Ricoh FT5035-S PARTS CATALOG ST26

RICOH ST26 (A554) PARTS CATALOG

INTRODUCTION

This chapter gives the numbers and names of parts in this machine.

INDEX to PARTS CATALOG

1.Exterior (A554)...................................................................................... 2

2.Staple Unit (A554)................................................................................. 4

3.Vertical Transport 1 (A554)................................................................... 6

4.Vertical Transport 2 (A554)................................................................... 8

5.Drive And Electrical Section (A554)...................................................... 10

6.Tray Drive Section (A554)..................................................................... 12

7.Copy Tray Unit (A554).......................................................................... 14

8.Decal And Document (A554)................................................................ 16

PARTS INDEX......................................................................................... 19

January,31’95

1. EXTERIOR (A554)

2

Part No.

1.EXTERIOR (A554)

Index
No.

1 A554 1541 Rear Cover 1
2 A554 1571 Exit Tray 1
3 AA12 0055 Antistatic Brush - 367mm 1
4 A554 1561 Upper Cover 1
5 AA06 6198 Proof Lever Spring 1
6 A374 2251 Proof Lever 1
7 A374 2141 Plate Spring - Upper Cover 2
8 A374 5250 Relay Harness - Bin Sensor 1
9 A554 1591 Lower Harness Cover 1
10 A554 1521 Front Cover 1
11 A374 1611 Hinge - Front Cover Cap 2
12 A554 1531 Front Cover Cap 1
13 A374 4556 Safety Switch Actuator 1
14 A374 3570 Sensor Cover 1
15 AW02 0025 Lower Bin/jam Sensor 1
16 A498 2266 Cushion - 8x40 2
17 A374 1855 Decal - Staple Position 1
18 A554 1861 Decal - Misfeed Removal 1
19 A554 1881 Decal - Staple Supply 1
20 A554 1871 Decal - Stapler Misfeed 1
21 A374 2147 Exit Roller Guide 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0434 0200B Pan Head Self-tapping Screw - M4x20
102 0313 0160B Philips Pan Head Screw - M3x16
103 0951 4008B Philips Screw With Washer - M4x8
104 0434 0060B Philips Tapping Screw - M4x6
105 0720 0040E Retaining Ring - M4
106 0344 0060F Philips Truss Head Screw - M4x6
107 0344 0080F Philips Truss Head Screw - M4x8
108 0710 0050B Hexagon Nut - M5

Description

Q’ty Per
Assembly

3

2. STAPLE UNIT (A554)

4

Part No.

2.STAPLE UNIT (A554)

Index
No.

1 A374 4521 Stapler Bracket 1
2 5054 0536 Magnet Catch Ass’y 1
3 A374 4531 Stapler Plate 1
4 A374 4522 Stapler Rotation Brackdt 1
5 AJ01 1005 Stapler Unit 1
6 A374 4551 Stapler Cover 1
7 AA04 3205 Timing Belt - 83XL 1
8 AB01 1142 Gear - 59Z 1
9 AB01 7275 Coupled Gear - 20/48Z 1
10 A374 4631 Small Side Plate 1
11 A374 4681 Gripper Shaft 1
12 AX04 0056 Stepping Motor - DC9.5V 9.0W 1
13 5409 1238 Rotary Catch 2
14 A374 4658 Upper Girpper Arm 1
15 AA06 6197 Lower Pawl Spring 1
16 A374 4656 Lower Gripper Arm 1
17 A374 4641 Cam Follower 1
18 AA06 0491 Upper Pawl Spring 1
19 A374 5215 Gripper Harness 1
20 AW02 0021 Photointerruptor - 175487-3 6
21 A374 4688 Gripper Connector Cushion 2
22 A374 5220 Gripper Relay Harness 1
23 A374 4667 Drive Cam 1
24 A374 4636 Drive Shaft 1
25 A374 4684 Connector Holder 1
26 A374 4611 Gripper Brackdt 1
27 AA06 0492 Jogger Stopper Spring 1
28 A374 4616 Jogger Stopper 1
29 A374 4621 Large Side Plate 1
30 AA08 2042 Bushing - 6x10x6.5mm 2
31 AA08 0072 Bushing - 6x10x3 2
32 5201 1796 Stepped Screw - M4 4
33 A554 5280 Grounding Harness 1
34 AA08 0074 Bushing - 4x6x6 2
35 5442 1659 Stepped Screw - M4 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 AA14 3062 Shoulder Screw - M4 1
37 A374 5260 Grounding Harness 2

101 0720 0080E Retaining Ring - M8
102 0720 0025E Retaining Ring - M2.5
103 0720 0040E Retaining Ring - M4
104 0951 4006B Philips Screw With Washer - M4x6
105 0632 0140G Parallel Pin
106 1105 0310 Wire Clamp
107 0434 0060B Philips Tapping Screw - M4x6
108 0313 0080B Philips Pan Head Screw - M3x8
109 0313 0050B Philips Pan Head Screw - M3x5
110 1204 2188 Interlock Switch
111 1106 0241 Bushing - 6.7mm
112 1105 0234 Clamp
113 0313 0140B Philips Pan Head Screw - M3x14
114 0413 0082W Tapping Screw - M3x8
115 0950 4006B Screw - M4X6

Description

Q’ty Per
Assembly

5

3. VERTICAL TRANSPORT 1 (A554)

6

Part No.

3.VERTICAL TRANSPORT 1 (A554)

Index
No.

1 A499 2444 Middle Belt Roller 6
2 AA06 3278 Spring 1
3 AA06 2279 Spring 2
4 A554 1161 Hinge Stopper Bracket 1
5 AA06 6235 Spring 1
6 A374 1146 Lower Stopper 1
7 5201 1796 Stepped Screw - M4 4
8 A554 2121 Upper Entrance Guide 1
9 A499 2445 Holder - Middle Belt Roller 6
10 AA06 2280 Spring 2
11 A554 2131 Lower Entrance Guide 1
12 A374 2134 Cushion 2
13 A554 2134 Gate Pawl Guide 1
14 5216 2113 Stepped Screw - Transfer 1
15 A374 1177 Lower Cushion 1
16 A374 1145 Lower Stay Bracket 1
17 A374 1186 Lower Hinge 1
18 A374 1191 Upper Hinge 1
19 A374 3562 Small Cover - Upper Sensor 1
20 AW02 0026 Upper Bin/jam Sensor 1
21 A374 3560 Large Cover - Upper Sensor 1
22 AA06 3239 Spring - Handle 1
23 A374 1625 Opening Handle Bracket 1
24 A554 1581 Release Lever Grip 1
25 AA14 3306 Stepped Screw - M6 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0344 0060F Philips Truss Head Screw - M4x6
102 0314 0040B Philips Pan Head Screw - M4x4
103 0313 0160B Philips Pan Head Screw - M3x16
104 1105 0234 Clamp
105 0434 0060B Philips Tapping Screw - M4x6

Description

Q’ty Per
Assembly

7

4. VERTICAL TRANSPORT 2 (A554)

8

Part No.

4.VERTICAL TRANSPORT 2 (A554)

Index
No.

1 A554 2152 Solenoid Cover 1
2 A374 2182 Bracket - Upper Exit Sensor 1
3 AW02 0049 Photointerruptor - OS - 580213-703 2
4 A554 5230 Transport Harness 1
5 AF02 0272 Relay Roller 1
6 AA08 0071 Bushing -6x10x6 1
7 A374 2181 Spacer 2
8 A374 2183 Bracket - Lower Exit Sensor 1
9 A554 2161 Gate Pawl 1
10 5447 2681 Snap Ring 1
11 A554 2135 Exit Guide Plate 1
12 A554 2171 Vibrating Holder 2
13 AA06 2281 Spring 2
14 AA12 0053 Antistatic Brush - 112mm 2
15 AA12 0052 Antistatic Brush - 62mm 1
16 A554 2172 Vibrating Roller 2
17 A554 2547 Paper Exit Belt 2
18 A554 2548 Paper Exit Shaft 2
19 AF02 0323 Lower Exit Roller 1
20 A374 2541 Exit Roller 2
21 A374 2331 Bin Supportor 1
22 AX11 0035 Solenoid - 24V 4.6W 1
23 AB03 0498 Timing Pulley - 27Z 1
24 A554 2151 Transport Frame 1
25 AA08 0141 Bushing - 5x12x4mm 5
26 AF02 0270 Upper Exit Roller 1
27 AA04 3362 Timing Belt - B40S2M520 1
28 AB01 7273 Sprocket/gear - 16/20Z 1
29 AA08 0030 Bushing - 5x13x7 1
30 A554 2141 Roller Bracket 1
31 A374 2190 Tightener Bracket 1
32 A374 2207 Pulley - 12M 1
33 A374 2200 Tension Arm 1
34 AA06 6196 Tension Spring 1
35 AA06 0611 Spring 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 A554 5280 Grounding Harness 1
37 AA06 2277 Spring 1
38 A554 2168 Solenoid Lever 1
39 A554 2156 Solenoid Bracket 1
40 AA06 2278 Spring 1

101 0720 0040E Retaining Ring - M4
102 0720 0030E Retaining Ring - M3
103 0950 4006B Screw - M4X6
104 0623 0100E Spring Pin - 3x10mm
105 0313 0040B Philips Pan Head Screw - M3x4
106 0434 0122W Pan Head Self-tapping Screw - M4x12

Description

Q’ty Per
Assembly

9

5. DRIVE AND ELECTRICAL SECTI ON (A554)

10

Part No.

5.DRIVE AND ELECTRICAL SECTI ON (A554)

Index
No.

1 A554 3111 Bin Drive Bracket 1
2 AB01 3731 Gear - 54Z 1
3 AB01 3730 Gear - 18Z 1
4 AX05 0074 DC Motor - 24V - 9.9W 1
5 A374 3120 Worm Gear Shaft 1
6 A374 3115 Encoder Disk 1
7 A374 3126 Bin Sensor Bracket 1
8 5053 0447 Bushing - 6mm 1
9 AB01 3709 Worm Gear 1
10 AA04 3203 Timing Belt - 77XL 1
11 AB03 0399 Pulley - 52Z 1
12 AW02 0021 Photointerruptor - 175487-3 6
13 AX05 0057 Stepping Motor - DC24V 3.84W 1
14 A374 2237 Stepping Motor Bracket 1
15 A554 2216 Encoder 1
16 AA04 3450 Timing Belt - 100XL 1
17 AB03 0497 Timing Pulley - 16Z 1
18 A374 2218 Pulley - 12M 1
19 A374 3187 Limit Switch Bracket - Upper 1
20 A374 2234 Encoder Sensor Bracket 1
21 A554 5270 Interface Harness 1
22 A554 5240 Bin Harness 1
23 A554 1198 Harness Bracket 1
24 A374 1195 Door Switch Bracket 1
25 A554 5200 Main Harness 1
26 A374 4711 Gripper Sensor Bracket 1
27 A374 5600 Fhotointerrupter - OS-580213-704 1
28 A374 1622 Bin Shaft Cover - Front 1
29 A374 1623 Harness Cover 1
30 AW03 0066 Optical Fiber - 500mm 1
31 A554 5100 Main Control Board 1
32 A554 5103 IC - 256K-X8-150NS 1
33 A554 3116 Motor Bracket 1
34 A351 4721 Drive Motor Grommet 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 0720 0040E Retaining Ring - M4
102 0434 0060B Philips Tapping Screw - M4x6
103 0951 4006B Philips Screw With Washer - M4x6
104 0574 0030E Hexagonal Set Screw - M4x3
105 0313 0050B Philips Pan Head Screw - M3x5
106 1204 2233 Microswitch -AH715254N
107 0313 0140B Philips Pan Head Screw - M3x14
108 0574 0040E Hexagon Headless Set Screw - M4x4
109 1105 0267 Wire Clamp
110 1105 0163 Locking Support
111 1105 0234 Clamp
112 1105 0291 Wire Saddle
113 1106 0250 Cord Stopper - 115V
114 1204 2188 Interlock Switch
115 1107 0748 Fuse - 2A, 250V
116 1106 0241 Bushing - 6.7mm
117 0740 3206 Ball Bearing - 6x19x6
118 1005 0933 Cushion - Stepper Motor
119 1105 0328 Harness Clamp - Es-0505
120 0324 0100B Philips Sunk Screw - M4x10
121 0951 3006B Philips Screw With Flat Washer - M3x6

Description

Q’ty Per
Assembly

11

6. TRAY DRIVE SECTION (A554)

12

Part No.

6.TRAY DRIVE SECTION (A554)

Index
No.

1 AB01 7274 Gear - 54Z 1
2 AA05 0084 Wire - Bin - Upper Lower 2
3 5053 0419 Bushing - 10mm 3
4 A374 3131 Wire Drive Shaft 1
5 AB03 0389 Timing Pulley - Jogger - Drive 2
6 AA08 0142 Bushing - 5x10x4mm 1
7 A374 4124 Jogger Drive Shaft 1
8 AA08 0140 Bushing - 3x9x5mm 1
9 A374 3165 Bin Block Stopper 2
10 A469 3175 Idle Pulley Stud - Short 1
11 5887 4185 Idler Pulley 1
12 A374 4141 Jogger Motor Bracket 1
13 AX04 0057 Stepping Motor - DC24V 3.72W 1
14 AB03 0388 Pulley - 16Z 2
15 AA04 3204 Timing Belt - 211XL 2
16 AA06 3240 Jogger - Spring 2
17 A374 4171 Upper Jogger Holder 1
18 A374 4151 Jogger Tension Bracket - Upper 1
19 A421 2521 Spring - Paper Volume 2
20 A374 1131 Upper Jogger Stay 1
21 A374 4131 Jogger Shaft 1
22 A374 1136 Lower Stay 1
23 A374 1142 Shaft - Lower Stay Roller 2
24 A374 1141 Lower Stay Roller 2
25 A374 3160 Bin Block Shaft - Right 1
26 A374 3142 Bin Support Block - Right Front 1
27 A374 3146 Bin Support Block - Right Rear 1
28 A374 3525 Cam Roller 46
29 A374 3521 Bin Roller 86
30 A374 3163 Bin Block Shaft - Left 1
31 A374 3156 Bin Support Block - Left 2
32 A374 4181 Lower Jogger Holder 1
33 AW02 0021 Photointerruptor - 175487-3 6
34 A374 1132 Lower Jogger Stay 1
35 A374 4161 Lower Tension Bracket 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

36 AA04 3204 Timing Belt - 211XL 2
37 AB03 2051 Wire Pulley - M26.5 1
38 A374 4617 Small Jogger Stopper 1

101 1105 0243 Wire Saddle
102 0313 0050B Philips Pan Head Screw - M3x5
103 0720 0030E Retaining Ring - M3
104 0720 0040E Retaining Ring - M4
105 0951 4006B Philips Screw With Washer - M4x6
106 0434 0060B Philips Tapping Screw - M4x6
107 0951 4008B Philips Screw With Washer - M4x8
108 0633 0250G Pin - M3x25
109 0720 0080E Retaining Ring - M8
110 1105 0291 Wire Saddle

Description

Q’ty Per
Assembly

13

7. COPY TRAY UNIT (A554)

14

Part No.

7.COPY TRAY UNIT (A554)

Index
No.

1 AB03 2052 Wire Pulley - M22.8 7
2 A374 3191 Pulley Bracket 1
3 A374 3196 Limit Switch Bracket - Lower 1
4 AA06 0490 Limit Switch Spring 1
5 AA14 3404 Stepped Screw - M4 6
6 A374 1621 Bin Shaft Cover - Rear 1
7 A374 3179 Rear Pulley Bracket 1
8 A374 4562 Stapler Guide 1
9 A374 3176 Front Pulley Bracket 1
10 A374 3550 Bin Link 2
11 A554 3535 Support Bin Ass’y 1
12 A374 3525 Cam Roller 46
13 A374 3555 Paper Support Plate 1
14 A374 3522 Bin Support Film 1
15 A554 3505 Bin Ass’y 19
16 A554 3515 Bin Guide Mylar 20
17 AA06 6205 End Fence Spring 20
18 A374 3516 End Fence 1
19 A374 3521 Bin Roller 86
20 A374 3520 Paper Support Film 19
21 A374 3513 Pressure Guide Mylar 19
22 A554 3507 Lower Bin Ass’y 1
23 A374 3526 Bin Spacer 2

Part No.

Description

Q’ty Per
Assembly

Index
No.

101 1204 2234 Microswitch - AH735254N
102 0313 0140B Philips Pan Head Screw - M3x14
103 0720 0060E Retaining Ring - M6
104 0720 0040E Retaining Ring - M4
105 0313 0050B Philips Pan Head Screw - M3x5
106 0434 0060B Philips Tapping Screw - M4x6
107 1105 0267 Wire Clamp
108 1105 0291 Wire Saddle
109 1106 0411 Bushing - 11.5mm

Description

Q’ty Per
Assembly

15

8. DECAL AND DOCUMENT (A554)

16

Part No.

8. DECAL AND DOCUMENT (A554)

Index
No.

1 A374 1855 Decal - Staple Position 1
2 A554 1861 Decal - Misfeed Removal 1
3 A554 1871 Decal - Stapler Misfeed 1
4 A554 1881 Decal - Staple Supply 1
5 A554 8610 Installation Procedure 1
6 A555 1850 Decal - Staple Position 1

Part No.

Description

Q’ty Per
Assembly

Index
No.

Description

Q’ty Per
Assembly

17

PARTS INDEX

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A554 1161 Hinge Stopper Bracket 7- 4
A554 1198 Harness Bracket 11- 23
A554 1521 Front Cover 3- 10
A554 1531 Front Cover Cap 3- 12
A554 1541 Rear Cover 3- 1
A554 1561 Upper Cover 3- 4
A554 1571 Exit Tray 3- 2
A554 1581 Release Lever Grip 7- 24
A554 1591 Lower Harness Cover 3- 9
A554 1861 Decal - Misfeed Removal 3- 18
A554 1861 Decal - Misfeed Removal 17- 2
A554 1871 Decal - Stapler Misfeed 3- 20
A554 1871 Decal - Stapler Misfeed 17- 3
A554 1881 Decal - Staple Supply 3- 19
A554 1881 Decal - Staple Supply 17- 4
A554 2121 Upper Entrance Guide 7- 8
A554 2131 Lower Entrance Guide 7- 11
A554 2134 Gate Pawl Guide 7- 13
A554 2135 Exit Guide Plate 9- 11
A554 2141 Roller Bracket 9- 30
A554 2151 Transport Frame 9- 24
A554 2152 Solenoid Cover 9- 1
A554 2156 Solenoid Bracket 9- 39
A554 2161 Gate Pawl 9- 9
A554 2168 Solenoid Lever 9- 38
A554 2171 Vibrating Holder 9- 12
A554 2172 Vibrating Roller 9- 16
A554 2216 Encoder 11- 15
A554 2547 Paper Exit Belt 9- 17
A554 2548 Paper Exit Shaft 9- 18
A554 3111 Bin Drive Bracket 11- 1
A554 3116 Motor Bracket 11- 33
A554 3505 Bin Ass’y 15- 15
A554 3507 Lower Bin Ass’y 15- 22
A554 3515 Bin Guide Mylar 15- 16

A554 3535 Support Bin Ass’y 15- 11
A554 5100 Main Control Board 11- 31
A554 5103 IC - 256K-X8-150NS 11- 32
A554 5200 Main Harness 11- 25
A554 5230 Transport Harness 9- 4
A554 5240 Bin Harness 11- 22
A554 5270 Interface Harness 11- 21
A554 5280 Grounding Harness 5- 33
A554 5280 Grounding Harness 9- 36
A554 8610 Installation Procedure 17- 5

20

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

AA04 3203 Timing Belt - 77XL 11- 10
AA04 3204 Timing Belt - 211XL 13- 15
AA04 3204 Timing Belt - 211XL 13- 36
AA04 3205 Timing Belt - 83XL 5- 7
AA04 3362 Timing Belt - B40S2M520 9- 27
AA04 3450 Timing Belt - 100XL 11- 16
AA05 0084 Wire - Bin - Upper Lower 13- 2
AA06 0490 Limit Switch Spring 15- 4
AA06 0491 Upper Pawl Spring 5- 18
AA06 0492 Jogger Stopper Spring 5- 27
AA06 0611 Spring 9- 35
AA06 2277 Spring 9- 37
AA06 2278 Spring 9- 40
AA06 2279 Spring 7- 3
AA06 2280 Spring 7- 10
AA06 2281 Spring 9- 13
AA06 3239 Spring - Handle 7- 22
AA06 3240 Jogger - Spring 13- 16
AA06 3278 Spring 7- 2
AA06 6196 Tension Spring 9- 34
AA06 6197 Lower Pawl Spring 5- 15
AA06 6198 Proof Lever Spring 3- 5
AA06 6205 End Fence Spring 15- 17
AA06 6235 Spring 7- 5
AA08 0030 Bushing - 5x13x7 9- 29
AA08 0071 Bushing -6x10x6 9- 6
AA08 0072 Bushing - 6x10x3 5- 31
AA08 0074 Bushing - 4x6x6 5- 34
AA08 0140 Bushing - 3x9x5mm 13- 8
AA08 0141 Bushing - 5x12x4mm 9- 25
AA08 0142 Bushing - 5x10x4mm 13- 6
AA08 2042 Bushing - 6x10x6.5mm 5- 30
AA12 0052 Antistatic Brush - 62mm 9- 15
AA12 0053 Antistatic Brush - 112mm 9- 14
AA12 0055 Antistatic Brush - 367mm 3- 3

AA14 3062 Shoulder Screw - M4 5- 36
AA14 3306 Stepped Screw - M6 7- 25
AA14 3404 Stepped Screw - M4 15- 5
AB01 1142 Gear - 59Z 5- 8
AB01 3709 Worm Gear 11- 9
AB01 3730 Gear - 18Z 11- 3
AB01 3731 Gear - 54Z 11- 2
AB01 7273 Sprocket/gear - 16/20Z 9- 28
AB01 7274 Gear - 54Z 13- 1
AB01 7275 Coupled Gear - 20/48Z 5- 9
AB03 0388 Pulley - 16Z 13- 14
AB03 0389 Timing Pulley - Jogger - Drive 13- 5
AB03 0399 Pulley - 52Z 11- 11
AB03 0497 Timing Pulley - 16Z 11- 17
AB03 0498 Timing Pulley - 27Z 9- 23
AB03 2051 Wire Pulley - M26.5 13- 37
AB03 2052 Wire Pulley - M22.8 15- 1
AF02 0270 Upper Exit Roller 9- 26
AF02 0272 Relay Roller 9- 5
AF02 0323 Lower Exit Roller 9- 19
AJ01 1005 Stapler Unit 5- 5
AW02 0021 Photointerruptor - 175487-3 5- 20
AW02 0021 Photointerruptor - 175487-3 11- 12
AW02 0021 Photointerruptor - 175487-3 13- 33
AW02 0025 Lower Bin/jam Sensor 3- 15
AW02 0026 Upper Bin/jam Sensor 7- 20
AW02 0049 Photointerruptor - OS - 580213-703 9- 3
AW03 0066 Optical Fiber - 500mm 11- 30
AX04 0056 Stepping Motor - DC9.5V 9.0W 5- 12
AX04 0057 Stepping Motor - DC24V 3.72W 13- 13
AX05 0057 Stepping Motor - DC24V 3.84W 11- 13
AX05 0074 DC Motor - 24V - 9.9W 11- 4
AX11 0035 Solenoid - 24V 4.6W 9- 22

21

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A351 4721 Drive Motor Grommet 11- 34
A374 1131 Upper Jogger Stay 13- 20
A374 1132 Lower Jogger Stay 13- 34
A374 1136 Lower Stay 13- 22
A374 1141 Lower Stay Roller 13- 24
A374 1142 Shaft - Lower Stay Roller 13- 23
A374 1145 Lower Stay Bracket 7- 16
A374 1146 Lower Stopper 7- 6
A374 1177 Lower Cushion 7- 15
A374 1186 Lower Hinge 7- 17
A374 1191 Upper Hinge 7- 18
A374 1195 Door Switch Bracket 11- 24
A374 1611 Hinge - Front Cover Cap 3- 11
A374 1621 Bin Shaft Cover - Rear 15- 6
A374 1622 Bin Shaft Cover - Front 11- 28
A374 1623 Harness Cover 11- 29
A374 1625 Opening Handle Bracket 7- 23
A374 1855 Decal - Staple Position 3- 17
A374 1855 Decal - Staple Position 17- 1
A374 2134 Cushion 7- 12
A374 2141 Plate Spring - Upper Cover 3- 7
A374 2147 Exit Roller Guide 3- 21
A374 2181 Spacer 9- 7
A374 2182 Bracket - Upper Exit Sensor 9- 2
A374 2183 Bracket - Lower Exit Sensor 9- 8
A374 2190 Tightener Bracket 9- 31
A374 2200 Tension Arm 9- 33
A374 2207 Pulley - 12M 9- 32
A374 2218 Pulley - 12M 11- 18
A374 2234 Encoder Sensor Bracket 11- 20
A374 2237 Stepping Motor Bracket 11- 14
A374 2251 Proof Lever 3- 6
A374 2331 Bin Supportor 9- 21
A374 2541 Exit Roller 9- 20
A374 3115 Encoder Disk 11- 6

A374 3120 Worm Gear Shaft 11- 5
A374 3126 Bin Sensor Bracket 11- 7
A374 3131 Wire Drive Shaft 13- 4
A374 3142 Bin Support Block - Right Front 13- 26
A374 3146 Bin Support Block - Right Rear 13- 27
A374 3156 Bin Support Block - Left 13- 31
A374 3160 Bin Block Shaft - Right 13- 25
A374 3163 Bin Block Shaft - Left 13- 30
A374 3165 Bin Block Stopper 13- 9
A374 3176 Front Pulley Bracket 15- 9
A374 3179 Rear Pulley Bracket 15- 7
A374 3187 Limit Switch Bracket - Upper 11- 19
A374 3191 Pulley Bracket 15- 2
A374 3196 Limit Switch Bracket - Lower 15- 3
A374 3513 Pressure Guide Mylar 15- 21
A374 3516 End Fence 15- 18
A374 3520 Paper Support Film 15- 20
A374 3521 Bin Roller 13- 29
A374 3521 Bin Roller 15- 19
A374 3522 Bin Support Film 15- 14
A374 3525 Cam Roller 13- 28
A374 3525 Cam Roller 15- 12
A374 3526 Bin Spacer 15- 23
A374 3550 Bin Link 15- 10
A374 3555 Paper Support Plate 15- 13
A374 3560 Large Cover - Upper Sensor 7- 21
A374 3562 Small Cover - Upper Sensor 7- 19
A374 3570 Sensor Cover 3- 14
A374 4124 Jogger Drive Shaft 13- 7
A374 4131 Jogger Shaft 13- 21
A374 4141 Jogger Motor Bracket 13- 12
A374 4151 Jogger Tension Bracket - Upper 13- 18
A374 4161 Lower Tension Bracket 13- 35
A374 4171 Upper Jogger Holder 13- 17
A374 4181 Lower Jogger Holder 13- 32

22

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

A374 4521 Stapler Bracket 5- 1
A374 4522 Stapler Rotation Brackdt 5- 4
A374 4531 Stapler Plate 5- 3
A374 4551 Stapler Cover 5- 6
A374 4556 Safety Switch Actuator 3- 13
A374 4562 Stapler Guide 15- 8
A374 4611 Gripper Brackdt 5- 26
A374 4616 Jogger Stopper 5- 28
A374 4617 Small Jogger Stopper 13- 38
A374 4621 Large Side Plate 5- 29
A374 4631 Small Side Plate 5- 10
A374 4636 Drive Shaft 5- 24
A374 4641 Cam Follower 5- 17
A374 4656 Lower Gripper Arm 5- 16
A374 4658 Upper Girpper Arm 5- 14
A374 4667 Drive Cam 5- 23
A374 4681 Gripper Shaft 5- 11
A374 4684 Connector Holder 5- 25
A374 4688 Gripper Connector Cushion 5- 21
A374 4711 Gripper Sensor Bracket 11- 26
A374 5215 Gripper Harness 5- 19
A374 5220 Gripper Relay Harness 5- 22
A374 5250 Relay Harness - Bin Sensor 3- 8
A374 5260 Grounding Harness 5- 37
A374 5600 Fhotointerrupter - OS-580213-704 11- 27
A421 2521 Spring - Paper Volume 13- 19
A469 3175 Idle Pulley Stud - Short 13- 10
A498 2266 Cushion - 8x40 3- 16
A499 2444 Middle Belt Roller 7- 1
A499 2445 Holder - Middle Belt Roller 7- 9
A555 1850 Decal - Staple Position 17- 6
5053 0419 Bushing - 10mm 13- 3
5053 0447 Bushing - 6mm 11- 8
5054 0536 Magnet Catch Ass’y 5- 2
5201 1796 Stepped Screw - M4 5- 32

5201 1796 Stepped Screw - M4 7- 7
5216 2113 Stepped Screw - Transfer 7- 14
5409 1238 Rotary Catch 5- 13
5442 1659 Stepped Screw - M4 5- 35
5447 2681 Snap Ring 9- 10
5887 4185 Idler Pulley 13- 11

23

Part No.

Description

Page and
Index No.

Part No.

Description

Page and
Index No

0313 0040B Philips Pan Head Screw - M3x4 9-105
0313 0050B Philips Pan Head Screw - M3x5 5-109
0313 0050B Philips Pan Head Screw - M3x5 11-105
0313 0050B Philips Pan Head Screw - M3x5 13-102
0313 0050B Philips Pan Head Screw - M3x5 15-105
0313 0080B Philips Pan Head Screw - M3x8 5-108
0313 0140B Philips Pan Head Screw - M3x14 5-113
0313 0140B Philips Pan Head Screw - M3x14 11-107
0313 0140B Philips Pan Head Screw - M3x14 15-102
0313 0160B Philips Pan Head Screw - M3x16 3-102
0313 0160B Philips Pan Head Screw - M3x16 7-103
0314 0040B Philips Pan Head Screw - M4x4 7-102
0324 0100B Philips Sunk Screw - M4x10 11-120
0344 0060F Philips Truss Head Screw - M4x6 3-106
0344 0060F Philips Truss Head Screw - M4x6 7-101
0344 0080F Philips Truss Head Screw - M4x8 3-107
0413 0082W Tapping Screw - M3x8 5-114
0434 0060B Philips Tapping Screw - M4x6 3-104
0434 0060B Philips Tapping Screw - M4x6 5-107
0434 0060B Philips Tapping Screw - M4x6 7-105
0434 0060B Philips Tapping Screw - M4x6 11-102
0434 0060B Philips Tapping Screw - M4x6 13-106
0434 0060B Philips Tapping Screw - M4x6 15-106
0434 0122W Pan Head Self-tapping Screw - M4x12 9-106
0434 0200B Pan Head Self-tapping Screw - M4x20 3-101
0574 0030E Hexagonal Set Screw - M4x3 11-104
0574 0040E Hexagon Headless Set Screw - M4x4 11-108
0623 0100E Spring Pin - 3x10mm 9-104
0632 0140G Parallel Pin 5-105
0633 0250G Pin - M3x25 13-108
0710 0050B Hexagon Nut - M5 3-108
0720 0025E Retaining Ring - M2.5 5-102
0720 0030E Retaining Ring - M3 9-102
0720 0030E Retaining Ring - M3 13-103
0720 0040E Retaining Ring - M4 3-105

0720 0040E Retaining Ring - M4 5-103
0720 0040E Retaining Ring - M4 9-101
0720 0040E Retaining Ring - M4 11-101
0720 0040E Retaining Ring - M4 13-104
0720 0040E Retaining Ring - M4 15-104
0720 0060E Retaining Ring - M6 15-103
0720 0080E Retaining Ring - M8 5-101
0720 0080E Retaining Ring - M8 13-109
0740 3206 Ball Bearing - 6x19x6 11-117
0950 4006B Screw - M4X6 5-115
0950 4006B Screw - M4X6 9-103
0951 3006B Philips Screw With Flat Washer - M3x6 11-121
0951 4006B Philips Screw With Washer - M4x6 5-104
0951 4006B Philips Screw With Washer - M4x6 11-103
0951 4006B Philips Screw With Washer - M4x6 13-105
0951 4008B Philips Screw With Washer - M4x8 3-103
0951 4008B Philips Screw With Washer - M4x8 13-107
1005 0933 Cushion - Stepper Motor 11-118
1105 0163 Locking Support 11-110
1105 0234 Clamp 5-112
1105 0234 Clamp 7-104
1105 0234 Clamp 11-111
1105 0243 Wire Saddle 13-101
1105 0267 Wire Clamp 11-109
1105 0267 Wire Clamp 15-107
1105 0291 Wire Saddle 11-112
1105 0291 Wire Saddle 13-110
1105 0291 Wire Saddle 15-108
1105 0310 Wire Clamp 5-106
1105 0328 Harness Clamp - ES-0505 11-119
1106 0241 Bushing - 6.7mm 5-111
1106 0241 Bushing - 6.7mm 11-116
1106 0250 Cord Stopper - 115V 11-113
1106 0411 Bushing - 11.5mm 15-109
1107 0748 Fuse - 2A, 250V 11-115

24

Part No.

1204 2188 Interlock Switch 5-110
1204 2188 Interlock Switch 11-114
1204 2233 Microswitch -AH715254N 11-106
1204 2234 Microswitch - AH735254N 15-101

Description

Page and
Index No.

Part No.

Description

Page and
Index No

25

RICOH ST26 (A554)
