Page 1
MODIFICATION BULLETIN NO. 1 PAGE 1 OF 2
ISSUED ON: March 31, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Blade Cam
Reason for
Modification
Old P/N New P/N Description Q’ty Used
AB017372 AB017388 Blade Cam
To prevent the vibration caused by the side to side movement of cleaning
blade.
Inter-
1 → 1
change-
ability
X/O 19 41 (Falcon) (Ricoh, OEM)
Index No. Page
Parts Catalog
Date of
Modification
To prevent the vibration caused by the side to side movement of cleaning blade, the shape of the ca m has been
changed as shown in the illustration. This is also to minimizes a poor contact at the density senso r terminal by the
vibration.
Serial Number
Cam Shape
Cam Shape
Sine wave
S. Hamano, Assistant General Manager
Technical Support Department
Page 2
MODIFICATION BULLETIN NO. 1 PAGE 2 OF 2
ISSUED ON: March 31, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A85020001
Ricoh FT4027 115/60 USA, Canada A157-17 A3635020001
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363503XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F80250001
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A3635020051
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22 8685020001
USA, Canada,
L. America
Asia, Middle
East
A157-10 869503XXXX
A157-29 A3635020202
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A55020001
Ricoh FT4527 115/60 USA, Canada A160-17 A3715020001
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A3715020202
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F90250001
Ricoh FT4527 220,230, 240/50 Europe A160-27 A3715020212
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22 8725020001
USA, Canada,
L. America
Asia, Middle
East
A160-10 8735020001
A160-29 A3715020434
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370503XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G00250001
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A3705020001
115/60
220, 230, 240/50 Europe etc. A159-22 870503XXXX
USA, Canada,
L. America
A159-10 871503XXXX
Page 3
MODIFICATION BULLETIN NO. 2 PAGE 1 OF 2
ISSUED ON: March 31, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Parts Catalog
Reason for
Parts Catalog Correction
Modification
New P/N Description Q’ty Used
A1532117 Roller Terminal
0 → 1
Index No. Page
30 39 (Falcon) (Ricoh, OEM)
30 A1532117
Roller Terminal
Parts Catalog
Date of
Modification
Serial Number
S. Hamano, Assistant General Manager
Technical Support Department
Page 4
MODIFICATION BULLETIN NO. 2 PAGE 2 OF 2
ISSUED ON: March 31, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15
Ricoh FT4027 115/60 USA, Canada A157-17
Ricoh FT4027 110/60 Taiwan, Saudi A157-19
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26
Ricoh FT4027 220, 230, 240/50 Europe A157-27
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22
USA, Canada,
L. America
Asia, Middle
East
A157-10
A157-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15
Ricoh FT4527 115/60 USA, Canada A160-17
Ricoh FT4527 110/60 Taiwan, Saudi A160-19
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22
USA, Canada,
L. America
Asia, Middle
East
A160-10
A160-29
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26
Ricoh FT4127 220, 230, 240/50 Europe A159-27
115/60
220, 230, 240/50 Europe etc. A159-22
USA, Canada,
L. America
A159-10
Page 5
MODIFICATION BULLETIN NO. 3 PAGE 1 OF 3
ISSUED ON: April 30, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Parts Catalog
Reason for
Parts Catalog Correction
Modification
Please correct your parts catalog as follows:
1. The following parts are missing in the parts catalog. Please add these parts to your parts catal og.
New P/N Description
Index No. Page
A1531676 Harness Guard Seal * 28 73
A1551331 LCT - Rear Right Cover (for LCT machine) 27 9
Parts Catalog
* New Index
28 (A1531676)
LCT machine
Date of
Modification
Serial Number
27
A1551331
M. Iwasa, Manager
Technical Support Department
Page 6
MODIFICATION BULLETIN NO. 3 PAGE 2 OF 3
DETAILS OF MODIFICATION
2. Please correct descriptions of the following parts.
ISSUED ON: April 30, ’95
New P/N Incorrect Description Correct Description
Index No. Page
A1571360 Operating Sheet Operating Sheet (A157, 159) 5 9
A1581360 Operating Sheet Operating Sheet (A160) 5 9
AX520026 Exposure Lamp - 85V 200W Exposure Lamp - 85V 200W (230V) 7 29
AX520028 Exposure Lamp - 97V 200W Exposure Lamp - 97V 200W (115V) 7 29
Parts Catalog
M. Iwasa, Manager
Technical Support Department
Page 7
MODIFICATION BULLETIN NO. 3 PAGE 3 OF 3
ISSUED ON: April 30, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15
Ricoh FT4027 115/60 USA, Canada A157-17
Ricoh FT4027 110/60 Taiwan, Saudi A157-19
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26
Ricoh FT4027 220, 230, 240/50 Europe A157-27
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22
USA, Canada,
L. America
Asia, Middle
East
A157-10
A157-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15
Ricoh FT4527 115/60 USA, Canada A160-17
Ricoh FT4527 110/60 Taiwan, Saudi A160-19
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22
USA, Canada,
L. America
Asia, Middle
East
A160-10
A160-29
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26
Ricoh FT4127 220, 230, 240/50 Europe A159-27
115/60
220, 230, 240/50 Europe etc. A159-22
USA, Canada,
L. America
A159-10
Page 8
MODIFICATION BULLETIN NO. 4 PAGE 1 OF 2
ISSUED ON: April 30, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Parts Catalog
Reason for
Parts Catalog Correction
Modification
Please correct your parts catalog as follows:
Old P/N New P/N Description Q’ty Used
09503005B Philips Screw with Spring Washer - M3 x 5
04130050Z Tapping Screw M3 x 5
07030030M Spring Washer M3
A0961873 Scanner Shoe Pin
2 → 0
0 → 2
0 → 2
0 → 4
change-
Date of
Modification
Inter-
ability
X/O 104 29
X/O * 110 29
Parts Catalog
Index No. Page
104 29
17 29
* : New Index
Serial Number
A0691873
04130050Z
07030030M
A0691873
M. Iwasa, Manager
Technical Support Department
Page 9
MODIFICATION BULLETIN NO. 4 PAGE 2 OF 2
ISSUED ON: April 30, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2635
nashuatec 3535
Savin 9035
Savin 9035 115/60 USA, Canada A153-15
Ricoh FT5035 115/60 USA, Canada A153-17
Ricoh FT5035 110/60 Taiwan, Saudi A153-19
Gestetner 2635
nashuatec 3535
Rex Rotary 8635Z
Infotec 5351Z
Ricoh FT5035
Ricoh FT5035 220/50 Asia, Middle East A153-29
nashuatec 5035 110/60 Taiwan A153-39
Gestetner 2635 110/60 Taiwan A153-50
Gestetner 2635T
nashuatec 3535T
Savin 9035L
115/60
220, 230,
240/50
220, 230,
240/50
220, 230,
240/50
115/60
USA, Canada,
L. America
Europe etc. A153-22
Europe A153-26
Europe A153-27
USA, Canada,
L. America
A153-10
A155-10
SERIAL
NUMBER
MODEL NAME V/Hz DESTINATION
CODE SERIAL NUMBER
Infotec 5351ZL
Ricoh FT5135
Gestetner 2635td
nashuatec 3535td
Savin 9035DL
Savin 9035DL 115/60 USA, Canada A156-15
Ricoh FT5535 115/60 USA, Canada A156-17
Ricoh FT5535 110/60 Taiwan, Saudi A156-19
Gestetner 2635td
nashuatec 3535td
Rex Rotary8635dz
Infotec 5351DZ
Ricoh FT5535
Ricoh FT5535 220/50 Asia, Middle East A156-29
220, 230,
240/50
220, 230,
240/50
115/60
220, 230,
240/50
220, 230,
240/50
220, 230,
240/50
Europe A155-26
Europe A155-27
USA, Canada,
L. America
Europe, etc. A156-22
Europe A156-26
Europe A156-27
A156-10
JAPAN PRODUCTION
Ricoh FT5135 115/60 USA, Canada A155-17
Gestetner 2635T
nashuatec 3535T
Rex Rotary
8635LZ
220, 230,
240/50
Europe, etc. A155-22
Page 10
MODIFICATION BULLETIN NO. 5 PAGE 1 OF 2
ISSUED ON: April 30, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Lower Fusing Guide
Reason for
To reduce paper creasing at fusing
Modification
Old P/N New P/N Description Q’ty Used
A1534196 A1534197
Lower Fusing
Guide
1 → 1
Inter-
change-
ability
X/O 1 47 (Falcon) (Ricoh, OEM)
Index No. Page
Parts Catalog
To reduce paper creasing at fusing, the height of the guide plate has been changed as follows.
Date of
Modification
Serial Number
Old
h
A1534196
h = 30.5 ± 0.3
New
A1534197
h = 36.25 ± 0.25
M. Iwasa Manager
Technical Support Department
Page 11
MODIFICATION BULLETIN NO. 5 PAGE 2 OF 2
ISSUED ON: April 30, ’95
MODEL NAME V/Hz
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A85020007
Ricoh FT4027 115/60 USA, Canada A157-17 A363504XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363504XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8504XXXX
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363504XXXX
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 ---
Gestetner 2627 110/60 Taiwan A157-50 ---
115/60
220, 230, 240/50 Europe etc. A157-22 868504XXXX
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
JAPAN PRODUCTION
CODE
A157-10 869504XXXX
A157-29 A3635030001
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5504XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371504XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371504XXXX
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9504XXXX
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371504XXXX
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 ---
115/60
220,230, 240/50 Europe, etc. A160-22 8725030001
USA, Canada,
L. America
Asia, Middle
East
A160-10 873504XXXX
A160-29 A3715030001
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 ---
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370504XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0504XXXX
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370504XXXX
115/60
220, 230, 240/50 Europe etc. A159-22 870504XXXX
USA, Canada,
L. America
A159-10 871504XXXX
Page 12
MODIFICATION BULLETIN NO. 6 PAGE 1 OF 2
ISSUED ON: April 30, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Spring Plate
Reason for
To improve the contact of the drum charge roller terminal.
Modification
Inter-
Old P/N New P/N Description Q’ty Used
A1533554 A1533570 Spring Plate
1 → 1
change-
ability
X/O 24 41 Falcon (Ricoh, OEM)
Index No. Page
Parts Catalog
Modification
To ensure the contact of the drum charge roller terminal, the shape of the spring plate has been cha nged.
Old
A1533554
0 = 11 ± 3°
New
A1533570
0 = 64 ± 3°
Date of
Serial Number
θ
M. Iwasa Manager
Technical Support Department
Page 13
MODIFICATION BULLETIN NO. 6 PAGE 2 OF 2
ISSUED ON: April 30, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8505XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363505XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363505XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8505XXXX
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363505XXXX
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 ---
Gestetner 2627 110/60 Taiwan A157-50 ---
115/60
220, 230, 240/50 Europe etc. A157-22 868505XXXX
USA, Canada,
L. America
Asia, Middle
East
A157-10 869505XXXX
A157-29 A363505XXXX
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5505XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371505XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371505XXXX
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9505XXXX
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371505XXXX
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 ---
115/60
220,230, 240/50 Europe, etc. A160-22 872505XXXX
USA, Canada,
L. America
Asia, Middle
East
A160-10 873505XXXX
A160-29 A371505XXXX
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 ---
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370505XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0505XXXX
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370505XXXX
115/60
220, 230, 240/50 Europe etc. A159-22 870505XXXX
USA, Canada,
L. America
A159-10 871505XXXX
Page 14
MODIFICATION BULLETIN NO. 8 PAGE 1 OF 2
ISSUED ON: May 15, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Seal - 5 x 82 x 4
Reason for
To prevent from cooling fan duct
Modification
A cushion seal has been added on the cooling fan duct to prevent noise.
Inter-
Old P/N New P/N Description Q’ty Used
AA151177 Seal - 5 x 82 x 4
0 → 2
change-
ability
Seal - 5 x 82 x 4
fan duct
Date of
Modification
Parts Catalog
Index No. Page
* 22 71
Serial Number
M. Iwasa, Manager
Technical Support Department
Page 15
MODIFICATION BULLETIN NO. 8 PAGE 2 OF 2
ISSUED ON: May 15, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8504XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363504XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363504XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8504XXXX
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363504XXXX
Ricoh FT4027 220/50 Asia, Middle East A157-29 A3635030001
nashuatec 3527 110/60 Taiwan A157-39 ---
Gestetner 2627 110/60 Taiwan A157-50 ---
Ricoh FT4027 110/60 Taiwan A157-59 ---
115/60
220, 230, 240/50 Europe etc. A157-22 868504XXXX
USA, Canada,
L. America
A157-10 869504XXXX
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5504XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371504XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371504XXXX
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9504XXXX
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371504XXXX
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 ---
115/60
220,230, 240/50 Europe, etc. A160-22 8725030001
USA, Canada,
L. America
Asia, Middle
East
A160-10 873504XXXX
A160-29 A3715030001
SERIAL
NUMBER
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370504XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0504XXXX
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370504XXXX
115/60
220, 230, 240/50 Europe etc. A159-22 870504XXXX
USA, Canada,
L. America
A159-10 871504XXXX
Page 16
MODIFICATION BULLETIN NO. 9 PAGE 1 OF 2
ISSUED ON: May 31, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Parts Catalog
Reason for
Parts Catalog Correction
Modification
Date of
Modification
Please correct your parts catalog as follows;
Falcon: Page 21
[Incorrect]
P/N Description Q’ty
AF031024
AF031030
Feed Roller 1 7 21
Parts Catalog
Index No. Page Index No. Page
[Correct]
P/N Description Q’ty
AF031025
AF031030
Feed Roller (A157)
Feed Roller (A159 / A160)
Parts Catalog
1 7 21
Note: Two different part numbers exist for the Feed Roller due to that these feed rollers are procu red from two different
venders.
Serial Number
M. Iwasa, Manager
Technical Support Department
Page 17
MODIFICATION BULLETIN NO. 9 PAGE 2 OF 2
ISSUED ON: May 31, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15
Ricoh FT4027 115/60 USA, Canada A157-17
Ricoh FT4027 110/60 Taiwan, Saudi A157-19
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26
Ricoh FT4027 220, 230, 240/50 Europe A157-27
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22
USA, Canada,
L. America
Asia, Middle
East
A157-10
A157-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15
Ricoh FT4527 115/60 USA, Canada A160-17
Ricoh FT4527 110/60 Taiwan, Saudi A160-19
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22
USA, Canada,
L. America
Asia, Middle
East
A160-10
A160-29
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26
Ricoh FT4127 220, 230, 240/50 Europe A159-27
115/60
220, 230, 240/50 Europe etc. A159-22
USA, Canada,
L. America
A159-10
Page 18
MODIFICATION BULLETIN NO. 10 PAGE 1 OF 3
ISSUED ON: May 31, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Decal - 10 key Zoom etc.
Reason for
Part Number set-up as per field request
Modification
Draw
No.
Old Parts
No.
New Parts
No.
A1531475 Decal - 10Key Zoom - LT/DLT
A1531478 Decal - 10Key Zoom - A4/A3
A1531476
A1561479
Decal - Margin Adjustment LT/DLT
Decal - Margin Adjustment A4/A3
Description
Rank
Q’ty Used
Old→New
0 → 1
0 → 1
0 → 1
0 → 1
Inter-
change-
ability
Date of
Modification
Parts needed for replacement by new part Parts Catalog
Part No. Description No. Page
Serial
Number
* 30 (32)
* 7 (8)977
* 30 (32)
* 7 (8)977
* 31 (33)
* 8 (9)977
* 31 (33)
* 8 (9)977
A1561495 Decal - Copy Ratio
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for
replacement by new part" to install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether
the new part can be used in the old machine. x = Not interchangeable o = Interchangeable
0 → 1
* : New Index
( ) : for OEM P/C
* 32 (34)
* 9 (10)977
Page 19
MODIFICATION BULLETIN NO. 10 PAGE 2 OF 3
*32 (34)
*30 (32)
*31 (33)
A3 / A4
ISSUED ON: May 31, ’95
LT / DLT
LT / DLT
A3 / A4
M. Iwasa, Manager
Technical Support Department
Page 20
MODIFICATION BULLETIN NO. 10 PAGE 3 OF 3
ISSUED ON: May 31, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15
Ricoh FT4027 115/60 USA, Canada A157-17
Ricoh FT4027 110/60 Taiwan, Saudi A157-19
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26
Ricoh FT4027 220, 230, 240/50 Europe A157-27
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22
USA, Canada,
L. America
Asia, Middle
East
A157-10
A157-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15
Ricoh FT4527 115/60 USA, Canada A160-17
Ricoh FT4527 110/60 Taiwan, Saudi A160-19
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22
USA, Canada,
L. America
Asia, Middle
East
A160-10
A160-29
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26
Ricoh FT4127 220, 230, 240/50 Europe A159-27
115/60
220, 230, 240/50 Europe etc. A159-22
USA, Canada,
L. America
A159-10
Page 21
MODIFICATION BULLETIN NO. 11 PAGE 1 OF 3
ISSUED ON: June 15, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Hinge Stopper, etc.
Reason for
To strengthen the hinge stopper and the spring plate of the platen cover.
Modification
Draw
No.
Old Parts
No.
A1531377 Hinge Stopper
A1531378 Spring Plate
New Parts
No.
A0531957 Flex Hinge Platen Cover
Description Rank
Q’ty Used
Old→New
2 → 0
2 → 0
0 → 2
Date of
Modification
Inter-
change-
ability
X/O * 13 11
Parts needed for replacement by new part
Part No. Description No. Page
* New Index
Serial Number
Parts Catalog
611
511
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for
replacement by new part" to install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether
the new part can be used in the old machine. x = Not interchangeable o = Interchangeable
Page 22
MODIFICATION BULLETIN NO. 11 PAGE 2 OF 3
13
ISSUED ON: June 15, ’95
DETAILS OF MODIFICATION
To strengthen the hin ge st oppe r a nd the sp ring plat e of the platen cover, two sep ara te parts have been
combined into one part.
6
5
6
5
13 : Flex Hinge Platen Cover
M. Iwasa, Manager
Technical Support Department
Page 23
MODIFICATION BULLETIN NO. 11 PAGE 3 OF 3
ISSUED ON: June 15, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15
Ricoh FT4027 115/60 USA, Canada A157-17
Ricoh FT4027 110/60 Taiwan, Saudi A157-19
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A3635020205
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
115/60
220, 230, 240/50 Europe etc. A157-22
USA, Canada,
L. America
Asia, Middle
East
A157-10
A157-29
SERIAL
NUMBER
A363503XXXX
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15
Ricoh FT4527 115/60 USA, Canada A160-17
Ricoh FT4527 110/60 Taiwan, Saudi A160-19
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22
USA, Canada,
L. America
Asia, Middle
East
A160-10
A160-29
SERIAL
NUMBER
Gestetner 2627 110/60 Taiwan A157-50
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26
115/60
220, 230, 240/50 Europe etc. A159-22
USA, Canada,
L. America
A159-10
Page 24
MODIFICATION BULLETIN NO. 12 PAGE 1 OF 3
ISSUED ON: June 15, ’95
Model Phoenix (Falcon) Volt/Hz
Modified Article Scanner Drive Shaft, etc.
Reason for
To eliminate rattling noise from the scanner drive shaft
Modification
Draw
No.
Old Parts
No.
AA140557 AA140599 Scanner Drive Shaft
AB033063 AB033069 Timing Pulley - 22Z / 24Z
05730040E 05730100E
New Parts
No.
Hexagon Headless Set
Screw - M3 x 10
Description Rank
Q’ty Used
Old→New
1 → 1
2 → 2
2 → 2
Date of
Modification
Inter-
change-
ability
X/X 4 33
X/X X /O as a set 3 33
X/X 101 33
Parts needed for replacement by new part
Part No. Description No. Page
Serial Number
Parts Catalog
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for
replacement by new part" to install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether
the new part can be used in the old machine. x = Not interchangeable o = Interchangeable
Page 25
MODIFICATION BULLETIN NO. 12 PAGE 2 OF 3
AA140599
ISSUED ON: June 15, ’95
DETAILS OF MODIFICATION
To eliminate rattling noise from the scanner drive shaft, the shaft ends have bee n mod ifie d from a D-cut
shape to a round shape.
05730040E
05730040E
AB033063
AA140557
AB033063
The Timing pulley - 22Z / 24Z and the hexagon head less set screw h ave been also modified to fit the
shape of the new shafts. These pa rts should be replaced as a set.
05730100E
AB033069
05730100E
AB033069
M. Iwasa, Manager
Technical Support Department
Page 26
MODIFICATION BULLETIN NO. 12 PAGE 3 OF 3
ISSUED ON: June 15, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8506XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363506XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363506XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8506XXXX
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363506XXXX
Ricoh FT4027 220/50 Asia, Middle East A157-29 A363506XXXX
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22 868506XXXX
USA, Canada,
L. America
A157-10 869506XXXX
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5506XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371506XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371506XXXX
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9065XXXX
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371506XXXX
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371506XXXX
115/60
220,230, 240/50 Europe, etc. A160-22 872506XXXX
USA, Canada,
L. America
Asia, Middle
East
A160-10 873506XXXX
A160-29 A371506XXXX
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363506XXXX
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370506XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0065XXXX
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370506XXXX
115/60
220, 230, 240/50 Europe etc. A159-22 870506XXXX
USA, Canada,
L. America
A159-10 871506XXXX
Page 27
M. Iwasa, Manager
Technical Support Department
MODIFICATION BULLETIN NO. 13 PAGE 1 OF 1
# 21
AB017365
# 22
AB013914
Swallow is combined
Reissued on: August 31, ’95
ISSUED ON: June 30, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Toner Hopper Gears
Reason for
Gear Part Numbers assigned due to field request
Modification
The following part numbers have bee n assig ned. Plea se ad d these numbers to your part catalog.
Inter-
Old P/N New P/N Description Q’ty Used
AB017365 Coupled Gear 15Z/22Z
AB013914 Gear 17Z
AB013915 Gear 26Z
0 → 1
0 → 1
0 → 1
change-
ability
Date of
Modification
No serial number cut-in
information
Parts Catalog
Index No. Page
21 37
22 37
23 37
Serial Number
# 23
AB013915
Page 28
M. Iwasa, Manager
Technical Support Department
MODIFICATION BULLETIN NO. 14 PAGE 1 OF 1
Swallow is conbimed
Reissued on: August 31, ’95
ISSUED ON: June 30, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Charge Roller Terminal Ass’y
Reason for
Modification
Old P/N New P/N Description Q’ty Used
A part number has been assigned for the charge roller terminal assembly to
facilitate part control.
A1532119 Charge Roller Terminal Ass’y
0 → 1
Inter-
change-
ability
Charge Roller Terminal
Roller Terminal
# 31 : Charge Roller Terminal
Ass’y A1532119
Date of
Modification
No serial number cut-in
information
Parts Catalog
Index No. Page
31 39
Serial Number
NOTE: The Roller Terminal and the Charge Roller Termin al
are still available as separate service parts.
Page 29
MODIFICATION BULLETIN NO. 15 PAGE 1 OF 1
ISSUED ON: August 31, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Toner Supply Unit No serial number cut-in information
Reason for
Part number assigned
Modification
Date of
Modification
The following part numbers have been assigned to the Toner Sup ply Unit s.
Old P/N New P/N Description Q’ty Used
A153 3150 Toner Supply Unit - EU
A153 3151 Toner Supply Unit - NA
A153 3153 Toner Supply Unit - AA/TWAN/OEM
0 → 1
0 → 1
0 → 1
Inter-
change-
ability
Index No. Page
Parts Catalog
35 35
35 35
35 35
Serial Number
M. Iwasa, Manager
Technical Support Departme nt
Page 30
MODIFICATION BULLETIN NO. 16 PAGE 1 OF 1
ISSUED ON: August 31, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Parts Catalog No serial number cut-in information
Reason for
Part Catalog Correction
Modification
Date of
Modification
Please correct your parts catalog as follows:
Incorrect P/N Correct P/N Description
Index No. Page
AW50 0012 AW50 0010 Push Switch 5 71
P/N Incorrect Description Correct Description
AW23 0008 ID Sensor Toner Density Sensor 7 37
Parts Catalog
Parts Catalog
Index No. Page
Serial Number
A153 5132 Density Sensor ID Sensor 29 41
M. Iwasa, Manager
Technical Support Departme nt
Page 31
MODIFICATION BULLETIN NO. 17 PAGE 1 OF 1
ISSUED ON: September 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Cleaning Blade No serial number cut-in information
Reason for
Modification
P/N P/N Description Q’ty Used
A153-2275 A153-2277 Cleaning Blade
To improve the effectiveness of cleaning when the temperature changes
from high (30°C 90%RH) to low (10°C 15%RH), the blade angle against the
drum has been changed from 15° to 17.5°
1 → 1
Inter-
change-
ability
O/O 5 41
Index No. Page
Date of
Modification
Parts Catalog
Serial Number
M. Iwasa, Manager
Technical Support Department
Page 32
MODIFICATION BULLETIN NO. 18 PAGE 1 OF 1
ISSUED ON: September 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Bottom Tray Sheet No serial number cut-in information
Reason for
Material change
Modification
Inter-
Incorrect P/N Correct P/N Description Q’ty Used
A157-2764 A157-2806 Bottom Tray Sheet
1 → 1
change-
ability
O/O 11 15
Index No. Page
Date of
Modification
Parts Catalog
Serial Number
M. Iwasa, Manager
Technical Support Department
Page 33
MODIFICATION BULLETIN NO. 19 PAGE 1 OF 1
ISSUED ON: October 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Part Catalog No serial number cut-in information
Reason for
Part number assigned for the spring wiper of the toner end sensor.
Modification
New P/N Description Q’ty Used
AA06 6246 Spring
0 → 1
Index No. Page
21 37
Parts Catalog
Date of
Modification
Serial Number
Toner End Senso r
Index 21
Spring
M. Iwasa, Manager
Technical Support Department
Page 34
MODIFICATION BULLETIN NO. 20 PAGE 1 OF 9
ISSUED ON: October 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article See Below
Reason for
To meet the Energy Star requirements, the following parts have been changed.
Modification
Draw
No.
Old Parts
No.
12041545 12042421 Main Switch
A1535804 A1535814 Main Switch Bracket
A1535301 A1535501 AC Main Harness
New Parts
No.
A1535562 Main Switch Relay Harness
A1535561 Relay Harness
12081392 Relay
Description Rank
Q’ty Used
Old→New
1 → 1
1 → 1
0 → 1
0 → 1
0 → 1
1 → 1
Date of
Modification
Inter-
change-
ability
X/X T-1 102 67
X/X T-1 12 67
X/X T-1 3 67
Part No. Serial Number Cut-in Table No. Page
T-1 19 69
T-1 20 69
T-1 110 69
Serial
Number
Parts
Catalog
A1571301 A1571302 Left Cover
A1575101 A1575181 Main Board X/X T-1 2 69
A1535104 A1535106 IC - 4M x 16 - 120NS (ROM) X/X T-1 4 69
A1535545 A1535550 AC Drive Board - 120V X/O T-2 11 69
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for
replacement by new part" to install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether
the new part can be used in the old machine. x = Not interchangeable o = Interchangeable
1 → 1
X/X T-1 16 9
Page 35
MODIFICATION BULLETIN NO. 20 PAGE 2 OF 9
ISSUED ON: October 15, ’95
Draw
No.
Old Parts
No.
A1585309 A1565509
A1575311 A1575511
A1545320 A1535520 Front Right Harness X/O — 5 67
New Parts
No.
A1578637
A1618637
Description Rank
Rear Lower Harness Duplex (A160/A162)
Rear Lower Harness - 2
Tray (A157/A159/A161)
Operating Instructions Energy Star
(Falcon: A157/A159/A160)
Operating Instructions Energy Star
(Swallow: A161/A162)
Q’ty Used
Old → New
Inter-
change-
ability
X/O — 17 69
X/O — 17 69
Part needed for replacement by new part
Part No. Description No. Page
T-3 7 77
T-3 9 77
Parts
Catalog
Page 36
DETAILS OF MODIFICATION
M. Iwasa, Manager
Technical Support Department
Relay
AC250V
12081392
Relay Harness
A1535561
Main Switch Relay Harness
Main
Switch
12042421
MODIFICATION BULLETIN NO. 20 PAGE 3 OF 9
ISSUED ON: October 15, ’95
Relay Harness
DC Drive Board
Relay (New Part)
12081392
Main Switch
Relay Harness
A1535562
Page 37
ISSUED ON: October 15, ’95
T-1
MODIFICATION BULLETIN NO. 20 PAGE 4 OF 9
MODEL NAME V/Hz
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8508XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363508XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26
Ricoh FT4027 220, 230, 240/50 Europe A157-27
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
JAPAN PRODUCTION
CODE
A157-10 869508XXXX
A157-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5508XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371508XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22
USA, Canada,
L. America
Asia, Middle
East
A160-10 873508XXXX
A160-29
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370508XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26
Ricoh FT4127 220, 230, 240/50 Europe A159-27
115/60
220, 230, 240/50 Europe etc. A159-22
USA, Canada,
L. America
A159-10 871508XXXX
Page 38
ISSUED ON: October 15, ’95
T-1
MODIFICATION BULLETIN NO. 20 PAGE 5 OF 9
MODEL NAME V/Hz
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15
Ricoh FT4022 115/60 USA, Canada A161-17 A364508XXXX
Ricoh FT4022 110/60 Taiwan, Saudi A161-19
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26
Ricoh FT4022 220, 230, 240/50 Europe A161-27
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59
115/60
220, 230, 240/50 Europe etc. A161-22
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
JAPAN PRODUCTION
CODE
A161-10
A161-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15
Ricoh FT4522 115/60 USA, Canada A162-17 A372508XXXX
Ricoh FT4522 110/60 Taiwan, Saudi A162-19
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26
Ricoh FT4522 220,230, 240/50 Europe A162-27
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59
115/60
220,230, 240/50 Europe, etc. A162-22
USA, Canada,
L. America
Asia, Middle
East
A162-10
A162-29
SERIAL
NUMBER
Page 39
ISSUED ON: October 15, ’95
T-2
MODIFICATION BULLETIN NO. 20 PAGE 6 OF 9
MODEL NAME V/Hz
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8508XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363508XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363508XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26
Ricoh FT4027 220, 230, 240/50 Europe A157-27
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
JAPAN PRODUCTION
CODE
A157-10 869508XXXX
A157-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5508XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371508XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371508XXXX
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22
USA, Canada,
L. America
Asia, Middle
East
A160-10 873508XXXX
A160-29
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370508XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26
Ricoh FT4127 220, 230, 240/50 Europe A159-27
115/60
220, 230, 240/50 Europe etc. A159-22
USA, Canada,
L. America
A159-10 871508XXXX
Page 40
ISSUED ON: October 15, ’95
T-2
MODIFICATION BULLETIN NO. 20 PAGE 7 OF 9
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15
Ricoh FT4022 115/60 USA, Canada A161-17
Ricoh FT4022 110/60 Taiwan, Saudi A161-19
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26
Ricoh FT4022 220, 230, 240/50 Europe A161-27
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59
115/60
220, 230, 240/50 Europe etc. A161-22
USA, Canada,
L. America
Asia, Middle
East
A161-10
A161-29
SERIAL
NUMBER
A364508XXXX
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15
Ricoh FT4522 115/60 USA, Canada A162-17 A372308XXXX
Ricoh FT4522 110/60 Taiwan, Saudi A162-19
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26
Ricoh FT4522 220,230, 240/50 Europe A162-27
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59
115/60
220,230, 240/50 Europe, etc. A162-22
USA, Canada,
L. America
Asia, Middle
East
A162-10
A162-29
SERIAL
NUMBER
Page 41
ISSUED ON: October 15, ’95
T-3
MODIFICATION BULLETIN NO. 20 PAGE 8 OF 9
MODEL NAME V/Hz
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8509XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363509XXXX
Ricoh FT4027 110/60
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26
Ricoh FT4027 220, 230, 240/50 Europe A157-27
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
115/60
220, 230, 240/50 Europe etc. A157-22
DESTINATION
USA,
Canada,
L. America
Taiwan,
Saudi
Asia, Middle
East
JAPAN PRODUCTION
CODE
A157-10
A157-19
A157-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5509XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371509XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22
USA, Canada,
L. America
Asia, Middle
East
A160-10 873509XXXX
A160-29
SERIAL
NUMBER
Gestetner 2627 110/60 Taiwan A157-50
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370509XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26
Ricoh FT4127 220, 230, 240/50 Europe A159-27
USA,
115/60
220, 230, 240/50 Europe etc. A159-22
Canada,
L. America
A159-10
Page 42
ISSUED ON: October 15, ’95
T-3
MODIFICATION BULLETIN NO. 20 PAGE 9 OF 9
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15
Ricoh FT4022 115/60 USA, Canada A161-17 A364509XXXX
Ricoh FT4022 110/60 Taiwan, Saudi A161-19
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26
Ricoh FT4022 220, 230, 240/50 Europe A161-27
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59
115/60
220, 230, 240/50 Europe etc. A161-22
USA, Canada,
L. America
Asia, Middle
East
A161-10
A161-29
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15
Ricoh FT4522 115/60 USA, Canada A162-17 A372509XXXX
Ricoh FT4522 110/60 Taiwan, Saudi A162-19
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26
Ricoh FT4522 220,230, 240/50 Europe A162-27
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59
115/60
220,230, 240/50 Europe, etc. A162-22
USA, Canada,
L. America
Asia, Middle
East
A162-10
A162-29
SERIAL
NUMBER
Page 43
MODIFICATION BULLETIN NO. 21 PAGE 1 OF 2
ISSUED ON: October 31, ’95
Fusing Unit
Model Phoenix (Falcon , Swallow ) Volt/Hz
Modified Article Parts Catalog No serial number cut-in information.
Reason for
Parts Catalog Correction
Modification
Date of
Modification
Serial Number
The following part numbe rs h ave assigned for the fusing unit .
Assigned Description Q’ty Used
A1344005 Fusing Exit Unit
A1574005 Fusing Unit - 115V
A1574007 Fusing Unit - 230V
A1614002 Fusing Unit - 115V
A1614003 Fusing Unit - 230V
0 → 1
0 → 1
0 → 1
0 → 1
0 → 1
Inter-
change-
ability
Index No. Page
Parts Catalog
16 47
* 45 (Falcon)
* 45 (Falcon)
* 45 (Swallow)
* 45 (Swallow)
Index 16
Fusing Exit Unit # A1344006. This part is not includ ed in the Fusing Unit.
Page 44
M. Iwasa, Manager
Technical Support Department
MODIFICATION BULLETIN NO. 21 PAGE 2 OF 2
18
21
22
ISSUED ON: October 31, ’95
Assigned P/N Description Q’ty Used
A1344153 Slide Rail - Fusing
A1344151 Fusing Frame
A1344250 Fusing Exit Frame
A1344280 Fusing Exit Guide - Lower
AF020326 Exit Roller Ass’y
AF040548 Exit Drive Roller
A1344272 Roller Holder
08053480 Bushing - 6mm
0 → 1
0 → 1
0 → 1
0 → 1
0 → 1
0 → 2
0 → 2
0 → 1
20
2
107
23
3
Parts Catalog
Index No. Page
17 47
18 47
19 47
20 47
21 47
22 47
23 47
107 47
107
16
19
17
Page 45
MODIFICATION BULLETIN NO. 22 PAGE 1 OF 1
M. Iwasa, Manager
Technical Support Department
ISSUED ON: October 31, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Parts Catalog No serial number cut-in information.
Reason for
Parts Catalog Correction
Modification
Date of
Modification
Serial Number
The following part numbers are missing fro m the part s ca talog. Please add these numbers to your pa rts cat alo g.
Old P/N New P/N Description Q’ty Used
A1561495 Decal - Copy Ratio
0 → 1
Inter-
change-
ability
8 (Falcon) 77
Parts Catalog
Index No. Page
A1561495
Combin
original decal
P/N A1531365
Symbol
Explanation
Decal
Page 46
MODIFICATION BULLETIN NO. 23 PAGE 1 OF 4
ISSUED ON: November 31, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article 6th Mirror Seal
Reason for
To prevent white bands in halftone areas in 200% enlargement mode.
Modification
Date of
Modification
The shield seal has been add ed on the 6th mirror bracket to prevent a white band from appearing in ha lft on e areas in
200% enlargement mode.
New P/N Description Q’ty Used
A0481801 Mirror Seal
A1531923 6th Mirror Bracket
0 → 1
0 → 1
Index No. Page
28 33
27 33
Parts Catalog
P/N A1531923 is assigned for th e 6th Mirror Bracket.
27 : 6th Mirror Bracket
Serial Number
28 : Mirror Seal
0 ~ 0.5mm
0 ± 0.5mm
M. Iwasa, Manager
Technical Support Department
Page 47
MODIFICATION BULLETIN NO. 23 PAGE 2 OF 4
ISSUED ON: November 15, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8507XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363507XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363507XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8075XXXX
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363507XXXX
Ricoh FT4027 220/50 Asia, Middle East A157-29 A363507XXXX
nashuatec 3527 110/60 Taiwan A157-39 904507XXXX
Gestetner 2627 110/60 Taiwan A157-50 904507XXXX
115/60
220, 230, 240/50 Europe etc. A157-22 868507XXXX
USA, Canada,
L. America
A157-10 869507XXXX
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5507XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371507XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371507XXXX
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9075XXXX
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371507XXXX
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371507XXXX
115/60
220,230, 240/50 Europe, etc. A160-22 872507XXXX
USA, Canada,
L. America
Asia, Middle
East
A160-10 873507XXXX
A160-29 A371507XXXX
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363507XXXX
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370507XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0075XXXX
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370507XXXX
115/60
220, 230, 240/50 Europe etc. A159-22 870507XXXX
USA, Canada,
L. America
A159-10 871507XXXX
Page 48
MODIFICATION BULLETIN NO. 23 PAGE 3 OF 4
ISSUED ON: November 15, ’95
RIF PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8
Ricoh FT4027 115/60 USA, Canada A157-17 A363
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 868
USA, Canada,
L. America
Asia, Middle
East
A157-10 869
A157-29 A363
SERIAL
NUMBER
RIF PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5
Ricoh FT4527 115/60 USA, Canada A160-17 A371
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 872
USA, Canada,
L. America
Asia, Middle
East
A160-10 873
A160-29 A371
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370
115/60
220, 230, 240/50 Europe etc. A159-22 870
USA, Canada,
L. America
A159-10 871
Page 49
MODIFICATION BULLETIN NO. 23 PAGE 4 OF 4
ISSUED ON: November 15, ’95
RPL PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8
Ricoh FT4027 115/60 USA, Canada A157-17 A363
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 868
USA, Canada,
L. America
Asia, Middle
East
A157-10 869
A157-29 A363
SERIAL
NUMBER
RPL PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5
Ricoh FT4527 115/60 USA, Canada A160-17 A371
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 872
USA, Canada,
L. America
Asia, Middle
East
A160-10 873
A160-29 A371
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370
115/60
220, 230, 240/50 Europe etc. A159-22 870
USA, Canada,
L. America
A159-10 871
Page 50
MODIFICATION BULLETIN NO. 24 PAGE 1 OF 7
ISSUED ON: November 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Left Original Scale
Reason for
To prevent the left original scale from warping.
Modification
Date of
Modification
To prevent the left orig inal scale from warping, a metal plate has been added to the new scale .
The scale bracket, which was missing fro m t he part s ca ta log , ha s now be en added . In addition, the P/N has been
changed as a result of the change to the left origin al scale.
Old P/N New P/N Description Q’ty Used
AC042112 AC042113 Left Original Scale - A4
AC042116 AC042117 Left Original Scale - LT
A1531750 A1531749 Scale Bracket
1 → 1
1 → 1
1 → 1
Inter-
change-
ability
X/X 20 9
X/X X/O as s set 20 9
X/X X/O as s set * 31 9
Parts Catalog
Index No. Page
Serial Number
* New Index
M. Iwasa, Manager
Technical Support Department
Page 51
MODIFICATION BULLETIN NO. 24 PAGE 2 OF 7
ISSUED ON: November 15, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8508XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363508XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363509XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8095XXXX
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363509XXXX
Ricoh FT4027 220/50 Asia, Middle East A157-29 A363509XXXX
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 868509XXXX
USA, Canada,
L. America
A157-10 869508XXXX
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5508XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371508XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371509XXXX
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9095XXXX
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371509XXXX
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 872509XXXX
USA, Canada,
L. America
Asia, Middle
East
A160-10 873508XXXX
A160-29 A371509XXXX
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370508XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0095XXXX
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370509XXXX
115/60
220, 230, 240/50 Europe etc. A159-22 870509XXXX
USA, Canada,
L. America
A159-10 871508XXXX
Page 52
MODIFICATION BULLETIN NO. 24 PAGE 3 OF 7
ISSUED ON: November 15, ’95
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A85860001
Ricoh FT4027 115/60 USA, Canada A157-17 A3635860196
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F88750001
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A3635870419
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 8685870001
USA, Canada,
L. America
Asia, Middle
East
A157-10 8695860001
A157-29 A3635860598
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A55860001
Ricoh FT4527 115/60 USA, Canada A160-17 A3715860507
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F98750001
Ricoh FT4527 220,230, 240/50 Europe A160-27 A3715870001
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 8725870001
USA, Canada,
L. America
Asia, Middle
East
A160-10 8735870001
A160-29 A3715860807
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G08750001
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A3705870001
115/60
220, 230, 240/50 Europe etc. A159-22 870
USA, Canada,
L. America
A159-10 871
Page 53
MODIFICATION BULLETIN NO. 24 PAGE 4 OF 7
ISSUED ON: November 15, ’95
RIF PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8
Ricoh FT4027 115/60 USA, Canada A157-17 A363
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 868
USA, Canada,
L. America
Asia, Middle
East
A157-10 869
A157-29 A363
SERIAL
NUMBER
RIF PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5
Ricoh FT4527 115/60 USA, Canada A160-17 A371
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 872
USA, Canada,
L. America
Asia, Middle
East
A160-10 873
A160-29 A371
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370
115/60
220, 230, 240/50 Europe etc. A159-22 870
USA, Canada,
L. America
A159-10 871
Page 54
MODIFICATION BULLETIN NO. 24 PAGE 5 OF 7
ISSUED ON: November 15, ’95
RPL PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8
Ricoh FT4027 115/60 USA, Canada A157-17 A363
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 868
USA, Canada,
L. America
Asia, Middle
East
A157-10 869
A157-29 A363
SERIAL
NUMBER
RPL PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5
Ricoh FT4527 115/60 USA, Canada A160-17 A371
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 872
USA, Canada,
L. America
Asia, Middle
East
A160-10 873
A160-29 A371
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370
115/60
220, 230, 240/50 Europe etc. A159-22 870
USA, Canada,
L. America
A159-10 871
Page 55
MODIFICATION BULLETIN NO. 24 PAGE 6 OF 7
ISSUED ON: November 15, ’95
MODEL NAME V/Hz
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A1
Ricoh FT4022 115/60 USA, Canada A161-17 A364508XXXX
Ricoh FT4022 110/60 Taiwan, Saudi A161-19 A364
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F6
Ricoh FT4022 220, 230, 240/50 Europe A161-27 A364509XXXX
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59 A364
115/60
220, 230, 240/50 Europe etc. A161-22 874
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
JAPAN PRODUCTION
CODE
A161-10 875
A161-29 A364
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A2
Ricoh FT4522 115/60 USA, Canada A162-17 A372508XXXX
Ricoh FT4522 110/60 Taiwan, Saudi A162-19 A372
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F7
Ricoh FT4522 220,230, 240/50 Europe A162-27 A372509XXXX
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59 A372
115/60
220,230, 240/50 Europe, etc. A162-22 876
USA, Canada,
L. America
Asia, Middle
East
A162-10 877
A162-29 A372
SERIAL
NUMBER
Page 56
MODIFICATION BULLETIN NO. 24 PAGE 7 OF7
ISSUED ON: November 15, ’95
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A1
Ricoh FT4022 115/60 USA, Canada A161-17 A364508XXXX
Ricoh FT4022 110/60 Taiwan, Saudi A161-19 A364
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F68750001
Ricoh FT4022 220, 230, 240/50 Europe A161-27 A364509XXXX
Ricoh FT4022 220/50 Asia, Middle East A161-29 A3645860226
Ricoh FT4022 110/60 Taiwan A161-59 A364
115/60
220, 230, 240/50 Europe etc. A161-22 8745870001
USA, Canada,
L. America
A161-10 875
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A2
Ricoh FT4522 115/60 USA, Canada A162-17 A372508XXXX
Ricoh FT4522 110/60 Taiwan, Saudi A162-19 A372
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F78750001
Ricoh FT4522 220,230, 240/50 Europe A162-27 A372509XXXX
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59 A372
115/60
220,230, 240/50 Europe, etc. A162-22 8765860001
USA, Canada,
L. America
Asia, Middle
East
A162-10 877
A162-29 A3725860396
SERIAL
NUMBER
Page 57
MODIFICATION BULLETIN NO. 25 PAGE 1 OF 1
ISSUED ON: November 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Lower Inner Cover No serial number cut-in information
Reason for
To prevent possible damage to the fusing idler gear.
Modification
Inter-
Old P/N New P/N Description Q’ty Used
A1571359 A1571339 Lower Inner Cover
1 → 1
change-
ability
O/O 8 9
Index No. Page
Date of
Modification
Parts Catalog
Serial Number
To prevent possible damage to th e fu sing idle ge ar, as it ma y collide against the lower inner cover when
the fusing unit is slid back into the ma chin e with the exit guide ope n, the lower inner cover has been
enlarged to reduce the gap bet wee n the gear and the cover as shown below.
Lower
Inner
Cover
Gap
70mm → 10mm
Exit Guide
M. Iwasa, Manager
Technical Support Department
Page 58
MODIFICATION BULLETIN NO. 26 PAGE 1 OF 1
ISSUED ON: November 15, ’95
M. Iwasa, Manager
Technical Support Department
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article By-pass Feed Table No serial number cut-in information
Reason for
Standardization with other models.
Modification
Inter-
Old P/N New P/N Description Q’ty Used
A1342690 A1342691 By-pass Feed Table Ass’y
A1342731 A1342741 By-pass Feed Entrance Guide
1 → 1
1 → 1
change-
ability
O/O 12 13
O/O 14 13
Index No. Page
Date of
Modification
Parts Catalog
Serial Number
Note: The new by-pass fe ed ent ran ce gu ide is req uire d to be a little warped when you inst all th e gu ide on th e main frame.
Page 59
M. Iwasa, Manager
Technical Support Department
MODIFICATION BULLETIN NO. 27 PAGE 1 OF 3
ISSUED ON: November15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Spacer - Vertical Transport Guide
Reason for
Modification
Old P/N New P/N Description Q’ty Used
To prevent the sensor on the vertical transport guide from chattering, a
spacer has been added between the guide and the LCT.
A1556112 Spacer - LCT
0 → 1
Inter-
change-
ability
Vertical Transport Guide
Date of
Modification
Parts Catalog
Index No. Page
38 17
Serial Number
Spacer - LCT LCT
Page 60
MODIFICATION BULLETIN NO. 27 PAGE 2 OF 3
ISSUED ON: November15, ’95
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8
Ricoh FT4027 115/60 USA, Canada A157-17 A363
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22 868
USA, Canada,
L. America
Asia, Middle
East
A157-10 869
A157-29 A363
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5 -----Ricoh FT4527 115/60 USA, Canada A160-17 A371 -----Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371 ------
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F98850001
Ricoh FT4527 220,230, 240/50 Europe A160-27 A3715880001
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371 ------
115/60
220,230, 240/50 Europe, etc. A160-22 8725870001
USA, Canada,
L. America
Asia, Middle
East
A160-10 873 ------
A160-29 A3715880597
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370 ------
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G08950001
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A3705880001
115/60
220, 230, 240/50 Europe etc. A159-22 870 ------
USA, Canada,
L. America
A159-10 871
Page 61
MODIFICATION BULLETIN NO. 27 PAGE 3 OF 3
ISSUED ON: November15, ’95
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A1
Ricoh FT4022 115/60 USA, Canada A161-17 A364
Ricoh FT4022 110/60 Taiwan, Saudi A161-19 A364
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F6
Ricoh FT4022 220, 230, 240/50 Europe A161-27 A364
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59 A364
115/60
220, 230, 240/50 Europe etc. A161-22 874
USA, Canada,
L. America
Asia, Middle
East
A161-10 875
A161-29 A364
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A2 ----Ricoh FT4522 115/60 USA, Canada A162-17 A372 ----Ricoh FT4522 110/60 Taiwan, Saudi A162-19 A372 -----
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F7885001
Ricoh FT4522 220,230, 240/50 Europe A162-27 A3725880001
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59 A372 ------
115/60
220,230, 240/50 Europe, etc. A162-22 8765880001
USA, Canada,
L. America
Asia, Middle
East
A162-10 877 -----
A162-29 A3725880631
SERIAL
NUMBER
Page 62
MODIFICATION BULLETIN NO. 28 PAGE 1 OF 5
ISSUED ON:November 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Timing Belt
Reason for
Modification
Old P/N New P/N Description Q’ty Used
AA043393 AA043420 Timing Belt - 80S3M519
To improve the durability of the Timing Belt, the material of the belt has been
changed.
Inter-
change-
ability
1 → 1
X/O 4 61
Date of
Modification
Parts Catalog
Index No. Page
Serial Number
M. Iwasa, Manager
Technical Support Department
Page 63
MODIFICATION BULLETIN NO. 28 PAGE 2 OF 5
ISSUED ON:November 15, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8510XXXX
Ricoh FT4027 115/60 USA, Canada A157-17 A363510XXXX
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363510XXXX
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8105XXXX
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363510XXXX
Ricoh FT4027 220/50 Asia, Middle East A157-29 A363510XXXX
nashuatec 3527 110/60 Taiwan A157-39 904 ------
Gestetner 2627 110/60 Taiwan A157-50 904 ------
115/60
220, 230, 240/50 Europe etc. A157-22 868510XXXX
USA, Canada,
L. America
A157-10 869510XXXX
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5510XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371510XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371510XXXX
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9105XXXX
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371510XXXX
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371 -----
115/60
220,230, 240/50 Europe, etc. A160-22 872510XXXX
USA, Canada,
L. America
Asia, Middle
East
A160-10 873510XXXX
A160-29 A371510XXXX
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363 ------
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370510XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0105XXXX
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370510XXXX
115/60
220, 230, 240/50 Europe etc. A159-22 870510XXXX
USA, Canada,
L. America
A159-10 871510XXXX
Page 64
MODIFICATION BULLETIN NO. 28 PAGE 3 OF 5
ISSUED ON:November 15, ’95
RIF PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8
Ricoh FT4027 115/60 USA, Canada A157-17 A363
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 868
USA, Canada,
L. America
Asia, Middle
East
A157-10 869
A157-29 A363
SERIAL
NUMBER
RIF PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5
Ricoh FT4527 115/60 USA, Canada A160-17 A371
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 872
USA, Canada,
L. America
Asia, Middle
East
A160-10 873
A160-29 A371
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370
115/60
220, 230, 240/50 Europe etc. A159-22 870
USA, Canada,
L. America
A159-10 871
Page 65
MODIFICATION BULLETIN NO. 28 PAGE 4 OF 5
ISSUED ON:November 15, ’95
RPL PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8
Ricoh FT4027 115/60 USA, Canada A157-17 A363
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 868
USA, Canada,
L. America
Asia, Middle
East
A157-10 869
A157-29 A363
SERIAL
NUMBER
RPL PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5
Ricoh FT4527 115/60 USA, Canada A160-17 A371
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 872
USA, Canada,
L. America
Asia, Middle
East
A160-10 873
A160-29 A371
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370
115/60
220, 230, 240/50 Europe etc. A159-22 870
USA, Canada,
L. America
A159-10 871
Page 66
MODIFICATION BULLETIN NO. 28 PAGE 5 OF 5
ISSUED ON:November 15, ’95
MODEL NAME V/Hz
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A1
Ricoh FT4022 115/60 USA, Canada A161-17 A364
Ricoh FT4022 110/60 Taiwan, Saudi A161-19 A364
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F6
Ricoh FT4022 220, 230, 240/50 Europe A161-27 A364510XXXX
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59 A364
115/60
220, 230, 240/50 Europe etc. A161-22 874
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
JAPAN PRODUCTION
CODE
A161-10 875
A161-29 A364
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A2
Ricoh FT4522 115/60 USA, Canada A162-17 A372510XXXX
Ricoh FT4522 110/60 Taiwan, Saudi A162-19 A372
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F7
Ricoh FT4522 220,230, 240/50 Europe A162-27 A372510XXXX
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59 A372
115/60
220,230, 240/50 Europe, etc. A162-22 876
USA, Canada,
L. America
Asia, Middle
East
A162-10 877
A162-29 A372
SERIAL
NUMBER
Page 67
MODIFICATION BULLETIN NO. 29 PAGE 1 OF 2
ISSUED ON: November 30, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Date of
Modification
Modified Article Main Board Components No serial Number Cut-in information
Reason for
Modification
Part numbers have been assigned for the following components on the main
board.
Please add a new page to your parts catalog for the following parts.
31-1. Electrical Section 2-A (Page 69-A).
IC
Symbol No.
IC3 100
IC4 101
IC5 102
IC6 103
IC7 104
IC8 105
IC9 106
IC10 107
IC11 108
IC12 109
IC13 109
IC14 110
IC15 111
IC16 112
IC17 113
IC18 113
IC19 113
IC20 113
IC21 114
IC22 114
IC23 114
IC24 115
IC25 116
IC26 117
IC31 118
INDEX
NO.
OSCILLATOR
Symbol No .
OSC1 124
INDEX
NO.
DIODE
Symbol No.
D3 119
D5 119
DA1 120
DA2 120
DA3 120
DA4 120
DA5 120
DA6 120
DA7 121
DA8 121
DA9 121
DA10 121
ZD1 122
ZD2 122
ZD3 122
ZD4 123
INDEX
NO.
TRANSISTOR
Symbol No.
Q1 125
Q2 126
INDEX
NO.
Serial Number
Page 68
MODIFICATION BULLETIN NO. 29 PAGE 2 OF 2
MAIN CONTROL BOARD(A153/A155/ A156/A157/ A159/A160/ A161/A162)
ISSUED ON: November 30, ’95
INDEX
NO.
100 14074401 LS I TE6250A 1
101 14080770 IC- L293D 1
102 14072496 IC- M 5261L 1
103 14073708 IC- SLA7026M 1
104 14081135 IC- X 9C104S 1
105 14080595 IC- N J M2904M 1
106 14072862 SWITCH 1
107 14080877 IC- LM339NS 1
108 14074137 IC- M M1035XF 1
109 14072187 IC- SN74LS07NS 1
110 14073257 IC- TC 74HC14A 1
111 14072862 SWITCH 1
112 14080595 IC- N J M2904M 1
113 14072187 IC- SN74LS07NS 1
114 14072231
115 14080874 T RANSI STOR ARRA Y-M 54587F 1
116 14072231
117 14080875 T RANSI STOR ARRA Y-TD62382 1
118 14080629 REGUL ATOR : NJM78M1:+12V 1
119 14021030 DIODE -1SS250 1
120 14020708 DIODE -1SS272 1
121 14020478 DIODE -1SS226TE85L 1
122 14021037 DIODE -U1ZB12 1
123 14020688 DIODE 1
124 15030435 OSCIL LA TOR AT - 51 20M HZ 1
125 14000369 T RANSI STOR-2SA 1213Y 1
126 14000558 T RANSI STOR-2SD780 1
Part No. Descriptio n
I C - TD 62308AF
I C - TD 62308AF
Assembly
Q'ty per
1
1
M. Iwasa, Manager
Technical Support Department
Page 69
MODIFICATION BULLETIN NO. 30 PAGE 1 OF 3
ISSUED ON: November 30, ’95
Model Phoenix (Falcon Swallow) Volt/Hz
Modified Article Fusing Exit Guide
Reason for
To prevent paper jams caused by the fusing exit guide peeling off.
Modification
Date of
Modification
The fusing exit guide has be en chan ge d to two fusing exit guides (Front / Rear) to prevent paper jams caused by the
current fusing exit guide peeling off.
Old P/N New P/N Description Q’ty Used
A134 4253 Fusing Exit Guide
A134 4254 Fusing Exit Guide - Rear
A134 4255 Fusing Exit Guide - Front
1 → 0
0 → 1
0 → 1
Inter-
change-
ability
Index No. Page
Parts Catalog
14 47
14 47
14 47
The new fusing exit guides are positioned as shown below.
Serial Number
New Fusing Exit Guides
A: 0 ~ 1 mm
A
A
B: 0 ~ 0.5 mm
M. Iwasa, Manager
B
B
Technical Support Departme nt
Page 70
MODIFICATION BULLETIN NO. 30 PAGE 2 OF 3
ISSUED ON: November 30, ’95
MODEL NAME V/Hz
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A85900001
Ricoh FT4027 115/60 USA, Canada A157-17 A3635900175
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F89050001
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A3635900001
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 8685900001
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
RAI PRODUCTION
CODE
A157-10 869591XXXX
A157-29 A3635890218
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A55890001
Ricoh FT4527 115/60 USA, Canada A160-17 A3715890431
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F98950001
Ricoh FT4527 220,230, 240/50 Europe A160-27 A3715900001
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371591XXXX
115/60
220,230, 240/50 Europe, etc. A160-22 8725900001
USA, Canada,
L. America
Asia, Middle
East
A160-10 8735900001
A160-29 A3715890838
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370591XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G09050001
115/60
220, 230, 240/50 Europe etc. A159-22 870591XXXX
USA, Canada,
L. America
A159-10 871591XXXX
A363591XXXX
Page 71
MODIFICATION BULLETIN NO. 30 PAGE 3 OF 3
ISSUED ON: November 30, ’95
MODEL NAME V/Hz
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A15890001
Ricoh FT4022 115/60 USA, Canada A161-17 A3645890461
Ricoh FT4022 110/60 Taiwan, Saudi A161-19 A364
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F69050001
Ricoh FT4022 220, 230, 240/50 Europe A161-27 A3645890428
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59 A364591XXXX
115/60
220, 230, 240/50 Europe etc. A161-22 8745890001
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
RAI PRODUCTION
CODE
A161-10 8755890001
A161-29 A3645890711
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A25890001
Ricoh FT4522 115/60 USA, Canada A162-17 A3725890263
Ricoh FT4522 110/60 Taiwan, Saudi A162-19 A372
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F78950001
Ricoh FT4522 220,230, 240/50 Europe A162-27 A3725890001
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59 A372591XXXX
115/60
220,230, 240/50 Europe, etc. A162-22 8765890001
USA, Canada,
L. America
Asia, Middle
East
A162-10 8775890001
A162-29 A3725900851
SERIAL
NUMBER
Page 72
MODIFICATION BULLETIN NO. 31 PAGE 1 OF 3
ISSUED ON: November 30, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Cushion
Reason for
Field Request
Modification
The cushion # A155 6270 has bee n adde d as an accesso ry t o pre ven t the originals on the LCT from
droppin g into the feed station.
Inter-
Old P/N New P/N Description Q’ty Used
A155 6270 Cushion 20 X 30
The position of the cushio n is a s shown below.
0 → 1
change-
ability
—
Index No. Page
10
11 (Swallow)
(-10, -15, -17 only)
The edge of the cushion is align ed wit h th e line where the stay is ben t at a slight angle.
Date of
Modification
Parts Catalog
Serial Number
77
slight angle position
Cushion
Center
LCT Upper Stay
(A155 6251 )
M. Iwasa, Manager
Technical Support Department
Page 73
MODIFICATION BULLETIN NO. 31 PAGE 2 OF 3
ISSUED ON: November 30, ’95
MODEL NAME V/Hz
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A8
Ricoh FT4027 115/60 USA, Canada A157-17 A363
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F8
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A363
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904
Gestetner 2627 110/60 Taiwan A157-50 904
115/60
220, 230, 240/50 Europe etc. A157-22 868
DESTINATION
USA, Canada,
L. America
Asia, Middle
East
RAI PRODUCTION
CODE
A157-10 869
A157-29 A363
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A5512XXXX
Ricoh FT4527 115/60 USA, Canada A160-17 A371512XXXX
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F9
Ricoh FT4527 220,230, 240/50 Europe A160-27 A371
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371
115/60
220,230, 240/50 Europe, etc. A160-22 872
USA, Canada,
L. America
Asia, Middle
East
A160-10 873512XXXX
A160-29 A371
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370512XXXX
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G0
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A370
115/60
220, 230, 240/50 Europe etc. A159-22 870
USA, Canada,
L. America
A159-10 871512XXXX
Page 74
MODIFICATION BULLETIN NO. 31 PAGE 3 OF 3
ISSUED ON: November 30, ’95
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A1
Ricoh FT4022 115/60 USA, Canada A161-17 A364
Ricoh FT4022 110/60 Taiwan, Saudi A161-19 A364
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F6
Ricoh FT4022 220, 230, 240/50 Europe A161-27 A364
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59 A364
115/60
220, 230, 240/50 Europe etc. A161-22 874
USA, Canada,
L. America
Asia, Middle
East
A161-10 875
A161-29 A364
SERIAL
NUMBER
JAPAN PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A2
Ricoh FT4522 115/60 USA, Canada A162-17 A372
Ricoh FT4522 110/60 Taiwan, Saudi A162-19 A372
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F7
Ricoh FT4522 220,230, 240/50 Europe A162-27 A372
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59 A372
115/60
220,230, 240/50 Europe, etc. A162-22 876
USA, Canada,
L. America
Asia, Middle
East
A162-10 877512XXXX
A162-29 A372
SERIAL
NUMBER
Page 75
MODIFICATION BULLETIN NO. 32 PAGE 1 OF 1
ISSUED ON: November 30, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article See below No serieal number cut-in information
Reason for
Vender change
Modification
Inter-
Old P/N New P/N Description Q’ty Used
AF03 1030 AF03 1025 Feed Roller
AG05 0078 AG05 0074 Registration Knob
AA08 3012 AA08 3010 Clutch Roller
1 → 1
1 → 1
1 → 1
change-
ability
O/O 7 21
O/O
O/O 13 21
Index No. Page
Date of
Modification
Parts Catalog
6
2
Serial Number
9
25
M. Iwasa, Manager
Technical Support Department
Page 76
MODIFICATION BULLETIN NO. 33 PAGE 1 OF 1
ISSUED ON: December 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Original Length Sensor No serial number cut-in information
Reason for
Vender Change
Modification
Inter-
Old P/N New P/N Description Q’ty Used
AW01 0042 AW01 0068 Original Length Sensor
2 → 2
change-
ability
O/O 5 27
Index No. Page
Date of
Modification
Parts Catalog
Serial Number
M. Iwasa, Manager
Technical Support Department
Page 77
MODIFICATION BULLETIN NO. 34 PAGE 1 OF 3
ISSUED ON: December 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Spring
Reason for
Modification
To prevent the spring from being deformed when the spring is hooked on the
spring arm of fusing unit.
The material of the sprin g ha s bee n cha ng ed .
Inter-
Old P/N New P/N Description Q’ty Used
AA06-0605 AA06-0659 Spring
2 → 2
change-
ability
X/O 4 47 (Falcon, Swallow)
Date of
Modification
Parts Catalog
Index No. Page
Serial Number
M. Iwasa, Manager
Technical Support Department
Page 78
MODIFICATION BULLETIN NO. 34 PAGE 2 OF 3
ISSUED ON: December 15, ’95
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A85900001
Ricoh FT4027 115/60 USA, Canada A157-17 A3635900175
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363 —
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F89150001
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A3635910001
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904 —
Gestetner 2627 110/60 Taiwan A157-50 904 —
115/60
220, 230, 240/50 Europe etc. A157-22 8685900001
USA, Canada,
L. America
Asia, Middle
East
A157-10 869 —
A157-29 A3635900195
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A55900001
Ricoh FT4527 115/60 USA, Canada A160-17 A3715900676
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371 —
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F99150001
Ricoh FT4527 220,230, 240/50 Europe A160-27 A3715900001
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371 —
115/60
220,230, 240/50 Europe, etc. A160-22 8725900001
USA, Canada,
L. America
Asia, Middle
East
A160-10 8735900001
A160-29 A3715901319
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363 —
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370 —
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G09050001
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A3705900001
115/60
220, 230, 240/50 Europe etc. A159-22 870 —
USA, Canada,
L. America
A159-10 871 —
Page 79
MODIFICATION BULLETIN NO. 34 PAGE 3 OF 3
ISSUED ON: December 15, ’95
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A15900001
Ricoh FT4022 115/60 USA, Canada A161-17 A3645900101
Ricoh FT4022 110/60 Taiwan, Saudi A161-19 A364 —
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F69050001
Ricoh FT4022 220, 230, 240/50 Europe A161-27 A3645900001
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59 A364 —
115/60
220, 230, 240/50 Europe etc. A161-22 8745900001
USA, Canada,
L. America
Asia, Middle
East
A161-10 8755900001
A161-29 A3645911176
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A25900001
Ricoh FT4522 115/60 USA, Canada A162-17 A3725910041
Ricoh FT4522 110/60 Taiwan, Saudi A162-19 A372 —
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F79050001
Ricoh FT4522 220,230, 240/50 Europe A162-27 A3725900801
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59 A372 —
115/60
220,230, 240/50 Europe, etc. A162-22 8765900001
USA, Canada,
L. America
Asia, Middle
East
A162-10 8775900001
A162-29 A3725900851
SERIAL
NUMBER
Page 80
MODIFICATION BULLETIN NO. 35 PAGE 1 OF 1
ISSUED ON: December 15, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Decal Key Top Cover (NST) No serial number cut-in information
Reason for
Modification
Old P/N New P/N Description Q’ty Used
A054 6330 C225 2867 Decal Key Top Cover (NST)
To change the color of the brand name letters to match the appearance.
(-10 model only)
1 → 1
Inter-
change-
ability
O/O
Index No. Page
Date of
Modification
Parts Catalog
32
8
Serial Number
9
77
M. Iwasa, Manager
Technical Support Department
Page 81
MODIFICATION BULLETIN NO. 36 PAGE 1 OF 4
ISSUED ON: December 31, ’95
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Stripper Bracket & Fusing Exit Frame
Reason for
To improve paper separation in the fusing unit
Modification
Date of
Modification
Serial Number
To improve paper separa tio n in the fusing unit, the number of hot roller strippers ha s bee n cha ng ed from five to seven.
The stripper bracket and the fusing exit frame have also been changed to match the ne w number of strippers as shown
in the illustration.
The numbers of the fu sing unit and the fusin g exit frame have also been chan ge d.
The part number for the St ripp er Bracket Ass’y has been assigned to facilitate servicing in the field.
Old P/N New P/N Description Q’ty Used
A134 4112 A153 4112 Stripper Bracket
A134 4250 A153 4250 Fusing Exit Frame
1 → 1
1 → 1
Inter-
change-
ability
X/X 19 45
X/X 19 47
Parts Catalog
Index No. Page
X/O as a set
A157 4005 A157 4006 Fusing Unit - 115V (Falcon)
A157 4007 A157 4008 Fusing Unit - 230V (Falcon)
A134 4005 A134 4006 Fusing Exit Unit
A153 9016 Stripper Bracket Ass’y
A161 4002 A161 4005
A161 4003 A161 4006
A134 4005 A134 4006 Fusing Exit Unit
Fusing Unit - 115V
(Swallow)
Fusing Unit - 230V
(Swallow)
1 → 1
1 → 1
1 → 1
0 → 1
1 → 1
1 → 1
1 → 1
X/X * 45 X/O as a set
X/X * 45 X/O as a set
X/X 16 47
27 47
X/X * 45 X/O as a set
X/X * 45 X/O as a set
X/X 16 47
Page 82
MODIFICATION BULLETIN NO. 36 PAGE 2 OF 4
X/O as a set
Stripper Bracket Ass’y
A153 9016
ISSUED ON: December 31, ’95
Stripper Bracket
A134 4112
OLD
Fusing Exit Frame
A134 4250
OLD
NEW
Stripper Bracket
A153 4112
NEW
Fusing Exit Frame
A153 4250
M. Iwasa, Manager
Technical Support Department
Page 83
MODIFICATION BULLETIN NO. 36 PAGE 3 OF 4
ISSUED ON: December 31, ’95
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15 1A85920001
Ricoh FT4027 115/60 USA, Canada A157-17 A3635920351
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363 —
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F89250001
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A3635920001
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39 904 —
Gestetner 2627 110/60 Taiwan A157-50 904 —
115/60
220, 230, 240/50 Europe etc. A157-22 8685920001
USA, Canada,
L. America
Asia, Middle
East
A157-10 869 —
A157-29 A3635910291
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A55920001
Ricoh FT4527 115/60 USA, Canada A160-17 A3715911752
Ricoh FT4527 110/60 Taiwan, Saudi A160-19 A371 —
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F99250001
Ricoh FT4527 220,230, 240/50 Europe A160-27 A3715920001
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59 A371 —
115/60
220,230, 240/50 Europe, etc. A160-22 8725920001
USA, Canada,
L. America
Asia, Middle
East
A160-10 873 —
A160-29 A3715912088
SERIAL
NUMBER
Ricoh FT4027 110/60 Taiwan A157-59 A363 —
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17 A370 —
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G09250001
Ricoh FT4127 220, 230, 240/50 Europe A159-27 A3705920001
115/60
220, 230, 240/50 Europe etc. A159-22 870 —
USA, Canada,
L. America
A159-10 871 —
Page 84
MODIFICATION BULLETIN NO. 36 PAGE 4 OF 4
ISSUED ON: December 31, ’95
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A15920001
Ricoh FT4022 115/60 USA, Canada A161-17 A3645920011
Ricoh FT4022 110/60 Taiwan, Saudi A161-19 A364 —
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F69250001
Ricoh FT4022 220, 230, 240/50 Europe A161-27 A3645920001
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59 A364 —
115/60
220, 230, 240/50 Europe etc. A161-22 8745920001
USA, Canada,
L. America
Asia, Middle
East
A161-10 8755920001
A161-29 A3645911176
SERIAL
NUMBER
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A25910001
Ricoh FT4522 115/60 USA, Canada A162-17 A3725910041
Ricoh FT4522 110/60 Taiwan, Saudi A162-19 A3725920001
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F79250001
Ricoh FT4522 220,230, 240/50 Europe A162-27 A3725920001
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59 A372 —
115/60
220,230, 240/50 Europe, etc. A162-22 8765920001
USA, Canada,
L. America
Asia, Middle
East
A162-10 8775920001
A162-29 A3725920436
SERIAL
NUMBER
Page 85
MODIFICATION BULLETIN NO. 37 PAGE 1 OF 1
ISSUED ON: January 15, ’96
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article
Reason for
Modification
New P/N Description Q’ty Used
A158 4600 Duplex Tray Ass’y
Parts Catalog
A part number has been assigned for the duplex tray ass’y.
Index No. Page
0 → 1
Duplex Tray Ass’y
Date of
Modification
No serial number cut-in information
Parts Catalog
*49
Serial Number
M. Iwasa, Manager
Technical Support Department
Page 86
MODIFICATION BULLETIN NO. 38 PAGE 1 OF 1
ISSUED ON: January 31, ’96
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article
Reason for
Modification
Parts Catalog
Parts Catalog Correction
Modification
No serial number cut-in information
The part number for the Fron t Sid e Pla te is incorrect. Please correct the part numb er as fo llows:
Incorrect P/N Correct P/N Description Q’ty Used
A155 6111 A155 6110 Front Side Plate
1 → 1
Index No. Page
Parts Catalog
29 19
The part number for Scanner Home Sensor is missin g. Please add the part number to you r parts catalog:
P/N Description
Index No. Page
A153 1981 Scanner Home Sensor Bracket 28 31
Parts Catalog
Date of
Serial Number
# 28
# 28
M. Iwasa, Manager
Technical Support Department
M. Iwasa, Manager
Technical Support Department
Page 87
MODIFICATION BULLETIN NO. 39 PAGE 1 OF 3
ISSUED ON: January 31, ’96
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article
Reason for
Modification
Old P/N New P/N Description Q’ty Used
Toner End Sensor Cover
To prevent the toner end sensor from being damaged by hitting the toner
bottole unit when the development unit is removed / installed, a sensor cover
has been added to the toner end sensor on the toner hopper.
A153 3227 Toner End Sensor Cover
0452 3010B
Tapping Bind Screw - M3 x 10
0 → 1
0 → 1
Inter-
change-
ability
Toner Hopper
Date of
Modification
Parts Catalog
Index No. Page
22 37
107 37
Serial Number
# 106
Toner End Sensor
# 22 Toner End Sensor Cover
Page 88
MODIFICATION BULLETIN NO. 39 PAGE 2 OF 3
ISSUED ON: January 31, ’96
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627
nashuatec 3527
Savin 9027
Savin 9027 115/60 USA, Canada A157-15
Ricoh FT4027 115/60 USA, Canada A157-17 A3635920351
Ricoh FT4027 110/60 Taiwan, Saudi A157-19 A363
Gestetner 2627
nashuatec 3527
Rex Rotary 8627Z
Infotec 5271Z 220, 230, 240/50 Europe A157-26 3F89250001
Ricoh FT4027 220, 230, 240/50 Europe A157-27 A3635920001
Ricoh FT4027 220/50
nashuatec 3527 110/60 Taiwan A157-39
Gestetner 2627 110/60 Taiwan A157-50
115/60
220, 230, 240/50 Europe etc. A157-22
USA, Canada,
L. America
Asia, Middle
East
A157-10
A157-29 A3635910291
SERIAL
NUMBER
1A85920001
8685920001
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2627td
nashuatec 3527td
Savin 9027DL
Savin 9027DL 115/60 USA, Canada A160-15 1A55910001
Ricoh FT4527 115/60 USA, Canada A160-17 A3715911339
Ricoh FT4527 110/60 Taiwan, Saudi A160-19
Gestetner 2627d
nashuatec 3535td
Rex Rotary 8627DZ
Infotec 5271DZ 220,230, 240/50 Europe A160-26 3F99250001
Ricoh FT4527 220,230, 240/50 Europe A160-27
Ricoh FT4527 220/50
Ricoh FT4527 110/60 Taiwan A160-59
115/60
220,230, 240/50 Europe, etc. A160-22 8725920001
USA, Canada,
L. America
Asia, Middle
East
A160-10 8735910001
A160-29
SERIAL
NUMBER
A371
A3715920001
A3715912088
Ricoh FT4027 110/60 Taiwan A157-59
Gestetner 2627t
nashuatec 3527t
Savin 9027L
Ricoh FT4127 115/60 USA, Canada A159-17
Gestetner 2627t
nashuatec 3527t
Rex Rotary
8627LZ
Infotec 5271zu 220, 230, 240/50 Europe A159-26 3G09250001
Ricoh FT4127 220, 230, 240/50 Europe A159-27
115/60
220, 230, 240/50 Europe etc. A159-22
USA, Canada,
L. America
A159-10
A3705920001
Page 89
MODIFICATION BULLETIN NO. 39 PAGE 3 OF 3
ISSUED ON: January 31, ’96
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822
nashuatec 3522
Savin 9220
Savin 9220 115/60 USA, Canada A161-15 2A15920001
Ricoh FT4022 115/60 USA, Canada A161-17 A3645910358
Ricoh FT4022 110/60 Taiwan, Saudi A161-19
Gestetner 2822
nashuatec 3522
Rex Rotary 8622Z
Infotec 5221Z 220, 230, 240/50 Europe A161-26 3F69250001
Ricoh FT4022 220, 230, 240/50 Europe A161-27
Ricoh FT4022 220/50
Ricoh FT4022 110/60 Taiwan A161-59
115/60
220, 230, 240/50 Europe etc. A161-22 8745920001
USA, Canada,
L. America
Asia, Middle
East
A161-10 8755920001
A161-29
SERIAL
NUMBER
A364
A3645920001
A3645911176
RAI PRODUCTION
MODEL NAME V/Hz DESTINATION
CODE
Gestetner 2822td
nashuatec 3522td
Savin 9220DL
Savin 9220DL 115/60 USA, Canada A162-15 2A25910001
Ricoh FT4522 115/60 USA, Canada A162-17 A3725910041
Ricoh FT4522 110/60 Taiwan, Saudi A162-19
Gestetner 2822td
nashuatec 3522td
Rex Rotary 8622DZ
Infotec 5221DZ 220,230, 240/50 Europe A162-26 3F79250001
Ricoh FT4522 220,230, 240/50 Europe A162-27
Ricoh FT4522 220/50
Ricoh FT4522 110/60 Taiwan A162-59
115/60
220,230, 240/50 Europe, etc. A162-22 8765920001
USA, Canada,
L. America
Asia, Middle
East
A162-10 8775920001
A162-29
SERIAL
NUMBER
A372
A3725920001
A3725920436
Page 90
M. Iwasa, Manager
Technical Support Department
MODIFICATION BULLETIN NO. 40 PAGE 1 OF 1
ISSUED ON: January 31, ’96
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article
Reason for
Modification
New P/N Description Q’ty Used
A134 4670 Duplex Guide Mylar
Parts Catalog
A part number for the duplex guide mylar has been assigned as per field
request.
0 → 1
Mylar position
Feed Roller
Shaft
Parts Catalog
Index No. Page
25 53
Date of
Modification
No serial number cut-in information
Serial Number
16.2±0.3mm
The distance between the edge
of the mylar and the center of the
feed roller shaft is 16.2 ± 0.3 m m .
Mylar
Duplex Guide Mylar
Page 91
MODIFICATION BULLETIN NO. 41 PAGE 1 OF 6
ISSUED ON: February 29, ’96
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article
Reason for
Modification
Draw
No.
Old Parts
No.
Parts Catalog
Part number assignment
New Parts
No.
A1531773 Rear Scanner Stay
A1531772 Front Scanner Stay
A1535814
A1535809 Interlock Switch Arm
A1535808 Interlock Switch Bracket
A1341071 Left Grip Arm
Description Rank
Main Switch Bracket
Q’ty Used
Old→New
0 → 1
0 → 1
0 → 1
0 → 1
0 → 1
0 → 4
Date of
Modification
No serial number cut-in information
Inter-
change-
ability
See page 3 of 6 17 29
See page 4 of 6 13 67
Parts needed for replacement by new part
Part No. Description No. Page
Number
Catalog
18 29
12 67
14 67
15 67
Serial
Parts
A1341072
A1341073 Left Bracket - Grip Plate
A1533270 Toner Supply Stay
A1535806 Tray Unit Bracket
A1535807
Rank: A : Replace with new parts immediately. B : Replace with new parts at time of repair. C : Replace with new parts at time of overhaul.
Interchangeability:
(1) When old and new parts are not mutually interchangeable, use additional parts or an assembly part as indicated in "Parts needed for
replacement by new part" to install the new part.
(2) The mark to the left of the slash indicates whether the old part can be used in the new machine, and the mark to the right indicates whether
the new part can be used in the old machine. x = Not interchangeable o = Interchangeable
Right Bracket - Grip Plate
ARDF Bracket
0 → 2
0 → 2
0 → 1
0 → 1
0 → 1
See page 5 of 6 20 69
16 67
17 67
18 67
21 69
Page 92
MODIFICATION BULLETIN NO. 41 PAGE 2 OF 6
ISSUED ON: February 29, ’96
Draw
No.
Old Parts
No.
New Parts
No.
AA152334 Second Mylar
Description Rank
Q’ty Used
Old → New
0 → 1
Inter-
change-
ability
See page 6 of 6 23 39
Part needed for replacement by new part
Part No. Description No. Page
Catalog
Parts
Page 93
MODIFICATION BULLETIN NO. 41 PAGE 3 OF 6
DETAILS OF MODIFICATION
ISSUED ON: February 29, ’96
#17
Rear Scanner Stay
#18
Front Scanner Stay
Page 94
MODIFICATION BULLETIN NO. 41 PAGE 4 OF 6
DETAILS OF MODIFICATION
ISSUED ON: February 29, ’96
#12
Main Switch Bracket
#14
Interlock
Switch
Bracket
#13
Interlock
Switch Arm
#15
Left Grip Arm
#16
Right Bracket Grip Plate
#17
Left bracket Grip Plate
#18
Toner Supply Stay
#15
Left Grip Arm
Page 95
MODIFICATION BULLETIN NO. 41 PAGE 5 OF 6
DETAILS OF MODIFICATION
ISSUED ON: February 29, ’96
#20
Tray Unit Bracket
#21
ARDF Bracket
Page 96
MODIFICATION BULLETIN NO. 41 PAGE 6 OF 6
#23
Second Mylar
DETAILS OF MODIFICATION
ISSUED ON: February 29, ’96
M. Iwasa, Manager
Technical Support Department
Page 97
MODIFICATION BULLETIN NO. 42 PAGE 1 OF 1
Re-issued on: May 15, ’96
ISSUED ON: March 15, ’96
T. Inoue, General Manager
1st Field Information Dept. QAC
Model Phoenix (Falcon Swallow) Volt/Hz
Modified Article Parts Catalog No serial number cut-in information
Reason for
Part number assignment.
Modification
New P/N Description Q’ty Used
A1531850 Lens Cover
11026739 Connector - 12P
0 → 1
0 → 1
Index No. Page
22 27
111 69
Parts Catalog
Date of
Modification
Serial Number
#22 A1531850
Lens Cover
# 111 P/N 1102 6739
Connector 12P
Page 98
MODIFICATION BULLETIN NO. 44 PAGE 1 OF 2
ISSUED ON: May 15, ’96
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article
Reason for
Modification
Parts Catalog
Parts Number assignment
The part numbers for the Rubber Foot and the Auto Response Sensor have been assig ne d.
Please add these part numbers to your pa rts cat alog.
New P/N Description Q’ty Used
AH01 0007 Rubber Foot
AW01 0065
Auto Response Sensor (Falcon only)
0 → 4
0 → 1
Index No. Page
15 75
33 9
Date of
Modification
No serial number cut-in information
Parts Catalog
Serial Number
Page 99
MODIFICATION BULLETIN NO. 44 PAGE 2 OF 2
T. Inoue, General Manager
1st Field Information Dept. QAC
DETAILS OF MODIFICATION
Please correct your Swallow parts catalog page 8 as follows.
ISSUED ON: May 15, ’96
Swallow only
Change this index from 31 to 10
10
Delete this
illustration
Page 100
MODIFICATION BULLETIN NO. 45 PAGE 1 OF 1
T. Inoue, General Manager
1st Field Information Dept . QAC
ISSUED ON: May 31, ’96
Model Phoenix (Falcon, Swallow) Volt/Hz
Modified Article Paper Size Sensor Board No serial number cut-in information.
Reason for
Modification
Old P/N New P/N Description Q’ty Used
A134 5280 A134 5282 Paper Size Sensor Board
To standardize with other models, the print circuit pattern has been changed
from solder to nickel coating.
Inter-
change-
ability
1 → 1
O/O 23 13
Parts Catalog
Index No. Page
Date of
Modification
Serial Number
Loading...
