Ricoh bp100 OPERATING INSTRUCTIONS admin

Administrator Guide

FIERY XJ BP100

This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics for Imaging, Inc., except as expressly permitted herein. I nformation in this document is subject to change without notice and does not represent a commitment on the part of Electronics for Imaging, Inc.

The software described in this publication is furnished under license and may only be used or copied in accordance with the terms of such license. Patents: 5,666,436; 5,553,200; 5,543,940; 5,537,516; 5,517,334; 5,506,946; 5,424,754; 5,343,311; 5,212,546; 4,941,038; 4,837,722; 4,500,919

Trademarks

EFI, the EFI logo, Fiery , the Fiery logo, EFICOLOR, and Rip-While-P rint are trademarks register ed in the U.S. P atent and Trademar k Ofﬁce. Fiery XJ, Fiery ZX, Fiery Driven, the Fiery Driven logo, Command WorkStation, AutoCal, Starr Compression, Memory Multiplier, ColorWise, NetWise, and VisualCal are trademarks of Electronics for Imaging, Inc.

Adobe, the Adobe logo, Adobe Illustrator , P ostScript, Adobe P hotoshop, Adobe S eparator , and A dobe P ageMaker are trademarks of A dobe Systems Incorporated, registered in certain jurisdictions. EPS (Encapsulated PostScript) is a trademark of Altsys Corporation. Apple, the A pple logo, AppleS hare, A ppleTalk, E therTalk, LaserWriter, and Macintosh are registered trademarks, and MultiFinder is a trademark of Apple Computer, Inc. Microsoft, MS, MS-DOS, and Windows are registered trademarks of Microsoft in the US and other countries. QuarkXPress is a registered trademark of Quark, Inc. Times, Helvetica, and Palatino are trademarks of Linotype AG and/or its subsidiaries. ITC Avant Garde, ITC Bookman, ITC Zapf Chancery, and ITC Zapf Dingbats are registered trademarks of International Typeface Corporation. Ethernet is a registered trademark of Xerox Corporation. Farallon, PhoneNET PC, and PhoneNET Talk are trademarks of Farallon Computing, Inc. COPS and COPSTalk are trademarks of CoOperative Printing Solutions, Inc. NetWare and Novell are registered trademarks and Internetwork Packet Exchange (IPX) is a trademark of N o vell, Inc. SyQ uest is a registered trademark, in the U nited S tates and certain other countries, of SyQuest Technology, Inc. UNIX is a registered trademark of UNIX System Laboratories, a wholly owned subsidiary of Novell, Inc.

All other terms and product names may be trademarks or registered trademarks of their respective owners, and are hereby acknowledged.

Legal Notices APPLE COMPUTER, INC. (“APPLE”) MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THE APPLE SOFTWARE. APPLE DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE APPLE SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR OTHER WISE. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE APPLE SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED WARRANTIES IS NOT PERMITTED BY SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL APPLE, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE TO YOU FOR ANY CONSEQUENTIAL, INCIDENTAL OR INDIRECT DAMA GES (INCLUDING DAMA GES FOR LOSS OF BUSINESS PR OFITS, BUSINESS INTERRUPTION, L OSS OF BUSINESS INFORMATION, AND THE LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE APPLE SOFTWARE EVEN IF APPLE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

Apple’s liability to you for actual damages from any cause whatsoever, and regardless of the form of the action (whether in contract, tort [including negligence], product liability or otherwise), will be limited to $50.

Restricted Rights Legends

For defense agencies: Restricted Rights Legend. Use, reproduction, or disclosure is subject to restrictions set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at 252.227.7013.

For civilian agencies: Restricted Rights Legend. Use, reproduction, or disclosure is subject to restrictions set forth in subparagraph (a) through (d) of the commercial Computer Software Restricted Rights clause at 52.227-19 and the limitations set forth in Electronics for Imaging, Inc.’s standard commercial agreement for this software. Unpublished rights reserved under the copyright laws of the United States.

Printed in the United States of America on recycled paper.

Part Number:

45000219

FCC Information

WARNING: FCC Regulations state that any unauthorized changes or modiﬁcations to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

Class A Compliance

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits ar e designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, and uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense.

Industry Canada Class A Notice

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled, “Digital Apparatus” ICES-003 from Industry Canada.

Avis de Conformation Classe A de l’Industrie Canada

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la Classe A prescrites dans la norme sur le matériel brouilleur, “Appareils Numériques” NMB-003 édictée par l’Industrie Canada.

Certiﬁcate by Manufacturer/Importer

This is to certify that the FC07 is shielded against radio interference in accordance with the provisions of VFG 243/1991. The G erman Postal Services have been advised that this device is being put on the market and that they have been given the right to inspect the series for compliance with the regulations. Electronics for Imaging, Inc.

Bescheinigung des Herstellers/Importeurs

Heirmit wird bescheinigt, dass der FC07 im Uebereinstimmung mit den Bestimmungen der VFG 243/1991 Funk-Entstort ist. Der D eutschen Bundespost wurde das Inverkehrbringen dieses Geraetes angezeigt und die Berechtigung zur Ueberpruefung der Serie auf Einhaltung der Bestimmungen eingeraumt. Electronics for Imaging, Inc.

RFI Compliance Notice

This equipment has been tested concerning compliance with the relevant RFI protection requirements both individually and on system level (to simulate normal operation conditions). However, it is possible that these RFI Requirements are not met under certain unfavorable conditions in other installations. It is the user who is responsible for compliance of his particular installation.

Dieses Geraet wurde einzeln sowohl als auch in einer Anlage, die einen normalen Anwendungsfall nachbildet, auf die Einhaltung der Funk-entstoerbestimmungen geprueft. Es ist jedoch moeglich, dass die Funk-enstoerbestimmungen unter unguenstigen Umstaenden bei anderen Geraetekombinationen nicht eingehalten werden. Fuer die Einhaltung der Funk-entstoerbestimmungen seigner gesamten Anlage, in der dieses Geraet betrieben wird, ist der Betreiber verantwortlich.

Compliance with applicable regulations depends on the use of shielded cables. It is the user who is responsible for procuring the appropriate cables. Einhaltung mit betreffenden Bestimmungen kommt darauf an, dass geschirmte Ausfuhrungen gebraucht werden. Fuer die beschaffung richtiger Ausfuhrungen

ist der Betreiber verantwortlich.

Software License Agreement

Before using the Software, please carefully read the following terms and conditions. BY USING THIS SOFTWARE, YOU SIGNIFY THAT YOU HAVE ACCEPTED THE TERMS OF THIS AGREEMENT. If you cannot or do not accept these terms, you may return the entire package within ten (10) days to the Distributor or Dealer from which you obtained them for a full refund.

Electronics for Imaging, Inc. grants to you a non-exclusive, non-transferable license to use the software and accompanying documentation (“Softwar e”) included with the Fiery XJ you have purchased, including without limitation the PostScript

software provided by Adobe Systems Incorporated.

You may: a. use the Software solely for your own customary business purposes and solely with Fiery XJ; b. use the digitally-encoded machine-readable outline and bitmap programs (“Font P rograms”) pro vided with Fiery XJ in a special encrypted format (“Coded Font

Programs”) to reproduce and display designs, styles, w eights, and versions of letters, numerals, characters and symbols (“Typefaces”) solely for your own customary business purposes on the display window of the Fiery XJ or monitor used with Fiery XJ;

c. use the trademarks used by Electronics for Imaging to identify the Coded Font Programs and Typefaces reproduced therefrom (“Trademarks”); and d. assign your rights under this Agreement to a transferee of all of your right, title and interest in and to Fiery XJ provided the transferee agrees to be bound by all

of the terms and conditions of this Agreement. You may not:

a. make use of the Software, directly or indirectly, to print bitmap images with print resolutions of 600 dots per inch or greater, or to generate fonts or typefaces for use other than with Fiery XJ;

b. make or have made, or permit to be made, any copies of the Software, Coded Font Programs, accompanying documentation or portions thereof, except as necessary for use with the Fiery XJ unit purchased by you; provided, however, that under no circumstances may you make or have made, or permit to be made, any copies of that certain portion of the Software which has been included on the Fiery XJ hard disk drive. You may not copy the documentation;

c. attempt to alter, disassemble, decrypt or reverse engineer the Software, Coded Font Programs or accompanying documentation. d. rent or lease the Software.

Proprietary Rights

You acknowledge that the Software, Coded Font Programs, Typefaces, Trademarks and accompanying documentation are proprietary to Electronics for Imaging and its suppliers and that title and other intellectual property rights therein remain with Electronics for Imaging and its suppliers. Except as stated above, this Agreement does not grant you any right to patents, copyrights, trade secrets, trademarks (whether registered or unregistered), or any other rights, franchises or licenses in respect of the Software, Coded Font Programs, Typefaces, Trademarks or accompanying documentation. You may not adapt or use any trademark or trade name which is likely to be similar to or confusing with that of Electronics for Imaging or any of its suppliers or take any other action which impairs or reduces the trademark rights of Electronics for Imaging or its suppliers. The trademarks may only be used to identify printed output produced by the Coded Font Programs. At the reasonable request of Electronics for Imaging, you must supply samples of any Typeface identiﬁed with a trademark.

Conﬁdentiality

You agr ee to hold the Software and Coded F ont P rograms in conﬁdence, disclosing the Softwar e and Coded Font P rograms only to authoriz ed users having a need to use the Software and Coded Font Programs as permitted by this Agreement and to take all reasonable precautions to prevent disclosure to other parties.

Remedies

Unauthorized use, copying or disclosure of the Software, Coded F ont Programs, Typefaces, Trademarks or accompanying documentation will result in automatic termination of this license and will make available to Electronics for Imaging other legal remedies.

Limited Warranty And Disclaimer

Electronics for Imaging warrants that, for a period of ninety (90) days from the date of delivery to you, the Software under normal use will perform without signiﬁcant errors that make it unusable. Electronics for Imaging’s entire liability and your exclusive remedy under this warranty (which is subject to you returning Fiery XJ to Electronics for Imaging or an authorized dealer) will be, at Electronics for Imaging’s option, to use reasonable commercial efforts to attempt to correct or work around errors, to replace the Software with functionally equivalent software, or to refund the purchase price and terminate this Agreement. Some states do not allow limitations on duration of implied warranty, so the above limitation may not apply to you.

Except for the above express limited warranty, Electronics for Imaging makes and you receive no warranties or conditions on the Products, express, implied, or statutory, and Electronics for Imaging speciﬁcally disclaims any implied warranty or condition of merchantability or ﬁtness for a particular purpose.

For warranty service, please contact your authorized service/support center. EXCEPT FOR THE ABOVE EXPRESS LIMITED WARRANTY, ELECTRONICS FOR IMAGING MAKES AND YOU RECEIVE NO WARRANTIES

OR CONDITIONS ON THE SOFTW ARE OR CODED FONT PROGRAMS, EXPRESS, IMPLIED, STATUT ORY, OR IN ANY OTHER PRO VISION OF THIS AGREEMENT OR COMMUNICATION WITH YOU, AND ELECTRONICS FOR IMAGING SPECIFICALL Y DISCLAIMS ANY IMPLIED WARRANTY OR CONDITION OF MER CHANT ABILITY OR FITNESS FOR A PAR TICULAR PURPOSE. Electr onics for Imaging does not warrant that the operation of the software will be uninterrupted or error free or that the Software will meet your speciﬁc requirements.

Limitation Of Liability

IN NO EVENT WILL ELECTRONICS FOR IMAGING OR ITS SUPPLIERS BE LIABLE FOR ANY DAMA GES, INCLUDING LOSS OF DATA, LOST PROFITS, COST OF COVER OR O THER SPECIAL, INCIDENT AL, CONSEQ UENTIAL OR INDIRECT DAMAGES ARISING FR OM THE USE OF THE SOFTWARE, CODED FONT PROGRAMS OR ACCOMPANYING DOCUMENTA TION, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY. THIS LIMITATION WILL APPLY EVEN IF ELECTRONICS FOR IMAGING OR ANY AUTHORIZED DEALER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. YOU ACKNO WLEDGE THAT THE PRICE OF THE UNIT REFLECTS THIS ALLOCATION OF RISK. BECAUSE SOME STATES/JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

Export Controls

You agr ee that you will not export or re-export the S oftware or Coded Font Programs in any form without the appropriate United States and foreign government licenses. Your failure to comply with this provision is a material breach of this Agreement.

Government Use

Use, duplication or disclosure of the Software by the United States Government is subject to restrictions as set forth in subdivision (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 or in subparagraphs (c) (1) and (2) of the Commercial Computer Software—Restricted Right Clause at 48 CFR 52.227-19, as applicable.

Third Party Beneﬁciary

You are hereby notiﬁed that Adobe Systems Incorporated, a California corporation located at 345 Park Avenue, San Jose, CA 95110-2704 (“Adobe”) is a thirdparty beneﬁciary to this Agreement to the extent that this Agreement contains provisions which relate to your use of the Fonts, the Coded Font Programs, the T ypefaces and the Trademarks licensed hereby. S uch provisions are made expr essly for the beneﬁt of Adobe and are enforceable by Adobe in addition to E lectronics for Imaging.

General

This Agreement will be governed by the laws of the State of California. This Agreement is the entire agreement held between us and supersedes any other communications or advertising with respect to the Software, Coded Font

Programs and accompanying documentation. If any provision of this Agreement is held invalid, the remainder of this Agreement shall continue in full force and effect. If you have any questions concerning this Agreement, please write to Electronics for Imaging, Inc., Attn: Licensing Dept. or see Electronics for I maging’s web site

at www.eﬁ.com. Electronics for Imaging, Inc.

2855 Campus Drive San Mateo, CA 94403

Contents

Introduction

About this manual About the documentation Network administration features Before you proceed

Levels of access and control xiii Fiery XJ print connections xiv Passwords xv Fiery WebTools xv Control level scenarios xvi

Chapter 1: Connecting to the Network

Fiery XJ on the network Stages of installation on the network Quick path to installation Before you begin Ethernet cable connection Parallel cable connection

Chapter 2: Performing Setup from the Control Panel

xi xii xii

xiii

1-1 1-2

1-4 1-11 1-12 1-15

About Fiery XJ Setup

Initial Setup from the Control Panel 2-1 Network server setup requirements 2-1

Fiery XJ Setup from the Control Panel

Accessing Setup options 2-3 About the Control Panel Setup interface 2-5 Types of Setup screens 2-6

Server Setup options

2-1

2-2

2-8

viii Table of Contents

Network Setup options

Port Setup options 2-13 Protocol Setup options 2-15 Service Setup options 2-21

Fiery XJ print connections

Direct connection 2-34 Queues 2-34

Printer Setup options PostScript Setup options Color Setup options Administrative functions in the Setup menu

Job Log Setup 2-40 Job Log Setup options 2-40 Calibration 2-41 Change Password 2-44 Clear Server 2-45 Exit Setup 2-45

Printing the Conﬁguration page from the Control Panel

Chapter 3: Setting up Network Servers

2-10

2-34

2-35 2-36 2-38 2-39

2-46

Fiery XJ on an IPX network Tips for experts—IPX networks

Overview of IPX printing to the Fiery XJ 3-3

Conﬁguring a NetWare server for printing

Setting up an NDS connection 3-6 Setting the NetWare 4.x bindery context 3-9 Setting up a NetWare print queue for bindery 3-12

Setting up NetWare Windows clients for printing Conﬁguring Windows 95 workstations for the Fiery utilities Fiery XJ on a TCP/IP network with Windows NT 4.0 Tips for experts—Windows NT 4.0 with TCP/IP

3-1

3-2

3-4

3-16 3-17 3-18 3-18

ix Table of Contents

Conﬁguring a Windows NT 4.0 server to support the Fiery XJ

Adding the Fiery XJ to the TCP/IP network 3-21 Installing the Fiery XJ as a shared PostScript printer 3-22 Setting up another printer 3-23

Conﬁguring Windows NT 4.0 clients

Conﬁguring Windows NT 4.0 workstations for the Fiery utilities 3-24

Using AppleTalk with Windows NT 4.0 Conﬁguring the Fiery XJ and clients for Fiery WebTools Fiery XJ on a network with UNIX workstations Tips for experts—UNIX workstations

Important note about the remote printer name 3-28 Setting up the Fiery XJ on TCP/IP networks 3-29

Chapter 4: Administering the Fiery XJ

Administrator functions Maintaining optimal Fiery XJ performance Troubleshooting the Fiery XJ

Troubleshooting during Setup from the Control Panel 4-3 Runtime error messages 4-8

3-19

3-24

3-25 3-26 3-27 3-28

4-1

4-2

4-3

Appendix A: Token Ring Network Option

Fiery XJ Token Ring option

Connecting Token Ring hardware A-1

IPX/SPX installations TCP/IP installations Setting up Token Ring on the Fiery XJ Setting up NetWare Windows clients

Index

A-1

A-3 A-3 A-3 A-3

xi About this manual

Introduction

This manual is intended for anyone who is responsible for integrating the Fiery XJ BP100 Color Server™ into a business environment that includes networked personal computers. After the Fiery XJ and client workstations are set up, as described in this manual and in

Getting Started

, individual users can print to the Fiery XJ as a

high-performance color PostScript printer.

The term “Fiery XJ” is used to refer to the Fiery XJ BP100 Color Server.

OTE

Any connectivity or administrative features speciﬁc to the copier are described in

Getting Started,

the

User Guide,

or the

Release Notes.

About this manual

This manual covers the following topics:

• Basic conﬁguration of the Fiery XJ to support printing over AppleTalk, TCP/IP, and IPX (Novell) networks

• Setting up a parallel port connection

• Conﬁguring Novell and Windows NT servers and UNIX systems to provide Fiery XJ printing services

• Administering network printing

• Using the Fiery XJ in mixed network environments

• Setting up a Token Ring connection

The network guidelines in this book are not intended to replace the services of

OTE

an experienced network engineer.

It is organized as follows:

• Chapter 1 illustrates the supported network conﬁgurations and shows the network connectors on the Fiery XJ.

• Chapter 2 describes Fiery XJ conﬁguration (Setup) from the Control Panel.

• Chapter 3 provides guidelines for setting up Windows network servers and UNIX systems for printing to the Fiery XJ.

xii Introduction

• Chapter 4 summarizes some administrative features of Fiery XJ software that are available for IPX/SPX, TCP/IP, and AppleTalk networks, and also offers some troubleshooting hints.

• Appendix A describes the Token Ring option.

OTE

Administrator features described in other manuals are summarized on page 4-1.

About the documentation

This manual is part of the set of Fiery XJ documentation, which includes the following manuals for users and system administrators:

• The

Administrator Guide

Fiery XJ for the supported platforms and network environments. It also includes guidelines for setting up UNIX, Windows NT, and Novell NetWare servers to provide PostScript printing services to clients.

•

Getting Started

Fiery XJ. Speciﬁcally, it describes installation of PostScript™ printer drivers, printer description ﬁles, and other user software provided on the User Software CD. It also explains how to connect each user to the network.

describes how to install software to enable users to print to the

explains basic conﬁguration and administration of the

• The

User Guide

jobs via remote workstations on the network or via a direct parallel port connection. It also explains how to use the Fiery WebTools and Fiery XJ client utilities to manage jobs and provides troubleshooting information for problems that may arise.

•

Release Notes

the problems you may encounter.

describes the printing features of the Fiery XJ for users who send

provide last-minute product information and workarounds for some of

Network administration features

Fiery XJ software has several important features that affect you as a network or printer administrator:

• Direct (native) support of NDS (Novell Directory Services) with NetWare 4.x

NetWare 4.x can also be supported in bindery emulation.

• Simultaneous NetWare 4.x and NetWare 3.x connections

One NetWare 4.x NDS tree and up to eight NetWare 3.x bindery servers (or NetWare 4.x servers in bindery emulation mode) can be connected to the Fiery XJ.

xiii Before you proceed

• Fiery utilities (Fiery Spooler™ and Fiery Downloader™) for Windows and Mac OS computers

The Fiery utilities can be run from Windows 95, Windows NT, and Mac OS computers.

• Fiery WebTools™ (Status, WebSpooler, and Installer)

Fiery WebTools allow you to manage the Fiery XJ from the Internet or from your company’s intranet. To use the Fiery WebTools, you need to set certain options in Network Setup and Printer Setup.

• Job tracking

Job Logs can include two user-entered Notes fields.

• Support for Windows (SMB) printing

Windows printing, also known as SMB (Server Message B lock) printing, allows you to print on TCP/IP networks using SMB, which is built-in Microsoft networking support, and without additional network software. Printing by this method allows you to print from your computer to a particular print connection (Print or Direct) on the Fiery XJ.

Before you proceed

No two Fiery XJ sites are identical, and the Fiery XJ system can be conﬁgured to suit your site’s particular requirements for ﬂexibility or control. As the system administrator, you decide the level of network and software access that will be accessible to users. To implement these levels of access, you publish print connections and set passwords.

Before you proceed with installation and setup, make sure you understand the spectrum of access and control possible with the Fiery XJ. Then decide what level is most appropriate for your site.

Levels of access and control

The level of control you implement can range from strict to moderate to minimal, or none. Strictest control might be appropriate for a high-volume printing environment where an administrator or operator controls the job ﬂow and all printing; jobs sent by users are spooled (stored) to the server disk until the operator decides it is time to print them. In addition, only the administrator and/or operator have access to certain software tools.

xiv Introduction

Least control might be appropriate for a small site where anyone on the local network can control all printing and server functions. Although there may be an administrator or operator charged with certain duties, all users have equal access to the system and its software tools.

When you conﬁgure the Fiery XJ by performing Setup, you (the system administrator) implement a particular level of control by enabling (or not enabling) printing connections, passwords, and access to Fiery WebTools.

Fiery XJ print connections

The Fiery XJ supports two print connections: Print queue and Direct connection. These print connections can be enabled, or “published,” to users on the network when you conﬁgure the server Setup.

Direct connection

The Direct connection transmits jobs directly to the Fiery XJ, but only when the Fiery XJ is ready to print. If the Fiery XJ is busy, the job remains at the user workstation until the Fiery XJ is ready. It is then processed as soon as the prior job is ﬁnished and before the next queued job is processed.

Jobs sent to the Direct connection are not stor ed on the Fiery XJ hard disk and do not appear in the display of current jobs seen from Fiery Spooler or Fiery WebSpooler; therefore the Direct connection provides a measure of security for sensitive ﬁles. Jobs sent to the Direct connection do appear in the Job Log, for accounting purposes.

OTE

To use the Fiery utilities, including downloading fonts with Fiery Downloader,

you must publish the Direct connection.

Print queue

If you publish the Print queue, jobs sent to it are processed and printed in the order they are received. Jobs prioritized b y an operator at Fiery Spooler or Fiery W ebSpooler or jobs sent via the Direct connection can take priority over jobs sent to the Print queue.

xv Before you proceed

Passwords

You can implement password requirements as a means of controlling access to Fiery XJ functions. The Fiery XJ allows for the Administrator password to be set from the Control Panel.

OTE

By default, no passwords are set on the Fiery XJ. If you do not speciﬁcally set passwords, all users will have administrator privileges, which include access to important functions such as Setup (including setting passwords), calibration, and job control. It is strongly recommended that you set at least an Administrator password to protect the server from random or accidental changes to Setup.

Administrator password privileges

Administrator control, which confers control of Setup, is the highest level of control, since the person who has access to Setup can control the printing and job management environment. Administrator privileges include publishing print connections, setting passwords, deleting fonts, and clearing the server of all job data.

Guest privileges (No password)

No password is needed for a user to log in as a Guest from Fiery Spooler or Fiery WebSpooler. A Guest can view the status of active jobs but cannot make changes to jobs or to the server’s state (for example, calibration).

Fiery WebTools

The Fiery XJ can support Internet or intranet access with Fiery WebTools from Windows 95, Windows NT 4.0, and Mac OS computers. To enable use of Fiery WebTools, you must do the following in Setup:

• Set Enable TCP/IP to Yes.

• Set an IP address for the Fiery XJ.

• Set a subnet mask.

• Enter a TCP/IP gateway address.

• Set Enable Web Services to Yes.

xvi Introduction

Fiery WebTools include Status, WebSpooler, and Installer.

Status

The Status WebTool provides you with current information on the jobs processing and printing on the Fiery XJ. It is not affected by any password setting. For more information, see the User Guide.

WebSpooler

The WebSpooler allows remote users to preview, manipulate, reorder, reprint, and delete jobs currently spooling, processing, or printing on the Fiery XJ. It also allows the administrator to view, print, or delete the Job Log.

Installer

The Installer WebT ool allows users to do wnload printer ﬁles installers directly from the server. It is not affected by any password setting. For more information, see Getting Started.

Control level scenarios

Typical scenarios of access and control, ranging from least control to strictest control, are described below. Choose the scenario that best matches your site requirements, and then refer to the corresponding number for guidance on how to conﬁgure your system for those requirements.

NOTE: It is strongly recommended that you set at least an Administrator password to

prevent unauthorized changes to system settings.

1. (Least control—not recommended) No designated administrator or operator

All users have equal access to all system functions including Setup, clearing the server, deleting printer fonts, setting the WebLink destination, performing calibration, printing to all three Fiery XJ print connections, and managing all jobs from remote workstations.

2. A designated administrator

Only an administrator can perform Setup and other administrator functions, but all other system functions are accessible to all users, including performing calibration, printing to all three Fiery XJ print connections, and managing all jobs from remote workstations.

xvii Before you proceed

3. (Strictest control) A designated administrator and a designated operator, no Fiery WebTool access

Only an administrator can perform Setup, and only an operator or administrator can perform calibration and control jobs from a remote workstation; users can print to the Print queue, but not to the Direct connection; the operator controls all job ﬂow, but jobs sent to the Print queue may not require operator intervention; no access to Fiery WebT ools.

Use these settings:

Enable Direct connection in Setup ÖÖ Enable Print queue in Setup ÖÖ Ö Enable Web Services in Setup ÖÖ Set an Administrator Password in Setup ÖÖ

(Least)

(Strictest)

1-1 Fiery XJ on the network

Chapter 1: Connecting to the Network

This chapter summarizes the stages in setting up the Fiery XJ BP100 Color Server, and includes diagrams that refer you to other chapters or other manuals for completing your installation. If you check those references, you should be able to ﬁnd the information you need quickly.

Fiery XJ on the network

When the Fiery XJ is connected to a network, it behaves as a networked PostScript printer. The built-in Ethernet interface on the Fiery XJ supports the following network protocols:

• AppleTalk

• TCP/IP (the lpd, nbt, and http protocols)

TCP/IP stands for Transmission Control Protocol/Internet Protocol. The lpd protocol is the standard TCP/IP printing protocol. The nbt protocol supports Windows (SMB) printing. The http protocol is commonly used for Web pages on the Internet and on intranets.

• IPX/SPX (Novell)

IPX/SPX stands for Internetwork Packet Exchange/Sequenced Packet Exchange.

These protocols (rules that enable computers on a network to communicate with each other) are supported on the Mac OS, Windows, and UNIX platforms and can run concurrently on the same cable. Workstations that use other protocols can print through a server that uses one of the protocols mentioned, or they can print to the Fiery XJ parallel port. A Token Ring option is also available. This option supports the TCP/IP and IPX/SPX protocols. The Fiery XJ is auto-sensing, and can handle all of these connections simultaneously.

When you add the Fiery XJ to a network, it is assumed that a network administrator has already installed a network cabling system and connected workstations and servers.

1-2 Connecting to the Network

• Physically connecting the Fiery XJ to a functioning network

• Conﬁguring the network server

• Setting up the Fiery XJ

Stages of installation on the network

Installation can be performed by a network or printing administrator. The stages of a successful installation are:

Prepare a network node for the Fiery XJ—obtain cable and route it to the location where the Fiery XJ will be installed (near the copier) and attach the cable to the network interface of the Fiery XJ. See page 1-11 for details.

When network servers are required, you need to conﬁgure those servers to provide client access to the Fiery XJ as a color PostScript printer. See Chapter 3 for information on conﬁguring network servers in Windows and UNIX network environments.

Conﬁgure the Fiery XJ for your particular printing and network environment. First read “Before you proceed” in the Introduction, and then see Chapter 2 for details.

• Preparing client workstations for printing

Install the ﬁles needed for printing, install additional user software, and connect the client to the Fiery XJ over the network. These steps are described in Getting Started, and some information is provided in Chapter 3 of this manual.

• Administering the Fiery XJ

Monitor and maintain system performance and troubleshoot problems that arise. See Chapter 4 and the User Guide for details.

1-3 Fiery XJ on the network

Summary of Fiery XJ network installation

CONNECTION

SERVER CONFIGURATION

COLOR SERVER SETUP

CLIENT SETUP

Fiery XJ

Network server

Fiery XJ

UNIX Mac OS Windows

Prepare a network node. Connect the Fiery XJ to the printer and to the network.

Conﬁgure UNIX, Windows NT and IPX (Novell) servers to specify Fiery XJ print queues and Fiery XJ users.

Install Fiery XJ remote utilities on the server.

No special conﬁguration of AppleShare servers is required.

From the Fiery XJ Control Panel, perform Server Setup, Network Setup, Printer Setup and Job Log Setup. Set up the Fiery XJ for all active protocols.

At each workstation that will print to the Fiery XJ:

• Install the PostScript printer driver and the Fiery XJ PostScript printer description ﬁle (PPD), and connect to one or more queues.

• For computers that will use them, install Fiery XJ remote utilities and optional user software.

• Verify the Fiery XJ in the list of printers and run a test print.

Fiery XJ available on the network

1-4 Connecting to the Network

Quick path to installation

The diagrams on the following pages show typical systems that can be used for printing and running Fiery software from remote workstations. Find the page with your preferred platform and network type, and then look up the setup procedures referenced in the “Key to setup” at the top left of each diagram.

The diagrams describe devices that use the supported networking protocols. They are logical diagrams and are not intended to describe the physical arrangement (topology) of devices on the network. A variety of physical arrangements is possible with each logical arrangement. For example, twisted pair Ethernet networks commonly use a star conﬁguration around a hub, rather than a bus arrangement. The design of physical networks is beyond the scope of this manual.

If the network uses more than one protocol or more than one type of workstation, combine the setups listed for each component of your system. Note that multiple protocols (shown in the diagrams as parallel lines) can run on the same cable. A solid connection from the Fiery XJ with an arrow indicates that other supported network types can be operational at the same time.

A Token Ring card is required for connection to a Token Ring network. Token Ring drivers for the card are already built in to the F iery XJ system software. See Appendix A for information about Token Ring.

NOTE: The IPX/SPX and TCP/IP functionality outlined in this section is available on

both Ethernet and Token Ring networks. AppleTalk is supported on Ethernet only.

The protocols used in these diagrams are indicated as follows:

IPX (Novell)

AppleTalk

TCP/IP (lpd, nbt or http)

Parallel

Other

1-5 Fiery XJ on the network

Mac OS environment with AppleTalk

Key to setup:

1 Mac OS computer Getting Started 2 Fiery XJ Setup Chapter 2

Another supported protocol

Fiery XJ connected to copier

AppleTalk

AppleTalk protocol

Mac OS computer

Mac OS computers can print directly and run Fiery utilities

Mac OS computer

1-6 Connecting to the Network

Windows computers in a Novell environment

Key to setup:

1 NetWare server page 3-1 2 Fiery XJ Setup Chapter 2 3 NetWare client Getting Started 4 Windows computer with SPX page 3-24

Another supported protocol

Fiery XJ connected to copier

Windows computer: NetWare client

IPX protocol

SPX protocol (TCP/IP or AppleTalk possible)

IPX

Windows computer: NetWare client

NetWare server

Windows computer: NetWare client running SPX

3, 4

IPX

SPX for running Fiery utilities TCP/IP (http) for Fiery WebTools

Printing on this network

All Windows computers can print through the NetWare server

For running Fiery utilities

A Windows 95 computer with IPX/SPX protocols loaded

For running Fiery WebTools

A Windows 95 computer with TCP/IP (http) loaded

1-7 Fiery XJ on the network

Windows NT 4.0 Server environment

Key to setup:

1 Windows NT 4.0 Server page 3-19 2 Fiery XJ Setup Chapter 2 3 Windows NT 4.0 client page 3-24

Windows NT Workstation or Windows NT Server acting as print server

LAN with NETBEUI, etc.

Another supported protocol

Fiery XJ connected to copier

TCP/IP (lpd) for printing TCP/IP (http) for Fiery WebTools TCP/IP for Fiery utilities

Windows computer

NETBEUI or other protocol available on the clients and the server

TCP/IP

Windows NT 4.0 computer with TCP/IP loaded

Printing on this network

Windows 95 clients can print using a protocol available on the Windows NT 4.0 print server

Windows NT 4.0 machines can print using TCP/IP with the lpd protocol

For running Fiery utilities and WebTools

A Windows NT 4.0 computer with TCP/IP loaded

1-8 Connecting to the Network

Windows computers using Windows printing

Key to setup:

1 Windows computer Getting Started 2 Fiery XJ Setup Chapter 2

Another supported protocol

Fiery XJ connected to copier

TCP/IP (nbt)

Windows computer

TCP/IP (nbt) protocol

Windows computer

For Windows printing

Windows computers Windows (SMB) printing enabled

1-9 Fiery XJ on the network

UNIX workstations and Windows NT 4.0 computers on a TCP/IP network

Key to setup:

1 UNIX server/host page 3-27 2 Fiery XJ Setup Chapter 2 3 UNIX workstation page 3-28 4 TCP/IP client Getting Started, page 3-24 5 Windows NT 4.0 client page 3-24

UNIX server or workstation

1, 3

Another supported protocol

Fiery XJ connected to copier

TCP/IP (lpd) protocol

TCP/IP client PC

TCP/IP (lpd and http)

Windows NT 4.0 computer with TCP/IP loaded

Printing on this network

UNIX workstations with the TCP/IP (lpd) protocol can print directly and act as host for shared printing

TCP/IP clients can print through UNIX server or directly; requires TCP/IP and the lpr print service loaded

For running Fiery utilities

Requires Windows NT 4.0 computer on same network with TCP/IP loaded

For running Fiery WebTools

Requires Windows or Mac OS computer on same network with TCP/IP loaded

1-10 Connecting to the Network

Fiery XJ parallel port connection

Key to setup:

1 Fiery XJ Setup Chapter 2 2 Windows computer User Guide

A supported network protocol

With the parallel port enabled, the Fiery XJ can accept and print jobs sent to its parallel port.

Parallel

The rest of this chapter and the next chapter describe the parts of an installation that are performed on the Fiery XJ itself. This chapter describes the physical network connections. Chapter 2 summarizes Fiery XJ Setup and other administrative functions available from the Control Panel.

Fiery XJ connected to copier

Parallel input

Protocol not directly supported on Fiery XJ

PC workstation, server, or laptop

1-11 Fiery XJ on the network

Before you begin

The following steps should be completed before you conﬁgure the Fiery XJ and the workstations that will print to the Fiery XJ. A service technician will have performed some initial installation.

TO PREPARE FOR FIERY XJ CONFIGURATION:

1. Print a copier test page to make sure the copier is functioning normally.

2. Turn off the copier and connect the interface cable from the copier to the Fiery XJ.

3. To conﬁrm this connection, turn on the copier and the Fiery XJ and print a Test Page from the Control Panel.

To print a Test Page, press the Menu button on the Control Panel to display the Functions menu. (See “Fiery XJ Setup from the Control Panel” on page 2-2.) Choose Print Pages, and then Test Page.

4. With both the copier and the Fiery XJ turned off, connect the network cable to the Fiery XJ, as described in the next section.

The network should already be installed and operational.

5. Turn on the copier and then the Fiery XJ.

6. Prepare network server s to shar e Fiery XJ user software and to enable netw orked user s to print to the Fiery XJ, and proceed to Setup.

See Chapters 2 and 3 for details.

1-12 Connecting to the Network

Ethernet cable connection

The Fiery XJ supports Ethernet cabling of three types:

• Thinnet (thin coaxial Ethernet cable or 10Base2)

Uses an external transceiver to attach to the AUI (Attachment Unit Interface) connector on the Ethernet interface of the Fiery XJ.

• Thicknet (thick coaxial Ethernet cable or 10Base5)

Connects directly to the AUI connector on the Ethernet interface of the Fiery XJ.

• Unshielded Twisted Pair (UTP) deﬁned as Category 5 for use with 100BaseT, or as

Category 3 or Category 5 for use with 10BaseT. Uses an 8-pin RJ-45 connector that plugs into the RJ-45 socket on the Fiery XJ.

NOTE: The 100BaseT type supported by the Fiery XJ is 100BaseTX, also known as Fast

Ethernet. If an Ethernet hub is used, it must be a 100BaseTX hub.The term “100BaseT” is used to refer to 100BaseTX.

1-13 Ethernet cable connection

Back view of the Fiery XJ

Centronics-type parallel connector

AUI connector for thinnet and thicknet

RJ-45 connector for twisted pair Ethernet

Not used

Slot for 100BaseT option

Copier connector slot

Slots for Token Ring option

SCSI connector for external CD-ROM drive

Shut down the Fiery XJ

to more than one Ethernet connector; only one Ethernet connection can be made at any one time.

If the Token Ring option is installed, you can attach a cable to the RJ-45 connector on the Token Ring board and attach a second cable, for an Ethernet connection, to the motherboard. For more information on Token Ring, see Appendix A.

Power switch

before attaching it to any network device. Do not attach cables

1-14 Connecting to the Network

TO USE THINNET CABLE:

1. With the Fiery XJ turned off, connect the transceiver to the AUI connector on the back of the Fiery XJ. Slide the latch to lock the transceiver connection.

2. Connect the thinnet cable to the BNC connector on the transceiver. N

OTE: If the external transceiver has an SQE switch, make sure the switch is set to OFF.

It should be set to OFF at all times. The functions controlled by the SQE switch are not required for use with the Fiery XJ.

3. Conﬁgure network servers for printing and then proceed to Setup.

TO USE THICKNET CABLE:

1. With the Fiery XJ turned off, connect the thicknet cable connector to the AUI connector on the back of the Fiery XJ. Slide the latch to lock the connector.

2. Conﬁgure network servers for printing and then proceed to Setup.

TO USE UTP CABLE FOR 100BASET OR 10BASET:

1. With the Fiery XJ turned off, connect the RJ-45 cable connector to the Ethernet RJ-45 socket on the back of the Fiery XJ.

2. Conﬁgure network servers for printing and then proceed to Setup. N

OTE: 100BaseT is available as an option. Contact your authorized Fiery XJ dealer for

more information.

1-15 Ethernet cable connection

Parallel cable connection

In addition to receiving print jobs over Ethernet and Token Ring, the Fiery XJ can accept print jobs from a Windows computer through its high-speed parallel port. This connection is advantageous for portable computers and for workstations on dedicated networks using protocols other than AppleTalk, TCP/IP, or IPX.

The parallel port connection can be active at the same time as the network ports.

NOTE: The parallel port cannot be used to connect the Fiery XJ with Fiery utilities.

TO USE PARALLEL CABLE:

1. With the Fiery XJ and the Windows computer turned off, attach the parallel cable to the parallel port of the Fiery XJ.

See the illustration on page 1-13 for the location of the parallel port.

2. Connect the other end of the cable to the parallel port on the Windows computer.

3. Turn on the computer and the Fiery XJ.

4. Proceed to Setup. N

OTE: Use only the parallel cable supplied with your Fiery XJ.

To print to the parallel port, you need to set up the parallel port connection. See “Parallel P ort S etup options ” on page 2-14. For information on setting up printing, see Getting Started; for printing to the parallel port, see the User Guide.

2-1 About Fiery XJ Setup

Chapter 2:

Performing Setup from the Control Panel

The Fiery XJ BP100 Color Server ﬁts into a variety of work environments. To prepare for printing at your site, you need to do some initial conﬁguration to specify the network environment and the kind of printing you will do.

About Fiery XJ Setup

Setup is required the ﬁrst time the Fiery XJ is turned on after new system software is loaded. In this initial Setup, you (or the service technician who loads the software) choose the language you want to use for Control Panel screens.

Initial Setup from the Control Panel

In initial Setup, you must conﬁgure at least Server Setup, Network Setup, and Printer Setup, in that order, from the Control Panel.

If you don’t configure the remaining Setups, the Fiery XJ uses default settings. These defaults allow the Fiery XJ to reach the Idle state, but might not allow users to print to the Fiery XJ. You need to make settings appropriate for the printing environment at your site.

Network server setup requirements

On NetWare or Windows NT 4.0 networks, the network servers must be conﬁgured for printing to the Fiery XJ before you enter network settings on the Fiery XJ. The diagrams on pages 1-4 through 1-9 give chapter references for network server setup.

You need a live network connection so that the Fiery XJ can query the network for zones, servers, and server-based queues.

Whenever the conﬁguration of servers, printers, or the network itself changes at your site, you can alter individual settings to correspond to the changed environment. Likewise, if printing needs or administrative requirements change, you can alter the corresponding settings.

NOTE: Changing network or port settings may require that you make changes in more

than one Setup menu.

2-2 Performing Setup from the Control Panel

Fiery XJ Setup from the Control Panel

Setup, performed from the Control Panel right after powering on or rebooting the Fiery XJ, conﬁgures the Fiery XJ to communicate with other devices and manage print jobs sent to it.

There are six groups of Setup options:

• Server Setup to specify system options

• Network Setup to specify all the active network systems that will transmit print jobs

to the Fiery XJ

• Printer Setup to specify the way print jobs and queues are managed

• PS Setup to specify PostScript settings

• Color Setup to specify color settings

• Job Log Setup to specify how the Fiery XJ handles its log of printed jobs

Other Setup options allow you to calibrate the Fiery XJ, to create and change an administrator password, and to clear the jobs queued on the Fiery XJ.

2-3 Fiery XJ Setup from the Control Panel

Accessing Setup options

The Control Panel on the front of the Fiery XJ enables you to set options and view information about jobs printed to the Fiery XJ.

It comprises the following parts:

• Display window—shows status information and options for setting up the Fiery XJ

• Line selection buttons—select a setting and proceed to the next option

• Up and down buttons

• Menu button (escape key)

• Cancel button

• Activity light—indicates normal or problem activity

Fiery XJ Control Panel

Activity light

Display window

Up and down arrow buttons

Menu button

Line selection buttons

The User Guide describes the online display screens in detail. This chapter describes only the screens you might see when performing Setup.

Run Setup Install Software Format Disk

 Startup

Exit Setup Server Setup Network Setup Printer Setup

Setup

PS Setup Color Setup  Job Log Setup Calibration

Setup

Change Password Clear Server 

  Setup

TO ACCESS SETUP WHEN THE FIERY XJ IS AT IDLE:



For software update or setup,  press any key.

2-4 Performing Setup from the Control Panel

1. Make sure the information screen on the Control Panel reads Idle.

If Printing or Ripping appears, the F iery XJ is processing, and you must wait until the system ﬁnishes and reaches the Idle state.

2. Press the Menu button on the Control Panel to go to the Functions menu.

3. Scroll with the down arrow and press the line selection button next to Reboot Server.

After automatic start-up diagnostics, the Fiery XJ displays the setup message screen.

4. At the setup message, press any key.

5. Choose Run Setup to access all Setup menus.

The Install Software and Format Disk commands are for service technicians. If an Administrator password has been set on the Fiery XJ, you are prompted to

enter it before you can perform Setup (see page 2-44).

6. Press the line selection button to choose a Setup menu or command.

Press the down button to view the second and third screens of the main Setup menu.

7. Choose setups in the same order as they appear in the menu: Server Setup, Network Setup, Printer Setup, PS Setup, Color Setup, and then Job Log Setup.

The sequence is important for ﬁrst-time Setup. Later, just go directly to the menu you want to change. However, if you make changes in Network Setup, you may need to change some settings in Printer Setup as well.

8. Set an Administrator password to protect your Setup from unauthorized alteration.

2-5 Fiery XJ Setup from the Control Panel

TO ACCESS SETUP WHEN THE FIERY XJ IS OFF:

1. Make sure the Fiery XJ is connected to the copier and to the network you will use.

2. Turn on the Fiery XJ.

The startup diagnostics are performed.

3. At the startup message, press any key.

4. Continue with step 5 from the previous procedure.

Review the settings described in this chapter. For more information on calibration and Control Panel screens other than those in Setup, see the User Guide.

About the Control Panel Setup interface

When you perform Setup from the Control Panel, you select one menu after another and enter information about your Fiery XJ and your network and printing environment.

In each Setup screen, the last line of the display window tells you the name of the current Setup menu. Most of the menus you see are sho wn on the Control Panel Map, a ﬂowchart that can be printed from the Control Panel.

TO PRINT THE CONTROL PANEL MAP:

1. At the Control Panel, press the Menu button to access the Functions menu.

2. Press the button for Print Pages.

The Control Panel displays the ﬁrst four types of pages you can print. To see the remaining types of pages, press the down button.

3. Press the button for Control Panel Map.

2-6 Performing Setup from the Control Panel

Types of Setup screens

There are two types of Setup options:

Multiple choice questions

Information entry options

You are given choices (for example, Yes or No, or a list of options from which to choose). Only one choice is displayed at a time, in highlighted text. The currently selected (or the default) value appears ﬁrst.

Use the up and down buttons to scroll through the selections, and choose OK when the correct information is displayed.

You must specify the information for your site. For example, the printer name or IP address.

In that case, use the up and down buttons to scroll the alphanumeric symbols to make your selection.

The cursor position is highlighted, and two of the line selection buttons become left and right arrow buttons. Arrows appear on the display window next to the corresponding buttons. Use these buttons to move between positions for entering information.

NOTE: When you enter text, enter it from left to right, as

the left arrow button acts as a delete key as well as a cursormoving key. This is indicated in the display by the delete symbol ( ).

2-7 Fiery XJ Setup from the Control Panel

Example: Multiple choice

Publish Print Queue

Yes 

 OK

Printer Setup

Press up or down to display the other option or options.

Example: Information entry with ﬁelds

Subnet Mask

255.0.0.0 >

< OK

TCP/IP (Ethernet)

From the starting position, press the right arrow button to move the cursor to the right.

Example: Information entry with

Publish Print Queue

No 

 OK

Printer Setup

When the setting you want is displayed, press the button beside OK to continue.

Subnet Mask

255.0.0.0 > < OK

TCP/IP (Ethernet)

The next ﬁeld is selected. Press up or down to change the number.

individual characters

Subnet Mask

255.255.0.0 > < OK

TCP/IP (Ethernet)

When the correct number is displayed, press the right arrow button to move to the third ﬁeld. Press the left arrow button to go back and edit, or press OK to select the choice and continue.

Enter Your File Server Password >  OK

Bindery Setup

From the starting position, press up or down to enter the ﬁrst character.

Enter Your File Server Password >

9 

OK

Bindery Setup

When the correct character is displayed, press the right arrow button to move the cursor to the next position.

Press up or down to enter a character in the second position. The delete button erases the current character and moves the cursor to the left. Pressing OK enters what is currently displayed.

Enter Your File Server Password >



9  OK

Bindery Setup

2-8 Performing Setup from the Control Panel

NOTE: If you make a mistake during Setup, you can always use the Menu button to

cancel without saving changes. If you are viewing a Setup screen, pressing the Menu button cancels what you are doing in the current screen to bring you to the next higher level menu. You may need to press Menu more than once to return to the top level for the particular Setup procedure with which you are working. Once at the top level, you can enter the current Setup again, or exit without making changes.

When you have entered all the settings or made all the changes you want, you need to save the changes. You are usually prompted to do so. If you choose Yes, your settings overwrite previous settings. If you choose No, your previous settings are retained. If necessary, the Fiery XJ reboots after you exit from the Setup menu.

Server Setup options

The Server Setup menu lets you specify system information that pertains to the Fiery XJ itself and all users. Accessing the menu is described on page 2-2.

Exit Setup Server Setup Network Setup Printer Setup

Setup

When you choose Server Setup, the options appear in sequence, as described below. Default values, where applicable, appear in square brackets. Words shown in italics indicate that a product- or site-specific value is displayed.

Server Name

Default server name

Use this option to give the F iery XJ a name (up to 10 characters long). This is the name that will appear in the Chooser on an AppleTalk network.

Also enter this name when you conﬁgure the connection for Fiery Downloader on IPX/SPX networks (see Getting Started).

NOTE: Do not use the device name (r2) as the server name. Also, if you have multiple

Fiery XJ servers and give them the same name, a unique number is appended to the name that appears in the list of available servers. Although this routes jobs correctly, it may be inconvenient to users and is not a recommended practice.

Press button for Server Setup

2-9 Fiery XJ Setup from the Control Panel

System Date

Use this option to change the system date. Enter the date in the standard form for your usage. The date is used on the cover page and in Job Logs.

System Time

Use this option to change the system time. Enter the time based on the 24-hour clock in the form HH:MM (Hours:Minutes). The time is used on the cover page and in Job Logs.

Print Start Page No/Yes [No]

Use this option to specify whether the Fiery XJ should print a start page every time it is powered on or rebooted. The start page displays information about the Fiery XJ, including the server name, current date and time, printer mode, amount of memory installed in the Fiery XJ, last calibration date, network protocols enabled, and connections published.

Use Character Set Macintosh/DOS/Windows [Macintosh]

Use this option to specify whether the Control P anel should use the M acintosh, DOS, or Windows character set for displaying ﬁlenames. This is important if ﬁlenames include accented or composite characters (such as é, ü, or æ).

For mixed-platform networks, choose the option that gives the best overall representation of the special characters you use.

Enable Printed Queue Yes/No [Yes]

Select Yes if you want to enable the Printed queue, which creates a storage location on the Fiery XJ disk for recent jobs that were printed from the Print queue. Users with Administrator access to Fiery WebSpooler can reprint jobs from the Printed queue without sending them to the Fiery XJ again. If you select No, jobs are deleted from the Fiery XJ disk immediately after they are printed.

Jobs Saved in Printed Queue 1-99 [10]

This option appears only if Enable Printed Queue is set to Yes. Specify the number of jobs to be stored in the Printed queue. Note that jobs in the Printed queue take up space on the Fiery XJ hard disk. If disk space is low, use a smaller value for saved jobs.

2-10 Performing Setup from the Control Panel

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in the Server Setup; select No to return to the main Setup menu without making any changes.

Network Setup options

Network Setup conﬁgures the Fiery XJ to receive print jobs over the network systems that will be used at your site.

Exit Setup Server Setup Network Setup Printer Setup

Setup

Exit Network Setup Port Setup Protocol Setup Service Setup

Network Setup

In the Setup menu, choose Network Setup.

The Network Setup menu includes three submenus that let you choose port types, protocols, and network services. You must perform Port Setup and enable at least one port.

For each item you enable, you are prompted to enter settings for that item. Default values, where applicable, appear in square brackets.

In Network Setup you specify network addresses and names to be used by workstations, servers, and the Fiery XJ when they communicate with each other.

You need to display and select options only for the network systems that are currently used at your site. If your network requirements change, you can change Network Setup at any time.

If the Fiery XJ is configured to enable more than one protocol, it automatically switches to the correct protocol when it receives a print job. When the parallel port and one or two network ports are enabled, print jobs can be received over all of those ports at the same time.

2-11 Fiery XJ Setup from the Control Panel

The available network types, and the Setup areas that pertain to them, are summarized in the following tables.

For this Network or

Connection Type:

AppleTalk over Ethernet Ethernet Setup AppleTalk Setup AppleTalk printing (PAP) is

TCP/IP over Ethernet Ethernet Setup TCP/IP Setup: Ethernet Setup LPD Setup

IPX/SPX over Ethernet Ethernet Setup IPX/SPX Setup PServer Setup (NDS,

Parallel Parallel Port Setup

For this Network or

Connection Type:

TCP/IP over Token Ring Token Ring Setup TCP/IP Setup: Token Ring Setup LPD Setup

IPX/SPX over Token Ring Token Ring Setup IPX/SPX Setup PServer Setup (NDS,

Use this Port Setup: Use this Protocol Setup: Use this Service Setup:

enabled automatically.

Web Services Setup Windows Setup

Bindery, or both)

—

If the Token Ring option is installed, you have these additional options:

Use this Port Setup: Use this Protocol Setup: Use this Service Setup:

Web Services Setup Windows Setup

Bindery, or both)

—

TO ACCESS NETWORK SETUP OPTIONS:

1. Conﬁrm that the network cable is connected to the Fiery XJ.

During Network Setup , the Fiery XJ queries the network for zones, servers, and serverbased queues. If you perform Network Setup without a connected and functioning network, default settings are used that may not meet your needs.

2. Choose Network Setup from the main Setup menu.

2-12 Performing Setup from the Control Panel

3. Choose Port Setup from the Network Setup menu.

4. To use Ethernet, choose Ethernet Setup from the Port Setup menu, and enter the

5. If the Token Ring option is installed, choose Token Ring Setup and enter the appropri-

6. To print to the parallel port, choose Parallel Port Setup from the Port Setup menu, and

7. When you have ﬁnished entering port settings, choose Exit P ort Setup and then choose

8. Enter the appropriate settings for the protocol or protocols you will use.

9. When you have ﬁnished entering protocol settings, choose Exit Protocol Setup and

10. Enter the appropriate settings for the services you will use.

appropriate settings.

ate settings.

enter the appropriate settings.

Protocol Setup.

then choose Service Setup.

The options are described in detail in the following pages.

TO EXIT NETWORK SETUP:

1. When you have ﬁnished entering service settings, choose Exit Network Setup.

2. Choose Yes when prompted to save changes.

3. From the main Setup menu, choose another Setup or choose Exit Setup.

Network Setup

Exit Port Setup Ethernet Setup Token Ring Setup Parallel Port Setup

Port Setup

Network Setup

Port Setup

2-13 Fiery XJ Setup from the Control Panel

Port Setup options

You can enable Ethernet and parallel communication simultaneously. If the Token Ring option is installed, you can also enable Token Ring. To conﬁgure the Fiery XJ, choose each port type you use and enter the settings for that port. Since network setups are nested, the names of higher-level menus are shown in this chapter to the left of each menu heading.

Ethernet Setup

Enable Ethernet Yes/No [Yes]

Select Yes if you have Ethernet cabling connected to the Fiery XJ.

Ethernet Speed Auto Detect/100 Mbps/10 Mbps [Auto Detect]

The Ethernet Speed options appear only if the 100BaseT option is installed. Select Auto Detect if your network envir onment is mixed, or if you do not know the

network speed. If you know the speed of the network to which the Fiery XJ is attached (10 Mbps or 100 Mbps), select it.

Token Ring Setup

Enable Token Ring Yes/No [No]

Select Yes if the Fiery XJ is to be connected to a Token Ring network.

Maximum Frame Size (bytes) 4202/2154/1130/632 [4202]

Select the maximum frame size recommended by the network administrator at your site. If you are uncertain of the setting to use, select the default value (4202).

Enable Source Routing Yes/No [Yes]

Select Yes if your network supports source routing.

Network Setup

Port Setup

2-14 Performing Setup from the Control Panel

Source Routing Request All Route Yes/No [Yes]

This option appears only if you enabled Source Routing. Select Yes if you want the Request packet to travel to its destination by all routes.

Source Routing Respond All Route Yes/No [No]

This option appears only if you answered No to the previous option. Select Yes if you want the Response packet to return by all routes to the originating computer.

Parallel Port Setup options

You must enable the parallel port in order to enter the Parallel Port Setup options and print to the parallel port.

Parallel Port Setup

Enable Parallel Port No/Yes [No]

Select Yes if you want to print through the parallel port. You can connect a single Windows computer to the parallel port and print directly to the Fiery XJ.

NOTE: Enabling the parallel port does not conﬂict with using Ethernet or Token

Ring communication with the Fiery XJ.

Port Timeout in Seconds 5-60 [5]

This option appears only if Enable Parallel Port is set to Yes. Your setting determines how long the Fiery XJ waits without receiving data from the parallel port before deciding that the current job is complete. Until the timeout, the Fiery XJ cannot receive new jobs through the parallel port, but it can continue to receive network print jobs.

2-15 Fiery XJ Setup from the Control Panel

Ignore EOF Character Yes/No [Yes]

This option appears only if Enable Parallel Port is set to Yes. This option speciﬁes that the Fiery XJ should ignore end-of-ﬁle (EOF) messages in a ﬁle. This option must be set to Yes to print PostScript ﬁles in binary format (not ASCII). When this option is set to

Yes, the Fiery XJ uses the parallel port timeout value to determine when the end of the

ﬁle has been reached. If you experience printing problems, set this option to No.

When you have configured the port options, choose another port type, or choose Exit Port Setup and proceed to Protocol Setup.

Protocol Setup options

Exit Protocol Setup AppleTalk Setup TCP/IP Setup IPX/SPX Setup

Protocol Setup

Network Setup

Protocol Setup

To conﬁgure the Fiery XJ, choose each protocol and enter the settings for that protocol. You can enable AppleTalk, TCP/IP, and IPX/SPX communication simultaneously.

AppleTalk Setup

Enable AppleTalk Yes/No [Yes]

Select Yes if you have an AppleTalk network connected to the Fiery XJ. This setting enables the Fiery XJ to communicate over AppleTalk networks.

2-16 Performing Setup from the Control Panel

AppleTalk Zone

List of zones

The Fiery XJ searches the network for AppleTalk zones in your network segment. Scroll through the list to select the AppleTalk zone in which you want the Fiery XJ to appear. If your segment has only one zone, the Fiery XJ is assigned to that zone automatically.

The message “No AppleTalk zone found” may mean your network has no zones, or the network cable is not connected (see page 4-4). Choose OK.

TCP/IP Setup options

Exit Protocol Setup AppleTalk Setup TCP/IP Setup IPX/SPX Setup

Protocol Setup

Exit TCP/IP Setup Ethernet Setup Token Ring Setup Gateway Setup

TCP/IP Setup

To conﬁgure the Fiery XJ for TCP/IP, choose TCP/IP Setup.

Choose Ethernet Setup and enter the appropriate settings. Choose each network type you use (Ethernet and/or Token Ring) and enter the appropriate settings. Token Ring Setup appears as an option only if you have enabled Token Ring in Port Setup. If your network uses a gateway, enter the gateway address in Gateway Setup.

NOTE: If TCP/IP is running on both an Ethernet and a Token Ring network, it is

assumed that the two networks are already routed to each other. The Fiery XJ does not function as a router.

Network Setup

Protocol Setup

TCP/IP Setup

2-17 Fiery XJ Setup from the Control Panel

TCP/IP Setup with Ethernet

Ethernet Setup

Enable TCP/IP for Ethernet Yes/No [No]

Select Yes if you have a TCP/IP network connected to the Fiery XJ over Ethernet cabling.

If you use Token Ring, enabling TCP/IP for Token Ring is required for enabling the Fiery WebT ools.

NOTE: If you are using TCP/IP for printing from Windows NT 4.0 workstations,

enabling T CP/IP her e also enables you to use Fiery utilities from Windows NT 4.0 workstations using TCP/IP protocols. At the same time, enabling TCP/IP enables the network layer that lets you use Fiery utilities from Windo ws 95 computers using IPX/SPX protocols.

IP Address [127.0.0.1]

Enter the Fiery XJ IP address for Ethernet. The Fiery XJ is shipped with the IP address set to the loopback address, which is an internal address used for network checking. If you plan to print with TCP/IP, you must ﬁrst assign the Fiery XJ a unique network IP address. For information about setting up printing with TCP/IP, see Chapter 3.

Subnet Mask [255.255.255.0]

This option lets you modify the subnet mask for printing with TCP/IP over Ethernet. The subnet mask is set to 255.255.255.0 by default. If you set the IP address and you need to set the subnet mask, enter one of the following values:

• 255.0.0.0 if the IP address starts with a number less than 128

• 255.255.0.0 if the IP address starts with a number from 128 through 191

• 255.255.255.0 if the IP address starts with a number greater than 191

NOTE: Be sure to conﬁrm the subnet mask setting with your network administrator

before proceeding. In some cases the required setting may be different from those listed.

Network Setup

Protocol Setup

TCP/IP Setup

2-18 Performing Setup from the Control Panel

TCP/IP Setup with Token Ring

Enable TCP/IP for Token Ring, and enter the IP address and subnet mask. Then, if your T CP/IP network has a gateway, and users outside the gateway plan to print to the Fiery XJ using TCP/IP, choose Gateway Setup and enter the gateway address (see page 2-19).

Token Ring Setup

Enable TCP/IP for Token Ring Yes/No [No]

Select Yes if you have a TCP/IP network connected to the Fiery XJ over Token Ring.

If you use Token Ring, enabling TCP/IP for Token Ring is required for enabling the Fiery WebT ools.

NOTE: If you are using TCP/IP for printing from Windows NT 4.0 workstations,

enabling TCP/IP here also lets you use the Fiery utilities from Windows NT 4.0 workstations using TCP/IP protocols. At the same time, enabling TCP/IP enables the network layer that lets you use the Fiery utilities from Windows 95 computers using IPX/SPX protocols.

IP Address [127.0.0.1]

Enter the Fiery XJ IP address for Token Ring. The Fiery XJ is shipped with the IP address set to the loopback address, which is an internal address used for network checking. If you plan to print with TCP/IP, you must ﬁrst assign the Fiery XJ a unique network IP address. For information about setting up printing with TCP/IP, see Chapter 3.

2-19 Fiery XJ Setup from the Control Panel

Subnet Mask [255.255.255.0]

This option lets you modify the subnet mask for printing with TCP/IP over Token Ring. The subnet mask is set to 255.255.255.0 by default. If you set the IP address and you need to set the subnet mask, enter one of the following values:

• 255.0.0.0 if the IP address starts with a number less than 128

• 255.255.0.0 if the IP address starts with a number from 128 through 191

• 255.255.255.0 if the IP address starts with a number greater than 191

NOTE: Be sure to conﬁrm the subnet mask setting with your network administrator

before proceeding. In some cases the required setting may be different from those listed.

Gateway

Exit TCP/IP Setup Ethernet Setup Token Ring Setup Gateway Setup

TCP/IP Setup

Network Setup

Protocol Setup

TCP/IP Setup

If your TCP/IP network has a gateway, and users outside the gateway plan to print to the Fiery XJ using TCP/IP, choose Gateway Setup and enter the gateway address here.

The gateway address applies to either a Token Ring or an Ethernet network. If TCP/IP is running on both an Ethernet and a Token Ring network, the gateway address you enter must be in the same subnet as either the Ethernet or the Token Ring address.

Gateway Setup

Gateway Address [127.0.0.1]

Use this option to set the gateway address for printing with TCP/IP. By default, the loopback address, 127.0.0.1, is set. (The loopback address is a specially reserved address that allows for certain TCP/IP diagnostic tests to be run without being connected to a network.)

After setting the gateway address, proceed to setup Token Ring, if applicable, or choose Exit TCP/IP Setup and proceed to Service Setup.

2-20 Performing Setup from the Control Panel

IPX/SPX Setup options

Exit Protocol Setup AppleTalk Setup TCP/IP Setup IPX/SPX Setup

Protocol Setup

Exit IPX/SPX Setup Select Frame Types Clear Frame Types



IPX/SPX Setup

Exit IPX/SPX Setup Ethernet 802.2 * Ethernet 802.3 Ethernet II

IPX/SPX Setup

To conﬁgure the Fiery XJ for IPX/SPX protocols, choose IPX/SPX Setup from the Protocol Setup menu.

Select Frame Types

Choose Select Frame Types. You must choose at least one frame type to enable IPX/SPX protocols. The Fiery XJ supports the following frame types for IPX/SPX:

• for Ethernet—Ethernet 802.2, Ethernet 802.3, Ethernet II, and Ethernet SNAP

• for Token Ring—Token Ring and Token Ring SNAP The frame selection screen allows you to make multiple selections. Depending on

your Port Setup selection, only Ethernet frame types, only Token Ring frame types, or all frame types are displayed. Press the line selection button beside each frame type used on your IPX/SPX network. An asterisk (*) appears beside each selected frame type. (Press the line selection button again to deselect a frame type.) Use the up and down buttons to scroll to additional frame types. The F iery XJ binds to each frame type as you select it.

When you have selected all the frame types used, choose Exit IPX/SPX Setup.

Clear Frame Types

If you selected several frame types by mistake, you can clear them all at once by choosing Exit IPX/SPX Setup, then choosing IPX/SPX Setup and selecting Clear Frame Types.

For protocols other than IPX/SPX, the frame type is automatically enabled and does not require setup, as follows:

With this protocol: And these printing services:

AppleTalk PAP (Printer Access Protocol) Ethernet SNAP

TCP/IP with Ethernet TCP/IP with Token Ring LPD (Line Printer Daemon) Token Ring SNAP

LPD (Line Printer Daemon) Ethernet II

This frame type is

automatically enabled:

2-21 Fiery XJ Setup from the Control Panel

Exit Service Setup LPD Setup PServer Setup Windows Setup

Service Setup

Web Services Setup

   Service Setup

Network Setup

Service Setup

LPD Setup

Service Setup options

Network Service Setup has options for TCP/IP and IPX/SPX networks.

• LPD Setup enables lpd printing on TCP/IP networks.

• For IPX/SPX networks, PServer Setup allows you to enter the names of the Novell

objects that are concerned with Fiery XJ print jobs.

• Windows Setup enables the Microsoft SMB (Server M essage Block) pr otocol, which

supports peer-to-peer printing, also known as Windows printing or SMB printing.

• Web Services Setup enables the http protocol and, therefore, use of the

Fiery WebT ools.

PServer is a program in the Fiery XJ that can service the Novell print queues assigned to the Novell print servers you have set up for printing to the Fiery XJ. When you choose PServer Setup and enable PServer, you can set up NDS (Novell Directory Services), Bindery Services, or both. NDS is used with NetWare 4.x; Bindery Services are used with NetWare 3.x or with NetWare 4.x in bindery emulation mode.

NOTE: Due to the number of options involved, PServer Setup is discussed last in this

section, after Web Services Setup.

LPD Setup options

Enable LPD Yes/No [Yes]

Select Yes to allow lpd printing. See “Setting up the Fiery XJ on TCP/IP networks” on page 3-29 for more information.

Network Setup

Service Setup

Windows Setup

2-22 Performing Setup from the Control Panel

Windows Setup options

Enable Windows Printing Yes/No [No]

Enabling Windows Printing enables SMB (Server Message Block), the built-in ﬁle and printer sharing protocol built into Windows. Enabling SMB allows the Fiery XJ to be listed on the network so that Windows clients can print to a particular print connection (Print or Direct) on the Fiery XJ without any other networking software. For information on how to set up a Windows computer for Windows printing, see Getting Started. Windows printing runs via TCP/IP, so TCP/IP must be conﬁgured on the Fiery XJ and on all workstations that use Windows printing.

Use WINS Name Server Yes/No [No]

Broadcasts from SMB devices cannot be routed without a WINS name server. Setting up the WINS name server is outside the scope of this manual. To ﬁnd out if a name server is available, contact your network administrator.

WINS IP Address [127.0.0.1]

This option appears only if you choose Yes for WINS Name Server. The address is set to the loopback address. Replace this with the correct IP address for the WINS Name Server. Obtain the correct address from your network administrator.

Server Name

Default Name

The server name is the name that will appear on the network for accessing the Fiery XJ via SMB. The default name is the same as the server name assigned in Server Setup (see page 2-8).

Server Comments

Server comments (optional) can contain information about the printer.

Workgroup or Domain

Enter the workgroup or domain you want the Fiery XJ to appear in.

Network Setup

Service Setup

Web Services Setup

2-23 Fiery XJ Setup from the Control Panel

Web Services Setup

Enable Web Services Yes/No [No]

Select Yes if TCP/IP is enabled on the Fiery XJ and on user workstations, and you wish to make the Fiery WebTools available to users (see page 3-26). The Fiery WebT ools include:

• Fiery WebSpooler

• Status

• Installer A Java-enabled Web browser and a valid IP address are required for each user. See

Getting Started for details on browser choice and workstation requirements.

PServer Setup options

Network Setup

Service Setup

PServer Setup

Exit PServer Setup NDS Setup Bindery Setup Polling Interval

PServer Setup

Enable PServer Yes/No [No]

Select Yes if you have a Novell network connected to the Fiery XJ.

Choose NDS Setup if your network uses NetWare 4.x in native mode. Choose Bindery Setup if your network uses NetWare 3.x or uses NetWare 4.x in bindery emulation mode.

If your network uses both NDS and Bindery, set up NDS ﬁrst. Setting up NDS after Bindery will overwrite Bindery Setup.

If your network uses both NDS and Bindery, and uses NetWare 4.x servers in bindery emulation, note that the Fiery XJ cannot service NDS and bindery emulation servers on the same NDS tree.

Network Setup

Service Setup

PServer Setup

2-24 Performing Setup from the Control Panel

NDS Setup

Before entering NDS settings, be sure the Fiery XJ is connected to the network and you have already conﬁgured an NDS directory tree with a Printer, a Print Server, and one or more Print Queue objects for Fiery XJ jobs (see page 3-4). To perform NDS Setup you may need permission to browse the NDS tree. If access to the P rint Server is restricted, you’ll need a login password.

The main objective of NDS Setup is to specify the Print Server object. In addition, you can indicate the location of the Fiery XJ print queues.

Note that the terms NetWare server, Novell server, and IPX server are in common use and are used here interchangeably to mean the server on an IPX network running Novell NetWare networking software.

Enable NDS No/Yes [No]

Select Yes if the NetWare servers you will use to print to the Fiery XJ are running NetWare 4.x in native mode.

Select NDS Tree

List of trees

Use the up and down buttons to browse the list of NDS tr ees available to the Fiery XJ. Choose OK when you have displayed the tree that contains the Printer, Print Server, and print queue objects you have previously deﬁned for the Fiery XJ.

Your new NDS tree selection automatically overwrites any previous tree selection. If you change the NDS tree selection and there are also current Bindery settings, you are alerted that they will be deleted. If you continue with NDS Setup, you can replace Bindery settings afterwards. If you don ’t want to continue, you can exit NDS Setup by pressing the Menu button to escape.

2-25 Fiery XJ Setup from the Control Panel

Is user login needed to browse NDS tree? Yes/No [No]

Select No if no password is required to browse the tree. You can proceed to navigate to the Print Server object.

Select Yes if network permissions require that you log in to browse the NDS tree and see the Print Server object you want to select. If you select Yes, you are prompted to navigate to the User Login object.

Navigate the NDS tree to the User Login object.

This message is displayed if you selected Yes for the previous option. Choose OK and browse the NDS tree as described in the following paragraphs.

NDS Tree name Object list, “..”

Browsing to ﬁnd the User Login object begins with the NDS tree that you selected previously (with Select NDS Tree). Use the up and down buttons to scroll a list of objects in the tree beneath the [Root] in the hierarchy, or use the navigation symbol “..” to go up one level at a time.

In each subsequent browse screen, the top line represents your current location. The second line contains:

• A list of objects in the current container directly below your current location

• The symbol “..” to go up one level. With an object selected, choose OK to travel down the tree, or choose “..” to go up the

tree. When you select an object and choose OK, that object is then displayed on the top line, and the second line lists objects directly below it.

Continue to browse the NDS tree until the User Login object is displayed in the second line. Choose OK.

2-26 Performing Setup from the Control Panel

Enter Password

Enter the login password for the NDS tree, using the up and down buttons to select characters, and the left and right arrow buttons to move the cursor. Choose OK.

Navigate the NDS tree to the Print Server.

Press OK to browse the NDS tree to the Print Server object. Browsing to ﬁnd the Print Server object begins with the NDS tree that you selected

previously (with sents your current location. The second line contains:

• A list of objects in the current container directly below your current location

• The symbol “..” to go up one level. With a container object selected, choose OK to travel down the tree, or choose “..” to

go up the tree. When you select an object and choose OK, that object is then displayed on the top line, and the second line lists objects directly below it.

Select NDS Tree). In each subsequent browse screen, the top line repre-

When the Print Server is displayed in the second line, choose OK.

Enter Print Server Password

Enter the Print Server password, using the up and down buttons to enter characters, and the left and right arrow buttons to move the cursor. Choose OK. (If no password is required, choose OK.)

Server should look for print queues in: Entire NDS Tree/Specified subtree [Entire NDS Tree]

By default, the Fiery XJ searches the entire NDS tree for Fiery XJ print connections. This option lets you restrict the search for Fiery XJ print jobs to a subtree (the Print Queue root) in which the Fiery XJ print connections have been deﬁned. This makes the search more efﬁcient. Select Entire NDS tree if the tree is small. Select Specified

subtree

to restrict the search and specify the subtree.

2-27 Fiery XJ Setup from the Control Panel

If you select Entire NDS tree, choosing OK returns to PServer Setup. Proceed with Bindery Setup (see page 2-38), set the Polling Interval (see page 2-43), or choose Exit PServer Setup to return to the Service Setup menu.

Browse to the root of the Print Queue subtree.

This message is displayed if you selected Specified subtree in the previous option. Choose OK to browse the NDS tree to the Print Queue subtree.

Browsing to ﬁnd the container object begins with the NDS tree that you selected previously (with Select NDS Tree). In each subsequent browse screen, the top line represents your current container. The second line contains:

• A list of objects directly below your current location

• The symbol “..” to go up one level

• The symbol “.” to select the current container object (displayed in the top line)

without traveling down the tree

With an object selected, choose tree. When you select an object and choose OK, that object is then displayed on the top line, and the second line lists objects contained within.

When the container that contains print queues is displayed in the second line, choose

OK. In the next screen, choose “.” and choose OK to select the object in the top line.

When the Fiery XJ displays the container name, choose OK to return to PServer Setup. Proceed with Bindery Setup (see page 2-38), set the Polling Interval (see page 2-43), or

choose Exit PServer Setup to return to the Service Setup menu.

OK to travel down the tree, or choose “..” to go up the

Network Setup

Service Setup

PServer Setup

2-28 Performing Setup from the Control Panel

Bindery Setup options

Bindery Setup

Use Bindery Setup if you have already conﬁgured one or more bindery servers (ﬁle servers running NetWare 3.x or NetWare 4.x in bindery emulation) with a Print Server and a Print Queue for F iery XJ jobs. Before entering bindery settings, be sure the Fiery XJ is connected to the network and the NetWare ﬁle server is running. If Guest Login is not supported, you’ll need a valid user name and password.

NOTE: The terms NetWare server, Nov ell server, and IPX ﬁle server are in common

use and are used here interchangeably to mean the server on an IPX network running Novell NetWare networking software.

Bindery Setup menu

Exit Bindery Setup Add File Server View Server List Edit Connection

Bindery Setup

Remove File Server

  

Bindery Setup

Because you can set up more than one Novell server to handle Fiery XJ print jobs, an additional menu is displayed for this purpose. The options are:

Add File Server—creates a new ﬁle server connection to the Fiery XJ. You can set

•

up a maximum of eight ﬁle server connections. After you have ﬁnished adding a new server, you return to the Bindery Setup menu, and you can set up another server if you wish.

• View Server List—displays the list of ﬁle servers that have already been selected to

communicate with the Fiery XJ.

• Edit Connection—lets you change the NetWare Print Server that will print to the

Fiery XJ.

• Remove File Server—lets you disconnect the Fiery XJ from a ﬁle server to which

it is currently connected. Remove a ﬁle server when you want to reduce the number of connections to the Fiery XJ or re-assign the connection to a different NetWare ﬁle server.

• Exit Bindery Setup—after you added all servers, viewed a list of ﬁle servers, or

removed a ﬁle server from the list.

2-29 Fiery XJ Setup from the Control Panel

NOTE: If you change your mind about any of the menus you have selected, you can use

the Menu button to escape and return to the main Bindery Setup menu. To cancel all changes you must exit Network Setup and select No to Save Changes.

Network Setup

Service Setup

PServer Setup

Bindery Setup

Add File Server

This option gives you two ways to add a Novell NetWare ﬁle server.

Select File Server From List/Search by Name [From List]

You may select the ﬁle server from a scrollable list, or by a name search. Choose From List if your network doesn’t have a large number of ﬁle servers.

Search by Name if the number of ﬁle servers is so large that scrolling through

Select the list would take a long time.

If you selected From List: If you selected Search by Name:

Add Server [list of all servers]

The Fiery XJ obtains a list of NetWare ﬁle servers by querying the IPX network. Use the up and down buttons to select a NetWare ﬁle server from the list. Choose the server on which you have conﬁgured a print server and print queue to handle Fiery XJ print jobs.

Enter First Letters of Server Name

Use the up and down buttons to enter the ﬁrst letters of the name of the ﬁle server you want to use, and choose OK.

Add Server [list of servers matching the search]

This option is displayed if you entered letters to search. Scroll to select the server you want from the list.

Once you have chosen a file server, the Fiery XJ immediately tries to log in as a guest without a password. If it succeeds, it skips to the NetWare Print Server option.

If you try to add a ﬁle server but all Fiery XJ connections are already being used, you are prompted to remove a ﬁle server (see “Remove File Server” on page 2-32).

2-30 Performing Setup from the Control Panel

File Server Login administrator/supervisor/Enter Login Name [supervisor]

This option appears only if a password is required for login or if there is no guest account or the guest account is restricted. Choose Enter Login Name to enter your own login name and password or to log in as a guest. Choose administrator or supervisor if you have those privileges.

Enter Your Login Name [guest]

This option and the next appear only if you selected Enter Login Name for the File

Server Login

Enter Your File Server Password

Enter the password for logging in to your NetWare ﬁle server. If you enter the password incorrectly, you are prompted to re-enter it.

NetWare Print Server

Print Server Name

. Enter your login name or select guest.

Select the name of the print server that you have conﬁgured in the NetWare utility PCONSOLE. This is the print server that will route print jobs to the Fiery XJ from computers on IPX networks.

Enter Your Print Server Password

This option appears only if your NetWare print server is set up to require you to log in with a password. Enter your print server password.

Choose Add Server again until you have connected each NetWare file server you have configured for printing to the Fiery XJ. When you have added all the IPX file servers for your site, choose Exit Bindery Setup.

Network Setup

Service Setup

PServer Setup

Bindery Setup

Network Setup

Service Setup

PServer Setup

Bindery Setup

2-31 Fiery XJ Setup from the Control Panel

View Server List

Supported Servers

This option lets you view the list of ﬁle servers currently connected to the Fiery XJ, that is, servers you have added in Bindery Setup. You are notiﬁed if there are none. When you choose OK, you return to the Bindery Setup menu.

Edit Connection

On each connected NetWare ﬁle server, you have deﬁned a print server to handle Fiery XJ print jobs. Use this option to change the print server assigned to the Fiery XJ.

Choose File Server [File server name]

From the list of connected NetWare ﬁle servers, choose the ﬁle server whose print server you wish to change.

NetWare Print Server [List of print servers on selected file server]

Choose the name of the print server that you now wish to use. This is the print server that will route print jobs to the Fiery XJ from computers on IPX networks.

If you change your mind, press the Menu button to return to the B indery Setup menu without making a change.

Enter Your Print Server Password

This option appears only if your NetWare print server is set up to require you to log in with a password. Enter your print server password.

Network Setup

Service Setup

PServer Setup

Bindery Setup

Network Setup

Service Setup

PServer Setup

Bindery Setup

2-32 Performing Setup from the Control Panel

The Bindery Setup menu is displayed again. You can edit other connections, choose another Bindery Setup option, or choose Exit Bindery Setup.

Remove File Server

Remove support for [File server name]

Allows you to select a NetWare ﬁle server from a list of connected ﬁle servers and remove the connection to it. You are notiﬁed that you have removed the connection, and the Bindery Setup menu is displayed again. If you change your mind and don’t want to remove any of the ﬁle servers, press the Menu button.

You can choose another Bindery Setup option (such as adding another ﬁle server) or choose Exit Bindery Setup and proceed to set the polling interval.

Exit Bindery Setup

Choose Exit Bindery Setup after you have viewed a list of IPX ﬁle servers, removed a ﬁle server from the list or connected all the conﬁgured NetWare ﬁle servers. After you select Exit Bindery Setup, you return to the PServer Setup menu.

Network Setup

Service Setup

PServer Setup

2-33 Fiery XJ Setup from the Control Panel

Polling Interval options

Polling Interval

Whether you are using NDS or Bindery services, you may choose Polling Interval from the main PServer Setup menu. If you do not reset the interval, the default value of 15 seconds is used.

NetWare Server Poll Interval in Seconds 1-3600 [15]

Specify the interval, in seconds, at which the Fiery XJ communicates with the Novell print server to see if there are print jobs waiting.

NOTE: If you select a short interval, the amount of network trafﬁc increases. This may

slow down other network jobs.

Exit Service Setup

This returns you to the main Network Setup menu.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in Network Setup; select No to return to the main Setup menu without making any changes.

2-34 Performing Setup from the Control Panel

Fiery XJ print connections

In Fiery XJ Printer Setup you decide how the Fiery XJ manages print jobs by deciding which print connections should be “published” to users over the network. All published connections are constantly checked for the presence of jobs. If you don’t want users to print to a connection, don’t publish it.

The Fiery XJ publishes two types of connections: the Direct connection and the Print queue. At least one connection to the Fiery XJ must be published.

Direct connection

Jobs are transmitted to the F iery XJ Direct connection only when the Fiery XJ is ready to print. They remain at the sending workstation until the Fiery XJ is ready, and are processed as soon as a prior job is ﬁnished, before the next queued job is processed.

Jobs sent to the Direct connection are not stored on the Fiery XJ hard disk. The jobs appear in display of current jobs in Fiery WebSpooler and Fiery Spooler, but they cannot be selected for reprinting, moving, or deletion. Therefore the Direct connection provides a measure of security for sensitive files. If you plan to download fonts to the Fiery XJ via the network, you must publish the Direct connection.

NOTE: You cannot use the Direct connection for lpd printing over TCP/IP. You can,

however, use the Direct connection for downloading fonts.

Queues

A queue is a storage area for print jobs. Queues are particularly useful when many print jobs are being sent to the Fiery XJ. When a job is printed to a queue on the Fiery XJ, it is stored on the Fiery XJ hard disk rather than the user’s hard disk, quickly freeing up the user’s workstation.

Remote users can print only to published connections. However, job storage areas for all queues exist on the server, so that administrators or other users of Fiery WebSpooler and Fiery Spooler can move or copy jobs to the Print queue, whether or not the Print queue is published.

The Fiery XJ hard disk supports up to two queues (Print and Printed). Users may print to only the Print queue.

2-35 Printer Setup options

• Print queue—This is the standard Fiery XJ queue. The F iery XJ prints jobs from the

Print queue in the order in which they were received.

• Printed queue—The Printed queue is a job storage area on the Fiery XJ disk; it con-

tains the most recent jobs printed from the Print queue. The Printed queue makes it convenient to reprint those jobs. A Server Setup option enables this queue and governs the maximum number of jobs retained in it at any given time (see page 2-9). Reprinting jobs in this queue requires Fiery WebSpooler or Fiery Spooler.

Printer Setup options

Printer Setup conﬁgures the connections and printing behavior associated with a particular printing device. For more information on Fiery XJ print connections, see page xiv of the Introduction.

Exit Setup Server Setup Network Setup Printer Setup

Setup

1. In the main Setup menu, choose Printer Setup.

2. Enter the options appropriate to the printing requirements at the site.

3. When you have ﬁnished, save changes.

Printer Setup includes:

• Publishing the Direct connection

• Publishing the Print queue In the list of options that follows, default values, where applicable, appear in square

brackets.

Publish Direct Connection Yes/No [Yes]

This option enables users to print (or download) jobs to the Fiery XJ without spooling. Note that jobs printed to the Direct connection are not saved in the Printed queue.

If you plan to download fonts from any system to the Fiery XJ, you must publish the Direct connection. If you do not want users to print to Direct, choose No.

2-36 Performing Setup from the Control Panel

Publish Print Queue Yes/No [Yes]

This option enables users to print (or download) jobs to the Print queue. Jobs that are printed to the Print queue are spooled to the Fiery XJ disk and printed on a ﬁrst-in, ﬁrst-out basis. Only queues published in the Printer Setup are available to remote users.

• If you are printing to the Fiery XJ over a TCP/IP network, you must publish the

Print queue.

• If you are printing to the Fiery XJ over the parallel port, you must publish a queue or

publish the Direct connection.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in the Printer Setup; select No to return to the main Setup menu without making any changes.

PostScript Setup options

PS (PostScript) Setup options allow you to set defaults for both the Fiery XJ and the copier. Most of these defaults can be overridden on a job-by-job basis. See the User Guide for more information.

TO ACCESS POSTSCRIPT SETUP OPTIONS:

1. In the main Setup menu, choose PS Setup.

2. Enter the options appropriate to the printing requirements at the site.

3. When you have ﬁnished, save changes.

In the list of options that follows, default values, where applicable, appear in square brackets.

Color Mode CMYK/Grayscale [CMYK]

Specify whether you will be printing color (CMYK) or Grayscale images to the Fiery XJ by default. CMYK gives you full color prints. Select CMYK as the Color Mode before performing calibration on the Fiery XJ. Grayscale converts all colors into shades of gray.

2-37 PostScript Setup options

Page Order Forward/Reverse [Reverse]

Forward prints pages in the order received, so that the last page is on the top of the

stack and the ﬁrst page is on the bottom. Reverse prints jobs in reverse order, so that the ﬁrst page is on the top of the stack and the last page is on the bottom.

Paper Sizes US/Metric [US]

Specify whether to print on US paper sizes (for example, letter, legal, tabloid), or Metric paper sizes (for example, A4, A3) by default. When no page size is deﬁned within a PostScript ﬁle, jobs are printed on Letter paper if you selected US, or A4 paper if you selected Metric.

Convert Paper Sizes No Letter/11x17->A4/A3 A4/A3->Letter/11x17 [No]

Specify whether to convert paper sizes in documents automatically to the default paper sizes speciﬁed. For example, if you selected Letter/11x17->A4/A3, a letter size document would automatically be printed on A4 paper. If you select No, the server only prints the document if it ﬁnds a media source in the size speciﬁed by the ﬁle.

Print Cover Page No/Yes [No]

Use this option to specify whether the Fiery XJ prints a cover (job summary) page at the end of each print job. If you select Yes, each print job is followed by a page containing the name of the user who sent the job, the document name, the server name, the time the job was printed, the number of pages printed, and the status of the job. If a PostScript error occurr ed and the Print to PS Error option is set to Yes, the status entry will be the PostScript error message.

Allow Courier Substitution Yes/No [Yes]

Specify whether to substitute Courier for fonts that are unavailable when you download PostScript ﬁles to the Fiery XJ, or when you print a document for which you do not have the corresponding printer font. If this option is set to No, jobs with fonts that are not available on the Fiery XJ hard drive generate a PostScript error and do not print.

2-38 Performing Setup from the Control Panel

Print to PS Error No/Yes [No]

Use this option to specify whether the Fiery XJ should print the available portion of a print job when it encounters a PostScript error. Select Yes to print the portion of the job that was processed before the error occurred; select No to cancel the print job entirely when a PostScript error is encountered. Leave this option at No unless you encounter printing problems.

NOTE: If you download fonts, set this option to No.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in PS Setup; select No to return to the main Setup menu without making any changes.

Color Setup options

Color Setup allows you to set the parameters the Fiery XJ uses to control color output. Most of these parameters can be overridden on a job-by-job basis. See the User Guide for more information.

Simulations, or press simulations, allow you to use the copier as a proofing device for jobs that will print on an offset press. Because the range of colors available on the copier is different from that of a press, the Fiery XJ can adjust the color so that the output falls within the range of colors a press can produce.

The Fiery XJ uses a default simulation for SWOP-Coated output. You can change the simulation target by downloading a file from the User Software CD to the Fiery XJ. The other simulations available are Euroscale (the European press standard) and DIC (the Japanese press standard). See the User Guide for more information.

TO ACCESS COLOR SETUP OPTIONS:

1. In the main Setup menu, choose Color Setup.

2. Enter the options appropriate to the printing requirements at the site.

3. When you have ﬁnished, save changes.

In the list of options that follows, default values, where applicable, appear in square brackets.

2-39 Administrative functions in the Setup menu

Rendering Style Photographic/Presentation/Solid [Presentation]

The CRD (Color Rendering Dictionary) used deﬁnes how color will be converted from RGB data to printed output. Photographic, designed for images, retains the relative balance between colors to maintain the overall appearance of the image. Presenta-

tion

, designed for bright colors, produces the saturated prints needed for most business presentations, but handles photographic images the same way as the Photographic CRD. Solid, designed for spot colors, retains the absolute value of each color. This is particularly useful for images such as corporate logos.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in Color Setup; select No to return to the main Setup menu without making any changes.

Administrative functions in the Setup menu

The remaining options in the Setup menu are intended to help you manage print jobs and color output but are not required for printing:

•In Job Log Setup you specify whether you want the Fiery XJ to print and clear its log

of printed jobs automatically. See the next section for details.

• Calibration enables you to calibrate the Fiery XJ and preview the results of calibra-

tion. It also lets you remove a calibration. See the User Guide for a detailed explanation of calibration.

• Change Password enables you to create or change an Administrator password on the

Fiery XJ so that casual users cannot enter the Setup menus and change Fiery XJ settings without permission.

• Clear Server clears all queued print jobs from the server—jobs in the Fiery XJ Print,

and Printed queues. Clear Server also clears the Job Log. If an Administrator password has been set, unauthorized users will not see this command (or any of the administrative or Setup options).

NOTE: If you keep Job Logs, be sure to print or export the Job Log before you choose

Clear Server.

2-40 Performing Setup from the Control Panel

Job Log Setup

The Job Log is a record of all jobs processed or printed on the Fiery XJ, whether they originate from a user workstation, a networked server, the Fiery XJ, or a computer attached to the parallel port. The J ob Log can be printed at any time from the Control Panel or Fiery WebSpooler.

The printed Job Log lists accounting information about each job including user name, document name, time and date printed, and number of pages. If you print with the Adobe printer drivers provided for Windows 95 and Mac OS computers, you can also enter job-specific notes that appear in the Job Log. See the User Guide for details.

By default, the Job Log is not printed or cleared automatically. You can change these defaults in Job Log Setup. You can also clear the Job Log from the Fiery WebSpooler.

PS Setup Color Setup  Job Log Setup Calibration

Setup

Scroll to the second screen of the main Setup menu and choose Job Log Setup. Enter the options as described below. When you have ﬁnished, save changes.

Job Log Setup options

Default values for the following options, where applicable, appear in square brackets.

Auto Print Job Log Every 55 Jobs Yes/No [No]

Use this option to specify whether you want the Fiery XJ to print the Job Log after every 55 jobs. If accounting for each printed page is important at your site, and an administrator checks the printed output, set the Job Log for automatic printing.

Auto Clear Job Log Every 55 Jobs Yes/No [No]

Use this option to specify whether to clear the Job Log after every 55 jobs. If you do not enable this option, and do not clear the Job Log from the Fiery XJ or from a remote workstation, the Fiery XJ saves a record of all jobs.

In addition to Auto Clearing, the Job Log (together with all queued jobs) is also clear ed when you choose Clear Server from the main Setup menu, when system software is reinstalled, or when a new version of system software is installed on the Fiery XJ.

2-41 Administrative functions in the Setup menu

NOTE: If Auto Print J ob Log E very 55 J obs is set to No, setting this option to Yes has no

effect.

Job Log Page Size Tabloid/A3 Letter/A4 [Tabloid/A3]

Select the paper size for printing the Job Log. Regar dless of page size, 55 jobs ar e listed on a page. The paper size used depends on the Default Paper Sizes setting in PS Setup . If the Default Paper Sizes setting is US, the Job Log is printed on tabloid or letter size paper, with tabloid the default.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in Job Log Setup; select No to return to the main Setup menu without making any changes.

Calibration

The Calibration menu lets you calibrate the Fiery XJ from the copier glass using AutoCal™ (automatic calibration). The Calibration menu also lets you remove the current calibration. When the Fiery XJ is calibrated, a color correction curve is applied to every color document that is processed for printing.

TO PREPARE FOR CALIBRATION:

1. If this is the ﬁrst time you are setting up the Fiery XJ, complete Server Setup, Network Setup, and Printer Setup before you perform a calibration. Save Setup changes and boot up to Idle.

Color Mode must be set to CMYK to perform calibration (see page 2-36).

2. When the Fiery XJ is at Idle, turn the power switch off.

3. Turn on the Fiery XJ.

4. When the Setup message appears, press any key.

5. Scroll to the second screen of the main Setup menu and choose Calibration.

PS Setup Color Setup  Job Log Setup Calibration

Setup

2-42 Performing Setup from the Control Panel

6. Choose Set Up Calibration.

7. Choose Calibrate, and perform calibration as described below.

8. When you have ﬁnished, save changes.

Exit Calibration Set Up Calibraton Calibrate Remove Calibration

Calibration

At the Tray menu, choose the source of Letter/A4 paper for printing color patch pages, either a regular paper tray or the Bypass tray (manual feed).

Calibrate

Calibration options are summarized below. See the User Guide for calibration procedures and a more detailed explanation of calibration options.

You can print a Configuration page at the server to find out when the Fiery XJ was last calibrated. The Start page also contains this information. (To print a Configuration page from the Fiery XJ at Idle status, press the Menu button to display the Functions screen, scroll down to select Print Pages, and select Configuration.)

NOTE: If any problems arise during calibration, press the Menu button to escape to the

Calibration menu.

Select Target Copier target/Linear [Copier target]

The copier target (the exact name will vary) calibrates the Fiery XJ to its deﬁned optimums. The linear target calibrates the Fiery XJ to a generic standard. Using the copier target is strongly recommended.

Print Measurement Page Yes/No [Yes]

Choose this option to print a page of known color data for measurement. You are notiﬁed that the copier is printing a measurement page without calibration.

The Fiery XJ prints a page of graduated colors that you place on the copier glass.

2-43 Administrative functions in the Setup menu

Measure Page Yes/No [Yes]

Select Yes to measure the colors on the measurement page. Position the Kodak Gray Scale strip (included in your Fiery XJ media pack) and the

measurement page on the copier. If you don’t use the Kodak Gray Scale strip, the Fiery XJ performs AutoCal 1, measuring only the color strips. If you do use the Kodak Gray Scale strip, the Fiery XJ performs AutoCal 2, which measures the gray tones (to correct for possible drift in the scanner) as well as the color strips. The copier scans the page and creates an internal measurements ﬁle.

If you select No, measurement is skipped and Print Comparison Page is displayed.

Print Comparison Page Yes/No [Yes]

Specify Yes if you want the Fiery XJ to print a page with two versions of a set of test images, one version using a calibration based on your most recent measurements and the selected target, and one with no calibration.

Apply/Overwrite Calibration? Yes/No [Yes]

Choose Yes if you ar e satisﬁed with the calibration shown in the comparison page. The newest calibration overwrites any previous one.

Choose No to return to the main Calibration Setup menu.

This affects all users. Continue? Yes/No [Yes]

This is a reminder that calibration is a global setting; if you overwrite calibration, every print job is affected by the new calibration.

If you choose Yes, calibration is overwritten and you return to the main Calibration menu. If you are ﬁnished, choose Exit Calibration. The Fiery XJ reboots.

If you choose No, calibration is not overwritten, and you return to the main Calibration menu.

2-44 Performing Setup from the Control Panel

Remove Calibration

Choose Remove Calibration when you wish to return the copier to its default state. You do not need to remove a calibration before applying a new calibration.

This affects all users. Continue? Yes/No [Yes]

This option is a reminder that calibration is a global setting; if you remove calibration, every print job is affected by your action.

If you choose Yes, the current calibration is removed and you return to the main Calibration screen. If you are ﬁnished, choose Exit Calibration. The Fiery XJ reboots.

If you choose No, the calibration is not removed, but you still return to the main Calibration screen.

Exit Calibration

When you choose Exit Calibration, the Fiery XJ reboots.

Change Password Clear Server 

  Setup

Change Password

Change Password enables you to set or change the Administrator password for the

Fiery XJ. This password determines whether a user can modify the Setup options. See page xiii for information on Administrator access privileges.

When the Fiery XJ is installed, there is no password. If you do not create an Administrator password, users are not required to enter a password to modify the Setup. If an Administrator password has been set previously, you are required to enter it when you run Setup. Use the up and down buttons to select the characters and the left and right arrow buttons to move between them (see page 2-6).

Scroll to the third screen of the main Setup menu and choose Change Password. Enter and conﬁrm the password as described below.

2-45 Administrative functions in the Setup menu

New Password

Use the up and down buttons to select the characters and the left and right arrow buttons to move between them. Enter characters from left to right, since the left arrow line selection button is a delete key. The password can be any combination of letters and numbers up to 19 characters. Choose OK when you are done. Be sure to write down the password. The only way to remove a password that you can’t remember is to reinstall system software.

Verify New Password

Enter the new password again exactly as before to verify that you have entered it correctly. If you make a mistake, you are prompted to enter the password again. The new password is effective after you save changes and reboot the Fiery XJ.

Clear Server

Clear Server enables you to clear all queued print jobs from the server—jobs in the

Fiery XJ Print and Printed queues. Clear Server also clears the J ob Log. If y ou keep J ob Logs, print or export the Job Log before you choose

Clear Server.

Change Password Clear Server 

  Setup

Exit Setup Server Setup Network Setup Printer Setup

Setup

Jobs can also be deleted, individually or as a group, from Fiery WebSpooler.

Scroll to the third screen of the main Setup menu to choose Clear Server. Choose Clear Server to clear all queued print jobs and the Job Log from the server.

You are asked to conﬁrm your selection.

Exit Setup

Choose ﬁnished making Setup changes.

The Fiery XJ reboots and any changes you saved during the Setup take effect.

Exit Setup from the ﬁrst screen of the main Setup menu when you have

2-46 Performing Setup from the Control Panel

Printing the Conﬁguration page from the Control Panel

The Conﬁguration page lists all the settings in effect from the current Setup. After you have ﬁnished running Setup, print a Conﬁguration page to conﬁrm your settings.

There are other pages you can print from the Control Panel of the Fiery XJ, including Test Page, Job Log, Control Panel Map, color charts, and font list. For information on these pages, see the User Guide.

TO PRINT THE CONFIGURATION PAGE:

1. At the Control Panel, press the Menu button to access the Functions menu.

2. Choose Print Pages.

3. Select Conﬁguration.

You may want to post the current Conﬁguration page near the server for quick reference. Some of the information on this page should be conveyed to remote users; for example, users sending print jobs will need to know the current printer default settings.

3-1 Fiery XJ on an IPX network

Chapter 3: Setting up Network Servers

This chapter describes environments that typically include one or more network servers—Novell NetWare servers and Windows NT 4.0 servers—that will share printing to the Fiery XJ. It describes setting up servers that use IPX/SPX or TCP/IP protocols for communicating with the Fiery XJ. In addition, it includes some guidelines for setting up direct communication from Windows NT 4.0 workstations and UNIX workstations, where a network server is optional. The chapter also outlines the requirements for network clients to print to the Fiery XJ and to run the Fiery utilities and Fiery WebTools.

If your network is based on Windows NT 4.0, skip to page 3-18. For information on UNIX workstations, skip to page 3-27.

NOTE: Setting up a NetWare environment correctly requires the presence and active

cooperation of the Novell network administrator. You must have administrator privileges on the network to create new NDS or bindery objects.

Fiery XJ on an IPX network

The NetWise™ features built into the Fiery XJ supports the following network operating environments:

• NetWare 4.x—NDS (Novell Directory Services)

• NetWare 3.x—Bindery services

• Servers running NetWare 4.x in bindery emulation mode

The term “bindery server” is used to refer to a Novell ﬁle server running NetWare 3.x, or running NetWare 4.x in emulation mode. The term “NDS” is used to describe components of a NetWare operating system running NetWare 4.x in native mode.

NetWare clients print to the Fiery XJ through the Novell network server. Server setup and client network setup are outlined here. Client printing setup is described in Getting Started, and printing is described in the User Guide.

3-2 Setting up Network Servers

The Fiery XJ can accept jobs concurrently from NetWare, Windows NT 4.0, and AppleShare servers, as well as jobs sent directly from Windows NT 4.0 or UNIX workstations. NetWare clients on Mac OS or Windows NT 4.0 computers can print either via the NetWare server or directly.

The Fiery XJ can receive print jobs from NetWare clients over the Ethernet or Token Ring network topologies. (Appendix A describes the Token Ring option.) During Fiery XJ Setup, you select the frame type or types that will be used for communication between the Fiery XJ and network servers. Frame type refers to the format of a communications packet; frame types are speciﬁed in a startup ﬁle when the NetWare server (or any other workstation) loads its network drivers.

In addition to printing, Fiery Downloader is available to Windows 95 users only via IPX/SPX and to Windows NT 4.0 users only via TCP/IP. Fiery Spooler is available to both Windows 95 and NT 4.0 users only via TCP/IP. With Fiery Downloader, Windows 95 workstations are communicating with the Fiery XJ directly, not through the NetWare server.

Tips for experts—IPX networks

Setting up the Fiery XJ is similar to setting up another PostScript printer on the network. The following information is all that experienced network administrators need.

The Fiery XJ with IPX connections has these characteristics:

• Both NetWare 3.x and NetWare 4.x are supported directly. NetWare 4.x is also supported through bindery emulation.

• A minimum connection to the Fiery XJ consists of a NetWare ﬁle server, a NetWare print server, and a NetWare queue.

• A single directory tree (for NetWare 4.x) and up to eight bindery servers can be conﬁgured simultaneously.

This limit is the same regardless of whether the Fiery XJ is connected to the network via Ethernet, via Token Ring, or both.

3-3 Tips for experts—IPX networks

• The Fiery XJ looks for print jobs on one NetWare print server per bindery server.

• Each print server can store jobs for any print connection on the Fiery XJ.

• Windows 95 workstations (whether a Novell server is present or not) can use IPX/SPX protocols for communicating with the Fiery XJ directly to use Fiery Downloader.

However, Windows 95 users must use Fiery Spooler via TCP/IP only.

Overview of IPX printing to the Fiery XJ

NetWare ﬁle servers support the creation of print queues, which are storage areas for print jobs. When a client on a remote computer decides to print, the job is directed to a print queue on the NetWare ﬁle server and spooled to the NetWare server disk, freeing up the client workstation.

The queues on the NetWare server must be named to match the Direct connection and Print queue on the Fiery XJ. The NetWare queue names should be given an extension corresponding to the Fiery XJ print connection, as follows:

_print _direct

NOTE: The extension names must be in all lowercase and must be in English.

There is no need to rerun Setup when adding or removing a NetWare queue; however you should reboot the Fiery XJ after a queue is created or removed.

When the Fiery XJ is conﬁgured to connect to a NetWare server, it polls the NetWare server for jobs in each of its queues. If jobs are found, they are automatically transferred over the network to the matching connection on the Fiery XJ. For example, jobs from the NetWare queue with the _print extension are sent to the Fiery XJ Print queue, and so on. While a job is processed and printed, a record of the job is being created. You can access the Job Log containing these records at any time.

3-4 Setting up Network Servers

Conﬁguring a NetWare server for printing

The following sections explain how to set up a NetWare ﬁle server so that networked users can print to the Fiery XJ from their workstations, and the Fiery XJ can obtain print jobs from the NetWare server.

For each NetWare ﬁle server that you conﬁgure, follow these general steps. More detail is provided in subsequent sections.

• Make sure the server is connected to a functioning IPX network.

• Log in as the Supervisor on a PC connected to the NetWare ﬁle server.

• For NetWare 4.x installations, set up an NDS connection (see page 3-6).

• For NetWare 4.x in emulation mode, set the bindery context (see page 3-9).

• For NetWare 3.x and for NetWare 4.x in bindery emulation, set up a ﬁle server, a

print server, and a print queue for the Fiery XJ (see page 3-12).

With bindery services, you can route all Fiery XJ print jobs through the same NetWare ﬁle server, or you can conﬁgure more than one ﬁle server to handle Fiery XJ jobs.

The functions you perform on the Novell server, on the Fiery XJ, and on the client workstation, are summarized in the following tables. The ﬁrst table applies to NDS connections, the second to bindery connections.

Complete the operations in the left column, then the center column, then the right column.

3-5 Conﬁguring a NetWare server for printing

Conﬁguring an NDS connection

Abbreviations:

FS = ﬁle server PS = print server PQ = print queue (on the NetWare server)

On NDS FS: On Fiery XJ Control Panel: On client workstation:

In NETADMIN:

Create NDS PQs Create NDS printer

and assign PQs Create PS and assign

the printer Conﬁgure users of

the PQs

Conﬁguring a bindery connection

On Bindery FS: On Fiery XJ Control Panel: On client workstation:

In PCONSOLE:

Select NetWare FS (up to 8)

For each FS: Conﬁgure PS

Conﬁgure PQ Conﬁgure users of

the PQ

Port Setup

Ethernet Setup and/or Token Ring Setup

Protocol Setup

IPX/SPX Setup—select frame type(s)

Service Setup

PServer Setup and NDS Setup Select Root Browse to select PS Specify PQ search root (optional) Set Polling Interval

Port Setup

Ethernet Setup and/or Token Ring Setup

Protocol Setup

IPX/SPX Setup—select frame type(s)

Service Setup

PServer Setup and Bindery Setup Add FS (up to 8) Set Polling Interval

Install user software For printing:

Connect client to PQ(s) that you set up on the NetWare FS (associated with the PS selected in NDS Setup)

For running the Fiery utilities: Conﬁgure the connection to the server

Install user software For printing:

Connect client to PQ(s) that you set up on the NetWare FS (associated with the PS selected in Bindery Setup)

For running the Fiery utilities: Conﬁgure the connection to the server

3-6 Setting up Network Servers

Setting up an NDS connection

In NDS, all NetWare entities (objects) are organized in a hierarchical tree structure. Objects have a name, properties, and a context which deﬁnes the location of the object in the directory tree. For the Fiery XJ you are mainly concerned with deﬁning a printer, a print server object and one or more print queue objects. Objects are created in NetWare administrator programs (PCONSOLE or NETADMIN which are textbased, or NetWare Administrator which has a graphical user interface and context-sensitive help).

The top-level tree object is known as the [Root] object. The name of the [Root] object is also the name of the tree. Below the [Root] are other objects: either containers (which consist of other objects) or leaf objects (which do not contain other objects). Access to objects is controlled by rights that are deﬁned as properties of each object. Rights are established by network administrators.

NOTE: The procedures that follow work with all versions of NetWare 4.x.

With NetWare 4.11 or later, you can combine the procedures using the Print Services Quick Setup dialog box.

TO CREATE AN NDS PRINT QUEUE:

1. Start NetWare Administrator and select the container in which you are going to deﬁne the print queue for the Fiery XJ.

2. Choose Create from the Object menu.

3. In the New Object dialog box, select Print Queue.

4. In the Create Print Queue dialog box, select Directory Service Queue.

5. Enter a name for the Netware print queue with the extension for the Fiery XJ connection: Astro_print, for example.

See page 3-3 for queue naming conventions.

6. Click the browser button to select a print queue volume.

3-7 Conﬁguring a NetWare server for printing

7. In the Select Object dialog box, double-click a container object in the Directory Context list and browse until the volume you want appears in the Objects list.

This volume holds the actual ﬁles while they are queued for printing, so make sure it has enough disk space.

8. Select the volume in the Objects list, and choose OK.

9. In the Create Print Queue dialog box, click Create.

10. Click Details for Print Queue.

11. Enable guest access and/or create users.

You must enable at least guest access for the queue to be usable. You can also create registered users.

TO CREATE AN NDS PRINTER AND ASSIGN A NETWARE PRINT QUEUE TO

THE PRINTER:

1. Start NetWare Administrator and select the container in which you are going to deﬁne the NDS printer for the Fiery XJ.

2. Choose Create from the Object menu.

3. In the New Object dialog box, select Printer.

4. Enter a name for the printer.

You can deﬁne additional properties for the printer at this point.

5. Click Create.

6. In Printer Details, click Assignments. Click Add.

7. In the Select Object dialog box, browse the containers until the Netware queue you want is listed in the Objects list.

8. Select the print queue you created for the Fiery XJ and choose OK.

9. From the Printer dialog box, select Conﬁguration and select Other/Unknown as the Printer Type and PostScript as the Banner Type.

3-8 Setting up Network Servers

TO CREATE AN NDS PRINT SERVER AND ASSIGN A PRINTER:

1. Start NetWare Administrator and select the container in which you are going to deﬁne the NDS print server for the Fiery XJ.

2. Choose Create from the Object menu.

3. In the New Object dialog box, select Print Server.

4. Enter a name for the print server.

5. Select Deﬁne Additional Properties.

6. Click Create.

7. In the Print Server dialog box, click Assignments.

8. Select Add and select the printer (object) you want to assign to the print server.

9. In the Select Object dialog box, brow se the Directory Conte xt list until the printer y ou want is listed under Objects.

10. Select the printer and click OK.

The remaining setup is performed on the Fiery XJ. An outline follows; for more detailed information, see page 2-10.

COMPLETING SETUP ON THE FIERY XJ:

1. With the Fiery XJ connected to the Novell network, restart the Fiery XJ to perform Setup.

For access to Setup, see page 2-1.

2. In the Network Setup, choose Port Setup and enable the port you will use for printing to the Fiery XJ.

This can be Ethernet, Token Ring (if you have installed the Token Ring option), or both.

3. Choose Protocol Setup and conﬁgure the protocols you will use.

4. Choose IPX/SPX Setup to select the frame type(s) that will be used between the NetWare server(s) and the Fiery XJ.

3-9 Conﬁguring a NetWare server for printing

5. Choose Service Setup, choose PServer Setup, and choose NDS Setup.

6. Identify the NDS tree on which the printer, print server, and print queue have been

7. Select the user login object.

8. Identify the deﬁned print server.

9. Finally, to restrict the search for the print queues you’ve deﬁned, browse to a con-

deﬁned.

tainer object that contains the print queue or queues.

Setting the NetWare 4.x bindery context

You can connect only one directory tree to the Fiery XJ. If you need to connect additional NetWare 4.x servers, you can do so by using bindery emulation, which causes the 4.x server to behave like and be accepted as a NetWare 3.x server.

NOTE: The ﬁle server selected must not be in the same tree as that selected in NDS

Setup.

Up to eight bindery servers, whether in native 3.x mode or in 4.x emulation, can connect to the Fiery XJ.

If your server is using NetWare 3.x, proceed to “Setting up a NetWare print queue for bindery” on page 3-12.

In order to set up the NetWare 4.x server in bindery emulation mode for printing to the Fiery XJ, the network administrator must do the following:

• Determine the Directory Services path to the container in which the print server and

the print queue for the Fiery XJ will be created. The container deﬁnes the “bindery context” for your network structure.

• Edit the network startup ﬁle to set the bindery context.

• Activate the new bindery context.

This section describes the second and third steps. Given the variety of possible network structures, it is impractical to suggest a bindery context that applies to every network.

3-10 Setting up Network Servers

TO SET THE BINDERY CONTEXT:

1. Establish a connection with the server which will have the Fiery XJ queue.

This is best done by the network administrator using PSERVER from the server console. It can also be done remotely using the RCONSOLE utility.

2. At the NetWare prompt type load install.

The NetWare Server Installation window is displayed.

3. Use the down arrow key to select Maintenance/Selective Install.

The Installations Options menu is displayed.

3-11 Conﬁguring a NetWare server for printing

4. Select NCF Files Options.

5. On the menu of available NCF ﬁles, select Edit AUTOEXEC.NCF ﬁle.

6. Type a new line anywhere in the ﬁle as follows:

set Bindery Context = enter your bindery context here

NOTE: After the “=” sign, type the bindery context obtained from the system adminis-

trator.

7. Press Esc to close the window, and save changes.

8. Proceed to the next section to activate the bindery context.

3-12 Setting up Network Servers

TO ACTIVATE THE BINDERY CONTEXT:

1. If you cannot reboot the NetW ar e server at this point, type the set command manually at the server’s colon prompt.

Use the same command as you entered in the AUTOEXEC.NCF ﬁle (in step 6 of the previous procedure).

2. If you can reboot the NetWare server, the set command is loaded automatically.

You are ready to set up the Fiery XJ print server and print queue. See the next section for details.

Setting up a NetWare print queue for bindery

For NetWare 3.x and for 4.x in emulation, the NetWare print server and print queue for Fiery XJ are created and conﬁgured from NetWare Print Console (PCONSOLE), a NetWare utility that is stored in NetWare’s PUBLIC directory.

As with NDS, ﬁrst you create several NetWare entities on a Novell server, then you select them in Network Setup on the Fiery XJ Control Panel.

TO SET UP A NETWARE SERVER FOR PRINTING TO THE FIERY XJ:

1. Log in to the NetWare server as the Supervisor.

2. At the NetWare MS-DOS prompt, type

If you are using NetWare 4.x in bindery mode, Print Console (PCONSOLE) has two modes. Press the F4 key to switch to Bindery mode.

The Available Options menu is displayed.

3. Choose Change Current File Server and press Enter.

pconsole.

3-13 Conﬁguring a NetWare server for printing

4. Using the arrow keys, select the name of the ﬁle server you’ll use for sharing Fiery XJ

5. Choose Print Server Information from the Available Options menu.

6. Press the Insert key, type a name for the new print server, and press Enter. Then

printing and press Enter.

This is the ﬁle server you select later in Fiery XJ Network/PServer/Bindery Setup.

press Esc.

You must select the same print server here and in Fiery XJ Network/PServer/Bindery Setup. In this example, “Atlas” is the name of the print server.

7. Choose Print Queue Information from the Available Options menu.

3-14 Setting up Network Servers

8. Press the Insert key and type a name for a new Fiery XJ print queue. Press Enter.

9. Make sure the print queue name you created is selected in the list of Print Queues,

See page 3-3 for queue naming conventions. In this example, “AtlasQ” is the name of the queue. The extension “_print” directs jobs to the Print queue on the Fiery XJ (as opposed to the Fiery XJ Direct connection).

and press Enter.

The Print Queue Information menu is displayed.

10. In the Print Queue Information menu, choose Queue Servers, and press Enter.

A blank Queue Servers list is displayed.

3-15 Conﬁguring a NetWare server for printing

11. Press the Insert key.

12. Use the arrow keys to select the name of the print server you created in step 6 and

The Queue Server Candidates list is displayed.

press Enter.

The server name you select will appear in the Queue Servers list. You have associated the selected Fiery XJ queue with the print server you created in

step 6.

NOTE: The Fiery XJ obtains jobs from all queues deﬁned for a print server, and all jobs

from one ﬁle server go to the same queue on the Fiery XJ.

13. If you wish to set up a print queue on another ﬁle server, press Esc to close the windows until only the Available Options menu is displayed. Repeat the steps beginning with step 3.

The Fiery XJ can support up to eight ﬁle servers on Ethernet or Token Ring or both.

14. If you have conﬁgured all the servers you need, press Esc to exit all Print Console windows.

15. Choose Yes or press Return to save changes to Print Console.

3-16 Setting up Network Servers

Setting up NetWare Windows clients for printing

Before setting up client workstations for printing, make sure you perform Network Setup on the Fiery XJ Control Panel (see page 2-10), and that the settings reﬂect the entities you created in the NetWare administrator utilities (see page 3-4).

NOTE: For printing to the Fiery XJ, connect all Windows clients to a Novell NetWare

server and permit them to connect to the Netware print server or servers on which you deﬁned a NetWare print queue for the Fiery XJ.

After the Novell server and the Fiery XJ have been set up, client setup consists of:

• Installing the networking protocol, binding it to the network adapter card, and

permitting the client to log in to the NetWare ﬁle server. On Windows 95 workstations, both the IPX/SPX-compatible protocol and the

Client for NetWare Networks should be loaded from the Network Control Panel. On Windows NT 4.0 workstations, Client Services for NetW are should be installed.

Use the CSNW option in Control Panel to set printing options and specify a preferred NetWare server.

• Setting up the Fiery XJ as a PostScript printer by installing a PostScript printer

driver and the Fiery XJ PPD (PostScript printer description).

• Adding a network port and connecting the workstation to one or more NetWare

queues that have been deﬁned for the Fiery XJ. See Getting Started for details on how to connect Windows 95 and

Windows NT 4.0 workstations.

• Installing Fiery XJ software, such as color reference ﬁles.

See Getting Started for details.

3-17 Conﬁguring Windows 95 workstations for the Fiery utilities

Conﬁguring Windows 95 workstations for the Fiery utilities

To run Fiery Downloader, a Windows 95 workstation on an IPX network must have IPX/SPX protocols loaded and bound to the network driver. There should be a NetWare server on the network.

Before you begin, for Windows 95, install the IPX/SPX-compatible protocol and Microsoft TCP/IP.

NOTE: To use Fiery Spooler with Windows 95, y ou cannot use IPX/SPX. You must use

TCP/IP.

TO INSTALL THE FIERY UTILITIES:

1. Conﬁgure your NetWare server and perform Fiery XJ Setup.

2. Insert the Fiery XJ User Software CD in the client workstation and install the Fiery utilities.

See Getting Started for installation instructions.

3. Before running the Fiery utilities, print a Conﬁguration page.

See page 2-46 for details on printing the Conﬁguration page.

4. Start the Fiery utilities and conﬁgure the connection (Getting Started).

3-18 Setting up Network Servers

Fiery XJ on a TCP/IP network with Windows NT 4.0

When a Windows NT 4.0 computer is conﬁgured to connect to the Fiery XJ using TCP/IP, it can print directly to the Fiery XJ. If the computer shares the printer over the network, it is acting as a print server to Windows NT 4.0 clients. Client machines print to the Fiery XJ by printing to the Windows NT 4.0 print server. Printing can then be monitored and controlled at the Windows NT 4.0 server machine.

With TCP/IP protocols loaded, you can run these utilities from Windows NT 4.0 or Windows 95:

• Fiery Spooler

• Fiery WebT ools

With TCP/IP, you can run Fiery Downloader from Windows NT 4.0 only.

If there are many Mac OS computers or other PostScript printers at the site, the Windows NT 4.0 server can also use AppleTalk protocols for printing to the Fiery XJ. You can load AppleTalk on the Windows NT 4.0 server as an alternative to TCP/IP (see page 3-25).

Tips for experts—Windows NT 4.0 with TCP/IP

Setting up printing from Windows NT 4.0 using TCP/IP protocols is similar in some respects to setting up UNIX workstations with TCP/IP. When TCP/IP network connections are made from Windows NT 4.0 workstations, note the following:

• Make sure you have a valid IP address for the Fiery XJ and for any workstations that will print to it or run the Fiery utilities.

• In Fiery XJ Network Setup>Protocol Setup>TCP/IP Setup>Ethernet Setup (or Token Ring Setup), enable TCP/IP and enter the IP address for the Fiery XJ. Also enter the Subnet mask and Gateway address.

• Make sure the Fiery XJ name and address are listed in a domain name services (DNS) or hosts name database used by your system.

• Make sure the system host table includes the corr ect internal name f or the Fiery XJ as a remote printer. See page 3-28 for more information.

3-19 Conﬁguring a Windows NT 4.0 server to support the Fiery XJ

• For Windows NT 4.0, install the Fiery XJ PostScript printer description on the

• Repeat the installation for everyone who prints to the Fiery XJ.

Windows NT 4.0 server (see Getting Started).

The Windows NT 4.0 PostScript printer driver is automatically installed with Windows NT 4.0. The Fiery XJ PostScript printer description is pro vided on the User Software CD.

Each server and workstation running the Fiery utilities with TCP/IP also needs the TCP/IP protocol and the Fiery utility software.

The Installer installs a blank conﬁguration (Eﬁnl.ini) ﬁle. When you run a utility for the ﬁrst time, you enter information that is used to conﬁgure the Eﬁnl.ini ﬁle automatically. See Getting Started for more information.

Conﬁguring a Windows NT 4.0 server to support the Fiery XJ

To conﬁgure a Windows NT 4.0 server to communicate with the Fiery XJ, follow these general steps. More detail is provided in subsequent sections.

• Load the TCP/IP network protocol (see the next section).

• Enter the host name of the Fiery XJ in the host database used by your system (see

page 3-21).

• On the Fiery XJ Control Panel, perform Server Setup (see page 2-8), Network Setup

(page 2-10), Printer Setup (page 2-35), PS Setup (page 2-36), and Color Setup (page 2-38).

• On the Windows NT 4.0 server, cr eate a printer for each Fiery XJ print connection,

install the appropriate printer drivers (if necessary) and (optionally) share the printer on the network (see page 3-22).

• Enter the host name and remote printer name of the Fiery XJ in the printer connec-

tion. See page 3-28 for more information.

• If the Windows NT 4.0 server is also a workstation, install the Fiery utilities (see

Getting Started and page 3-24).

3-20 Setting up Network Servers

TO ADD TCP/IP NETWORK SERVICES:

1. Log in to the Windows NT 4.0 server as Administrator.

2. In the Control Panel, double-click the Network icon.

The Network Settings dialog box appears.

3. Click the Services tab, and click Add.

4. In the Select Network Service dialog box, select Microsoft TCP/IP Printing and click OK.

5. In the Windows NT Setup dialog box, specify the location of y our Windo w s NT 4.0 so ftware ﬁles and click Continue.

Insert your Windows NT 4.0 system software CD and specify the CD-ROM drive’s volume; or, if the ﬁles reside on your hard drive or on the network, specify the appropriate path.

6. Click the Protocols tab and conﬁgure the Windows NT 4.0 server with its own IP address, subnet mask, and default gateway.

For Windows NT 4.0 conﬁguration options you can use with various host name systems, see your Windows NT 4.0 documentation.

7. When you are ﬁnished conﬁguring TCP/IP, click Apply, and close the Network control panel.

8. Restart your computer.

9. Add the Fiery XJ to the network (see the next section).

Ricoh bp100 OPERATING INSTRUCTIONS admin

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

About this manual

About the documentation

Network administration features

Before you proceed

Levels of access and control

Passwords

Fiery WebTools

Control level scenarios

Chapter 1: Connecting to the Network

Stages of installation on the network

Quick path to installation

Before you begin

Ethernet cable connection

Parallel cable connection

Initial Setup from the Control Panel

Network server setup requirements

Accessing Setup options

About the Control Panel Setup interface

Types of Setup screens

Server Setup options

Network Setup options

Port Setup options

Protocol Setup options

Service Setup options

Direct connection

Queues

Printer Setup options

PostScript Setup options

Color Setup options

Administrative functions in the Setup menu

Job Log Setup

Job Log Setup options

Calibration

Change Password

Clear Server

Exit Setup

Chapter 3: Setting up Network Servers

Tips for experts—IPX networks

Setting up an NDS connection

Setting the NetWare 4.x bindery context

Setting up a NetWare print queue for bindery

Setting up NetWare Windows clients for printing
