Ricoh FT5035-S PARTS CATALOG ST29



PARTS CATALOG

INTRODUCTION

This chapter ins tr ucts you the numbers and names of parts on th i s m achine.

INDEX to PARTS CATALOG

1.EXTERIOR (A658) .............................................................................. 2

2.STAPLE UNIT (A658).......................................................................... 4

3.TRANSPORT SECTION (A658).......................................................... 6

4.BIN DRIVE SECTION (A658).............................................................. 8

5.FRAME AND ELECTRICAL (A658) .................................................... 10

6.DECAL AND DOCUMENT (A658) ...................................................... 12

PARTS INDEX ........................................................................................ 17

April, 10’97

1. EXTERIOR (A658)

2

1. EXTERIOR (A658)

Index
No.

1 A658 1541 Lower Cover 1
2 A658 1551 Rear Cover 1
3 A658 1511 Upper Cover 1
4 A658 1181 Coupli ng Frame 1
5 A555 1231 Gate Pawl Bracket 1
6 AA14 3396 Screw - M4X4 2
7 A658 1146 Safety Switch Lever 1
8 A658 2116 Entrance Guide 1
9 A658 1142 Release Guide Plate 1
10 A555 6111 Door Stopper 1
11 A555 1566 Release Handle Pawl 1
12 A555 4156 Plate Nut - M4 1
13 A555 1551 Grip 1
14 AA06 0601 Release Spring 1
15 A658 1161 Bracket Knob 1
16 A658 1521 Front Cover 1
17 A658 1531 Stapler Door 1
18 A658 1168 Magnetic Catch 1
19 A658 1591 Door Sheet 1
20 5447 2681 Snap Ring 2
21 A658 1820 Decal - Misfeed Removal 1
22 A658 1830 Decal - Staple 1
23 A658 1169 Magnetic Vatch Mylar 1
24 A658 2117 Paper Extit Guide 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0802 5255 Tapping Screw - M3x8
102 0451 3006B Tapping Screw - M 3x6
103 0344 0060F Philips Truss Head Screw - M4x6
104 0314 0200B Philips Pan Head Screw - M4x20

Part No.

Description

Q’ty Per
Assembly

3

2. STAPLE UNIT (A658)

4

2. STAPLE UNIT (A658)

Index
No.

1 5403 6246 Stepped Screw - Cleaning 1
2 AA06 6567 Spring 1
3 A658 4181 Stapler Drive Bracket 1
4 AA13 2152 Spacer - 8 X 20 X 1 1
5 A658 4182 Staple Fixing Plate 1
6 AA14 0140 Screw - M3x4.5 2
7 AG07 0004 Magnetic Catch 1
8 A658 4192 Magnet Catch Plate 1
9 5442 1659 Stepped Screw - M4 2
10 A658 4171 Stapler Bracket 1
11 A658 5390 Grounding Wire 1
12 AJ01 1011 Stapler - EH155R 1
13 A658 4184 Lower Entrance Guide 1
14 A658 5260 Stapler Harness 1
15 A658 4183 Stapler Inner Cover 1
16 A658 5320 Stapler Sensor H ar ness 1
17 A555 5410 Grounding Harness 1
18 A658 4141 Stapler Support Pla te 1
19 AW02 0049 Photointerruptor - OS - 580213-703 1
20 AW02 0075 Photointerrupter 1
21 A555 4521 Chuck Motor Bracket 1
22 AA04 3226 Timing Belt - 180S2M 1
23 AB01 3919 Gear - 60Z 1
24 A555 4561 Chuck Movement Shaft 2
25 AX04 0056 Stepping Motor - DC9.5V 9.0W 1
26 A499 2444 Middle Belt Roller 4
27 A555 4532 Pressure Arm 1
28 5447 2681 Snap Ring 2
29 A555 4442 Middle Arm 1
30 A555 4426 Arm Link 1
31 AA06 3527 Pressure Spring 1
32 A555 4422 Upper Chuck Pawl 1
33 AA06 3528 Pressure Spring 1
34 A555 4423 Chuck Arm Pad 2
35 A555 4416 Chuck Move Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 A555 4432 Lower Chuck 1
37 A555 4476 Chuck Unit Fixer 1
38 A658 4121 Stapler Cam 1
39 A555 4461 Chuck Movement Pad 2
40 A555 4456 Roller Holder 1
41 A555 4451 Chuck Side Fence 1
42 A300 3759 Spring 1
43 A555 4411 Chuck Move Pl at e 1
44 A658 1850 Decal - Stapler Change 1

101 0450 3008B Tapping Screw - M 3x8
102 1105 0329 Clamp - ES-0510
103 0451 3006B Tapping Screw - M 3x6
104 0314 0060B Philips Pan Head Screw - M4x6
105 0802 5238 Tapping Screw - M4x12
106 0950 4006B Screw - M4X6
107 1105 0287 Wire Saddle
108 0313 0050B Philips Pan Head Screw - M3x5
109 0720 0040E Retaining Ring - M4
110 0951 4008B Philips Screw With Washer - M4x8
111 0951 3006B Philips Screw With Washer - M3x6

Part No.

Description

Q’ty Per
Assembly

5

3. TRANSPORT SECTION (A658)

6

3. TRANSPORT SECTION (A658)

Index
No.

1 A658 5360 Motor Harness 1
2 AX05 0098 DC Motor - D24V 6W 1
3 AB03 0546 Timig Pulley - T23 S2m 1
4 A658 2131 Drive Support Plate 1
5 A658 2152 Motor Upper Cover 1
6 5409 1855 Mounting Pin 1
7 A548 2139 Idle Pulley 2
8 A555 2156 Timing Pulley - 60Z/18Z 1
9 AA04 3471 Timing Belt - B40S2M166 1
10 AA04 3463 Timing Belt - B40S2M316 1
11 AB03 0496 Timing Pulley - 18Z 2
12 A658 2126 Tightner Bracekt 1
13 AA06 0685 Tension Spring:transport:8n 1
14 A377 4417 Support Roller 1
15 A658 2141 Transport Roller 1
16 5447 2681 Snap Ring 3
17 A658 2111 Lower Guide Plate 1
18 5053 0447 Bushing - 6mm 4
19 5442 1659 Stepped Screw - M4 1
20 A658 2124 Front Guide Bracket 1
21 AW02 0092 Photointerrupter 1
22 A658 5330 Paper Exit Harness 1
23 A658 2142 Exit Roller 1
24 A658 2121 Upper Entrance Guide 1
25 A658 2147 Grounding Plate 1
26 AA06 6566 Spring 1
27 AA06 6565 Spring 1
28 A555 2161 Anti Static Brush 1
29 AA06 3553 Pressure Spring 2
30 AA08 0225 Bushing - M6 2
31 AF02 2096 Roller:driven 1
32 A658 2125 Driven Roller Cover 1
33 A658 1840 Decal - Release Guide 1
34 A658 2151 Transport Drive Cover 1
35 AA14 3478 Stepping Screw - M9 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0451 3006B Tapping Screw - M 3x6
102 0574 0050E Hexagon Headless Set Screw - M4x5
103 0720 0040E Retaining Ring - M4
104 0450 3008B Tapping Screw - M 3x8
105 0807 4103 Spacer - 0.5mm
106 1105 0200 Clamp
107 0314 0060B Philips Pan Head Screw - M4x6

Part No.

Description

Q’ty Per
Assembly

7

4. BIN DRIVE SECTION (A658)

8

4. BIN DRIVE SECTION (A658)

Index
No.

1 A658 3121 Cam Shaft 2
2 AA04 3464 Timing Belt - B80S3M264 1
3 AA04 3466 Timing Belt - B80S5M475 2
4 A658 3124 Shading Plate 2
5 A377 1116 Stud Screw - M6 2
6 A658 3144 Gear - 18Z 1
7 A658 3145 Gear - 26Z 2
8 A658 1131 Base Ass’y 1

9 A658 3125 H.p. Sensor Bracket 1
10 AW02 0075 Photointerrupter 1
11 A658 5310 Jogger Sensor Harness 1
12 A658 4115 Jogger Motor Bracket 1
13 AX04 0095 Stepping Motor - 24V 1
14 AA06 0672 Belt Spring 1
15 A658 1581 Timing Belt Cover 1
16 A555 3102 Bin Ass’y 1
17 A377 3447 Small Guide R ol l er 2
18 AA04 3465 Timing Belt - 214P2M8 1
19 A555 3159 Timing Pulley 1
20 A548 2139 Idle Pulley 1
21 A658 3136 Tightnerbracket 1
22 AA06 0671 Tension Spring 1
23 A658 3131 Motor Bracke t 1
24 AB03 0547 Timing Pulley - T30 S2M 1
25 AX05 0110 Stepping Motor - 2.4V 7.2W 1
26 A658 4118 Jogger Drive Shaft 1
27 AB03 0389 Timing Pulley - Jogger - Dri ve 2
28 A658 4117 Lower Shaft Bracket 1
29 A354 4475 Timing Belt Stopper - Side fence 1
30 AA04 3403 Timing Belt - B40S3M858 2
31 A658 4111 Jogger Shaft 1
32 AA06 3554 Pressure Spring 1
33 5447 2681 Snap Ring 1
34 A658 3123 Front Lower Bracket 1
35 A658 3122 Front Upper Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 AB03 0388 Pulley - 16Z 1
37 A555 4141 Jogger Tension Bracket 1

101 0741 3006 Ball Bearing - 6x17x6mm
102 0451 3006B Tapping Screw - M 3x6
103 0805 0088 Retaining Ring - M6
104 0805 0089 Retaining Ring - M4
105 0313 0050B Philips Pan Head Screw - M3x5
106 0951 4006B Philips Screw With Washer - M4x6
107 0720 0040E Retaining Ring - M4
108 0720 0060E Retaining Ring - M6
109 1105 0349 Edge Saddle
110 0574 0050E Hexagon Headless Set Screw - M4x5
111 0314 0080B Philips Pan Head Screw - M4x8
112 0805 3384 Bushing - 5mm
113 1005 0946 Stepping Motor Cushion

Part No.

Description

Q’ty Per
Assembly

9

5. FRAME AND ELECTRICAL (A658)

10

5. FRAME AND ELECTRICAL (A658)

Index
No.

1 A658 5350 Relay Harness - Bin Sensor 1
2 A658 5280 Main Harness 1
3 A658 5105 Main Control Board 1
4 A658 1151 Upper Cover 1
5 AW03 0071 Optical Fiber 1
6 A658 5250 Interface Harness Ass‘y 1

7 AA06 3530 Pressure Spring 1
8 A658 1171 Bin Guide 4
9 A658 1126 Lower Stay 1
10 AW02 0087 Photosensor - LNB4301 1
11 A658 5380 Relay Harnes s - Bin Sensor 1
12 AW02 0049 Photointerruptor - OS - 580213-703 1
13 A658 3141 Bin H.p. Sensor Bracket 1
14 A658 4116 Jogger Lower Guide 1
15 AW02 0075 Photointerrupter 1
16 A658 5370 Relay Harness - Jogger Sensor 1
17 A658 1136 Stay 2
18 A658 1176 Screw Cover 1
19 A658 1135 Upper Right Stay 1
20 A658 1172 Upper Joger Guide 1
21 A658 1137 Upper Stay 1
22 A658 1138 Upper Sensor Bracket 1
23 AW02 0088 Photosensor - PNB43 01 1
24 A658 5340 Bin Sensor Harness 1
25 A658 1167 Switch Lever 1
26 AA14 3358 Stepped Screw - M4x3 1
27 A658 1166 Switch Bracket 1
28 5403 6246 Stepped Screw - Cleaning 1
29 AG07 0004 Magnetic Catch 1
30 A658 4191 Stapler Entranc ce G ui de 1
31 A555 1221 Roller Brcaket 2
32 A658 1143 Release Guide Bracket 2
33 A555 3183 Switch Bracket 1
34 A555 3182 Stapler Actuato r Swi t ch 1
35 A555 4156 Plate Nut - M4 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 A658 1156 Lower Joint Bracket 1
37 A658 1183 Stopper Cover 1
38 A658 1139 Missfeed Removal Guide 2

101 0451 3006B Tapping Screw - M 3x6
102 1107 0752 Fuse (glass Case) - 5A - 250 V
103 1105 0291 11050291
104 1105 0292 11050292
105 1106 0241 11060241
106 1105 0409 11050409
107 1105 0193 11050193
108 0950 4006B Screw - M4X6
109 1105 0322 Cord Bushing
110 1105 0328 Harness Clamp - ES-0505
111 1105 0200 Clamp
112 0313 0140B Philips Pan Head Screw - M3x14
113 1204 2384 Interlock Switch
114 0720 0060E Retaining Ring - M6
115 1106 0459 Bushing - 20.2mm
116 0314 0060B Philips Pan Head Screw - M4x6
117 0720 0040E Retaining Ring - M4
118 1105 0267 Wire Clamp
119 1106 0289 Bushing - SR-5N-1

Part No.

Description

Q’ty Per
Assembly

11

6. DECAL AND DOCUMENT (A658)

12

6. DECAL AND DOCUMENT (A658)

Index
No.

1 A555 1850 Decal - Staple Position 1
2 A658 1850 Decal - Staple Change 1
3 A658 1830 Decal - Staple 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

Part No.

Description

Q’ty Per
Assembly

13

PARTS INDEX

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A658 1126 Lower Stay 11- 9
A658 1131 Base Ass’y 9- 8

A658 1135 Upper Right Stay 11- 19
A658 1136 Stay 11- 17
A658 1137 Upper Stay 11- 21
A658 1138 Upper Sensor Bracket 11- 22
A658 1139 Missfeed Removal Guide 11- 38
A658 1142 Release Guide Plate 3- 9
A658 1143 Release Guide Bracket 11- 32
A658 1146 Safety Switch Lever 3- 7
A658 1151 Upper Cover 11- 4
A658 1156 Lower Joint Bracket 11- 36
A658 1161 Bracket Knob 3- 15
A658 1166 Switch Bracket 11- 27
A658 1167 Switch Lever 11- 25
A658 1168 Magnet i c C at ch 3- 18
A658 1169 Magneti c Vat ch Mylar 3- 23
A658 1171 Bin Guide 11- 8
A658 1172 Upper Joger Guide 11- 20
A658 1176 Screw Cover 11- 18
A658 1181 Coupling Frame 3- 4
A658 1183 Stopper Cover 11- 37
A658 1511 Upper Cover 3- 3
A658 1521 Front Cover 3- 16
A658 1531 Stapler Door 3- 17
A658 1541 Lower Cover 3- 1
A658 1551 Rear Cover 3- 2
A658 1581 Timing Belt Cover 9- 15
A658 1591 Door Sheet 3- 19
A658 1820 Decal - M isfeed Removal 3- 21
A658 1830 Decal - Staple 3- 22
A658 1830 Decal - Staple 13- 3
A658 1840 Decal - Release Guide 7- 33
A658 1850 Decal - Stapler Change 5- 44
A658 1850 Decal - Staple Change 13- 2

A658 2111 Lower Guide Plate 7- 17
A658 2116 Entrance G uide 3- 8
A658 2117 Paper Extit Guide 3- 24
A658 2121 Upper Entrance Guide 7- 24
A658 2124 Front Guide Bracket 7- 20
A658 2125 Driven Roller Cover 7- 32
A658 2126 Tightner Bra cekt 7- 12
A658 2131 Drive Support Plate 7- 4
A658 2141 Transport Roller 7- 15
A658 2142 Exit Roller 7- 23
A658 2147 Grounding Plate 7- 25
A658 2151 Transport Drive Cover 7- 34
A658 2152 Motor Upper Cover 7- 5
A658 3121 Cam Shaft 9- 1
A658 3122 Front Upper Bracket 9- 35
A658 3123 Front Lower Bracket 9- 34
A658 3124 Shading Plate 9- 4
A658 3125 H.p. Sensor Bracket 9- 9
A658 3131 Motor Bracket 9- 23
A658 3136 Tightnerbracket 9- 21
A658 3141 Bin H.p. Sensor Bracket 11- 13
A658 3144 Gear - 18Z 9- 6
A658 3145 Gear - 26Z 9- 7
A658 4111 Jogger Shaft 9- 31
A658 4115 Jogge r Mot o r Bracket 9- 12
A658 4116 Jogge r Lo w er Guide 11- 14
A658 4117 Lower Shaft Bracket 9- 28
A658 4118 Jogger Drive Shaft 9- 26
A658 4121 Stapler Cam 5- 38
A658 4141 Stapler Sup por t Pla te 5- 18
A658 4171 Stapler Bracket 5- 10
A658 4181 Stapler Drive Bracket 5- 3
A658 4182 Staple Fixing Plate 5- 5
A658 4183 Stapler Inner Cover 5- 15
A658 4184 Lower Entrance Guide 5- 13

16

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A658 4191 Stapler Entr ancce Guide 11- 30
A658 4192 Magnet C at ch Plat e 5- 8
A658 5105 Main Control Board 11- 3
A658 5250 Interface Harness Ass‘y 11- 6

A658 5260 Stapler Harness 5- 14
A658 5280 Main Harness 11- 2
A658 5310 Jogge r Sen sor Harness 9- 11
A658 5320 Stapler Sen sor H ar ness 5- 16
A658 5330 Paper Exit Harness 7- 22
A658 5340 Bin Sensor Harness 11- 24
A658 5350 Relay Har ness - Bin Sensor 11- 1
A658 5360 Motor Harness 7- 1
A658 5370 Relay H ar ness - Jogger Sensor 11- 16
A658 5380 Relay H ar ness - Bin Sensor 11- 11
A658 5390 Grounding Wire 5- 11

AA04 3226 Timing Belt - 180 S2M 5- 22
AA04 3403 Timing Belt - B40S3 M 858 9- 30
AA04 3463 Timing Belt - B40S2 M 316 7- 10
AA04 3464 Timing Belt - B80S3M264 9- 2
AA04 3465 Timing Belt - 214 P2M 8 9- 18
AA04 3466 Timing Belt - B80S5M475 9- 3
AA04 3471 Timing Belt - B40S2M166 7- 9
AA06 0601 Release Spring 3- 14
AA06 0671 Tension Spring 9- 22
AA06 0672 Belt Spring 9- 14
AA06 0685 Tension Spri ng: t ransport:8n 7- 13
AA06 3527 Pressure Spring 5- 31
AA06 3528 Pressure Spring 5- 33
AA06 3530 Pressure Spring 11- 7
AA06 3553 Pressure Spring 7- 29
AA06 3554 Pressure Spring 9- 32
AA06 6565 Spring 7- 27
AA06 6566 Spring 7- 26
AA06 6567 Spring 5- 2
AA08 0225 Bushing - M6 7- 30
AA13 2152 Spacer - 8 X 20 X 1 5- 4
AA14 0140 Screw - M3x4.5 5- 6
AA14 3358 Stepped Screw - M4 x3 11- 26
AA14 3396 Screw - M4X4 3- 6
AA14 3478 Stepping Screw - M9 7- 35
AB01 3919 Gear - 60Z 5- 23
AB03 0388 Pulley - 16Z 9- 36
AB03 0389 Timing Pulley - Jogger - Drive 9- 27
AB03 0496 Timing Pulley - 18Z 7- 11
AB03 0546 Timig Pulley - T23 S2m 7- 3
AB03 0547 Timing Pulley - T30 S2M 9- 24
AF02 2096 Roller:driven 7- 31
AG07 0004 Magnetic Catch 5- 7
AG07 0004 Magnetic Catch 11- 29
AJ01 1011 Stapler - EH155R 5- 12

17

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

AW02 0049 Photointerruptor - OS - 580213- 703 5- 19
AW02 0049 Photointerruptor - OS - 580213- 703 11- 12
AW02 0075 Photointerrupter 5- 20
AW02 0075 Photointerrupter 9- 10
AW02 0075 Photointerrupter 11- 15
AW02 0087 Photosensor - LNB4301 11- 10
AW02 0088 Photosensor - PNB4301 11- 23
AW02 0092 Photointerrupter 7- 21
AW03 0071 Optical Fiber 11- 5
AX04 0056 Stepping M ot or - DC 9. 5V 9. 0W 5- 25
AX04 0095 Stepping M ot or - 24V 9- 13
AX05 0098 DC Motor - D24V 6W 7- 2
AX05 0110 Stepping M ot or - 2.4V 7. 2W 9- 25

A300 3759 Spring 5- 42
A354 4475 Timing Belt Stopper - Side fence 9- 29
A377 1116 Stud Screw - M6 9- 5
A377 3447 Small Guide Roller 9- 17
A377 4417 Support Roller 7- 14
A499 2444 Middle Belt Roller 5- 26
A548 2139 Idle Pulley 7- 7
A548 2139 Idle Pulley 9- 20
A555 1221 Roller Brc aket 11- 31
A555 1231 Gate Pawl Bra cket 3- 5
A555 1551 Grip 3- 13
A555 1566 Relea se H andle Pawl 3- 11
A555 1850 Decal - Sta ple Position 13- 1
A555 2156 Timing Pulley - 60Z/18Z 7- 8
A555 2161 Anti Static Br ush 7- 28
A555 3102 Bin Ass’y 9- 16

A555 3159 Timing Pulley 9- 19
A555 3182 Stapler Act uat or Sw itc h 11- 34
A555 3183 Switch Bra cket 11- 33
A555 4141 Jogger Tension Bracket 9- 37
A555 4156 Plate Nut - M4 3- 12
A555 4156 Plate Nut - M4 11- 35
A555 4411 Chuck Move Plate 5- 43
A555 4416 Chuck Move Bracket 5- 35
A555 4422 Upper Chuck Pawl 5- 32
A555 4423 Chuck Arm Pad 5- 34
A555 4426 Arm Link 5- 30
A555 4432 Lower Chuck 5- 36
A555 4442 Middle Arm 5- 29
A555 4451 Chuck Side Fence 5- 41
A555 4456 Roller Holder 5- 40
A555 4461 Chuc k M ovement Pad 5- 39
A555 4476 Chuck Unit Fixer 5- 37
A555 4521 Chuck M ot or Bracket 5- 21
A555 4532 Pressure Arm 5- 27

18

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A555 4561 Chuc k M ovement Shaft 5- 24
A555 5410 Gro unding Harness 5- 17
A555 6111 Door Stopper 3- 10
5053 0447 Bushing - 6mm 7- 18
5403 6246 Stepped Screw - Cleaning 5- 1
5403 6246 Stepped Screw - Cleaning 11- 28
5409 1855 Mounting Pin 7- 6
5442 1659 Stepped Screw - M4 5- 9
5442 1659 Stepped Screw - M4 7- 19
5447 2681 Snap Ring 3- 20
5447 2681 Snap Ring 5- 28
5447 2681 Snap Ring 7- 16
5447 2681 Snap Ring 9- 33

0313 0050B P hilip s Pan Head Screw - M3x5 5-108
0313 0050B P hilip s Pan Head Screw - M3x5 9-105
0313 0140B P hilip s Pan Head Screw - M3x14 11-112
0314 0060B P hilip s Pan Head Screw - M4x6 5-104
0314 0060B P hilip s Pan Head Screw - M4x6 7-107
0314 0060B P hilip s Pan Head Screw - M4x6 11-116
0314 0080B P hilip s Pan Head Screw - M4x8 9-111
0314 0200B P hilip s Pan Head Screw - M4x20 3-104
0344 0060F Philips Truss Head Screw - M4x6 3-103
0450 3008B Tapping Screw - M3x8 5-101
0450 3008B Tapping Screw - M3x8 7-104
0451 3006B Tapping Screw - M3x6 3-102
0451 3006B Tapping Screw - M3x6 5-103
0451 3006B Tapping Screw - M3x6 7-101
0451 3006B Tapping Screw - M3x6 9-102
0451 3006B Tapping Screw - M3x6 11-101
0574 0050E Hexagon Headless Set Scr ew - M 4x5 7-102
0574 0050E Hexagon Headless Set Scr ew - M 4x5 9-110
0720 0040E Retaining Ring - M4 5-109
0720 0040E Retaining Ring - M4 7-103
0720 0040E Retaining Ring - M4 9-107
0720 0040E Retaining Ring - M4 11-117
0720 0060E Retaining Ring - M6 9-108
0720 0060E Retaining Ring - M6 11-114
0741 3006 Ball Bearing - 6x17x6mm 9-101
0802 5238 Tapping Screw - M4x12 5-105
0802 5255 Tapping Screw - M3x8 3-101
0805 0088 Retaining Ring - M6 9-103
0805 0089 Retaining Ring - M4 9-104
0805 3384 Bushing - 5mm 9-112
0807 4103 Spacer - 0.5mm 7-105
0950 4006B Screw - M4X6 5-106
0950 4006B Screw - M4X6 11-108
0951 3006B P hilip s Screw With Washer - M3x6 5-111
0951 4006B P hilip s Screw With Washer - M4x6 9-106

19

Part No.

0951 4008B P hilip s Screw With Washer - M4x8 5-110
1005 0946 Stepping M ot or Cushion 9-113
1105 0193 11050193 11-107
1105 0200 Clamp 7-106
1105 0200 Clamp 11-111
1105 0267 Wire Clamp 11-118
1105 0287 Wire Saddle 5-107
1105 0291 11050291 11-103
1105 0292 11050292 11-104
1105 0322 Cord Bushing 11-109
1105 0328 Harness Clamp - ES-0505 11-110
1105 0329 Clamp - ES-0510 5-102
1105 0349 Edge Saddle 9-109
1105 0409 11050409 11-106
1106 0241 11060241 11-105
1106 0289 Bushing - SR-5N-1 11-119
1106 0459 Bushing - 20.2mm 11-115
1107 0752 Fuse (glass Case) - 5A - 250V 11-102
1204 2384 Interlock Switch 11-113

Description

Page and
Index No.

Part No.

Description

Page and
Index No

20
