seal - 6x6x112 1
45 5219 3326 Rubber Seal - Paddle Roller 4
46 5056 0509 Nut Plate - Microswitch 2
47 A028 3620 Rear Side Plate - Toner Hopper 1
48 A028 5422 Development Harness - B 1
49 G001 2870 Sensor:Toner End 1
50 A028 3646 Right Hopper Casing 1
51 A028 3649 Insulating Sheet - Hopper Casing 1
52 AA15 1293 Seal - 2x23x25 1
53 AA15 1292 Seal - 8x3x83 1
54 5442 3069 Seal - 4 x 145 x 2T 1
55 A028 3651 Scraper Holder 1
56 A028 3648 Toner Supply Roller Exit Seal 1
57 A028 3666 Agitator Positioning Spring 1
58 AA14 0214 Agitaitor Shaft 1
59 A028 3667 Agitator Spring 2
60 AD03 3007 Toner Supply Roller 1
61 A028 3605 Toner Hopper Inner Cover 1
62 AA06 6068 Spring 1
63 A028 3641 Shutter Sensor Bracket 1
64 AA15 1291 Seal - 3x8x124 1
65 A028 3713 Shutter Actuator Roller 1

Part No. Description

Q’ty Per

Assembly

FT9101 47 Parts Location and List

Index

No.

66 A028 3711 Shutter Actuator Bracket 1
67 AB01 3386 Gear - 16Z 1
68 5418 2980 Gear - 28Z 1
69 A028 3611 Front Side Plate - Toner Hopper 1
70 5214 4113 Gear - 28T 1
71 AB01 3231 Gear - 21Z 1
72 A028 3633 Left Hopper Casing 1
73 AA14 3277 Stepped Screw - M4 2

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0050W Philips Pan Head Screw - M4x5
103 0314 0080W Philips Pan Head Screw - M4x8
104 0314 0100W Philips Pan Head Screw - M4x10
105 0314 0140W Philips Pan Head Screw - M4x14
106 0313 0060W Philips Pan Head Screw - M3x6
107 0951 4006B Philips Screw with Flat Washer - M4
108 0314 0080M Philips Pan Head Screw - M5x8
109 0951 3005W Philips Screw with Flat Washer - M3
110 0720 0030E Retaining Ring - M3
111 0720 0040E Retaining Ring - M4
112 0720 0060E Retaining Ring - M6
113 0805 3307 Ball Bearing - 8x14x4mm
114 0805 3371 Ball Bearing - 8x22x7mm
115 1105 0008 Nylon Clip - 2N
116 1106 0193 Bushing - 7.9mm
117 1105 0199 Clamp
118 0344 0060F Philips Truss Head Screw - M4x6
119 1204 1024 Switch

Part No. Description

Q’ty Per

Assembly

FT9101 47 Parts Location and List

A

20. DEVELOPMENT UNIT 2 (A112)

FT9101 48 Parts Location and List

Rev. 5/12/95

20. DEVELOPMENT UNIT 2 (A112)

Index

No.

1 A028 3597 Front Side Seal - Doctor Blade 1
2 AA15 1383 Seal - 2x3x25 2
3 AD03 0011 Development Doctor 1
4 A028 3598 Entrance Seal 1
5 A028 3599 Tape - Development Entrance 1
6 A028 3572 Rear Side Seal - Doctor Blade 1
7 A028 4105 Filter Cover 1
8 A028 3527 Development Filter 1
9 AA01 2016 Dust Filter 1
10 A028 3523 Development Lower Casing 1
11 AA15 1378 Seal - 4x7x24 2
12 AA15 1377 Seal - 4x6x461 1
13 A028 3508 Harness Cover 1
14 AA15 1280 Seal - 2x466x8 1
15 A028 3493 Left Casing 1
16 AA15 1282 Seal - 1x5x500 2
17 A028 3560 Development Shutter Stopper 1
18 AA15 1287 Seal - 2x4.5x92 1
19 A028 3582 Development Shutter 1
20 AA15 1287 Seal - 2x4.5x92 1
21 AD03 1097 Development Sleeve - 3 1
22 AA15 2063 V Ring - M14 6
23 A028 3559 1st/2nd Development Bias Terminal 1
24 A028 3521 Rear Holder - Development Roller 1
25 AA15 0154 Seal - 0.05x12x75 1
26 A028 3522 Holder Seal - Development Roller 2
27 A028 3555 Oil Seal 3
28 AB01 3346 Gear - 27Z 3
29 AB01 3171 Idler Gear 1
30 5216 2113 Stepped Screw - Transfer 2
31 A028 3509 Harness Bracket 1
32 5415 4125 Nylon Clip 1
33 AD03 1096 Development Sleeve - 2 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 AD03 1095 Development Sleeve - 1 1
35 AA14 0211 Joint Shaft 1
36 A028 3481 Rear Cover 1
37 AB01 7087 Joint Gear - 37Z 1
38 5429 3561 Ball Bearing - 10x26x8 2
39 A028 3549 Oil Seal 2
40 A028 3571 Stepped Screw 6
41 A028 3570 Toner Supply Unit Fixing Plate 1
42 A028 3568 Tightener Pulley 2
43 AB03 0079 Pulley - 18Z 1
44 A028 3566 Development Rear Tightener Bracket 1
45 AA08 4023 Bearing Case 2
46 AA08 4024 Bearing Case 4
47 A028 3535 Paddle Drive Gear 1
48 AA04 3027 Timing Belt - 279P3M10 1
49 AB03 0253 Pulley - 25Z 1
50 A028 3558 Third Development Bias Terminal 1
51 A028 5420 Development Harness - A 1
52 A028 3495 Right Development Casing 1
53 A028 3530 Insulating Sheet 1
54 A028 3548 Development Control Board Bracket 1
55 A028 5150 Density Sensor Board - F 1
56 AD03 8010 Paddle Wheel 2
57 5219 3326 Rubber Seal - Paddle Roller 4
58 AA15 1285 Seal - 3x16x14 1
59 A028 3542 Cross-Mixing Plate 1
60 A028 3500 Rear Side Plate 1
61 A028 3492 Lower Seal - Front Side Plate 2
62 AA15 1309 Seal - 2x3x62 1
63 5446 3105 Transport Auger 1
64 A028 3540 Cross-Mixing Casing 1
65 A028 3490 Front Side Plate 1
66 AG05 1034 Development Knob 1

Part No. Description

Q’ty Per

Assembly

FT9101 49 Parts Location and List

Index

No.

67 A028 3768 Development Unit Stopper 1
68 A028 3579 Front Tightener Bracket 1
69 AB03 0081 Pulley - 20Z 1
70 AA04 3026 Timing Belt - 255P3M10 1
71 AB03 0082 Pulley - 44Z 1
72 AG05 0027 Knob 1
73 A028 3575 Magnet Fixing Plate 3
74 A028 3511 Front Holder - Development Roller 1
75 AA15 0153 Seal - 0.05x12x53 1
76 A028 3587 Lock Unit Bracket 1
77 A028 3595 Lock Unit Spring Plate 1
78 A028 3591 Lock Unit Lever 1
79 5446 5233 Developer Sensor 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0951 4008B Philips Screw With Flat Washer - M4
103 0951 4006B Philips Screw with Flat Washer - M4
104 0314 0060G Philips Pan Head Screw - M4x6
105 0314 0060M Philips Pan Head Screw - M4x6
106 0344 0060F Philips Truss Head Screw - M4x6
107 0314 0100W Philips Pan Head Screw - M4x10
108 0951 4012B Philips Screw With Flat Washer
109 0314 0080W Philips Pan Head Screw - M4x8
110 0313 0050G Philips Pan Head Screw - M3x5
111 0951 4006W Philips Screw With Flat Washer - M4
112 0720 0030E Retaining Ring - M3
113 0720 0040E Retaining Ring - M4
114 0720 0060E Retaining Ring - M6
115 0720 0080E Retaining Ring - M8
116 0313 0100W Philips Pan Head Screw - M3x10
117 0725 0150E Retaining Ring C - M15
118 0805 3442 Ball Bearing - 15x32mm
119 0805 3370 Ball Bearing - 6x19x6mm
120 0805 3371 Ball Bearing - 8x22x7mm
121 0313 0060M Philips Pan Head Screw - M3x6

Part No. Description

Q’ty Per

Assembly

FT9101 49 Parts Location and List

A

21. TRANSFER AND SEPARATION (A112)

FT9101 50 Parts Location and List

Rev. 6/28/96

21. TRANSFER AND SEPARATION (A112)

Rev. 6/28/96

Index

No.

* AD00 4027 T&S Corona Unit 1
* A028 4340 Transport Unit 1
1 5446 9001 Transport Belt - 4pcs/set 1
2 A028 4388 Transport Drive Roller 1
3 A028 4368 Transport Chamber 1
4 AF02 2018 Driven Roller 1
5 AA15 1230 Seal - 20x8x59 2
6 AA15 1231 Seal - 5x44x64 1
7 A028 4369 Transport Guide Plate 1
8 AD00 4027 T&S Corona Unit 1
9 A028 5426 Separation Sensor Harness 1
10 A028 5393 T&S Sensor 1
11 A028 4392 Rear Unlock Lever 1
12 A028 4394 Unlock Hook 2
13 A028 4357 T & S Spring Plate 4
14 A028 4383 Transport Casing 1
15 AD02 2116 Rear End Block 1
16 AA06 0231 Spring 2
17 AD02 2118 Rear End Block Cover 1
18 AD02 3131 T&S Corona Casing 1
19 A028 4436 Adjusting Plate 1
20 A028 4438 Transfer Entrance Seal 1
21 A028 4442 Rear Paper Guide 1
22 A028 4441 Front Paper Guide 1
23 AA06 3128 Spring 2
24 A028 4449 Transfer Adjusting Knob 2
25 5447 2769 Stepped Screw 2
26 AD02 2117 Front End Block Cover 1
27 A028 9003 T&S Corona Wire 1
28 AD02 2115 Front End Block 1
29 AA06 3065 Spring 2
30 AD02 1026 Corona Wire Receptacle 1
31 A028 4448 T/S Corona Wiring 2

Part No. Description

Q’ty Per

Assembly

Index

No.

32 AB01 3236 Gear - 21Z 1
33 A028 4381 Transport Support Plate 1
34 A028 4840 Fusing Lock Bracket 1
35 A028 4393 Unlock Link Guide 2
36 A028 4395 Unlock Link 2
37 AA06 0149 Spring 2
38 AA14 8083 Link Shaft 2
39 A028 4414 Harness Clamp 1
40 A028 4412 Power Supply Cover 1
41 A028 4411 Power Pack Cover 1
42 AZ32 0021 TD Power Pack 1
43 A028 5425 T&S Harness 1
44 A028 4391 Front Unlock Lever 1
45 A028 4413 Unlock Stopper 1
46 5442 1659 Stepped Screw - M4 1
47 AD02 1027 Corona Wire Receptacle 1
48 A028 4451 Unlock Lever 1
49 A028 4453 Decal - Misfeed Removal C 1
50 A028 4415 Decal - High Voltage 1
51 A028 4378 Rear Shaft - Transport Unit 1
52 A028 4385 Separation Sensor Cover 1
53 AA15 1513 Sensor Seal 1
54 A028 4384 Separation Sensor Ass’y 1
55 A028 4440 Insulating Tape - 13.5x436mm 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080M Philips Pan Head Screw - M5x8
103 0324 0060W Philips Sunken Head Screw - M4x6
104 0313 0080W Philips Pan Head Screw - M3x8
105 0951 4008W Philips Screw with Flat Washer - M4
106 0951 4010W Philips Screw With Flat Washer - M4
107 0971 4006A Philips Polycarbonate Screw - M4x6
108 0720 0060E Retaining Ring - M6
109 0805 3307 Ball Bearing - 8x14x4mm
110 1105 0008 Nylon Clip - 2N
111 1105 0016 Nylon Clip - 4N
112 1106 0458 Bushing - 9.9mm
113 0807 3009 Leaf Spring
114 0701 0040W Flat Washer - M4
115 0972 4008A Philips Polycarbonate Screw - M4 x
116 0720 0040E Retaining Ring - M4
117 0805 3068 Ball Bearing
118 0805 3437 Ball Bearing - 5x13x4mm

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 51 Parts Location and List

A

22. CLEANING UNIT (A112)

FT9101 52 Parts Location and List

22. CLEANING UNIT (A112)

Index

No.

* A028 3913 Cleaning Unit 1
1 A028 4105 Filter Cover 1
2 A028 3527 Development Filter 1
3 AA01 2016 Dust Filter 1
4 A028 4099 Upper Cleaning Cover 1
5 AA07 0008 Slide Rail 2
6 AB01 7118 Knob 1
7 AB01 7117 Gear - 34Z 1
8 AA08 4009 Housing 1
9 5013 0447 Collar 1
10 AB01 3336 Gear - 25Z 1
11 A028 3955 Front Left Side Plate 1
12 AA15 1262 Seal - 1.5x10x15 2
13 AA15 1263 Seal - 3x14x6 2
14 AX64 0005 Fan 1
15 AA15 0091 Seal - 0.125x27x62 1
16 5219 3292 Bearing Case - Development Roller 2
17 AB01 3335 Gear - 37Z 1
18 AA14 3113 Front Stay 2
19 A028 3973 Front Sleeve Holder 1
20 A028 3976 Decal - Magnet Adjuster 1
21 A028 3972 Front Magnet Adjuster 1
22 AD00 4028 PCC Corona Unit 1
23 AD02 4014 Anchor Hook 1
24 AD02 3031 PCC Corona Casing 1
25 AD02 2139 Front End Block 1
26 AD02 4016 Corona Wire Spring 1
27 AD02 2140 Front End Block Cover 1
28 A028 9004 PCC Corona Wire (10pcs/set) 1
29 AD02 2141 Rear End Block 1
30 5446 3956 Transfer Terminal 1
31 5446 3957 Spring - Terminal 1
32 AD02 2142 Rear End Block Cover 1

Part No. Description

Q’ty Per

Assembly

Index

No.

33 AA07 0007 Slide Rail 2
34 A028 3991 Right Blade Holder 1
35 AD04 6004 Cleaning Blade 1
36 A028 3990 Left Blade Holder 1
37 5446 2183 Guide Pin - 8 2
38 A028 3978 Left Cleaning Casing 1
39 AA15 0105 Seal - 0.075x473x16 1
40 AA15 2060 Seal - 4x480x8 1
41 A028 4010 Cleaning Doctor 1
42 AD04 3012 Toner Collection Coil 1
43 AD04 5004 Scavenge Roller 1
44 AD04 0002 Sleeve 1
45 AA15 1264 Seal - 3x10x39 2
46 AA15 0166 Seal - 3x13x22 1
47 AA15 1260 Seal - 1.5x13.5x3 2
48 AA15 1261 Seal - 1.5x13.5x3 2
49 A028 4017 Sleeve Relay Terminal 2
50 A028 4015 Front Bias Terminal 1
51 A028 5432 Varistor Harness 1
52 AA14 3098 Adjusting Pin 2
53 A028 3959 Front Right Side Plate 1
54 AA15 1271 Seal - 3x480x6 1
55 A028 3995 Right Cleaning Casing 1
56 AD04 7005 Entrance Seal 1
57 AZ30 0021 PCC Power Pack 1
58 A028 4029 PCC Bracket 1
59 A028 4030 PCC Rail 1
60 AA06 0167 Spring 1
61 A028 4063 Unlock Link 1
62 5442 2117 Shoulder Screw - Hinge 2
63 A028 9007 Pick-off Pawl (10pcs/set) 1
64 AA08 4022 Bearing Case 1
65 A028 4018 Scavenge Roller Terminal 1

Part No. Description

Q’ty Per

Assembly

FT9101 53 Parts Location and List

Index

No.

66 AA14 3116 Terminal Pin 1
67 AA06 3064 Spring 2
68 AB01 7115 Joint 1
69 AA15 1374 Seal - 1.5x27x46 1
70 A028 3963 Rear Left Side Plate 1
71 AA15 1375 Seal - 1.5x27x46 1
72 5446 3620 Spring - Toner Receiving 1
73 5446 3619 Toner Receiving Pipe 1
74 A028 4016 Rear Bias Terminal 1
75 AB01 3237 Gear - 45Z 1
76 5219 3326 Rubber Seal - Paddle Roller 2
77 AA14 3114 Rear Stay 2
78 A028 3974 Rear Sleeve Holder 1
79 AA15 0093 Seal - 0.125x27x62 1
80 AA15 0167 Seal - 3x13x22 1
81 AD02 1038 Corona Wire Receptacle 1
82 5875 1521 Shoulder Screw - M4 1
83 AA14 3119 Terminal Pin 1
84 A028 5430 Cleaning Unit Harness 1
85 5446 3944 Spring - Charge Wire PCC 1
86 A028 3967 Rear Right Side Plate 1
87 5447 1778 Stepped Screw - M4 2

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0100W Philips Pan Head Screw - M4x10
104 0314 0120W Philips Pan Head Screw - M4x12
105 0313 0140W Philips Pan Head Screw - M3x14
106 0314 0200W Philips Pan Head Screw - M4x20
107 0314 0060M Philips Pan Head Screw - M4x6
108 0313 0080W Philips Pan Head Screw - M3x8
109 0951 4005W Philips Screw With Flat Washer - M4
110 0951 4006W Philips Screw With Flat Washer - M4
111 0951 4008W Philips Screw with Flat Washer - M4
112 0951 4012B Philips Screw With Flat Washer
113 0971 4005A Philips Polycarbonate Screw - M4x5
114 0972 4006A Philips Polycarbonate Screw - M4x6
115 0720 0040E Retaining Ring - M4
116 0720 0060E Retaining Ring - M6
117 0725 0150E Retaining Ring C - M15
118 0805 3432 Ball Bearing - 6x15x5mm
119 0805 3442 Ball Bearing - 15x32mm
120 0805 3441 Ball Bearing - 8x22mm
121 1105 0008 Nylon Clip - 2N
122 1105 0091 Cable Clip - 16mm
123 0951 4006B Philips Screw with Flat Washer - M4

Part No. Description

Q’ty Per

Assembly

FT9101 53 Parts Location and List

A

23. FUSING UNIT 1 (A112)

FT9101 54 Parts Location and List

23. FUSING UNIT 1 (A112)

Index

No.

* A112 0245 Fusing Unit Ass’y 1
1 A028 4731 Oil Application Base 1
2 A028 4734 Oil Pan 1
3 A028 4746 Blade Support Plate 1
4 AE04 3002 Cleaning Blade 1
5 A028 4740 Spring Plate 2
6 A028 4744 Oil Application Bracket 1
7 A028 4738 Stripper Return Bracket 2
8 A028 4739 Spring 2
9 A028 4749 Blade Support Plate 1
10 AD04 6004 Cleaning Blade 1
11 AA14 3191 Positioning Pin 1
12 AE04 5006 Oil Supply Pad 1
13 AE04 5003 Oil Supply Pad Bracket 1
14 A028 4761 Oil Sump 1
15 5201 1796 Stepped Screw - M4 2
16 A028 4766 Metering Blade Holder 1
17 AA06 0145 Spring 2
18 AA00 0015 Decal - High Temperature 1
19 A028 4823 Upper Cover 1
20 5403 2075 Stepped Screw 6
21 A028 4694 Left Guide Plate 1
22 A028 4697 Right Guide Plate 1
23 A028 4686 Fusing Transport Upper Stay 1
24 A028 4691 Driven Roller Bracket 3
25 AE03 1004 Bushing 6
26 AF04 0013 Driven Roller 3
27 A028 4692 Driven Roller Spring 3
28 A028 4665 Rear Lock Bracket 6
29 AE03 0006 Bushing 1
30 AB01 3306 Gear - 29Z 1
31 AB01 3308 Gear - 18Z 1
32 AB01 3307 Gear - 27Z 1

Part No. Description

Q’ty Per

Assembly

Index

No.

33 A028 4654 Operation Panel Rear Plate 1
34 A028 4662 Rear Lock Bracket - Guide Plate 1
35 AF02 0093 Transport Roller 1
36 A028 4681 Front Lock Bracket 1
37 A028 4679 Front Lock Bracket 1
38 A028 4674 Operation Panel Front Plate 1
39 AG05 0021 Fusing Knob 1
40 AA00 0028 Decal - D1 1
41 AG07 0001 Magnetic 1
42 A028 4723 Stripper Bracket Handle 1
43 A028 4725 Stopper - Hot Roller Stripper 1
44 A028 4722 Hot Roller Stripper Bracket 1
45 AA14 0200 Hook Shaft 1
46 AA06 0144 Spring 10
47 A028 9006 Hot Roller Stripper (10pcs/set) 1
48 A028 4735 Oil Supply Unit 1

101 0344 0060F Philips Truss Head Screw - M4x6
102 0314 0060W Philips Pan Head Screw - M4x6
103 0951 4012B Philips Screw With Flat Washer
104 0951 3006W Philips Screw With Flat Washer - M3
105 0951 4006B Philips Screw with Flat Washer - M4
106 0936 0250 Semicircle Key
107 0720 0040E Retaining Ring - M4
108 0720 0060E Retaining Ring - M6

Part No. Description

Q’ty Per

Assembly

FT9101 55 Parts Location and List

24. FUSING UNIT 2 (A112)

FT9101 56 Parts Location and List

24. FUSING UNIT 2 (A112)

Index

No.

1 A028 4809 Right Cover 1
2 A028 4818 Front Cover 1
3 AA00 0028 Decal - D1 1
4 A028 4605 Left Fusing Stay 1
5 A028 4646 Oil Guide Plate 1
6 5919 2201 Shoulder Screw - M4 2
7 AX45 0012 Fusing Lamp - 2Kw 230V 1
8 AE03 2005 Bushing 2
9 AA13 2049 Spacer - 26.2x38x2.3 2
10 A028 4608 Upper Fusing Stay 1
11 AE01 1014 Hot Roller 1
12 A028 4614 Harness Cover 1
13 AG05 0025 Knob 1
14 A028 4804 Fusing Unlock Lever 1
15 AA06 0147 Spring 1
16 AA14 3108 Lever Shaft 1
17 AA13 2050 Spacer - 26.5x38x2 1
18 5446 4090 Ball Bearing - 30x55x13mm 2
19 A028 5511 Thermofuse Harness 1
20 AA14 3107 Stopper Shaft 1
21 A028 4775 Unlock Plate 1
22 A028 4796 Oil Catch Felt 1
23 A028 4797 Oil Catch Pan 1
24 5403 2075 Stepped Screw 1
25 A028 4780 Fusing Stopper Arm 1
26 A028 4555 Front Side Plate 1
27 AA06 3062 Spring 2
28 A028 4571 Fusing Pressure Base 2
29 5219 4624 Ball Bearing - 12 x 20 x 42 mm 2
30 AE02 0011 Pressure Roller 1
31 A028 4632 Parallel Key 1
32 5446 4522 Pressure Spring Holder 2
33 A028 4564 Upper Pressure Lever 2

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 4566 Lower Pressure Lever 2
35 AA14 3105 Screw - M5x20 1
36 AA14 0197 Pressure Roller Shaft 1
37 A028 4712 Guide Plate - Pressure 1
38 5415 4056 Shaft Holder 1
39 A028 5510 Fusing Harness 1
40 AB01 3305 Gear - 78Z 1
41 5415 4125 Nylon Clip 1
42 5446 4390 Front Grip - Fusing Unit 1
43 A028 4604 Heater Rear Bracket 1
44 A028 4579 Rear Side Plate 1
45 A028 4625 Gear Cover 1
46 A028 4643 Blade Guide Holder 2
47 A028 4642 Blade Guide 2
48 A028 4647 Left Entrance Guide 1
49 A028 4783 Oil Seal Bracket 1
50 AA14 3106 Oil Seal Shaft 1
51 A028 4810 Grip Cover 1
52 AA06 0146 Spring 1
53 AG05 1026 Grip 1
54 5446 4157 Oil Seal Valve 1
55 A028 4794 Oil Seal Lever 1
56 A028 4711 Pressure Plate Guide 1
57 A028 2978 Decal - D3 1
58 A028 4713 Pressure Plate Cover 1
59 A028 4603 Right Fusing Stay 1
60 A028 4609 Shaft Holder - Pressure Guide Plate 1
61 A028 4597 Oil Blade Front Holder 1
62 5204 4148 Cleaning 2nd Blade 1
63 5429 4451 Blade Holder 1
64 A028 4580 Oil Pan 1
65 5429 4887 Decal - Thermofuse 1
66 A028 4629 Oil Stopper Scraper 1

Part No. Description

Q’ty Per

Assembly

FT9101 57 Parts Location and List

Index

No.

67 A028 4630 Scraper Holder 1
68 A028 4622 Right Entrance Guide 1
69 A028 4619 Thermistor Bracket 1
70 A028 4645 Front Heater Bracket 1
71 5429 5567 Thermofuse - 192C 1
72 A028 5370 Thermistor 1
73 5420 4323 Temperature Fuse Holder - 169C 1
74 A028 4617 Thermofuse Bracket 1
75 A028 4595 Oil Blade 1
76 5214 4970 Caution Decal - High Temperature (EU) 1
76 5214 4972 Caution Decal - High Temperature (USA) 1
77 A028 4855 Fusing Connector Bracket 1
78 A028 4856 Connector Shielding Bracket 1
79 AA06 6059 Spring 1
80 AA14 3109 Connector Shaft 1
81 A028 3627 Stepped Screw 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0725 0200E Retaining Ring C - M20
102 0725 0260E Retaining Ring C - M25
103 0344 0060F Philips Truss Head Screw - M4x6
104 0313 0060W Philips Pan Head Screw - M3x6
105 0314 0060W Philips Pan Head Screw - M4x6
106 0314 0500W Philips Pan Head Screw - M4x50
107 0805 3068 Ball Bearing
108 0951 5008B Philips Screw With Flat Washer - M5
109 0314 0040W Philips Pan Head Screw - M4x4
110 0313 0060M Philips Pan Head Screw - M3x6
111 0951 4006B Philips Screw with Flat Washer - M4
112 0585 0101W Bolt - M5x10
113 0712 0050B Hexagon Nut - M5
114 0710 0040W Hexagon Nut - M4
115 0951 4006W Philips Screw With Flat Washer - M4
116 0314 0060M Philips Pan Head Screw - M4x6
117 0951 4010W Philips Screw With Flat Washer - M4
118 0314 0120W Philips Pan Head Screw - M4x12
119 0315 0120W Philips Pan Head Screw - M5x12
120 0720 0030E Retaining Ring - M3
121 0720 0040E Retaining Ring - M4
122 0720 0060E Retaining Ring - M6
123 0801 1239 Screw - Inner Cover
124 0720 0020E Retaining Ring - M2

Part No. Description

Q’ty Per

Assembly

FT9101 57 Parts Location and List

A

Rev. 6/4/96

25. DUPLEX AND PAPER EXIT SECTION 1 (A112)

FT9101 58 Parts Location and List

25. DUPLEX AND PAPER EXIT SECTION 1 (A112)

Index

No.

1 A028 6814 Cover Seal 1
2 A028 6845 Fixing Bracket - 30 2
3 AB01 3239 Pinion Gear 1
4 A028 6812 Side Fence Guide Cover 1
5 A028 6811 Rear Side Fence Felt 1
6 A028 6810 Rear Side Fence Guide 1
7 A028 1658 Decal - Rear Guide 1
8 A028 6809 Rear Side Fence 1
9 A028 6801 Rear Rack 1
10 A028 6797 Potentiomiter Bracket 1
11 A028 5380 Resistor - 10K Ohm 1
12 A028 6800 Front Rack 1
13 A028 6798 Potentiomiter Lever 1
14 A028 6806 Front Side Fence Felt 1
15 A028 6804 Front Side Fence 1
16 A028 6805 Front Side Fence Guide 1
17 A028 1659 Decal - Front Guide 1
18 A028 6846 Fixing Bracket - 35 2
19 A112 6790 Copy Tray Cover 1
20 A028 1660 Decal - Middle Guide 1
21 A028 6749 Copy Tray Rear Hook 1
22 AA14 0192 Hook Lock Shaft 1
23 A028 6750 Copy Tray Front Hook 1
24 AA06 0150 Spring 1
25 A028 6751 Copy Tray Arm 1
26 AA13 4043 Roller 2
27 AF02 2022 Exit Driven Roller 1
28 A028 5447 Middle Tray Harness 1
29 AW01 0004 Photosensor 3
30 A028 6222 Pressure Lever 9
31 AA06 3058 Spring 9
32 A028 6747 Side Guide 2
33 A028 6743 Exit Guide Plate 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 AF02 2025 Transport Driven Roller 4
35 AA12 0033 Antistatic Brush 1
36 A028 6732 Upper Stay 1
37 AB01 3238 Gear - 10Z 1
38 A028 6756 Bushing - M10 1
39 A028 6758 Screw - M10 1
40 AA14 3092 Shaft 1
41 A028 6605 Sensor Bracket 2
42 A028 6763 Copy Tray Rear Cover 1
43 5214 1974 Screw - Slider Stopper 1
44 A028 6762 Copy Tray Front Cover 1
45 A028 6825 Right Cover 1
46 A028 6829 Upper Seal 2
47 A028 6830 Lower Seal 1
48 A028 6768 Connector Bracket 1
49 A028 6729 Right Lower Stay 1
50 A028 6769 Connector Cover 1
51 A028 6765 Bracket Cover 1
52 A028 6739 Interlock Switch Feeler 1
53 AA14 3091 Lever Pin 1
54 A028 6735 Front Bracket 1
55 A028 6740 Copy Tray Lever 1
56 5205 3966 Set Screw 1
57 AA13 4033 Roller 1
58 A028 6752 Front Hook Holder 1
59 A028 6844 Side Guide 2
60 A028 6764 Gas Spring Bracket 1
61 A028 6817 Inner Cover 2
62 AG07 0004 Magnet Catch Ass’y 2
63 AA14 0140 Screw - M3x4.5 4
64 A028 6528 Gas Spring 1
65 A028 6753 Rear Hook Holder 1
66 AA13 4034 Roller 4

Part No. Description

Q’ty Per

Assembly

FT9101 59 Parts Location and List

Rev. 6/4/96

Index

No.

67 A028 6785 Copy Tray Support Plate 1
68 AA14 5072 Clipper Shaft 2
69 A028 6787 Copy Tray Clipper 2
70 A028 6773 Copy Tray 1
71 A028 6780 Copy Tray Front Guide 1
72 A028 6781 Copy Tray Rear Guide 1
73 A028 6783 Copy Tray End Fence 1
74 A028 6778 Caster Bracket 3
75 A028 1661 Decal - SADF Operation 1
76 AA12 0033 Antistatic Brush 1
77 AA12 0033 Antistatic Brush 3
78 5875 1521 Shoulder Screw - M4 1
79 A028 5445 Duplex Harness - A 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0324 0060W Philips Sunken Head Screw - M4x6
103 0951 4006B Philips Screw with Flat Washer - M4
104 0313 0060W Philips Pan Head Screw - M3x6
105 0323 0100W Philips Sunken Head Screw - M3 x 10
106 0951 4006W Philips Screw With Flat Washer - M4
107 0313 0080W Philips Pan Head Screw - M3x8
108 0313 0100W Philips Pan Head Screw - M3x10
109 0324 0080W Philips Sunken Head Screw - M4x8
110 0344 0080F Philips Truss Head Screw - M4x8
111 0720 0040E Retaining Ring - M4
112 0720 0060E Retaining Ring - M6
113 0720 0030E Retaining Ring - M3
114 0701 0060W Flat Washer - M6
115 0805 3145 Ball Bearing - 6x12x4mm
116 0805 3058 Ball Bearing - 8x16x4mm
117 0805 3036 Ball Bearing - 8x16x5mm
118 0805 3035 Ball Bearing - 6x12x4mm
119 1105 0278 Harness Clamp
120 1106 0411 Bushing - 11.5mm

Part No. Description

Q’ty Per

Assembly

26. DUPLEX AND PAPER EXIT SECTION 2 (A112)

FT9101 60 Parts Location and List

26. DUPLEX AND PAPER EXIT SECTION 2 (A112)

Index

No.

1 AA06 0159 Spring 1
2 A028 6096 Sensor Lever 1
3 A028 6590 Sensor Guide 1
4 A028 6084 Rear Cooling Seal 1
5 A028 6229 Position Bracket 2
6 AA04 3021 Belt - 330P3M6 1
7 AB03 0061 Pulley - 21Z 1
8 AB01 7107 Gear - 21/27Z 1
9 AB01 7106 Gear - 21/27Z 1
10 AA06 3082 Spring 1
11 A028 6554 Tightener Spring Bracket 1
12 A028 6559 Roller 1
13 A028 6547 Tightener 1
14 A028 6582 Sensor Cover 1
15 5205 5250 LED Sensor Type S 1
16 A028 6280 Air Knife Exit Shaft 1
17 A028 6287 Duplex Exit Guide 1
18 AA06 3058 Spring 2
19 A028 6285 Air Knife Pressure Plate 2
20 A028 6276 Air Knife Exit Guide Plate 1
21 AB01 3269 Gear - 21Z 1
22 A028 6265 Rear Side Plate - Air Knife 1
23 A028 6298 Air Knife Duct Guide Plate 1
24 A028 6308 Exit Guide Plate 3
25 A028 6299 Air Knife Duct Seal 1
26 A028 6291 Air Knife Upper Duct 1
27 A028 6293 Air Knife Upper Seal 1
28 A028 6295 Air Knife Rear Lower Seal 1
29 A028 6294 Air Knife Front Lower Seal 1
30 AF02 0086 Air Knife Roller 1
31 AF02 5004 Separation Pawl 1
32 A028 6268 Air Knife Entrance Guide Plate 1
33 A028 6260 Front Side Plate - Air Knife 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 AA06 0155 Spring 1
35 A028 6302 Air Knife Separation Lever 1
36 A028 6592 Upper Left Inner Cover 1
37 A028 6566 Arm 1
38 A028 6575 Separation Solenoid 1
39 A028 6571 Solenoid Guide 1
40 A028 6563 Solenoid Bracket 1
41 A028 6304 Air Knife Unit Bracket 1
42 5887 4176 Screw 2
43 AA13 0013 Guide Plate Stopper 2
44 A028 6587 Drive Guide 1
45 A028 6588 Bushing Guide 1
46 AA13 4035 Roller 2
47 A028 6558 Fan Guide 1
48 AX64 0008 Fan 1
49 A028 1196 Left Lower Fan Guard 1
50 A028 6556 Fan Bracket 1
51 A028 6593 Lower Left Inner Cover 1
52 AF02 0079 Transport Roller 1
53 AA12 0033 Antistatic Brush 1
54 A028 6233 Upper Cooling Guide Plate 1
55 AA06 3085 Spring 1
56 A028 6249 Upper Position Bracket 1
57 AF02 2021 Cooling Roller 1
58 AA00 1127 Decal - Cooling Duct 1
59 AX64 0010 LD Cooling Fan 1
60 A028 6253 Guard 1
61 A028 6228 Middle Duct Cover 1
62 A028 6252 Guard 1
63 AX64 0009 Fan 1
64 5203 2679 Pinion Tightening Screw - M4x5 1
65 A028 6227 Front Duct Cover 1
66 A028 5449 Fan Duct Harness 1

Part No. Description

Q’ty Per

Assembly

FT9101 61 Parts Location and List

Index

No.

67 A028 6225 Cooling Duct 1
68 AA14 3195 Screw - M3 1
69 A028 6218 Lower Position Bracket 1
70 AA06 3084 Spring 1
71 AF02 0084 Cooling Roller 1
72 A028 6222 Pressure Lever 1
73 AA06 3058 Spring 2
74 A028 6208 Lower Cooling Guide Plate 2
75 A028 6110 Outer Guide Plate 1
76 A028 6605 Sensor Bracket 1
77 AW01 0004 Photosensor 1
78 A028 6098 Left Stay 1
79 A028 6099 Stay - Plate Nut 1
80 5408 2349 Stepped Screw - Cassette Detect 1
81 A028 6601 Connector Bracket 1
82 A028 5445 Duplex Harness - A 1
83 5214 4970 Caution Decal - High Temperature (EU) 1
83 5214 4972 Caution Decal - High Temperature (USA) 1
84 5875 1521 Shoulder Screw - M4 1
85 AA00 1273 Decal - E2 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0344 0080F Philips Truss Head Screw - M4x8
103 0344 0060F Philips Truss Head Screw - M4x6
104 0314 0100W Philips Pan Head Screw - M4x10
105 0314 0300W Philips Pan Head Screw - M4x30
106 0313 0100W Philips Pan Head Screw - M3x10
107 0313 0060W Philips Pan Head Screw - M3x6
108 0313 0050W Philips Pan Head Screw - M3x5
109 0314 0080W Philips Pan Head Screw - M4x8
110 0951 4006W Philips Screw With Flat Washer - M4
111 0801 1239 Screw - Inner Cover
112 0951 3006W Philips Screw With Flat Washer - M3
113 0720 0030E Retaining Ring - M3
114 0720 0040E Retaining Ring - M4
115 0720 0060E Retaining Ring - M6
116 0720 0080E Retaining Ring - M8
117 0805 3058 Ball Bearing - 8x16x4mm
118 0805 3145 Ball Bearing - 6x12x4mm
119 0805 3307 Ball Bearing - 8x14x4mm
120 0807 4075 Washer - 6.1 x 8.2 x 0.5mm
121 1105 0196 Harness Clamp
122 0951 4006B Philips Screw with Flat Washer - M4

Part No. Description

Q’ty Per

Assembly

FT9101 61 Parts Location and List

A

27. DUPLEX AND PAPER EXIT SECTION 3 (A112)

FT9101 62 Parts Location and List

Rev. 6/4/96

27. DUPLEX AND PAPER EXIT SECTION 3 (A112)

Index

No.

1 A028 6535 Drive Bracket 1
2 5203 2679 Pinion Tightening Screw - M4x5 2
3 AB01 1042 Gear - 30Z 1
4 AB01 1038 Gear - 30Z 1
5 AB01 1044 Gear - 59Z 1
6 AB01 1046 Gear - 50Z 1
7 A028 6538 Drive Bracket 1
8 AB01 3293 Gear - 25Z 1
9 AA14 5069 Horizontal Transport Shaft 1
10 AB01 1048 Gear - 30Z 1
11 AB01 1049 Gear - 50Z 1
12 AB01 7097 Gear - 21/27Z 1
13 A028 6643 Air Knife Exit Fan Seal 1
14 A028 6652 Vacuum Fan Seal 1
15 5887 4176 Screw 1
16 AB03 0067 Pulley - 18Z 1
17 A028 6559 Roller 2
18 AB03 0065 Pulley - 24Z 1
19 AB03 0062 Pulley - 24Z 1
20 A028 6549 Shaft 1
21 A028 6540 Bushing 1
22 AB01 3290 Gear - 16Z 1
23 A028 6547 Tightener 1
24 A028 6354 Guide Plate Stopper Holder 2
25 AA14 3099 Stopper Shaft 2
26 AA06 3073 Spring 2
27 A028 6353 Guide Plate Bracket Stopper 2
28 AB01 3272 Gear - 18Z 2
29 AF02 0087 Exit Tray Roller 1
30 AB01 3291 Gear - 36Z 1
31 AB01 3270 Gear - 28Z 1
32 A028 5453 Exit Sensor Harness 1
33 AW01 0004 Photosensor 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 6525 Exit Sensor Bracket 1
35 5203 1362 Ratch - Plunger 2
36 5203 1361 Ratch - Grommet 2
37 A028 6098 Left Stay 1
38 AF02 0083 Grip Roller 1
39 AF02 0085 Duplex Drive Roller 1
40 A028 6150 Guide Plate 1
41 A028 6156 Vertical Transport Guide 1
42 A028 6595 Upper Right Inner Cover 1
43 AB01 1037 Gear - 16Z 2
44 AB01 3279 Gear - 20Z 1
45 AB01 3278 Gear - 20Z 1
46 AB01 3220 Gear - 20Z 1
47 AB01 3230 Gear - 40Z 1
48 A028 6520 Duplex Feed Position Plate 1
49 A028 6597 Lower Right Inner Cover 1
50 A028 6122 Torque Limiter 1
51 AF03 2001 Separation Roller 1
52 5206 2686 Snap Ring 1
53 A028 6126 Torque Limiter Drive Shaft 1
54 AA06 6040 Spring 1
55 A028 6140 Front Lower Casing - Air Knife 1
56 A028 6131 Torque Limiter Guide Plate 1
57 A028 5452 Registration Sensor Harness 1
58 A028 5170 Upper Duplex Feed Sensor 1
59 A028 6142 Front Lower Seal - Air Knife 2
60 A028 6145 Rear Lower Casing - Air Knife 1
61 A028 6148 Rear Lower Entrance Seal 1
62 A028 6147 Rear Lower Seal - Air Knife 2
63 A028 3165 Grip Supporter 2
64 A028 3166 Spring Supporter 1
65 AA06 3059 Spring 1
66 A028 3168 Spring Slider 1

Part No. Description

Q’ty Per

Assembly

FT9101 63 Parts Location and List

Rev. 6/4/96

Index

No.

67 A028 6103 Middle Stay 1
68 A028 6136 Driven Roller Grip 1
69 A028 6512 Guide Plate 1
70 AA06 6039 Spring 1
71 AF02 2023 Upper Roller 1
72 AF02 2024 Lower Roller 1
73 A028 6222 Pressure Lever 1
74 AA06 3058 Spring 1
75 AA15 2400 Cushion - 5x7x75 1
76 AA15 2401 Cushion - 5x8x165 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0951 4010W Philips Screw With Flat Washer - M4
103 0951 4006B Philips Screw with Flat Washer - M4
104 0314 0100W Philips Pan Head Screw - M4x10
105 0951 3006W Philips Screw With Flat Washer - M3
106 0344 0080F Philips Truss Head Screw - M4x8
107 0951 4006W Philips Screw With Flat Washer - M4
108 0720 0030E Retaining Ring - M3
109 0720 0040E Retaining Ring - M4
110 0720 0060E Retaining Ring - M6
111 0805 3058 Ball Bearing - 8x16x4mm
112 0805 3307 Ball Bearing - 8x14x4mm
113 0740 3808 Bearing - 8x16x5mm
114 0805 3042 Ball Bearing - 6x10x3mm
115 0805 3145 Ball Bearing - 6x12x4mm
116 1105 0008 Nylon Clip - 2N
117 1105 0191 Wire Saddle

Part No. Description

Q’ty Per

Assembly

28. DUPLEX AND PAPER EXIT SECTION 4 (A112)

FT9101 64 Parts Location and List

28. DUPLEX AND PAPER EXIT SECTION 4 (A112)

Index

No.

1 AA04 3020 Belt - 1080P3 M6 1
2 A028 6591 Exit Inner Cover 1
3 AB03 0063 Pulley - 21Z 1
4 AB01 3302 Gear - 21Z 1
5 A028 6559 Roller 1
6 AB01 3300 Gear - 40Z 1
7 AB01 3288 Gear - 18Z 1
8 AB01 3289 Gear - 20Z 1
9 AB01 7109 Gear - 30/27Z 1
10 A028 6094 Rear Lock Bracket 1
11 AA13 4035 Roller 2
12 A028 6599 Inner Cover - Motor 1
13 A028 3165 Grip Supporter 2
14 A028 3166 Spring Supporter 2
15 AA06 3059 Spring 2
16 A028 3168 Spring Slider 2
17 AA14 3087 Adjusting Pin 2
18 A028 1199 Right Stay - Duplex Unit 1
19 AA12 0041 Antistatic Brush 1
20 A028 6106 Right Stay 1
21 AF02 2041 Transport Driven Roller 1
22 A028 6118 Duplex Outer Guide Plate 1
23 A028 6457 Duplex Rail 2
24 A028 6116 Inner Guide Plate 1
25 AF02 5005 Right Separation Pawl 1
26 A028 6574 Separation Arm 1
27 AA06 0153 Spring 1
28 A028 6093 Front Lock Bracket 1
29 5887 4162 Screw - Driven Guide Plate 1
30 A028 6588 Bushing Guide 1
31 AA06 0154 Spring 1
32 A028 6575 Separation Solenoid 1
33 A028 6577 Gas Spring Bracket 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 6350 Guide Plate Bracket 1
35 AF02 0082 Upper Exit Roller 1
36 AA13 4043 Roller 2
37 A028 6114 Lower Exit Guide Plate 1
38 A028 6356 Holder Bracket 1
39 AF02 0081 Lower Exit Roller 1
40 AF02 0080 Gear Roller 1
41 5214 4970 Caution Decal - High Temperature (EU) 1
41 5214 4972 Caution Decal - High Temperature (USA) 1
42 A028 6325 Duplex Upper Guide Plate 1
43 AB01 3170 Gear - 14Z 1
44 A028 6336 Roller Bracket 1
45 A028 6338 Duplex Upper Guide Plate Spring 1
46 AA14 5068 Duplex Shaft 1
47 A028 6346 Harness Bracket 1
48 A028 6337 Duplex Entrance Roller 1
49 A028 5451 Paper End Harness 1
50 AF02 0088 Duplex Roller 1
51 A028 5195 Paper Feed Sensor - Upper Duplex 1
52 A028 6340 Duplex Tray Pressure Guide Plate 1
53 A028 6348 Duplex Guide 1
54 AA12 0033 Antistatic Brush 1
55 5875 1521 Shoulder Screw - M4 1
56 AA00 1272 Decal - E1 1

Part No. Description

Q’ty Per

Assembly

FT9101 65 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0951 4008W Philips Screw with Flat Washer - M4
103 0315 0140W Philips Pan Head Screw - M5x14
104 0314 0080W Philips Pan Head Screw - M4x8
105 0951 3006W Philips Screw With Flat Washer - M3
106 0313 0060W Philips Pan Head Screw - M3x6
107 0720 0040E Retaining Ring - M4
108 0720 0060E Retaining Ring - M6
109 0720 0080E Retaining Ring - M8
110 0805 3058 Ball Bearing - 8x16x4mm
111 0805 3145 Ball Bearing - 6x12x4mm
112 0805 3042 Ball Bearing - 6x10x3mm
113 1105 0191 Wire Saddle
114 1105 0199 Clamp

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 65 Parts Location and List

A

29. DUPLEX AND PAPER EXIT SECTION 5 (A112)

FT9101 66 Parts Location and List

29. DUPLEX AND PAPER EXIT SECTION 5 (A112)

Index

No.

1 A028 6078 Rear Side Plate 1
2 A028 6415 Rear Side Fence 1
3 A028 6417 Rear Upper Felt 1
4 A028 6413 Lower Felt 1
5 A028 6448 Side Fence Adjusting Cam 2
6 A028 6369 End Fence Holder 2
7 A028 6366 Paper End Fence 1
8 A028 5521 Duplex Motor Harness 1
9 A028 6400 Right Bottom Plate 1
10 A028 6696 Connector Bracket 1
11 A028 6410 Front Side Fence 1
12 A028 6412 Front Upper Felt 1
13 A028 6413 Lower Felt 1
14 A028 5448 Duplex Sensor Harness 1
15 5205 5250 LED Sensor Type S 2
16 A028 6436 Side Fence Tension 1
17 AB03 0059 Pulley - 46Z 1
18 AA04 3018 Belt - 453MXL 4.8 1
19 A028 6386 End Fence Tension 1
20 AB03 0057 Pulley - 34Z 1
21 AA04 3019 Belt - 200MXL 4.8 1
22 A028 6391 End Fence Sensor Bracket 1
23 AA12 0012 Antistatic Brush 2
24 A028 6443 Front Lower Side Fence 1
25 A028 6069 Front Side Plate 1
26 A028 6442 Side Fence Actuator 1
27 A028 6440 Side Fence Belt Bracket 2
28 A028 6441 Side Fence Belt Holder 2
29 A028 6425 Side Fence Guide 2
30 A028 6396 End Fence Belt Holder 1
31 A028 6395 End Fence Belt Bracket 1
32 A028 6376 End Fence Guide 1
33 AA14 0161 End Fence Shaft 2

Part No. Description

Q’ty Per

Assembly

Index

No.

34 AB01 7067 Gear - 36/46Z 1
35 AB01 3276 Gear - 22Z 1
36 AX06 0022 DC Motor - 24V 1
37 A028 6380 End Fence Motor Bracket 1
38 AA14 0160 Side Fence Shaft 2
39 AX05 0022 DC Motor - 19V 1
40 AB01 3277 Gear - 22Z 1
41 A028 6430 Side Fence Motor Bracket 1
42 A028 6444 Rear Lower Side Fence 1
43 A028 6450 Right Inner Cover Bracket 1
44 A028 6471 Vacuum Guide 1
45 A028 6462 Vacuum Unit Guide Plate 1
46 AB01 3274 Gear - 23Z 1
47 A028 9009 Vacuum Belt (4pcs/set) 1
48 A028 6502 Belt Drive Driven Roller 1
49 5447 2681 Snap Ring 1
50 A028 6498 Belt Drive Front Roller 1
51 A028 6496 Feed Roller 1
52 A028 6490 Feed Sleeve 1
53 A028 6481 Belt Drive Roller 1
54 A028 6485 Belt Boss 1
55 AB01 3273 Gear - 16Z 1
56 A028 6474 Vacuum Unit Duplex Duct 1
57 A028 5175 Lower Duplex Feed Sensor 1
58 A028 6179 Sensor Bracket 1
59 A028 5200 Paper End Sensor - Lower Duplex 1
60 A028 5446 Duplex Harness - B 1
61 A028 6194 Inner Cover 1
62 A028 6171 Duplex Left Bottom Plate 1
63 AG07 0004 Magnet Catch Ass’y 1
64 A028 6188 Vacuum Tray Duct 1
65 A028 6190 Vacuum Entrance Seal 1
66 A028 6191 Vacuum Exit Seal 1

Part No. Description

Q’ty Per

Assembly

FT9101 67 Parts Location and List

Index

No.

67 AB01 3390 Gear - 16Z 1
68 A028 5325 Duplex Drive Motor 1
69 A028 5522 Relay Motor Harness 1
70 A028 5520 Duplex Feed Motor Harness 1
71 A028 6458 Vacuum Unit 1
72 A028 6478 Vacuum Unit Duplex Seal 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0314 0100W Philips Pan Head Screw - M4x10
104 0323 0060W Philips Sunken Head Screw - M3x6
105 0324 0060W Philips Sunken Head Screw - M4x6
106 0951 3006W Philips Screw With Flat Washer - M3
107 0951 4006B Philips Screw with Flat Washer - M4
108 0951 4008W Philips Screw with Flat Washer - M4
109 0951 4008B Philips Screw With Flat Washer - M4
110 0313 0060W Philips Pan Head Screw - M3x6
111 0574 0050E Hexagon Headless Set Screw - M4x5
112 0573 0050E Hexagon Headless Set Screw - M3x5
113 0720 0040E Retaining Ring - M4
114 0720 0030E Retaining Ring - M3
115 0720 0060E Retaining Ring - M6
116 0805 3145 Ball Bearing - 6x12x4mm
117 0807 3091 Flat Washer - M4
118 1105 0199 Clamp
119 1105 0191 Wire Saddle
120 1106 0430 Bushing - 13mm

Part No. Description

Q’ty Per

Assembly

FT9101 67 Parts Location and List

A

30. DRIVE SECTION (A112)

FT9101 68 Parts Location and List

30. DRIVE SECTION (A112)

Index

No.

1 AB03 0055 Pulley - 20Z 2
2 A028 1236 Duplex Drive Bracket 1
3 AA14 0174 Duplex Drive Shaft 1
4 AB01 1040 Gear - 30Z 1
5 AB03 0052 Pulley - 25Z 1
6 A028 1227 Fusing Drive Bracket 1
7 5429 4370 Spring 1
8 A028 1230 Fusing Drive Joint 1
9 AA14 5062 Drive Shaft 1
10 5429 2386 Key - 4x4x10 1
11 A028 4052 Friction Roller 1
12 AB03 0074 Pulley - 28Z 1
13 A028 1240 Cleaning Unit Drive Bracket 1
14 AA14 5074 Drive Shaft 1
15 A028 1243 Cooling Drive Joint 1
16 A028 4088 Pump Tube 1
17 A028 1254 Pulley - M47 1
18 A028 1252 Sub-Tightener 1
19 AA04 3017 Belt - 123Z 1
20 AA04 3016 Belt - 105Z 1
21 AA15 1086 Seal - 3x75x7 1
22 A028 1218 Bearing Cover 1
23 A028 1217 Drive Relay Bracket 1
24 AA14 5061 Relay Shaft 1
25 A028 1219 Paper Feed Drive Clutch 1
26 AB03 0050 Pulley - 28Z 1
27 A028 4050 Pulse Generator 1
28 AA06 3129 Spring 1
29 AB01 1339 Gear - 18Z 1
30 AB01 1338 Worm Hwile 1
31 A028 4054 Toner Collection Sensor Bracket 1
32 5205 5250 LED Sensor Type S 1
33 A028 4047 Toner Collection Bracket 1

Part No. Description

Q’ty Per

Assembly

Index

No.

34 A028 4055 Toner Catch Pan 1
35 AA03 4001 Collection Drawer 1
36 AA14 0209 Drive Shaft 1
37 5446 3707 Bushing - 6x10x6mm 1
38 A028 4058 Toner Collection Sensor Disc 1
39 A028 1246 Main Tightener 1
40 AB03 0048 Pulley - 24Z 1
41 AB03 0046 Pulley - 32Z 1
42 A028 1211 Main Motor Bracket 1
43 A028 1212 Packing 1
44 AX07 0001 DC Motor - 40V 1
45 AB01 1337 Gear - 30Z 1
46 5219 3722 Joint - Toner Recovery 1
47 AD04 3017 Toner Collection Coil 1
48 5446 3731 Pipe Holder - Toner Recovery 1
49 5446 3729 Band - Vinyl Tube 2
50 AA18 0015 Joint 1
51 AA18 1007 Pipe 1

Part No. Description

Q’ty Per

Assembly

FT9101 69 Parts Location and List

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0313 0060W Philips Pan Head Screw - M3x6
103 0314 0080W Philips Pan Head Screw - M4x8
104 0315 0100W Philips Pan Head Screw - M5x10
105 0315 0140W Philips Pan Head Screw - M5x14
106 0951 5008B Philips Screw With Flat Washer - M5
107 0586 0162W Bolt - M6x16
108 0720 0040E Retaining Ring - M4
109 0720 0060E Retaining Ring - M6
110 0720 0080E Retaining Ring - M8
111 0725 0100E Retaining Ring C - M10
112 0725 0120E Retaining Ring C - M12
113 0808 0001 O Ring - 13.8mm
114 0805 3251 Bushing - 10mm
115 0740 3008 Ball Bearing
116 0805 3433 Ball Bearing - 6x15x5mm
117 5506 7139 Spacer - 14.1mm x 18
118 0575 0050E Hexagon Headless Set Screw - M5x5
119 1105 0016 Nylon Clip - 4N
120 1105 0196 Harness Clamp
121 1106 0411 Bushing - 11.5mm
122 0930 0405G Parallel Key - 4x4x32
123 0930 0402G Parallel Key - 4x4x16

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 69 Parts Location and List

A

31. ELECTRICAL SECTION 1 (A112)

FT9101 70 Parts Location and List

31. ELECTRICAL SECTION 1 (A112)

Index

No.

1 A028 5129 DC Motor Drive Board (EU) 1
1 A028 5127 DC Motor Drive Board (USA) 1
2 A028 5135 Mirror/Lens Drive Board 1
3 A028 5141 Drum Potential Sensor Board 1
4 A028 5394 T&S Power Pack 1
5 A028 5130 Interface Board - A/D Converter 1
6 A028 2434 Erase Unit Fan Duct 1
7 A028 1657 Decal - Main Switch 1
8 A028 1529 Main Switch Bracket 1
9 A112 1450 Operation Panel Unit (EU) 1
9 A112 1451 Operation Panel Unit (USA) 1
10 A112 5070 Operation ROM Board (EU) 1
10 A112 5071 Operation ROM Board (USA) 1
11 A028 6678 Interlock Switch Cover 1
12 AA06 0108 Pick-up Spring 1
13 A028 6674 Interlock Switch 1
14 A028 5606 DC Control Fan Bracket 1
15 AX04 0006 Blower Fan 1
16 A028 5106 Duplex Blower DC Drive Board (EU) 1
16 A028 5108 Duplex Blower DC Drive Board (USA) 1
17 A028 5115 Jogger DC Drive Board 1
18 A028 5101 Main/OPC Motor DC Drive Board (EU) 1
18 A028 5100 Main/OPC Motor DC Drive Board (USA) 1
19 A028 5110 Paper Feed DC Drive Board 3
20 A028 5086 Paper Feed Control Board 1
21 A028 5087 IC - MBM-27C256A-25 1
22 A028 5088 IC - MBM-27C256A-25 1
23 A028 5120 DC Drive Board - Solenoid 1
24 A028 5506 Motor Harness 1
25 A112 5407 Paper Feed Control Harness (EU) 1
25 A112 5440 Paper Feed Control Harness (USA) 1
26 A112 5041 Main Control Board 1
27 A112 5102 IC210 - HN27C101AG-17 1

Part No. Description

Q’ty Per

Assembly

Index

No.

28 A112 5104 IC205 - HN27C101AG-17 1
29 A112 5103 IC198 - HN27C101AG-17 1
30 A112 5105 IC190 - HN27C101AG-17 1
31 A112 5108 IC123 - MBM27C512-20 1
32 A112 5109 IC124 - MBM27C512-20 1
33 A112 5400 DC Harness (EU) 1
33 A112 5405 DC Harness (USA) 1
34 A112 5500 AC Harness (EU) 1
34 A112 5505 AC Harness (USA) 1
35 AW03 0009 Optical Connector 1
36 A028 5820 Interface Harness 1
37 AW03 0010 Optical Connector 1
38 AW03 0008 Optical Connector 1
39 5205 5250 LED Sensor Type S 1
40 A028 1499 Safety Switch Bracket 1
41 AA14 5067 Actuator Shaft 1
42 A028 1503 Safety Switch Actuator 1
43 AA06 6043 Spring 1
44 A028 1500 Safety Switch Lever 1
45 AA14 5066 Shaft 1
46 A028 1495 Total Counter Bracket 1
47 A028 1497 Total Counter Bracket 1
48 A028 9011 Total Counter 1
49 A028 1492 Total Counter Cover 1
50 AA01 2034 Filter 1
51 A028 2433 Erase Unit Filter Bracket 1
52 AX64 0007 Cooling Fan - DC24V 1
53 A028 2432 Erase Unit Fan Bracket 1
54 AA14 3062 Shoulder Screw - M4 1
55 AA06 0108 Pick-up Spring 1
56 AA14 3201 Stepped Screw - M5x7 1
57 AX64 0010 LD Cooling Fan 1
58 A112 5205 IC201 - M5M27C101K-2 (EU) 1

Part No. Description

Q’ty Per

Assembly

FT9101 71 Parts Location and List

Rev. 11/16/95

Index

No.

58 A112 5225 IC201 - M5M27C101K-2 (USA) 1
59 A112 5206 IC202 - M5M27C101K-2 (EU) 1
59 A112 5226 IC202 - M5M27C101K-2 (USA) 1
60 A112 5207 IC205 - M5M27C101K-2 (EU) 1
60 A112 5227 IC205 - M5M27C101K-2 (USA) 1
61 A112 5208 IC206 - M5M27C101K-2 (EU) 1
61 A112 5228 IC206 - M5M27C101K-2 (USA) 1
62 A112 5209 IC203 - MBM27C512-20 (EU) 1
62 A112 5229 IC203 - MBM27C512-20 (USA) 1
63 A112 5210 IC204 - MBM27C512-20 (EU) 1
63 A112 5230 IC204 - MBM27C512-20 (USA) 1
64 A112 5211 IC207 - MBM27C512-20 (EU) 1
64 A112 5231 IC207 - MBM27C512-20 (USA) 1
65 A112 5212 IC208 - MBM27C512-20 (EU) 1
65 A112 5232 IC208 - MBM27C512-20 (USA) 1
66 A112 5213 IC210 - MBM27C512-20 (EU) 1
66 A112 5233 IC210 - MBM27C512-20 (USA) 1
67 A112 5214 IC211 - MBM27C512-20 (EU) 1
67 A112 5234 IC211 - MBM27C512-20 (USA) 1
69 A028 6679 Fan Guard 1
70 A028 5612 Heat Sink 1
71 A028 5611 Heat Sink 1
72 A028 5601 Main Control Board Shielding Sheet 1
73 A028 5600 Main Control Board Holder 1
74 A028 5610 Heat Sink 1
75 A028 1505 Safety Switch Seal 1
76 A112 5317 Power Supply Cord (USA) 1

Part No. Description

Q’ty Per

Assembly

Index

No.

101 0314 0060W Philips Pan Head Screw - M4x6
102 0314 0080W Philips Pan Head Screw - M4x8
103 0313 0300W Philips Pan Head Screw - M3x30
104 0314 0050W Philips Pan Head Screw - M4x5
105 0313 0280W Philips Pan Head Screw - M3x28
106 0951 4006B Philips Screw with Flat Washer - M4
107 0951 4008W Philips Screw with Flat Washer - M4
108 0344 0060F Philips Truss Head Screw - M4x6
109 0720 0030N Retaining Ring - M3
110 1105 0160 Clamp
111 1105 0111 Cable CliP
112 1105 0186 Cable Clip - 248
113 1204 1545 Main Switch
114 1204 1280 Push Switch
115 1102 7249 Plug - 250V 30A (USA)
116 1106 0725 Cord Bushing (USA)

Part No. Description

Q’ty Per

Assembly

FT9101 71 Parts Location and List

A

B

31A. ELECTRICAL SECTION 1 (A112)

FT9101 71 Parts Location and List

Rev. 5/12/95

1

2

9

3

8

7

4

5

6

31A. ELECTRICAL SECTION 1 (A112)

Rev. 5/12/95

Index

No.

1 A112 5250 Operation Touch Panel 1
2 A112 1900 Operation Panel Cover 1
3 A028 5247 Sheet - Key Board 1
4 A028 5235 Key Board 1
5 A028 5230 Operation Panel Board 1
6 A028 1753 Operation Panel Base 1
7 AW03 0011 Fiber Optical Cable - 100 mm 1
8 A028 5245 LCD Display 1
9 A028 5246 FL Stabilizer 1

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 71 Parts Location and List

C

31B. ELECTRICAL SECTION 1 (A112)

D

FT9101 71 Parts Location and List

Rev. 5/12/95

SYMBOL

NO.
IC 1

IC 2
IC 3
IC 4
IC 5

IC 6
IC 7
IC 8
IC 9

IC 10
IC 11

IC 12
IC 13
IC 14
IC 15

IC 16
IC 17
IC 18
IC 19
IC 20

INDEX

NO.
101

101
102
103
104

105
104
106
107
108

107
105
109
107
107

110

104

111
112
111

SYMBOL

NO.

IC 21
IC 22
IC 23
IC 24
IC 25

IC 26
IC 27
IC 28
IC 29
IC 30

IC 31
IC 32
IC 33
IC 34
IC 35

IC 36
IC 37
IC 38
IC 39
IC 40

INDEX

NO.

113
114
108
107
105

107
115
107
116
107

117
118
119
120
121

122
123
123
113
124

SYMBOL

NO.

IC 41
IC 42
IC 43
IC 44
IC 45

IC 46
IC 47
IC 48
IC 49
IC 50

IC 51
IC 54
IC 55
IC 56

INDEX

NO.
123

123
125
125

113

113
126
127
127
128

128
128
128

111

31B. ELECTRICAL SECTION 1 (A112)

Rev. 5/12/95

Index

No.

101 1407 1780 CMOSIC - SN74HC367NS
102 1407 2813 CMOSIC - SN74HC390NS
103 1407 2588 TTLIC - SN74ALSO4BNS
104 1407 2464 TTLIC - SN74ALS74ANS
105 1407 2817 TTLIC - SN74ALS32NS
106 1407 3128 TTLIC - SN74ALS19ANS
107 1407 2818 TTLIC - SN74ALS156NS
108 1407 2463 TTLIC - SN74ALS08NS
109 1407 2823 LSI - µPD71051GB-3B4
110 1407 2821 LSI - µPD71059GB-3B4
111 1407 2077 TTLIC - SN74LS138NS
112 1407 2822 LSI - µPD71054GB-3B4
113 1407 2816 TTLIC - SN74ALS374ANS
114 1407 3124 IC - PD70116C-10
115 1407 2811 CMOSIC - SN74HC4020NS
116 1408 0611 IC - MB3771PF
117 1407 3126 LSI - µPD71011C-10
118 1408 0705 Operational Amplifier - µPC251G2
119 1408 0321 IC - AUDIO AMP: LM386N-1
120 1407 2815 CMOSIC - µPD22148CA
121 1407 1783 TTLIC - SN74LSO2NS
122 1407 1813 TTLIC - SN74LS11NS
123 1408 0395 IC - AB6912S
124 1407 2158 TTLIC - SN74ALS373NS
125 1407 2812 CMOSIC - SN74HC540NS
126 1407 2820 LSI - HD64645F
127 1407 2378 TTLIC - SN74ALS245ANS
128 1407 1605 TTLIC - SN74S157NS

Part No. Description

Q’ty Per

Assembly

Index

No.

Part No. Description

Q’ty Per

Assembly

FT9101 71 Parts Location and List

E

32. ELECTRICAL SECTION 2 (A112)

FT9101 72 Parts Location and List
