Ricoh DF78, B616 Part List
DOCUMENT FEEDER DF78
B616
PARTS LOCATION AND LIST
This section instructs you as to the numbers and names of parts on this machine.
1.Exterior (B616)
B616 2 Parts Location and List
1.Exterior (B616)
Index
No.
1 B387 6021 Size Indication Decal 1
2 B387 4873 Positioning Plate 2
3 B387 4841 Left Cover 1
4 G564 6077 Decal - Exposure Glass (5-lang) 1
5 B387 4640 Front Side Fence 1
6 B387 4656 Rear Side Fence Ass'y 1
7 B387 6033 Decal - Original Table 1
8 B387 6013 Decal - Removal Misfeed 1
9 B387 4605 Upper Original Table 1
10 A859 2352 Pad Pressure Plate 1
11 B387 2310 Guide Plate - Paper Feed 1
12 B387 6053 Original Scale Decal - A4 1
12 B387 6054 Original Scale Decal - LT 1
13 B387 4875 Left Cover Band 1
14 B387 4812 Front Cover 1
15 5446 2824 Screw - Duplex Guide Plate 1
16 B387 4661 Front Rack - Side Fence 1
17 A859 4665 Gear - 16Z 1
18 B387 4681 Feeler - Original Trailing Edge 1
19 B387 4671 Rear Rack - Side Fence 1
20 AW02 0075 Photointerruptor 1
21 AW01 0103 Photo Sensor 1
22 B616 5705 Harness - Original Tray 1
23 B387 4822 Rear Cover 1
24 B386 7102 Scale - Machine Or Copier (Adhesion) 1
25 AC01 3004 Exposure Glass 1
26 A548 6121 Screw - M4 2
27 5206 2686 Snap Ring 1
28 B387 4621 Lower Original Table 1
29 A859 7211 Stepped Screw 2
30 B387 6043 Decal - Fence Side 1
31 B387 2321 Separation Guide Mylar 1
32 A628 3118 Screw Driver - DF 1
Part No.
Description
Q’ty Per
Assembly
Index
No.
101 0450 3008B Tapping Screw - M3x8
102 0452 3008B Tapping Screw - M3x8
103 0451 3008H Tapping Screw - M3x8
Part No.
Description
Q’ty Per
Assembly
B616 3 Parts Location and List
2.Original Feed Section 1 (B616)
B616 4 Parts Location and List
2.Original Feed Section 1 (B616)
Index
Index
No.
No.
1 B387 2151 Pickup Holder 1
2 B387 2162 Pickup Roller Shaft 1
3 B387 2113 Roller - Paper Feed Belt 1
4 AA06 3318 Spring - Belt Guide Roller 2
5 A859 2112 Drive Shaft Paper Feed Belt 1
6 B387 2111 Belt Holder 1
7 B387 2133 Pickup Arm 1
8 B387 2131 Rear Feed Guide 1
9 B387 4216 Feed Clutch Shaft 1
10 B387 2120 Shaft - Paper Feed Belt 1
11 B387 2164 Timing Pulley - 20Z 1
12 B387 2163 Pickup Collar 1
13 G412 3831 Pulley - 22Z 1
14 B387 2161 Pickup Roller 1
15 A859 2167 Gear - 22Z 1
16 B387 4872 Original Sensor Feeler 1
17 AA06 3315 Spring - Belt Drive Shaft 1
18 B387 2132 Front Feed Guide 1
19 A859 2114 Drive Roller Paper Feed Belt 1
20 A859 2141 Belt Paper Feed 1
21 A859 2121 Gear - 22Z 1
22 B387 1721 Left Lower Guide 1
23 B387 1722 Entrance Guide 1
24 B387 1711 Left Lower Stay 1
25 5447 2681 Snap Ring 2
26 5304 1639 Bushing - 8mm 2
27 B387 3322 Cover - Transport Driven Roller 1
28 B387 3318 Front Pressure Spring 1
29 B387 3311 Transport Driven Roller 1
30 B387 3313 Shaft - Transport Driven Roller 1
31 B387 3319 Rear Pressure Spring 1
32 B387 3321 Spring Cover 1
33 B387 3317 Main Shaft - Transport Driven 1
34 A859 2166 Timing Belt - 2XL 1
35 AA13 2013 Spacer 2
Part No.
Part No.
Description
Description
Q’ty Per
Q’ty Per
Assembly
Assembly
Index
Index
No.
No.
36 A628 1225 Bushing - 8mm 4
37 5053 0447 Bushing - 6mm 2
38 B387 1712 Center Bracket - Left Lower Stay 1
39 B387 1713 Outer Bracket - Left Lower Stay 2
40 B387 2100 Belt Unit - Paper Feed Ass'y 1
101 0451 3006B Tapping Screw - M3x6
102 0720 0040B Retaining Ring - M4
103 0632 0100G Pin - 2x10mm
104 0720 0060B Retaining Ring - M6
105 0720 0030B Retaining Ring - M3
106 0353 0060B Philips Pan Head Screw - M3x6
Part No.
Part No.
Description
Description
Q’ty Per
Q’ty Per
Assembly
Assembly
B616 5 Parts Location and List
3.Original Feed Section 2 (B616)
B616 6 Parts Location and List
