Ricoh AP204 User Manual
QUICK INSTALLATION GUIDE
<G033-8610>
Please read the Safety Information in the “Operating Instructions” before using this
machine. It contains important information related to USER SAFETY and PREVENTING
EQUIPMENT PROBLEMS.
Return the green lock levers to their original positions.
UNPA CKING THE PRINTER AND
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
CHECKING THE CONTENTS OF THE BO X
WHERE TO PUT YOUR PRINTER
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Your pr inter’s location should be carefully chosen because
environmental conditions greatly affect its performance.
Warning
Caution
•
T o pre vent injury, it is recommended that at least two people
are used to lift the printer.
Check the contents of the box according to the following
list. If one or more items are missing, please contact your
sales or service representative.
Important
❒ The interface cable is not included in the box. It is your
responsibility to provide the interface cable appropriate for
the computer that you are using.
Quick Installation Guide (this sheet)
Operating Instructions
CD-ROM
•
Make sure that the wall outlet is near the machine and
freely accessible, so that in the event of an emergency, it
can be easily unplugged.
Warning
•
Only connect the machine to the power source described on
this sheet.
•
Avoid multi-wiring.
•
Do not damage, break or make any modifications to the
power cord. Do not place heavy objects on it, pull it hard or
bend it more than necessary. These actions could cause
an electric shock or fire.
Caution
•
Keep the machine away from humidity and dust. A fire or
an electric shock might occur.
•
Place the machine on a strong and lev el surface. Otherwise,
the machine might fall and cause personal injury.
Caution
•
If you use the machine in a confined space, make sure
there is a continuous flow of air.
INSTALLING THE TONER CARTRIDGES
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Warning
•
Do not incinerate spilled toner or used toner. Toner dust
might ignite when exposed to an open flame.
•
Disposal can take place at our authorized dealer or at an
appropriate collection site.
•
If you dispose of the used toner containers yourself , dispose
of them according to your local regulations.
Caution
•
Do not open the front cover when the paper tray is pulled
out halfway. If you do, it might cause a personal injury.
Caution
•
Do not eat or swallow toner.
•
Keep toner (used or unused) and toner cartridges out of reach of children.
Caution
•
Our products are engineered to meet the highest standards of quality
and functionality. When purchasing expendable supplies, we
recommend using only those provided by an authorized dealer.
Open the front cover b y pulling the front co v er open lever.
INSTALLING THE PHOTOCONDUCTOR
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
UNIT
Important
❒
Do not touch the surface of the photoconductor unit. This could damage
the photoconductor unit and reduce the print quality.
❒
Do not expose the photoconductor unit to a light source greater than 800
luxes for more than two minutes. This could damage the photoconductor
unit and reduce the print quality.
Open the front cover by pulling the front cover open lever
and open the top cover b y pulling the top cov er open lev er .
TPOH195E
Lift the green lock levers to a vertical position.
○○○○○○○○○○○○○○○○○○○○○○○○○○○
TPOH245E
Important
❒ Do not return lock levers with force. If you cannot lock them
easily , remove the photoconductor unit from the printer . Then
re-insert it again until the gears mesh securely. After that, try
again to return the levers to their original positions.
Close the front and top covers until the centers of the co vers
lock securely.
INSTALLING THE FUSER OIL BO TTLE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
AND FUSER CLEANER
Caution
•
Do not incinerate the oil bottle. This action could cause a fire or a personal injury.
Caution
•
Spilt oil is very slippery . If oil is spilt, wipe it up with an alkaline cleaner.
Open the top cover by pulling the top cover open lever.
TPOH265E
Remove the orange lock pins.
Toner Cartr idge (Black)
Toner Cartridge (Yellow)
Toner Cartr idge (Cyan)
Toner Cartr idge (Magenta)
Fuser Cleaner
Photoconductor Unit
Fuser Oil Bottle
Power Cord
Syringe
Additional Documentation
Remove the plastic bag.
Lift the printer and move it to the place where y ou want to
install it.
When lifting the printer, use the inset grips on both sides of the printer.
TPOH115E
Remove adhesive tape [A] from the printer.
Optimum Environmental Conditions
The recommended temperature and humidity
%RH
80
70
60
50
20
10°C
50°F
Possible operation range Recommended range
The machine must be level within 5 mm, 0.2" both front to right and left to right.
To avoid possible build-up of ozone, make sure to locate this machine in a large
well ventilated room that has an air turnover more than 30m
17.5°C
63.5°F
27°C
80.6°F
32.5°C
90.5°F
TPOH145E
3
/hr/person.
Environments to Avoid
Important
❒ Locations exposed to direct sunlight or strong light
❒ Dusty areas
❒ Areas with corrosive gases
❒ Areas excessively cold, hot, or humid
❒ Locations near an air conditioner or humidifier
❒ Locations near other electronic equipment
❒ Locations where the printer might be subjected to frequent
strong vibration
Power Connection
Connect the power cord to a power source with a following specifications:
❒ 220-240V, 50/60Hz, 4 A or more
Space Required for Installing the Printer
Leave enough space around the printer. This space is necessary to operate the
printer. The recommended (or minimum) space requirements are as follows:
A
TPOH145E
Hold the new toner cartridge (cyan) and shake it well, about
10 times, as shown in the illustration.
TPOT015E
Important
❒
If the toner cartridge is not shaken enough, toner might not be evenly
distributed in the cartridge. In this case, the print quality might be reduced.
Remove the tape [1] and the protectiv e cover [2] as shown in the illustration.
1
2
TPOT035E
Align the toner cartridge (cyan) to the “C” mark of the printer as shown in
the illustration. Slide the cartridge in along the printer’s guide r ail.
TPOH205E
Remove the pins on the both side of the photoconductor unit.
TPOH225E
Remove the protective sheet.
TPOH215E
Insert the photoconductor unit so that the protr uding
green axles on both sides are aligned with the tracks
inside the green lock levers. Lower it until the gears
mesh securely.
TPOH235E
TPOH275E
Important
❒ These pins will be used when moving or transporting the
printer. Be sure to keep them for future use.
Insert the oil bottle. When inserting, the side with the label should
be facing to ward you, and the mouth of the bottle f acing do wn.
TPOH285E
Install the fuser cleaner . When installing, the roller should
be facing toward you.
TPOH295E
Turn the lock lev ers to hold the oil bottle and fuser cleaner .
Note
❒ Turn the right lock levers clockwise, and the left one
counterclockwise.
G033-8610
TPOT045E
A
TPOH125E
D
C
A: more than 10 cm (4.0")
B: more than 40 cm (15.6")
C: more than 10 cm (4.0")
D: more than 70 cm (27.6")
B
TPOH055E
Note
❒ Do not use excessive force in sliding in the cartridge.
❒ When inserting the cartridge, the side with the seal should be up.
Repeat steps 2 - 4 for installing the magenta, yellow, and
black toner cartridges. When installing, start with the
magenta toner cartridge, then yellow, and then black.
Close the front cover until the center of the front cover
locks securely.
Important
❒ When inserting the photoconductor unit, be careful not to touch
or damege the surface.
TPOH296E
Close the top cover until the center of the cover locks
securely.
INST ALLING THE PAPER TRA Y
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Caution
•
The paper tray does not have a stopper. When pulling it
out, be careful not to pull it strongly. If you do, the tray
might fall and cause personal injury.
The default settings of the paper size are as follows:
•
Metric version: A4 K (short-edge feed)
•
Inch version: 81/2" x 11"K (short-edge feed)
For settings other than the default paper size, see “Loading
Paper and Other Media” in the “Operating Instructions”.
For more information about the paper sizes that can be set
in the paper tray, see “Paper Supported by Your Printer” in
the “Operating Instructions”.
Pull the paper tray out of the printer . Place it on a flat surf ace.
CONNECTING THE POWER CORD
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Caution
•
When you pull the plug out of the socket, grip the plug to
avoid damaging the cord and causing a fire or an electric
shock.
Caution
•
It is dangerous to handle the plug with wet hands. Doing
this may result in receiving an electric shock.
Check that the pow er switch is turned off . If it is on, turn it off.
TPOH325E
Attach the power cord to the socket on the back side of
the printer.
SELECTING THE PANEL DISPLAY
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
LANGU AGE
PRINTING THE TEST P AGE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
You can check if the printer works properly by printing a test
page (configuration page). However, you cannot check the
Note
❒ You can select one of the following languages:
English, German, French, Italian, Dutch, or Japanese.
❒ The default setting is English.
❒ If you want to use the English panel display , it is not necessary
for you to do the following procedures.
connection between the printer and your computer by printing
the test page.
Check that the power switch is turned on.
If it is off, turn it on.
Turn on the power switch.
Press the Menu key.
The following message appears on the panel display.
<Menu> ▲
CONNECTING THE PRINTER TO A
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
COMPUTER
Connect the printer to your computer using a parallel port.
Important
❒ The parallel interface cable is not provided with the printer . It
is your responsibility to provide the interface cable appropriate
for the computer that you are using.
❒ The printer’s parallel connection is a standard bi-directional
interface. It requires a standard 36-pin parallel cable compliant
with IEEE1284 and a parallel port on your computer.
❒ To avoid electrical interference, use a shielded cable.
Note
❒ Do not use a parallel cable more than 2.5 meters (8.2 feet)
long.
IPDL-C Menu ▼
Check that the power switch is tur ned off.
TPOH325E
After the machine warms up, the ready message appears on the panel display.
Press the Menu key.
The following message appears on the panel display.
Press the ▲ ▼ keys until the f ollo wing message appears
on the panel display.
<Menu> ▲
List Print ▼
If it is on, turn it off.
Turn your computer off.
SETTING UP FOR PRINTING
○○○○○
Printing requires installation of a printer driver for your
operating system.
See “Installing the IPDL-C Printer Driver” in the “Operating
Instructions”.
TPOH455E
If necessary, slide the front and side guides to the paper
size you want to use.
TPOH305E
Load paper with the print side up, into the paper tray.
PAPER
LABEL
ENVEL OPE
OHP FILM
TPOH335E
Insert the plug of the power cord securely into the wall
socket.
<Menu> ▲
IPDL-C Menu ▼
Press the ▲ ▼ keys until the f ollo wing message appears
on the panel display.
<Menu> ▲
System Menu ▼
Press the Enter key.
The following message appears on the panel display.
<System Menu> ▲
1.Paper Tray ▼
Press the ▲ ▼ keys until the f ollo wing message appears
on the panel display.
<System Menu> ▲
10.Language ▼
Press the Enter key.
The following message appears on the panel display.
<List Print> ▲
1.Config.Page ▼
Press the Enter key.
The following message appears on the panel display.
<Config.Page>
Press # key
Press the Enter key.
In a short time, the test printing will start.
Important
❒ If you cannot complete the test printing correctly, see if an
error message appears on the panel display. For more
information about error messages, see “Troubleshooting” in
the “Operating Instructions”.
Press the On Line key.
Attach the interface cab le to the interface connector of the
printer. Secure the cable with the metal fittings as shown
in the illustration.
TPOH365E
Attach the other end of the interface cable to the interface
connector of the computer. Secure the cable.
TPOH315E
Important
❒ Make sure that the top of the stack is not higher than the limit
mark inside the tray.
❒ The front and side guides should be set exactly to the paper
size to avoid paper feed problems.
❒ Do not load different kinds of paper in the tray.
Note
❒ If you set a custom paper size, you should enter the paper
size with the printer’s operation panel. For more information,
see “Loading Paper in the Paper Tray” in the “Operating
Instructions”.
Slide the paper tray completely into the printer.
Important
❒ Be sure to insert the paper tray completely . Otherwise, misfeeds
might occur, or the front cover might touch the paper tray.
Press the Enter key.
Turn off the power switch.
Press the ▲ ▼ keys until the language y ou want to select
appears on the lower line of the panel display.
Press the Enter key.
Press the On Line key.
The On Line indicator is lit.
Press the On Line key again.
The On Line indicator turns off.
Press the Reset key.
The setting becomes effective.
Copyright© 1999 G033-8610 Printed in Japan
EE
G033
Operator’s Manual
Safety Information
Safety Information
When using your equipment, the following safety precautions should always be
followed.
Safety During Operation
In this manual, the following important symbols are used:
R
WARNING
Indicates a potentially hazardous situation which, if instructions are not followed, could result in death or serious injury.
R
CAUTION
Indicates a potentially hazardous situation which, if instructions
are not followed, may result in minor or moderate injury or damage to property.
R
WARNINGS
• Connect the power cord directly into a wall outlet and never use an extension cord.
• Disconnect the power plug (by pulling the plug, not the cable) if the power
cable or plug becomes frayed or otherwise damaged.
• To avoid hazardous electric shock or laser radiation exposure, do not remove any covers or screws other than those specified in this manual.
• Turn off the power and disconnect the power plug (by pulling the plug, not
the cable) if any of the following conditions exists:
• You spill something into the equipment.
• You suspect that your equipment needs service or repair.
• Your equipment’s cover has been damaged.
• Do not incinerate spilled toner or used toner. Toner dust might ignite when
exposed to an open flame.
• Disposal can take place at our authorized dealer or at appropriate collection sites.
• If you dispose the used toner containers yourself, dispose of it according
to local regulations.
i
R
CAUTIONS
• Protect the equipment from dampness or wet weather, such as rain, snow , and
so on.
• Unplug the power cord from the wall outlet before you move the equipment.
While moving the equipment, you should take care that the power cord will not
be damaged under the equipment.
• When you disconnect the power plug from the wall outlet, always pull the plug
(not the cable).
• Do not allow paper clips, staples, or other small metallic objects to fall inside the
equipment.
• Do not eat or swallow toner.
• Keep toner (used or unused) and toner cassette out of reach of children.
• For environmental reasons, do not dispose of the equipment or expended supply’s
wastes at household waste collection point. Disposal can take place at out authorized dealer or at appropriate collection sides.
• Our products are engineered to meet the highest standards of quality and functionality, and we recommend using the expendable supplies via authorized dealer .
• The inside of the machine could be very hot. Do not touch the parts with a label
indicating a hot surface. Otherwise, it could cause a personal burn.
ii
Safety Information
ENERGY STAR Program
As an ENERGY STAR Partner, we have determined that this
machine model meets the ENERGY STAR Guidelines for energy efficiency.
The ENERGY STAR Guidelines intend to establish an international energysaving system for developing and introducing energy-efficient office equipment to deal with environmental issues, such as global warming.
This product was designed to reduce the environmental impact associated with
printing equipment by means of energy-saving features, such as Low-power
mode (Energy Saver mode).
This printer automatically lowers its power consumption 60 minutes after the
last operation has been completed. To exit Low-power (Energy Saver) mode, press
any key on the operation panel. To change the setting of the Energy Saver mode,
see page 99.
Recycled paper
Please contact your sales or service representative for recommended recycled
paper types that may be used in this machine.
iii
Color Guide
Color Printing Basics
Additive (Emitted) and Subtractive (Reflected) Color Models
All light is a mixture of red, green, and blue, which is normally called the RGB
model. When red, green, and blue are of equal intensities, the RGB color model
produces white.
Note
❐ RGB is also called additive or emitted color. The colors on your computer
screen are produced by varying the intensities of RGB.
Printed color is a mixture of cyan, magenta, and yellow, which is normally called
the CMY color model. When mixed in equal proportions the CMY color model
produces black.
Note
❐ CMY is also called subtractive or reflective color. Your printer uses CMY toner
plus K (black) toner (CMYK color model) to provide full color printing.
iv
Color Guide
The colors of the RGB color model can be mixed to produce the cyan, magenta,
and yellow of the CMY color model and vice versa. Two colors of one model are
mixed to produce the color of the other model (mixing blue and green produces
cyan, for example). The remaining color is the compliment of the color produced
(red in this example). Complimentary colors are: red and cyan, green and magenta, blue and yellow.
v
Printed Color
Your printer produces full-color output using four toner colors: cyan, magenta,
yellow, and black. These four colors make up the CMYK color model.
Note
❐ Mixing CMY in equal proportions should hypothetically produce pure black,
but imperfections in the ink cause an equal measure of these colors to produce
a muddy or dark brown. Black toner is added to the color model in order to
make it possible to produce pure black.
If an image consisted of nothing by cyan, for example, cyan toner would be used
by itself and there would be no problem producing the desired color. Full-color
printing, on the other hand, required reproduction of tens of thousands of subtle
colors. These can be produced by controlling the relative proportions of the CMYK
toner particles printed within a unit area.
Relatively dense and light shades of the same color also can be reproduced by
controlling the volume of toner in a unit area.
vi
Color Guide
Example of Color Adjustments Using the Printer Driver
The following provides a number of examples to show you what happens when
you change the various color settings provided in the printer driver.
Quality Settings
Resolution
Resolution is the number of dots the printer can print within one inch. The
higher the resolution, the better the quality of the printed image. Resolution is
expressed in units of dpi, which stands for dots per inch.
Note
❐ Printing at a high resolution takes longer and requires more printer memory.
600dpi 300dpi
vii
Toner Saving
Turning on Toner Saving reduces the amount of toner used for printing. This
setting does not help to improve printout quality, but instead is used when
printing preliminary drafts of a document.
Limitation
• Turning on the Toner Saving can cause output to become blurred and result in very thin lines not printing at all. It can cause colors to be different
than expected when printing color.
Off On
Image Printing
This setting lets you select the resolution for printing of image data.
Standard Fast Fine
viii
Color Guide
Color Settings
The colors produced by the printer do not exactly match those you see on your
monitor. This is because the computer uses the reflected color model (RGB) while
the printer uses the emitted color model (CMYK). For details, see => P.iv “Color
Printing Basics”. The color settings provide you with a number of adjustments
that you can use to bring printed colors closer to what they look like on your
monitor. You can also use these settings to perform color correction, which changes
the clarity of the image.
You can change the color settings with the printer driver.
Color Correction
Use these settings to adjust the color correction pattern.
Off Photographic
This setting enhances midtone colors similar to those seen in photographs.
Vivid OHP Transparency
This setting enhances the basic colors for text and graphics. This setting is best for printing tables,
graphs, and presentation materials
that contain color.
This setting adjusts density to an
optimal level for printing OHP
transparencies.
ix
Brightness
This setting controls the overall brightness of the image. Moving the slider to
the plus (+) side increase brightness, while moving it to the minus (-) side
decreases brightness.
-30 0 +30
Contrast
This setting controls the range between the darkest and lightest shade of an
image. Moving the slider to the plus (+) side decreases the range and makes
contrast stronger, while moving it to the minus (-) side expands the range.
-30 0 +30
Saturation
x
This setting controls the purity of a color. Moving the slider to the plus (+)
side increases saturation and makes colors more vivid, while moving it to the
minus (-) side decreases saturation.
-30 0 +30
Color Guide
Color Balance
These settings let you control the relative intensity of the individual colors of
the additive color model (red, green, blue).
Note
❐ The position of the color bar also affects the complementary color relation-
ship. Red, for example, is printed using magenta and yellow toner, so increasing the level of red also decreases the level of cyan.
-30 0 +30
-30 0 +30
-30 0 +30
xi
Manuals for Your Printer
There are two manuals that describe the procedures separately for the installation of your printer and for the operation and maintenance of your printer and
its optional equipment.
To enhance safe and efficient operation of your printer, all users should read and
follow the instructions contained in the following manuals.
❖
Quick Installation Guide
Describes the procedures for installing your printer.
❖
Operating Instructions
Describes the procedures and necessary information on setting up and using
your printer and its optional equipment. (This Manual)
xii
How to Read this Manual
How to Read this Manual
Symbols
In this manual, the following symbols are used:
R
WARNING:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
CAUTION:
R
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, may result in minor or moderate injury or damage to property.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfed, originals might be
damaged, or data might be lost. Be sure to read this.
Preparation
This symbol indicates the prior knowledge or preparations required before
operating.
Note
This symbol indicates precautions for operation, or actions to take after missoperation.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
{ }
Keys built into the machine’s operation panel. Keys on the computer’s keyboard.
[]
Keys that appear on the machine’s panel display. Keys and buttons appear on
the computer’s display
xiii
Table of Contents
Safety Information....................................................................................... i
Color Guide................................................................................................ iv
Color Printing Basics .....................................................................................iv
Example of Color Adjustments Using the Printer Driver...............................vii
Manuals for Y our Printer ..........................................................................xii
How to Read this Manual........................................................................ xiii
Symbols.......................................................................................................xiii
1. Getting Acquainted
Features of Y our Printer............................................................................. 1
Office Color Printer........................................................................................ 1
Guide to the Printer.................................................................................... 2
Exterior - Front View ...................................................................................... 2
Exterior - Rear View....................................................................................... 3
Interior ........................................................................................................... 4
Operation Panel............................................................................................. 5
2. Installing Options
Available Options .......................................................................................8
Installing the Memory Unit ........................................................................ 9
Installing the RICOH-SCRIPT 2 Type204................................................ 11
Installing the Network Interface Board Type204 ................................... 13
Installing the IEEE 1284 Parallel Type204..............................................15
Installing the Paper Feed Unit Type204 .................................................17
Installing the Paper Cassette Type204...................................................21
3. Configuring the Printer for the Network with the Operation Panel
Configuring the Printer for the Network with the Operation Panel .....23
xiv
Table of Contents
4. Installing the IPDL-C Printer Driver
Before Installing the Printer Drivers....................................................... 29
Installing the Printer Drivers ........................................................................ 29
Windows 95/98 - Installing the IPDL-C Printer Driver ........................... 30
Installing the Printer Driver Using Plug and Play......................................... 31
Installing the Printer Driver Without Using Plug and Play............................ 34
Setting Up Options ...................................................................................... 36
Canceling a Print Job .................................................................................. 37
Windows 3.1x - Installing the IPDL-C Printer Driver ............................. 38
Installing the Printer Driver .......................................................................... 38
Setting Up Options ...................................................................................... 40
Canceling a Print Job .................................................................................. 41
Windows NT4.0 - Installing the IPDL-C Printer Driver ..........................42
Installing the Printer Driver .......................................................................... 42
Setting Up Options ...................................................................................... 44
Canceling a Print Job .................................................................................. 45
5. Paper and Other Media
Paper and Other Media Supported by this Printer................................47
Paper T ypes and Sizes ................................................................................ 47
Precautions for Paper .................................................................................. 48
Printable Area.............................................................................................. 50
Loading Paper .......................................................................................... 51
Loading Paper in the Paper Tray.................................................................. 51
Switching between Paper Trays...................................................................54
6. Tr oubleshooting
Error & Status Messages......................................................................... 55
Printed Error Message................................................................................. 55
Error & Status Messages on the Operation Panel....................................... 56
Getting Printer Information over the Network .............................................. 60
Printer Doesn’t Print ................................................................................65
Other Printing Problems.......................................................................... 67
Removing Misfed Paper........................................................................... 71
When the Message “Remove Misfeed From Tray” Appears........................ 72
When the Message “Open Rear Cover Remove Misfeed” Appears............ 73
When the Message “Remove Misfeed From Output Tray” Appears ............ 74
Cleaning and Adjusting the Printer ........................................................ 75
Cleaning the Charge Wire ........................................................................... 75
Adjusting the Image Density........................................................................ 77
Adjusting the Setting of “Registration” of the Optional Tray......................... 78
xv
Replacing Consumables ......................................................................... 80
Replacing the Toner Cartridges ................................................................... 80
Replacing the Photoconductor Unit ............................................................. 82
Replacing the Waste Toner Bottle................................................................ 86
Replacing the Fuser Oil Bottle and Ozone Filter ......................................... 87
Replacing the Fuser Cleaner....................................................................... 89
7. Making Printer Settings with the Operation Panel
Setting Menus........................................................................................... 92
Protecting the Menus............................................................................... 94
Protecting the Menus................................................................................... 94
Changing the Menu Settings without Removing Protect ............................. 95
Removing Protect ........................................................................................ 96
Menu Table................................................................................................ 97
Menu Settings........................................................................................... 98
IPDL-C Menu............................................................................................... 98
System Menu............................................................................................... 98
Printing the Configuration Page ........................................................... 101
Interpreting Configuration Page ........................................................... 102
Reference .................................................................................................. 102
Printer Information ..................................................................................... 102
Status List.................................................................................................. 103
Error Log.................................................................................................... 103
Printing the Color Sample ..................................................................... 104
Resetting Menus .................................................................................... 105
8. Appendix
Memory Capacity and Paper Size.........................................................107
Moving and Transporting the Printer ................................................... 109
Specifications......................................................................................... 110
Mainframe.................................................................................................. 110
Options ...................................................................................................... 112
Comsumbles........................................................................................... 114
Glossaries............................................................................................... 115
Index........................................................................................................ 117
xvi
1. Getting Acquainted
Features of Your Printer
Office Color Printer
You can enjoy the versatility of a full color printer and the performance of a
monochrome laser in a single compact unit. Text, spreadsheets, presentations,
design and other documents containing images can be beautifully printed in full
color. Windows applications using monochrome text or gray scale images are
rendered quickly in razor-sharp detail. Its compact design allows you to locate it
in a small convenient place. The efficient design of the internal mechanism make
it easy to access and replace consumables as paper and toner cartridge.
1
Getting Acquainted
8
Guide to the Printer
1
Exterior - Front View
1
2
3
4
5
1. Operation Panel
Contains keys for printer operation
and a display that shows the printer
status. =>P.5 “Operation panel”
2. Top Cover
Open this cover when accessing the
inside of the printer.
3. Front Cover
Open this cover when accessing the
inside of the printer.
4. Power Switch
Use this switch to turn printer
power on and off.
5. Paper Tray
Load up to 250 sheets of plain pa-
1
into this tray for printing. You
per*
can also load OHP transparencies
and custom paper sizes. => P.51
“Loading Paper in the Paper Tray”
*1:80 g/m
2
(metric version),
20 lb (inch version)
9
7
6
TPOH010E
6. Inset Grips
Hold the printer at the location indicated in the illustration when
transporting it. Note that there are
four grips, two on the left side and
two on the right side of the printer.
7. Front Cover Open Lever
Press this lever to open the front
cover.
8. Top Cover Open Lever
Press this lever to open the top
cover.
9. Output Tray
Printed pages are stacked here with
the print side down.
TPOH020E
2
Guide to the Printer
6
5
Exterior - Rear View
1
2
3
4
1. Ventilator
These holes help to keep components inside the printer from overheating. Also, this cover should be
removed to replace the ozone filter.
Note
❐ Do not leave the ventilator ob-
structed or blocked. Doing so
creates the danger of malfunction due to overheating.
2. Rear Cover
Open this cover to remove misfed
paper.
3. Power Connector
Connect the power cord to this connector.
4. Optional Paper Feed Unit Connec-
tor Cover
When installing the optional paper
feed unit, plug its cable into this
connector.
1
TPOH030E
5. Parallel Interface Connector
Plug the interface cable that connects the printer to your computer
into this connector.
6. Metal Plates
Remove to install certain options.
3
Getting Acquainted
1
Interior
3
4
5
1. Fuser Cleaner
This cleans unnecessary toner from
the fuser roller.
2. Fuser Oil Bottle
This bottle holds oil used for fusing toner on the paper.
3. Photoconductor Unit
This contains a photoconductor
unit belt that is used to compose the
image being printed.
Note
❐ The condition of the photo-
conductor unit belt directly affects output appearance and
quality. Always be careful to prevent the green film in this unit
from becoming dirty or damaged.
2
1
TPOH040E
4. Toner Cartridges
1 K: black toner
2 Y: yellow toner
3 M: magenta toner
4 C: cyan toner
5. Waste Toner Bottle
This bottle is a receptacle for waste
toner generated during the printing
process.
4
Guide to the Printer
0
2
Operation Panel
Important
❐ Never press any operation panel keys while the Data In indicator is flashing
on the operation panel.
1. Panel Display
The display shows the current status of the printer and error messages. => P.56 “Error & Status Mes-
sages on the Operation Panel”
2. On Line indicator
Tells you whether the printer is online or off-line.
Stays on while the printer is on-line
(a state in which the printer can receive data from the computer).
Stays off when the printer is off-line
(a state in which printer can not receive data).
3. Power indicator
Stays on while the printer power is
on. Stays off when the power is
turned off or while the printer is in
the Energy Saver mode.
On Line
4. {
} key
Press this key to switch the printer
between on-line and off-line conditions.
5. Error indicator
Lights up whenever any printer error occurs. A message describing
the cause of the error also appears
on the panel display.
Menu
6. {
} key
Press this key to make and check the
printer settings.
Media
7. {
Use this key to select a tray, change
} key
the paper size, and to make other
settings for printing.
1
8. {
2
3
4
5
6
7
Enter
} key
Power On Line Data In
Error
Media Enter
Reset
EscapeMenu
Press this key to execute menu
items selected on the panel display.
9. {U} {T} keys
Use these keys to increase and decrease values on the panel display,
and toggle menus when making
settings.
10.{Escape
} key
Press this key to return to the previous condition on the panel display.
11
. {
Reset
} key
Pressing this key when the printer
is off-line resets the printer to its
power on default settings.
Pressing this key during the on-line
condition cancels the ongoing print
job.
12
.Data In indicator
Blinks while the printer is receiving
data from the computer.
Stays on if there is data to be
printed.
1
11
1
9
8
TPOS010E
1
5
1
Getting Acquainted
6
2. Installing Options
R
CAUTION
• Make sure to turn off the printer and wait for about 30 minutes before installing options. Not waiting for the printer to cool down can result in a burn.
• It is recommended that at least two persons are used to lift the machine.
Otherwise, the machine might fall and cause a personal injury.
• When lifting the machine, use the inset grips on both sides of the machine.
Otherwise, the machine might fall and cause a personal injury.
R
CAUTION
• When you move the machine, unplug the power cord from the wall outlet to
avoid a fire or an electric shock.
7
2
Installing Options
Available Options
The following options can be installed to your printer.
TPOH350E
1. Memory Unit
You can install one of the following memory units.
• Memory Unit Type204 (16MB)
• Memory Unit Type204 (32MB)
2. RICOH-SCRIPT 2 Type204
3. Interface Board
You can install up to two interface boards. However, you cannot install two
boards of the same type at the same time. The following board are available.
• Network Interface Board Type204
• IEEE 1284 Parallel Type204
4. Paper Feed Unit Type204
5. Paper Cassette Type204
Note
❐ You cannot install more than one paper feed unit at a time.
❐ The standard tray or the tray of the optional paper feed unit can be replaced
with Paper Cassette Type204.
TPOH351E
8
Installing the Memory Unit
Installing the Memory Unit
Important
❐ The memory unit can be damaged
by small amounts of static electricity. Before touching it, touch something metal to remove static electricity from you.
A T urn off the printer’s power switch
and remove all cables and cords
from the printer.
B Remove both screws and remove
the printer board from the printer
as shown in the illustration.
TPOP130E
Note
❐ A coin can be used to remove the
screws.
C Align the memory unit as shown
in the illustration. Tilt it backwards so that it is 45 degrees from
perpendicular to the printer board
11
(
1), and slide it into the slot. Then
11
tilt it forwards so that it is perpendicular to the board (
make an audible click as it pops
into place.
Note
❐ When aligning the memory unit,
notice that the lower corner of
one side has a notch (a). This is
to prevent you from installing
the unit backwards.
22
2). It should
22
(a)
TPOP140E
2
9
Installing Options
2
D Insert the printer board into the
printer. Fasten both screws.
TPOP150E
Important
❐ Make sure that both screws are
used to secure the printer board.
Note
❐ A coin can be used to fasten the
screws.
E Plug the printer’s power cord back
into the printer and the wall outlet. Turn on the printer ’s power
switch.
F Print a configuration page to con-
firm that the memory unit is properly installed.
Reference
❐ =>P.101 “Printing the Configura-
tion Page”
Note
❐ You can check if the memory unit
is installed properly by checking
the “Total Installed RAM” item
of the “Reference” on the configuration page.
❐ If the memory unit is not prop-
erly installed, repeat steps A-F
again. If you fail again, contact
your sales or service representative.
Important
❐ To make the printer recognize
the installed option properly,
you must set up the option with
the printer driver. => P.36, 40, or
44 “Setting Up Options”
10
Installing the PostScript2 kit Type 204
Installing the RICOH-SCRIPT 2 Type204
Important
❐ The RICOH-SCRIPT 2 can be dam-
aged by small amounts of static
electricity. Before touching it, touch
something metal to remove static
electricity from you.
A Check the contents of the box for
the following items.
• DIMM (Dual Inline Memory
Module)
• Installation Guide
B T urn off the printer’s power switch
and remove all cables and cords
from the printer.
C Remove both screws and remove
the printer board from the printer
as shown in the illustration.
TPOP130E
Note
❐ A coin can be used to remove the
screws.
D Align the module as shown in the
illustration. Tilt it upwards so that
it is 45 degrees from parallel to the
printer board (
the slot. Then tilt it down so that
it is parallel to the board (
should make an audible click as it
pops into place.
Note
❐ If the optional interface board
has been installed to the printer
board, you should remove it
from the board before installing
the module. After installing the
module, reattach the interface
board to its original position.
❐ Be careful to notice that one side
has a notch (a). This is to prevent
you from installing the module
backwards.
11
1), and slide it into
11
22
2). It
22
(a)
TPOP160E
2
11
Loading...
