Ricoh FT5035-S PARTS CAT FT5640PC





PARTS CATALOG

PARTS CATALOG

INTRODUCTION

This chapter i nst r uct s you the numbers and n am es of parts on this machi ne.

INDEX to PARTS CATALOG

EAGLE 2 (A204/A206/A207)
FALCON 2 (A208/A210/A211)
DF64 (A663)
PS280/PS290 (A550/A549)
ST29 (A658)
ST30 (A664)
ST10 (A555)
CS220 (A556)
CS130 (A557)
SORTER ADAPER TYPE K (A568)



PARTS CATALOG

INTRODUCTION

This chapter ins tr ucts you the numbers an d names of parts on this machine.

INDEX to PARTS CATALOG

LOCATION OF UNIT ........................................................... 2

1.EXTERIOR (A204/A206/A207)......................................... 8

2.PLATEN COVER ASS’Y (A204/A206/A207).................... 10

3.OPERATION PANEL UNIT (A204/A206/A207) ............... 12

4.BY-PASS FEED SECTION (A204/A206/A207)................ 14

5.PAPER TRAY SECTION (A204/A206/A207)................... 16

6.LCT UNIT 1 (A206/A207) ................................................. 18

7.LCT UNIT 2 (A206/A207) ................................................. 20

8.PAPER FEED SECTION 1 (A204/A206/A207)................ 22

9.PAPER FEED SECTION 2 (A204/A206/A207)................ 24

10.PAPER FEED SECTION 3 (A204/A206) ........................ 26

11.PAPER REGISTRATION (A204/A206/A207).................. 28

12.OPTICAL SECTION 1 (A204/A206/A207) ...................... 30

13.OPTICAL SECTION 2 (A204/A206/A207) ...................... 32

14.OPTICAL SECTION 3 (A204/A206/A207) ...................... 34

15.OPTICAL SECTION 4 (A204/A206/A207) ...................... 36

16.TONER SUPPLY UNIT (A204/A206/A207)..................... 38

17.DEVELOPMENT UNIT (A204/A206/A207) .. ... ................ 40

18.DRUM UNIT 1 (A204/A206/A207)................................... 42

19.DRUM UNIT 2 (A204/A206/A207)................................... 44

20.TRANSFER UNIT (A204/A206/A207)............................. 46

21.FUSING UNIT 1 (A204/A206/A207)................................ 48

22.FUSING UNIT 2 (A204/A206/A207)................................ 50

23.DUPLEX TRAY 1 (A207)................................................. 52

24.DUPLEX TRAY 2 (A207)................................................. 54

25.DUPLEX TRAY 3 (A207)................................................. 56

26.DUPLEX TRAY 4 (A207)................................................. 58

27.PAPER EXIT SECTION (A204/A206/A207).................... 60

28.DRIVE SECTION 1 (A204/A206/A207)........................... 62

29.DRIVE SECTION 2 (A204/A206/A207)........................... 64

30.DRIVE SECTION 3 (A204/A206/A207)........................... 66

31.ELECTRICAL SECTION 1 (A204/A206/A207)................ 68

32.ELECTRICAL SECTION 2 (A204/A206/A207)................ 70

33.ELECTRICAL SECTION 3 (A204/A206/A207)................ 72

34.FRAME SECTION 1 (A204/A206/A207) ......................... 74

35.FRAME SECTION 2 (A204/A206/A207) ......................... 76

36.MAIN CONTROL BOARD (A204/A206/A207) ................ 78

37.DECAL AND DOCUMENT (A204/A206/A207) ............... 82

38.SPECIAL TOOLS (A204/A206/A207) ............................. 84

PARTS INDEX ..................................................................... 87

April,10’97

LOCATION OF UNIT

1. EXTERIOR (A204/A206/A207)

See Page 8

4. BY-PASS FEED SECTION
(A204/A206/A207)

2. PLATEN COVER ASS’Y (A204/A206/A207)

See Page 10

5. PAPER TRAY SECTION (A204/A206/A207)

3. OPERATION PANEL UNIT
(A204/A206/A207)

See Page 12

6. LCT UNIT 1 (A206/A207)

See Page 14

See Page 16

2

See Page 18

LOCATION OF UNIT

7. LCT UNIT 2 (A206/A207)

See Page 20

10. PAPER FEED SECTION 3 (A204/A206)

8. PAPER FEED SECTION 1 (A204/A206/A207)

See Page 22

11. PAPER REGISTRATION (A204/A206/A207)

9. PAPER FEED SECTION 2 (A204/A206/A207)

See Page 24

12. OPTICAL SECTION 1 (A204/A206/A207)

See Page 26

See Page 28

3

See Page 30

LOCATION OF UNIT

13. OPTICAL SECTION 2 (A204/A206/A207)

See Page 32

16. TONER SUPPLY UNIT (A204/A206/A207)

14. OPTICAL SECTION 3 (A2 04/ A206/A207)

See Page 34

17. DEVELOPMENT UNIT (A204/A206/A207)

15. OPTICAL SECT ION 4 ( A204/A206/A207)

See Page 36

18. DRUM UNIT 1 (A204/A206/A207)

See Page 38

See Page 40

4

See Page 42

LOCATION OF UNIT

19. DRUM UNIT 2 (A204/A206/A207)

See Page 44

22. FUSING UNIT 2 (A204/A206/A207)

20. TRANSFER UNIT (A204/A206/A207)

See Page 46

23. DUPLEX TRAY 1 (A207)

21. FUSING UNIT 1 (A204/A206/A207)

See Page 48

24. DUPLEX TRAY 2 (A207)

See Page 50

See Page 52

5

See Page 54

LOCATION OF UNIT

25. DUPLEX TRAY 3 (A207)

See Page 56

28. DRIVE SECTION 1 (A204/A20 6/A 207)

26. DUPLEX TRAY 4 (A207)

See Page 58

29. DRIVE SECTION 2 (A204/A2 06/ A207)

27. PAPER EXIT SECTION (A204/A206/A207)

See Page 60

30. DRIVE SECTION 3 (A204/ A206/A207)

See Page 62

See Page 64

6

See Page 66

LOCATION OF UNIT

31. ELECTRICAL SECTION 1 (A204/A206/A207)

See Page 68

34. FRAME SECTION 1 (A204/A206/A207)

32. ELECTRICAL SECTION 2 (A204/A206/A207)

See Page 70

35. FRAME SECTION 2 (A204/A206/A207)

33. ELECTRICAL SECTION 3 (A204/A206/A207)

See Page 72

See Page 74

See Page 76

7

1. EXTERIOR (A204/A206/A207)

8

1. EXTERIOR (A204/A206/A207)

Index
No.

1 A153 1285 Emblem (RIC) 1
1 A156 6413 Emblem (SVN) 1
1 A153 6423 Support Cover (INF) 1
2 A204 1277 Front Cover (A204)(RIC) 1
2 A204 6412 Front Cover (A204)(SVN) 1
2 A204 6422 Front Cover (A204)(INF) 1
2 A206 1277 Front Cover (A206)(RIC) 1
2 A206 6412 Front Cover (A206)(SVN) 1
2 A206 6422 Front Cover (A206)(INF) 1
2 A207 1277 Front Cover (A207)(RIC) 1
2 A207 6412 Front Cover (A207)(SVN) 1
2 A207 6422 Front Cover (A207)(INF) 1
2 A153 6403 Front Cover (NRG) 1
3 A153 1354 Hinge Pin 2
4 AG07 0004 Magnet ic C atch 2
5 A153 1360 Operating Sheet (A204/A206) 1
5 A154 1360 Operating Sheet (A207) 1
6 AG05 0074 Regist ration Knob 1
7 A153 1352 Right Lower Cover 1
8 A153 1339 Lower Inner Cover 1
9 A153 1351 Upper Inner Cover 1
10 A153 1261 Front Right Cover 1
11 AG05 0075 Mi ddle Knob 1
12 AG01 1344 Operation Panel Ass‘y - A4 (A204/A206) 1

12 AG01 1345 Operation Panel Ass’y - A4 (A207) 1
12 AG01 1340 Operation Panel Ass‘y - LT (A204/A206) 1
12 AG01 1341 Operation Panel Ass’y - LT (A207) 1
12 AG01 1350 Operation Panel Ass‘y (A204/A206)(SVN) 1
12 AG01 1351 Operation Panel Ass‘y (A207)(SVN) 1
13 A153 1469 Panel Cover 1
14 AF04 3069 Copy Tray 1
15 AF04 3076 Copy Tr ay Sl i de 1
16 AF04 3077 Copy Tr ay G ui de 1
17 A153 1301 Left Cover - A4 1
17 A153 1302 Left Cover - LT 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

18 AA14 3416 Stepped Screw - M4x3 2
19 AC04 2113 Left Original Sca l e - A4 1
19 AC04 2117 Left Original Sca l e - LT 1
20 AC01 2060 Exposure Glass - A3t-3.2 1
21 AW10 0027 Thermister 1
22 AC04 2120 Rear Original Scal e - A4 1
22 AC04 2124 Rear Original Scal e - LT 1
23 AA14 3417 Shoulder Screw - M4x4 2
24 A153 1251 Upper Cover 1
25 A204 1291 Rear Cover 1
26 AA01 2080 Dust Filter 1
27 A155 1331 LCT Rear Right Cover 1
27 A153 1271 Rear Right Cover 1
28 AA00 1373 Decal - Main Switch 1
29 A134 1328 Small Cap 1
30 A153 1478 Decal - 10key Zoom - A4/A3 1
30 A153 1475 Decal - 10key Zoom - l T/ D LT 1
31 A153 1476 Decal - Margin Adjustment - LT/DLT 1
31 A153 1479 Decal - Margin Adjustment - A4/A3 1
32 A204 1486 Operation Panel Sheet - LT (A204/A206) 1
32 A204 1487 Operation Panel Sheet - A4 (A 204/A206) 1
33 C225 2867 Decal - Cover - Panel - Nashua 1
33 C225 2866 Decal - Key Top Cover 1
33 A153 6409 Decal - Keytop Cove r 1
34 AW01 0065 Auto R esponse Sensor 1
35 A204 6404 Decal - Model Name - GES ( A204) 1
35 A204 6407 Decal - Model Nam e - NST (A204) 1
35 A204 6414 Decal - Model Name - REX (A 204) 1
35 A206 6404 Model Name Plate - GES (A206) 1
35 A206 6407 Model Name Plate - NST (A206) 1
35 A206 6414 Model Name Plate - REX (A206) 1
35 A207 6404 Model Name Plate - GES (A207) 1
35 A207 6407 Model Name Plate - NST (A207) 1
35 A207 6414 Model Name Plate - REX (A207) 1
36 AA00 1389 Large Decal - Energy Star 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0951 4016B Philips Screw With Flat Washer - M4
102 0964 4008B Tapping Screw Wit h Flat Washer-m4x8
103 0802 5094 Tapping Truss Head Screw - M4x8
104 0313 0040B Philips Pan Head Screw - M3x4
105 0953 4008M Screw - M4X8
106 0951 3006B Philip s Screw With Flat Washer-m3x6

Part No.

Description

Q’ty Per
Assembly

Index
No.

Part No.

Description

Q’ty Per
Assembly

9

2. PLATEN COVER ASS’Y (A204/A206/A207)

10

2. PLATEN COVER ASS’Y (A204/A206/A207)

Index
No.

1 A153 1369 Platen cover Ass’y 1
2 5448 2804 Platen Cover Sheet 1
3 A153 1370 Platen Cover Hinge 1
4 A134 1394 Front Platen Cover 1
5 A053 1957 Flex Hing e - Plat en Cover 2
6 AA16 2067 Platen Cover Pad 1
7 A134 1395 Rear Platen Cover 1
8 A134 1396 Original Holder 1
9 A153 1383 Platen Cover Feeler 1
10 AA14 8447 Guide Pin - Platen C over 2
11 A153 1380 Platen Cover Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0414 0142B Binding Self Tapping Scre w - M4x14

Part No.

Description

Q’ty Per
Assembly

11

3. OPERATION PANEL UNIT (A204/A206/A207)

12

3. OPERATION PANEL UNIT (A204/A206/A207)

Index
No.

*AG01 1344 O peration Panel Ass‘y - A4 (A204/A206) 1
*AG01 1345 Operation Panel Ass’y - A4 (A207) 1
*AG01 1340 Operation Panel Ass‘y - LT (A204/A206) 1
*AG01 1341 Operation Panel Ass’y - LT (A207) 1
*AG01 1350 Operation Panel Ass‘y (A204/A206) (SVN) 1
*AG01 1351 Operation Panel Ass‘y (A207) (SVN) 1
1 AW01 0073 Optics Sensor 1
2 A153 1452 Key-top Start 1
2 A156 1452 Key-top Start (SVN) 1
3 A153 1453 Key-top Interrupt 1
3 A156 1453 Key-top Interrupt (SVN) 1
4 A153 1454 Key-top Mode Clear 1
4 A156 1454 Key-top Mode Clear (SVN) 1
5 A153 1455 Key-top Program 1
5 A156 1455 Key-top Program (SVN) 1
6 A153 1456 Key-top 10 Key 1
6 A156 1456 Key-top 10 Key (SVN) 1
7 A153 1457 Key-top Cler/Stop 1
7 A156 1457 Key-top Cler/Stop (SVN) 1
8 A153 1458 Key-top Auto Density 1
8 A156 1458 Key-top Auto Density (SVN) 1
9 A153 1459 Key-top Darker 1
9 A156 1459 Key-top Darker (SVN) 1
10 A153 1460 Key-top Lighter 1
10 A156 1460 Key-top Lighter (SVN) 1
11 A153 1461 Key-top Auto Paper Select 1
11 A156 1461 Key-top Auto Paper Select (SVN) 1
12 A153 1462 Key-top Paper Select 1
12 A156 1462 Key-top Paper Select (SVN) 1
13 A153 1463 Key-top Full Size 1
13 A156 1463 Key-top Full Size (SVN) 1
14 A153 1464 Key-top Auto Reduce/Enlarge 1
14 A156 1464 Key-top Auto Reduce/Enlarge (SVN) 1
15 A153 1469 Panel Cover 1
16 A154 5458 IC - Operation (A207) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

17 A204 1486 Operation Panel Sheet - LT (A204/A206) 1
17 A204 1487 Operation Panel Sheet - A4 (A 204/A206) 1
18 A156 5462 Guidance Board (A 207) 1
19 A204 1471 Keytop - Halftone 1
19 A207 1471 Keytop - Halftone (SVN) 1
20 A204 1472 Keytop - Enlarge 1
20 A207 1472 Keytop - Enlarge (SVN) 1
21 A204 1473 Keytop - Reduce 1
21 A207 1473 Keytop - Reduce (SVN) 1
22 A204 1475 Operation Pane l Ca se - L T 1
22 A204 1476 Operation Panel Ca se - A4 1
23 A204 1481 Sheet - LT 1
23 A204 1482 Sheet - A4 1
24 A204 1477 Display Panel - LT (A204/A206) 1
24 A204 1478 Display Panel - A4 (A204 /A2 06) 1
24 A207 1477 Display Panel - LT (A207) 1
24 A207 1478 Display Panel - A4 (A207 ) 1
25 A204 1465 Key-top - Sorter 1
25 A207 1465 Key-top - Sorter (SVN) 1
26 A206 5465 Operation Panel Boar d - A4 ( A204/A206) 1
26 A206 5460 Operation Panel Boar d - LT (A204/A206) 1
26 A207 5466 Operation Panel Boar d - A4 ( A207) 1
26 A207 5461 Operation Panel Boar d - LT (A207) 1
27 A207 1467 Paper Exit Sheet - LT (A207) 1
27 A207 1480 Paper Exit Sheet - A4 (A207) 1
27 A204 1480 Sorter Sheet - A4 (A204/A206) 1
27 A204 1479 Sheet Sorter - LT (A204/A206) 1
28 A205 5831 Grounding Plate(A4)(A207) 1

101 0802 5094 Tapping Truss Head Screw - M4x8
102 0964 4 006B Tapping Screw With Flat Washer-m4x6

Part No.

Description

Q’ty Per
Assembly

13

4. BY-PASS FEED SECTION (A204/A206/A207)

14

4. BY-PASS FEED SECTION (A204/A206/A207)

Index
No.

1 A134 2586 Hinge Bracket (A204) 1
2 A134 2591 Vertical Transfer (A204) 1
3 A134 5316 Vertical Transfer Harness (A204) 1
4 A134 2587 Switch Bracket (A204) 1
5 AG07 0004 Magnet ic C atch (A204) 1
6 A134 2585 Vertical Transfer Guide Pl at e ( A 204) 1
7 AA08 0034 Bushing - 4x5x7 (A204) 4
8 AA06 3538 Spring - 10mm (A204) 4
9 AF02 0330 Vertic a l Driven Roller (A204) 2
10 AW02 0069 Photointerruptor (A204) 2
11 5447 2681 Sna p R i ng ( A 204) 1
12 5215 2621 Sna p R i ng - M6 1
13 A134 2692 By-pass Feed Table Ass’y 1

14 A134 2741 By-pass Feed Entrance Guide 1

15 5447 2927 Frict ion Pad - B 1

16 A134 2721 Front Paper Guide 1
17 A134 2711 Front Side Fence 1
18 A134 2726 Rear Paper Guide 1
19 A134 2716 Rear Side Fence 1
20 A134 2701 By-pass Feed Guide 1
21 A134 2697 By-pass Feed Table 1
22 A134 2705 Magnet Catch Plate 1
23 A134 5282 Paper Size Sensor Board 1
24 A134 2706 Rear Fence Rack 1
25 G011 3305 Gear - 16T 2
26 A134 2707 Front Fence Rack 1
27 A134 2746 By-pass Feed Cover 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1204 2356 Micro Switch - Am51612a531
102 0414 0082W Tapping Screw Wi t h Fl at Washer-m4x8
103 0802 5085 Tapping Screw - M4x8
104 0720 0030E Retaining Ring - M3
105 0965 3006B Tapping Screw Wit h Flat Washer M3x6
106 0313 0140B Philip s Pan Head Screw - M3x14

Part No.

Description

Q’ty Per
Assembly

15

5. PAPER TRAY SECTION (A204/A206/A207)

16

5. PAPER TRAY SECTION (A204/A206/A207)

Index
No.

1 A134 2956 Paper Feed Front Cover 1
2 A134 2997 Decal - Paper Setting 1
3 AF01 6084 Front Side Fence 1
4 A134 2976 Stopper Lever 1
5 A134 2978 Spring Plate 1
6 A153 2991 Front Side Fence Guide 1
7 AF01 7012 End Fence 1
8 A204 2953 Paper Tray 1

9 AF01 3014 Bottom Plate Pad 1

10 A048 2838 Nylon Rivet 2
11 AF01 6085 Rear Side Fence 1
12 A153 2992 Rear Side Fence Guide 1
13 AF01 5027 Paper Size Slider 1
14 AB01 3868 Gear - 16Z 1
15 A134 2968 Grounding Plate 1
16 A204 2972 Bottom Lift Lever 1
17 A204 2971 Bottom Lift Shaft 1
18 A134 2986 Bottom Plate 1
19 A153 2995 Decal Paper Size - LT 1
19 A153 2996 Decal Paper Size - A4 1
20 A134 2952 Universal Tray 1
21 A134 2960 Paper Tray Stopper 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0965 4008B Tapping Screw - M4 X 8
102 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
103 0720 0060E Retaining Ring - M6
104 0344 0060F Philips Truss Head Screw - M4x6

Part No.

Description

Q’ty Per
Assembly

17

6. LCT UNIT 1 (A206/A207)

18

6. LCT UNIT 1 (A206/A207)

Index
No.

1 A155 6324 End Fence 1
2 A155 6113 Decal - Paper Set 1
3 A155 6207 Cover Bracket 1
4 A155 6303 Fix Hinge 1
5 A155 6302 Hinge Angle 1
6 A155 6101 LCT Upper Cover 1
7 A335 3251 Top Cover Hinge 1
8 A155 6201 LCT Hinge Bracket 1
9 A155 6251 Upper Stay 1
10 A155 6312 Rear Paper Holder 1
11 A155 6313 Support Guide 2
12 A155 6307 Rear Side Fence 1

13 A421 2543 Friction Pad 1

14 A155 6142 LCT Paper Tray 1
15 A155 6221 LCT Rear Cover 1
16 A155 6231 LCT Right Cover 1
17 A155 6191 LCT Front Cover 1
18 A155 6181 Knob 1
19 A155 6171 Grip Bracket 1
20 AA06 3239 Spring - Handle 1
21 A155 6170 Hinge Bracket 1
22 A155 6306 Front Side Fence 1
23 A155 6311 Front Paper Holder 1
24 A155 6321 Front Spring Plate 1
25 A155 6322 Rear Sprig Plate 1
26 A155 6241 LCT Harness Cover 1
27 A155 6151 Vertical Transport G ui de 1
28 AW02 0069 Photointerruptor 1
29 A155 6152 Switch Bracket 1
30 A155 6169 Hinge Holder 1
31 A155 6160 Lower Hinge 1
32 A155 6175 LCT Positioning Plat e 1
33 A155 5349 LCT Vertical Harness 1
34 A155 6162 Cushion 1
35 A155 6114 Caution Decal - LCT 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 AF02 0330 Vertical Driven Roller 6
37 AA08 0034 Bushing - 4x5x7 6
38 A155 6112 Spacer - LCT 1
39 A155 6270 Cushion 20 X 30 1

101 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
102 0414 0080B Binding Self-tappin g Screw - M4x8
103 0802 5094 Tapping Truss Head Screw - M4x8
104 1204 2356 Micro Switch - Am51612a531
105 0433 0140B Pan Head Self-tapping Screw - M3x14

Part No.

Description

Q’ty Per
Assembly

19

7. LCT UNIT 2 (A206/A207)

20

7. LCT UNIT 2 (A206/A207)

Index
No.

1 A155 6143 Left Bracket 1
2 A155 6148 Paper End Sensor Feeler 1
3 A155 6147 Paper End Sensor Bracket 1
4 A155 5348 Paper End Sensor Harness 1
5 A155 6203 Paper Tray Stay 1
6 A155 6153 Upper Hinge 1
7 AW02 0075 Photointerrupter 1
8 AX05 0090 Motor - DC 24v 36w 1
9 AB03 0281 Timing Pulley - 28Z 4
10 A335 4351 Guide Roller 2
11 A155 6136 Lift Sensor Bracket 1
12 AA04 3456 Timing Belt - S3M167 2
13 5925 2258 Stopper Chain 1
14 AB01 1133 Gear - 49Z 1
15 AA14 0576 LCT Drive Shaft 1
16 AG07 0004 Magnetic Catch 1
17 A155 6141 Tray Bottom Plate 1
18 A155 5165 LCT Main Board 1
19 A155 6145 Tray Cover 1
20 A155 6118 Spring Plate 1
21 A155 6116 Safety Switch Bracket 1
22 A300 3155 Stepped Screw - M25x32 1
23 A155 6117 Safety Switch Lever 1
24 A155 5314 LCT Relay Harness 1
25 A335 4352 Timing Belt Clamp 2
26 5053 0223 Bushing - 8mm 2
27 A155 5170 Push Switch 1
28 A155 6125 Rear Side Bracket 1
29 A155 6110 Front Side Plate - LCT 1
30 A155 6215 Harness Guide 1
31 A155 5342 LCT Harness 1
32 A335 1341 Chain Hook 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
102 0802 5236 Binding Self-tapping Screw - M4x8
103 0443 0060B Hexagon Tapping Screw - M3x6
104 0720 0060E Retaining Ring - M6
105 1204 2355 Micro Switch - Am51632a531
106 0623 0160E Spring Pin - 3x16mm
107 1105 0196 Harness Clamp
108 1105 0197 Wire Saddle
109 1105 0192 Locking Support

Part No.

Description

Q’ty Per
Assembly

21

8. PAPER FEED SECTION 1 (A204/A206/A207)

22

8. PAPER FEED SECTION 1 (A204/A206/A207)

Index
No.

*A206 2651 Bypass Feed Unit 1
1 A134 2688 Positi oning Plate 1
2 A134 2660 Paper Feed Feeler 1
3 A134 2661 Feeler Roller 1
4 A134 2670 By-pass Feed Cover 1
5 A134 2658 Grounding Plate 1
6 A134 2656 Stopper Plate 1

7 AF03 1025 Feed Roller 1

8 5447 2681 Snap Ring 3
9 AB01 1343 Idle Gear - 23z 1

10 AF03 0024 Pick-up Roller 1

11 AA14 0534 Feed Shaft (A204) 1
11 AA14 0575 Paper Feed Shaft (A206/A207) 1
12 AX20 0101 Magnetic Clutch - 2.5kgf 35 z 1
13 AA08 3010 Clutch Roller - 6x14x10 1
14 A134 5311 By-pass Feed Harness 1
15 A134 2659 By-pass Feed Housing 1
16 AW02 0075 Photointerrupter 1
17 AW50 0012 Push Switch 1
18 A134 2662 Grounding Plate 1
19 A153 2560 Rear Guide Plate 1
20 A134 2663 Separation Guide 1

21 AF03 2025 Separation Roller 1
22 A134 2674 Torque Limitter - 400fg (A204) 1

22 A206 2804 Torque-limiter (A206/A207) 1
23 A134 2668 Separation Driven Shaft 1
24 AA08 0037 Bushing - 6 Mm 1
25 AA06 3499 Pressure Spring 1
26 A134 2689 Gear Cover 1
27 AB01 1344 Gear - 16Z 1
28 AB01 1345 Gear - 20Z 1
29 A134 2667 Separation Drive Shaft 1
30 A134 2654 Pick-up Arm 1
31 AB01 1346 Gear - 27Z 1
32 A155 2682 Lift Sensor Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

33 A155 5345 Ct Harness 1
34 A155 2667 Lift Sensor Feeler 1
35 AA14 3219 Stepped Screw 2

101 0720 0040E Retaining Ring - M4
102 0805 3480 Bushing - 6mm
103 0414 0080B Binding Self-tappin g Screw - M4x8
104 0622 0100E Spring Pin - 2x10mm
105 0802 5237 Binding Self-tapping Screw - M4x10
106 0434 0060B Pan Head Self-tapping Screw - M4x6

Part No.

Description

Q’ty Per
Assembly

23

9. PAPER FEED SECTION 2 (A204/A206/A207)

24

9. PAPER FEED SECTION 2 (A204/A206/A207)

Index
No.

*A204 2850 Lower Paper Feed Unit 1
1 A134 2839 Reverse Guide Plate 1
2 5447 2681 Snap Ring 3

3 AF03 0025 Pick-up Feed Roller 1

4 5447 2706 Gear - 15T 1
5 A204 2860 Pickup Arm 1
6 AA14 0542 Feed Roller Shaft 1
7 A130 2876 Paper End Sensor Bracket 1
8 AW02 0075 Photointerrupter 2
9 A134 2873 Positioning Sensor Bracket 1
10 AA06 0577 Release Spring 1
11 A134 2866 Pick-up Solenoid 1
12 AA08 3009 Clutch Roller - 8x18x11 1
13 AA08 2046 Bushing - 6x12x6 3
14 AB03 0466 Timing Pulley - 20Z 1
15 A134 2826 Rear Side Plate 1
16 A134 2855 Lower Feed Stay 1
17 A134 2862 Paper End Sensor Feeler 1
18 AA06 0523 Pick-up Pressure Sping 1
19 A134 2863 Paper End Sensor Lever 1
20 AA08 2047 Bushing - 8x16x7 2
21 A134 2830 Drive Shaft 1
22 AB01 3420 Gear - 18Z 2
23 A134 2832 Driven Shaft Ass’y 1

24 A134 2885 Torque Limitter 1

25 AF03 2027 Separation Roller 1

26 A134 2790 Reverse Stay 1
27 A134 2795 Pressure Lever 1
28 AA06 0636 Pressure Spring 1
29 AF02 0322 Lower Drive Roller - Transport 1
30 AA06 0575 Release Spring 1
31 A134 2810 Release Solenoid 1
32 AF02 0329 Relay Roller 1
33 AA08 0156 Bushing - M4 2
34 AA06 3487 Spring - 10mm 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

35 A134 2834 Vertical Transport G ui de 1
36 A134 5315 Relay Harness - Lo w er Paper Feed 1
37 A134 2846 Lower Guide Plate 1
38 A134 2821 Front Side Plate 1

39 AF03 1026 Paper Feed Roller 1

40 A134 2868 Solenoid Bracket 1

101 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
102 0720 0040E Retaining Ring - M4
103 0720 0030E Retaining Ring - M3
104 0805 0088 Retaining Ring - M6
105 0720 0060E Retaining Ring - M6
106 0742 3808 Ball Bearing - 8x 16x5
107 0353 0040B Screw - M3X4
108 1105 0199 Clamp

Part No.

Description

Q’ty Per
Assembly

25

10. PAPER FEED SECTION 3 (A204/A206)

26

10. PAPER FEED SECTION 3 (A204/A206)

Index
No.

*A204 2800 Upper Paper Feed Unit 1
1 A134 2839 Reverse Guide Plate 1
2 5447 2681 Snap Ring 3

3 AF03 0025 Pick-up Feed Roller 1

4 5447 2706 Gear - 15T 1
5 A134 2654 Pick-up Arm 1
6 AA14 0542 Feed Roller Shaft 1
7 A130 2876 Paper End Sensor Bracket 1
8 AW02 0075 Photointerrupter 2
9 A130 2871 Sensor Bracket 1
10 AA06 0577 Release Spring 1
11 A134 2866 Pick-up Solenoid 1
12 AA08 3009 Clutch Roller - 8x18x11 1
13 AA08 2046 Bushing - 6x12x6 2
14 AB03 0466 Timing Pulley - 20Z 1
15 A130 2824 Rear Upper Side Plate 1
16 A130 2850 Upper Feed Stay 1
17 A134 2862 Paper End Sensor Feeler 1
18 AA06 0523 Pick-up Pressure Sping 1
19 A134 2863 Paper End Sensor Lever 1
20 AA08 2047 Bushing - 8x16x7 2
21 A134 2830 Drive Shaft 1
22 AB01 3420 Gear - 18Z 2
23 A134 2832 Driven Shaft Ass’y 1

24 A134 2885 Torque Limitter 1

25 AF03 2027 Separation Roller 1

26 A134 2790 Reverse Stay 1
27 A134 2795 Pressure Lever 1
28 AA06 0636 Pressure Spring 1
29 AF02 0321 Paper Feed Drive Roller 1
30 AA06 0575 Release Spring 1
31 A134 2810 Release Solenoid 1
32 AF02 0329 Relay Roller 1
33 AA08 0156 Bushing - M4 2
34 AA06 3487 Spring - 10mm 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

35 A134 2834 Vertical Transport G ui de 1
36 A130 5314 Relay Harness - Pap er Feed 1
37 A130 2845 Upper Guide Plate 1
38 A130 2820 Front Upper Side Plate 1

39 AF03 1026 Paper Feed Roller 1

40 A134 2868 Solenoid Bracket 1

101 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
102 0720 0040E Retaining Ring - M4
103 0720 0030E Retaining Ring - M3
104 0805 0088 Retaining Ring - M6
105 0720 0060E Retaining Ring - M6
106 1105 0199 Clamp

Part No.

Description

Q’ty Per
Assembly

27

11. PAPER REGISTRATION (A204/A206/A207)

28

11. PAPER REGISTRATION (A204/A206/A207)

Index
No.

1 AG05 0075 Middl e Knob 1
2 AG05 0074 Regist ration Knob 1
3 AB01 3485 Gear - 20Z 1
4 5474 2152 Bushing - 8x12x12mm 2
5 AA06 3539 Spring - Registration Ro ll er 2
6 AA08 0172 Bushing 1
7 AA08 0171 Bushing 1
8 A153 3095 Development Rail 1
9 A204 2101 P.T.L. Lamp Ass‘y 1

10 A153 3114 Transfer Entrance Guide 1
11 AB01 3486 Gear - 14Z 1
12 AF02 1052 Upper Registration Roller 1
13 AF02 0316 Lower Registration Roller 1
14 A134 2557 Regist Sensor Bracket 1
15 AW02 0068 Photointerruptor 1
16 A153 5333 Ct Harness 1
17 A134 2580 Vertical Transfer Hunge (A204) 1
18 A153 2563 Middle Guide Plate 1
19 A153 2558 Upper Registration Guide 1
20 A134 2895 Vertical Relay Gu id e 1
21 AA08 3009 Clutch Roller - 8x18x11 (A2 07) 1
22 A134 2900 Duplex Stay (A207) 1
23 AA08 2047 Bushing - 8x16x7 (A207) 9
24 AF02 0321 Paper Feed Drive Roller (A207) 1
25 A134 2903 Upper Guide Plate - Duplex Feed (A207) 1
26 A204 2904 Lower Guide Plate - Duplex Feed (A207) 1
27 A134 2582 Sensor Bracket - Vertical Transfer (A204) 1
28 A134 2554 Lower Registrat i on G u ide 1
29 A155 6164 Positioning Guide 1
30 A155 6168 Vertical Support Guide 1
31 A153 3110 Upper Resist Guide Pla te 1
32 AB03 0466 Timing Pulley - 20Z 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0951 3006B Philips Screw With Flat Washer-m3x6
102 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
103 0720 0060E Retaining Ring - M6
104 0720 0040E Retaining Ring - M4
105 0313 0040B Philips Pan Head Screw - M3x4
106 0414 0080B Binding Self-tapping Screw - M4x8

Part No.

Description

Q’ty Per
Assembly

29

12. OPTICAL SECTION 1 (A204/A206/A207)

30

12. OPTICAL SECTION 1 (A204/A206/A207)

Index
No.

1 A204 1840 Lens Magnification Unit 1
2 AA15 0369 Original Sensor Seal 1
3 AA15 1941 Right Shield - Development Case 1
4 AA15 0368 Shielding Plate - Lens C over 1
5 AW01 0068 Original Length Sensor 2
6 A153 1961 Lens Cover 1
7 A111 1753 Seal - 0.1x18x49 1
8 A153 1971 Original Sensor Bracket 1
9 A153 5392 Optical Harness - 2 1
10 A153 5391 Optical Harness - 1 1
11 A204 1844 Lens Drive Unit 1
12 AA15 2330 Magnification Seal 2
13 AW02 0075 Photointerrupter 3
14 AB03 2059 Driven Pulley 2
15 A153 5395 Optical Harness - 5 1
16 A153 5141 Lens Drive Harne ss 1
17 A069 1883 Shoe - Scanner 2
18 A204 5212 Lens Drive Motor - D C2 4V 38W 1
19 AB01 7360 Gear Pulley 1
20 AA05 0086 Lens Drive Wire - Horizonta l 1
21 AB01 7361 Gear - 24Z/56Z 1
22 A153 1850 Lens Cover 1
23 A153 1974 Original Sensor She adi ng Plate 1
24 A153 1861 Harness Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0802 5237 Binding Self-tapping Screw - M4x10
102 0413 0062B Tapping Screw - M3x6
103 0802 5232 Binding Self-tapping Screw - M3x8
104 0951 4006B Philips Screw With Washer - M4x6
105 0965 3008W Tapping Screw Wi t h Fl at Washer-m3x8
106 0720 0040E Retaining Ring - M4
107 0414 0080B Binding Self-tapping Screw - M4x8

Part No.

Description

Q’ty Per
Assembly

31

13. OPTICAL SECTION 2 (A204/A206/A207)

32

13. OPTICAL SECTION 2 (A204/A206/A207)

Index
No.

1 A204 1790 Scanner Unit -97V 310W (120V) 1
1 A204 1770 Scanner Unit - 85V 310W (230V) 1
2 AC03 5022 Rear Mirror Clamp - 1st M i rr or 2
3 A069 1883 Shoe - Scanner 4
4 A153 1776 Front Mirror Clamp - 1st Mirror 1
5 A077 1673 Thermofuse Terminal 1
6 A153 1777 Front Terminal 1
7 AX53 0014 Exposure Lamp - 85V 310 W ( 230V) 1
7 AX53 0015 Exposure Lamp - 97V 310 W ( 120V) 1
8 A085 1670 Exposure Adjust i ng Plate 4
9 A153 1778 Rear Terminal 1
10 A153 1780 Exposure Lamp Harness 1
11 A153 1749 Scale Bracket 1
12 AW10 0027 Thermister 1
13 AC03 0103 1st Mirror 1
14 A153 1754 Exposure Stay 4
15 A153 1779 Thermostat - 121°C 250V 10A 1

16 A153 1781 Reflector 2
17 A096 1873 Scanner Shoe Pin 4
18 A153 1772 Stay Scanner Front 1
19 A153 1773 Stay Scanner Rear 1
20 A153 1774 Reflector - Main 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0951 3006B Philips Screw With Flat Washer - M3x6
102 0414 0082W Tapping Screw Wi t h Fl at Washer - M4x8
103 0413 0062W Tapping Screw - M 3x6
104 0413 0050Z Tapping Screw - M3x5
105 0413 0060W Tapping Screw - M 3x6
106 0964 4008B Tapping Screw Wit h Flat Washer - M4x8
107 0313 0040B Philips Pan Head Screw - M3x4
108 0313 0060B Philips Pan Head Screw - M3x6
109 0314 0060B Philips Pan Head Screw - M4x6
110 0703 0030M Spring Washer - M3

Part No.

Description

Q’ty Per
Assembly

33

14. OPTICAL SECTION 3 (A204/A206/A207)

34

14. OPTICAL SECTION 3 (A204/A206/A207)

Index
No.

1 A096 1873 Scanner Shoe Pin 4
2 A153 1807 Harness Guide 1
3 A153 1808 2nd Mirror 1
4 A077 1690 Spring Plate - Mirror 8
5 A153 1805 Front Mirror Holder 1
6 A069 1883 Shoe - Scanner 4
7 A153 1806 Rear Mirror Holder 1
8 A153 1801 2nd Scanner Ass’y 1

9 A153 1809 3rd Mirror 1
10 A153 1721 Spring Plate 2
11 AW01 0040 Original Sensor 1
12 A153 1720 Scanner Rail 2
13 AW02 0022 Photointerruptor 1
14 A204 1977 Density Sensor Cover 1
15 A204 1976 Density Sensor Case 1
16 AC03 0106 4/5 Mirror 2
17 A153 1908 Shielding Plate 1
18 A204 5160 ADS Sensor Board 1
19 A153 1914 3rd Scanner Rack 1
20 A153 1906 Adjust Shoe 1
21 AA06 3523 Adjust Spring 1
22 AX40 0047 Anticondensation Heater - 11 5V 15W (Option) 1
22 AX40 0048 Anticondensation Heater - 24 0V 15W (Option) 1
23 A153 5393 Optical Harness - 3 1
24 A153 9513 Harness - ADS (Option) 1
25 A153 3590 Density Sensor Bracket 1
26 A153 1912 3rd Scanner Stay 1
27 A096 5230 ADS Board (Option) 1
28 A153 1981 Scanner Home Sensor Bracket 1
29 A096 1692 ADS Case (Option) 1
30 A096 1693 ADS Cover (Option) 1
31 A153 1903 3rd Scanner Ass’y 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0314 0100B Philips Pan Head Screw - M4x10
102 0443 0080W Hexagon Head T apping Screw - M3x8
103 1105 0231 Clamp
104 0414 0080B Binding Self-tappin g Screw - M4x8
105 0951 3005B Philips Screw With Flat Washer
106 0802 5231 Binding Self-tapping Screw - M3x6
107 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
108 1105 0196 Harness Clamp

Part No.

Description

Q’ty Per
Assembly

35

15. OPTICAL SECTION 4 (A204/A206/A207)

36

15. OPTICAL SECTION 4 (A204/A206/A207)

Index
No.

1 AA04 3387 Timing Belt - 40S2M984 2
2 AA04 3386 Timing Belt - 40S2M122 4 2
3 AB03 3069 Timimng Pulley - 22z/44z 2
4 AA14 0599 Scanner Drive Shaft 1
5 A153 5213 Lens Drive Motor - DC24V 8.6 W 1
6 A153 1708 Tension Bracket - Short 2
7 AB01 7362 Gear - 25Z/32Z 1
8 AB01 7360 Gear Pulley 1
9 AB03 0486 Timing Pulley - 24Z 1
10 A153 5803 Upper Bracket - DC Drive Boar d 1
11 AA04 3388 Timing Belt - 60S2M180 1
12 AA06 0595 Tension Spring 5
13 A153 1700 Scanner Drive Motor - DC 2. 3V 13.5W 1
14 A153 1707 Tension Bracket - Long 2
15 AB03 0489 Timing Pulley - 22Z 2
16 AB03 0487 Timing Pulley - 44Z 2
17 AB01 7129 Gear - 20Z AND 72Z 1
18 AB01 7361 Gear - 24Z/56Z 1
19 A077 1690 Spring Plate - Mirror 2
20 AC03 0107 6th Mirror 1
21 A153 1952 Magnification Rail 1
22 A075 1766 Adjusting Cam 1
23 AB03 2059 Driven Pulley 1
24 A153 1947 Magnification Drive Unit Barcket 1
25 A153 5211 Mirror Drive Mot or - DC24V 8.6V 1
26 AA05 0087 Lens Drive Wire - Vertical 1
27 A153 1923 6th Mirror Bracket 1
28 A048 1801 Mirror Seal 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0573 0100E Hexagon Headless Set Screw - M3x10
102 0720 0040E Retaining Ring - M4
103 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
104 0951 4008B Philips Screw With Washer - M4x8
105 0574 0050E Hexagon Headless Set Screw - M4x5
106 0720 0060E Retaining Ring - M6
107 0740 3008 Ball Bearing - 8x 22x7
108 1105 0230 Clamp
109 0951 4006B Philips Screw With Washer - M4x6
110 0433 0060W Tapping Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

37

16. TONER SUPPLY UNIT (A204/A206/A207)

38

16. TONER SUPPLY UNIT (A204/A206/A207)

Index
No.

*A204 3150 Toner Bottle Drive (RIC NA) 1
*A204 3151 Toner Bottle Drive (RIC EU) 1
*A204 3153 Toner Bottle Drive (Other s) 1
1 A153 3187 Toner Supply Gear (RIC NA) 1
1 A153 3185 Toner Supply Gear (RIC EU) 1
1 A153 3189 Toner Supply Gear (Others) 1
2 AA15 1894 Seal - 67x53x2 1
3 A134 3180 Bottle Chuck 1
4 A134 3177 Toner Slider 1
5 AA14 3712 Chuck Shaft 1
6 A134 3181 Chuck Roller 1
7 A134 3179 Chuck Shaft 1
8 AA06 3366 Chuck Spring 1
9 A134 3215 Rubber Cap 1
10 A134 3190 Toner Bottle Stopper 1
11 AA14 3410 Stepped Screw - M4 1
12 AA06 3367 Pressure Spring 1
13 A134 3197 Bottle Holder 1
14 A204 3281 Bottle Bracket Cover 1
15 A134 3172 Toner Bottle Holder 1
16 A153 3173 Shutter Guide 1
17 AA06 6260 Shutter Spring 1
18 A153 3174 Shutter Holder 1
19 A153 3172 Shutter 1
20 AA15 0377 Shutter Seal 1
21 A153 3272 Hinge Slide Rail 1
22 AA06 6284 Torsion Spring 1
23 A134 3162 DC Motor - DC24V 5.85W 1
24 AB01 7347 Idle Gear 1
25 AA14 8413 Idle Gear Shaft 1
26 A134 3161 Bottle Drive Bracket 1
27 A217 3157 Toner Bottle Bracket 1
28 AA15 0234 Mylar Seal - Base 1
29 A204 3261 Release Bracket 1
30 A153 3266 Bottle Unit Link Plate 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

31 AA06 0453 Relay Adjusting Spring 1
32 A134 3201 Cam - Toner Bottle 1
33 A153 3264 Bottle Unit Upper Hi nge 1
34 AA14 3459 Knob Serew 1

101 0323 0060B Philips Sunk Screw - M3x6
102 0433 0050B Pan Head Self-tappin g Scr ew - M3x5
103 0802 5231 Binding Self-tapping Screw - M3x6
104 0413 0102B Tapping Screw - M3x10
105 0800 0072 Philips Pan Head Screw - M2.6x4
106 0720 0040E Retaining Ring - M4
107 0725 0100E Retaining Ring C - M10
108 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
109 1105 0199 Clamp

Part No.

Description

Q’ty Per
Assembly

39

17. DEVELOPMENT UNIT (A204/A206/A207)

40

17. DEVELOPMENT UNIT (A204/A206/A207)

Index
No.

*A204 3051 Development Unit 1
1 A153 3075 Entrance Seal 1
2 AA15 0382 Entrance Seal 4
3 A204 3200 Toner Hopper Ass’y 1

4 AA15 1935 Seal - 38x32x2.5 1
5 AW23 0009 Toner End Sensor 1
6 A153 5330 Ct Harness - 7p 1
7 AW23 0008 Toner Density Sensor 1
8 AA08 0188 Bushing - 5mm 1
9 AB01 3343 Gear - 22Z 1
10 AB01 3909 Idle Gear 1
11 AB01 3911 Gear 1
12 AA08 0186 Bushing - 6mm 1
13 AD03 7045 Toner Collection Coil 1
14 AB01 7366 Paddle Gear 1
15 G012 3897 Relay Harness - Toner End Sen sor 1
16 A153 3090 Development Positi on Plate 1
17 A153 3149 Knob Screw - M4x12 1

18 A204 3080 Development Filter 1

19 AB01 7367 Right Paddle Roller 1
20 AA15 0231 Seal - 15x30 1
21 AB01 7365 Coupled Gear - 15z/22z 1
22 AB01 3914 Gear - 17Z 1
23 AB01 3915 Gear - 26Z 1
24 AA06 6246 Spring 1
25 A153 3227 Toner End Sensor Cover 1
26 AA15 2334 Second Mylar 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0802 5231 Binding Self-tapping Screw - M3x6
102 0314 0060B Philips Pan Head Screw - M4x6
103 1105 0199 Clamp
104 0720 0060E Retaining Ring - M6
105 0720 0040E Retaining Ring - M4
106 0720 0030E Retaining Ring - M3
107 0452 3010B Tapping Screw - M3x10

Part No.

Description

Q’ty Per
Assembly

41

18. DRUM UNIT 1 (A204/A206/A207)

42

18. DRUM UNIT 1 (A204/A206/A207)

Index
No.

1 AZ48 0029 Ct Harness 1
2 A204 2110 Charge Roller Ass’y 1

3 A153 2126 Swing Arm 1
4 AB01 1358 Driven Gear 1
5 AA08 0219 Rear Roller Bushing 1
6 A077 1310 Snap Ring - M2 1
7 A153 2116 Grounding Plate 1

8 A153 2135 Charge Roller Terminal Ass’y 1

9 AA08 0197 Rear Roller Bushing 1
10 AA06 2286 Pressure Spring 2
11 AA08 0209 Rear Roller Housing 1
12 AA14 5808 Rear Support Shaft 1

13 AD02 7004 C harge Roller 1

14 A153 2143 Shielding Plate 1
15 AB01 0344 Roller Gear - 20Z 1
16 AB01 0343 Idle Gear - 14z 1
17 AB01 0342 Idle Gear - 20z 1
18 AA08 0191 Front Roller Bushing 1
19 AA14 3744 Stepped Screw 1
20 AA14 5794 Front Support Shaft 1
21 AA14 8439 Thermistor Shaft 1
22 AA06 6286 Pressure Spring 1
23 A153 2133 Thermistor Bracket 1

24 AW10 0032 Thermistor - 25°c 10k Ω 1

25 A204 2120 Drum Charge Roller Cleaner 1

26 A153 9510 OPC Drum 1
27 A204 3580 Toner Collection U nit 1
28 AA15 1945 Joint Seal 1
29 AA14 3730 Stepped Screw 1
30 A204 2155 Decal - Caution 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1102 6613 Relay Terminal - 2P
102 0720 0040E Retaining Ring - M4
103 0313 0060B Philips Pan Head Screw - M3x6
104 0720 0015E Retaining Ring - 1.5
105 0951 3008B Philips Screw With Flat Washer - M3x8
106 0720 0020E Retaining Ring - M2
107 0805 3471 Bushing - M8x22x7
108 0951 5010B Philips Screw With Washer - M5x10
109 0802 5233 Binding Self-tapping Screw - M3x10

Part No.

Description

Q’ty Per
Assembly

43

19. DRUM UNIT 2 (A204/A206/A207)

44

19. DRUM UNIT 2 (A204/A206/A207)

Index
No.

*A204 2256 Drum Unit 1
1 AB01 0341 Gear - 18Z 1

2 AD02 5019 Drum Pick-off Pawl 2

3 A153 3595 Pick-off Pawl Retainer 1
4 AA14 0321 Pick-off Pawl Shaft 1

5 A153 2277 Cleaning Blade 1

6 AA15 1943 Front Seal 1
7 G006 4317 Pressure Spring 1
8 AA15 1944 Rear Seal 1
9 AA15 1809 Rear Seal 2
10 AA06 0598 Pressure Spring 1
11 A204 3568 Rear Bushing 1
12 AA15 0389 Drum Guide Seal 1
13 AA15 2245 Front Drum Seal 1
14 AB01 1361 Drive Gear - 33Z 1
15 AA15 0380 Seal Front Holder 1
16 AD04 3035 Toner Collection Coil 1
17 AB01 7375 Drive Gear - 16Z 1
18 AB01 7374 Drive Gear - 12Z 1
19 AB01 7388 Blade Cam - 40Z 1
20 AB01 1360 Idle Gear - 19Z 1
21 AB01 7376 Separation Pawl Cam - 40Z 1
22 A153 3558 Blade Seal 1
23 AA15 1942 Side Seal 2
24 A153 3570 Spring Plate 1
25 AB01 7373 Idle Cam - 16/28Z 1
26 AA14 0560 Joint Shaft 1
27 AB01 1359 Joint Drive Gear - 20Z 1
28 A153 3590 Density Sensor Bracket 1
29 A153 5132 Density Sensor 1
30 AB01 1357 Collection Coil Gear - 15Z 1
31 AA15 2246 Rear Drum Seal 1
32 A153 3555 Cleaning Entrance Seal 1
33 AA15 0381 Seal Rear Holder 1
34 A153 2303 Grounding Plate 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0314 0060B Philips Pan Head Screw - M4x6
102 0802 5233 Binding Self-tapping Screw - M3x10
103 0803 0017 Knob Screw - M4x6 . 5
104 0965 3010B Tapping Screw Wit h Flat Washer M3x6
105 0720 0030E Retaining Ring - M3
106 0313 0080B Philips Pan Head Screw - M3x8
107 0720 0040E Retaining Ring - M4
108 0805 3384 Bushing - 5mm
109 0971 3006A Philip s Polycarbonate Screw - M3x6

Part No.

Description

Q’ty Per
Assembly

45

20. TRANSFER UNIT (A204/A206/A207)

46

20. TRANSFER UNIT (A204/A206/A207)

Index
No.

1 A153 3882 Transfer Belt Casing 1

2 A134 3850 Transfer Belt 1

3 A153 3866 Belt Drive Roller 1
4 A153 3863 Front Side Plate 1
5 A153 3873 Bias Roller Terminal 1
6 AA08 2061 Bias Roller Bushing - Front 1
7 A153 3862 Transfer Belt Frame 1
8 A153 3870 Transfer Bias Roller 1
9 A153 3864 Rear Side Plate 1
10 A153 3869 Drive Roller Bushing 1
11 AB01 3916 Belt Drive Gear - 25z 1
12 A153 3874 Earth Terminal 1
13 AA08 0195 Bias Roller Bushing - Rear 1
14 A153 3865 Belt Drive Roller 1
15 A153 3906 Support Plate 1
16 A153 3884 Belt Guide Plate 1
17 AA15 2332 Seal - 9x351 1
18 A077 3918 Spring - T/S Unit 2
19 A153 3886 Belt Pressure Lever 2
20 A153 3889 Connector Bracket 1
21 AA14 5537 Belt Release Shaft 2
22 A153 3887 Belt Release Stay 1
23 A153 3894 Bushing 1

24 A153 3892 Belt Cleaning Blade 1

25 A153 3893 Belt Cleaning Stay 1
26 AA06 6247 Torsion Spring 1
27 A153 3895 Front Bushing 1
28 A153 3888 Earth Plate 1
29 A153 3877 Spring Plate 2
30 A153 3901 Entrance Guide Plate 1
31 AZ30 0041 Power Pack - Transfer Unit 1
32 A153 3897 Harness Clamp 3
33 A153 3883 Tonner Collection Cap 1
34 A153 3591 Mylar - 17x335 1
35 A153 3923 Spacer:bearing:cl eaning:transfer Be 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0805 3485 Bushing - 8x12x3.5mm
102 0443 0080B Tapping Screw - M3x8
103 0802 5232 Binding Self-tapping Screw - M3x8
104 0720 0030E Retaining Ring - M3
105 1105 0196 Harness Clamp
106 0720 0060E Retaining Ring - M6
107 0964 4008B Tapping Screw Wit h Flat Washer - M4x8
108 0965 3008B Tapping Screw Wit h W asher - M3x8
109 0443 0060B Hexagon Tapping Screw - M3x6
110 1102 5 194 Connector - 7p

Part No.

Description

Q’ty Per
Assembly

47

21. FUSING UNIT 1 (A204/A206/A207)

48

21. FUSING UNIT 1 (A204/A206/A207)

Index
No.

*A204 4006 Fusing Unit - 120V (NA) 1
*A204 4007 Fusing Unit - 110V (TWN) 1
*A204 4008 Fusing Unit - 230V (EU) 1
1 AB01 3883 Idle Gear - 25z 1
2 A134 4130 Fusing Front Cover 1
3 A204 4200 Upper Frame 1
4 A204 4055 Upper Plate - Fusing Entrance Gui de 1
5 A153 4088 Thermistor 1
6 A153 4087 Thermistor holder 1
7 AA14 3715 Stepped Screw - M5 2
8 A134 4061 Rear Terminal Plate 1
9 A153 5265 Thermofuse - 169c 1
10 A204 4063 Front Terminal 1
11 A153 4074 Terminal Conn ect or - 2p 1
12 A204 4084 Fusing Connector Bracket 1
13 A204 5300 Fusing Unit Connector - 120V 1
13 A204 5665 Fusing Unit Connector - 230V 1
14 AA06 0103 Solenoid Spring 7

15 AE04 4019 Hot Roller Stripper 7

16 A153 4114 Stripper Stopper 7
17 A204 4115 Shielding Plate 1
18 A204 4312 Stripper Pawl Bracket 1

19 AE01 1045 Hot Roller 1

20 AB01 3882 Gear - 40Z 1
21 AE03 0026 Ball Bearing - 30x42x7 2
22 AX43 0039 Fusing Lamp - 230V 350W (EU) 1
22 AX43 0038 Fusing Lamp - 120V 350W (NA) 1
22 AX43 0043 Fusing Lamp - 110V 350W (TWN) 1
23 AX44 0099 Fusing Lamp - 230V 800W (EU) 1
23 AX44 0098 Fusing Lamp - 120V 800W (NA) 1
23 AX44 0102 Fusing Lamp - 110V 800W (TWN) 1
24 A204 4171 Heater Holder 2

25 AE04 0019 Oil Supply Roller 1

26 AA08 3016 Roller Clutch:6x14x10 1
27 AE03 1028 Bushing - 4mm 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

28 A204 4213 Clea ning Brush - Oil Supply Roller 1

29 A204 4217 Support Bracket-oil Supply Roller 1
30 A204 4221 Grounding Wier Oi l Suppl y 1

101 0957 3006B Screw - M3x6
102 0314 0060B Philips Pan Head Screw - M4x6
103 0725 0300E Retaining Ring C - M30
104 0720 0060E Retaining Ring - M6
105 0313 0080B Philips Pan Head Screw - M3x8
106 0950 4006M Philips Screw With Flat Washer - M4x6
107 0314 0120B Philips Pan Head Screw - M4x12
108 0954 4008B Philips Screw - M4x8
109 0954 3012B Screw - M3x12
110 0807 4072 Washer - Core
111 0314 0040B Philip s Pan Head Screw - M4x4

Part No.

Description

Q’ty Per
Assembly

49

22. FUSING UNIT 2 (A204/A206/A207)

50

22. FUSING UNIT 2 (A204/A206/A207)

Index
No.

1 A134 4006 Fusing Exit Unit 1
2 AB01 3885 Idle Gear - 20z 1
3 AB01 3884 Exit Gear - 17z 1
4 AF02 0326 Exit Roller Ass’y 1

5 AF04 0548 Exit Drive Roller 2
6 AG07 0009 Magnet ic C atch 1
7 A134 4280 Fusing Exit Guide - Lower 1
8 A153 4250 Fusing Exit Frame 1
9 AA06 2292 Tension Spring 2

10 AE02 0050 Pressure Rolle r 1

11 AE03 0022 Bearing - 12x24x64m 2
12 AG05 0076 Fusing Knob 1
13 A134 4161 Pressure Lever 2
14 A204 4101 Front Side Plate 1
15 A204 4181 Front Release Lever 1
16 A204 4110 Rear Side Plate 1
17 A204 4185 Rear Release Lever 1
18 A204 4116 Entrance Guide Stay 1
19 A077 4162 Shoulder Screw - M3 1
20 A134 4153 Slide Rail - Fusing 1
21 A204 4151 Fusing Unit Base 1
22 AE03 1028 Bushing - 4mm 2

23 AE04 2030 Cleaning Ro l le r 1

24 A204 4270 Cleaning Roller Bracket 1
25 A153 4207 Front Guide Plate 1
26 A153 4197 Lower Fusing G ui de 1
28 A204 4072 Front Holder 1
29 A204 4073 Rear Holder 1
30 A153 4208 Rear Guide Plate 1
31 A217 4123 Discharge Brush 1
32 A134 4272 Roller Holder 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0802 5236 Binding Self-tapping Screw - M4x8
102 0434 0082B Tapping Screw - M4x8
103 0805 3480 Bushing - 6mm
104 0720 0040E Retaining Ring - M4
105 0725 0120E Retaining Ring C - M12
106 0950 4008B Philips Screw With Spring Washer
107 0314 0060B Philips Pan Head Screw - M4x6
108 0951 4008B Philip s Screw With Washer - M4x8

Part No.

Description

Q’ty Per
Assembly

51

23. DUPLEX TRAY 1 (A207)

52

23. DUPLEX TRAY 1 (A207)

Index
No.

*A156 4610 Duplex Tray Ass’y 1
1 A134 2956 Paper Feed Front Cover 1
2 A134 4720 End Fence Upper Cover 1
3 A134 4701 Front Upper Cover 1
4 A134 4721 Connector Cover 1
5 A134 4728 Inverter Feeler 1
6 A134 4732 Upper Guide Plate 1
7 AF02 2077 Driv en Roller 7
8 5206 2686 Snap Ring 2
9 A134 4884 Decal - Duplex Misfeed R emoval 1
10 A134 4726 Guide Plate Knob 1
11 G694 4747 Guide Plate Holder 1
12 AA16 2068 Guide Plate Pad 1
13 5447 2768 Stepped Screw - M3 1
14 A134 4730 Entrance Feeler 1
15 A134 4740 Lower Guide Plate 1
16 AA12 0067 Anti Static Brush 1
17 A154 4616 Paper Holder 6
18 A134 4739 Lower Guide Plate Kno b 1
19 A134 4712 Right Cover Bracket 1
20 A134 4619 Guide Plate Link 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0344 0080F Philips Truss Head Screw - M4x8
102 0802 5236 Binding Self-tapping Screw - M4x8
103 0802 5231 Binding Self-tapping Screw - M3x6
104 0443 0 060W Hexa gon Head Tapping Screw - M3 x6

Part No.

Description

Q’ty Per
Assembly

53

24. DUPLEX TRAY 2 (A207)

54

24. DUPLEX TRAY 2 (A207)

Index
No.

1 A134 4751 Front Side Plate 1
2 5053 0447 Bushing - 6mm 3
3 A134 4781 Rear Side Plate 1
4 AA14 3307 Stepped Screw - M3x4 1
5 AA11 1208 Paper End Sensor Feeler 1
6 AF02 0319 Transport Roller 1
7 AF02 0320 Right Transport Roller 1
8 A134 4676 Paper End Feeler 1
9 A134 4804 Guide Plate Stopper 1
10 5443 2668 Bushing - 4x6x7mm 1
11 AB01 1166 Gear - 33Z 1
12 5304 1639 Bushing - 8mm 2
13 5215 2621 Snap Ring - M6 2
14 A134 4809 Front Guide Holder 1
15 AF02 0317 Stack Roller 2
16 A134 4649 Paper Guide Holder 2

17 AF03 1024 Feed Roller 1

18 A134 4808 Rear Guide Holder 1
19 AF02 2077 Driven Roller 2
20 A134 4690 Clutch Stopper 1
21 A134 4512 Feed Roller Shaft 1
22 AB03 0474 Pulley - 24Z 2
23 AA04 3373 Timing Belt - S2M308 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0443 0060B Hexagon Tapping Screw - M3x6
102 0951 4008B Philips Screw With Washer - M4x8
103 0720 0040E Retaining Ring - M4
104 0802 5236 Binding Self-tapping Screw - M4x8

Part No.

Description

Q’ty Per
Assembly

55

25. DUPLEX TRAY 3 (A207)

56

25. DUPLEX TRAY 3 (A207)

Index
No.

1 A134 4799 Motor Bracket 1
2 A134 4800 Motor Bracket 1
3 A134 5290 Transport Drive Motor - DC 3. 15V 8. 82W 1
4 AB01 7337 Gear - 15Z/55Z 1
5 AB01 1165 Gear - 32Z 2
6 5443 2668 Bushing - 4x6x7mm 1
7 5053 0447 Bushing - 6mm 4
8 A134 4790 Paper End Sensor Bracket 1
9 AA06 0593 Spring 1
10 5447 2681 Snap Ring 1
11 A334 4706 Disk - Bottom Plate Clutch 1
12 AB04 0015 Spring Clutch - Tray Bottom Plate 1
13 A079 3626 Stepped Screw - Swing Cleaning 3
14 AB01 7332 Gear - 24Z/41Z 1
15 AB01 1167 Gear - 25Z 1
16 A154 4623 Vibrating Plate 2
17 AA14 3307 Stepped Screw - M3x4 1
18 A134 4508 Inverter Guide Plate 1
19 AA16 1067 Cushion - Motor 3
20 AA13 2184 Motor Cushion 3
21 AW02 0075 Photointerrupter 2
22 A134 4765 Grounding Plate 1
23 A134 4527 Separation Roller 1
24 A134 4662 Duplex Guide Plate 1
25 A134 4670 Duplex Guide M yl ar 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1105 0199 Clamp
102 0313 0050B Philips Pan Head Screw - M3x5
103 0720 0030E Retaining Ring - M3
104 0443 0060B Hexagon Tapping Screw - M3x6
105 0802 5236 Binding Self-tapping Screw - M4x8
106 0720 0040E Retaining Ring - M4
107 0434 0060B Pan Head Self-tapping Screw - M4x6

Part No.

Description

Q’ty Per
Assembly

57

26. DUPLEX TRAY 4 (A207)

58

26. DUPLEX TRAY 4 (A207)

Index
No.

1 A154 4620 Bottom Plate 1

2 AF01 3003 Bottom Plate Pad - Duplex 1

3 AF01 6160 Rear Side Fence 1
4 AF01 6161 Front Side Fence 1
5 A204 4651 Bottom Pressure Plate 1
6 AA14 0291 Bottom Plate Shaft 1
7 A491 4690 Bottom Plate Hook 1
8 G011 3305 Gear - 16T 1
9 A134 4689 Rear Side Fence Rack 1
10 A134 4688 Front Side Fence Rack 1
11 AB03 0473 End Fence Pulley - 22z 2
12 AB01 3881 Gear - 31Z 1
13 AB01 7400 Gear- 18z/68z 1
14 AB01 7339 End Fence Gear - 22z/58z 1
15 A134 4714 Tightener 1
16 AA06 3370 Spring 1
17 AA04 3374 Timing Belt - S2M800 1
18 AW02 0075 Photointerrupter 3
19 A134 4620 Grounding Plate 1
20 A134 5291 Jogger Drive Mot or D C 6.48W 1
21 A134 5292 Jogger Drive Mot or D C 10. 56W 1
22 A134 5323 Motor Harness 1
23 A158 5191 Duplex Control Board 1
24 A134 4710 End Fence Actuator 1
25 A134 5321 Sensor Relay Harness 1
26 A134 5320 Duplex Main Harness 1
27 A134 4525 End Fence 1
28 A154 4621 Front Guide Plate 1
29 A154 4622 Rear Guide Plate 1
30 A134 5322 End Fence Harness 1
31 AF01 0018 Duplex Tray 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0951 3006B Philips Screw With Flat Washer - M3x6
102 0802 5232 Binding Self-tapping Screw - M3x8
103 0720 0040E Retaining Ring - M4
104 0802 5236 Binding Self-tapping Screw - M4x8
105 0802 5234 Tapping Screw - M3x12

Part No.

Description

Q’ty Per
Assembly

59

27. PAPER EXIT SECTION (A204/A206/A207)

60

27. PAPER EXIT SECTION (A204/A206/A207)

Index
No.

1 AX64 0059 Fan Motor - DC24V 3.12W 2
2 A153 4458 Exit Unit Knob (A204/A206) 1
3 A153 4454 Lower Guide Plate 1
4 A153 4453 Exit Driven Roller 2
5 AF04 0031 Upper Exit Roller 2
6 A153 4451 Upper Guide Plate 1
7 A153 5328 Ct Harness 1
8 A470 1703 Shift Clutch 1
9 AW02 0074 Sensor Actuator 1
10 AF02 0327 Exit Roller 1
11 AF02 5023 Exit Pick-off Pawl 1
12 A134 4459 Exit Cover 1
13 A470 1704 Spring - Lower Exit Roller 1
14 AB03 0536 Pulley - 18T S2M 2
15 AA14 3062 Shoulder Screw - M4 2
16 AF02 0328 Relay Drive Roller 2
17 A134 4464 Left Reverse Guide 1
18 A154 4465 Reverse Guide Plate - Ri ght Lower 1
19 A134 4471 Stripper Solenoid 1
20 AG07 0004 Magnetic Catch 2
21 A154 4462 Reverse Guide Plate - Upper Right 1
22 A154 4469 Reverse Roller Holder - Upper Right 2
23 A134 4458 Exit Unit Knob (A207) 1
24 A134 4455 Upper Guide Bracket 1
25 A134 4468 Lower Guide Plate Bracket 1
26 AA08 2058 Bushing - 6x10x9mm 2
27 AB01 3889 Gear - 24Z 1
28 AA12 0071 Exit Antistatic Brush 1
29 A153 4456 Photointerruptor Bracket 1
30 A153 4451 Upper Guide Plate 1
31 AX12 0039 DC Solenoid - 24V - 400gf 1
32 A204 4452 Grounding Wire 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0353 0300B Bind Screw - M3x30
102 1105 0199 Clamp
103 0802 5236 Binding Self-tapping Screw - M4x8
104 0720 0040E Retaining Ring - M4
105 0805 3480 Bushing - 6mm
106 0434 0082B Tapping Screw - M4x8
107 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
108 0434 0100B Pan Head Self-tappin g Scr ew - M4x10
109 0807 4072 Washer - Core
110 1102 4473 Ct Connector - 2p

Part No.

Description

Q’ty Per
Assembly

61

28. DRIVE SECTION 1 (A204/A206/A207)

62

28. DRIVE SECTION 1 (A204/A206/A207)

Index
No.

1 A153 5802 Lower Bracket - DC Drive Board 1
2 AA04 3411 Timing Belt - S2M 300 (A20 7) 1
3 AA04 3392 Drum Timing Belt 1
4 AA04 3394 Timing Belt - 60S3M459 1
5 AA04 3420 Timing Belt - 80S3M519 1
6 AB03 0492 Pulley - 25/25/34/125Z 1
7 AA04 3430 Timing Belt - 160S2M33 0 1
8 A204 1131 Development Support Plate 1
9 AB01 7346 Exit Gear 1
10 AX07 0020 Brushless Motor - DC24V 86W 1
11 A134 4481 Tightener Bracket (A207) 1
12 A153 1128 Tightener 1
13 AA06 0228 Spring - Transfer Drum Cleaning Sol 1
14 C105 2352 Stepped Screw - M6x1.7 1
15 A153 2936 Tray Lift Motor (A207) 1
15 A204 2936 Tray Lift Motor (A204/A206) 1
16 AB03 0463 Fusing Cam Pulley - 35Z 1
17 AB01 3872 Fusing Cam Gear - 28z 1
18 AB01 7345 Timing Pulley - 35Z 1
19 AA04 3395 Timing Belt - 30S3M327 1
20 5203 3151 Roller Cover Spring 1
21 AA05 1023 Release Plate 1
22 A134 1121 Joint Gear 1
23 5414 4630 Bottle Spring (A207) 1
24 A134 1072 Right Bracket - Grip Pla te 1
25 A134 1071 Left Grip Plate 2
26 A134 1073 Left Bracket - Grip Plate 1
27 A204 1135 Fusing Unit Support Plate 1
28 A153 1107 Bracket - Brushless Motor 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0707 8140B Bushing - 8x14mm
102 0720 0060E Retaining Ring - M6
103 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
104 1105 0199 Clamp
105 0964 4008B Tapping Screw Wit h Flat Washer - M4x8
106 0960 3006B Philips Flange Screw - M3 X 6
107 1105 0328 Harness Clamp - ES-0505

Part No.

Description

Q’ty Per
Assembly

63

29. DRIVE SECTION 2 (A204/A206/A207)

64

29. DRIVE SECTION 2 (A204/A206/A207)

Index
No.

1 AB01 7386 Cleaning Cam - 24Z 1
2 AB01 3917 Toner Supply Gear - 14Z 1
3 AA08 2047 Bushing - 8x16x7 6
4 AA14 5539 Solenoid Shaft 1
5 A153 1127 Clutch Shaft 1
6 AX20 0105 Magnetic Clutch - 15kgf 24z 1
7 AB01 7368 Cleaning Drive Gear - 17Z/46Z/18Z 1
8 A153 1125 Development Drive Bra cket 1
9 AX20 0106 Magnetic Clutch - 15kgf 52z 1
10 A153 5340 Ct Harness 1
11 A153 3087 Terminal Cap 1
12 A153 3086 Bias Terminal 1
13 A153 2130 Receptacle Housing 1
14 AB03 0494 Drum Pulley - 75Z 1
15 A153 1114 Drive Gear Hold er 1
16 A153 1132 Development Tightener 1
17 5442 1111 Spring - Main Drive Tig ht ner 2
18 AA06 2293 Roller Cover Spring 1
19 A153 1135 Drum Drive Tightener 1
20 AA06 3552 Driven Roller Spring 1
21 A153 1117 Drum Drive Shaft 1
22 AB01 7369 Transfer Belt Pulley - 24Z/20Z 1
23 A153 1119 Fusing Drive Tightener 1
24 AB01 7370 Development Pulley - 46Z/31Z 1
25 AZ43 0020 High Voltage Supply Cord 1
26 A204 3915 Magnet Clutch Bracket 1
27 AW02 0075 Photointerrupter 1
28 A153 3914 Magnetic Clutch Feeler 1
29 AB01 7385 Gear - 17Z/24Z 1
30 AX21 0059 Spring Clutch - 5kgf 1
31 A204 3911 Cam Shaft 1
32 A153 2142 Cam Lever 28
33 A204 3922 Brake Cam 1
34 A153 1126 Edging 1
35 A204 3921 Clutch Arm 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 A077 3918 Spring - T/S Unit 1
37 A204 3801 Spring Clutch - Transfer Belt 1
38 A153 1126 Edging 1

101 0740 3008 Ball Bearing - 8x 22x7
102 0573 0040E Hexagon Headless Set Screw - M3x4
103 0951 4012B Philips Screw With Flat Washer
104 1105 0197 Wire Saddle
105 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
106 0414 0080B Binding Self-tappin g Screw - M4x8
107 0802 5236 Binding Self-tapping Screw - M4x8
108 0802 5221 Tapping Screw - M3x10
109 0950 4008B Philips Screw With Spring Washer
110 0720 0060E Retaining Ring - M6
111 0720 0060 Retaining Ring - M6
112 1105 0196 Harness Clamp
113 1105 0199 Clamp

Part No.

Description

Q’ty Per
Assembly

65

30. DRIVE SECTION 3 (A204/A206/A207)

66

30. DRIVE SECTION 3 (A204/A206/A207)

Index
No.

1 A153 5813 Main Control Board Bracket 1
2 A155 2676 Pick-up Lever (A206/A207) 1
3 A134 2678 Solenoid Link (A204) 1
3 A155 2677 Pick-up Link (A206/A207) 1
4 AA06 0573 Release Spring 1
5 A134 2675 Solenoid Bracket (A204) 1
5 A155 2675 Pick-up Bracket (A206/A207) 1
6 AA06 0572 Pressure Spring 1
7 A134 2680 DC Solenoid (A204) 1
7 A155 2680 DC Solenoid - 24V - 510gf (A206/A207) 1
8 A134 2579 Stopper Bracket 1
9 5053 0223 Bushing - 8mm 1
10 A153 2570 Upper Support Plate 1
11 AA06 0664 Spring - Tightener 1
12 A134 2575 Tightener Arm 1
13 AB03 0455 Tightener Pulley - 8x20x13 2
14 AA06 0228 Spring - Transfer Drum Cleaning Sol 1
15 A134 2572 Middle Tightener 1
16 AB03 0465 Timing Pulley - 25Z 1
17 AA04 3364 Timing Belt - S3M300 1
18 AB01 1153 Idle Gear - 25z 1
19 AB03 3064 Drive Pulley - 34Z/25Z 1
20 AB01 3918 Drive Gear - 35z 1
21 AB01 7335 Timing Pulley - 22Z/37Z 1
22 AB01 7377 Gear - 25Z 1
23 AX20 0099 Magnetic Clutch - 7kgf.cm 26z 1
24 AB01 7336 Timing Pulley - 30Z/35Z 2
25 AX20 0098 Magnetic Clutch - 7kg Cm 35 z 1
26 AB01 3875 Reverse Gear - 27z 1
27 AX20 0100 Magnetic Clutch - 3.5kgf Cm 35z 1
28 AA04 3368 Timing Belt - S3M609 1
29 AB03 0464 Timing Pulley - 30Z 1
30 A153 5812 Left Lower Bracket 1
31 A153 2572 Paper Feed Harness Bracket (A204/A206) 1
32 A155 6325 Drive Cover Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0313 0050B Philips Pan Head Screw - M3x5
102 0951 3006B Philips Screw With Flat Washer - M3x6
103 1105 0197 Wire Saddle
104 0720 0040E Retaining Ring - M4
105 1105 0199 Clamp
106 0951 4006B Philip s Screw With Washer - M4x6

Part No.

Description

Q’ty Per
Assembly

67

31. ELECTRICAL SECTION 1 (A204/A206/A207)

68

31. ELECTRICAL SECTION 1 (A204/A206/A207)

Index
No.

1 A153 1353 Front Cover Hinge 1
2 A153 1355 Key Counter Bracket 1
3 A153 5501 AC Main Harness (NA) 1
3 A153 5661 AC Main Harness (EU/ASIA) 1
3 A153 5301 AC Main Harness (TWN) 1
4 AA05 1023 Release Plate 1
5 A153 5520 Front Right Harness (NA)(A204/A206) 1
5 A153 5320 Front Right Harness (EU/ASIA/TWN) 1
(A204/A206)
5 A156 5513 Front Right Harness (NA)(A207) 1
5 A154 5313 Front Right Harness (EU/ASIA/TWN)(A207) 1
6 AX40 0021 Anti-condensation He at er - 115V 18W 1
(Option)
6 AX40 0022 Anti-condensation He at er - 240V 18W 1
(Option)
7 5446 1239 Plate Nut - Key Co unt er 1
8 5442 4467 Spring - Stripper Pawl Plate 1
9 AX31 0022 Total Counter 1
10 A134 2947 Heater Cover (Option) 1
11 A153 5820 Total Counter Bracket 1
12 A153 5814 Main Switch Bracket (NA) 1
12 A153 5804 Main Switch Bracket (EU/ASIA/TWN) 1
13 A153 5809 Arm Interlock SW 1
14 A153 5808 Bracket - Safety Switch 1
15 A134 1071 Left Grip Plate 2
16 A134 1072 Right Bracket - Grip Pla te 1
17 A134 1073 Left Bracket - Grip Plate 1
18 A153 3270 Stay Toner Supply 1
19 A153 5562 Main Switch Relay Harness 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
102 1204 2421 Main Switch (NA)
102 1204 1545 Main Switch (EU/ASIA/TWN)
103 1204 2397 Safety Switch
104 0323 0080B Philips Sunk Screw - M3x8
105 1105 0229 Clamp
106 0314 0060B Philips Pan Head Screw - M4x6
107 1105 0231 Clamp
108 1105 0196 Harness Clamp
109 1105 0329 Clamp - ES-0510

Part No.

Description

Q’ty Per
Assembly

69

32. ELECTRICAL SECTION 2 (A204/A206/A207)

70

32. ELECTRICAL SECTION 2 (A204/A206/A207)

Index
No.

1 A204 5811 Main Board Bracket 1
2 A204 5101 Main Control Board (NA) 1
2 A204 5181 Main Control Board (EU/ASIA/TWN) 1
3 A153 5316 Paper Feed Harness (A204/A206) 1
3 A154 5310 Duplex Unit Harness (A2 07) 1
4 A204 5107 Ic-4m X16 100ns 1
5 A205 5319 Rear Upper Harness 1
6 A153 5803 Upper Bracket - DC Drive Board 1
7 A153 5645 AC Drive Board - 230V 1
7 A153 5550 AC Drive Board - 120V 1
8 AW03 0055 Optical F i ber - 420mm 1
9 AW03 0054 Optical F i ber - 250mm 1
10 AZ23 0054 DC Drive Board - 120V 295W 1
10 AZ24 0042 DC Power Supply Unit - 220/240V 31 5W 1
11 A153 5344 Power Supply Harness - 120V 1
(A204/A206)
11 A153 5644 Power Supply Harness - 230V 1

11 A154 5343 Power Supply Cord - 120V (A 207) 1
11 A156 5643 Power Supply Harness - 230V( A 207) 1
12 A153 5801 DC Drive Board Bracket 1
13 A153 5312 Optical Harness 1
14 AZ13 0023 Transformer - 230V 1
15 A153 5114 Ram Board 1
17 A204 5311 Rear Lower Harness (NA) (A204/A206) 1
17 A204 5611 Rear Lower Harness (EU/ASIA/TWN) 1

17 A205 5309 Duplex Relay Harness (NA)(A207) 1
17 A207 5609 Duplex Relay Harness (EU/ASIA/TWN) 1

18 A153 5807 Bracket ARDF 1
19 A153 5806 Bracket Paper Tray Unit 1
20 A153 5561 Relay Harness 1

Part No.

(A204/A206)

(A204/A206)

(A207)

Description

Q’ty Per
Assembly

Index
No.

101 1105 0367 Spacer
102 1102 4052 Optional Connector
103 1105 0409 Spacer
104 1107 0753 Fuse (Glass Ca se) - 6. 3A - 250V
105 1107 0392 Fuse (Glass Ca se) - 6. 3A - 125V
106 1107 0752 Fuse (Glass Ca se) - 5A - 250V
107 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
108 0323 0060B Philips Sunk Screw - M3x6
109 0801 0137 Philips Pan Head Screw With Spring
110 1102 6739 Connector - 12p
111 1208 1392 Relay - G2r-1- t-tu - DC24V
112 0951 4006B Philips Screw With Washer - M4x6
113 1105 0192 Locking Support

Part No.

Description

Q’ty Per
Assembly

71

33. ELECTRICAL SECTION 3 (A204/A206/A207)

72

33. ELECTRICAL SECTION 3 (A204/A206/A207)

Index
No.

1 A204 5326 Fusing Relay Harness 1
2 AZ32 0078 DC Power Pack 1
3 AZ43 0020 High Voltage Supply Cord 1
4 A134 2941 Bracket - Paper Size Sensor 1
5 AW50 0012 Push Switch 2
6 AX64 0058 Fan Motor - DC 24V 4.32W 2
7 A153 1986 Cooling Fan Duct 2
8 AW02 0022 Photointerruptor 1
9 AW03 0056 Optical F i ber - 550mm 1
10 AA14 3301 Stepped Screw - M3x4 2
11 AA14 3452 Stepped Screw 2
12 A153 5324 Sorter Relay Harness 1
13 A153 5571 Power Supply Cord (NA) 1
13 A153 5671 Power Supply Cord (EU/ASIA) 1
13 A153 5471 Power Supply Cord (TWN ) 1
14 AA06 3532 Spring 2
15 A154 5325 Duplex Unit Relay Harness 1
16 A153 5621 Noise Filter Board (EU/ASIA) 1
16 A204 5521 Noise Filter Board (TWN) 1
17 A204 5810 Power Supply Cord Brack et 1
18 A153 5888 Fusing Unit Joint Connector Bracket 1
19 A153 5601 AC Relay Harness (EU/ASIA/TWN) 1
20 AZ02 0008 Coil - 10Mh 2A 1
21 AA15 1177 Seal - 5x82x4 2
22 A153 1258 Platen Cover Bracket - Right 1
23 A153 1259 Platen Cover Bracket - Left 1
24 AX64 0075 Fan Motor - DC24V 4.32W 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1105 0192 Locking Support
102 0951 3006B Philips Screw With Flat Washer - M3x6
103 1102 4473 Ct Connector - 2p
104 1102 4052 Optional Connector
105 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
106 0414 0142B Binding Self Tapping Screw - M4x14
107 0434 0352W Pan Head Self-tapping Screw - M4x35
108 0964 4008B Tapping Screw Wit h Flat Washer - M4x8
109 0801 0137 Philips Pan Head Screw With Spring
110 0323 0060B Philips Sunk Screw - M3x6
111 1107 047 2 Circuit Breaker - 250V/8A (EU/ASIA)
112 0314 0300B Philips Pan Head Screw - M4x30
113 1105 0197 Wire Saddle

Part No.

Description

Q’ty Per
Assembly

73

34. FRAME SECTION 1 (A204/A206/A207)

74

34. FRAME SECTION 1 (A204/A206/A207)

Index
No.

1 AX40 0094 Anticondensatio n H eat er - 120V 9W 1
1 AX40 0095 Anticondedsatio n H eat er - 230V 9W 1
2 AA06 2291 Pressure Spring 1
3 AA06 2285 Release Spring 2
4 AA05 1025 Release Wire 1
5 A153 2072 Release Link Lever 1
6 A204 2187 Spacer-11mm 4
7 A204 2188 Spacer-15mm 2
8 AA13 2186 Collar 2
9 A153 2073 Guide Rail 1
10 A153 2084 Spacer 1
11 A153 2075 Front Roller Cam 1
12 A153 2076 Rear Roller Cam 1
13 A153 2060 Wire Pulley 1
14 A153 2090 Quenching Lamp 1
15 A153 2071 Cam Lever 1
16 A153 2083 Left Drum Rail 1
17 A153 2080 Eraser Lamp 1
18 AG07 0004 Magnetic Catch 1
19 A204 1674 Shield Glass Guide 2
20 A153 5339 Density Sensor Harness 1
21 A204 1677 Optical Filter 1
22 A153 3598 Pin Bracket 1
23 A153 2061 Release Lever 2
24 A153 1350 Right Middle C over 1
25 A153 3920 Belt Release Arm 1
26 AA14 3444 Stepped Screw 1
27 A153 2085 Spacer 1
28 A153 1676 Harness Guard Seal 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0434 0060B Pan Head Self-tappin g Scr ew - M4x6
102 0720 0030E Retaining Ring - M3
103 0720 0040E Retaining Ring - M4
104 0964 4 006B Tapping Screw With Flat Washer - M4x6

Part No.

Description

Q’ty Per
Assembly

75

35. FRAME SECTION 2 (A204/A206/A207)

76

35. FRAME SECTION 2 (A204/A206/A207)

Index
No.

1 A153 4352 Fusing Lock Lever 1
2 A157 3900 Support Plate 1
3 A134 2926 Paper Feed Lock Bracket 2
4 A096 6266 Tray Lock Arm 2
5 AA06 0534 Tray Lock Spring - 19mm 2
6 A134 2921 Left Slide Rail 2
7 5442 4467 Spring - Stripper Pawl Plate 1
8 5203 1686 Screw - Slide R ai l 1
9 A153 5334 Ct Harness - 7p 1
10 A134 4355 Fusing Unit Stopper 1
11 A134 4901 Duplex Right Rail 1
12 A153 3930 Belt Unit Handle 1
13 A134 2930 Right Slide Rail 1
14 A134 2929 Slide Rail Bracket - Front Right 1
15 AH01 0007 Rubber Foot 4
16 A130 2929 Slide Rail Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0040E Retaining Ring - M4
102 0964 4008B Tapping Screw Wit h Flat Washer - M4x8
103 1105 0199 Clamp
104 1106 0193 Bushing - 7.9mm
105 0960 4010B Philips Flange Screw - M4 x 10
106 0434 0060B Pan Head Self-tapping Screw - M4x6

Part No.

Description

Q’ty Per
Assembly

77

36. MAIN CONTROL BOARD (A204/A206/A207)

78

36. MAIN CONTROL BOARD (A204/A206/A207)

79

36. MAIN CONTROL BOARD (A204/A206/A207)

80

36. MAIN CONTROL BOARD (A204/A206/A207)

Index
No.

*A204 5181 Main Control Board (EU/ASIA/TWN) 1
*A204 5101 Main Control Board (NA) 1
1 A153 5114 RAM Board 1
2 A204 5107 IC-4M X16 100NS 1
3 A204 5117 IC - RF5A230 1

101 1102 3822 Connector - 20p
102 1102 4201 Connector - 2p

Part No.

Description

Q’ty Per
Assembly

Index
No.

103 1102 4202 Connector - 3p
104 1102 4203 CT Header - 4p
105 1102 4205 CT Header - 6p
106 1102 4206 Connector - 7p
107 1102 4207 Connector - 8p
108 1102 4208 Connector - 9p
109 1102 4210 Connector - 11p
110 1102 4211 CT Header - 12p
111 1102 4212 CT Header - 15p
112 1102 4497 Connector - 13p
113 1102 4619 Connector - 2p
114 1102 4621 CT Header - 4p
115 1102 4623 CT Connector - 6p
116 1102 4624 CT Connector - 7p
117 1102 4625 Ct Connector 8 p
118 1102 4628 Connector - 11p
119 1102 4629 Connector - 12p
120 1102 4630 CT Connector
121 1102 4631 Ct Connector - 2p
122 1102 4637 Ct Connector - 8p
123 1102 4639 Ct Connector - 10p
124 1102 4640 Ct Connector - 11p
125 1102 4643 Ct Connector - 2p
126 1102 4651 Ct Connector - 10p
127 1102 5007 CT Header - 14p
128 1102 5305 Connector - 6p
129 1102 5605 Connector - 13p
130 1102 5718 Optical Fiber C onnector
131 1102 6408 Connector - 30p
132 1103 1772 Pin Header - 6p
133 1103 1774 Pin Header - 8p
134 1104 0588 Dip Socket - 28p
135 1104 0612 Connector - 40p
136 1400 0369 Transistor - 2s a1213y
137 1400 0550 Transistor - BA1L3N

Part No.

Description

Q’ty Per
Assembly

Index
No.

138 1400 0558 Transistor - 2s d780
139 1402 0708 Diode - 1SS272
140 1402 0780 Diode - 200V 1A 11ES2
141 1402 1030 Diode - 1SS250
142 1402 1378 Diode - PTZ12A
143 1402 1380 Diode - PTZ 6.2A
144 1402 1387 Diode - HSM12 3
145 1407 2187 TTLIC - SN74LS07NS
146 1407 2231 IC - TD62308AF
147 1407 2496 IC - M5261L
148 1407 3173 Driver - 16bit - M 66311fp
149 1407 3257 Cmosic - Tc74h c14af
150 1407 3708 IC - SLA7026M
151 1407 3764 IC - TC7SU04F
152 1407 4164 IC - MMID75XF
153 1407 4316 IC - TD52308BF
154 1407 4686 IC - M54992FP
155 1407 4687 IC - TA8083F
156 1408 0595 IC - NJM2904M
157 1408 0629 IC - 78M12A
158 1408 0874 Transistor Array - M 54587fp
159 1408 1065 Comparator Ba10339f
160 1408 1135 IC - X9C104S
161 1503 0777 Oscillator - 32mhz 9.6pf

162 1600 1499 Resistor - 0.33 Ω ±2% 2W
163 1600 1660 Resistor - ERG2SJ101

164 1601 7793 Resistor - 10K Ω
165 1601 7798 Resistor Array - 68Ω ±55 1/16W
166 1601 7799 Resistor Array - 4.7KΩ ±5% 1/16W

167 1602 7032 Filter - EMI-2200pf
168 1604 4511 Capacitor - 0.15µF ±10% 50V
169 1630 1101 Resistor - 100 Ω 1/4W ±5%
170 1630 1161 Resistor - 160 Ω ±5% 1/8W
171 1630 3101 Resistor - 100 Ω 1/10W

Part No.

Description

Q’ty Per
Assembly

Index
No.

172 1630 3102 Resistor - 1k Ω 1/10W ±5%
173 1630 3103 Resistor - 10k Ω 1/10W ±5%
174 1630 3104 Resistor - 100k Ω 1/10W ±5%
175 1630 3155 Resistor - 1.5MΩ ±5% 1/10W
176 1630 3222 Resistor - 2.2k Ω 1/10W ±5%
177 1630 3223 Resistor - 22k Ω 1/10W
178 1630 3242 Resistor - 2.4k Ω ±5% 1/10W
179 1630 3330 Resistor - 33 Ω ±5% 1/10W
180 1630 3334 Resistor - 330K Ω ±5% 1/10W
181 1630 3393 Resistor - 39K Ω 1/10W
182 1630 3472 Resistor - 47K Ω 1/10W ±5%
183 1630 3473 Resistor - 47K Ω 1/10W ±5%
184 1630 3682 Resistor - 6.8K Ω 1/10W
185 1630 3824 Resistor - 820 Ω ±5% 1/10W
186 1633 1000 Resistor - 100 Ω ±1% 1/10W
187 1633 1002 Resistor - 10k Ω ±1% 1/10W
188 1633 2150 Resistor - 215Ω ±1% 1/10W
189 1633 4701 Resistor - 4.7k Ω ±1% 1/10W
190 1633 4702 Resistor - 47k Ω ±1/10W
191 1633 4871 Resistor - 4.87k Ω ±1% 1/10W
192 1633 5100 Resistor - 510 Ω ±1% 1/10W
193 1633 5231 Resistor - 5.23k Ω ±1% 1/10W
194 1633 6490 Resistor - 649 Ω ±1% 1/10W
195 1633 8209 Resistor - 820Ω ±1% 1/10W
196 1640 5101 Capacitor - 100µF ±20% 50V
197 1640 5470 Capacitor - 47µF ±20% 50V
198 1642 5100 Capacitor - 10µF ±20% 50V

199 1660 1100 Capacitor - 10PF 50V
200 1660 3470 Capacitor - 47PF ±5% 50V

201 1660 3471 Capacitor - 470PF 50V
202 1660 5103 Capacitor - 10000PF ±10% 50V
203 1660 5222 Capacitor - 2200PF ±10 % 50V
204 1660 7 104 Capacitor - 100000PF 50V

Part No.

Description

Q’ty Per
Assembly

81

37. DECAL AND DOCUMENT (A204/A206/A207)

10

17

*********
*********
******* *
*

*

*

****

*

***

*********
*********
*********
*********
****

*********
*********
*********
*********
****

*********
*********
*********
*********
****

*********
*********
*********
*********
****

18

19

82

37. DECAL AND DOCUMENT (A204/A206/A207)

Index
No.

*A204 1386 Multi Decal - German (RIC)(NRG) 1
*A204 1387 Multi Decal - French (RIC)(NRG) 1
*A204 1388 Multi Decal - Spanish (RIC)(NRG) 1
*A204 1389 Multi Decal - Italian (RIC)(NRG) 1
*A204 1396 Multi Decal - German (INF) 1
*A204 1397 Multi Decal - French (INF) 1
*A204 1398 Multi Decal - Spanish (INF) 1
*A204 1399 Multi Decal - Italian (INF) 1
1 A153 2995 Decal Paper Size - LT/DLT 1
1 A153 2996 Decal Paper Size - A4/A3 1
2 AA00 1373 Decal - Main Switch 1
3 A155 6113 Decal - Paper Set 1
4 A153 1285 Emblem (RIC) 1
4 A156 6413 Emblem (SVN) 1
4 A153 6423 Support Cover (INF) 1
5 A134 2997 Decal - Paper Setting 1
6 A204 8607 Operating Instructions - English LT (RIC) 1
6 A204 8650 Operating Instructions - Engli sh LT (SVN) 1
6 A204 8661 Operating Instructions - German (INF) 1
6 A204 8662 Operating Instructions - French (INF) 1
6 A204 8663 Operating Instructions - Italian(INF) 1
6 A204 8664 Operating Instructions - Spanish(INF) 1
6 A204 8660 Operating Instructions - English A4 (INF) 1
6 A204 8690 Operating Instructions - English A4 (NRG) 1
6 A204 8697 Operating Instructions - English LT (NRG) 1
6 A204 8608 Operating Instructions - English A4 (RIC) 1
6 A204 8609 Operating Instructions - Chinese (RIC) 1
6 A204 8600 Operating Instructions English - A4 (RIC) 1
7 A153 1475 Decal - 10key Zoom -LT/DLT 1
7 A153 1478 Decal - 10key Zoom - A4/A3 1
8 A153 1476 Decal - Margin Adjustment - LT/DLT 1
8 A153 1479 Decal - Margin Adjustment - A4/A3 1
9 A156 1495 Decal Copy Ratio 1
10 A204 1486 Opration Panel Sheet - LT (A 204/A206) 1
10 A204 1487 Opration Panel Sheet - A4 (A2 04/ A206) 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

11 C225 2867 Decal - Cover - Panel - Nashua 1
11 C225 2866 Decal - Key Top Cover 1
11 A153 6409 Decal - Keytop Cove r 1
12 AA00 2209 Decal - Paper Size 1
13 A204 6404 Decal - Model Name - GES ( A204) 1
13 A204 6407 Decal - Model Nam e - NST (A204) 1
13 A204 6414 Decal - Model Name - REX (A 204) 1
13 A206 6404 Model Name Plate - GES (A206) 1
13 A206 6407 Model Name Plate - NST (A206) 1
13 A206 6414 Model Name Plate - REX (A206) 1
13 A207 6404 Model Name Plate - GES (A207) 1
13 A207 6407 Model Name Plate - NST (A207) 1
13 A207 6414 Model Name Plate - REX (A207) 1
14 A153 1365 Symbol Explanation Decal 1
15 A204 2155 Decal - Caution 1
16 AA00 1389 Large Decal - Energy Star 1
17 A134 2997 Decal - Paper Setting 1
18 A134 4884 Decal - Duplex Mi sf eed Removal 1
19 A155 6114 Caution Decal - LCT 1

Part No.

Description

Q’ty Per
Assembly

83

38. SPECIAL TOOLS (A204/A206/A207)

84

38. SPECIAL TOOLS (A204/A206/A207)

Index
No.

1 5203 9501 Grease 501 1
2 5420 9507 Digital Multimeter - Beckman 1
3 5447 9078 Heat Resist i ng G r ease Mt-78 1
4 5442 9103 Launa Oil 40 1
5 5420 9516 Test Chart - Os - A3 (1 0psc/set) 1
6 A008 9502 Silicone Grease - G40m 1
7 A153 9001 Scanner Adjustment Tool 2
8 A153 9004 Wiping Cloth(100pcs/set) 1
9 5442 9101 Setting Powder 1
10 A028 9300 Grease Barrierta Jfe 55/ 2 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

Part No.

Description

Q’ty Per
Assembly

85

PARTS INDEX

PM Parts Index

Section Name

By-pass Feed Section (A204/A206/A207) 5447 2927 Bottom Plate Pad (By-pas feed) Friction Pad - B 1 15- 15
Paper Tray Sectio n (A204/A206/A207) AF01 3014 Bottom Plate Pad (Paper Tray) Bottom Plate Pad 1 17- 9
LCT Unit 1 (A206/A207) A421 2543 Bottom Plate Pad (LCT) Friction Pad 1 19- 13
Paper Feed Sectio n 1 (A204/A206/A207) A134 2674 Torque Limitte r Torque Limitter - 400fg 1 23- 22

Paper Feed Section 2 (A204/A206/A207) AF03 0025 Pick-up Roller Pick-up Feed Roller 1 25- 3

Paper Feed Section 3 (A204/A206) AF03 0025 Pick-up Roller Pick-up Feed Roller 1 27- 3

Development Unit (A204/A206/ A207) A204 3080 Development Fi l te r Development Filt er 1 41- 18
Drum Unit 1 (A2 04/ A206/A207) A153 2135 Drum Roller Ter m i nal Charge Roller Terminal Ass’y 1 43- 8

Drum Unit 2 (A204/ A206/A207) A153 2277 Cleaning Blade Cleaning Blade 1 45- 5

Transfer Unit (A204/A206/A207) A134 3850 Transfer Belt Transfer Belt 1 47- 2

Fusing Unit 1 (A204/A206/A207) A204 4213 Oil Supply Roller - Cleaning Brush Cleaning Brush - Oil Suppl y Rol l er 1 49- 28

Fusing Unit 2 (A207) AE02 0050 Pressure Roller Pressure Roller 1 51- 10

Duplex Tray 2 (A207) AF03 1024 Feed Roller Feed Roller 1 55- 17
Duplex Tray 4 (A207) AF01 3003 Bottom Plate Pad Bottom Plate Pad - Dupl ex 1 59- 2

Part No.

AF03 0024 Pick-up Roller (By-pass feed,LCT) Pick-up Roller 1 23- 10
AF03 1025 Feed Roller (By-pass feed,LCT) Feed Roller 1 23- 7
AF03 2025 Separation Roller(By-pass feed,LCT) Separation Roller 1 23- 21

AF03 1026 Feed Roller Paper Feed Roll er 1 25- 39
AF03 2027 Separation Roller Separation Roller 1 25- 25

AF03 1026 Feed Roller Paper Feed Roll er 1 27- 39
AF03 2027 Separation Roller Separation Roller 1 27- 25

A204 2120 Drum Charge Rolle r Cl eaner Drum Charge Roller C l eaner 1 43- 25
AD02 7004 Drum Charge Rol ler Charge Roller 1 43- 13

AD02 5019 Pick-off Pawl Drum Pick-off Pawl 2 45- 2

A153 3892 Transfer Belt Cleaning Blade Belt Cleaning Blade 1 47- 24

AE01 1045 Hot Roller Hot Roller 1 49- 19
AE04 0019 Oil Supply Roller Oil Supply Roller 1 49- 25
AE04 4019 Hot Roller Stripper Hot Roller Stripper 5 49- 15

AE04 2030 Cleaning Roller Cleaning R ol l er 1 51- 23

Description in Service Manual

Description in Parts Catalog

Q’ty Per
Assembly

Page and
Index No

88

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A204 1131 Development Support Plate 63- 8
A204 1135 Fusing Unit Suppor t Pla te 63- 27
A204 1277 Front Cover (A204)(RIC) 9- 2
A204 1291 Rear Cover 9- 25
A204 1386 Multi Decal - German (RIC)(NRG) 83-
A204 1387 Multi Decal - French (RIC)(NRG) 83-
A204 1388 Multi Decal - Span ish (RIC)(NRG) 83-
A204 1389 Multi Decal - Italian (RIC)(NRG) 83-
A204 1396 Multi Decal - German (INF) 83-
A204 1397 Multi Decal - French (INF) 83-
A204 1398 Multi Decal - Span ish (INF) 83-
A204 1399 Multi Decal - Italian (INF) 83-
A204 1465 Key-top - Sorter 13- 25
A204 1471 Keytop - Halftone 13- 19
A204 1472 Keytop - Enlarge 13- 20
A204 1473 Keytop - Reduce 13- 21
A204 1475 Operation Panel Ca se - L T 13- 22
A204 1476 Operation Panel Ca se - A4 13- 22
A204 1477 Display Panel - LT (A204/A206) 13- 24
A204 1478 Display Panel - A4 (A204/A206) 13- 24
A204 1479 Sheet Sorter - LT (A204/ A206) 13- 27
A204 1480 Sorter Sheet - A4 (A204/A2 06) 13- 27
A204 1481 Sheet - LT 13- 23
A204 1482 Sheet - A4 13- 23
A204 1486 Operation Panel Sheet - LT (A204/A206) 9- 32
A204 1486 Operation Panel Sheet - LT (A204/A206) 13- 17
A204 1486 Opration Panel She et - LT ( A204/A206) 83- 10
A204 1487 Operation Panel Sheet - A4 ( A204/A206) 9- 32
A204 1487 Operation Panel Sheet - A4 ( A204/A206) 13- 17
A204 1487 Opration Panel She et - A4 (A2 04/ A206) 83- 10
A204 1674 Shield Glass Gui de 75- 19
A204 1677 Optical Fil te r 75- 21
A204 1770 Scanner Unit - 85V 310W (2 30V) 33- 1
A204 1790 Scanner Unit -97V 310 W (120V) 33- 1
A204 1840 Lens Magnification Unit 31- 1

A204 1844 Lens Drive Unit 31- 11
A204 1976 Density Sensor Ca se 35- 15
A204 1977 Density Sensor Co ver 35- 14
A204 2101 P.T.L. Lamp Ass‘y 29- 9

*
*
*
*
*
*
*
*

A204 2110 Charge Roller Ass’y 43- 2
A204 2120 Drum Charge Roller Cleaner 43- 25
A204 2155 Decal - Caution 43- 30
A204 2155 Decal - Caution 83- 15
A204 2187 Spacer-11mm 75- 6
A204 2188 Spacer-15mm 75- 7
A204 2256 Drum Unit 45-
A204 2800 Upper Paper Feed Uni t 27-
A204 2850 Lower Paper Feed Uni t 25-
A204 2860 Pickup Arm 25- 5
A204 2904 Lower Guide Plate - Duplex Feed (A207) 29- 26
A204 2936 Tray Lift Motor (A20 4/ A206) 63- 15
A204 2953 Paper Tray 17- 8
A204 2971 Bottom Lift Shaft 17- 17
A204 2972 Bottom Lift Lever 17- 16
A204 3051 Development Uni t 41-
A204 3080 Development Fil t er 41- 18
A204 3150 Toner Bottle Drive (RI C NA) 39-
A204 3151 Toner Bottle Drive (RI C EU) 39-
A204 3153 Toner Bottle Drive (Ot her s) 39-
A204 3200 Toner Hopper Ass’y 41- 3
A204 3261 Release Bracket 39- 29
A204 3281 Bottle Bracket Cover 39- 14
A204 3568 Rear Bushing 45- 11
A204 3580 Toner Collectio n U ni t 43- 27
A204 3801 Spring Clutch - Transfer Belt 65- 37
A204 3911 Cam Shaft 65- 31
A204 3915 Magnet Clutch Bracket 65- 26
A204 3921 Clutch Arm 65- 35
A204 3922 Brake Cam 65- 33
A204 4006 Fusing Unit - 120V (N A) 49-

*
*
*

*

*
*
*

*

89

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A204 4007 Fusing Unit - 110V (T W N ) 49-
A204 4008 Fusing Unit - 230V (E U ) 49-
A204 4055 Upper Plate - Fusing Ent r ance Guide 49- 4
A204 4063 Front Terminal 49- 10
A204 4072 Front Holder 51- 28
A204 4073 Rear Holder 51- 29
A204 4084 Fusing Connector Bracket 49- 12
A204 4101 Front Side Plate 51- 14
A204 4110 Rear Side Plate 51- 16
A204 4115 Shielding Plate 49- 17
A204 4116 Entrance Guide Stay 51- 18
A204 4151 Fusing Unit Base 51- 21
A204 4171 Heater Holder 49- 24
A204 4181 Front Release Lever 51- 15
A204 4185 Rear Release L ever 51- 17
A204 4200 Upper Frame 49- 3
A204 4213 Cleaning Brush - Oi l Supply Roller 49- 28
A204 4217 Support Bracket-oil Supply Roller 49- 29
A204 4221 Grounding Wier O i l Su pply 49- 30
A204 4270 Cleaning Roller Bracket 51- 24
A204 4312 Stripper Pawl Bracke t 49- 18
A204 4452 Grounding Wi r e 61- 32
A204 4651 Bottom Pressure Pla te 59- 5
A204 5101 Main Control Board (NA) 71- 2
A204 5101 Main Control Board (NA) 81-
A204 5107 Ic-4m X16 100ns 71- 4
A204 5107 IC-4M X16 100NS 81- 2
A204 5117 IC - RF5A230 81- 3
A204 5160 ADS Sensor Board 35- 18
A204 5181 Main Control Board (EU/ASIA/TWN) 71- 2
A204 5181 Main Control Board (EU/ASIA/TWN) 81-
A204 5212 Lens Drive Motor - DC24V 38W 31- 18
A204 5300 Fusing Unit Connector - 120V 49- 13
A204 5311 Rear Lower Harness (NA) (A204/A206) 71- 17
A204 5326 Fusing Relay Harness 73- 1

*
*

*

*

A204 5521 Noise Filter Bo ar d (TWN) 73- 16
A204 5611 Rear Lower Harness (EU/ASIA/TWN) 71- 17
A204 5665 Fusing Unit Connector - 230V 49- 13
A204 5810 Power Supply Cord Bracket 73- 17
A204 5811 Main Board Bracket 71- 1
A204 6404 Decal - Model Nam e - GES (A 204) 9- 35
A204 6404 Decal - Model Nam e - GES (A 204) 83- 13
A204 6407 Decal - Model Nam e - NST (A204) 9- 35
A204 6407 Decal - Model N ame - NST (A204) 83- 13
A204 6412 Front Cover (A204)(SVN) 9- 2
A204 6414 Decal - Model Nam e - REX (A204) 9- 35
A204 6414 Decal - Model Nam e - REX (A204) 83- 13
A204 6422 Front Cover (A204)(INF) 9- 2
A204 8600 Operating Instructions English - A4 (RIC) 83- 6
A204 8607 Operating In st ructions - English LT (R IC) 83- 6
A204 8608 Operating In st ructions - English A4 (RIC ) 83- 6
A204 8609 Operating Instructions - Chinese (RIC) 83- 6
A204 8650 Operating Instructions - English LT (SVN) 83- 6
A204 8660 Operating In st ructions - English A4 (INF) 83- 6
A204 8661 Operating In st ructions - German (INF) 83- 6
A204 8662 Operating In st ructions - French (INF) 83- 6
A204 8663 Operating Instructions - Italian(INF) 83- 6
A204 8664 Operating In st ructions - Spanish(IN F) 83- 6
A204 8690 Operating In st ructions - English A4 (NRG ) 83- 6
A204 8697 Operating In st ructions - English LT (N R G ) 83- 6

90

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

AA00 1373 Decal - Main Swit ch 9- 28
AA00 1373 Decal - Main Swit ch 83- 2
AA00 1389 Large Deca l - Energy Star 9- 36
AA00 1389 Large Deca l - Energy Star 83- 16
AA00 2209 Decal - Paper Size 83- 12
AA01 2080 Dust Filter 9- 26
AA04 3364 Timing Bel t - S3M300 67- 17
AA04 3368 Timing Bel t - S3M609 67- 28
AA04 3373 Timing Bel t - S2M308 55- 23
AA04 3374 Timing Bel t - S2M800 59- 17
AA04 3386 Timing Bel t - 40S2 M 1224 37- 2
AA04 3387 Timing Belt - 40S2M984 37- 1
AA04 3388 Timing Bel t - 60S2 M 180 37- 11
AA04 3392 Drum Timing Belt 63- 3
AA04 3394 Timing Belt - 60S3M459 63- 4
AA04 3395 Timing Bel t - 30S3 M 327 63- 19
AA04 3411 Timing Bel t - S2M 300 (A207) 63- 2
AA04 3420 Timing Belt - 80S3M519 63- 5
AA04 3430 Timing Belt - 160S2M330 63- 7
AA04 3456 Timing Bel t - S3M167 21- 12
AA05 0086 Lens Drive W i re - Hor i zontal 31- 20
AA05 0087 Lens Drive W i re - Ver tic al 37- 26
AA05 1023 Release Plate 63- 21
AA05 1023 Release Plate 69- 4
AA05 1025 Release Wire 75- 4
AA06 0103 Solenoid Spring 49- 14
AA06 0228 Spring - Transfer Drum Cleaning Sol 63- 13
AA06 0228 Spring - Transfer Drum Cleaning Sol 67- 14
AA06 0453 Relay Adjus ting Spring 39- 31
AA06 0523 Pick-up Pressure Sping 25- 18
AA06 0523 Pick-up Pressure Sping 27- 18
AA06 0534 Tray Lock Sp ring - 19mm 77- 5
AA06 0572 Pressure Spring 67- 6
AA06 0573 Release Spring 67- 4
AA06 0575 Release Spring 25- 30

AA06 0575 Release Spring 27- 30
AA06 0577 Release Spring 25- 10
AA06 0577 Release Spring 27- 10
AA06 0593 Spring 57- 9
AA06 0595 Tension Spr i ng 37- 12
AA06 0598 Pressure Spr i ng 45- 10
AA06 0636 Pressure Spr i ng 25- 28
AA06 0636 Pressure Spr i ng 27- 28
AA06 0664 Spring - Tightener 67- 11
AA06 2285 Release Spring 75- 3
AA06 2286 Pressure Spr i ng 43- 10
AA06 2291 Pressure Spring 75- 2
AA06 2292 Tension Spring 51- 9
AA06 2293 Roller Cov er Spring 65- 18
AA06 3239 Spring - Handle 19- 20
AA06 3366 Chuck Spring 39- 8
AA06 3367 Pressure Spr i ng 39- 12
AA06 3370 Spring 59- 16
AA06 3487 Spring - 10mm 25- 34
AA06 3487 Spring - 10mm 27- 34
AA06 3499 Pressure Spr i ng 23- 25
AA06 3523 Adjust Sprin g 35- 21
AA06 3532 Spring 73- 14
AA06 3538 Spring - 10mm ( A 204) 15- 8
AA06 3539 Spring - Registration Roller 29- 5
AA06 3552 Driven Roller Spring 65- 20
AA06 6246 Spring 41- 24
AA06 6247 Torsion Spri ng 47- 26
AA06 6260 Shutter Spring 39- 17
AA06 6284 Torsion Spri ng 39- 22
AA06 6286 Pressure Spr i ng 43- 22
AA08 0034 Bushing - 4x5x7 (A204) 15- 7
AA08 0034 Bushing - 4x5x7 19- 37
AA08 0037 Bushing - 6 M m 23- 24
AA08 0156 Bushing - M4 25- 33

91

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

AA08 0156 Bushing - M4 27- 33
AA08 0171 Bushing 29- 7
AA08 0172 Bushing 29- 6
AA08 0186 Bushing - 6mm 41- 12
AA08 0188 Bushing - 5mm 41- 8
AA08 0191 Front Roller Bushing 43- 18
AA08 0195 Bias Roller Bushing - Rear 47- 13
AA08 0197 Rear Rolle r Bus hi ng 43- 9
AA08 0209 Rear Rolle r Housing 43- 11
AA08 0219 Rear Rolle r Bus hi ng 43- 5
AA08 2046 Bushing - 6x12x6 25- 13
AA08 2046 Bushing - 6x12x6 27- 13
AA08 2047 Bushing - 8x16x7 25- 20
AA08 2047 Bushing - 8x16x7 27- 20
AA08 2047 Bushing - 8x16x7 (A207) 29- 23
AA08 2047 Bushing - 8x16x7 65- 3
AA08 2058 Bushing - 6x10x9mm 61- 26
AA08 2061 Bias Roller Bushing - Front 47- 6
AA08 3009 Clutch Rol l er - 8x1 8x11 25- 12
AA08 3009 Clutch Rol l er - 8x1 8x11 27- 12
AA08 3009 Clutch Roller - 8x18x11 (A2 07) 29- 21
AA08 3010 Clutch Rol l er - 6x1 4x10 23- 13
AA08 3016 Roller Clut ch:6x14x10 49- 26
AA11 1208 Paper End Sensor Feeler 55- 5
AA12 0067 Anti Static Brus h 53- 16
AA12 0071 Exit Antistat ic Brush 61- 28
AA13 2184 Motor Cush i on 57- 20
AA13 2186 Collar 75- 8
AA14 0291 Bottom Plate Shaf t 59- 6
AA14 0321 Pick-off Pawl Shaf t 45- 4
AA14 0534 Feed Shaft (A2 04) 23- 11
AA14 0542 Feed Roller Shaft 25- 6
AA14 0542 Feed Roller Shaft 27- 6
AA14 0560 Joint Shaft 45- 26
AA14 0575 Paper Feed Shaft (A206/A207) 23- 11

AA14 0576 LCT Drive Shaft 21- 15
AA14 0599 Scanner Dr ive Shaft 37- 4
AA14 3062 Shoulder Scr ew - M4 61- 15
AA14 3219 Stepped Screw 23- 35
AA14 3301 Stepped Screw - M3x4 73- 10
AA14 3307 Stepped Screw - M3x4 55- 4
AA14 3307 Stepped Screw - M3x4 57- 17
AA14 3410 Stepped Screw - M4 39- 11
AA14 3416 Stepped Screw - M4x3 9- 18
AA14 3417 Shoulder Screw - M4x4 9- 23
AA14 3444 Stepped Screw 75- 26
AA14 3452 Stepped Screw 73- 11
AA14 3459 Knob Serew 39- 34
AA14 3712 Chuck Shaft 39- 5
AA14 3715 Stepped Screw - M5 49- 7
AA14 3730 Stepped Screw 43- 29
AA14 3744 Stepped Screw 43- 19
AA14 5537 Belt Relea se Shaft 47- 21
AA14 5539 Solenoid Shaft 65- 4
AA14 5794 Front Suppor t Shaf t 43- 20
AA14 5808 Rear Support Shaf t 43- 12
AA14 8413 Idle Gear Sha ft 39- 25
AA14 8439 Thermistor Shaft 43- 21
AA14 8447 Guide Pin - Platen Cover 11- 10
AA15 0231 Seal - 15x30 41- 20
AA15 0234 Mylar Seal - Base 39- 28
AA15 0368 Shielding Plate - Lens Cover 31- 4
AA15 0369 Original Sensor Seal 31- 2
AA15 0377 Shutter Seal 39- 20
AA15 0380 Seal Front Ho l der 45- 15
AA15 0381 Seal Rear Holder 45- 33
AA15 0382 Entrance Seal 41- 2
AA15 0389 Drum Guide Seal 45- 12
AA15 1177 Seal - 5x82x4 73- 21
AA15 1809 Rear Seal 45- 9

92

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

AA15 1894 Seal - 67x53x2 39- 2
AA15 1935 Seal - 38x32x2.5 41- 4
AA15 1941 Right Shield - Development Case 31- 3
AA15 1942 Side Seal 45- 23
AA15 1943 Front Seal 45- 6
AA15 1944 Rear Seal 45- 8
AA15 1945 Joint Seal 43- 28
AA15 2245 Front Drum Seal 45- 13
AA15 2246 Rear Drum Seal 45- 31
AA15 2330 Magnifi cat ion Seal 31- 12
AA15 2332 Seal - 9x351 47- 17
AA15 2334 Second Mylar 41- 26
AA16 1067 Cushion - M ot or 57- 19
AA16 2067 Platen Cover Pad 11- 6
AA16 2068 Guide Plate Pad 53- 12
AB01 0341 Gear - 18Z 45- 1
AB01 0342 Idle Gear - 20z 43- 17
AB01 0343 Idle Gear - 14z 43- 16
AB01 0344 Roller Gea r - 20Z 43- 15
AB01 1133 Gear - 49Z 21- 14
AB01 1153 Idle Gear - 25z 67- 18
AB01 1165 Gear - 32Z 57- 5
AB01 1166 Gear - 33Z 55- 11
AB01 1167 Gear - 25Z 57- 15
AB01 1343 Idle Gear - 23z 23- 9
AB01 1344 Gear - 16Z 23- 27
AB01 1345 Gear - 20Z 23- 28
AB01 1346 Gear - 27Z 23- 31
AB01 1357 Collecti on C oil G ear - 15Z 45- 30
AB01 1358 Driven Gear 43- 4
AB01 1359 Joint Drive Gear - 20Z 45- 27
AB01 1360 Idle Gear - 19Z 45- 20
AB01 1361 Drive Gea r - 33Z 45- 14
AB01 3343 Gear - 22Z 41- 9
AB01 3420 Gear - 18Z 25- 22

AB01 3420 Gear - 18Z 27- 22
AB01 3485 Gear - 20Z 29- 3
AB01 3486 Gear - 14Z 29- 11
AB01 3868 Gear - 16Z 17- 14
AB01 3872 Fusing Cam Gear - 28z 63- 17
AB01 3875 Reverse Gear - 27z 67- 26
AB01 3881 Gear - 31Z 59- 12
AB01 3882 Gear - 40Z 49- 20
AB01 3883 Idle Gear - 25z 49- 1
AB01 3884 Exit Gear - 17z 51- 3
AB01 3885 Idle Gear - 20z 51- 2
AB01 3889 Gear - 24Z 61- 27
AB01 3909 Idle Gear 41- 10
AB01 3911 Gear 41- 11
AB01 3914 Gear - 17Z 41- 22
AB01 3915 Gear - 26Z 41- 23
AB01 3916 Belt Drive Gear - 25z 47- 11
AB01 3917 Toner Supp ly G ear - 14Z 65- 2
AB01 3918 Drive Gea r - 35z 67- 20
AB01 7129 Gear - 20Z AND 72Z 37- 17
AB01 7332 Gear - 24Z/41Z 57- 14
AB01 7335 Timing Pulley - 22Z/37Z 67- 21
AB01 7336 Timing Pulley - 30Z/35Z 67- 24
AB01 7337 Gear - 15Z/55Z 57- 4
AB01 7339 End Fence Gear - 22z/58z 59- 14
AB01 7345 Timing Pul ley - 35Z 63- 18
AB01 7346 Exit Gear 63- 9
AB01 7347 Idle Gear 39- 24
AB01 7360 Gear Pulle y 31- 19
AB01 7360 Gear Pulley 37- 8
AB01 7361 Gear - 24Z/56Z 31- 21
AB01 7361 Gear - 24Z/56Z 37- 18
AB01 7362 Gear - 25Z/32Z 37- 7
AB01 7365 Coupled Gear - 15z/22z 41- 21
AB01 7366 Paddle Gea r 41- 14

93

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

AB01 7367 Right Paddle Roller 41- 19
AB01 7368 Cleaning Drive Gear - 17Z/46Z/18Z 65- 7
AB01 7369 Transfer Be lt Pull ey - 24Z/20Z 65- 22
AB01 7370 Development Pulley - 46Z/31Z 65- 24
AB01 7373 Idle Cam - 16/ 28Z 45- 25
AB01 7374 Drive Gea r - 12Z 45- 18
AB01 7375 Drive Gea r - 16Z 45- 17
AB01 7376 Separation Paw l C am - 40Z 45- 21
AB01 7377 Gear - 25Z 67- 22
AB01 7385 Gear - 17Z/24Z 65- 29
AB01 7386 Cleaning Cam - 24Z 65- 1
AB01 7388 Blade Cam - 40 Z 45- 19
AB01 7400 Gear- 18z/6 8z 59- 13
AB03 0281 Timing Pulley - 28Z 21- 9
AB03 0455 Tightene r Pull ey - 8x20x13 67- 13
AB03 0463 Fusing Cam Pulley - 35Z 63- 16
AB03 0464 Timing Pul ley - 30Z 67- 29
AB03 0465 Timing Pul ley - 25Z 67- 16
AB03 0466 Timing Pul ley - 20Z 25- 14
AB03 0466 Timing Pul ley - 20Z 27- 14
AB03 0466 Timing Pul ley - 20Z 29- 32
AB03 0473 End Fence Pulley - 22z 59- 11
AB03 0474 Pulley - 24Z 55- 22
AB03 0486 Timing Pulley - 24Z 37- 9
AB03 0487 Timing Pul ley - 44Z 37- 16
AB03 0489 Timing Pul ley - 22Z 37- 15
AB03 0492 Pulley - 25/25/34/125Z 63- 6
AB03 0494 Drum Pulley - 75Z 65- 14
AB03 0536 Pulley - 18T S2M 61- 14
AB03 2059 Driven Pul ley 31- 14
AB03 2059 Driven Pul ley 37- 23
AB03 3064 Drive Pulle y - 34 Z/ 25Z 67- 19
AB03 3069 Timimn g Pul l ey - 22z/44z 37- 3
AB04 0015 Spring Clutch - Tray Bottom Plate 57- 12
AC01 2060 Exposure Glass - A3t-3.2 9- 20

AC03 0103 1st Mirror 33- 13
AC03 0106 4/5 Mirror 35- 16
AC03 0107 6th Mirror 37- 20
AC03 5022 Rear Mirror Clamp - 1st Mirror 33- 2
AC04 2113 Left Original Scal e - A4 9- 19
AC04 2117 Left Original Scal e - LT 9- 19
AC04 2120 Rear Original Scal e - A4 9- 22
AC04 2124 Rear Original Scal e - LT 9- 22
AD02 5019 Drum Pick-off Pawl 45- 2
AD02 7004 Charge Roller 43- 13
AD03 7045 Toner Collectio n C oi l 41- 13
AD04 3035 Toner Collectio n C oi l 45- 16
AE01 1045 Hot Roller 49- 19
AE02 0050 Pressure Rol l er 51- 10
AE03 0022 Bearing - 12 x24x64m 51- 11
AE03 0026 Ball Bearin g - 30 x42x7 49- 21
AE03 1028 Bushing - 4mm 49- 27
AE03 1028 Bushing - 4mm 51- 22
AE04 0019 Oil Supply R oll er 49- 25
AE04 2030 Cleaning Roller 51- 23
AE04 4019 Hot Roller Stri pper 49- 15
AF01 0018 Duplex Tray 59- 31
AF01 3003 Bottom Plate Pad - Duplex 59- 2
AF01 3014 Bottom Plate Pad 17- 9
AF01 5027 Paper Size Slider 17- 13
AF01 6084 Front Side Fence 17- 3
AF01 6085 Rear Side Fence 17- 11
AF01 6160 Rear Side Fence 59- 3
AF01 6161 Front Side Fence 59- 4
AF01 7012 End Fence 17- 7
AF02 0316 Lower Registration R ol l er 29- 13
AF02 0317 Stack Roller 55- 15
AF02 0319 Transport Roller 55- 6
AF02 0320 Right Transport Roller 55- 7
AF02 0321 Paper Feed Drive Roller 27- 29

94
