UNIX Supplement
if
c1-Network-300.t
Read this manual carefully before you use this product and keep it handy for future
reference.
For safety, please follow the instructions in this manual.
Introduction
To get maximum versatility from this machine all operators should carefully read and follow the instructions in this manual. Please keep this manual in a handy place near the machine.
Please read the Safety Information in the Copy Reference before using this machine. It contains important information related to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.
Important
Parts of this manual are subject to change without prior notice. In no event will the company be liable
for direct, indirect, special, incidental, or consequential damages as a result of handling or operating
the machine.
Further Information
Please consult your authorized reseller concerning additional UNIX support.
Trademarks
PostScript is a registered trademark of Adobe Systems, Incorporated.
Sun, SunOS and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the
United States and other countries.
HP-UX is a registered trademark of Hewlett-Packard Company.
LINUX is a trademark of Linus Torvalds.
RED HAT is a registered trademark of Red Hat, Inc.
Other product names used herein are for identification purposes only and might be trademarks of their
respective companies. We disclaim any and all rights in those marks.
Manuals for This Machine
The following manuals describe the operational procedures and maintenance of
this machine.
To enhance safe and efficient operation of this machine, all users should read
and follow the instructions carefully.
❖❖❖❖ Copy Reference
Describes the procedures and functions for using this machine as a copier.
❖❖❖❖ System Settings
Describes the system settings of this machine.
❖❖❖❖ Printer Unit Type 1045 Printer Reference 1
Describes the system settings, procedures and functions for using this machine as a printer.
❖❖❖❖ Printer Unit Type 1045 Printer Reference 2
Describes the procedures and provides necessary information about using
this machine as a printer. This manual is included as a PDF file on the CDROM labeled “Operating Instructions for Printer”.
❖❖❖❖ Network Printing Guide Operating Instructions
Describes the procedures and provides necessary information about setting
up and using the printer under the network environment. We recommend
this manual as your first choice to read, and it is included as a PDF file on the
CD-ROM labeled “Operating Instructions for Printer”.
❖❖❖❖ PostScript 3 Unit Type 1045 Operating Instructions Supplement
Describes the menus and features you can set using the PostScript 3 printer
driver. This manual is provided as a PDF file on the CD-ROM labeled “Operating Instructions for Printer”.
❖❖❖❖ UNIX Supplement
Provides information about setting up and using the printer in a UNIX environment. This manual is included as a PDF file on the CD-ROM labeled “Operating Instructions for Printer” (this manual).
i
How to Read This Manual
R
R
Symbols
In this manual, the following symbols are used:
WARNING:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, could result in death or serious injury.
CAUTION:
This symbol indicates a potentially hazardous situation which, if instructions
are not followed, may result in minor or moderate injury or damage to property.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfeed, originals might be
damaged, or data might be lost. Be sure to read this.
Preparation
This symbol indicates the prior knowledge or preparations required before operating.
Note
This symbol indicates precautions for operation, or actions to take after misoperation.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
[]
Keys that appear on the machine's panel display.
Keys and buttons that appear on the computer's display.
{}
Keys built into the machine's control panel.
Keys on the computer's keyboard.
ii
TABLE OF CONTENTS
1.UNIX Configuration
Before Setup ............................................................................................... 1
Using the lp/lpr commands............................................................................. 1
Using the rsh/rcp/ftp commands .................................................................... 1
Using the Installation Shell Script ............................................................ 2
Assigning the IP Address ............................................................................... 2
Executing the Installation Shell Script ............................................................ 3
After Executing Install Shell ........................................................................... 7
Printing Method ........................................................................................ 12
Printing with lpr, lp........................................................................................ 12
Printing with rsh, rcp, ftp .............................................................................. 12
Printer Status............................................................................................ 15
Viewing the Print Job Status with lpq and lpstat .......................................... 15
Viewing the Printer Status with rsh and ftp .................................................. 15
Copying Information to a File ....................................................................... 16
INDEX......................................................................................................... 17
iii
iv
1. UNIX Configuration
This section explains how to set up a network printer and check the print status
using UNIX.
Limitation
❒ To print from a UNIX workstation, use the file that the printer supports.
Before Setup
Setting up can vary depending on the printing commands. Please make sure to
make the settings accordingly.
Using the lp/lpr commands
Use the Installation Shell Script to register the printer host name and the IP
A
address.
Start printing.
B
⇒ P.12 “Printing Method”
Using the rsh/rcp/ftp commands
Edit the host file to register the Printer host name and the IP address.
A
Start printing.
B
⇒ P.12 “Printing Method”
Reference
See P.7 “After Executing Install Shell” for host file editing.
Note
❒ If you cannot edit the host file, use the Install Shell Script to register the
host name.
1
1
UNIX Configuration
Using the Installation Shell Script
The installation shell script helps with the setup process. The installation shell
script automates some of the tasks in configuring /etc/hosts, /etc/printcap, and
in creating the spool directory for BSD UNIX, and in running lpadmin command
for System V UNIX.
Preparation
The installation shell script can be used on the following three kinds of workstations. This installation shell script cannot be used with other types of workstations.
• Solaris 2.5.1, 2.6, 7, 8
• HP-UX 8.x, 9.x, 10.x, 11.0
• Red Hat Linux 6.x, 7
When you use NIS (Network Information Service) or DNS, you should configure the server before running this installation shell script.
For more information about the configuration utility of your OS, see the manual that came with the utility.
Assigning the IP Address
Preparation
Configure the machine to use the TCP/IP protocol.
• Make sure that the TCP/IP protocol on the machine is set to active. (The
default is active.)
• Assign an IP address to the machine and configure the other settings required for using the TCP/IP protocol.
Reference
For more information about how to make the above settings, see the System
Settings that came with the printer option or printer/scanner option of this
machine.
2
Using the Installation Shell Script
Checking the IP address configuration
Follow the procedure below to make sure that the IP address has been configured correctly.
• The following procedure uses the sample IP address: 192.168.15.16.
Enter the following:
A
# ping 192.168.15.16
If the address has been configured correctly, the following message appears.
192.168.15.16 is alive
If the address has been configured incorrectly, the following message appears.
no answer from 192.168.15.16
Note
❒ When you use NIS, the IP address and host name are written to /etc/hosts
on the master server. When you use DNS, the information is written to a
data file on the name server. After writing the host name and IP address to
the file, make sure that the configuration is correct by pinging the host
name.
# ping host_name
1
❒ If the host name is registered with an IP address, the server can access the
printer using its host name instead of its IP address.
Executing the Installation Shell Script
After having configured the printer IP address, follow the procedure below to
execute the installation shell script and set up the workstation printing environment.
Preparation
Before executing the installation shell script, the IP address, the host name
and the printer name are required.
Following procedures use sample IP address: 192.168.15.16, sample host
name: nphost and sample printer name: np.
Note
❒ Use ftp to get the installation shell script from the printer.
Log on to the workstation as root account.
A
Note
❒ If you do not log on as root, the installation shell script will not run.
3
1
UNIX Configuration
Get the installation shell script from the printer.
B
A Move to the directory you want to copy the installation shell script to.
B Use ftp to connect to the printer with the IP address that you just config-
ured.
# ftp 192.168.15.16
Connected to 192.168.15.16
220 printer FTP server ready.
name (192.168.15.16:root:)
C When a user name is requested, leave blank and press the {{{{RETURN}}}} key.
331 Password required for root.
Password:
D When a password is requested, leave blank and press the {{{{RETURN}}}} key.
230 User root logged in.
ftp>
E Type the following to get the installation shell script.
ftp> get install
F Close the ftp session.
ftp> bye
221 Goodbye.
#
Run the installation shell script.
C
# sh ./install
Note
❒ Insert a period and slash before the current directory.
Enter a number to select the workstation OS that you are using.
D
Network printer install shell
Copyright RICOH CO.,LTD. 1994-2000
Select your workstation OS type.
1. SunOS 4.x.x
2. Solaris 2.x, Solaris 7-8 (SunOS5.x)
3. HP-UX 8.x,9.x,10.x,11.x
4. UnixWare
5. Linux
6. other
Enter <1-6>:
2
Note
❒ SunOS and UnixWare appear on the screen, but they are not supported.
Use Solaris, HP-UX or Linux.
❒ If you select “6”, the installation shell script exits.
4
Using the Installation Shell Script
Enter the IP address of the printer.
E
Enter Printer host IP address <xxx.xxx.xxx.xxx> [return=skip]:
192.168.15.16
Note
❒ The IP address will be added to the /etc/hosts file.
❒ If the host name of the printer has already been configured, press the {RE-
TURN} key. Nothing will be added to the /etc/hosts file.
Enter the host name of the printer.
F
Enter Printer host name : nphost
Note
❒ The host name will be added to the /etc/hosts file.
❒ If no IP address was entered in step
file.
Configure the printer name.
G
, nothing is added to the /etc/hosts
E
1
Enter logical printer name [default nphost_prn]
If you want to use the default name, press the {RETURN} key. Enter a new
name, if you want to use a different one.
Note
❒ The host name entered in step
Set the print option.
H
Enter remote printer name [default lp]:
• Press the {RETURN} key, print with PCL or PostScript is enabled.
• If you enter “text”, text printing is enabled.
If you enter “text”, printing with PCL and PostScript is unavailable.
Enter remote printer name [default lp]:text
Limitation
❒ You can enter up to 14 characters for HP-UX 11.0, 256 for Solaris 8, and 51
for Red Hat Linux 6.2.
❒ When printing with the lp command, use ( _ ) instead of ( = ) and ( ; ) in-
stead of ( , ) for operating systems that cannot use ( = ) and ( , ) such as Solaris 2.5 or later.
After the setup with the installation shell script is complete, and if you enter
the IP address in step
hosts file is modified
, the following message appears.
E
followed by “_prn” appears in “default”.
F
5
UNIX Configuration
Perform a test print to make sure that the settings are correct.
I
# lpr -Pnp file_name
# lp -d np file_name
1
For more information about lpr and lp, see P.12 “Printing Method”.
Deleting the printer
To print using the lp or lpr command, the option specified when the installation
shell script is executed is used. Change the option in accordance with the workstation you are using.
❖❖❖❖ BSD UNIX workstation, Linux
Delete the printer entry from /etc/printcap, then execute the installation
shell script again. Select options during the setup process.
Or, search the printer entry from /etc/printcap, and change its rp capability
to option setting.
❖❖❖❖ Solaris, HP-UX
Delete the printer entry, and then execute the installation shell script again.
Select options during the setup process. To delete the printer entry, follow the
procedure below.
Stop the scheduler.
A
# /usr/sbin/lpshut
Delete the printer.
B
# /usr/sbin/lpadmin -x printer_name
Restart the scheduler.
C
# /usr/lib/lpsched
6
Using the Installation Shell Script
After Executing Install Shell
The printing environment is set up automatically when the installation shell
script is executed.
This section describes the set up contents when the installation shell script is executed under Red Hat Linux, Solaris and HP-UX.
Linux
❖❖❖❖ Adding the IP address and host name to the /etc/hosts file
The following line is added to the /etc/hosts file. The IP address and printer
host name which you previously entered in the installation script will be
used.
192.168.15.16 nphost # Network Printer
• 192.168.15.16 is the IP address, nphost is the host name, from # to the end
of the line is a comment.
Note
❒ The /etc/hosts file contains a list of the IP addresses and host names of all
of the hosts communicating on the network. Each entry is delimited with
a space or a tab, and each line is separated with a return.
1
❒ If you do not use NIS or DNS, you must manually enter the IP address and
host name of each workstation using the network printer in the /etc/hosts
file.
❖❖❖❖ Adding an entry to the /etc/printcap file
The following entry is added to the /etc/printcap file, which is the configuration for printing with the lpr command. In order to use the lpr command to
print, you need to edit the /etc/hosts file, add an entry for the network printer to the /etc/printcap file and create a spool directory.
##PRINTTOOL3## REMOTE
np|Network Printer:\
:rm=nphost:\
:rp=option:\
:sd=/var/spool/lpd/npd:\
:lf=/var/log/npd-errs:\
:sh:\
:mx#0:
Note
❒ The /etc/printcap file is used to register the name and attributes of a print-
er. You must make an entry for the network printer in the /etc/printcap
file of all workstations using the network printer.
❒ Each entry is separated with colons into several fields. The syntax is to be-
gin each entry with a colon, followed by the entry, and then end with a colon, a back slash, and then a return.
7
1
UNIX Configuration
❒ The first line of the field is the name of the printer. You use this name when
logging on to a network printer from a workstation. You can define several
different names by separating each name with the “|” character.
❒ The second and following lines contain the printer's attributes. Attributes
of the printer are represented by two character names referred to as capabilities. For more information about capabilities, see the following table.
Capability Explanation Value Required for the Network
Printer.
rm Host name of the printer The host name that was registered
with the /etc/hosts file.
sd Path name of the spool directory. Path name of the spool directory
that is to be created.
lf Path name of the log file. Path name of the log file.
For example /var/log/lpd-errs.
mx Maximum file size which the di-
rectory can copy. When set to 0, the
size is unlimited. If nothing is entered, the size is set to 1024 k.
None or something suitable.
❖❖❖❖ Making the spool directory
Create a spool directory under /var/spool/lpd. The name of the spool directory should be the name of the printer followed by a “d”.
Note
❒ The spool directory is used to control the data used for a print job. For ex-
ample, when a print job is created, a temporary copy of the file data used
for printing is created in the spool directory. All workstations accessing the
network printer need to have a spool directory for the network printer.
❒ A spool directory should be made for every network printer entry listed in
the /etc/printcap file.
❒ The spool directory should normally be made under /var/spool/lpd and
the name should match that listed under the sd capability in /etc/printcap. Change the owner and group of the directory to root and lp. The following examples show how to make a /var/spool/lpd/npd spool
directory.
# cd /var/spool/lpd
# mkdir npd
# chown root npd
# chgrp lp npd
8
Using the Installation Shell Script
❖❖❖❖ Making the log file
Error messages are logged to a file created in the /var/log directory. The log
file name is the printer name followed by “d-errs”.
Note
❒ The log file is used for logging some errors or warning messages by the
UNIX workstation.
❒ The log file should be made for every network printer entry listed in the /
etc/printcap file.
❒ The log file should normally be made under /var/log directory and the
name should match that listed under the lf capability in /etc/printcap.
Change the owner and group of the log file to root and lp.The following
examples show how to make a /var/log/npd-errs file.
# cd /var/log
# touch npd-errs
# chown root npd-errs
# chgrp lp npd-errs
Solaris
1
❖❖❖❖ Adding the IP address and host name to the /etc/hosts file
The following line is added to the /etc/hosts file.The IP address and printer
host name which you previously entered in the installation script will be
used.
192.168.15.16 nphost # Network Printer
• 192.168.15.16 is the IP address, nphost is the host name, from # to the end
of the line is a comment.
Note
❒ The /etc/hosts file contains a list of the IP addresses and their host names
of all of the hosts communicating on the network. Each entry is delimited
with a space or a tab, and each line is separated with a return.
❒ If you do not use NIS or DNS, you must manually enter the IP address and
host name of each workstation using the network printer in the /etc/hosts
file.
9
1
UNIX Configuration
❖❖❖❖ Registering the printer
The installation shell script registers the printer as a remote printer.
If your workstation is Solaris 2.5.1, register the print server and print client
A
to the print service.
# lpsystem -t bsd -R 0 -y ″″″″Network Printer″″″″ nphost
Register the printer as a remote printer.
B
# lpadmin -p np -s nphost!"option" -T dump -I any
• np is the printer name, nphost is the host name.
“lp” will be assigned, if the device option is not used.
When printing with the lp command, use ( _ ) instead of ( = ) and ( ; )
instead of ( , ) for operating systems that cannot use ( = ) and ( , ) such as
Solaris 2.5 or later.
If your workstation is Solaris 2.5.1, set the print job to active so that it can
C
be accepted by the print queue.
/usr/lib/accept np
If your workstation is Solaris 2.5.1, set the print job to active to print.
D
/usr/lib/enable np
HP-UX
❖❖❖❖ Adding the IP address and host name to the /etc/hosts file
The following line is added to the /etc/hosts file. The IP address and printer
host name which you previously entered in the installation script will be
used.
192.168.15.16 np # Network Printer
• 192.168.15.16 is the IP address, np is the host name, from # to the end of
the line is a comment.
Note
❒ The /etc/hosts file contains a list of the IP addresses and their host names
of all of the hosts communicating on the network. Each entry is delimited
with a space or a tab, and each line is separated with a return.
❒ If you do not use NIS or DNS, you must manually enter the IP address and
host name of each workstation using the network printer in the /etc/hosts
file.
10
Using the Installation Shell Script
❖❖❖❖ Registering the printer
The installation shell script registers the printer as a remote printer following
the procedure below.
Stop the scheduler.
A
/usr/lib/lpshut
Register the printer.
B
/usr/lib/lpadmin -Pnp -v/dev/null -mrmodel
-ormnphost -orp"option" -ob3
• np is the printer name, nphost is the host name.
“lp” will be assigned, if the Device option is not used.
Set the printer so that the print job is listed in the print queue.
C
/usr/lib/accept np
Set the printer to perform the print job.
D
/usr/lib/enable np
Restart the scheduler.
E
/usr/lib/lpsched
1
11
UNIX Configuration
Printing Method
1
Printing with lpr, lp
Execute one of the following commands according to the type of workstation being used:
❖❖❖❖ BSD UNIX workstation, Linux
% lpr -Pprinter_name file_name [file_name...]
For example:
printer name is np, file names are file1 and file2
% lpr -Pnp file1 file2
❖❖❖❖ Solaris, HP-UX
% lp -d printer_name file_name [file_name...]
For example:
printer name is np, file names are file1 and file2
% lp -d np file1 file2
Note
❒ “printer_name” is the name that was entered when executing the installation
shell script.
❒ You can use wild cards ( * or ? ) for the file name.
Printing with rsh, rcp, ftp
You can also print using the rsh, rcp and ftp commands.
Note
❒ Print using the format that the printer can support.
❒ The message “print session full” appears when the maximum number of
print requests has been reached (max. 5 session) . You should try to print
again when the number of requests is less than five. You can check the number of print requests using telnet. For more information about using telnet,
see the Network Printing Guide Operating Instructions provided as a PDF
file on the CD-ROM labeled “Operating Instructions for Printer”.
12
Printing Method
rsh
% rsh host_name print < file_name
For example:
host name is nphost, file name is file1
% rsh nphost print < file1
Note
❒ “host_name” is the name entered when executing the installation shell script.
❒ If you use a HP-UX, use the remsh command instead of rsh.
rcp
❖❖❖❖ To specify and print the file
% rcp file_name [file_name...] host_name:
For example:
host name is nphost, file names are file1 and file2
% rcp file1 file2 nphost:
1
❖❖❖❖ To print all of the files in a directory
% rcp -r directory_name host_name:
For example:
host name is nphost, directory name is directory1
% rcp -r directory1 nphost:
Note
❒ “host_name” is the name entered when executing the installation shell script.
❒ You can use wild cards ( * or ? ) for the file name.
ftp
Depending on the number of files to be printed, use the put or mput commands.
Limitation
❒ File names cannot contain “=” or “,”.
❖❖❖❖ To print one file
ftp> put file_name
❖❖❖❖ To print several files
ftp> mput file_name [file_name...]
Note
❒ You can use wild cards ( * or ? ) for the file name with the mput command.
13
UNIX Configuration
The following procedure shows an example of how to print a file using ftp.
Start ftp using the IP address or host name of the printer.
A
% ftp IP_address
1
Note
❒ “host_name” is the name entered when executing the installation shell
script.
Enter the user name. Skip the password, and then press the {{{{RETURN}}}} key.
B
Name:
Password:
Set the file transfer mode to binary.
C
ftp> bin
Note
❒ If the file transfer mode is not set to binary, the image might not be printed
correctly.
Print the file.
D
Note
❒ For example, to print one file named file1:
ftp> put file1
❒ For example, to print two files named file1 and file2:
ftp> mput file1 file2
14
Exit ftp.
E
ftp> bye
Printer Status
Printer Status
You can use the following commands to have information and the printer status
displayed or copied to a file.
Use the lpq or lpstat command to display the status of the printer or information
about print jobs.
Use the rsh, rcp or ftp commands to get more detailed information from the
printer.
Viewing the Print Job Status with lpq and lpstat
❖❖❖❖ BSD UNIX workstation, Linux
% lpq -Pprinter_name
For example: Printer name is np
% lpq -Pnp
❖❖❖❖ System V UNIX, Solaris, HP-UX
1
% lpstat -o printer_name
For example: Printer name is np
% lpstat -o np
Note
❒ In case of HP-UX, do not put a space between “-o” and “printer name”.
Viewing the Printer Status with rsh and ftp
Use the rsh or ftp command to display the status of the printer or information
about print jobs using specified parameters.
You can use these commands for BSD and System V UNIX.
Note
❒ If your workstation is HP-UX, use the remsh command instead of the rsh.
% rsh host_name parameter
% ftp host_name
User user_name
password:
ftp> get parameter -
Note
❒ Leave the user name and password blank, and then press the {RETURN} key.
❒ " - " indicates the standard output. It will be displayed on screen if the stan-
dard output has not been specified.
15
1
UNIX Configuration
Parameters that can be used with rsh, rcp and ftp:
Parameter Information returned Reference
Network Printing Guide
stat
info
prnlog Record of the last 16 jobs printed. Network Printing Guide
syslog
Status of the printer.
Information about print jobs.
Information about the paper tray, output tray
and printer language.
Record of messages about the Network Interface
Board.
Operating Instructions
provided as a PDF file on
the CD-ROM labeled “Op-
erating Instructions for
Printer”.
System Settings provided
as a PDF file on the CDROM labeled “Operating
Instructions for Printer”.
Operating Instructions
provided as a PDF file on
the CD-ROM labeled “Op-
erating Instructions for
Printer”.
Copying Information to a File
Use the rcp or ftp command to copy information about the specified parameters
to a file.
You can use these commands for BSD and System V UNIX.
Note
❒ The same parameters are used as those above.
% rcp host_name:parameter file_name
% ftp host_name
User: user_name
password:
ftp> get parameter file_name
Note
❒ Leave the user name and password blank, and then press the {RETURN} key.
16
INDEX
B
BSD UNIX workstation, Linux
,
15
,
6
12
Deleting the printer
Printer Status
Printing Method
,
C
configuration
,
UNIX
1
D
Deleting the printer
,
6
F
ftp
,
Printing
13
I
installation shell script
,
2
P
Printer Status
Printing Method
Printing with lpr, lp
Printing with rsh, rcp, ftp
,
15
,
12
,
12
,
12
R
rcp
,
,
13
13
Printing
rsh
Printing
S
Solaris, HP-UX
,
,
15
6
12
Deleting the printer
Printing Method
System V UNIX, Solaris, HP-UX
Printer Status
,
U
,
UNIX
1
17
18
UE USA B362
Copyright © 2001
UNIX Supplement
UE USA B362-8667
Loading...
